XP-7100 User's Guide
Contents
3
4
5
6
7
8
9
10
11
12
XP-7100 User's Guide
Welcome to the XP-7100 User's Guide .
For a printable PDF copy of this guide, click here.
13
Product Basics
See these sections to learn about the basic features of your product.
Epson Connect Solutions for Smartphones, Tablets, and More
Android Printing Using the Epson Print Enabler
Using Windows 10 Mobile Printing
Using Epson Print and Scan App with Windows Tablets
Using the Mopria Print Service
Using the Control Panel
See these sections to learn about the control panel and select control panel settings.
Adjusting Control Panel Position
Control Panel Buttons and Lights
Adjusting Control Panel Sounds
Adjusting the Screen Brightness
Turning Off Auto Selection Mode
Parent topic:
14
Adjusting Control Panel Position
You can adjust the position of the control panel to make it easier to access. Raise or lower it to the desired angle as shown.
Note: The control panel rises and the output tray slides out automatically when printing starts.
Parent topic:
Control Panel Buttons and Lights
1 The power button and light
2 The LCD screen
15
Entering Characters on the LCD Screen
Parent topic:
The LCD Screen
1 Displays various status information; select an icon to check its status or adjust its settings
2 Menu options
3 Select a tab to view different options and settings
4 Displays available buttons
5 Setting options
Parent topic:
Control Panel Buttons and Lights
Status Icon Information
Your product displays status icons on the LCD screen for certain product status conditions.
Icons Description
Displays the Supply Status screen.
16
Icons Description
Displays the network connection status; select the icon to set up or change your network connection.
• The product is not connected to a wired (Ethernet) network.
•
•
The product is connected to a wired (Ethernet) network.
The product is not connected to a wireless network.
• The product is searching for an SSID or experiencing a wireless network connection issue.
• The product is connected to a wireless network; the number of bars indicates the connection's signal strength.
• Wi-Fi Direct is not enabled.
• Wi-Fi Direct is enabled.
The Quiet Mode setting is enabled or disabled. Select the icon to change the setting.
Depending on the selected paper type and print quality, when this feature is enabled noise is reduced during printing at the cost of print speed.
Displays the Help screen.
Closes the output tray.
Displays additional information or instructions, such as loading paper or placing a document on the scanner; select the icon to display the information.
There is a problem with the indicated setting; select the icon for information on resolving the problem.
Parent topic:
Control Panel Buttons and Lights
Entering Characters on the LCD Screen
Follow these guidelines to enter characters for passwords and other settings.
17
On-screen keyboard
1 Displays the character count
2 Moves the cursor left or right
3 Switches between uppercase and lowercase characters
4 Switches between characters and numbers or symbols
5 Changes the keyboard layout
6 Displays a list of common domain names to choose from
7 Enters a space
8 Select when you are finished
9 Deletes the previous character
18
On-screen keypad
1 Cancels entry and closes the keypad
2 Select when you are finished
3 Clears the entered number
4 Deletes the previous number
Parent topic:
Control Panel Buttons and Lights
Viewing Animations
You can view animations on the LCD screen to help guide you with a procedure or to troubleshoot a problem.
1.
Select the help icon.
19
You see a screen like this:
2.
Select Troubleshooting if you are experiencing a problem or How To to view instructions on common procedures.
3.
Select a topic from the list of available topics and follow the on-screen instructions.
20
While viewing the topics, you may see screens like this:
1 Displays the current step number and the total number of steps
2 Press the left arrow button to view the previous step
3 Indicates your overall progress through the animation
4 Press the right arrow button to view the next step
Parent topic:
Control Panel Buttons and Lights
Changing LCD Screen Language
You can change the language used on the LCD screen.
1.
Press the home icon, if necessary.
2.
Select Settings .
21
You see a screen like this:
3.
Select Basic Settings .
4.
Scroll down and select Language .
5.
Select a language.
6.
Press the home icon to exit.
Parent topic:
Adjusting Control Panel Sounds
You can adjust the sound level heard when you press buttons on the control panel.
1.
Press the home icon, if necessary.
2.
Select Settings .
You see a screen like this:
22
3.
Select Basic Settings .
4.
Select Sound .
5.
Select Normal Mode or Quiet Mode .
Note: You can also press the
Quiet Mode.
icon on the home screen to switch between Normal Mode and
6.
Select Button Press .
7.
Press the – or + icons to increase the sound.
8.
Select OK to exit.
Parent topic:
Adjusting the Screen Brightness
You can adjust the brightness of the LCD screen.
1.
Press the home icon, if necessary.
2.
Select Settings .
You see a screen like this:
3.
Select Basic Settings .
4.
Select LCD Brightness .
5.
Press the – or + buttons to decrease or increase the brightness.
6.
Select OK to exit.
23
Parent topic:
Turning Off Auto Selection Mode
Auto Selection Mode changes the menu options on the LCD screen automatically depending on the action you perform. For example, loading a memory card automatically displays memory card-related menu options on the screen. You can turn off this feature if desired.
1.
Press the home icon, if necessary.
2.
Select Settings .
You see a screen like this:
3.
Scroll down and select Guide Functions .
4.
Select Auto Selection Mode .
5.
Turn off this mode for the desired options displayed on the screen.
6.
Press the home icon to exit.
Parent topic:
Product Parts Locations
See these sections to identify the parts on your product.
Product Parts - Top and Bottom
Parent topic:
24
Product Parts - Top and Bottom
1 Automatic Document Feeder (ADF)
2 ADF cover
3 ADF edge guide
4 ADF input tray
5 ADF output tray
25
1 Rear paper feed slot
2 Paper support
3 Rear paper feed cover
4 Edge guides
5 CD/DVD tray
Parent topic:
Product Parts - Front
26
1 Front cover
2 Output tray
3 Cassette 1 (upper cassette)
4 Cassette 2 (lower cassette)
5 Cassette edge guides
1 CD/DVD tray slot
2 CD/DVD tray
Parent topic:
27
Product Parts - Inside
1 Document cover
2 Scanner glass
3 Memory card slot
28
4 USB Type A port for external devices
1 Scanner unit
2 Print head/ink cartridge holder
3 The power button and light
4 Control panel
Parent topic:
29
Product Parts - Back
1 AC inlet
2 Rear cover (duplexer)
3 Vent
4 USB port
5 LAN (Ethernet) port
Parent topic:
30
Using Power Saving Settings
Your product enters sleep mode automatically and turns off the LCD screen if it is not used for a period of time. You can make the time period shorter and select other options to save energy and resources.
Changing the Sleep Timer Settings
Changing the Power Off Timer Settings
Parent topic:
Changing the Sleep Timer Settings
You can adjust the time period before your product enters sleep mode and turns off the LCD screen.
1.
Press the home icon, if necessary.
2.
Select Settings .
You see a screen like this:
3.
Select Basic Settings .
4.
Scroll down and select Sleep Timer .
5.
Select a time period between 3minutes and 15minutes .
Parent topic:
Changing the Power Off Timer Settings
You can have the product turn off automatically if it is not used for a specified period of time.
1.
Press the home icon, if necessary.
2.
Select Settings .
31
You see a screen like this:
3.
Select Basic Settings .
4.
Scroll down and select Power Off Timer .
5.
Select a time period between 30minutes and 12h (12 hours).
Parent topic:
Epson Connect Solutions for Smartphones, Tablets, and More
Use your smartphone, tablet, or computer to print and scan documents, photos, emails, and web pages from your home, office, or even across the globe.
Note: If you are using your Epson product with the Windows 10 S operating system, you cannot use the software described in this section. You also cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows
Store.
Print from anywhere with these Epson Connect solutions:
• Epson Email Print
• Epson iPrint Mobile App
• Epson Remote Print
Scan and send a file as an email or upload it to an online service directly from your Epson product with
Epson Scan to Cloud or the Epson iPrint Mobile App.
Setting Up Epson Connect Services
32
Using the Epson iPrint Mobile App
Parent topic:
Setting Up Epson Connect Services
If you did not activate your product's email address for use with Epson Connect when you set up your product, you can activate it using the product control panel.
1.
Press the home icon, if necessary.
2.
Select Settings .
You see a screen like this:
3.
Select Web Service Settings .
4.
Select Epson Connect Services .
You see a screen like this:
33
5.
Select Register .
6.
Follow the instructions on the screen to activate your product's email address.
Parent topic:
Epson Connect Solutions for Smartphones, Tablets, and More
Related topics
Using Epson Email Print
With Epson Email Print, you can print from any device that can send email, such as your smartphone, tablet, or laptop. Just activate your product's unique email address. When you want to print, attach a
PDF, Microsoft Office document, or photo to an email and send it to your product. Both the email and the attachments will print automatically.
1.
Connect your product to your network. See the link below.
2.
If you did not already set up Email Print when you installed your product software, see the link below to use your product control panel to activate your unique email address. Or visit epson.com/connect
(U.S), epson.ca/connect (Canada), or epsonconnect.com
(Caribbean) to learn more about Email
Print, create your Epson Connect account, and register your product to the Epson Connect service.
3.
Now you are ready to send and print emails to your product's Email Print address.
Note: Go to epsonconnect.com
and log into your Epson Connect account to personalize your product's email, adjust print settings, and set up other Epson Connect services.
Parent topic:
Epson Connect Solutions for Smartphones, Tablets, and More
Related topics
Using the Epson iPrint Mobile App
Use this free Apple and Android app to print and scan with networked Epson products. Epson iPrint lets you print PDFs, Microsoft Office documents, photos, and web pages over a wireless network. You can scan and save a file on your device, send it as an email, or upload it to an online service such as Box,
Dropbox, Evernote, or Google Drive.
1.
Connect your product to your wireless network. See the link below.
2.
Visit epson.com/connect (U.S), epson.ca/connect (Canada), or epson.com.jm/connect (Caribbean) to learn more about Epson iPrint and check the compatibility of your mobile device.
3.
Download Epson iPrint from the Apple App Store or Google Play.
34
4.
Connect your mobile device to the same wireless network as your product.
5.
Open Epson iPrint and select your Epson product.
Now you are ready to print or scan with your mobile device and your Epson product.
Parent topic:
Epson Connect Solutions for Smartphones, Tablets, and More
Related topics
Using Epson Remote Print
With Epson Remote Print software, you can print from your laptop or desktop computer to an Epson
Email-enabled product anywhere in the world.
1.
Connect your Epson product to your wireless network. See the link below.
2.
If you did not already set up an Epson Connect account when you installed your product software, visit epsonconnect.com
to create your account and register your product to the Epson Connect service.
Note: Make a note of your product's email address.
3.
Visit epsonconnect.com
to learn more about Remote Print and how to download the Remote Print
Driver software.
4.
Download and install the Remote Print software.
5.
Enter the email address and optional access key of your Epson product during Remote Print setup.
6.
Now you are ready to print remotely. Select the print command in your laptop or desktop computer application and choose the Remote Print option for your Epson product.
Parent topic:
Epson Connect Solutions for Smartphones, Tablets, and More
Related topics
Using Epson Scan to Cloud
The Epson Scan to Cloud service allows you to scan and send a file as an email or upload it to an online service directly from your Epson product. Register an email address or online services such as Box,
DropBox, Evernote, or Google Drive with your Epson Connect account.
1.
Connect your Epson product to your network. See the link below.
35
2.
If you did not already set up an Epson Connect account when you installed your product software, visit epsonconnect.com
to create your account and register your product to the Epson Connect service.
Note: Make a note of your product's email address and password.
3.
Visit epsonconnect.com
to sign into your account with the email address and password you selected.
4.
Select your product, select Scan to Cloud , and select Destination List .
5.
Click Add , then follow the instructions on the screen to create your destination list.
6.
Now you are ready to use Scan to Cloud. Select the setting for scanning to Scan to Cloud on your
Epson product control panel.
Parent topic:
Epson Connect Solutions for Smartphones, Tablets, and More
Related topics
Using AirPrint
AirPrint enables instant wireless printing from iPhone, iPad, and iPod touch with the latest version of iOS, and Mac with the latest version of OS X or macOS.
Note: If you disabled paper configuration messages on your product control panel, you cannot use
AirPrint. See the link below to enable the messages, if necessary.
1.
Load paper in your product.
2.
Set up your product for wireless printing. See the link below.
3.
Connect your Apple device to the same wireless network that your product is using.
4.
Print from your device to your product.
Note: For details, see the AirPrint page on the Apple website.
36
Parent topic:
Related tasks
Turning Off the Paper Setting Alert
Related topics
Using Google Cloud Print
With a Google Account, you can print from your Apple or Android device to your Epson product. You can also print from Chromebooks and the Google Chrome browser without drivers or cables.
1.
Connect your Epson product to your wireless network. See the link below.
2.
Note your product's IP address by checking your network status. See the link below.
3.
Connect your computer or your Apple or Android device to the same wireless network as your Epson product.
4.
Enter your product's IP address into the address bar of a web browser.
5.
Select the Google Cloud Print Services option.
Note: If you don't see the Google Cloud Print Services option, turn your product off and back on. If the option still doesn't appear, select the Firmware Update option and follow the on-screen instructions to update your product.
6.
Click Register .
7.
Select the checkbox to agree to the Usage Advisory and click Next .
8.
Click OK to launch the sign-in page.
A separate browser window opens.
9.
Enter your Google Account username and password and click Sign in , or, if you don't have an account, click Sign up for a new Google Account and follow the on-screen instructions.
10. Click Finish printer registration to complete setup and print a test page.
Your product is now linked to your Google Account and can be accessed from any Chromebook, computer, Apple or Android device with Internet access. Visit Epson Support for Google Cloud Print
(U.S) or Epson Support for Google Cloud Print (Canada) for more information on using Google Cloud
Print, or the Google Cloud Print website for a list of supported apps .
Setting Up Google Cloud Print on a Chromebook
37
Parent topic:
Related topics
Setting Up Google Cloud Print on a Chromebook
With a Google Account, you can print from a Chromebook without drivers or cables.
1.
Connect your Epson product to your wireless network. See the link below.
2.
Turn on your Chromebook and connect it to the same wireless network as your product.
Note: See your Chromebook's documentation for details on connecting to a network.
3.
Do one of the following:
• Click Add to Cloud Print in the notification that appears in the corner of your Chromebook screen.
Note: If you do not see a notification, check to see if a number appears in the status area at the lower-right corner of the screen. Click this number to open the notifications menu, then click Add to Cloud Print .
• Open a web browser and enter chrome://devices in the address bar. Skip to step 5.
• If you see a registration confirmation screen instead, click Register .
4.
Click Add Device .
5.
Click the Register button that appears next to your product.
6.
Click Register on the confirmation screen. Your product's LCD screen displays a confirmation message.
7.
Select OK or press the OK button on your product to confirm the Google Cloud Print connection and print a test page.
Your product is now linked to your Google Account and can be accessed from any Chromebook, iPhone, or Android phone with Internet access. Visit Epson Support for Google Cloud Print (U.S) or Epson
Support for Google Cloud Print (Canada) for more information on using Google Cloud Print, or the
Google Cloud Print website for a list of supported apps .
Parent topic:
38
Related topics
Android Printing Using the Epson Print Enabler
You can wirelessly print your documents, emails, photos, and web pages right from your Android phone or tablet (Android v4.4 or later). With a few taps, your Android device will discover your nearby Epson product and print.
1.
Connect your Epson product to your wireless network. See the link below.
2.
On your Android device, download the Epson Print Enabler plug-in from Google Play.
3.
Go to Settings on your Android device, select Printing , and enable the Epson plug-in.
4.
Connect your Android device to the same wireless network as your product.
5.
Now you are ready to print. From an Android application such as Chrome or Gmail, tap the menu icon and print whatever is on the screen.
Note: If you do not see your product, tap All Printers and select your product.
Parent topic:
Related topics
Using Fire OS Printing
You can wirelessly print from Amazon Fire tablets and phones to your nearby networked Epson product.
There is no software to download, no drivers to install, and no cables to connect. With just a few taps in
Email, Calendar, Contacts, and WPS Office, you can send whatever is on the screen to an Epson product.
1.
Connect your Epson product to your wireless network. See the link below.
2.
Connect your Amazon device to the same wireless network as your product.
3.
Now you are ready to print. From your Amazon application, tap the print option and select your product to print whatever is on the screen.
Note: If you see a message telling you that a plug-in is required, tap OK and tap Download . If your
Amazon Fire product uses Fire OS 5 and above, your device automatically uses the built-in Mopria
Print Service app to print.
39
Visit epson.com/connect (U.S), epson.ca/connect (Canada), or epson.com.jm/connect (Caribbean) to learn more about Fire OS Printing (one of many Epson Connect Partner Solutions) and check the compatibility of your mobile device.
Parent topic:
Related topics
Using Windows 10 Mobile Printing
You can wirelessly print from Windows 10 Mobile tablets and phones to your nearby networked Epson product. There is no software to download, no drivers to install, and no cables to connect. Look for the print option in your Windows 10 application to send whatever is on the screen to an Epson product.
1.
Connect your Epson product to your wireless network. See the link below.
2.
Connect your Windows 10 Mobile device to the same wireless network as your product.
3.
Now you are ready to print. From your Windows 10 application, tap the print option and select your product to print whatever is on the screen.
Visit epson.com/connect (U.S), epson.ca/connect (Canada), or epson.com.jm/connect (Caribbean) to learn more about Windows 10 Mobile Printing (one of many Epson Connect Partner Solutions) and check the compatibility of your mobile device.
Parent topic:
Related topics
Using Epson Print and Scan App with Windows Tablets
You can use this free app to print photos and scan from your Windows (Windows 8 or higher) Surface
RT or Pro tablet with networked Epson products. Epson Print and Scan App allows you to scan and capture images right to your tablet or to Microsoft OneDrive.
Note: The Epson Print and Scan App does not support Windows 10 Mobile printing.
1.
Connect your Epson product to your wireless network. See the link below.
2.
Download Epson Print and Scan App from the Microsoft Windows Store.
3.
Connect your Windows tablet to the same wireless network as your product.
4.
Open Epson Print and Scan App and select your Epson product.
40
Now you are ready to print photos or scan.
Visit epson.com/connect (U.S), epson.ca/connect (Canada), or epson.com.jm/connect (Caribbean) to learn more about Epson Print and Scan App.
Parent topic:
Related topics
Using the Mopria Print Service
You can use the Mopria Print Service to print from your Android phone or tablet (Android v4.4 or later) to your Epson product or any Mopria-certified product from other manufacturers. You can download the
Mopria Print Service from Google Play.
Note: For details on the Mopria Print Service, click here (U.S) or click here (Canada).
1.
Connect your Epson product to your wireless network. See the link below.
2.
On your Android device, download the Mopria Print Service from Google Play.
Note: On some Samsung Galaxy devices, Mopria may come preinstalled.
3.
Go to Settings on your Android device, select Printing , and enable the Mopria Print Service.
4.
Connect your Android device to the same wireless network as your product.
5.
Now you are ready to print. From an Android application such as Chrome or Gmail, tap the menu icon and select Print . Then select All printers , select your Epson product, adjust your print settings, and print.
Parent topic:
Related topics
41
Wi-Fi or Wired Networking
See these sections to use your product on a Wi-Fi or wired network.
Network Security Recommendations
Wi-Fi Infrastructure Mode Setup
Printing a Network Status Sheet
Changing or Updating Network Connections
Network Security Recommendations
To help deter unauthorized access to your product over a network, you should protect your network environment using appropriate security measures.
Security measures such as these can help deter threats such as loss of user data, use of telephone and fax lines, and other intrusions:
• Enable security on your wireless LAN
Enable the appropriate security on the wireless LAN you plan to use with your product. Network security such as a network password can deter interception of traffic over the wireless LAN. Your router may already have a default password enabled by your Internet service provider (ISP). See your
ISP and router documentation for instructions on how to change the default password and better secure your network.
• Connect your product only to a network protected by a firewall
Connecting your product directly to the Internet may leave it vulnerable to security threats. Instead, connect it to a router or other network connection protected by a firewall. Your router may already have a firewall set up by your Internet service provider; check with your ISP for confirmation. For best results, set up and use a private IP address for your network connection.
• Change the default administrator password on your product
If your product has an option to set an administrator password, change the default administrator password to deter access by unauthorized users to personal data stored on your product, such as IDs, passwords, and contact lists.
Parent topic:
42
Wi-Fi Infrastructure Mode Setup
You can set up your product to communicate with your computer using a wireless router or access point.
The wireless router or access point can be connected to your computer over a wireless or wired network.
1 Epson product
2 Wireless router or access point
3 Computer with a wireless interface
4 Computer
5 Internet
6 Ethernet cable (used only for wired connection to the wireless router or access point)
Selecting Wireless Network Settings from the Control Panel
Parent topic:
43
Selecting Wireless Network Settings from the Control Panel
You can select or change wireless network settings using your product control panel.
To install your product on a wireless network, follow the instructions on the Start Here sheet and install the necessary software by downloading it from the Epson website. The installer program guides you through network setup.
Note: Breakdown or repair of this product may cause loss of network data and settings. Epson is not responsible for backing up or recovering data and settings during or after the warranty period. We recommend that you make your own backup or print out your network data and settings.
1.
Press the home icon, if necessary.
2.
Press the icon.
You see a screen like this:
3.
Select Wi-Fi (Recommended) . (If the product is already installed on a wired network, select
Router .)
4.
Select Start Setup or Change Settings . (If the product is already installed on a wired network, select Change to Wi-Fi Connection and select Yes to confirm.)
5.
Select Wi-Fi Setup Wizard .
6.
Select the name of your wireless network or select Enter Manually to enter the name manually. Use the displayed keypad to enter your network name.
44
7.
Select the Enter Password field and enter your wireless password using the on-screen keyboard.
Note: The network name and password are case sensitive. Be sure to correctly enter uppercase and lowercase letters, and numeric or special characters.
• To move the cursor, press the left or right arrows.
• To change the case of letters, press
• To delete the previous character, press
.
.
• To enter numbers and symbols, press .
• To enter a space, press .
8.
Press OK when you finish entering your password.
9.
Confirm the displayed network settings and select Start Setup to save them.
10. If you want to print a network setup report, select Print Check Report . (Otherwise, select OK .)
11. Select Close to exit.
You see the icon on the LCD screen and should be able to connect to your product directly from your computer or device, and then print. If you are printing from a computer, make sure you installed the network software as described on the Start Here sheet.
Note: If you don't see the icon on the LCD screen, you may have selected the wrong network name or entered the password incorrectly. Repeat these steps to try again.
45
Parent topic:
Wi-Fi Infrastructure Mode Setup
Related references
Related tasks
Entering Characters on the LCD Screen
Wi-Fi Direct Mode Setup
You can set up your product to communicate directly with your computer or another device without requiring a wireless router or access point. In Wi-Fi Direct Mode, the product itself acts as a network access point for up to 4 devices.
1 Epson product
2 Computer with a wireless interface
3 Other wireless device
Parent topic:
Related references
46
Enabling Wi-Fi Direct Mode
You can enable Wi-Fi Direct mode to allow direct communication between your product and computer or other devices without a wireless router or access point.
1.
Press the home icon, if necessary.
2.
Press the icon.
You see a screen like this:
3.
Select Wi-Fi Direct .
4.
Select Start Setup .
5.
Select Start Setup again.
You see a screen like this:
47
6.
Use your computer or wireless device to select the Wi-Fi network name (SSID) displayed on the
LCD screen, then enter the password shown.
7.
Press OK when you finish entering your password.
8.
Select Close to exit.
You see the icon on the LCD screen and should be able to connect to your product directly from your computer or device, and then print. If you are printing from a computer, make sure you installed the network software as described on the Start Here sheet.
Note: If you don't see the icon on the LCD screen, you may have selected the wrong network name or entered the password incorrectly. Repeat these steps to try again.
Parent topic:
Wi-Fi Protected Setup (WPS)
If your network uses a WPS-enabled wireless router or access point, you can quickly connect your product to the network using Wi-Fi Protected Setup (WPS).
Note: To check if your router is WPS-enabled, look for a button labeled WPS on your router or access point. If there is no hardware button, there may be a virtual WPS button in the software for the device.
Check your network product documentation for details.
Using WPS to Connect to a Network
Parent topic:
Using WPS to Connect to a Network
If you have a WPS-enabled wireless router or access point, you can use Wi-Fi Protected Setup (WPS) to connect your product to the network.
1.
Press the home icon, if necessary.
2.
Press the icon.
48
You see a screen like this:
3.
Select Wi-Fi (Recommended) . (If the product is already installed on a wired network, select
Router .)
4.
Select Start Setup or Change Settings . (If the product is already installed on a wired network, select Change to Wi-Fi Connection and select Yes to confirm.)
5.
Select Push Button Setup (WPS) .
6.
Follow the instructions on the LCD screen to complete WPS setup.
7.
Select Close to exit.
You see the icon on the LCD screen and should be able to connect to your product directly from your computer or device, and then print. If you are printing from a computer, make sure you installed the network software as described on the Start Here sheet.
Note: If you don't see the icon on the LCD screen, you may have selected the wrong network name or entered the password incorrectly. Repeat these steps to try again.
Parent topic:
Printing a Network Status Sheet
You can print a network status sheet to help you determine the causes of any problems you may have using your product on a network.
1.
Press the home icon, if necessary.
2.
Select Settings .
49
You see a screen like this:
3.
Select Network Settings .
4.
Select Network Status .
5.
Select Print Status Sheet .
6.
Select Print .
Examine the settings shown on the network status sheet to diagnose any problems you have.
Parent topic:
Changing or Updating Network Connections
See these sections to change or update how your product connects to a network.
Accessing the Web Config Utility
Changing a USB Connection to a Wi-Fi Connection
Changing a Wi-Fi Connection to a Wired Network Connection
Connecting to a New Wi-Fi Router
Parent topic:
Accessing the Web Config Utility
You can select your product's network settings and confirm its operating status using a web browser.
You do this by accessing your product's built-in Web Config utility from a computer or other device that is connected to the same network as your product.
1.
Print a network status sheet.
50
2.
Locate the IP address for your product that is listed on the network status sheet.
3.
On a computer or other device connected to the same network as your product, open a web browser.
4.
Enter your product's IP address into the address bar.
You see the available Web Config utility options.
Parent topic:
Changing or Updating Network Connections
Changing a USB Connection to a Wi-Fi Connection
If you have already connected your product to your computer using a USB connection, you can change to a Wi-Fi connection.
1.
Disconnect the USB cable from your product.
2.
Uninstall your product software.
3.
Download and install your product software from the Epson website using the instructions on the
Start Here sheet.
Parent topic:
Changing or Updating Network Connections
Changing a Wi-Fi Connection to a Wired Network Connection
If you have already connected your product to your computer wirelessly, you can change to a wired network connection if necessary.
1.
Disable your product's Wi-Fi features.
2.
Connect one end of an Ethernet network cable to the product's LAN port.
3.
Connect the other end to any available LAN port on your router or access point.
4.
Uninstall your product software.
5.
Download and install your product software from the Epson website.
6.
Follow the on-screen instructions to install the software.
7.
When you see the Select Your Connection screen, select Wired network connection .
8.
If you see a Select Setup Option screen, select Set up printer for the first time .
9.
Continue following the rest of the on-screen instructions.
Parent topic:
Changing or Updating Network Connections
51
Related tasks
Connecting to a New Wi-Fi Router
If you change the wireless router you have been using on your network, you need to update your product's Wi-Fi connection to the new router.
Note: If you switch to a 5 GHz wireless router, set the router to operate in dual band (2.4 GHz and
5 GHz) mode. See your router documentation for instructions.
1.
Do one of the following:
• Windows : Uninstall your product software.
• Mac : Go to the next step.
2.
Download and install your product software from the Epson website using the instructions on the
Start Here sheet.
Parent topic:
Changing or Updating Network Connections
Related tasks
Uninstalling Product Software - Windows
Disabling Wi-Fi Features
You may need to disable your product's Wi-Fi features if you change your network connection type or need to solve a problem with your network connection.
Note: Before disabling Wi-Fi features, make a note of your product's SSID (network name) and password, and any network settings selected for the Epson Connect services you may use.
1.
Press the home icon, if necessary.
2.
Press the icon.
52
You see a screen like this:
3.
Select Wi-Fi (Recommended) .
4.
Select Change Settings .
5.
Select Others .
6.
Select Disable Wi-Fi .
7.
Select Start Setup to disable Wi-Fi.
8.
Select Close .
Parent topic:
Changing or Updating Network Connections
53
Loading Paper
Before you print, load paper for the type of printing you will do.
Loading Paper in Cassette 1 (Upper Cassette)
Loading Paper in Cassette 2 (Lower Cassette)
Loading Paper in the Rear Paper Feed Slot
Selecting the Paper Settings for Each Source - Control Panel
Turning Off the Paper Setting Alert
Double-sided Printing Capacity
Borderless Paper Type Compatibility
Paper or Media Type Settings - Control Panel
Paper or Media Type Settings - Printer Software
Loading Paper in Cassette 1 (Upper Cassette)
You can load photo paper and other media in these sizes in the upper paper cassette:
• 3.5 × 5 inches (89 × 127 mm)
• 4 × 6 inches (102 × 152 mm)
• 5 × 7 inches (127 × 178 mm)
• 16:9 wide (4 × 7.1 inches [102 × 181 mm])
• A6 (4.1 × 5.8 inches [105 × 148 mm])
• B6 (5 × 7.2 inches [128 × 182 mm])
Note: Do not remove or insert the paper cassette during printing.
1.
Close the output tray by hand or by selecting the icon on the LCD screen, if necessary.
54
2.
Raise the control panel.
3.
Open the front cover.
55
4.
Slide out the upper paper cassette.
Note: If the cassette is too far inside the product to reach, turn off your product and turn it back on again to reset the cassette's position.
5.
Slide the edge guides outward.
6.
Slide the front edge guide to the position for the paper size you want to use.
56
7.
Insert paper in the cassette with the glossy or printable side facedown.
Note: Make sure the paper is loaded against the front edge guide and does not extend beyond the rear edge of the cassette.
57
8.
Slide the side edge guides against the paper, but not too tightly.
Note: Make sure the paper fits under the tabs on the edge guides.
58
9.
Keeping the cassette flat, slide it into your product. Align the edge of the cassette to your product using the alignment marks as shown.
10. Lower the control panel.
11. Select the size and type of the paper you loaded on the LCD screen and select Close .
The output tray extends automatically when you print.
Always follow these paper loading guidelines:
• Load only the recommended number of sheets.
• Load paper short edge first and printable side facedown.
• Make sure the paper is under the tabs on the edge guides and not sticking out from the end of the cassette.
• Check the paper package for any additional loading instructions.
Parent topic:
59
Related references
Double-sided Printing Capacity
Paper or Media Type Settings - Control Panel
Related tasks
Loading Paper in Cassette 2 (Lower Cassette)
Loading Paper in the Rear Paper Feed Slot
Loading Paper in Cassette 2 (Lower Cassette)
You can load paper up to this size in the lower paper cassette: Legal (8.5 × 14 inches [216 × 356 mm]).
Note: Do not remove or insert the paper cassette during printing.
1.
Raise the control panel, if necessary.
2.
Close the output tray by hand or by selecting the icon on the LCD screen, if necessary.
60
3.
Open the front cover.
61
4.
Pull on the front cover to slide out the lower paper cassette.
5.
Slide the edge guides outward.
62
6.
Set the front edge guide to the paper size you are using.
7.
Do one of the following:
• If you are using legal-size paper, remove the CD/DVD tray from the bottom of the lower cassette.
Press the button on the lower cassette and then extend it as shown.
63
• Insert paper with the glossy or printable side face down.
Note: Make sure the paper is loaded against the front edge guide and does not extend beyond the rear edge of the cassette.
