5

Chapter 5.

Managing projects using the

Eclipse and PTP framework

This chapter describes how to set up Eclipse and PTP Framework either by importing existing code or starting new projects. We also explain how to manage these projects from a local or remote site perspective. Through the chapter, we present different customizations involving building, running, and debugging parallel applications.

The following topics are covered:

򐂰

Available project scenarios:

– Synchronized

– Remote

– Local

򐂰

Creating a new parallel application

򐂰

Importing an existing parallel application

򐂰

Edit features of Eclipse

򐂰 Customize Eclipse to build and run parallel applications

򐂰

Building and running an application

򐂰

Debugging using Eclipse

򐂰

Integrating external applications

Note: The Eclipse and PTP Framework client side is available for Linux (32/64 bit), Mac

OSX (64 bit), and Windows (32/64 bit) distributions. For further details, check “Supported operating systems (software)” on page 3.

61

© Copyright IBM Corp. 2013. All rights reserved.

5.1 Available project scenarios

Depending on what resources we have or which target the code must run against, it is possible to use different approaches for each case. In this chapter, we present three specific code development layouts supported by Eclipse. From the complex one to the simple one, we have:

򐂰

Synchronized projects

򐂰

Remote projects

򐂰

Local projects

In Table 5-1, we can evaluate some differences between the three methods.

Table 5-1 Properties for the three project scenarios (client view)

Property Synchronized

Ability to build, run and debug Remote/Local

Development for x86 architecture

Development for Power architecture

Remote/Local

Remote

Code indexing

Symmetric dual-site code development

(same toolchain)

Fast (local)

Yes x86 (32/64 bit)

Remote

Remote

Remote

Remote

Slow (remote)

No

Local

Local

Local

NA

Fast (local)

No

5.1.1 Synchronized

Synchronized projects mirror project files on the local and remote machines. Build, run, and debug can take place on either or both. They use SSH connections to connect to a remote server and, currently, the Git software revision control subsystem to maintain the coherency

between local files and remote ones. Figure 5-1 on page 63 demonstrates the workflow for

the synchronized scenario.

62

IBM Parallel Environment (PE) Developer Edition

Figure 5-1 Communication workflow for synchronized Eclipse projects

The advantages of synchronized projects:

򐂰 Ability to use local machines to continue code development while the remote machine is not available.

򐂰 Maintain fast indexing of local code for speedy editing tasks like code navigation, code assist, outline, and search.

򐂰 Ability to develop code on different architectures without forcing eclipse to move to the same respective architectures.

򐂰 Ability to create and index Fortran projects. Remote projects do not provide indexing on

Fortran code.

To create a synchronized project:

1. Select File

New

Other. A new dialog appears (see Figure 5-2 on page 64), and in

the Remote folder you can create either a:

– Synchronized C/C++ project

– Synchronized Fortran project

1

2. Under the same folder, you can also convert an existing C/C++ or Fortran local project to a synchronized one with the option: Convert a C/C++ or Fortran project to a synchronized project

1

Synchronized Fortran project includes all the features of a C/C++ project too

Chapter 5. Managing projects using the Eclipse and PTP framework

63

Figure 5-2 Remote folder in new project wizard

5.1.2 Remote

Remote projects are based on a remote toolchain to build, run, and debug the code. They rely on SSH connections to connect to the targeted host for edit, index, build, run, and debug

commands. Figure 5-3 on page 65 demonstrates the workflow for the remote scenario.

64

IBM Parallel Environment (PE) Developer Edition

Figure 5-3 Communication workflow for remote Eclipse projects

Advantages of remote projects:

򐂰 No space requirements for code development in the local machine due to absence of code locally (the only space consumed will be for Eclipse internal management files). Also for security reasons, some developers might prefer not to store source code on the local machine.

򐂰 Decreased requirements for CPU performance on local machine because indexing, build, run, and so on, are all on the remote machine, and the local machine only needs to run

Eclipse.

