LED Monitor
User Manual
SMT-3231/4031
The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.
AB68-01126A
Table of contents
15
Parts 18
Anti-theft Lock
21
Before Installing the Product (Installation Guide) 25
Wall Mount Kit Specifications (VESA) 27
Connection using the D-SUB cable
Connection using a DVI cable (Digital type)
Connection Using an HDMI-DVI Cable
Connection Using an HDMI Cable
Changing the Resolution on Windows XP
Changing the Resolution on Windows Vista
Changing the Resolution on Windows 7
Changing the Resolution on Windows 8
Connection Using the component Cable
Connection Using an HDMI-DVI Cable
Connection Using an HDMI Cable
Connecting the network box (Sold separately) 50
Configuring Settings for Multi Control 53
Configuring settings for Multi Control 53
2
Table of contents
If the input source is PC, DVI 90
If the input source is AV, Component, HDMI 90
Backlight / Contrast / Brightness /
Sharpness / Colour / Tint (G/R) 91
Reset Picture 104
Sound Adjustment
Sound Mode 105
Sound Effect 106
Speaker Settings 107
Reset Sound 108
Network
Network Settings 109
Connecting to a Wired Network 109
Connecting to a Wireless Network
Configuring settings for Multi Control 117
3
Table of contents
Source AutoSwitch Settings 132
Read the following before using AllShare Play with a USB device
Connecting to a PC over a network
Using the AllShare Play features
Using the Basic AllShare Play Features
4
Table of contents
Viewing a Photo (or Slide Show) 156
Videos / Photos / Music Play Option menu 158
Supported Subtitle and AllShare Play file formats 160
Supported image resolutions 160
Read before using MagicInfo Lite player 163
Approving a connected device from the server 168
MagicInfo Premium S Player 186
Read before using MagicInfo Premium S Player 186
Approving a connected device from the server 192
MagicInfo Premium S Player 194
MagicInfo Videowall S Player 213
Read before using MagicInfo Videowall S Player 213
Requirements Before Contacting Samsung
Checking the Resolution and Frequency
5
Table of contents
Responsibility for the Pay Service
(Cost to Customers)
Not a product defect
234
234
A Product damage caused by customer's fault 234
Others 234
WEEE 235
Correct Disposal of This Product (Waste
Electrical & Electronic Equipment) 235
Correct disposal of batteries in this product 235
Optimum Picture Quality and Afterimage
Burn-in Prevention
Optimum Picture Quality
Prevention of Afterimage Burn-in
236
236
237
6
Chapter 01
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
© 2013 Samsung Techwin
Samsung Techwin owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Techwin is prohibited.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.
• An administration fee may be charged if either
(a) an engineer is called out at your request and there is no defect in the product
(i.e. where you have failed to read this user manual).
(b) you bring the unit to a repair centre and there is no defect in the product
(i.e. where you have failed to read this user manual).
• The amount of such administration charge will be advised to you before any work or home visit is carried out.
7
Safety Precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)
THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and maintenance has been included with this product.
Symbols
Warning
A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.
Cleaning
― Exercise care when cleaning as the panel and exterior of advanced LEDs are easily scratched.
― Take the following steps when cleaning.
― The following images are for reference only. Real-life situations may differ from what is shown in the images.
1 Power off the product and computer.
2 Disconnect the power cord from the product.
― Hold the power cable by the plug and do not touch the cable with wet hands. Otherwise, an electric shock may result.
3 Wipe the product with a clean, soft and dry cloth.
• Do not use detergents that contain alcohol, solvent or surface-active agents.
!
• Do not spray water or detergent directly on the product.
4 Wet a soft and dry cloth in water and wring thoroughly to clean the exterior of the product.
5
Connect the power cord to the product when cleaning is finished.
6
Power on the product and computer.
8
Storage
Due to the characteristics of high-glossy products, using a UV humidifier nearby may create whitecoloured stains on the product.
― Contact Customer Service Centre if the inside of the product needs cleaning (service fee will be charged).
Electricity and Safety
― The following images are for reference only. Real-life situations may differ from what is shown in the images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
• An electric shock or fire may result.
!
Do not use multiple products with a single power socket.
• Overheated power sockets may cause a fire.
Do not touch the power plug with wet hands. Otherwise, an electric shock may result.
!
Insert the power plug all the way in so it is not loose.
• An unsecure connection may cause a fire.
!
Connect the power plug to a grounded power socket (type 1 insulated devices only).
• An electric shock or injury may result.
Do not bend or pull the power cord with force. Be careful not to leave the power cord under a heavy object.
• Damage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
• A fire or electric shock may result.
Clean any dust around the pins of the power plug or the power socket with a dry cloth.
• A fire may result.
9
Caution
!
!
!
Do not disconnect the power cord while the product is being used.
• The product may become damaged by an electric shock.
Only use the power cord provided with your product by Samsung. Do not use the power cord with other products.
• A fire or electric shock may result.
Keep the power socket where the power cord is connected unobstructed.
• The power cord must be disconnected to cut off power to the product when an issue occurs.
• Note that the product is not completely powered down by using only the power button on the remote.
Hold the plug when disconnecting the power cord from the power socket.
• An electric shock or fire may result.
!
Installation
Warning
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF
THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
• A fire may result.
