software technical reference hp color LaserJet 5500 hp color LaserJet 5500 software technical reference (c) Copyright Hewlett-Packard Company, 2002 All Rights Reserved. Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. Edition 1, 09/2002 Warranty Trademark Credits The information contained in this document is subject to change without notice. Adobe, Adobe Photoshop, Acrobat, PostScript, and the Acrobat logo are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries/regions. Hewlett-Packard makes no warranty of any kind with respect to this information. HEWLETT-PACKARD SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not be liable for any direct, indirect, incidental, consequential, or other damage alleged in connection with the furnishing or use of this information. Arial is a U.S. registered trademark of the Monotype Corporation. AutoCAD (TM) is a U.S. trademark of Autodesk, Inc. CorelDraw (TM) is a trademark of Corel Corporation or Corel Corporation Ltd. Helvetica and Times are treadmarks of Linotype-Hell AG and/or its subsidiaries in the U.S. and other countries/regions. Intel (R) is a U.S. trademark of Intel Corporation. Java (TM) is a U.S. trademark of Sun Microsystems, Inc. HP-UX Release 10.20 and later and P-UX RElease 11.00 and later (in both 32- and 64bit configurations) on all HP 9000 computers are Open Group UNIX 95 branded products. Microsoft (R), MS-DOS (R), Windows (R), and Windows NT (R) are U.S. registered trademarks of Microsoft Corporation. Netscape and Netscape Navigator are trademarks or registered trademarks of Netscape Communications, Inc. PANTONE (R)* is Pantone, Inc.’s checkstandard trademark for color. Pentium (R) is a registered trademark of Intel Corporation. TrueType (TM) is a U.S. trademark of Apple Computer, Inc. UNIX (R) is a registered trademark of the Open Group. Hewlett-Packard Company 11311 Chinden Boulevard Boise, Idaho 83714 U.S.A. Table of Contents List of tables List of figures 1 Purpose and Scope Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 HP Color LaserJet 5500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 2 Software Description Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Supported operating systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Technology background information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP LaserJet user documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Adobe Acrobat Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP LaserJet guides. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP LaserJet product printing-system installation notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP LaserJet product printing-system release notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Other HP LaserJet documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Bidirectional communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Driver Autoconfiguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP Web Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Information tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Device status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Configuration information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Links to off-printer solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Settings tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Remote printer configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Networking tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Network settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Configurable e-mail alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Printer Status and Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Remote firmware update. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Determining the current level of firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Downloading the new firmware from the HP Web site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Downloading the new firmware to the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Remote firmware update through a local Windows port. . . . . . . . . . . . . . . . . . . . . . . . . . . Windows 95, Windows 98, and Windows Me . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Windows 95, 98, Me, NT 4.0, 2000, and XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Remote firmware update through a Windows network. . . . . . . . . . . . . . . . . . . . . . . . . . . . Remote firmware update for UNIX systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Remote firmware update using FTP on a direct network connection . . . . . . . . . . . . . . . . . Remote firmware update using FTP and a browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Using HP Web JetAdmin to download the firmware to the product . . . . . . . . . . . . . . . . . . . Printer messages during firmware upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Software Technical Reference 15 15 16 16 16 16 17 17 17 17 18 20 20 21 22 22 22 23 23 23 24 24 24 25 25 30 30 31 31 31 31 32 32 32 32 33 33 34 3 E-mail command and response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Euro character . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 International Color Consortium profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 PANTONE (R)* color profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Printing-system components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Printing system and installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 CD browser for Windows systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Installer features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Installable components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Printer drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 PCL 5c, PCL 6, and PS drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Windows 95, 98, Me, NT 4.0, 2000, and XP driver versions . . . . . . . . . . . . . . . . . . . . . . . . 40 Macintosh and Macintosh-compatible system driver versions . . . . . . . . . . . . . . . . . . . . . . . . 41 Additional driver availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Macintosh components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Additional productivity tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 HP Web Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Optional software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 HP Web JetAdmin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 3 Driver features Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 PCL 5c and PCL 6 driver features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Help system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 What's this? Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Context-sensitive Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Constraint messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Bubble Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Finishing tab features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Document preview image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Quick Sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 User’s Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Custom Quick Sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Document Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Print on Both Sides option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Flip Pages Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Booklet Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Activating booklet printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Selecting a booklet cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Pages per Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Print Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Graphics Settings group box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Output Settings group box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Manually printing on the second side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Scale Patterns (WYSIWYG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Print all Text as Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Font Settings group box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Effects tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Print Document On setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Scale to Fit option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 % of Normal Size option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 Watermarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64 Current Watermarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Watermark Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Message Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 4 Software Technical Reference Font Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Shading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Paper tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Printer image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . All Pages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Other Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Size is . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Custom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Name drop-down menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dynamic command button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Width and height controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Custom width and height control limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Paper and envelope icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Measurement Units button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Close button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Source Is. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Type Is . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Printer image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Destination tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Destination Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hardware configuration and availability of Job Storage options . . . . . . . . . . . . . . . . . . . . . . Configuring the printer driver for a printer hard disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Job storage modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Quick Copy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Proof and Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Using a PIN for Private Job and Stored Job. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Private Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Stored Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Document identifiers used in Job Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . User Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Job Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Using Job Storage options when printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Releasing stored jobs at the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Deleting a print job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Output Bin Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Printer image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Basics tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Copies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . About. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Driver extensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Color tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Color options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Manual color settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Configure tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Printer Model group box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Paper-handling options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Duplexing unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mopier enabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Optional Paper Destinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Optional Paper Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Other Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Software Technical Reference 65 65 66 66 67 67 67 67 68 69 69 70 71 72 72 73 74 74 74 74 75 75 76 76 77 77 78 78 78 78 79 79 79 79 80 80 80 81 81 81 82 82 82 83 83 84 85 85 86 86 87 88 89 90 90 91 91 91 92 5 Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 Printer Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 Include types in application source list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93 Fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94 Ignore Application Collation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95 Automatic Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 Printer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 NT Forms tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97 Configuring the trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97 Windows PS driver features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 PS 3 Emulation support for the HP LaserJet product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 Page Setup tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99 Advanced tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 Job Storage tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101 Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101 Quick Copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101 Proof and Hold. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102 Private Job and Stored Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102 PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102 Private Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102 Stored Job. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102 Device Settings tab features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104 HP LaserJet software CD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 In-box file layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 HP LaserJet software CD-ROM, Windows partition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 Directory structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 HP LaserJet software CD-ROM, Macintosh Partition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 Availability and fulfillment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 In-box CD-ROMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106 Web ordering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106 Web deployment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107 Printing-system software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107 Printer firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107 Standalone drivers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107 Operating system driver bundles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107 Point-and-print bundles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107 Other operating systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108 Software component availability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108 Software component localization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109 4 Installing Windows printing system components Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113 System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113 Windows 95, 98, Me, NT 4.0, 2000, and XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113 Windows 95, 98, Me, NT 4.0, 2000, and XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113 Font support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 Basic fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 Default fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 Installation instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118 General installation for Windows 95, 98, Me, NT 4.0, 2000, and XP OSs . . . . . . . . . . . . . . 118 Installing from the printing system CD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119 Installing from a network or from downloaded files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119 Detailed Windows installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119 Typical Installation dialog box sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119 Custom installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144 Product registration (HP WebReg) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146 6 Software Technical Reference Customization Utility for Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Silent installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Customized silent installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Driver Management and Configuration Utility (Internal) . . . . . . . . . . . . . . . . . . . . . . . . . . Command-line silent install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Method 1: Command line. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Method 2: SETUP.LST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Driver-only installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Point and Print installation for Windows 95, 98, Me, NT 4.0, 2000, and XP . . . . . . . . . . . . Setting a default printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Windows 3.1x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Printer support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156 156 156 157 157 157 157 158 158 160 160 160 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IBM OS/2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Macintosh component descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP LaserJet PPDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PDEs (Mac OS X) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP LaserJet Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Installation notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ColorSync profiles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Online Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP Auto Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Screen fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Font support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Installing the Macintosh printing system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . To install the HP LaserJet printer software for Macintosh OS . . . . . . . . . . . . . . . . . . . . . . . . Uninstalling the Macintosh printing system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . In-box disk layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Folders and files added through installation of the HP LaserJet software (Macintosh OS) . . Macintosh (Macintosh OS) installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Main Install dialog box sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Printer setup using AppleTalk Chooser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . HP LaserJet Screen Fonts Installer dialog box sequence . . . . . . . . . . . . . . . . . . . . . . . . . IBM OS/2 Warp 3.0 and later . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OS/2 installation instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Installing a printer in OS/2 when printer object is missing . . . . . . . . . . . . . . . . . . . . . . . . . Installing a printer in OS/2 with pre-existing printer object on desktop . . . . . . . . . . . . . . . . Font support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Changing a printer driver in the printer object. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Changing the printer properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Changing the job properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161 161 161 161 161 162 162 162 162 162 162 162 163 163 163 163 166 166 167 167 167 167 167 173 174 176 176 176 177 178 179 179 179 6 Engineering Detail Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Media attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Paper-source commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Media types and sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Paper Type commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181 181 181 182 185 Index Software Technical Reference 7 8 Software Technical Reference List of tables Table 1. Bidirectional communication support in various operating systems . . . . . . . . . . . . . . . . 18 Table 2. Default alerts selection state for connection type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Table 3. Update messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Table 4. Bubble Help messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Table 5. Page orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Table 6. Selected paper size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Table 7. Watermark color values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Table 8. Name drop-down menu text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73 Table 9. Custom width and height limits for the HP Color LaserJet 5500 . . . . . . . . . . . . . . . . . . . 74 Table 10. Close dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 Table 11. Printer behavior with Ignore Application Collation settings . . . . . . . . . . . . . . . . . . . . . . 95 Table 12. CD-ROM versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106 Table 13. Software component availability for HP Color LaserJet 5500 product . . . . . . . . . . . . 108 Table 14. Software component localization for the HP Color LaserJet 5500 product . . . . . . . . . 109 Table 15. Default fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 Table 16. Additional PS 3 fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116 Table 17. Choose Setup Language dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120 Table 18. Setup dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121 Table 19. Welcome dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122 Table 20. HP Software License Agreement dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . 123 Table 21. Web Update dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125 Table 22. Type of Connection dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126 Table 23. Select Port dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128 Table 24. Network Setup dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 Table 25. Network Printer Configuration dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . 131 Table 26. Identify Printer dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133 Table 27. Specify Network Path dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134 Table 28. Set Network Communication Mode dialog box text strings . . . . . . . . . . . . . . . . . . . . . 135 Table 29. Printer Model dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136 Table 30. Installation Type dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138 Table 31. Printer Name dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139 Table 32. Printer Sharing dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141 Table 33. Finish dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143 Table 34. Exit Setup dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144 Table 35. Custom Installation dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146 Table 36. Hewlett-Packard’s Electronic Registration text strings . . . . . . . . . . . . . . . . . . . . . . . . . 148 Table 37. Welcome to Hewlett-Packard’s Registration dialog box text strings . . . . . . . . . . . . . . 149 Table 38. Hewlett-Packard’s Electronic Registration dialog box text strings (1 of 3) . . . . . . . . . . 151 Table 39. Hewlett-Packard’s Electronic Registration dialog box text strings (2 of 3) . . . . . . . . . . 153 Table 40. Hewlett-Packard’s Electronic Registration dialog box text strings (3 of 3) . . . . . . . . . . 154 Table 41. Exiting registration text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155 Table 42. Windows servers with Windows clients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159 Table 43. HP LaserJet for Macintosh installer splash screen dialog box text strings . . . . . . . . . . 168 Table 44. HP LaserJet Installer dialog text strings (easy install) . . . . . . . . . . . . . . . . . . . . . . . . . 169 Table 45. HP LaserJet Installer dialog text strings (custom install) . . . . . . . . . . . . . . . . . . . . . . . 171 Table 46. Installing dialog text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172 Table 47. Installation successful dialog text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172 Table 48. Important! dialog box text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173 Table 49. How do I select my printer? dialog text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174 Software Technical Reference 9 Table 50. HP LaserJet Screen Fonts splash screen dialog text strings . . . . . . . . . . . . . . . . . . . . 174 Table 51. HP LaserJet Screen Fonts installer dialog text strings (1 of 2) . . . . . . . . . . . . . . . . . . . 175 Table 52. HP LaserJet Screen Fonts installer dialog text strings (2 of 2) . . . . . . . . . . . . . . . . . . . 175 Table 53. Installation was successful dialog text strings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176 Table 54. Paper-source commands for the HP LaserJet 5500 product . . . . . . . . . . . . . . . . . . . . 181 Table 55. Supported features and attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182 Table 56. Input-device supported sizes for the HP Color LaserJet 5500 product . . . . . . . . . . . . . 183 Table 57. Input-device supported media types for the HP Color LaserJet 5500 product . . . . . . . 184 Table 58. PCL 5e and PCL 6 custom paper sizes for the HP Color LaserJet 5500 product . . . . . 185 Table 59. Paper-type commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185 10 List of tables Software Technical Reference List of figures Figure 1. Device Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Figure 2. Configuration page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Figure 3. Configure Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Figure 4. Networking tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Figure 5. Configurable Alerts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Figure 6. Printer Status and Alerts icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Figure 7. Refresh Rate option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Figure 8. Printer Status and Alerts options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Figure 9. Installation CD browser main screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Figure 10. A typical constraint message with an OK button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Figure 11. A property page with Bubble Help icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Figure 12. The default appearance of the Finishing tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Figure 13. Finishing tab - User’s Manual Quick Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Figure 14. Activating booklet printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Figure 15. Selecting booklet printing type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Figure 16. Page-order preview images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Figure 17. Print Quality Details dialog box showing HP Color LaserJet Default setting . . . . . . . . 58 Figure 18. Effects tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Figure 19. Preview images - Legal on Letter; Scale to Fit off (left) and on (right) . . . . . . . . . . . . . 63 Figure 20. Watermark Details dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64 Figure 21. Paper tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 Figure 22. Other Pages mini-tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 Figure 23. Back Cover mini-tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 Figure 24. Custom Paper Size dialog box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Figure 25. Destination tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77 Figure 26. Basics tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83 Figure 27. About This Driver dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85 Figure 28. Color tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 Figure 29. Manual Color Options dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87 Figure 30. Configure tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89 Figure 31. More Configuration Options dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 Figure 32. Configure Font DIMMs dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94 Figure 33. Driver NT Forms tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97 Figure 34. Page Setup tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99 Figure 35. Advanced tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 Figure 36. Job Storage tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101 Figure 37. Device Settings tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104 Figure 38. Choose Setup Language dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120 Figure 39. Setup dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120 Figure 40. Welcome dialog box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122 Figure 41. HP Software License Agreement dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123 Figure 42. Web Update dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124 Figure 43. Type of Connection dialog box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126 Figure 44. Select Port dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127 Figure 45. Select Port dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127 Figure 46. Network Setup dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129 Figure 47. Network Setup dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129 Figure 48. Identify Printer dialog box (1 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132 Figure 49. Identify Printer dialog box (2 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132 Software Technical Reference 11 Figure 50. Figure 51. Figure 52. Figure 53. Figure 54. Figure 55. Figure 56. Figure 57. Figure 58. Figure 59. Figure 60. Figure 61. Figure 62. Figure 63. Figure 64. Figure 65. Figure 66. Figure 67. Figure 68. Figure 69. Figure 70. Figure 71. Figure 72. Figure 73. Figure 74. Figure 75. Figure 76. 12 List of figures Specify Network Path dialog box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134 Set Network Communication Mode dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135 Printer Model dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136 Installation Type dialog box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137 Printer Name dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139 Printer Sharing dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 Finish dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142 Finish dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142 Exit Setup dialog box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143 Exit Setup dialog box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143 Components dialog box, Custom Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145 Hewlett-Packard’s Electronic Registration dialog box . . . . . . . . . . . . . . . . . . . . . . . . . 147 Welcome to Hewlett-Packard’s Registration dialog box . . . . . . . . . . . . . . . . . . . . . . . 149 Hewlett-Packard’s Electronic Registration dialog box (1 of 3). . . . . . . . . . . . . . . . . . . 150 Hewlett-Packard’s Electronic Registration dialog box (2 of 3). . . . . . . . . . . . . . . . . . . 152 Hewlett-Packard’s Electronic Registration dialog box (3 of 3). . . . . . . . . . . . . . . . . . . 154 Exiting registration! dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155 HP LaserJet for Macintosh installer splash screen dialog box . . . . . . . . . . . . . . . . . . 167 HP LaserJet Installer dialog box (easy install) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168 HP LaserJet Installer dialog box (custom install) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170 Installing dialog box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172 Installation was successful dialog box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172 Important! dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173 How do I select my printer? dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173 HP LaserJet Screen Fonts splash screen dialog box . . . . . . . . . . . . . . . . . . . . . . . . . 174 HP LaserJet Screen Fonts installer dialog box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175 Installation was successful dialog box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176 Software Technical Reference 1 Purpose and Scope Introduction This Software Technical Reference (STR) provides information and troubleshooting tips for the printing system software for the HP Color LaserJet 5500 product. This document is prepared in an electronic format to serve as a quick-reference tool for Customer Care Center (CCC) agents, support engineers, system administrators, management information systems (MIS) personnel, and HP LaserJet product end-users, as appropriate. The following information is included in this technical reference: z z z z descriptions of drivers and platforms with system modifications procedures for installing and uninstalling software components descriptions of problems that can arise while using the product, and known solutions to those problems descriptions of known software issues and workarounds A description of the product model or models described in this STR is provided below. The printing system software for each product model accommodates the differences between models. Note Bundle configurations might vary among geographic regions. Software Technical Reference Introduction 13 HP Color LaserJet 5500 The HP Color LaserJet 4600 product is available in five bundle configurations. HP Color LaserJet 5500. This model includes a total of 96 megabytes (MB) of synchronous dynamic random access memory (SDRAM), expandable to 384 MB SDRAM (maximum); a multipurpose tray (tray 1); and a 500-sheet XY tray (tray 2). z HP Color LaserJet 5500n. This model includes a total of 96 megabytes (MB) of synchronous dynamic random access memory (SDRAM), expandable to 384 MB SDRAM (maximum); a multipurpose tray (tray 1); a 500-sheet XY tray (tray 2); and a Jetdirect print server enhanced input/output (EIO) network card. z HP Color LaserJet 5500dn. This model includes a total of 96 megabytes (MB) of synchronous dynamic random access memory (SDRAM), expandable to 384 MB SDRAM (maximum); a multipurpose tray (tray 1); a 500-sheet XY tray (tray 2); a Jetdirect print server enhanced input/output (EIO) network card; and a duplexing unit. z HP Color LaserJet 5500dtn. This model includes a total of 160 megabytes (MB) of synchronous dynamic random access memory (SDRAM), expandable to 384 MB SDRAM (maximum); a multipurpose tray (tray 1); two 500-sheet XY trays (trays 2 and 3); a Jetdirect print server enhanced input/output (EIO) network card; a duplexing unit, and a stand. z HP Color LaserJet 5500hdn. This model includes a total of 160 megabytes (MB) of synchronous dynamic random access memory (SDRAM), expandable to 384 MB SDRAM (maximum); a 10-gigabyte (GB) hard disk; multipurpose tray 1; three 500sheet XY trays (trays 2, 3, and 4); a Jetdirect print server enhanced input/output (EIO) network card; a duplexing unit, and a stand. The use guide might include memory that is found on the formatter called "Pageframe Memory" (32 MB) that can be used/allocated by the printer, for a print job along with the memory found on the 96-MB or 160-MB RAM dual in-line memory module (DIMM) in the printer. The driver and the configuration page show only the total memory found on the RAM DIMM(s). z 14 1 Purpose and Scope Software Technical Reference 2 Software Description Introduction The product comes with software and installers for Microsoft (R) Windows (R) and Apple Computer, Inc., Macintosh systems. UNIX (R) and OS/2 systems are supported, and software is available on the Web. For specific information about a system's installer, drivers, and components, locate the section that corresponds to that system. Supported operating systems The following operating systems (OSs) support the HP LaserJet printing-system software, including standard printer command language (PCL) drivers and PostScript (R) (PS) emulation drivers. Windows OSs support a full-featured configuration of the HP LaserJet product; other OSs support varying levels of functionality. Windows 95. z Windows 98. z Windows Millennium Edition (Me). z Windows NT (R) 4.0 (Service packs 3 through 6). z Windows 2000 (Service packs 1 and 2). z Windows XP Professional and Windows XP Home Edition (Windows XP) z IBM OS/2 2.0 or later (available on the IBM Web site at http://www.ibm.com). z Mac OS 8.6 to 9.x and Mac OS X Classic. Windows Terminal Server, Windows Cluster Server, and Citrix Terminal server technology allows as many as 128 devices or terminals to share the resources dynamically on a terminal server. A terminal server eliminates the need for modems, network interface cards, applications, or complete operating systems on the terminals. Terminals can include personal computers, so-called dumb terminals, printers, and other devices. Terminal clients connect to the terminal server through Transmission Control Protocol/Internet Protocol (TCP/IP). Citrix Metaframe supports connection through TCP/ IP, NETBIOS Extended User Interface (NetBEUI), Internetwork Packet Exchange/ Sequenced Packet Exchange (IPX/SPX), and asynchronous modem connections. In turn, the terminal server connects to a local area network (LAN) through a network interface card. For information (including a list of supported printers, recommendations for installing printer drivers, a description of terminal server configurations, differences between terminal server versions, and differences between remote client operating systems) about supported printers and driver versions, visit the Web site at the following URL: http://www.hp.com/cposupport/printers/support_doc/bpl10248.html z Software Technical Reference Introduction 15 Technology background information This section addresses the following topics: z z z z z z z z z "HP LaserJet user documentation" in HP LaserJet user documentation "Bidirectional communication" in Bidirectional communication "Driver Autoconfiguration" in Driver Autoconfiguration "HP Web Access" in HP Web Access "Printer Status and Alerts" in Printer Status and Alerts "Remote firmware update" in Remote firmware update "Euro character" in Euro character "International Color Consortium profiles" in International Color Consortium profiles "PANTONE (R)* color profiles" in PANTONE (R)* color profiles HP LaserJet user documentation Adobe Acrobat Reader The HP LaserJet software compact disk - read-only memory (CD-ROM) includes Adobe (R) Acrobat (R) Reader version 5.0 (version 4.05c for Russian) for viewing online documentation. When you click any of the documentation links in the HP LaserJet software CD browser, the installer scans the system for an installed Portable Document Format (PDF) reader. If the installer cannot find a reader, the installer presents the option to install the Adobe Acrobat Reader. Note Adobe Acrobat Reader 4.0 or later is required to view the documents on the HP LaserJet software CD browser. HP LaserJet guides On the CD-ROM that came with the product, the HP LaserJet 5500 use guide is supplied in Adobe Acrobat Reader PDF files for viewing on your computer. You can either view the guide from the HP LaserJet CD browser or install it on your system. To install the online use guide, select the User Guide check box during a Custom Installation. The guide is installed in the Manuals folder on the target system. You can also choose to install the guides later, or read the guide on the printing system software CD-ROM by navigating to <language>/Manuals. In accordance with the Americans with Disabilities Act (ADA), Hewlett-Packard provides a readable, onscreen version of the HP LaserJet 5500 use guide at the following HP Web site: http://www.hp.com/support/lj5500. A hyperlinked, screen-readable version of the HP Color LaserJet 5500 use guide is available on the printer software CD-ROM. To view the use guide, navigate to the "English" folder, and then to the "Manuals" folder. There, open HP5500EN.CHM. 16 2 Software Description Software Technical Reference HP LaserJet product printing-system installation notes The HP LaserJet 5500 Series Printing System Installation Notes are available on the HP LaserJet software CD-ROM. The installation notes (filename READ5500.RTF for the HP Color LaserJet 5500 product) contain important information about product features, instructions for installing the printing-system software, and technical assistance. To view this text file from the HP Color LaserJet 5500 software CD browser, click View Documentation, and then click Readme. You can also gain access to the file by inserting the CD-ROM, navigating to <LANGUAGE>, and then clicking the filename, READ5500.RTF. When you have the file open in Notepad, you can click File, and then click Save As to save a copy of the file to another location. HP LaserJet product printing-system release notes The Hewlett-Packard LaserJet 5500 Printing System Release notes, late-breaking information, and other technical assistance, are available on the Web at the following URL: http://www.hp.com/support/lj5500 Other HP LaserJet documents Guides for accessories and Jetdirect networking are also available as Adobe Acrobat PDF files. You can view these documents from the HP LaserJet software CD browser by clicking View Documentation and then clicking the name of the guide you want to view. To install the file, select the printer documentation check box during a Custom Installation. The following guides are available: • HP Jetdirect Administrator's Guide (click HP Jetdirect Guide) • HP Fast InfraRed Receiver for HP LaserJet Printers (click hp FIR Guide) Bidirectional communication Bidirectional communication is the product’s ability to respond to data inquiries from the computer and report back information, such as what type of print media is available or what accessories are connected to the printer. If a product does not have this capability (that is, if it has no bidirectional mode), it can only accept commands from the host and cannot report information back. Driver Autoconfiguration and Printer Status and Alerts use bidirectional communications software. The Typical Installation installs Driver Autoconfiguration in supported environments that contain the bidirectional communication software. Use Custom Installation when you do not want these features. Bidirectional communication depends upon the type of connection between your computer to your printer and your network operating system. The following table provides information about the operating systems and network environments that support bidirectional communication. Software Technical Reference Technology background information 17 Table 1. Bidirectional communication support in various operating systems Connection type Windows 95 Windows 98 Windows Me Windows NT 4.0 Windows 2000 Windows XP (32-bit only) Direct Connect X X X X1 X X X X X X X X X X X X X X X X X X X X X X X X X X X X Network Port Jetdirect TCP/IP2 IPX/SPX Standard TCP/IP (HP) 3 TCP/IP (MS4) IPX/SPX (HP) X X X LPR AppleTalk Novell4 NetWare 4.x Microsoft Share X X X X Bindery queue X X X X X X NDS5 queue X X X X X X Bindery queue X X X X X X NDS queue X X X X X X Windows 95, 98, or Me host TCP/IP X X X X X X IPX/SPX X X X X X X Windows NT 4.0, 2000, or XP6 host TCP/IP X X X X X X IPX/SPX X X X X X X LPR X X X X X X NetWare 5.x Macintosh X X 1 Windows NT 4.0 supports parallel but not universal serial bus (USB) connections. Transmission control protocol/Internet protocol. 