Fusion MS-AV600 Installation manual

53%2).34!,,!4)/.-!.5!,
-!2).%34%2%/
-3)0-3#$-3!6
WWWFUSIONELECTRONICSCOM
FUSION Electronics New Zealand
FUSION Electronics Australia
FUSION Electronics Europe
FUSION Electronics USA
Ph: +64 9 369 2997
Ph: +61 1300 736 012
Ph: +44 1268 889580
Ph: +1 623 580 9000
SPECS & LICENSING
02%#!54)/.3
Allow 50mm (2”) for
cables at rear of unit.
Do not attempt to open the units chassis. There are no user
serviceable parts or adjustment’s inside.
HANDLING COMPACT DISCS (CD/CD-R/CD-RW)
This unit has been tested with all compatible authentic iPod models
under normal expected operating conditions, free from any preexisting defects in either the unit or the iPod.
» Avoid exposing the disc to direct sunlight
No responsibility can be taken for use of the unit other than under
normally expected operating conditions in conjunction with fully
functional and undamaged iPod units which have been manufactured
and authorised by Apple Inc.
BEFORE INSERTING IPOD (MS-IP600)
» Avoid touching the surface of the disc
» Ensure the disc is clean
» Ensure the disc is not scratched or damaged
PLAYBACK OF CD-R/CD-RW
» If your CD-R/CD-RW will not play, Ensure that the last recording
session was closed or finalized.
Please ensure iPod dock connector is clean, dry & free from damage.
Check that the units iPod dock is free from obstructions. Insert
correct sleeve combination to match your iPod (Never insert iPod
without a correct sleeve.)
&###/-0,)!.#%34!4%-%.4
Ensure iPod is inserted with display facing upwards, Never force your
iPod into the dock, if the iPod does not mate with reasonable ease
the sleeve/iPod combination is most likely incorrect.
» This device must accept any interference received, including
interference that may cause undesired operation.
Always remove your iPod from the unit when not in use & do not
leave in your vessel, this in turn prevents risk of theft or damage as
vessel cabins can reach extreme temperatures.
RECORD YOUR PRODUCT DETAILS HERE:
Do not remove iPod or use stereo in a distractive manner whilst
operating the vessel, check and obey all marine laws in association
with use.
Take care when removing iPod from unit as surfaces may be warm.
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions:
» This device may not cause harmful interference, and
Model Number
Date Of Purchase
Affix Receipt Here
SPECS & LICENSING
30%#)&)#!4)/.3!.$,)#%.3).'
#/.4%.43
30%#)&)#!4)/.3
"544/.$%3#2)04)/.
).34!,,!4)/.
#/..%#4)/.3
7)2).'$)!'2!-
'%.%2!,/0%2!4)/.
2!$)//0%2!4)/.
3)2)533!4%,,)4%2!$)/53!/.,9
#$-0/0%2!4)/.
!58/0%2!4)/.
I0OD/0%2!4)/.
$6$/0%2!4)/.
-3!6)22%-/4%/0%2!4)/.
:/.%/0%2!4)/.
-%.53425#452%
42/5",%3(//4).'
&53)/.-!2).%!##%33/2)%3
30%#)&)#!4)/.3!.$,)#%.3).'
CHASSIS DIMENSIONS
CD PLAYER
Depth 168mm - 6-5/8”
Width 180mm – 7-1/8”
Height 52mm – 2-1/16”
FACE PLATE DIMENSIONS
Depth 35mm – 1-3/8”
Width 217mm – 8-9/16”
Height 79mm – 3-1/8”
OPERATING VOLTAGE:
10.2 – 16VDC Negative ground
FUSE RATING:
15 Amp
OUTPUT POWER:
70 Watts x 4 (Max)
26 Watts RMS @ 4 Ohms
43 Watts RMS @ 2 Ohms
SPEAKER IMPEDANCE:
2 – 4 Ohms per channel
PRE – OUTPUT VOLTAGE: 3V
TUNING RANGE
Europe and Australasia:
FM Radio
Frequency Range: 87.5 – 108 MHz
Frequency step: 100 kHz
USA
FM Radio
Frequency Range: 87.5 – 107.9 MHz
Frequency step: 200 kHz
Laser power Class 1
SUPPORTED MEDIA
» Only use discs with the following logo’s on the label.
