Troubleshooting and maintenance
This section helps you identify printer conditions and problems that you can often correct. When you first recognize a problem, determine whether it is located within the printer, the software application, or an option. For additional assistance and answers to your questions, contact your service representative.
When diagnosing a problem, see “Checklist for typical problems” on pag e112.
Problem
Status lights and alarms
Paper jams and paper feeding problems
Printing problems
Misaligned printhead
Poor print quality
Incorrect font or pitch
Auto Sheet Feeder problems
See …
“Checking the printer status”
“Clearing paper jams”
on page …
“Testing the printer”
“Adjusting bidirectional alignment”
“Dots are missing or print quality is poor”
“Is the font or pitch selected from the operator panel not printing or is it changing”?
“Paper does not feed from the Auto
Sheet Feeder”
111
Checklist for typical problems
To solve most basic problems, begin by following these steps:
1
Is power getting to the printer?
Make sure:
•
The power cord is both plugged into a properly grounded outlet and into the printer.
•
The other items plugged into the same power source are operating.
•
The power source cannot be turned Off by a wall switch.
112
2
Is print too light?
The ribbon density control knob has been preset to 1. (The knob is located on the ribbon cartridge.)
When print becomes light, turn the knob from
1 to 2 to increase darkness of print.
Ribbon density control knob
Ribbon advance knob
3
Is paper jamming the printer?
See “Clearing paper jams” on pag e126 for
information on clearing paper jams.
4
Are forms catching on items such as a forms carton or a printer stand?
Adjust the forms container so paper feeds freely from container to printer.
5
Is a part damaged?
Call for service.
113
6
Are options causing the problem?
a
Run the Printer Test. For more information,
see “Testing the printer” on pag e116.
b
If the Printer Test fails with no options installed, call service.
c
If the Printer Test fails with an option installed, try removing the option.
7
Is the Font or Pitch selected from the operator panel not printing or is it changing?
Set Font Lock or Pitch Lock On to keep your software application from overriding the font and pitch settings. For more information, see
“Selecting or locking a font” on page 31.
If you need to use a nonresident font, change the font within your software application.
Note: If you are using Windows programs, most
fonts are bitmapped (graphics) and override the printer Font or Pitch Lock.
Select a resident font to override from the operator panel.
8
Is the problem outside the printer?
a
Turn the printer Off.
b
Disconnect the printer cable from the back of the printer.
c
Run the Printer Test. For more information,
see “Testing the printer” on pag e116.
If the Printer Test runs, then the problem is in the printer cable or your computer.
d
Run the test procedures for your computer.
For more information, refer to your computer’s operator manual.
9
If a software application does not run correctly on the printer, does a different software application run correctly?
114
10 Are you experiencing unexpected printing
results?
Make sure:
•
You selected the appropriate printer driver for your software application. For more
information, see “Setting up your Windows and DOS application software” on pag e17.
•
You selected the appropriate emulation mode for your printer. For more
information, see “Using IBM emulation mode” on page 18.
11 Do the buttons on the operator panel not work
except for Start/Stop, LineFeed, FormFeed,
Tear Off and Load/Unload?
The operator panel is locked. For more
information, see “Locking/unlocking the operator panel” on pag e30.
115
Testing the printer
Each time you turn the power switch On, the printer performs an internal check, or Power-On Self Test.
Running the Printer Test produces a test printout that gives a visual indication of any problem the printer may be experiencing.
You can run the Printer Test with or without the printer being connected to your computer.
Running the printer test
1
Make sure paper and the ribbon cartridge are installed.
2
Turn the printer Off.
3
Press and hold LineFeed while you turn the printer On.
4
Release LineFeed when printing starts.
Printing continues until you stop the printer.
Hex Trace mode
Hex trace mode prints the control codes that are sent to the printer. Use trace mode to help diagnose software/driver problems.
To enter trace mode:
1
Make sure paper and the ribbon cartridge are installed
2
Turn the printer Off.
3
Press and hold Tractor while you turn the printer On.
4
Release Tractor when the lights go out.
5
Turn the printer Off and back On to exit this mode.
116
Interrupting or stopping the printer test
To interrupt the Printer Test:
1
Press Start/Stop.
The test stops after a complete line of characters has printed.
2
Press Start/Stop to continue the test sample.
To stop the Printer Test, turn the printer Off.
117
Checking the printer status
Observe the operator panel lights and compare their status with the following table. The different patterns and combinations of lights provide you with information about the condition of your printer and whether you need to take action.
