Fusion MS-AV600 Installation manual
Add to my manuals
12 Pages
Fusion MS-AV600 is a marine stereo system designed to withstand harsh marine environments. It features a DVD/CD/MP3 player, AM/FM radio, SiriusXM satellite radio (US only), and iPod/iPhone connectivity. The system also has three independent zones, each with adjustable volume limits, allowing you to customize your audio experience in different areas of your boat. The MS-AV600 also supports Bluetooth connectivity, enabling you to stream music wirelessly from your smartphone or other compatible devices.
advertisement
www.fusionelectronics.com
FUSION Electronics New Zealand Ph: +64 9 369 2900
FUSION Electronics Australia
FUSION Electronics Europe
FUSION Electronics USA
Ph: +61 1300 736 012
Ph: +44 1268 889580
Ph: +1 623 580 9000
USER / INSTALLATION MANUAL
MARINE STEREO
MS-IP600 / MS-CD600 / MS-AV600
PRECAUTIONS
Do not attempt to open the units chassis. There are no user serviceable parts or adjustment’s inside.
This unit has been tested with all compatible authentic iPod models under normal expected operating conditions, free from any preexisting defects in either the unit or the iPod.
No responsibility can be taken for use of the unit other than under normally expected operating conditions in conjunction with fully functional and undamaged iPod units which have been manufactured and authorised by Apple Inc.
BEFORE INSERTING IPOD (MS-IP600)
Please ensure iPod dock connector is clean, dry & free from damage.
Check that the units iPod dock is free from obstructions. Insert correct sleeve combination to match your iPod (Never insert iPod without a correct sleeve.)
Ensure iPod is inserted with display facing upwards, Never force your iPod into the dock, if the iPod does not mate with reasonable ease the sleeve/iPod combination is most likely incorrect.
Always remove your iPod from the unit when not in use & do not leave in your vessel, this in turn prevents risk of theft or damage as vessel cabins can reach extreme temperatures.
Do not remove iPod or use stereo in a distractive manner whilst operating the vessel, check and obey all marine laws in association with use.
Take care when removing iPod from unit as surfaces may be warm.
HANDLING COMPACT DISCS (CD/CD-R/CD-RW)
»
»
Avoid touching the surface of the disc
Avoid exposing the disc to direct sunlight
» Ensure the disc is clean
» Ensure the disc is not scratched or damaged
PLAYBACK OF CD-R/CD-RW
» If your CD-R/CD-RW will not play, Ensure that the last recording
session was closed or finalized.
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
» This device may not cause harmful interference, and
» This device must accept any interference received, including
interference that may cause undesired operation.
RECORD YOUR PRODUCT DETAILS HERE:
Model Number
Date Of Purchase
Affix Receipt Here
Allow 50mm (2”) for cables at rear of unit.
SPECIFICATIONS AND LICENSING
SPECIFICATIONS
CHASSIS DIMENSIONS Depth 168mm - 6-5/8”
Width 180mm – 7-1/8”
Height 52mm – 2-1/16”
FACE PLATE DIMENSIONS Depth 35mm – 1-3/8”
Width 217mm – 8-9/16”
Height 79mm – 3-1/8”
OPERATING VOLTAGE: 10.2 – 16VDC Negative ground
FUSE RATING: 15 Amp
OUTPUT POWER: 70 Watts x 4 (Max)
26 Watts RMS @ 4 Ohms
43 Watts RMS @ 2 Ohms
SPEAKER IMPEDANCE: 2 – 4 Ohms per channel
PRE – OUTPUT VOLTAGE: 3V
TUNING RANGE
Europe and Australasia:
FM Radio
Frequency Range: 87.5 – 108 MHz
Frequency step: 100 kHz
USA
FM Radio
Frequency Range: 87.5 – 107.9 MHz
Frequency step: 200 kHz
AM Radio
Frequency Range: 522 – 1620 MHz
Frequency step: 9 kHz
AM Radio
Frequency Range: 530 – 1710 MHz
Frequency step: 10 kHz
CD PLAYER
Laser power Class 1
SUPPORTED MEDIA
» Only use discs with the following logo’s on the label.
» If you use discs without the above logo’s, correct performance
cannot be guaranteed.
