User Guide
50" LED TV
LC-50LB150U
Before using your new product, please read these instructions to prevent any damage.
Contents
CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CAUTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
MHL™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CEC Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Motion Enhancement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTS Sound™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Game mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
4
4
4
4
Installing the stand or wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
What connection should I use? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connecting a cable or satellite box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Using HDMI (best) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Using DVI (same as HDMI but requires an audio connection) . . . . . . . . . . . . . . . . . . . . . . . . 15
Using component video (better) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using composite video (good) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using coaxial (good) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting an antenna or cable TV (no box) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Connecting a DVD or Blu-ray player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Using HDMI (best) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Using DVI (same as HDMI but requires an audio connection) . . . . . . . . . . . . . . . . . . . . . . . . 21
Using component video (better) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Using composite video (good) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Connecting an MHL-enabled device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Connecting a game console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Using HDMI (best) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Using component video (better) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Using composite video (good) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
ii
www.sharpusa.com
Contents
Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Using VGA (most common) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Using HDMI (best) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Using DVI (same as HDMI but requires an audio connection) . . . . . . . . . . . . . . . . . . . . . . . . 30
Connecting a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Connecting a basic home theater system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Using digital audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Using analog audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Connecting a home theater system with multiple devices . . . . . . . . . . . . . . . . . . . 35
Connecting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Turning on your TV for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Viewing channel information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Setting the power on picture mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Adjusting sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Selecting the audio out mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Viewing a favorite channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Adding or changing a channel label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Checking the digital signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Automatically adjusting the aspect ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Locking control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Downloading rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
www.sharpusa.com
iii
Contents
Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Selecting the analog closed captioning mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Selecting the digital closed captioning mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Customizing digital closed captioning settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Turning Input Sensor on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Labeling an input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Using CEC Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Turning CEC Control on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Turning Device Auto Power Off on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Turning TV Auto Power On on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Turning Audio Return Channel on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Displaying a list of CEC-compatible devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Waking CEC-compatible devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Opening a CEC-compatible device’s root menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Using an MHL-enabled device or Roku Streaming Stick . . . . . . . . . . . . . . . . . . . . . . 64
Using an MHL-enabled device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Using a Roku Streaming Stick . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Using a USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Switching to USB mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Browsing photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Viewing favorite photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Viewing photos in a slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Customizing slideshow settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Cleaning the TV cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Cleaning the TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Restoring settings to the defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Viewing system information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Video and audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
MHL-enabled device or Roku Streaming Stick . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
CEC-compatible device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Programming universal remote controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Common universal remote control codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
One-year limited warranty - Sharp Televisions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
iv
www.sharpusa.com
Contents
www.sharpusa.com
v
f
CHILD SAFETY
It makes a difference how and where you use
your flat panel display
As you enjoy your new product, keep these
safety tips in mind
The issue
The home theater entertainment experience is a growing trend, and larger TVs are popular
purchases. However, TVs are not always supported on the proper stands or installed
according to the manufacturer’s recommendations. We and the consumer electronics
industry are committed to making home entertainment enjoyable and safe.
TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or
carts may fall over and cause injury.
Tune into safety
•
•
•
•
•
•
One size of TV stand does not fit all. Use only a TV stand
rated for the weight of your TV.
Carefully read and understand all enclosed instructions
for proper use of this product.
Don’t let children climb on or play with entertainment
system furniture and TVs.
Don’t place TVs on furniture that can easily be used as
steps, such as a crate or chest of drawers.
Remember that children can become excited while
watching a program, especially on a “larger-than-life” TV.
Make sure that you place or install the TV where it cannot
be pushed, pulled over, or knocked down.
Make sure that you route all cords and cables so that they
cannot be pulled or grabbed by curious children.
Wall mounting
If you decide to wall mount your TV, always remember:
•
One size of wall mount does not fit all. Use only a wall mount rated for the weight of
your TV and that has been recommended by this TV manufacturer, listed in this
manual, or otherwise listed by an independent laboratory as suitable for your TV.
•
Follow all instructions supplied by the TV and wall mount manufacturers.
•
If you have any doubts about your ability to safely wall mount your TV, get help from a
professional installer.
•
Make sure that the wall where you are mounting the TV is
appropriate. Some wall mounts are not designed to be
mounted to walls backed with steel studs or cinder blocks. If
you are unsure, ask a professional installer.
•
TVs can be heavy. At least two people are required for safe wall mount installation.
www.sharpusa.com
1
Important Safety
Instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that
dangerous voltage
constituting a risk of electric
shock is present within your TV.
This label is located on the
back of your TV.
This symbol indicates that
there are important operating
and maintenance instructions
in the literature accompanying
your TV.
1
2
3
4
5
6
7
8
9
10
11
12
13
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer's
instructions.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
Only use attachments/accessories specified by
the manufacturer.
Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold with
the apparatus. When a cart is
used, use caution when moving
the cart/apparatus combination
to avoid injury from tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
15 The wall plug is the disconnecting device. The
plug must remain readily operable.
16 Remote control batteries should not be exposed
to excessive heat such as sunshine, fire, or the
like.
17 The apparatus should not be exposed to
dripping or splashing, and no objects filled with
liquids, such as vases, should be placed on the
apparatus.
WARNING
Electric shock hazard
To reduce the risk of fire or electric shock, do not
remove any cover or expose the device to rain or
moisture. No user-serviceable parts are inside. Refer
servicing to qualified service technicians.
Lightning
For added protection for your device receiver
during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the power outlet and disconnect any
antenna or cable system. This helps prevent
property damage and personal injury from
lightning and power line surges.
Power lines
An outside antenna system should not be located in
the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an
outside antenna system, take extreme care to keep
from touching such power lines or circuits as
contact with them might be fatal.
Handling the LCD panel
• Your TV’s screen is made of glass. Do not drop
your TV or hit, jolt, or press hard against the LCD
panel. If the screen breaks, be careful of broken
glass.
• If the LCD panel is broken, make absolutely sure
that you do not touch the liquid in the panel. This
may cause skin inflammation.
• If the liquid gets in your mouth, immediately
gargle, rinse, and consult with your doctor. Also, if
the liquid gets in your eyes or touches your skin,
consult with your doctor after rinsing for at least
15 minutes or longer in clean water.
Replacement parts
When replacement parts are required, make sure
that the service technician uses replacement parts
specified by the manufacturer that have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock,
personal injury, or other hazards.
www.sharpusa.com
2
LC-50LB150U
Safety check
After completing any service or repair to this device,
ask the service technician to perform routine safety
checks to determine that your TV is in correct
operating condition.
1 Antenna lead-in wire
2 Grounding clamp
Antenna discharge
unit
Grounding
4
conductors
5 Ground clamps
3
Power source
Operate your TV only from the type of power source
indicated on the marking label. If you are not sure
of the type of power supplied to your home, consult
an electrician or your local power company.
Servicing
These servicing instructions are for use by qualified
service personnel only. To reduce the risk of electric
shock, do not perform any servicing other than that
contained in the operating instructions unless you
are qualified to do so.
CAUTION
Damage requiring service
Unplug this TV from the power outlet and refer
servicing to qualified service personnel under the
following conditions:
• When the power supply cord or plug is damaged
or frayed.
• If liquid has been spilled or objects have fallen
into your TV.
• If your TV has been exposed to rain or water.
• If your TV does not operate normally by following
the operating instructions. Adjust only those
controls covered by the operating instructions
because incorrect adjustment of other controls
may result in damage and will often require
extensive work by a qualified technician to restore
your TV to its normal operation.
• If your TV has been dropped or damaged in any
way.
• When your TV exhibits a distinct change in
performance.
Outdoor antenna grounding
If an outside antenna or cable system is connected
to your TV, make sure that the antenna or cable
system is grounded to provide some protection
against voltage surges and built-up static charges.
Article 810 of the National Electrical Code,
ANSI/NFPA No. 70, provides information with
respect to correct grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of the antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
3
Power service
6 grounding electrode
system
Electric service
7
equipment
Note to CATV system installer
Article 820 of the National Electrical Code,
ANSI/NFPA No. 40 provides guidance for correct
grounding. Specifically, it states that the cable
ground must be connected to the grounding
system of the building as close to the point of cable
entry as practical.
Condensation
Moisture will form on the TV if the TV is brought
from cool surroundings into a warm room or if the
temperature of the room rises suddenly. When this
happens, the TV's performance may be impaired. To
prevent this, let the TV stand in its new
surroundings for about an hour before switching it
on, or make sure that the room temperature rises
gradually.
Condensation may also form during the summer if
the TV is exposed to the breeze from an air
conditioner. In such cases, change the location of
the TV.
Mobile telephone warning
To avoid interference with your TV picture and
sound, operating problems, or even damage, keep
your cordless and cellular telephones away from
the TV.
End of life directives
Your TV may contain materials that are regulated
for environmental reasons. Your TV also contains
materials that can be recycled and reused. To help
protect the environment, contact your local
authorities for information about disposal or
recycling and about finding a recycler in your area
before you dispose of your TV.
Non-active pixels
The LCD panel contains almost 3 million thin film
transistors, which provide exceptionally sharp video
quality. Occasionally, a few non-active pixels may
appear on the screen as a fixed blue, green, or red
point. These non-active pixels do not adversely
affect the performance of your TV, and are not
considered defects.
www.sharpusa.com
Sharp 50" LED TV
Sharp 50" LED TV
Introduction
Motion Enhancement
Congratulations on your purchase of a high-quality
Sharp product. Your LC-50LB150U represents the
state of the art in LED TV design and is designed for
reliable and trouble-free performance.
MHL™
Connect your MHL-enabled device, such as a cell
phone or Roku Streaming Stick™, and view your
device’s screen on your TV. Supports 1080p HD
video and 5.1 digital surround sound playback from
your mobile device. (Requires an MHL-enabled
phone or tablet and an MHL cable.) (See page 24 for
connection instructions.)
CEC Control
Enjoy the benefit of having HDMI CEC compatible
products plug and play! No setup is needed! CEC
technology lets different components discover and
communicate with each other. (See page 60 for
instructions on how to use CEC Control.)
With a 120 Hz screen refresh rate twice the rate of a
60 Hz screen, a screen with 1,080 lines of resolution
(up from 720 lines in the last generation of HDTVs),
and special motion-detection technology, you will
experience a picture with clearer detail and
brightness, smoother transitions, and reduced
motion blurring, particularly when watching
fast-motion sports and action scenes. (See the
Motion Enhancement option in “Adjusting the TV
picture” on page 43 for instructions on how to
adjust the TV picture.)
DTS Sound™
DTS Sound delivers clear, crisp, and natural sound
while providing deep enveloping bass.
Game mode
Video games generally require adjustments to the
television picture settings to get the maximum
experience. By simply pressing a button on your
remote control, your television settings will
automatically adjust for video games. It couldn't be
easier. (See the Game option in “Adjusting the TV
picture” on page 43 for instructions on how to
select Game mode.)
www.sharpusa.com
4
LC-50LB150U Sharp 50" LED TV
Installing the stand or wall-mount bracket
Notes
• If you plan to wall-mount your TV, do not install the stand.
• Store the stand and stand screws in case you decide to use the stand in
the future.
Installing the stand
To install the stand:
1 Secure the stand column to the TV stand using the four provided M6 (12 mm) screws. (These are the long
screws.)
Screw type
M6
Screw length
12 mm
# of screws
4
2 Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages and
scratches.
5
www.sharpusa.com
Sharp 50" LED TV
3 Insert the stand column into the TV.
4 Secure the TV stand to your TV using the four provided M4 (8 mm) screws. (These are the short screws.)
Screw type
M4
Screw length
8 mm
www.sharpusa.com
# of screws
4
6
LC-50LB150U Sharp 50" LED TV
Installing a wall-mount bracket
Warning
• This TV is intended to be supported by a UL Listed wall mount bracket
with suitable weight/load. (See “Miscellaneous” on page 76.)
• To prevent injury, this apparatus must be securely attached to the
floor/wall in accordance with the installation instructions.
To attach your TV to a wall-mount bracket:
1 Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages and
scratches.
2 If the stand is attached, remove the four screws that secure the TV stand to your TV.
3 Remove the TV stand.
7
www.sharpusa.com
Sharp 50" LED TV
4 Remove the screws in the mounting holes on the back of your TV, then follow the instructions that came with
the wall-mount bracket.
Notes
• The length of the wall-mount screws vary depending on the wall-mount
bracket you purchased. See the instructions that came with the
wall-mount bracket for screw lengths.
• The mounting holes on the back of your TV take type M6 screws.
15.75 in. (400 mm)
15.75 in. (400 mm)
Wall-mount
brackets
www.sharpusa.com
8
LC-50LB150U Sharp 50" LED TV
TV components
# Item
Package contents
•
•
•
•
•
•
•
50" LED TV
Remote control and batteries (2 AAA)
Stand column and screws (4)
TV stand and screws (4)
Power cord
Quick Setup Guide
Important Information
1
Remote control
sensor and
power indicator
2
MENU
3
INPUT
4
VOL+/VOL–
5
CH
Front
6
9
/CH
(power)
www.sharpusa.com
Description
The remote control sensor
receives signals from the remote
control. Do not block.
The power indicator:
• Lights blue when your TV is
on.
• Lights red when your TV is
off (standby mode).
Press to open the on-screen
menu. For more information, see
“Navigating the menus” on
page 41.
Press one or more times to select
the video input source your want,
then wait a few seconds. Your TV
switches to the source you
selected. For more information,
see “Selecting the video input
source” on page 40.
In menu mode, press to confirm
selections.
Press to increase or decrease the
volume.
Press to go to the next or previous
channel in the channel list. For
more information, see “Selecting
a channel” on page 42.
Press to turn your TV on or off
(standby mode).
Warning: When your TV is off,
power still flows through it. To
completely disconnect power,
unplug the power cord.
Sharp 50" LED TV
Side
# Item
1
/AUDIO OUT
2
HDMI 3/DVI
3
HDMI 2/MHL
4
HDMI 1/ARC
5
USB
www.sharpusa.com
Description
Connect headphones, an analog
audio amplifier, a home theater
system, or a sound bar to this jack.
For more information, see
“Connecting headphones” on
page 32 or “Using analog audio” on
page 34.
Connect an HDMI device to this
jack. For more information, see
“Using HDMI (best)” on pages 14,
20, 25, or 29.
OR
Connect the video for a DVI device
to this jack. For more information,
see “Using DVI (same as HDMI but
requires an audio connection)” on
pages 15, 21, or 30.
Connect an HDMI device to this
jack. For more information, see
“Using HDMI (best)” on pages 14,
20, 25, or 29.
OR
Connect an MHL-enabled device,
such as a cell phone or Roku
Streaming Stick™, to this jack to
view pictures and videos stored on
the device. For more information,
see “Connecting an MHL-enabled
device” on page 24 and “Using an
MHL-enabled device or Roku
Streaming Stick” on page 64.
Connect an HDMI device to this
jack. For more information, see
“Using HDMI (best)” on pages 14,
20, 25, or 29.
OR
Connect a home theater that
supports ARC to this jack.
Connect a USB flash drive to this
jack to view compatible JPEG
picture files. For more information,
see “Connecting a USB flash drive”
on page 31 and “Using a USB flash
drive” on page 66.
10
LC-50LB150U Sharp 50" LED TV
Back
# Item
1
Power connector
2
DIGITAL AUDIO
OUTPUT (optical)
COMPONENT/AV
Y/VIDEO, PB, PR
3 OR
COMPONENT/AV
Y/VIDEO
11
4
L and R (audio)
5
ANT/CABLE
6
PC IN
7
PC/DVI AUDIO IN
www.sharpusa.com
Description
Plug the power cord into this
connector.
Connect a digital audio
amplifier, a home theater
system, or a sound bar to this
jack to listen to TV audio
through the external speakers.
