Rimage AutoPrinter™
User Guide
Rimage Corporation
201 General Mills Blvd, Golden
Valley, MN 55427, USA
Toll Free +1.800.445.8288
Rimage Europe GmbH
Albert-Einstein-Straße 26
63128 Dietzenbach, GERMANY
Tel +49 (0)6074.8521.0
Rimage Japan Co., Ltd.
4F Arai #38 Bldg.,
2-7-1 Hamamatsu-cho,
Minato-ku, Tokyo 105-0013 JAPAN
Tel +81.3.6452.8780
Rimage Taiwan
2F.-7, No. 508, Sec. 5,
Zhongxiao East Road., Xinyi Dist.,
Taipei City 110, TAIWAN
Tel +886.2.2726.0100
Rimage Information
Technology (Shanghai)
Co., Ltd.
RM # 206, 207, 2F
No.1 FuXing Zhong Road
HuangPu District
Shanghai, 200025 CHINA
Tel +86.021.5887.8905
Rimage Corporation reserves the right to make improvements to the equipment and software described in this document at any time without any prior notice. Rimage Corporation reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Rimage Corporation to notify any person or organization of such revisions or changes.
This document may contain links to web sites that were current at the time of publication, but may have moved or become inactive since. This document may contain links to sites on the Internet that are owned and operated by third parties. Rimage Corporation is not responsible for the content of any such third-party site.
© 2020, Rimage Corporation
Rimage® and Everest ® are registered trademarks of the Rimage Corporation. AutoPrinter™ and Prism™ are trademarks of the Rimage Corporation.
Windows ® is a registered trademark of Microsoft Corporation.
All other trademarks and registered trademarks are the property of their respective owners.
The most recent version of this document can be found at www.rimage.com/support .
110656-000-O For more information visit www.rimage.com/support
Contents
Introduction
............................................................................ 1
About this User Guide ..................................................................................
1
About your Product ......................................................................................
1
Unpacking and Setup Instructions ...............................................................
1
Important Information
............................................................ 2
Support Contact Information .......................................................................
2
Learn More Online .......................................................................................
2
Technical Support and Product Updates ......................................................
2
Optical Disc Recording Software Disclaimer .................................................
2
Safety and Compliance Information .............................................................
3
Safety Precautions ................................................................................................
3
Compliance Information .......................................................................................
4
Identify the Parts of the AutoPrinter
........................................ 5
Front View ....................................................................................................
5
Back View .....................................................................................................
6
Operator Panel .............................................................................................
7
Operate the AutoPrinter
.......................................................... 8
Install the Carousel .......................................................................................
8
Power On and Off the AutoPrinter ...............................................................
8
Load and Unload Discs .................................................................................
9
Load the Discs ......................................................................................................
9
Unload the Discs...................................................................................................
9
Reset the AutoPrinter ..................................................................................
9
Set Printing Preferences ...............................................................................
9
Maintain the AutoPrinter
...................................................... 10
Install the Ribbons ......................................................................................
10
Cleaning Method and Schedule .................................................................
10
110656-000-O For more information visit www.rimage.com/support
Introduction
This manual provides the information needed to operate and identify the parts of the AutoEverest and AutoPrism III AutoPrinter. To set up your
AutoPrinter and install the CD Designer™ Software Suite, refer to the set up and installation guide included with your product.
For technical information, visit www.rimage.com/support .
Important!
Your Rimage AutoPrinter™ system may not look exactly like the model featured in this user guide.
About this User Guide
• While we try to maintain all versions of our manuals and documentations, please note that the English version found on our web site always contains the most up-to-date information.
• Unless otherwise indicated, all Windows navigation statements are
Windows 10 paths. Other Windows operating system navigation may differ slightly.
• These notes and symbols are used throughout the manual to help clarify information:
Tip: A Tip suggests alternative methods that may not be obvious and helps you understand the benefits and capabilities of the product.
Important!
• An Important note provides information essential to the completion of a task.
•
•
Important supplemental information.
You can disregard information in a Tip and still complete a task, but do not disregard an Important note.
Caution: A Caution indicates that failure to observe this guideline could result in loss or damage to the equipment, product, software, or data.
Warning!
A Warning indicates that failure to follow this guideline could result in bodily injury to personnel operating or maintaining the equipment.
About your Product
The Rimage AutoPrinter is available with either the Everest printer or the
Prism III printer. For specific information about your printer, refer to the
Everest or Prism printer user guide that shipped with your product.
Tip: The term ‘AutoPrinter’ is used throughout this user guide to refer to both the AutoEverest and the AutoPrism. The terms ‘AutoEverest’ and
‘AutoPrism’ are used only to refer to either product specifically.