» You can play audio discs recorded on DVD +R -R,
CD-R (Recordable), or CD-RW (Re Writable) media
» MP3 formatted audio files can also be played on DVD +R -R , CD-R
and CD-RW containing these files.
»
»
COMPATIBLE WITH THE FOLLOWING iPod MODELS:
» iPod classic, 80GB 120GB 160GB (2007, 2009);
» iPod with video, 30GB 60GB 80GB; iPod touch; iPod touch (2nd Gen);
» iPod nano (3nd Gen); iPod nano (4th Gen); iPod nano (5th Gen)
For latest news on supported iPod models visit www.fusionelectronics.com
LICENSING
Apple, the Apple logo, iPod and iTunes are Trademarks of Apple
Computer, Inc., registered in the U.S. and other countries.
© 2007 SIRIUS Satellite Radio Inc. “SIRIUS” and the SIRIUS dog logo are trademarks of Sirius Satellite Radio Inc. All rights reserved.
PUBLISHED BY FUSION ELECTRONICS LIMITED. © Copyright 2009 by FUSION Electronics Limited. All rights reserved. Specifications and design are subject to change without notice. v5.2
YOU CAN HELP PROTECT THE ENVIRONMENT Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal centre.
CONTENTS
BUTTON DESCRIPTION
INSTALLATION
CONNECTIONS
WIRING DIAGRAM
GENERAL OPERATION
RADIO OPERATION
SIRIUS SATELLITE RADIO
(USA ONLY)
CD/MP3 OPERATION
AUX OPERATION iPod OPERATION
DVD OPERATION
MS-AV600 IR REMOTE OPERATION
ZONE OPERATION
MENU STRUCTURE
TROUBLESHOOTING
FUSION MARINE ACCESSORIES
SPECIFICATIONS AND LICENSING
16
17
18
19
20
11
12
14
15
7
8
9
10
5
6
2
4
BUTTON DESCRIPTION
ROTARY ENCODER
Turn
To adjust volume, move up or down a menu structure, or adjust a specific setting item.
Press
To select a highlighted option, confirm a setting.
Press to step through each zone for volume adjustment.
Press and Hold
For quick access to subwoofer level adjustment
MS-IP600 model shown
CATCH RELEASE BUTTON
Press down to open front panel.
EJECT (MS-CD600 and MS-AV600 only)
Press to eject CD/DVD. (Located inside front panel)
POWER
Press to turn the unit ON/OFF.
MENU
Press to enter Menu System. Press to return to previous screen.
FUSION MARINE ACCESSORIES
iPod EXTERNAL DOCK
MS-IPDOCK / MS-IPDOCKG2
Connect this external iPod dock to the Marine CD Stereo
(MS-CD600) or the Marine DVD
Stereo (MS-AV600) to provide the additional benefit of an integrated housing for your iPod. The bulkhead mount dock complies with IPx5 Waterproof
Standards, protecting your iPod from the harsh marine environment.
The iPod marine external dock can be flush mounted or wall mounted.
iPod CONNECTION CABLE (1.5m)
MS-IP15L2
Enables the connection of your iPod to the Marine CD Stereo
(MS-CD600) or the Marine DVD
Stereo (MS-AV600).
MARINE WIRED REMOTE
MS-WR600
The Marine Wired Remote Control extends the capabilities of the
Stereo by enabling local control of the audio in each zone of your vessel. Up to three remote’s can be linked to the Stereo, via a
CANbus network, providing true system flexibility.
MARINE ZONE AMPLIFIER
MS-AM702
The Marine 2x70 Watt D-Class
Zone Amplifier is designed to support the multi-zone technology of the Marine Stereo.
The Zone Amplifier is small, enabling discrete installation and when combined with the Marine Stereo provides the platform for a True multi-zone audio system.
TROUBLESHOOTING
RESET BUTTON
Press the Reset button in the event of a malfunction to reset the unit, where normal operation is not automatically restored within 1 minute.
RESET BUTTON
RADIO
Press to access the Radio source AM - FM - SIRIUS.
CD (MS-CD600 only)
Press to access the CD/MP3 source.
DVD (MS-AV600 only)
Press to access the DVD/CD/MP3 source.