Printer status
Operator panel lights/status
Power
Ready
Paper Out
Power
Ready
Paper Out
Power
Ready
Paper Out
On
On
Off
On
Off
Off
On
Off
Blinking
Ready
Blinking
Action required
Norm0al operating condition. No action required.
Normal offline condition.
1
Load paper.
2
Press Start/Stop. Paper Out light goes off;
Ready light comes On.
Note:
If you installed the optional Tractor 2 Feeder and you are printing continuous forms, make sure the paper select lever is pushed down in the continuous forms position.
The printer has data in the buffer to be printed.
Power
Ready
Paper Out
Panel Lock
Font Lock
On
Blinking
Blinking
Blinking
Blinking
1
Check for a paper or ribbon jam.
2
Turn the printer Off.
3
Remove the ribbon cartridge. For
instructions, see “Removing the ribbon cartridge” on pag e142.
4
Check for paper dust or bits of paper.
5
Make sure the carrier packing tape has been removed.
6
With the printer On, run the Printer Test.
See “Testing the printer” on pag e116.
7
If the Printer Test fails, call for service.
Note:
If the printer is not beeping, there is a power supply problem. Call for service.
118
Printer status (continued)
Operator panel lights/status
Power Off
Power
Ready
On
Off
Paper Out
Blinking
Panel Lock Blinking
Power
Ready
Paper Out
On
Blinking
Blinking
Panel Lock Blinking
Power
Ready
Paper Out
Tractor 2
On
Blinking
Blinking
Blinking
Action required
Check the power cord and power source. If the power light remains Off, contact your service representative.
The paper select lever has been changed while paper was loaded. Move the paper select lever back to correct position and press Start/Stop.
Note:
Make sure paper is parked or unloaded before changing the position of the paper select lever.
1
Open and close the operator panel.
2
If you are attempting to perform a button power On sequence, verify you are holding the correct button.
3
Power printer Off and back On with no buttons held down.
4
If error continues, call for service.
Insure Tractor 2 option is install correctly. For instructions, see the Tractor 2 manual that came with your option.
119
Printer status (continued)
Operator panel lights/status
Power
Ready
Paper Out
Font Lock
All lights on solid
On
Blinking
Blinking
Blinking
On
Panel Lock Blinking
Action required
1
Turn the printer Off.
2
Turn the printer back On. If the same symptom occurs, contact your service representative.
Note:
If you need help in locating the nearest service representative, visit the Lexmark Web site at www.lexmark.com.
Power
Ready
Tractor 2
Paper Out
Font Lock
Power
Ready
Paper Out
Panel Lock
Font Lock
Power
Ready
Tractor 2
Paper Out
Panel Lock
Font Lock
Power
Ready
Tractor 2
Paper Out
Panel Lock
On
Blinking
Blinking
Blinking
Blinking
On
Blinking
Blinking
Blinking
Blinking
On
Blinking
Blinking
Blinking
Blinking
Blinking
On
Blinking
Blinking
Blinking
Blinking
120
Setting printer to default settings
To reset the printer to the factory defaults:
Initialize printer to US defaults
The standard defaults for the United States are:
•
Code page: 437
•
Character Set: 1
•
Form length: 11”
To change the defaults:
1
Make sure paper and the ribbon cartridge are installed.
2
Turn the printer Off.
3
Open the ribbon access cover.
4
Move the printhead over toward the operator panel side of the printer until it stops.
5
Close the ribbon access cover.
6
Press and hold Tear Off + Load/Unload while you turn the printer On.
7
Continue holding these buttons until the carrier moves.
Note: The operator panel lights blink On and
Off several times.
Once the carrier moves, your settings have been reset to factory defaults.
121
Initialize printer to EU defaults
The standard defaults for Europe are:
•
Code page: 858
•
Character Set: 2
•
Form length: 12”
To change the defaults:
1
Make sure paper and the ribbon cartridge are installed.
2
Turn the printer Off.
3
Open the ribbon access cover.
4
Move the printhead toward the operator panel side of the printer until it stops.
5
Close the ribbon access cover.
6
Press and hold Tear Off + Tractor while you turn the printer On.
7
Continue holding these buttons until the carrier moves.
Note: The operator panel lights blink On and
Off several times.
Once the carrier moves, your settings have been reset to factory defaults.
122
Adjusting bidirectional alignment
Occasionally, you may want to adjust the character alignment (also called bidirectional alignment) on your printer. The following steps illustrate how to adjust the alignment of the print wires.
Note: Make sure continuous forms are loaded in
your printer.