򐂰 Ability to develop code on different architectures without forcing eclipse to move to the same respective architectures.

To create remote projects, select File

New

Other. A new dialog (see Figure 5-2 on page 64) appears. In the Remote folder you can create a Remote C/C++ project. Under the

same folder, you can also convert an existing C/C++ project to a remote one with the option,

Convert to a remote project.

5.1.3 Local

Local projects are based on a local toolchain to build, run, and debug the code. They have no dependencies on other machines and therefore can be more reliable and fast (assuming the same code sizes compared with the other two scenarios).

Advantages of local projects:

򐂰 Easy to start with and has no external hardware requirements

򐂰 Local host has full control of development availability

Chapter 5. Managing projects using the Eclipse and PTP framework

65

Disadvantages of local projects:

򐂰 Most local machines (for example, mobile computers and workstations) do not provide the best environment for developing and running large parallel codes

There are two ways to create local projects:

򐂰

File

New

<PROJECT>

򐂰

File

New

Other

For the last option, a new window appears, and in the C/C++ and Fortran folders you can choose a local project.

5.2 Creating a new parallel application

In this section, we demonstrate how to create a simple Eclipse managed

Hello World

C and

MPI code project. The Eclipse project example is used on an x86 architecture platform using a synchronized scenario. For the example in this section, we used the following resources and respective requirements.

Resources:

򐂰 Local machine: x86_64 (Intel i5 560 M) with RHEL 6.2

򐂰 Remote machine: x86_64 (Intel Xeon X5570) with RHEL 6.2

Local machine requirements:

򐂰

Java 1.6, or later installed

򐂰

IBM PEDE client installed

Remote machine requirements (for a synchronized project):

򐂰 Reachable through SSH (with password or ssh key)

򐂰 Have Git installed for synchronization

򐂰

IBM PEDE server installed (check Table 4-1 on page 48)

To create a new parallel application:

1. After you completed those prerequisites, click File

New

Other (or Ctrl+N). A new

dialog appears as shown in Figure 5-2 on page 64.

2. Under the folder Remote, select Synchronized C/C++ Project, and click Next.The New

Synchronized Project window is displayed, as shown in Figure 5-4 on page 67.

66

IBM Parallel Environment (PE) Developer Edition

Figure 5-4 New synchronized C/C++ project wizard

In Figure 5-4:

1. Type a name for the project.

2. At the Local directory group, type a path to the project local directory, or use the default location (based on your workspace directory and project name).

3. At the Remote directory group, select the connection to the remote host (if already created) or create a new one: a. To create a new connection, click New, and a new window named Generic Remote

Host is displayed, as shown in Figure 5-5 on page 68.

b. Give a name to the target connection (target name).

c. At the Host Information group, select the Remote host option, specify the fully qualified host name or IP address of the remote host (Host), and the user that will login

(User). For the ssh authentication method, there are two possible ways: either through passphrase or through public key authentication: i.

For password authentication, type the selected user password (password).

ii. For public key authentication, specify the path location for the private ssh key file of the selected user. If the private key file has a passphrase, enter it on the respective field (passphrase).

Chapter 5. Managing projects using the Eclipse and PTP framework

67

d. Click the Finish to complete the Target Environment Configuration. The window returns to the new synchronized project dialog.

Figure 5-5 Target environment configuration wizard

4. On the Remote director

y

group, click Browse, and select the project remote directory path

(If the directory does not exist, it will be created).

5. Inside Project type, under the Executable folder, select MPI Hello World C Project.

6. Inside Remote Toolchain, select Remote Linux GCC Tool Chain.

7. Inside Local Toolchain, select Linux GCC. If you do not require a build on the local machine, a local toolchain is not required at all.

