Multimedia Projector
LV-7325U
Owner’s Manual
E
English
2
INFORMATION TO THE USER
NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
TO THE OWNER
As the owner of a new Multimedia Projector, you are probably eager to try out your new projector. Before you do, we suggest that your spend a little time reading this manual to familiarize yourself with the operating procedures so that you will receive maximum satisfaction from the many features included in your new projector.
This owner's manual will acquaint you with your projector's features. Reading it will help us too. Through the years, we have found that many service requests were not caused by problems with our projectors. They were caused by problems that could have been prevented, if the owner had followed the instructions in the manual.
You can often correct operating problems yourself. If your projector fails to work properly, see
"TROUBLESHOOTING" section on pages 44 ~ 45 and try the solution marked for each problem.
SAFETY PRECAUTIONS
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
This Projector has a grounding-type AC line plug. This is a safety feature to be sure that the plug will fit into the power outlet. Do not try to defeat this safety feature.
This projector produces intense light from the projection lens. Do not stare directly into the lens as possible eye damage could result. Be especially careful that children do not stare directly into the beam.
The Remote Control Unit, supplied to this projector, emits the laser beam as the Laser Pointer function from the Laser Light Window while pressing the LASER button (for 1 minute). Do not look into the Laser
Light Window or shine the laser beam on yourself or other people. Eye damage may result.
This projector should be set in the way indicated. If not, It may result in fire hazard.
If the projector will not be used for an extended time, unplug the projector from the power outlet.
READ AND KEEP THIS OWNER'S MANUAL FOR LATER USE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE EXCEPT LAMP REPLACEMENT. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE CONSTITUTING
A RISK OF ELECTRIC SHOCK IS
PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
OWNER'S MANUAL WITH THIS UNIT
.
IMPORTANT SAFETY INSTRUCTIONS
All the safety and operating instructions should be read before the product is operated.
Read all of the instructions given here and retain them for later use. Unplug this projector from AC power supply before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.
Do not use attachments not recommended by the manufacturer as they may cause hazards.
Do not place this projector on an unstable cart, stand, or table.
The projector may fall, causing serious injury to a child or adult, and serious damage to the projector. Use only with a cart or stand recommended by the manufacturer, or sold with the projector. Wall or shelf mounting should follow the manufacturer's instructions, and should use a mounting kit approved by the manufacturer.
Do not expose this unit to rain or use near water... for example, in a wet basement, near a swimming pool, etc...
Slots and openings in the back and bottom of the cabinet are provided for ventilation, to insure reliable operation of the equipment and to protect it from overheating.
The openings should never be covered with cloth or other materials, and the bottom opening should not be blocked by placing the projector on a bed, sofa, rug, or other similar surface. This projector should never be placed near or over a radiator or heat register.
This projector should not be placed in a built-in installation such as a book case unless proper ventilation is provided.
This projector should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied, consult your authorized dealer or local power company.
Do not overload wall outlets and extension cords as this can result in fire or electric shock. Do not allow anything to rest on the power cord. Do not locate this projector where the cord may be damaged by persons walking on it.
Never push objects of any kind into this projector through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the projector.
Do not attempt to service this projector yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Unplug this projector from wall outlet and refer servicing to qualified service personnel under the following conditions: a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the projector.
c. If the projector has been exposed to rain or water.
20cm d. If the projector does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the projector to normal operation.
e. If the projector has been dropped or the cabinet has been damaged.
f. When the projector exhibits a distinct change in performance-this indicates a need for service.
When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or injury to persons.
Upon completion of any service or repairs to this projector, ask the service technician to perform routine safety checks to determine that the projector is in safe operating condition.
GROUND
This projector is equipped with a grounding type AC line plug.
Should you be unable to insert the plug into the outlet, contact your electrician. Do not defeat the safety purpose of this grounding type plug.
Follow all warnings and instructions marked on the projectors.
For added protection to the projector during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet. This will prevent damage due to lightning and power line surges.
An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.
If the projector is to be built into a compartment or similarly enclosed, the minimum distances must be maintained.
Do not cover the ventilation slot on the projector.
Heat build-up can reduce the service life of your projector, and can also be dangerous.
PROJECTOR
(FRONT)
PROJECTOR
(SIDE)
WALL
50cm 50cm 50cm
3
4
TABLE OF CONTENTS
FEATURES AND DESIGN
PREPARATION 6
NAME OF EACH PART OF THE PROJECTOR 6
SETTING-UP THE PROJECTOR
POSITIONING THE PROJECTOR
7
7
ADJUSTABLE FEET
CONNECTING THE AC POWER CORD
VENTILATION
MOUNTING LENS COVER
MOVING THE PROJECTOR
8
9
7
8
9
SELECTING COMPUTER MODE
SELECTING COMPUTER SYSTEM
23
23
PC ADJUSTMENT 24
COMPATIBLE COMPUTER SPECIFICATION 26
PICTURE IMAGE ADJUSTMENT
PICTURE POSITION ADJUSTMENT
PICTURE SCREEN ADJUSTMENT
27
28
29
CONNECTING THE PROJECTOR 10
TERMINALS OF THE PROJECTOR 10
CONNECTING TO THE VIDEO EQUIPMENT 11
CONNECTING TO THE COMPUTER 12
VIDEO MODE
SELECTING VIDEO MODE
SELECTING COLOR SYSTEM
PICTURE SCREEN ADJUSTMENT
PICTURE IMAGE ADJUSTMENT
BEFORE OPERATION
OPERATION OF THE REMOTE CONTROL
LASER POINTER FUNCTION
REMOTE CONTROL BATTERY INSTALLATION
TOP CONTROLS AND INDICATORS
OPERATING ON-SCREEN MENU
HOW TO OPERATE THE ON-SCREEN MENU
FLOW OF ON-SCREEN MENU
MENU BAR
5
14
14
14
15
16
17
17
17
18
COMPUTER MODE
MCI MODE
OPERATING THE PC CARD SLOT
SELECTING MCI MODE
SHOW THE DATA IN THE MEMORY CARD
WRITE DATA INTO THE MEMORY CARD
PICTURE IMAGE ADJUSTMENT
PICTURE POSITION ADJUSTMENT
PICTURE SCREEN ADJUSTMENT
CF CARD AND PCMCIA ADAPTER
32
36
36
37
38
32
33
34
35
SETTING
SETTING MENU
SETTING LANGUAGE
23
30
30
30
30
31
40
40
40
BASIC OPERATION
TURNING ON / OFF THE PROJECTOR
ADJUSTING THE IMAGE
ZOOM ADJUSTMENT
FOCUS ADJUSTMENT
KEYSTONE ADJUSTMENT
BRIGHT SWITCH
NO SHOW FUNCTION
PICTURE FREEZE FUNCTION
SOUND ADJUSTMENT
SOUND VOLUME ADJUSTMENT
SOUND MUTE ADJUSTMENT
20
20
21
21
21
21
22
22
22
22
22
22
APPENDIX
OPERATING WIRELESS MOUSE
MAINTENANCE
TEMPERATURE WARNING INDICATOR
AIR FILTER CARE AND CLEANING
CLEANING THE PROJECTION LENS
LAMP REPLACEMENT
LAMP REPLACEMENT MONITOR TIMER
TROUBLESHOOTING
TECHNICAL SPECIFICATIONS
41
41
42
42
42
42
43
43
44
46
TRADEMARKS
● Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple Computer,Inc.
● IBM and PS/2 are trademarks or registered trademarks of International Business Machines, Inc.
● Windows and PowerPoint are registered trademarks of Microsoft Corporation.
● Each name of corporations or products in the owner's manual is a trademark or a registered trademark of its respective corporation.
FEATURES AND DESIGN
This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. The projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology.
◆
Compatibility
This projector is compatible with many different types of personal computers and video devices, including;
● IBM-compatible computers, including laptops, up to 1280 x 1024 resolution.
● Apple Macintosh and PowerBook computers up to 1280 x 1024 resolution.
● Various video equipment using any of the world wide video standards, including
NTSC, NTSC4.43, SECAM, PAL, PAL-M and PAL-N.
◆
Image Resolution
Picture Image of the computer is projected in the resolution of 1024 x 768 and it is provided just as it appears on your computer's monitor.
Screen resolutions between 1024 x 768 and
1280 x 1024 are compressed to 1024 x 768, and this projector cannot display screen resolutions above 1280 x 1024. If your computer's screen resolution is higher than
1280 x 1024, reset it to a lower resolution before you connect the projector.
◆
◆
Turbo Bright System
Brightness of 1500 ANSI lumens, the highest abailable in ultra portable models, is achieved.
(1200 ANSI lumens in the standard mode.)
PC CARD SLOT
This projector has a PC CARD SLOT for easier presentations. Pictures can be projected just by inserting a memory card including image data. Presentation data can be edited by "Media Card Imager" software
(supplied). Refer to the pages 32 ~ 39 of this manual and the Owner's Manual for Media
Card imager for operations.
◆
Laser Pointer Function
The Remote Control Unit of this projector includes the Laser Pointer function providing the ability to point and highlight during presentations.
◆
Other Features
This projector has Motor Zoom/Focus, No
Show, Picture Freeze, Keystone, Mute functions.
◆
Portability
This projector is quite compact in size and weight. Having a sophisticated shape like an attaché case with a retractable carrying handle, the projector will help you make powerful presentations wherever you go.
◆
Automatic Multiscanning System
This projector automatically tune to the most personal computers currently distributed by simply connecting. It is free from complicated adjustments to project picture images from most personal computers.
◆
Multilanguage Menu Display
Operation menu is displayed in; English,
Deutsch, Français, Italiano, Español, or
Japanese
◆
Accessories
This projector comes with the parts listed below. Check to make sure all are included. If any parts are missing, contact to a sales dealer.
● Owner's Manual.
● AC Power Cord.
● Wireless Remote Control Unit.
● Batteries for Remote Control Unit.
● VGA Cable.
● Control Cable for PS/2 Port.
● Media Card Imager for Windows 95 (CD-ROM) and Owner’s Manual for this software.
● Lens Cover and Strap for Lens Cover.
● Dust Cover.
5
6
PREPARATION
NAME OF EACH PART OF THE PROJECTOR
FRONT OF THE CABINET
PROJECTION LENS
PC CARD SLOT
LENS COVER
INFRARED REMOTE RECEIVER
SPEAKER (Monaural)
CARRY HANDLE
BACK OF THE CABINET
EXHAUST VENT
HOT AIR EXHAUSTED !
Air blown from the exhaust vent is hot.
When using or installing the projector, following attention should be taken.
● Do not put a flammable object near this vent.
● Keep heat-sensitive objects away from the exhaust vent.
● Do not touch this area especially screws and metallic parts. This area will become hot while the projector is used.
POWER CORD CONNECTOR
BRIGHT SWITCH
INFRARED
REMOTE RECEIVER
BOTTOM OF THE CABINET
AIR INTAKE VENTS
These Air Intake Vents should not be blocked.