1
Make sure the default macro is set to disabled.
For help, see “Entering Setup mode” on page 90.
2
Turn the printer Off.
3
Open the Operator panel cover to access layer 2.
4
Press and hold Pitch while turning On the printer.
123
5
The Draft Alignment bars print.
The current value is the number printed below the bars.
Draft alignment bars
Current value
01
6
To set Draft, select the best row of alignment bars from the 01 - 07 printout.
a
Press Micro
↑
or Micro
↓ to select the best alignment by number or keep the current value.
b
Press Set TOF to save your selection.
After making your selection, the printer prints a single row showing the current alignment setting.
124
c
The printer automatically starts printing the alignment bars for NLQ (Near-Letter-
Quality).
NLQ alignment bars
Current value
01
The current value is the number printed below the bars.
125
7
To set NLQ, select the best alignment bars from the 01 - 07 printout.
The current value is the number printed below the bars.
Press Micro
↑
or Micro
↓ to select the best alignment by number or keep the current value.
After making your selection, the printer prints a single row showing the current alignment setting.
8
Press Set TOF to save your selections.
9
Close the Operator panel cover.
The printer returns to Ready.
Clearing paper jams
The following steps explain how to clear paper jams.
Cut form jams
1
Turn the printer Off.
2
Set the forms thickness lever to position 7.
3
Push the paper select lever down to the continuous forms position.
4
Gently pull out the sheet of paper from the front of the printer.
5
Remove the ribbon access cover to clear any torn pieces of paper.
6
Set the paper select lever to the cut forms position.
126
7
Set the forms thickness lever to the proper setting for the type of paper you are using.
See “Setting the forms thickness lever” on page 44.
Continuous forms jams
1
Turn the printer Off.
2
Detach any continuous forms already printed.
3
Set the forms thickness lever to position 7.
4
Tear the continuous forms off at the perforation line before the forms enter the printer.
5
If using the tractor in the push position, open the front cover. (Skip this step if you are using the optional Tractor 2 Feeder.)
6
Open the left and right tractor doors.
7
Lift the paper away from tractor pins.
8
Carefully pull out the paper.
9
Remove the ribbon access cover to clear any torn paper.
10 Remove any torn perforation strips or bits of
paper from the paper path.
127
Problem conditions
Perform the steps listed for each condition to correct the problem. If the suggested action does not correct the problem, contact your service representative.
Printer problems
Problem Probable cause Action
Printer goes to Tear Off position before job finishes printing.
Tear Off is set to One
Second and software application or network is not sending data fast enough.
Set Tear Off to On instead of
One Second and run the job again.
Characters are wrong or missing; formatting control codes do not work.
Application program problem.
Dots are missing or print quality is poor.
Some wires seem to be missing from the printhead.
Forms thickness lever is incorrect for the type of paper you have loaded.
Refer to your software application manual.
1
Check the setting of the forms thickness lever.
See “Setting the forms thickness lever” on page 44 for more
information.
2
Run the Printer Test. See
“Testing the printer” on page 116.
3
Have printer repaired.
Check the setting of the forms
thickness lever. See “Setting the forms thickness lever” on page 44 for more information.
Dust or paper particles are stuck to the ribbon surface.
Remove the ribbon cartridge and check the ribbon surface.
128
Printer problems (continued)
Problem Probable cause
Dots are missing or print quality is poor.
(continued)
Forms are smudged or printing is too dark
.
Action
Ribbon problem.
• Make sure the ribbon is securely snapped down on the carrier.
• Adjust the density control
knob. See “Is print too light?” on pag e113 for
more information.
• Ribbon is worn; replace the ribbon cartridge.
Printhead is not working.
• Run the Printer Test. See
“Testing the printer” on page 116.
• Contact your service representative.
Forms thickness lever is incorrect for the type of paper you have loaded.
Check the setting of the forms
thickness lever. See “Setting the forms thickness lever” on page 44.
Ribbon is twisted.
• Make sure the ribbon is installed correctly. See
“Removing the ribbon cartridge” on page 142.
• If possible, untwist the ribbon.
• Take up ribbon slack using the ribbon advance knob.
Ribbon shield is damaged or missing.
Density control knob was set to 2 prematurely.
• Remove the ribbon cartridge. For help, see
“Removing the ribbon cartridge” on page 142.
• Replace the ribbon cartridge.
Set density control knob to 1.
See“Is print too light?” on page 113 for more information.
129
Printer problems (continued)
Problem Probable cause
Incorrect number of lines on a page.
