Machine type: 10097/2566 [B340]
10099/2568 [B540]
10101/3363 [B540p]
10098/2567 [B345]
10100/4749 [B545]
Lenovo
IdeaCentre B3/B5 Series
User Guide
Version 1.0
2012.02
31501557
Important Safety Information
Before using this manual, it is important that you read and understand all of the related safety information for this product. Refer to the Safety and Warranty Guide that you received with this product for the latest safety information. Reading and understanding this safety information reduces the risk of personal injury or damage to your product.
The interface and functions shown in this User Guide are provided for reference only and may differ from actual product appearance. Product design and specifications may be changed without notice.
Danger: Be aware of extremely hazardous or potentially lethal situations.
Attention: Be aware of possible damage to programs, devices, or data.
Note: Pay attention to this important information.
© Copyright Lenovo 2012. All rights reserved.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
© 2012. Lenovo
Contents
Important Safety Information
Chapter 1 Using the Computer Hardware .............................. 1
1.1 Front view of the computer ......................................................2
1.2 Left and right view of the computer .........................................3
1.3 Rear view of the computer .......................................................4
1.4 TV button instructions (selected models only) ..........................5
1.5 Computer stand ......................................................................6
1.6 Connecting your computer ......................................................7
1.7 Important information about using the computer .....................8
1.8 Wired keyboard (selected models only) ..................................10
Chapter 2 Touch screen user instruction ............................. 11
2.1 Touch Screen Calibration .......................................................12
2.2 User Gesture Instructions for the Touch screen ......................12
2.3 Attentions when using the Touch Screen ...............................20
Chapter 3 Using the Onekey TV (selected models only) ..... 23
3.1 Guide to the remote control (selected models only) ................25
3.2 Onekey TV Instructions (ASTC model) (selected models only) ......................................................................................28
3.3 Onekey TV Instructions (DVB-T model) (selected models only) ......................................................................................30
3.4 Onekey TV Instructions (ATV model) (selected models only) ...33
Chapter 4 Using the Rescue System .................................... 35
4.1 OneKey Recovery ..................................................................36
4.2 Driver and Application Installation ..........................................36
4.3 System Setup ........................................................................37
Contents
1
4.4 System Backup .....................................................................38
4.5 System Recovery ..................................................................38
4.6 Create Recovery Disc ............................................................38
Chapter 5 Troubleshooting and Confirming Setup .............. 39
5.1 Troubleshooting Display Problems .........................................40
5.2 Troubleshooting Audio Problems ...........................................41
5.3 Troubleshooting Software Problems.......................................41
5.4 Troubleshooting Problems with Optical Drives and Hard
Disks .....................................................................................42
5.5 Special considerations for troubleshooting Windows .............43
5.6 Performing Daily Maintenance Tasks ......................................44
Chapter 6 Hardware Replacement Guide ............................. 45
6.1 Overview ...............................................................................46
6.2 Replacing hardware ...............................................................49
Appendix. ....................................................................................60
Energy Star Statement .................................................................61
2
Contents
Chapter
Using the Computer Hardware
This chapter contains the following topics:
1
2
Ø Introduction to the computer hardware
Ø Information on computer connections
3
Note: The descriptions in this chapter might be different from what you see on your computer, depending on the computer models and configurations.
4
5
6
User Guide
1
1.1 Front view of the computer
Attention: Be careful not to block any air vents on the computer. Blocked air vents can cause overheating.
1 2
3 4 5 6 7 8
Built-in microphone area
Built-in IR Emitter(do not block)
(selected models only)
Bluetooth status indicator
TV indicator
Volume up
Brightness up
PC mode / HDMI-in / AV-in switch
9 10 11 12 13 14
Camera
Hard Disk Drive Indicator
WIFI status indicator
Volume down
Brightness down
Novo Vision button
Monitor On/Off
Attention: The effective range of the Built-in IR Emitter is 10 feet (3m).
2
User Guide
1.2 Left and right view of the computer
1
2
Optical drive
TV buttons (selected models only)
USB connector
Headphone port
Microphone port
USB connector
Memory card reader
Power button
5
6
3
4
7
8
User Guide
3
1.3 Rear view of the computer
8
7
8
1
2
Ethernet port
USB connectors
HDMI-out connector
HDMI-in connector (selected models only)
AV-IN connectors (selected models only)
TV tuner ports (selected models only)
Power connector
Air vents (do not block)
3 4 5
6
4
User Guide
1.4 TV button instructions (selected models only)
1
2
3
4
5
6
7
Channel up
Channel down
Volume up
Volume down
TV mode menu button
Signal source selection button
TV power On/Off
User Guide
5
1.5 Computer stand
Use the stand to position the display to your preference. It can be rotated between
15º and 40º from the vertical.
Attention:
1. The computer stand must remain installed at all times to ensure maximum system stability.
2. Make sure the angle of the computer is at least 15 degrees from the vertical; otherwise the computer will be unstable and could fall over.
6
User Guide
1.6 Connecting your computer
Note: Your computer may not have all of the connectors described in this section.
1.6.1 Basic connector instructions
Connector
Microphone
Headphone
USB connector
Ethernet connector
Description
Use this connector to attach a microphone to your computer when you want to record sound or if you use speech-recognition software.
Use this connector to attach headphones to your computer when you want to listen to music or other sounds without disturbing anyone.
Use this connector to attach a device that requires a
USB connection.
Use this connector to attach the computer to an
Ethernet-type local area network.
Connects to the HDMI connector on your display or TV.
HDMI connector
(optional)
TV-Tuner connector
(optional)
AV-in connector
(optional)
Connects to an external antenna to view programs using the optional TV tuner card.
Connects to the composite audio and video connectors on your video device.
Note: If your computer is equipped with a wireless keyboard or mouse, follow the installation instructions for those devices.
User Guide
7
1.6.2 Connecting the power cord
Connect the power cord properly to grounded electrical outlets.
1.7 Important information about using the computer
Press the power button on the side of the computer to turn on the computer.