Have a technician install the wall-mount hanger.
• Installation by an unqualified person can result in an injury.
• Only use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or closet.
• An increased internal temperature may cause a fire.
Install the product at least 10cm away from the wall to allow ventilation.
• An increased internal temperature may cause a fire.
!
Keep the plastic packaging out of the reach of children.
• Children may suffocate.
!
10
!
Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.)
• The product may fall and become damaged and/or cause an injury.
• Using the product in an area with excess vibration may damage the product or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture
(water drips, etc.), oil, or smoke.
• A fire or electric shock may result.
Caution
!
Do not expose the product to direct sunlight, heat, or a hot object such as a stove.
• The product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
• The product may fall and injure children.
• As the front is heavy, install the product on a flat and stable surface.
Edible oil, such as soybean oil, can damage or deform the product. Do not install the product in a kitchen or near a kitchen counter.
!
!
Do not drop the product while moving.
• Product failure or personal injury may result.
Do not set down the product on its front.
• The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the bottom edge of the front of the product is not protruding.
• The product may fall and become damaged and/or cause an injury.
• Install the product only on cabinets or shelves of the right size.
Set down the product gently.
• Product failure or personal injury may result.
SAMSUNG
Installing the product in an unusual place (a place exposed to a lot of fine particles, chemical substances or extreme temperatures, or an airport or train station where the product should operate continuously for an extended period of time) may seriously affect its performance.
• Be sure to consult Samsung Customer Service Centre if you want to install the product at such a place.
11
Operation
Warning
!
!
There is a high voltage inside the product. Never disassemble, repair or modify the product yourself.
• A fire or electric shock may result.
• Contact Samsung Customer Service Centre for repairs.
Before moving the product, turn off the power switch and disconnect the power cable and all other connected cables.
• Damage to the cord may result in a fire or electric shock.
If the product generates abnormal sounds, a burning smell or smoke, disconnect the power cord immediately and contact Samsung Customer
Service Centre.
• An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
• Children may become injured or seriously harmed.
!
!
!
If the product is dropped or the outer case is damaged, turn off the power switch and disconnect the power cord. Then contact Samsung Customer
Service Centre.
• Continued use can result in a fire or electric shock.
Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of the product.
• The product or heavy objects may fall as children try to reach for the toys or sweets resulting in a serious injury.
During a lightning or thunderstorm, power off the product and remove the power cable.
• A fire or electric shock may result.
Do not drop objects on the product or apply impact.
• A fire or electric shock may result.
GAS
Do not move the product by pulling the power cord or any cable.
• Product failure, an electric shock or fire may result from a damaged cable.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate the area immediately.
• Sparks can cause an explosion or fire.
Do not lift or move the product by pulling the power cord or any cable.
• Product failure, an electric shock or fire may result from a damaged cable.
12
!
100
Do not use or keep combustible spray or an inflammable substance near the product.
• An explosion or fire may result.
Caution
Ensure the vents are not blocked by tablecloths or curtains.
• An increased internal temperature may cause a fire.
!
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that burn easily (paper, matches, etc) into the product (via the vent or input/ output ports, etc).
• Be sure to power off the product and disconnect the power cord when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Centre.
• Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic objects on top of the product.
• Be sure to power off the product and disconnect the power cord when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Centre.
• Product failure, an electric shock or fire may result.
!
!
-_-
!
Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or defective pixels.
• Activate power-saving mode or a moving-picture screen saver if you will not be using the product for an extended period of time.
Disconnect the power cord from the power socket if you do not plan on using the product for an extended period of time (vacation, etc).
• Dust accumulation combined with heat can cause a fire, electric shock or electric leakage.
Use the product at the recommended resolution and frequency.
• Your eyesight may deteriorate.
Do not hold the product upside-down or move it by holding the stand.
• The product may fall and become damaged or cause an injury.
Looking at the screen too close for an extended period of time can deteriorate your eyesight.
Do not use humidifiers or stoves around the product.
• A fire or electric shock may result.
13
!
!
!
Rest your eyes for more than 5 minutes for every 1 hour of product use.
• Eye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an extended period of time as it will become hot.
Store small accessories out of the reach of children.
Exercise caution when adjusting the product angle or stand height.
• Your hand or finger may get stuck and injured.
• Tilting the product at an excessive angle may cause the product to fall and an injury may result.
Do not place heavy objects on the product.
• Product failure or personal injury may result.
!
!
When using headphones or earphones, do not turn the volume too high.
• Having the sound too loud may damage your hearing.
Be careful that children do not place the battery in their mouths when removed from the remote control. Place the battery in a location that children or infants cannot reach.
• If children have had the battery in their mouths, consult your doctor immediately.
When replacing the battery, insert it with the right polarity (+, -).
• Otherwise, the battery may become damaged or it may cause fire, personal injury or damage due to leakage of the internal liquid.
Use only the specified standardized batteries, and do not use a new battery and a used battery at the same time.
• Otherwise, the batteries may be damaged or cause fire, personal injury or damage due to a leakage of the internal liquid.
The batteries (and rechargeable batteries) are not ordinary refuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling.
• The customer can return used or rechargeable batteries to a nearby public recycling Centre or to a store selling the same type of the battery or rechargeable battery.