» If you use discs without the above logo’s, correct performance
cannot be guaranteed.
» You can play audio discs recorded on DVD +R -R,
CD-R (Recordable), or CD-RW (Re Writable) media
» MP3 formatted audio files can also be played on DVD +R -R , CD-R
and CD-RW containing these files.
COMPATABLE WITH FOLLOWING iPod MODELS:
iPod touch (Gen 1, Gen 2), iPod nano (Gen 2, Gen 3, Gen 4),
iPod classic (Gen 5, Gen 6, Gen 7)
For latest news on supported iPod models visit
www.fusionelectronics.com
AM Radio
Frequency Range: 522 – 1620 MHz
Frequency step: 9 kHz
,)#%.3).'
AM Radio
Frequency Range: 530 – 1710 MHz
Frequency step: 10 kHz
© 2007 SIRIUS Satellite Radio Inc. “SIRIUS” and the SIRIUS dog logo are
trademarks of Sirius Satellite Radio Inc. All rights reserved.
Apple, the Apple logo, iPod and iTunes are Trademarks of Apple
Computer, Inc., registered in the U.S. and other countries.
PUBLISHED BY FUSION ELECTRONICS LIMITED. © Copyright 2009 by FUSION Electronics Limited. All rights reserved. Specifications and design are subject to change without notice. v4.5
YOU CAN HELP PROTECT THE ENVIRONMENT Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal centre.
I0OD%84%2.!,$/#+
I0OD#/..%#4)/.#!",%M
MS-IPDOCK
MS-IP15L
Connect this external iPod
dock to the Marine CD Stereo
(MS-CD600) or the Marine DVD
Stereo (MS-AV600) to provide
the additional benefit of an
integrated housing for your
iPod. The bulkhead mount dock
complies with IPx5 Waterproof
Standards, protecting your iPod from the harsh marine environment.
The iPod marine external dock can be flush mounted or wall mounted.
Enables the connection of your
iPod to the Marine CD Stereo
(MS-CD600) or the Marine DVD
Stereo (MS-AV600).
MS-IP600 model shown
ROTARY ENCODER
Turn
To adjust volume, move up or down a menu
structure, or adjust a specific setting item.
Press
To select a highlighted option, confirm a setting.
Press to step through each zone for volume
adjustment.
Press and Hold
For quick access to subwoofer level adjustment
CATCH RELEASE BUTTON
Press down to open front panel.
EJECT (MS-CD600 and MS-AV600 only)
Press to eject CD/DVD. (Located inside front panel)
POWER
Press to turn the unit ON/OFF.
MENU
Press to enter Menu System. Press to return to
previous screen.
-!2).%7)2%$2%-/4%
-!2).%:/.%!-0,)&)%2
MS-WR600
MS-AM702
The Marine Wired Remote Control
extends the capabilities of the
Stereo by enabling local control
of the audio in each zone of your
vessel. Up to three remote’s can
be linked to the Stereo, via a
CANbus network, providing true
system flexibility.
The Marine 2x70 Watt D-Class
Zone Amplifier is designed
to support the multi-zone
technology of the Marine Stereo.
The Zone Amplifier is small,
enabling discrete installation and
when combined with the Marine Stereo provides the platform for a True
multi-zone audio system.
MARINE ACCESSORIES
&53)/.-!2).%!##%33/2)%3
BUTTON DESCRIPTION
"544/.$%3#2)04)/.
BUTTON DESCRIPTION
TROUBLESHOOTING
42/5",%3(//4).'
2%3%4"544/.
Press the Reset button in the event of a malfunction to reset the unit,
where normal operation is not automatically restored within 1 minute.
RADIO
Press to access the Radio source AM - FM - SIRIUS.
CD (MS-CD600 only)
Press to access the CD/MP3 source.
DVD (MS-AV600 only)
Press to access the DVD/CD/MP3 source.
DVD/CD/MP3/iPod - Select the next track.
AM/FM/Sirius - Start tuning up the frequency
spectrum. (Auto/Manual tuning mode) or next
preset (Preset mode).
Press and Hold
Press to access Auxiliary source.
DVD/CD/MP3/iPod - Forward the current track.
AM/FM/Sirius - Enter Manual Tuning mode.
iPod
PLAY/PAUSE
Press to access the iPod source.