3Internet packet exchange/sequences packet exchange. 4 Bidirectional functionality is supported only with the client software from Novell. It is not supported with Microsoft Client Service for Netware. 5Novell Directory Services. 6 Printer Status and Alerts is not installed when the share computer is running Terminal Server. 2 Driver Autoconfiguration The HP LaserJet PCL 6 and PCL 5c drivers for Windows feature bidirectional communication technology which, in supported environments, provides automatic discovery and driver configuration for printer accessories at the time of installation or later, if needed. Some accessories that are supported by Driver Autoconfiguration are the duplexing unit, optional paper trays, font dual inline memory modules (DIMMs), and the hard drive. 18 2 Software Description Software Technical Reference If the environment supports bidirectional communication, the installer presents Driver Autoconfiguration as an installable component by default for a Typical Installation, and as an optional installable component for a Custom Installation. The Driver Autoconfiguration component installs the bidirectional communication software. If the installation environment does not support bidirectional communication, the Driver Autoconfiguration option does not appear during installation. However, installed drivers will be configured automatically in accordance with the HP printer bundle selected during installation of the printing-system software. Driver Autoconfiguration works in four ways: z z In environments that support bidirectional communication, the computer communicates with the product, determines the physical configuration, and then configures the driver accordingly. If the configuration of the HP LaserJet product changes after installation, the driver can be automatically updated with the new configuration in environments that support bidirectional communication. For example, if the base printer model is installed and an optional duplexing unit is added later, you can automatically configure the duplexing unit in the driver by clicking the Update Now button on the driver's Configuration tab. The Update Now button activates the HP Network Registry Agent (HPNRA) and triggers the driver to recheck the registry for new information. The HPNRA automatically updates the registry and changes the configuration information that appears on the Configuration tab in the Printer folder. Note The bidirectional communication software necessary for the two methods of Driver Autoconfiguration described above is included in a Typical Installation when installing a network printer in supported environments. The feature is also a selectable option for a Custom Installation. z z In environments that do not support bidirectional communication, the driver automatically configures options based on the HP LaserJet product bundle selected during the installation of the printing-system software. For example, if the HP Color LaserJet 5500dn is selected, the driver automatically configures the duplexing unit and the correct amount of RAM. Configuration is based solely on the definition of the printer bundle. Enterprise AutoConfiguration (EAC) is a version of bidirectional communication that provides autoconfiguration functionality for an Add Printer Wizard installation (when you do not use autoselect). An Add Printer Wizard installation that includes EAC is identical to other Add Printer installations, except that when installation is complete, the driver for the supported product is configured with the same settings as the physical configuration of the device. Configuration occurs without user interaction. If bidirectional communication software has been installed previously, EAC will not be activated, and the Add Printer Wizard uses the pre-existing bidirectional communication to configure the printer. If bidirectional communication software has not been installed, EAC configures the driver to match the device configuration, which it detects automatically. EAC is active only as needed to use the autoconfiguration utility, and is then shut off. The files required to install EAC remain on your system. Software Technical Reference Technology background information 19 HP Web Access The HP Web Access feature, also known as the embedded Web server (EWS), contains the following components: z z z Embedded virtual machine for Java (TM) applications Web pages storage space HP Web Access provides a simple, easy-to-use solution for one-to-one printer management. In offices with a limited number of printers, remote management of printing devices can be accomplished without installing any management software, such as HP Web JetAdmin. The only requirement is that the management console have a supported Web browser. In environments with a larger number of printers, where one-to-one management is impractical, HP Web Access and HP Web JetAdmin work together to provide scalable remote printer management. HP Web JetAdmin is used for consolidated management tasks, where operations are performed on a selected set of printers instead of on individual printers. For such environments, HP has provided hooks between HP Web Access and HP Web JetAdmin so that Web Access features can be configured on multiple printers in one operation. For example, the security password for HP Web Access can be set on a population of printers simultaneously. For additional information and a copy of the HP Embedded Web Server for HP LaserJet Printers guide, go to the Web site at the following URL: http://www.hp.com/support/lj5500 To view information about the printer using HP Web Access, open a supported Web browser and type in the printer TCP/IP address or host name. To find the TCP/IP address, look for "IP Address" on the EIO Jetdirect page, in the "TCP/IP" section under "Protocol Information". To find the host name of the printer, look for "Host Name" in the "TCP/IP" section. To print a copy of the EIO Jetdirect page from the printer control-panel display, see the instructions for printing a configuration page in the “Determining the current level of firmware” section. You also can view information about an installed HP Jetdirect print server by clicking the Networking tab in the HP Web Access window. Information tab HP Web Access offers the following additional features. To view the information, click the items on the menu that is on the left side of the HP Web Access Information tab: • Device Status. This page provides current status information about your product. • Configuration Page. This page provides information about the configuration for your product. • Supplies Status. This page provides information about the print cartridge and the total pages printed, and the serial number of the product. • Event Log. This page provides information about reported printer errors. • Usage Page. This page provides information about product usage. • Device Information. This page shows device information, such as the product TCP/IP address and serial number. • Control Panel. This page shows the layout of the control panel. 20 2 Software Description Software Technical Reference Device status If a printer problem exists, status information (such as whether the printer is online or the toner is low) is available through your Web browser linked directly to the printer. You can view this information without physically going to the printer to identify the status. The following illustration shows how this information is presented on the printer's Web page. Figure 1. Device Status Software Technical Reference Technology background information 21 Configuration information The HP LaserJet printer configuration page is available remotely through HP Web Access. The HP Web Access configuration page provides configuration information about the product in the same way as the configuration page printed from the printer. The following illustration shows an example of a configuration page viewed remotely through HP Web Access. Figure 2. Configuration page Links to off-printer solutions Links within the home page of HP Web Access provide an easy way to locate information or complete tasks. • HP Instant Support (TM). This link connects you to a set of dynamic Web resources that will help you solve specific problems and determine additional services that might be available for your device. Specific status and configuration information about the product is retained and directed to the “Solve a Problem” Web site. This site offers targeted support content and messages to help resolve problems as quickly as possible. • Order Supplies. Click this link to connect to an ordering page where you can order genuine HP supplies, such as print cartridges and paper. • Product Support. This link connects you with an HP product support page from which you can search for information, contact the HP customer care home page, or find additional resources for your product. Settings tab The options on the left of the Settings tab are as follows: • Configure Device • Alerts • Email 22 2 Software Description Software Technical Reference • • • • Security Other Links Device Information Language Remote printer configuration Printer configuration information can be obtained through a Web browser by opening the printer HP Web Access page and changing any of the basic configuration information on the Settings tab. Security and password controls provide management information system managers with the level of control required within their environments. The following illustration shows an example of printer options that can be configured remotely. Figure 3. Configure Device Some configuration tasks cannot be performed remotely because printed pages must be examined. Networking tab The menu on the left of the screen contains other networking options under three categories: configuration, security, and diagnostics. Configuration • • • • Software Technical Reference Network Settings Other Settings Support Info Select Language Technology background information 23 Security • • • • • Admin Password SSL/TLS SNMPv3 Telnet Access Control Diagnostics • • • • Network Statistics Protocol Info Configuration Page Refresh Rate Network settings The following illustration shows the Network Settings option on the HP Web Access Networking tab. From this screen, you can enable and configure the following network services: • • • • • Figure 4. TCP/IP IPX/SPX AppleTalk Data Link Control/Logical Link Control (DLC/LLC) Simple Network Management Protocol (SNMP) Networking tab 24 2 Software Description Software Technical Reference Configurable e-mail alerts The printer can automatically send e-mail alerts about printer problems or job status to specified e-mail addresses. For example, if toner is low, the printer can notify the person responsible for ordering or changing the cartridge. If there is a printer failure, an e-mail alert can be sent directly to the person responsible for fixing the problem. These e-mail alerts can be configured to be sent to any device that can accept e-mail, such as digital phones, pagers, and personal digital assistants. In large environments, administrators can route e-mail addresses to list-servers or URLs for expanded notification. Figure 5. Configurable Alerts Printer Status and Alerts The HP LaserJet printing-system software includes a utility called Printer Status and Alerts that you can use to monitor print jobs and printer status from the desktop. The Printer Status and Alerts feature provides printer and job status information such as printing history, job progress, toner and paper levels, and consumables and supplies reorder information, and presents a simulated view of the product control panel. This utility offers several options for configuring pop-up windows to view the status of the printer and of individual print jobs. Printer Status and Alerts is a selectable component of Custom Installation. To install Printer Status and Alerts, choose Custom Installation and select the appropriate check box. Software Technical Reference Technology background information 25 Printer Status and Alerts features are available for printers connected by means of a connection, whether direct or over a network, that supports bidirectional functionality. The Printer Status and Alerts feature cannot be installed over infrared (IR) or serial ports. See “Bidirectional communication.” For Windows 95, the Microsoft Winsock2 patch must first be installed. To download the Microsoft Winsock2 patch, go to http://www.microsoft.com/windows95/downloads/ contents/WUAdminTools/S_WUNetworkingTools/W95Sockets2/Default.asp. For all operating systems, the computer must have Internet Explorer version 4.72 or later installed; version 5.0 or later is recommended. HP Printer Status and Alerts communicates with the printer only during an active print job to minimize network traffic. The following restrictions apply to HP products that use Printer Status and Alerts: z z z z z z z z z Windows NT 4.0, Windows 2000, and Windows XP do not support Printer Status and Alerts with terminal servers. For Device Status (printer icons in the status window), the computer must have Internet Explorer version 4.72.x or later installed. To find the version number, open Internet Explorer, click Help, and then click About Internet Explorer. Netscape browsers do not support Printer Status and Alerts. No Internet Explorer is necessary for getting status about jobs. Internet Explorer can be installed after installing Printer Status and Alerts. Netscape browsers do not support HP Printer Status and Alerts. On a few applications, such as Microsoft Excel and Seagate Crystal Reports, multiple copies of the same document show up in the Printer Status and Alerts window as separate jobs. This is because these applications actually send each copy as a separate job. For Windows screen reader applications, such as Job Access With Speech from Freedom Scientific, the computer must have Internet Explorer version 5.0 or later installed. To find the version number, open Internet Explorer and click Help, and then click About Internet Explorer. Version 5.0 is reported as Version 5.00.x or later. No Internet Explorer is necessary for getting status about jobs for network-connected printers. Internet Explorer can be installed after installing Printer Status and Alerts. When renaming a driver, job and device status will not be tracked until the computer is restarted. Drivers added after Printer Status and Alerts is installed are not recognized until the computer is restarted. Clicking the Cancel button in the Printer Status and Alerts window will not always cancel a job. This button sends a cancel request to the printer, but if the job has already been processed, it might not be possible to cancel the job (this is commonly the case with smaller jobs). When using Printer Status and Alerts with Microsoft printer sharing, the following items apply: • The Microsoft patch “Vredir” is required if you want to use Printer Status and Alerts on a Windows 98 or Windows Me computer for a printer that has been shared directly from a computer with Windows NT 4.0, Windows 2000, or Windows XP installed. Failure to install the patch could cause an intermittent blue screen to appear on the client computer. 26 2 Software Description Software Technical Reference • For Microsoft shared products, the host system must have either Printer Status and Alerts or the HP Driver Autoconfiguration option from the HP installer on the computer. Load Printer Status and Alerts on the computer sharing the printer before loading Printer Status and Alerts on the client computer. • For Windows 95, Windows 98, and Windows Me client computers that have Printer Status and Alerts installed, installing a printer using the Point and Print method will not activate Printer Status and Alerts. When the Printer Status and Alerts feature is installed, a status icon in the form of a printer is included in the Windows system tray in the lower-right corner of the screen. The printer icon remains unchanged until you send a print job to the HP LaserJet product. When you send a print job, the icon changes to alert you to the status of the print job. Eight icons exist in this feature. The eight icons in the following illustration show current job status. Neither the Receiving nor the Waiting icon ever shows up in the Systray. When the print job is in a receiving or waiting state, the Printing icon appears in the Systray. The icons behave differently, depending on whether the printer is connected through a direct connection (USB or parallel) or through a network. Figure 6. Printer Status and Alerts icons Double-click the status icon to open the Printer Status and Alerts window, shown in the following illustration. Note The appearance on the screen varies according to the HP LaserJet product and its configuration. The Printer Status and Alerts window consists of two panes. The left pane shows icons for the available products, an icon for each current print job in progress, and an Options icon. The right pane provides information based on what is selected in the left pane. The buttons at the top can be used to perform the following functions: z z z z z Left arrow: Return to the previous pane. Right arrow: Go to the next pane. Circular arrows: Refresh the pane. Home: Return to the device status. Clock face: Show print job history. Software Technical Reference Technology background information 27 Click a product icon in the left pane to view information about the product and supplies or to view a history of recent print jobs. The following product information is available: z z z z Device Status indicates the current status of the HP LaserJet product. Supplies shows information about the percentage of print-cartridge life remaining. Media provides information about paper-handling devices and the status of each device. For example, this section of the window shows the level of media present in each input device, as well as the status of output devices. This section also provides information about the type and size of media loaded in each input device. Capabilities provides information about such things as installed trays, paper-handling devices, and disk storage. Also listed are DIMM slots, the printer serial number, and the firmware date code. Click a print job icon to see information about the progress and status of the print job. Click the Options icon to select options for configuring popup status windows that contain document alerts and to set the refresh rate for showing printer status information. Figure 7. Refresh Rate option Note The appearance of the screen varies according to the HP LaserJet product and its configuration. There are six settings for the refresh rate. The default setting is halfway between Less Often and More Often. The Less Often setting specifies the least frequent update intervals, which have minimal impact on network traffic. The More Often setting updates the status more frequently, but also has the most impact on traffic. The Never setting disables the job-status monitoring mechanism for the selected printer. If the refresh rate for a given printer is set to Never, then subsequent jobs sent to that printer will not appear in the Printer Status and Alerts window. If the Never setting is selected when the scope control is set to All Printers, then all job-status monitoring will be disabled. However, even when job-status monitoring is disabled, you can still open the status window and view the product status panels. Changes to the refresh rate settings affect any subsequent jobs submitted to the affected printer. Existing jobs that are already being processed have a fixed refresh rate which was determined (according to the setting in the Refresh Rate panel) when the job was submitted. 28 2 Software Description Software Technical Reference Refresh-rate intervals for direct-connect printers are: Less Often setting: 5 minutes z One setting to the right of Less Often: 2 minutes z Two settings to the right of Less Often: 1 minute z Three settings to the right of Less Often: 30 seconds z More Often setting: 10 seconds On network printers, the refresh-rate interval changes, depending on the stage of the print job. z The Alerts options panel has controls to determine when the Printer Status and Alerts window automatically appears for each printer that has an icon in the left pane. The dropdown menu provides a list of available printers for which to make the selection. An option for all printers is included as the default selection. Each of the three, four, or five available selections, depending on the printer connection type, causes the Printer Status and Alerts window to automatically appear when that alert condition arises. The availability of each alert option and the default selection varies depending on connection type. The following table shows the default state of the alerts panel as it relates to connection type. Table 2. Default alerts selection state for connection type Connection type Alerts (first two options) Printer warning condition Toner low Printer error condition All printers Selected and activated1 Selected and activated Selected and activated Selected and activated Direct connect Selected and activated Selected and activated Selected and activated Selected and activated Network Selected and activated Selected and activated Unselected and grayed out Selected and activated 1 "Activated" means that the option is available; "selected" means that the option is selected by default. Printers that are involved with at least one active print job are queried for job status periodically according to the Status Check Rate setting. If an error or a warning condition is detected, the Printer Status and Alerts window will automatically appear according to the Alerts options. Software Technical Reference Technology background information 29 Note Depending upon the options you select, information in the status window changes for each job printed, each job completed, and each warning condition detected. Figure 8. Printer Status and Alerts options Note The appearance of the screen varies according to the HP LaserJet product and its configuration. Remote firmware update The HP LaserJet product features a remote firmware update capability. The method for downloading remote firmware updates from the http://www.hp.com/support/ lj5500_firmware Web site is similar to that used to download the latest printing-system software and printer drivers. The process for remotely upgrading printer firmware involves three steps: Step 1 Determine the current level of firmware installed on the HP Color LaserJet 5500 printer. Step 2 Go to the http://www.hp.com/support/lj5500_firmware Web site and download the latest firmware. Step 3 Download the new firmware to the product. Determining the current level of firmware To determine the current level of firmware, view the configuration page. Step 1 Press the select button (the one with the check mark) to open the menus. Step 2 Press the up and down buttons to scroll to INFORMATION. Step 3 Press the select button. Step 4 Press the up and down buttons to scroll to PRINT CONFIGURATION. Step 5 Press the select button to print the configuration page. 30 2 Software Description Software Technical Reference Step 6 Look in the configuration page section marked "Printer Information" for the Firmware Datecode. The firmware date code will look something like this: 03/14/2002 03.002.0 Downloading the new firmware from the HP Web site The remote firmware update (.RFU) file and an associated readme file are packaged together as a self-extracting .EXE file. For detailed instructions about how to download the .EXE file, go to the following URL: http://www.hp.com/support/lj5500_firmware The .EXE file consists of a readme file and the .RFU file. Downloading the new firmware to the product You can send an .RFU update to a printer as long as the printer is in “ready” state; the printer will wait for all input/output (I/O) channels to become idle before performing the update. Note If the firmware update involves a change in the format of nonvolatile random-access memory (NVRAM), any menu settings changed from the default settings will return to default settings, and must be changed again if you want settings different from the defaults. Examples of settings affected in this way are tray types, default symbol sets, and HP Web Access alerts. The elapsed time for an update depends on the I/O transfer time, as well as the time that it takes for the printer to reinitialize. The I/O transfer time depends on a number of things, including the speed of the host computer sending the update, the I/O method (Fast InfraRed Connect [FIR], parallel, or network). The reinitialization time will depend on the specific hardware configuration of the printer, such as the number of EIO devices installed, the presence of external paper- handling devices, and the amount of memory installed. CAUTION If a remote firmware update is interrupted before the firmware is downloaded, the firmware file must be resent. If the update is interrupted during the actual upgrade process, the firmware must be resent over a parallel port connection. Finally, any print jobs ahead of the .RFU job in the queue will be printed before the update is processed. Note The printer automatically power cycles after processing the update. Use one of the following methods to update your printer. Remote firmware update through a local Windows port Windows 95, Windows 98, and Windows Me If the printer is connected through a local port (USB or parallel), then the .RFU file can be sent directly to the printer with a COPY command from a command prompt or MS-DOS window. At the command prompt, follow the steps below for your operating system. From a command prompt or MS-DOS window type the following command: Mode lpt1:,,p Then press ENTER on the keyboard. Software Technical Reference Technology background information 31 Note If the printer is attached to a parallel port other than LPT1, then substitute the proper LPT port number in the Mode command. The response you receive should be similar to these examples: > LPT1 Not Rerouted > Infinite retry on parallel printer time-out Windows 95, 98, Me, NT 4.0, 2000, and XP The .RFU file can be sent directly to the printer with a COPY command from a command prompt or MS-DOS window: copy /b FILENAME PORTNAME where FILENAME is the name of the .RFU file and PORTNAME is the name of the appropriate printer port (such as LPT 1). Remote firmware update through a Windows network If the printer is shared on a Windows network, then the following command can be issued from a command prompt or MS-DOS (R) window: copy /b FILENAME \\<COMPUTERNAME>\<SHARENAME> where FILENAME is the name of the .RFU file, <COMPUTERNAME> is the name of the computer from which the printer is being shared, and <SHARENAME> is the printer share name (do not type the angle brackets). The message ONE FILE COPIED SUCCESSFULLY appears on the computer screen. Remote firmware update for UNIX systems Any method that delivers the .RFU file to the printer will work, including: $cp /home/yourmachine/FILENAME/dev/parallel where /home/yourmachine/FILENAME contains the .RFU file. Remote firmware update using FTP on a direct network connection If your HP LaserJet product uses a direct network connection, you can use file transfer protocol (FTP) to update your HP LaserJet firmware. Complete the following steps. Step 1 Note Take note of the TCP/IP address on the EIO JetDirect page (this is the second page of the Configuration Page printout. To print a configuration page, see “Determining the current level of firmware”). Before connecting to the printer, make sure that the printer is not in PowerSave Mode. Also make sure that any error messages are cleared from the control-panel display. Step 2 Open a MS-DOS command window on your computer. Step 3 Type FTP <TCP/IP PRINTER ADDRESS> (for example, if the TCP/IP address is 192.168.0.90, type FTP 192.168.0.90). Step 4 Press ENTER on the keyboard. Step 5 When prompted for user name and password, press ENTER for each. 32 2 Software Description Software Technical Reference Step 6 Type BIN at the > prompt. Step 7 Press ENTER. Step 8 Type: put <path> where <path> is the location where the .RFU file was downloaded from the Web. For example, type: PUT C:\CLJ5500\CLJ5500FW.RFU and then press ENTER. The download process begins and the firmware is updated on the printer. This can take about five minutes. Let the process finish without further interaction with the printer or computer. The printer automatically power cycles off and on again to activate the update. Remote firmware update using FTP and a browser Step 1 Step 2 Open a browser window. In the address line of the browser, type (without the arrow brackets [< >]): ftp://<IPaddress> where "<IPaddress>" is the TCP/IP address of your printer. Step 3 Open a Windows Explorer window and locate the .rfu file for your printer. Step 4 Drag and drop the .RFU file onto the PORT1 icon in the browser window. Using HP Web JetAdmin to download the firmware to the product This procedure requires that HP Web JetAdmin version 6.5 or later be installed. Complete the following steps to update a single printer through HP Web JetAdmin after downloading the .RFU file from the HP Web site. Step 1 Start HP Web JetAdmin. Step 2 Type the TCP/IP address or IP hostname of the printer in the Quick Device Find field, and then click Go. The printer Status window appears. Step 3 Locate the Update button. You might need to click the right arrow on the toolbar to locate this button. Step 4 Click Update. Step 5 When prompted for the type of update to perform, click Update Printers, and then click Continue. Step 6 Under Upload new firmware image:, click Browse to locate the .RFU file you downloaded from the http://www.hp.com/support/ lj5500_firmware Web site, depending on the product. Step 7 Click Upload to move the .RFU file from your hard drive to the HP Web JetAdmin server. Step 8 Refresh the browser. Step 9 Select the .RFU file from the Select new firmware version: drop-down menu. Step 10 Click Update Firmware. HP Web JetAdmin sends the selected .RFU file to the printer. Also, HP Web JetAdmin 6.5 can be used to perform multiple or unattended installations. Software Technical Reference Technology background information 33 Step 1 Start HP Web JetAdmin. Step 2 Create a device group. A simple way to do this is: a. Click Devices on the 1. Choose: drop-down menu. b. Click Device Model from the 2. Filter: drop-down menu. c. In the 3. Criteria (Optional): field, type your model number (for example, "5500" [without quotation marks]). d. Click Go. Step 3 In the Device List, select the printers you want to include in the group, and then click Create Group. Step 4 When prompted, type a name for the new device group, and then click OK. Step 5 Click Update. Step 6 When prompted for the type of update to perform, click Update Printers, and then click Continue. Step 7 From the list of HP Devices, select the printers to be updated, or click Select All. Step 8 Click Update to install the new firmware. Printer messages during firmware upgrade The printer shows three messages during a normal update process: Table 3. Update messages Printer message Explanation RECEIVING UPGRADE This message appears from the time the printer recognizes the beginning of an .RFU update until the time the printer has verified the validity and integrity of the .RFU update. UPGRADING PRINTER This message appears while the printer is actually reprogramming the firmware. WAIT FOR PRINTER TO REINITIALIZE This message appears from the time the printer has finished reprogramming the DIMM until the printer reinitializes. Note To verify that the firmware update succeeded, print a new configuration page from the product control panel and verify that the firmware datecode shown on the configuration page has changed. Note All HP LaserJet products leave the factory with the latest available firmware version installed. If a remote firmware update fails, the .RFU file must be sent over a parallel port connection. 