Introduction

This appendix includes some background to the calculation of the UIC774-3 track/bridge interaction analyses in LUSAS. It explains why results from running a

LUSAS nonlinear analysis that considers all thermal and train effects for the test cases in question in one analysis does not over-predict the rail stresses occurring under the combined thermal and rail loading - unlike results from simplified hand calculations or from results from other finite element analysis software systems where thermal and train effects are carried out by running separate nonlinear analyses.

From the verification testing carried out we can say that…

Even though a computer program may be validated against the standard test cases in the UIC774-3 code of practice, in situations when combined thermal and train loading from separate analyses gives track-structure interaction forces that exceed the stated yield resistance of the trackrestraint system (i.e. the ballast) then the separate analysis method will potentially over predict the rail stresses unless the loaded track yield surface is reduced by the mobilised track resistance over the extent of the train loading.

Rail stress over-predictions of up to 30% have been seen when thermal and train loading results are combined from separate analyses.

Description

The rail track analysis (UIC774-3) option in LUSAS allows the construction and solution of finite element models to study the interaction between the rail track and a bridge. This forms an essential part of the design process as the stresses within the rails of the tracks must remain within specified limits based upon the design and the state of maintenance. A number of calculation methods are available and each of these can lead to a slightly different solution for the combined thermal and rail loading condition. Each of these methods (except the hand calculation) has been investigated in this technical note prior to carrying out the analysis in LUSAS using the rail track analysis option.

27

Rail Track Analysis User Manual

The Hwashil Viaduct, a railway bridge in South Korea, has been used for this testing with continuous welded rail (CWR) and thermal effects only present in the structure for the following analyses:

In addition, two of the UIC standard test cases have also been reinvestigated to demonstrate that these results can be matched even if the analysis type is potentially invalid prior to providing guidance and conclusions on this type of analysis. These analyses were:

Combination of Separate Thermal And Rail Loading

In this form of analysis two or more separate analyses are carried out with each analysis considering a different loading regime to the structure. This is the simplest form of analysis of the track/bridge interaction as it assumes that superposition is valid for a nonlinear system and, according to the UIC774-3 code of practice, can generally overestimate the rail stresses with percentage errors up to 20 to 30% be it through hand calculation or computer methods.

This analysis procedure is replicated in LUSAS by performing two separate nonlinear analyses. The first considers only the thermal effects and uses the unloaded resistance bilinear curve for modelling the interaction between the track and bridge. The results of this analysis are identical for the two tracks in the model and so only the results for the first track are presented in the following figure.

28

Combination of Separate Thermal And Rail Loading

Figure 29: Axial Force In Rails Due To Thermal Effects Only

These thermal effects give a peak compressive rail stress of 46.06 N/mm

2

(F/A =

0.7065E+06/0.0153389). Having carried out the thermal analysis the rail loading will be considered in a separate analysis (both horizontal and vertical loading) for the

„worst‟ conditions. This rail load analysis is again a nonlinear analysis but it has no knowledge of the history from the thermal effects and therefore assumes a zero strain initial state prior to the application of the load. In addition to this unstrained condition, the loaded resistance bilinear curve is used underneath the locations of the rail loading while the unloaded lengths of track use the unloaded resistance bilinear curve. The results from the rail loading analyses are presented in the following two figures, the first being the track that has the braking train loading and the second being the track that has the accelerating train loading.