ADJUSTABLE FEET
AND
FEET LOCK LATCHES
LAMP COVER
PREPARATION
SETTING-UP THE PROJECTOR
POSITIONING THE PROJECTOR
● This projector is designed to project on a flat projection surface.
● The projector can be focused from 4.6’(1.4m) ~ 35.4’(10.8m).
● Refer to the figure below to adjust the screen size.
4.6’ (1.4m)
40”
11.8’ (3.6m)
100”
77”
18.0’ (5.5m)
24.0’ (7.3m)
200”
150”
115”
154”
30”
35.4’ (10.8m)
300”
231”
H1
H2
Screen Size
(W x H) mm
Height (H1)
Height (H2)
30”
610 x 457
17.1”(435mm)
0.9”(22mm)
60”
1219 x 914
34.3”(870mm)
1.7”(44mm)
100”
2032 x 1524
57.1”(1451mm)
2.9”(73mm)
150”
3048 x 2286
200”
4064 x 3048
300”
6096 x 4572
85.7”(2177mm) 114.3”(2903mm) 171.4”(4354mm)
4.3”(109mm) 5.7”(145mm) 8.6”(218mm)
ROOM LIGHT
The level of brightness in a room has a great influence on picture quality. It is recommended to limit ambient lighting in order to provide the best image.
ADJUSTABLE FEET
Picture tilt and projection angle can be adjusted by rotating the ADJUSTABLE FEET. Projection angle can be adjusted to 10 degrees.
1
2
Lift the front of the projector and pull the FEET LOCK
LATCHES on both sides of the projector.
Release the FEET LOCK LATCHES to lock the
ADJUSTABLE FEET and rotate the ADJUSTABLE
FEET to fine tune the position and the tilt.
3 To shorten the ADJUSTABLE FEET, lift the front of the projector and pull and undo the FEET LOCK LATCHES.
The position and the keystone distortion of the image can also be adjusted using the Menu Operation. (Refer to pages 21, 29, 30 and 37.)
ADJUSTABLE FEET
FEET LOCK
LATCHES
7
8
PREPARATION
CONNECTING THE AC POWER CORD
This projector uses nominal input voltages of 100-120 V
AC. The projector automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor.
To reduce the risk of electrical shock, do not plug into any other type of power system.
Consult your authorized dealer or service station if your are not sure of the type of power supply in use.
Connect the projector with the peripheral equipment before turning the projector on. (Refer to pages 10 ~ 13 for connection.)
CAUTION
For safety, unplug the AC Power Cord when the appliance is not in use.
When this projector is connected to the outlet with the AC Power Cord, the appliance is in Stand-by
Mode and consumes some electric power.
Connect the AC power supply cord (supplied) to the projector.
The socket-outlet must be near this equipment and must be easily accessible.
Projector side (Female) AC outlet side (Male)
VENTILATION
This projector is equipped with cooling fans for protection from overheating. Pay attention to the following to ensure proper ventilation and avoid a possible risk of fire and malfunction.
● Do not cover the vent slot.
● Keep the rear grill at least 3 feet (1m) away from any object.
● Keep sides clear of any obstructions. Obstructions may block cooling air.
EXHAUST VENT
(REAR SIDE)
AIR INTAKE VENTS
(BOTH SIDES)
PREPARATION
MOUNTING LENS COVER
When moving this projector, or when it is not used for an extended period, replace the lens cover.
1
2
3
Secure the Strap for Lens Cover through the hole of the
Lens Cover.
Turn the power off, and disconnect the AC power cord from the AC outlet.
Turn the projector upside down. Secure the Strap for
Lens Cover to the hole on the bottom of the projector with the screw.
LENS COVER
MOVING THE PROJECTOR
Use the Carry Handle when moving the Projector.
When moving the projector, replace the lens cover and retract the feet to prevent damage to the lens and the cabinet.
When this projector is not in use for an extended period, replace the Lens Cover, retract the Adjustable
Feet and cover the unit with the Dust Cover supplied with this projector.
STRAP FOR LENS COVER
(Secure to the hole with the screw.)
CAUTION IN CARRYING OR TRANSPORTING THE PROJECTOR
● Do not drop or bump the projector, otherwise damages or malfunctions may result.
● When transporting the projector, use a carrying case recommended by Canon.
● Do not transport the projector by using a courier or transport service in an unsuitable transport case. This may cause damage to the projector. To transport the projector through a courier or transport service, use a case recommended by Canon.
● For carrying or transportation cases, contact a Canon authorized dealer.
9
CONNECTING THE PROJECTOR
TERMINALS OF THE PROJECTOR
10
S-VIDEO INPUT JACK
Connect the S-VIDEO output from the video equipment to this terminal.
(Refer to P11.)
AUDIO INPUT JACKS
Connect the audio outputs from the video equipment to these terminals.
(Refer to P11.)
● When the audio output is monaural, connect it to the L
(mono) jack.
COMPUTER INPUT TERMINAL
Connect the computer output to this terminal.
(Refer to P12, 13.)
MONITOR OUTPUT TERMINAL
This terminal outputs the signal from the COMPUTER IN terminal. Connect to a monitor using this terminal.
(Refer to P12, 13.)
S-VIDEO
R-AUDIO-L (MONO)
COMPUTER IN
VIDEO
AUDIO
IN
OUT
MONITOR OUT
CONTROL PORT
VIDEO INPUT JACK
Connect the video output from the video equipment to this terminal.
(Refer to P11.)
COMPUTER AUDIO INPUT JACK
Connect the audio output from the computer to this terminal.
(Refer to P12, 13.)
AUDIO OUTPUT JACK (STEREO)
Connect the audio amplifier to this terminal.
(Refer to P12, 13.)
CONTROL PORT CONNECTOR
When controlling the computer with the Remote Control of this projector, connect the mouse port of your personal computer to this terminal. It is also used for write on or read from the data of the PC CARD SLOT in
MCI mode.
(Refer to P12, 13, 35.)
COMPUTER INPUT / MONITOR OUTPUT TERMINAL
Terminal : HDB15-PIN
Connect the display output terminal of the computer to COMPUTER INPUT with the VGA Cable (supplied). And connect the monitor to MONITOR OUTPUT with the monitor cable (not supplied). When connecting the Macintosh computer, the
MAC Adapter (not supplied) is required.
Pin Configuration
5 4
10
15 14
9
3
13
8
2
12
7
1
11
6
6
7
4
5
8
1
2
3
Red Input
Green Input
Blue Input
Sense 2
Ground (Horiz.sync.)
Ground (Red)
Ground (Green)
Ground (Blue)
9
10
11
12
13
14
15
Non Connect
Ground (Vert.sync.)
Sense 0
Sense 1
Horiz. sync.
Vert. sync.
Reserved
CONTROL PORT CONNECTOR
Terminal : Mini DIN 8-PIN
Connect control port (PS/2, Serial or ADB port) on your computer to this terminal with the Control Cable (the Control
Cable for PS/2 port is supplied).
Pin Configuration
5
8 7 6
4 3
2 1
3
4
5
6
1
2
7
8
PS/2
-----
CLK
DATA
GND
-----
-----
GND
-----
Serial
R X D
-----
-----
GND
RTS
T X D
GND
GND
ADB
-----
ADB
-----
GND
-----
-----
-----
GND
CONNECTING THE PROJECTOR
CONNECTING TO THE VIDEO EQUIPMENT
Video Source (example)
Video Cassette Recorder Video Disc Player
Video / Audio Output S-VIDEO Output
Cables used for connection
• VIDEO CABLE ✽
• S-VIDEO CABLE ✽
• AUDIO CABLE (stereo) ✽
✽ These cables are not supplied with this projector.
Video Audio Cable
✽
S-VIDEO Cable
✽
Use either the VIDEO jack or the S-VIDEO jack.
When the both jacks are connected, the S-VIDEO jack has priority over the
VIDEO jack.
S-VIDEO
R-AUDIO-L
(MONO)
VIDEO
AUDIO
IN
OUT
COMPUTER IN
MONITOR OUT
CONTROL PORT
Terminals of the Projector
Audio Cable (Stereo) ✽
NOTE :
When connecting the cable, the power cords of both the projector and the external equipment should be disconnected from AC outlet. Turn the projector and peripheral equipment on before the computer is switched on.
Audio Input
External Audio Equipment
Audio Speaker
(stereo)
Audio Amplifier
11
CONNECTING THE PROJECTOR
CONNECTING TO THE COMPUTER
To connect to the computer, refer to the figure below.
Cables used for connection
• VGA CABLE
• CONTROL CABLE FOR PS/2 PORT
• CONTROL CABLE FOR SERIAL PORT,or ADB PORT ✽
• MAC ADAPTER ✽
• MONITOR CABLE ✽
• PC AUDIO CABLE (stereo) ✽
✽ These cables are not supplied with this projector.
IBM-compatible computers or Macintosh computers (VGA / SVGA / XGA / SXGA)
Desktop type
Laptop type
Monitor
Audio Speaker
(stereo)
12
Audio Amplifier
To the Monitor
To each terminal of your computer
Monitor Output
ON DIP
1 2 3 4 5 6
MAC Adapter ✽
Set the slide switches following the chart on the next page.
Serial port PS/2 port
Terminal Terminal
ADB port Audio Output
Terminal
Audio Input
Audio Cable (stereo)
✽
Control Cable for ADB Port ✽
Control Cable for PS/2 Port
Control Cable for Serial Port ✽
VGA Cable
Monitor Cable ✽
NOTE :
When connecting the cable, the power cords of both the projector and the external equipment should be disconnected from AC outlet. Turn the projector and peripheral equipment on before the computer is switched on.
CONNECTING THE PROJECTOR
S-VIDEO
R-AUDIO-L
(MONO)
VIDEO
AUDIO
IN
OUT
COMPUTER IN
MONITOR OUT
CONTROL PORT
COMPUTER
IN
MONITOR
OUT
CONTROL
PORT
AUDIO
IN
AUDIO
OUT
Use one of these Control
Cables corresponding with the terminal of your computer.
◆ MAC ADAPTER (Not supplied)
Set the switches as shown in the table below depending on the RESOLUTION
MODE that you want to use before your turn on the projector and computer.
ON
OFF
ON DIP
1 2 3 4 5 6
13" MODE (640 x 480)
16" MODE (832 x 624)
19" MODE (1024 x 768)
21" MODE (1152 x 870)
1 2
ON ON
OFF ON
OFF
ON
3
OFF
OFF
ON ON
ON ON
4 5 6
OFF OFF OFF
ON OFF OFF
OFF OFF OFF
ON OFF OFF
13
BEFORE OPERATION
OPERATION OF THE REMOTE CONTROL
Left Side
ON
ALL OFF
VIDEO BUTTON
Used to select VIDEO source. (P30)
COMPUTER / MCI BUTTON
Used to select source either
COMPUTER or MCI mode.