34 2 Software Description Software Technical Reference E-mail command and response The HP LaserJet product can send e-mail messages directly. However, you must configure e-mail information to initiate this capability. One use for this feature is to send diagnostic information to solve a printer problem. An e-mail sent to the printer requests configuration information. The printer automatically sends that information back to the service provider. In many cases, the problem can be identified quickly and solved remotely. For more information about e-mail command and response, see the HP Embedded Web Server for HP LaserJet Printers guide. To configure your product to send e-mails, follow these steps: Step 1 Take note of your product’s TCP/IP address on the EIO X JetDirect page (this is the second page of the Configuration Page printout. To print a configuration page, see “Determining the current level of firmware”.) Step 2 Launch your Web browser. Step 3 In the Address: or Go to: field, type the TCP/IP address assigned to the product (for example, 192.168.0.20) or the host name (for example, http:// myprinter). The HP Web Access home page appears. Step 4 From the top of the HP Web Access screen, click Device. Step 5 On the navigational bar on the left, click Alerts. Step 6 Under Notification Recipients, type your e-mail address (for example, "[email protected]".) Step 7 Click Apply. Step 8 Under Select Events, click Media Path. Step 9 Select the List1 check box next to CLOSE DRAWERS/DOORS/COVERS. Step 10 Click Apply. A screen stating that your selections have been accepted should appear. Click OK. Step 11 In the SMTP Server: field under Outgoing Mail, type the TCP/IP address for the Simple Mail Transfer Protocol (SMTP) server (for example, 192.168.0.201). Step 12 In the Domain Name: field under Outgoing Mail, type the domain name. Step 13 Click Apply. Step 14 Click Security. Step 15 Under Security, select the Outgoing Mail check box. Step 16 Click Apply. Step 17 To test the configuration, open the top cover of the product, then go to your computer and verify that you have received an e-mail message from the product. Euro character The euro is the name for the currency of the European Union (EU). Use of this unit was launched on January 1, 1999. The euro has changed the way business is conducted in Europe and has affected every company and industry in the world. It is vital that companies understand and prepare for the changes the euro brings. Software Technical Reference Technology background information 35 This HP LaserJet product includes euro characters for each of the internal fonts. The printer can print the euro character in the Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP operating systems. Hewlett-Packard is committed to maximizing document portability through supporting and promoting eurosymbol standards. International Color Consortium profiles HP provides cyan-magenta-yellow-black (CMYK) (HP5500C.ICM) and sustained redgreen-blue (sRGB) (HP5500R.ICM) International Color Consortium (ICC) profiles with its HP Color LaserJet 5500 printers. The CMYK profile can only be used with the PostScript driver; the sRGB profile can be used with any of the HP Color LaserJet 5500 drivers. The profiles are available on the HP Web site at the following URL: (http://www.hp.com/support/lj5500) ICC profiles describe the way color will be interpreted in the default CMYK and RGB modes. The sRGB profile matches the default RGB mode (sRGB), which is enabled with the Screen Match or Automatic Color Smart II setting in either the PCL or PostScript driver. The CMYK profile is based on the default mode, which is a Specifications for Web Offset Publications (SWOP) simulation with a CMYK Inkset setting of FAST in the PostScript driver. These profiles can be used for color conversions in a color-managed workflow. PANTONE (R)* color profiles Automatic PANTONE (R)* Calibration is the default setting for HP Color LaserJet printers. This feature automatically converts PANTONE (R)* colors to optimal color values for the printer by recognizing the PANTONE (R)* color name or number in the data stream sent to the printer. The feature is activated when printing colors that were chosen using the PANTONE (R)* Color picker in supported graphics applications. Applications known to generate PostScript files with graphic objects preserving the PANTONE (R)* name are listed below: z z z z z z z Adobe Illustrator Adobe Photoshop (R) Adobe PageMaker Adobe InDesign CorelDRAW (TM) Macromedia Freehand QuarkXPress Some applications substitute CMYK values to the printer if they cannot provide PANTONE (R)* names. If your application does not pass the PANTONE (R)* names to the printer, the application will substitute default CMYK values to be printed for each color. In this case, the accuracy of color matching will depend on the ink emulation selected FAST, SWOP, Euro standard, or DIC (Dainippon). If your application does not pass the PANTONE (R)* names to the printer, the custom CMYK values created by PANTONE (R)* for this printer are available in the manual PANTONE (R)* palettes. PANTONE (R)* Application Palettes might be available on the Web at the following URL: http://www.hp.com/support/lj5500 36 2 Software Description Software Technical Reference Vector graphics such as company logos created in PANTONE (R)* Application Palettes can be imported into Microsoft Word, PowerPoint, or other MS Office applications. To do this, the color application must create an Encapsulated PostScript (EPS) file of the image for insertion as a file into the Office document (using the insert file function). Note Cutting and pasting from the clipboard does not work. These tasks do not preserve the PANTONE (R)* name or the CMYK palette value. Printing-system components Printing system and installer CD browser for Windows systems In previous versions of the printing-system software, the installer was started by locating and running the SETUP.EXE file. For the Microsoft Windows environment (Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP), the HP LaserJet software CD-ROM provides an interactive CD browser that you can use not only to install the printer drivers and related components, but also to gain access to online product registration, user documentation, a customization utility, Adobe Acrobat Reader software, and optional HP software. Software Technical Reference Printing-system components 37 The following illustration shows the main screen of the printing system software CD browser, which appears when you insert the printing software CD-ROM in your CDROM drive. If the screen does not appear when you insert the CD-ROM, click Start, click Run, click Browse..., navigate to the root directory of the CD-ROM, and then double-click the SETUP.EXE file to start the browser. Figure 9. Installation CD browser main screen The product software CD browser contains the following options for the HP LaserJet product. The text that follows each option listed below is approximately the same text that appears when you put the cursor on the option button. Note The options on your product might vary from the illustration. Install Printer - This wizard guides you through the installation of your HP LaserJet printing system. You are given the choice of performing a Typical Installation or a Custom Installation. If you select Typical Installation, only the necessary software will be installed. If you select Custom Installation, you can select the components you want to install. Register Product - This option can be used to register your HP LaserJet product now and to receive the following information at no cost: • notification of driver updates • technical support updates • news about emerging technologies View Documentation - This option can be used to view the HP LaserJet product documentation. The following document options are available: • Readme 38 2 Software Description Software Technical Reference • • • • Note User Guide HP Jetdirect Guide hp FIR Guide (the HP Fast Infrared Receiver Guide) Release Notes For systems that do not have Adobe Acrobat Reader 4.0 (or later) installed, you will be given the option to download that software. Clicking any of the links to documentation that is provided in the Adobe Acrobat PDF file format opens a dialog box from which you can install Adobe Acrobat Reader software from the HP LaserJet software CD browser. — This utility can be used to create a custom software installer for the HP LaserJet product that can then be copied to other media, such as a local hard drive or a network drive. Optional Software — To increase productivity and get the most out of your HP LaserJet product, view a list of optional software available for installation. The following options for the HP Color LaserJet 5500 product are available as Web links: • HP Web Jetadmin • Color Matching Information Installer features The common installer is designed to provide a simple and consistent installation method for the product line. The common installer is available for the Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP operating systems. The common installer offers the following features: • The HP Color LaserJet 5500 software CD-ROM features a CD browser. See "CD browser for Windows systems." • Acrobat Reader 5.0 is automatically installed (Acrobat Reader 4.05 is installed for languages that read from right to left). • The installer is Web-enabled, providing access to the HP Web site for the latest software components and drivers. • Network connection is integrated so that you can install drivers and connect to a network printer in a single process. • The selection dialog box sets the operating-system language as the default language (for Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP only). You can use the installer to select any of the languages on the HP LaserJet software CD. • The installer includes the HP LaserJet Uninstaller Utility. • Product registration is available using the Web and e-mail. • The Customization Utility is available on the CD browser. All of the Windows system components are installed by using the HP LaserJet printing-system installer. The installer automatically senses your language of choice and your operating system. It offers selections for each printer model. You can select the type of installation you prefer: Typical Installation or Custom Installation. The installer compares the versions of the software components on the HP LaserJet software CD-ROM to those on the HP Web site. If newer versions are on the HP Web site, the installer downloads them. Software Technical Reference Printing-system components 39 Installable components This section provides information about the various installable components available either with the HP LaserJet software CD-ROM or from the HP Web site. Printer drivers HP supports the use of older drivers with new printers. Because earlier HP LaserJet printers might have different versions of the PCL language, new drivers are not supported with earlier printers. The drivers associated with each printer use the version of PCL language that is installed in the printer. The printing system for the HP LaserJet product includes the following printer drivers. PCL 5c, PCL 6, and PS drivers The PCL 5c, PCL 6, and PS drivers are included with the HP LaserJet software CD-ROM. The PCL 5c and PCL 6 drivers feature a graphical user interface that has a shared look and feel. Note PCL 5c is not supported in Asian languages. If a Typical Installation is chosen during installation of the printing system software, the PCL 6 driver is set as the default driver. Windows 95, 98, Me, NT 4.0, 2000, and XP driver versions PCL 5c and PCL 6 support for Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP operating systems is provided by using the HP LaserJet 5500 printer drivers for the HP LaserJet 5500 product. The HP LaserJet 5500 PS printer description (PPD) provides PS support for the HP LaserJet 5500 product. Printer driver version numbers can be found by clicking the HP logo found in the lower-left corner of the following HP PCL 5c and PCL 6 printer driver tabs: • • • • • • • • Configure NT Forms Finishing Effects Paper Destination Color Basics Printer driver version numbers can be found on the PS driver by clicking on HP Color LaserJet 5500 PS at the top of the Advanced tab, and then clicking on About PostScript Printer Driver. For the latest printer driver version numbers, go to the following URL: http://www.hp.com/support/lj5500_software 40 2 Software Description Software Technical Reference Macintosh and Macintosh-compatible system driver versions The HP LaserJet printing solution for Macintosh is composed of the Apple LaserWriter driver, which is provided with the operating system, and HP-created PPD files. The driver uses these files to determine the features and PS commands that the printer supports. Bidirectional support in AppleTalk and universal serial bus (USB) connections allows autoconfiguration of the software. The installable components are: • • • • • • • • • the HP LaserJet Installer for Mac OS 8 and Mac OS 9. the HP LaserJet Installer for Mac OS X. the HP LaserJet Screen Fonts Installer. SYSTEM/EXTENSIONS/PRINTER DESCRIPTIONS (for Mac OS 8 and Mac OS 9). LIBRARY/PRINTERS/PPDS/CONTENTS/RESOURCES/LANGUAGE.LPROJ (for Mac OS X). the HP LaserJet Utility, an HP printer utility installed in the HP LaserJet folder of Macintosh operating systems 8 and 9. It provides configuration and management support for PS and PCL printers. online Help, an HTML-based printer and utility help that can be viewed through a browser or the Macintosh OS Help Center. the HP Auto Setup Utility, installed in the Startup Items folder of Mac OS 8 and later versions. It provides assistance to set up the new printer, then moves itself to Trash. installation notes. Additional driver availability Additional drivers are available from your Hewlett-Packard distributor or from the http:/ /www.hp.com/support/lj5500_software Web site. These drivers are: • OS/2 PCL 5c, OS/2 PS, and OS/2 PCL 6 printer drivers. The OS/2 drivers are available from IBM and are packaged with OS/2. • UNIX model scripts. Go to http://www.hp.com/support/net_printing, then select hp printer installation software for further information about UNIX drivers. • Linux drivers. Go to http://www.hp.com/go/linux for further information about Linux drivers for HP LaserJet products, or to http://hp.sourceforge.net (HP Linux support home page). Macintosh components • HP LaserJet PPDs for past projects • ColorSync profiles • Screen fonts Software Technical Reference Printing-system components 41 Additional productivity tools HP Web Registration You can use this component to register your HP LaserJet product on the HP Web site or through e-mail. After you have successfully installed the software, the installer prompts you to register your HP LaserJet product. Also, you can gain access to HP Web Registration from the HP LaserJet software CD browser by clicking Register Product. You can choose to complete the online registration at that time or later. If you want to register your product later, click Register Product from the HP LaserJet 5500 program group when you decide to complete your registration. Optional software The HP LaserJet software CD browser provides links to download and install HP Web JetAdmin as optional software. HP Web JetAdmin Use HP Web JetAdmin to manage HP Jetdirect connected printers within your intranet by using a browser. HP Web JetAdmin is a browser-based management tool and should be installed only on the network administrator’s computer. When installed on a host server, any client can use HP Web JetAdmin through a supported Web browser (such as Microsoft Internet Explorer 4.x or later, or Netscape Navigator 4.x or later) by browsing to the HP Web JetAdmin host. HP Web JetAdmin 6.2 and later have the following features: • • • • • • • • task-oriented user interface, providing configurable views for network managers customizable user profiles that can be customized to let network administrators include only the function viewed or used routing of instant e-mail notification of hardware failure, low supplies, and other printer problems to different people remote installation and management from anywhere by using only a standard Web browser advanced automatic discovery of peripherals on the network without manually typing information about each printer into a database simple integration into enterprise-management packages capacity to find peripherals based on parameters such as Internet Protocol (IP) address, color capability, and model name capacity to organize peripherals into logical groups, with an option that provides virtual office maps for easy navigation HP WebJet Admin can be used for access to HP Web Access (the embedded Web server), ordering supplies, and remote firmware update. The HP LaserJet software CD browser provides a link to the HP Web site (http://www.hp.com/go/webjetadmin) to download the latest version of the HP Web JetAdmin software. Click Optional Software from the CD-ROM browser, and then click . HP Web JetAdmin is available for the following network operating environments: • 42 2 Software Description Microsoft Windows 2000 Software Technical Reference • • • Software Technical Reference Microsoft Windows NT 4.0 Red Hat Linux 7.1 SuSE Linux 7.1 Printing-system components 43 44 2 Software Description Software Technical Reference 3 Driver features Introduction This chapter describes the features of the PCL 5c and PCL 6 printing system drivers in one section, and the Windows PS driver in another. The third section describes the structure and availability of the printing-system software CD-ROM. PCL 5c and PCL 6 driver features This section describes the options available on each tab of the PCL 6 and PCL 5c driver interfaces. Help system The HP LaserJet PCL 6 and PCL 5c drivers include a full-featured Help system to provide assistance with printing and configuration options. What's this? Help In Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP, "What's this?" Help is supported. You can gain access to "What's this?" Help messages in any of the following ways: • Right-click a control and click What's this?, and a pop-up Help window appears. • Click the ? button at the upper-right corner of the frame, next to the X, to change the cursor to an arrow with a question mark. Use this special cursor to select a control, and the pop-up Help window for that feature appears. • Press the F1 key, and the Help window for the currently selected control appears. Context-sensitive Help Press the Help button on a driver tab or in a dialog box, and context-sensitive Help appears. Software Technical Reference Introduction 45 Constraint messages Constraint messages are unsolicited messages that appear in response to specific actions you take. These messages alert you to selections that are illogical or impossible given the capabilities of the product or the current settings of other controls. For example, if you click Print on Both Sides and then change the paper type to transparencies, a message appears asking you to resolve this conflict. Figure 10. A typical constraint message with an OK button Whenever a constraint message appears with OK or Cancel buttons, the interpretation of the buttons is as follows: • Clicking OK accepts the change that was just made, and the driver then resets the conflicting control to a setting that is compatible with the new value. • Clicking Cancel rejects the change that was just made, setting the control back to its previous value. 46 3 Driver features Software Technical Reference Bubble Help Bubble Help features a graphical icon resembling a cartoon speech bubble with a small i in it, representing the international symbol for information. The following illustration shows Bubble Help icons on a driver tab. Figure 11. A property page with Bubble Help icons The bubble typically appears next to a disabled control, although it can also accompany an enabled control if there is an important note concerning its use. Moving the pointer over the bubble changes the arrow to a gloved hand, which indicates that the area underneath the pointer is selectable. When the bubble is selected by using either the mouse or the keyboard, a message box appears with a brief explanation about why the control is disabled and what can be done to enable it. If the control is not disabled, the message is a tip or a precaution to be aware of when using that particular feature. The following table lists Bubble Help messages and the conditions that cause them to appear. Software Technical Reference PCL 5c and PCL 6 driver features 47 Table 4. Bubble Help messages Condition Effect Message Finishing tab: Pages per Sheet is greater than 1 Finishing tab: Booklet Printing is not available if Print on Both Sides check box is selected. To use this feature, set "Pages per Sheet" to 1 (see "Finishing" tab). Finishing tab: Pages per Sheet is greater than 1 Effects tab: To use this feature, set "Pages per Print Document On is not available. Sheet" to 1 (see "Finishing" tab ). Finishing tab: Pages per Sheet is greater than 1 Effects tab: % of Normal Size is not available. Finishing tab: Finishing tab: Booklet Printing setting is any Pages per Sheet is not available. setting except Off. To use this feature, set "Pages per Sheet" to 1 (see "Finishing" tab ). To use this feature, set the "Booklet Printing" option to Off (see "Finishing" tab). Finishing tab: Effects tab: To use this feature, set the "Booklet Booklet Printing setting is any Print Document On is not available. Printing" option to Off (see "Finishing" setting except Off. tab). Finishing tab: Effects tab: Booklet Printing setting is any % of Normal Size is not available. setting except Off. To use this feature, set the "Booklet Printing" option to Off (see "Finishing" tab). Effects tab: Effects tab: The Print Document On check % of Normal Size is not available. box is selected. To use this feature, turn off the "Print Document On:" option (see "Effects" tab). Effects tab: Paper tab: The Print Document On check a Help bubble points to Size Is. box is selected. Although your document will be formatted for the paper size indicated, it will be printed on the paper size specified on the "Effects" tab. Effects tab: Finishing tab: The Print Document On check Pages per Sheet is not available. box is selected. To use this feature, turn off the "Print Document On:" option (see "Effects" tab). Effects tab: Effects tab: To use this feature, set "% of Normal The % of Normal Size setting is Print Document On is not available. Size" to 100 (see "Effects" tab ). any value except 100%. Effects tab: Finishing tab: The % of Normal Size setting is Booklet Printing is not available. any value except 100%. To use this feature, set "% of Normal Size" to 100 (see "Effects" tab ). Effects tab: Finishing tab: The % of Normal Size setting is Pages per Sheet is not available. any value except 100%. To use this feature, set "% of Normal Size" to 100 (see "Effects" tab ). Paper tab: Finishing tab: Type Is setting is Transparency, Bubble Help points to the Print on Labels, or Envelope. Both Sides check box. This feature is not available with the currently selected paper type. (see Paper tab ) Paper tab: The Size Is setting is for any envelope. Finishing tab: Bubble Help points to the Print on Both Sides check box. This feature is not available with the currently selected paper size (see "Paper" tab). Paper tab: The Size Is setting is for anything except Letter, Legal, or A4. Finishing tab: Bubble Help points to the Booklet Printing drop-down menu, which is not available. To use this feature, set the paper size to Letter, Legal or A4 (see "Paper" tab). 48 3 Driver features Software Technical Reference Table 4. Bubble Help messages (continued) Condition Effect Message Paper tab: Paper tab: In order to use this feature, choose a The Source Is tray in the Other Bubble Help points to Type Is drop- source tray different from the first Pages mini-tab is the same as down menu. page. the one defined in the First Page mini-tab. Effects tab: Watermarks exceed 30. Effects tab: You cannot add a new watermark Bubble Help points to Watermarks. because the list is full. You may edit existing watermarks, or you may delete unused ones to make more room. Bidirectional communication is not installed. Configure tab: The configuration settings cannot be Update Now button is not available. updated automatically because bi-directional communication is not available. Finishing tab: Basics tab: The Print on Both Sides check Bubble Help points to the Copies box is selected, and the Allow option. Manual Duplexing check box (on the Configure tab) is also selected. Software Technical Reference Only 1 copy allowed per job for manually duplexed printing. To change, first disable "Print On Both Sides" option. PCL 5c and PCL 6 driver features 49 Finishing tab features The Finishing tab is the default tab that appears when you click Document Defaults... (or Printing Preferences..., depending on your operating system) for the driver or for a software application. Figure 12. The default appearance of the Finishing tab The options in the Print Quality group box might vary, depending on your HP LaserJet product. The Finishing tab contains a document preview image and three group boxes: Quick Sets Document Options Print Quality z z z Document preview image The preview image is a line-drawn image of a page that represents graphics and text. For color printers the bitmap contents appear in color, while for monochrome printers the contents appear in tones of gray. The image is always oriented so that the contents of the page are right side up. The preview image appears in the upper right corner of all properties tabs except for the Configure tab. 50 3 Driver features Software Technical Reference Switching between tabs does not change the location or appearance of the preview image. When you move the mouse over the preview image, the mouse cursor will change from an arrow to a gloved hand. You can toggle between portrait and landscape page orientation by clicking on the image. The light-yellow dimensions label that appears below the preview image reflects the selected page size. The horizontal dimension is always first, so the order of the numbers will reverse when the orientation changes. Click on the label to toggle between English and metric units. Quick Sets This group box is present on each tab for the driver. Quick sets are either preset or user-defined printing specifications (such as paper size, pages per sheet, and so on). Defaults The default setting is Defaults. Other settings are User’s Manual and Untitled. When Defaults is selected, nearly all settings are restored to the combination that existed after the driver was installed. However, if the attribute combinations associated with watermark definitions, custom paper sizes, or the User’s Manual quick set have been changed or deleted, the original settings are not restored. The Defaults setting appears automatically if no other driver settings have been changed since the driver was installed, or if all driver settings match the original settings. Otherwise, the setting in the Quick Sets menu will be the same label that appeared when you last closed the printing Properties dialog box by clicking OK. Software Technical Reference PCL 5c and PCL 6 driver features 51 User’s Manual This setting provides a quick set for optimal printing of the use guide (User’s Manual), as shown in the following illustration. Figure 13. Finishing tab - User’s Manual Quick Set Custom Quick Sets When you change any of the default settings on the Finishing tab or any of the other tabs, the name in the Quick Set drop-down menu dynamically changes to Untitled. If you want to save this configuration as a quick set, highlight the word Untitled, type the name you want for your new quick set, and click Save. Quick sets are saved in the system registry. To delete a quick set, select it from the dropdown menu and click Delete. You can store a maximum of ten user-defined Quick Sets on a particular system. If you attempt to save too many, a message box appears that reads, "There are too many Quick Sets defined. Please delete some before adding new ones." Document Options Print on Both Sides option The default setting for the Print on Both Sides option is OFF (not selected). Print on Both Sides is not available when: 52 3 Driver features Software Technical Reference • Type is on the Paper tab is set to Transparency, Cardstock, or Labels. • Size is is anything except Letter, Legal, A3, A4, A5, B4, B5 (Japanese Industry Standard, or JIS), Executive, 11 x 17, or custom sizes greater than or equal to 148 mm by 210 mm (5.8 inches by 8.3 inches) and less than or equal to 312 mm by 470 mm (12.3 inches by 18.5 inches). When Paper Size is set to Letter, Legal, or A4, clicking Print on Both Sides makes the Flip Pages Up and Booklet Printing options available. The default for both of these options is OFF. Flip Pages Up The Flip Pages Up check box, enabled only when Print on Both Sides is selected, is used to specify the duplex-binding option. The following table demonstrates the results of selecting this box, depending upon the paper orientation selected on the Basics tab. Table 5. Page orientation Orientation (Basics tab) Flip Pages Up selected Flip Pages Up not selected Portrait Short-edge binding Long-edge binding Landscape Long-edge binding Short-edge binding When Print on Both Sides is selected, the document preview image changes to show a spiral binding along either the left or the top edge of the page. In addition, a folded-over corner appears in the lower-right portion of the preview image, indicating that printing will occur on the back side. An arrow on the folded-over corner points in the direction that the pages would be flipped if they were bound together. Booklet Printing The Booklet Printing drop-down menu, visible when Print on Both Sides is selected, offers eight choices, two of which are based on the current paper size. The list contains the items like the following examples: • Off • [paper size] (Left Binding) • [paper size] (Right Binding) where [paper size] depends on the paper size set on the Paper tab. The following table shows the appropriate entries in the Booklet Printing drop-down menu for each selected paper size. Software Technical Reference PCL 5c and PCL 6 driver features 53 Table 6. Selected paper size Paper size selected Entries in Booklet Printing Drop-down menu Letter Off Letter (Left Binding) Letter (Right Binding) Legal (Left Binding) Legal (Right Binding) 11 x 17 (Left Binding) 11 x 17 (Right Binding) B4 (JIS) (Left Binding) B4 (JIS) (Right Binding) Legal Off Legal (Left Binding) Legal (Right Binding) A4 Off A4 (Left Binding) A4 (Right Binding) A3 (Left Binding) A3 (Right Binding) B4 (JIS) B4 (JIS) (Left Binding) B4 (JIS) (Right Binding) Booklet printing is disabled when the following paper sizes are selected: Executive, A3, A5, B5, and envelopes and postcards of any size. The Booklet Printing drop-down menu appears only when: • • • • • 54 3 Driver features Print on Both Sides is selected. % of Normal Size (on the Effects tab) is 100. Pages per Sheet is 1. Size Is (on the Paper tab) is set to Letter, Legal, A4, or B4 (JIS). Print Document On (on the Effects tab) is not selected. Software Technical Reference If any except the first of these conditions is not met, a Bubble Help appears next to Booklet Printing to tell you why it is disabled. Activating booklet printing Note The following instructions apply only to PCL drivers. Booklet Printing is supported by the HP PS (PostScript) driver through Windows applications that provide booklet-printing configuration settings. Step 1 Click File, click Print, and then click Properties. Figure 14. Activating booklet printing Step 2 Click the Finishing tab. On the drop-down menu, select Print on Both Sides. Software Technical Reference PCL 5c and PCL 6 driver features 55 Step 3 In the Booklet Printing drop-down menu, select the type of booklet printing you want. The booklet printing type consists of the media size and the location of the binding. For example, Letter (Left binding). Figure 15. Selecting booklet printing type Note The appearance of the screen might vary from product to product. Print Quality settings, for instance, can be "600 dpi", or "Faster Printing", or "Default". Selecting a booklet cover The booklet cover must be the same size as the inside sheets. Step 1 Click File, click Print, and then click Properties. Step 2 Click the Paper tab, and then select the Use different paper for first page check box. Step 3 Click the First Page tab. On the Size is, Source is, and Type is menus, select the size, source, and type settings for your cover. Step 4 Click the Other Pages tab. On the Size is, Source is, and Type is menus, select the size, source, and type settings for the inside sheets of your print job. Step 5 Click the Back Cover tab. The back cover, if there is one, must be the same size as the booklet cover and the inside sheets. The No back cover is the default setting. If your print job has a back cover that uses the same source and type settings you selected in the First Page tab, select Use the first page source. If not, select Use an alternate source, and then select the back-cover settings in the Source is and Type is menus. 56 3 Driver features Software Technical Reference Pages per Sheet The Pages per Sheet drop-down menu provides six settings: 1 (default), 2, 4, 6, 9, and 16. If you type another value into the box (for example, 3), the control will round the value entered to the nearest valid value (in this example, 4). Related controls indented beneath the Pages per Sheet edit box are Print Page Borders and Page Order, which become active when Pages Per Sheet is greater than 1. Print Page Borders sets a line around each page image on a printed sheet to help visually define the borders of each logical page. The Page Order drop-down menu contains four selections: • • • • Right, then Down Down, then Right Left, then Down Down, then Left The preview document image changes to reflect alterations in these settings, as shown by the examples in the following illustration. Figure 16. Page-order preview images 1 2 pages per sheet 2 4 pages per sheet 3 6 pages per sheet 4 9 pages per sheet, with Print Page Borders selected 5 9 pages per sheet, with Down, then Right page order selected 6 16 pages per sheet Print Quality The HP LaserJet printer driver Print Quality group box provides options that control resolution, graphics settings, and font settings. The group box includes the following options: • Default • Custom The Print Quality group box also includes a Details button. Clicking this button opens the dialog box. The Print Quality Details dialog box provides options for various print-quality settings. Software Technical Reference PCL 5c and PCL 6 driver features 57 The following illustration shows default Print Quality Details settings for the HP Color LaserJet 5500 product. The menu on your HP LaserJet product might vary. Figure 17. Print Quality Details dialog box showing HP Color LaserJet Default setting Default For the HP Color LaserJet PCL 6 and PCL 5c drivers, the Default mode contains the following options: • • • • • • • 58 3 Driver features Resolution is 600 dpi Rendering mode is automatic (PCL 5c only) Manually Print on 2nd Side is not selected Scale Patterns (WYSIWYG) is selected Print all Text as Black is not selected Raster Compression is Automatic Send TrueType as Bitmaps is not selected Software Technical Reference Graphics Settings group box The Raster Compression settings under the Graphics Settings group box, available on the PCL 6 driver only, support adaptive compression modes for Joint Photographic Experts Group (JPEG) data. These settings are available: • Automatic: (default). When this setting is used, the printer driver determines and applies the best compression method. • Best Quality: This setting forces the driver to use a compression method that results in no loss of data. • Maximum Compression: Where applicable, this setting requires the printer driver to use JPEG compression. Output Settings group box The Output Settings group box contains controls for selecting resolution and other print-job settings, including pattern scaling, printing all text as black, and manually printing on second side. Resolution The resolution setting for the HP Color LaserJet 5500 is 600 dpi. Manually printing on the second side Use the duplexing unit in the printer to automatically print on two sides of the paper when that option is specified in the job.To achieve the best print quality when printing on the second side of the page, the printer needs to make adjustments to its print modes. These adjustments are automatic when the duplexing unit is used. Media sizes supported by the duplexing unit are Letter, A4, and Legal only. All other media sizes must be duplexed manually. The following media types cannot be automatically duplexed: • • • • Transparencies Labels Heavy Cardstock The following media types have a different print mode when you manually print on the second side: • • • • • • • • • • Software Technical Reference Plain Preprinted Letterhead Prepunched Bond Recycled Colored Light Glossy Glossy film PCL 5c and PCL 6 driver features 59 Heavy and Cardstock media can be manually printed on the second side, but there is no change to the print mode. Transparencies and labels should not be manually printed on the second side. Manually printing on the second side of a page is available when you are using the PCL 6 or PS driver (the PCL 5c driver does not support the feature). Select the Manually Print on 2nd Side check box to print on the second side of the paper for the base HP Color LaserJet model printers. Also select Manually Print on 2nd Side on the other HP LaserJet models for media sizes that are not available when using the automatic duplexing unit, such as card stock, glossy paper, labels, and thick media. To print a multiple-page document, follow these steps: Step 1 Print all even-number pages. Some applications have a selection in the file print window that specifies printing even or odd pages. Step 2 If your finished document has an odd number of pages, add a blank page to the bottom of the stack of even-number pages (behind the last even-number page). Step 3 Select MANUAL FEED as the paper source in your application (often found under page setup) or in the printer driver (click Document Defaults, click the Paper tab, and then select Manual Feed in the Source Is drop-down menu). Step 4 If you are using the PCL 6 driver, click Document Defaults, click the Finishing tab, click Details, and then select the Manually Print on 2nd Side check box. If you are using the PS driver, click Document Defaults, click the Advanced tab, select Manual Print on 2nd Side under Printer Features, and then click On. Manual Print on 2nd Side is not an option for the PCL 5c driver. Step 5 Print all odd number pages by completing the following procedure. When the printer's control panel shows the MANUALLY FEED message, insert the stack of paper (on which the even-number pages have been printed) into tray 1 in one of the following orientations: a. For portrait-orientation, long-edge binding (flips like a book), place the stack with the already-printed side facing up and the top of the pages toward the printer. b. For portrait-orientation, short-edge binding (flips like a note pad), place the stack with the already-printed side facing up and the top of the pages away from the printer. c. For landscape-orientation, long-edge binding (flips like a calendar), place the stack with the already-printed side facing up and the top of the pages to the left. d. For landscape-orientation, short-edge binding (flips like a wide book), place the stack with the already-printed side facing up and the top of the page to the right. (The top page should have page 2 facing downward.) 