29

Rail Track Analysis User Manual

Figure 30: Axial Force In Rails Due To Braking Train Loads On Track 1

Figure 31: Axial Force In Rails Due To AcceleratingTrain Loads On Track 2

30

Combination of Separate Thermal And Rail Loading

From these results the peak compressive rail stresses for the two tracks are as follows:

Track 1: 48.93 N/mm

2

Track 2: 57.59 N/mm

2

A basic combination of the loading can be defined to add the results from the thermal and rail loading analyses together which gives the following track peak compressive stresses (see following figures):

Track 1: 94.99 N/mm

2

Track 2: 103.66 N/mm

2

Figure 32: Axial Force In Rails Due To Combined Thermal And Train Loads In

Track 1

31

Rail Track Analysis User Manual

Figure 33: Axial Force In Rails Due To Combined Thermal And Train Loads In

Track 2

Inspection of the two plots shows that there is a reduction in the axial force / rail stresses over the first two span transition piers towards the left end of the structure for track 1 only (subjected to the braking train). The following figures show zoomed plots of the rail axial force for this location with the thermal diagram showing identical values either side of these piers for all of the spans in the model. The reason for the reduction in the axial force becomes clear from the axial force diagram for the train

braking load alone, Figure 35, where the axial force has a positive peak over the span

transition piers which is not symmetrical. Looking at the transition from the first span to the second (2 nd

pier from left abutment) the axial force in the rail over the end of the first span is equal to a tension force of 362.4 kN while the axial force over the start of the second span is equal to a tension force of 344.7 kN. Like for like comparison of the elements a certain distance from the pier for each span shows that the second span is consistently lower and this difference has caused the nonsymmetric nature of the combined axial force / rail stress diagram over the span transition piers.

32

Combination of Separate Thermal And Rail Loading

Figure 34: Zoomed Axial Force In Rails Due To Thermal Effects Only

Figure 35: Zoomed Axial Force In Rails Due To Braking Train Loads On Track 1

33

Rail Track Analysis User Manual

NOTE: When viewing this axial force diagram it should be recognised that while the first two spans (2*25m each) have identical geometry and pier/bearing properties, the first span segment of the first span does not carry any of the braking train load and this is contributing to the difference in the behaviours observed over the piers.

Looking at the yield in the track/bridge interaction for this track, Figure 36, the reason

for the differences in axial force either side of the pier becomes clear as yielding has occurred to the left but not to the right of the span transition pier for these first two spans.

Figure 36: Yield In Track/Bridge Interaction Due To Train Braking Load On Track

1

34

Combination of Separate Thermal And Rail Loading

Looking now at the second track where the accelerating train is at the right-hand end of the structure, the interaction remains unloaded and so the rail axial force / stress observed it basically due to the bending of the bridge deck due to the action of the braking train load on the other track. Because there is no direct loading to the track then the axial force in the rail displays a continuous variation over the span transition piers and therefore no reduction is observed in the combined diagram for this track.

Figure 37: Zoomed Axial Force In Rails Due To Accelerating Train Loads On Track

2

Looking again at the yielding, Figure 38, the difference between this track and the one

with the braking train becomes obvious as, without the action of any train load over the span transition for this track, the yield is roughly symmetrical and occurring across the transition between spans – colour change indicates changing yield direction. This yield over the whole region of the span transition is the whole reason why a smooth behaviour is observed in the rail force / stress in the second track as opposed to the first track that has the braking train load.

35

Rail Track Analysis User Manual

Figure 38: Yield In Track/Bridge Interaction Due To Train Acceleration Load On

Track 2

Analysis Of Combined Thermal And Rail Loading (One Step)

In this form of analysis a single nonlinear analysis is carried out where the thermal and rail loading are applied concurrently to the model. In terms of the track/bridge interaction, the resistance bilinear curves used in the modelling are determined by the positioning of the rail loading so that loaded properties are used where the rail loading is applied and unloaded properties everywhere else. As with the separate method highlighted above, this analysis ignores any initial straining of the track/bridge interaction under pure thermal loading and therefore assumes that the loaded resistance properties are active under the thermal loading over the extent of the train loading.

The results from the analysis are shown in the following figures and give the following results for the track peak compressive stresses:

Track 1:

Track 2:

85.6 N/mm

2

100.6 N/mm

2

NOTE: For this analysis the reduction in axial force / rail stress is not observed at the span discontinuities towards the left end of the structure.

