Clarity

®

Advanced solutions for 10 Gig,

Category 6 and 5e copper connectivity

P R O D U C T S O L U T I O N G U I D E

E X P E R T I S E . T E C H N O L O G Y . S O L U T I O N S .

Center Tuned

Components

Higher Signal-to-

Noise Ratio

Optimal Mated

Connector Balance

Clarity

®

components provide an optimized medium for the high speed applications required in today's business environment.

Clarity

10G

, Clarity

6

and Clarity

5E

components are engineered to meet and surpass the most stringent industry requirements including TIA and IEEE. Clarity connectivity utilizes patented and patent pending designs that include Ortronics technologies such as center tuning and dual and synchronized reactance to achieve more transparent mated unions and higher signal-to-noise ratio for field-measurable performance beyond the standards. This core technology makes Clarity the industry benchmark for elevated copper solutions.

Clarity

10G

Clarity

6

Clarity

5E

New Products

Clarity

10G

02

Clarity

10G connectivity represents another major technology advancement from Ortronics/Legrand by fully supporting the internal and alien performance requirements of 10

Gigabit Ethernet.

Clarity 10G components utilize

Ortronics’ innovative technique of synchronized reactance to minimize internal crosstalk while reducing the injection of common mode noise – also a significant source of alien crosstalk. Jack ports implement Tactical Isolation Zones, to provide additional barriers against noise radiating from the connector as well as defending against the influence of alien noise sources on the connector.

When these technologies are combined with Ortronics previously developed advancements of dual reactance and center tuning, the result is superior 10G performance.

A nearly transparent, high speed signal path between the Clarity 10G jacks or patch panels and patch cords ensures enhanced signal-to-noise

(internal and alien) performance.

FEATURES

I

ETL tested to TIA T568B.2-10 Category 6A and characterized out to 500 MHz

I

Meets TIA T568B.2-10 Category 6A component specifications

I

Backwards compatible to TIA Category 6 and 5e

I Synchronized reactance minimizes internal and alien crosstalk

I

Tactical Isolation Zones minimize effect of alien noise

Fully compliant with RoHS standards

Clarity

10G

Patch

Panels

JACKS PANELS CORDS

ANGLED MULTI

-

PORT PATCH PANEL TRADITIONAL MULTI

-

PORT PATCH PANEL

ANGLED

,

FLAT AND

TRACJACK PATCH PANELS

Clarity 10G patch panels are available in the traditional panel format with multi-port modules, with the added flexibility of flat or angled versions.

Utilizing innovative methods for circuit isolation, the Clarity

10G multi-port patch panels support the alien crosstalk requirements of IEEE 10G and TIA Category 6A cabling specifications without requiring the use of individual jacks for your panel termination.

Clarity 10G multi-port panels support traditional termination practices with mechanical accommodations for easy termination of the larger conductors of 10 Gig cables, providing a labor-saving alternative to the individual jack panel.

We also offer a Clarity

10G individual jack panel, which holds 24 Clarity 10G

TracJacks to provide an alternative horizontal cross connect solution for

10 Gigabit Ethernet networks.

I

INDIVIDUAL TRACJACK PATCH PANEL

FEATURES

I More transparent signal path with Clarity 10G cords

I Standard termination practice—110 tool

I IDC towers designed to accept larger 10 Gig cable conductors

I Easy-to-follow universal wiring label is quick and user-friendly to eliminate confusion

I High density panels include label fields and rear cable management

I Meets TIA T568B.2-10 Category 6A component specifications

I Backwards compatible to Category 6 and Category 5e

ORDERING INFORMATION

03

24-port Angled Clarity 10G patch panel, T568A/B, 1.75”x 19” (1RU)

48-port Angled Clarity 10G patch panel, T568A/B, 3.5”x 19” (2RU)

24-port Flat Clarity

10G patch panel, T568A/B, 1.75”x 19” (1RU)

OR-PHA610U24

OR-PHA610U48

OR-PHD610U24

48-port Flat Clarity 10G patch panel, T568A/B, 3.5”x 19” (2RU) OR-PHD610U48

24-port TracJack ® panel with tactical isolation for 10G, 1.75" x 19" (1RU) OR-PHDTJA24

NOTE: 10G TracJacks sold separately.