8
User Guide
Note: The buttons at the bottom of the screen are touch buttons. When you touch these, the indicator lights turn on.
Hold the computer tightly when you carry it.
User Guide
9
1.8 Wired keyboard (selected models only)
LVT —— After entering Windows, press this key to launch the LVT (Lenovo
Vantage Technology) program, Lenovo’s pre-loaded Home PC software.
In addition to its own functions, the LVT program will allow you to start other Windows compatible software, specially configured to run on this model of computer.
F2 —— Your computer has the Lenovo Rescue System installed. To learn more about this program, repeatedly press and release the F2 key once turning on the computer until the Lenovo Rescue System open.
10
User Guide
Chapter
Touch screen user instruction
This chapter contains the following topics:
1
2
Ø Touch Screen Calibration
Ø User Gesture Instructions for the Touch screen
Ø Attentions when using the Touch Screen
3
Attention: Only some selected models are equipped with touch screens.
4
5
6
User Guide
11
The monitor has touch capability due to a touch-sensitive screen installed. A touch screen is an input device just like a mouse or a keyboard, and the user’s hand transmits position information via the touch screen to the computer. With this technology, you only need to touch the pictures or words on the computer display lightly with your finger, and the computer will react.
2.1 Touch Screen Calibration
Prior to first use or whenever the touch screen reacts in a different place where you are touching it, start the calibration program. The procedure is as follows:
1. In Windows 7, Select “Start” – “Control Panel”.
2. In Control Panel, select “Hardware and Sound”.
3. In “Hardware and Sound” window, select “Tablet PC Settings”.
4. In “Tablet PC Settings” dialogue, click “Calibrate” button.
2.2 User Gesture Instructions for the Touch screen
The Touch screen supports single touch and rotational movements, enlargement and reduction multi-touch operations, and the user can transmit position information to the computer via touch. The touch screen uses a very low pressure movement recognition method, which only needs the finger to move lightly on the computer display screen or make a simple hand gesture to be detected by the main computer processor.
2.2.1 Basic Hand Gestures
1. Single Click / Double Click
For the item selected on the touch screen, touch it one or two times with finger, to perform a single click or double click operation. This is similar to the action performed by clicking the mouse left button.
12
User Guide
2. Single Finger Right Click
For the item selected on the touch screen, press and hold your finger on the screen until a circle appears. After lifting your finger from the touch screen, a menu bar will pop up, completing the single finger right click operation. This is similar to the action performed by clicking the mouse right button.
User Guide
13
3. Double Finger Right Click
First touch a finger to the screen to select the desired item and hold it there, then touch another finger anywhere nearby on the screen and quickly lift it up again, to complete a double finger right click operation. The area where the first finger is placed can be used to show the right-click menu or perform related operations.
1
2
4. Dragging Movement
First touch your finger on the desired item on the screen and hold it there, then make a dragging movement. This is similar to the click and drag movement you can make with a mouse.
14
User Guide
5. High Speed Slide
If you touch the screen with a single finger and slide it a short distance horizontally
(about 5 cm), then quickly lift it up again, this is called a High Speed Slide, and the screen will show the “Forward” or “Back” icon.
In the default situation, a high speed horizontal sliding movement will execute a forward or back operation. For example: Forward and Back operations for the
IE browser; or Previous and Next slide operations in Windows Photo Viewer slideshow mode.
about 5 FP
6. Rolling Movement
When you move your finger one time vertically (or horizontally) on the touch screen, this is called a Rolling Operation. For example: This operation is similar to moving the scroll wheel on the top of a mouse, and produces the same results as the scroll wheel interface does.
User Guide
15
7. Zoom Operation
Touch two fingers lightly on the desired item on the touch screen, then keeping both fingers on the screen, change the distance between them. By increasing (or decreasing) the distance, you can perform a zoom out (or zoom in) operation. For example: you can enlarge or reduce the picture size in Windows Photo Viewer.
8. Rotation Operation
Use two figures to touch the desired item on the touch screen, then rotate them in the desired direction. For example: you can rotate the picture which is being displayed in Windows Photo Viewer.
16
User Guide
2.2.2 Related Touch Screen Settings
1. Flicks: In the notification area of the taskbar at the bottom of the screen, click on the Flicks icon, and the current Flicks window will appear. Click once anywhere in this window to enter Flicks Training. The user can perform operations according to the advice given on screen.
User Guide
17
2. For more detailed configuration, you can click on the Flicks icon in the notification area of the taskbar at the bottom of the screen, then click on
“ Customize your flicks setting ” in the Flicks pop-up window. In the “ Pen and
Touch ” window, the user can adjust more settings related to “ Pen and Touch ” according to their specific preferences.
On the Flicksmenu you can:
• SelectcommonlyusedFlicksoperationgroups
• Adjustthesensitivityofthetouchscreen
18
User Guide
On the Touch menu you can:
• Enable/disableoptionssuchas“
Use your finger as an input device ” and
“ Enable multi-touch gestures and inking ”.
• Selecttouchactionswhichyouwishtoadjust.Byclickingon“
Settings ”, you can adjust the “ Speed ” and “ Spatial tolerance ” parameters, to match the user’s natural way of double-clicking. You can double-click on the lower right corner of the icon to test this.
• Enable/disabletouchPointer.
Note: Users can access more help information from the Windows “ Help and Support ” menu.
User Guide
19
2.3 Attentions when using the Touch Screen
1. When using it please remember not to tear the screen surface with any sharp object.
2. In order not to affect the normal use of the touch screen, please keep its surface clean and dry, and ensure that your fingers are clean and dry.
3. In order not to affect the precision of positioning on the touch screen, please avoid handling or touching the glass frame of the touch screen by your hands when you are carrying out touching operations.
4. To ensure the safety of users, please clean the screen and frame with a soft cotton cloth after turning the screen off. In order to prevent the remaining water mark from affecting the touch operations, do not wipe it with a damp rag.
