Control for HDMI/External Audio Device. Sony 3-285-995-11(1), DAV-DZ660
62
GB
Control for HDMI/External Audio
Device
Using the Control for
HDMI Function for
“BRAVIA” Sync
This function is available on TVs with the
“BRAVIA” Sync function only.
By connecting Sony components that are compatible with the Control for HDMI function with an HDMI cable (not supplied), operation is simplified as below:
– System Audio Control (page 64)
Control for HDMI is a mutual control function standard used by CEC (Consumer Electronics
Control) for HDMI (High-Definition
Multimedia Interface).
The Control for HDMI function will not work in the following cases:
– When you connect this system to a component which is not compatible with the
Control for HDMI function.
– A component does not have an HDMI jack.
There are convenient buttons on the system’s remote for operating the TV, such as
THEATRE, ONE-TOUCH PLAY, TV [/1. For
details, see “Controlling the TV with the
Supplied Remote” (page 83) and refer to the
operating instructions of the TV.
THEATRE
ONE-TOUCH
PLAY TV
BRAVIA Sync
Note
• Depending on the connected component, the Control for HDMI function may not work. Refer to the operating instructions supplied with the component.
• The Control for HDMI function may not work if you connect a component other than Sony, even if the component is compatible with the Control for HDMI function.
Preparing for the Control for
HDMI function
(Control for HDMI - Easy Setting)
The system is compatible with the Control for
HDMI - Easy Setting function. If the TV is compatible with the Control for HDMI - Easy
Setting function, you can set the system’s
[CONTROL FOR HDMI] function automatically by setting the TV. For details, refer to the operating instructions of the TV.
If the TV is not compatible with the Control for
HDMI - Easy Setting function, set the Control for HDMI function of the system and TV manually.
Note
• Displayed items vary depending on the country model.
1
Make sure that the system and the TV are connected with an HDMI cable.
2
Turn on the TV and press [/1 to turn on
the system.
3
Switch the input selector on your TV so that the signal from the system through the HDMI input appears on the TV screen.
4
Set the Control for HDMI function of the system and TV.
For details of the setting of the system, see the following Steps. For details of the setting of the TV, refer to the operating instructions of the TV (depending on the
TV, the default setting of the Control for
HDMI function is set to off).
To set the [CONTROL FOR HDMI] function to on/off
1
Press FUNCTION +/– repeatedly until
“DVD” appears in the front panel display.
2
Press DISPLAY while the system is in stop mode.
The Control Menu display appears on the
TV screen.
3
Press
X/x to select
[SETUP], then press .
The options for [SETUP] appear.
4
Press
X/x to select [CUSTOM], then
press .
The Setup Display appears.
5
Press
X/x to select [HDMI SETUP], then
press .
The options for [HDMI SETUP] appear.
6
Press
X/x to select [CONTROL FOR
HDMI], then press .
7
Press
X/x to select the setting, then
press .
• [OFF]: Off.
• [ON]: On.
Note
• When [Please verify the HDMI connection.] appears, make sure the HDMI connection is correct.
Using the Theatre Mode
(Theatre Mode)
If your TV is compatible with the Theatre Mode, you can enjoy optimal image suited for movies and the sound is output from the system’s speaker automatically by pressing THEATRE.
Watching DVD by a single button press
(One-Touch Play)
By only pressing ONE-TOUCH PLAY, the TV turns on, the TV is set for DVD input mode, and the system starts playing a disc automatically.
The One-Touch Play also works when:
– You press A while the disc tray is opened and
H appears in the front panel display.
– You close the disc tray by pressing the disc tray.
– You press DVD TOP MENU/DVD MENU and H appears in the front panel display.
– You select the “DVD” function by pressing
FUNCTION +/– and H appears in the front panel display.
Note
• One-Touch Play does not work when you press H.
The system and TV work as follows (e.g.):
This system TV
Turns on. (If not already turned on.) r
Switches to “DVD” function.
r
Starts playing the disc and outputs the sound.
Turns on. (If not already turned on.) r
Switches to HDMI input.
r
Minimizes sound level.
(System Audio Control)
Note
• Make sure the HDMI connection is correct, and set the [CONTROL FOR HDMI] to [ON].
• Depending on the TV, the beginning of the content may not be played back.
• Depending on the disc, playback may take a while to start.
Turning the system off in sync with the TV
(System Power Off)
When you turn the TV off by using the POWER button on the TV’s remote or TV [/1 on the system’s remote, the system turns off automatically.
Note
• Before using the System Power Off function, set the function for TV power. For details, refer to the operating instructions of the TV.
• Depending on the status of the system (ex. while other than “DVD” or “TV” function, or playing a
CD), the system may not turn off automatically.
63
GB
64
GB
Enjoying TV sound from the speakers in this system
(System Audio Control)
You can enjoy TV sound in this system by easy operation.
To use this function, connect the system and the
TV with an audio cord (not supplied) and an
HDMI cable (not supplied) (page 20).
Depending on the TV, when you set the system to the “TV” function, the System Audio Control function is activated. TV sound is output from the system speakers, and the volume of the TV speakers is minimized automatically.
You can use the System Audio Control function as follows:
• While you are watching the TV and the function of the system is switched to “TV,” TV sound is output from the system speakers automatically.