36

Analysis Of Combined Thermal And Rail Loading (One Step)

Figure 39: Axial Force In Rails Due To Combined Thermal And Train Loads In

Track 1 (One Step)

Figure 40: Axial Force In Rails Due To Combined Thermal And Train Loads In

Track 2 (One Step)

37

Rail Track Analysis User Manual

Analysis Of Combined Thermal And Rail Loading Taking

Account Of Effects Of Material Change Under Rail Loading

The previous two analysis methods fail to take account of the train rail loading being applied to the rail when it has already undergone movement/stresses due to thermal effects alone. In this current form of analysis (implemented into LUSAS) the initial thermal effects are considered prior to the application of the train rail loading and the behaviour under this rail loading takes account of this history.

To illustrate the analysis, consider the following:

When the train is not on the track the stresses in the rails are governed purely by the thermal effects. For the Hwashil Viaduct the thermal effects due to the bridge only are considered and therefore the action of this causes the structure to move thus inducing relative movement between the track and the bridge and therefore an associated stress in the rail. For this condition the unloaded resistance properties apply across the whole extent of the track

As the train load arrives over a particular part of the bridge the initial relative movement of the track/bridge from the thermal effects remains and therefore the application of the train load changes the resistance state from unloaded to loaded without the loss of this initial rail stress caused by the relative movement

The train load causes increased slip of the interaction based on the loaded resistance with the end of the force-displacement curve for the unloaded resistance used as the starting point for the loaded resistance

If it was modelled, the departure of the train load would change the resistance state back to unloaded

38

Analysis Of Combined Thermal And Rail Loading Taking Account Of

Effects Of Material Change Under Rail Loading

Yield Of Loaded Track

Loaded Resistance Under

Thermal And Train Load

Yield Of Unloaded Track

Unloaded Resistance

During Thermal Load

Force-strain corresponding to applied thermal loading (no train)

Strain

Figure 41: Representation Of Transition From Unloaded To Loaded In LUSAS

The key is that the interaction resistance switches from unloaded to loaded the moment the rail load arrives thereby „locking in‟ any initial movement that has occurred under the thermal loading until that rail load departs. The results from this form of analysis are shown in the following figures which give peak compressive rail stresses of:

Track 1 and 2 (Thermal Only): 46.06 N/mm

2

Track 1 (Thermal and Train): 79.08 N/mm

2

Track 2 (Thermal and Train): 92.58 N/mm

2

39

Rail Track Analysis User Manual

Figure 42: Axial Force In Rails Due To Thermal Only

Figure 43: Axial Force In Rails Due To Combined Thermal And Train Loads In

Track 1

40

Analysis Of Combined Thermal And Rail Loading Taking Account Of

Effects Of Material Change Under Rail Loading

Figure 44: Axial Force In Rails Due To Combined Thermal And Train Loads In

Track 2

The analyses produced using this method can give a lower peak compressive stress in the rails than observed using the other approaches but agrees closely with the published test cases using rigorous methods in UIC774-3 as observed in the following sections for test E1-3 and H1-3.

Discussion

The peak compressive stresses in track/rail 2 which has the accelerating load and track/rail 1 that is subjected to the braking train show differences in the peak compressive stress in the rails based on the position of the train loads used in the analysis. As the loading and geometry of the models are identical the differences can only be associated with the track resistance modelling/behaviour. It has been noted

previously in Section 0 above that the transition from unloaded resistance to loaded

resistance is only incorporated into the LUSAS modelling so this track resistance is investigated by looking at the yield under the effects of the rail loading.

Looking first at the second track/rail that has the accelerating load, the yielding occurring from the three analyses are shown in the following figures. Comparing the

yield layout for the LUSAS analysis (Figure 48) and the concurrent thermal/train loading analysis (Figure 47) shows that the overall yield behaviour is almost identical,

hence the similarity in the peak compressive rail stresses obtained albeit with the

LUSAS value slightly lower. Looking now at the separate analysis, the yield layout for both the LUSAS and concurrent thermal/train loading analyses are comparable

41

Rail Track Analysis User Manual

with the yield layout for thermal effects alone (Figure 45) with very little yield associated with the accelerating rail load analysis (Figure 46). This is primarily due to

the accelerating train only just entering the bridge with the majority of the loads over the right approach embankment which are vertical not horizontal.

