Implementing Virtual Address Hardware Support on the ρ-VEX Platform

Jens Johansen

Abstract

The ρ-VEX is a run-time reconfigurable Very Long Instruction Word (VLIW)

processor.

This unique processor allows separation of its issue lanes to form independently operating processing cores.

Switching between these configuration during run-time allows optimizing the platform for the task(s) it is performing. Porting an

Operating System (OS) to this platform is an important step towards a software layer

that can control these reconfigurations.

All contemporary operating systems implement a virtual memory abstraction layer.

This technique makes the physical memory layout transparent to the processes hosted by the operating system. Implementing virtual memory is impossible without hardware support. This thesis presents the design and implementation of the addition of this hardware to the ρ-VEX platform.

The platforms unusual architecture puts specific requirement on the memory system.

The implemented hardware fully supports the platforms abilities for static configuration and dynamic reconfiguration.

To verify that the implemented solution is able to support an OS, software is designed that emulates the task switching and memory virtualization tasks of an OS. By running this software it is proven that the hardware support all features required by a real OS.

Finally, the performance of the implemented hardware is measured running benchmarks in different static configurations and several dynamic reconfiguration scenarios.

These measurements are compared and recommendations are made for performance optimization of real applications.

CE-MS-2016-05

Faculty of Electrical Engineering, Mathematics and Computer Science

Implementing Virtual Address Hardware Support on the ρ-VEX Platform

THESIS submitted in partial fulfillment of the requirements for the degree of

MASTER OF SCIENCE

in

COMPUTER ENGINEERING

by

Jens Johansen born in The Hague, The Netherlands

Computer Engineering

Department of Electrical Engineering

Faculty of Electrical Engineering, Mathematics and Computer Science

Delft University of Technology

Implementing Virtual Address Hardware Support on the ρ-VEX Platform by Jens Johansen

Abstract

The ρ-VEX is a run-time reconfigurable VLIW processor. This unique processor allows

separation of its issue lanes to form independently operating processing cores. Switching between these configuration during run-time allows optimizing the platform for the task(s) it is performing.

Porting an OS to this platform is an important step towards a software layer that can control

these reconfigurations.

All contemporary operating systems implement a virtual memory abstraction layer. This technique makes the physical memory layout transparent to the processes hosted by the operating system. Implementing virtual memory is impossible without hardware support. This thesis presents the design and implementation of the addition of this hardware to the ρ-VEX platform.

The platforms unusual architecture puts specific requirement on the memory system. The implemented hardware fully supports the platforms abilities for static configuration and dynamic reconfiguration.

To verify that the implemented solution is able to support an OS, software is designed that emulates the task switching and memory virtualization tasks of an OS. By running this software it is proven that the hardware support all features required by a real OS.

Finally, the performance of the implemented hardware is measured running benchmarks in different static configurations and several dynamic reconfiguration scenarios.

These measurements are compared and recommendations are made for performance optimization of real applications.

Laboratory

Codenumber

Committee Members :

: Computer Engineering

: CE-MS-2016-05

Advisor: dr. ir. Stephan Wong, CE, TU Delft

Chairperson: dr. ir. Stephan Wong, CE, TU Delft

Member:

Member: dr. ir. Arjan van Genderen, CE, TU Delft i

ii