14
Chapter 02
Preparations
Checking the Contents
Removing the Packaging
― The following images are for reference only. Real-life situations may differ from what is shown in the images.
1 Remove the black locking device at the bottom of the box.
2
Remove the styrofoam from the product.
3
Check the product and remove the styrofoam and plastic bag.
― The appearance of the actual product may differ from the image shown.
― This image is for reference only.
4
Store the box in a dry area so that it can be used when moving the product in the future.
15
Contact the vendor where you purchased the product if any components are missing.
The appearance of the components and items sold separately may differ from the image shown.
A stand is not provided with the product.
To install a stand, you can purchase one separately.
Checking the Components
Components
― Components may differ in different locations.
Quick setup guide
Warranty card
(Not available in some locations)
-
+
+
Batteries Remote Control
User manual
Power cord
MagicInfo Lite Edition Software
CD
D-SUB cable
16
The following items can be purchased at your nearest retailer.
Items sold separately
Wall-mount Kit Stand RS232C-Stereo cable (
DVI cable (
) HDMI-DVI cable (
HDMI cable (
) Video cable (
)
The RS232C adapter can be used to connect to another monitor using the
D-SUB (9-pin) type RS232C cable.
Ensure you connect each of the adapters to the correct RS232C IN or OUT port on the product.
AV/Component adapter (
Stereo cable
Component cable (
) RCA stereo cable (
RCA cable (
RS232C(IN) adapter RS232C(OUT) adapter LAN cable
Network Box
DP-DVI cable
(Used to connect a network box)
17
Parts
Control Panel
Panel Key
Speaker
POWER
― The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.
Panel Key
Buttons Description
Power on the product.
If you press the button when the product is turned on, the control menu will be displayed.
― To exit the OSD menu, press and hold the panel key for at least one second.
Remote sensor
Move to the upper or lower menu. You can also adjust the value of an option.
Move to the left or right menu.
― You can adjust the volume by moving the panel key left or right when the control menu is not displayed.
Receives signals from the remote.
― Using other display devices in the same space as the remote control of this product can cause the other display devices to be inadvertently controlled.
Remote sensor
18
― If you press the button on the panel key (
) when the product is turned on,
the control menu will be displayed.
Control menu
Buttons
CONTENT
Return
CONTENT
Source
MENU
Contents Home
Power off
Description
Select the connected input source.
Move the panel key right to select Source in the control menu. When the list of input sources is displayed, move the panel key up or down to select the desired input source. Next, press the panel key.
Display the OSD menu.
Move the panel key left to select menu in the control menu. The OSD control screen will appear. Move the panel key right to select the desired menu. You can select a sub-menu item by moving the panel key up, down, left, or right. To change settings, select the desired menu and press the panel key.
Enter Contents Home mode.
Move the panel key up to select Contents Home
CONTENT
in the control menu.
Power off the product.
Move the panel key down to select Power off in the control menu. Next, press the panel key.
Return Exit the control menu.
19
Reverse Side
― The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.
HDMI IN
DVI IN /
MAGICINFO IN
USB
COMPONENT
IN
RGB IN
Port
RS232C IN
RS232C OUT
AUDIO OUT
RGB / DVI / HDMI / AV / COMPONENT /
AUDIO IN
USB
HDMI IN
DVI IN / MAGICINFO IN
RGB IN
AV IN / COMPONENT IN
RJ45
Description
Connects to MDC using an RS232C-stereo adapter.
Connects to the audio of a source device.
Receives sound from a PC via an audio cable.
Connect to a USB memory device.
Connects to a source device using an HDMI cable.
DVI IN: Connects to a source device using a DVI cable or HDMI-DVI cable.
MAGICINFO IN: To use MagicInfo, make sure to connect the DP-DVI cable.
Connects to a source device using a D-SUB cable.
Connects to a source device using the AV/Component adapter.
Connects to MDC using a LAN cable.
RGB / DVI /
HDMI / AV /
COMPONENT
/ AUDIO IN
AUDIO OUT
RJ45
RS232C
OUT IN
20
Anti-theft Lock
― An anti-theft lock allows you to use the product securely even in public places.
― The locking device shape and locking method depend on the manufacturer. Refer to the user guide provided with your anti-theft locking device for details.
― Stand: Sold separately
To lock an anti-theft locking device:
1
Fix the cable of your anti-theft locking device to a heavy object such as a desk.
2
Put one end of the cable through the loop on the other end.
3
Insert the locking device into the anti-theft lock slot at the back of the product.
4
Lock the locking device.
An anti-theft locking device can be purchased separately.
Refer to the user guide provided with your anti-theft locking device for details.
Anti-theft locking devices can be purchased at electronics retailers or online.
21
Remote Control
― Using other display devices in the same space as the remote control of this product can cause the other display devices to be inadvertently controlled.
Power on the product.
Adjust the volume.
Change the input source.
MagicInfo Lite , MagicInfo Premium S ,
MagicInfo Videowall S Launch Button.
The buttons can vary according to the
Play Mode settings.
.QZ
1
GHI
4
PRS
7
DEL-/--
ABC
2
JKL
5
TUV
8
SYMBOL
0
CONTENT
(HOME)
VOL
SOURCE
OFF
DEF
3
MNO
6
WXY
9
MUTE
CH
MagicInfo
Lite/S
MENU
BLANK
Power off the product.