Figure 45: Track/Rail 2 Yield Due To Thermal Load On Track Alone

Figure 46: Track/Rail 2 Yield Due To Accelerating Train Loads On Track 2 –

Separate Analysis

42

Analysis Of Combined Thermal And Rail Loading Taking Account Of

Effects Of Material Change Under Rail Loading

Figure 47: Track/Rail 2 Yield Due To Accelerating Train Loads On Track 2 -

Thermal And Rail Applied Concurrently

Figure 48: Track/Rail 2 Yield Due To Accelerating Train Load On Track 2 - LUSAS

Combined Analysis

43

Rail Track Analysis User Manual

Looking at what is effectively happening in these analyses, Figure 49, the concurrent

loading analysis uses the loaded resistance throughout the analysis and follows the loaded stiffness curve from the origin and potentially gives the location indicated on the plastic part of this curve as illustrated with a force in the interaction limited to the resistance of the loaded track. For the separate analysis, the thermal effects use the unloaded curve and the behaviour of this part of the analysis is limited by the resistance of the unloaded track. Under these conditions the analysis may give a location indicated by the „Thermal Alone‟ point on the unloaded curve. Separate consideration of the train loading effectively places the origin of the loaded bilinear curve at this „Thermal Alone‟ position and any loading could potentially give the location indicated by the „Separate Train Load Added To Thermal‟ position. This could give an apparent increase in the resistance of the track and therefore increase rail stresses in the loaded track.

Separate Train Load

Added To Thermal

Concurrent thermal and train loading (loaded resistance)

Apparent increase in resistance of loaded track

Loaded Stiffness

Thermal Alone

Strain

Unloaded stiffness

(Thermal)

Figure 49: Illustration Of Behaviour Of Separate Analysis Vs. Concurrent Thermal

And Rail Loading

44

Analysis Of Combined Thermal And Rail Loading Taking Account Of

Effects Of Material Change Under Rail Loading

Similar comparisons can be made between the separate analysis and the LUSAS

analysis - Figure 50. While both of these effectively use the „Thermal Alone‟ location

as an origin for the loaded resistance curve, the key difference between the two approaches is that the LUSAS analysis enforces the track resistance at which plasticity occurs instead of allowing the potential for an apparent increase in the track resistance equal up to the unloaded plus the loaded track resistance.

These differences have affected the peak compressive rail stresses in the track subjected to accelerating train loads with all three analyses predicting stresses in the range of 93 to 103 N/mm

2

.

Separate Train Load

Added To Thermal

Apparent increase in resistance of loaded track

LUSAS Analysis

Loaded Stiffness

Thermal Alone

Strain

Unloaded stiffness

(Thermal)

Figure 50: Illustration Of Behaviour Of Separate Analysis Vs. LUSAS Analysis

Looking now at the track/rail that has the braking train on it, the following figures show the same yield plots for this track/rail resistance. The immediate observation is the different yield behaviour observed for the LUSAS analysis. Looking initially at the separate analysis and the concurrent thermal and rail loading analysis the yielding

observed in the thermal alone for the separate analysis (Figure 51) shows close

similarity to the yielding observed when the thermal and train loading are applied

concurrently (Figure 53) – minimal yielding is observed under the action of the train load alone in the separate analysis (Figure 52).

45

Rail Track Analysis User Manual

Concentrating on the LUSAS analysis, the front of the braking train load is just over the right end of the structure and the carriages cover most of the remaining bridge.

This has the effect, unlike the accelerating track, of changing nearly all of the resistance from unloaded to loaded for this track over the bridge and therefore the interaction is no longer under yield because the loaded resistance now governs plastic yield. The LUSAS analysis however does not display the possible apparent increase in the resistance of the track that can be observed with the separate analysis method.