Application software problem.
Action
Refer to your software application manual.
Left margin moves to the right during printing.
The stack of continuous forms is catching on something.
Make sure paper is free to feed from carton and there is nothing obstructing paper movement (such as cables).
Top-Of-Form is set too low. Readjust Top-Of-Form. For help,
see “Setting Top-Of-Form” on page 81.
Printer page length is set incorrectly.
The printhead is not moving correctly.
Adjust page length in Setup
Setup mode to change printer settings” on pag e89.
• Check that the ribbon cartridge and paper are correctly installed.
• Make sure the carrier packing tape has been removed.
• Check to see if anything is blocking the movement of the carrier.
• If a paper jam has recently occurred, turn Off the printer and try again.
• Contact your service representative.
Forms thickness lever is incorrect for the type of paper you have loaded.
Software application problem.
Reset the forms thickness lever.
See “Setting the forms thickness lever” on page 44.
Refer to your software application manual.
130
Printer problems (continued)
Problem Probable cause
Line length is wrong; lines do not start at the left margin.
Application program problem.
Paper loads wrong.
Action
• Refer to your software application manual.
• Make sure the correct printer driver is selected.
Adjust the left margin by adjusting the tractor or paper guide.
Graphics do not print. Software application problem.
Line spacing is incorrect, or overprinting occurs.
Forms are jamming between printing surface and the printhead.
• Refer to your software application manual.
• Make sure the correct printer driver is selected.
Reset forms thickness lever. See
“Setting the forms thickness lever” on page 44.
Problem with the software applications.
Refer to your software application manual.
Specified pitch or font selected is not printing or is changing.
• Your software is overriding your operator panel selection.
• Your software is using bitmapped (graphic) fonts. If possible, select resident fonts.
Use Font Lock and Pitch Lock.
See “Selecting or locking a font” on page 31.
131
Printer problems (continued)
Problem Probable cause
Printer is printing beyond side edge of forms.
Action
Paper is adjusted incorrectly.
Adjust tractors or paper guides
and the paper. See “Aligning the left margin” on page 77.
Problem with the software application.
Refer to your software application manual.
A printhead jam caused by the ribbon or a paper jam.
• Make sure the ribbon cartridge is correctly installed.
• Clear the paper jam. See
“Adjusting bidirectional alignment” on page 123.
• Turn the printer Off and then back On.
Printing continues beyond edge of the form.
• Computer program set the assigned paper size larger than the actual page size.
• The printer is trying to print in the last ½ inch of form.
Change the software application so that the assigned paper size is the same as the actual paper size.
132
Printer problems (continued)
Problem Probable cause Action
Printer sounds as if it is printing but doesn’t print; printing is light.
Forms thickness lever is set too high for the type of paper you are using.
See “Setting the forms thickness lever” on page 44.
• Ribbon is jamming, is twisted, or is not between the printhead and the ribbon shield.
• Ribbon is out of ink.
• Make sure the ribbon cartridge is correctly installed and securely
snapped down on the carrier.
• Adjust the ribbon density
control knob. See “Is print too light?” on page 113 for
more information.
• Printer ribbon is out of ink.
Replace the ribbon
cartridge. See “Removing the ribbon cartridge” on page 142.
Printing is unstable; wrong characters print; left margin changes; printing stops.
• If you are using a grounded or shielded printer cable, it may not be attached correctly.
• Wrong driver in software.
• Make sure the printer cable is properly shielded and correctly connected at both ends.
• Select the correct driver. See
“Setting up your Windows and DOS application software” on page 17.
133
Printer problems
Problem
Printer does not feed paper.
Cannot adjust right tractor past rubber tractor stop in pull tractor position.
Probable cause
Paper is jamming.
Action
• Remove all forms and pieces of paper. Look for loose pinfeed hole strips that can sometimes tear from continuous forms and remain in the printer.
• The right tractor position may be incorrectly adjusted.
• Before you load new forms, fan the forms to loosen the sheets.
See “Setting the forms thickness lever” on page 44
for more information.
The forms thickness lever is set incorrectly for the type of paper you are using.
The Continuous form paper is parked.
The Auto Cut Sheet Load option is not set.
Press Load/Unload.
See “Auto Cut Sheet Load” on page 97 for more
information.
Adjust the right paper guide.
The right paper guide is not set correctly for your paper width.
The paper select lever is in the wrong position.
Rubber tractor stop has been pushed out of seated position.
• If you are trying to print a cut sheet, make sure the paper select lever is in the cut sheet position.