Clarity

10G

TracJacks

®

and

Patch Cords

JACKS PANELS CORDS

OR-MC61005-09

TRACJACKS

Clarity 10G TracJacks exceed all

TIA Category 6A component requirements in addition to being characterized out to 500 MHz, addressing all IEEE 802.3 target frequencies. They support standard

110 termination practices with mechanical accommodations for easy termination of the larger conductors of 10 Gig cables.

These front-loading jacks can be used in any TracJack ® workstation outlet or in the Clarity 10G individual jack panel.

I

04

FEATURES

I More transparent signal path with Clarity 10G cords

I Standard termination practice—110 tool

I New low emission IDC contacts

I TracJack IDC towers designed to accept larger

10 Gig cable conductors

I TracJacks feature an easy-to-follow universal wiring label that is quick and user-friendly

I Jacks fit in all TracJack plates and housings

I Icon compatible, “10” marking on jack face

I Jacks available in ten colors

I Clarity 10G TracJacks can be installed in the

OR-PHDTJA24 patch panel

PATCH CORDS

Clarity

10G patch cords combine 10 Gig performance with the flexibility of stranded conductor cordage for increased flexibility and ease of cable management. MC610 (10 Gig) patch cord assemblies combine with TJ610 jacks and panels to deliver reliable 10 Gig channel performance. I

FEATURES

I

Stranded conductor 10 Gig patch cords for greater flexibility

I

More transparent signal path with Clarity10G jacks and patch panels

I

100% factory tested for performance, reliability and long life

ORDERING INFORMATION

DESCRIPTION

TracJack Clarity

10G

EXIT

180º

PART NO.

OR-TJ610

NOTE: Standard color is fog white. To order other standard colors add suffix on TracJacks: -00=black, -36=blue,

-42=red, -43=orange, -44=yellow, -45=green, -68=Wiremold ® gray, -88=cloud white, -99=Wiremold ® ivory.

ORDERING INFORMATION

DESCRIPTION

Modular Cord, white, Clarity 10G

LENGTH

3 ft.

5 ft.

7 ft.

9 ft.

15 ft.

25 ft.

PART NO.

OR-MC61003-09

OR-MC61005-09

OR-MC61007-09

OR-MC61009-09

OR-MC61015-09

OR-MC61025-09

Note: To order other standard colors change suffix on MC cords: -02=red, -04=yellow, -05=green, -06=blue,

-08=gray, -09=white, -00=black.

Clarity

6

and

Clarity

5E

Clarity ® elevated copper solutions marked an evolutionary advancement in UTP and FTP

Category 6 and Category 5e connectivity. ETL verified to

Category 6 and 5e component standards, Clarity components utilize center tuned connector technology to provide significant elevation of channel performance that is field-measurable. Clarity solutions include patch panels, patch cords, TracJack ® and Series

II ® workstation modules, and 110 cross-connect systems.

FEATURES

I Clarity

6 connectivity meets TIA/EIA 568B.2-1 Category 6 component requirements

I

Clarity 5E connectivity meets TIA/EIA 568B.2 Category 5e requirements

I

Center tuned connectivity for improved channel performance

05

Clarity

6

Patch

Panels

JACKS PANELS CORDS

FLAT

ANGLED

06

CLARITY

6

PATCH PANELS

Ortronics Clarity 6 standard and high density patch panels utilize center tuned technology to exceed

TIA Category 6 component compliance requirements and are precision tuned to the same optimized value as Clarity 6 patch cords. This maximizes each mated union for significantly improved cross talk and return loss performance that is field measurable in the link or channel. Clarity 6 patch panels are available in flat, angled or curved versions. I

ANGLED PATCH PANELS

Ortronics angled Clarity ® patch panels offer a new slant to patch cord management. Built around

CURVED

the elevated performance of

Clarity 6 , these high density patch panels utilize a unique, patented, recessed angle design to help direct cords more easily to vertical rack or cabinet management within a lower profile. This design provides a better alternative for installations which have limited rack space for horizontal management.