• Insert up to 10 envelopes, printable side down and flap edge left, as shown.
64
8.
Slide the side edge guides against the paper, but not too tightly.
Note: Make sure the paper fits under the tabs on the edge guides.
9.
Keep the cassette flat as you slide it into your product.
65
Note: Leave enough space in front of the product for the paper to be fully ejected. Do not remove or insert the paper cassette while the product is operating.
10. Lower the control panel.
11. Select the size and type of the paper you loaded on the LCD screen and select Close .
The output tray extends automatically when you print.
Always follow these paper loading guidelines:
• Load only the recommended number of sheets.
• Load paper short edge first and printable side down.
• Make sure the paper is under the tabs on the edge guides and not sticking out from the end of the cassette.
• If you have trouble loading a stack of envelopes, press each envelope flat before loading it or load one envelope at a time.
• Do not load an envelope that is curled, folded, or too thin, or that has a plastic window.
• If print quality declines when printing multiple envelopes, try loading one envelope at a time.
• Check the paper package for any additional loading instructions.
Parent topic:
Related references
Double-sided Printing Capacity
Paper or Media Type Settings - Control Panel
Related tasks
Loading Paper in Cassette 1 (Upper Cassette)
Loading Paper in the Rear Paper Feed Slot
Loading Paper in the Rear Paper Feed Slot
You can load a single envelope or sheet of a variety of paper types and sizes using the rear paper feed slot.
1.
Do one of the following:
• If you are printing from a computer, select Rear Paper Feed Slot as the Paper Source setting and click Print .
66
• If you are printing from the product's control panel, select Rear Paper Feed Slot as the Paper
Source Setting and press the start button.
You see a message on the LCD screen, then you see instructions for loading paper.
2.
Open the rear paper feed slot cover.
3.
Raise the paper support.
67
4.
Slide the edge guides outward.
5.
Do one of the following:
• Insert a single sheet of paper, glossy or printable side up and short edge first, centered at the arrow mark on the paper support. Insert the paper approximately 2 inches (5 cm) into the slot.
68
• Load an envelope printable side up and flap edge left, centered at the arrow mark on the paper support.
• Load a single sheet of loose-leaf or other paper with holes facing as shown, centered at the arrow mark on the paper support. Load only one sheet at a time in only these sizes: Letter (8.5 × 11 inches [216 × 279 mm]), A4 (8.3 × 11.7 inches [210 × 297 mm]), or Legal (8.5 × 14 inches
[216 × 356 mm]).
69
6.
Slide the edge guides against the paper or envelope, but not too tightly.
7.
When you are ready to print, press the start button.
The output tray extends automatically when you print.
Always follow these paper loading guidelines:
• Load only one sheet at a time.
• Load paper short edge first, no matter which way your document faces.
• Load letterhead or pre-printed paper top edge first.
• Do not load an envelope that is curled, folded, or too thin, or that has a plastic window.
• Check the paper package for any additional loading instructions.
Parent topic:
Related references
Double-sided Printing Capacity
Paper or Media Type Settings - Control Panel
Related tasks
Loading Paper in Cassette 1 (Upper Cassette)
Loading Paper in Cassette 2 (Lower Cassette)
Selecting the Paper Settings for Each Source - Control Panel
You can change the default paper size and paper type for each source using the control panel on the product.
1.
Press the home icon, if necessary.
2.
Select Settings .
70
You see a screen like this:
3.
Select Printer Settings .
4.
Select Paper Source Setting .
Note: To turn off the automatic display of the paper settings selection screen after paper is loaded in the cassettes, set the Paper Configuration setting to Off . (AirPrint is disabled in this setting.)
5.
Select Paper Setup .
6.
Select the paper source you want to change.
7.
Select Paper Size .
8.
Select the paper size you loaded.
9.
Select Paper Type .
10. Select the paper type you loaded.
Note: To save a preset paper type, select the Favorite Paper Settings icon and specify the paper size and type.
11. Press to select another paper source to change, or press the home icon to exit.
Parent topic:
Turning Off the Paper Setting Alert
The Paper Setting Alert warns you when the paper settings do not match the paper you loaded. You can turn off this feature from the product's control panel.
71
1.
Press the home icon, if necessary.
2.
Select Settings .
3.
Scroll down and select Guide Functions .
You see this screen:
4.
Select Paper Mismatch .
5.
Set the Paper Mismatch setting to Off .
6.
Select Close to exit.
Parent topic:
Paper Loading Capacity
You can load 1 sheet of paper or one envelope at a time in the rear paper feed slot. See the table here for the loading capacity of the paper cassettes.
Paper type
Plain paper
Load up to this many sheets
Cassette 2 (lower cassette)
Letter (8.5 × 11 inches
[216 × 279 mm]) and A4
(8.3 × 11.7 inches
[210 × 297 mm]) size: up to the arrow symbol on the front edge guide
Legal (8.5 × 14 inches
[216 × 356 mm]) size: 50 sheets
Cassette 1 (upper cassette)
—
72
Paper type Load up to this many sheets
Cassette 2 (lower cassette)
80 sheets Epson Bright White Pro Paper
Epson Bright White Premium
Paper
Epson Multipurpose Plus Paper
Epson Presentation Paper Matte
Epson Premium Presentation
Paper Matte
Epson Ultra Premium Presentation
Paper Matte
Epson Photo Paper Glossy
Epson Iron-on Cool Peel Transfer paper
Epson Brochure & Flyer Paper
Matte Double-sided
Envelopes
20 sheets
20 sheets
Epson Premium Photo Paper
Glossy
Epson Ultra Premium Photo Paper
Glossy
Epson Premium Photo Paper
Semi-gloss
Epson Ultra Premium Photo Paper
Luster
Epson Premium Presentation
Paper Matte Double-sided
Epson Photo Quality Self-adhesive
Sheets
1 sheet
10 envelopes
Parent topic:
Cassette 1 (upper cassette)
—
—
20 sheets
—
—
73
Related references
Double-sided Printing Capacity
Double-sided Printing Capacity
You can print double-sided using Auto or Manual mode on the paper types and sizes listed here.
Note: You can not print double-sided from the rear paper feed slot.
Paper type Size Double-sided Printing Capacity
Auto Manual
100 sheets (cassette 2) 30 sheets
(cassette 2)
Plain paper
Copier paper
Epson Bright
White Pro Paper
Epson Bright
White Premium
Paper
Epson
Multipurpose
Plus Paper
Epson Premium
Presentation
Paper Matte
Double-sided
Epson Brochure
& Flyer Paper
Matte Doublesided
Letter (8.5 × 11 inches
[216 × 279 mm]) and A4 (8.3 × 11.7
inches [210 × 297 mm])
Legal (8.5 × 14 inches
[216 × 356 mm])
Letter (8.5 × 11 inches
[216 × 279 mm]) and A4 (8.3 × 11.7
inches [210 × 297 mm])
Letter (8.5 × 11 inches
[216 × 279 mm])
You cannot print double-sided on these paper types:
• Epson Presentation Paper Matte
—
80 sheets (cassette 2)
1 sheet (cassette 2)
30 sheets
(cassette 2)
30 sheets
(cassette 2)
1 sheet
(cassette 2)
74
• Epson Premium Presentation Paper Matte
• Epson Ultra Premium Presentation Paper Matte
• Epson Photo Paper Glossy
• Epson Premium Photo Paper Glossy
• Epson Premium Photo Paper Semi-gloss
• Epson Ultra Premium Photo Paper Glossy
• Epson Ultra Premium Photo Paper Luster
• Epson Iron-on Cool Peel Transfer paper
• Epson Photo Quality Self-adhesive Sheets
• Envelopes
Parent topic:
Related references
Compatible Epson Papers
You can purchase genuine Epson ink and paper at epson.com
(U.S. sales), epson.ca
(Canadian sales), or epson.com.jm
(Caribbean sales). You can also purchase supplies from an Epson authorized reseller.
To find the nearest one, call 800-GO-EPSON (800-463-7766) in the U.S. or 800-807-7766 in Canada.
Paper Type
Epson Bright White Pro Paper
Epson Bright White Premium
Paper
Epson Multipurpose Plus Paper
Size
Letter (8.5 × 11 inches
[216 × 279 mm])
Letter (8.5 × 11 inches
[216 × 279 mm])
Letter (8.5 × 11 inches
[216 × 279 mm])
Part number
S041586
S450218
S450217
Sheet count
500
500
500
75
Paper Type
Epson Photo Paper Glossy
Epson Premium Photo Paper
Glossy
Size
Letter (8.5 × 11 inches
[216 × 279 mm])
Part number
4 × 6 inches (102 × 152 mm) S041809
S042038
S041141
S041649
S041271
4 × 6 inches (102 × 152 mm) S041808
S041727
5 × 7 inches (127 × 178 mm) S041464
8 × 10 inches (203 × 254 mm) S041465
Letter (8.5 × 11 inches
[216 × 279 mm])
S042183
S041667
Epson Ultra Premium Photo Paper
Glossy
4 × 6 inches (102 × 152 mm) S042181
S042174
5 × 7 inches (127 × 178 mm) S041945
8 × 10 inches (203 × 254 mm) S041946
Letter (8.5 × 11 inches
[216 × 279 mm])
S042182
S042175
Epson Ultra Premium Photo Paper
Luster
Epson Premium Photo Paper
Semi-gloss
Letter (8.5 × 11 inches
[216 × 279 mm])
S041405
4 × 6 inches (102 × 152 mm) S041982
Letter (8.5 × 11 inches
[216 × 279 mm])
S041331
S041062 Epson Presentation Paper Matte Letter (8.5 × 11 inches
[216 × 279 mm])
Legal (8.5 × 14 inches
[216 × 356 mm])
S041067
20
20
25
50
50
20
20
25
50
60
100
50
100
40
100
Sheet count
50
100
20
40
20
100
100
76
Paper Type
Epson Premium Presentation
Paper Matte
Epson Premium Presentation
Paper Matte Double-sided
Epson Ultra Premium Presentation
Paper Matte
Epson Brochure & Flyer Paper
Matte Double-sided
Epson Photo Quality Self-adhesive
Sheets
Epson Iron-on Cool Peel Transfer paper
Size Part number
8 × 10 inches (203 × 254 mm) S041467
Letter (8.5 × 11 inches
[216 × 279 mm])
S041257
S042180
S041568 Letter (8.5 × 11 inches
[216 × 279 mm])
Letter (8.5 × 11 inches
[216 × 279 mm])
S041341
S042384 Letter (8.5 × 11 inches
[216 × 279 mm])
A4 (8.3 × 11.7 inches
[210 × 297 mm])
Letter (8.5 × 11 inches
[216 × 279 mm])
S041106
S041153
Parent topic:
Borderless Paper Type Compatibility
You can print borderless photos on compatible paper types in compatible sizes:
Borderless Paper Types
• Epson Photo Paper Glossy
• Epson Premium Photo Paper Glossy
• Epson Ultra Premium Photo Paper Glossy
• Epson Premium Photo Paper Semi-gloss
• Epson Ultra Premium Photo Paper Luster
• Epson Presentation Paper Matte
• Epson Premium Presentation Paper Matte
• Epson Premium Presentation Paper Matte Double-sided
• Epson Brochure & Flyer Paper Matte Double-sided
10
10
Sheet count
50
50
100
50
50
150
77
Borderless Paper Sizes
• 4 × 6 inches (102 × 152 mm)
• 5 × 7 inches (127 × 178 mm)
• 8 × 10 inches (203 × 254 mm)
• 16:9 wide (4 × 7.1 inches [102 × 181 mm])
• Letter (8.5 × 11 inches [216 × 279 mm])
• A4 (8.3 × 11.7 inches [210 × 297 mm])
Parent topic:
Paper or Media Type Settings - Control Panel
For this paper
Plain paper
Copier paper
Epson Bright White Pro Paper
Epson Bright White Premium Paper
Epson Multipurpose Plus Paper
Epson Iron-on Cool Peel Transfer paper
Epson Photo Quality Self-adhesive Sheets
Epson Ultra Premium Photo Paper Glossy
Epson Premium Photo Paper Glossy
Epson Photo Paper Glossy
Epson Presentation Paper Matte
Epson Premium Photo Paper Semi-gloss
Epson Ultra Premium Photo Paper Luster
Select this Paper Type setting
Plain Paper
Ultra Glossy
Prem. Glossy
Glossy
Presentation Matte
Prem. Semi-Gloss
Ultra Prem. Photo Luster
78
For this paper Select this Paper Type setting
Epson Premium Presentation Paper Matte
Epson Premium Presentation Paper Matte Doublesided
Prem. Matte
Epson Ultra Premium Presentation Paper Matte
Epson Brochure & Flyer Paper Matte Double-sided
Envelopes Envelope
Parent topic:
Paper or Media Type Settings - Printer Software
For this paper
Plain paper
Epson Bright White Pro Paper
Epson Bright White Premium Paper
Epson Multipurpose Plus Paper
Epson Iron-on Cool Peel Transfer paper
Epson Photo Quality Self-adhesive Sheets
Select this paper Type or Media Type setting
Plain Paper/Bright White Paper
Epson Ultra Premium Photo Paper Glossy
Epson Premium Photo Paper Glossy
Epson Photo Paper Glossy
Epson Presentation Paper Matte
Ultra Premium Photo Paper Glossy
Premium Photo Paper Glossy
Photo Paper Glossy
Presentation Paper Matte
Epson Premium Photo Paper Semi-gloss
Epson Ultra Premium Photo Paper Luster
Premium Photo Paper Semi-Gloss
Ultra Premium Photo Paper Luster
Epson Premium Presentation Paper Matte
Epson Premium Presentation Paper Matte Doublesided
Epson Ultra Premium Presentation Paper Matte
Epson Brochure & Flyer Paper Matte Double-sided
Premium Presentation Paper Matte
79
For this paper
Envelopes
Select this paper Type or Media Type setting
Envelope
Note: The settings listed here are available only when printing from your computer; they do not apply to your product's control panel settings.
Parent topic:
80
Placing Originals on the Product
Follow the instructions here to place your original documents or photos on the product.
Caution: Do not place anything on top of your product or use its cover as a writing surface to avoid damaging it.
Placing Originals on the Scanner Glass
Placing Originals in the Automatic Document Feeder
Placing Originals on the Scanner Glass
You can place originals up to this size on the scanner glass: Letter (8.5 × 11 inches [216 × 279 mm]) or
A4 (8.3 × 11.7 inches [210 × 297 mm]).
1.
Open the document cover.
81
2.
Do one of the following to place your originals:
• Single sheet : Place your original facedown on the scanner glass with the top facing into the corner. Slide the original to the edges of the indicated corner about 0.05 inch (1.5 mm) away from the corner mark on the scanner glass as shown.
• ID card : Place an ID card 0.2 inch (5 mm) away from the corner mark on the scanner glass as shown.
• Multiple photos for copying : You can place multiple photos of different sizes on the scanner glass to make separate copies. Make sure your photos are at least 0.2 inch (5 mm) away from
82
each other and from the corner mark on the scanner glass. You can place photos up to this size:
4 × 6 inches (102 × 152 mm).
• Multiple photos for scanning : You can place multiple photos of different sizes on the scanner glass and save them separately using Photo Mode in Epson Scan 2. Make sure your photos are at least 0.6 inch × 0.6 inch (15 × 15 mm) in size. Place them away from each other and the corner mark by at least the distances shown.
1 0.2 inch (4.5 mm)
2 0.8 inch (20 mm)
Note: To view multiple scanned photos in Epson Scan 2, select the Thumbnail checkbox in the preview window.
83
3.
Close the document cover gently to keep your original in place.
Caution: Do not push down on the document cover or scanner glass or you may damage the product.
Remove your originals after scanning. If you leave the originals on the scanner glass for a long time, they may stick to the glass surface.
Parent topic:
Placing Originals on the Product
Placing Originals in the Automatic Document Feeder
You can place single- or multi-page original documents in the Automatic Document Feeder (ADF). You can also use the ADF to scan both sides of a 2-sided document. Make sure the originals meet the
Automatic Document Feeder specifications before loading them.
Caution: Make sure your originals are not creased or folded, and do not contain holes, staples, tape, or other materials that could obstruct the feeder.
Caution: Do not place photographs or valuable artwork in the ADF. Place fragile or valuable originals on the scanner glass to avoid wrinkling or damaging them.
Note: When originals are placed in the ADF and on the scanner glass, priority is given to the originals in the ADF.
84
1.
Open the ADF input tray.
2.
Slide the ADF edge guide outward.
85
3.
Fan your stack of originals and tap them gently on a flat surface to even the edges.
4.
Insert the originals into the ADF faceup and short edge first.
86
Note: Do not load originals above the arrow mark on the ADF edge guide.
The ADF icon on the LCD screen appears.
5.
Slide the ADF edge guide against the originals, but not too tightly.
Note: If you are copying two originals onto one sheet, make sure the originals are loaded as shown.
Select the link below to select the copy orientation setting that matches how you loaded your original.
ADF Original Document Specifications
Parent topic:
Placing Originals on the Product
87
Related references
ADF Original Document Specifications
ADF Original Document Specifications
You can load original documents that meet these specifications in the ADF.
Paper type
Plain paper
Paper size
Letter (8.5 × 11 inches
[216 × 279 mm])
A4 (8.3 × 11.7 inches
[210 × 297 mm])
Legal (8.5 × 14 inches
[216 × 356 mm])
Paper weight
17 to 24 lb
(64 to 95 g/m²)
Loading capacity
Approximately 30 sheets
10 sheets
Caution: Do not load the following types of originals in the ADF, or they may be damaged or may damage the scanner. Use the scanner glass for these types of originals:
• Ripped, curled, folded, deteriorated, or wrinkled originals
• Originals with holes
• Originals containing staples or paper clips
• Originals with labels, stickers, or sticky notes
• Originals that are cut in an irregular shape or with corners that are not right angles
• Originals that are bound
• Thermal paper
• Fabric or other non-paper originals
• Originals with uneven surfaces, such as embossed documents
• Originals with carbon paper backing
• Originals with wet ink
• Transparencies
Parent topic:
Placing Originals in the Automatic Document Feeder
88
Copying
See the information here to copy documents or photos using your product.
Note: Copies may not be exactly the same size as your originals.
Restoring Photos While Copying
Copying Books, ID Cards, or Borderless Photos
Copying Documents or Photos
You can copy documents or photos onto various sizes and types of paper, including Epson special papers.
1.
Place your original document or photo on the product.
2.
Load the paper you want to print on.
3.
Press the home icon, if necessary.
4.
Select Copy .
You see a screen like this:
5.
To print more than one copy, select Copies and use the displayed numeric keypad to select the number of copies (up to 99).
6.
Change any of the displayed settings as necessary.
89
7.
Select the Advanced Settings tab to view and change additional copy settings, if necessary.
8.
Select Preview to preview your copy on the LCD screen.
Note: You can only preview documents that are placed on the scanner glass.
9.
When you are ready to copy, press the Copy icon.
Note: To cancel printing, select Cancel .
Parent topic:
Related references
Related topics
Placing Originals on the Product
Restoring Photos While Copying
You can restore the colors in faded photos as you copy them.
1.
Load the paper you want to print on.
2.
Press the home icon, if necessary.
3.
Select Various prints
4.
Select Various copies .
You see a screen like this:
90
5.
Select Copy/Restore Photos .
6.
Make sure the Restore Color setting is set to On .
7.
Select your other paper and print settings as necessary, then select To Placing Originals .
8.
Place your originals on the scanner glass.
9.
Select Start Scanning .
Your originals are scanned and a preview appears on the LCD screen.
10. If you need to edit the copy, select Edit and change any of these settings as necessary:
• Photo Adjustments : Select Fix Photo On to improve the color, contrast, and sharpness of flawed photos.
• Filter : Select B&W to apply a monochrome filter.
• Crop/Zoom : Zoom in and enlarge a part of the photo and crop it.
11. To print more than one copy, select Copies and use the displayed numeric keypad to select the number of copies (up to 99).
12. When you are ready to copy, press the Copy icon.
Note: To cancel printing, select Cancel .
Parent topic:
Related references
Related topics
Placing Originals on the Product
Copying Books, ID Cards, or Borderless Photos
You can copy two pages of a book or both sides of an ID card onto a single sheet of paper. You can also copy a photo and print it without any borders.
1.
Load the paper you want to print on.
2.
Press the home icon, if necessary.
3.
Select Various prints
91
4.
Select Various copies .
You see a screen like this:
5.
Select one of these options:
• ID Card to scan and copy both sides of an ID card onto one side of paper.
• Book Copy to copy two facing pages of a book onto a single sheet of paper.
Note: Make sure the first page of your original is placed on the scanner glass as described on the
LCD screen and select Print Settings to view and change the print settings, if necessary.
• Borderless Copy to make a copy without margins around the edges.
6.
Place your book, card, or photo on the product.
7.
To print more than one copy, select Copies and use the displayed numeric keypad to select the number of copies (up to 99).
8.
Change any of the displayed settings as necessary.
9.
Select the Advanced Settings tab to view and change additional copy settings, if necessary.
10. Select Preview to preview your copy on the LCD screen.
11. When you are ready to copy, press the Copy icon.
Note: To cancel printing, select Cancel .
12. For ID Card and Book Copy , follow any on-screen instructions to place the rest of your originals and select Start Scanning .
Parent topic:
92
Related references
Related topics
Placing Originals on the Product
Copying Options
Select the copying options you want to use for your copies.
Note: Not all options or settings may be available, depending on other copying settings.
Copy
Copying option Available settings Description
Color mode B&W
Color
Select whether to copy the original in color or black and white
2-Sided 1>1-Sided
2>2-Sided
1>2-Sided
2>1-Sided
Select to make 2-sided copies. When you select 1>2-Sided or 2>2-Sided , also select the Advanced Settings tab to select the orientation and binding edge for your originals or copies.
Density selector Varying levels Adjusts the lightness or darkness of copies
Advanced Settings
Copying option Available settings Description
Reduce/Enlarge 100% Copies the original at its full size
Actual Size
25%->400% and other conversions
Auto Fit Page
Automatically sizes the image at 100%
Automatically converts from one size to another
Automatically sizes the image to fit the paper size you selected
93
Copying option Available settings Description
Paper Size Various sizes Select the paper size you loaded
Paper Type Various paper types Specifies the paper type you loaded
Paper Cassettes Cassette 1 Select the paper source that you want to use
Multi-Page
Original Type
Cassette 2
Rear Paper Feed
Slot
Single Page
2-up
Copies each page of the original onto an individual sheet
Copies multiple page documents onto one sheet. Scroll down and select the document orientation and layout order settings as necessary.
Select the type of original you loaded
Quality
Remove
Background
Expansion
Text
Text & Image
Draft
Standard
Best
Off
On
Various levels
Provides lower quality for draft copies (plain paper only)
Provides good quality for most copies
Provides the highest quality for special copies
Removes or lightens the background color. May not remove very dark or vivid colors.
Enlarges the image to remove borders from the edges of the paper
Parent topic:
94
Printing from a Computer
Before printing from your computer, make sure you have set up your product and installed its software from the Epson website.
Note: If you have an Internet connection, it is a good idea to check for updates to your product software on Epson's support website. If you see a Software Update screen, select Enable automatic checking and click OK . The update scans your system to see if you have the latest product software. Follow the on-screen instructions.
Printing with the Built-in Epson Driver - Windows 10 S
Cancelling Printing Using a Product Button
Printing with Windows
You can print with your product using any Windows application, as described in these sections.
Note: If you are using your Epson product with the Windows 10 S operating system, you cannot use the software described in this section. You also cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows
Store.
Selecting Basic Print Settings - Windows
Selecting Double-sided Printing Settings - Windows
Selecting Additional Layout and Print Options - Windows
Selecting a Printing Preset - Windows
Selecting Extended Settings - Windows
Printing Your Document or Photo - Windows
Selecting Default Print Settings - Windows
Changing Automatic Update Options
Parent topic:
Selecting Basic Print Settings - Windows
Select the basic settings for the document or photo you want to print.
95
1.
Open a photo or document for printing.
2.
Select the print command in your application.
Note: You may need to select a print icon on your screen, the Print option in the File menu, or another command. See your application's help utility for details.
3.
If necessary, select your product name as the printer you want to use.
Note: You may also need to select Properties or Preferences to view your print settings.
You see the Main tab of your printer settings window:
4.
For the Paper Source setting, select where you loaded the paper you want to print on.
96
5.
Select the size of the paper you loaded as the Document Size setting.
6.
If you are printing a borderless photo, select Borderless . You can click Settings to access additional options for borderless printing.
Note: You must select a compatible borderless paper type and size to print without borders. Check the borderless paper compatibility list for details.
7.
Select the orientation of your document.
Note: If you are printing an envelope, select Landscape .
8.
Select the type of paper you loaded as the Paper Type setting.
Note: The setting may not exactly match the name of your paper. Check the paper type settings list for details.
9.
Select the Quality setting that matches the print quality you want to use.
10. Select a Color option:
• To print a color document or photo, select the Color setting.
• To print text and graphics in black or shades of gray, select the Black/Grayscale setting.
11. To print on both sides of the paper, select a 2-Sided Printing option.
12. To print multiple pages on one sheet of paper, or print one image on multiple sheets of paper, select one of the settings in the Multi-Page menu and select the printing options you want.
13. To print multiple copies and arrange their print order, select the Copies options.
14. To reduce noise during printing when you select Plain Paper/Bright White Paper , turn on Quiet
Mode (printing will be slower).
15. To preview your job before printing, select Print Preview .
16. To save your print job as a project that can be modified and combined with other print jobs, select
Job Arranger Lite .
Paper Source Options - Windows
Print Quality Options - Windows
Multi-Page Printing Options - Windows
Parent topic:
97
Paper Source Options - Windows
You can select any of the available options in the Paper Source menu to print on the paper loaded in that source.
Auto Cassette Selection
Automatically selects the paper source based on the selected paper size.
Cassette 1
Selects the paper in cassette 1 as the paper source.
Cassette 2
Selects the paper in cassette 2 as the paper source.
Cassette 1 > Cassette 2
Selects the paper in cassette 1 as the paper source and automatically switches to cassette 2 when cassette 1 is empty.
Rear Paper Feed Slot
Selects the paper in the rear feed slot as the paper source.
CD/DVD Tray
Selects the CD or DVD loaded in the CD/DVD tray.
Parent topic:
Selecting Basic Print Settings - Windows
Print Quality Options - Windows
You can select any of the available Quality options to fine-tune the quality of your print. Some settings may be unavailable, depending on the paper type and border setting you have chosen.
Draft
For draft printing on plain paper.
Standard
For everyday text and image printing.
High
For photos and graphics with high print quality.
More Settings
Opens a window that lets you choose among levels of speed and quality.
Parent topic:
Selecting Basic Print Settings - Windows
Multi-Page Printing Options - Windows
You can select any of the available options in the Multi-Page menu to set up your multi-page print job.
98
2-Up and 4-Up
Prints 2 or 4 pages on one sheet of paper. Click the Page Order button to select page layout and border options.
2×1 Poster, 2×2 Poster, 3×3 Poster, 4×4 Poster
Prints one image on multiple sheets of paper to create a larger poster. Click the Settings button to select image layout and guideline options.
Parent topic:
Selecting Basic Print Settings - Windows
Selecting Double-sided Printing Settings - Windows
You can print on both sides of the paper by selecting one of the 2-Sided Printing options on the Main tab.
Note: Some options may be pre-selected or unavailable, depending on other settings you have chosen or if you are accessing the product over a network.
1.
Select one of the following options for 2-Sided Printing :
• Auto (Long-edge binding) to print your double-sided print job by automatically flipping the paper on the long edge.
• Auto (Short-edge binding) to print your double-sided print job by automatically flipping the paper on the short edge.
• Manual (Long-edge binding) to print your double-sided print job by printing one side and prompting you to flip the paper over on the long edge to print the other side (recommended for paper types that do not support automatic duplexing).
• Manual (Short-edge binding) to print your double-sided print job by printing one side and prompting you to flip the paper over on the short edge to print the other side (recommended for paper types that do not support automatic duplexing).
2.
Click the Settings button.
99
You see this window:
3.
Select the double-sided printing options you want to use.
4.
Click OK to return to the Main tab.
5.
Click the Print Density button.
100
You see this window:
6.
Select the type of document you are printing as the Document Type setting. The software automatically sets the Adjustments options for that document type.
7.
If necessary, select the Adjustments options you want to use.
8.
Click OK to return to the Main tab.
9.
Print a test copy of your double-sided document to test the selected settings.
10. Follow any instructions displayed on the screen during printing.
Double-sided Printing Options - Windows
Print Density Adjustments - Windows
Parent topic:
Related references
Double-sided Printing Capacity
Double-sided Printing Options - Windows
You can select any of the available options on the Binding Settings window to set up your double-sided print job.
Binding Edge Options
Select a setting that orients double-sided print binding in the desired direction.
101
Binding Margin Options
Select options that define a wider margin to allow for binding.
Start Page
Selects whether printing starts on the front or back page.
Create Folded Booklet Options
Select the Booklet checkbox and a binding option to print double-sided pages as a booklet.
Parent topic:
Selecting Double-sided Printing Settings - Windows
Print Density Adjustments - Windows
You can select any of the available options on the Print Density Adjustment window to adjust the print quality of your double-sided print job.
Print Density
Sets the level of ink coverage for double-sided printing.
Increase Ink Drying Time
Sets the amount of time required for drying ink after printing on one side of the paper before printing the other side in double-sided printing to prevent ink smearing.
Parent topic:
Selecting Double-sided Printing Settings - Windows
102
Selecting Additional Layout and Print Options - Windows
You can select a variety of additional layout and printing options for your document or photo on the More
Options tab.
1.
To change the size of your printed document or photo, select the Reduce/Enlarge Document checkbox and select one of these sizing options:
• Select the Fit to Page option to size your image to fit the paper you loaded. Select the size of your document or photo as the Document Size setting, and the size of your paper as the Output
Paper setting. If you want to center your image on the paper, select the Center option.
• Select the Zoom to option to reduce or enlarge your document or photo by a specific percentage.
Select the percentage in the % menu.
2.
Select one of the following Color Correction options:
• Select Automatic to automatically adjust the sharpness, brightness, contrast, and color saturation for your image.
103
• Select Custom and click the Advanced button to manually adjust the color correction settings or turn off color management in your printer software.
• Select Image Options to access additional settings for improving printed images.
Note: You can also select Color Universal Print settings.
3.
To add the following features, click the Watermark Features button:
• Watermark : adds a visible watermark to your printout
• Header/Footer : adds information such as the date and time to the top or bottom of your printout
Note: Click the Settings button to customize the text and location of the header or footer.
4.
Select any of the Additional Settings options to customize your print.
Custom Color Correction Options - Windows
Image Options and Additional Settings - Windows
Header/Footer Settings - Windows
Parent topic:
104
Custom Color Correction Options - Windows
You can select any of the available options in the Color Correction window to customize the image colors for your print job.
Color Controls
Lets you select a Color Mode setting, individual settings for Brightness , Contrast , Saturation , and
Density , and individual color tones. Depending on the selected color mode, you can also adjust the midtone density using the Gamma setting.
Fix Photo
Improves the color, contrast, and sharpness of flawed photos.
Note: Fix Photo uses a sophisticated face recognition technology to optimize photos that include faces. For this to work, both eyes and the nose must be visible in the subject's face. If your photo includes a face with an intentional color cast, such as a statue, you may want to turn off Fix Photo to retain the special color effects.
105
ICM
Lets you manage color using installed color printing profiles.
No Color Adjustment
Turns off color management in your printer software so you can manage color using only your application software.