For more information, see
“Using digital audio” on
page 33.
The COMPONENT/AV Y/VIDEO
jack works as one of the three
component video jacks or as a
composite video jack.
Connect the video for a
component video device to
these jacks. For more
information, see “Using
component video (better)” on
page 16, 22, or 26.
OR
Connect the video for a
composite video device to the
COMPONENT/AV Y/VIDEO
jack. For more information, see
“Using composite video (good)”
on page 17, 23, or 27.
Connect the audio for a
component video device to
these jacks. For more
information, see “Using
component video (better)” on
page 16, 22, or 26.
OR
Connect the audio for a
composite video device to
these jacks. For more
information, see “Using
composite video (good)” on
page 17, 23, or 27.
Connect an antenna or cable TV
to this jack. For more
information, see “Using coaxial
(good)” on page 18 or
“Connecting an antenna or
cable TV (no box)” on page 19.
Connect the video (VGA) for a
computer to this jack. For more
information, see “Using VGA
(most common)” on page 28.
Connect the audio for a
computer to this jack. For more
information see “Using VGA
(most common)” on page 28.
OR
Connect the audio for a DVI
device to this jack. For more
information see, “Using DVI
(same as HDMI but requires an
audio connection)” on
pages 15, 21, or 30.
Sharp 50" LED TV
Remote control
# Button
Description
8
SOUND MODE
Press to select the sound mode. You can select
Standard, Movie, Music, Voice, or User. For more
information, see “Sound Mode” in “Adjusting sound
settings” on page 45.
9
CC
Press to turn closed captioning on or off. You can select
Off, On Always or On When Mute. For more
information, see “Turning closed captioning on or off”
on page 55.
10 S T W X
Press to navigate in on-screen menus and to adjust
settings.
11 ENTER
Press to confirm selections or changes or to open
sub-menus.
12 EXIT
Press to close the on-screen menu.
13 CEC controls
Press to control CEC devices connected to your TV. for
more information, see “Using CEC Control” on page 60.
14 INPUT
Press to open the INPUT SOURCE list, press S or T on
the remote control to select the video input source,
then press ENTER. For more information, see
“Selecting the video input source” on page 40.
15 ENT
Press to go to the channel you selected using the
number buttons.
16 SLEEP
Press to set the sleep timer. You can select Off, 5, 10,
15, 30, 60, 90, 120, 180, or 240 minutes. For more
information, see “Setting the sleep timer” on page 59.
17 VIEW MODE
Press to change how the picture looks on the screen
(aspect ratio). For more information, see the View
Mode option in “Adjusting the TV picture” on page 43.
18
Press to mute the sound. Press again to restore the
sound.
MUTE
19 CH
/CH
Press to change TV channels. For more information,
see “Selecting a channel” on page 42.
20 MENU
Press to open the on-screen menu.
21 FAVORITE
Press to open the FAVORITES LIST. For more
information, see “Setting up a favorite channel list” on
page 49 and “Viewing a favorite channel” on page 49.
# Button
Description
22 INFO*
1
Press to turn your TV on or off (standby mode).
Warning: When your TV is off, power still flows
through it. To disconnect power, unplug the power
cord.
Press to display TV status information, such as the
channel number, channel name (if available), or signal
source. For more information, see “Viewing channel
information” on page 42.
Press to enter channel numbers and the parental
control password.
23 HOME
Opens the MHL device’s home menu when an MHL
device is plugged in. For more information, see “Using
an MHL-enabled device or Roku Streaming Stick” on
page 64.
2
POWER
Numbers
3
Press to enter a digital sub-channel number. For more
information, see “Selecting a channel” on page 42.
4
AUDIO
Press to select the audio mode for an analog program.
You can select:
• Mono—Select this option if there is noise or
static on weak stereo broadcasts.
• Stereo—Select this option for programs
broadcast in stereo.
• SAP—Select this option to listen to a
secondary audio program, if available.
OR
Press to select the audio language for a digital
program, if alternate languages are available.
5
AV MODE
Press to select the AV (picture) mode. You can select
Dynamic, Natural, Standard, Movie, Game, or
User.
6
VOL+/–
Press to increase or decrease the volume.
7
FLASHBACK
In TV mode, press to return to the previous channel.
www.sharpusa.com
12
LC-50LB150U Sharp 50" LED TV
What connection should I
use?
Connection
type and
jack
Your TV has several connection types for
connecting devices to your TV.
For the best video quality, you should connect a
device to the best available connection.
Use the following tables to identify cables:
Video
quality
Best (use this
if your devices
have HDMI)
Connection
type and
jack
HDMI
video/audio
Component
video (requires
Better than
an audio
composite or connection)
coaxial
Cable connectors
Optical digital
audio
Cable connector
Analog audio
input
Analog audio
output
VGA (computer)
video and audio
Composite video
(requires an
audio
Better than
connection)
coaxial
You can use the HDMI 3/DVI jack on your TV to
connect a DVI device to your TV. You need to attach
an HDMI-to-DVI adapter to the end of the HDMI
cable that connects to the DVI device.
Cautions
• Check the jacks for position and type
before making any connections.
• Loose connections can result in image or
color problems. Make sure that all
connections are tight and secure.
• The external audio/video equipment
shown may be different from your
equipment. If you have questions, refer to
the documentation that came with your
equipment.
• Always unplug the power cord when
connecting external equipment.
Coaxial
video/audio
Good
13
www.sharpusa.com
Sharp 50" LED TV
Connecting a cable or satellite box
Many cable or satellite TV boxes have more than one connection type. To get the best video, you should use the
best connection type available. For more information, see “What connection should I use?” on page 13.
Using HDMI (best)
Side of TV
On your TV
Cable or
satellite box
HDMI cable
HDMI cable
connector
HDMI jack
To connect a cable or satellite box using HDMI:
1 Make sure that your TV’s power cord is unplugged and all connected equipment is turned off.
2 Connect the incoming cable from the cable wall jack to the cable-in jack on the cable or satellite box.
3 Connect an HDMI cable (not provided) to one of the HDMI jacks on the side of your TV and to the HDMI OUT
jack on the cable or satellite box.
4 Plug your TV’s power cord into a power outlet, turn on your TV, then turn on the cable or satellite box.
5 Press INPUT to open the INPUT SOURCE list.
6 Press S or T to highlight HDMI 1, HDMI 2, or HDMI 3, then press ENTER.
Note
An HDMI cable carries both audio and video. You do not need to use any
audio cables.
www.sharpusa.com
14
LC-50LB150U Sharp 50" LED TV
Using DVI (same as HDMI but requires an audio connection)
Note
You must use the HDMI 3/DVI jack to connect a cable or satellite box using
DVI. If you use another HDMI jack, you will not hear sound from the TV
speakers.
Cable or
satellite box
Side of TV
On your TV
HDMI cable
connector
HDMI cable
with
HDMI-DVI
adapter
3.5mm audio
connector
3.5mm audio
cable
HDMI 3/DVI PC/DVI
jack
AUDIO IN
jack
Back of TV
To connect a cable or satellite box using DVI:
1 Make sure that your TV’s power cord is unplugged and all connected equipment is turned off.
2 Connect the incoming cable from the cable wall jack to the cable-in jack on the cable or satellite box.
3 Connect an HDMI-DVI adapter (not provided) to one end of an HDMI cable (not provided), then connect the
adapter to the DVI OUT jack on the cable or satellite box.
4 Connect the other end of the cable to the HDMI 3/DVI jack on the side of your TV.
5 Connect a 3.5mm audio cable (not provided) to the PC/DVI AUDIO IN jack on the back of your TV and to the
AUDIO OUT jacks on the cable or satellite box.
Note
When you connect the audio using the PC/DVI AUDIO IN jack, the audio
output is analog.
6 Plug your TV’s power cord into a power outlet, turn on your TV, then turn on the cable or satellite box.
7 Press INPUT to open the INPUT SOURCE list.
8 Press S or T to select HDMI 3, then press ENTER.
15
www.sharpusa.com
Sharp 50" LED TV
Using component video (better)
Note
Cables are often color-coded to match color-coded jacks.
Cable or
satellite box
On your TV
Component
Analog
video cable audio cable
connectors connectors
Component video cable
Audio cable
Component
video jacks
Analog
audio jacks
Back of TV
To connect a cable or satellite box using component video:
1 Make sure that your TV’s power cord is unplugged and all connected equipment is turned off.
2 Connect the incoming cable from the cable wall jack to the cable-in jack on the cable or satellite box.
3 Connect a component video cable (not provided) to the COMPONENT/AV Y/VIDEO, PB, and PR video jacks on
the back of your TV and the component video out jacks on the cable or satellite box.
4 Connect an audio cable (not provided) to the L and R audio jacks on the back of your TV and to the audio out
jacks on the cable or satellite TV box.
Notes
• The COMPONENT/AV Y/VIDEO, PB, and PR video jacks (used to connect
a component video device) share the L and R audio jacks with the
COMPONENT/AV Y/VIDEO jack (used to connect a composite video
device).
• When you connect the audio using the L and R audio jacks, the audio
output is analog.
5 Plug your TV’s power cord into a power outlet, turn on your TV, then turn on the cable or satellite box.
6 Press INPUT to open the INPUT SOURCE list.
7 Press S or T to select Component, then press ENTER.
www.sharpusa.com
16
LC-50LB150U Sharp 50" LED TV
Using composite video (good)
Notes
• Cables are often color-coded to match color-coded jacks.
• The yellow video connector on the AV cable connects to the green
COMPONENT/AV Y/VIDEO jack.
On your TV
Composite
video cable
connector
Cable or
satellite box
Analog audio
cable
connectors
AV cable (composite video cable)
Composite
video jack
Analog
audio jacks
Back of TV
To connect a cable or satellite box using composite video:
1 Make sure that your TV’s power cord is unplugged and all connected equipment is turned off.
2 Connect the incoming cable from the cable wall jack to the cable-in jack on the cable or satellite box.
3 Connect an AV cable (not provided) to the COMPONENT/AV Y/VIDEO jack and L and R audio jacks on the back
of your TV and to the composite video and audio out jacks on the cable or satellite box.
Notes
• The COMPONENT/AV Y/VIDEO, PB, and PR video jacks (used to connect
a component video device) share the L and R audio jacks with the
COMPONENT/AV Y/VIDEO jack (used to connect a composite video
device).
• When you connect the audio using the L and R audio jacks, the audio
output is analog.
4 Plug your TV’s power cord into a power outlet, turn on your TV, then turn on the cable or satellite box.
5 Press INPUT to open the INPUT SOURCE list.
6 Press S or T to select AV, then press ENTER.
17
www.sharpusa.com
Sharp 50" LED TV
Using coaxial (good)
On your TV
Cable or
satellite box
Coaxial cable
connector
ANT/CABLE
jack
Back of TV
To connect a cable or satellite box using coaxial:
1 Make sure that your TV’s power cord is unplugged and all connected equipment is turned off.
2 Connect the incoming cable from the cable wall jack to the cable-in jack on the cable or satellite box.
3 Connect a coaxial cable (not provided) to the ANT/CABLE jack on the back of your TV and to the coaxial out jack
on the cable or satellite box.
4 Plug your TV’s power cord into a power outlet, turn on your TV, then turn on the cable or satellite box.
5 Press INPUT to open the INPUT SOURCE list.
6 Press S or T to highlight TV, then press ENTER.
7 If you cannot tune to channels you know exist, scan for channels. See “Automatically scanning for channels” on
page 47.
Notes
• Use a coaxial cable to eliminate interference and noise from radio
waves.
• Do not bundle the coaxial cable with the power cord or other cables.
www.sharpusa.com
18
LC-50LB150U Sharp 50" LED TV
Connecting an antenna or cable TV (no box)
On your TV
Antenna or cable TV
(no box)
Coaxial cable
connector
ANT/CABLE
jack
Back of TV
To connect an antenna or cable TV (no box):
1 Make sure that your TV’s power cord is unplugged and all connected equipment is turned off.
2 Connect a coaxial cable (not provided) to the ANT/CABLE jack on the back of your TV and to the antenna or
cable TV wall jack.
3 Plug your TV’s power cord into a power outlet, then turn on your TV.
4 Press INPUT to open the INPUT SOURCE list.
5 Press S or T to highlight TV, then press ENTER.
6 If you cannot tune to channels you know exist, scan for channels. See “Automatically scanning for channels” on
page 47.
Notes
• Use a coaxial cable to eliminate interference and noise from radio
waves.
• Do not bundle the coaxial cable with the power cord or other cables.
• If the antenna is not installed correctly, contact qualified service
personnel to correct the problem.
• If the signal level for a channel is weak, the picture may be distorted.
Adjust the antenna or use a highly directional outdoor or set-top
antenna with a built-in amplifier.
• If the picture quality is good on some channels and poor on others, the
problem may be caused by a poor or weak signal from the broadcaster
or cable TV provider.
• If you connect to cable or satellite TV without a set-top box and
experience poor picture quality, you may need to install a set-top box to
improve signal reception and picture quality. Contact your cable or
satellite TV provider about upgrading to a set-top box.
• Many high-definition (HD) channels upscale standard-definition (SD)
content. The picture displayed on your TV is still displayed as SD, thus
the picture quality will not be as clear or crisp as it would be if the
content was originally recorded in HD.
19
www.sharpusa.com
Sharp 50" LED TV
Connecting a DVD or Blu-ray player
Many DVD or Blu-ray players have more than one connection type. To get the best video, you should use the best
connection type available. For more information, see “What connection should I use?” on page 13.
Using HDMI (best)
Side of TV
On your TV
HDMI cable
HDMI cable
connector
HDMI jack
DVD or Blu-ray player
To connect a DVD or Blu-ray player using HDMI:
1 Make sure that your TV’s power cord is unplugged and the DVD or Blu-ray player is turned off.
2 Connect an HDMI cable (not provided) to one of the HDMI jacks on the side of your TV and to the HDMI OUT
jack on the DVD or Blu-ray player.
3 Plug your TV’s power cord into a power outlet, then turn on your TV.
4 Turn on the DVD or Blu-ray player, then set it to the correct output mode. For more information, see the
documentation that came with the player.
5 Press INPUT to open the INPUT SOURCE list.
6 Press S or T to highlight HDMI 1, HDMI 2, or HDMI 3, then press ENTER.
Note
An HDMI cable carries both audio and video. You do not need to use any
audio cables.
www.sharpusa.com
20
LC-50LB150U Sharp 50" LED TV
Using DVI (same as HDMI but requires an audio connection)
Note
You must use the HDMI 3/DVI jack to connect a DVD or Blu-ray player using
DVI. If you use another HDMI jack, you will not hear sound from the TV
speakers.
Side of TV
On your TV
DVD or Blu-ray player
HDMI cable
connector
3.5mm audio
cable
connector
HDMI 3/
DVI jack
PC/DVI
AUDIO IN
jack
HDMI cable
with
HDMI-DVI
adapter
3.5mm audio
cable
Back of TV
To connect a DVD or Blu-ray player using DVI:
1 Make sure that your TV’s power cord is unplugged and the DVD or Blu-ray player is turned off.
2 Connect an HDMI-DVI adapter (not provided) to one end of an HDMI cable (not provided), then connect the
adapter to the DVI OUT jack on the DVD or Blu-ray player.
3 Connect the other end of the cable to the HDMI 3/DVI jack on the side of your TV.
4 Connect a 3.5mm audio cable (not provided) to the PC/DVI AUDIO IN jack on the back of your TV and to the
AUDIO OUT jacks on the DVD or Blu-ray player.
Note
When you connect the audio using the PC/DVI AUDIO IN jack, the audio
output is analog.
5 Plug your TV’s power cord into a power outlet, then turn on your TV.
6 Turn on the DVD or Blu-ray player, then set it to the correct output mode. For more information, see the
documentation that came with the player.