• If you are trying to print continuous forms, make sure the paper select lever is in the continuous sheet
position.
Firmly slide tractor and rubber tractor stop.
134
Printer problems (continued)
Problem Probable cause
Paper does not feed from the Auto Sheet Feeder.
The Auto Sheet Feeder locking lever is in the front position.
The paper select lever is in the tractor feed position.
The optional Auto Sheet
Feeder is not set to On in
Setup mode.
Too many sheets are in the paper bin.
The weight of the paper is too great.
Paper sheets seem to hold together at the bottom edge.
Dirty feed rollers.
Action
Set the Auto Sheet Feeder locking lever to the back position.
Set the paper select lever to the cut sheet position.
Enter Setup mode and set the
more information.
• Remove the extra sheets.
• Ensure that the stack of paper is not more than 150 sheets (64 g/m 2 ). For larger or thicker paper, use fewer sheets.
Remove all paper from the paper bin and install paper that has a lower weight. See the optional Auto Sheet
Feeder manual for recommended paper weights.
Remove all paper from the paper bin and fan the top and bottom edges with your thumb. Then place the paper in the paper bin.
Auto Sheet Feeder rollers” on page 143.
135
Printer problems (continued)
Problem Probable cause
Paper jam in the Auto
Sheet Feeder.
The paper is not loaded correctly in the paper bin.
The paper is not stacked evenly in the supply bin.
The Auto Sheet Feeder is not correctly installed.
Action
Remove the paper and reload the paper bin.
Remove the paper, align the edges of the paper, and reload the paper bin.
Remove the Auto Sheet
Feeder, and reinstall it.
Paper fed from Auto
Sheet Feeder jams at entrance to printer.
Foreign objects are in the
Auto Sheet Feeder paper path.
The printer paper feed path is dirty or the ribbon is jammed.
The Auto Sheet Feeder is not correctly installed.
Remove the Auto Sheet
Feeder. Remove the foreign objects. Reinstall the Auto
Sheet Feeder.
Remove the Auto Sheet
Feeder. Remove pieces of paper from the paper feed path. Reinstall the Auto Sheet
Feeder.
Remove the Auto Sheet
Feeder, and then reinstall it.
The paper guide is too far to the right.
Move the paper guide to the left.
The continuous forms were not moved to the park position before the
Auto Sheet Feeder was used.
Forms thickness lever is set incorrectly for your paper thickness.
Remove the Auto Sheet
Feeder. Move the continuous forms to the park position using the Load/Unload button.
Adjust the forms thickness
lever. For help, see “Setting the forms thickness lever” on page 44.
136
Printer problems (continued)
Problem
Paper fed from the Auto
Sheet Feeder is skewed in the printer.
The Auto Sheet Feeder feeds multiple sheets.
Probable cause
The left and right paper guides are not correctly adjusted.
Paper is not correctly placed in the paper bin.
Paper is not correctly placed in the paper bin.
The weight of the paper is too low.
Paper sheets seem to hold together at the bottom edge.
Not enough paper in the paper bin.
Action
Adjust the left and right paper guides so they are tight against the edge of the paper.
• Remove paper from the paper bin.
• Fan the paper.
• Reload the paper correctly.
Remove paper from the paper bin. Reload the paper correctly.
Remove all paper from the paper bin, and install a heavier paper. See the optional Auto Sheet Feeder manual for recommended paper weights.
Remove all paper from the paper bin and fan the top and bottom edges with your thumb. Place the paper in the paper bin.
Add more paper to the paper bin.
137
Printer problems (continued)
Problem
The Auto Sheet Feeder feeds paper at an incorrect rate.
Probable cause
The weight of the paper is too great.
Paper is jammed in the
Auto Sheet Feeder.
The forms thickness lever is set incorrectly for the type of paper you are using.
Too much paper loaded.
Action
Remove all paper from the
Auto Sheet Feeder and use paper that has a lower weight. See the optional Auto
Sheet Feeder manual for recommended paper weights.
Sheet Feeder jams at entrance to printer.” on pag e136.
Adjust the forms thickness
lever. See “Setting the forms thickness lever” on page 44
for more information.
Remove some of the paper.
The Auto Sheet Feeder places the paper at the wrong Top-Of-Form position.
Top-Of-Form is set incorrectly.
The paper is too short.
Dirty auto sheet feed rollers.
See the optional Auto Sheet
Feeder manual for information in setting
Top-Of-Form.
