Mobility Services Platform 3.3
Software Installation Guide
Mobility Services Platform 3.3 Software Installation Guide
72E-100159-09
Revision G
September 2009
© 2009 by Motorola, Inc. All rights reserved.
No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in writing from Motorola. This includes electronic or mechanical means, such as photocopying, recording, or information storage and retrieval systems. The material in this manual is subject to change without notice.
The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on a licensed basis. Motorola grants to the user a non-transferable and non-exclusive license to use each software or firmware program delivered hereunder (licensed program).
Except as noted below, such license may not be assigned, sublicensed, or otherwise transferred by the user without prior written consent of Motorola. No right to copy a licensed program in whole or in part is granted, except as permitted under copyright law. The user shall not modify, merge, or incorporate any form or portion of a licensed program with other program material, create a derivative work from a licensed program, or use a licensed program in a network without written permission from Motorola. The user agrees to maintain Motorola’s copyright notice on the licensed programs delivered hereunder, and to include the same on any authorized copies it makes, in whole or in part. The user agrees not to decompile, disassemble, decode, or reverse engineer any licensed program delivered to the user or any portion thereof.
Motorola reserves the right to make changes to any software or product to improve reliability, function, or design.
Motorola does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any
Motorola, Inc., intellectual property rights. An implied license only exists for equipment, circuits, and subsystems contained in Motorola products.
MOTOROLA and the Stylized M Logo and Symbol and the Symbol logo are registered in the US
Patent & Trademark Office. All other product or service names are the property of their respective owners.
Motorola, Inc
One Motorola Plaza
Holtsville, New York 11742-1300 http:/motorola.com/enterprisemobility
Table of Contents
Chapter 2 – MSP Server Requirements.............................................................5
iv -- Mobility Services Platform 3.3 Software Installation Guide
Before You Begin
Read This First
Motorola recommends that you read this entire document before you begin installing MSP 3.3. http://support.symbol.com/support/product/softwaredownloads.do
.
Related Documents
MSP 3.3 Release Notes, p/n 72E-100160
Understanding Mobility Services Platform 3.3, p/n 72E-128712
Using Mobility Services Platform 3.3, p/n 72E-128802
MSP Client Software Guide, p/n 72E-128805
Using the MSP 3.3 Administration Program, p/n 72E-128775
Using the Athena Remote Control Solution, p/n 72E-127346
Using the Motorola Remote Control Solution, p/n 72E-127347
AirBEAM Package Builder Product Reference Guide, p/n 72E-55769
AirBEAM Package Builder Version 2.X Addendum
Service Information
If you have a problem with your software, contact Motorola Enterprise Mobility support for your region. Contact information is available at: http://www.symbol.com/contactsupport.
2 -- Mobility Services Platform 3.3 Software Installation Guide
When contacting Enterprise Mobility support, please have the following information available:
Serial number of the software
Model number or product name
Software type and version number
Software license information
Motorola responds to calls by email, telephone or fax within the time limits set forth in support agreements.
If you purchased your Enterprise Mobility business product from a Motorola business partner, contact that business partner for support.
Chapter 1 - Introduction
Introduction
Mobility Services Platform 3.3 (MSP) is being released on CD with a new install interface and simplified instructions for the two most common types of installation. Users that find these two install scenarios inappropriate for their installation of MSP are highly encouraged to contact the
MSP Help Desk for assistance.
Mobility Services Platform version 3.3 is available in several Editions that allow you to choose to purchase and install just the functionality you need. MSP Stage Edition provides support only for initial deployment of devices. MSP Provision Edition provides all the features of MSP Stage
Edition plus the ability to use Provisioning to keep your devices continuously up to date. MSP
Control Edition provides all the features of MSP Provision Edition plus the ability to perform Data
Collection and optionally Collection Analysis and the ability to perform Actions on selected devices. Depending on the MSP Edition you choose to install, the functionality you elect to use, and the complexity of the enterprise you need to manage, the installation of MSP will vary in complexity.