60 3 Driver features Software Technical Reference Scale Patterns (WYSIWYG) The Scale Patterns (WYSIWYG) feature is implemented to address the moiré effect created when certain applications encounter certain patterns. Use this feature to turn off the pattern scaling. What you lose is WYSIWYG with patterns, but the printed result might look better. The feature works only with programs that use vector hatch patterns. This option is on by default. Print all Text as Black Print all Text as Black is off by default. When selected, this option causes the driver to print all text as black regardless of the original document text color. By design, however, white text remains white, as a fail-safe method of printing reverse typeface against a dark background. This setting does not affect graphic images on the page. Print all Text as Black remains selected only for the current print job. When the current print job is completed, Print all Text as Black is automatically turned off. Use the Print in Grayscale option on the Color tab to print graphic images in gray rather than color. Font Settings group box In the Font Settings group box, the only available option is Send TrueType as Bitmaps, which provides a safety net for applications that cannot easily use TrueType fonts for special graphic purposes, such as shading, rotation, or slanting. Software Technical Reference PCL 5c and PCL 6 driver features 61 Effects tab features The Effects tab is used to create unique paper effects such as scaling and watermarks. Figure 18. Effects tab Print Document On setting Use Print Document On to format the document for one paper size and then print the document on a different paper size, with or without scaling the page image to fit the new paper size. The Print Document On control is disabled by any of the following conditions: • Percent of Normal Size is not 100. • Pages per Sheet (on the Finishing tab) is not 1. When Print Document On is selected, the drop-down menu shows the media sizes on which you can print. The list contains all standard media sizes supported by the selected media source and any custom sizes that you have created (if the currently selected media source is manual, auto, or any tray). When Print Document On is selected, Scale to Fit is automatically selected. 62 3 Driver features Software Technical Reference Scale to Fit option The Scale to Fit option specifies whether each formatted document page image is scaled to fit the target paper size. By default, Scale to Fit is selected when Print Document On is selected. If the setting is turned off, then the document page images will not be scaled, and are instead centered at full size on the target paper. If the document size is larger than the target paper size, then the document image is clipped. If it is smaller, then it is centered within the target paper. The following illustration shows preview images for a document formatted for Legal paper with the Print Document On option selected, and the target size specified as Letter. Figure 19. Preview images - Legal on Letter; Scale to Fit off (left) and on (right) When the size for which the document is formatted (that is, the logical size) differs from the target size, the preview image uses a dashed gray line to show the boundaries of the logical page in relation to the target page size. % of Normal Size option The % of Normal Size option provides a slider bar for scaling the percentage setting. The default setting in the entry box is 100 percent of normal size. Normal size is defined as the paper size selected within the driver or what the driver receives from the application (if the application does not negotiate paper size with the driver). The driver will scale the page by the appropriate factor and send it to the printer. The limits of the range are from 25 percent to 400 percent, and any values outside the range are clipped to those limits as soon as the focus is removed from the control (that is, when the TAB key is pressed or another control is selected). Any change to the scale also changes the page preview, which increases or decreases from the top-left corner of the preview. The slider bar controls the scale directly. The value in the edit box changes as the scroll bar indicator is dragged, and the preview image is updated to the new image scale. Each click on the scroll bar arrows increases or decreases the scale by one percent. Each click on the slider bar affects the scale by 10 percent. You cannot achieve an exact value by dragging the scroll bar indicator at the default Windows resolution; use the scroll bar indicator to approximate the desired value, and then use the scroll bar arrows to refine the value. The following settings disable % of Normal Size: • Print Document On is selected. • Pages per Sheet is not 1. • Booklet Printing is ON. Software Technical Reference PCL 5c and PCL 6 driver features 63 Watermarks Use the Watermarks feature to choose a watermark, create your own custom watermarks (text only), or edit an existing watermark. The following watermarks are preset in the driver: • • • • (none) Confidential Draft SAMPLE The drop-down menu shows alphabetically sorted watermarks that are currently available on the system, plus the string "(none)", which indicates that no watermark is selected. This is the default setting. Any watermark selected from this list appears in the preview image. When First Page Only is selected, the watermark is printed only on the first page of the document. The First Page Only check box is disabled when the current watermark selection is "(none)". Watermarks are applied to logical pages. For example, when Pages per Sheet is set to “4” and First Page Only is turned off, four watermarks appear on the physical page (one on each logical page). Click Edit, and the Watermark Details dialog box appears. Figure 20. Watermark Details dialog box 64 3 Driver features Software Technical Reference The dialog box shows a preview image and provides options for creating a new watermark and controlling the message angle and font attributes. Click OK to accept all changes made in the Watermark Details dialog box. However, clicking Cancel does not cancel all changes. If you make changes to a watermark, and then select a different watermark or click New, all changes made to the previous watermark are saved, and only the current, unsaved changes can be canceled. Current Watermarks The Current Watermarks group box contains a list of available watermarks, both predefined watermarks made available in the driver and any new watermarks you have created. To create a new watermark, click New. The new watermark appears in the Current Watermarks list and in the Watermark Message edit box as “Untitled” until you name it. To name the new watermark, type the selected watermark text in the Watermark Message edit box. To delete a watermark, select the watermark in the Current Watermarks list and click Delete. Note You can have no more that 30 watermarks in the Current Watermarks list at one time. When the limit of 30 watermarks is reached, the New button is disabled, and a Bubble Help appears that explains why the button is disabled and how to enable it. To edit an existing watermark, select the watermark in the Current Watermarks list. If you change the Watermark Message for that watermark, you are, in effect, creating a new watermark. Watermark Message The Watermark Message is also the name that identifies the watermark in the Current Watermarks list, except when more than one watermark has the same message. For example, you might want several different watermarks with the message DRAFT, each with a different font or size. When this occurs, the string is appended with a space, a pound sign, and a number (for example, Draft #2). When a number is added, the number two is used first, but if the resulting name is also in the list, then the number increases until the name is unique. Message Angle Use the controls in the Message Angle group box to print the watermark in a diagonal, horizontal, or angle (custom) orientation to the page's text. The default is Diagonal. All three settings automatically center the watermark string within the page; the selection of a particular setting affects only the angle of the string placement. Diagonal places the text along a line that spans the lower-left to upper-right corners of the page. Font Attributes Use controls in the Font Attributes group box to change the font and the color, shading, size, and style of the font. Name The Name drop-down menu lists TrueType (TM) fonts that are currently installed on the system. Software Technical Reference PCL 5c and PCL 6 driver features 65 Color The color selection combo box provides a fixed, unalterable set of color choices, in palette/color name-pair form, for the watermark. The triplet values for these colors are shown in the following table. Table 7. Watermark color values Setting Gray Red Yellow Green Cyan Blue Magenta Lightest 255 255 255 255 232 232 255 255 232 232 232 255 255 255 232 232 232 255 255 255 Very Light Light Med Light Medium Med Dark Dark Very Dark Darkest 232 224 255 255 224 224 224 255 224 224 255 255 255 224 224 224 224 224 224 255 255 255 192 255 255 192 192 192 255 192 192 255 255 255 192 192 192 192 192 192 255 255 255 160 255 255 160 160 160 255 160 160 255 255 255 160 160 160 160 160 160 255 255 255 128 255 255 128 128 128 255 128 128 255 255 255 128 128 128 128 128 128 255 255 255 96 255 255 96 96 96 255 96 96 255 255 255 96 96 96 96 96 96 255 255 255 64 255 255 64 64 64 255 64 64 255 255 255 64 64 64 64 64 64 255 255 255 32 255 255 32 32 32 255 32 32 255 255 255 32 32 32 32 32 32 255 255 255 0 255 255 0 0 0 255 0 0 255 255 255 0 0 0 0 0 0 255 255 255 Shading The following range of shades is available from the Shading drop-down menu: • • • • 66 3 Driver features Lightest Very Light Light Medium Light Software Technical Reference • • • • • Medium Medium Dark Dark Very Dark Darkest These values represent the intensity of the color selected in the Color attribute. Size Font sizes from 1 to 999 points are available from the Size menu. The default point size is language-dependent. The choice of regular, bold, italic, and bold italic is available from the Style drop-down menu. Default settings The default settings for new watermarks are Arial (R) font, Gray color, Very Light shading, 150 points, and Regular style. The default settings for preset watermarks are Arial font, Gray color, Very Light shading, and Bold style. The default point size for preset watermarks is language-dependent, and varies. Paper tab features Use the Paper tab to specify the size, type, and source of the media, as well as to define a custom paper size. If you want to, you can indicate different paper-selection choices for the first page and back cover of the document. The first group box in the upper-left portion of the Paper tab view is Quick Sets. This feature is described in the “Finishing tab features” section. Any change to the Quick Sets group box that is made on the Paper tab affects the group box on the Finishing tab and on the Destination tab, and vice versa—they are all one and the same control. Printer image The bitmap image in the lower-right portion of the Paper tab represents the current physical configuration of the printer and corresponds to its configuration data, either obtained automatically through bidirectional communication or configured manually. It should look the same as the image that appears in the same location on the Destination tab and the Configure tab. On the Paper tab, the printer image contains hot spots where you can select a paper source. When the pointer moves over a hot spot, the arrow reverts to the gloved hand used in the Bubble Help, the preview image, and other areas. The current paper source, whether selected from the drop-down menu or from a printer-image hot spot, is highlighted in bright green on the printer bitmap. The following points are worth noting: • Auto Select does not have a corresponding area to highlight in the printer image. • Selecting Manual Feed, Tray 1, Tray 2, Tray 3, or Tray 4 in the drop-down menu highlights the corresponding part in the printer image. • Selecting the area that represents tray in the bitmap always selects the corresponding tray in the Source Is option. Manual Feed, which is available from the Source is option, cannot be selected by selecting the bitmap. • On the Paper tab, only input trays have printer-image hot spots and can be highlighted. Output bins must be selected from the Destination tab. Software Technical Reference PCL 5c and PCL 6 driver features 67 Note The printer image shown in the following illustration might differ from your HP LaserJet product, depending on the model number and accessory devices. Figure 21. Paper tab All Pages The controls on this mini-tab are contained in an All Pages mini-tab. As the name implies, this means that the settings specified on that mini-tab apply to all pages of the document. However, when you select the Use different paper for first page check box, the All Pages mini-tab is replaced by three mini-tabs. These three mini-tabs are: • First Page, which contains the same controls as All Pages • Other Pages, which contains different controls, as noted in the following sections • Back Cover, which also contains different controls, as noted in the following sections 68 3 Driver features Software Technical Reference Other Pages Use the Other Pages mini-tab to select an alternative media type or source for the pages that follow the first page of a document. The choices and defaults for Source is and Type is are the same as for First Page. Figure 22. Other Pages mini-tab Back Cover Use this feature to include a blank back cover on a document, or include a back cover from a paper source different from that used for the remainder of the document. Use the Back Cover mini-tab allows to select an alternative media source (or the same source as First Page) from which a blank page is drawn and placed after the final page of the body of the document. The mini-tab contains three option buttons and two drop-down menus. The three option buttons are: • No back cover • Use the first page source • Use an alternate source The two drop-down menus, which become available when Use an alternate source is selected, are: • Source is • Type is No back cover is selected as the default, with the drop-down Source is and Type is selection boxes disabled. Clicking Use an alternate source activates the drop-down menus. The drop-down menu value defaults to the same source as that chosen for the First Page mini-tab. Clicking Use the first page source changes the drop-down value to match the first page, if necessary, but the drop-down menus remain inactive. Software Technical Reference PCL 5c and PCL 6 driver features 69 When the Back Cover mini-tab is active, clicking No back cover deactivates the drop-down menus, but does not change their value. No Bubble Help is available for the inactive drop-down menus. The settings revert to defaults when Use different paper for first page is selected again. Figure 23. Back Cover mini-tab Size is This feature actually functions as two controls: a drop-down menu that contains all the supported media sizes (including any user-defined custom sizes) and a text label that indicates the dimensions of the selected size. Moving the pointer over the text label causes the arrow to change to a gloved hand, which indicates that the area beneath the pointer is selectable. Clicking here toggles the units of measure between inches and millimeters, offering the same options on the dimensions label in the preview image. Selecting a new size from the drop-down menu updates the media-dimensions text label as well as the preview image. Changing the orientation (on the Basics tab) also updates the dimensions text label. Size can be specified only for the first page or for all pages. On the Other Pages and Back Cover mini-tabs, the Size is drop-down menu does not appear because the media size must be consistent for all pages of the job. Certain applications can override this command and specify different media sizes within a single document. Any change in the media size selection causes the Booklet Printing feature to be turned off. 70 3 Driver features Software Technical Reference Custom The Custom Paper Size dialog box appears when you click the Custom button on the Paper tab. The following illustration shows the initial appearance of the Custom Paper Size dialog box. Figure 24. Custom Paper Size dialog box When the Custom Paper Size dialog box appears, the drop-down menu in the Name group contains one of two things, depending upon the current paper size selection in the Paper tab: • If the paper size selection is a previously defined custom size, then the drop-down menu contains the name of that custom size. • If the paper size selection is a standard paper size, then the drop-down menu shows the default name Untitled for a custom paper size. Note In Windows 95, Windows 98 and Windows Me, two names for the same size media can coexist (for example, "big" and "BIG" can both be used as names for custom-size paper measuring 8.4 inches by 11 inches). In Windows NT 4.0, Windows 2000, and Windows XP, both upper and lower-case names can be used, but they cannot be used to name the same paper size. The new name is compared only against the list of user-defined custom paper-size names, and not against the standard paper-size names. The complete set of titles for this button and the specific characteristics that determine its title and capabilities are discussed in the dynamic command button section. Software Technical Reference PCL 5c and PCL 6 driver features 71 Name drop-down menu The Name drop-down menu displays the name of the last selected custom paper size. Use the Name drop-down menu to type new names for custom paper sizes and to select from the list of currently defined custom paper sizes. The name displayed in the Name drop-down menu is one of three things, depending upon the following conditions: • If a saved custom paper size has been selected from the drop-down menu and the other controls in the dialog box have not been changed since then, the Name dropdown menu displays the name of the last selected custom paper size. • If the width or height controls have been changed since a custom size was selected or saved, or if a saved paper size has just been deleted, then the Name drop-down menu displays the default name of Untitled. • If a new name has been typed into the Name drop-down menu for the purpose of saving a new size or renaming an existing size, then that new name will remain in the drop-down menu display until a saved custom paper size has been selected from the drop-down menu. If you type a new name into the Name drop-down menu, but then do not click the Save button, you should be able to change the width and height values without losing the name. However, if a saved paper-size name is selected from the drop-down menu, any unsaved name or size values are lost without warning, and replaced by the values of the selected custom paper size. Dynamic command button The button located to the right of the Name drop-down menu has three possible labels: Save, Delete, and Rename. • Save is the button title whenever the height and width values have been changed since the last save or since the selection of an existing custom paper size. Clicking the button causes the name in the Name drop-down menu to be compared against each of the saved names. If a duplicate is found, a dialog box appears, asking if it is okay to replace the existing item. If you click Yes, the old item is updated with the new values. If you click No, the driver returns to the Custom Paper Size dialog box, where you can type a different name.The new name is compared only against the list of user-defined custom paper names, and not against the standard papersize names. Whenever the command button has the Save title, it is the default button. • Delete is the button title whenever the name of an existing (previously saved) custom paper size appears in the Name drop-down menu, such as immediately after selecting an item from the drop-down menu or clicking the Save button. Clicking the Delete button causes the saved custom paper size to be deleted, after which the Name drop-down menu changes to Untitled, the height and width controls are unchanged, and the button title changes to Save. • Rename is the button title when you type something into the Name drop-down menu after selecting an existing custom paper size from the drop-down menu. If no duplicate is found, the name of the stored custom paper size changes to match the contents of the Name drop-down menu. Whenever the command button has the Rename title, it is also the default button. 72 3 Driver features Software Technical Reference The following table illustrates the relationships between the Name drop-down menu, the command button, and the actions that take users from one state to another. Table 8. Name drop-down menu text strings State Drop-down Button Action menu contents label Next state 1 Click Save 3 Type something into the Name drop-down menu 2 Change the width or height values 1 Select a saved item from the drop-down menu 3 Click Save 3 Type something into the Name drop-down menu 2 Change the width or height values 2 Select a saved item from the drop-down menu 3 Click Delete 1 Type something into the Name drop-down menu 4 Change the width or height values 1 Select a saved item from the drop-down menu 3 2 3 4 Untitled Save <user-typed text> Save <name of saved item> Delete <user-typed text> Rename Click Rename (when the name is unique) 3 Click Rename (when the name is a duplicate) 4 Type something into the Name drop-down menu 4 Change the width or height values 2 Select a saved item from the drop-down menu 3 Width and height controls The width and height values can be changed either by typing numeric strings into the edit boxes, or by selecting the up and down arrows. Any entry that is greater than the maximum limits of the width and height control is rounded down to the maximum valid entry, while any entry that is smaller than the minimum limits of the width and height control is rounded up to the minimum valid entry. See “Custom width and height control limits.” If units are in millimeters, the custom paper-size range minimum is the limit rounded up to the nearest whole millimeter. The custom paper-size range maximum is the limit rounded down to the nearest whole millimeter. Any non-numerical entry reverts to the last valid entry. Width and height entries are validated when the focus has changed. The resolution of each control is one millimeter or one-tenth of an inch, depending upon the current measurement units. Clicking the up and down arrows increases or decreases the current value by the increment amount (within the allowed range of values). The computer determines the rate at which the values change. Unit indicator labels change dynamically to indicate inches or millimeters, depending upon the measurement units the driver is currently using. To change measurement units, click the Measurement Units button. Software Technical Reference PCL 5c and PCL 6 driver features 73 Custom width and height control limits The minimum paper size for the HP Color LaserJet 5500 product is 76 mm by 127 mm (3.0 inches by 5.0 inches) and the maximum is 297 mm by 470 mm (12.05 inches by 18.5 inches). The following table summarizes paper size limits for each paperhandling device. Table 9. Custom width and height limits for the HP Color LaserJet 5500 Media source or paper handling accessory Minimum size width by height Maximum size width by height Tray 1 (multi-purpose) 76 mm by 127 mm 306 mm by 470 mm (3.0 inches by 5.0 inches) (12.05 inches by 18.50 inches) 148 mm by 210 mm 297 mm by 432 mm (5.83 inches by 8.27 inches) (11.69 inches by 17.00 inches) 148 mm by 210 mm 297 mm by 432 mm (5.83 inches by 8.27 inches) (11.69 inches by 17.00 inches) 148 mm by 210 mm 297 mm by 432 mm (5.83 inches by 8.27 inches) (11.69 inches by 17.00 inches) Tray 2 Tray 3 Tray 4 Paper and envelope icons The paper and envelope icons visually define width and height. Measurement Units button Like the dynamic command button previously described, the Measurement Units button is also multi-titled, although its function is always to toggle the unit of measurement between standard (inches) and metric (millimeters) units of measurement. Close button The Close button closes the Custom Paper Size dialog box according to the logic in the table below. In all cases, any custom paper sizes successfully saved (and not renamed or deleted) while the dialog box is open will remain in the paper size list in the Paper tab. The following table lists options that appear when you click the Close button. Table 10. Close dialog box text strings If the drop-down menu contains … And the button says … Then this happens when the Close button is clicked Untitled Save The dialog box closes, but you lose the changes that were not saved. The current paper size remains the same as it was when the Custom button was selected. 74 3 Driver features Software Technical Reference Table 10. Close dialog box text strings (continued) If the drop-down menu contains … And the button says … Then this happens when the Close button is clicked <user-typed text> Save The dialog box closes, but you lose the changes that were not saved. The current paper size remains the same as it was when the Custom button was selected. <name of saved item> Delete The dialog box closes, and the current paper size is set to that which was last displayed in the drop-down menu. <user-typed text> Rename The dialog box closes, but you lose the changes that were not saved. The current paper size remains the same as it was when the Custom button was selected. Source Is The Source Is drop-down menu shows the input trays available according to Configure tab settings. The list contains: • • • • • • Auto Select Manual Feed Tray 1 Tray 2 Tray 3 (if installed) Tray 4 (if installed) The default setting is Auto Select, which allows the printer firmware to select the media source. Any optional paper trays that are installed through the Configure tab are also shown here. If a conflict exists among paper source, size, or type, and you choose to keep the conflicting settings, the settings are processed in the following order: paper size, paper type, and paper source. For information about media types and sizes, see "Media attributes". Type Is The Type Is drop-down menu shows all the paper types supported by the HP LaserJet product, as well as any user-defined types created by a printer administrator. The default setting is Auto Select, which allows the application to select the paper type. Software Technical Reference PCL 5c and PCL 6 driver features 75 No mechanism exists for manually adding custom paper types from the driver. Custom sizes can be added only by using the bidirectional communication mechanism, so they must already exist in the printer when the bidirectional query occurs. If bidirectional communication is enabled, then the information returned is an updated list of paper types. If bidirectional communication is not enabled, then the driver looks for custom paper types saved from a previous bidirectional communication query, and uses those. Otherwise, no custom paper types are available through the driver. The standard types that appear in the lists are: • • • • • • • • • • • • • • • • • Bond Cardstock Color Envelope Glossy Heavy Glossy Heavy Labels Letterhead Light Plain Preprinted Prepunched Recycled Tough Paper Transparency Unspecified For more information about media types and sizes, see “Media attributes”. Printer image The bitmap image in the lower-right portion of the Paper tab screen represents the current physical configuration of the printer according to the driver configuration data (obtained automatically through bidirectional communication, or configured manually through the driver). It should have the same appearance as the image in the same location on the Destination tab and the Configure tab. On the Paper tab, the printer image contains hot spots for selecting a media source. When the pointer moves over a hot spot, the arrow reverts to the gloved hand used in the Bubble Help, the preview image, and other areas. The current media source is highlighted in a bright green color on the printer bitmap. Destination tab features The Destination tab provides options for job storage and output bins. Note The Destination tab appears only if the Printer Hard Disk and Job Storage Enabled check boxes are selected. To select these options, click More... on the Configure tab. 76 3 Driver features Software Technical Reference The printer image in the lower-right portion of the Destination tab represents the current physical configuration of the printer and corresponds to its configuration data, either obtained automatically through bidirectional communication or configured manually. It should look the same as the image that appears in the same location on the Paper tab and the Configure tab. Note The printer image shown in the illustration might differ from your HP LaserJet product, depending on the model number and accessory devices. Figure 25. Destination tab Destination Features The Destination Features group box provides controls for Job Storage. This group box is only visible if the Printer Hard Disk and Job Storage Enabled check boxes are selected in the More Configuration Options dialog box available on the Configure tab. Hardware configuration and availability of Job Storage options The Job Storage options available to you depends upon whether your printer has an optional hard disk installed. Job Storage options require a printer hard disk (an optional HP EIO disk drive). Software Technical Reference PCL 5c and PCL 6 driver features 77 To use the Job Storage and Job Storage Enabled options, the printer must have the optional hard disk installed, the Printer Hard Disk selected in the More... dialog box of the Configure tab, and the print driver configured to use hard-disk storage. Configuring the printer driver for a printer hard disk If the print driver on your computer is not yet configured to use the hard disk, follow these steps: Note These steps must be completed for each driver. Step 1 Double-click the My Computer icon. This opens the My Computer window. Step 2 Open the Printers window. Step 3 Right-click the printer icon. This opens a drop-down menu. Click Properties. The Properties dialog box appears. Step 4 Click the Configure tab. Step 5 Under Other Options, click More. Step 6 Under Storage, click the Printer Hard Disk check box. (This also selects Job Storage Enabled). Step 7 Close all of the dialog boxes by clicking OK. Your PCL printer driver is now configured to use the hard-disk and Job Storage features of your HP LaserJet product. Job storage modes Using the HP LaserJet product's Job Storage feature, you can store documents at the printer and then control the printing of these documents using the printer control panel. This feature is intended to provide greater flexibility, convenience, security, and cost savings. Once the Job Storage feature has been enabled, you have access to its features in the Destination tab of the printer driver. The HP LaserJet product offers the following Job Storage options. Off This option turns the Job Storage feature off (it is disabled), which means the print job will not be stored in the printer. Quick Copy Quick Copy stores a copy of a printed job on the hard disk, and allows you to print additional copies of a print job using the control panel. The number of quick-copy print jobs that can be stored in the printer is set from the printer control panel. Note The printer configuration can be set to hold a maximum of 50 quick-copy or proof-and-hold jobs. The number is set on the printer control panel in the Configuration menu, and the default is 32. When this preset limit is reached, a newer document will overwrite the oldest. Also, a document that has the same user and job name as one already stored on the hard disk will overwrite the existing document. Quick-copy jobs are deleted if the printer's power is removed. 78 3 Driver features Software Technical Reference Proof and Hold This option stores the print job on the printer hard disk, and prints only the first copy of the job, allowing you to check the first copy. If the document prints correctly, you can print the remaining copies of the print job from the printer control panel. The number of proof-and-hold print jobs that can be stored in the printer is set from the printer control panel. Using a PIN for Private Job and Stored Job The Private Job and Stored Job options can be secured by a four-digit personal identification number (PIN). This number must be typed in the printer control panel before the printer prints the job. The box labeled PIN is usually inactive. Selecting Private Job or Stored Job along with Require PIN to Print activates the PIN box. The Stored Job/PIN coupling has a PIN restriction of four ASCII numeric characters (ASCII 0-30 through 0-39). If you enter non-numeric characters, they are removed immediately. If you enter more than four characters, the characters past the fourth are truncated. The field temporarily allows fewer than four digits in the string, but when the edit field loses focus, the zeroes pad the left end until there are exactly four digits. The default initialized value for the PIN is 0000 for Private Job and Stored Job with Require PIN to Print selected. Private Job This option allows you to send a print job directly to the printer memory. Selection of Private Job activates the PIN field. The print job can be printed only after you type a PIN in the printer control panel. After the job is printed, the printer removes the job from the printer memory. This feature is useful when you are printing sensitive or confidential documents that you do not want to leave in an output bin after printing. Private Job stores the print job on the hard disk. Once released for print, the private job is immediately deleted from the printer. If more copies are needed, it will be necessary to reprint the job from the application. If you send a second private job to the printer with the same user name and job name as an existing private job (and you have not released the original job for printing), the second job will overwrite the older job, regardless of the PIN. Private jobs are deleted if power to the printer is removed. Stored Job The Stored Job option allows you to send a print job directly to the printer hard disk. The print job will be stored in the printer as if it is an electronic file cabinet. After the print job is stored in the printer's hard disk, you can print the job from the printer control panel. The job remains stored on the printer until it is deleted or overwritten by a document with the same user and job names. Stored jobs remain on the printer hard disk when power is interrupted. Use this feature for forms and other common or shared documents. Software Technical Reference PCL 5c and PCL 6 driver features 79 A stored job can be handled in two ways, as either a private or a public job. A private stored job allows you to send a print job directly to the printer memory and can be printed only after you type a PIN in the printer control panel. (You can set the PIN in the Print dialog box.) After the job is printed, the job remains in the printer memory and can be printed again from the printer control panel. This feature is useful when you are printing sensitive or confidential documents you do not want to leave in an output bin after printing. Private mode is initiated by clicking the Require PIN to Print check box. In this mode, a PIN entry at the control panel is required to release the job. The box labeled PIN is usually inactive. The Require PIN to Print option is activated if you click Stored Job. If selected, you must enter a PIN to make the stored job private. Note A private stored job is not the same as a private job (see above). Private jobs are deleted from the printer memory after they are printed. Private stored jobs are retained in the printer memory after printing, but require that a PIN be typed each time they are printed. Document identifiers used in Job Storage When you use a Job Storage feature, your document is identified in the printer control panel by user name and job name. User Name The User Name edit box allows you to identify the job at the printer control panel. When the driver is first installed (or when Factory Defaults Quick Set is selected), this string initializes to the empty string (““), but the dialog box detects this condition and replaces the string with your login name in Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP. It replaces it with “Untitled” in Windows 3.1x. Restrictions for the User Name field are described below. Job Name The Job Name is used for specifying a name to identify the job on the printer control panel. When the driver is installed, or when the Factory Defaults Quick Set is selected, this string is initialized to the empty string (" "), but the dialog box will detect this condition and replace the string with "Untitled". Restrictions for the Job Name field are described below. The Job Name and the User Name fields can contain no more than 16 characters each, and are limited to A through Z and 0 through 9, because the name is displayed on the printer control panel. If you try to enter a lowercase character, it automatically shifts to uppercase. If you try to enter a character with an ASCII code of less than 32 or greater than 126 characters, the character is removed from the edit field, along with all characters that follow it. If you try to enter more than 16 characters, any character beyond 16 is truncated. When the dialog box is closed, or the edit box loses focus, an empty string is replaced with “Untitled”. In those languages for which “Untitled” cannot be translated without the use of invalid characters, the driver uses a string of three dashes. The acceptable characters for job name and user name vary for each operating system. The string must be displayable on the printer control panel. 