Number buttons
Enter the password in the OSD menu.
Mute the sound.
Unmuting the sound: Press MUTE again or press the volume control(+ VOL -) button.
Contents Home Launch Button.
Temporarily turn off the video and mute the audio.
Disabling the BLANK function
- Press BLANK one more time.
- Press SOURCE.
- Turn the product off and then on again.
Display or hide the onscreen display menu, or return to the previous menu.
Remote control button functions may differ for different products.
22
TOOLS INFO
Quickly select frequently used functions.
Return to the previous menu.
RETURN EXIT
PC
A
MagicInfo
DVI
B
3D
HDMI
C
LOCK
DP
D
MagicInfo Quick Launch Button.
This button is disabled for products that do not support MagicInfo.
MagicInfo can only be enabled when a network box is connected.
Display information about the current input source.
Move to the upper, lower, left or right menu, or adjust an option's setting.
Confirm a menu selection.
Exit the current menu.
Manually select a connected input source from
PC , DVI , HDMI .
It sets safe lock function.
Use these buttons in Videos , Photos , Music and
Anynet+ modes.
Remote control button functions may differ for different products.
To place batteries in the remote control
23
Adjusting the OSD with the Remote Control
Buttons Description
1
Open the OSD menu.
2
Select from Picture , Sound , Network , System or
Support in the displayed OSD menu screen.
Remote Control Reception Range
30˚
30˚
3 Change settings as desired.
4 Finish setting.
5 Close the onscreen display (OSD) menu.
Use the remote control within 7m to 10m from the sensor on the product at an angle of 30 from the left and right.
― Store used batteries out of reach of children and recycle.
― Do not use a new and used battery together. Replace both batteries at the same time.
― Remove batteries when the remote control is not to be used for an extended period of time.
24
Before Installing the Product (Installation
Guide)
15 ˚
To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
• Ensure that an authorized installation company installs the wall mount.
• Otherwise, it may fall and cause personal injury.
• Make sure to install the specified wall mount.
Tilting Angle and Rotation
― Contact Samsung Customer Service Centre for further details.
• The product can be tilted at a maximum angle of 15 from a perpendicular wall surface.
• To use the product vertically (portrait), turn it clockwise so that the LED is pointing down.
Ventilation
Installation on a Perpendicular Wall
A Minimum 40 mm
B Ambient temperature: Under 35 C
• When installing the product on a perpendicular wall, allow at least 40 mm of space between the product and wall surface for ventilation and ensure that the ambient A temperature is kept below 35 C.
A
B
Figure 1.1 Side view
25
B
A
E
C
Figure 1.2 Side view
Dimensions
2
1
Figure 1.3 Side view
D
4
3
D
Installation on an Indented Wall
― Contact Samsung Customer Service Centre for further details.
Plane view
A Minimum 40 mm
B Minimum 70 mm
C Minimum 50 mm
D Minimum 50 mm
E Ambient temperature: Under 35 C
― When installing the product on an indented wall, allow at least the space specified above between the product and wall for ventilation and ensure that the ambient temperature is kept below 35 C.
5
Model name
SMT-3231
SMT-4031
1
736.0 ( 29)
925.4 (36.4)
1 2
703.4 (27.7)
890.6 (35.1)
2 3
397.8 (15.7)
503.2 (19.8)
3 4
436.0 (17.2)
542.6 (21.4)
4 5
Unit: mm (inches)
93.5 (3.68)
93.5 (3.68)
― All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice.
Refer to the dimensions prior to performing installation of your product. Not responsible for typographical or printed errors.
26
Installing the Wall Mount
Installing the Wall Mount Kit
The wall mount kit (sold separately) allows you to mount the product on the wall.
For detailed information on installing the wall mount, see the instructions provided with the wall mount.
We recommend you contact a technician for assistance when installing the wall mount bracket.
Samsung Techwin is not responsible for any damage to the product or injury to yourself or others if you elect to install the wall mount on your own.
Wall Mount Kit Specifications (VESA)
― Install your wall mount on a solid wall perpendicular to the floor. Before attaching the wall mount to surfaces other than plaster board, please contact your nearest dealer for additional information.
If you install the product on a slanted wall, it may fall and result in severe personal injury.
• Samsung wall mount kits contain a detailed installation manual and all parts necessary for assembly are provided.
• Do not use screws that are longer than the standard length or do not comply with the VESA standard screw specifications. Screws that are too long may cause damage to the inside of the product.
• For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ depending on the wall mount specifications.
• Do not fasten the screws too firmly. This may damage the product or cause the product to fall, leading to personal injury.
Samsung is not liable for these kinds of accidents.
• Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.
• Do not mount the product at more than a 15 degree tilt.
• Always have two people mount the product on a wall.
• Standard dimensions for wall mount kits are shown in the table below.
27
Unit: mm (inches)
Model name VESA screw hole specs (A * B) in millimeters
Standard Screw Quantity
SMT-3231
200 × 200 / 7.9 × 7.9 M6 4
SMT-4031
― Do not install your Wall Mount Kit while your product is turned on. It may result in personal injury due to electric shock.