Parent topic:
Selecting Additional Layout and Print Options - Windows
Image Options and Additional Settings - Windows
You can select any of the Image Options and Additional Settings to customize your print. Some options may be pre-selected or unavailable, depending on other settings you have chosen.
Image Options
Emphasize Text
Adjusts the weight of printed text to increase readability.
Emphasize Thin Lines
Adjusts the weight of printed lines to increase visibility.
Edge Smoothing
Smooths jagged edges in low-resolution images such as screen captures or images from the Web.
Fix Red-Eye
Reduces or removes red-eye in photos.
Print Text in Black
Prints colored text in black.
For Color Text
Prints colored text on a background pattern or underlined.
For Color Graphs and Images
Prints colored graphics and images with overlay patterns.
For Color Text, Graphs, and Images
Prints colored text, graphics, and images with overlay patterns.
Enhancement Options
Specifies Color Universal Print enhancement settings for text, graphics, and images.
Additional Settings Options
Rotate 180º
Prints the image rotated 180º from its original orientation.
106
High Speed
Speeds up printing but may reduce print quality.
Mirror Image
Flips the printed image left to right.
Parent topic:
Selecting Additional Layout and Print Options - Windows
Header/Footer Settings - Windows
You can select any of the Header/Footer Settings options to add headers or footers when you print. The items are available to print at the top or bottom of your pages, in either the left, right, or center of the page.
Note: These settings are not saved with your document.
You can select to print the following information:
• User Name
• Computer Name
• Date
• Date/Time
• Collate Number (copy number)
Note: The user name, computer name, date, and time come from the Windows Control Panel on your computer.
Parent topic:
Selecting Additional Layout and Print Options - Windows
107
Selecting a Printing Preset - Windows
For quick access to common groups of print settings, you can select a printing preset on the Main or
More Options tab.
Note: You can create your own preset by clicking the Add/Remove Presets button.
1.
Click the Main or More Options tab.
You see the available Printing Presets on the left:
2.
Place your cursor over one of the Printing Presets to view its list of settings.
3.
Click on a preset to change its settings, or use any of the available options on the screen to control your printing presets.
4.
To choose a preset for printing, select it.
5.
Click OK .
Parent topic:
108
Selecting Extended Settings - Windows
You can select additional settings that apply to all the print jobs you send to your product.
1.
Access the Windows Desktop and right-click the icon for your product in the right side of the
Windows taskbar, or click the up arrow and right-click .
2.
Select Printer Settings .
3.
Click the Maintenance tab.
You see the maintenance options:
4.
Click the Extended Settings button.
109
You see this window:
5.
Select any of the extended settings to customize your print.
6.
Click OK to close the Extended Settings window.
7.
Click OK to close the printer software window.
Parent topic:
Extended Settings - Windows
You can select from these settings on the Extended Settings window.
Show Progress Meter
Displays the progress of print jobs as they are being printed.
Enable EPSON Status Monitor 3
Enables product monitoring for ink and paper supplies and other issues.
Check Paper Width Before Printing
Prevents printing beyond the edges of the paper if the paper size setting is incorrect; may reduce print speed.
110
Thick Paper and Envelopes
Prevents ink from smearing when you print on envelopes or other thick paper.
Separator Page
Before each document, prints a separator page containing the title, user, date, and time.
Always Spool RAW Datatype
Increases print speed and may solve other printing problems.
Page Rendering Mode
Increases print speed when printing is extremely slow or the print head stops during printing.
Print as Bitmap
Increases print speed when printing is extremely slow or the print head stops during printing, and other settings do not help.
Skip Blank Page
Ensures that your product does not print pages that contain no text or images.
Change Standard Resolution
Reduces the resolution of print data to correct printing problems.
Refine screening pattern
Prints graphics with a finer screening pattern.
Allow Applications to Perform ICM Color Matching
Allows applications to perform ICM color matching.
Always Use the Driver's Paper Source Setting
Prints using the paper source setting in the printer driver, rather than the setting in your application.
Parent topic:
Selecting Extended Settings - Windows
Printing Your Document or Photo - Windows
Once you have selected your print settings, you are ready to save your settings and print.
1.
Click OK to save your settings.
111
You see your application's Print window, such as this one:
2.
Click OK or Print to start printing.
Checking Print Status - Windows
Parent topic:
112
Checking Print Status - Windows
During printing, you see this window showing the progress of your print job. It allows you to control printing and check ink cartridge status.
• To cancel printing, click Cancel .
• To see print jobs waiting to print, click Print Queue .
• To check ink status, click Consumables Status .
Parent topic:
Printing Your Document or Photo - Windows
Selecting Default Print Settings - Windows
When you change your print settings in a program, the changes apply only while you are printing in that program session. If you want to change the print settings you use in all your Windows programs, you can select new default print settings.
1.
Access the Windows Desktop and right-click the icon for your product in the right side of the
Windows taskbar, or click the up arrow and right-click .
2.
Select Printer Settings .
113
You see the printer settings window:
3.
Select the print settings you want to use as defaults in all your Windows programs.
4.
Click OK .
These settings are now the defaults selected for printing. You can still change them as needed for printing in any program session.
Changing the Language of the Printer Software Screens
Parent topic:
Changing the Language of the Printer Software Screens
You can change the language used on the Windows printer software screens.
1.
Access the Windows Desktop and right-click the icon for your product in the right side of the
Windows taskbar, or click the up arrow and right-click .
2.
Select Printer Settings .
114
You see the printer settings window.
3.
Click the Maintenance tab.
You see the maintenance options:
4.
Select the language you want to use as the Language setting.
5.
Click OK to close the printer software window.
The printer software screens appear in the language you selected the next time you access them.
Parent topic:
Selecting Default Print Settings - Windows
Changing Automatic Update Options
Your printer software for Windows automatically checks for updates to the product software. You can change how often the software checks for updates or disable this feature.
115
1.
Access the Windows Desktop and right-click the icon for your product in the right side of the
Windows taskbar, or click the up arrow and right-click .
2.
Select Software Update Settings .
You see this window:
3.
Do one of the following:
• To change how often the software checks for updates, select a setting in the Check every menu.
• To disable the automatic update feature, select the Never option.
4.
Click OK to exit.
Note: If you choose to disable the automatic update feature, you can check for updates manually.
Parent topic:
Printing with the Built-in Epson Driver - Windows 10 S
You can print with the built-in Epson printer driver using any printing program on Windows 10 S, as described in these sections.
Note: The built-in Epson driver in Windows 10 S does not include all the available print settings for your product. To print with additional settings, download and install the Epson Print and Scan utility from the
Windows Store. You cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows Store.
116
Selecting Print Settings - Windows 10 S
Parent topic:
Selecting Print Settings - Windows 10 S
Select the settings for your print job in your Windows 10 S application.
1.
Open a photo or document for printing.
2.
Select the print command in your application.
Note: You may need to select a print icon on your screen, the Print option in the File menu, or another command. See your application's help utility for details.
3.
If necessary, select your product name as the printer you want to use.
Note: You may also need to select Properties or Preferences to view your print settings.
You see a window like this:
117
4.
Select the type of paper you loaded as the Media setting.
Note: The setting may not exactly match the name of your paper. Check the paper type settings list for details.
5.
Click the Advanced button.
You see a window like this:
6.
Select the size of the paper you loaded as the Paper Size setting.
7.
To print multiple copies, select or enter the number as the Copy Count setting.
8.
To print multiple copies of multi-page documents in sets, select the Collated checkbox.
9.
Click OK .
You return to the printing preferences window.
118
10. Select the Layout tab.
11. Select the orientation of your document as the Orientation setting.
119
12. To print double-sided, select one of the Print on Both Sides options, depending on how you want to orient the page layout. The icon next to each option shows the layout.
13. Click OK to save your settings.
You see your application's Print window.
14. Click OK or Print to start printing.
Parent topic:
Printing with the Built-in Epson Driver - Windows 10 S
Printing on a Mac
You can print with your product using any Mac printing program, as described in these sections.
Note: If you have an Internet connection, it is a good idea to check for updates to your product software on Epson's support website.
Selecting Basic Print Settings - Mac
Selecting Page Setup Settings - Mac
120
Selecting Print Layout Options - Mac
Selecting Double-sided Printing Settings - Mac
Selecting Printing Preferences - Mac
Printing Your Document or Photo - Mac
Parent topic:
Selecting Basic Print Settings - Mac
Select the basic settings for the document or photo you want to print.
1.
Open a photo or document for printing.
2.
Select the print command in your application.
Note: You may need to select a print icon on your screen, the Print option in the File menu, or another command. See your application's help utility for details.
3.
Select your product as the Printer setting.
4.
If necessary, click the arrow next to the Printer setting or the Show Details button to expand the print window.
121
You see the expanded printer settings window for your product:
Note: The print window may look different, depending on your version of the Mac operating system and the application you are using.
5.
Select the Copies and Pages settings as necessary.
Note: If you do not see these settings in the print window, check for them in your application before printing.
122
6.
Select the page setup options: Paper Size and Orientation .
Note: If you do not see these settings in the print window, check for them in your application before printing. They may be accessible by selecting Page Setup from the File menu.
7.
Select any application-specific settings that appear on the screen, such as those shown in the image above for the Preview application.
8.
Select Print Settings from the pop-up menu.
123
You see these settings:
9.
Select the Paper Source you wish to print from.
10. Select the type of paper you loaded as the Media Type setting.
Note: The setting may not exactly match the name of your paper. Check the paper type settings list for details.
11. Select the Print Quality setting you want to use.
12. Select the Borderless checkbox if you want to print a borderless photo. If the option is grayed out, change the Media Type setting to a paper type that supports borderless printing.
13. Select any of the available print options.
Parent topic:
124
Paper Source Options - Mac
You can select any of the available options in the Paper Source menu to print on the paper loaded in that source.
Auto Select
Automatically selects the paper source based on the selected paper size.
Cassette 1
Selects the paper in cassette 1 as the paper source.
Cassette 2
Selects the paper in cassette 2 as the paper source.
Rear Paper Feed Slot
Selects the paper in the rear feed slot as the paper source.
Parent topic:
Selecting Basic Print Settings - Mac
Print Quality Settings - Mac
You can select any of the Print Quality settings to fine-tune the quality of your print. Some settings may be unavailable, depending on the paper type and border setting you have chosen.
Draft
For draft printing on photo paper.
Fast Economy
For the fastest printing with draft quality.
Economy
For fast printing with reduced quality.
Normal
For everyday text and image printing.
Fine
For text and graphics with good quality and print speed.
Quality
For photos and graphics with good quality and print speed.
Best Quality
For the best print quality, but the slowest print speed.
Parent topic:
Selecting Basic Print Settings - Mac
125
Print Options - Mac
You can select any of the print options to customize your print. Some options may be unavailable, depending on other settings you have chosen.
Expansion
If you selected a borderless paper size setting, this option adjusts the image expansion settings to control printing at the edges of borderless prints.
Grayscale
Prints text and graphics in black or shades of gray.
Mirror Image
Lets you flip the printed image horizontally.
Note: If you select the Min option for the Expansion setting, you may see white borders on your printed photo.
Parent topic:
Selecting Basic Print Settings - Mac
Selecting Page Setup Settings - Mac
Depending on your application, you may be able to select the paper size and orientation settings from the print window.
Note: If you do not see these settings in the print window, check for them in your application before printing. They may be accessible by selecting Page Setup from the File menu.
1.
Select the size of the paper you loaded as the Paper Size setting. If you are printing a borderless photo, select the Borderless checkbox or a paper size with a Borderless option. You can also select a custom setting to create a custom paper size, but the Quality setting will be limited to
Normal . You can also select a custom setting to create a custom paper size. The Quality setting will be limited to Normal .
Note: You must select a compatible borderless paper type and size to print without borders. Check the borderless paper compatibility list for details.
126
2.
Select the orientation of your document or photo as shown in the print window.
Note: If you are printing an envelope, select the icon.
Note: You can reduce or enlarge the size of the printed image by selecting Paper Handling from the pop-up menu and selecting a scaling option.
Parent topic:
Selecting Print Layout Options - Mac
You can select a variety of layout options for your document or photo by selecting Layout from the popup menu on the print window.
• To print multiple pages on one sheet of paper, select the number of pages in the Pages per Sheet pop-up menu. To arrange the print order of the pages, select a Layout Direction setting.
• To print borders around each page on the sheet, select a line setting from the Border pop-up menu.
• To invert or flip the printed image, select the Reverse page orientation or Flip horizontally settings.
• To print on both sides of each page, select a setting from the Two-Sided pop-up menu.
Parent topic:
127
Selecting Double-sided Printing Settings - Mac
You can print on both sides of the paper by selecting Two-sided Printing Settings from the pop-up menu on the print window.
Note: Some options may be pre-selected or unavailable, depending on other settings you have chosen or if you are accessing the product over a network. This screen may be different, depending on the Mac
OS version you are using.
1.
Select one of the Two-sided Printing options.
128
2.
Select the type of document you are printing as the Document Type setting. The software automatically sets the Adjustments options for that document type.
3.
If necessary, customize the Adjustments settings as instructed on the screen.
4.
Print a test copy of your double-sided document to test the selected settings.
5.
Follow any instructions displayed on the screen during printing.
Double-sided Printing Options and Adjustments - Mac
Parent topic:
Double-sided Printing Options and Adjustments - Mac
You can select any of the available options in the Two-sided Printing Settings or Output Settings pop-up menu to set up your double-sided print job.
129
Two-sided Printing Options
Long-Edge binding
Orients double-sided printed pages to be bound on the long edge of the paper.
Short-Edge binding
Orients double-sided printed pages to be bound on the short edge of the paper.
Adjustments
Print Density
Sets the level of ink coverage for double-sided printing.
Increased Ink Drying Time
Sets the amount of time required for drying ink after printing on one side of the paper before printing the other side in double-sided printing.
Parent topic:
Selecting Double-sided Printing Settings - Mac
Managing Color - Mac
You can adjust the Color Matching and Color Options settings to fine-tune the colors in your printout, or turn off color management in your printer software.
1.
Select Color Matching from the pop-up menu in the print window.
2.
Select one of the available options.
130
3.
Select Color Options from the pop-up menu in the print window.
Note: The available settings on the Color Options menu depend on the option you selected on the
Color Matching menu.
4.
Select one of the available options.
Color Matching and Color Options - Mac
Parent topic:
Color Matching and Color Options - Mac
You can select from these settings on the Color Matching and Color Options menus.
Color Matching Settings
EPSON Color Controls
Lets you manage color using controls in your printer software or turn off color management.
ColorSync
Prints using standard color profiles for your product and paper to help match image colors. You can customize the conversion method and filter settings on the ColorSync pop-up menu in the print window.
131
Color Options Settings
Manual Settings
Lets you select manual color adjustments. Click the arrow next to Advanced Settings and select settings for Brightness , Contrast , Saturation , and individual color tones. You can also select a color
Mode setting for printing photos and graphics and the Fix Red-Eye setting to reduce or remove redeye in photos. Depending on the selected color mode, you can also adjust the midtone density using the Gamma setting.
Fix Photo
Improves the color, contrast, and sharpness of flawed photos. Click the arrow next to Advanced
Settings and select the Fix Red-Eye setting to reduce or remove red-eye in photos.
Note: Fix Photo uses a sophisticated face recognition technology to optimize photos that include faces. For this to work, both eyes and the nose must be visible in the subject's face. If your photo includes a face with an intentional color cast, such as a statue, you may want to turn off Fix Photo to retain the special color effects.
Off (No Color Adjustment)
Turns off color management in your printer software so you can manage color using only your application software.
Note: An ICC profile is required if color management is turned off.
Parent topic:
Selecting Printing Preferences - Mac
You can select printing preferences that apply to all the print jobs you send to your product.
1.
In the Apple menu or the Dock, select System Preferences .
2.
Select Print & Fax , Print & Scan , or Printers & Scanners , select your product, and select Options
& Supplies .
3.
Select Driver or Options .
132
You see a screen like this:
4.
Select any of the available printing preferences.
5.
Click OK .
Parent topic:
Printing Preferences - Mac
You can select from these settings on the Options or Driver tab.
Thick Paper and Envelopes
Prevents ink from smearing when you print on envelopes or other thick paper.
Skip Blank Page
Ensures that your product does not print pages that contain no text or images.
Quiet Mode
Lessens noise during printing but may decrease print speed.
Permit temporary black printing
Allows you to print using black ink when color ink is expended.
133
Automatic Cassette Switching
Automatically switches to the other cassette when one of the cassettes runs out of paper.
High Speed Printing
Speeds up printing but may reduce print quality.
Warning Notifications
Lets you choose whether or not to receive warning notifications from the printer software for various operating conditions.
Establish bidirectional communication
Allows the product to communicate with the computer. Do not change the default setting unless you experience issues when using a shared printing pool.
Parent topic:
Selecting Printing Preferences - Mac
Printing Your Document or Photo - Mac
Once you have selected your print settings, you are ready to print.
Click Print at the bottom of the print window.
Parent topic:
134
Checking Print Status - Mac
During printing, you can view the progress of your print job, control printing, and check ink status.
1.
Click the printer icon when it appears in the Dock.
You see the print status window:
2.
Select the following options as necessary for your Mac OS version:
• To cancel printing, click the print job and click or Delete .
• To pause a print job, click the print job and click paused print job and click or Resume .
or Hold . To resume a print job, click the
• To pause printing for all queued print jobs, click Pause or Pause Printer .
• To display other printer information, click Settings or Supply Levels .
Parent topic:
Printing Your Document or Photo - Mac
Cancelling Printing Using a Product Button
If you need to cancel printing, select Cancel on the LCD screen.
Parent topic:
135
Scanning
You can scan your originals and save them as digital files.
Scanning to Online Destinations Using Easy Photo Scan
Starting a Scan
After placing your originals on your product for scanning, start scanning using one of these methods.
Starting a Scan Using the Product Control Panel
Starting a Scan Using the Epson Scan 2 Icon
Starting a Scan from a Scanning Program
Starting a Scan from a Smart Device
Parent topic:
Starting a Scan Using the Product Control Panel
You can scan an image to a variety of destinations uing your product's control panel.
1.
Make sure you installed the product software and connected the product to your computer or network.
Note: Restart your computer after installing the product software to enable scanning from the control panel.
2.
Place your original on the product for scanning.
3.
Press the home icon, if necessary.
4.
Select Scan .
136
You see a screen like this:
5.
Select one of the following Scan to options:
• Memory Device saves your scan file on a USB device or memory card and lets you select the file format, quality, and other settings.
• Computer lets you scan to a connected computer using your saved scan settings.
• Cloud sends your scanned files to a destination that you have registered with Epson Connect.
• WSD lets you manage network scanning in Windows 10, Windows 8.x, Windows 7, or Windows
Vista (English only). To use this feature, you must first set up WSD (Web Services for Devices) on the computer.
6.
Follow the instructions in the links below to complete your scan.
Scanning to a Connected Computer
Scanning Using Web Services for Devices (WSD) - Windows
Control Panel Scanning Options
Changing Default Scan Job Settings
Parent topic:
Scanning to a Memory Device
You can scan an original and save the scanned image to a memory card.
1.
Insert a memory card into your product's memory card slot.
2.
Place your original on the product for scanning.
137
3.
Press the home icon, if necessary.
4.
Select Scan .
You see a screen like this:
5.
Select Memory Device .
You see a screen like this:
6.
Select OK to close the information screen, if necessary.
7.
Change any of the displayed settings on the Scan tab as necessary.
8.
Select the Advanced Settings tab to view and change additional scan settings, if necessary.
9.
On the Scan tab, select the Save icon to start scanning.
Your product scans your original and saves the scanned file to a memory device.
Parent topic:
Starting a Scan Using the Product Control Panel
138
Scanning to a Connected Computer
You can scan an original and save it to a connected computer using your product's control panel. The computer must be connected using a USB cable or connected to the same network as your product.
You can save the scanned file as a JPEG or PDF file, or attach it to an email. You can also set up custom scan settings using Event Manager and automatically scan using those settings on your product control panel.
Note: Be sure you have installed Epson Scan 2 and Event Manager on your computer before scanning to your computer.
1.
Place your original on the product for scanning.
2.
Press the home icon, if necessary.
3.
Select Scan .
You see a screen like this:
4.
Select Computer .
139
You see a screen like this:
5.
Select OK to close the information screen, if necessary.
6.
Select Select a computer and choose one of the following options:
• If your computer is connected to your product over a network, select a connected computer from the displayed list. (If the computer is not listed, select Search Again .)
• If your computer is connected to your product using a USB cable, select USB Connection .
7.
Select Save as PDF and choose one of the following options:
• Save as JPEG to save the scanned scanned image as a JPEG file.
• Save as PDF to save the scanned document or image as a PDF file.
• Attach to email to open the default email software on your computer and save the scanned document or image as a JPEG email attachment.
• Follow custom setting to save the scanned document or image using custom settings you have selected using the Event Manager custom scan settings option.
Note: You can customize the settings for each of the options above using Event Manager.
8.
Select 1-sided and select whether or not you want to scan both sides of the original.
9.
Select Save to start scanning.
Parent topic:
Starting a Scan Using the Product Control Panel
Scanning to the Cloud
You can use the control panel to send your scanned files to a destination that you have registered with
Epson Connect.
140
Note: Make sure to set up your product using Epson Connect before using this feature.
1.
Place your original on the product for scanning.
2.
Press the home icon, if necessary.
3.
Select Scan .
You see a screen like this:
4.
Select Cloud .
You see a screen like this:
5.
Select Select Destination and choose a destination.
6.
Change any of the displayed settings on the Scan tab as necessary.
7.
Select the Advanced Settings tab to view and change additional scan settings, if necessary.
8.
On the Scan tab, select the Upload icon to start scanning.
141
Your product scans your original and saves the scanned file to the selected destination.
Parent topic:
Starting a Scan Using the Product Control Panel
Scanning Using Web Services for Devices (WSD) - Windows
You can scan originals to a computer from the product control panel using WSD (Web Services for
Devices) for network scanning in Windows 10, Windows 8.x, Windows 7, or Windows Vista (English only).
Note: To use this feature on Windows 7 or Windows Vista, you must first set up WSD on the computer.
See Windows help for instructions.
1.
Make sure you installed the product software and connected the product to your computer or network.
2.
Place your original on the product for scanning.
3.
Press the home icon, if necessary.
4.
Select Scan .
You see a screen like this:
5.
Select WSD .
6.
Select a computer.
7.
Select start to start scanning.
Your product scans your original and saves the scanned file to the selected computer.
Parent topic:
Starting a Scan Using the Product Control Panel
142
Control Panel Scanning Options
Select the options you want to use for scanning.
Note: Not all options or settings may be available, depending on the Scan to option selected.
Scan to setting
Color Mode
File Format
2-Sided
Original Type
Scan Settings
Available options
B&W
Color
JPEG
1-Sided
2-Sided
Text
Letter
A4
Legal
Auto Cropping
Max Area
Varying levels
Description
Select whether to scan images in color or black and white
Select for photos
Select for documents
Select whether to scan one or both sides of the original
Specifies the type of original you are scanning
Select the page size for documents, then select the orientation of the original
Contrast
Select for photos with dark edges
Select for most photos
Adjusts the lightness or darkness of scanned images
Parent topic:
Starting a Scan Using the Product Control Panel
Changing Default Scan Job Settings
You can view or change the default scan job settings your product uses when you scan to your computer. You do this using the Event Manager program.
1.
Do one of the following to open Event Manager:
• Windows 10: Click and select EPSON Software > Event Manager .
• Windows 8.x
: Navigate to the Apps screen and select Event Manager .
143
• Windows (other versions) : Click or Start > All Programs or Programs > EPSON Software
> Event Manager .
• Mac : Open the Applications folder, click Epson Software , and select Event Manager .
2.
Open the Scanner (Windows) or Select Scanner (Mac) drop-down list and select your product, if necessary.
3.
Click Make Job Settings .
4.
Open the Edit Job Settings drop-down list and select the scan job settings you want to view or change.
5.
Change the settings as necessary.
6.
Click OK .
7.
Click Close to close the Event Manager window.
Parent topic:
Starting a Scan Using the Product Control Panel
Starting a Scan Using the Epson Scan 2 Icon
You can start the Epson Scan 2 program to select scan settings, scan, and save the scanned image to a file.
Note: If you are using your Epson product with the Windows 10 S operating system, you cannot use the software described in this section. You also cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows
Store.
• Windows 10: Click and select EPSON > Epson Scan 2 .
• Windows 8.x
: Navigate to the Apps screen and select Epson Scan 2 .
• Windows (other versions) : Click or Start , and select All Programs or Programs . Select EPSON
> Epson Scan 2 > Epson Scan 2 .
• Mac: Open the Applications folder, open the Epson Software folder, and select Epson Scan 2 .
144
You see an Epson Scan 2 window like this:
145
Parent topic:
Starting a Scan from a Scanning Program
You can start Epson Scan 2 from a TWAIN-compliant scanning program to select scan settings, scan, and open the scanned image in the program.
Note: If you are using your Epson product with the Windows 10 S operating system, you cannot use the software described in this section. You also cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows
Store.
1.
Open your scanning program and select its scanning option. (See your scanning program help for instructions.)
2.
Select your product.
Note: In certain programs, you may need to select your product as the "source" first. If you see a
Select Source option, choose it and select your product. With Windows, do not select a WIA option for your product; it will not work correctly.
146
You see an Epson Scan 2 window like this:
147
Parent topic:
Starting a Scan from a Smart Device
You can start a scan from a smart device using the Epson iPrint app. You can save the scanned document to your device or a cloud service, e-mail it, or print it.
Note: If you are using your Epson product with the Windows 10 S operating system, you cannot use the software described in this section. You also cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows
Store.
Note: Your device must be connected to the same wireless network as your Epson product.
1.
Download the Epson iPrint app from your device's app store or from Epson's website.
2.
Place your original on the product for scanning.
3.
Open the Epson iPrint app and select your product.
4.
Select the scan settings and scan your original.
5.
Save your scanned image to a file or cloud location.
Parent topic:
Related tasks
Using the Epson iPrint Mobile App
Scanning in Epson Scan 2
Epson Scan 2 automatically scans your document and saves the scanned file in PDF format in your operating system's Documents or My Documents folder, or opens it in your scanning program. You can select settings, preview, and change the scanned file settings as necessary.
Note: If you are using your Epson product with the Windows 10 S operating system, you cannot use the software described in this section. You also cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows
Store.
1.
Start Epson Scan 2.
148
You see this window:
149
2.
Select the Mode setting that matches the type of original you are scanning.
3.
Select the Document Source setting that matches where you placed your original, or select Auto
Detect to have Epson Scan 2 automatically detect the source.
4.
Select the Scanning Side setting if you are scanning from the ADF.
5.
Select the Document Size setting that matches the size of your original. You can select Customize to enter a custom size, if necessary.
6.
Select the image type of your original and how you want it scanned as the Image Type setting.
7.
Select the Resolution setting you want to use for your scan.
8.
Click the Preview button.
Epson Scan 2 previews your original and displays the results in the Epson Scan 2 window.
9.
Reinsert your original into the ADF, if necessary.
10. Select any of the additional settings that you want to use on the Main Settings tab.
11. Do one of the following:
• If you're scanning in Document Mode, select any of the additional settings that you want to use on the Main Settings tab.
150
• If you're scanning in Photo Mode, select the Color Management and Thumbnail Options settings as necessary.
12. Click the Advanced Settings tab and select any settings that you want to use.
13. Select the format in which you want to save your scanned file as the Image Format setting. If necessary, select Options and select any desired format options.
14. Enter the file name for your scanned file in the File Name field. If necessary, select Settings to modify the file name settings.
15. Select the location in which you want to save your scanned file as the Folder setting. If necessary, select Select to create a new folder.
16. Click Scan .
The product scans your original and saves the scanned file in the location you specified.
Additional Scanning Settings - Main Settings Tab
Additional Scanning Settings - Advanced Settings Tab
Saving Scanned Documents as a Searchable PDF Using Epson Scan 2
Parent topic:
Additional Scanning Settings - Main Settings Tab
You can select these additional scanning settings on the Epson Scan 2 Main Settings tab. Not all adjustment settings may be available, depending on other settings you have chosen.
Stitch Images
When scanning double-sided originals, lets you lay out images from both sides of the original onto one scanned page.
Rotate
Rotates the original image clockwise to the desired angle before scanning it. Select Auto to allow your product to automatically rotate the image based on the orientation of the text (may take longer to scan).
Correct Document Skew
Corrects skewed originals, image contents, or both.
Add or edit pages after scanning
Lets you add, remove, or edit the pages in a job, including rotating pages and changing the page order.
151
Note: To save multiple pages in a single file, you must select a file format that supports multiple pages such as PDF or Multi-TIFF . If you select another file format, each scanned image or page is saved as a separate file.
Skip Blank Pages
If the scanner detects marks from the other side of a blank page and adds the marks to the scanned image, adjust this setting to prevent this.
Parent topic:
Additional Scanning Settings - Advanced Settings Tab
You can select these additional scanning settings on the Epson Scan 2 Advanced Settings tab. Not all adjustment settings may be available, depending on other settings you have chosen.
Remove Background
Removes the background of the originals.
Text Enhancement
Sharpens the appearance of letters in text documents.
Auto Area Segmentation
Makes black and white images clearer and text recognition more accurate by separating the text from the graphics.
Threshold
Adjusts the level at which black areas in text and line art are delineated, improving text recognition in
OCR (Optical Character Recognition) programs.
Color Enhance
Enhances the shades of the color you select in the scanned image. This setting is available only if you select Grayscale or Black & White as the Image Type setting.
Brightness
Adjusts the overall lightness and darkness of the scanned image.
Contrast
Adjusts the difference between the light and dark areas of the overall scanned image.
Gamma
Adjusts the midtone density of the scanned image.
Unsharp Mask
Makes the edges of certain image areas clearer. Turn off this option to leave softer edges.
152
Descreening
Removes the ripple pattern that might appear in subtly shaded image areas, such as skin tones. This option improves results when scanning magazines or newspapers. (The results of descreening do not appear in the preview image, only in your scanned image.)
Edge Fill
Corrects shadowing around the edges of the image by filling the shadows with black or white.
Dual Image Output
Scans the original image twice using different output settings (Windows only).
Parent topic:
Saving Scanned Documents as a Searchable PDF Using Epson Scan 2
You can scan a document and save the text in a searchable PDF. In a searchable PDF, text is recognized using Optical Character Recognition (OCR) and then embedded in the scanned original.
Note: The required Epson Scan 2 OCR Component is installed automatically when you install your product software. If you install your scanner software programs individually, be sure to also install this component if you want to perform OCR.
1.
Load your original in the product for scanning.
2.
Start Epson Scan 2.
3.
Select your scan settings.
4.
Click Preview and adjust the area you want to scan, if necessary.
5.
If you are using the ADF, reload the ejected original.
6.
Select Searchable PDF as the Image Format setting.
7.
Select Options from the Image Format list.
153
You see this window:
8.
Select any of the options on the General tab.
9.
Select the Text tab.
10. Make sure the language used in the document text is selected as the Text Language setting.
11. Select the Security tab if you want to add a password to the PDF or protect printing or editing properties.
12. Click OK .
13. Confirm the File Name setting and select a Folder setting for your document.
14. Click Scan .
The scanned image is saved as a searchable PDF.
Parent topic:
Image Format Options
You can select different image formats and related options. For details on available options, click the ?
icon on the Epson Scan 2 Image Format Options window. Not all image formats have options.
154
Bitmap (*.bmp)
A standard image file format for most Windows programs.