AUX (MS-IP600 only)
Press to access Auxiliary source.
iPod
Press to access the iPod source.
Press again to access Auxiliary source (MS-CD600
& MS-AV600).
BACK/PREVIOUS
Short Press
DVD/CD/MP3/iPod - Select the previous track.
AM/FM/Sirius - Start tuning down the frequency spectrum. (Auto/Manual tuning mode) or previous preset (Preset mode).
Press and Hold
DVD/CD/MP3/iPod - Rewind the current track.
AM/FM/Sirius - Enter Manual Tuning mode.
FORWARD/NEXT
Short Press
DVD/CD/MP3/iPod - Select the next track.
AM/FM/Sirius - Start tuning up the frequency spectrum. (Auto/Manual tuning mode) or next preset (Preset mode).
Press and Hold
DVD/CD/MP3/iPod - Forward the current track.
AM/FM/Sirius - Enter Manual Tuning mode.
PLAY/PAUSE
DVD/CD/MP3/iPod - Pause / resume the current track.
AM/FM/Sirius - Switch between Auto/Preset tuning mode.
Press and Hold
AM/FM/Sirius - Store the current station as a Preset.
MUTE
Mutes all sound in all zones.
CLOCK
Displays the clock.
DISPLAY
Press to enter the display settings screen.
Adjustment can be made to the Contrast and
Brightness.
INSTALLATION
IF ANY MODIFICATION TO THE VESSEL IS REQUIRED, SUCH AS DRILLING HOLES ETC FUSION
RECOMMENDS CONSULTATION WITH YOUR BOAT DEALER OR MANUFACTURER BEFOREHAND.
»
»
»
»
Remove the Sun Cover from the unit
Fit mounting gasket
Insert the unit into the mounting hole
Pull down the front face to expose the mounting screw locations.
» Use either the supplied 4 x wood screws, or 4 x machined screws
and metal clamps to affix the unit into position.
» The unit must be mounted within 30 degrees of the horizontal plane.
Mounting Gasket
Note: In some circumstances a back strap or brace may be required at the rear of the Unit
(Back Strap / brace is not included).
Appropriate mounting is very important to ensure correct operation. Select a location that allows both free/open airflow around rear of chassis, whilst minimizing exposure to moisture. Allow adequate room at the rear of the unit for the cable looms (approx 2-3”).
MENU STRUCTURE
ROOT MENU
ELECTRICAL WIRING
Caution: The MS-IP600, MS-CD600 and MS-AV600 are designed for vessels with a 12V DC Negative ground electrical system
ZONE OPERATION
The FUSION Marine Stereo makes it possible to have 3 ‘Zones’, that have independent volume control.
Zone 1 and 2 are powered and can be linked, Zone 3 requires a
FUSION Marine Amplifier. All Zones have adjustable volume limits.
Note: If the Zone is selected as ‘Off ’ The features are not available.
LINEOUT
Lineout gives you the ability to connect a FUSION Marine Amplifier.
Note: The lineout can independently be assigned to Zone 1, 2 or 3.
Press the ‘Menu’ button and select ‘Zones’. Select ‘Lineout’. Select the
Zone you are assigning to the Lineout.
ZONE SETUP
Press the ‘Menu’ button and select ‘Zones’. Select the Zone you wish to setup.
ZONE ON/OFF
Select ‘On’ if Zones are present on the vessel.
Note: Zone 1 cannot be turned OFF
VOLUME LIMIT
Select ‘Volume Limit’ to set the desired maximum output volume for each individual Zone.
LINK ZONE 1 + 2
Allows the volume control to operate Zones 1 + 2 as a combined pair.
The Zone set up for Zone 1 and 2 can be configured separately when in this mode.
Press the ‘Menu’ button and select ‘Zones’. Select ‘Zone 1’ then
‘Link Zone 1 + 2’. Select ‘On’ to activate this feature.
SUBWOOFER
Change the assigned zone of the subwoofer. Also adjust the sub level and filter.
SUBOUT ZONE
Press the ‘Menu’ button and select ‘Zones’. Select ‘Subwoofer’ then
‘Subout Zone’. Select the desired subwoofer zone.
Note: The subwoofer can independently be assigned to Zone 1, 2 or 3.