Press again to access Auxiliary source (MS-CD600
& MS-AV600).
DVD/CD/MP3/iPod - Pause / resume the current track.
AM/FM/Sirius - Switch between Auto/Preset tuning
mode.
AUX (MS-IP600 only)
RESET BUTTON
FORWARD/NEXT
Short Press
BACK/PREVIOUS
Short Press
DVD/CD/MP3/iPod - Select the previous track.
AM/FM/Sirius - Start tuning down the frequency
spectrum. (Auto/Manual tuning mode) or previous
preset (Preset mode).
Press and Hold
DVD/CD/MP3/iPod - Rewind the current track.
AM/FM/Sirius - Enter Manual Tuning mode.
Press and Hold
AM/FM/Sirius - Store the current station as a Preset.
MUTE
Mutes all sound in all zones.
CLOCK
Displays the clock.
DISPLAY
Press to enter the display settings screen.
Adjustment can be made to the Contrast and
Brightness.
)&!.9-/$)&)#!4)/.4/4(%6%33%,)32%15)2%$35#(!3$2),,).'(/,%3%4#&53)/.
2%#/--%.$3#/.35,4!4)/.7)4(9/52"/!4$%!,%2/2-!.5&!#452%2"%&/2%(!.$
2//4-%.5
» Remove the Sun Cover from the unit
» Fit mounting gasket
» Insert the unit into the mounting hole
» Use either the supplied 4 x wood screws, or 4 x machined screws
and metal clamps to affix the unit into position.
» The unit must be mounted within 30 degrees of the horizontal plane.
» Pull down the front face to expose the mounting screw locations.
Note: In some circumstances a back strap or
brace may be required at the rear of the Unit
(Back Strap / brace is not included).
Mounting Gasket
Appropriate mounting is very important to
ensure correct operation. Select a location
that allows both free/open airflow around
rear of chassis, whilst minimizing exposure
to moisture. Allow adequate room at the rear
of the unit for the cable looms (approx 2-3”).
%,%#42)#!,7)2).'
Caution: The MS-IP600, MS-CD600 and MS-AV600 are designed for vessels with a 12V DC Negative ground electrical system
MENU STRUCTURE
-%.53425#452%
INSTALLATION
).34!,,!4)/.
The FUSION Marine Stereo makes it possible to have 3 ‘Zones’, that
have independent volume control.
,).%/54
$%3#2)04)/.
#/,/52
Lineout gives you the ability to connect a FUSION Marine Amplifier.
Note: The lineout can independently be assigned to Zone 1, 2 or 3.
Battery +12VDC
Accessory +12V switched
Negative Ground
Remote Amplifier Turn On
Yellow
Red
Black
Blue/White
Press the ‘Menu’ button and select ‘Zones’. Select ‘Lineout’. Select the
Zone you are assigning to the Lineout.
:/.%3%450
35"7//&%2
Note: The +12V switched and +12V battery can be joined for some
installation requirements.
Change the assigned zone of the subwoofer. Also adjust the sub
level and filter.
ANTENNA CONNECTION
ZONE ON/OFF
Select ‘On’ if Zones are present on the vessel.
Note: Zone 1 cannot be turned OFF
VOLUME LIMIT
Select ‘Volume Limit’ to set the desired maximum output volume for
each individual Zone.
LINK ZONE 1 + 2
Allows the volume control to operate Zones 1 + 2 as a combined pair.
The Zone set up for Zone 1 and 2 can be configured separately when
in this mode.
Press the ‘Menu’ button and select ‘Zones’. Select ‘Zone 1’ then
‘Link Zone 1 + 2’. Select ‘On’ to activate this feature.
CONNECTIONS
#/..%#4)/.3
Zone 1 and 2 are powered and can be linked, Zone 3 requires a
FUSION Marine Amplifier. All Zones have adjustable volume limits.
Note: If the Zone is selected as ‘Off ’ The features are not available.
Press the ‘Menu’ button and select ‘Zones’. Select the Zone you wish
to setup.
ZONE OPERATION
:/.%/0%2!4)/.
SUBOUT ZONE
Press the ‘Menu’ button and select ‘Zones’. Select ‘Subwoofer’ then
‘Subout Zone’. Select the desired subwoofer zone.