JPEG (*.jpg)
An image format that lets you highly compress image data. However, the higher the compression, the lower the image quality. (The TIFF format is recommended when you need to modify or retouch your scanned image.)
PNG (*.png)
An image format that does not lose quality during editing.
TIFF (*.tif)
A file format created for exchanging data between many programs, such as graphic and DTP software.
Multi-TIFF (*.tif)
A TIFF file format when multiple pages are saved to the same file, allowing you to edit the images using a compatible program.
PDF (*.pdf)
A document format that is readable by Windows and Mac systems using Adobe Reader, Acrobat, or other programs. You can save multi-page documents in one PDF file.
Searchable PDF (*.pdf)
A document format that is readable by Windows and Mac systems using Adobe Reader, Acrobat, or other programs. You can save multi-page documents in one PDF file. Recognized text in the scanned document can be searched.
Parent topic:
Scan Resolution Guidelines
The Resolution setting, measured in dpi (dots per inch), controls the amount of detail captured in your scans. Increasing the resolution raises the amount of detail captured but comes with the following disadvantages:
• Larger file sizes
• It takes longer to scan your originals, send/receive your scans by email or fax, and to print your scans
• The image may become too large to fit on your display or print on paper
If you plan to enlarge a scanned image so you can print it at a larger size, you may need to increase the resolution from the default resolution set by Epson Scan 2. Follow these guidelines to determine the resolution setting you need:
• You will scan the image at its original size but enlarge it later in an image-editing program.
155
Increase the Epson Scan 2 Resolution setting in your scan. Increase the resolution by the same amount you will increase the image size to retain a high image quality. For example, if the resolution is
300 dpi (dots per inch) and you will double the image size later, change the Resolution setting to 600 dpi.
• You will scan the image at 100% or smaller size.
Select the Epson Scan 2 Resolution setting based on how you will use the scanned image:
• Email/view on a computer screen/post on the web: 96 to 200 dpi
• Print/fax/convert to editable text (OCR)/create searchable PDF: 200 to 300 dpi
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
You can scan documents or photos and upload them to Facebook and other online destinations, such as photo-sharing sites, web servers, or network folders using Easy Photo Scan.
Note: If you are using your Epson product with the Windows 10 S operating system, you cannot use the software described in this section. You also cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows
Store.
Scanning Using Easy Photo Scan
Uploading Scanned Images to Facebook
Uploading Scanned Images to Google Photos
Uploading Scanned Images to Evernote
Uploading Scanned Images to SugarSync
Uploading Scanned Images to a Web Folder
Uploading Scanned Images to Email
Saving Scanned Images to a Folder
Epson TIFF and Multi-TIFF File Settings
Parent topic:
Scanning Using Easy Photo Scan
You can use Easy Photo Scan to easily scan your originals, edit the scanned images, and upload them to Facebook or other online destinations.
156
1.
Place your original on your product for scanning.
2.
Do one of the following to open Easy Photo Scan:
• Windows 10: Click and select Epson Software > Easy Photo Scan . Select your product and click OK , if necessary.
• Windows 8.x
: Navigate to the Apps screen and select Easy Photo Scan . Select your product and click OK , if necessary.
• Windows (other versions) : Click or Start , and select All Programs or Programs . Select
Epson Software > Easy Photo Scan . Select your product and click OK , if necessary.
• Mac : Open the Applications folder, select Epson Software , and select Easy Photo Scan .
Select your product and click OK , if necessary.
You see a window like this:
3.
Click the Scan icon.
Your scanning program launches.
4.
Click Scan in the window that appears to scan your original.
157
The scanned image is displayed in the Easy Photo Scan window with an automatically generated name.
Note: You may need to close the scanning program window to display Easy Photo Scan.
5.
To edit the name of the file, select the image thumbnail at the bottom of the screen, click the icon, and enter the new filename.
6.
To edit the scanned image, click the Edit icon and select one of the displayed options.
Note: See the Easy Photo Scan help for additional information on image editing options.
7.
Repeat these steps for each image you want to upload.
8.
When you finish scanning, click one of the destination icons to upload the images.
Note: You may need to click the arrow next to the icons in order to see all of them. The available icons may vary, depending on the software version you are using.
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
Uploading Scanned Images to Facebook
You can configure a Facebook account for use with Easy Photo Scan and upload your scanned images to it.
1.
Scan your original using Easy Photo Scan.
2.
Click the icon.
158
You see a window like this:
Note: If you have already configured a Facebook account in Easy Photo Scan, you can select the
Setting Name or Destination Name for the account, click Login if necessary, and click Send to upload your images.
3.
Click Login .
4.
On the Application Authentication screen, log in to your Facebook account.
Note: To enable automatic image uploading, select the option for staying logged in.
159
5.
Select an album from the Album list.
Note: If you cannot select an album, make sure the Setting Name is set to (No Selection) , click
Login to log in to your Facebook account, and try again. If you want to create a new album, you must create it directly in Facebook.
6.
Select the image format for the uploaded files from the File or File Type list.
7.
If there are options for the selected file format, click Options or Option and select the options you want.
8.
If you also want to save the images to a local folder, select the Copy the image(s) to a local folder checkbox and select a folder.
9.
If you want to save the current settings, click Edit , or the Setting Name or Destination Name field, and select Save As . Enter a name for the setting and click OK .
10. Click Send to upload the images to your Facebook account, or click Cancel to cancel the operation.
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
Uploading Scanned Images to Google Photos
You can configure a Google Photos account for use with Easy Photo Scan and upload your scanned images.
1.
Scan your original using Easy Photo Scan.
2.
Click the icon.
160
You see a window like this:
Note: If you have already configured a Google Photos account in Easy Photo Scan, you can select the Setting Name or Destination Name for the account, click Login if necessary, and click Send to upload your images.
3.
Click Login .
4.
On the Application Authentication screen, log into your Google account.
5.
Click Accept to allow Easy Photo Scan to upload images to your account.
An authentication code is generated.
6.
Copy the authentication code into the Please enter authentication code field and click OK .
161
7.
Select an album from the Album list.
Note: If you cannot select an album, make sure the Setting Name is set to (No Selection) , click the
Login button to log into your Google Photos account, and try again. If you want to create a new album, you must create it directly in Google Photos.
8.
Select an Image Size option for the uploaded images.
9.
Select the image format for the uploaded files from the File or File Type list.
10. If there are options for the selected file format, click Options or Option and select the options you want.
11. If you also want to save the images to a local folder, select the Copy the image(s) to a local folder checkbox and select a folder.
12. If you want to save the current settings, click Edit , or the Setting Name or Destination Name field, and select Save As . Enter a name for the setting and click OK .
13. Click Send to upload the images to your Google Photos account, or click Cancel to cancel the operation.
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
Uploading Scanned Images to Evernote
You can configure an Evernote account for use with Easy Photo Scan and upload your scanned images to it (Windows only).
Note: You must install Evernote before you can use it with Easy Photo Scan.
1.
Scan your original using Easy Photo Scan.
2.
Click the icon.
162
You see a window like this:
Note: If you have already configured an Evernote account in Easy Photo Scan, you can select the
Setting Name or Destination Name for the account and click Send to upload your images.
3.
Select a notebook from the Notebook list.
Note: If you want to create a new notebook, you must create it directly in Evernote.
4.
Select the image format for the uploaded files from the File or File Type list.
5.
If there are options for the selected file format, click Options or Option and select the options you want.
6.
If you also want to save the images to a local folder, select the Copy the image(s) to a local folder checkbox and select a folder.
163
7.
If you want to save the current settings, click Edit , or the Setting Name or Destination Name field, and select Save As . Enter a name for the setting and click OK .
8.
Click Send to upload the images to your Evernote account, or click Cancel to cancel the operation.
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
Uploading Scanned Images to SugarSync
You can configure a SugarSync account for use with Easy Photo Scan and upload your scanned images.
1.
Scan your original using Easy Photo Scan.
2.
Click the icon.
You see a window like this:
164
Note: If you have already configured a SugarSync account in Easy Photo Scan, you can select the
Setting Name or Destination Name for the account and click Send to upload your images.
3.
Enter the account information in the E-Mail Address and Password fields.
4.
Select a Place option for the uploaded images.
Note: In SugarSync, the Magic Briefcase is now called "My SugarSync". Uploads to the Magic
Briefcase appear in the My SugarSync folder.
5.
Enter a folder name in the Folder field.
If you enter the name of an existing folder, the images are uploaded to that folder. If the folder does not exist, a new folder with that name is created.
6.
If you want to replace existing files with the same name with the uploaded images, click the
Overwrite file(s) with the same name checkbox.
7.
Click Check Connection to test whether the SugarSync account information is correct.
8.
Select the image format for the uploaded files from the File or File Type list.
9.
If there are options for the selected file format, click Options or Option and select the options you want.
10. If you also want to save the images to a local folder, select the Copy the image(s) to a local folder checkbox and select a folder.
11. If you want to save the current settings, click Edit , or the Setting Name or Destination Name field, and select Save As . Enter a name for the setting and click OK .
12. Click Send to upload the images to your SugarSync account, or click Cancel to cancel the operation.
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
Uploading Scanned Images to a Web Folder
You can upload your scanned images to a Web Folder (WebDAV) using Easy Photo Scan.
1.
Scan your original using Easy Photo Scan.
2.
Click the icon.
165
You see a window like this:
Note: If you have already configured a Web Folder account in Easy Photo Scan, you can select the
Setting Name or Destination Name for the account and click Send to upload your pictures.
3.
Enter the Web Folder URL in the Address field.
4.
Enter the login information in the User Name and Password fields.
5.
If you want to replace existing files with the same name with the uploaded images, click the
Overwrite file(s) with the same name checkbox.
6.
Click Check Connection to test whether the account information is correct.
7.
Select the image format for the uploaded files from the File or File Type list.
8.
If there are options for the selected file format, click Options or Option and select the options you want.
166
9.
If you also want to save the images to a local folder, select the Copy the image(s) to a local folder checkbox and select a folder.
10. If you want to save the current settings, click Edit , or the Setting Name or Destination Name field, and select Save As . Enter a name for the setting and click OK .
11. Click Send to upload the images to your Web Folder, or click Cancel to cancel the operation.
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
Uploading Scanned Images to Email
You can save your scanned images to a local network folder and send them by email using Easy Photo
Scan.
Note: With Windows, Easy Photo Scan supports Microsoft Outlook 2000/2002/2003/2007/2010
(x86)/2013 (x86) and Windows Mail/Windows Live Mail. If you do not have one of these email applications, Easy Photo Scan saves the images, but the email application does not open.
1.
Scan your original using Easy Photo Scan.
2.
Click the icon.
You see a window like this:
Note: On a Mac, you also enter an email address and email text in the window. If you have already configured email settings in Easy Photo Scan, you can select them using the Destination Name field.
3.
Select the image format for the saved files from the File or File Type list.
167
4.
If there are options for the selected file format, click Options or Option and select the options you want.
5.
Do one of the following:
• Windows : Click Browse to choose the folder where you want to save the images. Then click OK to save the images to the folder and launch your email program, or click Cancel to cancel the operation.
• Mac : If you also want to save the images to a local folder, select the Copy the image(s) to a local folder checkbox and select a folder. Then click Send , or click Cancel to cancel the operation.
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
Saving Scanned Images to a Folder
You can save your scanned images to a local network folder using Easy Photo Scan.
1.
Scan your original using Easy Photo Scan.
2.
Click the icon.
You see a window like this:
3.
Select the image format for the saved files from the File or File Type list.
4.
If there are options for the selected file format, click Options and select the options you want.
5.
Click Browse or the Save in field to choose the folder where you want to save the images.
6.
Click OK to save the images to the folder, or click Cancel to cancel the operation.
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
168
Epson JPEG File Settings
You can select from the following settings in the JPEG settings window in Easy Photo Scan.
Note: The available settings may vary, depending on the operating system you are using.
Setting
Image Quality Options
Encoding
Embed ICC Profile
169
Description
Specifies the compression level. The file size increases with higher quality.
Specifies the encoding method.
Standard : Images are rendered from the top to the bottom when displayed on a web browser.
Progressive : Images are rendered in low resolution in a web browser, then replaced with a higher resolution.
Allows the ICC profile (information on color reproducibility of scanned image) to be embedded in the image. Programs that use color management software will display the colors of the image using the ICC profile.
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
Epson TIFF and Multi-TIFF File Settings
You can select from the following settings in the TIFF settings window in Easy Photo Scan.
Note: The available settings may vary, depending on the operating system you are using.
Setting
Byte Order
Compression
Embed ICC Profile
170
Description
Specifies the operating system where the scanned image will be used.
Specifies the compression format and level for
Color/Grayscale and B&W images. The file size increases with higher quality.
Allows the ICC profile (information on color reproducibility of scanned image) to be embedded in the image. Programs that use color management software will display the colors of the image using the ICC profile.
Parent topic:
Scanning to Online Destinations Using Easy Photo Scan
171
Using Memory Cards with Your Product
Follow the instructions here to work with a memory card inserted into your product.
Transferring Photos on a Memory Card
Inserting a Memory Card
Insert a memory card into the memory card slot on your product as described here.
1.
Make sure the memory card and the files on it are compatible with your product before inserting the card.
2.
Insert your memory card into the slot, making sure the card is oriented correctly.
Note: Do not force the card all the way into the slot. Insert it only until it meets resistance.
The memory card access light flashes and then stays lit.
Caution: Do not remove a memory card or turn off your product while the memory card access light is flashing or you may lose data from the memory card.
Memory Card File Specifications
Parent topic:
Using Memory Cards with Your Product
172
Memory Card Types
You can insert these types of memory cards in your product.
Note: Cards marked with an asterisk (*) require an adapter; consult your adapter documentation for details on using it.
You can insert the following cards in the memory card slot:
• SD
• SDHC
• SDXC
• miniSD*
• miniSDHC*
• microSD*
• microSDHC*
• microSDXC*
Parent topic:
Related references
Memory Card File Specifications
You can insert memory cards in your product containing files that meet these specifications.
File format
Image size
File size
Number of files
JPEG with the Exif version 2.31 standard (taken with digital camera using DCF (Design rule for Camera File system) version 1.0 or 2.0
compliant)
80 × 80 pixels to 10200 × 10200 pixels
Up to 2GB
Up to 9990
Note: DCF 2.0 files stored in a camera's built-in memory are not supported.
Parent topic:
173
Related references
Removing a Memory Card
After you finish working with a memory card, check to make sure it is safe to remove it from your product.
Caution: Do not remove a memory card or turn off your product while the memory card access light is flashing or you may lose data from the memory card.
1.
Make sure the memory card access light is not flashing.
2.
If your product is connected to your computer using a USB cable, do one of the following:
• Windows : Open the My Computer , Computer , Windows Explorer , or File Explorer utility.
Then right-click the name of your memory card (listed as a removable disk) and select Eject .
• Mac : Drag the removable disk icon for your memory card from the desktop or computer window into the trash.
3.
Pull the memory card straight out of its slot.
Parent topic:
Printing from a Memory Card
See these sections to print photos from a memory card inserted into your product:
174
Printing Photo Layouts from a Memory Card
Printing ID Photos from a Memory Card
Printing Photos with a Template
Parent topic:
Using Memory Cards with Your Product
Viewing and Printing Photos
See these sections to view and print photos displayed on your product's LCD screen.
Viewing and Printing Photos from the LCD Screen
Parent topic:
Viewing and Printing Photos from the LCD Screen
You can select photos for printing as you view them on the LCD screen.
Note: You can also select Settings > Basic Settings > Screen Saver > Memory Card Data to display photos on the memory card as a slideshow when the LCD screen is not used for a period of time.
1.
Load photo paper in your product.
2.
Insert a memory card into your product's memory card slot.
3.
Press the home icon, if necessary.
Note: If Auto Selection Mode is turned on in the Guide Functions menu, select to function index when you see the information screen.
4.
Select Print Photos .
175
5.
Select Print and select OK .
You see a screen like this:
6.
Do one of the following to select your photos:
• Select the thumbnail images of the photos you want to print. Each photo you select has a number on it to indicate the number of prints you selected.
• Select Single View , select the thumbnail of the photo you want to print, then press the left or right arrow buttons to scroll through and select additional photos. You can also select Tile View to return to the thumbnail image view and select additional photos.
• To select all photos, select the menu icon and select Select all photos .
7.
Select Print Settings and select your paper and print settings as necessary.
8.
Select Preview and Print .
You see a screen like this:
176
9.
Press the right or left arrow buttons to scroll through the photos you selected, if necessary.
10. If you need to edit a photo, select Edit .
You see an image like this:
1 Adjusts the cropping area. You can move the cropping area or change the frame size by sliding the corner points. Press the Rotation button to rotate the frame.
2 Applies a sepia or monochrome filter to the photo.
3 Lets you make color and red-eye corrections, and adjust brightness, contrast, sharpness, and saturation if necessary.
Note: Press the Correction On button to switch between Correction Off and Correction On . If
Correction On is selected, any color corrections you make to a photo are displayed on the screen. If
Correction Off is selected, any color corrections you make are not displayed on the screen but will be applied to your printouts.
11. For each image, select photo(s) and change the number of copies as necessary.
177
12. When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
Parent topic:
Related references
Related tasks
Memory Card Print Settings
Select the Print Settings options you want to use when printing photos displayed on the LCD screen.
Print Settings Description
Paper Size
Paper Type
Available options
Various paper sizes
Various paper types
Indicates the size of paper you have loaded
Paper Cassettes
Border
Cassette 1
Cassette 2
Cassette
1>Cassette 2
Rear Paper
Feed Slot
Borderless
Indicates the type of paper you have loaded; see the list of paper types for copying (available options depend on the selected Paper Size setting)
Prints onto paper loaded in Cassette 1 (upper cassette)
Prints onto paper loaded in Cassette 2 (lower cassette)
Prints onto paper loaded in Cassette 1 and then onto paper loaded in Cassette 2 when the first cassette is empty (load the same size and type of paper in both cassettes when selecting this option)
Prints onto paper loaded in the rear paper feed slot
With Border
Expands the image to the edge of the paper (slight cropping may occur)
Leaves a small margin around the image
178
Print Settings
Expansion
Fit Frame
Quality
Date
Print Info. On
Photos
Available options
Standard
Medium
Minimum
On
Off
Draft
Standard
Best
Various date formats
Off
Camera
Settings
Camera Text
Landmark
Description
Expands images correctly for most borderless prints
Expands images slightly less for borderless prints
Expands images the least for borderless prints (you may see some white border)
Automatically crops the photo to fit into the selected photo layout
Turns off automatic cropping
Provides lower quality for draft printing
Provides good quality for most prints
Provides the highest quality for important prints
Prints the date the photo was taken on the photo in the format you select
Turns off this setting
Prints Exif information (shutter speed, f-ratio, and ISO sensitivity)
Prints text that you added in your camera
Prints location information embedded in a photo by cameras that have a built-in GPS feature
Parent topic:
Related tasks
Viewing and Printing Photos from the LCD Screen
Printing Photo Layouts from a Memory Card
You can print one or more photos from a memory card in special layouts on various sizes of photo paper.
Note: Photos are placed automatically in the layout. If you want to manually select where they appear in the layout, see the Printing Photos with a Template topic instead.
1.
Load photo paper in your product.
179
2.
Insert a memory card into your product's memory card slot.
3.
Press the home icon, if necessary.
Note: If Auto Selection Mode is turned on in the Guide Functions menu, select to function index when you see the information screen.
4.
Select Print Photos .
5.
Select Print Layout .
You see this screen:
6.
Select one of the displayed layout options.
180
You see this screen:
7.
Select your paper and print settings as necessary.
8.
Select Select Photo and select OK .
9.
Do one of the following to select your photos:
• Select the thumbnail images of the photos you want to print. Each photo you select has a number on it to indicate the number of prints you selected.
• Select Single View , select the thumbnail of the photo you want to print, and press the left or right arrow buttons to scroll through and select additional photos. You can also select Tile View to return to the thumbnail image view and select additional photos.
• To select all photos, select the
10. Select Preview and Print .
menu icon and select Select all photos .
11. If you need to edit a photo, select Edit and then select the photo you want to edit.
181
You see an image like this:
1 Adjusts the cropping area. You can move the cropping area or change the frame size by sliding the corner points. Press the Rotation button to rotate the frame.
2 Applies a sepia or monochrome filter to the photo.
3 Lets you make color and red-eye corrections, and adjust brightness, contrast, sharpness, and saturation if necessary.
Note: Press the Correction On button to switch between Correction Off and Correction On . If
Correction On is selected, any color corrections you make to a photo are displayed on the screen. If
Correction Off is selected, any color corrections you make are not displayed on the screen but will be applied to your printouts.
12. Select Copies to change the number of copies as necessary.
13. When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
182
Parent topic:
Related references
Related tasks
Related topics
Printing ID Photos from a Memory Card
You can print ID photos from a memory card. Two copies of one photo are printed at different sizes onto this size photo paper: 4 × 6 inches (102 × 152 mm).
1.
Load photo paper in your product.
2.
Insert a memory card into your product's memory card slot.
3.
Press the home icon, if necessary.
Note: If Auto Selection Mode is turned on in the Guide Functions menu, select to function index when you see the information screen.
4.
Select Print Photos .
5.
Select Print photo ID and select OK .
183
You see a screen like this:
6.
Select the photo you want to print.
7.
Select Print Settings and select your paper and print settings as necessary.
8.
Select Preview and Print .
9.
If you need to edit a photo, select Edit and then select the photo you want to edit.
You see an image like this:
184
1 Adjusts the cropping area. You can move the cropping area or change the frame size by sliding the corner points. Press the Rotation button to rotate the frame.
2 Applies a sepia or monochrome filter to the photo.
3 Lets you make color and red-eye corrections, and adjust brightness, contrast, sharpness, and saturation if necessary.
Note: Press the Correction On button to switch between Correction Off and Correction On . If
Correction On is selected, any color corrections you make to a photo are displayed on the screen. If
Correction Off is selected, any color corrections you make are not displayed on the screen but will be applied to your printouts.
10. Select photo(s) to change the number of copies as necessary.
11. When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
Parent topic:
Related references
Related tasks
Related topics
Printing Photos with a Template
You can print one or more photos from a memory card in special layouts on various sizes of photo paper.
You can have the product automatically place the photos in the layout or you can manually place them yourself.
1.
Load photo paper in your product.
2.
Insert a memory card into your product's memory card slot.
3.
Press the home icon, if necessary.
Note: If Auto Selection Mode is turned on in the Guide Functions menu, select to function index when you see the information screen.
185
4.
Select Print Photos .
5.
Select Print with template .
You see this screen:
6.
Select one of the displayed layout options.
186
You see this screen:
7.
Select your paper and print settings as necessary.
8.
Select To place photo and select OK .
9.
Do one of the following:
• If you selected a single photo template, select the photo you want to print. Select a photo on the select photo screen, select Preview and Print and go to step 10.
• If you selected a multiple-photo template, you see a screen like this:
• To place photos in the template automatically, select Automatic Layout , select the photos you want to print, and select Preview and Print .
• To place photos in the layout template manually, select the icon and follow the instructions on the LCD screen to select and place photos in your template.
187
10. When you see the Preview screen, confirm your selected photos and make any changes as necessary.
11. When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
Parent topic:
Related references
Related tasks
Printing Photo Greeting Cards
You can create custom greeting cards using photos on your memory card or other device, and add your own handwritten or printed text.
First you select your photo and print a template on plain paper. Then you fill out the template, add your message, and print your cards.
Creating and Printing a Greeting Card Template
Printing a Greeting Card from a Template
Parent topic:
Creating and Printing a Greeting Card Template
Before you start, make sure plain paper is loaded and your memory card is inserted.
1.
Press the home icon, if necessary.
2.
Select Various prints .
188
3.
Select Greeting Card .
4.
Select Select Photo and Print Template and select OK .
5.
Do one of the following to select your photos:
• Select the thumbnail images of the photos you want to print. Each photo you select has a number on it to indicate the number of prints you selected.
• Select Single View , select the thumbnail of the photo you want to print, and press the left or right arrow buttons to scroll through and select additional photos. You can also select Tile View to return to the thumbnail image view and select additional photos.
• To select all photos, select the menu icon and select Select all photos .
6.
Select Print Settings .
7.
Select Letter as the Paper Size to print a template for three cards on one letter-size sheet or 4x6in to print a template for one card.
8.
Select the Paper Type and Layout settings, as necessary.
9.
Select Select Photo and Print Template .
10. Select To Check Printing .
11. Select Copies and use the numeric keypad to select the number of copies (up to 99).
12. When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
Parent topic:
189
Related references
Related tasks
Printing a Greeting Card from a Template
Printing a Greeting Card from a Template
After your greeting card template is printed, you fill it out to create your card and add your message.
1.
Use a dark pen or pencil to fill in the circles and select the Text Style and Text Effects.
2.
Add your greeting card message within the box. You can write it in by hand, print a message and paste it into the box, or draw a picture.
Note: When adding text, place it in the direction that your photo faces.
3.
Load photo paper in Cassette 2 (lower) for this size: Letter (8.5 × 11 inches [216 × 279 mm]), or in
Cassette 1 (upper) for this size: 4 × 6 inches (102 × 152 mm).
4.
Press the home icon and select Various prints > Greeting Card > Print Using the Template >
OK .
5.
Follow the instructions on the LCD screen to place the template facedown on the scanner glass with the blue triangle facing into the front right corner.
6.
Close the document cover.
190
7.
Select Copies and use the numeric keypad to select the number of copies (up to 99).
8.
When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
When you finish printing, cut your greeting cards apart, if necessary.
Parent topic:
Related tasks
Printing a Greeting Card from a Template
Transferring Photos on a Memory Card
You can transfer photos to and from a memory card inserted into a memory card slot on your product.
Setting Up File Sharing for Photo Transfers from Your Computer
Transferring Photos from a Memory Card to Your Computer
Parent topic:
Using Memory Cards with Your Product
Related tasks
Setting Up File Sharing for Photo Transfers from Your Computer
Before you transfer photos from a computer to a memory card inserted into a memory card slot on your product, you may need to set up your product's file sharing settings.
Caution: Remove the memory card before you change this setting or you may lose data from the memory card. Do not remove a memory card or turn off your product while the memory card access light is flashing or you may lose data from the memory card.
1.
Remove any memory cards from the product.
2.
Press the home icon, if necessary.
191
3.
Select Settings .
4.
Scroll down and select File Sharing Setup .
5.
Select your connection type.
Parent topic:
Transferring Photos on a Memory Card
Related tasks
Transferring Photos from a Memory Card to Your Computer
You can transfer photos to and from a memory card inserted into a memory card slot on your product and a computer connected to your product.
Note: Do not transfer photos to and from a memory card while you are printing from the memory card.
1.
Make sure your product is connected to a computer.
2.
Insert a memory card into a memory card slot on your product.
3.
Do one of the following to access your memory card files from your computer:
• Windows : Open the Computer , My Computer , Windows Explorer , or File Explorer utility, then select the removable disk icon.
• Mac with a USB connection : Look for the removable disk icon on your desktop or computer window, then select it.
• Mac with a network connection : Select the hard drive icon on your desktop or computer window, select your product in the SHARED section of the sidebar (you may need to widen the sidebar to see the name), then select the MEMORYCARD icon.
192
4.
Select the folder that contains your photos.
5.
Drag the photos you want to transfer to the desired folder on your computer or on your memory card.
Note: Your product's LCD screen does not update to display new photos transferred to the memory card. Wait until the memory card access light stops flashing, then remove and insert the memory card to update the photos displayed.
Parent topic:
Transferring Photos on a Memory Card
Related tasks
193
Using an External Device with Your Product
Follow the instructions in these sections to use your product with an external device, such as a camera, smartphone, or other device.
Viewing or Printing from a USB Flash Drive or External Device
Printing from a Camera
If you have a digital camera that supports PictBridge printing, you can print your photos directly from the camera. Check your camera manual to see if it is compatible.
Note: Your photos must be in JPG format and sized from 80 × 80 to 10200 × 10200 pixels. Epson cannot guarantee the compatibility of your camera. Some combinations of paper type, size, and layout may not be supported, depending on your camera and the product settings.
Selecting Print and Photo Adjustment Settings
Connecting and Printing from a Camera
Printing from a Camera Wirelessly
Parent topic:
Using an External Device with Your Product
Selecting Print and Photo Adjustment Settings
Before printing from your camera, you can make image adjustments and select the print settings for your photos. Image adjustments affect only the printed copy of the photo, not the original file.
1.
Press the home icon, if necessary.
2.
Select Settings .
194
3.
Scroll down and select Camera print settings .
4.
Select Print Settings .
5.
Select the print settings you want to use.
6.
When you are done, press .
195
7.
Select Photo Adjustments .
8.
Select the photo adjustments you want to use.
9.
When you are done, press the home icon to exit.
After you select settings, you are ready to connect your camera and print your photos.
Parent topic:
Related tasks
Connecting and Printing from a Camera
Print Settings - Camera
Select these print settings options when printing photos from your camera.
Print settings
Paper Size
Paper Type
Available options
Various paper sizes
Various paper types
Description
Indicates the size of paper you have loaded
Indicates the type of paper you have loaded; see the list of paper types for copying (available options depend on the selected Paper Size setting)
196
Print settings
Paper Cassettes
Border
Expansion
Fit Frame
Quality
Date
Available options
Cassette 1
Description
Prints onto paper loaded in Cassette 1 (upper cassette)
Cassette 2 Prints onto paper loaded in Cassette 2 (lower cassette)
Cassette 1> Cassette 2 Prints onto paper loaded in Cassette 1 and then onto paper loaded in Cassette 2 when the first cassette is empty (load the same size and type of paper in both cassettes when selecting this option)
Rear Paper Feed Slot Prints onto paper loaded in the Rear Paper Feed
Slot
Borderless Expands the image to the edge of the paper (slight cropping may occur)
With Border
Standard
Medium
Minimum
Leaves a small margin around the image
Expands images correctly for most borderless prints
Expands images slightly less for borderless prints
On
Expands images the least for borderless prints
(you may see some white border)
Automatically crops the photo to fit into the selected photo layout
Off
Draft
Standard
Best
Off
On
Turns off automatic cropping
Provides lower quality for draft printing
Provides good quality for most prints
Provides the highest quality for important prints
Does not print the date on which the photo was taken
Prints the date on which the photo was taken
197
Print settings
Print Info. on Photos
Available options
Off
Camera Settings
Camera Text
Landmark
Description
Does not print text that you added in your camera
Prints exif information (shutter speed, f-ration, and
ISO sensitivity)
Prints text that you added in your camera
Prints location information embedded in a photo by cameras that have a built-in GPS feature
Adjusts the print density when printing on
CDs/DVDs from your camera
CD Density Standard
Darker
Darkest
Parent topic:
Selecting Print and Photo Adjustment Settings
Photo Adjustments - Camera
Select these photo adjustment options when printing photos from your camera. The modifications affect only the printed copy of the photo, not the original file.
Adjustments settings
Enhance
Available options Description
Auto
Fix Red-Eye
People
Landscapes
Night Scene
P.I.M
Enhance Off
Off
On
Automatically adjusts the brightness, contrast, and saturation of the photo based on the content detected
Best for photos of people
Best for photos of landscapes
Best for photos taken at night
Uses your camera's PRINT Image Matching or Exif Print adjustments
Turns off automatic adjustments; see Note below
Does not automatically fix the red-eye effect in photos
Automatically fixes the red-eye effect in photos
198
Adjustments settings
Filter
Available options Description
Off
Sepia
B&W
Various settings
Print in sepia or monochrome
Brightness
Contrast
Sharpness
Saturation
Adjust individual qualities in your photo
Parent topic:
Selecting Print and Photo Adjustment Settings
Connecting and Printing from a Camera
Before you connect your camera, make sure the product is turned on but not printing.