SUB FILTER
Press the ‘Menu’ button and select ‘Zones’. Select ‘Subwoofer’ then
‘Sub Filter’. Select the desired frequency.
SUB LIMIT
Press the ‘Menu’ button and select ‘Zones’. Select ‘Subwoofer’ then
‘Sub Limit’. Select the desired maximum subwoofer output volume.
Note: Press and Hold the ‘Rotary Encoder’ for quick access to subwoofer level adjustment
CONNECTIONS
DESCRIPTION COLOUR
Battery +12VDC Yellow
Accessory +12V switched Red
Negative Ground
Remote Amplifier Turn On
Black
Blue/White
Refer to the wiring diagram for reference (pg 6)
Note: The +12V switched and +12V battery can be joined for some installation requirements.
ANTENNA CONNECTION
Connect an AM/FM marine antenna.
AUX INPUT
Connect an Auxiliary source to the left and right RCA
(White = L, Red = R).
iPod CONNECTION (MS-CD600 and MS-AV600 only)
Connect the 1.5m iPod accessories lead MS-IP15L (not included), or connect the MS-IPDOCK (not included)
SIRIUS SATELLITE RADIO (For use in USA only)
Connect to SiriusConnect™ tuner (not included)
WIRED REMOTE (MS-WR600)
Connect a marine wired remote to the CANbus system connector.
Up to 3 remotes can be connected to the system.
VIDEO CONNECTION (MS-AV600)
Connect the composite video or the S-Video output to a TV / LCD monitor.
ZONE CONNECTIONS
Zone 1
Zone 2
White = Speaker Left Positive
White / Black = Speaker Left Negative
Grey = Speaker Right Positive
Grey/ Black = Speaker Right Negative
Green = Speaker Left Positive
Green / Black = Speaker Left Negative
Purple = Speaker Right Positive
Purple / Black = Speaker Right Negative
Note: Speaker connection (2 Ohm Stereo minimum). 2 pairs of 4 Ohm speakers per channel can be connected in parallel to achieve 2 Ohm configuration.
Zone 3/Lineout Low level output
(For connection to external amplifier)
White RCA= Left Output
Red RCA = Right Output
Orange RCA= Subwoofer Output
Note: Line Output / Sub can both be independently assigned to Zone 1,
Zone 2 or as a unique Zone 3.
WIRING DIAGRAM
Note: The +12V switched and +12V battery can be joined for some installation requirements.
MS-AV600 IR REMOTE OPERATION
MENU Direct access to the menu
SEL NAVIGATION Navigate & adjust using the up, down, left & right keys.
Select the item with the SEL key
POWER
CLOCK
MUTE
SOURCE
Press to turn the unit ON / OFF
Displays the clock
Mutes all sound in all zones
Select the source required
DVD - iPod - AUX - FM - AM - Sirius
ZOOM Select picture size video output
SUB-T Select subtitle language
RANDOM Press to cycle through options
REPEAT
DISPLAY
Press to cycle through options
Press to cycle through options
0-9 KEYPAD Direct track access
SETUP Used to access the DVD settings
SYSTEM SET UP TV System - Auto Play - TV Type
- Password - Rating -Default -
Exit Setup
LANGUAGE SET UP OSD Language - Audio Language
- Subtitle Language -
Menu Language - Exit Setup
VIDEO SET UP Brightness - Contrast - Hue
- Saturation - Sharpness -
Exit Setup
PREVIOUS Selects previous track
NEXT Selects next track
PLAY/PAUSE Pause or play the track
BACK Rewind track
FORWARD Fast-forward track
STOP Press Once: to ‘Pre-stop’
Press Again: to stop disc completely
VOLUME Press + to increase the volume
Press - to decrease the volume
Press volume then ‘SEL’ to select different zone for volume adjustment
DVD OPERATION
MS-AV600 only
PRECAUTIONS
Never insert foreign objects into the disc slot. If the disc does not insert easily, there may already be another disc inserted. Some disc formats may not be readable if the format is not compatible.
PLAYING A DVD/CD/MP3
Press the ‘DVD’ button to select DVD / CD / MP3 source. Playback of the disc will start automatically. The disc loading time will vary.