80 3 Driver features Software Technical Reference Using Job Storage options when printing You can use Job Storage options in the Destination tab of the printer driver. Note The printer driver installed on your computer must be configured to use the Job Storage features. See the "Configuring the printer driver for a printer hard disk" section. Step 1 Click Print from the software application. The Print dialog box appears. Step 2 Click Properties. The Properties dialog box appears. Step 3 Click the Destination tab to display the destination options. Step 4 Click Job Storage on the drop-down menu under Destination Features. Step 5 Click Settings. The Job Storage Settings dialog box appears. You can then select one of the Job Storage options described above by clicking the appropriate option button. Note These instructions are specific to the Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP environments using the latest available PCL 5 and PCL 6 drivers. While the basic concepts of Job Storage are the same for PS print jobs, there are significant differences in the driver user interface. Also, there are some limitations in naming and PIN selection. Releasing stored jobs at the printer Once you send a print job using Job Storage, you can release the job to print using the printer control panel. Step 1 Press the select button (the one with the check mark) to enter MENUS. RETRIEVE JOB is highlighted. Step 2 Press the select button to select RETRIEVE JOB. Step 3 Press the down arrow to highlight your USER NAME. Step 4 Press the select button to select your USER NAME . Step 5 Press the down arrow to highlight a JOB NAME. Step 6 Press the select button to select the JOB NAME. PRINT is highlighted. Step 7 Press the select button to select PRINT. Step 8 If you assigned a PIN number to the job, press the up or down arrow to select the first digit of the PIN. Step 9 Press the select button to select the digit. The number changes to an asterisk. Step 10 Repeat the last two steps for each of the remaining three digits of the PIN. Step 11 Press the select button when finished entering PIN. Step 12 Press the up or down arrow to select the number of copies needed. Step 13 Press the select button to print the job. Deleting a print job Sometimes it is necessary to delete a print job from the printer memory or hard disk. This can be done from the printer control panel. Software Technical Reference PCL 5c and PCL 6 driver features 81 Step 1 Press the select button (the one with the check mark) to enter MENUS. Step 2 RETRIEVE JOB is highlighted. Step 3 Press the select button to select RETRIEVE JOB. Step 4 Press the down arrow to highlight your USER NAME. Step 5 Press the select button to select your USER NAME. Step 6 Press the down arrow to highlight a JOB NAME. Step 7 Press the select button to select the JOB NAME. Step 8 Press the down arrow to highlight DELETE. Step 9 Press the select button to select DELETE. Step 10 If you assigned a PIN number to the job, press the up or down arrow to select the first digit of the PIN. Step 11 Press the select button to select the digit. The number changes to an asterisk. Step 12 Repeat the last two steps for each of the remaining three digits of the PIN. Step 13 Press the select button when finished entering PIN. Step 14 Press the select button to delete the job. Output Bin Options The HP Color LaserJet 5500 product has one output bin that can be selected in the driver, so one item appears in the Bin list: Top Bin (Face-Down). Top Bin (Face-Down) refers to the main output bin at the top of the printer and is the only setting for the HP Color LaserJet 4600 printer driver. Jobs sent to this bin are delivered face-down. This option is always available and has no paper size or type constraints beyond those determined by the printer hardware. Options The Options drop-down menu is inactive. This setting can be used to enable non-HP paper-handling devices. Printer image The bitmap image in the lower-right portion of the Destination tab screen represents the current physical configuration of the printer according to the driver configuration data (obtained automatically through bidirectional communication, or configured manually through the driver). It should have the same appearance as the image in the same location on the Paper tab and the Configure tab. On the Destination tab, the printer image contains hot spots for selecting an output bin. When the pointer moves over a hot spot, the arrow reverts to the gloved hand used in the Bubble Help, the preview image, and other areas. The current output bin is highlighted in a bright green color on the printer bitmap. Note On the Destination tab, only output bins have hot spots and can be highlighted; source trays must be selected from the Paper tab. 82 3 Driver features Software Technical Reference Basics tab features The Basics tab provides options for setting the number of copies to be printed and for the orientation of the print job. It also lets you retrieve information about the driver. Figure 26. Basics tab Copies The Copies feature allows you to specify the number of copies to print. The number of copies you request appears in the Copies box. You can select the number by typing in the box or by using the up and down arrows to the right of the edit box. Valid entries are numbers from 1 to 9999 for the HP Color LaserJet 5500 product. The copies value will not advance from the maximum number (9999) to 1 when the up arrow is used, or change from 1 to the maximum number (9999) when the down arrow is used. Invalid entries into the edit box (such as non-numerical input, numbers less than 1 or greater than the maximum allowed) are changed to the last valid value entered when you click on another group box or leave the Basics tab. The default number of copies is 1. Software Technical Reference PCL 5c and PCL 6 driver features 83 Because applications can also be used to set the desired number of copies, conflicts between the application and the driver can arise. In most cases, the application and the driver communicate, so that the number of copies set in one location (such as the application) will appear in the other (such as the driver). For some applications, this communication does not take place, and the copies values are treated independently. For these applications, setting 10 copies in the application and then setting 10 copies in the driver will result in 100 copies (10 x 10) being printed. It is recommended to set the number of copies in the application, wherever possible. Orientation Orientation refers to the layout of the image on the page, and does not affect the manner in which media is fed into the printer. You can specify the orientation of the print job. The three available orientations are portrait, landscape, and rotated. The default orientation is portrait. The three orientation options have these configurations: • Portrait. The top edge of the document is the shorter edge of the paper. • Landscape. The top edge of the document is the longer edge of the paper. • Rotated. Rotated is a form of landscape or portrait in which the image is rotated 180 degrees. This setting is useful for printing envelopes and when using some third-party paper-handling devices. Orientation can toggle between portrait and landscape by left-clicking the preview image. If you select the Rotate by 180 degrees check box, there is no change in the preview image. 84 3 Driver features Software Technical Reference About By clicking the About button on the Basics tab or selecting the HP logo on any of the driver property pages, the About box appears. To close the About box, click OK, press ESC, press ALT + F4, or press ENTER. The figure below shows the About box. The information varies according to HP LaserJet model number, driver, date, and versions. Figure 27. About This Driver dialog box Driver extensions The Driver Extensions text box provides you with some visibility of any extended driver functionality. It can contain a brief description of the driver extension and a version number. Software Technical Reference PCL 5c and PCL 6 driver features 85 Color tab features Use the Color tab to specify predefined color-option settings or to fine-tune the color treatments and half-toning. Color output can also be converted to grayscale. The Color tab is shown in the following illustration. Figure 28. Color tab Color options Use the Color Options group box to adjust the independent color controls. The settings affect the print job's color rendering and print quality. To use default coloration settings, click the Automatic option button. To change the default coloration settings, click the Manual option button and then click the Settings button. To convert color information to grayscale and print the document in black and white, select the Print in Grayscale check box. 86 3 Driver features Software Technical Reference Manual color settings When you click the Settings... option button, the Color Settings dialog box appears. The default settings are shown in the following illustration. To change the settings, make your selections using the drop-down menus in the Color Settings dialog box, and then click OK. You are then prompted to save your selections as a Custom, or manual, setting. Figure 29. Manual Color Options dialog box The Manual Color Options dialog box gives you independent control of neutral grays and halftone for the three major page components: text, graphics, and photographs. The Neutral Grays: drop-down menu controls the selection of a device-dependent color table that is embedded in the printer firmware. The options are Black Only or 4-Color. You can adjust the Neutral Grays: setting independently for text, graphics, or photographs. • Black Only. This option generates neutral colors (grays and blacks) using only black toner which ensures that neutral colors do not have a color cast. • 4-Color. This option generates neutral colors by combining all four colors of toner, which produces smoother gradients and transitions to non-neutral colors. It also produces the darkest possible black. Software Technical Reference PCL 5c and PCL 6 driver features 87 The Halftone setting controls the selection of a device-dependent halftone algorithm that is embedded in the printer firmware. The Halftone options, Detail and Smooth, affect the resolution and clarity of your color output. You can independently adjust halftone settings for text, graphics, and photos. • Smooth. This option provides better results for large, solid-filled print areas. It also enhances photographs by smoothing out fine color gradations. Choose this option for uniform and smooth area fills. • Detail. This option is useful for text and graphics that require sharp distinctions among lines or colors, or for images that contain a pattern or a high level of detail. Choose this option for sharp edges and detail. The General Color Options settings are Edge Control and RGB Color. Edge control, which determines how edges are rendered, consists of two components: adaptive halftoning and trapping. Adaptive halftoning increases the edge sharpness of text and graphics while maintaining the quality of area fills. Trapping reduces the effect of color plane misregistration by slightly overlapping the edges of adjacent objects. The following options are available: • Off, which sets Trapping and Adaptive Halftoning to Off. • Light, which provides minimal trapping. Adaptive Halftoning is set to On. • Normal, which provides the default Trapping setting. Adaptive Halftoning is set to On. • Maximum, which provides the most trapping. Adaptive Halftoning is set to On. Settings under RGB Color affect the color treatment for all objects and determines how colors are rendered. The options are Default (sRGB) and Device. Default. This option interprets RGB color as standard default RGB color space (sRGB), which is the accepted standard for many software companies and organizations, such as Microsoft and the Worldwide Web Consortium. Device (sRGB). This option sets the printer to print RGB data in raw device mode. To render photographs properly when this option is selected, you must manage color in the application in which you are working or in the operating system. Note If your software application converts text and graphics to raster, the Photographs settings also control the Text and Graphics settings. Configure tab features Use the Configure tab to tell the driver about the hardware configuration of the printer. If bidirectional communication is enabled in a supported environment, set up this tab by clicking the Update Now button. If your environment does not support bidirectional communication, the Update Now button will be unavailable, so you must manually configure the options on this tab. 88 3 Driver features Software Technical Reference The Configure tab is available when the driver is opened from the Printers folder by clicking Properties. When you open the driver from within an application, the Configure tab will not be visible, with a few exceptions, such as when using Excel 5.0 or Corel (R) Chart 4.0. When opened from the Printers folder, the Configure tab looks like the following illustration. Figure 30. Configure tab The printer image in the lower-right portion of the Configure tab represents the current physical configuration of the printer and corresponds to its configuration data, either obtained automatically through bidirectional communication or configured manually. It should look the same as the image that appears in the same location on the Paper tab and the Destination tab. For more information, see “Paper tab features.” Note The printer image shown in the illustration might differ from your HP LaserJet product, depending on the model number and accessory devices. Printer Model group box In the Printer Model group box, the driver title remains HP Color LaserJet 5500 for all models. Selection of another printer bundle makes the appropriate changes to other configuration options on the tab. The list of models and the changes they produce are described below. Software Technical Reference PCL 5c and PCL 6 driver features 89 When the HP Color LaserJet 5500 or the HP Color LaserJet 5500n is selected, the following settings apply: • The Driver Work Space (DWS) value shown in the Other Options dialog box is 6.0 MB. • The Total Printer Memory value is 96 MB. • No optional paper destinations, paper sources, duplexing unit, or hard disk are selected. HP Color LaserJet 5500dn resets all configuration settings to match the capabilities of the 5500dn model. Settings affected are: • The Total Printer Memory value is 96 MB. • Duplexing Unit is selected. • No optional paper destinations, paper sources, or hard disk are selected. When the HP LaserJet 5500dtn is selected, the following changes are made to the default settings: • • • • The Total Printer Memory value is 160 MB. Duplexing Unit is selected. HP 500-Sheet Input Tray is selected in Optional Paper Sources. No optional paper destinations are selected. When the HP Color LaserJet 5500hdn is selected, the following changes are made to the default settings: • • • • • The Total Printer Memory value is 160 MB. Duplexing Unit is selected. Mopier Enabled is selected. Printer Hard Disk and Job Storage Enabled are selected. 2 x 500-Sheet Input Tray is selected. If it is installed and working, the bidirectional mechanism will detect the correct model and update the configuration accordingly, either during installation or when you select Update Now on the Configure tab. However, the printer model name shown in the Printer Model text box does not change. Paper-handling options The Paper Handling Options group box provides options for configuring most of the paper-handling device features. Duplexing unit Select this option if a duplexing unit is installed in the printer. When it is selected, additional controls appear in the Document Options group box in the Finishing tab. Unlike most options in this group box, the Duplexing Unit option does not affect the printer image because the duplexing unit is contained within the printer. To print on both sides, click Print from the application, click the Properties button, click the Finishing tab, and then click Print on Both Sides. 90 3 Driver features Software Technical Reference Mopier enabled A mopier is an HP-designed printer that produces multiple, collated copies from a single print job. Multiple-original printing (mopying) increases printer performance and reduces network traffic by sending the job to the printer once, then storing it on the hard disk. The remainder of the copies are printed at the printer’s fastest speed. All documents can be created, controlled, managed, and finished from the desktop, which eliminates the extra step of using a photocopier. The HP Color LaserJet 5500 product supports the Transmit Once mopying feature, and the Mopier Enabled option is selected by default, if a hard disk is installed and Printer Hard Disk is selected in the driver software. Mopier Enabled is enabled only when the Configure tab settings indicate (whether set manually or with Auto Configure) that the printer has a hard disk and at least 64 MB of RAM installed. When the Mopier Enabled check box is disabled, a Bubble Help appears next to it, explaining that a printer hard disk and or at least 64 MB of Total Printer Memory is required to enable this feature. All models of the HP Color LaserJet 5500 product come with 96 MB or more memory installed. Optional Paper Destinations The Optional Paper Destinations drop-down menu contains the following options: • (None) The Optional Paper Destinations drop-down list setting is (None) because no optional paper devices exist for the HP Color LaserJet 5500 product. Optional Paper Sources The Optional Paper Sources drop-down menu lists optional paper sources for the HP Color LaserJet 5500. The list of available paper sources varies, depending on your product, its input accessories, and the product configuration settings on the Configure tab. For the HP Color LaserJet 5500 product, two optional paper sources are available. The settings in the Optional Paper Sources drop-down menu are as followings: • (None) (the default setting for the HP Color LaserJet 5500, 5500n, and 5500dn models) • 2 x HP 500-Sheet Input Tray (the default setting for the HP Color LaserJet 5500hdn model) • HP 500-Sheet Input Tray (the default setting for the HP Color LaserJet 5500dtn model) Software Technical Reference PCL 5c and PCL 6 driver features 91 Other Options The Other Options group box contains a single More command button. Clicking the More button opens the More Configuration Options dialog box. Figure 31. More Configuration Options dialog box Storage In Storage, you can specify whether a printer hard disk is installed and whether Job Storage is enabled. Job Storage is enabled by default. The printer hard disk control can be set manually or updated by a successful bidirectional communication query using the Update Now button in environments supporting bidirectional communication. Job Storage Enabled determines whether Job Storage appears as a feature on the Destination tab. Because this is the only possible Destination Feature for the HP LaserJet product, this also determines whether the Destination tab appears. When the Printer Hard Disk check box is disabled, a Bubble Help message appears next to the Mopier Enabled and Job Storage Enabled check boxes, explaining that a printer hard disk and at least 96 MB of Total Printer Memory are required to enable these features. Printer Memory Total Memory. This shows the total amount of memory physically installed in the printer. The default values for Total Printer Memory are specified in the Printer Model section of the Configuration tab and are based on the printer model. 92 3 Driver features Software Technical Reference Selecting Printer Hard Disk enables the Job Storage check box and selects it as the default. Selecting Printer Hard Disk also enables and selects the Mopier Enabled check box by default for all HP Color LaserJet 5500 models except the HP Color LaserJet 5500hdn model, for which Printer Hard Disk, Job Storage, and Mopier Enabled are preselected default settings. Total Printer Memory updates from a successful bidirectional query, or can be set manually. Driver Work Space. Use the Driver Work Space (DWS) option to specify the amount of work-space memory available to the printer. In environments that support bidirectional communication, this option is configured automatically. To manually set DWS, print a configuration page and find the DWS value in the Memory section of the configuration page. The DWS value might change if you switch printer model settings. Then, type that value in the DWS box in the More Configuration Options dialog box. An accurate DWS value optimizes driver performance. Include types in application source list When the Include types in application source list check box is selected, all paper types (such as envelopes and transparencies) are available from the Source is: list on the Paper tab. When you are in an application, you can open the Paper tab by clicking Print from the File menu, and then clicking Properties. Software Technical Reference PCL 5c and PCL 6 driver features 93 Fonts The Fonts group box contains a Font DIMM check box and a corresponding Configure button. Selecting the Font DIMM check box tells the driver that a Font DIMM is installed, and that stored data regarding the fonts on the DIMM is available. When the check box is selected, the Configure button is enabled. Click the Configure button to open the Configure Font DIMMs dialog box. If the Font DIMM check box was not selected when you entered the More Configuration Options dialog box, selecting that check box automatically opens the Configure Font DIMMs dialog box. Figure 32. Configure Font DIMMs dialog box Use the Configure Font DIMMs dialog box to perform the following tasks: • • • • Add up to two font DIMMs by clicking the Add button. Specify a unique font DIMM name. Select specific font DIMM data files that contain lists of fonts on specified DIMMs. Select one or more installed DIMMs in the Installed DIMM list, and based on the selected DIMM(s). The list to the right (Fonts on DIMM) will display all of the fonts available on the selected DIMM(s). • Enable or disable one or more of the selected font(s). Use the following procedure to configure a font DIMM. 94 3 Driver features Step 1 Make sure that the font DIMM is properly installed. Step 2 Click Add. The Add Font DIMM dialog box appears. Step 3 Click Browse. The Font DIMM Files dialog box appears. Step 4 Find and select the appropriate Printer Cartridge Metrics (PCM) file that came with the font DIMM. Software Technical Reference Note Step 5 Click Open. Step 6 If you want, specify a Font DIMM Name in the Add Font DIMM dialog box. Step 7 Click OK. The selected printer cartridge metrics (.PCM) file appears in the Installed DIMMs list. Select the .PCM file to display a list of available fonts in the Fonts on DIMM list. Step 8 Click OK to close the Add Font DIMM dialog box. The fonts on the DIMM should now be available on the system. When using font DIMMs with the PCL 5c and PCL 6 drivers: To install screen fonts that match the font DIMM, use the .HPB file specifically designed to work with that DIMM. If there are no screen fonts for the DIMM, use the .PCM file specifically designed to work with that DIMM. Ignore Application Collation The Ignore Application Collation check box is disabled and set to OFF when the Mopier Enabled check box is clear (not selected). The table below shows the expected behavior for a two-page print job when the number of copies is three. Table 11. Printer behavior with Ignore Application Collation settings Hard disk on printer Mopier Enabled check box Ignore Application Collation check box Application Commands Pages sent Pages Collation sent by to printer output from check box printer printer in Print dialog box Yes On On On QTY=3 1,2 1,2,1,2,1,2 Off None Yes On On On QTY=3 1,2 1,2,1,2,1,2 Yes On Off Off Copies=3 1,2 1,1,1,2,2,2 Yes/No Off Off On Copies=1 1,2,1,2,1,2 1,2,1,2,1,2 Yes/No Off Off Off Copies=3 1,2 1,1,1,2,2,2 Yes/No Off Off None Copies=1 1,2,1,2,1,2 1,2,1,2,1,2 Yes/No Off Off None Copies=3 1,2 1,1,1,2,2,2 No On On On QTY=3 1,2 1, 2 QTY=3 1,2 1, 2 Off None No On Off On Off None Placing the Ignore Application Collation setting in the printer properties means that, on a Windows NT network, clients connecting to the printer through a network share cannot change its value; only the print queue administrator has the power to decide how the printer driver is set up. Software Technical Reference PCL 5c and PCL 6 driver features 95 The Ignore Application Collation setting is not a means to print non-collated copies. If you want to print non-collated copies, disable mopying. Automatic Configuration If you have modified the configuration of the HP LaserJet product since installation, click the Update Now button to automatically reflect the new configuration in the driver. For more information about the Driver Automatic Configuration feature, see “Driver Autoconfiguration.” Printer image The bitmap image in the lower-right portion of the Configure tab screen represents the current physical configuration of the printer according to the driver configuration data (obtained automatically through bidirectional communication, or configured manually in the Paper-Handling Options group box). It should have the same appearance as the image in the same location on the Paper tab and the Destination tab. 96 3 Driver features Software Technical Reference NT Forms tab features The NT Forms tab appears only in the Microsoft Windows NT 4.0, Windows 2000, and Windows XP operating environments. The NT Forms tab (like the Configure tab) can be viewed only from the Properties window. Figure 33. Driver NT Forms tab The NT Forms tab lets you specify which media sizes and types are loaded in each of the available paper trays. The advantage is that it constrains the choices available in the Size and Type lists on the Paper tab. This constraint prevents information overload when you request unavailable sizes or types. Available Trays is a drop-down menu containing all product trays specified on the Configure tab. The This Tray Contains/Size (Forms) drop-down menu contains a list of standard paper sizes supported by the HP LaserJet product, as well as any custom forms defined in the Forms tab. The This Tray Contains/Type drop-down menu lists all of the media types supported by the HP LaserJet product. The Clear All button removes all size and type constraints on the Paper tab. Configuring the trays Step 1 Select the appropriate tray from the Available Trays list. Step 2 Use the This Tray Contains/Size (Forms) drop-down menu to select the paper size (or form) loaded in that tray. Software Technical Reference PCL 5c and PCL 6 driver features 97 Step 3 Use the This Tray Contains/Type drop-down menu to select the paper type that is configured for the tray. Step 4 Repeat steps 1 through 3 for the remaining trays. Step 5 If necessary, click the Clear All button to reconfigure all the trays, and remove the size and type constraints imposed on the Paper tab. Windows PS driver features This section provides information about the features of the Windows PS printer driver. PS 3 Emulation support for the HP LaserJet product The PS Level 3 Emulation maintains full compatibility with Adobe PS Level 3 when PS Level 3 soft fonts are purchased from Adobe. A set of 92 PS Level 3 soft fonts is included with the printing-system software. If you want to permanently install the fonts in the printer, PS Level 3 emulation fonts are also available from HP in an optional font DIMM. Users of Adobe-licensed applications might also have the right to use the Adobe PS level 3 printer drivers from Adobe with the HP LaserJet printer PS Level 3 emulation PPD, available on the HP LaserJet printer software CD-ROM or from the HP Web site. When using the Adobe PS Level 3 printer driver, users must comply with all Adobe licensing agreements, as stated on the Adobe Web site at http://www.adobe.com/support/ downloads/license.html. See “Font support” for a list of the additional fonts. Note The driver interface shown in this section is for Windows NT 4.0. The order and appearance of tabs can vary among operating systems. 98 3 Driver features Software Technical Reference Page Setup tab features The Page Setup tab contains controls for the following options: • • • • • Figure 34. Paper Size Paper Source Copy Count Orientation Color Appearance Page Setup tab Software Technical Reference Windows PS driver features 99 Advanced tab features The Advanced tab contains controls for the following types of options: • Paper/Output (advanced control over the options available on the Page Setup tab) • Graphic (including resolution, scaling, and TrueType font controls) • Document Options (including printer features and PostScript options) Figure 35. Advanced tab 100 3 Driver features Software Technical Reference Job Storage tab features The Job Storage tab for the PCL 6 driver (using Windows NT 4.0, Windows 2000, or Windows XP operating systems) is shown in the following figure. Note Limited Job Retention functions for Windows 95, Windows 98, and Windows Me operating systems is supported under Printer Features (on the PS driver Advanced tab). Figure 36. Job Storage tab When a hard disk is installed and Job Storage is enabled, the HP Color LaserJet 5500 product offers the following PS 3 emulation Job Storage options: Off This option turns the Job Retention feature off (it is disabled), which means the print job will not be stored in the printer. Quick Copy Quick Copy stores a copy of a printed job on the hard disk, and you can print additional copies of a print job by using the control panel. The number of quickcopy print jobs that can be stored in the printer is set from the printer control panel. Software Technical Reference Windows PS driver features 101 Note The printer configuration can be set to hold a maximum of 50 quick-copy or proof-and-hold jobs. The number is set on the printer control panel in the Configuration menu, and the default is 32. When this preset limit is reached, a newer document will overwrite the oldest. Also, a document that has the same user and job name as one already stored on the hard disk will overwrite the existing document. Quick-copy jobs are deleted if the printer's power is removed. Proof and Hold Use this option to store the print job on the printer hard disk, and print only the first copy of the job, which allows you to check the first copy. If the document is correct, you can print the remaining copies of the print job from the printer control panel. The number of proof-and-hold print jobs that can be stored in the printer is set from the printer control panel. Private Job and Stored Job The Private Job and Stored Job options can be secured by a four-digit personal identification number (PIN). PIN You can assign a four-digit PIN to a print job when you are using the Private Job or Stored Job feature. This number must be typed in the printer control panel before the job can be printed. The box labeled PIN is usually inactive. Selecting Private Job or Stored Job along with Require PIN to Print activates the PIN box. The Stored Job/PIN coupling has a PIN restriction of four ASCII numeric characters (ASCII 0-30 through 0-39). If you type non-numeric characters, they are removed immediately. If you type more than four characters, the characters after the fourth are truncated. The field temporarily accepts fewer than four digits in the string, but when the edit field loses focus, the zeroes pad the left end of the PIN until it contains exactly four digits. The default initialized value for the PIN is 0000 for Private Job and Stored Job with Require PIN to Print selected. Private Job Use this option to send a print job directly to the printer memory. Selection of Private Job activates the PIN field. The print job can be printed only after you type a PIN in the printer control panel. After the job is printed, the printer removes the job from the printer memory. This feature is useful when you are printing sensitive or confidential documents that you do not want to leave in an output bin after printing. Private Job stores the print job on the hard disk. After it is released for printing, the private job is immediately deleted from the printer. If more copies are needed, you will have to reprint the job from the application. If you send a second private job to the printer with the same user name and job name as an existing private job (and you have not released the original job for printing), the second job will overwrite the older job, regardless of the PIN. Private jobs are deleted if power to the printer is interrupted. Stored Job Use Stored Job to send a print job directly to the printer hard disk. The print job is stored in the printer as if it is an electronic file cabinet. After the print job is stored in the printer's hard disk, you can print the job from the printer control panel. Nothing will be printed until the job is requested from the printer control panel. 102 3 Driver features Software Technical Reference The job remains stored on the printer until it is deleted or overwritten by a document with the same user and job names. Stored jobs remain on the printer hard disk when power is interrupted. Use this feature for forms and other common or shared documents. A stored job can be handled in two ways: as either a private or a public job. If you create a private stored job, a print job is sent directly to the printer memory and can be printed only after you type a PIN in the printer control panel. (You can set the PIN in the Print dialog box.) After the job is printed, the job remains in the printer memory and can be printed again from the printer control panel. This feature is useful when you are printing sensitive or confidential documents that you do not want to leave in an output bin after printing. Private mode is initiated by selecting the Require PIN to Print check box. In this mode, you have to type a PIN at the control panel to release the job. The box labeled PIN is usually inactive. The Require PIN to Print option is activated if you click Stored Job. If the Require PIN to Print option is selected, you must type a PIN to make the stored job private. Note A private stored job is not the same as a private job (see above). Private jobs are deleted from the printer memory after they are printed. Private stored jobs are retained in the printer memory after printing, but require a PIN to be used each time the private stored jobs are printed. Software Technical Reference Windows PS driver features 103 Device Settings tab features The Device Settings tab contains controls for paper-handling devices and controls for managing the HP LaserJet product. To gain access to the Device Settings tab, click Start, click Settings, and then click Printers. Right-click the product name, click Properties, and then click the Device Settings tab. Figure 37. Device Settings tab 104 3 Driver features Software Technical Reference HP LaserJet software CD-ROM In-box file layout The HP LaserJet printer system consists of two partitions: one for installation using Windows operating systems, the other for Macintosh operating systems. The files include both documentation files and files required to install and uninstall the systems. HP LaserJet software CD-ROM, Windows partition Directory structure The files contained in the Windows partition of the HP LaserJet software CDROM, grouped by language, reside in the following directories: • • • • • • Root directory Drivers directory Fonts directory Manuals directory Reader directory Setup File layouts differ according to language for the European and Asian versions of the software CD-ROM. To view the files, insert the HP LaserJet printing system software CD-ROM, rightclick Start, click Explore, and then select the CD-ROM drive. HP LaserJet software CD-ROM, Macintosh Partition The files contained in the Macintosh partition of the HP LaserJet software CD-ROM, grouped by language, reside in the following directories: • Root directory • HP LASERJET INSTALLERS (for Macintosh operating systems) • PDF (for guides and manuals) File layouts differ according to language for the European and Asian versions of the software CD-ROM. Availability and fulfillment This section provides information about the availability of the HP LaserJet printing system software and related software and firmware. Software is available on CD-ROM from HP fulfillment centers or can be downloaded from the Web at the following URL: http://www.hp.com/support/lj5500_software Software Technical Reference HP LaserJet software CD-ROM 105 In-box CD-ROMs The HP LaserJet software CD-ROM is available in three regional versions. The following table lists the three versions of the software CD-ROM, along with the languages each version supports. Table 12. CD-ROM versions CD-ROM version Languages supported Americas Dutch (Nederland) English French (Français) German (Deutsch) Hebrew Italian (Italiano) Portuguese (Português) - Brazilian Spanish (Español) Asian English Chinese (Simplified) Chinese (Traditional) Korean Japanese Thai Rest of world Arabic Czech (Cesky) Danish (Dansk) English Finnish (Suomi) French (Français) Hungarian (Magyar) Norwegian (Norsk) Polish (Polski) Russian (Russ) Swedish (Svenska) Turkish (Turkçe) Web ordering The HP Color LaserJet 5500 software CD-ROM and related software CD-ROMs can be ordered from the http://www.hp.com/support/lj5500_cdrom Web site. Search by product name and number to find the appropriate Web links. 106 3 Driver features Software Technical Reference Web deployment Software and firmware to support HP LaserJet products are available for download from the http://www.hp.com/support/lj5500_software and http://www.hp.com/support/ lj5500_firmware Web sites. This is the preferred method for obtaining the latest software and firmware. The Web site offers a notification option for automatic e-mail notification about new software and firmware releases. Printing-system software The HP LaserJet printing system software is available for download from the HP Web site at the following URL: http://www.hp.com/support/lj5500_software The software supports the following operating systems: • Windows 95, Windows 98, and Windows Me • Windows NT 4.0, Windows 2000, and Windows XP Printer firmware Firmware to support the HP LaserJet products is available for download from the HP Web site at the following URLs: http://www.hp.com/support/lj5500_firmware Use the notification option to be notified of new firmware releases. Standalone drivers The HP LaserJet PCL 5ce, PCL 6, and PS drivers are available individually to support the following operating systems: • • • • Note Windows 95, Windows 98, and Windows Me Windows NT 4.0 Windows 2000 Windows XP PCL 5c is not supported in Asian languages. Operating system driver bundles The HP Color LaserJet 5500 PCL 5c, PCL 6, and PS drivers are available in bundled configurations to support the following operating systems: • Windows 95, Windows 98, and Windows Me • Windows NT 4.0 • Windows 2000 and Windows XP Point-and-print bundles The HP Color LaserJet 5500 PCL 6 driver is available in a point-and-print bundle to support the Windows operating environments. Software Technical Reference HP LaserJet software CD-ROM 107 Other operating systems Drivers and related software are available for these additional operating environments: • Macintosh OS (PPDs and Universal Installer) • AutoCAD (AutoCAD family drivers) • OS/2 (PCL 5c,and PS) Software component availability The following table lists the availability of HP LaserJet software components by operating system. Note In the following table, “9x/Me” refers to Windows 95, Windows 98, and Windows Me. “2K” refers to Windows 2000; “4.0” refers to Windows NT 4.0; and “XP” refers to Windows XP. Table 13. Software component availability for HP Color LaserJet 5500 product Component 9x/ Me 4.0 2K/ XP PCL 6 (Wizard) X X X PCL 5c (Wizard) X X X PScript Driver & Postscript Printer Description (PPD) X X X OS/2 Mac UNIX Linux Drivers Mac QuickDraw PPD X OS/2 IBM Drivers1 X Unix Model Script X Linux Printing Architecture X Installers Common Windows Installer X X X CD-ROM Browser X X X Customization Utility X X X Fonts X X X INF File (Add Printer) X X X Font Installer2 Macintosh Installer for OSs 8 and 9 X Macintosh Installer for OS X X Web Registration X X X Network Bidirectional Communications X X X Direct Connect Bidirectional Communications X X X Enterprise Autoconfiguration X X X Proxy server X X X Bidirectional communication 108 3 Driver features Software Technical Reference Table 13. Software component availability for HP Color LaserJet 5500 product (continued) Component 9x/ Me 4.0 2K/ XP Web JetAdmin3 X X Applet for Web JetAdmin X X OS/2 Mac UNIX Linux Remote management and status X X Macintosh LJ Utility X Printer Status and Alerts X X X Autoconfiguration X X X Adobe Acrobat Reader X X X X HP LaserJet 5500 use guide X X X X HP LaserJet 5500 Installation X X X X HP LaserJet 5500 Release Notes X X X X HP Jetdirect Guide X X X X HP Fast InfraRed Receiver Guide X X X Online Documentation Mac PS Help X Help X X X X ICC color profiles X X X X PANTONE (R)* Color profiles X X X PS Fonts X X X PS Fonts DIMM X X X Color Management Other X 1 OS/2 drivers are PCL 5, PCL 6, and PS. as a standalone utility. 