(P23)
MENU BUTTON
Used to select MENU operation. (P17-19)
COMPUTER/
MCI VIDEO
POWER
ZOOM FOCUS VOLUME
MUTE
D.ZOOM
PAGE
MENU
ALL-OFF SWITCH
When using the Remote Control
Unit, turn this switch to “ON” and turn it “ALL OFF” when it is not used.
SELECT BUTTON
Used to execute the item selected or to expand the image in DIGITAL ZOOM mode. (P29, 37)
It is also used as a PC mouse in Wireless Mouse Operation.
(P41)
LASER BUTTON
Used to operate laser pointer function. The laser beam is emitted while pressing this button within 1 minute. When using the laser pointer for more than 1 minute, release the button and press it again.
LASER
NO SHOW
KEYSTONE
FREEZE
AUTO IMAGE NORMAL
POWER ON-OFF BUTTON
Used to turn the projector on or off. (P20)
POINT BUTTON
Used to move the pointer on the MENU, to adjust the item, or to pan the image in DIGITAL
ZOOM mode. (P29, 37)
It is also used as a PC mouse in Wireless Mouse Operation.
(P41)
✽ When pressing the center of this button, it works as the SELECT button.
RIGHT CLICK BUTTON
Used to compress the image in DIGITAL ZOOM mode.
(P29, 30, 37)
It is also used as a PC mouse in Wireless Mouse Operation.
(P41)
LASER POINTER FUNCTION
This remote control emits a laser beam as the Laser Pointer from the Laser Light Window. When the LASER button is pressed, the laser light goes on. And when the button is pressed more than 1 minute or the button is released, light goes off.
Laser light is emitted with the RED light which tells the laser beam being emitted.
The laser emitted is a class II laser; therefore, do not look into the Laser Light Window or shine the laser beam on yourself or other people. The three marks below are the caution labels for the laser beam.
CAUTION : Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
These caution labels are put on the remote control.
Laser Light Window
14
BEFORE OPERATION
ZOOM BUTTON
Used to adjust zoom.
(P21)
COMPUTER/
MCI VIDEO
POWER
ZOOM FOCUS VOLUME
FOCUS BUTTON
Used to adjust focus.
(P21)
MUTE
D.ZOOM
PAGE
MENU
MUTE BUTTON
Used to mute sound.(P22)
NO SHOW BUTTON
Used to turn the picture into a black image. (P22)
AUTO IMAGE BUTTON
Use to operate AUTO
IMAGE function. (P28)
LASER
NO SHOW
KEYSTONE
FREEZE
AUTO IMAGE NORMAL
VOLUME BUTTON
Used to adjust volume.
(P22)
D.ZOOM BUTTON
Used to turn the projector into DIGITAL ZOOM mode. (P29, 37)
PAGE BUTTONS
Used to move to next / previous page of the data in memory card. These buttons are activated in
MCI mode only. (P34)
Operating Range
Point the remote control toward the projector (Receiver Window) when pressing the buttons. Maximum operating range for the remote control is about 16.4” (5m) and 60° front and rear of the projector
60°
16.4”
(5 m)
FREEZE BUTTON
Used to stop the picture.
(P22)
NORMAL BUTTON
Used to reset to normal picture adjustments preset by the factory.
(P27, 31, 36)
KEY STONE BUTTON
Used to correct the key stone distortion.
(P21, 29, 30, 37)
60°
16.4”
(5 m)
REMOTE CONTROL BATTERY INSTALLATION
1
Remove the battery compartment lid.
Press the lid downward and slide it.
2
Slide the batteries into the compartment.
Two AA size batteries
For correct polarity (+ and –), be sure the battery terminals are in contact with the pins in the compartment.
3
Replace the compartment lid.
To insure safe operation, please observe the following precautions :
● Use (2) AA type alkaline batteries.
● Replace two batteries at the same time.
● Do not use a new battery with a used battery.
● Avoid contact with water or liquid.
● Do not expose the Remote Control Unit to moisture, or heat.
● Do not drop the remote control unit.
● If batteries have leaked on the remote control, carefully wipe the case clean and install new batteries.
15
BEFORE OPERATION
TOP CONTROLS AND INDICATORS
MENU BUTTON
Used to open or close the
MENU operation.
(P17, 19)
NORMAL BUTTON
Used to reset to normal picture adjustment preset by factory. (P27, 31, 36)
SELECT BUTTON
Used to execute the item selected. It is also used to expand the image in
DIGITAL ZOOM mode.
(P29, 37)
ZOOM BUTTONS
Used to select zoom adjust.
(P21)
VOLUME BUTTON
Used to adjust volume.
(P22)
BRIGHT SWITCH INDICATOR
This indicator lights when the BRIGHT SWITCH is set to BRIGHTER. (P22)
POWER
POWER ON–OFF BUTTON
Used to turn the projector on or off. (P20)
MODE BUTTON
Used to select input source among Computer, Video or
MCI. (P23, 30)
NORMAL
ZOOM
WIDE
TELE
MENU
SELECT
MODE AUTO IMAGE
AUTO IMAGE BUTTON
Used to operate AUTO
IMAGE function. (P28)
VOLUME
BRIGHT
PAGE
LAMP
REPLACE
WARNING
TEMP.
READY
LAMP
FOCUS
POINT BUTTONS
Used to select an item and adjust the value on the
MENU. It is also used to pan the image in DIGITAL
ZOOM mode. (P29, 37)
FOCUS BUTTONS
Used to select focus adjust.
(P21)
PAGE BUTTON
Used to move to the next / previous page of the data in the memory card plugged into PC CARD SLOT.
Page buttons are activated in MCI mode (P34).
LAMP REPLACE INDICATOR
This indicator turns to yellow when the life of the projection lamp draws to an end. (P43)
WARNING TEMP. INDICATOR
This indicator flashes red when internal projector temperature is too high.
(P42)
READY INDICATOR
This indicator is lit in green when the projector is ready to be turned on.
LAMP INDICATOR
This indicator is dim when the projector is turned on.
And bright when the projector is in stand-by mode.
16
BEFORE OPERATION
OPERATING ON-SCREEN MENU
HOW TO OPERATE ON-SCREEN MENU
You can control and adjust this projector through the
ON-SCREEN MENU. Refer to the following pages to operate each adjustment on the ON-SCREEN MENU.
WIRELESS REMOTE CONTROL
POINT BUTTON
Used to move the
Pointer UP/ DOWN/
RIGHT/ LEFT.
1 MOVING THE POINTER
Move the pointer (see the NOTE below) by pressing POINT button(s) on the TOP CONTROL or the REMOTE CONTROL.
SELECT BUTTON
Used to select the item.
2 SELECT THE ITEM
Select the item by pressing SELECT button.
NOTE : Pointer is the icon on the ON-SCREEN Menu to select the item. See the figures on the section
"FLOW OF ON-SCREEN MENU" below.
TOP CONTROL
SELECT BUTTON
Used to select the item.
SELECT
POINT BUTTONS
Used to move the
Pointer UP/ DOWN/
RIGHT/ LEFT.
FLOW OF ON-SCREEN MENU
MENU BAR
1
Display ON-SCREEN MENU
Press MENU button to display the ON-SCREEN MENU
(MENU BAR). The red frame is the POINTER.
POINTER
(red frame)
Select the Item
2 Move the POINTER (red frame) to the ITEM ICON that you want to select by pressing POINT RIGHT/ LEFT buttons.
3 Select the ITEM by pressing SELECT button. The dialog box of the ITEM appears.
4
Control and adjust through ON-SCREEN MENU
Move the POINTER downward by pressing POINT
DOWN button. (The shape of the POINTER becomes an arrow.)
5 Move the POINTER to the ITEM that you want to adjust and adjust the ITEM by pressing SELECT button.
Refer to the following pages for details of respective adjustments.
SELECT
BUTTON
POINT
DOWN
BUTTON
ITEM ICON
POINTER
(red frame)
MENU
POINTER
17
BEFORE OPERATION
MENU BAR
MENU BAR IN COMPUTER MODE Press MENU BUTTON while in Computer mode.
MODE MENU
Used to select the Computer input mode.
(Refer to P23)
SYSTEM MENU
Used to select a computer system.
(Refer to P23)
POSITION MENU
Used to adjust the position of the image.
(Refer to P28)
PC ADJUST MENU
Used to adjust the parameters to match with the input signal format.
(Refer to P24, 25)
SETTING MENU
Used to set the Display
Menu and to reset
Lamp Replacement
Monitor Timer.
(Refer to P40)
18
AUTO IMAGE MENU
Used to adjust Fine sync., Total dots, and Picture Position automatically.
(Refer to P28)
IMAGE MENU
Used to adjust the computer image. [Fine sync. / Total dots /
White Balance /
Contrast / Brightness]
(Refer to P27)
SCREEN MENU
Used to adjust the size of the image or to correct the
Keystone distortion.
(Refer to P29)
LANGUAGE MENU
Used to select the language used in the
Menu.
(Refer to P40)
MENU BAR IN VIDEO MODE Press MENU BUTTON while in Video mode.
MODE MENU
Used to select the Video input.
(Refer to P30)
IMAGE MENU
Used to adjust the picture image. [ Color /
Tint / White Balance /
Contrast / Brightness/
Sharpness ]
(Refer to P31)
These icons have the same function as the Computer Mode.
SYSTEM MENU
Used to select a color system among
[ PAL, SECAM, NTSC,
NTSC 4.43, PAL-M and
PAL-N ].
(Refer to P30)
SCREEN MENU
Used to set the size of the image either
Regular or Wide, or to correct the
Keystone distortion.
(Refer to P30)
BASIC OPERATION
MENU BAR IN MCI MODE
MODE MENU
Used to select the MCI input mode.
(Refer to P33)
Press MENU BUTTON while in MCI mode.
POSITION MENU
Used to adjust the position of the image.
(Refer to P36)
These icons have the same function as the Computer Mode.
VIEW MENU
Used to display, read or write the image data in a memory card through the PC CARD
SLOT.
(Refer to P34, 35)
IMAGE MENU
Used to adjust the computer image. [White
Balance / Contrast
/ Brightness]
(Refer to P36)
SCREEN MENU
Used to adjust the size of the image or to correct the
Keystone distortion.
(Refer to P37)
19
BASIC OPERATIONS
TURNING ON / OFF THE PROJECTOR
TURNING ON THE PROJECTOR
1 Complete the peripheral connections (with Computer, VCR, etc.) before turning on the projector. (Refer to "CONNECTING
TO THE PROJECTOR" on Pages 10~13 for connecting that equipment.)
2 Connect the projector's AC power cord into a wall outlet. The
LAMP indicator lights RED, and the READY indicator lights
GREEN.
3 Press the power ON-OFF button on the Remote Control Unit or on the Top Control to ON. The LAMP POWER indicator dims, and the Cooling Fans start to operate. The Preparation Display appears on the screen and the count-down starts. The signal from the source appears after 30 seconds.
30
The Preparation Display disappears after 30 seconds.