5. Please promptly remove any dust accumulated in the four corners of the screen and the screen frame, because this will prevent accumulated dust from affecting the screen’s touch localization. Do not place or drop anything which could obstruct it in the four corners of the screen or any part of its frame, because this could separate the screen from the frame and stop the screen from being able to sense position properly. Please avoid leaving water and dust in the gap between the casing and glass when you are cleaning the frame.
6. Avoid using it in dusty environments, or in very hot or humid conditions. The abrupt change of environmental temprature may in a short time cause on the glass screen inner surface some tiny spray, which will disappear after some time and will not affect the normal use.
Note: When it is used in normal operation, the touch screen process will not affect the running of other computer processes.
20
User Guide
7. The recognition of touch gestures by this product can be influenced by the following factors:
• Touchingthecorrectplaceonthescreen.
• Thespeedofmovement.
• Thetimeintervalfromwhenthescreenwaslasttouched.
Note: To learn accurate hand gesture operations, the user can consult this manual and also the related Windows help content.
8. The touch screen does not function in Rescue System mode.
9. The touch screen also does not function during the startup process, and in
Sleep mode or Safe mode.
User Guide
21
22
User Guide
Chapter
Using the Onekey TV
(selected models only)
This chapter contains the following topics:
Ø Guide to the remote control
Ø Onekey TV Instructions (ASTC model)
Ø Onekey TV Instructions (DVB-T model)
Ø Onekey TV Instructions (ATV model)
1
2
3
4
5
6
User Guide
23
To turn on the Onekey TV
Press the power button on the side of the computer or remote control to turn on the TV.
To turn on the computer
Press the power button on the side of the computer to turn on the computer.
24
User Guide
3.1 Guide to the remote control (selected models only)
Notes:
1. The remote control can only turn on the Onekey TV, it cannot turn on the computer.
2. Use the remote control within 23 feet of the TV.
3. The color and shape may vary depending on the model.
User Guide
25
Button Description
Display and select the available video sources.
Turn the TV on and off.
Alternate the video between the main picture and subpicture.
Alternate the audio between the main picture and subpicture.
Picture in Picture
ATSC & ATV model: Press to select additional channels being broadcast by the same station.
DVB-T model: Enter the password to access a channel locked by the Child Lock function.
Return to the previous channel.
Display information on the TV screen.
Select the picture mode.
Move the cursor to navigate and select options.
Confirm a setting
Press to directly access channels.
Display the main on-screen menu.
Return to the previous menu.
Adjust the volume.
Turn the TV sound off.
Change channels.
Freeze the screen.
C.C. : Control the caption decoder. (ATSC)
SUB : Display digital subtitles. (DVB-T)
Not available on ATV models.
26
User Guide
Button Description
Teletext ON/OFF
Press the colored buttons to operate the Teletext screen.
Press to return to the main index page.
Press to hold the Teletext page when viewing information. Press again to return to automatic page update.
Press repeatedly to display the upper part of the teletext screen, then the lower part, and then to return to full screen.
Press to reveal hidden words e.g. quiz page answers. Press again to hide.
Electronic Programme Guide.
Not available on ATV models.
Change the screen size mode.
Note:
These buttons are usable with
TV Tuner cards installed and in countries that support Teletext functions only.
Change the video source of sub-picture.
Automatically shut off the TV at a preset time.
Not available on this model.
User Guide
27
3.2 Onekey TV Instructions (ASTC model) (selected models only)
Notes:
1. The interface and functions shown in the instructions below are for reference only.
2. The touch function cannot be used in Onekey TV mode.
3. You must be in TV mode to perform these operations.
Scan for channels
Press the MENU button on the remote control, then select Setup Auto Scan to scan for channels and store them in the TV automatically.
Language settings
Press the MENU button on the remote control, then select Setup Language .
28
User Guide
Picture In Picture (PIP) Size
Press the MENU button on the remote control, then select PIP PIP Size to adjust the size of the sub-picture.
Note: When in PIP mode, press the button on the remote control to alternate the video between the main picture and sub-picture.
Record TV
The Onekey TV must be turned off in order to use the recording function. Once it is turned off, use Windows Media Center or the Total Media software in PC mode to record TV programs.
User Guide
29
3.3 Onekey TV Instructions (DVB-T model) (selected models only)
Notes:
1. The interface and functions shown in the instructions below are for reference only.
2. The touch function cannot be used in Onekey TV mode.
3. You must be in TV mode to perform these operations.
Scan for channels
Press the MENU button on the remote control, then select Setup Channels to scan for channels and store them in the TV automatically.
Note: The default password is “8888” . Change the password by using the
Password option.
Note: If a channel is locked using the Child Lock function, press the button to unlock it.
30
User Guide
Language settings
Press the MENU button on the remote control, then select Setup Menu
Language .
Picture In Picture (PIP) Size
Press the MENU button on the remote control, then select PIP PIP Size to adjust the size of the sub-picture.
Note: When in PIP mode, press the button on the remote control to alternate the video between the main picture and sub-picture.
User Guide
31
Password settings
You need to enter the original password before setting a new password or removing the password. The default password is “8888” .
Note: If you forget the password you entered, enter the Super Password
“1357” to set a new password.
Record TV
The Onekey TV must be turned off in order to use the recording function. Once it is turned off, use Windows Media Center or the Total Media software in PC mode to record TV programs.
32
User Guide
3.4 Onekey TV Instructions (ATV model) (selected models only)
Notes:
1. The interface and functions shown in the instructions below are for reference only.
2. The touch function cannot be used in Onekey TV mode.
3. You must be in TV mode to perform these operations.
Scan for channels
1) Press the MENU button on the remote control, then select Setup Auto
Scan to scan for channels and store them in the TV automatically.
2) Press the MENU button on the remote control, then select Setup Manual
Scan to scan for channels and store them in the TV automatically.
User Guide
33
Language settings
Press the MENU button on the remote control, then select Setup Language .
Picture In Picture (PIP) Size
Press the MENU button on the remote control, then select PIP PIP Size to adjust the size of the sub-picture.