1.
Remove any memory cards from the product.
2.
Load the paper you want to use for printing.
3.
Connect the USB cable that came with your camera to the USB port on the front of your product.
Note: You cannot use the USB port to transfer images from your camera to your computer.
4.
Turn on your camera.
5.
Follow the instructions that came with your camera to select and print your photos.
When you finish printing, turn off your camera and disconnect it from the product.
Parent topic:
Related tasks
Related topics
199
Printing from a Camera Wirelessly
You can print photos from a digital camera using a wireless connection. Make sure your digital camera can connect to a network and is PictBridge compatible (DPS over IP).
Note: You cannot use other printer functions or print from other devices while using PictBridge.
1.
Remove any memory cards from the product.
2.
Load the paper you want to print on.
3.
Turn on your camera.
4.
Set up the camera's wireless network connection. See the documentation that came with your camera for details.
Note: Connect the camera to the same network that your product uses. You can print a Network
Status sheet to view your product's network settings.
5.
Follow the instructions that came with your camera to select and print your photos.
When you finish printing, turn off your camera and disconnect it from the network.
Parent topic:
Related tasks
Printing a Network Status Sheet
Related topics
Viewing or Printing from a USB Flash Drive or External Device
You can view and print photos from a USB flash drive or other external USB device, such as an external hard drive or CD/DVD burner.
Note: Make sure the files on your device are compatible with the product.
USB Device File Specifications
Connecting and Using a USB Flash Drive or External Device
Parent topic:
Using an External Device with Your Product
200
Related tasks
Viewing and Printing Photos from the LCD Screen
USB Device File Specifications
You can print external device files that meet these specifications.
File format
Image size
File size
Number of files
JPEG with the Exif version 2.31 standard (taken with digital camera using DCF (Design rule for Camera File system) version 1.0 or 2.0
compliant)
80 × 80 pixels to 10200 × 10200 pixels
Up to 2GB
Up to 9990
Note: DCF 2.0 files stored in a camera's built-in memory are not supported.
Parent topic:
Viewing or Printing from a USB Flash Drive or External Device
Connecting and Using a USB Flash Drive or External Device
Before you connect your flash drive or external device, make sure the product is turned on but not printing.
Note: Epson cannot guarantee the compatibility of your drive.
1.
Remove any memory cards from the product.
2.
Load the paper you want to use for printing.
3.
Insert your USB flash drive or the USB cable that came with your device into the USB port on the front of your product.
4.
Insert storage media (such as a CD) into your drive, if necessary.
5.
Select the photos to print from the LCD screen.
When you finish printing, make sure the access light on the device is not flashing, then remove or disconnect it from the product.
Caution: Do not remove the USB device or turn off the product when the access light is flashing, or you may lose photos on the device.
201
Parent topic:
Viewing or Printing from a USB Flash Drive or External Device
Related tasks
Viewing and Printing Photos from the LCD Screen
Related topics
202
Printing Personalized Projects
You can print a variety of personalized projects, including some with a photo background.
Printing Lined Paper, Graph Paper, and Music Sheets
Printing Personalized Note Paper
Printing Patterned Paper
You can print patterned paper from preset designs in your product.
1.
Load one of these types of paper in either Letter (8.5 × 11 inches [216 × 279 mm]) or A4 (8.3 × 11.7
inches [210 × 297 mm]) size:
• Plain paper
• Epson Bright White Paper
• Epson Presentation Paper Matte
• Epson Premium Presentation Paper Matte
2.
Press the home icon, if necessary.
3.
Select Various prints .
4.
Select Design Paper .
5.
Select one of the design templates.
203
6.
Select the size and type of paper that you loaded, and where you loaded it.
7.
Select To Check Printing .
8.
Select Copies and use the numeric keypad to select the number of copies (up to 99).
9.
When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
Parent topic:
Printing Personalized Projects
Related topics
Printing Calendar Pages
You can create and print a weekly or monthly calendar page that includes your own photo.
1.
Load plain paper in either Letter (8.5 × 11 inches [216 × 279 mm]) or A4 (8.3 × 11.7 inches
[210 × 297 mm]) size.
2.
Press the home icon, if necessary.
3.
icon, if necessary.
4.
Select Various prints .
5.
Select Calendar .
6.
Select one of the calendar format options.
Note: View the images for each option to preview the design layout.
204
7.
Select the size and type of the paper you loaded, and where you loaded it.
8.
Select Set Date .
9.
Select the year and month, and select OK .
10. Do one of the following to select your photos:
• Select the thumbnail images of the photos you want to print.
• Select Single View , select the thumbnail of the photo you want to print, and press the left or right arrow buttons to scroll through and select additional photos. You can also select Tile View to return to the thumbnail image view and select additional photos.
• To select all photos, select the
11. Select Preview and Print menu icon and select Select all photos .
12. If you need to edit a photo, select Edit and then select the photo you want to edit.
13. Select Copies and use the numeric keypad to select the number of copies (up to 99).
14. When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
Parent topic:
Printing Personalized Projects
Related references
Related tasks
Related topics
Printing Schedule Pages
You can create and print a monthly, weekly, or daily schedule page.
1.
Load plain paper in one of the following sizes: Letter (8.5 × 11 inches [216 × 279 mm]) or A4
(8.3 × 11.7 inches [210 × 297 mm]).
2.
Press the home icon, if necessary.
205
3.
Select Various prints .
4.
Select Schedule .
5.
Select one of the format options.
Note: View the images for each option to preview the design layout.
6.
Select your paper and print settings as necessary.
7.
Select Set Date or To Check Printing .
8.
If you selected Monthly or Daily , set the date and select OK .
9.
Select Copies and use the numeric keypad to select the number of copies (up to 99).
10. When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
Parent topic:
Printing Personalized Projects
Related topics
Printing Lined Paper, Graph Paper, and Music Sheets
You can print music sheets, wide-rule or narrow-rule notebook paper, and graph paper.
1.
Load plain paper in either Letter (8.5 × 11 inches [216 × 279 mm]) or A4 (8.3 × 11.7 inches
[210 × 297 mm]) size.
2.
Press the home icon, if necessary.
206
3.
Select Various prints .
4.
Select Ruled paper .
5.
Select one of the layout options.
Note: View the images for each option to preview the design layout.
6.
Select the size and type of the paper you loaded, and where you loaded it.
7.
Select To Check Printing .
8.
Select Copies and use the numeric keypad to select the number of copies (up to 99).
9.
When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
207
Parent topic:
Printing Personalized Projects
Related topics
Printing Personalized Note Paper
You can print lined or unlined note paper with one of your own photos in the background.
1.
Load plain paper in either Letter (8.5 × 11 inches [216 × 279 mm]) or A4 (8.3 × 11.7 inches
[210 × 297 mm]) size.
2.
Insert a memory card into your product's memory card slot.
3.
Press the home icon, if necessary.
4.
Select Various prints .
5.
Select Writing Papers .
208
6.
Select one of the layout options.
Note: View the images for each option to preview the design layout.
7.
Select one of the following background options:
• Photo : select the thumbnail image of the photo you want to print, select Print Settings to choose paper settings, and select Preview and Print .
• Color : select a background color, choose paper settings, and select To Check Printing .
• No Background : choose paper settings and select To Check Printing .
8.
Select Copies and use the numeric keypad to select the number of copies (up to 99).
9.
When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
Parent topic:
Printing Personalized Projects
Related references
Related tasks
Related topics
Printing Coloring Book Pages
You can create a coloring book page from a photo on your memory card, or from a photo or drawing placed on the scanner glass.
1.
Load one of these types of paper in either Letter (8.5 × 11 inches [216 × 279 mm]) or A4 (8.3 × 11.7
inches [210 × 297 mm]) size:
• Plain paper
• Epson Bright White Paper
• Epson Presentation Paper Matte
• Epson Premium Presentation Paper Matte
2.
Insert a memory card or place a photo or drawing on the scanner glass.
209
3.
Press the home icon, if necessary.
4.
Select Various prints .
5.
Select Coloring Book .
6.
Select one of the following settings:
• Scan an original to print a design from an original placed facedown on the scanner glass, in the front right corner
• Choose from the memory card to print a design from a memory card inserted in your product, then select a photo
7.
Select the size and type of paper that you loaded, and where you loaded it.
8.
If necessary, adjust the following settings:
• Density to make the print lighter or darker
• Line Detection to change the amount of detail in the print
9.
Select Copies and use the numeric keypad to select the number of copies (up to 99).
10. When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select Close to exit.
Parent topic:
Printing Personalized Projects
Related references
Related tasks
210
Related topics
Placing Originals on the Product
211
Printing on CDs/DVDs
Follow the instructions in this section to print a design onto ink jet-printable CDs or DVDs to create a custom label.
Placing a CD/DVD on the Scanner Glass
Printing Photos from a Memory Card Onto a CD/DVD
Printing a Jewel Case Insert from a Memory Card
Printing on CDs/DVDs from a Computer
CD/DVD Printing Features
You can use any of the following features to print custom CD/DVD/Blu-ray Disc labels and accessories:
• Copy an existing label onto a new CD/DVD/Blu-ray Disc
• Use your product's control panel to print photos from a memory card onto a CD/DVD/Blu-ray Disc
• Print text and images from your computer using the Epson Print CD software
You can also use your product's control panel to create a jewel case insert with photos from a memory card.
Parent topic:
Related tasks
Printing Photos from a Memory Card Onto a CD/DVD
Printing a Jewel Case Insert from a Memory Card
Related topics
Printing on CDs/DVDs from a Computer
Loading a CD/DVD
You can print on any compatible, ink jet-printable CDs or DVDs, including Blu-ray Discs.
212
Caution: Do not insert the CD/DVD tray while the product is printing, copying, or performing other operations. Otherwise, your product may be damaged or the surface of the CD/DVD may become dirty or scratched.
Note: If you are using discs where the printable area extends to within 0.16 inch (4 mm) of the center hole, you may need to adjust the inner diameter setting using the control panel or Epson Print CD software.
1.
Burn your files, music, or video onto your disc before printing on it.
2.
Press the home icon, if necessary.
3.
Raise the control panel.
4.
Make sure nothing is on the output tray, then press the
5.
Remove the CD/DVD tray from beneath cassette 2.
icon to close it.
213
6.
Place a CD or DVD on the CD/DVD tray with the printable side faceup. Press on the center of the CD or DVD to make sure it is secure in the tray.
Note: Be sure to fully seat the CD or DVD or it may fall out when the tray is turned over.
7.
Insert the tray into the slot above the output tray.
Note: Make sure the marks on the tray and the marks on the product line up.
Caution: Do not turn off the product with a CD or DVD loaded in it. Always remove the disc first.
Parent topic:
214
Removing a Printed CD/DVD
After your CD or DVD is printed, the tray extends automatically.
1.
Pull the CD/DVD tray out of the product and remove your CD or DVD from the tray.
2.
Insert the CD/DVD tray into the storage slot beneath cassette 2.
Caution: After printing, handle the CD or DVD carefully. You may need to wait up to 24 hours for the ink to dry fully before inserting it in a drive, depending on the type of disc you used. Keep printed discs away from moisture and direct sunlight.
Parent topic:
Placing a CD/DVD on the Scanner Glass
You can place a CD or DVD on the scanner glass and copy the label design onto another CD or DVD.
1.
Open the document cover.
2.
Place your CD or DVD facedown in the center of the scanner glass.
3.
Close the document cover gently to keep your disc in place.
Parent topic:
Copying onto a CD/DVD
You can copy a printed photo or CD/DVD label directly onto an ink jet-printable CD or DVD. If you want, you can first print a test design on plain paper.
215
1.
Load the CD, DVD, or plain paper you want to print on.
2.
Press the home icon, if necessary.
3.
Select Various prints .
4.
Select Copy to CD/DVD .
5.
Follow the instructions on the LCD screen to place your original CD, DVD, or photo on the scanner glass and select Proceed to set up Outer/Inner .
6.
If necessary, adjust the inner and outer diameter of your CD as shown on the screen and select
Select Type .
You see this screen:
7.
Select Print on CD/DVD to print on a CD or DVD. If printing a test print on plain paper, select Test
Print on Letter/A4 .
8.
Select any copy settings as needed.
9.
When you are ready to print, select Print on CD/DVD .
Note: To cancel printing, select Cancel and select OK to exit.
Parent topic:
Related references
Related tasks
Placing a CD/DVD on the Scanner Glass
216
Related topics
Placing Originals on the Product
Printing Photos from a Memory Card Onto a CD/DVD
You can print one or more photos from a memory card directly onto a CD/DVD. If you want, you can first print a test design on plain paper.
1.
Insert a memory card into the memory card slot on your product.
2.
Load the CD, DVD, or plain paper you want to print on.
3.
Press the home icon, if necessary.
4.
Select Various prints .
5.
Select Copy to CD/DVD > Print on CD/DVD .
You see this screen:
6.
Select one of the CD/DVD layout options.
7.
Follow the instructions on the screen to select your photo or photos.
8.
When you see the screen to adjust the inner and outer diameter of your CD or DVD, adjust the settings if necessary, and select Select Type .
217
You see this screen:
9.
Select Print on CD/DVD to print on a CD or DVD. If printing a test print on plain paper, select Test
Print on Letter/A4 .
10. When you are ready to print, select Print on CD/DVD .
Note: To cancel printing, select Cancel and select OK to exit.
Parent topic:
Related tasks
Printing a Jewel Case Insert from a Memory Card
You can print a photo from a memory card on a CD/DVD jewel case insert. Your product automatically resizes the photo to fit, but you can also print multiple thumbnail images formatted to fit on a jewel case insert. After the insert is printed, you can cut and fold it to fit.
1.
Insert a memory card into the memory card slot on your product.
2.
Load the paper you want to print on.
3.
Press the home icon, if necessary.
218
4.
Select Various prints .
5.
Select Copy to CD/DVD .
You see this screen:
6.
Select Print on Jewel Case .
7.
Select one of the following options:
• Jewel Upper to print one photo on the upper half of the insert.
• Jewel Index to print 24 or 48 thumbnail images on the insert.
8.
Select your paper size and type.
9.
Follow the instructions on the LCD screen to select your photos and the number of copies.
219
10. When you are ready to print, select the Print icon.
Note: To cancel printing, select Cancel and select OK to exit.
11. After your insert is printed, cut and fold it following the crop lines.
Parent topic:
Related tasks
Related topics
Printing on CDs/DVDs from a Computer
Before printing directly on CDs or DVDs from your computer, make sure you have set up your product as described on the Start Here sheet and installed the Epson Print CD software.
Note: If you are using your Epson product with the Windows 10 S operating system, you cannot use the software described in this section. You also cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows
Store.
Starting Epson Print CD - Windows
Printing Your CD/DVD Design - Windows
Printing Your CD/DVD Design - Mac
Parent topic:
Starting Epson Print CD - Windows
You can use Epson Print CD to design your disc by importing photos, adding text, and creating special effects.
1.
Select the Epson Print CD icon on your Windows Desktop.
220
You see a screen like this:
2.
Use the buttons on the left side of the screen to select a pre-designed template or add a background image, picture, text, or graphic elements. For more information, select the Help menu.
3.
When you are finished creating your design, click Save and save your design file.
Parent topic:
Printing on CDs/DVDs from a Computer
Related tasks
Printing Your CD/DVD Design - Windows
Printing Your CD/DVD Design - Windows
After you create your design, you can print it on paper to test it, then print it on the CD or DVD that contains your data, photos, video, or music. Make sure the disc is loaded for printing before you start.
1.
Open your file in Epson Print CD and click Print .
221
You see a screen like this:
2.
Make sure your product is selected as the Printer setting.
3.
To see how your design will look without printing on the disc, click Test Print and follow the instructions on the screen.
4.
When you are ready to print on the disc, click the Print button on the screen.
5.
Click Print .
Note: If you need to adjust the print position or print quality, see the Epson Print CD Help utility for instructions.
Parent topic:
Printing on CDs/DVDs from a Computer
Related tasks
Starting Epson Print CD - Windows
Starting Epson Print CD - Mac
You can use Epson Print CD to design your disc by importing photos, adding text, and creating special effects.
222
1.
Open the Epson Print CD program in the Applications > Epson Software > Print CD folder on your
Mac.
You see a screen like this:
2.
Use the icons on the left side of the screen to add a background image, picture, text, or graphic elements.
3.
When you are finished creating your design, make sure you save it.
Parent topic:
Printing on CDs/DVDs from a Computer
Related tasks
Printing Your CD/DVD Design - Mac
Printing Your CD/DVD Design - Mac
After you create your design, you can print it on paper to test it, then print it on the CD or DVD that contains your data, photos, video, or music. Make sure the disc is loaded for printing before you start.
1.
Open your file in Epson Print CD and select Print from the File menu.
223
You see a screen like this:
2.
Make sure your product is selected as the Printer setting.
3.
To see how your design will look without printing on the disc, select Test Print and follow the instructions on the screen.
4.
When you are ready to print on the disc, click the Print button on the screen.
Note: If you need to adjust the print position or print quality, see the Epson Print CD Help utility for instructions.
Parent topic:
Printing on CDs/DVDs from a Computer
Related tasks
224
Replacing Ink Cartridges
When an ink cartridge is expended, you need to replace it.
You may also need to replace a cartridge that is more than six months old, or if your printouts do not look their best, even after cleaning and aligning the print head.
Note: Please dispose of your used Epson branded ink cartridges responsibly and in accordance with local requirements. If you would like to return your used ink cartridges to Epson for proper disposal, please go to epson.com/recycle for more information.
Removing and Installing Ink Cartridges
Printing with Black Ink and Expended Color Cartridges
Conserving Low Black Ink with Windows
Check Cartridge Status
Your product and its printing software will let you know when an ink cartridge is low or expended.
Checking Cartridge Status on the LCD Screen
Checking Cartridge Status - Windows
Checking Cartridge Status - Mac
Parent topic:
Checking Cartridge Status on the LCD Screen
You can check the status of the cartridges using the product's LCD screen.
1.
Press the home icon, if necessary.
2.
Select the icon.
225
You see a screen like this:
Note: The displayed ink levels are approximate.
3.
For more information, select Print Supply Status Sheet .
4.
If you want to replace an ink cartridge, select Replace Ink Cartridge(s) and follow the on-screen instructions.
Parent topic:
Related tasks
Removing and Installing Ink Cartridges
Checking Cartridge Status - Windows
A low ink reminder appears if you try to print when ink is low, and you can check your cartridge status at any time using a utility on your Windows computer.
1.
To check your cartridge status, access the Windows Desktop and double-click the icon for your product in the right side of the Windows taskbar, or click the up arrow and double-click .
226
You see this window:
2.
Replace or reinstall any ink cartridge indicated on the screen.
Note: Depending on the color of the expended cartridge and how you are printing, you may be able to continue printing temporarily.
Note: If any of the cartridges installed in the product are broken, incompatible with the product model, or improperly installed, Epson Status Monitor will not display an accurate cartridge status.
3.
To disable the low ink reminder, right-click the product icon in the Windows taskbar and select
Monitoring Preferences .
227
You see this window:
4.
Deselect the See Low Ink Reminder alerts checkbox at the bottom of the screen.
5.
To disable promotional offers, deselect the Display Epson Offers checkbox.
Parent topic:
Related tasks
Removing and Installing Ink Cartridges
Printing with Expended Color Cartridges - Windows
228
Checking Cartridge Status - Mac
You can check your cartridge status using a utility on your Mac.
1.
In the Apple menu or the Dock, select System Preferences . Select Print & Fax , Print & Scan , or
Printers & Scanners , select your product, and select Options & Supplies . Select Utility and select
Open Printer Utility .
2.
Select EPSON Status Monitor .
You see a window like this:
3.
Do the following as necessary:
• To update the ink cartridge status, click Update .
229
• Replace or reinstall any ink cartridge indicated on the screen.
Note: Depending on the color of the expended cartridge and how you are printing, you may be able to continue printing temporarily.
Note: If any of the cartridges installed in the product is broken, incompatible with the product model, or improperly installed, Epson Status Monitor will not display an accurate cartridge status.
Parent topic:
Related tasks
Removing and Installing Ink Cartridges
Printing with Expended Color Cartridges - Mac
Purchase Epson Ink Cartridges
You can purchase genuine Epson ink and paper at epson.com
(U.S. sales), epson.ca
(Canadian sales), or epson.com.jm
(Caribbean sales). You can also purchase supplies from an Epson authorized reseller.
To find the nearest one, call 800-GO-EPSON (800-463-7766) in the U.S. or 800-807-7766 in Canada.
Note: This printer is designed for use with Epson cartridges only, not third-party cartridges or ink. Other brands of ink supplies are not compatible and, if described as compatible, may not function properly or continuously. Such restrictions can be avoided with some other printers such as Epson EcoTank cartridge-free printers.
The included initial cartridges are designed for reliable printer setup and cannot be used as replacement cartridges or resold. After setup, the remaining ink is available for printing. Yields are based on ISO
24711 in default mode, printing continuously. Yields vary due to print images, settings, and temperatures. Printing infrequently or primarily with one color reduces yields. All cartridges must be installed with ink for printing and printer maintenance. For print quality, some ink remains in replaced cartridges.
Parent topic:
Ink Cartridge Part Numbers
Use these part numbers when you order or purchase new ink cartridges.
Note: For best printing results, use up a cartridge within 6 months of opening the package.
230
Ink color
Photo Black (PBK)
Black (BK)
Cyan
Magenta
Yellow
Part number
Standard-capacity
410
410
410
410
410
High-capacity
410XL
410XL
410XL
410XL
410XL
Parent topic:
Removing and Installing Ink Cartridges
Make sure you have your replacement cartridges handy before you begin. You must install new cartridges immediately after removing the old ones.
Caution: Leave your old cartridges in the printer until you are ready to replace them to prevent the print head nozzles from drying out. Do not open ink cartridge packages until you are ready to install the ink.
Cartridges are vacuum packed to maintain reliability.
1.
Make sure that the CD/DVD tray is not inserted.
2.
Turn on your product.
• If an ink cartridge is expended, you see a message on the LCD screen. Note which cartridges need to be replaced, select Next , and select Yes, replace now .
• If you are replacing a cartridge before you see a message on the LCD screen, select
Maintenance > Ink Cartridge Replacement . Select Next and select Start .
231
3.
Lift up the scanner unit.
232
Caution: Do not move the print head by hand; otherwise, you may damage your product. Do not touch the flat white cable or the metal bar inside the product.
233
4.
Push in the blue tab to unlock the ink cartridge you are replacing. Then lift the ink cartridge as shown to remove it.
Warning: If ink gets on your skin, wash it thoroughly with soap and water. If ink gets into your eyes, flush them immediately with water. If ink gets into your mouth, spit it out and see a doctor right away.
Keep ink cartridges out of the reach of children.
5.
Recap the used ink cartridge using the cap that came with it. You can also use the cap from your replacement cartridge package.
Note: Dispose of used cartridges carefully. Do not take the used cartridge apart or try to refill it.
6.
If you are replacing the black ink cartridge, gently shake the new black ink cartridge four or five times. Do not shake the color ink or photo black cartridges.
Caution: Do not shake the cartridges after opening the packages, or ink may leak.
234
7.
Remove the new ink cartridge from the package.
Caution: Do not touch the areas shown here. Doing so may prevent normal operation and printing.
8.
Remove the cap from the cartridge and save the cap so you can recap ink cartridges before storing or disposing of them.
235
Caution: Do not remove any other labels or seals, or ink will leak.
9.
Insert the ink cartridge at a slight angle into the ink cartridge holder as shown. Then press the ink cartridge all the way down as shown until it clicks into place.
10. After you replace all the cartridges that need replacing, close the scanner unit and select Completed on the LCD screen.
The print head moves to its home position and the product starts charging the ink. This takes a few minutes. When you see a completion message on the LCD screen, ink replacement is complete.
Note: If you see an error screen telling you an ink cartridge is installed incorrectly, lift up the scanner unit and press the ink cartridge down until it clicks into place. When you're finished, close the scanner unit.
Caution: Do not turn off the product while ink is charging or you may not be able to print.
Caution: If you remove an ink cartridge for later use, recap the ink cartridge using the cap that came with it to prevent the ink from drying out and to protect the surrounding area from getting smeared by ink.
Store the ink cartridge in the same environment as the product. Do not leave the product with the ink cartridges removed for an extended period of time. Otherwise, ink remaining in the print head nozzles may dry out and you may not be able to print.
Parent topic:
Related concepts
236
Printing with Black Ink and Expended Color Cartridges
When a color or photo black ink cartridge is expended, you can temporarily continue printing from your computer using black ink. Replace the expended cartridge as soon as possible for future printing.
Note: You cannot print with expended color ink cartridges using your product's control panel.
Printing with Expended Color Cartridges - Windows
Printing with Expended Color Cartridges - Mac
Parent topic:
Printing with Expended Color Cartridges - Windows
If you see a message during printing telling you that you can temporarily print in black ink with an expended color or photo black cartridge, you can cancel your print job and select settings to print on plain paper or on an envelope.
Note: If you are using your Epson product with the Windows 10 S operating system, you cannot use the software described in this section. You also cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows
Store.
Note: To use this feature, Epson Status Monitor must be enabled.
1.
Click Cancel or Cancel Print to cancel your print job.
Note: If the message screen appears on another computer on a network, you may need to cancel the print job using the product control panel.
2.
Load plain paper or an envelope in your product.
3.
Access the print settings in your print application.
4.
Click the Main tab and make sure Borderless is not selected.
5.
Select Plain Paper/Bright White Paper or Envelope as the paper type setting.
6.
Select the Black/Grayscale checkbox.
7.
Click OK .
8.
Print your document.
237
Epson Status Monitor 3 displays a print message.
9.
Click Print in Black to print your document.
Parent topic:
Printing with Black Ink and Expended Color Cartridges
Related topics
Printing with Expended Color Cartridges - Mac
If printing stops, you can cancel your print job and select settings to temporarily print with only black ink on plain paper or on an envelope.
1.
Click the printer icon in the Dock.
2.
If you see a message telling you that you can temporarily print with only black ink, click the Delete or button to cancel your print job. If you see an error message, click OK .
Note: If the message screen appears on another computer on a network, you may need to cancel the print job using the product control panel.
3.
In the Apple menu or the Dock, select System Preferences .
4.
Select Print & Fax , Print & Scan , or Printers & Scanners , select your product, and select Options
& Supplies .
5.
Select Driver or Options .
238
You see a screen like this:
6.
Select On as the Permit temporary black printing setting.
7.
Click OK .
8.
Close the utility window.
9.
Load plain paper or an envelope in your product.
10. Access the print settings in your print application.
11. Select Print Settings from the pop-up menu.
12. Select Plain Paper/Bright White Paper or Envelope as the paper type setting.
13. Select the Grayscale option.
14. Click Print to print your document.
Parent topic:
Printing with Black Ink and Expended Color Cartridges
Related topics
239
Conserving Low Black Ink with Windows
The following window appears when black ink runs low and there is more color ink.
Note: The window appears only when you have selected Plain Paper/Bright White Paper as the paper type setting, and depends on other selected print settings. To use this feature, Epson Status Monitor must be enabled.
• Click Yes to use a mixture of color inks to create black, or No to continue using the remaining black ink for the document you are printing.
• Click Disable this feature to continue using the remaining black ink.
Note: If you disable this feature, it remains disabled until you install a new black ink cartridge.
Parent topic:
240
Adjusting Print Quality
If your print quality declines, you may need to run a utility to clean or align the print head.
Note: If you are using your Epson product with the Windows 10 S operating system, you cannot use the software described in this section. You also cannot download and install any Epson product software from the Epson website for use with Windows 10 S; you must obtain software only from the Windows
Store.
If running these utilities does not solve the problem, the translucent film inside the printer may be smeared or you may need to replace the ink cartridges.
Aligning the Print Head Using the Product Control Panel
Print Head Maintenance
If your printouts become too light, or you see dark or light bands across them, you may need to clean the print head nozzles. Cleaning uses ink, so clean the nozzles only if print quality declines.
You can check for clogged nozzles before you clean them so you don’t clean them unnecessarily.
Note: You cannot clean the print head if an ink cartridge is expended, and may not be able to clean it when a cartridge is low. You must replace the cartridge first.
Parent topic:
Related concepts
Print Head Nozzle Check
You can print a nozzle check pattern to check for clogged nozzles.
Checking the Nozzles Using the Product Control Panel
Checking the Nozzles Using a Computer Utility
Parent topic:
241
Checking the Nozzles Using the Product Control Panel
You can check the print head nozzles using the control panel on your product.
1.
Make sure there are no errors on the LCD screen and the CD/DVD tray is not inserted for printing.
2.
Load a few sheets of plain paper in Cassette 2.
3.
Press the home icon, if necessary.
4.
Select Maintenance .
You see a screen like this:
5.
Select Print Head Nozzle Check .
You see a screen like this:
6.
Select Print .
The nozzle pattern prints.
242
7.
Check the printed pattern to see if there are gaps in the lines.
Print head is clean
Print head needs cleaning
8.
Do one of the following:
• If there are no gaps, select O .
• If there are gaps or the pattern is faint, select X and continue.
9.
Follow the instructions on the screen to clean the print head, check the nozzles, and repeat the process as necessary.
Caution: Never turn off the product or open the front cover during a cleaning cycle or you may not be able to print.
If you don’t see any improvement after cleaning the print head up to 2 times, wait at least 6 hours without printing or longer if printing. Then try cleaning the print head again. If quality still does not improve, contact Epson.
Parent topic:
Related concepts
Checking the Nozzles Using a Computer Utility
You can check the print head nozzles using a utility on your Windows or Mac computer.
243
1.
Load a few sheets of plain paper in Cassette 2.
2.
Do one of the following:
• Windows: Access the Windows Desktop and right-click the icon for your product in the right side of the Windows taskbar, or click the up arrow and right-click .
• Mac : In the Apple menu or the Dock, select System Preferences . Select Print & Fax , Print &
Scan , or Printers & Scanners , select your product, and select Options & Supplies . Select
Utility and select Open Printer Utility .
3.
Select Nozzle Check .
You see a window like this:
4.
Click Print .
244
5.
Check the printed pattern to see if there are gaps in the lines.
Print head is clean
Print head needs cleaning
6.
If there are no gaps, click Finish .
If there are gaps or the pattern is faint, clean the print head.
Parent topic:
Related concepts
Print Head Cleaning
If print quality has declined and the nozzle check pattern indicates clogged nozzles, you can clean the print head.
Note: You cannot clean the print head if an ink cartridge is expended, and may not be able to clean it when a cartridge is low. You must replace the cartridge first.
Cleaning the Print Head Using the Product Control Panel
Cleaning the Print Head Using a Computer Utility
Parent topic:
245
Related concepts
Related tasks
Removing and Installing Ink Cartridges
Cleaning the Print Head Using the Product Control Panel
You can clean the print head using the control panel on your product.
1.
Load a few sheets of plain paper in the product.
2.
Press the home icon, if necessary.
3.
Select Maintenance .
You see a screen like this:
4.
Select Print Head Cleaning .
You see a screen like this:
246
5.
Select Start to clean the print head.
When the cleaning cycle is finished, you see a message on the screen.
Caution: Never turn off the product or open the front cover during a cleaning cycle or you may not be able to print.
6.
Select Check .
7.
Select Print to print a nozzle check pattern and confirm that the print head is clean.
If you don’t see any improvement after cleaning the print head up to 2 times, wait at least 6 hours without printing. Then try cleaning the print head again. If quality still does not improve, contact Epson.