28
Remote Control (RS232C)
Cable Connection
RS232C Cable
Interface
Pin
Bit rate
Data bits
Parity
Stop bit
Flow control
Maximum length
RS232C (9 pins)
TxD (No.2), RxD (No.3), GND (No.5)
9600 bps
8 bit
None
1 bit
None
15 m (only shielded type)
• Pin assignment
1 2 3 4 5
6
7
8
9
3
4
5
Pin
1
2
6 7 8 9
Signal
Detect data carrier
Received data
Transmitted data
Prepare data terminal
Signal ground
Prepare data set
Send request
Clear to send
Ring indicator
29
• RS232C cable
Connector: 9-Pin D-Sub to Stereo Cable
9 5
6
-P1-
1
-P1-
Female Rx
Tx
Gnd
-P1-
2
3
5
-------->
<--------
----------
-P2-
3
2
5
Tx
Rx
Gnd
-P2-
STEREO
PLUG
(3.5ø)
3
2
1
-P2-
LAN Cable
• Pin assignment
6
7
8
4
5
2
3
1
Pin No
1 2 3 4 5 6 7 8
Standard Colour
White and orange
Orange
White and green
Blue
White and blue
Green
White and brown
Brown
Signal
TX+
RX-
NC
NC
NC
NC
TX-
RX+
30
Signal
TX+
TX-
RX+
RX-
• Connector : RJ45
Direct LAN cable (PC to HUB)
HUB
P2
RJ45
P1
P1
P2
RJ45 MDC
2
3
6
P1
1 <-------->
<-------->
<-------->
<-------->
2
3
6
P2
1
Signal
TX+
TX-
RX+
RX-
Cross LAN cable (PC to PC)
RJ45 P1
Signal
TX+
TX-
RX+
RX-
2
3
6
P1
1
P2
<-------->
<-------->
<-------->
<-------->
6
1
2
P2
3
Signal
RX+
RX-
TX+
TX-
31
Connection
• Connection 1
IN
RS232C
OUT IN
RS232C
OUT IN
RS232C
OUT IN
RS232C
OUT
• Connection 2
RJ45
• Connection 3
RJ45
RJ45 RS232C
OUT IN
RS232C
OUT IN
RS232C
OUT IN
RS232C
OUT
32
Control Codes
Viewing control state (Get control command)
Header Command ID Data length Checksum
0xAA Command type 0
Controlling (Set control command)
Header Command ID Data length
0xAA Command type 1
8
9
5
6
7
2
3
4
Command
No.
Command type
1 Power control
Volume control
Input source control
Screen mode control
Screen size control
PIP on/off control
Auto adjustment control (PC and
BNC only)
Video wall mode control
Safety Lock
Command
0x11
0x12
0x14
0x18
0x19
0x3C
0x3D
0x5C
0x5D
Data
Value
0~1
0~1
Checksum
Value range
0~1
-
0~100
-
0~255
0~1
0
No.
10
11
Command type
Video Wall On
Video Wall User Control
Command
0x84
0x89
Value range
-
0~1
• All communications take place in hexadecimals. The checksum is calculated by adding up all values except the header. If a checksum adds up to be more than 2 digits as shown below
(11+FF+01+01=112), the first digit is removed.
E.g. Power On & ID=0
Header
0xAA
Command
0x11
ID Data length
1
Data 1
"Power"
Checksum
Header
0xAA
Command
0x11
ID Data length
1
Data 1
1
12
• To control all devices connected by a serial cable simultaneously irrespective of IDs, set the ID as
"0xFE" and transmit commands. Commands will be executed by each device but ACK will not respond.
33
Power control
• Function
A product can be powered on and off using a PC.
• Viewing power state (Get Power ON / OFF Status)
Header Command ID Data length
0xAA 0x11 0
Checksum
• Setting power ON/Off (Set Power ON / OFF)
Header Command ID Data length
0xAA 0x11 1
"Power": Power code to be set on a product.
1: Power ON
0: Power OFF
• Ack
Header Command ID Data length
0xAA 0xFF 3
Ack/Nak
'A'
Data
"Power" r-CMD
0x11
"Power": Power code to be set on a product.
• Nak
Header Command ID Data length
0xAA 0xFF 3
"ERR" : A code showing what error has occurred.
Ack/Nak
'N' r-CMD
0x11
Checksum
Val1
"Power"
Checksum
Val1
"ERR"
Checksum
Volume control
• Function
The volume of a product can be adjusted using a PC.
• Viewing volume state (Get Volume Status)
Header Command ID Data length
0xAA 0x12 0
Checksum
• Setting the volume (Set Volume)
Header
0xAA
Command
0x12
ID Data length
1
"Volume": Volume value code to be set on a product. (0-100)
• Ack
Header Command ID Data length Ack/Nak
0xAA 0xFF 3 'A'
Data
"Volume" r-CMD
0x12
"Volume": Volume value code to be set on a product. (0-100)
• Nak
Header Command ID Data length Ack/Nak
0xAA 0xFF 3 'N' r-CMD
0x12
"ERR" : A code showing what error has occurred.
Val1
"ERR"
Checksum
Val1
"Volume"
Checksum
Checksum
34
Input source control
• Function
The input source of a product can be changed using a PC.
• Viewing input source state (Get Input Source Status)
Header Command ID Data length Checksum
0xAA 0x14 0
• Setting the input source (Set Input Source)
Header Command ID Data length
0xAA 0x14 1
Data
"Input Source"
Checksum
"Input Source": An input source code to be set on a product.
