Universal Dock
Using the Apple Universal Dock
Congratulations on purchasing your Apple Universal Dock.
You can use this Dock with iPhone or any iPod that has a Dock connector.
Here are the things you can do with your new Dock:
ÂÂ Connect the Dock to your computer, and then place your iPod or iPhone in the Dock
to charge the battery and sync content from iTunes (page 6).
ÂÂ Connect the Dock to a power outlet (using an Apple USB Power Adapter, available
separately), and then place your iPod or iPhone in the Dock to charge the battery
(page 6).
ÂÂ If you have an iPhone or an iPod that displays photos, display photos on a TV or
other video device (using an Apple Composite or Component AV Cable, available
separately; page 8).
ÂÂ If you have an iPhone or an iPod that plays video, display videos on a TV or other
video device (using an Apple Composite or Component AV Cable, available
separately; page 8).
ÂÂ Connect the Dock to speakers or a stereo (using an audio cable, available separately)
to play music from your iPod or iPhone (page 9).
ÂÂ Control playback from a distance using the Apple Remote (page 10).
English
3
Important: Never force a connector into a port. If the connector and port don’t join
with reasonable ease, they probably don’t match. Make sure that the connector
matches the port and that you have positioned the connector correctly in relation
to the port.
Your Universal Dock includes the following:
Universal Dock
Dock adapters (5)
Apple Remote
4
4 English
Universal Dock at a Glance
Infrared (IR)
receiver
Dock connector port
Dock connector
What You Can Do
Infrared (IR) receiver
Dock connector port
Control playback from a distance using the Apple Remote.
Connect the Dock to your computer or a USB Power Adapter
using the cable that came with your iPod or iPhone. Or
connect an Apple Composite or Component AV Cable to
view photos or videos on a TV or other video device (with
iPhone and some iPod models).
Place your iPod or iPhone in the Dock to charge the battery,
sync content from iTunes, listen to music, or view photos or
videos (with iPhone and some iPod models).
Connect to external speakers or a stereo receiver using an
audio cable with a standard 3.5 millimeter stereo miniplug.
Dock connector
English 5
To use the Dock with your iPod or iPhone:
1 Attach the cable included with your iPod or iPhone to your computer or to a USB
Power Adapter (sold separately) that’s plugged into a power outlet, and connect the
other end to the Dock.
2 Choose the adapter that fits your iPod or iPhone. Your iPod or iPhone fits snugly into
the correct adapter.
The number (9–18)
shows which iPod or iPhone fits
iPod and
iPod classic
9
5th generation (30GB),
iPod classic 80GB and
120/160GB
iPhone
iPod touch
15
iPhone 3G
and 3GS
iPod nano
iPod nano
16
17
18
2nd generation
4th generation 5th generation
Note: If a dock adapter for your iPod or iPhone model isn’t included with your Universal
Dock, you can purchase one at www.apple.com/store.
6
6 English
3 Insert the dock adapter into the connector well of your Dock, and then put your iPod or
iPhone in the Dock.
Dock adapter
Connector well
You can remove the dock adapter
with your fingernail by using this slot.
If the Dock is connected to your computer and iTunes is set to sync your iPod or iPhone
automatically, syncing begins as soon as you put your iPod or iPhone in the Dock.
For more information about syncing content to your iPod or iPhone and using all of its
features, see the user guide for your iPod or iPhone.
English 7
Viewing Photos and Videos on a TV or Other Video Device
With iPhone and most iPod models, you can use the Dock to view photos and video
on a TV or other video device (such as a digital projector). The TV or other device must
have standard RCA type connectors that support either composite or component
video signals.
To connect the Dock, you need an Apple Composite AV Cable or Component AV Cable.
Choose your cable based on the available inputs on your TV or video device. These
cables are available separately at www.apple.com/store.
Important: Make sure you enable your iPod or iPhone to send a video signal out to
your TV or receiver. For more information, see the user guide for your iPod or iPhone.
