Combi HP thermostatic mixer shower

Flush fit

Note:

The outlet of the shower must not be connected to anything other than the hose, showerhead or fixed showerhead supplied.

dO nOT use jointing compounds on any pipe fittings for the installation.

dO nOT solder fittings near of the shower unit, as heat transfer can damage components.

Note:

Suitable isolating valves (complying with water Regulations) must be fitted on the hot and cold water supplies to the shower as an independent means of isolating water supplies should maintenance or servicing be necessary.

when connecting pipework avoid using tight

90° elbows. Swept or formed bends will give the best performance.

ImportaNt: The water circuit should be installed such that the flow is not significantly affected by other taps and appliances being operated elsewhere on the premises. Water pressure must not fall below the specification of the valve.

The hot water pipe entry must be on the lefthand side.

This mixer valve also includes a wall bracket which allows the installer to mount the shower into a solid, stud partition or other hollow wall structures. The bracket can also be used for fitting in a shower cubicle providing the back of the cubicle is accessible.

when installing into a stud partition or other hollow wall structure the installer may wish to consider building rear supports or other options.

Such options are beyond the scope of this guide.

Solid wall

The building-in depth for the shower into a solid wall is between 57 mm and 66 mm. The building-in depth calculation must include the thickness of the plaster and tiles. This dimension determines how much of the shower control is visible through the concealing plate when the installation is completed.

decide on the shower position and whether the hot and cold water supplies will enter the

T00249

T00250

77.5 m m

220 mm

Opening needs to be at the bottom if using a bulkhead

35 m m

10 -

12.5 mm

48 m m

50 m m

Fig.9

Fig.0

Fig.

T00251

Fig.

T00252

Fig.

T00253

Combi HP thermostatic mixer shower

Seal tight up to shroud shower from the top (falling), the bottom (rising) or the rear.

Mark the route of the incoming and outgoing pipework.

Note:

The final separation between pipe centres needs to be about 153 mm but absolute accuracy is not essential as the inlet elbows are adjustable between 146 mm and 160 mm.

Remove the plaster and brickwork to the depth shown

(fig.9)

. where applicable, chase out any additional areas of the wall for the pipework to either the bulkhead or fixed head.

Offer the mounting bracket up to the wall and mark the two plain fixing holes

(fig.0)

. drill and plug then screw bracket to the wall.

Note:

The valve can be fitted to the mounting bracket if required or secured directly to the wall with the screws supplied.

If installing a fixed head, the outlet adaptor needs to be fitted into the top outlet hole in the valve housing

(fig.)

. The adaptor is sealed with an ‘O’ ring. Make sure the adaptor is fitted with the hose end

(fig.7)

in the valve housing.

Fit the blanking plug into the bottom outlet hole using an ‘O’ ring to seal it.

If fitting a bulkhead outlet, the outlet adaptor needs to be fitted into the bottom outlet hole in the valve housing. The adaptor is sealed with an

‘O’ ring. Make sure the adaptor is fitted with the hose end in the valve housing

(fig.7)

.

Fit the blanking plug into the top outlet hole using an ‘O’ ring to seal it

(fig.8)

.

Make sure the inlet elbows are positioned correctly. Offer the valve up to the mounting bracket or wall surface, and secure using the screws provided

(fig.)

.

complete the pipework to the shower marking off the length to enter the elbows. Remove the valve and cut the pipes to length.

Flush pipework to clear the system of all debris and check for leaks.

ImportaNt:

The inlet elbows contain check valves that may be damaged if debris is not flushed through prior to fitting.

Combi HP thermostatic mixer shower

where this is not possible refer to the

‘flushing procedure’

on page 20.

Refit the valve to the mounting bracket/wall surface and pipework

(fig.)

. Tighten the inlet nuts and inlet elbow grub screws.

If fitting a fixed head, refer to the

‘Fitting the fixed head’

section and complete the outlet pipework to the fixed head position.

Note:

The outlet pipe for the fixed head should protrude from the surface of the wall between

50 mm and 65 mm. Before fitting the fixed head to the wall, connect a hose to the pipework and direct to waste.

If fitting a riser rail kit, refer to

‘Fitting the bulkhead’

and complete outlet pipework.