I

CURVED PATCH PANELS

Ortronics curved Clarity ® patch panels offer yet another alternative for patch cord management. Built around the elevated performance of

Clarity 6 , these high density patch panels feature a new look, utilizing a patent pending, recessed curved design. This design helps direct cords to vertical rack or cabinet management within a lower profile and provides another alternative for installations which have limited rack space for horizontal management.

I

FEATURES

I

Meets Category 6 component specifications

I

TIA/EIA-568-B.2

ETL 3rd party component tested and verified

I

Mated union with Clarity 6 cords is more

I transparent to signal

New low emission IDC contacts for better noise protection and improved return loss

I

Supports standard termination practice—110 impact tool

I

Universal T568B and T568A wiring

I

Available in 6 or 8 port groupings

I

Easy lace IDCs and easy to follow wiring labels

I

Supplied label fields

I

Icon compatible

I

Includes rear cable management

I

Available in high and standard density

Clarity

6

Patch Panels and

Patch Cords

JACKS PANELS CORDS

PATCH CORDS

Clarity

6 patch cords utilize center tuned technology and Ortronics’ patented

Paralign 2 termination technique to achieve elevated channel performance that can be field measured. Clarity

6 cords are ETL verified to Category 6 component standards.

I

FEATURES

I Transparent to signal with Clarity 6 jacks and panels

I Plug targets TIA center values, paired bi-level contact array

I Snagless plug design provides bend radius support

I Precision performance stranded conductor cordage

I Available in 7 standard colors

ORDERING INFORMATION

DESCRIPTION

ANGLED, HIGH DENSITY 6 PORT PATCH PANELS

24-port, Category 6, T568A/B, 1.75" x 19" (1RU)

48-port, Category 6, T568A/B, 3.5" x 19" (2RU)

CURVED, HIGH DENSITY 6 PORT PATCH PANELS

24-port, Category 6, T568A/B, 1.75” x 19” (1RU)

48-port, Category 6, T568A/B, 3.5” x 19” (2RU)

FLAT, HIGH DENSITY 6 PORT PATCH PANELS

24-port, Category 6, Universal A/B, 1.75" x 19" (1RU)

48-port, Category 6, Universal A/B, 3.5" x 19" (2RU)

96-port, Category 6, Universal A/B, 7" x 19" (4RU)

FLAT, STANDARD DENSITY 6 PORT PATCH PANELS

12-port, Category 6, Universal A/B, 1.75" x 19" (1RU)

24-port, Category 6, Universal A/B, 3.5" x 19" (2RU)

48-port, Category 6, Universal A/B, 5.25" x 19" (3RU)

96-port, Category 6, Universal A/B, 10.5" x 19" (6RU)

FLAT, HIGH DENSITY 8 PORT PATCH PANELS

24-port, Category 6, Universal A/B, 1.75" x 19" (1RU)

48-port, Category 6, Universal A/B, 3.5" x 19" (2RU)

96-port, Category 6, Universal A/B, 7" x 19" (4RU)

NOTE: See pg. 12 for new Clarity individual jack panels and 48 port 1RU panels.

PART NO.

OR-PHA66U24

OR-PHA66U48

OR-PHC66U24

OR-PHC66U48

OR-PHD66U24

OR-PHD66U48

OR-PHD66U96

OR-PSD66U12

OR-PSD66U24

OR-PSD66U48

OR-PSD66U96

OR-PHD68U24

OR-PHD68U48

OR-PHD68U96

TECHNOLOGICAL ADVANCEMENTS

Paralign 2 boot accepts identification icons

Plug contact array targets center of TIA C6 plug performance values

Pair alignment sled controls positioning of conductors under contacts

Cordage with superior NEXT values

Paralign 2 separates pairs and protects pair twist far into the plug providing low NEXT variation

ORDERING INFORMATION

DESCRIPTION LENGTH PART NO.

Modular cord blue, Clarity

6

3 ft

5 ft

7 ft

OR-MC603-06

OR-MC605-06

OR-MC607-06

9 ft

15 ft

OR-MC609-06

OR-MC615-06

25 ft OR-MC625-06

Note: To order other standard colors change suffix on MC cords: -02=red, -04=yellow, -05=green, -06=blue,

-08=gray, -09=white, -00=black.