• You can control the system’s volume by the remote of the TV.
• If you turn the system off or set the function of the system to other than “TV,” TV sound is output from the TV speakers.
You can also operate the System Audio Control function from the TV menu. For details, refer to the operating instructions of the TV.
Note
• If the TV is turned on before turning on the system,
TV sound will not be output for a moment.
• While the TV is in PAP (picture and picture) mode, the System Audio Control function will not work.
When the TV exits PAP mode, the output method of the TV returns to the one before PAP mode.
• If you select a TV program during DVD playback with the system, the “TV” function is automatically set to output TV sound.
• When you activate One-Touch Play during watching
TV, the System Audio Control function is activated and the TV sound is muted.
• While recording songs on an audio CD into a USB device, the System Audio Control function will not work.
Tip
• You can connect the system and the TV audio
digitally. For details, see (page 21).
Setting the Maximum Volume
Level of the System
(Volume Limit)
If you change the output method of the TV to the system speaker on the TV menu or by pressing
THEATRE, loud sound may be output depending on the volume level of the system.
You can prevent this by limiting the maximum
level of the volume. For details, see “[VOLUME
Playing Back Audio
Files/JPEG Image Files of a USB Device
You can play audio files (MP3/WMA/AAC files)/JPEG image files stored in a USB device such as the digital music player or USB storage media (not supplied) by connecting the USB device to the unit.
For a list of USB devices that can be connected to the unit, see “Playable USB Devices”
(supplement).
The audio format that can be played back by the system is MP3/WMA/AAC files* only.
* Files with copyright protection (Digital Rights
Management) cannot be played by the system.
Note
• The system cannot play WMA/AAC files on a DATA
CD/DATA DVD.
About playable USB devices
• Do not use USB devices other than those listed in “Playable USB Devices” (supplement).
Operation of models not listed is not guaranteed.
• Operation is not guaranteed, even when using these USB devices.
• Some of these USB devices may not be available for purchase in certain areas.
Connecting the USB device
Front panel
USB device
Note
• When you use the AUDIO IN/A.CAL MIC jack while a USB device is connected, be careful as space is restricted.
1
Press FUNCTION +/– repeatedly until
“USB” appears in the front panel display.
2
Connect a USB device (digital music player or USB storage media) to the
(USB) port.
When you connect the USB device,
“READING” appears in the front panel display until the system reads all data of the
USB device.
Note
• When you connect the USB device, make sure that the direction of the jack is correct.
• Do not forcibly insert the USB device, as this may cause the device to be damaged.
• Do not connect other device or objects besides the
USB device.
• It may take about 10 seconds before “READING” appears in the front panel display depending on the type of the USB device.
To remove the USB device
1
Press x to stop playback.
2
Press [/1 to turn off the system.
3
Remove the USB device.
Notes on the USB device
• The system can play back up to 200 folders, including albums that do not contain audio files and JPEG image files. When more than
200 folders are in the USB device, folders that are recognized by the system differ depending on the folder configuration.
• The system can play back the following files.
File
MP3 file
WMA file
AAC file
JPEG image file
Extension of the file
“.mp3”
“.wma”
“.m4a”
“.jpg” or “.jpeg”
The system will play back any data with the extension above, even if it is not MP3/WMA/
AAC/JPEG format. Playing this data may generate a loud noise which could damage your speaker system.
65
GB
66
GB
• The following USB devices/situations can increase the time it takes to start playback:
– a USB device recorded with a complicated tree structure.
– when the audio files or JPEG image files in another folder have just been played back.
• Some USB devices cannot be played back on the system depending on the file format.
• The system can play back to a depth of 8 folders only.
• The system may not be able to play an audio file depending on the kind of file.
• When the USB device is inserted, the system reads all the files on the USB device. If there are many folders or files on the USB device, it may take a long time to finish reading the USB device.
• Do not connect the system and the USB device through a USB hub.
• With some connected USB devices, after an operation is performed, there may be a delay before it is performed by this system.
• This system does not necessarily support all the functions provided in a connected USB device.
• Files recorded by a device such as a computer may not be played back in the order in which they were recorded.
• The playback order for the system may differ from the playback order of the connected USB device.
• Always turn off the system before removing the USB device. Removing the USB device while the system is on may corrupt the data on the USB device.
• Do not save other types of files or unnecessary folders on a USB device that has audio files or
JPEG image files.
• Folders that have no audio files or JPEG image files are skipped.
• Compatibility with all MP3/WMA/AAC encoding/writing softwares, recording devices, and recording media cannot be guaranteed. Incompatible USB device may produce noise or interrupted audio or may not play at all.
• Before using the USB device, make sure that no virus-ridden files are on the USB device.
Selecting an audio file or folder
1
Press FUNCTION +/– repeatedly until
“USB” appears in the front panel display.
2
Press DISPLAY while the system is in stop mode.
The Control Menu display appears on the
TV screen.
3
Press
X/x to select
[MODE
(MUSIC, IMAGE)], then press .
The options for [MODE (MUSIC,
IMAGE)] appear.
4
Press
X/x to select [MUSIC].
5
Press .
6
Press DVD MENU.
The folders recorded on the USB device appear. When a folder is being played, its title is shaded.