Note: When in PIP mode, press the button on the remote control to alternate the video between the main picture and sub-picture.
Record TV
The Onekey TV must be turned off in order to use the recording function. Once it is turned off, use Windows Media Center or the Total Media software in PC mode to record TV programs.
34
User Guide
Chapter
Using the Rescue System
This chapter contains the following topics:
Ø OneKey Recovery
Ø Driver and Application Installation
Ø System Setup
Ø System Backup
Ø System Recovery
Ø Create Recovery Disc
1
2
3
Attention: Using this program will result in loss of data.
• YoucanrestoretheC:driveofthecomputer to factory default settings or to the last system backup status using OneKey Recovery . If you do this, all of the existing data on drive
C:willbelost,butthecontentandformatof the other partitions of the hard disk drive will remain unchanged.
• Ifyouwanttoinstallanoperatingsystemand back it up with OneKey Recovery , you must formattheC:partitioninNTFSformatand installtheoperatingsystemontheC:partition.
Otherwise, the OneKey Recovery system cannot run.
4
5
6
User Guide
35
Note about the service partition:
The files and relevant data used by the rescue system are saved in the service partition. Deleting this partition will make the rescue system unusable. For more detailed information, see the following instructions.
By selecting Control Panel Administrative Tools Computer Management
Disk Management , you can see the service partition, which must not be deleted.
Note: The recovery files and relevant data used by the rescue system are saved in the service partition. If the service partition is deleted or damaged by someone other than authorized Lenovo service personnel, Lenovo will not be liable for any losses arising therefrom in any way.
4.1 OneKey Recovery
OneKey Recovery is an easy-to-use application. You can use it to restore your computer to the system default or to a previously backed up state.
Detailed Operation Procedure
1. Repeatedly press and release the F2 key after turning on the computer until the
Lenovo Rescue System opens, then select OneKey Recovery .
Note:
SystemRecoverywilloverwriteallofthedataontheC:drive.To prevent loss of data, be sure to back up relevant data before performing system recovery.
2. Follow the on-screen instructions to select the backup task you want to restore from and the disk where you want to install the operating system, then press
Next to start the restore.
3. Please wait during the process of system recovery. Do not interrupt the operation during the recovery process.
4. After the system is recovered successfully, the software will prompt you to restart the computer. Restart the computer and start the operating system.
4.2 Driver and Application Installation
The Driver and Application Installation function in the rescue system provides a way for the user to conveniently reinstall all of the Lenovo applications and drivers that were shipped with your Lenovo hardware.
36
User Guide
Method 1: Automatic Installation
Repeatedly press and release the F2 key after turning on the computer until the
Lenovo Rescue System opens, then select Drivers and Application Installation .
Follow the on-screen prompts to install the Lenovo drivers and applications.
Click Install to start installing the Lenovo Drivers and Application Installation software.
The system will restart. After the system has restarted, the installation process will continue until it has completed.
Method 2: Manual Installation
In the Windows system, Click Start All Programs Lenovo Lenovo
Drivers and Application Installation .
After starting the procedure, install all the drivers and software manually by following the prompts.
Notes:
1. Do not install software which is already installed on the computer.
2. Make sure that the Drivers and Application Installation software has been automatically installed before starting the operating system. The manual installation function can only be used after the software has been installed.
4.3 System Setup
System Setup configures the network configuration for the Lenovo Rescue
System to ensure your Rescue System can connect to internet. In addition, System
Setup sets and manages all passwords for the Lenovo Rescue system.
4.3.1 Launch
Repeatedly press and release the F2 key after turning on the computer until the
Lenovo Rescue System opens, then select System Setup .
4.3.2 Network Settings
Depending on the network access mode of the computer, select “ADSL” or “LAN
Connection” in the network connection modes.
1. If you select “ADSL” input the user name and password of the ADSL connection.
2. If you select “LAN connection” configure the IP address and proxy server of the LAN.
User Guide
37
4.3.3 Password Management
Password Management allows you to set and manage the password for Lenovo
Rescue System.
The default password is blank.
Set a password when you access Password Management for the first time. If you don’t want to set a password, access the system directly and use it accordingly.
4.4 System Backup
This backs up your system partition to an image file. In case of a system failure, you can restore your system from this image file.
In the Windows system, click Start All Programs Lenovo Lenovo
Rescue System .
After starting Rescue System, click System Backup to back up your system partition by following the prompts.
4.5 System Recovery
Reboot your computer into the system recovery environment. You can choose to restore to a system backup point or the initial state (factory default settings).
4.6 Create Recovery Disc
Create a bootable recovery disc from the current system. These recovery discs are used to boot your computer and will guide you through the entire restoration process.
In the Windows system, click Start All Programs Lenovo Lenovo
Rescue System .
After starting Rescue System, click Create Recovery Disc to create a bootable recovery disc from the current system.
Follow the on-screen prompts to create a recovery disc.
38
User Guide
Chapter
Troubleshooting and
Confirming Setup
This chapter contains the following topics:
1
2
Ø Troubleshooting and Problem Resolution
Note: The description of the TV tuner card in this manual is only applicable to machines which have the TV tuner card. It does not apply to machines that do not have a TV tuner card.
3
4
5
6
User Guide
39
Solving Problems
Follow these tips when troubleshooting your computer:
• Ifyouaddedorremovedapartbeforetheproblemstarted,reviewthe installation procedures to ensure that the part is correctly installed.
• Ifaperipheraldevicedoesnotwork,ensurethatthedeviceisproperly connected.
• Ifanerrormessageappearsonthescreen,writedowntheexactmessage.This message may help support personnel diagnose and fix the problem(s).
• Ifanerrormessageoccursinaprogram,seetheprogram’sdocumentation.
5.1 Troubleshooting Display Problems
Problem: Blank screen or no image is displayed on the monitor.
Troubleshooting and problem resolution:
Check that the LCD screen has been turned on; If not, press the LCD On/Off button to turn on the LCD.
If still cannot solve the problem, contact to Lenovo Customer Service.