07

Clarity

6

TracJacks and

Series II Modules

JACKS PANELS CORDS

08

TRACJACKS

Clarity ® TracJacks feature the improved performance of center tuned Category 6 connector technology, combined with the ease and reliability of a front-loading individual jack with 110 termination. Clarity TracJacks utilize enhanced IDC designs that make it easier to terminate while reducing the size of the jack.

Universal wiring makes these jacks compatible with T568A/B.

I

SERIES II MODULES

Clarity Series II modules provide the ease and reliability of the rugged, front-loading Series II footprint with linear 110 termination. These modules are precision targeted to

Clarity 6 patch cords for optimum performance that is field measurable in the link or channel.

The Series II modules include mechanical improvements that make it easier to terminate, protecting the printed circuit board and reducing the depth of the module. Series II is a front removable, snap-in module footprint that makes moves, adds, and changes easy with a wide variety of interfaces, surface boxes or faceplates. I

FEATURES

I

Icon compatible, C6 marking on face of module

I

Easy to follow T568A and T568B wiring label, quick and user-friendly

I

Fits in all Series II plates and housings

FEATURES

I

Low emission IDC contacts

I

Supports standard termination practice—110 impact tool

I

Retention enhanced IDC contacts hold laced conductors in position until punch down

I

Easy to follow universal wiring label

I

Flush TracJack available in 18 colors. Angled

TracJack available in 13 colors

ORDERING INFORMATION

DESCRIPTION

TracJack, Category 6, 8-position, T568A/B wiring, fog white

NOTE: Series II modules are also available in -99=Wiremold ® ivory, -88=cloud white and -00=black.

180º

45º

ORDERING INFORMATION

DESCRIPTION

Series II, Category 6, 8-position, T568A/B wiring, fog white

OR-TJ600

OR-TJ645 single 180º OR-S21600 dual 180º OR-S22600

NOTE: Standard color is fog white. TracJacks are also available in: -13=electrical ivory, -36=blue, -42=red, -43=dark orange,

-44=dark yellow, -45=dark green, -68=Wiremold ® light gray, -78=Wiremold ® and -00=black. To order other colors, add suffix to part number. gray, -88=cloud white, -99=Wiremold ® ivory,

CLARITY

6

TECHNOLOGICAL ADVANCEMENTS

Tapered towers assist spreading pairs

Low EMI IDC limits the noise contribution of connection and improves impedance matching

Dual reactance modular insert is key to extended useable bandwidth

Expanded wire slots accept larger

Category 6 conductors

Clarity

5E

TrackJacks and

Series II Modules

JACKS PANELS CORDS

TRACJACKS

Ortronics Clarity 5E flush and angled

TracJacks exceed TIA Category 5e component compliance and are center tuned to Clarity

5E patch cords.

TracJacks offer the ease and flexibility of a front-loading jack with 110 termination.

I

FEATURES

I Meets Category 5e component specifications

I

TIA/EIA-568-B.2

ETL 3rd party component tested and verified

I Mated union with Clarity 5E cords is more

I transparent to signal

Low emission IDC contacts for better noise

I protection and improved return loss

Supports standard termination practice—110

I impact tool

Easier termination with retention-enhanced IDC contacts that hold laced conductors in position until punch down

I Easy to follow universal wiring label

I Fits in all TracJack plates and housings

I Icon compatible, 5E marking on jack face

I Broad selection of colors

SERIES II MODULES

Clarity 5E Series II modules exceed TIA Category 5e component compliance requirements and are center tuned to Clarity 5E patch cords. Series II modules provide the ease and reliability of a front-loading module with linear 110 termination.