Installing MSP 3.3 Stage or MSP 3.3 Provision Edition will typically be the least demanding. You may choose to use either Microsoft SQL Server Express 2005 or Microsoft SQL Server
2005/2008 Standard or Enterprise edition to host your MSP database. Microsoft SQL Server
Express 2005 is license-free, and hence Microsoft offers no support. In addition, Microsoft SQL
Server Express 2005 has limitations on maximum database size and generally is not considered an enterprise-class solution. Depending on your situation, you may want to use Microsoft SQL
Server 2005/2008 Standard or Enterprise editions even though they require the purchase of licenses from Microsoft. By paying for licenses, you get an enterprise-class solution and support from Microsoft.
Installing MSP 3.3 Control Edition without Data Collection is comparable in complexity to installing MSP 3.3 Stage Edition or MSP 3.3 Provision Edition. You may choose to use either
Microsoft SQL Server Express 2005 or Microsoft SQL Server 2005/2008 Standard or Enterprise editions to host your MSP database. For the same reasons stated above, it is often advisable to use Microsoft SQL Server 2005/2008 Standard or Enterprise editions to ensure that you have an enterprise-class scalable and supported solution.
4 -- Mobility Services Platform 3.3 Software Installation Guide
Installing MSP 3.3 Control Edition with Data Collection always requires the use of Microsoft SQL
Server 2005/2008 Standard or Enterprise editions to host your MSP database. In addition, if you wish to use Collection Analysis, you will need to install the optional Analysis Services feature of
Microsoft SQL Server 2005/2008 Standard or Enterprise editions.
Deciding Your Installation Scenario
All Components on One Server
In this installation scenario, you will install all MSP Server Components and the MSP Core
Database on one server on which your instance of SQL Server is already installed.
Components Split Between Two Servers
In this installation scenario, you will install the MSP Core Database on one server on which your instance of SQL Server is already installed and all other MSP Components will be installed on another server with connectivity to the SQL/MSP Database server.
Advanced Installations
Any scenario involving the distribution of MSP Components across multiple servers requires expertise that only the most-advanced IT professionals possess. These types of installation scenarios can be accomplished with the MSP 3.3 Installer, but specific details for these scenarios are not covered in this document. Before such installations are attempted users are highly encouraged to contact the MSP Help Desk.
5 -- Mobility Services Platform 3.3 Software Installation Guide
Chapter 2 – MSP Server Requirements
Minimum Software and Hardware Requirements
Servers on which you plan to install MSP 3.3 must meet the minimum software and hardware
Category
Windows Operating
Systems
Requirements
Windows Server 2003 Standard/Enterprise/Web editions x86/x64 with SP2 or higher
Windows Server 2003 R2 Standard/Enterprise editions x86/x64 with SP2 or higher
Windows Server 2008 Standard/Enterprise/Datacenter editions x86/x64 with SP1 or higher
Important:
Installation on Windows XP or Vista are not supported. MSP 3.3 is not supported on Windows Server systems that are Domain Controllers.
6 -- Mobility Services Platform 3.3 Software Installation Guide
Category
Additional Software
Requirements
Microsoft Internet Information Services 6/7.
Microsoft .NET Framework 2.0 SP2
Microsoft SQL Server 2005/2008.
Note:
If you will not be installing the Data Collection or Long-Term Analysis features of MSP 3.3, you can use SQL Server 2005 Express. This version of SQL Server is free and included for your use on the MSP
3.3 Installation CD. You need not use SQL Server 2008 Express for such an installation.
Hardware for Stage,
Provision, or Control
Editions without Data
Collection and
Analysis
Windows Installer 4.5 Update
These are recommended minimum specifications for the computer on which you will run these editions of MSP. These are only recommendations and you may obtain satisfactory performance on computers with a configuration that differs from these specifications.
3 GHz processor
2 GB of memory
40 GB hard drive
Note:
The perceived performance of MSP Server is affected by many parameters other than the configuration of the computer on which it runs. See the Understanding MSP 3.3 for more information on factors that can affect MSP performance.
Hardware for Control
Edition with Data
Collection and
Analysis
These are recommended minimum specifications for the computer on which you will run these editions of MSP.
Dual 2.33 GHz dual-core processors
4 GB of memory
40 GB space available on hard drive
Note:
The perceived performance of MSP Server is affected by many parameters other than the configuration of the computer on which it runs. See the Understanding MSP 3.3 for more information on factors that can affect MSP performance.