1
2
3
TURNING OFF THE PROJECTOR
Press the power ON-OFF button on the Remote Control Unit or on the Top Control, and the message "Power off?" appears on the screen.
Press the power ON-OFF button again to turn off the projector.
The LAMP indicator lights bright and the READY indicator turns off. The Cooling Fans operate for 90 seconds after the projector is turned off. (During this "Cooling Down" period, this appliance cannot be turned on.)
When cooling the projector has finished, the READY indicator turns to green again and you can turn the projector on. After cooling down completely, disconnect the AC power cord.
Power off?
The message disappears after 4 seconds.
TO MAINTAIN THE LIFE OF THE LAMP, ONCE YOU TURN IT ON, WAIT AT LEAST 5
MINUTES BEFORE TURNING IT OFF.
When the TEMPERATURE WARNING indicator flashes red, the projector is automatically turned off. Wait at least 5 minutes before turning the projector on again.
If the TEMPERATURE WARNING indicator continues to flash, follow procedures below:
1. Disconnect the AC power cord from the AC outlet.
2. Check the air filters for dust accumulation.
3. Clean the Air Filter. (See "AIR FILTER CARE AND CLEANING" section on page 42.)
4. Press the power ON-OFF button to ON.
If the TEMPERATURE WARNING indicator still continues to flash, call your authorized dealer or service station.
NOTE: The Cooling Fan may work for cooling while the projector is turned off. When the Cooling
Fan is working, TEMPERATURE WARNING INDICATOR flashes red.
20
BASIC OPERATION
ADJUSTING THE IMAGE
ZOOM ADJUSTMENT
1 Press the ZOOM WIDE/TELE buttons on the Top Control or the
ZOOM ▲ / ▼ button on the Remote Control Unit to turn into the
ZOOM mode.
2 Press the ZOOM WIDE button or the ZOOM ▲ button to make the image larger, and press the ZOOM TELE button or the
ZOOM ▼ button to make the image smaller.
In the Computer mode, the image can be expanded, compressed, and panned with the Digital Zoom function. Refer to page 29 and 37 for the Digital Zoom operation.
Zoom
The message disappears after 4 seconds.
1
FOCUS ADJUSTMENT
Press the FOCUS ▲ / ▼ button(s) on the Top Control or on the
Remote Control Unit to turn into the FOCUS mode.
2 Adjust the focus of the image by pressing the FOCUS ▲ / ▼ button(s).
Focus
The message disappears after 4 seconds.
KEYSTONE ADJUSTMENT
If the picture has keystone distortion, correct image with KEYSTONE adjustment.
1 Press the KEYSTONE ▲ / ▼ button on the Remote Control Unit or select the Keystone on the SCREEN menu. (Refer to page
29, 30, 37.) The message “Keystone” is displayed.
Keystone
2 Correct the Keystone distortion by pressing the KEYSTONE
▲ / ▼ button or the POINT UP/DOWN button(s). Press the
KEYSTONE ▲ button or the POINT UP button to reduce the upper part or the image, and press the KEYSTONE ▼ button or the POINT DOWN button to reduce the lower part.
Reduce the upper width with the KEY STONE ▲ button or the POINT UP button.
The message disappears after 4 seconds.
Reduce the lower width with the KEY STONE ▼ button or the POINT DOWN button.
21
BASIC OPERATION
BRIGHT SWITCH
Slide the BRIGHT SWITCH to the BRIGHTER position to enhance the picture brightness. When the BRIGHT SWITCH is set to the
BRIGHTER position, the BRIGHT SWITCH INDICATOR lights on.
(P16) To return the original image, slide the switch to the
STANDARD position.
✽ When the BRIGHT SWITCH is set to the BRIGHTER position, the color of image may change slightly.
BRIGHTER
ST
AND
ARD
BRIGHT SWITCH (on the side)
Set the switch firmly.
NO SHOW FUNCTION
Press the NO SHOW button on the Remote Control Unit to black out the image. This function is cancelled when the NO SHOW button is pressed again or any other function button is pressed.
No show
The message disappears after 4 seconds.
PICTURE FREEZE FUNCTION
Press the FREEZE button on the Remote Control Unit to freeze the picture on screen. This function is cancelled when the FREEZE button is pressed again or any other function button is pressed.
SOUND ADJUSTMENT
SOUND VOLUME ADJUSTMENT
Press the VOLUME button on the Top Control or the VOLUME (+/–) button on the Remote Control Unit to adjust the volume. The Volume dialog box appears on the screen for a few seconds.
The POINT UP or VOLUME (+) button increase the volume, and the
POINT DOWN or the VOLUME (–) button decrease the volume.
SOUND MUTE ADJUSTMENT
Press the MUTE button on the Remote Control Unit to mute the sound. To restore the sound to its previous level, press the MUTE button again or press Volume button(s).
It indicates the level of the volume.
Press the MUTE button to set the Mute function On or Off.
The display disappears after 4 seconds.
22
COMPUTER MODE
SELECTING COMPUTER MODE
DIRECT OPERATION
Select COMPUTER mode by pressing the MODE button on the Top
Control or the COMPUTER / MCI button on the Remote Control Unit.
MODE button
COMPUTER
MCI
COMPUTER / MCI button
COMPUTER
MCI
VIDEO
MENU OPERATION
Press the MENU button and the ON-SCREEN MENU will appear.
Press the POINT LEFT/RIGHT buttons to select Computer press the SELECT button. and
CURRENT MODE DISPLAY
When selecting the Computer Mode, the Current Mode display appears. It shows the information of the computer of the mode selected.
Providing the information of the computer detected by the projector.
SELECTING COMPUTER SYSTEM
AUTOMATIC MULTISCANNING SYSTEM
This projector automatically tunes to most different types of computer based on VGA, SVGA, XGA or SXGA (refer to “COMPATIBLE
COMPUTER SPECIFICATION” on page 26). When selecting
Computer, this projector automatically tunes to the incoming signal and projects the proper image without any special setting. (Setting of the Computer System may be required when connecting some computers.)
Note : The projector may provide the messages below.
Go to PC adj.
The projector cannot discriminate or detect the input signal from the computer. Adjust and set the computer system manually. (Refer to page 24.)
No signal
There is no signal input from the computer. Make sure the connection of the computer and the projector is set correctly. (Refer to
TROUBLESHOOTING on page 44.)
SYSTEM BOX
It displays the SYSTEM being selected.
SELECT COMPUTER SYSTEM MANUALLY
To set the Computer system manually, select the mode on the ON-
SCREEN MENU.
1
2
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
SYSTEM and press the SELECT button. Another dialog box
COMPUTER MODE Menu will appear.
Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to the system that you want to set, and then press SELECT button.
The system being selected.
The systems on this dialog box can be selected.
Close the SYSTEM
Menu.
23
COMPUTER MODE
PC ADJUSTMENT
This Projector can automatically tune to the display signals from most personal computers currently distributed.
However, some computers employ the special signal formats which are different from the standard ones and may not be tuned by Multiscanning of this projector. If this happens, the projector cannot reproduce a proper image and the image is recognized as a flickering picture, a non-synchronized picture, a non-centered picture or a skewed picture.
This projector has PC ADJUSTMENT function, to enable you to precisely adjust several parameters to match with those exceptional signal formats and the projector has five independent memory areas to memorize those parameters manually adjusted. This enables you to recall the setting for a specific computer whenever you use it.
Note : This PC ADJUSTMENT function cannot be operated when “RGB,” “HDTV1035i” or “HDTV1080i” is selected on the
SYSTEM MENU (P23 and 26).
1
2
3
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT RIGHT/LEFT buttons to select PC
ADJUST and press the SELECT button. Another dialog box “Where to reserve” Menu will appear.
In this dialog box, you can store the parameter into the area from “Mode 1” to “Mode 5.” When memorizing the new computer parameter, select the Mode with the message of
“Free” by pressing the POINT UP/DOWN buttons and the
SELECT button. To change the parameters of the Mode previously set, select the Mode with “Stored.”
When the Mode is selected, Parameter adjustment dialog box appears. Move the arrow to the item that you want to change by pressing the POINT UP/DOWN buttons, and adjust each item to match your computer. To change the value, press either the POINT RIGHT button or the POINT LEFT button.
Refer to the next page for adjusting each item.
This Mode has parameters being stored.
The Vacant Mode.
Manual set Computer
Mode (1 to 5).
Close the PC
ADJUSTMENT Menu.
4
5
Move the arrow to “Stored” and press the SELECT button. The parameter is memorized in the selected Mode.
To activate the Mode manually adjusted in this PC
ADJUSTMENT Menu, select the Mode at the SYSTEM
SELECT Menu. (Refer to page 23.)
Press the POINT
RIGHT/LEFT button(s) to adjust the value.
Press the
SELECT button to set Full screen function on/off.
24
Total lines
The number of the total vertical lines. Adjust the number to match the image of your personal computer.
Total dots
The number of the total dots in one horizontal period. Adjust the number to match the image of your personal computer.
Horizontal / Vertical
Adjustment of the horizontal or vertical picture position. When the image is not centered on the screen, adjust each of those items.
Clamp
Adjustment of the clamp level. When the image has a dark bar(s), try this adjustment.
Display area
Adjustment of the area displayed with this projector. Select the resolution at the Display area dialog box, or adjust the number at the column of “H” or “V” to match the resolution of the image.
Full Screen
Set “On” to resize the image with 4 x 3 aspect ratio to fit the screen.
Each of the keys operates as follow.
Reset Recalls the parameter data that was previously adjusted.
Mode free
Stored
Quit
Clears the parameter data previously set .
Stores the parameters in the memory.
Closes the PC ADJUST Menu.
Press the
SELECT button to select the typical resolution of the image.
COMPUTER MODE
25
COMPUTER MODE
26
COMPATIBLE COMPUTER SPECIFICATIONS
Basically this projector can accept the signal from all computers with the V, H-Frequency mentioned below and less than
140 MHz of Dot Clock.
ON-SCREEN
DISPLAY
RESOLUTION
VGA 1 640 x 480
VGA 2 720 x 400
VGA 3
VGA 4
VGA 5
VGA 6
VGA 7
640 x 400
640 x 480
640 x 480
640 x 480
640 x 480
MAC LC13 640 x 480
MAC 13 640 x 480
–––––––– RGB
RGB ––––––––
SVGA 1
SVGA 2
SVGA 3
SVGA 4
SVGA 5
SVGA 6
SVGA 7
SVGA 8
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
SVGA 9 800 x 600
SVGA 10 800 x 600
SVGA 11 800 x 600
SVGA 12 800 x 600
MAC1 6
XGA 1
832 x 624
1024 x 768
XGA 2
XGA 3
XGA 4
XGA 5
XGA 6
XGA 7
XGA 8
XGA 9
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1024 x 768
(Interlace)
H-Freq.