Problem: You need to change the display property settings.
Setting display background and icon properties:
1. Right-click the desktop anywhere except over an icon, then select Personalize from the pop-up menu.
2. From here, select the appropriate options to:
• Changethedesktopbackground
• Selectascreensaver
• Selectcolorsandappearanceoptionsforiconsandtext
• Setresolutionandcolorsinthe
Display Settings options
Problem: Ripple on screen.
Troubleshooting and problem resolution:
1. Check to see if any of the following devices are located less than one meter from the computer: refrigerators, electric fans, electric dryers, UPS systems, regulators, fluorescent lamps or other computers that may be generating magnetic interference.
2. Move any interfering devices away from the computer.
3. If the problem persists, contact Lenovo Service.
40
User Guide
5.2 Troubleshooting Audio Problems
Problem: No sound from the integrated speakers.
Troubleshooting and problem resolution:
• AdjusttheWindowsvolumecontrol—double-clickthespeakericoninthe lower-right corner of your screen. Ensure that the volume is turned up and the sound is not muted. Adjust the volume, bass, or treble controls to eliminate distortion.
• Reinstalltheaudiodriver.
• Disconnectanyheadphonesfromtheheadphoneconnector—soundfrom the speakers is automatically disabled when headphones are connected to the computer’s side-panel headphone connector.
Problem: No sound from headphones.
Troubleshooting and problem resolution:
• Checktheheadphonecableconnection—ensurethattheheadphonecableis securely inserted into the headphone connector.
• AdjusttheWindowsvolumecontrol—clickordouble-clickthespeakericonin the lower-right corner of your screen. Ensure that the volume is turned up and the sound is not muted.
5.3 Troubleshooting Software Problems
Problem: You are unable to exit a running program normally.
Troubleshooting and problem resolution:
1. Open the Task Manager window by pressing Ctrl , Alt and Delete at the same time.
2. Select the Application tab, select the problem program, then click the End
Task button.
Problem: You need to install or uninstall a program.
Problem resolution:
During installation never abort the install process by powering the system off or through other drastic means. This can cause system program problems or even failure during system initialization.
User Guide
41
During the uninstall process , never directly delete the files or folders. This is harmful to the system, and might cause a system-wide malfunction.
Use the following procedure to properly uninstall programs:
1. Back up all documents and system settings related to the program before removing it.
2. If the program has its own uninstaller, run it directly to uninstall the program.
3. If the program does not have its own uninstaller, then select Control Panel from the Start menu.
4. From the Control Panel , choose Programs and Functions .
5. Find the applicable program from the Programs and Functions dialog box and then select Uninstall/Modify .
6. Perform the instructions displayed to uninstall the software.
5.4 Troubleshooting Problems with Optical Drives and
Hard Disks
Problem: The Optical drive is unable to read a CD/DVD.
Troubleshooting and problem resolution:
1. Check to determine if there is an optical drive icon in the resource manager of the operating system. If not, restart your computer. If there is still no icon, contact Lenovo Service. Otherwise, continue with the next step of this procedure.
2. Confirm that the CD/DVD has been properly placed in the drive. If not, reload the CD or DVD. Otherwise, continue with the next step of this procedure.
3. Check the specifications that came with your computer to confirm that this optical drive is capable of reading this type of CD or DVD.
4. If the CD/DVD cannot be read, replace it with a known good CD/DVD such as one that was shipped with the computer.
5. If the known good CD cannot be read, visually check the operating side of the
CD/DVD for defects.
Problem: The capacity of the hard disk, as indicated by the system, is less than the nominal capacity.
Troubleshooting and problem resolution: For computers equipped with the
OneKey Recovery feature, the system recovery feature needs to occupy some hard disk space. This may account for the apparent hard disk capacity deficit.
42
User Guide
Further Technical Explanation: The nominal capacity of the hard disk is expressed in the decimal system as 1000 bytes. But the actual hard disk capacity is expressed in the binary system as 1024 bytes (For example, the nominal capacity 1G is 1000M, while the actual capacity 1G is 1024M).
The capacity of the hard disk shown in Windows can be calculated according to the calculations in the following example:
The nominal capacity of the hard disk is 40G, while its actual capacity should be: 40 x 1000 x 1000 x 1000/(1024 x 1024 x 1024) = 37G.
If the Service partition of 3G - 3 x 1000 x 1000 x 1000/(1024 x 1024 x 1024) =
2.79G is subtracted, the capacity of the hard disk shown in the system can be obtained.
The capacity of the hard disk as calculated using this method may be slightly different from the actual capacity due to the rounding of totals.
5.5 Special considerations for troubleshooting Windows
1. Record the serial number of the computer as it may be useful later when troubleshooting system problems. The serial number was shipped with the computer and provided separately by the manufacturer. The Help Center is unable to retrieve this number.
2. The drivers for this computer model only support the Windows 7 system.
3. When you use the Windows Media Center to watch TV, be particularly attentive to the following:
• Inthefollowingtwosituations,youmustre-saveachannellist: a. When you change your TV signal from digital to analog, your saved channel list for digital TV is deleted. When you want to watch digital TV again, you must create and save a new channel list.
b. When you change your TV signal from analog to digital, your saved channel list for analog TV is deleted. When you want to watch analog TV again, you must create and save a new channel list.
• YoumustsettheTVtunerinputsignaltoanalogbeforeyoucanwatch
Teletext programming.
User Guide
43
5.6 Performing Daily Maintenance Tasks
Cleaning the computer components
Because many of the computer components consist of sophisticated integrated circuit boards, it is very important to periodically clean the computer to prevent dust buildup. The cleaning supplies you need to clean the components include: a vacuum cleaner, a soft cotton cloth, clear water (preferably purified or distilled water) and cotton swabs.
Attention: Before you clean your computer, disconnect the computer from the electrical outlet. Clean your computer with a soft cloth dampened with water. Do not use liquid or aerosol cleaners, which may contain flammable substances.