0x14 PC
0x1F
0x30
0x40
0x21
0x18
0x0C
0x08
0x20
DVI
Input source
Component
MagicInfo
DVI_video
RF(TV)
DTV
HDMI
0x22 HDMI_PC
― DVI_video, HDMI_PC cannot be used with the Set command. They only respond to "Get" commands.
― This model does not support HDMI, HDMI_PC ports.
― MagicInfo is only available with models that contain the MagicInfo function.
― RF(TV), DTV are only available with models that include a TV.
• Ack
Header Command ID Data length Ack/Nak r-CMD Val1
0xAA 0xFF 3 'A' 0x14 "Input
Source"
"Input Source": An input source code to be set on a product.
• Nak
Header Command ID Data length Ack/Nak
0xAA 0xFF 3 'N'
"ERR" : A code showing what error has occurred.
r-CMD
0x14
Val1
"ERR"
Checksum
Checksum
35
Screen mode control
• Function
The screen mode of a product can be changed using a PC.
Screen mode cannot be controlled when the Video Wall function is enabled.
― This control can only be used on models that include a TV.
• Viewing screen status (Get Screen Mode Status)
Header Command ID Data length Checksum
0xAA 0x18 0
• Setting the picture size (Set Picture Size)
Header Command ID Data length
0xAA 0x18 1
Data
"Screen Mode"
"Screen Mode": A code that sets the product status
0x01 16 : 9
0x04
0x31
0x0B
Zoom
Wide Zoom
4 : 3
• Ack
Header
0xAA
Command
0xFF
ID Data length Ack/Nak
3 'A' r-CMD
0x18
Checksum
Val1
"Screen
Mode"
"Screen Mode": A code that sets the product status
Checksum
• Nak
Header
0xAA
Command
0xFF
ID Data length Ack/Nak
3 'N' r-CMD
0x18
Val1
"ERR"
"ERR": A code showing what error has occurred
Screen size control
• Function
The screen size of a product can be changed using a PC.
• Viewing the screen size (Get Screen Size Status)
Header Command ID Data length Checksum
0xAA 0x19 0
• Ack
Header Command ID Ack/Nak r-CMD
0xAA 0xFF
Data length
3 'A' 0x19
Val1
"Screen Size"
"Screen Size": product screen size (range: 0 – 255, unit: inch)
• Nak
Header Command ID Data length
Ack/Nak r-CMD
0xAA 0xFF 3 'N' 0x19
"ERR": A code showing what error has occurred
Val1
"ERR"
Checksum
Checksum
Checksum
36
PIP On/Off control
• Function
The PIP mode of a product can be turned on or off using a PC.
― Only available on models that have the PIP function.
― The mode cannot be controlled if Video Wall is set to On .
― This function is not available in MagicInfo .
• Viewing PIP on/off state (Get the PIP ON / OFF Status)
Header Command ID Data length Checksum
0xAA 0x3C 0
• Setting PIP on/off (Set the PIP ON / OFF)
Header Command ID Data length
0xAA 0x3C 1
Data
"PIP"
"PIP": A code used to turn the PIP mode of a product on or off
1: PIP ON
0: PIP OFF
• Ack
Header Command ID Data length
Ack/Nak r-CMD
0xAA 0xFF 3 'A' 0x3C
Val1
"PIP"
Checksum
Checksum
"PIP": A code used to turn the PIP mode of a product on or off
• Nak
Header Command ID Data length
Ack/Nak r-CMD
0xAA 0xFF 3 'A' 0x3C
"ERR": A code showing what error has occurred
Val1
"PIP"
Checksum
Auto adjustment control (PC and BNC only)
• Function
Automatically adjust the PC system screen using a PC.
• Viewing auto adjustment state (Get Auto Adjustment Status)
None
• Setting auto adjustment (Set Auto Adjustment)
Header Command ID Data length Data
0xAA 0x3D 1 "Auto
Adjustment"
"Auto Adjustment" : 0x00 (at all times)
• Ack
Header Command ID Data length
0xAA 0xFF 3
Ack/Nak
'A' r-CMD
0x3D
Val1
Checksum
"Auto
Adjustment"
Checksum
• Nak
Header Command ID Data length
3 0xAA 0xFF
"ERR": A code showing what error has occurred
Ack/Nak
'A' r-CMD
0x3D
Val1
"ERR"
Checksum
37
Video Wall Mode Control
• Function
Video Wall mode can be activated on a product using a PC.
This control is only available on a product whose Video Wall is enabled.
• Viewing video wall mode (Get Video Wall Mode)
Header Command ID Data length Checksum
0xAA 0x5C 0
• Setting the video wall (Set Video Wall Mode)
Header Command ID Data length
0xAA 0x5C 1
Data
"Video Wall Mode"
"Video Wall Mode": A code used to activate Video Wall mode on a product
1: Full
0: Natural
• Ack
Header Command ID Data length
Ack/Nak r-CMD Val1
0xAA 0xFF 3 'A' 0x5C "Video Wall
Mode"
"Video Wall Mode": A code used to activate Video Wall mode on a product
• Nak
Header Command ID Data length
Ack/Nak r-CMD Val1
0xAA 0xFF 3 'A' 0x5C "ERR"
"ERR": A code showing what error has occurred
Checksum
Checksum
Checksum
Safety Lock
• Function
PC can be used to turn the Safety Lock function on or off on a product.