Chapter 2 – MSP Server Requirements -- 7
SQL Server 2005/2008 Requirements
The edition of Microsoft SQL Server 2005/2008 you must use is determined by how the installation of MSP 3.3 will be used. The following table delineates which edition you must use:
Table 2 – SQL Server 2005/2008 Version Requirements
If MSP 3.3 will be used for a new installation or
Upgrade from 3.2/3.2.1…
SQL Server 2005/2008 Version Requirements
On a single server
Without Data Collection and Analysis
Microsoft SQL Server 2005 Express or SQL
Server 2005/2008 Standard or Enterprise without SSAS enabled, as well as the other software and hardware requirements listed in
Table 1 – Minimum Software and Hardware
Requirements.
On a single server
With Data Collection and Analysis
The instance of Microsoft SQL Server is on a second, separate server
Without Data Collection and Analysis
SQL Server 2005/2008 Standard or Enterprise with SSAS enabled, as well as the other software and hardware requirements listed in
Table 1 – Minimum Software and Hardware
Requirements.
Microsoft SQL Server 2005 Express or SQL
Server 2005/2008 Standard or Enterprise without SSAS enabled, as well as the other software and hardware requirements listed in
Table 1 – Minimum Software and Hardware
Requirements.
Note:
TCP/IP must be enabled under SQL Server Network Configuration
8 -- Mobility Services Platform 3.3 Software Installation Guide
Chapter 3 – Installing MSP 3.3
Before Installing MSP 3.3
If you are planning to install the MSP Core Database on a SQL Server instance that is running on a different box than the rest of the MSP components will be, then you should have two domain users available before beginning the installation of MSP 3.3. One domain user is required for
Authentication to install the Core Database and access it at runtime.
Upgrading from Previous MSP Versions
1. Upgrades to MSP 3.3 are supported only from MSP versions 3.2/3.2.1.
2. Export all Objects before continuing; see Using MSP 3.3 – Understanding Objects for more detail.
3. All upgrades begin with uninstalling the current version of MSP (and Package Builder if appropriate) using Add/Remove Programs.
IMPORTANT:
If you have an installation of MSP 3.2.0 with the Package Builder 1.0 add-on installed, you MUST uninstall Package Builder BEFORE you uninstall MSP
3.2.0
. If you do not remove this software in this order, you may not be able to uninstall Package Builder or reinstall MSP later.
4. Make sure you chose to keep the existing data.
IMPORTANT:
Uninstall the existing version of MSP keeping the existing data.
Failure to select the check box to keep your data will result in a loss of your database.
10 -- Mobility Services Platform 3.3 Software Installation Guide
5. Migrate the User Data Files shared folder, if applicable.
Domain User for Runtime Access
This domain user does not need special domain permissions and does not need any special permissions granted before installing MSP 3.3. This domain user only needs to be a member of the “domain users” group.
Domain User for Installation
This domain user does not need special domain permissions. It simply needs to be a member of the administrators group on the server where the MSP components will be installed. This user also needs permissions on the SQL Server. The easiest way to grant these permissions are to make the user a member of the administrators group on the SQL Server.
Important:
This domain user is not needed once the install is completed. The installation configuration file will keep track of which user was specified while installing, but this user is not used by the MSP components once the installation is complete.
Installing MSP 3.3
To Install MSP 3.3:
1. Put the Installation CD in the machine on which you are installing all MSP Components or on which you are installing all MSP Components except the MSP Database.
2. When the MSP 3.3 CD Launcher dialog box displays, you will see the results of the pre-
requisite software check in the Pre-requisites area at the top of the dialog box (Figure
Figure 1
Note:
If all three pre-requisites are installed, go to Step 3.
If IIS is not installed, go to Appendix A for installation instructions.
If either .NET Framework 2.0 SP2 or Windows Installer 4.5 Update are not installed, click Install and then Finish when the installation is complete.
4. When the Welcome dialog box for the MSP Install Point Installer is displayed, click Next.
5. Accept the license agreement and click Next.
Chapter 3 – Installing MSP 3.3 -- 11
6. Accept or change the Destination folder and click Next.
9. When the Install Interviewer opens, choose your installation scenario and click Next.
10. Indicate which, if any, MSP Control Component features you plan to use and click Next.
Notes:
Data collection requires SQL Server 2005/2008 Standard or Enterprise Edition. It is not supported on SQL Server Express edition.