Note: The subwoofer can independently be assigned to Zone 1, 2 or 3.
SUB FILTER
Press the ‘Menu’ button and select ‘Zones’. Select ‘Subwoofer’ then
‘Sub Filter’. Select the desired frequency.
SUB LIMIT
Press the ‘Menu’ button and select ‘Zones’. Select ‘Subwoofer’ then
‘Sub Limit’. Select the desired maximum subwoofer output volume.
Note: Press and Hold the ‘Rotary Encoder’ for quick access to
subwoofer level adjustment
:/.%
#/..%#4)/.3
Zone 1
White = Speaker Left Positive
White / Black = Speaker Left Negative
Grey = Speaker Right Positive
Grey/ Black = Speaker Right Negative
Zone 2
Green = Speaker Left Positive
Green / Black = Speaker Left Negative
Purple = Speaker Right Positive
Purple / Black = Speaker Right Negative
Refer to the wiring diagram for reference (pg 6)
Connect an AM/FM marine antenna.
AUX INPUT
Note: Speaker connection (2 Ohm Stereo minimum). 2 pairs of 4 Ohm
Connect an Auxiliary source to the left and right RCA
(White = L, Red = R).
speakers per channel can be connected in parallel to achieve 2 Ohm
configuration.
iPod CONNECTION (MS-CD600 and MS-AV600 only)
Connect the 1.5m iPod accessories lead MS-IP15L (not included), or
connect the MS-IPDOCK (not included)
Zone 3/Lineout
SIRIUS SATELLITE RADIO (For use in USA only)
Connect to SiriusConnect™ tuner (not included)
WIRED REMOTE (MS-WR600)
Connect a marine wired remote to the CANbus system connector.
Up to 3 remotes can be connected to the system.
VIDEO CONNECTION (MS-AV600)
Connect the composite video or the S-Video output to a TV / LCD
monitor.
Low level output
(For connection to external amplifier)
White RCA= Left Output
Red RCA = Right Output
Orange RCA= Subwoofer Output
Note: Line Output / Sub can both be independently assigned to Zone 1,
Zone 2 or as a unique Zone 3.
MENU
Direct access to the menu
SETUP
Used to access the DVD settings
SYSTEM SET UP
TV System - Auto Play - TV Type
- Password - Rating -Default Exit Setup
SEL NAVIGATION Navigate & adjust using the up,
down, left & right keys.
Select the item with the SEL key
LANGUAGE SET UP OSD Language - Audio Language
- Subtitle Language Menu Language - Exit Setup
VIDEO SET UP
POWER
Press to turn the unit ON / OFF
CLOCK
Displays the clock
PREVIOUS
Selects previous track
MUTE
Mutes all sound in all zones
NEXT
Selects next track
SOURCE
Select the source required
DVD - iPod - AUX - FM - AM - Sirius
PLAY/PAUSE Pause or play the track
BACK
Rewind track
Select picture size video output
FORWARD
Fast-forward track
STOP
Press Once: to ‘Pre-stop’
Press Again: to stop disc completely
VOLUME
Press + to increase the volume
Press - to decrease the volume
Press volume then ‘SEL’ to select
different zone for volume
adjustment
ZOOM
Note: The +12V switched and +12V
battery can be joined for some
installation requirements.
Brightness - Contrast - Hue
- Saturation - Sharpness Exit Setup
SUB-T
Select subtitle language
RANDOM
Press to cycle through options
REPEAT
Press to cycle through options
DISPLAY
Press to cycle through options
0-9 KEYPAD Direct track access
MS-AV600 IR REMOTE
-3!6)22%-/4%/0%2!4)/.
WIRING DIAGRAM
7)2).'$)!'2!-
GENERAL OPERATION
DVD OPERATION
$6$/0%2!4)/.
'%.%2!,/0%2!4)/.
02%#!54)/.3
POWER
TONE
Press the ‘Power’ button to turn the unit ON/OFF
Adjust the treble and bass settings. Press the ‘Rotary Encoder’ to
switch between bass and treble selection.
MS-AV600 only
Never insert foreign objects into the disc slot. If the disc does not
insert easily, there may already be another disc inserted. Some
disc formats may not be readable if the format is not compatible.