7 Press INPUT to open the INPUT SOURCE list.
8 Press S or T to select HDMI 3, then press ENTER.
21
www.sharpusa.com
Sharp 50" LED TV
Using component video (better)
Note
Cables are often color-coded to match color-coded jacks.
On your TV
DVD or Blu-ray player
Component
video cable
connectors
Analog audio
cable
connectors
Component video cable
Audio cable
Component
video jacks
Analog
audio jacks
Back of TV
To connect a DVD or Blu-ray player using component video:
1 Make sure that your TV’s power cord is unplugged and the DVD or Blu-ray player is turned off.
2 Connect a component video cable (not provided) to the COMPONENT/AV Y/VIDEO, PB, and PR jacks on the
back of your TV and to the COMPONENT OUT jacks on the DVD or Blu-ray player.
3 Connect an audio cable (not provided) to the COMPONENT/AV L and R audio jacks on the back of your TV and
to the L and R AUDIO OUT jacks on the DVD or Blu-ray player.
Notes
• The COMPONENT/AV Y/VIDEO, PB, and PR video jacks (used to connect
a component video device) share the L and R audio jacks with the
COMPONENT/AV Y/VIDEO jack (used to connect a composite video
device).
• When you connect the audio using the L and R audio jacks, the audio
output is analog.
4 Plug your TV’s power cord into a power outlet, then turn on your TV.
5 Turn on the DVD or Blu-ray player, then set it to the correct output mode. For more information, see the
documentation that came with the player.
6 Press INPUT to open the INPUT SOURCE list.
7 Press S or T to select Component, then press ENTER.
www.sharpusa.com
22
LC-50LB150U Sharp 50" LED TV
Using composite video (good)
Notes
• Cables are often color-coded to match color-coded jacks.
• The yellow video connector on the AV cable connects to the green
COMPONENT/AV Y/VIDEO jack.
On your TV
DVD or Blu-ray player
Composite
video cable
connector
Analog audio
cable
connectors
AV cable (composite video cable)
Composite
video jack
Analog
audio jacks
Back of TV
To connect a DVD or Blu-ray player using composite video:
1 Make sure that your TV’s power cord is unplugged and the DVD or Blu-ray player is turned off.
2 Connect an AV cable (not provided) to the COMPONENT/AV Y/VIDEO jack and L and R audio jacks on the back
of your TV and to the AV OUT jacks on the DVD or Blu-ray player.
Notes
• The COMPONENT/AV Y/VIDEO, PB, and PR video jacks (used to connect
a component video device) share the L and R audio jacks with the
COMPONENT/AV Y/VIDEO jack (used to connect a composite video
device).
• When you connect the audio using the L and R audio jacks, the audio
output is analog.
3 Plug your TV’s power cord into a power outlet, then turn on your TV.
4 Turn on the DVD or Blu-ray player, then set it to the correct output mode. For more information, see the
documentation that came with the player.
5 Press INPUT to open the INPUT SOURCE list.
6 Press S or T to select AV, then press ENTER.
23
www.sharpusa.com
Sharp 50" LED TV
Connecting an MHL-enabled device
You can connect an MHL-enabled device, such as a cell phone or Roku Streaming Stick™, and view your device’s
screen on your TV.
Side of TV
On your TV
MHL-enabled
device
HDMI cable
connector
MHL cable
HDMI 2/MHL
jack
To connect an MHL-enabled device:
1 Connect the small connector on an MHL cable (not provided) to the micro USB port on the MHL-enabled device.
2 Connect the other end of the cable to the HDMI 2/MHL jack on the side of your TV.
3 Turn on the MHL-enabled device.
4 If your TV is turned on, press ENTER when a message appears. Your MHL-enabled device’s menu opens.
OR
If your TV is turned off, turn on your TV. Press HOME. Your MHL-enabled device’s menu opens.
Notes
You can also switch to MHL mode by:
• Pressing INPUT and selecting HDMI 2 (MHL/ACC) or HDMI 2 (Roku)
• Pressing MENU and selecting MHL/ACC or Streaming
For instructions on using your MHL-enabled device, see “Using an
MHL-enabled device or Roku Streaming Stick” on page 64.
www.sharpusa.com
24
LC-50LB150U Sharp 50" LED TV
Connecting a game console
Using HDMI (best)
Side of TV
On your TV
HDMI cable
connector
Game
console
HDMI jack
HDMI cable
To connect a game console using HDMI:
1 Make sure that your TV’s power cord is unplugged and the game console is turned off.
2 Connect an HDMI cable (not provided) to one of the HDMI jacks on the side of your TV and to the HDMI OUT
jack on the game console.
3 Plug your TV’s power cord into a power outlet, then turn on your TV.
4 Turn on the game console, then set it to the correct output mode. For more information, see the documentation
that came with the console.
5 Press INPUT to open the INPUT SOURCE list.
6 Press S or T to highlight HDMI 1, HDMI 2, or HDMI 3, then press ENTER.
Note
An HDMI cable carries both audio and video. You do not need to use any
audio cables.
25
www.sharpusa.com
Sharp 50" LED TV
Using component video (better)
Note
Cables are often color-coded to match color-coded jacks.
On your TV
Component
video cable
connectors
Game
console
Analog
audio cable
connectors
Console-specific component
video and audio cable
Component
video jacks
Analog
audio
jacks
Back of TV
To connect a game console using component video:
1 Make sure that your TV’s power cord is unplugged and the game console is turned off.
2 Connect the video and audio connectors on the component video cable (not provided) to the
COMPONENT/AV Y/VIDEO, PB, and PR video jacks and COMPONENT/AV L and R audio jacks on the back of
your TV and to the component jack(s) on the game console.
Note
• Your game console may require a special component video cable. See
the documentation that came with your game console or check the
manufacturer’s website.
• The COMPONENT/AV Y/VIDEO, PB, and PR video jacks (used to connect
a component video device) share the L and R audio jacks with the
COMPONENT/AV Y/VIDEO jack (used to connect a composite video
device).
• When you connect the audio using the L and R audio jacks, the audio
output is analog.
3 Plug your TV’s power cord into a power outlet, then turn on your TV.
4 Turn on the game console, then set it to the correct output mode. For more information, see the documentation
that came with the console.
5 Press INPUT to open the INPUT SOURCE list.
6 Press S or T to select Component, then press ENTER.
www.sharpusa.com
26
LC-50LB150U Sharp 50" LED TV
Using composite video (good)
Notes
• Cables are often color-coded to match color-coded jacks.
• The yellow video connector on the AV cable connects to the green
COMPONENT/AV Y/VIDEO jack.
On your TV
Game
console
AV cable
connector
Analog audio
cable
connectors
Console-specific AV cable
Composite
video jack
Analog
audio jacks
Back of TV
To connect a game console using composite video:
1 Make sure that your TV’s power cord is unplugged and the game console is turned off.
2 Connect the video and audio connectors on the game console’s AV cable (not provided) to the
COMPONENT/AV Y/VIDEO jack and L and R audio jacks on the back of your TV and to the composite jack(s) on
the game console.
Note
• Most game consoles come with a special AV (composite video) cable.
See the documentation that came with your game console or check the
manufacturer’s Web site.
• The COMPONENT/AV Y/VIDEO, PB, and PR video jacks (used to connect
a component video device) share the L and R audio jacks with the
COMPONENT/AV Y/VIDEO jack (used to connect a composite video
device).
• When you connect the audio using the L and R audio jacks, the audio
output is analog.
3 Plug your TV’s power cord into a power outlet, then turn on your TV.
4 Turn on the game console, then set it to the correct output mode. For more information, see the documentation
that came with the console.
5 Press INPUT to open the INPUT SOURCE list.
6 Press S or T to select AV, then press ENTER.
27
www.sharpusa.com
Sharp 50" LED TV
Connecting a computer
Using VGA (most common)
On your TV
VGA cable
connector
PC IN jack
Audio cable
with stereo
mini plug
VGA cable
Audio cable
with stereo
mini plug
PC/DVI
AUDIO IN
jack
Back of TV
To connect a computer using VGA:
1 Make sure that your TV’s power cord is unplugged and the computer is turned off.
2 Connect a VGA cable (not provided) to the PC IN jack on the back of your TV and to the VGA jack on the
computer.
3 Connect an audio cable with a stereo mini plug (not provided) to the PC/DVI AUDIO IN jack on the back of your
TV and to the AUDIO OUT (headphone) jack on the computer.
4 Plug your TV’s power cord into a power outlet, then turn on your TV and the computer.
5 Press INPUT to open the INPUT SOURCE list.
6 Press S or T to select PC, then press ENTER.
7 Adjust the display properties on the computer, if necessary.
www.sharpusa.com
28
LC-50LB150U Sharp 50" LED TV
Using HDMI (best)
Side of TV
On your TV
HDMI cable
HDMI cable
connector
HDMI jack
To connect a computer using HDMI:
1 Make sure that your TV’s power cord is unplugged and the computer is turned off.
2 Connect an HDMI cable (not provided) to one of the HDMI jacks on the side of your TV and to the HDMI OUT
jack on the computer.
3 Plug your TV’s power cord into a power outlet, then turn on your TV and the computer.
4 Press INPUT to open the INPUT SOURCE list.
5 Press S or T to highlight HDMI 1, HDMI 2, or HDMI 3, then press ENTER.
6 Adjust the display properties on the computer, if necessary.
29
www.sharpusa.com
Sharp 50" LED TV
Using DVI (same as HDMI but requires an audio connection)
Note
You must use the HDMI 3/DVI jack to connect a computer using DVI. If you
use another HDMI jack, you will not hear sound from the TV speakers.
Side of TV
On your TV
HDMI cable
connector
HDMI 3/DVI
jack
HDMI cable
with HDMI-DVI
adapter
Audio cable
with stereo
mini plug
Audio cable
with stereo
mini plug
PC/DVI
AUDIO IN
jack
Back of TV
To connect a computer using DVI:
1 Make sure that your TV’s power cord is unplugged and the computer is turned off.
2 Connect an HDMI-DVI adapter (not provided) to one end of an HDMI cable (not provided), then connect the
adapter to the DVI OUT jack on the computer.
3 Connect the other end of the cable to the HDMI 3/DVI jack on the side of your TV.
4 Connect an audio cable with a stereo mini plug (not provided) to the PC/DVI AUDIO IN jack on the back of your
TV and to the AUDIO OUT (headphone) jack on the computer.
Note
When you connect the audio using the PC/DVI AUDIO IN jack, the audio
output is analog.
5
6
7
8
Plug your TV’s power cord into a power outlet, then turn on your TV and the computer.
Press INPUT to open the INPUT SOURCE list.
Press S or T to select HDMI 3, then press ENTER.
Adjust the display properties on the computer, if necessary.
www.sharpusa.com
30
LC-50LB150U Sharp 50" LED TV
Connecting a USB flash drive
Side of TV
USB flash drive
To connect a USB flash drive:
1 Plug a USB flash drive into the USB port on the side of your TV.
Caution
Do not remove the USB flash drive or turn off the TV while using the USB
flash drive. You may lose data or damage the USB flash drive.
2 If your TV is turned on when you connect the USB flash drive, press S or T to select Yes in the message that
appears, then press ENTER. The PHOTOS menu opens.
OR
If you switch to a different video input source after you plug in the USB flash drive and want to switch back to
the drive, press INPUT to open the INPUT SOURCE list, press S or T to select USB(Photos), then press ENTER.
The PHOTOS menu opens.
Note
The PHOTOS viewer only supports JPEG format images (with “.jpg” file
extensions) and not all JPEG files are compatible with your TV.
For more information, see “Using a USB flash drive” on page 66.
31
www.sharpusa.com
Sharp 50" LED TV
Connecting headphones
When you connect headphones, the TV speakers muted.
Warning
Loud noise can damage your hearing. When using headphones, use the
lowest volume setting on your headphones that still lets you hear the sound.
Side of TV
To connect headphones:
1 Connect the headphones to the /AUDIO OUT jack on the side of your TV.
2 In the screen that opens, press W or X to highlight Headphone, then press ENTER. For more information, see
“Selecting the audio out mode” on page 46.
Notes
• If you connect headphones when your TV is turned off, then you turn on
your TV, the TV speakers are muted and the audio plays through the
headphones.
• You can also connect an amplifier, home theater system, or sound bar to
the /AUDIO OUT jack. If you want to connect an amplifier, home
theater system, or sound bar, you need to disconnect the headphones.
www.sharpusa.com
32
LC-50LB150U Sharp 50" LED TV
Connecting a basic home theater system
Using digital audio
On your TV
Home theater
system
Digital optical
audio cable
connector
Digital optical
audio jack
Digital optical audio cable
To connect a basic home theater system or sound bar using digital audio:
1 Make sure that your TV’s power cord is unplugged and the home theater system or sound bar is turned off.
2 Connect a digital optical audio cable (not provided) to the DIGITAL AUDIO OUTPUT jack on the back of your TV
and to the optical AUDIO IN jack on the digital home theater system or sound bar.
3 Plug your TV’s power cord into a power outlet, then turn on your TV.
4 Turn on the home theater system or sound bar, then set it to the correct source. For more information, see the
documentation that came with the home theater system or sound bar.
5 On your TV, set the Digital Audio Out option on the AUDIO menu to PCM. See “Adjusting sound settings” on
page 45.
33
www.sharpusa.com
Sharp 50" LED TV
Using analog audio
When you connect a home theater system or sound bar to the
/AUDIO OUT jack, the TV speakers are muted.
Side of TV
On your TV
Home theater
system
3.5mm audio
cable connector
/AUDIO OUT
jack
3.5mm audio cable
To connect a home theater system or sound bar using analog audio:
1 Make sure that your TV’s power cord is unplugged and the home theater system or sound bar is turned off.
2 Connect a 3.5mm audio cable (not provided) to the /AUDIO OUT jack on the side of your TV and to the
AUDIO IN jacks on the analog home theater system or sound bar.
3 Plug your TV’s power cord into a power outlet, then turn on your TV.
4 Turn on the home theater system or sound bar, then set it to the correct source. For more information, see the
documentation that came with the home theater system or sound bar.
Notes
• For information about selecting the audio out mode for a home theater
or sound bar, see the Headphones/Audio Out option in “Adjusting
sound settings” on page 45.
• You can connect headphones to the /AUDIO OUT jack. If you want to
use headphones, you need to disconnect the amplifier, home theater
system, or sound bar.
www.sharpusa.com
34
LC-50LB150U Sharp 50" LED TV
Connecting a home theater system with multiple devices
DVD or Blu-ray player
Cable or satellite box
AV receiver
Game console
USB flash drive
Antenna or cable
TV connected
directly to the
wall jack
Computer
The connections you make depend on the video and audio jacks available on your devices. Refer to the
documentation that came with your devices for connection information.
Just remember to use the best connection types available for the best picture and sound. For information about
connection types, see “What connection should I use?” on page 13.
35
www.sharpusa.com
Sharp 50" LED TV
Connecting power
To connect the power:
1 Connect the AC power cord to the AC IN connector on the back of your TV.
2 Connect the other end of the cord to a power outlet.
Caution
• Your TV should only be operated from the power source indicated on
the label.
• Always unplug the AC power cord from the power outlet when you will
not be using your TV for an extended period of time.
www.sharpusa.com
36
LC-50LB150U Sharp 50" LED TV
Using the remote control
Cautions
• Batteries should not be exposed to
excessive heat, such as sunshine, heat
registers, or fire.
• Battery chemicals can cause a rash. If the
batteries leak, clean the battery
compartment with a cloth. If chemicals
touch your skin, wash immediately.
• Make sure that batteries are disposed of
correctly. Do not burn or incinerate.
Installing remote control batteries
To install remote control batteries:
1 While pressing the release latch on the back of
the remote control, lift the battery
compartment cover off of the remote control.
Notes
• Do not mix batteries of different types.
• Do not mix old and new batteries.
• Remove batteries when the charge is
depleted.