I

FEATURES

I

Meets Category 5e component specifications TIA/EIA-568-B.2

I

ETL 3rd party component tested and verified

I

Mated unions with Clarity 5E cords are more transparent to signal

I

New low emission IDC contacts for better noise protection and improved return loss

I

Supports standard termination practice—110 impact tool

I

Traditional linear 110 punch down sequence

I

Mechanical improvements for easier termination and reduced depth of the module

I

Easy lace IDCs and easy to follow T568B and T568A wiring labels

I

Fits in all Series II plates and housings

I

Icon compatible, 5E marking on module face

ORDERING INFORMATION

WIRING

TracJack, T568A/B, fog white

PART NO. 180º FLUSH

OR-TJ5E00

PART NO. ANGLED

OR-TJ5E45

NOTE: Standard color is fog white. To order other standard colors add suffix: -13=electrical ivory, -36=dark blue, -42=dark red, -43=dark orange, -44=dark yellow, -45=dark green, -68=Wiremold

-99=Wiremold ® ivory, and -00=black.

® light gray, -78=Wiremold ® gray, -88=cloud white,

ORDERING INFORMATION

DESCRIPTION

Series II, 1 unit, 180°, fog white

Series II, 2 units, 180°, fog white

PART NO.

OR-S215E00

OR-S225E00

NOTE: Standard color is fog white. To order other standard colors add suffix: -00=black and -99=Wiremold ® Ivory.

09

Clarity

5E

Patch

Panels

TRADITIONAL

JACKS PANELS CORDS

ANGLED

CLARITY

5E

PATCH PANELS

Ortronics Clarity

5E standard and high density patch panels utilize center tuned technology to exceed TIA

Category 5e component compliance requirements and are precision tuned to the same optimized value as Clarity

5E cords. This maximizes each patch mated union for significantly improved cross talk and return loss performance; field measurable in the link or channel. I

ANGLED PATCH PANELS

Ortronics angled Clarity

® patch panels offer a new slant to patch cord management. Built around the elevated performance of Clarity 6 and Clarity

5E these high density patch panels utilize a unique, patent pending, recessed angle design to help direct cords more easily to vertical rack or cabinet management within a lower profile.

This design provides a better alternative for installations which have limited rack space for horizontal management.

I

CURVED PATCH PANELS

Ortronics curved Clarity ® patch panels offer yet another alternative for patch cord management.

CURVED

Built around the elevated performance of Clarity 5E , these high density patch panels feature a new look, utilizing a patent pending, recessed, curved design to help direct cords to vertical rack or cabinet management within a lower profile. This design provides another alternative for installations which have limited rack space for horizontal management.

I

10

FEATURES

I

Meets Category 5e component specifications

I

TIA/EIA-568-B.2

ETL 3rd party component tested and verified

I

Mated union with Clarity 5E cords is more

I transparent to signal

New low emission IDC contacts for better noise protection and improved return loss

I

Supports standard termination practice—110 impact tool

I

Universal T568B and T568A wiring

I

Available in 6 or 8 port groupings

I

Easy lace IDCs and easy to follow wiring labels

I

Supplied label fields

I

Icon compatible

I

Includes rear cable management

I

Available in high and standard density

Clarity

5E

Patch Panels and

Patch Cords

JACKS PANELS CORDS

PATCH CORDS

Ortronics Clarity

5E patch cords utilize center tuned technology to elevate the performance of

Category 5e structured cabling.

Clarity

5E cords are finely controlled to an optimum center target shared by Clarity

5E connecting hardware for heightened performance that is confirmed by factory testing.

This ensures an interface with improved signal-to-noise ratio for a more transparent signal path that is field measurable in the link or channel.

Clarity 5E cords use Ortronics’ patented Paralign 2 termination technique to maintain pair integrity between the point of exit from the cable jacket and the contact termination. The plug is designed to the center of the range of TIA de-embedded plug values.

I

FEATURES

I

Exceeds Category 5e component specifications

I

TIA/EIA-568-B.2

ETL 3rd party component tested and verified

I

Factory tested for Category 5e performance

I

Transparent to signal with Clarity 5E jacks

I and panels

Snagless design also provides bend

I radius support

Optimized plug paired bi-level contact array

I

Premium performance Category 5e stranded

I conductor cordage

Compatible with both T568A and T568B wiring

I

Icon compatibility to support TIA 606 standard

I

Available in 7 standard colors

ORDERING INFORMATION

DESCRIPTION

ANGLED

,

HIGH DENSITY 6 PORT PATCH PANELS

24-port, T568A/B, 1.75" x 19" (1RU)