(kHz)
31.47
31.47
31.47
37.86
37.86
37.50
43.269
34.97
35.00
15.734
15.625
35.156
37.88
46.875
53.674
48.08
37.90
34.50
38.00
38.60
47.90
32.70
38.00
49.72
48.36
68.677
60.023
56.47
60.31
48.50
44.00
63.48
36.00
V-Freq.
(Hz)
59.88
70.09
70.09
74.38
72.81
75.00
85.00
66.60
66.67
30
25
56.25
60.32
75.00
85.06
72.19
61.03
55.38
60.51
60.31
71.92
51.09
60.51
74.55
60.00
84.997
75.03
70.07
74.92
60.02
54.58
79.35
43.59
ON-SCREEN
DISPLAY
RESOLUTION
XGA 10 1024 x 768
XGA 11
XGA 12
XGA 13
XGA 14
XGA15
MAC 19 1024 x 768
MAC21 1152 x 870
SXGA 1 1152 x 864
SXGA 2 1280 x 1024
SXGA 3 1280 x 1024
SXGA 4 1280 x 1024
SXGA 5 1280 x 1024
SXGA 6 1280 x 1024
SXGA 7 1280 x 1024
SXGA 8 1280 x 1024
SXGA 9 1280 x 1024
SXGA 10 1280 x 960
SXGA 11 1152 x 900
SXGA 12 1152 x 900
SXGA 13
SXGA 14
1280 x 1024
(Interlace)
1280 x 1024
(Interlace)
SXGA 15 1280 x 1024
SXGA 16 1280 x 1024
SXGA 17 1152 x 900
SXGA 18
1280 x 1024
(Interlace)
SXGA 19 1280 x 1024
MAC
HDTV720p
HDTV1035i
HDTV1080i
NOTE : Specifications are subject to change without notice.
MAC
1024 x 768
1024 x 768
(Interlace)
1024 x 768
1024 x 768
1024 x 768
1280 x 960
1280 x 1024
––––––––
––––––––
––––––––
43.35
60.18
75.08
75.08
60.00
60.00
60.00
60.02
75.025
60.00
65.20
75.60
43.00
47.00
60.01
72.00
66.00
75.06
70.40
58.60
60.00
59.98
60.01
67.19
76.107
V-Freq.
(Hz)
77.07
75.70
43.48
58.20
58.30
72.0
75.08
46.43
63.79
75.00
80.00
45.00
33.75
33.75
63.98
79.976
60.00
61.20
71.40
50.00
50.00
63.37
76.97
61.85
68.68
64.20
62.50
63.90
63.34
63.74
71.69
81.13
H-Freq.
(kHz)
62.04
61.00
35.522
46.90
47.00
58.03
60.24
PICTURE IMAGE ADJUSTMENT
ADJUST PICTURE IMAGE MANUALLY
1
2
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
IMAGE and press the SELECT button. Another dialog box
PICTURE IMAGE ADJUSTMENT Menu will appear.
Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to the item that you want to change by pressing the POINT UP/DOWN buttons. To change the value, press either the POINT RIGHT button or the POINT LEFT button.
Fine sync.
Adjust the picture as necessary to eliminate flicker from the display.
(From 0 to 255.)
Total dots
The number of the total dots in one horizontal period. Adjust the number to match your PC image.
White balance (Red / Green / Blue)
Move the arrow to the color that you want to adjust. Press POINT
LEFT button to lighten the color and press POINT RIGHT button to deepen the color. (From 0 to 63.)
Contrast
Press POINT LEFT button to decrease contrast, and press POINT
RIGHT button to increase contrast. (From 0 to 63.)
Brightness
Press POINT LEFT button to darken the image, and press POINT
RIGHT button to brighten the image. (From 0 to 63.)
Each of the keys operates as follow.
Reset
Stored
Quit
Recalls the data previously adjusted.
Stores the adjusted data in the memory.
Closes the PICTURE IMAGE ADJUSTMENT Menu.
NOTE : The Fine sync. and the Total dots cannot be fully adjusted when “RGB,” “HDTV1035i” or “HDTV1080i” is selected on the SYSTEM MENU (P23 and 26).
NORMAL FUNCTION
The normal picture level is preset on this projector at the factory and can be restored anytime you press the NORMAL button (located on the Top Control or on the Remote Control Unit). The “Normal” display will be displayed on the screen for a few seconds.
Normal
COMPUTER MODE
It indicates the level of the item.
Move the arrow to the item and press
POINT RIGHT /
LEFT button.
Close the PICTURE
IMAGE ADJUSTMENT
Menu.
27
COMPUTER MODE
28
AUTO IMAGE FUNCTION
The Auto Image function is provided to automatically adjust Fine sync., Total dots, and Picture Position for most computers.
1
2
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
AUTO IMAGE and press the SELECT button.
Another dialog box AUTO IMAGE Menu will appear.
Move the arrow to an item that you want to adjust by pressing the POINT UP/DOWN button. Change the setting On or Off by pressing the SELECT button.
Fine sync.
Adjust the picture as necessary to eliminate flicker from the display.
This item can be adjusted manually. (Refer to page 27.)
Total dots
The number of the total dots in one horizontal period. This item can be adjusted manually. (Refer to page 27.)
Position
Adjustment of the position of the image. This item can be adjusted manually. (Refer to page 28.)
Starts the adjustment on the item set to "On".
Close the PICTURE IMAGE
ADJUSTMENT Menu.
Move the arrow to the item and then press the SELECT button.
3 Move the arrow to “Go!” and press the SELECT button to start the Auto Image function.
This adjustment can be executed by pressing AUTO IMAGE button on the Top Control and the Remote Control Unit.
Stored
Go!
Stores the On/Off setting of each item.
Starts the Auto Image Adjustment.
Quit Closes the AUTO IMAGE ADJUSTMENT Menu.
NOTE : The Fine sync. and the Total dots cannot be fully adjusted when “RGB,” “HDTV1035i” or “HDTV1080i” is selected on the SYSTEM MENU (P23 and 26).
The Fine sync., Total dots, and Picture Position of some computers may not be fully adjusted with the Auto Image
Function. In that case, manual adjustment is required to make fine image. (Refer to page 27 to adjust "Fine sync." or "Total dots" and page 28 to adjust Picture Position.)
PICTURE POSITION ADJUSTMENT
The position of the image can be adjusted vertically and horizontally through PICTURE POSITION
ADJUSTMENT.
1
2
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
POSITION and press the SELECT button. The PICTURE
POSITION dialog box will appear.
Move the image by pressing the POINT UP / DOWN / RIGHT /
LEFT buttons.
To cancel POSITION mode, press any button except SELECT,
RIGHT CLICK, POINT, PAGE ▲ / ▼ or LASER button. To recall the position previously adjusted, press NORMAL button.
PICTURE POSITION dialog box
Press the POINT UP /
DOWN / RIGHT / LEFT buttons to move the image
COMPUTER MODE
PICTURE SCREEN ADJUSTMENT
This projector has a picture screen resize function, which enables you to display the image in desirable size.
1 Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
SCREEN and press the SELECT button. Another dialog box PICTURE SCREEN Menu will appear.
2 Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to the function that you want to select and then press SELECT button.
True
To make the image into its original size select True in the dialog box. When the original image size is larger than the screen size
(1024 x 768), this projector enters Digital Zoom mode automatically.
Move the arrow to the function and press the
SELECT button.
Keystone
When the image is distorted vertically, select Keystone in the dialog box. The ON-SCREEN menu and SCREEN ADJUST menu disappears and the message “Keystone” is displayed. Correct the
Keystone distortion by pressing the KEYSTONE ▲ / ▼ button or the
POINT UP/DOWN button(s). Refer to KEYSTONE ADJUSTMENT on page 21.
Digital Zoom
To adjust the image size or pan the image, select Digital zoom in the dialog box. The ON-SCREEN menu and SCREEN ADJUST menu disappears and the message “D. Zoom” is displayed.
This projector also enters Digital Zoom mode by pressing the
D.ZOOM ▲ / ▼ button on the Remote Control Unit.
Refer to the following for operation.
Expand function
To expand the image size, press the D.ZOOM ▲ button or the SELECT button. The image is magnified by degrees.
Compress function
To compress the image size, press the D.ZOOM ▼ button or the RIGHT CLICK button. The size of image is reduced by degrees.
Panning function
To pan the image, press the POINT UP/DOWN/LEFT/RIGHT buttons. Panning function can work only when the image is larger than the screen size.
To cancel Digital Zoom mode, press any button except D.ZOOM ▲ / ▼ , SELECT, RIGHT CLICK, POINT, PAGE ▲ / ▼ or
LASER button. To adjust the image to the screen size (1024 x 768), press NORMAL button.
● This projector cannot display in any resolution higher than 1280 X 1024. If your computer’s screen resolution is higher than 1280 X 1024, reset the resolution lower before connecting the projector.
● The image data in other than XGA (1024 x 768) is modified to fit the screen size in the initial mode.
● The normal "Panning Operation" may not function properly if the computer system prepared with the "PC Adjust" is used.
NOTE : The True and the Digital Zoom cannot be operated when “RGB,” “HDTV1035i” or “HDTV1080i” is selected on the SYSTEM MENU (P23 and 26).
29
VIDEO MODE
SELECTING VIDEO MODE
DIRECT OPERATION
Select VIDEO mode by pressing the MODE button on the Top
Control or the VIDEO button on the Remote Control Unit.
MODE button
COMPUTER
MCI
MENU OPERATION
Press the MENU button and the ON-SCREEN MENU will appear.
Press the POINT LEFT/RIGHT buttons to select Video press the SELECT button. and
SELECTING COLOR SYSTEM
1 Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
SYSTEM and press the SELECT button. Another dialog box
VIDEO SYSTEM Menu will appear.
2 Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to "Auto", and then press the SELECT button.
Auto
The projector automatically detects the incoming Video system, and adjusts itself to optimize its performance.
When the Video System is PAL-M or PAL-N, select the system manually.
PAL / SECAM / NTSC / NTSC4.43 / PAL-M / PAL-N
If the projector cannot reproduce the proper video image, it is required to select a specific broadcast signal format among PAL,
SECAM, NTSC, NTSC 4.43, PAL-M, or PAL-N.
VIDEO
This box indicates the system being selected.
Move the arrow to the Mode and press the SELECT button.
PICTURE SCREEN ADJUSTMENT
This projector has a picture screen resize function, which enables you to display the image in desirable size.
1 Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
SCREEN and press the SELECT button. Another dialog box PICTURE SCREEN ADJUSTMENT DISPLAY will appear.
2 Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to the screen size that you want to set, and then press the SELECT button.
Regular
Normal Video Image size with 4 x 3 aspect ratio.
Wide
Resizes the image for wide screen size with 16 x 9 aspect ratio.
Keystone
When the image is distorted vertically, select Keystone in the dialog box. Correct the Keystone distortion by pressing KEYSTONE ▲ / ▼ button or POINT UP/DOWN button(s). Refer to KEYSTONE
ADJUSTMENT on page 21.
Move the pointer to the function and press the SELECT button.