Note: To avoid damaging the computer or display, do not spray cleaning solution directly onto the display. Only use products specifically designed for cleaning displays, and follow the instructions included with the product.
The following are general methods for cleaning the components:
• Youcanuseasoftclothtoremovedustonthesurfaceofthecomputer,the monitor, the printer, the speakers and the mouse.
• Youcanuseavacuumcleanertocleaninotherwiseinaccessiblecorners.
• Tocleanthekeyboardthoroughly,shutdownthecomputerandscrubitgently with a wet cloth. Do not use the keyboard until it is dry.
Do not do any of the following:
• Allowwatertoenterthecomputer.
• Useaheavilydampenedcloth.
• Spraywaterdirectlyontothesurfaceofthemonitororinsidethecomputer.
LCD monitors should be cleaned daily. Use a dry cloth to brush dust from the monitor and keyboard every day. Keep all surfaces clean and free of grease stains.
44
User Guide
Chapter
Hardware Replacement Guide
This chapter contains the following topics:
1
2
Ø Removing the computer cover
Ø Installing a wall mount bracket adapter
Ø Installing a B-CAS card
Ø Replacing a memory module
Ø Replacing the optical drive
Ø Replacing the hard disk drive
Ø Replacing the keyboard and mouse
Ø Replacing the power cord
3
4
5
6
User Guide
45
6.1 Overview
This guide is intended to be used by customers who are replacing Customer
Replaceable Units (CRUs) as well as trained service personnel who are replacing
Field Replaceable Units (FRUs). In this guide, CRUs and FRUs will often be referred to as parts.
Note: Trained service personnel should refer to the Hardware Maintenance
Manual (HMM) for parts ordering information.
This guide does not include procedures for all parts. It is expected that cables, switches, and certain mechanical parts can be replaced by trained service personnel without the need for step-by-step procedures.
Note: Use only parts provided by Lenovo®.
The description of the TV-Tuner card in this manual applies only to those computer models that have the TV-Tuner card installed. It does not apply to those computer models that do not have the TV-Tuner card installed.
This guide contains procedures for replacing the following parts:
• Memorymodules
• Harddiskdrive
• Opticaldrive
• Keyboard,mouse(wired)
• Powercord
Safety information for replacing CRUs
Do not open your computer or attempt any repairs before reading the “Important safety information” in the Safety and Warranty Guide that was included with your computer. If you no longer have this copy of the Safety and Warranty Guide , you can obtain one online from the Support Web site at http://consumersupport.lenovo.com.
46
User Guide
Additional information resources
If you have Internet access, the most up-to-date information for your computer is available from the World Wide Web.
You can find the following information:
• CRUremovalandinstallationinformation
• Publications
• Troubleshootinginformation
• Partsinformation
• Linkstootherusefulsourcesofinformation
To access this information, go to: http://consumersupport.lenovo.com
Tools required
To disassemble the computer, you need the following tools:
• Wristgroundingstrapandconductivematforpreventingelectrostaticdischarge
• Flatscrewdriver
• Phillipsscrewdriver
• Hexscrewdriver
• Plasticlatscrewdriver
• Plastictweezers
Note: The screws for the different components vary in size. During the disassembly procedure, group the screws with their corresponding components to avoid a mismatch when replacing the components.
User Guide
47
Handling static-sensitive devices
Static electricity, although harmless to you, can seriously damage computer components.
When you are replacing a part, do not open the anti-static package containing the new part until the defective part has been removed from the computer and you are ready to install the new part.
When you handle parts and other computer components, take these precautions to avoid static electricity damage:
• Limityourmovement.Movementcancausestaticelectricitytobuilduparound you.
• Alwayshandlepartsandothercomputercomponentscarefully.Handle adapters, memory modules, system boards, and microprocessors by the edges. Never touch any exposed circuitry.
• Preventothersfromtouchingthepartsandothercomputercomponents.
• Beforeyoureplaceanewpart,touchtheanti-staticpackagecontainingthe part to a metal expansion slot cover or other unpainted metal surface on the computer for at least two seconds. This reduces static electricity in the package and your body.
• Whenpossible,removethenewpartfromtheanti-staticpackaging,andinstall it directly in the computer without setting the part down. When this is not possible, place the anti-static package that the part came in on a smooth, level surface and place the part on it.
• Donotplacethepartonthecomputercoverorothermetalsurface.
48
User Guide
6.2 Replacing hardware
Attention: Do not remove the computer cover or attempt any repairs before reading the “Important safety information” in the Safety and
Warranty Guide that was included with your computer or in the Hardware
Maintenance Manual (HMM) for the computer. To obtain copies of the
Safety and Warranty Guide or HMM
,gototheSupportWebsiteat: http://consumersupport.lenovo.com
Note: Use only parts provided by Lenovo.
6.2.1 General information
Pre-disassembly instructions
Before proceeding with the disassembly procedure, make sure that you do the following:
1. Turn off the power to the system and all peripherals.
2. Unplug all power and signal cables from the computer.
3. Place the system on a flat, stable surface.
6.2.2 Removing the computer cover
Attention: Turn off the computer and wait 3 to 5 minutes to let it cool down before removing the cover.
Note: It may be helpful to place the computer face-down on a soft flat surface for this procedure. Lenovo recommends that you use a blanket, towel, or other soft cloth to protect the computer screen from scratching or other damage.
To remove the computer cover
1. Remove any media (disks, CDs, or memory cards) from the drives, shut down the operating system, and turn off the computer and all attached devices.
2. Unplug all power cords from electrical outlets.
3. Disconnect all cables attached to the computer. This includes power cords, input/output (I/O) cables, and any other cables that are connected to the computer. Refer to “Left and right view” and “Rear view” for help with locating the various connectors.
User Guide
49
4. Remove the 2 cover pieces by sliding them in opposite directions as shown.
6.2.3 Mounting the computer onto a wall
The computer can be mounted onto a wall. Before doing this, you will first need to install a UL listed VESA wall mount* (to be purchased separately) onto the back of the computer.