48-port, T568A/B, 3.5" x 19" (2RU)

CURVED

,

HIGH DENSITY 6 PORT PATCH PANELS

24-port, Category 5E, T568A/B, 1.75” x 19” (1RU)

48-port, Category 5E, T568A/B, 3.5” x 19” (2RU)

FLAT

,

HIGH DENSITY 6 PORT PATCH PANELS

24-port, T568A/B, 1.75" x 19" (1RU)

48-port, T568A/B, 3.5" x 19" (2RU)

96-port, T568A/B, 7.0" x 19" (4RU)

FLAT

,

STANDARD DENSITY 6 PORT PATCH PANELS

12-port, T568A/B, 1.75" x 19" (1RU)

24-port, T568A/B, 3.5" x 19" (2RU)

48-port, T568A/B, 5.25" x 19" (3RU)

96-port, T568A/B, 10.5" x 19" (6RU)

FLAT

,

HIGH DENSITY 8 PORT PATCH PANELS

24-port, T568A/B, 1.75" x 19" (1RU)

48-port, T568A/B, 3.5" x 19" (2RU)

96-port, T568A/B, 7.0" x 19" (4RU)

NOTE: See pg. 12 for new Clarity individual jack panels and 48 port 1RU panels.

PART NO.

OR-PHA5E6U24

OR-PHA5E6U48

OR-PHC5E6U24

OR-PHC5E6U48

OR-PHD5E6U24

OR-PHD5E6U48

OR-PHD5E6U96

OR-PSD5E6U12

OR-PSD5E6U24

OR-PSD5E6U48

OR-PSD5E6U96

OR-PHD5E8U24

OR-PHD5E8U48

OR-PHD5E8U96

ORDERING INFORMATION

DESCRIPTION LENGTH PART NO.

Modular Cord, 3 ft green, Clarity 5E 5 ft

7 ft

9 ft

15 ft

25 ft

OR-MC5E03-05

OR-MC5E05-05

OR-MC5E07-05

OR-MC5E09-05

OR-MC5E15-05

OR-MC5E25-05

Note: to order other standard colors change suffix on MC cords: -02=red, -04=yellow, -05=green, -06=blue,

-08=gray, -09=white, -00=black.

11

Clarity

®

Patch

Panels

MAXIMUM DENSITY

NEW PRODUCTS

UNLOADED

12

CLARITY

6

& CLARITY

5E

MAXIMUM DENSITY

PATCH PANELS

Ortronics new maximum density patch panels offer 48 ports of Clarity

6 or 5E performance in 1 rack unit

(1.75” x 19”). Panels are supplied with 24 rear-loading dual port termination (Clarity 6 or 5E) modules.

I

CLARITY 48-PORT

MAXIMUM DENSITY

UNLOADED PANELS

& DUAL JACKS

Ortronics new 48-port maximum density panel kit utilizes Clarity 6 and Clarity 5E dual panel jacks that can be terminated and snapped in from the back of the panel. A variety of panel configurations allow a wide choice of field configurable and easyto-install horizontal cross connects utilizing only 1 rack unit. The panel is supplied without the jacks. I

REAR

-

LOAD

INDIVIDUAL

JACK PANEL

ORDERING INFORMATION

DESCRIPTION

CLARITY

6

& CLARITY

5E

MAXIMUM DENSITY PATCH PANELS

PART NO.

1 rack unit, 19”x 1.75”, maximum density, Clarity 5E OR-PMD5EU481U

1 rack unit, 19”x 1.75”, maximum density, Clarity 6 OR-PMD6U481U

NOTE: Panels are also available unloaded. Dual port jacks are ordered separately. (Available in six colors.)

ORDERING INFORMATION

DESCRIPTION PART NO.

CLARITY 48-PORT MAXIMUM DENSITY UNLOADED PANELS & DUAL MOUNT JACKS

48-port, maximum density panel, 19” x 1.75”, with rear wire management

Panel jack, dual, Clarity, Category 6, T568A/B, 8 pos, blue, 180°

OR-PMDU481U

OR-DJ600

Panel jack, dual, Clarity, Category 5e, T568A/B, 8 pos, blue, 180° OR-DJ5E00

NOTE: Clarity panel jacks are available in these colors: -36 blue, -42 red, -43 orange, -44 yellow, -45 green. Add tail code to the end of dual jack part number.