30
VIDEO MODE
PICTURE IMAGE ADJUSTMENT
1
2
ADJUSTING THE PICTURE IMAGE
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
IMAGE and press the SELECT button. Another dialog box
PICTURE IMAGE ADJUSTMENT Menu will appear.
Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to the item that you want to adjust by pressing the POINT UP/DOWN buttons. To change the value, press either the POINT RIGHT button or the POINT LEFT button.
Color
Press POINT LEFT button to lighten the image, and press POINT
RIGHT button to deepen the image. (From 0 to 63.)
Tint
Press POINT LEFT button to increase purple, and press POINT
RIGHT button to increase green. (From 0 to 63.)
White balance (Red / Green / Blue)
Move the arrow to the color that you want to adjust. Press POINT
LEFT button to lighten the color, and press POINT RIGHT button to deepen the color. (From 0 to 63.)
Contrast
Press POINT LEFT button to decrease contrast, and press POINT
RIGHT button to increase contrast. (From 0 to 63.)
Brightness
Press POINT LEFT button to darken the image, and press POINT
RIGHT button to brighten the image. (From 0 to 63.)
Sharpness
Press POINT LEFT button to soften the image, and press POINT
RIGHT button to sharpen the image. (From 0 to 63.)
Each of the keys operates as follow.
Reset Recalls the data previously adjusted.
Stored Stores the data in the memory.
Quit Closes the PICTURE IMAGE ADJUSTMENT Menu.
NORMAL FUNCTION
The normal picture level is preset on this projector at the factory and can be restored anytime you press the NORMAL button (located on the Top Control or on the Remote Control Unit). The "Normal" display will be displayed on the screen for a few seconds.
Normal
It indicates the level of the item.
Move the arrow to the item and press
POINT RIGHT /
LEFT button.
Close the PICTURE
IMAGE ADJUSTMENT
Menu.
31
MCI MODE
OPERATING THE PC CARD SLOT
This projector has a PC CARD SLOT and the data in a memory card (Compact Flash™ Card with PCMCIA
Adapter or PC card) can be displayed just by inserting the card into it. It is unnecessary to connect with other input equipment. Media Card Imager (supplied with CD-ROM) can edit the image data and record it into a memory card for projecting with the projector.
PC with Windows 95
Media Card Imager
(CD-ROM) MC I
PC Card
(not supplied)
Digital Camera
Compact Flash™ (with Adapter)
(not supplied)
PC CARD SLOT (Front)
HOW TO LOAD THE MEMORY CARD INTO THE PROJECTOR
PC CARD SLOT LOAD
Insert PCMCIA Adapter (with Compact Flash™ Card) or PC card into
PC CARD SLOT. Make sure EJECT button pops out.
NOTE : Be sure to insert the memory card with the front side facing left of the projector. Do not insert the card in the reverse.
The card may be damaged.
UNLOAD
Press EJECT button, and the memory card pops out.
NOTE : Do not take the card out of the PC CARD SLOT while the data is loading. Data and the card can be damaged.
Memory Card
Insert with the front side of the card to the left side of the projector.
PC CARD INDICATOR
WHEN THIS INDICATOR IS LIT, THE
PROJECTOR IS READING OR WRITING THE
DATA INTO THE MEMORY CARD. DO NOT
REMOVE THE MEMORY CARD. DATA IN
THE MEMORY CARD MAY BE DAMAGED.
EJECT BUTTON
32
MCI MODE
AVAILABLE DATA
This projector can project the image data through the PC CARD
SLOT, as follows;
● The data edited by “Media Card Imager.”
● The data of the resolution between VGA (640 X 480) and SXGA
(1280 X 1024) in Bit Map type (BMP) or JPEG type (JPG), such as
Digital Camera data, can be also displayed.
(Some image data in SXGA size may not be displayed properly.
In that case, reset the resolution lower.)
Refer to “SHOW THE DATA IN THE MEMORY CARD” on page 34 to display the image data.
Media Card Imager
Media Card Imager (CD-ROM) is supplied with this projector to edit the image data for projecting. Installation of Media Card
Imager is recommended. Refer to
Owner’s Manual of Media Card Imager for installation and operation.
AVAILABLE CARD
Compact Flash™ Card (with PCMCIA Adapter) or Type || PCMCIA-ATA Card can be used with this projector. (Those memory cards are not supplied with this projector.)
Refer to CF CARD AND PCMCIA ADAPTER on pages 38 and 39 for operation.
NOTE : Some PCMCIA Adapter or PC Card is not available for this projector and cannot provide the image data. In that case, use the optional Canon Compact Flash Card and PCMCIA Adapter.
SELECTING MCI MODE
When the memory card is inserted into PC CARD SLOT, the MCI mode is automatically selected and the first
Page of the latest Index is projected onto the screen. To switch to the MCI mode manually, operate as follows.
DIRECT OPERATION
Select MCI mode by pressing the MODE button on the Top Control or the COMPUTER / MCI button on the Remote Control Unit.
MODE button
COMPUTER
COMPUTER / MCI button
COMPUTER
MCI MCI
VIDEO
MENU OPERATION
Press the MENU button and the ON-SCREEN MENU will appear.
Press the POINT LEFT/RIGHT buttons to select MCI and press the SELECT button.
33
MCI MODE
SHOW THE DATA IN THE MEMORY CARD
1
BASIC OPERATION
Insert the memory card and select the MCI mode. The data in the memory card is displayed.
2
Select the Index
To change pages, press the PAGE button on the Top Control and then press the POINT UP/DOWN buttons. (The pages can also be changed with the PAGE ▲ / ▼ button on the Remote
Control.) When the “Display Timer” is set in the image with the
Media Card Imager, the image is changed to another automatically.
To select Index or Page in the table, follow the instructions of
INDEX SELECTION and PAGE SELECTION below.
Index
Pages in the Index
Index and Page
The data edited with Media Card Imager is the Index format consisting of several Pages. To project the desirable image, select the Index and then select the Page in the Index.
● This projector can project only image data in Bit Map or in JPEG format or the data edited by Media Card Imager
(supplied) through the PC CARD SLOT. Other data is not compatible and should be edited and written to a memory card with Media Card Imager before loading into PC CARD SLOT.
(The data in Bit Map or in JPEG format, such as the data captured with a digital camera, can be projected directly through PC CARD SLOT.)
● If there is the data edited by Media Card Imager and other data (such as in Bit Map type or JPEG type) together in one memory card, the data edited by Media Card Imager has a priority to be projected with the LCD projector. The other image data in Bit Map type or JPEG type is not projected. In that case, edit that data and write it to the memory card with the Media Card Imager.
INDEX SELECTION
1
2
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select VIEW and press the SELECT button. Another dialog box VIEW
SETTING menu will appear.
Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to "Index", and then press the
SELECT button. The table of Indexes in the memory card will appear.
3 Press the POINT UP/DOWN/LEFT/RIGHT buttons to move to the Index that you want to project and press the SELECT button. The first Page of the Index selected is displayed.
(Press SELECT button again to display the table of Pages.)
1
2
3
PAGE SELECTION
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select VIEW and press the SELECT button. Another dialog box VIEW
SETTING menu will appear.
Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to "Page", and then press the
SELECT button. The table of pages of the index card will appear.
Press the POINT UP/DOWN/LEFT/RIGHT buttons to move to the Page that you want to project and press the SELECT button. The page selected is displayed on the screen.
The table of Pages can be displayed by pressing the SELECT button when the page is displayed on full screen.
Move the arrow to each operation and press the SELECT button.
34
MCI MODE
WRITE DATA INTO THE MEMORY CARD
The data edited by Media Card Imager in the computer can be written to or read from the memory card with the
PC Card drive of your Personal Computer or the PC CARD Slot of this projector.
The data edited by Media Card Imager is written in Bit Map type (BMP) or JPEG type (JPG).
ACCESS TO THE MEMORY CARD THROUGH THE PROJECTOR
If your computer doesn't have the PC card writing equipment, the data can be written or read by connecting with this projector.
NOTE : This operation can be made only by Media Card Imager in the Personal Computer.
Connect the projector to the Personal Computer with the
Control Cable for Serial Port (optionally supplied / refer to page 12, 13).
1 Connect the projector to your computer with the Control Cable for Serial Port (optionally supplied). (Refer to “CONNECTING
COMPUTER” on Page 12, 13.)
Insert the memory card into PC CARD SLOT of the projector.
And then, turn on the projector first and then the computer.
2 Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select VIEW and press the SELECT button. Another dialog box VIEW
SETTING menu will appear.
3 Press POINT DOWN button and a red arrow will appear. Move the arrow to Card access by pressing POINT UP/DOWN button. And then press SELECT button. “Ready to access” is displayed.
Operate Media Card Imager of your computer to write/read the data in the PC card. (Refer to Owner's Manual of Media Card
Imager for operation.)
NOTE : Connect the projector to the computer with Control Cable before turning those appliances on.
Do not press any button while read/write operations are in progress. Those operations are canceled and the data in the memory card may be damaged.
Move the arrow to
“Card access” and press the SELECT button.
35
MCI MODE
PICTURE IMAGE ADJUSTMENT
ADJUST THE PICTURE IMAGE MANUALLY
1
2
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
IMAGE and press the SELECT button. Another dialog box
PICTURE IMAGE ADJUSTMENT Menu will appear.
Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to the item by pressing the POINT
UP/DOWN buttons. To change the value press either the
POINT RIGHT button or the POINT LEFT button.
White balance (Red / Green / Blue)
Move the arrow to the color that you want to adjust. Press POINT
LEFT button to lighten the color, and press POINT RIGHT button to deepen the color. (From 0 to 63.)
Contrast
Press POINT LEFT button to decrease contrast, and press POINT
RIGHT button to increase contrast. (From 0 to 63.)
Brightness
Press POINT LEFT button to darken the image, and press POINT
RIGHT button to brighten the image. (From 0 to 63.)
Each of the keys operates as follow.
Reset Recalls the data previously adjusted.
Stored Stores the adjusted data in the memory.
Quit Closes the PICTURE IMAGE ADJUSTMENT Menu.
NORMAL FUNCTION
The normal picture level is preset on this projector at the factory and can be restored anytime you press the NORMAL button (located on the Top Control or on the Remote Control Unit). The "Normal" display will be displayed on the screen for a few seconds.
Normal
It indicates the level of the item.
Move the arrow to the item and press
POINT RIGHT /
LEFT button.
Close the PICTURE
IMAGE ADJUSTMENT
Menu.
36
PICTURE POSITION ADJUSTMENT
The position of the image can be adjusted vertically and horizontally through PICTURE POSITION
ADJUSTMENT.
1
2
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
POSITION and press the SELECT button. The PICTURE
POSITION dialog box will appear.
Move the image by pressing the POINT UP / DOWN / RIGHT /
LEFT buttons.
To cancel POSITION mode, press any button except SELECT,
RIGHT CLICK, POINT, AUTO IMAGE, PAGE ▲ / ▼ or LASER button.
To recall the position previously adjusted, press NORMAL button.