To install a VESA wall mount
Note: It may be helpful to place the computer face-down on a soft flat surface for this procedure. Lenovo recommends that you use a blanket, towel, or other soft cloth to protect the touch screen from scratching or other damage.
* VESA wall mount spec: VESA100, 100mm x 100mm, M4 bolts.
50
User Guide
1. Push the stand lock upward to unlock it and then slide the stand out.
1
2 3
2. Align the VESA wall mount with the mounting holes on the computer, and then secure it to the computer with the 4 screws.
User Guide
51
6.2.4 Installing a B-CAS card
Attention: Before using the TV function, a B-CAS card will need to be installed on to the computer. Follow the steps below to install the B-CAS card.
Notes:
BeforeinstallingtheB-CAScard,makesurethatyoudothefollowing:
• Turnoffthepowertothesystemandallperipherals.
• Unplugallpowerandsignalcablesfromthecomputer.
• Placethesystemonalat,stablesurface.
1. Remove the computer cover. Refer to “Removing the computer cover”.
2. Insert the B-CAS card into the card port.
3. Align then slide the computer cover back into position.
52
User Guide
6.2.5 Replacing a memory module
Attention: Turn off the computer and wait 3 to 5 minutes to let it cool down before removing the cover.
Note: It may be helpful to place the computer face-down on a soft flat surface for this procedure. Lenovo recommends that you use a blanket, towel, or other soft cloth to protect the touch screen from scratching or other damage.
1. Remove any media (disks, CDs, or memory cards) from the drives, shut down the operating system, and turn off the computer and all attached devices.
2. Unplug all power cords from electrical outlets.
3. Disconnect all cables attached to the computer. This includes power cords, input/output (I/O) cables, and any other cables that are connected to the computer. Refer to “Left and right view” and “Rear view” for help with locating the various connectors.
4. Remove the computer cover. Refer to “Removing the computer cover”.
5. Push out the latches on both sides of the memory socket to release the memory module and gently pull the memory module upward to remove it from its socket.
All of the memory modules can be removed by using the same procedure.
6. Align then insert the new memory module into the socket and push down on the top edge of the memory module. Make sure the latches lock the memory module in place.
7. Align then slide the computer cover back into position.
User Guide
53
6.2.6 Replacing the optical drive
Attention: Turn off the computer and wait 3 to 5 minutes to let it cool down before replacing the optical drive.
To remove the optical drive:
Note: It may be helpful to place the computer face-down on a soft flat surface for this procedure. Lenovo recommends that you use a blanket, towel, or other soft cloth to protect the screen from scratching or other damage.
1. Remove any media (disks, CDs, or memory cards) from the drives, shut down the operating system, and turn off the computer and all attached devices.
2. Unplug all power cords from electrical outlets.
3. Disconnect all cables attached to the computer. This includes power cords, input/output (I/O) cables, and any other cables that are connected to the computer. Refer to “Left and right view” and “Rear view” for help with locating the various connectors.
4. Remove the computer cover. Refer to “Removing the computer cover”.
5. Push down the pin that locks the optical disk drive to the chassis then use the screwdriver push the disk out.
1
2
54
User Guide
6. Push a small iron stick (paper clip) into the small hole on the optical drive cover so that the disk springs out as shown.
7. Remove the 2 screws that secure the optical drive to the metal bracket.
8. Use a small flat head screwdriver to press and push out the pins that secure the cover to the disk.
9. Separate the cover from the defective optical drive.
User Guide
55
10. Install the new optical drive as follows:
(1) Align the new optical drive with the cover, and then push the cover back into position.
(2) Screw the metal bracket back onto the new optical drive.
(3) Slide the new optical drive into the drive bay.
11. Screw the new optical drive back onto the chassis.
12. Slide the computer cover back into position.
6.2.7 Replacing the hard disk drive
Attention: Turn off the computer and wait 3 to 5 minutes to let it cool down before replacing the hard disk drive.
To replace the hard disk drive:
Note: It may be helpful to place the computer face-down on a soft flat surface for this procedure. Lenovo recommends that you use a blanket, towel, or other soft cloth to protect the screen from scratching or other damage.
1. Remove the computer cover. Refer to “Removing the computer cover”.
56
User Guide
2. Push then slide the hard disk drive and bracket out of the chassis as shown.
1
2
3. Push the pins and release the hard disk drive from the bracket.
4. Install the new hard disk drive as follows:
Line up the new hard disk drive with the bracket and secure it with the pins.
5. Slide the hard disk drive and bracket back into position.
6. Slide the computer cover back into position.
User Guide
57
6.2.8 Replacing the keyboard and the mouse
Attention: Do not remove the computer cover or attempt any repairs before reading the “Important safety information” in the Safety and
Warranty Guide that was included with your computer or in the Hardware
Maintenance Manual (HMM) for the computer. To obtain copies of the
Safety and Warranty Guide or HMM
,gototheSupportWebsiteat: http://consumersupport.lenovo.com
To replace the keyboard:
1. Remove any media (disks, CDs, or memory cards) from the drives, shut down the operating system, and turn off the computer and all attached devices.
2. Unplug all power cords from electrical outlets.
3. Locate the connector for the keyboard. Refer to “Left and right view” and “Rear view”.
Note: Your mouse will be connected to the USB connector at either side or the rear of the computer.
4. Disconnect the defective keyboard cable from the computer and connect the new keyboard cable to the same connector.
* The mouse can be replaced using the same method.
58
User Guide
6.2.9 Replacing the power cord
Attention: Do not remove the computer cover or attempt any repairs before reading the “Important safety information” in the Safety and
Warranty Guide that was included with your computer or in the Hardware
Maintenance Manual (HMM) for the computer. To obtain copies of the
Safety and Warranty Guide or HMM
,gototheSupportWebsiteat: http://consumersupport.lenovo.com
To replace the power cord:
1. Remove any media (disks, CDs, or memory cards) from the drives, shut down the operating system, and turn off the computer and all attached devices.