FOLDER LIST
01 Let's Talk About Love (1985)
02 1st Album (1986)
03 In the Middle of Nowhere (1986)
04 Ready for Romance (1986)
05 In the Garden of Venus (1987)
06 Romantic Warriors (1987)
07 Back for Good (1988)
08 Alone (1999)
7
Press
X/x to select a folder. x To play audio files in a folder
Press H to start playing the selected folder.
x To select an audio file
Press .
The list of files contained in the folder appears.
TRACK LIST
03 In the Middle of Nowher...
01_Geronimo_s_Cadillac
02_Riding_On_A_White_Swan
03_Give_Me_Peace_On_Earth
04_Sweet_Little_Shella
05_Ten_Thousand_Lonely_Drums
06_Lonely_Tears_In_Chinatown
07_In_Shaire
Press X/x to select a file and press .
The system starts playing the selected file.
You can turn the file list off by pressing
DVD MENU. Pressing DVD MENU again will display the folder list.
Tip
• The system can recognize up to 150 audio files in a single folder.
To stop playback
Press x.
To play the next or previous audio file
Press >/.. Note that you can select the next folder by continuing to press > after the last file on the current folder, but that you cannot return to the previous folder by pressing ..
To return to the previous folder, select the folder from the folder list.
To return to the previous display
Press O RETURN.
To turn off the display
Press DVD MENU.
Other operations
See “Other operations” (page 34).
Selecting a JPEG image file or folder
1
Press FUNCTION +/– repeatedly until
“USB” appears in the front panel display.
2
Press DISPLAY while the system is in stop mode.
The Control Menu display appears on the
TV screen.
3
Press
X/x to select
[MODE
(MUSIC, IMAGE)], then press .
The options for [MODE (MUSIC,
IMAGE)] appear.
4
Press
X/x to select [IMAGE].
5
Press .
6
Press DVD MENU.
The folders recorded on the USB device appear. When a folder is being played, its title is shaded.
FOLDER LIST
01 Let's Talk About Love (1985)
02 1st Album (1986)
03 In the Middle of Nowhere (1986)
04 Ready for Romance (1986)
05 In the Garden of Venus (1987)
06 Romantic Warriors (1987)
07 Back for Good (1988)
08 Alone (1999)
7
Press
X/x to select a folder. x To play JPEG image files in a folder
as a slide show
Press H to start playing the selected folder.
The JPEG images are played as a slide show. You can change the interval of the
slide show (page 68), and add effects to the slide show (page 68).
x To select a JPEG image file by
displaying the subscreens
Press PICTURE NAVI.
Images of JPEG image files in the folder appear in 16 subscreens.
1
5
2
6
3
7
4
8
9 10 11 12
13 14 15 16
Press
C/X/x/c to select the JPEG image file you want to view, then press .
To return to normal screen, press O
RETURN.
Tip
• A scroll box is displayed at the right side of the
TV screen. To display the additional JPEG image files, select the bottom JPEG image file and press x. To return to the previous JPEG image file, select the top JPEG image file and press X.
• The system can recognize up to 150 JPEG image files in a single folder.
67
GB
68
GB
To play the next or previous JPEG image file
Press c/C when the Control Menu display is not displayed. Note that you can select the next folder by continuing to press c after the last image on the current folder, but that you cannot return to the previous folder by pressing C. To return to the previous folder, select the folder from the folder list.
To rotate a JPEG image file
When a JPEG image file is displayed on the TV screen, you can rotate the JPEG image file by 90 degrees.
Press
X/x while viewing a JPEG image file.
Press CLEAR to return to normal view.
Note
• You cannot rotate the JPEG image file when you set
[JPEG RESOLUTION] in [HDMI SETUP] to [(1920
× 1080i) HD ] or [(1920
× 1080i) HD].
To stop playback
Press x.
Other operations
See “Other operations” (page 34).
To select the slide show duration of JPEG image files
1
Press
The Control Menu display appears on the
TV screen.
2
Press
X/x to select
[INTERVAL], then press .
The options for [INTERVAL] appear.
3
Press
X/x to select a setting.
• [NORMAL]: You can set the duration to about 6 to 9 seconds.
• [FAST]: You can set the duration shorter than [NORMAL].
• [SLOW 1]: You can set the duration longer than [NORMAL].
• [SLOW 2]: You can set the duration longer than [SLOW 1].
4
Press .
Note
• Some JPEG image files may take longer to display than the option you selected. Especially progressive
JPEG image files or JPEG image files of 3,000,000 pixels or more.
To select an effect for JPEG image files in the slide show
1
Press DISPLAY twice.
The Control Menu display appears on the
TV screen.
2
Press
X/x to select
[EFFECT], then press .
The options for [EFFECT] appear.
3
Press
X/x to select a setting.
• [MODE 1]: The JPEG image file sweeps in from top to bottom.
• [MODE 2]: The JPEG image file stretches out from left to right of the TV screen.
• [MODE 3]: The JPEG image file stretches out from the center of the TV screen.
• [MODE 4]: The JPEG image files randomly cycle through the effects.
• [MODE 5]: The next JPEG image file slides over the previous image.
• [OFF]: Off.
4
Press .
