Trendnet TFC-1000 MSC
Manuals and User Guides for Trendnet TFC-1000 MSC. We found 6 manuals for free downloads Quick Installation Guide
Below you will find brief information for Fiber Converter TFC-1000 MSC, Fiber Converter TFC-1000 S20, Fiber Converter TFC-1000 S50, Fiber Converter TFC-1000 S70, Fiber Converter TFC-1000 S40D3. This fiber converter converts signal from twisted-pair copper cable (UTP/STP) to fiber optic and vice versa. It connects to a switch via a RJ-45 network port, and uses SC fiber optic connector. TFC-1000 MSC works with multimode fiber, while TFC-1000 S20, TFC-1000 S50, and TFC-1000 S70 – with single-mode fiber. TFC-1000 S40D3, TFC-1000 S10D3, and TFC-1000 S60D3 are bi-directional fiber optic converters with both TX & RX fiber ports. The TFC-1000 series is designed for Gigabit Ethernet applications where long distances are required.
Key Features
Converts 10/100/1000 Mbps RJ-45 to fiber optic
Supports multimode and single-mode fiber
Supports bi-directional fiber optic conversion
Supports distances up to 70 km for single-mode
Supports distances up to 550 m for multimode
LED indicators for power, link/activity
Pages: 12 Trendnet TFC-1000 MSC Quick Installation Guide
Brand: Trendnet Category: Network media converters Size: 336 KB
Languages: English
Open manualOther manuals and documents
Frequently Answers and Questions
After connecting the Fiber converter, the LEDs do not turn on. What should I do?
First, check that the power outlet is receiving power. Second, make sure the power adapter is firmly connected to the Fiber converter and the power outlet. Third, make sure the Ethernet and the Fiber cables are connected.
All the LEDs are on, but I can't make a connection. What should I do?
First, verify that you are using the proper fiber cable (e.g. multi-mode fiber cable for multi-mode converter; single-mode fiber cables for single-mode converters). Second, verify that the TX and RX cables have been reverse on the opposite Fiber connection. Third, power down the fiber converters and the switches. Wait 15 seconds, then plug the switches and the fiber converters back in.
What is the maximum distance that is supported by the fiber converter?
Please reference section 4 for distance information.
