Keysight M9021A Gen 2, x8 PCIe Cable
Manuals and User Guides for Keysight M9021A Gen 2, x8 PCIe Cable. We found 1 manuals for free downloads installation Guide
Keysight M9021A Gen 2, x8 PCIe Cable provides a very high bandwidth serial link between a computer and a PXIe chassis. With such a link, almost any computer application can have complete control over PXI and PXIe modules installed in that chassis. Additionally, this device has LEDs on its front panel which help to indicate the communication speed between the PC and chassis. For applications where this device will be used to connect to a downstream RAID solution (such as the JMR mass storage), the module must be installed in a x8 hybrid slot within the PXIe chassis.
Key Features
- High bandwidth serial link
- PCIe link between computer and PXIe chassis
- Control PXI and PXIe modules from computer application
- LEDs indicate communication speed
- Compatible with Keysight M9018A PXIe chassis
- x8 PCIe cable connector
- Data bandwidth up to 4 GB/s
Pages: 4 Keysight M9021A Gen 2, x8 PCIe Cable installation Guide
Brand: Keysight Category: Electrical equipment & supplies Size: 200 KB
Languages: English
Open manualFrequently Answers and Questions
In which slot should the M9021A be installed when it is being used in the Keysight M9018A PXIe chassis?
What is the default setting for the S301 switches?
What type of cable should be used with the M9021A?
How do the LEDs on the M9021A's front panel help the user?
Can the M9021A be used with a downstream RAID solution?