Before you begin connecting components, turn down the volume on your iPod or
iPhone, turn off iPod or iPhone, and turn off the power to all your components. Make
all connections firmly to avoid hum and other noise. For information about avoiding
hearing damage, see page 13.
To connect the Dock to your TV, receiver, or video device:
1 Connect the AV Cable to the dock connector port on the Dock and to your TV or video
device. See the instructions that came with your AV Cable.
2 Turn on your iPod or iPhone and your TV or video device to start playing.
To display photos or videos on your TV or video device:
mm See the user guide for your iPod or iPhone, available on the web at:
www.apple.com/support/manuals
8
8 English
Playing Music Through External Speakers or a Stereo
Using the Universal Dock, you can play music from your iPod or iPhone through
external speakers or a stereo receiver. You need an audio cable (available separately)
with a standard 3.5 millimeter stereo miniplug (many external speakers use this
type of cable).
To use your iPod or iPhone with the Dock to play music through speakers
or a stereo:
1 Place your iPod or iPhone in the Dock.
2 Connect the speakers or stereo to the Dock line out port.
3 Use the iPod or iPhone controls or the Apple Remote to play music.
Use the remote or the volume controls on the speakers or stereo to change the
volume. With some iPod models, you can also use the Click Wheel.
Note: You can play music using your iPod or iPhone in the Dock while the Dock
is connected to a power outlet (using the optional USB Power Adapter) or to your
computer. If the Dock is connected to your computer, your iPod must not be enabled
for disk use. For information about enabling iPod for disk use, see the user guide for
your iPod, available on the web at www.apple.com/support/manuals.
To purchase external speakers or audio cables, go to www.apple.com/store.
English 9
Using the Apple Remote
You can use the included infrared (IR) remote to control playback from your iPod or
iPhone connected to the Dock. Make sure there are no obstructions between the
remote and the Dock.
10
10 Volume Up
IR window
Previous/Rewind
Next/Fast-forward
Volume Down
Play/Pause
Menu
Battery compartment
English
To use the Apple Remote:
To
Do This
Play or pause a song or video
Press ’
Change the volume
Press ∂ or D
Skip to the next song
Press ‘
Start a song or video over or
play the previous song
Press ] once to start a song or video over. Press it twice to
play the previous song.
Fast-forward or rewind a song
or video
Press and hold ‘ or ]
Note: You can’t use the remote to choose a different playlist. Use the iPod or iPhone
controls instead.
To set the Dock to work with only a particular remote:
The Apple Remote works with other compatible Apple products that have a built-in
infrared (IR) receiver. You can pair your Dock to work only with a particular remote,
so remotes for your other devices don’t affect the Dock.
1 Place your iPod or iPhone in the Dock and press any button on your iPod or iPhone to
turn it on.
2 Make sure other products that are compatible with the Apple Remote are out of range
or powered off, and then hold the remote close to the IR receiver on the Dock (within 3
to 4 inches or 8 to 10 cm).
3 Press and hold both » and ‘ on the Apple Remote for about six seconds.
Your Dock now works only with the paired remote.
English 11
Note: You may want to pair your other Apple Remote compatible devices with
other remotes, so the remote you use with your Dock doesn’t affect those devices.
For instructions, see the documentation that came with those devices.
To reset the Dock to work with other Apple Remotes:
Follow steps 1 and 2 above. Then press and hold both » and ] on the Apple Remote
for about six seconds.
The Dock now works with any Apple Remote.
To change the battery:
The Apple Remote includes a battery. When needed, you can replace it with a CR2032
battery.
Press this button with a small object.
Positive (+) side faces up.
Pull the battery
compartment free.
WARNING: There is a risk of explosion if the battery is replaced with an incorrect type.
Dispose of used batteries according to your local environmental laws and guidelines.
12
12 English
Important Safety Instructions
WARNING: Failure to follow these safety instructions could result in injury or damage.
Avoid Hearing Damage
Permanent hearing loss may occur if your iPod or iPhone is used at high volume. Set
the volume to a safe level. You can adapt over time to a higher volume that may sound
normal but can be damaging to your hearing. If you experience ringing in your ears or
muffled speech, stop listening and have your hearing checked. The louder the volume,
the less time is required before your hearing could be affected. Hearing experts suggest
that to protect your hearing:
ÂÂ Limit the amount of time you listen at high volume.