8. Click Next.

9. In the Basic Settings window, Figure 5-6 on page 69, use the defaults, and click Next or

edit the following items: a. Code author b. Copyright notice c. Hello world greeting d. Source directory name

68

IBM Parallel Environment (PE) Developer Edition

Figure 5-6 Basic settings dialog for MPI project

10.This project is specified before as an MPI project; therefore, the next window presents you

with MPI Project Settings (see Figure 5-7) where it can be used to add paths to the build.

For this example, accept the default settings by clicking Next.

Figure 5-7 MPI project settings dialog

11.The last window (Figure 5-8 on page 70) shows two pre-built build configurations. Accept

the two default selected configurations to include them in your project, and finally click

Finish.

Chapter 5. Managing projects using the Eclipse and PTP framework

69

Figure 5-8 Available pre-built configurations for the MPI based hello world project

Eclipse now creates the Hello World project and synchronizes all data with the remote host.

5.3 Importing an existing parallel application

In this section, we demonstrate how to import an existing C based code (makefile project) to

Eclipse using a synchronized scenario. When creating a project with existing code, it can initially be located either locally or remotely. For the presented example, we are using a code that already exists on the local machine and the synchronized project setup copies automatically the code to the remote machine.

Resources:

򐂰 Local machine: x86_64 (Intel i5 560M) with RHEL 6.2

򐂰 Remote machine: x86_64 (Intel Xeon X5570) with RHEL 6.2

Local machine requirements:

򐂰

Java 1.6, or later installed

򐂰

IBM PEDE client installed

Remote machine requirements (for a synchronized project):

򐂰 Reachable through SSH (with password or ssh key)

򐂰 Have Git installed for synchronization

򐂰

IBM PEDE server installed (check Table 4-1 on page 48)

To import an existing parallel application:

1. After you have all the prerequisites, click File

New

Other (or Ctrl+N). A new window

is displayed, as shown in Figure 5-2 on page 64.

2. Under the Remote folder, select Synchronized C/C++ project, and click Next. The New

Synchronized Project window is displayed, as shown in Figure 5-4 on page 67.

70

IBM Parallel Environment (PE) Developer Edition

In this window (Figure 5-4 on page 67):

1. Type a name for the project.

2. At the Local directory group, type a path to the directory where the code resides. This directory will be used as your local project directory.

3. At the Remote directory group, select the connection to the remote host (if already created) or create a new one: a. To create a new connection, click New, and a new window named Generic Remote

Host is displayed, as shown in Figure 5-5 on page 68.

b. Give a name to the target connection (target name).

c. At the Host Information group, select the Remote host option, specify the fully qualified host name or IP of the remote host (host), and specify the user that will login (user). For the authentication method, there are two possible ways, either using passphrase or through public key authentication: i.

For the first method, type the selected user password (password) ii. For the second method, specify the path location for the private key file of the selected user. If the private key file has a passphrase, enter it on the respective field

(passphrase) d. Click Finish to complete the Target Environment Configuration.

4. On the Remote directory group, click Browse, and select the Project remote directory

path (path must be already created).

5. Inside the Project type, under the folder Makefile project, select Empty Project.

6. Inside the Remote Toolchain, select Remote Linux GCC Tool Chain.

7. Inside the Local Toolchain, select Linux GCC.

8. Click Next.

9. The last window presents you with two pre-built build configurations. Accept the two default selected configurations to include them in your project, and click Finish.

Eclipse now synchronizes all of the files between the two sites. After the synchronization process is completed, the project can be built and run.

Assumptions: This section example is based on a makefile that is built with the

make all

command.

5.4 Building and running an application

In this section, we demonstrate how to create Eclipse builds (targets) and profile runs using an existing code (makefile based) already imported to Eclipse, and inside a synchronized scenario.

When you create a synchronized Eclipse Project, there are two locations implicit: local and remote. Creating additional build configurations depend only on the toolchain you choose. So we can create new configurations for different compilers or event environment variables depending on the objectives, and when required inspect these build properties by right-clicking the project directory and then clicking Properties. This procedure applies to the

Chapter 5. Managing projects using the Eclipse and PTP framework

71

active build configurations. So whenever you need to edit the properties of a certain build, you need either to edit that configuration directly or activate it first and then go through the same process again. The next steps demonstrates how to go through both ways:

To create a new toolchain build configuration in Eclipse:

1. Go to Project

Build Configurations

Manage.