This control is available regardless of whether or not the power is turned on.
• Viewing the safety lock state (Get Safety Lock Status)
Header Command ID Data length Checksum
0xAA 0x5D 0
• Enabling or disabling safety lock (Set Safety Lock Enable / Disable)
Header Command ID Data length Data
0xAA 0x5D 1 "Safety Lock"
"Safety Lock": Safety lock code to be set on a product
1: ON
0: OFF
• Ack
Header Command ID Data length
Ack/Nak
0xAA 0xFF 3 'A' r-CMD
0x5D
Val1
Checksum
"Safety Lock"
"Safety Lock": Safety lock code to be set on a product
• Nak
Header Command ID Data length
Ack/Nak
0xAA 0xFF 3 'N'
"ERR": A code showing what error has occurred r-CMD
0x5D
Val1
"ERR"
Checksum
Checksum
38
Video Wall On
• Function
Turn Video Wall on or off on the product from your computer.
• Get Video Wall On/Off Status
Header Command ID Data length Checksum
0xAA 0x84 0
• Set Video Wall On/Off
Header
0xAA
Command
0x84
ID Data length
1
Data
V.Wall_On
• V.Wall_On: Video Wall code to be assigned to the product
1: Video Wall ON
0: Video Wall OFF
• Ack
Header Command ID Data length Ack/Nak
0xAA 0xFF 3 'A' r-CMD
0x84
Checksum
Val1
V.Wall_
On
Checksum
V.Wall_On : Same as above
• Nak
Header
0xAA
Command
0xFF
ID Data length Ack/Nak
3 'N' r-CMD
0x84
Val1
ERR
"ERR": A code showing what error has occurred
Video Wall User Control
• Function
Turn the Video Wall function on or off on the product from your computer.
• Get Video Wall Status
Header Command ID Data length Checksum
0xAA 0x89 0
• Set Video Wall
Header
0xAA
Command
0x89
ID Data length
2
Wall_Div: Video Wall Divider code assigned to the product
Val1
Wall_Div
Val2
Wall_SNo
Checksum
Checksum
39
10x10 Video Wall Model
Off
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00
1
2
0x11 0x12 0x13 0x14 0x15 0x16 0x17 0x18 0x19 0x1A 0x1B 0x1C 0x1D 0x1E 0x1F
0x21 0x22 0x23 0x24 0x25 0x26 0x27 0x28 0x29 0x2A 0x2B 0x2C 0x2D 0x2E 0x2F
3
4
5
6
7
8
9
10
11
12
13
14
15
0x31 0x32 0x33 0x34 0x35 0x36 0x37 0x38 0x39 0x3A 0x3B 0x3C 0x3D 0x3E 0x3F
0x41 0x42 0x43 0x44 0x45 0x46 0x47 0x48 0x49 0x4A 0x4B 0x4C 0x4D 0x4E 0x4F
0x51 0x52 0x53 0x54 0x55 0x56 0x57 0x58 0x59 0x5A 0x5B 0x5C 0x5D 0x5E 0x5F
0x61 0x62 0x63 0x64 0x65 0x66 0x67 0x68 0x69 0x6A 0x6B 0x6C 0x6D 0x6E 0x6F
0x71 0x72 0x73 0x74 0x75 0x76 0x77 0x78 0x79 0x7A 0x7B 0x7C 0x7D 0x7E N/A
0x81 0x82 0x83 0x84 0x85 0x86 0x87 0x88 0x89 0x8A 0x8B 0x8C N/A N/A N/A
0x91 0x92 0x93 0x94 0x95 0x96 0x97 0x98 0x99 0x9A 0x9B N/A N/A N/A N/A
0xA1 0xA2 0xA3 0xA4 0xA5 0xA6 0xA7 0xA8 0xA9 0xAA N/A N/A N/A N/A N/A
0xB1 0xB2 0xB3 0xB4 0xB5 0xB6 0xB7 0xB8 0xB9 N/A N/A N/A N/A N/A N/A
0xC1 0xC2 0xC3 0xC4 0xC5 0xC6 0xC7 0xC8 N/A N/A N/A N/A N/A N/A N/A
0xD1 0xD2 0xD3 0xD4 0xD5 0xD6 0xD7 N/A N/A N/A N/A N/A N/A N/A N/A
0xE1 0xE2 0xE3 0xE4 0xE5 0xE6 0xE7 N/A N/A N/A N/A N/A N/A N/A N/A
0xF1 0xF2 0xF3 0xF4 0xF5 0xF6 N/A N/A N/A N/A N/A N/A N/A N/A N/A
40
...
99
1
2
10x10 Video Wall Model : ( 1 ~ 100)
Set Number Data
0x01
0x02
...
0x63
100 0x64
• Ack
Header
0xAA
Command
0xFF
ID Data length
4
• Nak
Header
0xAA
Command
0xFF
ID Data length
3
"ERR": A code showing what error has occurred
Ack/Nak
'A' r-CMD
0x89
Ack/Nak
'N' r-CMD
0x89
Val1
ERR
Val1
Wall_Div
Val2
Wall_SNo
Checksum
Checksum
41
Chapter 03
Connecting and Using a Source Device
Before Connecting
Check the following before you connect this product with other devices. Devices that can be connected to this product include PCs, camcorders, speakers, set top boxes and DVD/Blu-ray Disc players.