Note
• The [EFFECT] setting is not effective when you set
[JPEG RESOLUTION] in [HDMI SETUP] to [(1920
× 1080i) HD ] or [(1920
Displaying the list of audio files/JPEG image files
1
Press DISPLAY during playback.
The Control Menu display appears on the
TV screen.
2
Press
X/x to select
[BROWSING], then press .
The options for [BROWSING] appear.
3
Press
X/x to select the desired list,
then press .
• [FOLDER LIST]: The list of folders
appears. Follow Step 2 of “Selecting an
audio file or folder” or “Selecting a JPEG image file or folder.”
• [PICTURE LIST]: Images of JPEG image files in the folder appear in 16 subscreens.
Follow Step 2 of “Selecting a JPEG image file or folder.”
Playing repeatedly
(Repeat Play)
You can play the audio files/JPEG image files on the USB device repeatedly.
1
Press DISPLAY during playback.
The Control Menu display appears on the
TV screen.
2
Press
X/x to select
[REPEAT], then press .
The options for [REPEAT] appear.
3
Press
X/x to select the item to be
repeated.
• [OFF]: Off.
• [MEMORY]: You can repeat all of the folders on the USB device.
• [FOLDER]: You can repeat the current folder.
• [TRACK] (audio files only): You can repeat the current file.
4
Press .
The item is selected.
To return to normal play
Press CLEAR, or select [OFF] in Step 3.
To turn off the Control Menu display
Press DISPLAY repeatedly until the Control
Menu display is turned off.
Note
• When [MODE (MUSIC, IMAGE)] is set to [IMAGE]
(page 67), you cannot select [TRACK].
Searching for an audio file/
JPEG image file/folder
You can search a USB device by audio file,
JPEG image file, or folder. As audio files and
JPEG image files are assigned unique numbers on the USB device, you can select the desired audio file or JPEG image file by entering its number.
1
Press DISPLAY. (When playing a
JPEG image files, press DISPLAY twice.)
The Control Menu display appears on the
TV screen.
2
Press
X/x to select the search method.
• [TRACK]: audio files.
• [FILE]: JPEG image files.
• [FOLDER]: Folders.
[** (**)] is selected (** refers to a number).
The number in parentheses indicates the total number of audio files, JPEG image files, or folders.
1 ( 1 )
1 ( 1 4 4 )
T 0 : 2 3
USB
MUSIC
Selected row
3
Press .
[** (**)] changes to [– – (**)].
1 ( 1 )
1 ( 1 4 4 )
T 1 : 3 1
USB
MUSIC
4
Press
X/x or the number buttons to
select the desired number.
If you make a mistake, press CLEAR to cancel the number.
69
GB
70
GB
5
Press .
The system starts playback from the selected number.
Bit rate
T 0: 13 192k MP3
Viewing the information of an audio file in the front panel display
Press DISPLAY repeatedly.
Each time you press DISPLAY while playing the disc, the display changes:
1 y 2
1
Playing time and current track number
2
Track (file) name*
* If an MP3 file has the ID3 tag, the system will display a folder name/track (file) name from the ID3 tag information.
The system can support ID3 ver 1.0/1.1/2.2/2.3.
ID3 ver 2.2/2.3 tag information display has priority when both ID3 ver 1.0/1.1 and ver 2.2/2.3 tags are used for a single MP3 file.
Note
• If a file name of the audio file cannot be displayed,
“*” will appear in the front panel display instead.
• The file name may not be displayed depending on the text.
• Playing time of MP3 files may not be displayed correctly.
2002_Remixes
Soul_Survivor_rap_version
Folder name* File name*
* If an MP3 file has the ID3 tag, the system will display a folder name/track (file) name from the ID3 tag information.
The system can support ID3 ver 1.0/1.1/2.2/2.3.
ID3 ver 2.2/2.3 tag information display has priority when both ID3 ver 1.0/1.1 and ver 2.2/2.3 tags are used for a single MP3 file.
Note
• Characters/marks may not be displayed in some languages.
• Depending on the type of file being played, the system can only display a limited number of characters. Also, depending on the file, not all text characters will be displayed.
Viewing the information of an audio file on the TV screen
You can display the information of an audio file such as time information, name of the folder/ audio file, and the audio bit rate (the amount of data per second of the current audio) on the TV screen.
Press DISPLAY during playback.
The information of an audio file appears on the
TV screen.
Checking the date information of JPEG image file
You can check the date information during playback when the Exif* tag is recorded in the
JPEG image file.
Press DISPLAY twice during playback.
The Control Menu display appears on the TV screen.
2 ( 2 )
6 ( 3 0 )
1 6 / 9 / 2 0 0 2
USB
Date information
* “Exchangeable Image File Format” is a digital camera image format defined by the Japan
Electronics and Information Technology Industries
Association (JEITA).
Tip
• Date information is [DD/MM/YYYY].
DD: Day
MM: Month
YYYY: Year
Storing Songs in a USB
Device
You can record songs on an audio CD in a USB device by encoding to MP3 format. You can also copy the MP3 files on a DATA CD/DATA DVD into the USB device.
For connecting the USB device, see
“Connecting the USB device” (page 65).
The recorded music is limited to private use only. Use of the music beyond this limit requires permission of the copyright holders.