Before fitting the bulkhead to the wall connect the shower hose and direct it to waste.

Open the isolating valves to the shower and flush through checking that the flow control is opened fully and the temperature control is rotated to ‘HOT’ and then to ‘cOld’ (if necessary depress the maximum temperature override button). check for leaks and remedy if necessary.

If a fixed head is installed, make good the outlet pipe channel.

Note:

If fitting a fixed head, the tiling around the outlet pipe must be as tight as possible so that the special lock washer will seat, otherwise a larger diameter washer will have to be placed behind the lock washer.

Make good the wall surface around the valve and make sure the plastering/sealing is taken tight to the PVc shroud

(fig.)

.

Should the shroud protrude beyond the wall surface, trim flush with a sharp knife

(fig.)

.

Offer the flush mount plate up to the finished tile surface and making sure the valve and plate are aligned, mark the ‘arrowed’ fixing holes

(fig.)

. Remove the flush mount plate then drill and plug holes.

Break off the alignment tabs on the flush mount plate

(fig.)

. Place a ring of silicon sealant round the plate so that the plate seals against the wall. Secure the plate to the wall using the screws provided. wipe off any excess sealant.

T00254

T00255

T00256

Alignment tab

Fig.

Fig.

Fig.

Combi HP thermostatic mixer shower

Fig.7

T00257

Fig.8

T00258

Fig.9

35 mm

T00259

77.5 mm 65 mm 77.5 mm

Opening needs to be at the bottom if using a bulkhead

220 mm

115 mm

Fit the flush mount cover

(fig.7)

. locate the lugs on the trim ring in the holes on the cover

(fig.8)

and twist clockwise.

complete the fitting of your shower accessories.

Hollow wall

The wall mounting bracket supplied with the shower is suitable for use on a plasterboard wall of 9.5 mm or 12.5 mm in thickness.

decide on the shower position and whether the hot and cold water supplies will enter the shower from the top (falling), the bottom (rising) or the rear.

Mark an opening as shown plus the route of inlet and outlet pipework

(fig.9)

.

Note:

The final separation between pipe centres needs to be about 153 mm but absolute accuracy is not essential as the inlet elbows are adjustable between 146 mm and 160 mm.

Take out the plasterboard and offer the mounting bracket up to the wall

(fig.0)

. Mark the outer fixing holes and drill. Insert the wall bracket into wall cavity and secure using the bolts and washers provided

(fig.)

.

If a fixed head is to be installed, the outlet adaptor needs to be fitted into the top outlet hole in the valve housing

(fig.)

. The adaptor is sealed with an ‘O’ ring. Make sure the adaptor is fitted with the hose end in the valve housing

(fig.7)

. Fit the blanking plug into the bottom outlet hole using an ‘O’ ring to seal it.

If a bulkhead outlet is to be fitted, the outlet adaptor needs to be fitted into the bottom outlet hole in the valve housing. The adaptor is sealed with an ‘O’ ring

(fig.)

. Make sure the adaptor is fitted with the hose end in the valve housing

(fig.7)

. Fit the blanking plug into the top outlet hole using an ‘O’ ring to seal it

(fig.8)

.

If installing a fixed head, make a hole in the wall for the fixed head pipe.

Note:

If fitting a fixed head, the hole in the wall for the pipe must be close to 15 mm diameter as possible. It must not exceed the diameter of the special lock washer, otherwise a larger diameter washer will have to be placed behind the lock

Combi HP thermostatic mixer shower

washer.

Make sure the inlet elbows are positioned the correct way. Offer the valve up to the mounting bracket and secure using the screws provided

(fig.)

.

complete the pipework to the shower marking off the length to enter the elbows. Remove the valve and cut the pipes to length.

Flush pipework to clear the system of all debris and check for leaks.

ImportaNt: The inlet elbows contain check valves that may be damaged if debris is not flushed through prior to fitting.

where this is not possible refer to the

‘flushing procedure’

on page 20.

Refit the valve to the mounting bracket and pipework. Tighten the inlet nuts and inlet elbow grub screws.

If fitting a fixed head, refer to the

‘Fitting the fixed head’

section and complete the outlet pipework to the fixed head position.