PICTURE POSITION dialog box
Press the POINT UP /
DOWN / RIGHT / LEFT buttons to move the image
MCI MODE
PICTURE SCREEN ADJUSTMENT
This projector has a picture screen resize function, which enables you to display the image in desirable size.
1 Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
SCREEN and press the SELECT button. Another dialog box PICTURE SCREEN Menu will appear.
2 Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to the function that you want to select and then press SELECT button.
True
To turn the image into its original size select True in the dialog box.
When the original image size is larger than the screen size (1024 x
768), this projector enters Digital Zoom mode automatically.
Move the arrow to the function and press the
SELECT button.
Keystone
When the image is distorted vertically, select Keystone in the dialog box. The ON-SCREEN menu and SCREEN ADJUST menu disappears and the message “Keystone” is displayed. Correct the
Keystone distortion by pressing KEYSTONE ▲ / ▼ button or POINT
UP/DOWN button(s). Refer to KEYSTONE ADJUSTMENT on page 21.
Digital Zoom
To adjust the image size or pan the image, select Digital zoom in the dialog box. The ON-SCREEN menu and SCREEN ADJUST menu disappears and the message “D. Zoom” is displayed.
This projector also enters Digital Zoom mode by pressing D.ZOOM
▲ / ▼ button on the Remote Control Unit.
Refer to the following for operation.
Expand function
To expand the image size, press D.ZOOM ▲ button or SELECT button. The image is magnified by degrees.
Compress function
To compress the image size, press the D.ZOOM ▼ button or the RIGHT CLICK button. The size of image is reduced by degrees.
Panning function
To pan the image, press POINT UP/DOWN/LEFT/RIGHT buttons. Panning function can work only when the image is larger than the screen size.
To cancel Digital Zoom mode, press any button except D.ZOOM ▲ / ▼ , SELECT, RIGHT CLICK, POINT, PAGE ▲ / ▼ ,
AUTO IMAGE, or LASER button. To adjust the image to the screen size (1024 x 768), press NORMAL button.
● This projector cannot display in any resolution higher than 1280 X 1024. If your computer’s screen resolution is higher than 1280 X 1024, reset the resolution lower before connecting the projector.
● The image data in other than XGA (1024 x 768) is modified to fit the screen size in the initial mode.
37
MCI MODE
CF CARD AND PCMCIA ADAPTER
You can use the optional Canon Compact Flash TM Card (CF card) and its PCMCIA adapter designed for the
Canon Digital Camera PowerShot series.
By inserting the CF card into the PCMCIA adapter, it can be loaded into the PC card slot (PCMCIA 2.1/Jeida 4.2
Standard slot) of a computer.
Refer to page 46 for "How to load a CF card into the LCD projector."
Canon Compact Flash TM Card for Digital Camera PowerShot series
FC-4MB (capacity 4MB)
FC-8MB (capacity 8MB)
FC-15MB (capacity 15MB)
PCMCIA adapter
Inserting / Removing the CF Card
● Insert the CF card firmly into the PCMCIA adapter, aligning the arrows on the CF card and PCMCIA adapter.
PCMCIA adapter
(Not supplied)
● When remove the CF card from the PCMCIA adapter, pull it straight out .
Compact Flash TM
(Not supplied)
Card
Insert the CF card aligning the arrows.
D
AR
H C
AS
FL
CT
PA
M
CO
CF-4M
C la
PCMCIA
IMPORTANT NOTE
Data stored on a CF card may be damaged or lost due to physical damage to the CF card or accidental erasure. It is recommended that any important data should be copied as a backup onto separate media, such as a floppy disk, a hard disk or a MO disk, etc. We shall not be liable for any damage or loss of profits arising from the loss of data caused by the misoperation of or the damage to a CF card or its appliances.
The following may result in damaged or lost data:
• Misoperation of the CF card.
• Turning the LCD projector or the computer power off or removing the CF card / PCMCIA adapter while the
CF card is in access operations (storing, reading or deleting the files).
• Exposure to a strong static electric charge.
• It has reached the end of its life.
38
MCI MODE
Handling CF Card and PCMCIA Adapter
● Do not turn the LCD projector or the computer power off or remove the CF card / PCMCIA adapter while the CF card is in access operation (storing, reading or deleting files).
● CF cards / PCMCIA adapters are high-precision electronic devices. do not bend, drop, apply strong forces or shock or place it where a strong static electrical charge may be generated.
● Do not touch the surface of the contact area with your fingers or allow it to be stained with foreign materials.
● Do not attempt to disassemble or alter CF cards.
● Moving CF card rapidly between hot and cold temperatures may cause condensation (water droplets) to form on it, leading to malfunctions. Avoid this problem by placing the CF card in a plastic bag and letting it slowly adjust to temperature changes before removing it from the bag. If condensation should occur, maintain the CF card at a constant temperature and let the moisture evaporate naturally.
● Store CF cards / PCMCIA adapters in the protective case provided.
● Do not use or store CF cards / PCMCIA adapter in places subject to the following conditions: strong magnetic fields abundant dirt or dust high temperatures, high humidity
Specifications
Interface : PCMCIA / ATA PCMCIA 2.1/ JEIDA 4.2
Card Slot Type : Type II
Dimensions : 1.4 x 1.7 x 0.1 inches / 36.1 x 42.8 x 3.3 mm (CF card only)
3.4 x 2.1 x 0.2 inches / 86 x 54 x 5 mm (with PCMCIA Adapter)
Weight : 0.4 oz / 10g (CF card only)
1.2 oz / 34g (with PCMCIA Adapter)
Subject to change without notice
Weight and dimensions are approximate.
39
SETTING
SETTING MENU
1
2
Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select
SETTING and press the SELECT button. Another dialog box SETTING Menu will appear.
Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to the item that you want to set, and then press the SELECT button to set it "On" or "Off".
Blue back
When this function is in the "On" position, this projector will produce a blue image instead of the video noise on the screen when all input sources are unplugged or turned off.
Display
When this function is in the "On" position, the On-
Screen Displays always appears when adjustments are made. (The following displays disappear by switching this function "Off.")
● Preparation Display
(The Number-counting-down Display)
● Mode Display
● Volume/Mute Display
● Zoom Display
● Focus Display
● Normal Display
● No show Display
● Keystone Display
● D.Zoom Display
Ceiling
Rear
Split wipe
Lamp age
When this function is in the “On” position, the top / bottom and the left / right reversed picture is provided to project the image from a ceiling mounted projector.
When this function is in the “On” position, the left / right reversed picture is provided to project the image to a rear projection screen.
Turn this function “On” position in the SETTING menu.
The picture will change into the next one by sliding black image side ways like drawing the black curtains when the input source is turned into another one.
The Lamp age function is designed to reset the lamp replacement monitor timer. When replacing the lamp, reset the lamp replacement monitor timer by using this function. (Refer to page 43.)
Ceiling function
Rear function
Set the Pointer to the item, and then press the SELECT button.
SELECTING LANGUAGE
The language used in the ON-SCREEN MENU is selectable from among English, German, French, Italian, Spanish and Japanese.
1
2
Press the MENU button and the ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT buttons to select
LANGUAGE and press the SELECT button. Another dialog box LANGUAGE Menu will appear.
Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to the language that you want to set, and then press the SELECT button.
Move the Pointer to the language that you want to set, and then press the SELECT button.
40
APPENDIX
OPERATING WIRELESS MOUSE
The Wireless Remote Control Unit is not only able to operate the projector but also can be used as a wireless mouse for most Personal Computers. The POINT buttons and the two CLICK buttons are used for the wireless mouse operation.
The wireless mouse is available only when PC mouse pointer is displayed on the screen. When the menu or the indicator of the projector is displayed on the screen instead of the PC mouse pointer, the wireless mouse cannot be used.
INSTALLATION
To use the Wireless Remote Control Unit as the Wireless Mouse for a Personal Computer, installation of the mouse driver (not supplied) is required. Make sure that the mouse driver is properly installed in your computer. And make sure that the mouse port of the computer connected to Control Port is activated.
1
2
Connect the mouse port of your computer to the Control Port of the projector with the Control Cable. (Refer to page 10 to 13 for connection.)
Turn the projector on first, and then turn on your computer.
When the computer is switched on first, the Wireless Mouse may not work properly.
Note : When the computer has no mouse port, connect the Serial
Port of the computer to Control
Port of the projector with the
Control Cable for Serial Port.
OPERATING WIRELESS MOUSE
When controlling the pointer of the computer, operate the Wireless Mouse with POINT button, SELECT button, and RIGHT CLICK button on the Wireless Remote Control Unit.
POINT button
Used to move the pointer. The pointer is moved corresponding with the direction you are pressing.
POINT button (Move the pointer)
SELECT (LEFT CLICK) button
This button has the same function as the left button in a PC mouse.
RIGHT CLICK button
This button has the same function as the right button in a PC mouse.
Pressing this button does not affect any operation when in Menu mode.
SELECT button
(left button of the mouse)
RIGHT CLICK button
(right button of the mouse)
41
APPENDIX
MAINTENANCE
TEMPERATURE WARNING INDICATOR
1
2
3
The TEMPERATURE WARNING Indicator flashes red when the internal temperature of the projector exceeds the normal temperature. The Indicator stops flashing when the temperature of the projector becomes normal.
When the TEMPERATURE WARNING Indicator continues to flash, check the item listed below.
The Ventilation slots of the projector may be blocked. In such an event, reposition the appliance so that the ventilation slots are not obstructed.
Air filters are clogged with dust particles. Clean the air filters by following AIR FILTER CARE AND CLEANING below.
If the TEMPERATURE WARNING Indicator remains on after performing the above checks, the Cooling Fans or the
Internal Circuits may be malfunctioning. Request service from an authorized dealer or service station.
AIR FILTER CARE AND CLEANING
The Removable Air Filters prevent dust from accumulating on the surface of the Projection Lens and the
Projection Mirror. Should the Air Filters become clogged with dust particles, it will reduce the Cooling Fans' effectiveness and may result in internal heat build up and adversely affect the life of the projector.
Clean the Air Filters following the steps below:
1
2
3
Turn the power off, and disconnect the AC power cord from the
AC outlet.
Turn the projector upside down and remove 2 Air Filters by pulling the latches upward.
Clean the Air Filters with brush or wash out the dust and particles.
AIR FILTERS
4 Replace the Air Filter. Make sure that the Air Filters are fully inserted.
CAUTION
Do not operate the projector with the Air Filter removed.
Dust may become stuck on the LCD Panel and the Mirror degrading picture quality.
Do not put small parts into the Air Intake Vents. It may result in malfunctions of the projector.
The Air Filter is small. Ensure that children don’t eat or swallow it.
● Replacement Lamp
Type No. : DY4-5798-000
RECOMMENDATION
We recommend to avoid dusty/smoky place for operating the projector. Using in these environments may cause poor image quality.
When using under dusty or smoky conditions, dust may accumulate on the liquid crystal panel and lens inside, and may resultantly be projected onto the screen together with the picture.