This means the track interaction around the front of the braking train resisting the movement of the rails cannot sustain the same level of loading and therefore yield to a larger extent than observed in the separate analysis, thereby reducing the compressive

stress in the rails underneath the train – compare Figure 52 and Figure 54 where the

yielding underneath the braking train is greater for the LUSAS analysis than in the separate rail load analysis.

Figure 51: Track/Rail 1 Yield Due To Thermal Load On Track Alone

46

Analysis Of Combined Thermal And Rail Loading Taking Account Of

Effects Of Material Change Under Rail Loading

Figure 52: Track/Rail 1 Yield Due To Braking Train Loads On Track 1 – Separate

Analysis

Figure 53: Track/Rail 1 Yield Due To Braking Train Loads On Track 1 - Thermal

And Rail Applied Concurrently

47

Rail Track Analysis User Manual

Figure 54: Track/Rail 1 Yield Due To Braking Train Load On Track 1 - LUSAS

Combined Analysis

48

Analysis Of Combined Thermal And Rail Loading Taking Account Of

Effects Of Material Change Under Rail Loading

Looking at the behaviour of the track interaction for the separate analysis we can plot the values of the force per metre length for the track subjected to the braking train

loads. Figure 55 and Figure 56 show the forces per metre length for the thermal

loading and the train braking loading for the separate analyses. Clearly, near the righthand abutment, the force per metre length under the thermal loading is equal to

40kN/m and due to the train loading is equal to 60kN/m. Combination of these two results means that the track interaction has mobilised 100kN/m in this region when it is actually only able to mobilise 60kN/m based on the loaded track resistance bilinear curve – the separate analysis method is giving an apparent increase in the loaded track resistance that can be mobilised before plastic yielding occurs. This apparent increase in the loaded track resistance has the consequence of allowing the rail stresses to increase beyond the value that would occur if the true loaded track resistance was used as in the LUSAS modelling where the track resistance is correctly limited to the

loaded value of 60kN/m – Figure 57.

NOTE: This difference in the amount of track resistance that can be mobilised in the loaded condition is the main reason for the differences in the solutions obtained for the separate and LUSAS methods and demonstrates that the correct modelling of the interaction is critical to the solution.

Figure 55: Force In Interaction At Right-Hand End Of Structure Where Peak

Compressive Stresses Occur In The Rail - Track 1 – Separate Thermal Loading (N/m length)

49

Rail Track Analysis User Manual

Figure 56: Force In Interaction At Right-Hand End Of Structure Where Peak

Compressive Stresses Occur In The Rail - Track 1 - Separate Train Loading (N/m length)

Figure 57: Force In Interaction At Right-Hand End Of Structure Where Peak

Compressive Stresses Occur In THe Rail - Track 1 – LUSAS Nonlinear (N/m length)

50

Revisit Of UIC774-3 Test E1-3 Using The Separate And LUSAS Methods

Of Analysis

Revisit Of UIC774-3 Test E1-3 Using The Separate And

LUSAS Methods Of Analysis

The standard UIC774-3 test E1-3 has been reanalysed using the following two approaches:

The results of these two analyses are presented in the following sections and then discussed briefly.

Separate Analyses

The analysis of the thermal effects due to the temperature in the bridge and rail are presented in the following figure. These two thermal effects give a peak compressive rail stress of 150.21 N/mm

2

which compares well with the code of practice value of

156.67 N/mm

2

(allowing for slight differences in material properties which have been estimated).

Figure 58: Axial Force In Rails Due To Temperature In Bridge And Rail

To determine the worst location of the train load for compressive rail stresses the bridge has been analysed with the rail loading at 31 separate locations (starting from

51

Rail Track Analysis User Manual

the left abutment of the bridge and finishing 90m from the right abutment of the bridge – train moving from left to right) and these results enveloped. The results of this analysis are presented in the following figure which give a peak compressive rail stress of 40.64 N/mm

2

.