Note: The disc will resume from the start.
DVD/CD/MP3 NAVIGATION
Navigation is controlled by the supplied Infrared Remote Control, and is presented on external screen. (See MS-AV600 IR Remote Operation)
DVD FUNCTIONS
DVD Press to access the DVD/CD/MP3 source
PLAY/PAUSE Play or Pause the track
BACK/PREVIOUS Short Press: Selects previous track/chapter
Press and Hold: Rewind
NEXT/FORWARD Short Press: Selects next track/chapter
Press and Hold: Fast-forward
GENERAL OPERATION
POWER
Press the ‘Power’ button to turn the unit ON/OFF
SELECTING A SOURCE
Press the desired source button:
RADIO AM/FM/Sirius (Sirius - US Only)
CD / DVD CD/MP3 (MS-CD600) / DVD (MS-AV600) iPod/AUX Press for iPod
Press twice for AUX (MS-CD600 and MS-AV600)
AUX AUX (MS-IP600)
ADJUSTING THE VOLUME
Turn the ‘Rotary Encoder’ to adjust the volume.
ZONE VOLUME
Press the ‘Rotary Encoder’ to step through zones.
Zone 1 All zones Zone 2 Zone 3
Note: The last adjusted zone, becomes the start of the above zone selection cycle.
SETUP
Press the ’Menu’ button and select ‘Setup’. Select the desired function. Turn the ‘Rotary Encoder’ to adjust or press to switch selection (if available). Press ’Menu’ to return.
Note: Remember, whilst in the Setup system the ‘Menu’ button acts as a back/return to the previous screen.
TONE
Adjust the treble and bass settings. Press the ‘Rotary Encoder’ to switch between bass and treble selection.
BALANCE
Adjust the audio balance from left to right.
CLOCK ADJUST
Adjust the Clock time, 12/24 hour. Turn the ‘Rotary Encoder’ to adjust the
Hour, Press to confirm, repeat to adjust the minutes. Press to confirm.
REGIONS
Select Europe for the following tuner frequency stepping:
FM Radio
Frequency Range: 87.5 – 108 MHz
Frequency step: 50 kHz
AM Radio
Frequency Range: 522 – 1620 MHz
Frequency step: 9 kHz
Select USA for the following tuner frequency stepping:
FM Radio
Frequency Range: 87.5 – 107.9 MHz
Frequency step: 100 kHz
AM Radio
Frequency Range: 530 – 1710 MHz
Frequency step: 10 kHz
Note: Select ‘Europe’ for Australasian tuner frequency stepping
LANGUAGE
Select the desired language for the on screen display.
POWER SAVE
OFF Backlight on constantly
ON Backlight display goes off after one minute of non-operation
Note: The MS-CD600, MS-IP600 and MS-AV600 feature Clock battery back up and EEPROM technology. This allows the unit to be completely disconnected from the constant +12V voltage supply
(Battery switch) with no settings being lost.
RADIO OPERATION
SETUP
REGION SELECTION
Press the ‘Menu’ button and select ‘Setup’. Select ‘Tuner Region’ and select your tuner region.
OPERATION
BAND SELECTION
Press the ‘Radio’ button to select band. FM – AM – SIRIUS (USA only)
AUTOMATIC SEEK TUNING
Press the ‘Previous’ or ‘Next’ button to scan to the next station.
MANUAL SEEK TUNING
Press and hold the ‘Previous’ or ‘Next’ button for 3 seconds to enter manual mode. The manual tuning icon will flash on screen. Press the
‘Previous’ or ‘Next’ button to step up and down the spectrum.
Note: After remaining idle for six seconds, the tuning mode will revert to automatic.
PRESETS
You can manually store radio frequencies in the preset memory, or automatically in FM band. There are 15 presets available per band.
STORING A STATION AS A PRESET
When listening to a frequency, press and hold the ‘Play’ button to store preset.
Alternatively: Press the ‘Menu’ button and select ‘Presets’. Select
‘Save Current’ to store station.
AUTOMATIC SEARCH AND STORE PRESETS (FM only)
Press the ‘Menu’ button and select ‘Search Stations’ to automatically search and store stations.
