sealed gas cooktop. KitchenAid 3186523

Sealed Gas Cooktop

Gas supply requirements

Input ratings shown on the model/serial

JBI

2,000 feet. For elevations above 2,000 feet ratings should be reduced at a rate of 4% for each 1,000 feet above sea level.

Copies of the standards listed above may be obtained from: l

American Gas Association

1515 Wilson Boulevard

Arlington, Virginia 22209

Explosion Hazard

Use a new AGA approved gas supply line.

Install a shut-off valve.

Securely tighten all gas connections.

If connected to LP, have a qualified person make sure gas pressure does not exceed water column rating specified in LP conversion kit. Examples of a qualified person include licensed heating personnel, authorized gas company personnel, and authorized service personnel.

Failure to do so can result in death, explosion, or fire.

Observe all governing codes and ordinances.

Important: Cooktop must be connected to a regulated gas supply.

This installation must conform with local codes and ordinances. In the absence of local codes, installation must conform with American National Standard,

National Fuel Gas Code ANSI 2223.1 - latest edition.*

Ic.I

This cook-top is manufactured for use with NATURAL gas and it is design- certified by A.G.A.

L.P. gas conversion

This cooktop can be converted for use with L.P. gas. However, no attempt shall be made to convert the appliance from the gas specified on the rating plate for use with a different gas without consulting the serving gas supplier.

Conversion must be done by a qualified service technician. Conversion Kit No. 4173627 is available from your KitchenAid dealer or authorized parts distributor.

Provide a gas supply line of 3/4” rigid

. pipe to the cooktop location. A

IDI smaller size pipe on long runs may result in insufficient gas supply. Pipe-joint compounds made for use with NATURAL and

L.P. gas must be used.

El

If local codes and ordinances permit,

. A.G.A.-design-certified, new flexible metal tubing is recommended for connecting cook-top to the gas supply line. Do

Not kink or damage the flexible tubing when moving the cooktop. A l/2” male pipe thread is needed for connection to pressure regulator female pipe threads. shutoff valve

“open” position

The supply line shall be equipped with an approved shutoff valve. This valve should be located in the same room as the cooktop and should be in a location that allows ease of opening and closing. Do Not block access to shutoff valve. The valve is for turning on or shutting off gas to the appliance.

El

If rigid pipe is

. used as a gas supply line, a co pipe fittings must be used connection to the cooktop. All strains must be removed from the supply and fuel lines so cooktop will be level and in line.

The regulator must be checked at a

. minimum 1” water column above the set pressure. The inlet pressure to the regulator should be as follows for operation and checking the regulator setting:

NATURAL GAS:

Set pressure 4 inches

Maximum pressure 14 inches

Line Pressure Testing:

Testing above l/2 psi (gauge)

The cooktop and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that pressures greater than l/2 psig (3.5 kPa).

Testing at l/2 psi (gauge) or lower

The cooktop must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than l/2 psig (3.5 kPa).

19

20 Sealed Gas Cooktop (cont.)

Electrical requirements

Electrical Shock Hazard

Plug into a grounded 3-prong outlet.

Do not remove ground prong.

Do not use an adapter.

Failure to follow these instructions can result in death, fire, or electrical shock.

If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate.

Do Not ground to a gas pipe.

Check with a qualified electrician if you are not sure the appliance is properly grounded.

Do Not have a fuse in the neutral or ground circuit.

See back page for wiring diagram.

A 120-volt, 60-Hz, AC only, 15-ampere, fused electrical supply is required. Time-delay fuse or circuit breaker is recommended. It is recommended that a separate circuit serving only this appliance be provided.

Electronic ignition systems operate within wide voltage limits, but proper grounding and polarity is necessary. In addition to checking that the outlet provides 120-volt power and is correctly grounded, the outlet must be checked by a qualified electrician to see if it is wired with correct polarity.

A wiring diagram is provided on the bottom of the cooktop box and in the literature package.

Recommended ground method

For your personal safety, this appliance must be grounded. This appliance is equipped with a power supply cord having a 3-prong ground plug.

To minimize possible shock hazard, the cord must be plugged into a mating 3-prong ground- type outlet, grounded in accordance with National

Electrical Code, ANSVNFPA 70 - latest edition and all local codes and ordinances. See Figure 8.

If a mating outlet is not available, it is the personal responsibility and obligation of the customer to have a properly grounded 3-prong outlet installed by a qualified electrician.

Sprang ground- type outlet 7m-l

Now start...

With cooktop and/or grill in kitchen.

If installing more than one appliance in the same cutout, work with one appliance at a time. Start with the appliance that will be to the left side of the cutout. Make all adjustments; then follow steps to add adjacent appliances.

)1. package from the side of the carton.

l-z-l

E-J caps package from shipping box.

Remove pressure regulator and hardware package from side of carton.

To avoid scratching countertop, lift entire cooktop up from cutout when repositioning cooktop into countertop opening.

13.1

Insert the cooktop into the countertop opening.

Check that the front of the cooktop is parallel to the front edge of the countertop. Check that all required clearances are met. Use a pencil to mark a line along the rear of the cooktop on the countertop.