0,!9).'!$6$#$-0
Press the ‘DVD’ button to select DVD / CD / MP3 source. Playback of
the disc will start automatically. The disc loading time will vary.
Note: The disc will resume from the start.
SELECTING A SOURCE
RADIO
$6$&5.#4)/.3
DVD
Press to access the DVD/CD/MP3 source
PLAY/PAUSE
Play or Pause the track
BACK/PREVIOUS Short Press: Selects previous track/chapter
Press and Hold: Rewind
NEXT/FORWARD Short Press: Selects next track/chapter
Press and Hold: Fast-forward
Adjust the audio balance from left to right.
AM/FM/Sirius (Sirius - US Only)
CD / DVD CD/MP3 (MS-CD600) / DVD (MS-AV600)
iPod/AUX Press for iPod
$6$#$-0.!6)'!4)/.
Navigation is controlled by the supplied Infrared Remote Control, and
is presented on external screen. (See MS-AV600 IR Remote Operation)
BALANCE
Press the desired source button:
AUX
CLOCK ADJUST
Adjust the Clock time, 12/24 hour. Turn the ‘Rotary Encoder’ to adjust the
Hour, Press to confirm, repeat to adjust the minutes. Press to confirm.
Press twice for AUX (MS-CD600 and MS-AV600)
REGIONS
AUX (MS-IP600)
Select Europe for the following tuner frequency stepping:
FM Radio
Frequency Range: 87.5 – 108 MHz
Frequency step: 50 kHz
ADJUSTING THE VOLUME
Turn the ‘Rotary Encoder’ to adjust the volume.
ZONE VOLUME
Press the ‘Rotary Encoder’ to step through zones.
Zone 1
All zones
Zone 2
Zone 3
Note: The last adjusted zone, becomes the start of the above zone
selection cycle.
3%450
Press the ’Menu’ button and select ‘Setup’. Select the desired
function. Turn the ‘Rotary Encoder’ to adjust or press to switch
selection (if available). Press ’Menu’ to return.
Note: Remember, whilst in the Setup system the ‘Menu’ button acts
as a back/return to the previous screen.
AM Radio
Frequency Range: 522 – 1620 MHz
Frequency step: 9 kHz
Select USA for the following tuner frequency stepping:
FM Radio
AM Radio
Frequency Range: 87.5 – 107.9 MHz Frequency Range: 530 – 1710 MHz
Frequency step: 100 kHz
Frequency step: 10 kHz
Note: Select ‘Europe’ for Australasian tuner frequency stepping
LANGUAGE
Select the desired language for the on screen display.
POWER SAVE
OFF Backlight on constantly
ON Backlight display goes off after one minute of non-operation
Note: The MS-CD600, MS-IP600 and MS-AV600 feature Clock
battery back up and EEPROM technology. This allows the unit to be
completely disconnected from the constant +12V voltage supply
(Battery switch) with no settings being lost.
iPod Operation
RADIO OPERATION
2!$)//0%2!4)/.
3%450
02%3%43
REGION SELECTION
You can manually store radio frequencies in the preset memory, or
automatically in FM band. There are 15 presets available per band.
Press the ‘Menu’ button and select ‘Setup’. Select ‘Tuner Region’ and
select your tuner region.
STORING A STATION AS A PRESET
Press the ‘Radio’ button to select band. FM – AM – SIRIUS (USA only)
When listening to a frequency, press and hold the ‘Play’ button to
store preset.
Alternatively: Press the ‘Menu’ button and select ‘Presets’. Select
‘Save Current’ to store station.
AUTOMATIC SEEK TUNING
AUTOMATIC SEARCH AND STORE PRESETS (FM only)
/0%2!4)/.
BAND SELECTION
Press the ‘Previous’ or ‘Next’ button to scan to the next station.
MANUAL SEEK TUNING
Press and hold the ‘Previous’ or ‘Next’ button for 3 seconds to enter
manual mode. The manual tuning icon will flash on screen. Press the
‘Previous’ or ‘Next’ button to step up and down the spectrum.
Note: After remaining idle for six seconds, the tuning mode will
revert to automatic.
Press the ‘Menu’ button and select ‘Search Stations’ to automatically
search and store stations.
Note: Automatic search mode will erase all other presets already
stored, and will automatically store the stations into the preset
menu in numerical order.