Note: Automatic search mode will erase all other presets already stored, and will automatically store the stations into the preset menu in numerical order.
RECALLING A PRESET STATION
To listen to a radio frequency stored in the preset menu, select the required band, FM - AM - Sirius. Press the ‘Play’ button to enter ‘Presets’ mode. Press the ’Previous’ or ‘Next’ button to select previous or next preset.
Alternatively: Select the required band. FM - AM - Sirius. Press ‘Menu’ and select ’Presets’. Select the desired preset.
DELETING A STORED PRESET
Press ‘Menu’ and select ‘Presets’. Select ‘Remove Presets’. Select the desired preset, or ‘All’.
F.A.S.T
FUSION ALPHA SEARCH TECHNOLOGY
If your iPod contains more than 50 Artists, Songs or Albums you can use F.A.S.T to quickly navigate by letter or number.
Example: Press the ‘Menu’ button and select ‘Artists’. Select ‘D’ and the first ‘Artist’ beginning with ‘D’ will automatically highlight.
Using the ‘Rotary Encoder’ you can then scroll up or down from this selection.
F.A.S.T THRESHOLD
The threshold (number of items) at which point the Alpha Search screen appears for iPod menus can be changed. To change the threshold, navigate as follows - press the ‘Menu’ button and select
‘Setup’, then ’Searching’. Select your desired item number threshold.
ON OFF 50 100 200 400 800
NO iPod CONNECTED
If this appears on the display possible causes are
»
»
Ensure the iPod is correctly connected
Ensure the cable is not excessively bent (MS-CD600, MS-AV600)
» The iPods battery remains low (refer to iPod manual and charge the battery)
iPod OPERATION
PRECAUTIONS FOR iPod
(MS-IP600 only) Before inserting your iPod into the MS-IP600 you must first insert the correct sleeves to match iPod model.
» For the iPod nano (3rd gen), the iPod must be placed inside the
adapter sleeve, and then placed inside Dock sleeve combination A.
» Before inserting iPod,
Please ensure iPod dock connector is clean, dry & free from damage.
Check that unit iPod dock is free from obstructions.
Insert correct sleeve combination to match your iPod
Never insert iPod without a correct sleeve.
» Ensure iPod is inserted with display facing upwards, Never force
your iPod into the dock, if the iPod does not mate with reasonable
ease the sleeve/iPod combination is most likely incorrect.
Note: To check your iPod model, go to www.apple.com/support and enter the serial number found on the back of the iPod.
LISTENING TO AN iPod
Press the ‘iPod’ button. Playback of the iPod will start automatically.
iPod NAVIGATION
Press the ‘Menu’ button to enter the iPod menu. The rotary encoder operates similar to the click wheel on your iPod. Turn to navigate and press to enter.
Note: Press the ‘Menu’ button to return to the previous menu screen.
iPod
PLAY/PAUSE
Press to access the iPod source
Play or Pause the track
BACK/PREVIOUS Short Press: Selects previous track
Press and Hold: Rewind track
NEXT/FORWARD Short Press: Selects next track
Press and Hold: Fast-forward track
SELECTING THE CORRECT IPOD SLEEVE
(MS-IP600 only) A different set of sleeves is used for each iPod model.
The different sleeve combinations are outlined in the chart below: iPod TOP SLEEVE iPod with video, 30GB A iPod with video, 60GB 80GB A iPod classic, 80GB B iPod classic, 160GB (2007) B iPod classic, 120GB B iPod classic, 160GB (2009) B iPod touch, iPod touch, 2nd gen
D
D iPod touch, 2nd gen (2009) D nano, 3rd Gen nano, 4th Gen nano, 5th Gen
Other
G
F
A
E
BOTTOM SLEEVE
A
A
D
D
A
B
A
B
F
A
A + adapter
E
G
REPEAT / SHUFFLE
Press the ‘Menu’ button and select ‘Repeat/Shuffle’.
Select ‘Repeat Track’, ‘Shuffle Track or ‘Shuffle Album’.
Select ON/OFF. Default setting is OFF.
SIRIUS SATELLITE RADIO
USA only - SIRIUS TUNER NOT INCLUDED
ACTIVATING YOUR SIRIUS TUNER
You must activate the SIRIUS tuner before you can begin to receive the
SIRIUS Satellite Radio Service.