Parent topic:
Related tasks
Loading Paper in Cassette 1 (Upper Cassette)
Loading Paper in Cassette 2 (Lower Cassette)
Loading Paper in the Rear Paper Feed Slot
Cleaning the Print Head Using a Computer Utility
You can clean the print head using a utility on your Windows or Mac computer.
1.
Make sure there are no errors on the LCD screen and the CD/DVD tray is not inserted for printing.
2.
Load a few sheets of plain paper in the product.
3.
Do one of the following:
• Windows: Access the Windows Desktop and right-click the icon for your product in the right side of the Windows taskbar, or click the up arrow and right-click .
• Mac : In the Apple menu or the Dock, select System Preferences . Select Print & Fax , Print &
Scan , or Printers & Scanners , select your product, and select Options & Supplies . Select
Utility and select Open Printer Utility .
4.
Select Head Cleaning .
247
You see a window like this:
5.
Click Start to begin the cleaning cycle.
The power light flashes throughout the cleaning cycle and stays on when the cleaning cycle is finished.
Caution: Never turn off the product or open the scanner unit during a cleaning cycle or you may not be able to print.
6.
When the cleaning cycle is finished, you can check to see if the nozzles are clean; click Print Nozzle
Check Pattern and click Print .
248
7.
Check the printed pattern to see if there are gaps in the lines.
Print head is clean
Print head needs cleaning
• If there are no gaps, click Finish .
• If there are gaps or the pattern is faint, click Clean to clean the print head again.
If you don’t see any improvement after cleaning the print head up to 2 times, wait at least 6 hours without printing. Then check the print head nozzles and try cleaning the print head again, if necessary. If quality still does not improve, contact Epson.
Parent topic:
Related tasks
Loading Paper in Cassette 1 (Upper Cassette)
Loading Paper in Cassette 2 (Lower Cassette)
Loading Paper in the Rear Paper Feed Slot
Aligning the Print Head Using the Product Control Panel
If your printouts become grainy or blurry, you notice misalignment of vertical lines, or you see dark or light horizontal bands, you may need to align the print head.
Note: Banding may also occur if your print head nozzles need cleaning.
249
1.
Load a few sheets of plain paper in the product.
2.
Press the home icon, if necessary.
3.
Select Maintenance .
You see a screen like this:
4.
Select Print Head Alignment .
5.
Select one of the following options:
• Vertical Alignment if your printout is blurry.
• Horizontal Alignment if your printout contains horizontal banding.
6.
Follow the on-screen instructions to print an alignment sheet.
Note: Do not cancel printing while you are printing head alignment patterns.
7.
Check the printed patterns on the alignment sheet and select the following on the LCD screen, depending on the alignment pattern you printed:
• Vertical Alignment : For patterns 1 through 4, select the number representing the pattern with the least amount of separation or overlap.
250
• Horizontal Alignment : Select the number representing the pattern with the least amount of separation or overlap.
8.
Select OK .
Parent topic:
Related tasks
Loading Paper in Cassette 1 (Upper Cassette)
Loading Paper in Cassette 2 (Lower Cassette)
Loading Paper in the Rear Paper Feed Slot
Cleaning the Paper Guide
If you see ink on the back of a printout, you can clean the paper guide rollers to remove any excess ink.
1.
Load plain paper in this size: Letter (8.5 × 11 inches [216 × 279 mm]) or A4 (8.3 × 11.7 inches
[210 × 297 mm]).
2.
Press the home icon, if necessary.
3.
Select Maintenance .
251
You see a screen like this:
4.
Scroll down and select Paper Guide Cleaning .
5.
Select Start .
6.
Follow the on-screen instructions to clean the paper guide.
7.
Repeat these steps as necessary until the paper comes out clean.
8.
If there is still ink on your printouts after several cleanings, turn off the product.
9.
Unplug the power cable.
10. Disconnect any connected cables.
11. Raise the control panel.
12. Slide out the output tray.
252
13. Use a soft, moist cloth to clean the white rollers shown here. Gently rotate the rollers to clean them completely.
Parent topic:
Related tasks
Loading Paper in Cassette 1 (Upper Cassette)
Loading Paper in Cassette 2 (Lower Cassette)
Loading Paper in the Rear Paper Feed Slot
253
Cleaning and Transporting Your Product
See these sections if you need to clean or transport your product.
Cleaning Your Product
To keep your product working at its best, you should clean it several times a year.
Close the output tray and front cover when you are not using the product to protect it from dust.
Caution: Do not use a hard brush, alcohol, or paint thinner to clean the product or you may damage it.
Do not use oil or other lubricants inside the product or let water get inside it.
1.
Turn off the product.
2.
Unplug the power cable.
3.
Disconnect any connected cables.
4.
Remove all the paper.
5.
Open the ADF cover.
254
6.
Use a soft, dry, lint-free cloth (microfiber is recommended) to clean the rollers and the interior of the
ADF.
7.
Close the ADF cover.
8.
Open the document cover.
255
9.
Clean the scanner glass and the glass area on the left with a soft, lint-free cloth (microfiber is recommended), moistened with a little glass cleaner.
Caution: Do not spray glass cleaner directly on the glass and do not press the glass surface with any force.
256
10. Press the tabs and remove the document mat.
11. Use a soft, dry, lint-free cloth (microfiber is recommended) to clean the transparent part on the underside of the document mat.
12. Replace the document mat by reversing the steps to remove it. Close the document cover.
13. Clean the outer case and control panel with a soft, dry cloth. Do not use liquid or chemical cleansers.
Parent topic:
Cleaning and Transporting Your Product
257
Cleaning the Paper Rollers
If you encounter issues with paper feeding properly from the cassettes, clean the paper rollers inside your product.
1.
Turn off the product.
2.
Unplug the power cable.
3.
Disconnect any connected cables.
4.
Remove both paper cassettes.
258
5.
Place the product on its right side.
Warning: Be careful not to trap your fingers under the product.
6.
Use a soft, moist cloth to clean the cassette rollers shown here. Gently rotate the rollers to clean them completely.
7.
Return the printer to its normal position.
Caution: Do not leave the product on its side for an extended period of time. Ink may leak.
8.
Insert the paper cassettes into your product.
259
Parent topic:
Cleaning and Transporting Your Product
Cleaning the Translucent Film
If the print quality has not improved after aligning the print head and cleaning the paper path, the translucent film inside the product may be smeared with ink.
To clean the printer head path, use the following:
• Several cotton swabs
• ¼ cup (59 ml) water containing 2 to 3 drops of mild dish detergent
• A small flashlight
Caution: Do not use any other liquid to clean the printer head path or you may damage your product.
1.
Turn off the product.
2.
Unplug the power cable.
3.
Disconnect any connected cables.
4.
Lift up the scanner unit.
260
5.
Using the flashlight, check the translucent film shown here for ink smears.
1
2
Translucent film
Print head rail
Caution: Do not touch the print head rail or you may not be able to print. Do not wipe off the grease on the rail.
261
6.
Moisten a cotton swab with the water and detergent mixture and squeeze out any excess moisture, then lightly wipe the ink off the translucent film.
Caution: Do not press too hard on the film or you may dislocate the anchor springs and damage your product.
7.
Use a new, dry cotton swab to dry the translucent film.
8.
Repeat steps 6 and 7 as necessary to clean all ink smears.
9.
When the translucent film is dry and free of any fibers, close the scanner unit.
10. Reconnect any disconnected cables, plug in the power cord, and turn on the product.
Parent topic:
Cleaning and Transporting Your Product
Related tasks
Aligning the Print Head Using the Product Control Panel
Transporting Your Product
If you need to store your product or transport it a long distance, prepare it for transportation as described here.
262
Caution : During transportation and storage, follow these guidelines:
• Avoid tilting the product or turning it upside down. Also avoid placing the product on its side for an extended period of time. Ink may leak.
• Leave the ink cartridges installed. Removing the cartridges can dry out the print head and may prevent the product from printing.
• Do not carry the product by its control panel; this may damage the product.
Note: Before storing your product for a long period, replace low, expended, or expired ink to help prevent the print head from drying out. Store your product in a cool, dry place.
1.
Turn off the product.
2.
Lift up the scanner unit and check to see if the print head is in the far right position (the home position). If not, turn on the product, wait for the print head to move, then turn the product off again.
3.
Secure the ink cartridge holder to the case with tape.
Caution: Do not place tape on the white flat cable inside the product; otherwise, you may damage your product.
4.
Lower the scanner unit.
5.
Remove all the paper from the product.
6.
Remove any memory card inserted in the product.
263
7.
Unplug the power cable.
8.
Disconnect any connected cables.
9.
Close all parts on the product as shown.
10. Place the product in its original packing materials, if possible, or use equivalent materials with cushioning around the product.
Keep the product level during transportation. Be sure to remove the tape from the ink cartridge holder before turning on your product. If print quality has declined when you print again, clean and align the print head.
Parent topic:
Cleaning and Transporting Your Product
Related concepts
264
Solving Problems
Check these sections for solutions to problems you may have using your product.
Resetting Control Panel Defaults
Solving Problems Printing from a Computer
Solving Page Layout and Content Problems
Solving Print Quality Problems
Solving Scanned Image Quality Problems
Uninstall Your Product Software
Checking for Software Updates
It's a good idea to check Epson's support website occasionally for free updates to your product software.
Visit epson.com/support (U.S.), epson.ca/support (Canada), or epson.com.jm/support (Caribbean) and select your product.
Note: Epson periodically provides firmware updates to address issues of security, performance, minor bug fixes and ensure your printer functions as designed. Your printer was designed to work only with genuine Epson ink cartridges, therefore some updates may affect the functionality of third-party ink.
265
• Windows : Your printer software automatically checks for updates. You can also manually update the software by selecting Software Update here:
• Accessing the Windows Desktop and right-clicking the icon for your product in the right side of the Windows taskbar, or clicking the up arrow and right-clicking .
• On the Maintenance tab in the printer settings window
You can also update the software by selecting EPSON Software Updater in the EPSON or EPSON
Software program group, accessible by the Start button, or on the Start or Apps screens, depending on your version of Windows.
• OS X : You can manually update the software by opening the Applications > Epson Software folder and selecting EPSON Software Updater .
• macOS 10.12.x or 10.13.x
: You can manually update the software by opening the App Store , selecting Updates , searching for a software update option for Epson Software, and selecting Update .
Parent topic:
Product Status Messages
You can often diagnose problems with your product by checking the messages on its LCD screen. You can also press the help button to see help information and how-to instructions on the screen.
LCD screen message Condition/solution
Printer error. Turn on the printer again. See your documentation for more details.
A fatal error has occurred. Turn the product off and then back on again. If the error continues, check for a paper jam or any protective material inside the product. If there is no paper jam or protective material, contact Epson for support.
Operation canceled. An error occurred while saving.
Ink is low.
The memory card or external USB device may be damaged. Make sure the memory card or USB device is inserted correctly and meets the specifications for the product.
The ink cartridge is low. You can continue printing until you are prompted to replace the cartridge. Make sure you have the replacement cartridge ready.
The ink cartridge is expended. Replace the cartridge.
You need to replace the following ink cartridge(s).
266
LCD screen message Condition/solution
Paper Configuration is set to Off. Some features such as paper size and type settings may be unavailable. For details, see your documentation.
The Paper Configuration setting must be enabled to use AirPrint.
The printer's ink pad is nearing the end of its service life. Contact
Epson support.
The printer's ink pad is at the end of its service life. Please contact
Epson support.
The ink pads are near the end of their service life and the message will be displayed until the ink pad is replaced. Contact Epson for support. (To resume printing, select OK .)
The ink pad is at the end of its service life. Turn off the product and contact
Epson for support.
The printer's borderless printing ink pad is nearing the end of its service life. It is not a user-replaceable part.
Please contact Epson support.
The printer's borderless printing ink pad has reached the end of its service life. It is not a user-replaceable part.
Please contact Epson support.
Communication error.
Check if the computer is connected.
The ink pad is near the end of its service life and the message will be displayed until the ink pad is replaced. Contact Epson for support. (To resume printing, select OK .)
The ink pad is at the end of its service life. Turn off the product and contact
Epson for support.
Connect the computer and the printer correctly. If you are connecting over a network, see the page that describes the network connection method from the computer. If the error message is still displayed, make sure that Epson
Scan 2 and Epson Event Manager are installed on the computer.
267
LCD screen message Condition/solution
The combination of the
IP address and subnet mask is invalid. See your documentation for more details.
There is a problem with the network connection to your product. Check the solutions in this guide.
Access your product's built-in Web Config utility and update the root certificate for your product.
To use cloud services, update the root certificate from the
Epson Web Config utility.
Cannot recognize the media. See your documentation for more details about the media.
See the specifications for external USB devices or memory cards for more information.
Cannot use the inserted
Memory Device. See your documentation for details.
Print Head Adjustment
Canceled. There is a problem with the print head. Contact Epson
Support.
Install the Epson Event
Manager software in the computer to use this feature. See your documentation for more details.
Clean the print head. If print quality does not improve after repeating the head cleaning 2 times, turn off the printer and wait for at least six hours without printing. Then run the nozzle check again and repeat the head cleaning if necessary. If print quality still does not improve, contact Epson for support.
Try uninstalling the Epson Event Manager software and installing it again. If you still receive this error message, contact Epson for support.
268
LCD screen message Condition/solution
Check the following when the computer is not found.
- Connection between the printer and the computer (USB or network)
Check the connection between the printer and the computer and make sure all necessary software is installed. See the links at the end of this section for more information.
- Installation of necessary software
- Computer powered on
- Settings for firewall and security software
- Search again
See your documentation for more details.
Check that the printer driver is installed on the computer and that the port settings for the printer are correct.
Check that the printer driver is installed on the computer and that the
USB port settings for the printer are correct.
Access the following or see documentation for details. Select Dismiss after confirming it.
Make sure the printer port is selected correctly on the Port tab of the Printer
Properties screen (Windows) or the System Properties > USB list (Mac).
Select USBXXX for a USB connection or EpsonNet Print Port for a network connection.
See the instructions for using an external device with your product.
269
LCD screen message Condition/solution
Paper settings for XX do not match the Print
Settings. Pull out Paper
Cassette 1 or Paper
Cassette 2 to place the following paper. XX XX
Load paper that matches the print settings in the paper cassette, then change the paper or print settings. If you do not want to display this message next time, turn off the Paper Configuration setting on the control panel.
The paper size and type set in XX does not match specified Print
Settings.
No paper has been loaded that matches the paper size setting.
Recovery mode
Change the print settings according to the paper size loaded in the paper cassette, then change the paper or print settings. If you do not want to display this message next time, turn off the control panel.
Paper Mismatch setting on the
An error has occurred during firmware updating. Connect your product using a USB cable and try updating the firmware again. If you still receive this error message, contact Epson for support.
Note: The ink pads in the printer collect, distribute, and contain the ink that is not used on printed pages.
During the life of your product it may reach a condition where either satisfactory print quality cannot be maintained or the ink pads have reached the end of their usable life. The Epson Status Monitor, your
LCD screen, or lights on the control panel will advise you when these parts need replacing. If this happens during the standard warranty of the product, the exchange of the product or replacement of the pads is covered under the standard warranty. If the product is out of warranty, the pads can be replaced by any Epson authorized service provider. The waste ink pads are not a user-replaceable part.
Parent topic:
Related concepts
Uninstall Your Product Software
Related references
External USB Device Specifications
Related tasks
270
Related topics
Solving Problems Printing from a Computer
Using an External Device with Your Product
Running a Product Check
Running a product check helps you determine if your product is operating properly.
1.
Disconnect any interface cables connected to your product.
2.
Make sure there are no errors on the LCD screen and the CD/DVD tray is not inserted for printing.
3.
Load plain paper in Cassette 2.
4.
Press the home icon, if necessary.
5.
Select Maintenance .
You see a screen like this:
6.
Select Print Head Nozzle Check .
271
You see a screen like this:
7.
Select Print .
The nozzle pattern prints.
8.
Do one of the following, depending on the results of the product check:
• If the page prints and the nozzle check pattern is complete, the product is operating properly. Any operation problem you may have could be caused by your computer, cable, software, or selected settings. Check the other solutions in this manual or try uninstalling and reinstalling your printer software.
• If the page prints but the nozzle check pattern has gaps, clean the print head.
• If the page does not print, the product may have a problem. Check the other solutions in this manual. If they do not work, contact Epson.
Parent topic:
Related concepts
Uninstall Your Product Software
Related tasks
Aligning the Print Head Using the Product Control Panel
Resetting Control Panel Defaults
If you have a problem with settings on the product control panel, you can reset them to their factory defaults. You can choose which settings to reset or reset them all.
1.
Press the home icon, if necessary.
272
2.
Select Settings .
3.
Scroll down and select Restore Default Settings .
You see a screen like this:
4.
Select one of these options:
• Network Settings : Resets all network settings
• All Except Network Settings : Resets all settings except for network settings
• All Settings : Resets all control panel settings
You see a confirmation screen.
5.
Select Yes to reset the selected settings. (Select No if you want to cancel the operation.)
Parent topic:
Solving Setup Problems
Check these sections if you have problems while setting up your product.
Product Does Not Turn On or Off
Software Installation Problems
Parent topic:
273
Product Does Not Turn On or Off
If you cannot turn the product on or off, try these solutions:
• If you cannot turn on your product, make sure the power cord is securely connected and hold down the power button a little longer.
• If you cannot turn off your product, hold down the power button a little longer. If you still cannot turn off your product, unplug the power cord, plug the power cord back in, then turn your product on and off again using the power button.
Parent topic:
Noise After Ink Installation
If you hear noises from your product after installing ink, check the following:
• The first time you install the ink cartridges, the product must charge its print head. Wait until charging finishes before you turn off the product, or it may charge improperly and use excess ink the next time you turn it on.
• If the product's print head stops moving or making noise, and the charging process has not finished after approximately 5 minutes, turn off your product. Turn it back on and check to see if charging is still in progress. If it is still in progress, contact Epson for help.
Parent topic:
Software Installation Problems
If you have problems while installing your product software, try these solutions:
• Make sure your product is turned on and any necessary cables are securely connected at both ends. If you still have problems installing software, disconnect the cable and carefully follow the instructions on the Start Here sheet. Also make sure your system meets the requirements for your operating system.
• Close any other programs, including screen savers and virus protection software, and install your product software again.
• In Windows, make sure your product is selected as the default printer and the correct port is shown in the printer properties.
• If you see any error message or your software does not install correctly in Windows, you may not have software installation privileges. Contact your system administrator.
• If you are printing over a network, make sure your product is set up properly on the network.
Parent topic:
274
Related concepts
Uninstall Your Product Software
Related references
Solving Network Problems
Check these solutions if you have problems setting up or using your product on a network.
Note: Breakdown or repair of this product may cause loss of network data and settings. Epson is not responsible for backing up or recovering data and settings during or after the warranty period. We recommend that you make your own backup or print out your network data and settings.
Product Cannot Connect to a Wireless Router or Access Point
Network Software Cannot Find Product on a Network
Product Does Not Appear in Mac Printer Window
Parent topic:
Product Cannot Connect to a Wireless Router or Access Point
If your product has trouble finding or connecting to a wireless router or access point, try these solutions:
• If you are connecting the product via Wi-Fi Protected Setup (WPS) and the Wi-Fi icon on your product's LCD screen is not lit or does not appear, make sure you select one of the WPS options from the product control panel within 2 minutes of pressing the WPS button on your router.
• Make sure to place your product within contact range of your 2.4 GHz router or access point. Avoid placing your product near a microwave oven, 2.4 GHz cordless phone, or large metal object, such as a filing cabinet.
Note: If you are using a 5 GHz wireless router, set the router to operate in dual band (2.4 GHz and
5 GHz) mode. If your router uses a single network name (SSID) for both the 2.4 GHz and 5 GHz band, give each band its own network name (SSID) instead, such as Home Network 2.4 GHz and Home
Network 5 GHz. See your router documentation or contact your internet service provider for instructions.
275
• Verify that your router or access point is operating correctly by connecting to it from your computer or another device.
• You may need to disable the firewall and any anti-virus software on your wireless router or access point.
• Check to see if access restrictions, such as MAC address filtering, are set on the router or access point. If access restrictions are set, add your product's MAC address to your router's address list. To obtain your product's MAC address, print a network status sheet. Then follow the instructions in your router or access point documentation to add the address to the list.
• If your router or access point does not broadcast its network name (SSID), follow the instructions that came with your product to enter your wireless network name manually.
• If your router or access point has security enabled, determine the kind of security it is using and any required password or passphrase for connection. Then make sure to enter the exact WEP key or WPA passphrase correctly.
• Check if your computer is restricting the available wireless channels. If so, verify that your wireless access point is using one of the usable channels and change to a usable channel, if necessary.
• If you are using a Wi-Fi Direct connection that suddenly disconnects, the Wi-Fi direct password on your device may have been changed. If necessary, delete the existing DIRECT-xxxxxxxx connection settings from your device and enter a new password. See your device documentation for instructions.
Parent topic:
Related tasks
Selecting Wireless Network Settings from the Control Panel
Printing a Network Status Sheet
Related topics
Network Software Cannot Find Product on a Network
If EpsonNet Setup cannot find your product on a network, try these solutions:
• Make sure your product is turned on and connected to your network. Verify connection using your product control panel.
• Check if your network name (SSID) contains non-ASCII characters. Your product cannot display non-
ASCII characters.
• Make sure your product is not connected to a guest network.
276
• If necessary, reinstall your product software and try running EpsonNet Setup again:
1. Reset your product's network settings to their factory defaults.
2.
Windows only: Uninstall your product software.
3. Initialize your router following the instructions in your router documentation.
Note: If you are reading these instructions online, you will lose your Internet connection when you initialize your router, so note the next step before initializing it.
4. Download your product software from the Epson website using the instructions on the Start Here sheet.
• If you have replaced your router, reinstall your product software to connect to the new router.
Note: If you are using a 5 GHz wireless router, set the router to operate in dual band (2.4 GHz and
5 GHz) mode. If your router uses a single network name (SSID) for both the 2.4 GHz and 5 GHz band, give each band its own network name (SSID) instead, such as Home Network 2.4 GHz and Home
Network 5 GHz. See your router documentation or contact your internet service provider for instructions.
• Check to see if your wireless router or access point has an enabled Privacy Separator function that is preventing detection of your device over the network. See your router or access point documentation for instructions on disabling the Privacy Separator function.
Parent topic:
Related concepts
Uninstall Your Product Software
Related topics
Product Does Not Appear in Mac Printer Window
If your product does not appear in the Mac printer window, try these solutions:
• Turn your product off, wait 30 seconds, then turn it back on again.
• If you are connecting the product wirelessly via EpsonNet Setup and a WiFi symbol is not displayed on the product's LCD screen, make sure your product software was installed correctly. If necessary, reinstall your software.
277
• Make sure you installed your product software correctly for your network. See the Start Here sheet for instructions.
• If your Mac includes both wired and wireless network services, make sure the network to which you connected your product is at the top of the Set Service Order list. Check your Mac documentation for instructions.
Note: If you are using a 5 GHz wireless router, set the router to operate in dual band (2.4 GHz and
5 GHz) mode. If your router uses a single network name (SSID) for both the 2.4 GHz and 5 GHz band, give each band its own network name (SSID) instead, such as Home Network 2.4 GHz and Home
Network 5 GHz. See your router documentation or contact your internet service provider for instructions.
Parent topic:
Related concepts
Uninstall Your Product Software
Cannot Print Over a Network
If you cannot print over a network, try these solutions:
• Make sure that your product is turned on.
• Make sure you install your product's network software as described in your product documentation.
• Print a network status sheet and verify that the network settings are correct. If the network status is
Disconnected , check any cable connections and turn your product off and then on again.
• If you are using TCP/IP, make sure the product's IP address is set correctly for your network. If your network does not assign IP addresses using DHCP, set the IP address manually.
• Make sure your computer and product are both using the same wireless network.
• If network printing is slow, print a network status sheet and check the signal strength. If it is poor, place your product closer to your router or access point. Avoid placing your product near a microwave oven,
2.4 GHz cordless phone, or large metal object, such as a filing cabinet.
Note: If you are using a 5 GHz wireless router, set the router to operate in dual band (2.4 GHz and
5 GHz) mode. If your router uses a single network name (SSID) for both the 2.4 GHz and 5 GHz band, give each band its own network name (SSID) instead, such as Home Network 2.4 GHz and Home
Network 5 GHz. See your router documentation or contact your internet service provider for instructions.
278
• Check to see if your wireless router or access point has an enabled Privacy Separator function that is preventing printing from a device over the network. See your router or access point documentation for instructions on disabling the Privacy Separator function.
• If you are connecting the product via Wi-Fi Protected Setup (WPS) and the Wi-Fi icon on your product is not active, repeat the WPS setup process on the product control panel and be sure to complete it within 2 minutes of pressing the WPS button on your router.
• If you are connecting the product wirelessly via EpsonNet Setup and the Wi-Fi connection icon is not lit or does not appear on the product's LCD screen, make sure your product software was installed correctly. If necessary, reinstall your software.
Parent topic:
Related concepts
Uninstall Your Product Software
Related tasks
Printing a Network Status Sheet
Related topics
Cannot Scan Over a Network
If you cannot start Epson Scan 2 for scanning over a network, try these solutions:
• If you cannot scan from your product control panel, make sure you restarted your computer after installing the product software. Make sure the Event Manager program is not being blocked by your firewall or security software.
Note: If you are using a 5 GHz wireless router, set the router to operate in dual band (2.4 GHz and
5 GHz) mode. If your router uses a single network name (SSID) for both the 2.4 GHz and 5 GHz band, give each band its own network name (SSID) instead, such as Home Network 2.4 GHz and Home
Network 5 GHz. See your router documentation or contact your internet service provider for instructions.
• If you are scanning a large original at a high resolution, a network communication error may occur. Try scanning again at a lower resolution.
• If network communication was interrupted while starting Epson Scan 2, exit Epson Scan 2, wait a few seconds, and restart it. If Epson Scan 2 cannot restart, turn off your product, turn it back on, and try restarting Epson Scan 2 again.
• Check the scanner setting and reset the connection if necessary using Epson Scan 2 Utility:
279
Windows 10: Click and select EPSON > Epson Scan 2 Utility . Make sure your product is selected. If necessary, select the Other tab and click Reset .
Windows 8.x
: Navigate to the Apps screen, select EPSON , and select Epson Scan 2 Utility . Make sure your product is selected. If necessary, select the Other tab and click Reset .
Windows (other versions) : Click or Start > All Programs or Programs > EPSON > Epson
Scan 2 > Epson Scan 2 Utility . Make sure your product is selected. If necessary, select the Other tab and click Reset .
Mac : Open the Applications folder, click Epson Software , and click Epson Scan 2 Utility . Make sure your product is selected. If necessary, select the Other tab and click Reset .
• You may need to disable the firewall and any anti-virus software on your wireless router or access point.
Parent topic:
Related tasks
Starting a Scan Using the Product Control Panel
Starting a Scan Using the Epson Scan 2 Icon
Starting a Scan from a Scanning Program
Starting a Scan from a Smart Device
Solving Copying Problems
Check these solutions if you have problems copying with your product.
Product Makes Noise, But Nothing Copies
Product Makes Noise When It Sits for a While
Parent topic:
Related concepts
Product Makes Noise, But Nothing Copies
If your product makes a noise, but nothing copies, try these solutions:
• Run a nozzle check to see if any of the print head nozzles are clogged. Then clean the print head, if necessary.
280
• If the nozzle check page does not print, but the product's power is on, make sure your product software is installed correctly.
• Make sure your product is level (not tilted).
Parent topic:
Product Makes Noise When It Sits for a While
Your product is performing routine maintenance. This is normal.
Parent topic:
Solving Paper Problems
Check these sections if you have problems using paper with your product.
Paper Jam Problems Inside the Product
Paper Jam Problems in the Paper Cassette
Paper Jam Problems in the Rear Cover
Paper Jams in the Automatic Document Feeder
Parent topic:
Paper Feeding Problems
If you have problems feeding paper, try these solutions:
• Place the product on a flat surface.
• If paper does not feed for printing, remove it. Then reload it in the middle of the rear paper feed. Slide the edge guide against the edge of the paper, making sure that the paper stack is not above the arrow mark on the edge guide.
• If multiple pages feed at once, remove the paper, fan the edges to separate the sheets, and reload it.
• If paper jams when you load only one or two sheets, try loading more sheets at a time. Do not load more than the recommended number of sheets.
• If paper jams when you print on both sides of the paper, try loading fewer sheets.
• Make sure your paper meets the specifications for your product.
• Make sure the paper size and paper type settings on the control panel are correct.
• Try cleaning the paper path.
281
• For best results, follow these guidelines:
• Use new, smooth, high-quality paper that is not curled, creased, old, too thin, or too thick.
• Load paper in the rear paper feed printable side up.
• Follow any special loading instructions that came with the paper.
Parent topic:
Related references
Paper Jam Problems in the Paper Cassette
Paper Jam Problems in the Rear Cover
Paper Jam Problems Inside the Product
Paper Jams in the Automatic Document Feeder
Paper Jam Problems Inside the Product
If you see a message that paper has jammed inside the product, follow the steps here or on the LCD screen to clear the jam.
1. Cancel the print job, if necessary.
2. Remove any jammed paper from the rear paper feed slot and the ADF.
3. Lift the scanner unit and remove any jammed paper inside.
282
Caution: Do not touch the flat white cable or the translucent film inside your product.
4. Close the scanner unit.
283
5. Follow the prompts on the LCD screen to clear any error messages. If you still see a paper jam message, check the other paper jam solutions.
Parent topic:
Related references
Paper Jam Problems in the Paper Cassette
Paper Jam Problems in the Rear Cover
Paper Jams in the Automatic Document Feeder
Paper Jam Problems in the Paper Cassette
If you see a message that paper has jammed in the paper cassette, follow the steps here or on the LCD screen to clear the jam.
1. Cancel the print job, if necessary.
2. Remove both paper cassettes and carefully remove any jammed paper.
284
3. Make sure the paper is loaded under the edge guides and does not stick out from the back of the cassettes.
4. Keep the cassettes flat as you insert them.
5. Follow the prompts on the LCD screen to clear any error messages. If you still see a paper jam message, check the other paper jam solutions.
Parent topic:
Related references
Paper Jam Problems Inside the Product
Paper Jam Problems in the Rear Cover
Paper Jams in the Automatic Document Feeder
Related tasks
Cancelling Printing Using a Product Button
Paper Jam Problems in the Rear Cover
If you see a message that paper has jammed in the rear cover, follow the steps here or on the LCD screen to clear the jam.
1. Cancel the print job, if necessary.
285
2. Press the buttons to release the rear cover and remove it from your product. Carefully remove any jammed paper from inside the product.
3. Remove any jammed paper from inside the rear cover.
286
4. Turn the rear cover over, open the cover, and remove any paper jammed inside.
5. Reattach the rear cover.
6. Follow the prompts on the LCD screen to clear any error messages. If you still see a paper jam message, check the other paper jam solutions.
Parent topic:
Related references
Paper Jam Problems Inside the Product
Paper Jam Problems in the Paper Cassette
Paper Jams in the Automatic Document Feeder
287
Related tasks
Cancelling Printing Using a Product Button
Paper Jams in the Automatic Document Feeder
If you have problems with paper jams in the automatic document feeder (ADF), follow the steps below or on the LCD screen to clear the jam.
1. Cancel the print job, if necessary.
2. Remove your originals from the ADF.
3. Open the ADF cover and carefully remove any jammed paper.
Caution: Make sure you open the ADF cover before removing any jammed paper. Otherwise the product may be damaged.