Note:

The outlet pipe for the fixed head should protrude from the surface of the wall between

50 mm and 65 mm. Before fitting the fixed head to the wall, connect a hose to the pipework and direct to waste.

If fitting a riser rail kit refer to

‘Fitting the bulkhead’

and complete the outlet pipework.

Before fitting the bulkhead to the wall, connect the shower hose and direct it to waste.

Open the isolating valves to the shower and flush through. Make sure the flow control is opened fully and the temperature control is rotated to ‘HOT’ and then to ‘cOld’ (if necessary depress the maximum temperature override button). check for leaks and remedy if necessary.

Make good the wall surface and make sure the plastering/sealing is taken tight to the PVc shroud

(fig.)

. Should the shroud protrude beyond the wall surface, trim flush with a sharp knife

(fig.)

.

Offer the flush mount plate up to the finished surface. Make sure the valve and the plate are aligned and mark the ‘arrowed’ fixing holes

(fig.)

. Remove the flush mount plate then

T00260

T00261

T00262

7

Fig.0

Fig.

Fig.

Fig.

T00253

Fig.

T00263

Fig.

T00264

Seal tight up to shroud

PP

3ODWHIL[LQJ

KROH

Combi HP thermostatic mixer shower

0DUNERWK

KROHV

%UDFNHW

IL[LQJKROH

9LHZIURP

EHKLQGSDQHO

8

drill and plug the holes.

Note:

If fitting to plasterboard, use suitable cavity fixings.

Break off the alignment tabs on the flush mount plate

(fig.).

Place a ring of silicon sealant round the plate so that the plate seals against the wall. Secure the plate to the wall using the screws provided. wipe off any excess sealant.

Fit the flush mount cover

(fig.7)

. locate the lugs on the trim ring in the holes on the plate and twist clockwise

(fig.8)

.

complete the fitting of your shower accessories by referring to the appropriate section.

Shower cubicle or panel

To use the wall mounting bracket supplied with a shower cubicle or a laminated panel, wooden blocks are required to increase the depth of the bracket. These blocks need to increase the depth of the bracket to between 56 mm and 67 mm from the finished surface

(fig.)

.

decide on the shower position and whether the hot and cold water supplies will enter the shower from the top (falling), the bottom (rising) or the rear.

Mark the wall for an opening of about 93 mm diameter.

cut the opening and offer the mounting bracket up to the back of the panel

(fig.)

. Mark the inner fixing holes and drill the panel and wooden support blocks.

If installing a fixed head, fit the outlet adaptor into the top outlet hole in the valve housing

(fig.)

. The adaptor is sealed with an ‘O’ ring. Make sure the adaptor is fitted with the hose end in the valve housing

(fig.7)

. Fit the blanking plug into the bottom outlet hole using an ‘O’ ring to seal it.

If installing a bulkhead outlet, fit the outlet adaptor into the bottom outlet hole in the valve housing. The adaptor is sealed with an ‘O’ ring.

Make sure the adaptor is fitted with the hose end in the valve housing

(fig.7)

. Fit the blanking plug into the top outlet hole using an

‘O’ ring to seal it

(fig.8)

.

Make sure that the inlet elbows are facing the

Combi HP thermostatic mixer shower

correct way. Offer the valve up to the mounting bracket and secure using the screws provided.

Secure the mounting bracket together with the valve to the panel using two bolts in the innermost fixing holes

(fig.)

.

complete the pipework to the shower marking off the length to enter the elbows. Remove the valve and mounting bracket and cut the pipes to length.

If fitting a fixed head, make a hole in the panel for the fixed head position.

Note:

Make sure the hole in the panel for the outlet pipe is no larger than required (either

½” BSP or 15 mm).

Should the shroud protrude beyond the wall surface, trim flush with a sharp knife

(fig.)

.

Place a ring of silicon sealant round the flush mount plate up to the finished surface. Make sure the valve and plate are aligned, and secure in the outer fixing holes using the two bolts supplied

(fig.7)

.

Break off the alignment tabs on the flush mount plate

(fig.)

and fit the flush mount cover

(fig.8)

. locate the lugs on the trim ring in the holes on the cover and twist clockwise

(fig.9)

.

complete the fitting of your shower accessories.