2. When Figure 5-9 is displayed, click New.

Figure 5-9 Manage build configurations

3. When Figure 5-10 is displayed:

a. Type the new build configuration name.

b. Type a description for that build.

c. Select the creation method of this new build, which might be one of the following items: i.

Existing configuration (can be one of already created build configurations) ii. Default configuration (if you have set some one already) iii. Import from projects (other projects that you have already configured in Eclipse) iv. Import predefined configurations (delivered with Eclipse) d. Click OK when you are satisfied with the options.

Figure 5-10 Create new build configuration wizard

The window in Figure 5-9 is displayed again, now with the newly created configuration.

72

IBM Parallel Environment (PE) Developer Edition

4. If you want, select it and make it active. The options, Delete and Rename are also available.

5. To exit this management area, click OK to accept all changes or Cancel to discard them.

5.4.1 Building (using targets)

Eclipse is flexible enough to allow you to configure the build environment in many details, so the build process can be entirely controlled through its GUI. For either a C/C++ or Fortran project, it allows you to change several build settings, for example:

򐂰 Build directory (root folder by default), command (

make

by default), and targets.

򐂰 Customize environment variables that are exported at build time.

򐂰

Enable and disable build logging.

򐂰 Choose binary and error parsers that best fits.

򐂰 Switch between toolchain.

򐂰 Change toolchain flags (only for Eclipse managed build). For makefile-based projects where the makefile content is not managed by Eclipse, change the toolchain settings

(compiler, flags, steps,) manually.

All build properties are accessible by right-clicking the project folder and then selecting

Properties

C/C++ Build (or Fortran Build). The project properties window along with

sections for build configuration are shown in Figure 5-11.

Figure 5-11 Project properties window

The simplest way to build a synchronized project is to right-click the project folder and then

click Build project, as shown in Figure 5-12 on page 74. Eclipse uses connection

configuration specified when the project was created to log into the remote target and then run

make all

to build the application. A similar procedure can be followed to clean up build artifacts (right-click the project folder and then select Clean Project) where it executes

make clean

.

Chapter 5. Managing projects using the Eclipse and PTP framework

73

Figure 5-12 Build project

Custom build targets

It is relatively common for projects requiring makefile targets to build and clean up other than all and clean defaults. Thus, we can create specific build targets for the project without

changing the toolchain or creating an entirely new configuration (as the one presented in 5.4,

“Building and running an application” on page 71).

Custom build targets are often used when a makefile project has several ways of building a program or when there are different targets inside the makefile. Therefore, you must execute different targets.

When creating targets, you can either use the Project Explorer view or use the Make Target view. To do this, make sure you are already in the C/C++ or Fortran perspective. Go to

Window

Show View

Make Target.

The Make Target view appears at the right-top corner of the Eclipse window (see Figure 5-16 on page 77).

Depending on your current view, the Make Target view might be shown or not in the Show

View submenu of the Menu Window. To open it, in these cases, you can either switch back to the C/C++ or Fortran views first or go to Window

Show View

Other (Alt+Shift+Q)

Make

Make Target.

In this case, the Make Target view appears at the bottom of Eclipse window, as shown in

Figure 5-13 on page 75.

74

IBM Parallel Environment (PE) Developer Edition

Figure 5-13 Alternative location for the make target view

To actually create a target example, we use the Project Explorer:

1. Select a directory inside the Project Explorer where you have a makefile, and right-click it.

2. Select Make Targets

Create, as shown in Figure 5-14 on page 76.