Remove the paper and ensure that the paper meets the paper specifications. See the optional Auto Sheet Feeder manual for paper specifications.
Auto Sheet Feeder rollers” on page 143.
138
Printer problems (continued)
Problem Probable cause
The printer does not feed from the Tractor 2
Feeder.
You are trying to print continuous forms and the paper select lever is in the cut sheet position.
A tractor feeder with no paper loaded is selected.
Tractor 2 Feeder is not plugged in.
Action
Move the paper select lever down to the continuous forms
position.
Press Tractor to select the other tractor feeder or load paper on the selected tractor feeder.
Plug Tractor 2 Feeder into the back of the printer.
Paper jam in the
Tractor 2 Feeder.
The Tractor 2 Feeder places paper at the wrong Top-Of-Form position.
The continuous form on one tractor feeder was not properly parked before switching to the other tractor feeder.
Top-Of-Form is set incorrectly.
Make sure you tear off the leading edge of the continuous form on the currently selected tractor feeder before switching tractor feeders. For help, refer to the documentation shipped with your option.
See“Setting Top-Of-Form” on page 81.
139
Problem
Print test works, but printer does not print when attached to the computer.
Probable cause
Printer cable problem.
Software application problem.
Port being used is not selected.
Action
Set both the printer and computer power switches Off.
Make sure the printer cable is correctly connected at both
ends. See “Supplies” on page 107 for information
about which printer cable to use.
Refer to your software application manual. Make sure you have selected the correct printer driver. See
“Setting up your Windows and DOS application software” on page 17.
Set to Auto or the port you are trying to use.
Buttons do not work
(except Start/Stop
FormFeed, Tear Off and
Load/Unload).
Operator panel is locked
(Padlock light is On).
Printer beeps when using
Micro
↑
or Micro
↓.
Printer is in the set Tear
Off position mode.
• Turn Off the printer.
• Press and hold
Load/Unload and Tractor and turn On the printer.
When the padlock light goes Off, the operator panel is unlocked.
Close the operator panel.
Printer is noisy.
The printer vibrates.
Ribbon access cover or front cover is open.
• Move any objects touching the printer.
• Make sure the printer is on a level, sturdy surface.
Close the cover.
140
Problem
Printer power switch is
On, but Power light is
Off.
Printer alarm sounds.
Probable cause
Printer is not getting power.
This might indicate an error or normal operation.
The optional Auto Sheet
Feeder or Tractor 2
Feeder is noisy.
The option is incorrectly installed.
Printing speed becomes slower.
The print operation has slowed down.
Action
• Make sure the power cord is correctly connected at both ends.
• Verify that the power source works.
Check the status of the operator panel lights. See
“Checking the printer status” on page 118.
Remove and reinstall the option. For help, refer to the documentation shipped with your option.
• Check the forms thickness lever. Make sure the setting is appropriate for the thickness of your forms. Printing speed is slower when the setting is
4 or higher.
• Your software application is using bitmapped
(graphic) fonts. If possible, select resident fonts.
Note:
Automatic thermal slowdown protects the printhead from overheating. This operation is normal and is affected by print type being used (letter quality, for example) and the amount and density of graphics being printed.
141
Maintenance
This section describes how to remove the ribbon cartridge and clean the printer.
Removing the ribbon cartridge
1
Turn the printer Off.
2
Remove the ribbon access cover.
3
Set the forms thickness lever to position 7.
4
Squeeze the left and right latches on the ribbon cartridge and lift.
The cartridge unlatches from the printer carrier.
Cleaning the printer
Before you clean the printer:
1
Turn the printer Off.
2
Unplug the power cord.
3
Wait until the printhead is cool.
4
Remove the ribbon cartridge.
Cleaning the inside of the printer:
Every few months, use a soft brush and a vacuum to remove dust, ribbon lint, and pieces of paper. Vacuum any dust from around the printhead and in the printer cavity.
Cleaning the cover:
Clean the outside of the printer with a damp cloth and mild soap. Do not use any spray-type or chemical cleaners anywhere on your printer. Do not put any liquids or spray near the air vents. For stubborn ink stains on the cover, use a commercial mechanic's hand cleaner.
142
Cleaning the Auto Sheet Feeder rollers
1
Remove all paper from the printer.
2
Turn the Auto Sheet Feeder upside down and place it on a flat surface.
3
Clean the two paper-guide wheels located inside the bottom of the Auto Sheet Feeder using isopropyl alcohol and a clean cloth.
You can rotate one roller while applying the cleaning cloth to the other roller.
143
144
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