RECALLING A PRESET STATION
To listen to a radio frequency stored in the preset menu, select
the required band, FM - AM - Sirius. Press the ‘Play’ button to
enter ‘Presets’ mode. Press the ’Previous’ or ‘Next’ button to select
previous or next preset.
Alternatively: Select the required band. FM - AM - Sirius. Press ‘Menu’
and select ’Presets’. Select the desired preset.
DELETING A STORED PRESET
Press ‘Menu’ and select ‘Presets’. Select ‘Remove Presets’. Select the
desired preset, or ‘All’.
&!34
&53)/.!,0(!3%!2#(4%#(./,/'9
./I0OD#/..%#4%$
If your iPod contains more than 50 Artists, Songs or Albums you can
use F.A.S.T to quickly navigate by letter or number.
Example: Press the ‘Menu’ button and select ‘Artists’. Select ‘D’
and the first ‘Artist’ beginning with ‘D’ will automatically highlight.
Using the ‘Rotary Encoder’ you can then scroll up or down from this
selection.
»
Ensure the iPod is correctly connected
»
Ensure the cable is not excessively bent (MS-CD600, MS-AV600)
»
The iPods battery remains low (refer to iPod manual and charge
the battery)
&!344(2%3(/,$
The threshold (number of items) at which point the Alpha Search
screen appears for iPod menus can be changed. To change the
threshold, navigate as follows - press the ‘Menu’ button and select
‘Setup’, then ’Searching’. Select your desired item number threshold.
ON
OFF
50
100
200
400
800
If this appears on the display possible causes are
USA only - SIRIUS TUNER NOT INCLUDED
02%#!54)/.3&/2I0OD
,)34%.).'4/!.I0OD
!#4)6!4).'9/523)2)5345.%2
(MS-IP600 only) Before inserting your iPod into the MS-IP600 you
must first insert the correct sleeves to match iPod model.
Press the ‘iPod’ button. Playback of the iPod will start automatically.
You must activate the SIRIUS tuner before you can begin to receive the
SIRIUS Satellite Radio Service.
» For the iPod nano (3rd gen), the iPod must be placed inside the
adaptor sleeve, and then placed inside Dock sleeve combination A.
» Before inserting iPod,
Please ensure iPod dock connector is clean, dry & free from damage.
Check that unit iPod dock is free from obstructions.
Insert correct sleeve combination to match your iPod
Never insert iPod without a correct sleeve.
» Ensure iPod is inserted with display facing upwards, Never force
your iPod into the dock, if the iPod does not mate with reasonable
ease the sleeve/iPod combination is most likely incorrect.
3%,%#4).'4(%#/22%#4)0/$3,%%6%
(MS-IP600 only) A different set of sleeves is used for each iPod model.
The different sleeve combinations are outlined in the chart below:
iPod
TOP SLEEVE
BOTTOM SLEEVE
classic, 5th Gen (30gb)
A
A
classic, 5th Gen (60/80gb) A
B
classic, 6th Gen (80gb)
B
A
classic, 6th Gen (160gb)
B
B
classic, 7th Gen
B
A
touch, 1st Gen, 2nd Gen
D
D
nano, 2nd Gen
C
C
nano, 3rd Gen, + Adapter
A
A
nano, 4th Gen
E
E
Other
F
F
Note: To check your iPod model, go to www.apple.com/support
and enter the serial number found on the back of the iPod.
I0OD.!6)'!4)/.
Press the ‘Menu’ button to enter the iPod menu. The rotary encoder
operates similar to the click wheel on your iPod. Turn to navigate and
press to enter.
Note: Press the ‘Menu’ button to return to the previous menu screen.
iPod
Press to access the iPod source
PLAY/PAUSE
Play or Pause the track
BACK/PREVIOUS
Short Press: Selects previous track
Press and Hold: Rewind track
NEXT/FORWARD
Short Press: Selects next track
Press and Hold: Fast-forward track
2%0%!43(5&&,%
Press the ‘Menu’ button and select ‘Repeat/Shuffle’.
Select ‘Repeat Track’, ‘Shuffle Track or ‘Shuffle Album’.
Select ON/OFF. Default setting is OFF.