Figure 59: Envelope Of Axial Force In Rails Due To Rail Loading

Manual combination of the peaks would give a peak compressive rail stress of 190.85

N/mm

2

(ignoring locations of the peaks) and combination of the results in LUSAS gives 190.82 N/mm

2

.

52

Revisit Of UIC774-3 Test E1-3 Using The Separate And LUSAS Methods

Of Analysis

Figure 60: Axial Force In Rails Due To Combined Temperature And Rail Loading

Comparison of these results with the UIC774-3 code of practice test results shows that the result compares directly with the 190.07 N/mm

2

compressive rail stress from the simplified analysis in the test case (which is based on evaluating the effect of each part of the loading separately) and are close to the rigorous answer of 182.4 N/mm

2

.

LUSAS Nonlinear Analysis

The UIC774-3 E1-3 test case has been reanalysed using the LUSAS rail option and gives the following peak compressive rail stress for the thermal loading alone and the combined thermal and rail loading:

Thermal: 150.21 N/mm

2

Thermal & Rail: 187.56 N/mm

2

Comparison of the results shows that the rail stresses are in excellent agreement for both parts of the analysis with the compressive rail stress having a percentage error of

2.83% when compared against the target rigorous solution of 182.4 N/mm

2

.

53

Rail Track Analysis User Manual

Figure 61: Axial Force In Rails Due To Temperature In Bridge And Rail

Figure 62: Axial Force In Rails Due To Combined Temperature And Enveloped Rail

Loading

54

Revisit Of UIC774-3 Test E1-3 Using The Separate And LUSAS Methods

Of Analysis

Discussion

For this test case the difference in the results due to the track resistance modelling between the two methods is minimal. Combining the results of two nonlinear analysis, while invalid, gives almost identical results to the LUSAS analysis which correctly represents the transition from unloaded to loaded resistance on arrival of the train load. The train load position that gives the worst compressive stress in the rail does however differ slightly between the two analyses with the separate analysis giving a train front position of 75m from the left abutment of the bridge and the

LUSAS combined analysis giving a train front position of 80m from the left abutment of the bridge.

Looking at the yield behaviour it becomes clear why the two methods agree so closely for this UIC774-3 standard test case and not for the Hwashil Viaduct. For both analyses, the rail stresses and interaction yield over the single span bridge due to

thermal loading are identical – Figure 63. On consideration of the train loading, the

right-hand end of the structure (roller bearing) where the peak compressive rail stresses are observed shows no sign of yield with yield only occurring over the left

end and embankment – Figure 64 and Figure 65. This indicates that the separate

analysis, while invalid due to the linear combination of two nonlinear analyses, is giving the correct result and this only occurs because the interaction over the structure at this location is nowhere near yield.

Figure 63: Yield Layout For Thermal Loading Only

55

Rail Track Analysis User Manual

Figure 64: Yield Layout For Train Loading Only From Separate Analysis

Figure 65: Yield Layout For Combined Thermal And Train Loading From LUSAS

Nonlinear Analysis

56

Revisit Of UIC774-3 Test E1-3 Using The Separate And LUSAS Methods

Of Analysis

The following two plots show the forces in the interaction joints for the thermal and train loads from the separate analysis. The thermal loading has caused yielding of the unloaded track interaction with a value of 20 kN/m in accordance with the unloaded resistance but the train loads have only induced up to about 25.7 kN/m over the structure. Combining these two results means that the total force per unit length for the separate analysis is 45.7 kN/m which is comparable to the LUSAS nonlinear

solution of 40.4 kN/m – see Figure 68. Because the interaction is well below yield for

the loaded interaction resistance of 60 kN/m the two solution method effectively have

identical solutions and their behaviour can be visualised in Figure 69.