In order to activate your radio subscription, you will need the SIRIUS
ID (SID) which uniquely identifies your tuner. The 12 digit SID is displayed on the LCD on initialization. MS-CD600, MS-IP600 and MS-
AV600 will display the SID on Channel 0.
Power on your system and make sure that you are receiving good signal, you are able to hear audio on the SIRIUS Preview channel (Ch-184)
Note: Have your credit card handy and contact SIRIUS on the internet at https://activate.sirius.radio.com/ and follow the prompts to activate your subscription. You can also call SIRIUS toll-free at 1-888-
539-SIRIUS (1-888-539-7474) Once activated, you will be able to begin enjoying SIRIUS Satellite Radio’s digital entertainment and can tune to other channels.
SIRIUS OPERATION
Press ‘Radio’ to select Sirius source radio.
FAVOURITES
Add your favourite channel to your favourites list by selecting ‘Add
Favourite’ (Maximum 15 channels). Remove channels by selecting
‘Remove Favourite’. Select ‘All’ or the individual channel. Exit by pressing the ‘Menu’ button.
Alternatively: Press and hold the ‘Play’ button to store favourite.
PARENTAL MODE
ENABLE ON/OFF
Select to enable channels to be locked/unlocked
PIN #
Turn the ‘Rotary Encoder’ to select number and press to enter, repeat to enter the 4 digit code. (Factory setting is 0000)
Note: Must be entered before the following items are operational.
LOCK / UNLOCK
Select the channel to be locked or unlocked
SKIP / UN-SKIP
Select the channel to be bypassed
CHANGE PIN
Personalise your Pin number. (4 digits max)
SIRIUS NAVIGATION
Press the ‘Menu’ button and navigate the functions.
CHANNELS
Select the desired channel (listed in channel order) and music preference
CATEGORY
Select the desired genre type. (The unit will only play the selected option)
CD/MP3 OPERATION
MS-CD600 only
PRECAUTIONS FOR CD/MP3
Never insert foreign objects into the CD slot. If the CD does not insert easily, there may already be another disc in the unit. Some CD-R/CD-RW may not be readable if the format is not compatible.
The format of an MP3 disc must be ISO9660 Level 1 or 2 or Joliet in the expansion Format. When naming an MP3 file, ensure the file extension is .MP3
MP3 NAVIGATION
Note: The MP3 disc will take approx 10 seconds to load the disc data
(if available) to the unit.
Press the ‘Menu’ button and select ‘Songs’ to enter the MP3 root directory. Use the ‘Rotary Encoder’ to navigate the functions of your
MP3 folders and files. Select the highlighted folder or file.
Note: Press the ‘menu’ button to return to the previous menu screen.
LISTENING TO A CD/MP3
Press the ‘CD’ button. Playback of the CD will start automatically.
REPEAT / SHUFFLE
Press the ‘Menu’ button and select ‘Repeat/Shuffle’.
Select ‘Repeat Track’, ‘Repeat Album’, ‘Shuffle Album’ or ‘Shuffle All’.
Select ON/OFF. Default setting is OFF.
CD NAVIGATION
Press the ‘Menu’ button and select ‘Tracks’. Select desired track.
CD / MP3 FUNCTIONS
CD Press to access the CD/MP3 source
PLAY/PAUSE Play or Pause the track
BACK/PREVIOUS Short Press: Selects previous track
Press and Hold: Rewind track
NEXT/FORWARD Short Press: Selects next track
Press and Hold: Fast-forward track
AUX OPERATION
»
CONNECTING AN
AUXILIARY AUDIO DEVICE
The Left & Right AUX RCA plugs are located at the rear of the unit.
» Connect your auxiliary audio device.
Note: You may require an adapter cable to connect your device.
LISTENING TO YOUR
AUXILIARY AUDIO DEVICE
» Press the ‘AUX’ button to select AUX mode (MS-IP600) or press
the ‘iPod’ button twice (MS-CD600 or MS-AV600)
» Start playback on your auxiliary audio device. Use both the volume
control on your auxiliary device (if available) and the volume control
on the FUSION Marine Stereo to set the volume level.
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