In order to activate your radio subscription, you will need the SIRIUS
ID (SID) which uniquely identifies your tuner. The 12 digit SID is
displayed on the LCD on initialization. MS-CD600, MS-IP600 and MSAV600 will display the SID on Channel 0.
FAVOURITES
Add your favourite channel to your favourites list by selecting ‘Add
Favourite’ (Maximum 15 channels). Remove channels by selecting
‘Remove Favourite’. Select ‘All’ or the individual channel. Exit by
pressing the ‘Menu’ button.
Alternatively: Press and hold the ‘Play’ button to store favourite.
0!2%.4!,-/$%
Power on your system and make sure that you are receiving good signal,
you are able to hear audio on the SIRIUS Preview channel (Ch-184)
ENABLE ON/OFF
Note: Have your credit card handy and contact SIRIUS on the internet
at https://activate.sirius.radio.com/ and follow the prompts to
activate your subscription. You can also call SIRIUS toll-free at 1-888539-SIRIUS (1-888-539-7474) Once activated, you will be able to
begin enjoying SIRIUS Satellite Radio’s digital entertainment and can
tune to other channels.
PIN #
Select to enable channels to be locked/unlocked
Turn the ‘Rotary Encoder’ to select number and press to enter, repeat
to enter the 4 digit code. (Factory setting is 0000)
Note: Must be entered before the following items are operational.
LOCK / UNLOCK
Select the channel to be locked or unlocked
3)2)53/0%2!4)/.
Press ‘Radio’ to select Sirius source radio.
3)2)53.!6)'!4)/.
Press the ‘Menu’ button and navigate the functions.
CHANNELS
Select the desired channel (listed in channel order) and music preference
CATEGORY
Select the desired genre type. (The unit will only play the selected option)
SKIP / UN-SKIP
Select the channel to be bypassed
CHANGE PIN
Personalise your Pin number. (4 digits max)
SIRIUS SATELLITE RADIO
3)2)533!4%,,)4%2!$)/
iPod Operation
I0OD/0%2!4)/.
AUX OPERATION
CD/MP3 OPERATION
#$-0/0%2!4)/.
!58/0%2!4)/.
02%#!54)/.3&/2#$-0
-0.!6)'!4)/.
Never insert foreign objects into the CD slot. If the CD does not insert
easily, there may already be another disc in the unit. Some CD-R/CD-RW
may not be readable if the format is not compatible.
Note: The MP3 disc will take approx 10 seconds to load the disc data
#/..%#4).'!.
!58),)!29!5$)/$%6)#%
,)34%.).'4/9/52
!58),)!29!5$)/$%6)#%
» The Left & Right AUX RCA plugs are located at the rear of the unit.
» Press the ‘AUX’ button to select AUX mode (MS-IP600) or press
the ‘iPod’ button twice (MS-CD600 or MS-AV600)
MS-CD600 only
The format of an MP3 disc must be ISO9660 Level 1 or 2 or Joliet
in the expansion Format. When naming an MP3 file, ensure the file
extension is .MP3
,)34%.).'4/!#$-0
Press the ‘CD’ button. Playback of the CD will start automatically.
#$.!6)'!4)/.
Press the ‘Menu’ button and select ‘Tracks’. Select desired track.
#$-0&5.#4)/.3
CD
Press to access the CD/MP3 source
PLAY/PAUSE
Play or Pause the track
BACK/PREVIOUS
Short Press: Selects previous track
Press and Hold: Rewind track
NEXT/FORWARD
Short Press: Selects next track
Press and Hold: Fast-forward track
(if available) to the unit.
Press the ‘Menu’ button and select ‘Songs’ to enter the MP3 root
directory. Use the ‘Rotary Encoder’ to navigate the functions of your
MP3 folders and files. Select the highlighted folder or file.
Note: Press the ‘menu’ button to return to the previous menu screen.
2%0%!43(5&&,%
Press the ‘Menu’ button and select ‘Repeat/Shuffle’.
Select ‘Repeat Track’, ‘Repeat Album’, ‘Shuffle Album’ or ‘Shuffle All’.
Select ON/OFF. Default setting is OFF.
» Connect your auxiliary audio device.
Note: You may require an adapter cable to connect your device.
» Start playback on your auxiliary audio device. Use both the volume
control on your auxiliary device (if available) and the volume control
on the FUSION Marine Stereo to set the volume level.