Selecting Long Term Analysis will install the MSP Analysis Database.
The SQL Server 2005/2008 Standard or Enterprise Edition restrictions will be checked later in the process once the target SQL Server has been identified.
11. On the MSP Core Database dialog box select the SQL instance on which the MSP Core
Database will be installed:
If you selected the all in one scenario, the SQL Server choices will be prepopulated as the dialog is displayed and will be restricted to the local server.
If you selected the scenario where you are going to install all MSP Components except the MSP Database on the installation machine, you will encounter a list of all the SQL instances on all the servers to which there is connectivity from the installation machine. You will not be able to choose the installation machine.
12. Choose the authentication method for installation of the MSP Core Database. Windows
Authentication is the default, but you can choose SQL Authentication.
If you select SQL Authentication, you will need to provide a SQL login that has sysadmin permissions.
Note:
If you select SQL Authentication, the SQL Server instance must be configured to support mixed mode authentication.
If you select Windows Authentication, then you will need to be logged in as a user that has sufficient permissions to install the MSP Core and MSP Analysis Services
Databases.
Note:
If this is a one box install, an administrator login on the server will have the proper permissions.
If this is a two box install, then a separate domain user who is an administrator on the current server is required.
If you selected the scenario where you are going to install all MSP Components except the MSP Database on the installation machine and if you wish to stay with the
Windows Authentication option, you will need to be logged in to the server with a domain user that has been configured to have sysadmin permissions on the SQL
Server.}
12 -- Mobility Services Platform 3.3 Software Installation Guide
13. Click Next to go to an MSP Core Database Review dialog box. If you indicated a SQL instance on which an Existing MSP Database is installed, the installer defeaults to keeping the MSP data. If you accept the information, click Next. If you need to change it, click Back.
Note:
If you selected MSP Control Component features but do not have SQL 2005/2008
Standard or Enterprise Edition, you will be informed that MSP Control Component features will not be installed and you will be allowed to continue.
If you do not want to keep any data that was in the previous MSP database, you can check the box to delete the existing data. When the MSP server installs it will wipe out all existing MSP data and install a clean database.
14. On the SQL Server Analysis Services dialog box, it will show the SQL Server instance where the MSP Core Database is being installed along with the Analysis Database name.
15. On the MSP Runtime Windows Authentication dialog box, default values are provided for a one box install. Click Next to continue.
If a one box install was selected, then this default local user will be created if it doesn’t exist.
If you selected the scenario where you are going to install all MSP Components except the MSP Database on the installation machine, then this user should be a domain user.
16. On the MSP Authentication to SQL Database dialog box, choose the method of authentication and click Next.
If you select SQL Authentication, then the SQL login credentials that you provide will be used to create a SQL login when MSP is installed.
If you select Windows Authentication, then the Windows account specified in the previous dialog will be granted the necessary permissions to access the SQL and
Analysis databases.
17. On the Install MSP Users dialog box, review the two initial users that will be created for connection to the MSP UI Console.
Important:
These two MSP Users must be used once MSP is installed to configure any other
MSP users or even to configure MSP to use LDAP to authenticate users.
18. Click Next to display the Review Installation Settings dialog box.
19. Review the settings. If you accept the settings, click Install; if you need to change something, click Back until you reach the information that needs to be changed.
20. After clicking Install, the MSP Server installation process will begin.
Chapter 3 – Installing MSP 3.3 -- 13
Notes:
During the install you will see components being installed that are related to SQL
Server 2008.
There is a possibility that one of the installed components will force a system restart.
If this occurs, log in again and launch the install from the CD again. The installation process will resume without having to repeat the Interviewer process.
If an error occurs while installing MSP Server that requires changing an answer provided during the interview process then you will need to uninstall the Install Point installation and reinstall it.
21. When you receive the Install Succeeded message, the installation is finished. Please see Understanding MSP 3.3 and Using MSP 3.3 for details about enabling non-default configuration options, such as:
Enter License keys to enable Provision and Control Editions (Using MSP 3.3 –
Administrative Setup).
Configure Authentication Sources and MSP Users (Using MSP 3.3 – Administrative
Setup).
