Overview

The ViVOpay Kiosk II is a compact stand-alone contactless reader designed to support contactless transactions based on ISO 14443 Type A/Type B/MiFare compatible cards, fobs, and tags as well as NFC phones. The ViVOpay Kiosk II is comprised of a compact controller module and an antenna module packaged individually. This two-part design allows the controller module to be installed within the cabinetry of a kiosk and the antenna installed on an exterior surface with a separation of up to 1 meter. The antenna is available with a square or angled bezel.

The ViVOpay Kiosk II supports USB and serial RS232 host communication using the protocol defined in the Global Reader Serial Interface Developers Guide. The ViVOpay

Kiosk II is designed to support a wide input power range. Both data and power can be supplied via a single cable to reducing the effort and complexity of installation.

Features

 Supports ISO 14443 Type A, Type B, MiFare and NFC based contactless transactions

 32-bit Microcontroller with ample memory capable of supporting future application upgrades

 Crypto data processing for contactless EMV cards

 RS232 (9600, 19200, 38, 400, 57, 600, 115, 200 baud) host interface

 RS232 or USB data communications

 Small antenna flush-mounted on external cabinetry with square or angled bezel

 Internal mounted controller board with 1 meter controller/antenna separation

Valid Card Types

ViVOpay Kiosk II supports the following contactless payment applications in the latest release of firmware:

 ISO 14443

M/Stripe

 PayPass

 PayPass

MXI

 VisaWave 1 and 2

 VisaPay/Wave MSD and qVSDC

 JCB

J/Speedy

 JCB

 American Express- ExpressPay

Zip ePurse

Copyright © 2010-2014, International Technologies & Systems Corp. All rights reserved.

Page 5 of 18

Kiosk II Specifications

Hardware

MTBF

Transmitter Frequency

Transmitter Modulation

Receiver Subcarrier Frequency

Receiver Subcarrier Data

Typical Read Range

Physical

Controller

Square Bezel Antenna

Angle Bezel Antenna

Environmental

Operating Temperature

Storage Temperature

Operating Humidity

Operating Environment

Electrical

Reader Input Voltage

500,000 hrs based on Telcordia Technologies

SR-332 modeled at 40° C.

13.56 MHz +/- 0.01%

ISO 14443-2 Type A

Rise/Fall Time: 2-3 µsec. Rise, <1 µsec fall

ISO 14443-2 Type B

Rise/Fall Time: <2 µsec. each; 8%-14% ASK

847.5 KHz

ISO 14443-2 Type A: Modified Manchester

ISO 14443-2 Type B: NRZ-l, BPSK

4-6 cm (1.5 to 2.3 inches)

Height 105 mm (4.13 inches)

Width 76.2 mm (3.00 inches)

Depth 22.5 mm (0.88 inches)

Height 75 mm (2.95 inches)

Width 60 mm (2.36 inches)

Depth 16.8 mm (0.66 inches)

Height 96.2 mm (3.787 inches)

Width 82.3 mm (3.24 inches)

Depth 16.8 mm (0.66 inches)

-25° to 70° C (-13° to 158° F)

-40° to 85° C (-40° to 185° F)

10% to 90% non-condensing

Water resistant for indoor and outdoor use

+7.5v to 36 VDC

Copyright © 2010-2014, International Technologies & Systems Corp. All rights reserved.

Page 6 of 18