• If the remote control is not going to be
used for an extended period of time,
remove the batteries.
Aiming the remote control
2 Insert two AAA batteries into the battery
compartment. Make sure that you match the +
and – symbols on the batteries with the + and –
symbols in the battery compartment.
To aim the remote control:
• Point the remote control towards the remote
sensor on the front of your TV. For the location
of the remote sensor, see “Front” on page 9.
3 Replace the battery compartment cover.
37
www.sharpusa.com
Sharp 50" LED TV
Turning on your TV for the
first time
The first time you turn on your TV, the EZ SETUP
wizard opens. The wizard guides you through
setting up basic settings including the menu
language, time setting, picture mode, TV signal
source, and channel list.
To set up your TV:
1 Make sure that you have:
• Installed the remote control batteries. (See
page 37 for details.)
• Connected an antenna, cable TV, or satellite
TV. (See page 14 through 19 for details.)
• Connected the power cord. (See page 36 for
details.)
2 Press (power) to turn on your TV. The Please
select your language screen opens.
6 Press S or T to highlight Time Zone, then press
X to access the setting.
7 Press S or T to select your time zone. You can
select Eastern, Central, Mountain, Pacific,
Alaska, Hawaii, Atlantic, or Newfoundland,
then press ENTER, MENU, or W.
8 Press S or T to highlight Daylight Saving, then
press X to access the setting.
9 Press S or T to select On (if your viewing area
observes Daylight Saving Time) or Off (if your
viewing area does not observe Daylight Saving
Time), then press ENTER, MENU, or W.
10 If you selected Manual for Mode:
• Press S or T to highlight Year, Month, or Day,
then press X to access the setting. Press S or
T to adjust the setting, then press ENTER.
• Press S or T to highlight Time, then press X to
access the setting. Press W or X to highlight
the hour, minute, or AM/PM field, then press S
or T to adjust the setting. When you are
finished, press ENTER.
11 When you have finished setting the time, press
ENTER. The What is your viewing environment
screen opens.
3 Press S or T to highlight the language you
want, then press ENTER. The time setting screen
opens.
12 Press S or T to highlight Home or Store, then
press ENTER.
If you selected Store mode, a message asks if
you are sure you want this mode. Select Yes to
continue using Store mode or select No to
change your selection, then press ENTER. Store
mode is not an energy savings mode and
displays a retail banner.
The Please select your tuner mode screen opens.
4 Press S or T to highlight Mode, then press X to
access the setting.
5 Press S or T to select Manual (to set the date
and time manually) or Auto (to set the date and
time automatically from a TV signal source
based on the time zone you select), then press
ENTER, MENU, or W.
Note
If you select Auto, the displayed time will
be incorrect until your TV gets the correct
time from a TV signal source.
www.sharpusa.com
38
LC-50LB150U Sharp 50" LED TV
13 Press S or T to highlight Antenna, Cable, or
Satellite Box, then press ENTER.
A If you select Antenna, your TV scans for
available channels. The scan may take
several minutes.
Note
You can press EXIT to stop the auto
channel search, but you will need to run
the auto channel search again to create a
channel list.
B If you select Cable, a message asks if you
have a cable box:
• Select No, then press ENTER if no cable
box is connected. Your TV scans for
available channels. The scan may take
several minutes.
• Select Yes, then press ENTER if a cable box
is connected. A message asks how you
connected the cable box to your TV.
• Select HDMI, Component, or AV, then
press ENTER if you connected a cable
box to your TV using one of these
cables. Read the message, then press
ENTER to close the wizard.
• Select Coaxial, then press ENTER if you
connected a cable box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan
(VHF channels only).
Note
You can press EXIT to stop the auto channel
search, but you will need to run the auto
channel search again to create a channel
list.
39
www.sharpusa.com
Sharp 50" LED TV
C If you select Satellite Box, a message asks
how you connected the satellite box to
your TV:
Understanding the basics
Turning your TV on or off
To turn your TV on or off:
1 Make sure that the power cord is connected to
your TV and a power outlet. See “Connecting
power” on page 36.
2 Press POWER to turn on your TV. The power
indicator turns blue.
3 Press POWER again to turn off your TV. Your
TV enters standby mode, and the power
indicator turns red.
• Select HDMI, Component, or AV, then
press ENTER if you connected a satellite
box to your TV using one of these cables.
Read the message, then press ENTER to
close the wizard.
• Select Coaxial, then press ENTER if you
connected a satellite box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan (VHF
channels only).
Note
You can press EXIT to stop the auto channel
search, but you will need to run the auto
channel search again to create a channel
list.
14 To watch TV, press INPUT, press S or T to
highlight the video input source for your TV in
the INPUT SOURCE list, then press ENTER.
• If your TV is connected to an antenna, cable TV
(no box), or cable or satellite TV box using a
coaxial cable, select TV.
• If your TV is connected to a cable or satellite
box using an HDMI cable or HDMI cable with a
DVI adapter, select HDMI 1, HDMI 3, or
HDMI 2.
• If your TV is connected to a cable or satellite
box using a component video cable, select
Component.
• If your TV is connected to a cable or satellite
box using a composite video cable, select AV.
Warning
When your TV is in standby mode, it is still
receiving power. To completely disconnect
power, unplug the power cord.
Note
If your TV does not receive an input signal
for several minutes, it automatically goes
into standby mode.
Selecting the video input source
To select the video input source:
1 Turn on your TV, then press INPUT. The INPUT
SOURCE list opens.
2 Press S or T to select a video input source, then
press ENTER.
www.sharpusa.com
Note
The INPUT SOURCE list displays
Component when a component video
device is connected or displays AV when a
composite video device is connected.
40
LC-50LB150U Sharp 50" LED TV
On-screen menu overview
SETUP menu (TV mode)
Notes
• Depending on the signal source
selected, you may see different
options on your screen.
• Menu items that are not selectable are
grayed out.
• Menus in this manual are described in
TV mode, unless otherwise indicated.
• The screens shown in this manual are
for explanation purposes and may
vary from the actual screens on your
TV.
PHOTOS menu (USB mode)
PICTURE menu (TV mode)
Navigating the menus
SOUND menu (TV mode)
Press MENU to open the on-screen menu.
Press the right or left arrow to move the cursor
on the screen or to adjust a selected item.
CHANNELS menu (TV mode)
Press the up or down arrow to select menu
options.
Press ENTER to confirm a selection or enter a
sub-menu.
Press MENU to return to the previous menu.
Press EXIT to close the menu.
41
www.sharpusa.com
Sharp 50" LED TV
Selecting a channel
Viewing channel information
To select a channel:
• Press CH
or CH to go to the next or previous
channel on the memorized channel list.
• Press the number buttons to enter the channel
number you want, then wait for the channel to
change or press ENTER to immediately change
the channel.
• To select a digital sub-channel, press the number
buttons to enter the main digital channel, press
(sub-channel), then press the number button
for the sub-channel. Wait for the channel to
change, or press ENTER to immediately change
the channel. For example, to tune to channel 5.1,
press 5, (sub-channel), then 1.
Note
Button presses must be within three
seconds of each other.
To view channel information:
• Press INFO* to view an information banner. The
information banner shows the current program
information such as channel number, video input
source, and resolution.
• Digital channel information—Displays the
channel number, station name, channel label,
broadcast program name, TV rating, signal
type, audio information, resolution, current
time, signal strength, day of the week, date
and current program start and end times, if
provided by the broadcaster.
• Analog channel information—Displays
channel number, channel label, signal type,
audio information, day of the week, date, and
resolution, if provided by the broadcaster.
• Press FLASHBACK to go to the last viewed
channel.
• Press FAVORITE to open the favorite channel list,
press S or T to highlight a channel, then press
ENTER. For information about setting up a
favorite channel list, see “Setting up a favorite
channel list” on page 49.
Note
If a list has more than one page, press S or
T to scroll through the pages.
Adjusting the volume
To adjust the volume:
• Press VOL+ or VOL– to increase or decrease the
volume.
• Press MUTE to turn off the sound.
Press MUTE again to turn the sound back on.
www.sharpusa.com
42
LC-50LB150U Sharp 50" LED TV
Adjusting the picture
• Color—Adjusts the color intensity of the
picture. A low setting may make the color look
faded. A high setting may make the color look
artificial.
• Tint—Adjusts the color balance of the picture.
Use this control to make skin tones look more
natural.
• Sharpness—Adjusts the color detail of
images. If you set this control too high, dark
images may appear with light or white edges.
• Advanced Settings—Opens the
PICTURE · ADVANCED SETTINGS menu where
you can adjust additional video options.
Adjusting the TV picture
You can adjust various settings to improve the
quality of the TV picture. Also, you can reset all
picture settings to the factory default.
To adjust the TV picture:
1 Press MENU. The on-screen menu opens with
the PICTURE menu displayed.
2 Press T or ENTER to access the menu.
3 Press S or T to highlight an option, then press
ENTER to access the option. You can select:
• AV Mode—Selects the picture mode. You can
select:
• Dynamic—(a bright and vivid picture).
Significantly increases the contrast,
brightness, and sharpness. This selection is
good for video games, animation, and in
bright light environments.
• Natural—(a standard picture). Moderately
increases the contrast, brightness, and
sharpness. This selection is good for
standard TV broadcasts.
• Standard—(the backlight brightness is
decreased). Your TV has a backlight that
provides light for displaying a picture. By
reducing the amount of light, your TV uses
less energy.
• Movie—(a finely detailed picture). Adjusts
the brightness and contrast and lowers the
sharpness for a more realistic picture. This
selection is good for watching the highest
quality video such as Blu-ray Discs, DVDs,
and HDTV.
• Game—Adjusts the picture for the
ultimate gaming experience. This option is
available when the video input source is
set the HDMI, Component, AV, or VGA.
• User—(customized picture). Lets you
manually adjust picture settings such as
brightness, contrast, and sharpness.
Note
You can also press AV MODE to select the
picture mode.
• Backlight—Sets the overall brilliance of the
screen.
• Brightness—Adjusts the brightness of the
dark areas of the picture.
• Contrast—Adjusts the brightness of the light
areas of the picture.
43
• View Mode—Adjusts how the picture fills
the screen (aspect ratio). You can select:
Aspect ratio
options
Normal:
Displays the image in the
original aspect ratio. Black
bars appear if the image is
not in the widescreen (16:9)
aspect ratio.
Zoom:
Expands the image to fill
the screen. The top and
bottom of the image may be
cropped.
Example
Wide:
Use this option to view
content recorded in a 16:9
(widescreen) aspect ratio.
Cinema:
Stretches the image at the
edges, but keeps a clear
image in the center.
Auto:
Automatically adjusts the
image based on the screen
size and the TV program.
Note: Auto is only
available when Auto View
Mode in the CHANNELS
menu is set to On.
www.sharpusa.com
Note
You can also press VIEW MODE to select
the aspect ratio.
Sharp 50" LED TV
• Overscan—Extends text and images past
the screen edges to hide edge artifacts.
You can select On or Off.
• Active Backlight—Enhances the contrast
ratio between light and dark areas of the
picture. You can select On or Off.
• Motion Enhancement—Reduces motion
blur and eliminates film judder with clear
detail and smooth motion. You can select
Off, On (Low), On (High), or Film Mode.
• Color Temperature—Selects the color
temperature. You can select Cool (to
enhance the blues), Normal, or Warm (to
enhance the reds).
• Noise Reduction—Selects the noise
reduction mode to reduce picture noise
(snow). You can select Off, Low, Middle, or
High.
• Active Contrast—Automatically adjusts
picture detail and brightness. You can
select On or Off.
• Reset Picture Settings—Resets all picture
settings to factory mode.
4 Press W or X to adjust the option, or press S or
T to select a setting.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Setting the power on picture mode
You can set the picture mode your TV uses when
you turn it on.
To set the power on picture mode:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
3 Press S or T to highlight Reset All, then press
ENTER. The SETUP · RESET ALL menu opens.
4 Press S or T to highlight Power on in Dynamic
Mode, then press ENTER.
5 Press S or T to highlight On (when you turn on
your TV, it will be in Dynamic picture mode) or
Off (when you turn on your TV, it will be in the
picture mode it was in before you turned it off ),
then press ENTER.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
www.sharpusa.com
44
LC-50LB150U Sharp 50" LED TV
Adjusting the computer image
When you connect a computer to your TV using the
PC IN jack, you may need to adjust the computer
image to improve the quality.
Note
The PC option is only available when a
computer is connected to the PC IN jack
on the back of your TV.
To adjust the computer image:
1 Make sure that your TV is in PC mode. For more
information, see “Selecting the video input
source” on page 40.
2 Press MENU. The on-screen menu opens.
3 Press W or X to highlight SETUP, then press
ENTER. The SETUP menu opens.
4 Press S or T to highlight PC, then press ENTER.
The SETUP · PC menu opens.
5 Press S or T to highlight an option, then press
ENTER to access the option. You can select:
• Auto Adjust—Automatically adjusts the
image settings such as position and phase.
• H. Position—Moves the image right or left.
• V. Position—Moves the image up or down.
• Clock—Minimizes vertical stripes in the
screen image.
• Phase—Adjusts the focus of stable images.
• Reset PC Settings—Resets all computer
settings to factory mode.
6 Press W or X to adjust the option, or press S or
T to select a setting.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
45
Adjusting the sound
Adjusting sound settings
You can adjust sound settings to improve the sound
quality. You also can reset all sound settings to the
factory default.
To adjust sound settings:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SOUND, then press T
or ENTER. The SOUND menu opens.
3 Press S or T to highlight an option, then press
ENTER to access the option. You can select:
• Sound Mode—Selects the sound mode. You
can select:
• Standard—Balances treble and bass. This
setting is good for watching standard TV
broadcasts.
• Movie—Enhances treble and bass for a
rich sound experience. This setting is good
for watching DVDs, Blu-ray Discs, and
HDTV.
• Music—Preserves the original sound. This
setting is good for listening to music.
• Voice—Enhances vocals for TV audio. This
setting is good for watching news
broadcasts.
• User—Lets you manually adjust sound
settings.
• Balance—Adjusts the balance between the
left and right audio channels.
• Bass—Adjusts the low sounds.
• Treble—Adjusts the high sounds.
• Speaker—Selects where the TV audio is
played. You can select On (default setting) to
play audio through the TV speakers, or select
Off to turn off the TV speakers and play audio
through a connected sound system.
• Digital Audio Out—Sends digital audio to an
external audio system. You can select:
• Dolby Digital—Outputs the original
digital audio sound.
• PCM—Outputs audio in 2-channel stereo.
• Audio Delay—Fine tunes the audio when
it is not in sync with the video.
www.sharpusa.com
Sharp 50" LED TV
• Analog TV Sound—(Analog channels only)
Selects the audio mode. You can select:
• Mono—Select this option if there is noise
or static on weak stereo broadcasts.
• Stereo—Select this option for programs
broadcast in stereo.
• SAP—Select this option to listen to a
secondary audio program, if available.
Note
You can also press AUDIO one
or more times to select the
audio mode.
• Audio Language—(Digital channels only)
Selects an alternate audio language, if
available.
• Headphones/Audio Out—You can use the
/AUDIO OUT jack on the side of your TV to
connect headphones, an amplifier, a home
theater system, or a sound bar. When a device
is connected to the /AUDIO OUT jack, the
TV speakers are muted. This option selects
where the audio is played. You can select:
• Headphone—Select this option if you
connected headphones.
• Audio Out Fixed—Select this option to
use the remote control that came with the
amplifier, home theater system, or sound
bar you connected to the /AUDIO OUT
jack to control the audio.
• Audio Out Variable—Select this option to
use the remote control that came with
your TV to control the audio from the
amplifier, home theater system, or sound
bar you connected to the /AUDIO OUT
jack.
This option is only available when a device is
connected to the /AUDIO OUT jack.
• Reset Sound Settings—Reset all audio
settings to factory defaults.