Chapter 5. Managing projects using the Eclipse and PTP framework

75

Figure 5-14 Create targets from the project explorer view

3. A new window is displayed named Create Make Target (see Figure 5-15 on page 77):

a. Type a new name for this target.

b. Customize the Make Target if needed.

c. Customize the Build Command.

d. Leave all the other options default. After you finish, click OK.

76

IBM Parallel Environment (PE) Developer Edition

Figure 5-15 Create make target dialog

The Target will now appear on the Make Target view under the same directory you issued the

creation. For example, Figure 5-16 shows two custom build targets called

install

and

cluster

.

Figure 5-16 Make target view

To execute a specific build target, we can do it through the:

1. Eclipse menu: a. Select Project

Make Target

Build (Shift+F9).

b. Select a target build configuration and click Build.

2. Project Explorer: a. Right-click over the directory containing a Make Target configuration.

b. Select Make Targets

Build (Shift+F9).

c. Select a target build configuration, and click Build.

3. Make Target view: a. Double-click the target configuration or right-click it, and select Build Target.

Chapter 5. Managing projects using the Eclipse and PTP framework

77

5.4.2 Running

When your code is built and becomes ready to be tested, you can either execute it and watch the whole process from beginning to the end, debug it, or profile it. There is also a fourth option that is available for external applications, but we talk about it at the end of this chapter.

In Eclipse, we can create separate configurations for each of these three types:

򐂰 Run configuration

򐂰 Debug configuration

򐂰 Profile configuration

All three are separate configurations (although they can be created from each other) and therefore run independently. When a specific configuration is created, it is automatically made available to the other two options because some of the configurations are shared between them and others are specific, for example:

򐂰

After creating an Eclipse project, and building it, usually a run configuration has to be configured for the program to run (unless it runs in a command line or is used by a third party program). After creating this

run configuration

, you can also debug it and profile it. If necessary, it is possible to edit these configurations in debug or profile mode to access the specific options for each mode.

򐂰 For example, if a run configuration is created, both the debug and profile configurations are available for the same run configuration options but with specific configurations (debug options and profile options respectively) that are not configured by the time that the run configuration is created (assumes default values).

򐂰 External applications mode does not share these configurations, as detailed in the

“Integrating external applications” on page 91.

򐂰 You can access these modes through the Eclipse Run menu or using the Eclipse quick

buttons, as shown in Figure 5-17.

Figure 5-17 Eclipse quick access buttons for debug, run and profile options

Run configuration

To create, edit, and delete run configurations:

1. Select Run

Run Configurations.

2. The Run Configurations window is displayed, shown in Figure 5-18 on page 79. In this

window, you have two separate areas, the left side is where you manage your configurations, and the right side is where you actually edit the configurations for the selected run configuration.

78

IBM Parallel Environment (PE) Developer Edition

Figure 5-18 Run configurations dialog

3. Figure 5-24 on page 83 illustrates the buttons you can use to create, duplicate (for already

created configurations), and delete configurations, respectively from left to right.

4. In Run Configurations (Figure 5-18), you have the following predefined configurations from

where you can create customized configurations:

– C/C++ application

– Fortran local application

– Launch group

– Parallel application

5. To create an example of a

Parallel Application

, select it, and click New Launch

configuration (first button as shown in Figure 5-24 on page 83). A new subentry label of

the Parallel Application label is displayed. You can name it and customize it with the following options, which are available on the right side of the Run Configurations window:

– Resources (Figure 5-19 on page 80).

– Application (Figure 5-21 on page 81).

– Arguments (Figure 5-22 on page 81).

– Environment (Figure 5-23 on page 82).

– Synchronize

– Common

6. This mode represents the baseline configuration of a run, and it shares all the configurations with the other two modes (except synchronize for the profile mode). The most important tabs are the Resources, Application, Arguments, and Environment tabs.

Inside these tabs, we can edit:

– The engine that distributes the processes and their respective options. Currently it is the available interface to several target system configurations, including IBM Parallel

Environment (PE) and LoadLeveler, as shown in Figure 5-20 on page 80.