Notes on the USB recording/ copying
• Do not connect the unit and the USB device through an USB hub.
• Make sure there is enough space in the USB device for recording or copying.
• Do not remove the USB device during recording/copying.
• When you are recording tracks from a CD, the tracks are recorded as 128 kbps MP3 files.
• When you are copying MP3 files from a
DATA CD/DATA DVD, the MP3 files are recorded with the same bit rate as the original
MP3 files.
• CD text information is not recorded in the created MP3 files.
• If you stop a recording partway, an MP3 file whose recording was stopped halfway is deleted.
• Recording stops automatically if:
– The USB device runs out of space during recording/copying.
– The number of MP3 files on the USB device reaches the limit for the number that the system can recognize.
• You can store up to 150 files in a folder.
• You can store up to 199 folders in a single
USB device.
• If the folder to be erased contains non-audio format files or sub folders, these are not erased.
• If a folder or file that you are trying to record already exists on the USB device with the same name, a sequential number is added after
71
GB
72
GB
the name without overwriting the original folder or file.
• Some USB devices cannot be played back on the system depending on the file format.
Recording songs on an audio
CD into a USB device
1
Load an audio CD.
2
Press DISPLAY while the system is in stop mode.
The Control Menu display appears on the
TV screen.
3
Press
X/x to select
[USB
RECORDING], then press .
4
Press
X/x to select [TRACK], then
press .
“READING” appears in the front panel display until the tracks recorded on the audio CD appear on the TV screen.
Note
• It takes several minutes to display the tracks depending on the number of tracks.
5
Select a track that you want to record.
USB RECORDING
1
2
3
TRACK
TRACK
TRACK
TRACK
TRACK
TRACK
TRACK
TRACK
01
02
03
04
05
06
07
08
Recordable space of the USB device
Free:
START
ALL
ALL
Tracks to be recorded.
x To select the desired track
Press
X/x to select the track, then press
.
The tracks are marked in the order that you select. x To select all tracks on the audio CD
Press C/X/x/c to select [x ALL], then press .
x To cancel the track
Press X/x to select the track, then press .
The mark on the track is removed.
x To cancel all the track
Press C/X/x/c to select [s ALL], then press .
6
Press
C/X/x/c to select [START], then
press .
The system starts recording and the status of recording appears.
To cancel recording, press x.
Copying MP3 files on a DATA
CD/DATA DVD into a USB device
1
Load a DATA CD/DATA DVD.
2
Press DISPLAY while the system is in stop mode.
The Control Menu display appears on the
TV screen.
3
Press
X/x to select
[USB
RECORDING], then press .
4
Press
X/x to select [TRACK] or
[FOLDER], then press .
• [TRACK]: The folders recorded on the
DATA CD/DATA DVD appear. You can copy the desired MP3 file.
• [FOLDER]: The folders recorded on the
DATA CD/DATA DVD appear. You can copy all MP3 files in the folder. Go to
Step 6.
“READING” appears in the front panel display until the tracks/folders appear on the TV screen.
Note
• It takes several minutes to display the tracks/ folders depending on the number of tracks/ folders.
5
Press
X/x to select the desired folder,
then press .
The MP3 files in the selected folder appear.
6
Select a MP3 file/folder that you want to copy.
Recordable space of the USB device
USB RECORDING
2002_Remixes
01_Back_Seat_O...
02_One_Nights_...
03_Are_You_Ma...
04_I_Can_Lose_...
05_Soul_Survivo...
06_Strangers_B...
07_Stay_maxi_ve...
Free:
START
ALL
ALL
MP3 files/folders to be copied.
x To select the desired MP3 file/folder
Press X/x to select the MP3 file/folder, then press .
The MP3 files/folders are marked. x To select all MP3 files/folders
Press C/X/x/c to select [ ALL], then press .
x To cancel the MP3 file/folder
Press X/x to select the MP3 file/folder, then press . The mark on the MP3 file/folder is removed.
x To cancel all MP3 files/folder
Press C/X/x/c to select [ ALL], then press .
7
Press
C/X/x/c to select [START], then
press .
The system starts copying and the copying status appears.
To cancel copying, press x.
To return to the previous display
Press O RETURN.
Note
• The audio file on a DATA CD/DATA DVD that you can copy is the MP3 file only.
2
Press
X/x to select a folder. x To erase all audio files in a folder
Press CLEAR.
x To erase an audio file
Press .
The list of files contained in the folder appears.
Press X/x to select the desired audio file, then press
CLEAR
.
3
Press
C/c to select [YES], then press
.
To cancel, select [NO], then press .
Note
• Do not remove the USB device while erasing.
• If the folder to be erased contains non-audio format files or sub folders, these are erased from the list on the TV screen, but are not erased from the USB device.
To return to the previous display
Press O RETURN.
Erasing audio files on a USB device
You can erase audio files on the USB device.
1
Press FUNCTION +/– repeatedly until
“USB” appears in the front panel display.
73
GB
74
GB
Using the DIGITAL MEDIA
PORT Adapter
The DIGITAL MEDIA PORT (DMPORT) adapter (not supplied) is for enjoying sound from a portable audio source or computer. By connecting a DIGITAL MEDIA PORT adapter, you can enjoy sound from the connected component on the system.