288
4. Leave the ADF cover open and raise the scanner unit.
5. Press the tabs and remove the document mat.
289
6. Carefully remove any jammed paper.
7. Reattach the document mat, lower the scanner unit, and close the ADF cover.
8. Open the ADF input tray as shown.
290
9. Carefully remove any jammed paper from beneath the ADF input tray.
10. Close the ADF input tray.
11. Reload your originals.
Caution: Do not load the ADF beyond its capacity for your paper size. Also make sure your originals are not bent, folded, or curled and do not have tape, staples, or other materials that could obstruct the feeder.
12. Follow the prompts on the LCD screen to clear any error messages. If you still see a paper jam message, check the other paper jam solutions.
Parent topic:
Related references
Paper Jam Problems Inside the Product
Paper Jam Problems in the Rear Cover
Paper Jam Problems in the Paper Cassette
Related tasks
Cancelling Printing Using a Product Button
Paper Ejection Problems
If you have problems with paper ejecting properly, try these solutions:
• If paper does not eject fully, you may have set the wrong paper size. Cancel printing to eject the paper.
Select the correct paper size when you reprint.
291
• If paper is wrinkled when it ejects, it may be damp or too thin. Load new paper and be sure to select the correct paper type setting when you reprint.
Parent topic:
Related references
Paper or Media Type Settings - Printer Software
Related tasks
Cancelling Printing Using a Product Button
Related topics
Solving Problems Printing from a Computer
Check these sections if you have problems while printing from your computer.
Note: When printing using AirPrint, the available print settings are different from those covered in this manual. See the Apple website for details.
Product Icon Does Not Appear in Windows Taskbar
Parent topic:
Nothing Prints
If you have sent a print job and nothing prints, try these solutions:
• Make sure your product is turned on.
• Make sure any interface cables are connected securely at both ends.
• If you connected your product to a USB hub, make sure it is a first-tier hub. If it still does not print, connect your product directly to your computer instead of the hub.
• Make sure the printer status is not offline or pending.
• Run a product check to see if a test page prints. If the test page prints, check to see if your product software is installed correctly.
292
• Make sure your system meets the requirements for your operating system. If you are printing a highresolution image, you may need more than the minimum requirements. If necessary, increase your system's memory.
• In Windows, make sure your product is selected as the default printer.
• In Windows, make sure the printer port setting matches the printer connection port.
• In Windows, delete all jobs from the Windows Spooler. Click Print Queue on the Maintenance tab in the printer settings window, and cancel any stalled print jobs.
• On a Mac, make sure the printer is added to the printer list.
• On a Mac, make sure the printer is not paused.
Parent topic:
Solving Problems Printing from a Computer
Product Icon Does Not Appear in Windows Taskbar
If you do not see your product icon in the Windows taskbar, first try restarting your computer. If that does not work, try this solution:
1. Do one of the following:
• Windows 10: Click and select (Settings) > Devices > Printers & scanners . Select your product name and select Manage > Printing preferences .
• Windows 8.x
: Navigate to the Apps screen and select Control Panel > Hardware and Sound >
Devices and Printers . Right-click your product name, select Printing Preferences , and select your product name again if necessary.
• Windows 7 : Click and select Devices and Printers . Right-click your product name, select
Printing Preferences , and select your product name again if necessary.
• Windows Vista : Click , select Control Panel , and click Printer under Hardware and Sound .
Right-click your product name, select Printing Preferences , and select your product name again if necessary.
2. Click the Maintenance tab.
3. Click the Extended Settings button.
4. Select Enable EPSON Status Monitor 3 and click OK .
5. Click the Monitoring Preferences button.
6. Click the checkbox for the option that adds the shortcut icon to the taskbar.
7. Click OK to close the open program windows.
293
Parent topic:
Solving Problems Printing from a Computer
Printing is Slow
If printing becomes slow, try these solutions:
• Make sure your system meets the requirements for your operating system. If you are printing a highresolution image, you may need more than the minimum requirements. If necessary, increase your system's memory.
• If you are using Windows 7, close the Devices and Printers window before you print.
• On a Mac, make sure you download and install the Epson printer driver.
• Make sure Quiet Mode is turned off.
• Clear space on your hard drive or run a defragmentation utility to free up existing space.
• Close any programs you are not using when you print.
• If your product is connected to a USB hub, connect it directly to your computer instead.
• If printing becomes slower after printing continuously for a long time, the product may have automatically slowed down to protect the print mechanism from overheating or becoming damaged.
Let the product rest with the power on for 30 minutes, then try printing again.
• If you are printing over a wireless network, factors such as interference, network traffic, or weak signal strength may affect your printing speed.
• If you are printing photos on plain paper, print speed may be reduced to maintain image quality.
For the fastest printing, select the following settings in your product software:
• Make sure the paper type setting matches the type of paper you loaded.
• Turn on any high speed settings in your product software.
• Select a lower print quality setting.
• Make sure the ink drying time has not been increased for double-sided printing.
• Windows : Click the Maintenance or Utility tab, select Extended Settings or Speed and Progress , and select the following settings:
• Always Spool RAW Datatype
• Page Rendering Mode
• Print as Bitmap
• Windows : Select Printer Properties , click the More Options tab, and make sure the High Speed setting is enabled.
294
• Mac : Select System Preferences , select Printers & Scanners , and select your product. Select
Options & Supplies , select Options (or Driver ), and enable the High Speed Printing setting.
• Enable the bidirectional setting on the product control panel ( Settings > Printer Settings >
Bidirectional ).
If printing is still slow and you are using Windows 7 or Windows Vista, try the following:
1. Click and select Computer or My Computer . Double-click the C: drive and open these folders:
ProgramData > EPSON > PRINTER .
Note: If you do not see the ProgramData folder, open the Organize menu and select Folder and search options . In the window that appears, click the View tab, select Show hidden files, folders, and drives in the Advanced settings list, and click OK .
2. Right-click the EPAUDF01.AUD
file and select Delete .
3. Restart your computer and try printing again.
Parent topic:
Solving Problems Printing from a Computer
Related references
Paper or Media Type Settings - Printer Software
Related tasks
Selecting Basic Print Settings - Windows
Selecting Extended Settings - Windows
Selecting Basic Print Settings - Mac
Selecting Printing Preferences - Mac
Solving Page Layout and Content Problems
Check these sections if you have problems with the layout or content of your printed pages.
Note: When printing using AirPrint, the available print settings are different from those covered in this manual. See the Apple website for details.
295
Border Appears on Borderless Prints
Incorrect Image Size or Position
Parent topic:
Inverted Image
If your printed image is inverted unexpectedly, try these solutions:
• Turn off any mirror or inversion settings in your printing application.
• Turn off the Mirror Image , Flip horizontally , or Reverse page orientation settings in your printer software. (This option has different names, depending on your operating system version.)
Parent topic:
Solving Page Layout and Content Problems
Related tasks
Selecting Additional Layout and Print Options - Windows
Selecting Basic Print Settings - Mac
Too Many Copies Print
Make sure that the Copies setting in your printing program or printer software is not set for multiple copies.
Parent topic:
Solving Page Layout and Content Problems
Blank Pages Print
If blank pages print unexpectedly, try these solutions:
• Make sure you selected the correct paper size settings in your printing program and printer software.
• If a blank page exists in a document you are printing and you want to skip printing it, select the Skip
Blank Page setting in your printer software, if available.
• Run a print head nozzle check to see if any of the nozzles are clogged. Then clean the print head, if necessary.
• Make sure your product is selected as the printer in your printing program.
Parent topic:
Solving Page Layout and Content Problems
296
Related concepts
Related tasks
Selecting Basic Print Settings - Windows
Selecting Extended Settings - Windows
Selecting Basic Print Settings - Mac
Incorrect Margins on Printout
If your printed page has incorrect margins, try these solutions:
• Make sure you selected the correct paper size settings in your printing program and printer software.
• Make sure you selected the correct margins for your paper size in your printing program.
• Make sure your paper is positioned correctly for feeding into the product.
• When placing originals on the scanner glass, align the corner of the original with the corner indicated by the arrow. If the edges of the copy are cropped, move the original slightly away from the corner.
• Clean the scanner glass and the document cover. If there is dust or stains on the glass, the copy area may extend to include the dust or stains.
You can use the preview option in your printer software to check your margins before you print.
Parent topic:
Solving Page Layout and Content Problems
Related tasks
Selecting Basic Print Settings - Windows
Selecting Basic Print Settings - Mac
Selecting Page Setup Settings - Mac
Border Appears on Borderless Prints
If you see a border on borderless prints, try these solutions:
• Make sure you are printing on a compatible borderless paper type and size.
Note: For custom paper sizes, make sure you select a supported borderless page width.
• Windows : Make sure you selected the Borderless setting in your printer software.
297
• Mac : Make sure you selected the Borderless checkbox or a paper size with a Borderless option in your printer software.
• Adjust the Expansion setting to adjust the amount of image expansion on the edges of borderless prints.
• Make sure the image size and the paper size are set correctly; if the image is small, the enlargement may not be enough to cover the paper.
Parent topic:
Solving Page Layout and Content Problems
Related references
Borderless Paper Type Compatibility
Related tasks
Selecting Basic Print Settings - Windows
Selecting Basic Print Settings - Mac
Selecting Page Setup Settings - Mac
Incorrect Characters Print
If incorrect characters appear in your prints, try these solutions before reprinting:
• Make sure any cables are securely connected at both ends.
• In Windows, delete all jobs from the Windows Spooler. Click Print Queue on the Maintenance tab in the printer settings window, and cancel any stalled print jobs.
• If your product is connected to a USB hub, connect it directly to your computer instead.
• If your computer entered sleep mode the last time you printed, the next print job after your computer exits sleep mode may contain garbled characters. Print your document again.
• If incorrect characters still appear in your prints, try connecting your product using a different cable.
Parent topic:
Solving Page Layout and Content Problems
Incorrect Image Size or Position
If your printed image is the wrong size or in the wrong position, try these solutions:
• Make sure you selected the correct paper size and layout settings in your printing program and printer software.
• Make sure you selected the correct paper size on the control panel.
• Make sure your paper is positioned correctly for feeding into the printer.
• Slide the edge guides against the edges of the paper.
298
• Clean the scanner glass and document cover.
• If the edges of a copy are cropped, slightly move the original away from the edges of the scanner glass.
• Make sure you selected the correct margins for your paper size in your printing program.
You can use the preview option in your printer software to check your margins before you print.
Parent topic:
Solving Page Layout and Content Problems
Related tasks
Selecting Basic Print Settings - Windows
Selecting Basic Print Settings - Mac
Selecting Page Setup Settings - Mac
Related topics
Slanted Printout
If your printouts are slanted, try these solutions:
• Slide the edge guides against the edges of the paper.
• Select a higher print quality setting in your printer software.
• Turn off any high speed settings in your product software.
• Align the print head.
• Adjust the print quality.
• Make sure the product is not printing while tilted or at an angle.
Parent topic:
Solving Page Layout and Content Problems
Related tasks
Aligning the Print Head Using the Product Control Panel
Selecting Basic Print Settings - Windows
Selecting Basic Print Settings - Mac
Related topics
299
Solving Print Quality Problems
Check these sections if your printouts have problems with print quality, but your image looks fine on your computer screen.
White or Dark Lines in Printout
Faint Printout or Printout Has Gaps
Parent topic:
White or Dark Lines in Printout
If you notice white or dark lines in your prints (also called banding), try these solutions before you reprint:
• Run a nozzle check to see if any of the print head nozzles are clogged. Then clean the print head, if necessary.
• Make sure the paper type setting matches the type of paper you loaded.
• Make sure you loaded the printable side of the paper correctly for your product.
• Turn off any high speed settings in your product software.
• Align the print head.
• Adjust the print quality in the product software.
• If you continue to see horizontal bands or streaks in your printouts after cleaning the print head and adjusting the print quality, make print quality adjustments for each paper type.
• You may need to replace the ink cartridges.
Parent topic:
Solving Print Quality Problems
Related concepts
Related references
Paper or Media Type Settings - Printer Software
Related tasks
Aligning the Print Head Using the Product Control Panel
Selecting Additional Layout and Print Options - Windows
300
Selecting Printing Preferences - Mac
Removing and Installing Ink Cartridges
Related topics
Blurry or Smeared Printout
If your printouts are blurry or smeared, try these solutions:
• Make sure your paper is not damp, curled, old, or loaded incorrectly in your product.
• Use a support sheet with special paper, or load special paper one sheet at a time.
• Make sure your paper meets the specifications for your product.
• Use Epson papers to ensure proper saturation and absorption of genuine Epson inks.
• Make sure the paper type setting in your product software matches the type of paper you loaded.
• Make sure you loaded the printable side of the paper correctly for your product.
• If you are printing on thick paper or envelopes, turn on the Thick Paper setting from the control panel or select Thick Paper and Envelopes in the Extended Settings of the printer software. (Turning this setting on will decrease print speed.)
• If you are printing on thick paper or envelopes, make sure you select the appropriate settings.
• Remove each sheet from the output tray as it is printed.
• Avoid handling printouts on glossy paper right after printing to allow the ink to set.
• Turn off any high speed settings in your product software.
• If you print on both sides of a sheet of paper, smudges may appear on the reverse side of heavily saturated or dark images. If one side of a sheet will contain a lighter image or text, print that side first.
Make sure the ink has dried before reloading the paper to print on the other side. Adjust the density and/or ink drying time settings.
• If printed copies are smeared, lower the copy density setting on the product control panel.
• Run a nozzle check to see if any of the print head nozzles are clogged. Then clean the print head, if necessary.
• Align the print head.
• Adjust the print quality in the product software.
• Clean the paper path.
301
• Do not press too hard on the original or the document cover when you are scanning originals on the scanner glass.
• Clean the scanner glass.
• Clean the ADF.
Note: Your product will not operate properly while tilted at an angle. Place it on a flat, stable surface that extends beyond the base of the product in all directions.
Parent topic:
Solving Print Quality Problems
Related concepts
Related references
Related tasks
Aligning the Print Head Using the Product Control Panel
Selecting Basic Print Settings - Windows
Selecting Additional Layout and Print Options - Windows
Selecting Basic Print Settings - Mac
Selecting Printing Preferences - Mac
Selecting Double-sided Printing Settings - Windows
Selecting Double-sided Printing Settings - Mac
Related topics
Faint Printout or Printout Has Gaps
If your printouts are faint or have gaps, try these solutions:
• Run a nozzle check to see if any of the print head nozzles are clogged. Then clean the print head, if necessary.
• The ink cartridges may be old or low on ink, and you may need to replace them.
• Make sure the paper type setting matches the type of paper you loaded.
302
• Make sure your paper is not damp, curled, old, or loaded incorrectly in your product.
• Align the print head.
• Adjust the print quality in the product software.
• Clean the paper path.
Parent topic:
Solving Print Quality Problems
Grainy Printout
If your printouts are grainy, try these solutions:
• Make sure you loaded the printable side of the paper correctly for your product.
• Select a higher print quality setting and turn off any high speed settings in your product software.
• Run a nozzle check to see if any of the print head nozzles are clogged. Then clean the print head, if necessary.
• Align the print head.
• Adjust the print quality.
• You may need to increase the image resolution or print a smaller size; see your software documentation.
Note: Images from the Internet may be low resolution and not result in a high quality printout.
• If you enlarged the image size in an image-editing program, you need to increase the image resolution setting to retain a high image quality. Increase the image resolution by the same amount you increase the image size. For example, if the image resolution is 300 dpi (dots per inch) and you will double the image size for printing, change the resolution setting to 600 dpi.
Note: Higher resolution settings result in larger file sizes, which take longer to process and print.
Consider the limitations of your computer system when selecting a resolution, and select the lowest possible resolution that produces acceptable quality to keep file sizes manageable.
Parent topic:
Solving Print Quality Problems
Related concepts
303
Related references
Paper or Media Type Settings - Printer Software
Related tasks
Aligning the Print Head Using the Product Control Panel
Removing and Installing Ink Cartridges
Related topics
Incorrect Colors
If your printouts have incorrect colors, try these solutions:
• Make sure the paper type setting matches the paper you loaded.
• Make sure the Black/Grayscale or Grayscale setting is not selected in your printer software.
• Select EPSON Standard as the Color Mode (Windows) or Mode (Mac) setting in the printer software.
• Run a nozzle check to see if any of the print head nozzles are clogged. Then clean the print head, if necessary.
• The ink cartridges may be old or low on ink, and you may need to replace them.
• After you print, the colors in your printout need time to set as the ink dries. During this time, the colors may look different than you expect. To speed up drying time, do not stack your printouts on top of each other.
• Your printed colors can never exactly match your on-screen colors. However, you can use a color management system to get as close as possible. Try using the color management options in your printer software.
• Try selecting a different Color Management setting on the More Options tab of the printer software, and changing the Scene Correction setting to something other than Auto Correct .
• For best results, use genuine Epson paper.
• On the product control panel, change the Enhance setting from Auto to another option, or select
Enhance Off .
Parent topic:
Solving Print Quality Problems
Related concepts
304
Related tasks
Selecting Basic Print Settings - Windows
Selecting Additional Layout and Print Options - Windows
Selecting Basic Print Settings - Mac
Removing and Installing Ink Cartridges
Solving Scanning Problems
Check these solutions if you have problems scanning with your product.
Scanning Software Does Not Operate Correctly
Parent topic:
Scanning Software Does Not Operate Correctly
If your scanning software does not operate correctly, try these solutions:
• Make sure your computer has adequate memory and meets the system requirements for your operating system.
• Make sure your computer is not running in a power-saving mode, such as sleep or standby. If so, wake your system and restart your scanning software.
• If you upgraded your operating system but did not reinstall your scanning software, try reinstalling it.
• In Windows, make sure your product is listed as a valid device in the Scanners and Cameras control panel.
Parent topic:
Related concepts
Uninstall Your Product Software
Related references
305
Cannot Start Epson Scan 2
If you cannot start Epson Scan 2, try these solutions:
• Make sure your product is turned on and any interface cables are securely connected at both ends.
• If your product is connected to a USB hub, connect it directly to your computer instead.
• If you scan at a high resolution over a network, a communication error may occur. Lower the resolution.
• If you are scanning with the ADF, check that the document cover and ADF cover are closed.
• If you are scanning with the ADF, make sure that you are not in Photo Mode .
• Make sure Epson Scan 2 is selected as your scanning program.
• Make sure your computer is not running in a power-saving mode, such as sleep or standby. If so, wake your system and restart Epson Scan 2.
• Check the connection setting and test the connection using Epson Scan 2 Utility:
Windows 10: Click and select EPSON > Epson Scan 2 Utility . Make sure the correct product is selected. If necessary, select the Other tab and click Reset .
Windows 8.x
: Navigate to the Apps screen and select Epson Scan 2 Utility . Make sure the correct product is selected. If necessary, select the Other tab and click Reset .
Windows (other versions) : Click or Start > All Programs or Programs > EPSON > Epson Scan
2 > Epson Scan 2 Utility . Make sure the correct product is selected. If necessary, select the Other tab and click Reset .
Mac : Open the Applications folder, click Epson Software , and click Epson Scan 2 Utility . Make sure the correct product is selected. If necessary, select the Other tab and click Reset .
• Make sure you do not have multiple versions of Epson Scan 2 installed. If you do, uninstall both versions and install one version.
• If you upgraded your operating system but did not reinstall Epson Scan 2, try reinstalling it.
Parent topic:
Related references
Additional Scanning Settings - Advanced Settings Tab
Related tasks
Starting a Scan from a Scanning Program
Placing Originals on the Scanner Glass
Placing Originals in the Automatic Document Feeder
306
Scanning is Slow
If scanning becomes slow, try these solutions:
• Scan your original at a lower resolution, if possible.
• Make sure your system meets the requirements for your operating system. If you are scanning a highresolution image, you may need more than the minimum requirements. If necessary, increase your system's memory or reduce the resolution.
• In Epson Scan 2, open the Configuration screen and turn off Quiet Mode on the Scan tab.
• The scanning speed may be reduced depending on the image adjustment features in Epson Scan 2.
• If you are scanning over a wireless network, factors such as interference, network traffic, or weak signal strength may affect your scanning speed.
Parent topic:
Solving Scanned Image Quality Problems
Check these sections if a scanned image on your computer screen has a quality problem.
Image Consists of a Few Dots Only
Line of Dots Appears in All Scanned Images
Straight Lines in an Image Appear Crooked
Image Colors are Patchy at the Edges
Back of Original Image Appears in Scanned Image
Ripple Patterns Appear in an Image
Scanned Image Colors Do Not Match Original Colors
Scanned Image Edges are Cropped
Parent topic:
Image Consists of a Few Dots Only
If your scanned image consists only of a few dots, try these solutions:
• Make sure you placed your original for scanning facing the correct way.
• If the Image Type setting is Black & White , adjust the Threshold and scan again.
307
• Remove any lint or dirt from your original.
Parent topic:
Solving Scanned Image Quality Problems
Related tasks
Line of Dots Appears in All Scanned Images
If a line of dots appears in all your scanned images, clean the scanner glass with a soft, dry, lint-free cloth or use a small amount of glass cleaner on the cloth, if necessary. Paper towels are not recommended.
Caution: Do not spray glass cleaner directly on the scanner glass.
If you are scanning from the ADF, try cleaning the ADF and scan again.
Parent topic:
Solving Scanned Image Quality Problems
Related tasks
Straight Lines in an Image Appear Crooked
If straight lines in an original appear crooked in a scanned image, make sure to place your original straight when you scan it.
If you are scanning from the ADF, try cleaning the ADF and scan again.
Parent topic:
Solving Scanned Image Quality Problems
Related tasks
Placing Originals on the Scanner Glass
Image is Distorted or Blurry
If a scanned image appears distorted or blurry, try these solutions:
• Do not move your original or your product during scanning.
• Your product will not operate properly while tilted at an angle. Place your product on a flat, stable surface that extends beyond its base in all directions.
• Adjust these Epson Scan 2 settings (if available) and try scanning again:
• Increase the Resolution setting.
308
• If the Image Type setting is Black & White , adjust the Threshold setting.
• If the Image Type setting is Color or Grayscale , select the Unsharp Mask setting.
• If the Image Type setting is Black & White , select Text Enhancement . If the Image Type setting is
Color or Grayscale , change the Text Enhancement setting to High .
Parent topic:
Solving Scanned Image Quality Problems
Image Colors are Patchy at the Edges
If you are scanning a thick or warped original, cover its edges with paper to block external light as you scan it.
Parent topic:
Solving Scanned Image Quality Problems
Image is Scanned Upside-Down
Your product scans using the Auto Photo Orientation setting. This setting checks the preview image for faces, the sky, and other features, and then correctly rotates the photo when it is scanned, if necessary.
If your photo is not oriented correctly using this option, you can turn Auto Photo Orientation off and scan again. When Photo Mode is selected, select Thumbnail Options from the Main Settings tab.
Select On or Off and scan your document again.
Note: Auto Photo Orientation does not work when you scan newspapers, magazines, documents, illustrations, or line art, or images smaller than 2 inches (5.1 cm) on any side.
Parent topic:
Solving Scanned Image Quality Problems
Image is Too Dark
If your scanned image is too dark, try these solutions:
• If the Image Type is set to Color or Grayscale , adjust the Brightness setting.
• Check the brightness and contrast settings of your computer monitor.
Parent topic:
Solving Scanned Image Quality Problems
Related tasks
309
Back of Original Image Appears in Scanned Image
If an image from the back of a thin original appears in your scanned image, try these solutions:
• Place a piece of black paper on the back of the original and scan it again.
• Adjust these Epson Scan 2 settings (if available) and try scanning again:
• Select the Advanced Settings tab and adjust the Brightness setting.
• If the Image Type is set to Black & White , select Text Enhancement . If the Image Type is set to
Color or Grayscale , change the Text Enhancement setting to High .
Parent topic:
Solving Scanned Image Quality Problems
Ripple Patterns Appear in an Image
You may see a ripple pattern (called a moiré) in scanned images of printed documents. This is caused by interference from differing pitches in the scanner's screen and your original's halftone screen. To reduce this effect, adjust these Epson Scan 2 settings (if available) and try scanning again:
• Select the Descreening setting.
• Select a lower Resolution setting.
Parent topic:
Solving Scanned Image Quality Problems
Related tasks
Scanned Image Colors Do Not Match Original Colors
Printed colors can never exactly match the colors on your computer monitor because printers and monitors use different color systems: monitors use RGB (red, green, and blue) and printers typically use
CMYK (cyan, magenta, yellow, and black).
Check the color matching and color management capabilities of your computer, display adapter, and the software you are using to see if they are affecting the palette of colors you see on your screen.
To adjust the colors in your scanned image, adjust these Epson Scan 2 settings (if available) and try scanning again:
• If the Image Type setting is Color or Grayscale , adjust the Contrast setting.
• If the Image Type setting is Black & White or Grayscale , adjust the Color Enhance setting.
Parent topic:
Solving Scanned Image Quality Problems
310
Related tasks
Scanned Image Edges are Cropped
If the edges of a scanned image are cropped, make sure your original is placed correctly for scanning. If necessary, move your original away from the edges of the scanner glass slightly.
Parent topic:
Solving Scanned Image Quality Problems
Solving Memory Card Problems
Check these solutions if you have problems using memory cards with your product.
Memory Card Does Not Fit Into a Slot
Cannot View or Print Photos from a Memory Card or Device
Cannot Transfer Photos to or from a Memory Card or Device
Parent topic:
Memory Card Does Not Fit Into a Slot
If a memory card does not fit properly in a slot, do not force it in. You may need to use an adapter with your memory card.
Parent topic:
Related references
Related tasks
Cannot View or Print Photos from a Memory Card or Device
If you cannot view or print photos from a memory card or USB device inserted in your product, try these solutions:
• Make sure your memory card or device is compatible with the product.
• Make sure the files on your memory card or device are in the correct format.
• If you have too many photos on your memory card or device, you may not see all the photos you expect or may be prompted to select a group of photos by date. Reduce the number of photos on your card or select one group of photos at a time. Check the specifications for the maximum number of photos.
311
Parent topic:
Related references
External USB Device Specifications
Related tasks
Connecting and Printing from a Camera
Related topics
Viewing or Printing from a USB Flash Drive or External Device
Cannot Transfer Photos to or from a Memory Card or Device
If you have problems transferring photos to or from a memory card or USB device inserted in your product, try these solutions:
• Make sure your memory card or device is compatible with the product.
• Make sure your product is securely connected to your computer.
• If you are transferring photos to a memory card, check the memory card's write-protect tab to make sure it is set to allow writing to the card.
• Make sure that the file sharing setting for your product is set correctly.
Parent topic:
Related references
External USB Device Specifications
Solving USB Device Problems
Check these solutions if you have problems using USB devices with your product.
Cannot View or Print from a USB Device
Cannot Save Files on a USB Device
Cannot Transfer Files To or From a USB Device
Parent topic:
312
Cannot View or Print from a USB Device
If you cannot view or print photos or documents from a USB device connected to your product, try these solutions:
• Make sure memory devices are enabled on the product.
• Make sure your device is compatible with the product.
• Make sure the files on your device are in the correct format.
• If you see an exclamation point on the photo selection screen, the image file format is not supported.
Parent topic:
Related references
External USB Device Specifications
USB Device File Specifications
Related tasks
Setting Up File Sharing for Photo Transfers from Your Computer
Viewing and Printing Photos from the LCD Screen
Cannot Save Files on a USB Device
If you cannot save files on a USB device connected to your product, try these solutions:
• Make sure the device is not write-protected.
• Make sure the device has enough available space.
• Make sure memory devices are enabled on your product.
• Make sure the device is compatible with the product.
Parent topic:
Related references
External USB Device Specifications
Related tasks
Setting Up File Sharing for Photo Transfers from Your Computer
313
Cannot Transfer Files To or From a USB Device
If you have problems transferring files to or from a USB device connected to your product, try these solutions:
• Make sure your device is compatible with the product.
• Make sure the device is not write-protected.
• Make sure your product is securely connected to your computer.
• Make sure that the file sharing setting for your product is enabled.
Parent topic:
Related references
External USB Device Specifications
Related topics
Transferring Photos on a Memory Card
Solving CD/DVD Problems
Check these sections if you have problems printing on a CD/DVD with your product.
Parent topic:
CD/DVD Jam Problems
If a CD/DVD has jammed in the product and you see an error message, you need to remove the
CD/DVD tray:
1. Cancel the print job from your computer, if necessary.
2. Slowly pull the CD/DVD tray out of the product.
3. Clear the error message.
4. If an error is still displayed, turn off the product, wait a moment, and then turn it back on.
5. If you are unable to remove the CD/DVD tray, contact Epson for support.
314
Parent topic:
Image Not Centered on CD/DVD
If your printed image is not centered on the disc, do one of the following:
• If you are printing from a computer, adjust the print position using the Epson Print CD software. See the Epson Print CD help utility for details.
• If you are printing from the control panel, adjust the printing position using the product menus.
Parent topic:
Related tasks
Printing Your CD/DVD Design - Windows
Printing Your CD/DVD Design - Mac
Printing Photos from a Memory Card Onto a CD/DVD
Ink Smears on CD/DVD
If you notice smeared ink on your disc, try these solutions:
• Make sure you are printing on ink jet-printable CDs or DVDs and that the surface of the disc is dry.
• Handle printed discs carefully and let them dry for 24 hours before inserting them in a drive.
• Adjust the print quality using the Epson Print CD software. See the Epson Print CD help utility for details.
Parent topic:
Related tasks
Printing Your CD/DVD Design - Windows
Printing Your CD/DVD Design - Mac
Faint Image on CD/DVD
If your printed image is faint, adjust the print quality using the Epson Print CD software. See the Epson
Print CD help utility for details.
Parent topic:
Related tasks
Printing Your CD/DVD Design - Windows
Printing Your CD/DVD Design - Mac
315
Uninstall Your Product Software
If you have a problem that requires you to uninstall and re-install your software, follow the instructions for your operating system.
Uninstalling Product Software - Windows
Uninstalling Product Software - Mac
Parent topic:
Uninstalling Product Software - Windows
You can uninstall and then re-install your product software to solve certain problems.
1.
Turn off the product.
2.
Disconnect any interface cables.
3.
Do one of the following:
• Windows 10 : Click and select (Settings) > Apps > Apps & features . Then select the program you want to uninstall and select Uninstall .
• Windows 8.x
: Navigate to the Apps screen and select Control Panel > Programs > Programs and Features . Select the uninstall option for your Epson product, then select Uninstall/Change .
Note: If you see a User Account Control window, click Yes or Continue .
Select your product again, if necessary, then select OK , and click Yes to confirm the uninstallation.
• Windows (other versions) : Click or Start , and select All Programs or Programs . Select
EPSON , select your product, then click EPSON Printer Software Uninstall .
Note: If you see a User Account Control window, click Yes or Continue .
In the next window, select your product and click OK . Then follow any on-screen instructions.
4.
Do one of the following to uninstall Epson Scan 2, then follow any on-screen instructions:
• Windows 10 : Select Epson Scan 2 and click Uninstall .
• Windows 8.x
/ Windows 7 / Windows Vista: Select Epson Scan 2 and click Uninstall/Change .
5.
Restart your computer, then see the Start Here sheet to re-install your software.
316
Note: If you find that re-installing your product software does not solve a problem, contact Epson.
Parent topic:
Uninstall Your Product Software
Uninstalling Product Software - Mac
In most cases, you do not need to uninstall your product software before re-installing it. However, you can download the Uninstaller utility from the Epson support website to uninstall your product software as described here.
Note: If you find that re-installing your product software does not solve a problem, contact Epson.
1.
To download the Uninstaller utility, visit epson.com/support (U.S.), epson.ca/support (Canada), or epson.com.jm/support (Caribbean) and select your product.