– The nodes that are used to run the application.

– The application path (available in all nodes).

– The application arguments and alternative working paths.

– The definition of additional environment variables.

Chapter 5. Managing projects using the Eclipse and PTP framework

79

7. To save the changes, click Apply or just click Run to save them and run the configuration.

Figure 5-19 Run configurations (resources tab)

Figure 5-20 List of target system configurations in the resources tab

80

IBM Parallel Environment (PE) Developer Edition

Figure 5-21 Run configurations (application tab)

Figure 5-22 Run configurations (arguments tab)

Chapter 5. Managing projects using the Eclipse and PTP framework

81

Figure 5-23 Run configurations (environment tab)

Detailed information about how to create a run configuration for a parallel application and submit it to any job scheduler supported, as for instance IBM PE or LoadLeveler, can be performed with the following menu path Help

Help Contents

Parallel Tools Platform

(PTP) User Guide

Running Parallel Programs.

Debug configuration

To create, edit, and delete debug configurations:

1. Select Run

Debug Configurations.

2. The Debug Configurations window is displayed, shown in Figure 5-25 on page 84. In this

window, you have two separate areas, the left side where you manage your configurations and the right side where you actually edit the configurations for the selected debug configuration.

Figure 5-24 on page 83 illustrates the buttons you can use to create, duplicate (for already

created configurations) and delete configurations, respectively from left to right.

82

IBM Parallel Environment (PE) Developer Edition

Figure 5-24 Eclipse configuration management buttons

3. In the Debug Configurations window (Figure 5-24), you have the following predefined

configurations from where you can create customized configurations:

– C/C++ application

– C/C++ attach to application

– C/C++ postmortem debugger

– C/C++ remote application

– Fortran local application

– Launch group

– Parallel application

4. To create an example of a Parallel Application, select it, and click New launch

configuration (first button from Figure 5-24). A new subentry label of the Parallel

Application label is displayed. You can name it and customize it with the following options, which are available on the right side of the Debug Configurations window:

– Resources

– Application

– Arguments

– Debugger

– Environment

– Synchronize

– Source

– Common

5. As the name suggests, the specific configuration in this mode is the Debugger tab. Inside

that tab, choose which debugger to use and what options it uses, as shown in Figure 5-25 on page 84.

Chapter 5. Managing projects using the Eclipse and PTP framework

83

6. To save the changes, click Apply, or click Debug to save them and run the debug configuration.

Figure 5-25 Debug configurations dialog

The Eclipse PTP parallel debugger capabilities and more details about how to set up a debug

configuration properly are described in “Eclipse PTP Parallel debugger” on page 138.

Profile configuration

To create, edit, and delete profile configurations:

1. Select Run

Profile Configurations. The Profile Configurations window is displayed,

shown in Figure 5-26 on page 85. In this window, you have two separate areas. The left

side is where you manage your configurations, and the right side is where you actually edit the configurations for the selected profile configuration.

Figure 5-24 on page 83 illustrates the buttons you can use to create, duplicate (for already

created configurations) and delete configurations, respectively from left to right.

In the Profile Configurations window (Figure 5-26 on page 85), you have the following

predefined configurations from where you can create customized configurations:

– C/C++ application

– Launch group

– Parallel application

2. To create an example of a Parallel Application, select it, and click New launch

configuration (first button from Figure 5-24 on page 83). A new subentry label of the

Parallel Application label appears. You can name it and customize it with the following options that are available on the right side of the Profile Configurations window:

– Resources

– Application

– Arguments

– Environment

84

IBM Parallel Environment (PE) Developer Edition

– Performance analysis

– Parametric study

– Common

– HPC Toolkit

3. The specific configurations for this mode are the Performance Analysis, Parametric Study

and the HPC Toolkit tabs, shown in Figure 5-26. Inside these tabs we can edit the tool to

use for performance analysis (currently only HPC Toolkit is available), parametric tests options, and the HPC Toolkit specific options for instrumentation:

– Data collection

– Performance analysis using HPM (Hardware Performance Monitoring)

– Profiling and trace MPI calls

– MIO (I/O analysis and optimization)

4. To save the changes, click Apply, or just press Profile to save them and run the profile configuration.

Figure 5-26 Profile configurations (HPC Toolkit tab)

5.5 Edit features of Eclipse

For the current section, we gathered a group of features, which Eclipse can help enhance your code development of C, C++, or Fortran parallel applications.