When the above symptoms are noticed, contact your authorized dealer or service station for the cleaning.
CLEANING THE PROJECTION LENS
2
3
Follow these steps to clean the projection lens:
1 Apply a non-abrasive camera lens cleaner to a soft, dry cleaning cloth. Avoid using an excessive amount of cleaner.
Abrasive cleaners, solvents or other harsh chemicals might scratch the lens.
Lightly wipe the cleaning cloth over the lens.
When you are not using the projector, replace the lens cover.
42
APPENDIX
LAMP REPLACEMENT INDICATOR
When the life of the Lamp of this projector draws to an end, the LAMP REPLACEMENT indicator lights red.
When the image becomes dark or the color of the image becomes unnatural, replacement of the Lamp is required.
LAMP REPLACEMENT
CAUTION
● For continued safety, replace with a lamp assembly of the same type.
● Allow the projector to cool for at least 45 minutes before you open the lamp cover. The inside of the projector can become very hot.
● Do not drop the lamp assembly or touch the glass bulb! The glass can shatter and may cause injury.
Follow these steps to replace the lamp assembly.
1 Turn off the projector and disconnect the AC plug. Allow the projector to cool for at least 45 minutes.
2
3
4
Remove a screw with a screwdriver and remove the Lamp
Cover.
Remove 2 screws with a screwdriver and pull out the Lamp
Assembly by grasping the handle.
Replace the Lamp Assembly with new one and tighten 2 screws. Make sure that the Lamp Assembly is set properly.
And replace the Lamp Cover and tighten a screw.
LAMP COVER
HANDLE
5
6
Connect the AC Power Cord to the projector and turn the projector on.
Reset the Lamp Replacement Monitor Timer (refer to the section “Lamp Replacement Monitor Timer” below).
NOTE : Do not reset the LAMP REPLACEMENT MONITOR
TIMER, when the lamp is not replaced.
LAMP
ASSEMBLY
ORDER REPLACEMENT LAMP
Replacement Lamp can be ordered through your dealer. When ordering the Lamp, give the following information to the dealer.
● Model No. of your projector : LV-7325U
● Replacement Lamp Type No. : LV-LP05
(Service Parts No. 610 280 6939)
LAMP REPLACEMENT MONITOR TIMER
Be sure to reset the Lamp Replacement Monitor Timer when the Lamp Assembly is replaced. When the
Lamp Replacement Monitor Timer is reset, the LAMP REPLACEMENT indicator stops lighting.
1
2
Turn the projector on, and press the MENU button and the ON-SCREEN MENU will appear. Press the POINT
LEFT/RIGHT buttons to select SETTING dialog box SETTING MENU will appear. and press the SELECT button (refer to the page 40). Another
Press the POINT DOWN button and a red-arrow icon will appear. Move the arrow to Lamp age, and then press the
SELECT button. The message "Lamp replace monitor Reset?" is displayed.
3 Select [Yes] to reset the Timer.
Do not reset the Lamp Replacement Monitor Timer, except after the lamp is replaced.
43
APPENDIX
TROUBLESHOOTING
Before calling your dealer or service station for assistance, check the items below once again.
1. Make sure you have connected the projector to your equipment as described in the section "CONNECTING
THE PROJECTOR" on pages 10 ~ 13.
2. Check cable connection. Verify that all computer, video and power cord are properly connected.
3. Verify that all power is switched on.
4. If the projector still does not produce the image, re-start the computer.
5. If the image sill does not appear, unplug the projector from the computer and check the computer monitor's display. The problem may be with your graphics controller rather than with the projector. (When you reconnect the projector, remember to turn the computer and monitor off before your power up the projector.
Power the equipment back in order of : Projector and computer.)
6. If the problem still exists, check the following chart.
Problem:
No power.
Image is out of focus.
Try these Solution
● Plug the projector into the AC outlet.
● Be sure READY Indicator light is On.
● Wait 90 seconds after the projector is turned OFF before turning the projector back on.
NOTE : After pressing the power ON-OFF switch to OFF, make sure the projector works as follow.
1. The LAMP indicator will light and the READY indicator will turn off.
2. After 90 seconds, the READY indicator will light green again and the projector may be turned on by pressing the power ON-OFF button.
● Check the TEMPERATURE WARNING indicator. If the indicator flashes red, the projector cannot be turned on.
(See "TURNING ON/OFF THE PROJECTOR" section on page 20.)
● Check the Projection Lamp. (Refer to page 43.)
● Adjust the focus
● Make sure the projection screen is at least 4.6’ (1.4m) from the projector.
● Check the projection lens to see if it needs cleaning.
NOTE : Moving the projector from a cool temperature location to a warm temperature location may result in moisture condensation on the lens. In such an event, leave the projector OFF an d wait until condensation disappears.
● Check Ceiling / Rear feature. (See “SETTING” section on page 40.)
Picture is Left/Right reversed.
Picture is
Top/Bottom reversed.
Some displays are not seen during the
Operation.
No image.
No sound.
● Check Ceiling feature. (See “SETTING” section on page 40.)
● Check Display feature.(See “SETTING” section on page 40.)
● Check the connection between the computer or video equipment and the projector.
● When turning the projector on, it takes about 30 seconds to display the image.
● Check the system that you select is corresponding with the computer or the video equipment.
● Make sure the temperature is not out of the Operating Temperature (5°C ~ 35°C).
● Check audio cable connection from audio input source.
● Adjust the audio source.
● Press VOLUME (+) button.
● Press MUTE button.
44
APPENDIX
Problem:
Remote Control Unit does not work.
Wireless Mouse function does not work.
The image data in memory card isn’t displayed.
The image data can’t be written in, read from the memory card.
Try these Solution
● Check the batteries.
● Check the ALL-OFF switch on the Remote Control Unit is set to “ON.”.
● Make sure nothing is between the Remote Receiver and the Remote Control Unit.
● Make sure you are not too far from the projector when using the Remote Control Unit.
Maximum operating range is 16.4’ (5m)..
● Check the cable connection between the projector and the computer.
● Check the mouse setting on your computer.
● Turn the projector on before you turn on the computer.
● Check the memory card is inserted properly into PC CARD SLOT.
● Check a memory card is set properly.
● Check MCI mode is selected.
● Check the image data is recorded in the memory card properly.
● Start the projector again.
● Check the projector is turned on.
● Check “Card access” in VIEW menu is selected.
● Check Control Cable for Serial Port (optional) is connected properly.
● Check the memory card is inserted properly into PC CARD SLOT.
● Check Media Card Imager (supplied) is installed in your computer properly.
● Check the setting in Media Card Imager (like Serial Port Setting) is set properly.
WARNING :
High voltages are used to operate this projector. Do not attempt to open the cabinet.
45
APPENDIX
TECHNICAL SPECIFICATIONS
Projector Type
Dimensions (W x H x D)
Net Weight
LCD Panel System
Panel Resolution
Number of Pixels
Color System
Scanning Frequency
Projection Image size (Diagonal)
Horizontal Resolution
Projection Lens
Throw Distance
Brightness
Projection Lamp
AV Input Jacks
Computer Input Jacks
Control Port Jack
Monitor Output Jack
Computer Audio Input Jack
Audio Output Jack
Internal Audio Amp
Built-in Speaker
Feet Adjustment
Voltage
Power Consumption
Operating Temperature
Storage Temperature
Remote Control Transmitter
Accessories
Multi-media Projector
9.45" x 3.66" x 13.23" (240mm x 93mm x 336mm) (not including Adjustable Feet)
9.48 lbs (4.3 kg)
0.9" TFT Active Matrix type, 3 panels
1024 x 768 dots
2,359,296 (1024 x 768 x 3 panels)
PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N
H-sync. 15 ~ 100 KHz, V-sync. 50 ~ 100 Hz
Adjustable from 30” to 300”
800 TV lines
F 1.7 ~ 2.0 lens with f 33.2mm ~ 43.1mm Motor zoom and focus
4.6’ ~ 35.4’ (1.4 m ~ 10.8 m)
1500 ANSI lumen (Brighter mode)
1200 ANSI lumen (Standard mode)
150 W UHP
RCA Type x 1 (Video, Audio R and L) and Mini DIN 4 pin (S-Video) x 1
(VGA) HDB 15 Terminal x 1
Mini DIN 8 pin x 1
(VGA) HDB 15 Terminal x 1
Mini Jack (stereo)
Mini Jack (stereo)
1W RMS (Monaural)
1 speaker, 1.57" x 1.18" (40mm x 30mm)
0˚ to 10˚
AC 100 ~ 120 V, 50 / 60 Hz
2.5 A (Max. Ampere)
41 ˚F ~ 95 ˚F (5 ˚C ~ 35 ˚C)
14 ˚F ~ 140 ˚F (-10 ˚C ~ 60 ˚C)
Power Source : AA Type x 2
Operating Range : 16.4’ (5m) / ±30˚
Dimensions : 2.2” x 1.3” x 7.6” (55mm x 34mm x 192mm)
Net Weight
Laser Pointer
: 0.35 lbs (160 g) (including batteries)
: Class II Laser (Max. Output : 1mW / Wave length : 650±20nm)
Owner’s Manual
AC Power Cord
Remote Control Transmitter and Batteries
VGA Cable
Control Cable for PS/2 port
Media Card Imager for Windows 95 (CD-ROM) and Owner's Manual for this software
Dust Cover
Lens Cover, Strap for Lens Cover and Screw
● The specifications are subject to change without notice.
This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety standards against risk of fire, casualty and electrical hazards.
46
OPTIONAL PARTS
The parts listed below are optionally supplied. When ordering those parts, give the name and the Type No. of it to the sales dealer.
● Control Cable for Serial Port
● Control Cable for ADB Port
Type No. : LV - CA26
Type No. : LV - CA27
● MAC Adapter
● Canon Digitizer
Type No. : LV - AD02
Type No. : LV - DP10
APPENDIX
47
CANON INC. 30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan
CANON U.S.A., INC. NEW YORK OFFICE
One Canon Plaza, Lake Success, NY 11042-1198, U.S.A.
phone : 516-328-5960
CANON U.S.A., INC. LOS ANGELES OFFICE
15955 Alton Parkway, irvine, CA 92718-3616, U.S.A.
phone : 949-753-4320
CANON CANADA, INC.
6390 Dixie Road Mississauga, Ontario L5T 1P7 Canada phone : 905-795-1111
1AA6P1P2169-- (MB6S)
©CANON INC. 2000
YT1-1311-000 PRINTED IN JAPAN
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
Key Features
- Standard throw projector Blue, Grey
- 3LCD 1500 ANSI lumens
- Lamp
- XGA (1024x768) 4:3 250:1
- Screen size compatibility: 787.4 - 7620 mm (31 - 300") Number of colours: 16.78 million colours
- Focus: Manual Zoom capability
- Built-in speaker(s) 1 W
- AC 240 W
Related manuals
advertisement