4

Remove the cooktop from the cutout and place it upside down on a protected surface.

Remove the paper backing from a small section of the foam sealing strip. Place the strip l/8” from cooktop edge on the underside of the glass.

Continue until foam strip completely outlines the edge of the cooktop.

If you are installing more than one appliance in the same cutout, you do not need to place a foam strip on the side that will be adjacent to another appliance.

Do Not use additional sealant around outer edge of cooktop(

Attach mounting

151 side of the burner box with the 5/l 6” screws.

Do Not tiahten the screws. furn the mounting brackets so each is under the burner box. a

If you are installing additional appliances in the same cutout, attach one mounting bracket to the right side of each additional appliance.

Insert the cooktop into the cutout and align it with the pencil line. Check that cooktop is parallel to the front edge of the countertop. Lift the entire cooktop to make adjustments so the foam sealing strip can seal properly.

If you are installing only one appliance in cutout, go to Step 8.

If you are installing additional gas cooktops in the same cutout, complete Steps 1, 2, 4, 5, 6 and 7 for each additional appliance.

If you are installing an electric cooktop or grill or a downdraft vent as an additional appliance, read and follow specific installation instructions for those products. support brace

Do Not over-tighten screws.

I glass cooktop

I I

5/16” clamping bracket screw countertop

I /

One cooktop in cutout: Rotate the mounting brackets away from the burner box. Do Not overtighten screws: Tighten the mounting brackets to the burner box. Insert the

2-l/2” clamping screws into the mounting brackets. Use a screwdriver to tighten the screws against the underside of the countertop.

Remove the pencil outline from countertop. screws cooktop that will be adjacent to another appliance. Insert additional cooktop into the cutout and align with the pencil line used for first cooktop. Check that cooktop is parallel to the front edge of the countertop. Lift the entire cooktop to make adjustments so the foam sealing strip can seal properly.

Repeat for additional cooktops or grills.

21 Sealed Gas Cooktop (cont.)

Multiple cooktops and/or grill combinations:

Rotate the left mounting bracket away from the burner box of the first appliance. Tighten the mounting bracket to the burner box. Insert the

2-l/2” clamping screw into the mounting bracket.

Use a screwdriver to tighten the screw against the underside of the countertop.

Rotate right mounting bracket away from the burner box. Attach other end of mounting bracket to adjacent appliance with a 5/l 6” screw. Use a screwdriver to tighten mounting bracket to both appliances. Repeat for each additional appliance.

Rotate mounting bracket of the appliance that will be adjacent to the right side of the cutout away from the burner box. Tighten the mounting bracket to the burner box. Insert the 2-l/2” clamping screw into the mounting bracket. Use a screwdriver to tighten the screw against the underside of the countertop.

Remove the pencil outline from countertop.

191 arrow on the regulator pointing up toward unit and in a position where you can reach the access cap.

3/B” nipple

3W nipple flexible connector

Use pipe-joint compound made for use with NATURAL and L.P. gas to seal all gas connections. If flexible connectors are used, be certain connectors are not kinked.

318” adapter

\ manual shutoff valve

All connections must be wrench-tightened. pressure regulator

Assemble the flexible connector from the aas

SUDDIV oipe to the oressure regulator in orde;: Man;l’aishutoff valve, 318” nipple, 3/8” adapter, flexible connector, 318” adapter, and 3/8” nipple.

22

Open the shutoff valve in the gas supply line.

Wait a few minutes for gas to move through the gas line.

Numbers correspond to steps.

1131

test all gas connections for leaks.

Bubbles around connections will indicate a leak.

If a leak appears, shut off gas valve controls and adjust connections. Then check connections again. NEVER TEST FOR GAS LEAKS WITH A

MATCH OR OTHER FLAME. Clean all detergent solution from cooktop.

Plug the power supply cord into the grounded outlet.

115.1

Place burner grates over burners and caps. Install control knobs on valve stems.

Electronic Ignition System - initial lighting

Cooktop burners use electronic ignitors in place of standing pilots. When the cooktop control knob is turned to the “HI” position, the system creates a spark to light the burner. This sparkina continues until the burner ignites.

I I6.1Checkthe

- operation of the cooktop burners.

Push in and turn each control knob to “HI” position. The flame should light within 4 seconds.

If the burners do not light properly, turn the control knob to the “OFF” position. Check that the burner cap is plugged in and that the circuit breaker or fuse has not blown. Check that the shutoff valve is in the “ON” position. Check operation again. If burner does not light at this point, contact your KitchenAid dealer for assistance.

6 b-l n

Push in and turn each control knob l ~ - -1 to the “LO” (or simmer) setting. The

“LO” setting of each burner has been factory set to the lowest setting available to provide reliable reignition of the burner. If it does not stav lit on the”L0” setting, contact your KitchenAid dealer for assistance.-

To get the most efficient use from your new cooktop, read your

KitchenAid Use and Care Guide.

Keep Installation Instructions and

Guide close to cooktop for easy reference.

1171 for prooer flame. The small inner cone should have a very distinct blue flame approximately l/2” long. The outer cone is not as distinct as the inner cone.