The C/C++ editor

Eclipse CDT (C/C++ Development Toolkit) provides a full-featured and rich editor for C and

C++ languages. In the C/C++ perspective, you cannot perform common tasks, such as the

following ones but also the more advanced tasks, which are described in Table 5-2 on page 86:

– Code with syntax highlights for C, C++ and makefile

Chapter 5. Managing projects using the Eclipse and PTP framework

85

– Code navigation

– Outline C/C++ syntax elements

– View user-defined make targets

– Outline makefile syntax elements

– Source code refactoring and transformation

Table 5-2 Eclipse edit features for C/C++

Feature Description

Jump into function declaration Can right-click and jump into the function code.

Code template

Content assist

Provides hundreds of code templates to make coding faster and easier. Moreover, there are templates for Fortran language in its diverse variants and code statements for OpenACC, OpenMP, and

MPI frameworks.

Code templates can be inserted into application code by pressing

Ctrl+Space and then selecting a desired template, as shown in

Figure 5-30 on page 89.

As you are typing, it displays a list of statements, such as variables, subroutines, intrinsics, and code templates, based in the scope and alphabetical in what you typed. The content assist is also triggered

by pressing Ctrl+Space. See Figure 5-31 on page 89 as an

example of content assist.

Show type hierarchy

Show call hierarchy

Include browser

Shows a tree display of a type or method. The operation is executed when you select a type or method, right-click it, and select Open

Type Hierarchy. As a result, it shows a type hierarchy view, as

shown in Figure 5-27 on page 87.

Shows a tree display of function call hierarchy. The operation is executed when you select function call or declaration, right-click it, and select Open Call Hierarchy. As a result, it shows a call

hierarchy view, as shown in Figure 5-28 on page 87.

Shows a tree display with a relationship between the source and header files. The view is opened by right-clicking an open file in the editor and then selecting Show In

Include Browser

As a result,

it opens a view, as shown in Figure 5-29 on page 88.

86

IBM Parallel Environment (PE) Developer Edition

Figure 5-27 C/C++ editor type hierarchy

Figure 5-28 C/C++ editor call hierarchy view

Chapter 5. Managing projects using the Eclipse and PTP framework

87

Figure 5-29 C/C++ include browser

The Fortran editor

Eclipse Photran implements a full-featured and rich editor but rather specific for the Fortran

language, which are discussed in Table 5-3. Likewise the CDT editor provides the following

features:

򐂰

Code navigation

򐂰

Syntax-highlighting editor

򐂰

Outline view

򐂰

Makefile-based compilation along with make target view

Table 5-3 Eclipse edit features for Fortran

Feature Description

Code template It provides hundreds of code templates to make coding faster and easier. Moreover, there are templates for Fortran language in its diverse variants and code statements for OpenACC, OpenMP, and

MPI frameworks.

Code templates can be inserted into application code by pressing

Ctrl+Space and then selecting a desired template, as shown in

Figure 5-30 on page 89.

Content assist

Declaration view

As you type, it displays a list of statements, such as variables, subroutines, intrinsics, and code templates based on the scope and alphabets that you typed. The content assist is also triggered

by pressing Ctrl+Space. See Figure 5-31 on page 89 as an

example of content assist.

Provides a view tab that displays detailed information about any selected (positioning cursor in) program, variable, subprogram, or

subroutine statement. See the bottom view tab in Figure 5-32 on page 90 as an example.