ORDERING INFORMATION

DESCRIPTION PART NO.

CLARITY REAR-LOAD

JACK PANEL KITS

Ortronics new rear-loading individual jack panels utilize reduced-size Clarity

6 and Clarity

5E panel jacks that can be terminated and snap-in from the back of the patch panel. A variety of panel configurations allow a wide choice of field configurable, easy to install horizontal cross connects. Panels are supplied without jacks. Jacks can be ordered individually or in full carton quantities of 24.

I

REAR-LOAD PANEL & INDIVIDUAL PANEL JACKS

(SEE PANEL JACK PART NO. BELOW PANEL NO.)

24-port, panel jack panel kit, angled, unloaded, 1 rack unit, 19” x 1.75”, HD OR-PHAPJU24

48-port, panel jack panel kit, angled, unloaded, 2 rack units, 19” x 3.5”, HD OR-PHAPJU48

72-port, panel jack panel kit, angled, unloaded, 2 rack units, 19” x 3.5”, HD OR-PHAPJU72

24-port, panel jack panel kit, flat, unloaded, 1 rack unit, 19” x 1.75”, HD OR-PHDPJU24

48-port, panel jack panel kit, flat, unloaded, 2 rack units, 19” x 3.5”, HD

72-port, panel jack panel kit, flat, unloaded, 2 rack units, 19” x 3.5”, HD

Panel jack, Clarity, Category 6, T568A/B, 8 pos, black, 180º

OR-PHDPJU48

OR-PHDPJU72

OR-PJ600-00

Panel jack, Clarity, Category 5e, T568A/B, 8 pos, black, 180º OR-PJ5E00-00

NOTE: Clarity panel jacks are available in these colors: -36 blue, -42 red, -43 orange, -44 yellow, -45 green. Add tail code to the end of jack part number.

Clarity

®

Specifications

CLARITY

10G

JACKS

Materials

High impact plastic housing

Flame retardant UL ® 94V-0

MODULAR CONTACTS: beryllium copper, nickel under plating and minimum 50 micro-inches of gold in contact area

IDC CONTACTS: phosphor bronze, nickel under plating with tin over plate. Serve

22-24 AWG

Compatible with 110 impact tool

PANELS

Materials

.094 aluminum, durable black powder coat finish high impact thermoplastic TracJack mounting bezel

CORDS

Materials

8-position modular plug, Polycarbonate housing

Plug IDC contacts phosphor bronze with 50 micro-inch selective gold plating over nickel

Four pair (stranded) UTP non plenum cable,

26 AWG tinned copper, Polyolefin insulation, PVC jacket

Cable diameter .29 inches

Impedance 100 Ohm

Performance

Tested and characterized to 500 MHz

Meets TIA Category 6 component requirements

Meets FCC part 68 subpart F

Meets UL 1863

Jacks rated for 750 plug insertions

Jack contacts exceed 100 gram requirement

Exceeds PoE voltage requirements by 4x

RoHS compliant

RELATED PRODUCTS

Mighty Mo ® 10 and Mighty Mo 6 cable management racking systems (designed and proven to support the requirements of 10G)

CLARITY

6

TRACJACK MODULES

Materials

MODULAR CONTACTS: beryllium copper, nickel under plating and minimum of 50 micro-inches of gold in contact area

High impact plastic housing

Flame retardant UL ® 94V-0

IDC CONTACTS: phosphor bronze, nickel plating with tin over plate.

Serve 22-24 AWG

Performance

Meets Category 6 component requirements

TIA/EIA-568-B.2-1

Meets FCC part 68 subpart F

Rated for 750 plug insertions

Exceeds 100 gram contact force

UL Listed 1863, file #E131600

Compatible with 110 impact tool

Exceeds IEEE 802.3af DTE power specifications by 500%

SERIES II MODULES

Materials

MODULAR CONTACTS: beryllium copper, nickel under plating and minimum of 50 micro-inches of gold in contact area

High impact plastic housing

Flame retardant UL ® 94V-0

IDC CONTACTS: phosphor bronze, nickel plating with tin over plate.