4 Press W or X to adjust the option, or press S or
T to select a setting.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Selecting the audio out mode
If your TV is on when you connect a device to the
/AUDIO OUT jack on the side of your TV, a screen
opens where you select which audio out mode you
want to use.
To select the audio out mode:
1 Connect headphones, an amplifier, a home
theater system, or a sound bar to the
/AUDIO OUT jack on the side of your TV. The
following screen opens.
2 Press W or X to highlight the audio out mode
you want to use, then press ENTER. You can
select:
• Headphone—Select this option if you
connected headphones.
• Audio Out Fixed—Select this option to use
the remote control that came with the
amplifier, home theater system, or sound bar
you connected to the /AUDIO OUT jack to
control the audio.
• Audio Out Variable—Select this option to
use the remote control that came with your TV
to control the audio from the amplifier, home
theater system, or sound bar you connected to
the /AUDIO OUT jack.
www.sharpusa.com
46
LC-50LB150U Sharp 50" LED TV
Playing TV audio only
You can turn off the picture on your TV and listen to
the program audio only.
To play TV audio only:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight CHANNELS, then press
T or ENTER. The CHANNELS menu opens.
To automatically scan for channels:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight CHANNELS, then press
T or ENTER. The CHANNELS menu opens.
3 Press S or T to highlight Auto Channel Search,
then press ENTER. The CHANNELS · AUTO
CHANNEL SEARCH screen opens.
3 Press S or T to highlight Audio Only, then
press ENTER.
4 Press S or T to select On.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Notes
• The picture turns off in about five
seconds.
• Audio Only works only when the
input source is TV and your TV is
receiving a broadcast signal.
• To exit audio only mode, press any
button. When you exit audio only
mode, the Audio Only option is
automatically reset to Off.
4 Press S or T to highlight Antenna, Cable, or
Satellite Box, then press ENTER.
A If you select Antenna, your TV scans for
available channels. The scan may take
several minutes.
Changing channel settings
Automatically scanning for channels
When you scan for channels, your TV searches for
channels with signals and stores the channel
information in the channel list. When you press
CH
or CH , your TV goes to the next or
previous channel in the channel list.
If the TV signal source changes, for example you
change from an outdoor antenna to cable TV (no
box), you need to scan for channels.
Note
You can press EXIT to stop the auto
channel search, but you will need to run
the auto channel search again to create a
channel list.
47
www.sharpusa.com
Sharp 50" LED TV
B If you select Cable, a message asks if you
have a cable box:
• Select No, then press ENTER if no cable
box is connected. Your TV scans for
available channels. The scan may take
several minutes.
• Select Yes, then press ENTER if a cable box
is connected. A message asks how you
connected the cable box to your TV.
C If you select Satellite Box, a message asks
how you connected the satellite box to your
TV:
• Select HDMI, Component, or AV, then
press ENTER if you connected a satellite
box to your TV using one of these cables.
Read the message, then press ENTER to
close the wizard.
• Select Coaxial, then press ENTER if you
connected a satellite box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan (VHF
channels only).
Note
You can press EXIT to stop the auto
channel search, but you will need to run
the auto channel search again to create a
channel list.
• Select HDMI, Component, or AV, then
press ENTER if you connected a cable
box to your TV using one of these
cables. Read the message, then press
ENTER to close the wizard.
• Select Coaxial, then press ENTER if you
connected a cable box to your TV using
a coaxial cable. Read the message, then
press ENTER to start the channel scan
(VHF channels only).
Note
You can press EXIT to stop the auto
channel search, but you will need to run
the auto channel search again to create a
channel list.
www.sharpusa.com
48
LC-50LB150U Sharp 50" LED TV
Hiding channels
Setting up a favorite channel list
You can hide channels in the channel list. When you
press CH
or CH , your TV skips the hidden
channels. You can still tune to a hidden channel by
pressing the number buttons for the channel.
You can create a favorite channel list so you can
quickly browse through your favorite channels by
pressing FAVORITE, then selecting a channel from
the favorite channel list.
To hide channels:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight CHANNELS, then press
T or ENTER. The CHANNELS menu opens.
To set up a favorite channel list:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight CHANNELS, then press
T or ENTER. The CHANNELS menu opens.
3 Press S or T to highlight Channel Skip, then
press ENTER. The CHANNELS · CHANNEL SKIP
screen opens.
3 Press S or T to highlight Favorites, then press
ENTER. The CHANNELS · FAVORITES screen
opens.
4 Press S T W or X to highlight the channel you
want to hide, then press ENTER. The check mark
disappears.
4 Press S T W or X to highlight the channel you
want to add to the favorites list, then press
ENTER. A check mark appears next to the
channel.
Notes
• A channel with a check mark is not
hidden. A channel with no check mark
is hidden.
• If the list has more than one page,
press S or T to scroll through the
pages.
Notes
• To remove a channel from the
favorites list, highlight the channel,
then press ENTER. The check mark
disappears and the channel is
removed from the list.
• If the list has more than one page,
press S or T to scroll through the
pages.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Viewing a favorite channel
To view a favorite channel:
1 Press FAVORITE. The favorite channel list opens.
2 Press S or T to highlight a channel, then press
ENTER.
49
www.sharpusa.com
Sharp 50" LED TV
Adding or changing a channel label
Checking the digital signal strength
If a channel is not already labeled, you can label the
channel to make it easier to identify. You can also
relabel a channel that is already labeled.
To add or change a channel label:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight CHANNELS, then press
T or ENTER. The CHANNELS menu opens.
3 Press S or T to highlight Channel Edit, then
press ENTER. The CHANNELS · CHANNEL EDIT
screen opens with the channel number field
highlighted.
You can check the digital signal strength to
determine if you need to adjust your antenna or
digital cable input. The higher the signal strength,
the less likely you are to experience picture
degradation.
To check the digital signal strength:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight CHANNELS, then press
T or ENTER. The CHANNELS menu opens.
3 Press S or T to highlight Signal Strength, then
press ENTER. The Signal Strength screen opens
showing the signal strength meter.
4 Press MENU to return to the previous menu, or
press EXIT to close the menu.
4 Press S or T to select the channel you want to
label, then press X to move to the channel label
field.
5 Press S or T to select a character, then press W
or X to move to the previous or next character
position. Repeat this step to enter additional
characters. You can enter as many as 11
characters.
6 When you have completed the label, press
ENTER.
7 Press EXIT to close the menu.
www.sharpusa.com
50
LC-50LB150U Sharp 50" LED TV
Automatically adjusting the aspect ratio
Auto View Mode automatically changes how the
picture looks on the screen (aspect ratio) based on
the TV program you are viewing.
3 Press S or T to highlight Parental Controls,
then press ENTER. The Enter password screen
opens.
To automatically adjust the aspect ratio:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight CHANNELS, then press
T or ENTER. The CHANNELS menu opens.
4 Press the number buttons to enter the four-digit
password. The default password is 0000. You
should change the password to a number you
can remember. The SETUP · PARENTAL CONTROLS
menu opens.
3 Press S or T to highlight Auto View Mode, then
press ENTER.
4 Press S or T to select On (automatically adjust
the aspect ratio) or Off (does not automatically
adjust the aspect ratio), then press ENTER.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Note
You can also press VIEW MODE to select
the aspect ratio.
5 Press S or T to highlight Change Password,
then press ENTER. The SETUP · PARENTAL
CONTROLS · CHANGE PASSWORD screen opens.
Setting parental controls
Parental controls let you prevent your children from
watching inappropriate material on TV. When set,
parental controls read the rating of the program
(with some exceptions, such as news and sports)
and deny access to programs that exceed the
ratings level you select. To watch programs that
exceed the selected rating, you must enter a
password.
Setting or changing the password
To set or change the password:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
6 Press the number buttons to enter a password,
then enter the password again. A message tells
you that the password has been changed.
Note
If you forget your password, enter 9999.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
51
www.sharpusa.com
Sharp 50" LED TV
Locking control buttons
Blocking unrated TV
When the button block is turned On, the buttons
on the side of your TV are locked, and you can only
operate your TV using the remote control.
To lock control buttons:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
Some TV programs, such as news and sports shows
are not rated. When you set UnRated/Exempt
Ratings to Block, TV programs that do not have
ratings are blocked. When you try to watch a
blocked program, you are prompted to enter the
parental controls password.
To block unrated TV:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
3 Press S or T to highlight Parental Controls,
then press ENTER. The Enter password screen
opens.
3 Press S or T to highlight Parental Controls,
then press ENTER. The Enter password screen
opens.
4 Press the number buttons to enter the four-digit
password. The SETUP · PARENTAL CONTROLS
menu opens.
4 Press the number buttons to enter the four-digit
password. The SETUP · PARENTAL CONTROLS
menu opens.
5 Press S or T to highlight Button Block, then
press ENTER.
6 Press S or T to select On (locks the buttons) or
Off (unlocks the buttons).
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
5 Press S or T to highlight UnRated/Exempt
Ratings, then press ENTER.
6 Press S or T to select Block (to block unrated
TV) or View (to unblock unrated TV).
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
www.sharpusa.com
52
LC-50LB150U Sharp 50" LED TV
Setting parental control levels
Canadian French ratings
E
Exempt programming
G
General audiences
8ans+
Suitable for children 8 and older
13ans+
Suitable for children 13 and older
16ans+
Suitable for children 16 and older
18ans+
Adult only
You can set parental controls for the U.S. and
Canada.
U.S. rating levels
U.S. TV ratings
NONE
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Not rated
All children
Suitable for children 7 and older
General audiences
Parental guidance suggested
Parental guidance strongly
suggested
Mature audiences only
To set parental control levels:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
Some of the age-based TV Parental Guidelines
ratings also have content-based ratings.
U.S. TV content ratings
All
All ratings are blocked
FV
Fantasy violence
L
Strong language
S
Sexual situations
V
Violence
D
Suggestive dialog
3 Press S or T to highlight Parental Controls,
then press ENTER. The Enter password screen
opens.
U.S. movie (MPAA) ratings
None
Movie not rated
G
General audiences
PG
Parental guidance suggested
PG-13
Suitable for children 13 and older
R
Parental guidance suggested for
children under 17
NC-17
Not suitable for children under 17
X
Adults only
Canadian rating levels
Canadian English ratings
E
Exempt programming
C
Suitable for all children
C8+
Suitable for children 8 and older
G
General audiences
PG
Parental guidance suggested
14+
Suitable for children 14 and older
18+
Adult only
53
4 Press the number buttons to enter the four-digit
password. The SETUP · PARENTAL CONTROLS
menu opens.
www.sharpusa.com
Sharp 50" LED TV
5 Press S or T to highlight U.S. V-CHIP, then press
ENTER. (To set Canadian ratings, select
Canada V-CHIP.)
U.S. V-CHIP
Downloading rating information
If the program you are viewing has downloadable
rating information, you can download the
information to use when setting parental controls.
Note
If the program you are viewing does not
have V-Chip rating information,
Open V-CHIP is grayed on the
SETUP · PARENTAL CONTROLS menu and
cannot be selected.
To download rating information:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
Canada V-CHIP
6 Press W or X to highlight:
• Movie Ratings or TV Ratings for USA ratings.
• Canadian English or Canadian French for
Canadian ratings.
7 Press S or T to select the rating. If a rating has
sub-ratings, press W or X to highlight a
sub-rating.
3 Press S or T to highlight Parental Controls,
then press ENTER. The Enter password screen
opens.
Note
When you block a rating, that rating and
all higher ratings are blocked.
8 Press ENTER to confirm. A lock symbol appears
when a rating is blocked.
9 Press MENU to return to the previous menu, or
press EXIT to close the menu.
4 Press the number buttons to enter the four-digit
password. The SETUP · PARENTAL CONTROLS
menu opens.
www.sharpusa.com
54
LC-50LB150U Sharp 50" LED TV
5 Press S or T to highlight Open V-CHIP, then
press ENTER. The SETUP · PARENTAL
CONTROLS · OPEN V-CHIP screen opens. The
screen that you see may vary depending on the
broadcaster.
Using closed captioning
Closed captioning displays a text version of the TV
program audio or displays information provided by
the broadcaster.
Turning closed captioning on or off
To turn closed captioning on or off:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
6 Press S T W or X to select the program and
content types you want to block, then press
ENTER. The SETUP · PARENTAL CONTROLS menu
opens.
3 Press S or T to highlight Closed Caption, then
press ENTER. The SETUP · CLOSED CAPTION
menu opens.
7 To reset the V-Chip information to the factory
default, press S or T to highlight
Reset Downloadable Data, then press ENTER.
A box opens.
8 Press S or T to highlight OK or Cancel, then
press ENTER.
9 Press MENU to return to the previous menu, or
press EXIT to close the menu.
4 Press S or T to highlight CC Settings, then
press ENTER. A menu opens.
5 Press S or T to select Off (turns off closed
captioning), On Always (turns on closed
captioning), or On When Mute (turns on closed
captioning when the sound is muted).
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Note
You can also press CC to turn closed
captioning on or off.
55
www.sharpusa.com
Sharp 50" LED TV
Selecting the analog closed captioning mode
Selecting the digital closed captioning mode
Analog channels usually have one or more closed
captioning modes. The CC1 mode usually displays a
text version of the TV program audio in a small
banner. The other CC modes display information
provided by the broadcaster. The Text modes
display information in a box that covers half of the
screen.
Digital channels usually have one or more closed
captioning modes. The Service1 and CC1 modes
usually display a text version of the TV program
audio in a small banner. The other Service and CC
modes display information provided by the
broadcaster. Services1 mode displays a text version
of the audio in the same language as the audio.
To select the analog closed captioning mode:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
To select the digital closed captioning mode:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
3 Press S or T to highlight Closed Caption, then
press ENTER. The SETUP · CLOSED CAPTION
menu opens.
3 Press S or T to highlight Closed Caption, then
press ENTER. The SETUP · CLOSED CAPTION
menu opens.
4 Press S or T to highlight Analog CC Type, then
press ENTER. A menu opens.
5 Press S or T to select an analog caption setting.
You can select:
• CC1 through CC4—Closed captioning
appears in a small banner across the bottom
of the screen. CC1 is usually the “printed”
version of the audio. CC2 through CC4 display
content provided by the broadcaster.
• Text1 through Text4—Closed captioning
covers half or all of the screen. Text1 through
Text4 display content provided by the
broadcaster.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
4 Press S or T to highlight Digital CC Type, then
press ENTER. A menu opens.
5 Press S or T to select a digital caption setting.
You can select:
• Service1 through Service6—Service1 is
usually the “printed” version of the audio.
Service2 through Service6 display content
provided by the broadcaster. You can change
the way digital closed captioning is displayed
on the screen. For more information, see
“Customizing digital closed captioning
settings” on page 57.
• CC1 through CC4—Closed captioning
appears in a small banner across the bottom
of the screen. CC1 is usually the “printed”
version of the audio. CC2 through CC4 display
content provided by the broadcaster.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
www.sharpusa.com
56
LC-50LB150U Sharp 50" LED TV
Customizing digital closed captioning
settings
To customize digital closed captioning styles:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
3 Press S or T to highlight Closed Caption, then
press ENTER. The SETUP · CLOSED CAPTION
menu opens.
5 Press ENTER, then press S or T to select
Custom.
6 Press S or T to highlight an option, then press
ENTER. You can select:
• Digital CC Size—Selects the font size.
• Digital CC Font—Selects the font style.
• Digital CC Color—Selects the color for the
words.
• Digital CC Opacity—Selects the opacity level
for the words.
• Digital CC Background Color—Selects the
color for the background.
• Digital CC Background Opacity—Selects the
opacity level for the background.
• Digital CC Edge Effect—Selects the style of
the letter edges.
• Digital CC Edge Color—Selects the color of
the letter edges.
7 Press S or T to select a setting, then press
ENTER.
8 Press MENU to return to the previous menu, or
press EXIT to close the menu.