Unpacking and Setup Instructions
Unpacking and installation instructions are included with the Rimage
AutoPrinter. Refer to the setup and installation guide included with your
Rimage AutoPrinter.
110656-000-O For more information visit www.rimage.com/support 1
Important Information
This section provides support contact information, and cautions and warnings, for the Rimage AutoPrinter.
Technical Specifications for this product can be found at www.rimage.com/support .
Support Contact Information
US, Canada, Latin America
Rimage Corporation
201 General Mills Blvd, Golden
Valley, MN 55427, USA
Attn: Rimage Services
Email: [email protected]
Telephone:
North America: 800.553.8312
Mexico/Latin America: 952.946.0004 option 2
Fax: 952.944.7808
Europe
Rimage Europe GmbH
Albert-Einstein-Straße 26
63128 Dietzenbach, GERMANY
Asia/Pacific
Rimage Japan Co., Ltd.
4F Arai #38 Bldg.,
2-7-1 Hamamatsu-cho,
Minato-ku, Tokyo 105-0013, JAPAN
Rimage Taiwan
2F.-7, No. 508, Sec. 5
Zhongxiao East Rd., Xinyi Dist.,
Taipei City 110, TAIWAN
Rimage China
RM # 206, 207, 2F
No.1 FuXing Zhong Road
HuangPu District
Shanghai, 200025 CHINA
Contact Rimage Services
Website: www.rimage.com/support
110656-000-O
Email: [email protected]
Telephone: +49 (0)6074.8521.0
Fax: +49 (0)6074.8521.100
When you contact Rimage
Services, please provide:
• System serial number and software version
• Functional and technical description of the problem
• Exact error message received
Copy and record the following information from your Rimage product for future reference.
Note: Make sure you update the Serial
Number anytime you receive a replacement system .
Serial Number:
Product Name:
Date of Purchase:
Learn More Online
At www.rimage.com/support , you can experience Rimage’s world-class
Support and Services. From this online site you can access:
• Information about the latest software and firmware updates
• Product specifications
• The latest documents
• Current firmware downloads
Email: [email protected]
Telephone: +81.3.6452.8780
Fax: +81.3.6452.8785
Email: [email protected]
Telephone: +886.2.2726.0100
Technical Support and Product Updates
Rimage offers a variety of service and support options for the Prism III printer including Exchange Services. Please contact your Rimage Value
Added Reseller or Rimage for additional information and pricing.
Email: [email protected] [email protected]
Telephone: +86.021.5887.8905
Optical Disc Recording Software Disclaimer
This Product, Software, or Documentation may be designed to assist you in reproducing material in which you own the copyright or have obtained permission to copy from the copyright owner. Unless you own the copyright or have permission to copy from the copyright owner, you may be violating copyright law and be subject to payment of damages and other remedies.
If you are uncertain about your rights, you should contact your legal advisor. If you are neither in possession of the copyright nor have authorization from the owner of the copyright, unauthorized copying of copyrighted material on an optical disc or any other media violates national and international legislation and can result in severe penalties.
For more information visit www.rimage.com/support 2
Important Information
Safety and Compliance Information
This manual and the indications on the product allow proper and safe operation. The indication marks below help protect you and other persons from injury, and equipment from damage.
Safety Precautions
This manual and the indications on the product allow proper and safe operation. The indication marks below help protect you and other persons from injury, and equipment from damage.
Warnings!
• Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiant exposure.
• Do not disassemble or use tools on a Rimage printer. All service procedures should be performed by a Rimage-authorized technician, or sent in for
Rimage-authorized repair.
• Do not service a Rimage printer with the power cord plugged in the AC outlet.
• The interior of a Rimage printer contains sharp edges.
• Do not use a Rimage printer if it is overheating or an abnormal smell is detected. This may result in a fire and an electric shock. In case of heating or abnormal smell, immediately disconnect the cable from the outlet.
Contact your Rimage-authorized dealer for repairs.
• The front bezel of the Rimage Everest™ printer can be opened by hand. Do not insert your fingers.
• Do not touch the heat roller in a Rimage Everest printer.
Cautions:
• All equipment with AC line voltage, or low DC voltages, such as switches, power supplies, fuses, fans, non-stepper motors, must be replaced with
Rimage-approved components to maintain the safety approval issued by
UL.
• Use only the supplied AC power cord. For more information or to order a new power cord, contact Rimage Customer Service.
• This product is designed for an office environment.
• Allow sufficient free space for opening the printer tray. Do not touch the printer tray while it is moving.