Serve 22-24 AWG

Performance

Meets Category 6 component requirements

TIA/EIA-568-B.2-1

Meets FCC part 68 subpart F

Rated for 750 plug insertions

Exceeds 100 gram contact force

UL Listed 1863, file #E131600

Compatible with 110 impact tool

Exceeds IEEE 802.3af DTE power specifications by 500%

PATCH PANELS

Materials

PANEL: .094” aluminum, durable black powder coat finish

MODULE: high impact plastic housing

MODULAR CONTACTS: beryllium copper, nickel under plating and minimum of 50 micro-inches of gold in contact area

Flame retardant UL ® 94V-0

Fully encased printed circuitry protection

IDC CONTACTS: phosphor bronze, nickel under plating and tin lead over plate.

Serve 22-24 AWG

Performance

Clarity 6 meets TIA Category 6 component requirements TIA/EIA-568-B.2-1

Meets FCC part 68 subpart F

Rated for 750 plug insertions

Exceeds 100 gram requirement

UL Listed 1863, file #E131600

Exceeds IEEE 802.3af DTE power specifications by 500%

CLARITY 5E

JACKS

Materials

High impact plastic housing

Flame retardant UL ® 94V-0

MODULAR CONTACTS: beryllium copper, nickel under plating and minimum of 50 micro-inches of gold in contact area

IDC CONTACTS: phosphor bronze, nickel plating with tin over plate. Serve 22-24 AWG

Performance

Meets TIA Category 5e component requirements 568B.2

Meets FCC part 68 subpart F

Rated for 750 plug insertions

Exceeds 100 gram requirement

UL 1863 listed, file #E131600

Compatible with 110 impact tool

SERIES II MODULES

Materials

High impact plastic housing

Flame retardant UL ® 94V-0

MODULAR CONTACTS: beryllium copper with nickel under plating and minimum of

50 micro-inches of gold in contact area

IDC CONTACTS: phosphor bronze, nickel plating with tin over plate. Serve 22-24 AWG

Performance

Exceeds TIA Category 5e component requirements

Meets FCC part 68 subpart F

Rated for 750 plug insertions

Exceeds 100 gram requirement

UL 1863 listed, file #E131600

Compatible with 110 impact tool

Exceeds IEEE 802.3af DTE power specifications by 500%

PANELS

Materials

PANEL: .094” aluminum, durable black powder coat finish

MODULE: high impact plastic housing

Flame retardant UL ® 94V-0

Full encasement protects printed circuitry

MODULAR CONTACTS: phosphor bronze with nickel under plating and minimum 50 micro-inches of gold in contact area

IDC CONTACTS: phosphor bronze, nickel plating with tin over plate. Serve 22-24 AWG

Performance

Meets Category 5e component specifications TIA/EIA-568-B.2

Meets FCC part 68 subpart F

Rated for 750 plug insertions

Exceeds 100 gram requirement

UL 1863 listed, file #E131600

Compatible with 110 impact tools

Exceeds IEEE 802.3af DTE power specifications by 500%

CORDS

Materials

PLUG HOUSING: clear polycarbonate

UL ® 94V-0

PLUG CONTACTS: copper alloy with 50 micro-inch gold plating on mating surfaces

CORDAGE: premium Category 5e stranded cable, 4 pair 24 AWG, PVC jacket

Performance

Meets TIA Category 5e component requirements (568B.2)

Meets FCC part 68 subpart F

Cable assembly, UL

® listed

Rated for 750 plug insertions

Plug & termination meet FCC part 68 and

IEC 60603-7

ALL CLARITY COMPONENTS ARE

ROHS COMPLIANT

13

CANADA

570 Applewood Crescent

Vaughan , Ontario L4K 4B4

905-738-9195

125 Eugene O'Neill Drive

New London, CT 06320

800-934-5432

860-445-3900 (sales)

860-405-2992 (fax) www.ortronics.com

rev.5/08

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