4 Press S or T to highlight Digital CC Style, then
press ENTER. The SETUP · CLOSED
CAPTION · DIGITAL CC Style menu opens with
Caption Style highlighted.
57
www.sharpusa.com
Sharp 50" LED TV
Adjusting time settings
When you set up your TV for the first time, the clock
was set up. If the power is disconnected or you
move your TV to a different time zone, you need to
reset the clock to the correct time.
Setting the clock
To set the clock:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
7 Press S or T to highlight Time Zone, then press
ENTER.
8 Press S or T to select your time zone, then press
ENTER. You can select Eastern, Central,
Mountain, Pacific, Alaska, Hawaii, Atlantic, or
Newfoundland.
9 If your viewing area observes Daylight Saving
Time, press S or T to highlight
Daylight Saving, then press ENTER.
10 Press S or T to select On or Off, then press
ENTER to close the menu.
11 If you selected Manual for Mode:
• Press S or T to highlight Year, Month, or Day,
then press X to access the setting. Press S or
T to adjust the setting, then press ENTER.
• Press S or T to highlight Time, then press X to
access the setting. Press W or X to highlight
the hour, minute, or AM/PM field, then press S
or T to adjust the setting. When you are
finished, press ENTER.
12 Press MENU to return to the previous menu, or
press EXIT to close the menu.
3 Press S or T to highlight Time Setup, then
press ENTER. The SETUP · TIME SETUP menu
opens.
4 Press S or T to highlight Date/Time, then press
ENTER. The SETUP · TIME SETUP · DATE/TIME
menu opens.
5 Press S or T to highlight Mode, then press
ENTER. A menu opens.
6 Press S or T to highlight Manual (to set the
options manually) or Auto (the options are
automatically set by the TV signal source), then
press ENTER.
www.sharpusa.com
58
LC-50LB150U Sharp 50" LED TV
Setting the sleep timer
You can specify the amount of time before your TV
automatically turns off.
To set the sleep timer:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
Adjusting menu settings
Selecting the menu language
Your TV can display the on-screen menu in English,
French, or Spanish. When you set your TV up for the
first time, the language was selected. You can
change the menu language to a different language.
To select the menu language:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
3 Press S or T to highlight Time Setup, then
press ENTER. The SETUP · TIME SETUP menu
opens.
3 Press S or T to highlight Language, then press
ENTER. A menu opens.
4 Press S or T to highlight a language, then press
ENTER. You can select English, Français, or
Español.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Turning Input Sensor on or off
4 Press S or T to highlight Sleep Timer, then
press ENTER. A menu opens.
5 Press S or T to select the amount of time before
your TV turns off automatically. You can select
Off, 5 minutes, 10 minutes, 15 minutes,
30 minutes, 60 minutes, 90 minutes, 120
minutes, 180 minutes, or 240 minutes.
To turn off the sleep timer, select Off.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
When the Input Sensor feature is turned on, your TV
automatically detects which video jacks have
devices connected to them. Your TV uses this
information to determine what options you can
select on the INPUT SOURCE list when you press
INPUT.
To turn Input Sensor on or off:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
Note
You can also press SLEEP to set the sleep
timer.
3 Press S or T to highlight Auto Input Sensing,
then press ENTER. A menu opens.
4 Press S or T to select On (turns on the input
sensor) or Off (turns off the input sensor).
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
59
www.sharpusa.com
Sharp 50" LED TV
Labeling an input source
You can add a label to an input source to make it
easier to identify in the INPUT SOURCE list.
To label an input source:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
Using CEC Control
CEC Control lets you control HDMI CEC-compatible
devices connected to the HDMI jacks on your TV
using the remote control that came with your TV. To
use CEC Control, you must set the CEC Control
setting on the SETUP · CEC menu to On.
Notes
• HDMI cables must be used to connect
HDMI CEC-compatible devices to your
TV.
• The connected device’s HDMI CEC
feature must be turned on.
• If you connect an HDMI device that is
not HDMI CEC-compatible, all of the
CEC features do not work.
• Depending on the connected HDMI
device, the CEC feature may not work.
Turning CEC Control on or off
3 Press S or T to highlight Input Labels, then
press ENTER. The SETUP · INPUT LABELS screen
opens with the input source field highlighted.
To turn CEC Control on or off:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
4 Press S or T to select the input source you want
to label, then press X to move to the label field.
3 Press S or T to highlight CEC, then press
ENTER. The SETUP · CEC menu opens.
5 Press S or T to select a character, then press
W or X to move to the previous or next character
position. Repeat this step to enter additional
characters.
6 When you have completed the label, press
ENTER to save your label and return to the
previous menu. The next time you press INPUT,
your label appears in the INPUT SOURCE list.
7 Press EXIT to close the menu.
4 Press S or T to highlight CEC Control, then
press ENTER.
5 Press S or T to highlight On or Off, then press
ENTER.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
www.sharpusa.com
60
LC-50LB150U Sharp 50" LED TV
Turning Device Auto Power Off on or off
61
Turning TV Auto Power On on or off
When CEC Control is set to On, Device Auto Power
Off automatically turns off HDMI CEC devices when
you turn off your TV.
TV Auto Power On automatically turns on your TV
when an HDMI CEC device is turned on, if the
device has this feature.
To turn Device Auto Power Off on or off:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
To turn TV Auto Power On on or off:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
3 Press S or T to highlight CEC, then press
ENTER. The SETUP · CEC menu opens.
3 Press S or T to highlight CEC, then press
ENTER. The SETUP · CEC menu opens.
4 Make sure that the CEC Control option is turned
on. See “Turning CEC Control on or off” on
page 60.
5 On the SETUP · CEC menu, press S or T to
highlight Device Auto Power Off, then press
ENTER.
6 Press S or T to highlight On (turns off the
connected devices when you turn off your TV)
or Off (does not turn off the connected devices
when you turn off your TV), then press ENTER.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
4 Make sure that the CEC Control option is turned
on. See “Turning CEC Control on or off” on
page 60.
5 On the SETUP · CEC menu, press S or T to
highlight TV Auto Power On, then press
ENTER.
6 Press S or T to highlight On (turns on your TV
when you turn on the connected device) or Off
(does not turn on your TV when you turn on the
connected device), then press ENTER.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
www.sharpusa.com
Sharp 50" LED TV
Turning Audio Return Channel on or off
Displaying a list of CEC-compatible devices
When CEC Control is turned on and you have
connected an audio receiver to your TV, turning on
Audio Return Channel lets you use your TV’s
remote control to control the volume on the audio
receiver.
To turn Audio Return Channel on or off:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
You can display a list of HDMI CEC devices that are
connected to your TV.
To display a list of CEC-compatible devices:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
3 Press S or T to highlight CEC, then press
ENTER. The SETUP · CEC menu opens.
3 Press S or T to highlight CEC, then press
ENTER. The SETUP · CEC menu opens.
4 Make sure that the CEC Control option is turned
on. See “Turning CEC Control on or off” on
page 60.
5 On the SETUP · CEC menu, press S or T to
highlight Audio Return Channel, then press
ENTER.
6 Press S or T to highlight On (your TV’s remote
control controls the connected audio receiver’s
volume) or Off (your TV’s remote control does
not control the connected audio receiver’s
volume), then press ENTER.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
4 Make sure that the CEC Control option is turned
on. See “Turning CEC Control on or off” on
page 60.
5 On the SETUP · CEC menu, press S or T to
highlight CEC Device Lists, then press ENTER. A
list of the HDMI CEC-compatible devices you
have connected appears.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
www.sharpusa.com
62
LC-50LB150U Sharp 50" LED TV
Waking CEC-compatible devices
When a connected CEC-compatible device is in
turned off (standby mode), Connect wakes (turns
on) the device.
To wake CEC-compatible devices:
1 Press INPUT, press S or T to highlight the
CEC-compatible device you want to wake, then
press ENTER.
2 Press MENU. The on-screen menu opens.
3 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
4 Press S or T to highlight CEC, then press
ENTER. The SETUP · CEC menu opens.
You can open a CEC-compatible device’s root menu,
then use your TV’s remote control to control the
device, if the device has this feature.
To open a CEC-compatible device’s root menu:
1 Press INPUT, press S or T to highlight the
CEC-compatible device you want to control,
then press ENTER.
2 Press MENU. The on-screen menu opens.
3 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
4 Press S or T to highlight CEC, then press
ENTER. The SETUP · CEC menu opens.
5 Make sure that the CEC Control option is turned
on. See “Turning CEC Control on or off” on
page 60.
6 On the SETUP · CEC menu, press S or T to
highlight Connect, then press ENTER to wake
the HDMI CEC-compatible device connected to
the HDMI input you selected.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
63
Opening a CEC-compatible device’s root
menu
5 Make sure that the CEC Control option is turned
on. See “Turning CEC Control on or off” on
page 60.
6 On the SETUP · CEC menu, press S or T to
highlight Root Menu, then press ENTER. The
device’s root menu opens, and you can use your
TV’s remote control to control the device.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
www.sharpusa.com
Sharp 50" LED TV
Using an MHL-enabled
device or Roku Streaming
Stick
To switch to an MHL-device that is already
connected:
1 Press INPUT, then press S or T to select
HDMI 2 (MHL/ACC).
You can connect your MHL-enabled device, such as
a cell phone or Roku Streaming Stick™, and view
your device’s screen on your TV.
Using an MHL-enabled device
To use an MHL-enabled device:
1 Connect an MHL-enabled device to your TV. For
connection instructions, see “Connecting an
MHL-enabled device” on page 24. A message
tells you the device is connected.
2 Press ENTER to access your MHL-enabled
device. Your device’s menu opens.
OR
Press MENU, then press W or X to highlight
MHL/ACC.
Note
Your device’s menu will vary depending on
the device and the apps you have loaded
on the device.
2 Press ENTER to access your MHL-enabled
device. Your device’s menu opens.
Note
Your device’s menu will vary depending on
the device and the apps you have loaded
on the device.
3 Use S T W X and ENTER to navigate on your
device.
Note
The buttons you use to navigate on your
device may vary depending on the device.
3 Use S T W X and ENTER to navigate on your
device.
Note
The buttons you use to navigate on your
device may vary depending on the device.
www.sharpusa.com
64
LC-50LB150U Sharp 50" LED TV
Using a Roku Streaming Stick
To use a Roku Streaming Stick:
1 Connect a Roku Streaming Stick™ to your TV. For
connection instructions, see “Connecting an
MHL-enabled device” on page 24. A message
tells you the stick is connected.
2 Press ENTER to access your Roku Streaming
Stick™. Your stick’s menu opens.
To switch to a Roku Streaming Stick that is
already connected:
1 Press INPUT, then press S or T to select
HDMI 2 (Roku).
Note
Your Roku Streaming Stick’s menu will
vary depending on the content you have
loaded on the device.
OR
Press MENU, then press W or X to highlight
Streaming.
3 Use S T W X and ENTER to navigate on your
Roku Streaming Stick™.
2 Press ENTER to access your Roku Streaming
Stick™. Your stick’s menu opens.
Note
Your Roku Streaming Stick’s menu will
vary depending on the content you have
loaded on the device.
3 Use S T W X and ENTER to navigate on your
Roku Streaming Stick™.
65
www.sharpusa.com
Sharp 50" LED TV
Using a USB flash drive
You can connect a USB flash drive to your TV to
view compatible JPEG pictures.
Notes
• Never remove the USB flash drive or
turn off your TV while viewing JPEG
pictures.
• The JPEG picture viewer only supports
JPEG format images (with “.jpg” file
extensions) and not all JPEG files are
compatible with your TV.
2 Press S or T to highlight Browse Photos, then
press ENTER. The screen displays folder names
and photo files stored on the USB flash drive in a
thumbnail index with the first photo or folder
highlighted. A control bar appears at the
bottom of the screen.
Note
Photos are shown in the order they appear
on the USB flash drive. They may not be
listed in file name order.
Switching to USB mode
To switch to USB mode:
1 Make sure that you have connected the USB
flash drive to the USB port on your TV.
2 If your TV is turned on when you connect the
USB flash drive, press S or T to highlight Yes in
the message that appears, then press ENTER.
The PHOTOS menu opens.
OR
If you connected the USB flash drive, then
changed to a different video input source, press
INPUT to open the INPUT SOURCE list, press S or
T to highlight USB (Photos), then press ENTER.
The PHOTOS menu opens.
Note
To exit USB mode, press INPUT to open
the INPUT SOURCE list, then select another
input source.
Browsing photos
To browse photos:
1 Switch to USB mode. See “Switching to USB
mode” on page 66. The PHOTOS menu opens.
3 To navigate the thumbnail index screen, press:
• S T W or X to browse through the files and
folders.
• ENTER to view a highlighted photo full-screen
or open a highlighted folder.
• MENU to open the PHOTOS menu.
• FAVORITE to add or remove a photo from the
favorite photo list. A heart appears on a photo
that has been added to the favorite photo list.
When a photo is displayed full-screen, a control
bar appears at the bottom of the photo. The file
name, picture resolution, size, and date are
displayed on the bottom of the control bar. If
you do not press a button within 10 seconds,
the control bar closes. Press INFO* to open the
control bar again.
4 To navigate on the photo screen, press:
• W to go to the previous photo.
• X to go to the next photo.
• ENTER to rotate the photo clockwise.
• VIEW MODE one or more times to enlarge the
image by ×2 or ×4 or to select Fill (to fill the
screen). You can press S T W or X to pan the
photo.
• EXIT to return to the thumbnail index.
• MENU to return to the PHOTOS menu.
www.sharpusa.com
66
LC-50LB150U Sharp 50" LED TV
Viewing favorite photos
Viewing photos in a slideshow
After you create your favorite photo list, you can
browse among your favorite photos quickly.
To view favorite photos:
1 Switch to USB mode. See “Switching to USB
mode” on page 66. The PHOTOS menu opens.
You can view your photos in a slideshow.
To view photos in a slideshow:
1 Switch to USB mode. See “Switching to USB
mode” on page 66. The PHOTOS menu opens.
2 If the photos you want to view are in a folder on
the USB flash drive, select the folder. For
information about selecting a folder, see
“Browsing photos” on page 66 or “Viewing
favorite photos” on page 67.
3 Press MENU. The PHOTOS menu opens again.
2 Press S or T to highlight Favorite Photos, then
press ENTER. A thumbnail index of your favorite
photos opens with a control bar at the bottom
of the screen. A heart appears on a favorite
photo.
Note
Photos are shown in the order they appear
on the USB flash drive. They may not be
listed in file name order.
4 Press S or T to highlight View Slideshow, then
press ENTER. A slideshow starts with the first
photo in the current folder.
5 To control the slideshow, press:
• ENTER to pause or start the slideshow.
• EXIT to exit the slideshow and go to the
PHOTOS menu.
• MENU to go to the PHOTOS menu.
You select photos and navigate on the photo
screen in the same way you do when you are
browsing through photos. For more
information, see “Browsing photos” on page 66.
67
www.sharpusa.com
Sharp 50" LED TV
Customizing slideshow settings
You can customize the slideshow settings,
including Slideshow Repeat, Slideshow Shuffle,
Slideshow Interval, and Slideshow Effect.
To customize slideshow settings:
1 Switch to USB mode. See “Switching to USB
mode” on page 66. The PHOTOS menu opens.
Maintaining
• Do not use your TV in areas that are too hot or too
cold, because the cabinet may warp or the screen
may malfunction. Your TV works best in
temperatures that are comfortable to you.
• Storage temperatures are 32° to 122°F (0° to 50°C).
• Working temperatures are 41° to 104°F
(5° to 40°C).
• Do not place your TV in direct sunlight or near a
heat source.
Cleaning the TV cabinet
Clean the cabinet with a soft, lint-free cloth. If the
cabinet is especially dirty, moisten a soft, lint-free
cloth in a weak detergent solution, squeeze the
excess moisture from the cloth, then wipe the
cabinet with the cloth. Use a clean cloth to dry the
cabinet.