3 Webjet Admin is not currently supported in Windows XP. 2Supported Software component localization The following table provides localization information about the HP LaserJet Series Printing system software. The information in this table does not necessarily reflect inbox solutions. Components that are not available in any given language are supported in English. Table 14. Software component localization for the HP Color LaserJet 5500 product Component Operating AR EN FR IT system GE SP JN KO TC SC TH SW DU PG NW FN DN CZ PO RU HU TU PS PPD 9x, 4.0, 2000, XP x1 x x x x x x x x x x1 x x x x x x x x x x x Printer Status and Alerts 9x, 4.0, 2000, XP x x x x x x x x x x x x x x x x x x x x x Macintosh PS PPD Mac x2 x x x x x x x x x x x x x x x x Software Technical Reference x x HP LaserJet software CD-ROM 109 Table 14. Software component localization for the HP Color LaserJet 5500 product Component Operating AR EN FR IT system GE SP JN KO TC SC TH SW DU PG NW FN DN CZ PO RU HU TU Macintosh LJ Mac Utility x x x x x x x x x x x Macintosh Installation Notes Mac x x x x x x x x x x x x x x x x PCL 6 9x, 4.0, 2000, XP x x x x x x x x x x x2 x x x x x x x x x x x PCL 5c 9x, 4.0, 2000, XP x x x x x x x2 x x x x x x x x x x x Printing System Installation Notes ReadMe 9x, 4.0, 2000, XP x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x Printing 9x, 4.0, System 2000, XP Release Notes (Latebreaking ReadMe) x Common Windows Installer 9x, 4.0, 2000 Web JetAdmin 4.0, 2000, UNIX x x x x x x x x x x x x x x x x x x x x Web JetAdmin Help 4.0, 2000, UNIX x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x HP Web Access Online manuals (PDF) 9x, 4.0, 2000, XP x x x x x x x x IBM OS/2 Driver PCL5C OS/2 x x x x x x x x x x x IBM OS/2 Driver - PS OS/2 x x x x x x x x x x x Standard Fonts 9x, 4.0, 2000, XP x x x x x x x x x x x x x x x x x x PS 3 Fonts 9x, 4.0, 2000, XP x x x x x x x x x x x x x x x x x x 1 For the Windows NT 4.0 operating system, the English driver is used. The English driver is used. 2 Language Key: AR = Arabic CZ = Czech DN = Danish DU = Dutch EN = English FN = Finnish FR = French GE = German HE = Hebrew HU = Hungarian IT = Italian JN = Japanese KO = Korean NW = Norwegian 110 3 Driver features Software Technical Reference PG = Portuguese PO = Polish Ru = Russian SC = Simplified Chinese SW = Swedish SP = Spanish TC = Traditional Chinese TH = Thai TU = Turkish Software Technical Reference HP LaserJet software CD-ROM 111 112 3 Driver features Software Technical Reference 4 Installing Windows printing system components Introduction This section provides system requirements and procedures for installing and removing the HP LaserJet printing system software using Windows operating systems. It also provides information about font support and system modifications. The following Windows operating systems are supported: z z Windows 95, Windows 98, and Windows Me Windows NT 4.0, Windows 2000, and Windows XP System Requirements The system requirements necessary to install and use the HP LaserJet printing system software on each supported operating system are listed below. Note The available disk space listed in the subsections below must be available on the same partition as the operating system. Windows 95, 98, Me, NT 4.0, 2000, and XP z z z z Pentium (R) processor Minimum 16 color/grayscale display with 640 by 480 pixel resolution (video graphics array [VGA]) Same amount of RAM as the minimum requirements for the operating system 93 MB of available disk space for full installation Windows 95, 98, Me, NT 4.0, 2000, and XP This section addresses the following topics: z z z z Font support General installation for Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP operating systems Detailed Windows installation instructions Setting a default printer Software Technical Reference Introduction 113 Font support Basic fonts Microsoft Windows software includes these basic fonts that can be used with any HP printer: • • • • • • • • • • • • • • Arial (R) Courier New Italic Times New Roman Italic Arial Italic Courier New Bold Times New Roman Bold Arial Bold Courier New Bold Italic Times New Roman Bold Italic Arial Bold Italic Symbol Wingdings Courier New Times New Roman Default fonts The following default fonts are installed through a Typical Installation of the HP LaserJet printing system software. Table 15. Default fonts File name Font name albr85w.TTF Albertus Extra Bold albr55w.TTF Albertus Medium olvr55w.TTF Antique Olive olvr75w.TTF Antique Olive Bold olvr56w.TTF Antique Olive Italic cgor45w.TTF CG Omega cgor65w.TTF CG Omega Bold cgor66w.TTF CG Omega Bold Italic cgor46w.TTF CG Omega Italic cgtr45w.TTF CG Times cgtr65w.TTF CG Times Bold cgtr66w.TTF CG Times Bold Italic cgtr46w.TTF CG Times Italic clar67w.TTF Clarendon Condensed Bold coronet.TTF Coronet cpsr45w.TTF CourierPS 114 4 Installing Windows printing system components Software Technical Reference Table 15. Default fonts (continued) File name Font name cpsr65w.TTF CourierPS Bold cpsr66w.TTF CourierPS Bold Oblique cpsr46w.TTF CourierPS Oblique garr45w.TTF Garamond garr65w.TTF Garamond Bold garr46w.TTF Garamond Italic garr66w.TTF Garamond Kursiv Halbfett helr45w.TTF Helvetica helr65w.TTF Helvetica Bold helr66w.TTF Helvetica Bold Oblique helr47w.TTF Helvetica Narrow helr67w.TTF Helvetica Narrow Bold helr68w.TTF Helvetica Narrow Bold Oblique helr48w.TTF Helvetica Narrow Oblique helr46w.TTF Helvetica Oblique avgr45w.TTF ITC Avant Garde Gothic Book avgr46w.ttg ITC Avant Garde Gothic Book Oblique avgr65w.TTF ITC Avant Garde Gothic Demi avgr66w.TTF ITC Avant Garde Gothic Demi Oblique bokr75w.TTF ITC Bookman Demi bokr76w.TTF ITC Bookman Demi Italic bokr35wq.TTF ITC Bookman Light bokr36w.TTF ITC Bookman Light Italic chanc___.TTF ITC Zapf Chancery Medium Italic dings___.TTF ITC Zapf Dingbats letr65w.TTF Letter Gothic letr65w.TTF Letter Gothic Bold letr46w.TTF Letter Gothic Italic marigold.TTF Marigold ncsr75w.TTF New Century Schoolbook Bold ncsr76w.TTF New Century Schoolbook Bold Italic ncsr56w.TTF New Century Schoolbook Italic ncsr55w.TTF New Century Schoolbook Roman palr65w.TTF Palatino Bold palr66w.TTF Palatino Bold Italic palr46w.TTF Palatino Italic palr45w.TTF Palatino Roman symps__.TTF SymbolPS timr65w.TTF Times Bold timr66w.TTF Times Bold Italic Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 115 Table 15. Default fonts (continued) File name Font name timr46w.TTF Times Italic timr45w.TTF Times Roman unvr65w.TTF Univers Bold unvr66w.TTF Univers Bold Italic unvr67w.TTF Univers Condensed Bold unvr68w.TTF Univers Condensed Bold Italic unvr57w.TTF Univers Condensed Medium unvr58w.TTF Univers Condensed Medium Italic unvr55w.TTF Univers Medium unvr56w.TTF Univers Medium Italic Ninety-two additional PS 3 fonts are also available on the CD-ROM. Table 16. Additional PS 3 fonts File name Font name PS_12639.TTF Albertus MT PS_12640.TTF Albertus MT Italic PS_14530.TTF Albertus MT Light PS-11120.TTF Antique Olive CompactPS PS_11119.TTF Antique Olive Roman PS_11118.TTF Antique Olive Roman Bold PS_11846.TTF Antique Olive Roman Italic PS_24516.TTF Apple Chancery Italic PS_12704.TTF Bodoni Poster PS_14508.TTF Bodoni PosterCompressed PS_12581.TTF BodoniPS PS_12585.TTF BodoniPS Bold PS_12586.TTF BodoniPS Bold Italic PS_12582.TTF BodoniPS Italic PS_24517.TTF Candid PS_24518.TTF Chicago PS_14513.TTF Clarendon Light PS_10269.TTF ClarendonPS PS_12968.TTF ClarendonPS Bold PS_10369.TTF Cooper Black PS_10370.TTF Cooper Black Italic PS_14514.TTF Copperplate32bc PS_14515.TTF Copperplate33bc PS_10249.TTF Coronet PS_10267.TTF Eurostile 116 4 Installing Windows printing system components Software Technical Reference Table 16. Additional PS 3 fonts (continued) File name Font name PS_10268.TTF Eurostile Bold PS_14512.TTF Eurostile Bold ExtendedTwo PS_14511.TTF Eurostile ExtendedTwo PS_10267.TTF Eurostile Medium PS_24509.TTF Geneva PS_13872.TTF GillSans PS_13874.TTF GillSans Bold PS_13875.TTF GillSans Bold Italic PS_14053.TTF GillSans Condensed PS_14054.TTF GillSans Condensed Bold PS_14051.TTF GillSans ExtraBold PS_13873.TTF GillSans Italic PS_13870.TTF GillSans Light PS_13871.TTF GillSans Light Italic PS_12542.TTF Goudy PS_12544.TTF Goudy Bold PS_10695.TTF Goudy Bold Italic PS_12545.TTF Goudy ExtraBold PS_12543.TTF Goudy Italic PS_14526.TTF Helvetica Condensed PS_14528.TTF Helvetica Condensed Bold PS_14529.TTF Helvetica Condensed Bold Italic PS_14527.TTF Helvetica Condensed Italic PS_24519.TTF Hoefler Text PS_24521.TTF Hoefler Text Black PS_24522.TTF Hoefler Text Black Italic PS_24520.TTF Hoefler Text Italic PS_24523.TTF Hoefler Text Ornaments PS_14503.TTF Joanna MT PS_14505.TTF Joanna MT Bold PS_14506.TTF Joanna MT Bold Italic PS_14504.TTF Joanna MT Italic PS_13778.TTF Letter Gothic Italic PS_13777.TTF Letter GothicPS PS_13779.TTF Letter GothicPS Bold PS_13780.TTF Letter GothicPS Bold Italic PS_12675.TTF Lubalin Graph PS_12677.TTF Lubalin Graph Bold PS_12625.TTF Lubalin Graph Bold Italic PS_12623.TTF Lubalin Graph Italic Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 117 Table 16. Additional PS 3 fonts (continued) File name Font name PS_94073.TTF Marigold PS_14525.TTF Mona Lisa Recut PS_24524.TTF Monaco PS_24510.TTF New York PS_12506.TTF Optima PS_12510.TTF Optima Bold PS_12511.TTF Optima Bold Italic PS_12507.TTF Optima Italic PS_14072.TTF Oxford Italic PS_11546.TTF Stempel Garamond Roman Italic PS_11545.TTF StempelGaramond Roman PS_11547.TTF StempelGaramond Roman Bold PS_11548.TTF StempelGaramond Roman Bold Italic PS_14507.TTF Taffy PS_13501.TTF Univers 45 Light PS_14023.TTF Univers 45 Light Bold PS_14024.TTF Univers 45 Light Bold Italic PS_13502.TTF Univers 45 Light Italic PS_14030.TTF Univers 47 Condensed Light Bold PS_14040.TTF Univers 47 CondensedLIght Bold Italic PS_14021.TTF Univers 55 PS_14022.TTF Univers 55 Italic PS_14029.TTF Univers 57 Condensed PS_14039.TTF Univers 57 Condensed Italic PS_13548.TTF Univers Extended Italic PS_13547.TTF Univers ExtendedPS PS_14481.TTF Univers ExtendedPS Bold Italic PS_14480.TTF Univers ExtendedPS Italic Installation instructions General installation for Windows 95, 98, Me, NT 4.0, 2000, and XP OSs General installation instructions for the Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP operating systems are similar. If the HP LaserJet product is connected through a file or print server, the HP LaserJet printing system software must first be installed on the server before being installed on any client systems. If the HP LaserJet printing system software is not first installed on the server, bidirectional communication, some Driver Autoconfiguration methods, and Printer Status and Alerts will not be available to the client systems. 118 4 Installing Windows printing system components Software Technical Reference For Windows NT 4.0, Windows 2000, and Windows XP, administrator rights on the system are necessary to install the software. When the HP LaserJet printing system installer runs, the HP LaserJet uninstaller is always added to the system. Installing from the printing system CD-ROM To install the HP LaserJet printing system from the CD-ROM that came with your product, follow these instructions: Step 1 Close all applications. Step 2 Insert the CD-ROM in the CD-ROM drive. Note If your CD-ROM does not start automatically, click Start, click Run, and then browse to and click the SETUP.EXE file in the root location of the CD-ROM. Step 3 Click Install Printer and follow the onscreen prompts. Installing from a network or from downloaded files Follow these instructions if you downloaded the files from the Web, or if you are installing the printing system files from a network. You may need to see your administrator for the location of the printing system software file. Step 1 Browse to the location of the SETUP.EXE file. Step 2 Double-click the SETUP.EXE file. Step 3 Click Install Printer and continue to follow the instructions until the product is installed. For detailed installation instructions, see “Detailed Windows installation.” Detailed Windows installation This section provides information about the installation dialog box sequence for installing the HP LaserJet printing system software in Microsoft Windows environments. You can choose to install the software by using either a Typical Installation or a Custom Installation. Typical Installation dialog box sequence Note The dialog boxes shown here appear in the Windows NT 4.0 installation sequence. The order and appearance of dialog boxes can vary among operating systems. The Typical Installation includes the following components: • HP LaserJet PCL 6 driver. • Screen fonts. • Driver Autoconfiguration (in environments that support bidirectional communication). This option will not appear in unsupported bidirectional communications environments. Note The components of a typical installation might vary from product to product. Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 119 When you select the Install Printer option from the HP LaserJet software CD-ROM browser, the Choose Setup Language dialog box appears. This dialog box does not appear when the setup language is Hebrew or Arabic. Figure 38. Choose Setup Language dialog box Note The Choose Setup Language dialog box lists only the languages available on the particular HP LaserJet software CD-ROM you are using. Table 17. Choose Setup Language dialog box text strings Title of dialog box Text in dialog box Choose Setup Language Select the language for this The installer automatically detects installation from the choices below: your computer system language and presents this choice as the default. [Drop-down menu lists available languages for installation.] OK [button] Cancel [button] User options and descriptions You can select another language available on the CD-ROM by clicking the down arrow of the dropdown menu. Click OK to initiate the printing system setup. Click Cancel to go to the Exit Setup dialog box. Next, the Setup dialog box appears. Figure 39. Setup dialog box 120 4 Installing Windows printing system components Software Technical Reference Note While the Setup dialog box appears, the installer is decompressing files into the system Temp directory. The elapsed time to complete this action depends upon the performance of the system. Table 18. Setup dialog box text strings Title of dialog box Text in dialog box User options and descriptions Setup HP LaserJet 5500 Series Printing System Setup is preparing the InstallShield (R) Wizard that will guide you through the rest of the setup process. Please wait. No user options. This is an information-only dialog box. Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 121 Figure 40. Welcome dialog box Table 19. Welcome dialog box text strings Title of dialog box Text in dialog box Welcome Welcome to the color HP LaserJet Next takes you to the 5500 Series Printing System Setup HP Software License Agreement Wizard. dialog box. It is strongly recommend that you close all other applications before running this Setup wizard. Before continuing, refer to the Setup poster and make any required connections. User options and descriptions Click Installation Notes to open the file READXXXX.RTF Click Cancel to go to the Exit Setup dialog box. Click Next to continue. Copyright Hewlett-Packard XXXX 122 4 Installing Windows printing system components Software Technical Reference Figure 41. HP Software License Agreement dialog box Table 20. HP Software License Agreement dialog box text strings Title of dialog box Text in dialog box User options and descriptions HP Software License Agreement Please read the following license agreement. Use the scroll bar to view the entire agreement. Yes takes you to the Web Update dialog box. [Scrolling fields with text of license agreement] Back returns you to the Welcome dialog box. No takes you to the Exit Setup Do you accept the terms of the dialog box. preceding license agreement? If so, click Yes. If you click No, Setup will close. Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 123 Figure 42. Web Update dialog box 124 4 Installing Windows printing system components Software Technical Reference Table 21. Web Update dialog box text strings Title of dialog box Text in dialog box Web Update Setup can look for updated software This is a conditional dialog box; that at the Hewlett-Packard Web site. is, it appears only if the Setup program determines there might be an Internet connection available. Would you like Setup to check the Web for updated software? (Conditional) User options and descriptions Yes (requires an active Internet connection) [option button] No [option button] If No is selected, Next takes you to the Type of Connection dialog box. This is the default option. If Yes is selected, clicking Next starts the Web Update. Details of the Internet installation are not covered in this document. Web Update requires Internet Explorer 4.0 or later. Back returns you to the HP Software License Agreement dialog box. Cancel takes you to the Exit Setup dialog box. Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 125 Figure 43. Type of Connection dialog box Table 22. Type of Connection dialog box text strings Title of dialog box Text in dialog box Type of Connection Please select the way your printer will be connected: Connected to this computer (by parallel cable, USB cable or IR) [option button] Connected to the network (that is, the printer is connected directly to the network or shared through another computer on the network) [option button] User options and descriptions If Connected to this computer (a “direct connection” using a parallel cable, universal serial bus cable, or infrared connection) is selected, Next takes you to the Select Port dialog box. This is the default option. If Connected to the network is selected, Next takes you to the Network Setup dialog box. Back returns you to the HP Software License Agreement dialog box. Cancel takes you to the Exit Setup dialog box. 126 4 Installing Windows printing system components Software Technical Reference Figure 44. Select Port dialog box Figure 45. Select Port dialog box Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 127 Table 23. Select Port dialog box text strings Title of dialog box Text in dialog box User options and descriptions Select Port Select the port you want to use with Regardless of the port chosen this printer: (Parallel or Other), clicking Next takes you to the printer Model dialog box. (If Connected to this computer was selected in the Type of Connection Parallel [option button] dialog box) [Default. When selected, a pullClicking Back returns you to the down list of parallel ports is Type of Connection dialog box. available.] The Express Install check box, Express Install using HP selected by default, will install the recommended defaults [check box] PCL 6 driver. Other [option button] [When selected, a pull-down list of other port types is available] 128 4 Installing Windows printing system components Clicking Cancel takes you to the Exit Setup dialog box. Software Technical Reference Figure 46. Network Setup dialog box Figure 47. Network Setup dialog box Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 129 Table 24. Network Setup dialog box text strings Title of dialog box Text in dialog box User options and descriptions Network Setup Indicate the type of network connection If you choose the Client Setup option, Next takes you to the Specify Network Path dialog box, and then to the Installation Type dialog box. [If Connected to the network was selected in the Type of Connection Basic Microsoft Server Setup dialog box], Next takes you to the Create a connection (network port) Network Printer Configuration to a printer attached directly to the dialog box. network. Your computer will manage its own print jobs and may optionally share the printer with other network users. [option button] If the Help me option is chosen, Next initiates a series of question dialog boxes that help you determine the best connection type option to follow. This series begins with the Cable Type Selection dialog box. Client Setup Back returns you to the Type of The printer is already set up as a Connection dialog box. shared printer on the network and is managed by a server or another computer. Cancel takes you to the Exit Setup dialog box. [option button] Help me determine which setup is right for me Setup will ask you questions to help you determine the appropriate network setup for your situation. [option button] 130 4 Installing Windows printing system components Software Technical Reference Table 25. Network Printer Configuration dialog box text strings Title of dialog box Text in dialog box User options and descriptions Network Printer Configuration How do you want to identify the network printer you are installing? If you click Search from a list of available printers, Next takes you to the Identify Printer dialog box. Search from a list of available printers [option button] If you click Specify a printer by address, Next takes you to the Identify Printer dialog box. [Description] Searches the local network for printers and allows you to choose your printer from a list of Always choose Specify a printer by discovered printers. address when the printer address is available. On large networks, selecting Search from a list of available printers might not result Specify a printer by address in the location of a specific printer. [option button] Back returns you to the Network [Description] Allows you to specify Setup dialog box. your printer by entering one of the following attributes: Hardware Address, IP Address, IP Hostname, Cancel takes you to the Exit Setup or IPX Address. dialog box. Description [Conditional text] Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 131 Figure 48. Identify Printer dialog box (1 of 2) Figure 49. Identify Printer dialog box (2 of 2) 132 4 Installing Windows printing system components Software Technical Reference Table 26. Identify Printer dialog box text strings Title of dialog box Text in dialog box User options and descriptions Identify Printer Select the network printer you want If you identify the printer by selecting from the list, and your HP LaserJet to install. product appears in the list and is selected, Next takes you to the Set Network Communication Mode Printers on your local network: dialog box. [List, with attributes of Hardware Address, IP Address, and IPX Address listed, if available] If your HP LaserJet product is not found on the network, click Refresh or go back to the Network Printer If your printer is not found on the Configuration dialog box to specify list, click ’Refresh’, or go back and the device by address. click ’Specify a printer by address’. Refresh updates the list of network printers. OR Specify the network printer you want to install. Specify by: Hardware Address. [option button] [text field] IP Address [option button} If you identify the printer by specifying a specific network address, Next takes you to the Set Network Communication Mode dialog box. Back returns you to the Network Printer Configuration dialog box. Cancel takes you to the Exit Setup dialog box. [text fields] IP Hostname [option button] [text field] IPX Address [option button} [text fields] Description [Conditional text] Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 133 Figure 50. Specify Network Path dialog box Table 27. Specify Network Path dialog box text strings Title of dialog box Text in dialog box Specify Network Path Type the network path or the queue If a network path or queue name is name of your printer. If you do not entered, Next takes you to the know its name, click Browse to view Cable Type Selection dialog box. the available network printers. Network path or queue name: [text field] User options and descriptions NOTE: If you reached this dialog box from the Connected to Selection dialog box, Next takes you to the Installation Type dialog box. Browse ...[button] Click Browse to bring up a list of devices available on the network. Back returns you to the Network Setup dialog box. Cancel takes you to the Exit Setup dialog box. 134 4 Installing Windows printing system components Software Technical Reference Figure 51. Set Network Communication Mode dialog box Table 28. Set Network Communication Mode dialog box text strings Title of dialog box Text in dialog box Set Network Communication Mode Select a communication mode for this printer [drop-down menu: User options and descriptions Select a communication mode and type the appropriate address information. Windows TCP/IP (recommended) After you have specified a communications mode, Next takes you to the printer Model dialog box. other modes listed] TCP/IP Settings [Conditional fields for entering TCP/ Back returns you to the Identify Printer dialog box. IP or other address information] Use default port name [check box] Software Technical Reference Cancel takes you to the Exit Setup dialog box. Windows 95, 98, Me, NT 4.0, 2000, and XP 135 Figure 52. Printer Model dialog box Table 29. Printer Model dialog box text strings Title of dialog box Text in dialog box User options and descriptions Model Select the model you are setting up. Next takes you to the Installation Type dialog box. Model: [List of HP LaserJet models] Description [Conditional text, depending upon which model is chosen in the list] Back returns you to the Select Port dialog box when you are performing a direct connection installation, or to the Set Network Communication Mode dialog box when you are performing a network installation. Cancel takes you to the Exit Setup dialog box. 136 4 Installing Windows printing system components Software Technical Reference Figure 53. Installation Type dialog box Note The components of a Typical Installation might vary from product to product. Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 137 Table 30. Installation Type dialog box text strings Title of dialog box Text in dialog box User options and descriptions Installation Type Choose the installation type. If Typical Installation is selected, Next takes you to the Printer Name dialog box. Typical Installation [option button] z HP color LaserJet 5500 PCL 6 Driver z Automatic Driver Configuration z Screen Fonts Custom Installation [option button] Recommended for advanced users If Custom Installation is selected, and system administrators. Next takes you to the Components Provides more flexibility for dialog box. installing drivers and software. Back returns you to the printer Model dialog box. Cancel takes you to the Exit Setup dialog box. 138 4 Installing Windows printing system components Software Technical Reference Figure 54. Printer Name dialog box Table 31. Printer Name dialog box text strings Title of dialog box Text in dialog box User options and descriptions Printer Name Specify a name for this printer. You Next takes you to the Printer can use the name supplied below or Sharing dialog box. type a new one. The name will be used to identify the printer in your Printers folder. The default printer name in the text field is HP LaserJet 5500 PCL 6. Printer Name: [text entry field] Back returns you to the Installation Type dialog box. Do you want your Windows-based programs to use this as the default printer? Cancel takes you to the Exit Setup dialog box. Yes [option button] No [option button] Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 139 Figure 55. Printer Sharing dialog box Note When you do not share the printer, additional driver support is not available. If you share the printer on Windows NT 4.0, Windows 2000, or Windows XP operating systems by selecting Share as, you must type a name. You can also provide additional printer driver support for other operating systems. 140 4 Installing Windows printing system components Software Technical Reference Table 32. Printer Sharing dialog box text strings Title of dialog box Text in dialog box User options and descriptions Printer Sharing Indicate whether this printer will be Next starts the file copy process. shared with other network users. If you choose sharing, give the printer a share name. Back returns you to the Printer Name dialog box. Not shared [option button] Cancel takes you to the Exit Setup dialog box. Share as [text entry field] NOTE: Exceeding 7 characters may make the printer inaccessible to Windows 95/98/Me clients. A share will be created for each driver type using the name specified above. Example: LJ 7900. Client Driver Support Additional drivers can be installed on this computer to support automated driver download to clients. Install a Windows 95/98/Me driver. [check box] Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 141 Figure 56. Finish dialog box Figure 57. Finish dialog box 142 4 Installing Windows printing system components Software Technical Reference Table 33. Finish dialog box text strings Title of dialog box Text in dialog box User options and descriptions Finish Your HP LaserJet 5500 printer has been successfully installed. Finish completes the installation process and initiates test-page printing and Web-page registration if those options are selected. Installation Details [button] Select the actions to perform when Setup finishes. Print a test page [check box] Click Installation Details to open a dialog box that shows installation details. NOTE: If the computer must be restarted, the Print a test page and Web Registration functions will occur after the computer is started. Web Registration [check box] Figure 58. Exit Setup dialog box Figure 59. Exit Setup dialog box Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 143 Table 34. Exit Setup dialog box text strings Title of dialog box Text in dialog box User options and descriptions Exit Setup Setup is not complete. If you quit the Setup program now, the program will not be installed. Exit Setup quits the Installer program. [when Cancel is selected during installation] Resume takes you to the dialog box You can run the Setup program at a you most recently canceled. later time to complete the installation. To continue installing the program, click Resume. To quit the Setup program, click Exit Setup. Custom installation The custom installation gives you the option of installing the following components: • • • • • • • Note HP color LaserJet 5500 PCL 6 driver (for direct-connect and network installations) HP color LaserJet 5500 PCL 5c driver (for direct-connect and network installations) HP color LaserJet 5500 PS driver (for direct-connect and network installations) Automatic Driver Configuration (for network installations) Printer Status and Alerts (for network installations) Screen fonts (for direct-connect and network installations) User Guide (for direct-connect and network installations) The components of a Custom Installation might vary from product to product. 144 4 Installing Windows printing system components Software Technical Reference Note Windows NT 4.0, Windows 2000, and Windows XP computers running a terminal server do not support the Printer Status and Alerts option. Figure 60. Components dialog box, Custom Installation Note The appearance of this screen might vary, depending on product and connection type. Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 145 Table 35. Custom Installation dialog box text strings Title of dialog box Text in dialog box Components Select the components you want to Next takes you to the Printer Name dialog box. install. Components: [list] User options and descriptions Back returns you to the Installation Type dialog box. Description [Conditional text, according to the item currently highlighted in the list] Space Required [Specifies disk space required to install components currently selected in list] Space Available [Specifies disk space available on disk drive specified in Choose Destination Location dialog box (00)] Cancel takes you to the Exit Setup dialog box. NOTE: Custom Installation automatically selects the options available in the Typical Installation. You can also select from among the following components: z hp color LaserJet 5500 PCL 6 Driver z hp color LaserJet 500 PCL 5c Driver z hp color LaserJet 5500 PS Driver z Automatic Driver Configuration z Printer Status and Alerts z Screen Fonts z User Guide Product registration (HP WebReg) The HP LaserJet software CD-ROM browser provides two options for registering the HP LaserJet product: • Registration through the Internet to the http://register.hp.com Web site • Registration by e-mail Note Web registration for reverse-directional languages is in English. 146 4 Installing Windows printing system components Software Technical Reference To gain access to the product-registration options, go to the main menu of the HP LaserJet software CD-ROM browser and click Register Product. This starts the HP WebReg utility and opens the following window. Figure 61. Hewlett-Packard’s Electronic Registration dialog box Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 147 Table 36. Hewlett-Packard’s Electronic Registration text strings Title of dialog box Text in dialog box User options and descriptions Hewlett-Packard's Electronic Registration Welcome to HP's registration. This information is confidential and for HP registration purposes only. This is the fastest and easiest way for you to join our select group of HP owners who register to receive: Click the WWW Registration button to open the default Web browser and connect to the product registration page at the http://register.hp.com Web site. Direct-to-you details about: z ideas and ways to use your new HP product. z other exciting HP products. z news about emerging technologies. Click the Electronic Registration button to open the Welcome to HewlettPackard's Registration dialog box. Click the Exit button to open the Exiting Registration! dialog box. Technical support updates. If you have internet access and would like to register using our World Wide Web registration page, click here: WWW Registration [button] [default option] If you do not have internet access or would rather register using email, please click here to continue with Hewlett-Packard's Electronic Registration. Electronic Registration [button] Exit [button] 148 4 Installing Windows printing system components Software Technical Reference Figure 62. Welcome to Hewlett-Packard’s Registration dialog box Table 37. Welcome to Hewlett-Packard’s Registration dialog box text strings Title of dialog box Text in dialog box User options and descriptions Welcome to Hewlett-Packard's Registration Welcome to HP's electronic registration. This information is confidential and for HP registration purposes only. Click the Previous button to return to the Hewlett-Packard's Electronic Registration dialog box. Please select the country/region Click the Continue button to start a where you are located. [drop-down sequence of three screens. The menu] first screen provides fields for typing your registration information. The second screen prompts you for information about your HP LaserJet Please continue to go to the next screen and begin your registration 5500 product. The third screen gives you the option of sending the e-mail message to register the product. Previous [button] Continue [button] [default option] Click the Exit button to open the Exiting Registration! dialog box. Exit [button] Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 149 Figure 63. Hewlett-Packard’s Electronic Registration dialog box (1 of 3) 150 4 Installing Windows printing system components Software Technical Reference Table 38. Hewlett-Packard’s Electronic Registration dialog box text strings (1 of 3) Title of dialog box Text in dialog box User options and descriptions Hewlett-Packard's Electronic Registration Please complete the following (required fields are denoted by a blue asterisk): Click the Previous button to go back to the Welcome to HewlettPackard's Registration dialog box. [The following items are fields unless otherwise noted.] Click the Continue button to go to the second screen in this sequence. First name* Click the Exit button to open the Exiting Registration! dialog box. [This is the first of three screens.] Middle Initial Last Name* Company/Organization Name* Building/Mail Stop/Dept. Mailing Address* City/Town* State* [drop-down menu] Zip Code* E-mail Address Telephone Number Extension Occasionally HP communicates information about products and/or programs that might be relevant to you. Please select the method(s) HP can use to contact you. (check all that apply) E-mail [check box] Mail [check box] Telephone [check box] Please don't contact me unless I specifically request it [check box] Previous [button] Continue [button] Exit [button] Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 151 Figure 64. Hewlett-Packard’s Electronic Registration dialog box (2 of 3) 152 4 Installing Windows printing system components Software Technical Reference Table 39. Hewlett-Packard’s Electronic Registration dialog box text strings (2 of 3) Title of dialog box Text in dialog box User options and descriptions Hewlett-Packard's Electronic Registration Please tell us about the HewlettPackard product you purchased: Click the Previous button to go back to the first screen in this sequence. [This is the second of three screens.] Where will your new HewlettPackard product primarily be used?* [drop-down menu] Click the Continue button to go to the third screen in this sequence. Which Hewlett-Packard product did Click the Exit button to open the you purchase?* [drop-down menu] Exiting Registration! dialog box. When did you purchase your Hewlett-Packard product?* [field] Type the date you purchased your Hewlett-Packard product. Serial Number* [field] Type the product’s serial number. Approximately how many employees work at your...site? Worldwide? The questions about the number of employees and your job responsibility (answering is optional) appear only if you answered that you will use your What is your job responsibility as it Hewlett-Packard product primarily for business or telecommuting. relates to HP products? Dropdown boxes with possible answers are provided for your convenience. Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 153 Figure 65. Hewlett-Packard’s Electronic Registration dialog box (3 of 3) Table 40. Hewlett-Packard’s Electronic Registration dialog box text strings (3 of 3) Title of dialog box Text in dialog box User options and descriptions Hewlett-Packard's Electronic Registration Please send your registration to Hewlett-Packard via e-mail. [This is the third of three screens.] E-mail [button] [default option] Click the E-mail button to send an e-mail to HP containing the registration information you specified. A thank-you screen appears when the e-mail is sent. Previous [button] Click the Previous button to go back to the second screen in this sequence. Exit [button] Click the Exit button to open the Exiting Registration! dialog box. 154 4 Installing Windows printing system components Software Technical Reference Figure 66. Exiting registration! dialog box Table 41. Exiting registration text strings Title of dialog box Text in dialog box User options and descriptions Exiting Registration! You have selected to exit HewlettPackard's registration. Click the Continue button to go back to the screen where you were when you clicked the Exit button. If you would like to continue with registration, please press the continue button to return to the place where you exited. Click the Exit button to close the WebReg utility. Continue [button] [default option] Otherwise, you can go to the universal resource locator (URL) below to register your product at any time. http://register.hp.com/go/register Thank you for your valuable time! Exit [button] Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 155 Customization Utility for Windows Use the Customization Utility button to create your own customized installation of printing-system components. To start the utility, click Customization Utility on the main menu of the HP LaserJet software CD-ROM browser. The available options for creating a customized installation are: • Copy printer drivers only. Using this option, you can copy the HP LaserJet Windows printer drivers to a selected form of media (disk, CD-ROM, network drive, and so on). You can use the resulting disk set with the Windows Add Printer Wizard. The Customization Utility prompts these choices: • operating system • printer model • printing system components (drivers to copy) • destination path • Create customized installer. Using this option, you can create either an interactive or silent (unattended) installer customized by any of the following selections: • operating system • printer model • printing system components • interactive or silent (unattended) installer • Copy entire printing system installer. Using this option, you can copy the HP LaserJet printing system installer to a selected form of high-capacity media such as a network drive. The customization utility prompts these choices: • Language • Operating system Silent installer You can use the HP LaserJet printing system software to create a silent installer that runs the SETUP.EXE program without user interaction. This installation method is useful when you want to use the default selections provided by the installer or when you want to run the installation without being prompted. You also have the option of creating a custom disk image that contains specific drivers and utilities, allowing users to run the installer without further interaction. Silent installation can be performed in two ways: • Customized silent installer • Command-line silent installer Customized silent installer Use this option to select the printing-system components to include in the silent installation. You can select the operating system, language, printer models, drivers, utilities, and documentation to install. 156 4 Installing Windows printing system components Software Technical Reference Driver Management and Configuration Utility (Internal) Driver Management and Configuration (DMC) is a software architecture and set of tools that permits HP and third-party software to be customized and distributed within managed corporate printing environments. It provides network administrators with the capability to preconfigure printer drivers and other printing software and manage that software on client workstations remotely. With DMC, customized printer settings can be retained during driver updates, rather than be replaced with the default settings of the new driver. Command-line silent install This method cannot be customized and installs only the printing-system components that are included in the Typical Installation. Note Values that follow equal signs ( = ) in a command line must not contain intervening spaces. Method 1: Command line Type the following at the command line (do not type the beginning and ending quotation marks): "<CD-ROM-ROOT>/SETUP/SETUP.EXE /U /PORT=XXXX /PRINTER=N / PD=N" Method 2: SETUP.LST Use the SETUP.LST file to specify command-line arguments to the installer for an unattended installation. You can send command-line arguments in one of the following ways: • • • Send the command directly to the installer. Send the command using the SETUP.LST file located in the setup directory. Use a combination of the two methods. For example, this file contains two options: /port and /printer. The installer operates as normal because the /u option has not been specified. If you use setup /u for the installer, it operates in unattended mode and uses the two values specified in the defaults section of the SETUP.LST file. If you use setup /u / printer=4 for the installer, it operates in unattended mode and chooses the HP LaserJet 5500. The options specified on the command line override the options specified in the SETUP.LST file. The options available can also include the /u option. Using this option key makes the installer always operate as unattended. The following descriptions explain the available options: • /u signals the installer to use the specified port and printer given on the command line (or in this file), and to use all default selections. Installation then proceeds without prompting the user. • /port=xxxx is used to specify the default port when performing an unattended installation. The value specified by xxxx should be a valid port and should contain no spaces; for example, LPT1 • /printer=n is used to specify the default printer when doing an unattended installation. The value specified by “n” is an integer that references the list of available printers. For example, the following printers are available for the HP LaserJet 5500 series printer installation: Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 157 0 = HP LaserJet 5500 printer 1 = HP LaserJet 5500n printer 2 = HP LaserJet 5500dn printer 3 = HP LaserJet 5500dtn printer 4 = HP LaserJet 5500hdn printer • /pd=n is used to specify whether the selected printer is the default printer, when you have multiple printers connected to your network. The value specified by n is an integer (that is, 0 or 1). For this argument, entering 1 (one) sets the selected printer as the default printer. Entering zero (0) or not specifying a value at all sets the printer as a non-default printer. You can preset these options in the SETUP.LST file located in the root directory of the HP LaserJet software CD-ROM. In the defaults section, add the following syntax: [Defaults] Options= /port=<value> /printer=<number> /pd=<number> For example, <value> = LPT1, Driver-only installation Step 1 Close all software applications. Step 2 Click Start, click Settings, and then click Printers. Step 3 Double-click Add Printer. Step 4 Answer the questions in the Add Printer Wizard dialog box until you reach the screen with the printer manufacturer list. Step 5 Click Have Disk. Step 6 Browse to the driver location using one of these options: • Inbox CD-ROM. Browse to the appropriate directory for your operating system and language. • Internet download. Browse to the folder where the Web files were downloaded and decompressed. Step 7 Select the appropriate information (.INF) file. Step 8 Click Open, and then click OK. Step 9 Select the appropriate printer. Step 10 Follow the remaining instructions to complete the printer installation. At this point, the driver has been copied to your hard disk and is included with the list of installed printers. Point and Print installation for Windows 95, 98, Me, NT 4.0, 2000, and XP The following information will assist you as you install a printer driver using the Microsoft Point and Print function when you cannot see the printer on the network. Point and Print is a Microsoft term used to describe a two-step driver installation process. The first step is to install a shared driver on a network print server. The second step is to “point” to the print server from a network client so that the client can use the print driver. 158 4 Installing Windows printing system components Software Technical Reference Note This section outlines the procedures for installing print drivers with Point and Print. If these procedures are not successful, contact Microsoft. Hewlett-Packard provides drivers that are compatible with the Point and Print feature, but this is a function of the Microsoft operating systems, not of HP print drivers. Windows NT, Windows 2000, and Windows XP drivers from HP are supported only on Intel X86 (R) processor types. Any other processor types must use Windows NT drivers from Microsoft. To install the printer driver on a Windows NT 4.0, Windows 2000, or Windows XP server, you must have administrator privileges. To completely install the Windows NT 4.0 printer driver on the Windows NT 4.0 server (or the Windows 2000 printer driver on the Windows 2000 server), you must have administrator privileges on the server. The Windows NT 4.0 Printer .INF file (or the Windows 2000 Printer .INF file) must contain the same printer name as the Windows 95, Windows 98, or Windows Me printer .INF file. Point and Print installation of a PS driver is supported only with a Microsoft Windows 95, Windows 98, or Windows Me PS driver version 4.0 or later. For all operating systems, use the Add Printer Wizard to install the appropriate operating system driver on the server and client machines, as shown in the following table. Table 42. Windows servers with Windows clients Computer function Steps Server and clients 1. Click Start, click Settings, and then click Printers. Server and clients 2. In the Printers folder, double-click the Add Printer icon to start the Add Printer Wizard. Server only 3. Click Next, and then click Local Printer. Click Next. If your operating system is Windows 95, Windows 98, or Windows Me, go to step 6. Server and clients 4. Select the appropriate port in the list of ports, or click Add Port to connect to a network port not in the list of available ports. Server and clients 5. Select the printer model in the list of available printers, or click Have Disk if installing the driver from an alternative source, such as disk, CDROM, or software download. If installing from a software download, you must know the path where the software has been downloaded. Server only 6. After the installation is complete, highlight the Printer icon and click File, and then click Properties. In the Printer Properties window, click the Sharing tab. Server only 7. You must enable the File and Print Sharing service for either Microsoft networks or Novell networks on the server. Server only 8. To exit Properties, click OK. A hand appears beneath the Printer icon in the Printers folder, indicating that the printer is shared. Software Technical Reference Windows 95, 98, Me, NT 4.0, 2000, and XP 159 Table 42. Windows servers with Windows clients (continued) Computer function Steps Client only 9. You can install the driver using Point and Print in one of the following four ways: · In Network Neighborhood, locate the server and double-click the printer share name. · In Network Neighborhood, locate the server. Then drag and drop the icon for the shared printer into your Printers folder. · In the Printers folder, open the Add Printer Wizard. Then, depending on the operating system: · For Windows 95, Windows 98, and Windows Me, click Network Printer. · For Windows NT 4.0, Windows 2000, and Windows XP, click Network printer server. Client only 10. Click Next. Type the network path or queue name, or choose Browse to search the network to locate the appropriate path. Client only 11. In Network Neighborhood, locate the server and double-click. Then locate the printer share name and right-click. Client only 12. Click Install to complete the installation through the Add Printer Wizard. Setting a default printer This section applies to the Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP operating systems. Step 1 From the Start menu, click Settings, and then click Printers. Step 2 Select the printer you want to set as the default printer. Step 3 From the File menu, click Set As Default. A check mark appears next to the menu option. Step 4 Click Close. Windows 3.1x Printer support z The HP Color LaserJet 5500 printer has not been tested with and is not supported with Windows 3.1x. 160 4 Installing Windows printing system components Software Technical Reference 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Introduction This section provides system requirements and procedures for installing and removing the HP LaserJet printing system software for supported operating system other than Windows. It also provides information about font support and system modifications. Supported operating systems include: z z z Macintosh IBM OS/2 Linux System Requirements System requirements necessary to install and use the HP LaserJet printing system software on each supported operating system are listed below. Macintosh z z z z 68-kilobyte processor Macintosh OS 8.6 or later 16 MB RAM 20 MB available disk space IBM OS/2 z z z Pentium processor 32 MB RAM (required for OS/2) 5 MB available disk space (required for driver) Linux For information about Linux support for the printer, see the following Web sites: z z http://hp.sourceforge.net (HP Linux support home page) http://www.hp.com/go/linux (Hewlett-Packard’s Linux Web site) Software Technical Reference Introduction 161 Macintosh Macintosh component descriptions The printer includes the following software for Macintosh computers. PPDs (Mac OS 8.6 to 9.x and Mac OS X classic) HP LaserJet PPDs These PS printer-definition files for HP LaserJet products are installed to the Printer Descriptions folder, which is in the Extensions folder within the System folder. PPDs, in combination with the LaserWriter driver, provide access to the printer features and allow the computer to communicate with the printer. An installation program for the PPDs is provided on the printing software CD-ROM. For Mac OS 8.6 to 9.x, the Apple LaserWriter 8 driver must be installed to use the PPD file. Use the Apple LaserWriter 8 driver that came with your Macintosh. For Mac OS X, use Print Center to print. PDEs (Mac OS X) Printer Dialog Extensions (PDEs) are code plug-ins that provide access to printer features, such as number of copies, duplexing, and quality settings. An installation program for the PDEs and other software is provided on the printing software CD-ROM. HP LaserJet Utility This Hewlett-Packard printer utility is installed to the HP LaserJet folder in Macintosh OS 8.6 to 9.1 Macintosh systems. It provides configuration and management support for PS and PCL printers. HP LaserJet Utility allows control of features that are not available in the driver. The illustrated screens make selecting printer features from the Macintosh computer easier than ever. Use the HP LaserJet Utility to do the following: • customize the printer’s control panel messages. • name the printer, assign it to a zone on the network, download files and fonts, and change most of the printer settings. • set a password for the printer. • from the computer, lock out functions on the printer’s control panel to prevent unauthorized access. (See the printer software help.) Installation notes This text file contains important information about product features, instructions for installing the printing-system software, and technical assistance. ColorSync profiles These text files contain color-matching information for the Macintosh system and HP LaserJet color printers. 162 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Software Technical Reference Online Help This HTML-based help system replaces the Apple Guide help system provided with earlier HP printers. The help system can be viewed through a browser or in the Macintosh OS Help Center. HP Auto Setup Utility This utility is installed to the Startup Items folder of Macintosh OS 8.6 and newer Macintosh systems. It provides assistance to set up a new printer, then moves itself to Trash. Screen fonts These screen fonts are available only for Macintosh computers and Macintosh compatibles. The screen fonts match your printer fonts, allowing you to see on screen how your printed page will look. Font support To ensure that you can use all installed fonts with the HP LaserJet product, the Macintosh printing system includes the standard 35 screen fonts in 11 families: • • • • • • • • • • • Avant Garde Helvetica Narrow Times (R) Bookman New Century Schoolbook Zapf Chancery Courier Palatino Zapf Dingbats Helvetica (R) Symbol The Macintosh printing system also includes the HP 45 XPS font families: • • • • • • • • • • • • • Software Technical Reference Clarendon Condensed Bold Symbol Albertus Medium Coronet Times New Roman Antique Olive Courier Univers Arial Garamond Univers Condensed CG Omega Letter Gothic Macintosh 163 • Wingdings • CG Times • Marigold The following bitmap screen fonts reside on the HP LaserJet product: • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • ITC Avant Garde Gothic Book Helvetica Palatino ITC Avant Garde Gothic Book Oblique Helvetica Bold Palatino Bold ITC Avant Garde Gothic Demi Helvetica Bold Oblique Palatino Bold Italic ITC Avant Garde Gothic Demi Oblique Helvetica Oblique Palatino Italic ITC Bookman Demi Helvetica Narrow Symbol ITC Bookman Demi Italic Helvetica Narrow Bold Times Bold ITC Bookman Light Helvetica Narrow Bold Oblique Times Bold Italic ITC Bookman Light Italic Helvetica Narrow Oblique Times Italic Courier New Century Schoolbook Bold Times Roman Courier Bold New Century Schoolbook Bold Italic ITC Zapf Chancery Medium Italic Courier Bold Oblique New Century Schoolbook Italic ITC Zapf Dingbats Courier Oblique New Century Schoolbook Roman 164 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Software Technical Reference The following fonts are resident on all HP LaserJet products, but can be used by Macintosh platforms only by installing additional screen fonts. You can either use these screen fonts directly from the HP LaserJet software CD browser, or obtain them from the HP Web site at CD-ROM. • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Software Technical Reference Albertus Extra Bold CG Times Italic Marigold Albertus Medium Clarendon Condensed Bold Symbol Antique Olive Coronet Times New Roman Antique Olive Bold Courier Times New Roman Bold Antique Olive Italic Courier Bold Times New Roman Bold Italic Arial Courier Bold Oblique Times New Roman Italic Arial Bold Courier Italic Univers Bold Arial Bold Italic Garamond Antiqua Univers Bold Italic Arial Italic Garamond Halbfett Univers Condensed Bold Italic CG Omega Garamond Kursiv Univers Condensed Medium CG Omega Bold Garamond Kursiv Halbfett Univers Condensed Medium Italic CG Omega Bold Italic Letter Gothic Univers Medium CG Omega Italic Letter Gothic Bold Univers Medium Italic CG Times Letter Gothic Italic Univers Italic Macintosh 165 • • • • CG Times Bold CG Times Bold Italic Wingdings CG Times Bold Italic Installing the Macintosh printing system On a Macintosh-compatible computer, the installation procedures are the same for a network administrator, a network client, and a single user. Install the software on any computer that has access rights to the printer. Note If the computer is connected to the product by a LocalTalk (Printer Port) or EtherTalk connection, the AppleTalk (or Network) control panel must be configured for the correct connection to communicate with the product. The HP LaserJet product must be set up, connected to the computer, and turned on before the software is installed. Macintosh OS systems do not support parallel connections. You must use a USB connection for a direct connection to a computer running Macintosh OS. In the following instructions, “XXXX” represents the HP LaserJet product model number. The Macintosh partition contains an installer program for each language. Find the language appropriate for the operating system being used, and use the installer program for that language. To install the HP LaserJet printer software for Macintosh OS Step 1 Insert the CD-ROM that came with the Macintosh product software into the CD-ROM drive. Note If the CD screen does not open automatically, double-click the CD-ROM icon on the desktop to open the CD-ROM window. Step 2 Open the HP LaserJet Installers folder. Find the Installer icon for the appropriate language. Double-click the Installer icon to launch the Installer. In the opening dialog, click Continue. Step 3 The main Installer dialog box appears. Click Install and then follow the instructions on the screen to complete the software installation. Step 4 When software installation is complete, click Restart. Step 5 Run the Apple Desktop Printer Utility. Step 6 Click HP Printer (USB) and then click OK. Step 7 Click Change in the USB Printer Selection area. Step 8 Click HP Printer (USB) and then click OK. Step 9 Click Auto Setup. This attempts to match a PPD file and USB driver to your printer. If this fails, click Change, scroll through the list, click HP LaserJet XXXX, and then click Select. Step 10 Click Create. 166 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Software Technical Reference Uninstalling the Macintosh printing system To uninstall the Macintosh Printing System, drag the PPDs and the unwanted component(s) to Trash. In-box disk layout The Macintosh Printing System consists of one file: the HP LaserJet Installer Integrated installer program. Folders and files added through installation of the HP LaserJet software (Macintosh OS) The tables in the following sections detail the changes to your system as new folders and files are added when the HP LaserJet product software is installed on Macintosh OS systems. Note This listing does not include temporary directories and files that are created, and then deleted, during the installation process. In the following listing, "MACINTOSH HD" indicates the drive on which the software was installed. Macintosh (Macintosh OS) installation This section provides information about the various installation dialog box sequences for the Macintosh operating system. Main Install dialog box sequence This section provides information about the Macintosh installation dialog box sequence for the Easy Install (the typical installation option). Figure 67. HP LaserJet for Macintosh installer splash screen dialog box Software Technical Reference Macintosh 167 Table 43. Figure 68. HP LaserJet for Macintosh installer splash screen dialog box text strings Title of dialog box Text in dialog box User Options and Descriptions Splash screen hp LaserJet for Macintosh Click Continue to open the HP LaserJet Installer dialog box. [This title does not appear in the dialog box.] Continue... [button} HP LaserJet Installer dialog box (easy install) 168 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Software Technical Reference Table 44. HP LaserJet Installer dialog text strings (easy install) Title of dialog box Text in dialog box User Options and Descriptions HP LaserJet Installer Easy Install [drop-down menu] If you want to install the files in a location other than the default "Macintosh HD," click Select Folder to specify a location. Click the Install button to install: · Printer Descriptions · HP LaserJet Utility · Installation Notes You can also choose a Custom installation option from the dropdown menu at upper left. · ColorSync Profiles Disk space available: [conditional] Approximate disk space needed: [conditional] Click the Read Me button to open the Installer readme file. Click the Install button to start the installation on the selected disk The folder "HP LaserJet Folder" will be created on the disk "Macintosh Click the Quit button to quit the HD" Installer without making changes to the system. Select Folder [button] Quit [button] Install [button] (default option) Software Technical Reference Macintosh 169 Figure 69. HP LaserJet Installer dialog box (custom install) 170 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Software Technical Reference Table 45. HP LaserJet Installer dialog text strings (custom install) Title of dialog box Text in dialog box User Options and Descriptions HP LaserJet Installer Custom Install [drop-down menu] Select the install location using the Select Folder option (if the desired location is different from "Macintosh HD"). Printer Descriptions HP LaserJet Utility Select available components to install by using the check boxes in the list. Installation Notes Click the Read Me button to open the Installer readme file. ColorSync Profiles HP LaserJet Help LaserJet Printer Help Clicking Install starts the installation on the selected disk. Click the Quit button to quit the Installer without making any changes to the system. USB Components Disk space available: [conditional] Approximate disk space needed: [conditional] The HP LaserJet Folder will be created on the disk "Macintosh HD." Select Folder [button] Quit [button] Install [button] [default option] Software Technical Reference Macintosh 171 Figure 70. Installing dialog box Table 46. Installing dialog text strings Title of dialog box Text in dialog box User Options and Descriptions Installing Items remaining to be installed: [conditional number] This dialog box shows installation progress. No action is required unless you wish to stop the installation. Click the Stop button to interrupt the install file copy process. Installing: HP LaserJet XXXX Series Stop [button] Figure 71. Installation was successful dialog box Table 47. Installation successful dialog text strings Title of dialog box Text in dialog box User Options and Descriptions [This untitled dialog box begins with Installation was successful. If you Click the Quit button to exit the the words "Installation was are finished, click Quit to leave the Installer. The Printer Setup Assistant successful.”] Installer. If you want to perform opens. additional installations, click Continue. Click the Continue button to return to the HP LaserJet Installer. 172 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Software Technical Reference Printer setup using AppleTalk Chooser This section provides information about installing the printer using the AppleTalk Chooser. Figure 72. Important! dialog box Table 48. Important! dialog box text strings Title of dialog box Text in dialog box User Options and Descriptions Important! To set up your HP LaserJet printer, Click OK, and then continue use one of the following methods: installing the printer using either the AppleTalk Chooser, or USB/LPR. AppleTalk - Open the Chooser (in the [Apple icon] menu) and select a printer. USB/LPR - Open the Desktop Printer Utility and select a printer. Figure 73. How do I select my printer? dialog box Software Technical Reference Macintosh 173 Table 49. How do I select my printer? dialog text strings Title of dialog box Text in dialog box User Options and Descriptions How do I select my printer? For instructions, click the right arrow. This is a standard Macintosh OS help sequence. Topics [button] [An eight-panel Apple Guide sequence describes how to gain access to the Macintosh Chooser and how to select and set up the printer.] HP LaserJet Screen Fonts Installer dialog box sequence This section provides information about the installation dialog box sequence for the HP Screen Font Installer. Figure 74. HP LaserJet Screen Fonts splash screen dialog box Table 50. HP LaserJet Screen Fonts splash screen dialog text strings Title of dialog box Text in dialog box User Options and Descriptions HP LaserJet Screen Fonts HP LaserJet Screen Fonts Click the Continue button to open the HP LaserJet Screen Fonts dialog box. [The phrase "Screen Fonts" is repeated in multiple scripts and languages.] Continue [button] 174 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Software Technical Reference Figure 75. HP LaserJet Screen Fonts installer dialog box Table 51. HP LaserJet Screen Fonts installer dialog text strings (1 of 2) Title of dialog box Text in dialog box User Options and Descriptions HP LaserJet Screen Fonts Click the Install button to install: Click the Install button to start the installation. Screen Fonts Items will be installed on the disk "Apple External HD" Click the Quit button to quit the Installer without making changes to the system. Quit [button] Install [button] (default option} When you click Install, an installation progress bar dialog box briefly appears. The following table details the contents of that dialog box. Table 52. HP LaserJet Screen Fonts installer dialog text strings (2 of 2) Title of dialog box Text in dialog box User Options and Descriptions Installing Items remaining to be installed: [conditional number] Click the Stop button to interrupt the install file copy process. Stop [button] Software Technical Reference Macintosh 175 Figure 76. Installation was successful dialog box Table 53. Installation was successful dialog text strings Title of dialog box Text in dialog box User Options and Descriptions [This untitled dialog box begins with Installation was successful. If you Click the Quit button to exit the the words "Installation was are finished, click Quit to leave the Installer. successful."] Installer. If you want to perform additional installations, click Continue. Click the Continue button to return to the HP LaserJet Screen Fonts installer. IBM OS/2 Warp 3.0 and later OS/2 installation instructions Installation procedures differ depending upon whether or not a printer object does or does not exist on the OS/2 Desktop being used. Use the instructions that match the desktop. Installing a printer in OS/2 when printer object is missing Use this procedure when a printer object does not appear on the computer desktop. To create a printer object and install a printer driver, follow these steps: Note Use this procedure if the OS/2 desktop does not have a printer object. A system can have this configuration if no printer was selected during OS/2 installation, or if all the print objects have been deleted from the desktop. Step 1 Open the templates folder that is located in OS/2 system folder after OS/2 installation. Step 2 Click the Printer template. Press and hold the right mouse button. Step 3 Drag the template to Desktop. Step 4 Release the right mouse button. Step 5 Type a name for the printer in the Name field. Step 6 Select a port to which the printer is connected. Step 7 Click Install new printer driver. A window appears with a list of the printer drivers that are shipped with O/S2. Step 8 Click Other printer driver. 176 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Software Technical Reference Step 9 Point to the downloaded printer drivers. Step 10 Click Refresh. Wait until the window fills with printer drivers. Step 11 Select a driver by clicking the left mouse button over the desired driver. Step 12 Click Install. Installing a printer in OS/2 with pre-existing printer object on desktop To install a new printer driver using an existing printer object, use the following procedure: Note If the 16-bit HP LaserJet driver is installed on a system, delete it before installing this driver. Use these directions if a printer object exists on the OS/2 desktop, but you do not have the correct printer driver installed on the system. This could happen if a different printer has been added to the system. Step 1 Right-click the Printer object. Step 2 Click Settings. Step 3 Click the Printer Driver tab. Step 4 Right-click one of the Printer Driver objects. Step 5 Click Install. Step 6 Click Other OS/2 printer driver. Step 7 Point to the downloaded printer drivers. Step 8 Click the Refresh button. Wait until the window fills with printer drivers. Step 9 Click the driver you want to use. Step 10 Click Install. Additional information about the OS/2 drivers is included in the readme files that come with each driver. Software Technical Reference IBM OS/2 Warp 3.0 and later 177 Font support Note Fonts can be downloaded to the printer by using the Font Installer feature of the printer driver. z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z z Albertus CG Times Italic Symbol Albertus Extra Bold Clarendon Condensed Times New Roman Antique Olive· Coronet Times New Roman Bold Antique Olive Bold Courier Times New Roman Bold Italic Antique Olive Italic Courier Bold Times New Roman Italic Arial Courier Bold Italic Univers Arial Bold Courier Italic Univers Bold Arial Bold Italic Garamond Antiqua Univers Bold Italic Arial Italic Garamond Halbfett Univers Italic CG Omega Garamond Kursiv Univers Condensed CG Omega Bold Garamond Kursiv Halbfett Univers Condensed Bold CG Omega Bold Italic Letter Univers Condensed Bold Italic CG Omega Italic Letter Bold Univers Condensed Medium Italic CG Times Letter Italic Wingdings 178 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Software Technical Reference z z z z CG Times Bold Line Printer CG Times Bold Italic Marigold Changing a printer driver in the printer object Once both the printer object and the printer driver have been installed, the correct printer driver should be selected in the print object. This might also be necessary if you are using different printer drivers with a single print object. To change to a different printer driver: Step 1 Right-click the Printer object. Step 2 Click Settings. Step 3 Click the Printer Driver tab. Step 4 Double-click the Titlebar icon. The printer object is now set up to use a different printer driver. To customize the settings for this printer driver, see "Changing the printer properties" or "Changing the job properties." Changing the printer properties Printer properties describe how a particular printer is physically set up. Examples of printer properties include the amount of memory in a printer, forms defined by the printer, forms associated with the printer paper trays, and installed printer patterns. To set or change printer properties: Step 1 Point to the Printer object. Right-click the Printer object. Step 2 Click Settings. Step 3 Click the Printer Driver tab. Step 4 Right-click the correct printer driver. Step 5 Click Settings. Step 6 Change the properties to match the printer setup. Step 7 Double-click the Titlebar icon. The printer object is now set up to print a job. For information about how to print a job, see the OS/2 tutorial or the information folder for information about printing. Changing the job properties Job properties describe how a particular print job is printed. Examples of job properties include number of copies, print resolution, print quality, and orientation (portrait or landscape). Applications generally allow the selection of a printer object, and they allow you to change the job properties associated with a particular job by selecting setup or options buttons. Under certain conditions, it is appropriate to change job properties outside of an application, such as when performing drag-and-drop printing. To change the default job properties associated with a printer object outside of an application: Step 1 Right-click the Printer object. Software Technical Reference IBM OS/2 Warp 3.0 and later 179 Step 2 Click Settings. Step 3 Click the Job Properties tab. Step 4 Change the properties. Step 5 Click Save. The default job properties associated with a printer object are now set up. For more information about how to print a job, see the OS/2 tutorial or the information folder. 180 5 Installation for Macintosh, IBM OS/2, and Linux operating systems Software Technical Reference 6 Engineering Detail Introduction This section presents engineering detail for the following topic: z "Media attributes" Media attributes This section includes the following information about media attributes: z z z paper-source commands media types and sizes PCL 5c and PCL 6 custom paper sizes Paper-source commands The PCL 5e escape sequence for paper source is “Esc&l#H” (the “l” is a lowercase “L” rather than the numeral “1”). See the following table for values of #. For example, “Esc& l1H” is the command for tray 2. The PCL 6 escape sequence for paper source is “ubyte # MediaSource”. See the following table for values of #. For example, “ubyte 4 MediaSource” is the command for tray 2. Table 54. Paper-source commands for the HP LaserJet 5500 product Paper source PCL 5e PCL 6 Tray 1 4 3 Tray 2 1 4 Tray 3 (if installed) 5 5 Tray 4 (if installed) 20 8 Auto Select 7 1 Manual Feed 2 2 Software Technical Reference Introduction 181 Media types and sizes The tables in this section provide information about media features, media attributes, and paper-handling constraints for the HP LaserJet products. Note Table 55. The following table lists the features and attributes of various media listed under the Size Is: dropdown menu on the Paper tab. The list order can vary, depending on the product and operating system. The list will contain all the sizes shown below, and might contain sizes from other drivers. Supported features and attributes Paper sizes Width Height PCL 5 PCL 62 escape value1 PCL 5 margin x,y portrait PCL 5 margin x,y landscape PCL 6 margins Letter 216 mm (8.5 inches) 279 mm (11.0 inches) 2 “LETTER” 150,100 120,100 100, 100 Legal 216 mm (8.5 inches) 356 mm (14.0 inches) 3 “LEGAL” 150,100 120,100 100, 100 Executive 184 mm (7.25 inches) 267 mm (10.5 inches) 1 “EXEC” 150,100 120,100 100, 100 A3 297.0 mm (11.69 inches) 420.0 mm 27 (16.53 inches) “A3” 142,100 118,100 100, 100 A4 210.0 mm (8.27 inches) 297 mm 26 “A4” 142, 100 118, 100 100, 100 A5 148 mm (5.83 inches) 210 mm (8.27 inches) 25 “A5” 150,100 120,100 100, 100 11 by 17 279 mm 432 mm 6 “LEDGER” 100, 100 100, 100 100, 100 (11.0 inches) (17.0 inches) 81 “COM10” 150, 100 120, 100 100, 100 (11.69 inches) Envelope 105 mm Commercial #10 (4.12 inches) 241 mm Envelope DL (ISO) 110 mm (4.3 inches) 220 mm (8.66 inches) 90 “DL” 142, 100 118, 100 100, 100 Envelope C5 (ISO) 162 mm 229 mm 91 “C5” 142, 100 118, 100 100, 100 (6.38 inches) (9.01 inches) Envelope B5 (ISO) 176 mm 250 mm 100 “B5 ENV” 142, 100 118, 100 100, 100 (6.93 inches) (9.84 inches) Envelope Monarch 98 mm 190 mm 80 “MONARCH” 150, 100 120,100 100, 100 (3.87 inches) (7.5 inches) B4 (JIS) 257 mm 364 mm 46 “JIS B4” 100, 100 100, 100 100, 100 (10.12 inches) (14.33 inches) 182 mm 257 mm 45 “JIS B5” 142,100 142, 100 100, 100 (7.16 inches) (10.12 inches) 176 mm 250 mm 65 “ISOB5” 142, 100 118, 100 100, 100 (6.93 inches) (9.84 inches 273 mm 394 mm 19 “ROC8K” 100, 100 100, 100 100, 100 (10.75 inches (15.5 inches) B5 (JIS) (ISO)3,4 B5 3 8K 182 6 Engineering Detail (9.5 inches) Software Technical Reference Table 55. Supported features and attributes (continued) Paper sizes Width Height PCL 5 PCL 62 escape value1 PCL 5 margin x,y portrait PCL 5 margin x,y landscape PCL 6 margins 16K3 197 mm 273 mm 17 “ROC16K” 150, 100 120, 100 100, 100 (7.75 inches) (10.75 inches) 216 mm 330 mm 18 “JISEXEC” 150, 100 120, 100 100, 100 (8.5 inches) (12.99 inches) 148 mm 200 mm 72 “JPOSTD” 100, 100 100, 100 100, 100 (5.83 inches) (7.87 inches) 101 5 5 5 5 Executive (JIS)3 Double Postcard4 Minimum: Custom (leading Minimum: edge) 76 mm (3.0 inches) (other edge) Maximum: 127 mm (5.0 inches) Maximum: 306 mm 470 mm (12.05 inches) (18.5 inches) 1 The PCL escape sequence for paper size is Esc&1#A. The values in this column are for #. The PCL 6 command for paper size is ubyte array(String)MediaSize. The values in this column are the values for “String”. 