88

IBM Parallel Environment (PE) Developer Edition

Feature

Hover Tip

Description

Fortran hover tips display the same information as the declaration view but in an embedded window just below the selected

statement. See the hover tip in Figure 5-32 on page 90 as an

example.

Fortran language-based search Provides search mechanics focused in Fortran syntax, allowing specific queries in statements (variable, function, subroutine,

module, and so on.). The fortran search window (see Figure 5-33 on page 90) can be opened in the menu Search

Fortran.

Figure 5-30 Fortran editor code templates

Figure 5-31 Fortran editor content assist

Chapter 5. Managing projects using the Eclipse and PTP framework

89

Figure 5-32 Fortran declaration view and hover tip

Figure 5-33 Fortran search window

Notice that most of the Fortran editor features described in Table 5-3 on page 88 rely on

source code analysis that must be enabled using the menu Project

general

properties

Fortran

Analysis/refactoring and then setting the options for each feature, as shown in

Figure 5-34 on page 91.

90

IBM Parallel Environment (PE) Developer Edition

Figure 5-34 Enable Fortran analysis

The Eclipse PTP also provides tools for static analysis of parallel applications source code

that is discussed in “Parallel Static Analysis” on page 133.

5.6 Debugging using Eclipse

The Eclipse PTP comes with a parallel debugger that provides parallel applications some specific debugging features that distinguish it from the Eclipse debugger for serial applications. In particular, it was designed to threat parallel application as a set of processes; therefore, providing different visualization modes, a special type of breakpoint called Parallel

Breakpoint, multiple current instruction pointers, and other features that ease the debugging of parallel applications.

Refer to “Eclipse PTP Parallel debugger” on page 138 for further details about PTP parallel

debugger features along with information about how it integrates within IBM Parallel

Environment (PE) Developer Edition.

5.7 Integrating external applications

In this section, we present the option to incorporate an external tool or call program into

Eclipse. These programs can either be configured to run after building a project or for all projects of the same selected workspace.

Chapter 5. Managing projects using the Eclipse and PTP framework

91

To create, edit, and delete external program configurations:

1. Select Run

External Tools

External Tools Configurations. The External Tools

Configurations window is displayed, as shown in Figure 5-35. In this window, you can

create, duplicate (for already created configurations), and delete configurations,

respectively from left to right, as shown also in Figure 5-24 on page 83.

Figure 5-35 External tools configurations dialog

2. In the External Tools Configurations window (Figure 5-35), you have a predefined

configuration called Program from where you can create customized configurations.

92

IBM Parallel Environment (PE) Developer Edition

Figure 5-36 Creating a program configuration inside the external tools configurations

3. To create an example of a Program configuration, select it, and click New Launch

Configuration (first button from Figure 5-24 on page 83). A new subentry label of the

Program label appears. After creating it, a second area is distinguished to the right side of the External Tools Configuration window, where you actually give it a name and customize it within the following tabs:

– Main

– Refresh

– Build

– Environment

– Common

4. The specific configurations for this mode are the Main, Refresh and the Build tabs

(Figure 5-36). Inside these tabs, we can edit which program to use where and for what

projects to run it:

– At the Main tab, you specify the program to run, where it runs, and its arguments

(Figure 5-36).

– Inside the Refresh tab, you can specify what you want to refresh in the Eclipse

workspace upon completion of the program you specified (see Figure 5-37 on page 94).

– Under the Build tab, you can choose when to run the program. The available options are the possibility to run it after or before building a specific project or the entire

workspace (Figure 5-38 on page 94).

Chapter 5. Managing projects using the Eclipse and PTP framework

93

Figure 5-37 Refreshing the configuration tab

Figure 5-38 Build configuration tab

5. To save the changes, click Apply, or just press Run to save them and run the external tool configuration.

94

IBM Parallel Environment (PE) Developer Edition

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