Cleaning the TV screen
2 Press S or T to highlight Photo Settings, then
press ENTER. The PHOTOS · PHOTOS SETTINGS
menu opens.
Clean the screen with a soft, lint-free cloth.
3 Press S or T to highlight an option, then press
ENTER. You can select:
• Slideshow Repeat—Repeats the slideshow
when it reaches the end. You can select On or
Off.
• Slideshow Shuffle—Displays the slideshow
photos in random order. You can select On or
Off.
• Slideshow Interval—Sets the amount of time
a photo is displayed before the slideshow
moves to the next photo. You can select 4 sec,
6 sec, or 8 sec.
• Slideshow Effect—Selects the way photos
transition when moving to the next file in the
slideshow. You can select:
• None—No transition effect.
• Fade to Black—Fades the screen to black
between photos.
• Vertical Wipe—Wipes the screen from top
to bottom between photos.
• Horizontal Wipe—Wipes the screen from
left to right between photos.
• Random—Randomly selects a transition
effect.
4 Press S or T to select a setting, then press
ENTER.
5 Press EXIT to close the menu.
www.sharpusa.com
68
LC-50LB150U Sharp 50" LED TV
Troubleshooting
Viewing system information
You may need to view system information during
troubleshooting.
Warning
Do not try to repair your TV yourself.
Contact authorized service personnel.
To view system information:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
Restoring settings to the defaults
When you restore default settings, all the settings
you have customized (including parental controls)
are reset.
To restore settings to the defaults:
1 Press MENU. The on-screen menu opens.
2 Press W or X to highlight SETUP, then press T or
ENTER. The SETUP menu opens.
3 Press S or T to highlight System Information,
then press ENTER. Information about the TV
software version is displayed.
4 Press MENU to return to the previous menu, or
press EXIT to close the menu.
3 Press S or T to highlight Reset All, then press
ENTER. The SETUP · RESET ALL menu opens.
4 Press S or T to highlight Reset All, then press
ENTER. A message asks if you want to reset all
TV settings to the default settings.
5 Press S or T to select OK (to reset) or Cancel (to
not reset), then press ENTER.
If you select OK, the EZ SETUP wizard opens.
6 Go through the EZ SETUP wizard. For more
information, see “Turning on your TV for the first
time” on page 38.
69
www.sharpusa.com
Sharp 50" LED TV
Video and audio
Problem
Problem
Solution
Picture does not
fill the screen.
There are black
bars around the
picture.
• Change the aspect ratio. An
increasing amount of digital TV
and movies are presented in
wide screen (16:9). See View
Mode option in “Adjusting the
TV picture” on page 43.
No picture (screen
is not lit) and no
sound.
• Press on the TV or the
remote control.
• Make sure that the Audio Only
option is set to Off. See “Playing
TV audio only” on page 47.
• Make sure that the video cables
are connected securely to your
TV.
• Adjust the contrast and
brightness. See “Adjusting the
TV picture” on page 43.
• Make sure that the power cord
is plugged in.
• Make sure that the correct
video input source is selected.
See “Selecting the video input
source” on page 40.
• Try another channel. The station
may be experiencing problems.
• Make sure that the incoming
signal is compatible.
• Make sure that the antenna or
cable TV is connected correctly
and securely. See “Connecting a
cable or satellite box” on
page 14 or “Connecting an
antenna or cable TV (no box)”
on page 19.
• Check the closed caption
settings. Some TEXT modes can
block the screen.
Solution
Dark, poor, or no
picture (screen is
lit), but sound is
good.
• Try another channel. The station
may be experiencing problems.
• Make sure that the antenna or
cable TV is connected correctly
and securely. See “Connecting a
cable or satellite box” on
page 14 or “Connecting an
antenna or cable TV (no box)”
on page 19.
• Adjust the brightness. See
“Adjusting the TV picture” on
page 43.
• Make sure that the correct
picture mode is selected. See
“Adjusting the TV picture” on
page 43.
• If you are using an antenna, the
digital channel signal may be
low. To check the digital
channel signal strength, see
“Checking the digital signal
strength” on page 50.
• If you are using an antenna and
the signal strength is low, adjust
the antenna or use a highly
directional outdoor antenna or
set-top antenna with a built-in
amplifier.
• Make sure that the video cables
are connected securely to your
TV.
• The video cable(s) you are using
may be bad. Try a new set.
• Try another channel. The station
may be experiencing problems.
No color, dark
picture, or color is
not correct.
• Try another channel. The station
may be experiencing problems.
• Adjust the color settings. See
“Adjusting the TV picture” on
page 43.
• Make sure that the video cables
are connected correctly and
securely to your TV.
• Make sure that the antenna or
cable TV is connected correctly
and securely. See “Connecting a
cable or satellite box” on
page 14 or “Connecting an
antenna or cable TV (no box)”
on page 19.
• If you are using an antenna, the
digital channel signal may be
low. To check the digital
channel signal strength, see
“Checking the digital signal
strength” on page 50.
• If you are using an antenna and
the signal strength is low, adjust
the antenna or use a highly
directional outdoor antenna or
set-top antenna with a built-in
amplifier.
www.sharpusa.com
70
LC-50LB150U Sharp 50" LED TV
Problem
Solution
Problem
Only snow (noise)
appears on the
screen.
• Try another channel. The station
may be experiencing problems.
• Make sure that the antenna or
cable TV is connected correctly
and securely. See “Connecting a
cable or satellite box” on
page 14 or “Connecting an
antenna or cable TV (no box)”
on page 19.
• If you are using an antenna, the
digital channel signal may be
low. To check the digital
channel signal strength, see
“Checking the digital signal
strength” on page 50.
• If you are using an antenna and
the signal strength is low, adjust
the antenna or use a highly
directional outdoor antenna or
set-top antenna with a built-in
amplifier.
Picture quality is
good on some
channels and poor
on others. Sound
is good.
• The problem may be caused by
a poor or weak signal from the
broadcaster or cable TV
provider.
• If you connect to cable or
satellite TV without a set-top
box and experience poor
picture quality, you may need
to install a set-top box to
improve signal reception and
picture quality. Contact your
cable or satellite TV provider
about upgrading to a set-top
box.
71
Solution
Dotted lines or
stripes appear on
the screen.
• Make sure that the antenna or
cable TV is connected correctly
and securely. See “Connecting a
cable or satellite box” on
page 14 or “Connecting an
antenna or cable TV (no box)”
on page 19.
• If you are using an antenna, the
digital channel signal may be
low. To check the digital
channel signal strength, see
“Checking the digital signal
strength” on page 50.
• If you are using an antenna and
the signal strength is low, adjust
the antenna or use a highly
directional outdoor antenna or
set-top antenna with a built-in
amplifier.
• Make sure that the video cables
are connected securely to your
TV.
• The video cable(s) you are using
may be bad. Try a new set.
• Other devices (for example, a
surround sound receiver,
external speakers, fans, or hair
dryers) may be interfering with
your TV. Try turning off one
device at a time to determine
which device is causing
interference. After you have
determined which device is
causing interference, move it
further from the TV to eliminate
the interference.
Double images.
• Use a highly directional outdoor
antenna, cable TV, or satellite
TV.
The picture has a
few bright or dark
spots.
• A few bright or dark spots on an
LCD screen is normal. It does
not affect the operation of
your TV.
www.sharpusa.com
Sharp 50" LED TV
Problem
Good picture, but
no sound.
Solution
Problem
• Increase the volume.
• Make sure that the sound is not
muted.
• Make sure that you do not have
headphones connected. When
headphones are connected, no
sound comes from the TV
speakers.
• Make sure that the correct
audio mode is selected.
• Make sure that the audio cables
are connected correctly and
securely to your TV.
• Make sure that the antenna or
cable TV is connected correctly
and securely. See “Connecting a
cable or satellite box” on
page 14 or “Connecting an
antenna or cable TV (no box)”
on page 19.
• If you are using an antenna, the
digital channel signal may be
low. To check the digital
channel signal strength, see
“Checking the digital signal
strength” on page 50.
• The audio cable(s) you are using
may be bad. Try a new set.
Poor picture.
• Make sure that the room is not
too bright. Light reflecting off
the screen can make the picture
difficult to see.
• If an S-VHS camera or a
camcorder is connected while
another connected device is
turned on, the picture may be
poor. Turn off one or more
devices.
Good sound, but
poor color.
• Adjust the contrast, color, and
brightness settings. See
“Adjusting the TV picture” on
page 43.
Audio noise.
• Other devices (for example, a
surround sound receiver,
external speakers, fans, or hair
dryers) may be interfering with
your TV. Try turning off one
device at a time to determine
which device is causing
interference. After you have
determined which device is
causing interference, move it
further from the TV to eliminate
the interference.
Solution
No output from
one of the
speakers.
• Adjust the audio balance. See
“Adjusting sound settings” on
page 45.
• Make sure that the audio cables
are connected correctly and
securely to your TV.
After images
appear.
• Do not display a still image,
such as a logo, game, or
computer image, for an
extended period of time. This
can cause a permanent
after-image to be burned into
the screen. This type of damage
is not covered by your warranty.
Remote control
Problem
Remote
control does
not work.
Solution
• Make sure that the power cord is
correctly connected to your TV
and a power outlet.
• Make sure that there are no
obstructions between the remote
control and the remote control
sensor on the front of the TV.
• Point the remote control directly
at the remote control sensor on
your TV. For the location of the
remote control sensor, see “Front”
on page 9.
• The supplied batteries are
wrapped tightly in clear plastic.
Make sure that you have removed
this plastic from the batteries.
• Make sure that the batteries are
installed correctly. See “Installing
remote control batteries” on
page 37.
• Replace dead batteries with new
batteries. See “Installing remote
control batteries” on page 37.
General
Problem
No power.
www.sharpusa.com
Solution
• Make sure that the power cord
is correctly connected to your
TV and a power outlet.
• Unplug the power cord, wait 60
seconds, then plug the cord
back in and turn on your TV.
• Other devices (for example, a
surround sound receiver,
external speakers, fans, or hair
dryers) may be interfering with
your TV. Try turning off one
device at a time to determine
which device is causing
interference. After you have
determined which device is
causing interference, move it
further from the TV to eliminate
the interference.
72
LC-50LB150U Sharp 50" LED TV
Problem
“No signal”
error message is
displayed.
After Auto
Channel Search,
there are no
channels.
One or more
channels do not
display.
Solution
Problem
• Press INPUT and make sure that
you have selected the correct
input for the device or service
you are trying to use.
• If you are using a cable or
satellite box, use the remote
that came with that box to
change channels.
• Make sure that you have the
correct input selected to view
channels from the cable or
satellite box.
• Reception can vary by channel
depending on the broadcast
power level of a given station.
Contact your cable or satellite
TV provider.
• Make sure that the antenna or
cable/satellite TV is connected
securely to your TV.
• Try replacing the cable between
the antenna/cable or
cable/satellite box and your TV.
• Make sure that the channels are
not blocked. See “Setting
parental control levels” on
page 53.
• Make sure that the channels are
not hidden. The channel may
have been deleted from the
channel list. You can tune to the
channel by pressing the
number buttons or you can add
the channel back to the channel
list. See “Hiding channels” on
page 49.
• If you are using a cable or
satellite box, use the remote
that came with that box to
change channels.
• Make sure that you have the
correct input selected to view
channels from the cable or
satellite box.
• If you are using an antenna, the
digital channel signal may be
low. To check the digital
channel signal strength, see
“Checking the digital signal
strength” on page 50.
Password is lost.
• Enter 9999 to access parental
controls, then set a new
password. See “Setting or
changing the password” on
page 51.
Some settings
cannot be
accessed.
• If a setting is grayed, the setting
is not available in the current
video input mode.
TV cabinet
creaks.
• When the TV is in use, the
temperature rises naturally and
may cause the cabinet to
expand or contract which can
cause a creaking noise. This is
not a malfunction.
73
Solution
Control buttons
do not work.
• Make sure that the Button
Block option is set to Off. See
“Locking control buttons” on
page 52.
• Unplug the power cord, wait a
few seconds, then plug the cord
back in and turn on your TV.
TV keeps
turning off.
• Make sure that the sleep timer
is not turned on. See “Setting
the sleep timer” on page 59.
A retail banner
is displayed.
• You selected “Store” mode
when you ran the EZ SETUP
wizard. Reset your TV to the
factory defaults, then select
Home on the What is your
viewing environment screen. See
“Restoring settings to the
defaults” on page 69.
MHL-enabled device or Roku Streaming Stick
Problem
Solution
The mobile
device does not
charge when
connected to
the
HDMI 2/MHL
jack.
• Make sure that the MHL cable is
connected securely to your TV
and the device.
• Make sure that you are using an
MHL cable. An MHL cable may
be difficult to identify. It may
look like a micro USB-to-HDMI
cable because the cable
connectors are the same, but
the cable itself is thinner. The
cable also may not be labeled
MHL.
My TV is not
displaying the
video or playing
the audio from
the connected
mobile device.
• Make sure that the MHL cable is
connected securely to your TV
and the device.
• Make sure that you are using an
MHL cable. An MHL cable may
be difficult to identify. It may
look like a micro USB-to-HDMI
cable because the cable
connectors are the same, but
the cable itself is thinner. The
cable also may not be labeled
MHL.
• Try adjusting the picture
settings on your TV.
• Some apps may not work on
your TV, depending on how the
app developer programmed
the app.
www.sharpusa.com
Sharp 50" LED TV
Problem
CEC-compatible device
Solution
My TV is playing
the audio from
a connected
device but is
not displaying
the video.
• Make sure that the MHL cable is
connected securely to your TV
and the device.
• Make sure that you are using an
MHL cable. An MHL cable may
be difficult to identify. It may
look like a micro USB-to-HDMI
cable because the cable
connectors are the same, but
the cable itself is thinner. The
cable also may not be labeled
MHL.
• Try adjusting the picture
settings on your TV.
• Some Apps may not work on
your TV, depending on how the
app developer programmed
the app.
My TV is
displaying the
video from the
connected
device but is
not playing the
audio.
• Make sure that the volume on
your mobile device is turned up
and not muted.
• Make sure that the volume on
your TV is turned up and not
muted.
• Make sure that the MHL cable is
connected securely to your TV
and the device.
• Make sure that you are using an
MHL cable. An MHL cable may
be difficult to identify. It may
look like a micro USB-to-HDMI
cable because the cable
connectors are the same, but
the cable itself is thinner. The
cable also may not be labeled
MHL.
• Try adjusting the audio settings
on your TV.
• Some Apps may not work on
your TV, depending on how the
app developer programmed
the app.
Problem
Solution
My TV is not
displaying the
video from the
connected CEC
device.
• Make sure that the HDMI cable
is connected securely to your
TV and the device.
• Make sure that the device is
connected to your TV with an
HDMI cable.
• Make sure that the device is a
CEC-compatible device. See the
documentation that came with
the device for more
information.
• Make sure that the correct
video input source is selected.
See “Selecting the video input
source” on page 40.
• Make sure that the CEC Control
feature is turned on. See
“Turning CEC Control on or off”
on page 60.
• Try adjusting the TV picture. See
“Adjusting the TV picture” on
page 43.
• If the device is not a Sharp
device, it may not be
compatible with your TV.
My TV is not
playing the
audio from the
connected CEC
device.
• Make sure that the HDMI cable
is connected securely to your
TV and the device.
• Make sure that the device is
connected to your TV with an
HDMI cable.
• Make sure that the device is a
CEC-compatible device. See the
documentation that came with
the device.
• Make sure that the TV volume is
turned up and not muted.
• Try adjusting the TV sound. See
“Adjusting sound settings” on
page 45.
• Make sure that the TV speakers
are turned on and not muted.
See “Adjusting sound settings”
on page 45.