• If the side cover on the Rimage Everest printer is opened while power is supplied, the printer will stop. Do not reach into the printer while it is operating. Do not attempt to bypass the door interlock.
• The Rimage Everest printer has no power switch. Power is disconnected completely by unplugging the cable. Rimage recommends installing the printer in a position that allows immediate disconnection of the power cable. Always hold the plug when disconnecting the cable from the outlet.
• The Rimage Everest printer has a voltage slide switch on the back of the unit. Before use, make sure that it is set to the correct voltage. Please do not use any voltage other than 110VAC or 220VAC. This could result in a fire and an electric shock.
110656-000-O For more information visit www.rimage.com/support 3
Important Information
Compliance Information
Product
Model
Notice for USA
Notice for Canada
Notice for Europe
Notice for Japan
Notice for Australia
AutoPrinter
RAS25
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when this equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.
This product complies with UL 60950-1, 2nd edition.
This Class A digital apparatus complies with Canadian ICES-003 Issue 4:2004. Cet appareil numerigue de la classe A est conforme a la norme NMB-003 du Canade.
This product complies with CAN/CSA-C22.2 No. 60950-1-07, 2nd edition.
This product is in conformity with the EMC Directive (2014/30/EU) and the Low-Voltage Directive (2014/35/EU) through compliance with the following European standards:
IEC 60950:1999, 3rd edition, EN 55022:1998 + A1:2000 + A2:2003, EN 55024:1998 + A1:2001 + A2:2003, EN 61000-3-2:2000
+ A2:2005, EN 61000-3-3:1995 + A1:2001.
The CE mark has been affixed in accordance with the CE Marking Directive 93/68/EEC.
This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology
Equipment (VCCI). If this equipment is used in a domestic environment, radio interference may occur, in which case, the user may be required to take corrective action.
Translation:
この装置は、情報処理装置等電波障害自主規制協議会(VCCI)の基準に基づくクラス
A 情報技術装置です。この装置を家庭環境で使用すると電波妨害を引き起こすことがありま
す。この場合には使用者が適切な対策を講ずるよう要求されることがあります。
This product complies with AS/NZS CISPR 22: 2006.
110656-000-O For more information visit www.rimage.com/support 4
Identify the Parts of the AutoPrinter
This section identifies the different parts of the AutoPrinter. For detailed information about the parts of the Everest or Prism printer, refer the printer user guide that shipped with your product.
Front View
AutoEverest AutoPrism
Lift Arm
Lift Arm
Everest
Printer
Prism
Printer
Printer
Operator
Button
Control
Panel
Printer
Operator
Button
Control
Panel
Operator
Panel
Operator
Panel
Carousel
110656-000-O
Carousel
For more information visit www.rimage.com/support 5
Identify the Parts of the AutoPrinter
Back View
Power
Cord
AutoEverest
Control
Cable
USB
Cable
Serial
Cable
Port
Serial
Cable
Port
USB
Cable
AutoPrism
Power
Cord
Control
Cable
AutoPrinter
Power
Switch
AutoPrinter
Power
Switch
Important! The serial cable is used only for updating the firmware. Do not connect the serial cable to the AutoPrinter during normal operation.
110656-000-O For more information visit www.rimage.com/support 6
Identify the Parts of the AutoPrinter
Operator Panel
The operator panel is located on the front of the
AutoPrinter. It includes an operator button and four indicator lights. (One light is on the operator button.)
The control panel allows you to monitor and control the printer.
The table below identifies the name and function of all parts of the control panel.
Operator Panel Indicators
Image Name Functionality
Carousel indicator light
The Carousel indicator light blinks when the AutoPrinter resumes operation after being paused.
Active indicator light
Power indicator light
The Active indicator light illuminates when the control center (PC) is communicating with the AutoPrinter. The light blinks one time per second when the system is paused and four times per second when the system is waiting for you to reset the bins. Refer to the Reset the AutoPrinter section for more information.
The Power indicator light illuminates when the AutoPrinter is powered on.
Operator
Button
Each time you press the operator button, the carousel rotates to the next bin.
Fault indicator light
The Fault indicator light is located on the operator button and illuminates if an error is detected.
110656-000-O For more information visit www.rimage.com/support 7
Operate the AutoPrinter
This section provides the information needed to operate your Rimage
AutoPrinter.
Install the Carousel
Important!
To prevent errors, install the carousel before operating the software or powering on the AutoPrinter.
1. Slide the carousel into the AutoPrinter so that the shaft slides into the opening of the bearing guide . Refer to the Front View section on page 5 for proper carousel placement.