ÂÂ Avoid turning up the volume to block out noisy surroundings.
ÂÂ Turn down the volume if you can’t hear people speaking near you.
For information about how to set a maximum volume limit, see the user guide for your
iPod or iPhone.
Service and Support
For troubleshooting, service, and support information on iPod or iPhone, the Universal
Dock, and the Apple Remote, go to www.apple.com/support.
English 13
14
15
16
17
18
19
20
21
22
22
23 23
24
25
Station d’accueil
Universal Dock
26
27
iPhone
16
iPod nano
iPod touch
iPod nano
29
30
l’adresse : www.apple.com/fr/support/manuals.
31
32
Suivant/Avance rapide
Moins fort
Menu
33
Appuyez sur ‘
35
36
37
Universal Dock
Dock adapters (5)
Apple Remote
39
Dock Connector
Infrarotempfänger
Dock Connector
40
9
5. Generation (30 GB),
iPod classic 80 GB und
120/160 GB
iPhone
16
iPod nano
iPod touch
iPod nano
41
Dock-Adapter
Connector-Wanne
43
44
45
46
Lauter
Taste „Menu“
Aktion
47
48
49
50
51
52
53
54
iPhone
15
iPhone 3G
y 3GS
iPod nano
iPod touch
iPod nano
55
57
www.apple.com/es/support/manuals.
58
59
60
Subir el volumen
Bajar el volumen
Menú
Pulse ’
Pulse ∂ o D
Pulse ‘
61
62
Polo positivo (+) hacia arriba.
63
64
65
Dock universale
Adattatori Dock (5)
Telecomando
Apple Remote
66
Italiano
67
iPhone
iPod nano
iPod touch
iPod nano
68
Italiano
69
www.apple.com/it/support/manuals
70
71
72
Volume su
Menu
Italiano
Premi ’
Premi ∂ o D
Premi ‘
73
Italiano
75
Regulatory Compliance Information
Compliance Statement
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation. See instructions if interference to radio or
television reception is suspected.
L‘utilisation de ce dispositif est autorisée seulement
aux conditions suivantes: (1) il ne doit pas produire de
brouillage et (2) l’utilisateur du dispositif doit étre prêt
à accepter tout brouillage radioélectrique reçu, même
si ce brouillage est susceptible de compromettre le
fonctionnement du dispositif.
Radio and Television Interference
This computer equipment generates, uses, and can
radiate radio-frequency energy. If it is not installed and
used properly—that is, in strict accordance with Apple’s
instructions—it may cause interference with radio and
television reception.
This equipment has been tested and found to comply
with the limits for a Class B digital device in accordance
with the specifications in Part 15 of FCC rules. These
specifications are designed to provide reasonable
protection against such interference in a residential
installation. However, there is no guarantee that
interference will not occur in a particular installation.
You can determine whether your computer system is
causing interference by turning it off. If the interference
stops, it was probably caused by the computer or one
of the peripheral devices. If your computer system does
cause interference to radio or television reception, try
to correct the interference by using one or more of the
following measures:
• Turn the television or radio antenna until the
interference stops.
• Move the computer to one side or the other of the
television or radio.
• Move the computer farther away from the television
or radio.
• Plug the computer into an outlet that is on a different
circuit from the television or radio. (That is, make
certain the computer and the television or radio are
on circuits controlled by different circuit breakers or
fuses.)
If necessary, consult an Apple Authorized Service
Provider or Apple. See the service and support
information that came with your Apple product. Or,
consult an experienced radio/television technician for
additional suggestions.
Important: Changes or modifications to this product
not authorized by Apple Inc. could void the EMC
compliance and negate your authority to operate the
product.
This product was tested for EMC compliance under
conditions that included the use of Apple peripheral
devices and Apple shielded cables and connectors
between system components.