• Make sure that the CEC control
feature is turned on. See
“Turning CEC Control on or off”
on page 60.
• If you have connected an HDMI
CEC audio receiver, adjust the
volume on the receiver. When
your TV detects an audio
receiver, the TV speakers turn
off and sound plays through
receiver speakers only.
www.sharpusa.com
74
LC-50LB150U Sharp 50" LED TV
Problem
My TV’s remote
control does
not control the
device.
The device does
not show up in
the CEC Device
list.
My device does
not turn off
when I turn off
my TV.
75
Solution
Problem
• Make sure that there are no
obstructions between the
remote control and the remote
control sensors on your TV and
the device.
• If the device is not a Sharp
device, all the buttons may not
work.
• Make sure that the CEC Control
feature is turned on. See
“Turning CEC Control on or off”
on page 60.
• If you are trying to control the
volume on an HDMI CEC audio
receiver using your TV remote
control, make sure that the
Audio Return Channel option
on the CEC menu is set to On.
See “Turning Audio Return
Channel on or off” on page 62.
• The device may not support this
feature. See the documentation
that came with the device for
more information.
• Make sure that the device is
turned on.
• Make sure that the HDMI cable
is connected securely to your
TV and the device.
• Make sure that the device is
connected to your TV with an
HDMI cable.
• Make sure that the CEC Control
feature is turned on. See
“Turning CEC Control on or off”
on page 60.
• Make sure that the device is a
CEC-compatible device. See the
documentation that came with
the device.
• If the device is not a Sharp
device, it may not be
compatible with your TV.
Solution
My TV does not
turn on when I
turn on my
device.
• Make sure that the CEC Control
feature is turned on. See
“Turning CEC Control on or off”
on page 60.
• Make sure that TV Auto Power
On is set to On on the CEC
menu. See “Turning TV Auto
Power On on or off” on page 61.
• The device may not support this
feature. See the documentation
that came with the device for
more information.
The Audio
Return
Channel
setting on the
CEC menu
keeps turning
back on after it
is turned off.
• When Audio Return Channel is
set to Off and CEC Control is
set to On and you adjust the
volume on the audio receiver,
Audio Return Channel is
automatically set to On. To
prevent this from happening,
turn off the CEC Control feature.
See “Turning CEC Control on or
off” on page 60.
I cannot select
the Root Menu
option on the
CEC menu.
OR
The device’s
root menu does
not open when
I select Root
Menu on the
CEC menu.
• The device may not support this
feature. See the documentation
that came with the device for
more information.
Note
If the problem is not solved by using these
troubleshooting instructions, turn off your
TV, then turn it on again.
• Make sure that the CEC Control
feature is turned on. See
“Turning CEC Control on or off”
on page 60.
• Make sure that Device Auto
Power Off is set to On on the
CEC menu. See “Turning Device
Auto Power Off on or off” on
page 61.
• The device may not support this
feature. See the documentation
that came with the device for
more information.
www.sharpusa.com
Sharp 50" LED TV
Specifications
Specifications are subject to change without notice.
With stand
44.3 × 26.3 × 2.4 in. (112.5 × 66.9 × 6.2 cm)
32 lb. (14.5 kg)
44.3 × 27.9 × 10 in. (112.5 × 70.8 × 25.5 cm)
37.3 lb. (16.9 kg)
DTS Tuning Package
Speakers
Power consumption
49.5 in.
Power input
LED
120Hz
1080p
1920 (H) × 1080 (V)
16:9
OSD languages
MHL-enabled
ENERGY STAR qualified
Internet connectable
3000:1
2,000,000:1
TV base screws
220 nits
V-Chip (version 2.0)
Sleep timer
Channel labeling
VESA mount (mm)
(horizontal × vertical)
VESA mount screws
3d y/c digital
8 ms
176°
176°
1080p, 1080i, 720p, 480p, 480i
1080i, 720p, 480p, 480i
Tuner
Analog
Digital
On: 125W
Standby: <1W
AC 120 V, 60Hz
Miscellaneous
Display resolutions
HDMI suggested resolutions
Component video suggested
resolutions
DTS Sound
Number: 2
Watts per channel: 10W
Power
Screen
Screen size measured
diagonally
Display type
Screen refresh rate
Display resolution
Panel resolution
Aspect ratio
Contrast ratio
(typical)–panel
Dynamic contrast ratio–
list value
TV Brightness (minimum)
cd/m2
Comb filter
Response time
Horizontal viewing angle
Vertical viewing angle
1 (optical) (back)
No
No
Audio
Dimensions and weight
Without stand
Digital audio
WiFi
Ethernet
NTSC
ATSC, 8-VSB, Clear-QAM
English, French, Spanish
Yes (HDMI 2/MHL jack)
Yes
No
Stand column to TV screen:
M4 type (8 mm length) (4 pcs)
Base to stand column:
M6 type (12 mm length) (4 pcs)
Yes
Yes
Yes
400 × 400
M6 type
Note
The length of the wall-mount screws vary
depending on the wall-mount bracket you
purchased. See the instructions that came
with the wall-mount bracket for screw
lengths.
Inputs
HDMI
Component video
Composite video
Shared audio (component
and composite)
S-Video
PC/VGA
3.5mm PC audio input
DVI
USB
Antenna/Cable
3 (side)
E-EDID compliant
HDCP compliant
MHL-enabled (HDMI 2/MHL jack)
1 (back)
1 (back)
Shared with component Y
Yes
No
1 (back)
1 (back)
1 (side)
HDMI 3/DVI jack
1 (side)
Supports JPEG and firmware upgrade
1 (back)
Outputs
Video
Analog audio/Headphone
No
1 (side)
www.sharpusa.com
76
LC-50LB150U Sharp 50" LED TV
Programming universal
remote controls
UNIVERSAL REMOTE TV CODES
10032, 10036, 10039, 10093, 10153, 10157,
10165, 10281, 10381, 10386, 10491, 10688,
10720, 10818, 10851, 10854, 11089, 11393,
11589, 11602, 11917
Dish
005, 026, 091, 105, 106, 107, 108, 128, 129,
Network
214, 521, 526, 546, 585, 591, 605, 606, 607,
608, 628, 629, 654, 655, 658, 663, 670 702,
739, 740, 741, 803, 835, 965
Time Warner 016, 022, 023, 024, 025, 026, 027, 028, 029,
073, 107, 179, 251, 363, 0026, 0039, 0090,
0091, 0093, 0107, 0129, 0141, 0153, 0157,
0165, 0200, 0220, 0224, 0225, 0281, 0386,
0398, 0491, 0688, 0689, 0702, 0818, 0851,
1004, 1006, 1010, 1022, 1025, 1079, 1093,
1094, 1095, 1100, 1137, 1139, 1197, 1602
TiVo
0011, 0020, 0025, 0028, 0033, 0034, 0077,
0132, 0151, 0154, 0235, 0236, 0361, 0375
Verizon
342, 0120, 0205, 0518, 0715, 0716, 0878,
3005, 3008, 3021, 3025, 3027, 3073, 3121,
3125, 3132, 3138, 3142, 3206, 3222
DirectTV
You can operate your Sharp TV with a new or
existing universal remote control.
To program a universal remote control:
1 See the table in “Common universal remote
control codes” for common codes. If you have
problems programming your remote or need a
different remote control code, see the
instructions that came with the remote control
or check the remote control manufacturer’s
website for the latest remote control code
information.
2 Follow your universal remote control’s
instructions to enter the TV code you found in
Step 1.
Tips
• If your universal remote control has a
code search feature, run a code search
to identify a code that matches your
TV. See your universal remote control’s
instructions for details.
• If your universal remote control has a
“Learn” feature, you can manually
program it using the Sharp TV remote
to “teach” the commands one at a
time. See your universal remote
control’s instructions for details.
For additional help and information:
• Visit the remote control manufacturer’s website
• Call technical support for the universal remote
control or cable/satellite company of the
remote/set-top box you are trying to program.
UNIVERSAL REMOTE CONTROLS
One for All 0039, 0093, 0157, 0165, 0386, 0688, 0689,
0818, 10093, 10818, 20048, 20848
Phillips
0002, 0111, 0202, 0224, 0228, 0502, 0509,
0603, 0813, 0907, 0913, 2550
RCA
005, 008, 018, 020, 067, 077, 083, 089, 097,
10093, 10818, 12360
Sony
00093, 00650, 00653, 00818, 01193, 01393,
01659
Common universal remote control codes
The following is a list of the most common remote
control codes. Check the remote control
manufacturer’s website or check with your cable or
satellite TV provider for the remote control code.
UNIVERSAL REMOTE TV CODES
CABLE BOX, SATELLITE BOX, OR OTHER SET-TOP BOX
Cablevision 004, 014, 019, 022, 028, 081, 127, 236, 251,
496
Charter
004, 014, 016, 019, 022, 023, 024, 025, 026,
027, 028, 029, 081, 0093, 127, 175, 143,
251, 236, 393, 395, 409, 496, 0039, 0093,
0165, 0386, 0491, 0688, 0689, 0851, 1917,
10093, 10165, 10386, 10688, 10851, 10818,
11602, 10818, 12360
Comcast
0093, 0165, 10032, 10036, 10093, 10153,
10165, 10386, 10398, 10491, 10851, 10854,
11089, 11407, 11602
Cox
002, 008, 049, 050, 051, 052, 070, 071, 072,
073, 098, 102, 107, 139, 166, 167, 179,
0039, 0093, 0153, 0157, 0165, 0220, 0281,
0386, 0398, 0491, 0630, 0688, 0689, 0818,
0851,1004, 1006, 1010, 1022, 1025, 1079,
1093, 1094, 1095, 1100, 1137, 1139
77
www.sharpusa.com
Tips
• The brand name is often visible on the
front of the universal remote control,
and the model number is often visible
on the back.
• If your universal remote control isn’t
listed on the chart, refer to your
universal remote control’s instructions
and try codes for the brands Orion,
Emerson, Memorex, Sansui, Sylvania,
or Zenith. You may need to try several
codes before finding a match.
Sharp 50" LED TV
Legal notices
Dolby License Notice and Trademark Acknowledgement
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
HDMI
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
DTS Sound™
Manufactured under license from DTS Licensing Limited.
DTS, the Symbol, & DTS and the Symbol together are
registered trademarks and DTS Sound is a trademark of
DTS, Inc. © DTS, Inc. All Rights Reserved.
MHL™ (Mobile High-Definition Link)
MHL and the MHL logo are trademarks or
registered trademarks of MHL Licensing, LLC
in the United States and other countries.
Energy Star
Warning
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
Cables
Your Sharp TV is ENERGY STAR® qualified in the “Standard”
mode. It meets strict energy efficiency guidelines set by the
U.S. Environmental Protection Agency and Department of
Energy. ENERGY STAR is a joint program of these government
agencies, designed to promote energy efficient products and
practices. Changes to certain features, settings, and
functionalities of this TV (i.e. Picture, Sound) can increase or
change the power consumption. Depending upon such
changed settings, the power consumption may exceed the
limits required for the ENERGY STAR qualification in the
“Standard” mode.
Connections to this device must be made with shielded cables
with metallic RF/EMI connector hoods to maintain compliance
with FCC Rules and Regulations.
Canadian Notice
CAN ICES-3 (B)/NMB-3(B)
Standard Television Receiving Apparatus – Appareil de réception
télévision ordinaire, NORMES CANADIENNES BETS-7 / NTMR-7
IC Statement
This device complies with Industry Canada licence-exempt RSS
standard(s).
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
This equipment complies with IC radiation exposure limits set
forth for an uncontrolled environment.
www.sharpusa.com
78
LC-50LB150U Sharp 50" LED TV
One-year limited warranty Sharp Televisions
Definitions:
Best Buy (“Warrantor”) warrants to you, the original purchaser of
this new Sharp-branded television (“Product”), that the Product
shall be free of defects in the original manufacturer of the
material or workmanship for a period of one (1) year from the
date of your purchase of the Product (“Warranty Period”). For this
warranty to apply, your Product must be purchased in the United
States from a Best Buy Retail location or www.bestbuy.com.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you
purchased the Product. Your purchase date is printed on the
receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the
material or workmanship of the Product is determined to be
defective by an authorized Warrantor repair center or store
personnel, Warrantor will (at its sole option): (1) repair the
Product with new or rebuilt parts; or (2) replace the Product at no
charge with new or rebuilt comparable products or parts.
Products and parts replaced under this warranty become the
property of Warrantor and are not returned to you. If service of
Products or parts are required after the Warranty Period expires,
you must pay all labor and parts charges. This warranty lasts as
long as you own your Sharp Product during the Warranty Period.
Warranty coverage terminates if you sell or otherwise transfer
the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy Retail store location or
www.bestbuy.com and your television Product has a screen size
of less than 42 inches, please take your original receipt and the
Product to a Best Buy Retail store. Make sure that you place the
Product in its original packaging or packaging that provides the
same amount of protection as the original packaging.
To obtain in-home warranty service for a television with a screen
42 inches or larger, call 1-855-544-2030 or 1-888-BESTBUY. Call
agents will diagnose and correct the issue over the phone or will
have a Warrantor-approved repair technician dispatched to your
home.
•
Failures or Damage caused by any contact including but
not limited to liquids, gels or pastes.
• Up to three (3) pixel failures (dots that are dark or
incorrectly illuminated) grouped in an area smaller than
one tenth (1/10) of the display size or up to five (5) pixel
failures throughout the display. (Pixel based displays may
contain a limited number of pixels that may not function
normally.)
• Problems with delay in motion or action of video images
while playing first-person style video games.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
YOUR EXCLUSIVE REMEDY FOR BREACH OF WARRANTY.
WARRANTOR SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT
NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT,
LOST BUSINESS OR LOST PROFITS. WARRANTOR MAKES NO
OTHER EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT,
ALL EXPRESS AND IMPLIED WARRANTIES FOR THE PRODUCT,
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE
WARRANTY PERIOD SET FORTH ABOVE AND NO WARRANTIES,
WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE
WARRANTY PERIOD. SOME STATES, PROVINCES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY
FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Product information www.sharpusa.com
Product support (855) 544-2030
This product is manufactured for Best Buy China Ltd., as trustee
for Best Buy China, and distributed and warranted by Best Buy
Purchasing, LLC (7601 Penn Avenue South, Richfield, Minnesota,
U.S.A. 55423-3645) under brand license by SHARP Corporation.
©2013 Best Buy China LTD. All rights reserved.
SHARP is a registered trademark of Sharp Corporation; used
under license by SHARP Corporation. All other trademarks are
property of their respective owners.
Where is the warranty valid?
This warranty is valid only in the United States at Best Buy Retail
stores or www.bestbuy.com to the original purchaser of the
product.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
• Installation
• Set up adjustments
• Cosmetic damage
• Damage due to acts of God, such as power surges
• Accident(s)
• Misuse, unintentional or intentional
• Abuse, unintentional or intentional
• Negligence
• Commercial purposes/use, including but not limited to use
in a place of business or in communal areas of a multiple
dwelling condominium or apartment complex, or
otherwise used in a place of other than a private home.
• Modification of any part of the Product, including the
antenna
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Outages, static or other problems with over-the-air
reception of the television broadcast signals.
• Attempted repair by any person not authorized by
Warrantor to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA,
AAA, C etc.)
• Products where the factory applied serial number has been
altered or removed
• Loss or Theft of this product or any part of the product
79
www.sharpusa.com
Product information www.sharpusa.com
Product support (855) 544-2030
This product is manufactured for Best Buy China Ltd, as trustee for Best Buy China, and distributed and warranted by Best Buy Purchasing, LLC
(7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645) under brand license by SHARP Corporation.
©2013 Best Buy China LTD. All rights reserved.
SHARP is a registered trademark of Sharp Corporation; used under license by SHARP Corporation .
All other trademarks are property of their respective owners.
V2 ENGLISH
13-0436
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