2. Lower the carousel so that the top support bearing drops into the bearing guide .
3. If necessary, rotate the carousel to seat the carousel securely.
Bearing Guide
Top Support Bearing
Power On and Off the AutoPrinter
Important!
The carousel must be installed before you power on the system.
Refer to the Install the Carousel section.
Tips:
• The Prism printer has a separate power switch. The Prism power switch must be in the On position in order for the printer to power on at the same time as the AutoPrinter.
• The Everest printer does not have a power switch. The Everest printer powers on when the AutoPrinter powers on. The Everest printer takes 1 to 2 minutes to complete initialization
• Press the power switch on the rear of the AutoPrinter to the On position.
The AutoPrinter powers on.
• Press the power switch to the Off position.
The AutoPrinter powers off.
Shaft
Power Switch
110656-000-O For more information visit www.rimage.com/support 8
Operate the AutoPrinter
Load and Unload Discs
You can load up to 100 discs per carousel bin. You may load discs in the bins before installing the carousel.
When the carousel is installed in the AutoPrinter, discs can be installed one bin at a time by using the following procedure
Tip: Use carousel bins 1, 2, and 3 to load blank discs. Bin 4 is used only for outputting completed discs.
Load the Discs
Important!
When you rotate the carousel to load discs, the AutoPrinter pauses. After loading discs in the carousel, you must prompt the AutoPrinter to resume operation. Refer to step 4.
Unload the Discs
Important!
When you rotate the carousel to unload discs, the AutoPrinter pauses. After unloading discs from the carousel, you must prompt the
AutoPrinter to resume operation. Refer to step 4
1. Press the operator button to rotate the carousel and place a bin in a position to unload discs. The AutoPrinter pauses, allowing you to unload discs. The active indicator light blinks.
2. Remove the discs from the bin.
3. Repeat steps 1–2 until the desired bins are empty.
4. Press and hold the operator button for two blinks of the carousel indicator light. The AutoPrinter resumes operation, using the input/ output bin combination that was in place when the AutoPrinter was paused.
5. If necessary, reset the AutoPrinter. Refer to the Reset the AutoPrinter section.
Reset the AutoPrinter
By default, the AutoPrinter is set to use bins 1, 2, and 3 as the input bins, and bin 4 as the output bin.
1. Press the operator button to rotate the carousel and place a bin 1, 2, and 3 in position to load discs. The AutoPrinter pauses, allowing you to load discs. The active indicator light blinks.
2. Place blank discs in the bin.
Important!
Place the discs into the bin with the recording side facing down
Tip: The AutoPrinter begins to picks discs from bin 3. When bin 3 is empty, the AutoPrinter picks discs from bin 2. When bin 2 is empty, the AutoPrinter picks discs from bin 1. The AutoPrinter continues to pick discs in this configuration until all discs have been printed, or the bin configuration is changed.
Tip: Hold the discs by the outer edge so you do not put fingerprints on either the top or the bottom surface of the discs. Fingerprints on the top of a disc can affect printing quality. Rimage recommends wearing lint free gloves.
3. Repeat steps 1–2 until the bins 1, 2, and 3 are filled.
If the default bin configuration is changed and the AutoPrinter needs to be reset, the active indicator light will blink 4 times per second. To reset the
AutoPrinter, press and hold the operator button for 3 blinks of the carousel indicator light.
4. Press and hold the operator button for two blinks of the carousel indicator light. The AutoPrinter resumes operation, using the input/ output bin combination that was in place when the AutoPrinter was paused.
5. If necessary, reset the AutoPrinter. Refer to the Reset the AutoPrinter section.
110656-000-O
Tip: The AutoPrinter can be reset to the default bin configuration at any time.
Set Printing Preferences
Printing preferences allow you to set up your AutoPrinter to produce the best possible labels on your discs. Refer to your Everest or Prism printer user guide for specific printing preferences instructions.
For more information visit www.rimage.com/support 9
Maintain the AutoPrinter
Use the information in this section to keep your AutoPrinter in optimal operating condition.
Install the Ribbons
Tips:
• Before installing ribbons in the Everest or Prism printer, stop any operations.
• To change ribbons in a Prism printer, refer to the Rimage Prism III
Printer User Guide .
• To change ribbons in an Everest printer, refer to the Rimage Everest
Printer User Guide .
Cleaning Method and Schedule
Task
Clean the AutoPrinter
Remove dust from the AutoPrinter and the surrounding work area
Frequency
Once a week
110656-000-O For more information visit www.rimage.com/support 10
advertisement
Related manuals
advertisement