76 It is important that you use Apple peripheral devices
and shielded cables and connectors between system
components to reduce the possibility of causing
interference to radios, television sets, and other
electronic devices.
VCCI Class B Statement
Responsible party (contact for FCC matters only):
Apple Inc. Corporate Compliance
1 Infinite Loop, MS 26-A
Cupertino, CA 95014
European Compliance Statement
This product complies with the requirements of
European Directives 72/23/EEC, 89/336/EEC, and
1999/5/EC.
Korea Statements
Taiwan Class B Statement
Apple and the Environment
Apple Inc. recognizes its responsibility to minimize the
environmental impacts of its operations and products.
More information is available on the web at:
www.apple.com/environment
European Community
Complies with European Directives 72/23/EEC and 89/
336/EEC.
77
For information about Apple’s recycling program, visit
www.apple.com/environment/recycling.
Battery Disposal Information
Dispose of batteries according to your local
environmental laws and guidelines.
California: The coin cell battery in your remote contains
perchlorates. Special handling and disposal may apply.
Refer to www.dts.ca.gov/hazardouswaste/perchlorate.
Deutschland: Das Gerät enthält Batterien. Diese
gehören nicht in den Hausmüll. Sie können verbrauchte
Batterien beim Handel oder bei den Kommunen
unentgeltlich abgeben. Um Kurzschlüsse zu vermeiden,
kleben Sie die Pole der Batterien vorsorglich mit einem
Klebestreifen ab.
Nederlands: Gebruikte batterijen kunnen worden
ingeleverd bij de chemokar of in een speciale
batterijcontainer voor klein chemisch afval (kca) worden
gedeponeerd.
Disposal and Recycling Information
Taiwan:
This symbol indicates that your product must be
disposed of properly according to local laws and
regulations. When your product reaches its end of life,
contact Apple or your local authorities to learn about
recycling options.
78 Europäische Union—Informationen zur Entsorgung
Das Symbol oben bedeutet, dass dieses Produkt
entsprechend den geltenden gesetzlichen Vorschriften
und getrennt vom Hausmüll entsorgt werden muss.
Geben Sie dieses Produkt zur Entsorgung bei einer
offiziellen Sammelstelle ab. Bei einigen Sammelstellen
können Produkte zur Entsorgung unentgeltlich
abgegeben werden. Durch das separate Sammeln
und Recycling werden die natürlichen Ressourcen
geschont und es ist sichergestellt, dass beim Recycling
des Produkts alle Bestimmungen zum Schutz von
Gesundheit und Umwelt beachtet werden.
Unione Europea—informazioni per l’eliminazione
Questo simbolo significa che, in base alle leggi e alle
norme locali, il prodotto dovrebbe essere eliminato
separatamente dai rifiuti casalinghi. Quando il prodotto
diventa inutilizzabile, portarlo nel punto di raccolta
stabilito dalle autorità locali. Alcuni punti di raccolta
accettano i prodotti gratuitamente. La raccolta
separata e il riciclaggio del prodotto al momento
dell’eliminazione aiutano a conservare le risorse naturali
e assicurano che venga riciclato in maniera tale da
salvaguardare la salute umana e l’ambiente.
Europeiska unionen—uttjänta produkter
Symbolen ovan betyder att produkten enligt lokala
lagar och bestämmelser inte får kastas tillsammans
med hushållsavfallet. När produkten har tjänat ut
måste den tas till en återvinningsstation som utsetts
av lokala myndigheter. Vissa återvinningsstationer tar
kostnadsfritt hand om uttjänta produkter. Genom att
låta den uttjänta produkten tas om hand för återvinning
hjälper du till att spara naturresurser och skydda hälsa
och miljö.
79
www.apple.com
www.apple.com/support
© 2009 Apple Inc. All rights reserved.
Apple, the Apple logo, iPod, iPod classic, iPod nano, iPod touch, and iTunes are trademarks of Apple Inc.,
registered in the U.S. and other countries. iPhone is a trademark of Apple Inc.
ZM034-4948-A
Printed in XXXX
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Languages

Only pages of the document in English were displayed