If, however, the train loading had induced interaction forces in the region of 40 kN/m

(taking account of the track resistance already mobilised by the thermal loading) instead of the observed 25.7 kN/m then significant differences could be observed in the two analysis methods as the separate method would still allow a further 20 kN/m track resistance to be mobilised before the onset of plastic yielding and the separate analysis would potentially over predict the rail stresses occurring. This potentially means that…

…even though a computer program is validated against the standard test cases in the UIC774-3 code of practice, it may be predicting excessive rail stresses if it does not correctly take account of the loaded track resistance

that can be mobilised.

Figure 66: Force Per Metre Length In Interaction From Thermal Loading - Separate

Analysis

57

Rail Track Analysis User Manual

Figure 67: Force Per Metre Length In Interaction From Train Loading - Separate

Analysis

Figure 68: Force Per Metre Length In Interaction From Combined Loading - LUSAS

Analysis

58

Revisit Of UIC774-3 Test E1-3 Using The Separate And LUSAS Methods

Of Analysis

Apparent Loaded Yield Separate Analysis

Loaded Yield LUSAS Analysis

Loaded Stiffness

Separate Train Load

Added To Thermal

And LUSAS Analysis

Thermal Alone

Strain

Unloaded stiffness

(Thermal)

Figure 69: Illustration Of Behvaiour For UIC774-3 Standard Test E1-3 For Separate

And LUSAS Analyses

59

Rail Track Analysis User Manual

Revisit Of UIC774-3 Test H1-3 Using The Separate And

LUSAS Methods Of Analysis

The previous test case (E1-3) is one of the key test cases that must be matched for computer programs carrying out this form of analysis with the results for both the separate method and the LUSAS method being in close agreement to the results required. The deck type for this test is however a concrete slab underlain by I-section steel beams which does not compare with the deck being used for Hwashil Viaduct.

For this reason the H1-3 test is also revisited and solved using the two methods of analysis.

Separate Analyses

The analysis of the thermal effects due to the temperature in the bridge and rail are presented in the following figure. These two thermal effects give a peak compressive rail stress of 161.48 N/mm

2

which compares well with the code of practice value of

169.14 N/mm

2

(allowing for slight differences in material properties which have been estimated).

Figure 70: Axial Force In Rails Due To Temperature In Bridge And Rail

To determine the worst location of the train load for compressive rail stresses the bridge has been analysed with the rail loading at 37 separate locations (starting from the left abutment of the bridge and finishing 90m from the right abutment of the

60

Revisit Of UIC774-3 Test H1-3 Using The Separate And LUSAS Methods

Of Analysis

bridge – train moving from left to right) and these results enveloped. The results of this analysis are presented in the following figure which give a peak compressive rail stress of 29.09 N/mm

2

.

Figure 71: Envelope Of Axial Force In Rails Due To Rail Loading

Manual combination of the peaks would give a peak compressive rail stress of 190.57

N/mm

2

(ignoring locations of the peaks) and combination of the results in LUSAS gives 190.56 N/mm

2

.

61

Rail Track Analysis User Manual

Figure 72: Axial Force In Rails Due To Combined Temperature And Rail Loading

Comparison of these results with the UIC774-3 code of practice test results shows that the result compares well with the 188.23 N/mm

2

compressive rail stress from the complex analysis in the test case.

LUSAS Nonlinear Analysis

The UIC774-3 H1-3 test case has been reanalysed using the LUSAS rail option and gives the following peak compressive rail stress for the thermal loading alone and the combined thermal and rail loading:

Thermal: 161.48 N/mm

2

Thermal & Rail: 189.65 N/mm

2

Comparison of the results shows that the rail stresses are in excellent agreement for both parts of the analysis with the compressive rail stress having a percentage error of

0.75% when compared against the target solution of 188.23 N/mm

2

.