2. Locate the connector for the power cord. Refer to “Rear view”.
3. Disconnect the defective power cord from the computer and connect the new power cord to the same connector.
User Guide
59
Appendix.
Declaration
Thank you for using Lenovo products.
Carefully read all documents shipped with your computer before you install and use the product for the first time. Lenovo is not responsible for any loss except when caused by installation and operations performed by Lenovo professional service personnel. You are responsible if you fail to operate the product according to instructions and requirements in the manuals included with your computer, or operate the product inappropriately.
This manual could include technical inaccuracies or typographical errors. Changes are made periodically to the information herein; these changes will be incorporated in new editions of the publication.To provide better service, Lenovo reserves the right to improve and/or modify the products and software programs described in the manuals included with your computer, and the content of the manual, at any time without additional notice.
The manuals included with your computer are provided to help you use Lenovo’s products appropriately. For the configuration of the product, refer to the related contract (if any) or product packing list, or consult the distributor for the product sales.
The content of the manuals included with your computer is protected by copyright laws and rules. None of the manuals included with your computer may be reproduced or transcribed by any means or translated into any language without prior written permission of Lenovo.
The software interface and function and hardware configuration described in the manuals included with your computer might not match exactly the actual configuration of the computer that you purchase.You are welcome to contact us about the manuals included with your computer. For the latest information or any questions or comments, contact or visit the Lenovo Web site:
Service Web site: http://consumersupport.lenovo.com
60
User Guide
Trademarks
Lenovo and the Lenovo logo, IdeaCentre and IdeaCentre logo are trademarks of
Lenovo in the United States, other countries, or both.
Microsoft, Windows, and Windows Vista are trademarks of the Microsoft group of companies.
Intel Inside is a trademark of Intel Corporation in the U.S. and/or other countries.
AMD, the AMD Arrow logo, ATI, AMD Athlon, AMD LIVE!, AMD Opteron, AMD
Phenom, AMD Sempron, Catalyst, Cool ‘n’ Quiet, CrossFire, PowerPlay, Radeon, and The Ultimate Visual Experience are trademarks of Advanced Micro Devices,
Inc.
Other company, product, or service names referred to herein or in other Lenovo publications may be trademarks or service marks of others.
All rights reserved.
Names or marks of certain companies mentioned in the manuals included with your computer or this document do not necessarily indicate that related software or hardware is included. The actual configuration of the product depends on the packing list description.
Energy Star Statement
ENERGY STAR® is a joint program of the U.S. Environmental Protection Agency and the U.S. Department of Energy aimed at saving money and protecting the environment through energy efficient products and practices.
Lenovo is proud to offer our customers products with an ENERGY STAR compliant designation. The following machine types have been designed and tested to conform to the ENERGY STAR program requirement for computers at the time of manufacture. For more information about ENERGY STAR ratings for Lenovo computers, go to http://www.lenovo.com.
•
10097/2566
•
10099/2568
•
10101/3363
•
10098/2567
User Guide
61
•
10100/4749
By using ENERGY STAR compliant products and taking advantage of the powermanagement features of your computer, you reduce the consumption of electricity.
Reduced electrical consumption contributes to potential financial sayings, a cleaner environment, and the reduction of greenhouse gas emissions.
For more information about ENERGY STAR, go to: http://www.energystar.gov
Lenovo encourages you to make efficient use of energy an integral part of your day-to-day operations. To help in this endeavor, Lenovo has preset the following power-management features to take effect when your computer has been inactive for a specified duration:
ENERGY STAR power-management features, by operating system
Microsoft Windows XP
• Turnoffmonitor:After15minutes
• Turnoffharddiskdrives:Never
• Systemstandby:After20minutes
• Systemhibernates:Never
Microsoft Windows Vista and
Windows 7
Power plan: Balanced
• Turnoffthedisplay:After10minutes
• Putthecomputertosleep:After
25 minutes
• Advancedpowersettings:
- Turn off hard disk drives: After
20 minutes
- Hibernate: Never
To awaken your computer from a Sleep or System Standby mode, press any key on your keyboard. For more information about these settings, refer to your
Windows Help and Support information system.
62
User Guide
Lenovo
IdeaCentre B320 21.5" 57306215
Описание Характеристики
ф мл ни дит нл н з 2 мин ты
Д т в в з з в ии гл т чн я л жб дд ж и л т з з любым д бным б м м нии Д т в и л т вин и тзывы ции и ид и
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
Related manuals
advertisement
Table of contents
- 7 Chapter 1 Using the Computer Hardware
- 8 1.1 Front view of the computer
- 9 1.2 Left and right view of the computer
- 10 1.3 Rear view of the computer
- 11 1.4 TV button instructions (selected models only)
- 12 1.5 Computer stand
- 13 1.6 Connecting your computer
- 14 1.7 Important information about using the computer
- 16 1.8 Wired keyboard (selected models only)
- 17 Chapter 2 Touch screen user instruction
- 18 2.1 Touch Screen Calibration
- 18 2.2 User Gesture Instructions for the Touch screen
- 26 2.3 Attentions when using the Touch Screen
- 29 Chapter 3 Using the Onekey TV (selected models only)
- 31 3.1 Guide to the remote control (selected models only)
- 34 only)
- 41 Chapter 4 Using the Rescue System
- 42 4.1 OneKey Recovery
- 42 4.2 Driver and Application Installation
- 43 4.3 System Setup
- 44 4.4 System Backup
- 44 4.5 System Recovery
- 44 4.6 Create Recovery Disc
- 45 Chapter 5 Troubleshooting and Confirming Setup
- 46 5.1 Troubleshooting Display Problems
- 47 5.2 Troubleshooting Audio Problems
- 47 5.3 Troubleshooting Software Problems
- 48 Disks
- 49 5.5 Special considerations for troubleshooting Windows
- 50 5.6 Performing Daily Maintenance Tasks
- 51 Chapter 6 Hardware Replacement Guide
- 52 6.1 Overview
- 55 6.2 Replacing hardware
- 66 Appendix
- 67 Energy Star Statement