3In Windows NT 4.0, this paper size is treated as a custom size. 4 B5 (ISO) is not supported on PS drivers because of firmware implementation limits. 5 For custom sizes, the PCL 6 Wizard specifies actual dimensions - for example, for 8-inch by 9-inch custom size, “real32_8.000000 9.000000 CustomMediaSize”. 2 The following table shows paper sizes that are supported by HP Color LaserJet 5500 product input devices, trays 1 through 4. Table 56. Input-device supported sizes for the HP Color LaserJet 5500 product Standard paper sizes Tray 1 Tray 2 Tray 3 Tray 4 Letter Y Y Y Y Legal Y Y Y Y Executive Y Y Y Y A3 Y Y Y Y A4 Y Y Y Y A5 Y Y Y Y 11 by 17 Y Y Y Y Envelope #10 Y N N N Envelope B5 Y N N N Envelope C5 Y N N N Envelope DL Y N N N Envelope Monarch Y N N N B4 (JIS) Y Y Y Y B5 (ISO) Y Y Y Y B5 (JIS) Y N N N Software Technical Reference Media attributes 183 Table 56. Input-device supported sizes for the HP Color LaserJet 5500 product Standard paper sizes Tray 1 Tray 2 Tray 3 Tray 4 Double Postcard Y N N N 8K Y Y Y Y 16K Y Y Y Y Executive (JIS) Y Y Y Y Custom Y Y Y Y The following table identifies the media types that are supported by HP Color LaserJet 5500 product input devices, trays 1 through 4. Table 57. Input-device supported media types for the HP Color LaserJet 5500 product Input media types (PS string) Tray 1 Tray 2 Tray 3 Tray 4 Plain Y Y Y Y Preprinted Y Y Y Y Letterhead Y Y Y Y Transparency Y Y Y Y Prepunched Y Y Y Y Labels Y Y Y Y Bond Y Y Y Y Recycled Y Y Y Y Color Y Y Y Y Y Y Y Y Heavy (106 to 163 g/m ) Y Y Y Y Envelope Y N N N Y Y Y Y Light (<75 g/m2) Y Y Y Y Heavy Glossy Y N N N Tough Paper Y Y Y Y Card stock1 2 Glossy (75 to 105 g/m2 ) 1 Maximum weight for cardstock in tray 1 is 164.9 g/m2 (45-lb.). Maximum weight in trays 2 and 3 is 58 g/m2 (16 lb) to 103 g/m2 (28 lb). 184 6 Engineering Detail Software Technical Reference Note PCL 5c and PCL 6 custom paper sizes The PS driver does not support user-defined media sizes. The following table shows custom paper sizes available for the HP Color LaserJet 5500 product. Table 58. PCL 5e and PCL 6 custom paper sizes for the HP Color LaserJet 5500 product Tray Paper sizes Width Height Tray 1 Custom (leading edge) Minimum: Minimum: 76 mm (3.0 inches) 127 mm (5.0 inches) Maximum: Maximum: 306 mm 470 mm (12.05 inches) (18.5 inches) Minimum: Minimum: 148 mm (5.83 inches) 210 mm (8.27 inches) Maximum: Maximum: 297 mm 432 mm (11.69 inches) (17.01 inches) (other edge) Trays 2 through 4 Custom (leading edge) (other edge) Paper Type commands The PCL 5c escape sequence for paper type is “Esc&n#Wdpapertype”, where “n#” is the number of characters in the paper type plus 1. For example, in the sequence “Esc&n6WdPlain”, “Plain” has 5 letters plus 1, for a total of 6. For the command to work properly, at least one of the paper trays in the product must be configured in the control panel for the paper type used in the command. Note Some paper type options listed in the table below might not be defined in the printer driver. Table 59. Paper-type commands Esc& n# Wd Paper type Esc& 5 Wd Bond Esc& 10 Wd Card stock1 Esc& 6 Wd Color Esc& 7 Wd Labels Esc& 11 Wd Letterhead Esc& 6 Wd Plain Esc& 11 Wd Preprinted Esc& 11 Wd Prepunched Esc& 9 Wd Recycled Esc& 6 Wd Rough Software Technical Reference Media attributes 185 Table 59. Paper-type commands Esc& n# Wd Paper type Esc& 13 Wd Transparency2 Esc& 6 Wd Heavy Esc& 9 Wd Envelope Esc& 7 Wd Glossy Esc& 6 Wd Light Esc& 13 Wd Heavy glossy Esc& 11 Wd Tough Paper 1 The correct command for card stock is “Esc&n11WdCard Stock”, with a space between the “d” and the “S”, and with an uppercase “S”. 2You must spell out the word “Transparency” in the string, although it is abbreviated on the printer control panel. 186 6 Engineering Detail Software Technical Reference Index Symbols % of Normal Size option in printer drivers 63 .HPB files 95 .INF file (add printer) 108 .PCM files 95 .RFU (remote firmware update) files description 31 Numerics 2-sided printing. See duplexing A About This Driver dialog box 85 accessibility screen-readable documentation 16 accessories autoconfiguration 18 documentation 17 monitoring with Printer Status and Alerts utility 25, 28 verifying installed options 28 Acrobat Reader requirement for documentation 16 Adobe Acrobat Reader requirement for documentation 16 PS Level 3 printer drivers 98 Web site 98 Advanced tab in printer drivers 100 alerts configuring pop-up windows 25, 28 configuring refresh rate 28 disabling in Printer Status and Alerts utility 28 e-mail 25 icons 27 monitoring with Printer Status and Alerts utility 25 All Pages tab in printer drivers 68 Apple LaserWriter driver 41 AppleTalk Chooser, installing printers 173 AppleTalk connection 41 asynchronous modem connect and terminal servers 15 attributes media 181 printer drivers 182 Auto Select option for media source 75 option for paper type 75 AutoCAD printer drivers availability of components by operating system 108 autoconfiguration accessories supported 18 availability of components by operating system 108 description 18 See also EAC (Enterprise AutoConfiguration) automatic e-mail notifications about software and firmware releases 107 B Back Cover tab in printer drivers 70 back covers including for documents 69 selecting for booklets 56 backup for firmware update 34 Basics tab in printer drivers 83 bidirectional communication Software Technical Reference autoconfiguration 18 availability of components by operating system 108 description 17, 18 supporting operating systems and network environments 18 bindery See also NDS; Novell NetWare binding options 53 bins. See output bins bitmaps, sending TrueType fonts as 61 black, printing all text as 61 booklets binding options 53 impositioning 55 page borders option 57 page order option 57 pages per sheet option 57 paper sizes for which disabled 54 printing 53 selecting covers 56 borders option for printing 57 Bubble Help 47 bundle configurations of product, geographic variations 13 C Cancel button in messages 46 CD browser for HP LaserJet printing system software availability of components by operating system 108 description 37, 38 CD-ROM for installation availability and fulfillment 105 in-box file layout 105 regional versions 105 character, euro 35 Choose Setup Language dialog box 120 Citrix Metaframe 15 CMYK color standard 36 codes for firmware level 30 collating multiple original print jobs 91 collating, overriding settings in software programs 95 color profiles PANTONE 36 Color tab in printer drivers 86 colors ICC profiles 36 selecting for watermarks 66 setting 86 ColorSync profiles for Macintosh operating systems 162 commands paper source, description 181 paper source, HP Color LaserJet 5500 181 paper type 185 Components dialog box 145 compression settings 59 confidential documents, printing 79, 80, 102, 103 configuration automatic using Driver Autoconfiguration 18 verifying physical 77 verifying printer 67 viewing remotely 23 Configuration options in HP Web Access 23 Index 187 configuration page printing 30 viewing remotely using HP Web Access 22 configurations of product, geographic variations 13 Configure Font DIMMs dialog box 94 Configure tab in driver help 88 configuring destinations 91 devices remotely 23 duplexing unit 90 e-mail alerts 25 e-mail command and response 35 font DIMMs 94 job retention 92 links to off-printer solutions 22 mopier 91 paper destinations 91 paper sources 91 pop-up windows in Printer Status and Alerts utility 25, 28 predefined user settings for printing 51 printer driver hard disk 78 printer driver work space 93 printer memory 92 printer storage 92 Quick Sets 51 refresh rate for printer status and alerts 28 trays for Windows operating systems 97 conflict in settings for printing 75 connections EtherTalk 166 LocalTalk 166 parallel for Macintosh operating systems 166 setting up for Windows 126 consumables monitoring with Supplies Status page 20 consumables, monitoring with Printer Status and Alerts utility 25, 28 context-sensitive help 45 control panel, viewing simulation with Printer Status and Alerts utility 25 copies conflict between printer driver and application 84 maximum number 83 printing noncollated 96 selecting number to print 83 setting number to print 83, 99 Copies option in printer drivers 83 covers including for document back 69 selecting for booklets 56 Current Watermarks option in printer drivers 65 custom paper types 76 quick sets 52 Custom installation Windows operating systems 144 Custom Paper Size dialog box 71 custom paper sizes defining 67 limits on width and height 74 naming 73 PCL 5c and PCL 6 printer drivers 185 PCL 5c, PCL 5c, and PCL 6 printer drivers 185 removing 72, 73 renaming 72, 73 selecting 72 setting 71 setting width and height 73 supported by HP Color LaserJet 5500 184 188 Index custom paper sizes, continued supported by PS printer driver 185 viewing list of supported 70 See also paper sizes Customization Utility for installation 156 D defaults installed fonts for Windows 114 job properties for printer objects 179 number of quick-copy and proof-and-hold jobs 78, 102 printer 160 printer driver Basics options 83 printer driver Configure options 88 printer driver Destination options 76 printer driver Effects options 62 printer driver Finishing options 50 printer driver Paper options 67 watermarks 67 deleting. See removing Destination Features options in printer drivers 77 Destination tab in printer drivers 76 destinations, configuring 91 Device Settings tab in HP Web Access 22 Device Settings tab in printer drivers 104 devices configuring remotely 23 monitoring with Printer Status and Alerts utility 28 verifying installation 28 viewing status with HP Web Access 21 dialog boxes About This Driver 85 Choose Setup Language 120 Components 145 Configure Font DIMMs 94 Custom Paper Size 71 Exit Setup 143 Exiting Registration 155 Finish 142 Hewlett-Packard’s Electronic Registration 147, 150 HP LaserJet for Macintosh Installer splash screen 167 HP LaserJet Installer (custom install) 170 HP LaserJet Installer (easy install) 168 HP LaserJet Installing 172 HP LaserJet Screen Fonts Installer 174 HP Software License Agreement 123 Identify Printer 132 Installation Type 137 Model 136 More Configuration Options 92 Network Setup 129 Print Quality Details (HP Color LaserJet default settings) 58 Printer Name 139 Printer Sharing 140 Select Port 127 Set Network Communication Mode 135 Setup 120 Specify Network Path 134 Type of Connection 126 Watermark Details 64 Web Update 124 Welcome 122 Welcome to Hewlett-Packard’s Registration 149 different paper for first page 68 DIMMs (dual inline memory modules) availability of fonts by operating system 108 configuring fonts 94 directory structure on installation CD-ROM 105 Software Technical Reference disabling alerts 28 job retention 78, 101 disk storage, verifying installed options 28 Document Options for printer drivers 52 documentation for product accessibility screen-readable versions 16 availability of components by operating system 108 configuring quick set for optimal printing 52 description 16 localization of components by operating system 109 location on installation CD-ROM 105 obtaining 16 documents configuring settings for all pages 68 including back cover 69 indentifier for job storage 80 options for printing 52 printing confidential or sensitive 79, 80, 102, 103 scaling for different paper sizes 62 scaling to fit target paper size 63 selecting number to copy 83 setting different first page 68 dots per inch (dpi) setting in printer drivers 57, 59 double-sided printing. See duplexing downloading firmware updates 30, 31, 105 firmware updates using HP Web JetAdmin 33 HP LaserJet printing system software 107 operating system driver bundles 107 software 105 standalone printer drivers 107 dpi (dots per inch) setting in printer drivers 57, 59 Driver Autoconfiguration. See autoconfiguration; EAC (Enterprise AutoConfiguration) Driver Work Space (DWS) option in printer drivers 90, 93 drivers. See printer drivers dual inline memory modules (DIMMs). See DIMMs (dual inline memory modules) duplex printing accessory. See duplexing unit duplexer. See duplexing unit duplexing binding option 53 media sizes not available using duplexing unit 59 option 52 orientation of pages 53 setting defaults 52 duplexing unit configuring 90 Print on Both Sides option 52 DWS (Driver Work Space) option in printer drivers 90, 93 E EAC (Enterprise AutoConfiguration) and bidirectional communication 19 See also autoconfiguration Edge Control color setting 87 Effects tab in printer drivers 62 e-mail alerts 25 command and response 35 notifications about software and firmware releases 107 registration of product 146 e-mail servers See also servers embedded Web server (EWS). See HP Web Access enabling. See configuring Software Technical Reference envelopes dimensions supported 182 supported by HP Color LaserJet 5500 183 error messages. See messages EtherTalk connection 166 euro character 35 Event Log page, viewing with HP Web Access 20 Exit Setup dialog box 143 Exiting Registration dialog box 155 extensions for printer drivers 85 F face-down bin. See output bins face-up bin. See output bins features HP Color LaserJet 5500 14 HP LaserJet printing system software 16 HP LaserJet printing system software installer 39 printer driver 45 .INF file (add printer) 108 files added through installation of HP LaserJet printing system for Macintosh operating systems 167 .HPB 95 included on installation CD-ROM 105 .INF 108 .PCM 95 PPD 41, 108, 109, 162 Finish dialog box 142 Finishing tab in printer drivers 50 firmware automatic notification of releases 107 determining current level 30 downloading 107 updating remotely 30 firmware update. See RFU (remote firmware update) first page, setting to be different 68 Flip Pages Up option for duplexing 53 folders added through installation of HP LaserJet printing system for Macintosh operating systems 167 font DIMMs 94 Font Settings option in printer drivers 61 fonts availability of components by operating system 108 euro character 35 installing for IBM operating systems 176 installing for Macintosh operating systems 174 localization of components by operating system 109 location on installation CD-ROM 105 printer driver options 61, 94 PS 3 available on printer CD-ROM 116 selecting for watermarks 65 support for IBM operating systems 176 support for Macintosh operating systems 163 support for Windows operating systems 114 TrueType, controlling in printer driver 100 TrueType, sending as bitmaps 61 fulfillment centers 105 G graphic options, setting in printer driver 100 Graphics Settings for printer drivers 59 grayscale, setting 86 Index 189 H halftones, setting 87 hard disk configuring printer driver 78, 92 removing jobs 81 sending jobs directly to 79, 102 height and width, setting custom 73 help Bubble 47 context sensitive 45 for PCL 5c and PCL 6 drivers 45 localization by operating system 109 What’s this? 45 Hewlett-Packard’s Electronic Registration dialog box 147, 150 history information for jobs 25 HP Auto Setup Utility for Macintosh operating systems 163 HP Color LaserJet 5500 configurations 14 custom paper size limits on width and height 74 features 14 media supported by input devices 184 models 14 Printer Model options in printer driver 90 software component localization 109 HP Color LaserJet 5500dn Printer Model options in printer driver 90 HP Color LaserJet 5500dtn Printer Model options in printer driver 90 HP Color LaserJet 5500hdn Printer Model options in printer driver 90 HP Color LaserJet 5500n Printer Model options in printer driver 90 HP LaserJet 5500 availability of software components 108 custom paper size limits on width and height 74 media sizes supported by input devices 183 HP LaserJet for Macintosh Installer splash screen dialog box 167 HP LaserJet Installer (custom install) dialog box 170 HP LaserJet Installer (easy install) dialog box 168 HP LaserJet Installing dialog box 172 HP LaserJet printing system software availability of components by operating system 108 bidirectional communication technology 17 CD browser 37 components 37 Custom installation for Windows operating systems 144 downloading 107 features 16, 39 installable components 40 installation CD-ROM 105 installing on Macintosh operating systems 166 installing on Windows operating systems 113 localization of components by operating system 109 operating systems supported 15 printer drivers 40 Printer Status and Alerts utility 25 requirements for IBM operating systems 161 requirements for Linux operating systems 161 requirements for Macintosh operating systems 161 Typical installation for Windows operating systems 119 versions 37 HP LaserJet Screen Fonts Installer dialog box 174 HP LaserJet Utility 162 HP Resource Manager, localization by operating system 109 190 Index HP Software License Agreement dialog box 123 HP Web Access description 20 localization of components by operating system 109 printer configuration page 22 HP Web JetAdmin availability of components by operating system 108 description 42 localization of components by operating system 109 supported operating systems 42 using to download firmware 33 using with HP Web Access 20 Web site 42 HP Web Registration 42 HP WebReg 146 .HPB files 95 I IBM operating systems availability of components 108 changing job properties 179 changing printer driver in printer object 179 changing printer properties 179 font support 176 installing fonts 176 installing printers when printer object missing from desktop 176 installing printers when printer object present on desktop 177 localization of components by operating system 109 printer drivers 41 requirements for HP LaserJet printing system software 161 supporting HP LaserJet printing system software 15 ICC color profiles 36 icons printer in Destinations tab 76, 82, 96 printer in Paper tab 67 status and alert 27 Identify Printer dialog box 132 Ignore Application Collation option in printer drivers 95 images orientation 84 previewing 50 impositioning for booklet printing 55 inches selecting as unit of measure 70 switching to millimeters 74 .INF file (add printer) 108 Information tab in HP Web Access 20 infrared connection, setting up for Windows 126 installation customizing 156 Microsoft Point and Print 158 notes 17 printer drivers only 158 requirements for IBM operating systems 161 requirements for Linux operating systems 161 requirements for Macintosh operating systems 161 requirements for Windows operating systems 113 silent 156 using autoconfiguration 18 Installation Type dialog box 137 installers availability of components by operating system 108 for HP LaserJet printing system software 38, 39 for Macintosh operating system 167 localization of components by operating system 109 Software Technical Reference installing fonts for IBM operating systems 176 fonts for Macintosh operating systems 174 HP LaserJet printing system software 37, 118 Macintosh printing system 166 Microsoft Point and Print 158 online documentation 16 only printer driver 158 Printer Status and Alerts utility 25 printers using AppleTalk Chooser 173 using Customization Utility 156 using silent installer 156 Windows printing system 113 IPX/SPX and terminal servers 15 IR connection, setting up for Windows 126 J Java software included with HP Web Access 20 JetAdmin. See HP Web JetAdmin Job Retention option in printer drivers description 76 disabling 78, 101 enabling 92 job retention modes 78 system requirements 77, 78 Job Retention tab in printer drivers 101 Job Storage option in printer drivers document identifier 80 limitations among printer drivers 81 using when printing 81 Job storage option in printer drivers availability without printer hard disk 77 Job Storage tab in printer drivers 101 jobs changing properties 179 collating multiple original print 91 disabling monitoring in Printer Status and Alerts utility 28 history information 25 identifier for job storage 80 monitoring with Printer Status and Alerts utility 25 naming 80 private 79, 102 private stored 80, 103 proof-and-hold 79, 102 quick copy 78, 101 releasing stored 81 removing from memory or hard disk 81 sending directly to hard disk 79, 102 sending directly to printer memory 79, 102 setting number of copies to print 83 stored 79, 102 using PINs 79, 102 JPEG data compression 59 K known issues 17 L LAN connection and terminal servers 15 landscape orientation description 84 duplex-binding option 53 languages choosing for Windows setup 120 for Macintosh operating systems 166 key to abbreviations 110 localization of components by operating system 109 reverse-directional language registration 146 Software Technical Reference languages, continued supported on installation CD-ROM 106 license agreement 123 links to off-printer solutions 22 Linux operating systems availability of components 108 printer drivers 41 requirements for HP printing system software 161 Web sites 161 local area network connection and terminal servers 15 localization of components by operating system 109 LocalTalk connection 166 M Macintosh LaserJet Utility, availability of components by operating system 108 Macintosh operating systems availability of components 108 component descriptions 162 directory structure on installation CD-ROM 105 folders and files added through installation of HP LaserJet software 167 font support 163 HP LaserJet printing system software components 41 installable components 41 installing fonts 174 installing printers 173 installing printing system 166 localization of components by operating system 109 requirements for HP LaserJet printing system software 161 supported printer drivers 41 supporting bidirectional communication 18 supporting HP LaserJet printing system software 15 uninstalling printing system 167 managing printers using HP Web Access 20 using HP Web JetAdmin 42 manually printing on second side 59 manually printing on second side option in printer drivers 59 manuals. See documentation for product Measurement Units button 74 media attributes for paper-source commands, type, and size 181 configuring destinations 91 supported by input devices 184 supported types and sizes 182 viewing list of supported sizes 70 memory configuring 92 removing jobs 81 sending jobs directly to printer 79, 102 storing documents in printer 78 view amount physically installed in printer 92 viewing total for printer 90 viewing total installed in printer 92 messages Bubble Help 47 firmware update 34 Microsoft Point and Print installation 158 Microsoft Windows. See Windows operating systems Microsoft Winsock2patch 26 millimeters selecting as unit of measure 70 switching to inches 74 Model dialog box 136 model numbers, viewing 85 Index 191 models HP Color LaserJet 5500 14 moire effect, resolving 61 monitoring disabling in Printer Status and Alerts utility 28 print jobs and printer status using Printer Status and Alerts utility 25 mopier, enabling 91 More Configuration Options dialog box 92 N naming custom paper sizes 72, 73 jobs 80 NDS See also bindery; Novell NetWare NETBIOS Extended User Interface (NETBEUI) and terminal servers 15 NetWare. See Novell NetWare network operating systems. See IBM operating systems; Linux operating systems; operating systems; Macintosh operating systems; UNIX operating systems; Windows operating systems Network Settings option in HP Web Access 24 Network Setup dialog box 129 Networking tab in HP Web Access 23 nonvolatile random-access memory (NVRAM). See NVRAM (nonvolatile random-access memory) notifications configuring e-mail 25 e-mail software and firmware releases 107 Novell Directory Printer Services (NDPS). See NDPS (Novell Directory Printer Services) Novell NetWare bidirectional communication support 18 operating systems supporting bidirectional communication 18 NT Forms tab in printer driver 97 numbers firmware level 30 NVRAM (nonvolatile random-access memory), changes from firmware update 31 O OK button in messages 46 online documentation for product availability of components by operating system 108 description 16 installing 16 obtaining 16 viewing 16 online help for Macintosh operating systems 163 operating systems availability of components 108 localization of components 109 supported by HP Web JetAdmin 42 supporting bidirectional communication 18 supporting HP LaserJet printing system software 15 See also IBM operating systems; Linux operating systems; Macintosh operating systems; UNIX operating systems; Windows operating systems optimizing printer driver performance 93 Optional Paper Destinations menu 91 Optional Paper Sources menu 91 Options menu 82 order of pages 57 ordering from HP Web site 106 orientation of image on page 192 Index description 84 setting in printer driver 99 when duplexing 53 See also landscape orientation; portrait orientation; rotated orientation OS/2. See IBM operating systems Other Options options in printer drivers 92 Other Pages tab in printer driver 69 output bins custom size limits on width and height 74 printing options 82 selecting on Destination tab 76, 82 Output Settings options in printer drivers 59 P Page Order option in printer drivers for booklets 57 page orientation duplex-binding options 53 setting in printer driver 99 Page Setup tab in printer drivers 99 Pages per Sheet menu 57 PANTONE color profiles 36 paper configuring destinations 91 supported by input devices 184 Paper Handling options in printer driver 90 paper level, monitoring with Printer Status and Alerts utility 25 paper sizes disabled for printing booklets 54 priority when settings conflict 75 selecting for first and subsequent pages 70 setting for custom 73 setting in printer driver 99, 100 supported by HP Color LaserJet 5500 183 supported features and attributes 182 See also custom paper sizes paper source commands description 181 paper sources configuring 91 setting in printer driver 99 Paper tab in printer drivers 67 paper type commands 185 paper types adding manually from the driver 76 auto select 75 priority when settings conflict 75 supported 75 supported features and attributes 182 parallel connections for Macintosh operating systems 166 for Windows operating systems 128 pattern scaling 59 PCL (printer command language) supporting operating systems 15 PCL 5 printer driver supported features and attributes 182 PCL 5c printer driver autoconfiguration 18 bidirectional communication 18 custom paper sizes 185 description 40, 45 font DIMMs 95 help system 45 localization by operating system 109 paper source commands, HP Color LaserJet 5500 181 paper type commands 185 support for Windows 3.1x 160 Software Technical Reference PCL 6 printer driver autoconfiguration 18 bidirectional communication 18 custom paper sizes 185 description 40, 45 font DIMMs 95 help system 45 localization by operating system 109 paper source commands, HP Color LaserJet 5500 181 support for Windows 3.1x 160 supported features and attributes 182 .PCM files 95 PDEs (Printer Dialog Extensions) 162 Percentage of Normal Size option in printer drivers 63 PIN, assigning to print jobs 79, 102 plug and play component availability by operating system 108 point and print component availability by operating system 108 port, selecting for Windows 128 portrait orientation description 84 duplex-binding option 53 postcards supported by HP LaserJet 5500 184 supported dimensions 183 PostScript (PS) printer driver. See PS (PostScript) printer driver PPDs (printer definition files) availability of components by operating system 108 description 41, 162 localization of components by operating system 109 previewing documents scaled to fit 63 images 50 page order for booklets 57 Print all Text as Black option in printer drivers 61 Print Document On option in printer drivers 62 print jobs. See jobs Print on Both Sides option in printer drivers 52 Print Page Borders option in printer drivers for booklets 57 Print Quality Details dialog box (HP Color LaserJet default settings) 58 print quality options in printer drivers 57 Print Quality portion of Finishing tab 50 printer command language (PCL) supporting operating systems 15 printer definition files (PPDs). See PPDs (printer definition files) Printer Dialog Extensions (PDEs) 162 printer driver options % of Normal Size 63 binding 53 booklet printing 53 Copies 83 Current Watermarks 65 Destination Features 77 Document Options 52 dpi setting 57, 59 Driver Work Space (DWS) 93 duplex-binding options 53 Flip Pages Up 53 Font Settings 61 Fonts 94 Graphics Settings 59 Ignore Application Collation 95 Job Retention 78, 80, 81, 92, 101 Job Storage 81 manually printing on second side 59 Software Technical Reference printer driver options, continued Other Options 92 Output Settings 59 Page Order 57 Pages per Sheet 57 Paper Handling Options 90 Print all Text as Black 61 Print Document On 62 Print on Both Sides 52 Print Page Borders 57 print quality 57 Printer Hard Disk 78 Printer Memory 92 Printer Model 89 Private Job 79, 102 Proof and Hold 79, 102 Quick Copy 78, 101, 102 Resolution 59 resolution 59 Scale Patterns (WYSIWYG) 61 Scale to Fit 63 Size is 70 Storage 92 Stored Job 78, 79, 81, 102 Watermarks 64 printer driver tabs Advanced 100 All Pages 68 Back Cover 70 Basics 83 Configure 88 Destination 76 Device Settings 104 Effects 62 Finishing 50 Job Retention 101 Job Storage 101 NT Forms 97 Other Pages 69 Page Setup 99 Paper 67 Windows NT Forms 97 printer drivers adding paper types manually 76 Adobe PS level 3 98 autoconfiguration 18 availability of components by operating system 108 changing in printer object 179 Color tab 86 configuring for hard disk 78 downloading Macintosh, AutoCAD, and IBM 108 downloading standalone 107 downloading system driver bundles 107 enabling hard disk or job retention for storage 92 extensions 85 features 45 help systems 45 included with HP LaserJet printing system software 40 installing only 158 installing when printer object missing from desktop 176 installing when printer object present on desktop 177 localization of components by operating system 109 location on installation CD-ROM 105 optimizing performance 93 support for Macintosh operating systems 41 supported features and attributes 182 supporting operating systems 15 viewing version number and date 85 Printer Hard Disk option in printer drivers 78 Index 193 Printer Memory options in printer drivers 92 Printer Model options in printer drivers 89 Printer Name dialog box 139 printer objects changing printer driver 179 creating 176 installing printer when missing from desktop 176 installing printer when present on desktop 177 Printer Sharing dialog box 140 Printer Status and Alerts utility availability of components by operating system 108 description 25 disabling monitoring 28 icons 27 installing 25 localization of components by operating system 109 restrictions for HP products 26 supporting operating systems and browsers 26 window 27 printers changing properties 179 configuring memory 92 configuring storage 92 default 160 downloading firmware 107 information provided by image in printer driver Destinations tab 76, 82, 96 information provided by image in printer driver Paper tab 67 installing using AppleTalk Chooser 173 managing using HP Web Access 20 sharing in Windows operating systems 140 viewing total memory installed 92 printing booklets 53 confidential or sensitive documents 79, 80, 102, 103 configuration page 30 configuring user-defined settings 51 noncollated copies 96 priority when settings conflict 75 setting number of copies 83 using Job Storage option while 81 printing all text as black 59 printing system software. See HP LaserJet printing system software Private Job option in printer drivers description 79, 102 private stored jobs 80, 103 Proof and Hold option in printer drivers description 79, 102 maximum number of jobs 78, 102 PS (PostScript) printer driver custom paper sizes 185 description 40 features 98 operating systems supported by 15 PS 3 Emulation support for HP LaserJet products 98 PS 3 fonts available on printer CD-ROM 116 localization of components by operating system 109 Quick Sets configuring for product documentation 52 custom 52 description 51 removing 52 too many defined 52 R raster compression 58 raster compression settings 59 readme file for installation 17 refresh rate configuring for printer status alerts 28 description 28 registration of product availability of components by operating system 108 description 38 for reverse-directional languages 146 options 39, 146 using HP Web Registration 42 release notes 17 releasing stored jobs 81 remote firmware update. See RFU (remote firmware update) remote management using HP Web Access 20 removing custom paper sizes 72, 73 private jobs 79, 102 quick sets 52 stored jobs 79, 103 renaming custom paper sizes 72, 73 rendering mode 58 requirements for IBM operating systems 161 for Linux operating systems 161 for Macintosh operating systems 161 for Windows operating systems 113 Resolution Enhancement technology (REt) option in printer drivers 59 Resolution option in printer drivers 59 resolution, setting in printer drivers 100 Resource Manager. See HP Resource Manager REt (Resolution Enhancement technology) option in printer drivers 59 retention of jobs. See Job storage option in printer drivers reverse-directional language registration 146 RFU (remote firmware update) backup 34 changes to NVRAM 31 description 30 messages 34 using FTP on a direct network connection) FTP, using for remote firmware update 32 using TCP/IP address) TCP/IP address, using for remote firmware update 33 verifying success 34 .RFU (remote firmware update) files description 31 RGB color standard 36 setting colors 87 rotated orientation 84 Q quality of print options in printer drivers 57 Quick Copy option in printer drivers availability 78, 101 description 78, 101 maximum number of jobs 78, 102 system requirements 78 194 Index Software Technical Reference S scale patterns 58 Scale Patterns (WYSIWYG) option in printer drivers 61 Scale to Fit option in printer drivers 63 scaling documents for different paper sizes 62 documents to fit target paper size 63 setting percentage 63, 100 Security options in HP Web Access 24 Select Port dialog box 127 servers See also e-mail servers Set Network Communication Mode dialog box 135 Settings tab in HP Web Access 22 Setup dialog box 120 shading, selecting for watermarks 66 sharing printers in Windows operating systems 140 silent installer 156 Size is option in printer drivers 70 software automatic notification of releases 107 downloading 107 embedded virtual machine for Java 20 HP Web Access 20 included with product 15 Software License Agreement dialog box 123 Source Is menu 75 Specifications for Web Offset Publications (SWOP) 36 Specify Network Path dialog box 134 sRGB color standard 36 status configuring pop-up windows 25, 28 configuring refresh rate 28 disabling in Printer Status and Alerts utility 28 icons 27 monitoring with Printer Status and Alerts utility 25, 28 Storage options in printer drivers 92 Stored Job option in printer drivers description 79, 102 releasing stored jobs 81 requirements 79, 102 system requirements 78 storing documents in printer memory 78 supplies monitoring with Supplies Status page 20 Supplies Status page, viewing with HP Web Access 20 supplies, monitoring with Printer Status and Alerts utility 25, 28 SWOP (Specifications for Web Offset Publications) 36 system requirements. See requirements trays, continued paper sizes supported by HP LaserJet 5500 183 paper sizes supported by PCL 5c and PCL 6 printer drivers 185 paper source commands 181 verifying installation 28 viewing available 75 troubleshooting known issues 17 workarounds 17 TrueType fonts controlling in printer driver 100 sending as bitmaps 61 two-sided printing. See duplexing Type Is menu 75 Type of Connection dialog box 126 Typical installation Windows operating systems 119 U uninstalling Macintosh printing system 167 Windows printing system 119 units of measurement, switching between inches and millimeters 70, 74 UNIX operating systems availability of components 108 printer drivers 41 remote firmware update 32 updating status and alerts 28 upgrades. See RFU (remote firmware update) URLs. See Web sites Usage Page, viewing with HP Web Access 20 USB connection, setting up for Windows 126 utilities availability of components by operating system 108 HP Auto Setup for Macintosh operating systems 163 HP LaserJet Utility for Macintosh operating systems 162 localization of components by operating system 109 Printer Status and Alerts 25 V versions HP LaserJet printing system software 37 installation CD-ROM 106 printer drivers supported 40 viewing and updating firmware level 30 viewing printer driver 85 W T TCP/IP and terminal servers 15 setting up for Windows operating systems 135 terminal server technology 15 toner monitoring level with Printer and Status Alerts utility 25 Total Printer Memory value 90 Transmit Once mopying feature 91 trays auto select 75 configuring for Windows operating systems 97 configuring media size and type for Windows NT, 2000, and XP 97 controlling in printer driver 104 custom paper sizes supported 185 custom size limits on width and height 74 media supported 184 Software Technical Reference Watermark Details dialog box 64 watermarks creating new 65 editing existing 65 limit to number of 65 preset 64 printing only on first page 64 selecting font, color, shading, size, and style 65 selecting from available 64 selecting shading 66 setting message angle 65 Watermarks option in printer drivers 64 Web Access. See HP Web Access Web Registration. See HP Web Registration Index 195 Web sites Adobe 98 firmware 31, 107 firmware update 30 known issues and workarounds 17 Linux 161 Microsoft Winsock2 patch 26 product registration 146 software 106, 107 terminal server technology 15 Web Update dialog box 124 Welcome dialog box 122 Welcome to Hewlett-Packard’s Registration dialog box 149 What’s this? help 45 width and height, setting custom 73 Windows 3.1x support for printers 160 Windows Cluster Server 15 Windows NT Forms tab 97 Windows operating systems booklet printing support 55 configuring trays 97 directory structure on installation CD-ROM 105 font support 114 installing Microsoft Point and Print function 158 installing printing system 113 localization of components by operating system 109 PS (PostScript) printer driver 98 remote firmware update 32 requirements for installing printing system 113 supporting bidirectional communication 18 supporting HP LaserJet printing system software 15 Windows Terminal Server 15 Winsock2patch 26 Wizards, availability of components by operating system 108 workspace option for printer drivers 93 workspace value for printer drivers 90 196 Index Software Technical Reference copyright © 2002 Hewlett-Packard Company