62

Revisit Of UIC774-3 Test H1-3 Using The Separate And LUSAS Methods

Of Analysis

Figure 73: Axial Force In Rails Due To Temperature In Bridge And Rail

Figure 74: Axial Force In Rails Due To Combined Temperature And Enveloped Rail

Loading

63

Rail Track Analysis User Manual

Discussion

As with the previous E1-3 test case, the difference in the results due to the track resistance modelling between the two methods is minimal. Combining the results of two nonlinear analysis, while invalid, gives almost identical results to the LUSAS analysis which correctly represents the transition from unloaded to loaded resistance on arrival of the train load. The train load position that gives the worst compressive stress in the rail does however differ slightly between the two analyses with the separate analysis giving a train front position of 100m from the left abutment of the bridge and the LUSAS combined analysis giving a train front position of 110m from the left abutment of the bridge.

Referring back to test E1-3, similar plots can be generated for the yield and forces in the interaction. These, as with the E1-3 test, show that the train loading is not bringing the force per metre length in the interaction close the loaded yield resistance of 60 kN/m and therefore the separate analysis and LUSAS analysis methods agree even though the separate method potentially allows more track resistance to be mobilised than is allowed when the thermal and rail results are combined.

Separate: 27.8 kN/m

LUSAS: 26.1 kN/m

Figure 75: Force Per Metre Length In Interaction From Thermal Loading - Separate

Analysis

64

Revisit Of UIC774-3 Test H1-3 Using The Separate And LUSAS Methods

Of Analysis

Figure 76: Force Per Metre Length In Interaction From Train Loading - Separate

Analysis

Figure 77: Force Per Metre Length In Interaction From Combined Loading - LUSAS

Analysis

65

Rail Track Analysis User Manual

Conclusions

Three solution methods for carrying out the UIC track/bridge interaction analyses have been investigated and differences observed in the assumed behaviour and results highlighted. The key observations were as follows:

Separate Thermal And Rail Loading Analysis

Concurrent Thermal And Rail Loading Analysis

LUSAS Nonlinear Thermal And Rail Analysis With

Material Change

66

References

Referring back to Figure 49 and Figure 50, the key issue with the separate analysis

approach is the ability for the track resistance to be overestimated by the combination of the two nonlinear analyses and potentially cause the rail stresses to be overestimated. In the concurrent loading and LUSAS rail option analyses the limit of track resistance is correctly modelled as the value determined from the loaded bilinear curve and therefore this potentially leads to reduced rail stresses observed in the analyses. As the initial movement under pure thermal loading in the concurrent analysis uses the loaded track resistance this will give different results to the LUSAS rail option analysis. Referring back to the Hwashil Viaduct analyses, the rail stresses observed for the three analysis types are:

Separate Analysis

Of Thermal And

Train Loading

Concurrent

Thermal And

Train Loading

LUSAS Nonlinear

Thermal And Train

Loading With Material

Change

79.08

Track 1 (Braking)

94.99 85.6

103.66 100.6 92.58

Track 2 (Accelerating)

Table 1: Comparison Of Peak Compressive Rail Stresses (in N/mm

2

) For Different

Analysis Methods

Comparison of the results for the separate and LUSAS analyses shows that the peak compressive stress for the separate analysis is 1.2 times that of the LUSAS analysis for track 1 and 1.12 times for track 2. It should be noted however that the separate analysis could be giving an apparent increase in track resistance of up to 1.6 times that of the loaded track due to the combination of the nonlinear results. The concurrent analysis gave results that are between the separate and LUSAS analysis as expected since the correct limit of loaded track resistance is modelled even though the thermal effects are only approximated.

One overall conclusion is obvious from these test case analyses and discussions made in this appendix:

When a combined thermal and train loading from a separate analysis gives interaction forces that exceed the stated yield resistance then the separate analysis method will potentially over predict the rail stresses unless the loaded track yield surface is reduced by the mobilised track resistance over the extent of the train loading.

References

U1 UIC Code 774-3 R. Track/bridge Interaction. Recommendations for

Calculations (2001) Union Internationale des Chemins de fer, Paris, France

67

Rail Track Analysis User Manual

68

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
