8 - Your Acer notebook tour
Y
OUR
A
CER NOTEBOOK TOUR
After setting up your computer as illustrated in the Setup Guide, let us show you around your new Acer computer.
Front view
1
2
2
3
#
1
3
Icon Item
Webcam
Touchscreen
Speakers
Description
Web camera for video communication.
Displays computer output, supports multi-touch input.
Deliver stereo audio output.
Your Acer notebook tour - 9
Rear view
1
2
#
1
2
Icon Item
Webcam
Fingerprint reader
Bottom view
1
Description
Web camera for video communication.
Fingerprint reader for Acer ProShield
Security Suite (configuration may vary by model).
#
1
2
Icon Item
Keyboard connector
Keyboard hook slots
2
Description
Connects to the keyboard.
Fastens to the keyboard.
10 - Your Acer notebook tour
Left view
#
1
2
3
4
5
1 2 3 4 5
Icon Item
DC-in jack
Description
Connects to an AC adapter.
USB Type-C port
Headset/ speaker jack
Connects to USB devices that adopt the USB Type-C connector. Supports
USB 3.1 Type-C, Gen 1 with transfer speeds up to 5 Gb/s.
Connects to audio devices (e.g., speakers, headphones) or a headset with microphone.
MicroSD card slot
Insert a microSD card into this slot.
Microphone
Internal microphone for sound recording.
Information on USB 3.0
• USB 3.0 compatible ports are blue.
• Compatible with USB 3.0 and earlier devices.
• For optimal performance, use USB 3.0-certified devices.
• Defined by the USB 3.0 specification (SuperSpeed USB).
Your Acer notebook tour - 11
Right view
#
1
2
3
4
1 2
Icon Item
Power button
+ / -
Volume control key
Windows key
Reset pinhole
3 4
Description
Turns the computer on and off.
Adjusts the system volume.
Push to return to the Start screen, or to the last open app.
Insert a paperclip into the hole to reboot the computer.
Keyboard front view
1
2
3
#
1
2
Icon Item Description
Keyboard hooks Fastens to the computer.
Keyboard
For entering data into your computer.
See "Using the keyboard" on page
12 - Your Acer notebook tour
#
3
Icon Item
Touchpad
Keyboard left view
For keyboard featuring HDD
Description
Touch-sensitive pointing device.
The touchpad and selection buttons form a single surface.
Press down firmly on the touchpad surface to perform a left click.
Press down firmly on the lower right corner to perform a right click.
#
1
1
Icon Item
Ethernet (RJ-45) port (optional)
Description
Connects to an Ethernet 10/100/
1000-based network.
For keyboard without HDD
Note
The slimline keyboard does not feature an internal disk drive or Ethernet port.
Your Acer notebook tour - 13
Keyboard right view
For keyboard featuring HDD
#
1
Icon Item
USB ports
(optional)
For keyboard without HDD
1
Description
Connect to USB devices.
#
1
Icon Item
USB port
(optional)
1
Description
Connect to USB devices.