Available DIGITAL MEDIA PORT adapters vary in each area.
For details on connecting the DIGITAL MEDIA
PORT adapter, see “To connect the DIGITAL
MEDIA PORT adapter” (page 21).
Note
• Do not connect an adapter other than the DIGITAL
MEDIA PORT adapter.
• Do not connect or disconnect the DIGITAL MEDIA
PORT adapter to/from the unit while the system is turned on.
• Depending on the type of DIGITAL MEDIA PORT adapter, the images are also output. In this case, the system outputs the EURO AV OUTPUT signal only regardless of the type of video signal.
• When you use the system and the Bluetooth Wireless
Audio Adapter (such as TDM-BT1, not supplied) at the same time, transmission distance between the
Bluetooth transmitter and Bluetooth Wireless Audio
Adapter may be reduced. In this case, place the
Bluetooth transmitter as far as possible from the system, or move the Bluetooth Wireless Audio
Adapter closer to the Bluetooth transmitter.
• When you use the system and the Wireless Network
Audio Adapter (such as TDM-NC1, not supplied) at the same time, place the Wireless Network Audio
Adapter as far as possible from the system.
The sound and images from the connected component are played on the system or connected TV.
For operation details, refer to the operating instructions of the DIGITAL MEDIA
PORT adapter.
Tip
• When listening to MP3 files or other compressed music using a portable audio source, you can enhance the sound. Select “A.F.D. STD” for “DEC. MODE”
(page 30). To cancel, select other than “A.F.D. STD.”
• Depending on the type of DIGITAL MEDIA PORT adapter, you may be able to operate a connected component using either the buttons on the remote or the unit. The following illustration shows an example of buttons that can be used in this case.
X
./>
H x
Playing the connected component on the system
1
Press FUNCTION +/– repeatedly until
“DMPORT” appears in the front panel display.
2
Start playback of the connected component.
Using an S-AIR Product
The unit is compatible with the S-AIR function
(page 104), which allows sound transmission
between S-AIR products.
When you purchase the S-AIR product, you need to perform the following settings to establish the sound transmission.
About S-AIR products
There are two types of S-AIR product.
• S-AIR main unit (this unit): This is for transmitting sound. You can use up to three
S-AIR main unit. (The number of usable
S-AIR main unit depends on the use environment.)
• S-AIR sub unit: This is for receiving sound.
– Surround amplifier: You can enjoy surround speaker sound wirelessly.
– S-AIR receiver: You can enjoy system sound in another room.
the unit and the wireless transceiver (not supplied) into the S-AIR sub unit.
Note
• When you insert the wireless transmitter/transceiver, make sure that the AC power cord (mains lead) is not connected to a wall outlet (mains).
• Do not touch the terminals of the wireless transmitter/ transceiver.
To insert the wireless transmitter into the unit
1
Remove the screws and detach the slot cover.
Rear of the unit
CENTER
SPEAKER
SUBWOOFER
DIGITAL IN
COAXIAL
TV
OPTICAL
FRONT R FRONT L
SPEAKER
SUR R SUR L
HDMI OUT
DC5V
0.7A MAX
DMPORT
R AUDIO IN
LINE
L
EZW-T100
ANTENNA
COAXIAL 75
FM
EURO AV
AM
OUTPUT(TO TV)
Slot cover
EZ
W-T
100
S-AIR sub unit
(S-AIR receiver)
S-AIR main unit
S-AIR sub unit
(surround amplifier)
Inserting the wireless transmitter/transceiver
To make use of the S-AIR function, you need to insert the wireless transmitter (not supplied) into
Note
• Remove the screws from the slot cover bearing the caution mark. Do not remove other screws.
• The slot cover is no longer necessary; however, keep it after detaching.
2
Insert the wireless transmitter.
Rear of the unit
CENTER
SPEAKER
SUBWOOFER
DIGITAL IN
COAXIAL
TV
OPTICAL
FRONT R FRONT L
SPEAKER
SUR R SUR L
HDMI OUT
DC5V
0.7A MAX
DMPORT
R AUDIO IN
LINE
L
EZW-T100
ANTENNA
COAXIAL 75
FM
EURO AV
AM
OUTPUT(TO TV)
EZW
-T100
Note
• Insert the wireless transmitter with the S-AIR logo facing up.
75
GB
76
GB
• Insert the wireless transmitter so that the V marks are aligned.
• Do not insert other than the wireless transmitter into the EZW-T100 slot.
3
Make sure to use the same screws to secure the wireless transmitter.
Rear of the unit
CENTER
SPEAKER
SUBWOOFER
DIGITAL IN
COAXIAL
TV
OPTICAL
FRONT R
SPEAKER
FRONT L SUR R SUR L
HDMI OUT
DC5V
0.7A MAX
DMPORT
-T100
EZW
R AUDIO IN L
LINE
EZW-T100
ANTENNA
COAXIAL 75
FM
EURO AV
AM
OUTPUT(TO TV)
Note
• Do not use other screws to fasten the wireless transmitter.
To insert the wireless transceiver into the S-AIR sub unit
For details on installing the wireless transceiver into the S-AIR sub unit, such as a surround amplifier or S-AIR receiver, see the operating instructions of the S-AIR sub unit.