Re-enable optional settings through the MSP Administration Program (Using the
MSP 3.3 Administration Program).
22. Depending on your need for various features in MSP, you may need to import one or more MSP Addons. Please see the Bulk Import for Addons section in Using the MSP
3.3 Administration Program for more information. You will need to import them from the
MSP 3.3 Installer CD which contains the .zip files for each of the default Addons. You can also check for updated Addon files at Support Central. It is important to note that there are some commonly used Addons that must be imported before you are able to use the functionality they provide. Some examples include:
AthenaMonitor
AthenaRemoteControl
Motorola SSL VPN
MotorolaRemoteControl
AppCenter
Uninstalling and Reinstalling MSP Server 3.3 to
Change Your Configuration
MSP Install Point is a separate program that controls the installation of MSP 3.3. Install Point keeps track of the configuration files used to install MSP 3.3. You can make changes to the following now by reinstalling MSP Server via MSP 3.3 Install Point:
Addition or Removal of support for Long Term Analysis
The MSP runtime connection to the MSP Core Database
The User under which MSP runs
The initial MSP Users
Completely wipe the database clean.
14 -- Mobility Services Platform 3.3 Software Installation Guide
Caution!
You will lose all of your settings and data if and when you wipe the database clean.
To make Changes to MSP 3.3:
MSP Package builder. MSP 3.3 Install Point will remain installed. uninstalled, but MSP 3.3 Install Point has saved configuration files from the previous installation.
4. When the MSP 3.3 Installation Interviewer restarts, move through the interview process and change the appropriate information.
5. When the interview process concludes, click Install to reinstall MSP Server 3.3 with the new settings.
Uninstalling MSP 3.3
Complete removal of MSP 3.3, excluding the MSP Core Database and the Archive and Temp
files, will require removing MSP Install Point:
MSP Package builder. MSP 3.3 Install Point will remain installed.
Install Point.
Appendix A – Installing Microsoft IIS
Important:
MSP assumes all the default settings are included with the installation of IIS. Therefore if you install IIS with any configuration other than the defaults, or if the configuration of IIS is modified in any way after it is installed, MSP may not function correctly. It is the responsibility of the end user to make sure the necessary security levels and permissions are in place for all web aspects of IIS prior to installing MSP.
Installing IIS 6
Use the following steps to install IIS 6:
3. In the list of Windows Components, select Application Server and click Details.
4. In the list of Application Server subcomponents, select Internet Information Services
(IIS) and click the Details.
5. In the list of IIS subcomponents, select World Wide Web Service and click Details.
6. In the World Wide Web Service list, select World Wide Web Service and click OK. prompt you for the Windows CD that was used to install the operating system. Follow the prompts to complete the installation of IIS.
9. To verify that IIS has been installed correctly– b. Verify that Internet Information Services (IIS) Manager is listed as one of the
Administrative tools.
16 -- Mobility Services Platform 3.3 Software Installation Guide
Installing IIS 7 under Windows Server 2008
Use the following steps to install IIS 7:
1. Click Start > Administrative Tools > Server Manager.
2. Click on the Roles node in the left hand pane, and wait until information is displayed.
4. Following the wizard, select the Application Server role and then the Web Server role service under the Application Server role.
5. Verify that the ASP.Net role service under the Web Server also is added.
Wait until the roles and role for it to finish adding the role and role services.
8. To verify that IIS 7is properly installed: b. Click on the Roles node in the left hand pane, and wait until information is displayed. d. Verify that the Internet Information Services (IIS) Manager is listed in the left pane. e. Click on the Internet Information Services (IIS) Manager node in the left hand pane. f. In the middle pane, click on the node that has the server name. g. Verify in the right hand pane that ASP.NET features are shown.
Appendix A – Installing Microsoft IIS -- 17
18 -- Mobility Services Platform 3.3 Software Installation Guide
Motorola, Inc.
One Motorola Plaza
Holtsville, New York 11742, USA
1-800-927-9626 http:/motorola.com/enterprisemobility
MOTOROLA and the Stylized M Logo and Symbol and the Symbol logo are registered in the U.S.
Patent and Trademark Office. All other product or service names are the property of their registered owners.
© MOTOROLA, Inc. 2009
72E-100159-09
advertisement
Related manuals
advertisement