2.
Click Downloads .
3.
Select your operating system, click Utilities , locate the Uninstaller utility, and click Download .
4.
Run the file you downloaded.
5.
Double-click the Uninstaller icon.
6.
In the Epson Uninstaller screen, select the checkbox for each software program you want to uninstall.
7.
Click Uninstall .
8.
Follow the on-screen instructions to uninstall the software.
9.
Reinstall your product software.
Note: If you uninstall the printer driver and your product name remains in the Print & Fax , Print & Scan , or Printers & Scanners window, select your product name and click the – (remove) icon to remove it.
Parent topic:
Uninstall Your Product Software
Where to Get Help
If you need to contact Epson for technical support services, use the following support options.
Internet Support
Visit Epson's support website at epson.com/support (U.S.), epson.ca/support (Canada), or epson.com.jm/support (Caribbean) and select your product for solutions to common problems. You can
317
download drivers and documentation, get FAQs and troubleshooting advice, or e-mail Epson with your questions.
Speak to a Support Representative
Before you call Epson for support, please have the following information ready:
• Product name
• Product serial number (located on a label on the product)
• Proof of purchase (such as a store receipt) and date of purchase
• Computer configuration
• Description of the problem
Then call:
• U.S.: (562) 276-4382, 6 AM to 8 PM, Pacific Time, Monday through Friday, and 7 AM to 4 PM, Pacific
Time, Saturday
• Canada: (905) 709-3839, 6 AM to 8 PM, Pacific Time, Monday through Friday, and 7 AM to 4 PM,
Pacific Time, Saturday
Days and hours of support are subject to change without notice. Toll or long distance charges may apply.
Purchase Supplies and Accessories
You can purchase genuine Epson ink and paper at epson.com
(U.S. sales), epson.ca
(Canadian sales), or epson.com.jm
(Caribbean sales). You can also purchase supplies from an Epson authorized reseller.
To find the nearest one, call 800-GO-EPSON (800-463-7766) in the U.S. or 800-807-7766 in Canada.
Parent topic:
318
Technical Specifications
These sections list the technical specifications for your product.
Note: Epson offers a recycling program for end of life Epson products. Please go to this site (U.S) or this site (Canada) for information on how to return your Epson products for proper disposal.
Automatic Document Feeder (ADF) Specifications
External USB Device Specifications
Network Interface Specifications
Safety and Approvals Specifications
Windows System Requirements
To use your product and its software, your computer should use one of these Microsoft operating systems:
• Windows 10
• Windows 8.x
• Windows 7
• Windows Vista
319
Note: For the latest product software available for your operating system, visit the Epson support site at epson.com/support (U.S.), epson.ca/support (Canada), or epson.com.jm/support (Caribbean), select your product, and select Downloads .
Parent topic:
Mac System Requirements
To use your product and its software, your Mac should use one of these operating systems:
• macOS 10.13.x
• macOS 10.12.x
• OS X 10.11.x
• OS X 10.10.x
• OS X 10.9.x
• OS X 10.8.x
• OS X 10.7.x
• OS X 10.6.8
Note: For the latest product software available for your operating system, visit the Epson support site at epson.com/support (U.S.), epson.ca/support (Canada), or epson.com.jm/support (Caribbean), select your product, and select Downloads .
Parent topic:
Paper Specifications
Note: Since the quality of any particular brand or type of paper may be changed by the manufacturer at any time, Epson cannot guarantee the quality of any non-Epson brand or type of paper. Always test a sample of paper stock before purchasing large quantities or printing large jobs.
320
Single-sheets
Size
Paper types
Weight
A4 (8.3 × 11.7 inches [210 × 297 mm])
A6 (4.1 × 5.8 inches [105 × 148 mm])
Letter (8.5 × 11 inches [216 × 279 mm])
Legal (8.5 × 14 inches [216 × 356 mm])
4 × 6 inches (102 × 152 mm)
5 × 7 inches (127 × 178 mm)
8 × 10 inches (203 × 254 mm)
3.5 × 5 inches (89 × 127 mm)
16:9 wide (4 × 7.1 inches [102 × 181 mm])
Half Letter (5.5 × 8.5 inches [140 × 216 mm])
Plain paper
Note: Your product also supports compatible papers distributed by
Epson. See the link at the end of this topic for a list of compatible
Epson papers.
Plain paper: 17 lb (64 g/m 2 ) to 24 lb (90 g/m 2 )
Envelopes
Size
Paper types
Weight
No. 10 (4.1 × 9.5 inches [105 × 241 mm])
Plain bond paper
20 lb (75 g/m 2 ) to 24 lb (90 g/m 2 )
Parent topic:
Related references
Borderless Paper Type Compatibility
321
Printable Area Specifications
Note: When printing borderless, quality may decline in the expanded printable area.
Single sheets - borders
1 Top/bottom/left/right margins: 0.12 inch (3 mm) minimum
2 Reduced print quality area/top: 1.61 inches (41 mm) minimum
3 Reduced print quality area/bottom: 1.46 inches (37 mm) minimum
Single sheets - borderless
322
1 Reduced print quality area/top: 1.73 inches (44 mm) minimum
2 Reduced print quality area/bottom: 1.57 inches (40 mm) minimum
Envelopes
1 Right/left margins: 0.12 inch (3 mm) minimum
2 Top/bottom margins: 0.20 inch (5 mm) minimum
3 Reduced print quality area/right: 0.71 inch (18 mm) minimum
4 Reduced print quality area/left: 1.61 inches (41 mm) minimum
CD/DVD
323
1 Minimum inner margin: 0.71 inch (18 mm)
2 Inner reduced print quality area: 1.69 inches (43 mm)
3 Outer reduced print quality area: 4.57 inches (116 mm)
4 Maximum outer margin: 4.72 inches (120 mm)
Parent topic:
Scanning Specifications
Scanner type
Photoelectric device
Document size
Scanning resolution
Image data
Light source
Flatbed, color
CIS
Maximum: 8.5 × 11.7 inches (216 × 297 mm)
Scanner glass: US letter or A4
1200 dpi (main scan)
2400 dpi (sub scan)
Color:
48 bits per pixel internal (16 bits per pixel per color)
24 bits per pixel external (8 bits per pixel per color)
Grayscale:
16 bits per pixel internal
8 bits per pixel external
Black and white:
16 bits per pixel internal
1 bit per pixel external
LED
Parent topic:
324
Automatic Document Feeder (ADF) Specifications
Paper size
Paper type
Paper weight
Sheet feeding capacity
US letter, legal, or A4 size
Plain paper
17 lb (64 g/m 2 ) to 25 lb (95 g/m 2 )
Total thickness: 0.13 inch (3.3 mm)
Approximately 30 sheets (US letter or A4) or 10 sheets (legal)
Parent topic:
Ink Cartridge Specifications
Note: This printer is designed for use with Epson cartridges only, not third-party cartridges or ink. Other brands of ink supplies are not compatible and, if described as compatible, may not function properly or continuously. Such restrictions can be avoided with some other printers such as Epson EcoTank cartridge-free printers.
The included initial cartridges are designed for reliable printer setup and cannot be used as replacement cartridges or resold. After setup, the remaining ink is available for printing. Yields are based on ISO
24711 in default mode, printing continuously. Yields vary due to print images, settings, and temperatures. Printing infrequently or primarily with one color reduces yields. All cartridges must be installed with ink for printing and printer maintenance. For print quality, some ink remains in replaced cartridges.
Color
Cartridge life
Temperature
Black, Cyan, Magenta, Yellow, Photo Black
Opened package: 6 months
Unopened package: do not use if the date on the package has expired
Storage: –22 to 104 °F (–30 to 40 °C)
1 month at 104 °F (40 °C)
Ink freezes at 3.2 °F (–16 °C)
Ink thaws and is usable after 3 hours at 77 °F (25 °C)
Note: For best printing results, use up a cartridge within 6 months of opening the package.
325
Parent topic:
Related concepts
Memory Card Specifications
Note: Cards marked with an asterisk (*) require an adapter; consult your adapter documentation for details on using it.
Compatible types and maximum capacities
Media format DCF
SD: 2GB
SDHC: 32GB
SDXC: 64GB miniSD*: 2GB miniSDHC*: 32GB microSD*: 2GB microSDHC*: 32GB microSDXC*: 64GB
JPEG with the exif Version 2.31 standard taken by digital cameras that are DCF (Design rule for Camera File system) version 1.0 or 2.0
compliant; photos stored in built-in digital camera memory are not supported
Parent topic:
Dimension Specifications
Height
Width
Depth
Stored: 7.5 inches (191 mm)
Printing: 8.7 inches (221 mm)
Stored: 15.4 inches (390 mm)
Printing: 15.4 inches (390 mm)
Stored: 13.3 inches (339 mm)
Printing: 23.5 inches (598 mm)
326
Weight
(without ink cartridges, power cord, or CD/DVD tray)
18.5 lb (8.4 kg)
Parent topic:
Electrical Specifications
Power supply rating
Rated frequency range
Rated current
Power consumption
100 to 120 V
50/60 Hz
0.7 A
Standalone copying: Approximately 16 W (ISO/IEC24712)
Ready mode: Approximately 8.3 W
Sleep mode: Approximately 1.4 W
Power off mode: Approximately 0.2 W
Parent topic:
Environmental Specifications
Temperature
Humidity
(without condensation)
Operating: 50 to 95 °F (10 to 35 °C)
Storage: –4 to 104 °F (–20 to 40 °C)
1 month at 104 °F (40 °C)
Operating: 20 to 80% RH
Storage: 5 to 85% RH
Parent topic:
Interface Specifications
Interface type Hi-Speed USB (Device Class for computers)
Hi-Speed USB (for external USB devices and PictBridge)
327
Note: Epson cannot guarantee the operation of externally connected devices.
Parent topic:
External USB Device Specifications
Do not use devices with the following requirements:
• Dedicated driver
• Security settings (password, encryption, etc.)
• Built-in USB hub
Note: Use only external storage devices with independent AC power sources. External storage devices that are powered via USB are not recommended. Epson cannot guarantee the operation of externally connected devices.
CD-R, DVD-R, or Bluray drive CD-ROM/CD-R: 700MB maximum capacity
DVD-ROM/DVD-R: 4.7GB maximum capacity
1.3GB maximum capacity Magneto-optical drive
Hard disk and USB flash drives
2TB maximum capacity
Formatted in FAT, FAT32, or exFAT.
Parent topic:
Network Interface Specifications
Wireless LAN standard
Wireless security
Frequency band
Communication mode
IEEE 802.11 b/g/n
WEP (64/128 bit)
WPA2-PSK (AES); WPA2 compliant with support for WPA/WPA2
Personal
2.4 GHz
Infrastructure mode
Wi-Fi Direct (Simple AP); not supported for IEEE802.11b
328
Maximum radio frequency power transmitted
Security protocol
20 dBm (EIRP)
SSL/TLS
HTTPS Server/Client, IPPS
Note: Wireless LAN standard complies with either IEEE 802.11 b/g or IEEE 802.11 b/g/n, depending on purchase location.
Parent topic:
Safety and Approvals Specifications
United States
Canada
Safety: UL60950-1
EMC: FCC part 15 Subpart B class B
Safety: CAN/CSA C22.2 No. 60950-1
EMC: CAN/CSA-CEI/IEC CISPR 22 Class B
This equipment contains the following wireless module:
• Manufacturer: Seiko Epson Corporation.
• Type: J26H006
This product conforms to Part 15 of FCC Rules and RSS-210 of the IC Rules. Epson cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.
To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and operated so that the radiator is kept at least 7.9 inches (20 cm) or more away from a person's body (excluding extremities: hands, wrists, feet and ankles).
Parent topic:
329
Notices
Check these sections for important notices about your product.
Note: Epson offers a recycling program for end of life Epson products. Please go to this site (U.S) or this site (Canada) for information on how to return your Epson products for proper disposal.
Important Privacy Notice (Printer Serial Number)
Binding Arbitration and Class Waiver
Important Safety Instructions
Before using your Epson product, read and follow these safety instructions.
General Product Safety Instructions
Ink Cartridge Safety Instructions
Wireless Connection Safety Instructions
LCD Screen Safety Instructions
Parent topic:
General Product Safety Instructions
• Be sure to follow all warnings and instructions marked on the product.
• Use only the type of power source indicated on the product's label.
• Use only the power cord that comes with the product. Use of another cord may cause fires or shock.
Do not use the cord with any other equipment.
• Make sure the AC power cord meets the relevant local safety standard.
• Place the product near a wall outlet where the plug can be easily unplugged.
• Avoid plugging the product into an outlet on the same circuit as a photo copier or air control system that regularly switches on and off, or on an outlet controlled by a wall switch or timer.
330
• Do not let the power cord become damaged or frayed. Place it to avoid abrasions, cuts, fraying, crimping, and kinking. Do not place objects on top of it and do not allow it to be stepped on or run over.
Be careful to keep the cord straight at each end.
• If you use an extension cord with the product, make sure the total ampere rating of the devices plugged into the extension cord does not exceed the cord's ampere rating. Also, make sure the total ampere rating of all devices plugged into the wall outlet does not exceed the wall outlet's ampere rating.
• Always turn off the product using the power button, and wait until the power light stops flashing before unplugging the product or cutting off power to the electrical outlet.
• If you will not be using the product for a long period, unplug the power cord from the electrical outlet.
• Place the product on a flat, stable surface that extends beyond its base in all directions. It will not operate properly if it is tilted or at an angle.
• Allow space behind the product for the cables, and space above the product so that you can fully raise the document cover.
• Leave enough space in front of the product for the paper to be fully ejected.
• Avoid locations that are subject to rapid changes in heat or humidity, shocks or vibrations, or dust.
• Do not place or store the product outdoors.
• Do not place the product near excessive heat sources or in direct sunlight.
• Leave enough room around the product for sufficient ventilation. Do not block or cover openings in the case or insert objects through the slots.
• Keep the product away from potential sources of electromagnetic interference, such as loudspeakers or the base units of cordless telephones.
• Keep your product at least 8.7 inches (22 cm) away from cardiac pacemakers to prevent your product's radio waves from affecting the operation of the pacemaker.
• When connecting the product to a computer or other device with a cable, ensure the correct orientation of the connectors. Each connector has only one correct orientation. Inserting a connector in the wrong orientation may damage both devices connected by the cable.
• Do not touch the flat white cable inside the product.
• Do not move the print head by hand; this may damage the product.
• Do not put your hand inside the product while it is printing.
• Do not spill liquid on the product or use the product with wet hands.
331
• Do not use aerosol products that contain flammable gases inside or around the product. Doing so may cause fire.
• Do not press too hard on the document table when placing originals.
• Do not open the scanner section while the product is copying, printing, scanning, or performing any other functions.
• Be careful not to trap your fingers when closing the document cover or scanner.
• Except as specifically explained in your documentation, do not attempt to service or disassemble the product yourself.
• Unplug the product and refer servicing to qualified service personnel under the following conditions: if the power cord or plug is damaged; if liquid has entered the product; if the product has been dropped or the case damaged; if the product does not operate normally or exhibits a distinct change in performance. Adjust only those controls that are covered by the operating instructions.
• Leave the ink cartridges installed. Removing the cartridges can dehydrate the print head and may prevent the product from printing.
• Before transporting the product, make sure that the print head is in the home (far right) position and the ink cartridges are in place.
• When storing or transporting the product, do not tilt it, stand it on its side, or turn it upside down; otherwise ink may leak.
Parent topic:
Ink Cartridge Safety Instructions
• Keep ink cartridges out of the reach of children and do not drink the ink.
• Be careful when you handle used ink cartridges; there may be ink remaining around the ink supply port. If ink gets on your skin, wash it off with soap and water. If it gets in your eyes, flush them immediately with water. If ink gets in your mouth, see a doctor immediately.
• Do not put your hand inside the product or touch any cartridges during printing.
• Do not allow dust or foreign objects to get inside the ink cartridge holder or you may not be able to print. Carefully remove any dust or foreign objects from the holder before installing ink cartridges and printing.
• Install a new ink cartridge immediately after removing an expended one. Leaving cartridges uninstalled can dry out the print head and may prevent the product from printing.
• Do not touch the green IC chip on the side of the cartridge. This may prevent normal operation.
332
• Do not shake, squeeze, or drop cartridges after opening their packages and do not tear the cartridge labels; this can cause them to leak.
• If you remove an ink cartridge for later use, recap the ink cartridge using the cap that came with it to prevent the ink from drying out and to protect the surrounding area from getting smeared by ink.
• Use an ink cartridge before the date printed on its package.
• Do not dismantle an ink cartridge. This could damage the print head.
• Do not disassemble the ink cartridges; you may get ink in your eyes or on your skin.
• Store ink cartridges in a cool, dark place.
• After bringing an ink cartridge inside from a cold storage site, allow it to warm up at room temperature for at least three hours before using it.
• Store ink cartridges with their labels facing up. Do not store cartridges upside down.
Parent topic:
Wireless Connection Safety Instructions
Radio waves from this product may adversely affect the operation of medical equipment or automatically controlled devices, such as pacemakers, automatic doors or fire alarms. When using this product near such devices or inside a medical facility, follow the directions from authorized staff members at the facility, and follow all posted warnings and directions on the device to avoid causing an accident.
Parent topic:
LCD Screen Safety Instructions
• Use only a dry, soft cloth to clean the LCD screen. Do not use liquid or chemical cleansers.
• If the LCD screen is damaged, contact Epson. If the liquid crystal solution gets on your hands, wash them thoroughly with soap and water. If the liquid crystal solution gets into your eyes, flush them immediately with water. If discomfort or vision problems remain after a thorough flushing, see a doctor immediately.
• Do not press too hard on the LCD screen or subject it to heavy impacts.
• Do not use a pointy or sharp object, such as a pen or your fingernail, to operate the LCD screen.
• If the LCD screen chips or cracks, do not touch or attempt to remove the broken pieces; contact Epson for support.
• Do not subject your product to sudden changes in temperature or humidity; this may cause condensation to develop inside the LCD screen and degrade its performance.
Parent topic:
333
Important Privacy Notice (Printer Serial Number)
As part of setup, your product's serial number will be sent to a secure Epson server so that you can be eligible to participate in programs we may offer from time to time, including the Epson ink replenishment program. You will have a separate opportunity to consent to participating in such programs.
If you have any questions concerning this process, you can contact us by using the Privacy Feedback
Form , or you can write to:
Epson America, Inc.
Attn: Privacy Coordinator
3840 Kilroy Airport Way
Long Beach, CA 90806-2469
Parent topic:
FCC Compliance Statement
For United States Users
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio and television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING
The connection of a non-shielded equipment interface cable to this equipment will invalidate the FCC
Certification or Declaration of this device and may cause interference levels which exceed the limits established by the FCC for this equipment. It is the responsibility of the user to obtain and use a shielded equipment interface cable with this device. If this equipment has more than one interface connector, do
334
not leave cables connected to unused interfaces. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.
For Canadian Users
CAN ICES-3(B)/NMB-3(B)
Parent topic:
Binding Arbitration and Class Waiver
1. DISPUTES, BINDING INDIVIDUAL ARBITRATION, AND WAIVER OF CLASS ACTIONS AND
CLASS ARBITRATIONS
1.1
Disputes . The terms of this Section 1 shall apply to all Disputes between you and Epson. The term
"Dispute" is meant to have the broadest meaning permissible under law and includes any dispute, claim, controversy or action between you and Epson arising out of or relating to this Agreement, Epson branded products (hardware and including any related software), or other transaction involving you and
Epson, whether in contract, warranty, misrepresentation, fraud, tort, intentional tort, statute, regulation, ordinance, or any other legal or equitable basis. "DISPUTE" DOES NOT INCLUDE IP CLAIMS, or more specifically, a claim or cause of action for (a) trademark infringement or dilution, (b) patent infringement,
(c) copyright infringement or misuse, or (d) trade secret misappropriation (an "IP Claim"). You and Epson also agree, notwithstanding Section 1.6,that a court, not an arbitrator, may decide if a claim or cause of action is for an IP Claim.
1.2
Binding Arbitration . You and Epson agree that all Disputes shall be resolved by binding arbitration according to this Agreement.
ARBITRATION MEANS THAT YOU WAIVE YOUR RIGHT TO A JUDGE
OR JURY IN A COURT PROCEEDING AND YOUR GROUNDS FOR APPEAL ARE LIMITED .
Pursuant to this Agreement, binding arbitration shall be administered by JAMS, a nationally recognized arbitration authority, pursuant to its code of procedures then in effect for consumer related disputes, but excluding any rules that permit joinder or class actions in arbitration (for more detail on procedure, see
Section 1.6 below). You and Epson understand and agree that (a) the Federal Arbitration Act (9 U.S.C.
§1, et seq.) governs the interpretation and enforcement of this Section 1, (b) this Agreement memorializes a transaction in interstate commerce, and (c) this Section 1 shall survive termination of this
Agreement.
1.3
Pre-Arbitration Steps and Notice . Before submitting a claim for arbitration, you and Epson agree to try, for sixty (60) days, to resolve any Dispute informally. If Epson and you do not reach an agreement to resolve the Dispute within the sixty (60) days), you or Epson may commence an arbitration. Notice to
Epson must be addressed to: Epson America, Inc., ATTN: Legal Department, 3840 Kilroy Airport Way,
Long Beach, CA 90806 (the "Epson Address"). The Dispute Notice to you will be sent to the most recent address Epson has in its records for you. For this reason, it is important to notify us if your address changes by emailing us at [email protected] or writing us at the Epson Address above. Notice of
335
the Dispute shall include the sender's name, address and contact information, the facts giving rise to the
Dispute, and the relief requested (the "Dispute Notice"). Following receipt of the Dispute Notice, Epson and you agree to act in good faith to resolve the Dispute before commencing arbitration.
1.4
Small Claims Court . Notwithstanding the foregoing, you may bring an individual action in the small claims court of your state or municipality if the action is within that court's jurisdiction and is pending only in that court.
1.5
WAIVER OF CLASS ACTIONS AND CLASS ARBITRATIONS. YOU AND EPSON AGREE THAT
EACH PARTY MAY BRING DISPUTES AGAINST THE OTHER PARTY ONLY IN AN INDIVIDUAL
CAPACITY, AND NOT AS A PLAINTIFF OR CLASS MEMBER IN ANY CLASS OR
REPRESENTATIVE PROCEEDING, INCLUDING WITHOUT LIMITATION FEDERAL OR STATE
CLASS ACTIONS, OR CLASS ARBITRATIONS. CLASS ACTION LAWSUITS, CLASS-WIDE
ARBITRATIONS, PRIVATE ATTORNEY-GENERAL ACTIONS, AND ANY OTHER PROCEEDING
WHERE SOMEONE ACTS IN A REPRESENTATIVE CAPACITY ARE NOT ALLOWED.
ACCORDINGLY, UNDER THE ARBITRATION PROCEDURES OUTLINED IN THIS SECTION, AN
ARBITRATOR SHALL NOT COMBINE OR CONSOLIDATE MORE THAN ONE PARTY'S CLAIMS
WITHOUT THE WRITTEN CONSENT OF ALL AFFECTED PARTIES TO AN ARBITRATION
PROCEEDING.
1.6
Arbitration Procedure . If you or Epson commences arbitration, the arbitration shall be governed by the rules of JAMS that are in effect when the arbitration is filed, excluding any rules that permit arbitration on a class or representative basis (the "JAMS Rules"), available at http://www.jamsadr.com
or by calling
1-800-352-5267, and under the rules set forth in this Agreement. All Disputes shall be resolved by a single neutral arbitrator, and both parties shall have a reasonable opportunity to participate in the selection of the arbitrator. The arbitrator is bound by the terms of this Agreement. The arbitrator, and not any federal, state or local court or agency, shall have exclusive authority to resolve all disputes arising out of or relating to the interpretation, applicability, enforceability or formation of this Agreement, including any claim that all or any part of this Agreement is void or voidable. Notwithstanding this broad delegation of authority to the arbitrator, a court may determine the limited question of whether a claim or cause of action is for an IP Claim, which is excluded from the definition of "Disputes" in Section 1.1
above. The arbitrator shall be empowered to grant whatever relief would be available in a court under law or in equity. The arbitrator may award you the same damages as a court could, and may award declaratory or injunctive relief only in favor of the individual party seeking relief and only to the extent necessary to provide relief warranted by that party's individual claim. In some instances, the costs of arbitration can exceed the costs of litigation and the right to discovery may be more limited in arbitration than in court. The arbitrator's award is binding and may be entered as a judgment in any court of competent jurisdiction.
You may choose to engage in arbitration hearings by telephone. Arbitration hearings not conducted by telephone shall take place in a location reasonably accessible from your primary residence, or in Orange
County, California, at your option.
336
a) Initiation of Arbitration Proceeding. If either you or Epson decides to arbitrate a Dispute, both parties agree to the following procedure:
(i) Write a Demand for Arbitration. The demand must include a description of the Dispute and the amount of damages sought to be recovered. You can find a copy of a Demand for Arbitration at http://www.jamsadr.com
("Demand for Arbitration").
(ii) Send three copies of the Demand for Arbitration, plus the appropriate filing fee, to: JAMS, 500 North
State College Blvd., Suite 600 Orange, CA 92868, U.S.A.
(iii) Send one copy of the Demand for Arbitration to the other party (same address as the Dispute
Notice), or as otherwise agreed by the parties.
b) Hearing Format. During the arbitration, the amount of any settlement offer made shall not be disclosed to the arbitrator until after the arbitrator determines the amount, if any, to which you or Epson is entitled.
The discovery or exchange of non-privileged information relevant to the Dispute may be allowed during the arbitration.
c) Arbitration Fees. Epson shall pay, or (if applicable) reimburse you for, all JAMS filings and arbitrator fees for any arbitration commenced (by you or Epson) pursuant to provisions of this Agreement.
d) Award in Your Favor. For Disputes in which you or Epson seeks $75,000 or less in damages exclusive of attorney's fees and costs, if the arbitrator's decision results in an award to you in an amount greater than Epson's last written offer, if any, to settle the Dispute, Epson will: (i) pay you $1,000 or the amount of the award, whichever is greater; (ii) pay you twice the amount of your reasonable attorney's fees, if any; and (iii) reimburse you for any expenses (including expert witness fees and costs) that your attorney reasonably accrues for investigating, preparing, and pursuing the Dispute in arbitration. Except as agreed upon by you and Epson in writing, the arbitrator shall determine the amount of fees, costs, and expenses to be paid by Epson pursuant to this Section 1.6d).
e) Attorney's Fees. Epson will not seek its attorney's fees and expenses for any arbitration commenced involving a Dispute under this Agreement. Your right to attorney's fees and expenses under Section
1.6d) above does not limit your rights to attorney's fees and expenses under applicable law; notwithstanding the foregoing, the arbitrator may not award duplicative awards of attorney's fees and expenses.
1.7
Opt-out. You may elect to opt-out (exclude yourself) from the final, binding, individual arbitration procedure and waiver of class and representative proceedings specified in this
Agreement by sending a written letter to the Epson Address within thirty (30) days of your assent to this Agreement (including without limitation the purchase, download, installation of the
Software or other applicable use of Epson Hardware, products and services) that specifies (i) your name, (ii) your mailing address, and (iii) your request to be excluded from the final, binding individual arbitration procedure and waiver of class and representative proceedings specified in this Section 1. In the event that you opt-out consistent with the procedure set forth above, all other terms shall continue to apply, including the requirement to provide notice prior to litigation.
337
1.8
Amendments to Section 1 . Notwithstanding any provision in this Agreement to the contrary, you and Epson agree that if Epson makes any future amendments to the dispute resolution procedure and class action waiver provisions (other than a change to Epson's address) in this Agreement, Epson will obtain your affirmative assent to the applicable amendment. If you do not affirmatively assent to the applicable amendment, you are agreeing that you will arbitrate any Dispute between the parties in accordance with the language of this Section 1 (or resolve disputes as provided for in Section 1.7, if you timely elected to opt-out when you first assented to this Agreement).
1.9
Severability . If any provision in this Section 1 is found to be unenforceable, that provision shall be severed with the remainder of this Agreement remaining in full force and effect.
The foregoing shall not apply to the prohibition against class or representative actions as provided in Section 1.5. This means that if Section 1.5 is found to be unenforceable, the entire Section 1 (but only Section 1) shall be null and void.
Parent topic:
Trademarks
EPSON ® is a registered trademark, EPSON Exceed Your Vision is a registered logomark, and Epson
Connect TM is a trademark of Seiko Epson Corporation.
Epson Store SM is a service mark of Epson America, Inc.
Epson iPrint TM and Remote Print TM are trademarks of Seiko Epson Corporation.
Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries.
Apple, App Store, AirPrint, AirPrint logo, iPad, iPhone, iPod touch, Mac, macOS, and OS X are trademarks of Apple Inc., registered in the U.S. and other countries.
Google ® is a registered trademark and Android TM , Chromebook TM , Gmail TM , Google Chrome TM , Google
Cloud Print TM , Google Drive TM , and Google Play TM are trademarks of Google LLC.
Wi-Fi Direct ® is a registered trademark of Wi-Fi Alliance ® .
General Notice: Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Epson disclaims any and all rights in those marks.
Parent topic:
338
Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. The information contained herein is designed only for use with this Epson product. Epson is not responsible for any use of this information as applied to other products.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation's operating and maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson
Approved Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic interference that occurs from the use of any interface cables other than those designated as Epson approved Products by Seiko Epson Corporation.
This information is subject to change without notice.
libTIFF Software Acknowledgment
A Note Concerning Responsible Use of Copyrighted Materials
Default Delay Times for Power Management for Epson Products
Parent topic:
libTIFF Software Acknowledgment
Copyright © 1988-1997 Sam Leffler
Copyright © 1991-1997 Silicon Graphics, Inc.
Permission to use, copy, modify, distribute, and sell this software and its documentation for any purpose is hereby granted without fee, provided that (I) the above copyright notices and this permission notice appear in all copies of the software and related documentation, and (ii) the names of Sam Leffler and
Silicon Graphics may not be used in any advertising or publicity relating to the software without the specific, prior written permission of Sam Leffler and Silicon Graphics.
339
THE SOFTWARE IS PROVIDED "AS-IS" AND WITHOUT WARRANTY OF ANY KIND, EXPRESS,
IMPLIED OR OTHERWISE, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL SAM LEFFLER OR SILICON GRAPHICS BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR ANY DAMAGES
WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER OR NOT
ADVISED OF THE POSSIBILITY OF DAMAGE, AND ON ANY THEORY OF LIABILITY, ARISING OUT
OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
Parent topic:
A Note Concerning Responsible Use of Copyrighted Materials
Epson encourages each user to be responsible and respectful of the copyright laws when using any
Epson product. While some countries' laws permit limited copying or reuse of copyrighted material in certain circumstances, those circumstances may not be as broad as some people assume. Contact your legal advisor for any questions regarding copyright law.
Parent topic:
Default Delay Times for Power Management for Epson Products
This product will enter sleep mode after a period of nonuse. This is to ensure that the product meets
Energy Star standards of energy efficiency. More energy savings can be achieved by setting the time to sleep to a shorter interval.
Parent topic:
Copyright Attribution
© 2018 Epson America, Inc.
8/18
CPD-55773
Parent topic:
340
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
Key Features
- Compact wireless all-in-one: Print, scan, copy
- Mobile printing: Freedom to print and scan from almost anywhere
- Automatic Document Feeder: Scan and copy mutiple documents
- Flexible paper trays: Two front-loading trays and a rear feed
- 10.9cm interactive touchscreen: Easy navigation and PC-free photo printing from a memory card
Related manuals
advertisement