Establishing sound transmission between the unit and S-AIR sub unit
(ID setting)
For the surround amplifier
For the S-AIR receiver
Simply by matching the ID of the unit and the
S-AIR sub unit, you can establish sound transmission. You can use multiple S-AIR main unit by setting a different ID for each component.
To set the ID of the unit
1
Press "/1 on the unit.
The system turns on.
2
Press FUNCTION +/– repeatedly until
“DVD” appears in the front panel display.
3
Press DISPLAY while the system is in stop mode.
The Control Menu display appears on the
TV screen.
4
Press
X/x to select
[SETUP], then press .
The options for [SETUP] appear.
5
Press
X/x to select [CUSTOM], then
press .
The Setup Display appears.
6
Press
X/x to select [AUDIO SETUP],
then press .
The options for [AUDIO SETUP] appear.
7
Press
X/x to select [S-AIR SETUP t],
then press .
Note
• When the wireless transmitter is not inserted in the unit, [S-AIR SETUP] cannot be selected.
8
Press
X/x to select [ID], then press
.
9
Press
X/x to select the desired ID, then
press .
You can select any ID (A, B, or C).
The confirmation display appears.
10
Press .
Set the S-AIR sub unit to the same ID.
Sound transmission is established as follows (example):
This unit
ID A
Other S-AIR main unit
ID B
ID A
S-AIR sub unit
ID A
S-AIR sub unit
ID B
S-AIR sub unit
Tip
• To confirm the current ID, perform Steps 1 to 7 above. When you pair the unit with the S-AIR sub
unit (page 78), [(PAIRING)] appears beside ID on
the display for selecting ID.
To set the ID of the surround amplifier
Refer to the operating instructions of the surround amplifier.
To set the ID of the S-AIR receiver
Refer to the operating instructions of the S-AIR receiver.
Note
• It is easy to set the same ID for the unit and S-AIR sub unit to establish sound transmission. However, neighbors may also receive your system’s sound if
IDs are the same, or you may receive the sound from neighbors. To prevent this, you can identify the unit with a specific S-AIR sub unit by performing the
Enjoying the system’s sound in another room
For the S-AIR receiver
You can enjoy the system’s sound by using the
S-AIR receiver. The S-AIR receiver can be installed anywhere, regardless of the location of the unit, for enjoying the system’s sound in another room.
For details of the S-AIR receiver, refer to the operating instructions of the S-AIR receiver.
1
Set the ID of the S-AIR receiver to that of the unit.
• To set the ID of the unit, see “To set the ID of the unit” (page 76).
• To set the ID of the S-AIR receiver, refer to the operating instructions of the S-AIR receiver.
Note
• When you are using another S-AIR sub unit, such as a surround amplifier, do not change the
ID of the unit. Set the ID of the S-AIR receiver to the same ID as the unit.
• When you pair the unit and another S-AIR sub unit, such as a surround amplifier, by the pairing operation, you need to perform the pairing operation between the unit and the S-AIR
2
Press S-AIR MODE on the remote.
The S-AIR mode appears in the front panel display. Each time you press S-AIR
MODE, the S-AIR mode changes.
• “PARTY”: The S-AIR receiver outputs sound according to function set on the unit.
• “SEPARATE”: You can set the desired function for the S-AIR receiver while unit functions do not change.
3
Select the desired function on the
S-AIR receiver.
x When “PARTY” is set
The function changes in the same sequence
as you press FUNCTION +/– (page 28).
x When “SEPARATE” is set
The function changes as follows.
“MAIN UNIT” t “TUNER FM” t
“TUNER AM” t “DMPORT” t
“AUDIO” t …
To enjoy the same function as the unit, select “MAIN UNIT.”
When “TUNER FM” or “TUNER AM” is selected on the unit, you can only select the same band for the tuner on the S-AIR receiver. In this case, when you select other than “TUNER FM” or “TUNER AM” on the unit, you can select any band for the tuner on the S-AIR receiver.
4
Adjust the volume on the S-AIR receiver.
Note
• When the sound is other than 2 channel stereo, multi channel sound is downmixed to 2 channel.
• The sound of the S-AIR receiver may be cut off by operation of the unit.
77
GB
78
GB
To control the system from the
S-AIR receiver
You can control the system from the S-AIR receiver by using the following buttons.
Press
H, X, x,
./>
Operation
Share the same operations on the remote and unit.
S-AIR CH Change the function of the system.
For details, refer to the operating instructions of the S-AIR receiver.
transmission between the unit and S-AIR receiver is established) in the front panel display.
• If you turn the system off with the disc tray opened while “S-AIR STBY” is set to “ON,” the disc tray may not close automatically.
• When the wireless transmitter is not inserted in the unit, you cannot set “S-AIR STBY.”
• “S-AIR STBY” is set to “OFF” automatically when the wireless transmitter is removed from the unit.
Enjoying the S-AIR receiver while the unit is in standby mode
For the S-AIR receiver
You can enjoy the S-AIR receiver while the unit is in standby mode by setting “S-AIR STBY” to
“ON.”
1
Press SYSTEM MENU.
2
Press
X/x repeatedly until “S-AIR
STBY” appears in the front panel display, then press or
c.
3
Press
X/x to select the desired setting.
• “ON”: You can enjoy the S-AIR receiver while the unit is in standby mode or turned on.
• “OFF”: You cannot enjoy the S-AIR receiver while the unit is in standby mode.
The default setting differs depending on the model.
4
Press .
The setting is made.
5
Press SYSTEM MENU.
The system menu turns off.
Note
• When you set “S-AIR STBY” to “ON,” the power consumption during the standby mode increases.
• When you turn the system off while “S-AIR STBY” is set to “ON,” “S-AIR” flashes (when sound transmission between the unit and S-AIR receiver is not established), or lights up (when sound
Identifying the unit with a specific S-AIR sub unit
(Pairing operation)
For the surround amplifier
For the S-AIR receiver
It is easy to set the same ID for the unit and an
S-AIR sub unit, such as a surround amplifier or
S-AIR receiver, to establish sound transmission.
However, neighbors may also receive your system’s sound if IDs are the same, or you may receive the sound from neighbors. To prevent this, you can identify the unit with a specific
S-AIR sub unit by performing the pairing operation.
When you perform pairing
Before pairing, sound transmission is established by the ID (example).
Neighbor Your room
This unit
ID A
ID A
S-AIR sub unit
ID A
S-AIR sub unit
After pairing, sound transmission is established between the paired unit and S-AIR sub unit(s) only.
Your room
This unit
ID A
ID A
S-AIR sub unit
Neighbor
No transmission
ID A
S-AIR sub unit
Pairing
1
Place the S-AIR sub unit that you want to pair near the unit.
Note
• Remove headphones from the surround amplifier (if connected).
2
Match the IDs of the unit and the S-AIR sub unit.
• To set the ID of the unit, see “To set the ID of the unit” (page 76).
• To set the ID of the S-AIR sub unit, refer to the operating instructions of the S-AIR sub unit.
3
Press FUNCTION +/– repeatedly until
“DVD” appears in the front panel display.
4
Press DISPLAY while the system is in stop mode.
The Control Menu display appears on the
TV screen.
5
Press
X/x to select
[SETUP], then press .
The options for [SETUP] appear.
6
Press
X/x to select [CUSTOM], then
press .
The Setup Display appears.
7
Press
X/x to select [AUDIO SETUP],
then press .
The options for [AUDIO SETUP] appear.
8
Press
X/x to select [S-AIR SETUP t],
then press .
Note
• When the wireless transmitter is not inserted in the unit, [S-AIR SETUP] cannot be selected.
9
Press
X/x to select [PAIRING], then
press .
The confirmation display appears.
10
Press
C/c to select [YES], then press
.
The unit starts pairing.
To not perform pairing, select [NO].
11
Start pairing of the S-AIR sub unit.
x For the surround amplifier
Refer to the operating instructions of the surround amplifier.
When sound transmission is established, the confirmation display appears.
x For the S-AIR receiver
Refer to the operating instructions of the
S-AIR receiver.
When sound transmission is established, the confirmation display appears.
Note
• Perform the pairing within several minutes after
Step 10. If you do not, the pairing is canceled automatically and the confirmation display appears. To perform pairing, select [YES]. To return to the previous display, select [NO].
12
Press
C/c to select the next operation. x To finish pairing
Select [NO], then press .
x To perform pairing of another S-AIR
sub unit
Select [YES], then press .
Note
• If you perform the pairing operation between the unit
and another S-AIR sub unit (page 78), sound
transmission established by ID is canceled.
• When you perform pairing, [(PAIRING)] appears beside ID on the display for selecting ID.
To cancel pairing
Perform the ID setting of the unit according to
the procedure of “To set the ID of the unit.” If
you select a new ID (you can select the same ID as before), pairing is canceled.
79
GB
80
GB
If sound transmission is unstable
For the surround amplifier
For the S-AIR receiver
If you use multiple wireless systems which sharing the 2.4 GHz band, such as wireless LAN or Bluetooth, the transmission of S-AIR products or other wireless systems may be unstable. In this case, the transmission may be improved by changing the following “RF
CHANGE” setting.
1
Press SYSTEM MENU.
2
Press
X/x repeatedly until “RF
CHANGE” appears in the front panel display, then press or
c.
3
Press
X/x to select the desired setting.
• “AUTO”: Normally select this. The system change “RF CHANGE” to “ON” or “OFF” automatically.
• “ON”: The system transmits sound by searching the better channel for transmitting.
• “OFF”: The system transmits sound by fixing the channel for transmitting.
4
Press .
The setting is made.
5
Press SYSTEM MENU.
The system menu turns off.
6
When you set “RF CHANGE” to “OFF,” select the ID so that sound transmission is most stabilized
Note
• When the wireless transmitter is not inserted in the unit, you cannot set “RF CHANGE.”
• In most cases, you will not need to change this setting.
• If “RF CHANGE” is set to “OFF,” transmission between the unit and S-AIR sub unit can be performed using one of the following channels.
– S-AIR ID A: equivalent channel for Wi-Fi channel 1
– S-AIR ID B: equivalent channel for Wi-Fi channel 6
– S-AIR ID C: equivalent channel for Wi-Fi channel 11
• The transmission may be improved by changing the transmission channel (frequency) of the other wireless system(s). For details, refer to the operating instructions of the other wireless system(s).
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