Pre-connection Checkpoints
― Before connecting a source device, read the user manual provided with it.
The number and locations of ports on source devices may differ from device to device.
― Do not connect the power cable until all connections are completed.
Connecting the power cable during connection may damage the product.
― Connect the sound ports correctly: left = white and right = red.
― Check the types of ports at the back of the product you want to connect.
POWER
42
Connecting to a PC
• Do not connect the power cable before connecting all other cables.
Ensure you connect a source device first before connecting the power cable.
• A PC can be connected to the product in a variety of ways.
Select a connection method suitable for your PC.
― Connecting parts may differ in different products.
Connection using the D-SUB cable (Analogue type) Connection using a DVI cable (Digital type)
RGB IN
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
DVI IN /
MAGICINFO IN
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
43
Connection Using an HDMI-DVI Cable
― When you connect a PC to the product using an HDMI-DVI cable, set Edit Name to DVI PC to access video and audio content stored on the PC.
Connection Using an HDMI Cable
HDMI IN
HDMI IN
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
44
Changing the Resolution
― Adjust the resolution and refresh rate in Control Panel on your PC to obtain optimum picture quality.
― The picture quality of TFT-LCDs may degrade if the optimum resolution is not selected.
Changing the Resolution on Windows XP
Go to Control Panel Display Settings, and change the resolution.
Changing the Resolution on Windows Vista
Go to Control Panel Personal Settings Display Settings, and change the resolution.
45
Changing the Resolution on Windows 7
Go to Control Panel Display Screen Resolution, and change the resolution.
Changing the Resolution on Windows 8
Go to Settings Control Panel Display Screen Resolution, and change the resolution.
46
Connecting to a Video Device
• Do not connect the power cable before connecting all other cables.
Ensure you connect a source device first before connecting the power cable.
• You can connect a video device to the product using a cable.
― Connecting parts may differ in different products.
― Press the SOURCE button on the remote control to change the source.
Connection Using the AV Cable
AV IN / COMPONENT IN
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
Connection Using the component Cable
AV IN / COMPONENT IN
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
47
Connection Using an HDMI-DVI Cable
― Audio will not be enabled if the product is connected to a video device using an HDMI-DVI cable. To resolve this, additionally connect an audio cable to the audio ports on the product and video device.
When you connect a video device to the product using an HDMI-DVI cable, set Edit Name to DVI
Devices to access video and audio content stored on the video device.
― Supported resolutions include 1080p (50/60Hz), 720p (50/60Hz), 480p, and 576p.
HDMI IN
Connection Using an HDMI Cable
Using an HDMI cable or HDMI to DVI Cable (up to 1080p)
• For better picture and audio quality, connect to a digital device using an HDMI cable.
• An HDMI cable supports digital video and audio signals, and does not require an audio cable.
To connect the product to a digital device that does not support HDMI output, use an HDMI-DVI and audio cables.
• The picture may not display normally (if at all) or the audio may not work if an external device that uses an older version of HDMI mode is connected to the product. If such a problem occurs, ask the manufacturer of the external device about the HDMI version and, if out of date, request an upgrade.
• Be sure to use an HDMI cable with a thickness of 14 mm or less.
• Be sure to purchase a certified HDMI cable. Otherwise, the picture may not display or a connection error may occur.
• A basic high-speed HDMI cable or one with ethernet is recommended.
This product does not support the ethernet function via HDMI.
RGB / DVI / HDMI / AV / COMPONENT
/ AUDIO IN
HDMI IN
48
Connecting to an Audio System
― Connecting parts may differ in different products.
AUDIO OUT
49
Connecting the network box (Sold separately)
― For details on how to connect to a network box, refer to the user's manual provided with the network box upon purchase.
MagicInfo
To use MagicInfo , a network box (sold separately) must be connected to the product.
― To change the MagicInfo settings, run "MagicinfoSetupWizard" on the desktop.
― For details on how to use MagicInfo , refer to the DVD provided with the network box.
― The information in this section is subject to change without notice for quality improvement.
― If a problem occurs after installing an operating system other than the one provided with the network box, restoring the previous version of the operating system, or installing software that is not compatible with the operating system provided, you will not be able to benefit from technical support and will be charged a fee for a visit from a service technician. A product exchange or refund will also not be available.
MagicInfo Setup Wizard - v.1.12
Select Application - step 1
MagicInfo Pro (LAN, WAN based version)
MagicInfo-i Premium (Web-based version)
Select Later
Entering MagicInfo mode
1
After installing and connecting the network box (sold separately) to the product, power on the product.
2
Press SOURCE on the remote control, and select MagicInfo .
― Connecting the network box to the DVI IN / MAGICINFO IN port on the product will change Source from DVI to MagicInfo .
3
Select the default application you want to run when MagicInfo starts.
< Back(B) Next(N) > Finish Cancel
50
MagicInfo Setup Wizard - v.1.12
Select TCP/IP - step 2
Obtain an IP address automatically
Use the following IP address:
IP address: 192 . 168 . 0 . 102
Subnet mask:
Default gateway:
255 . 255 . 255 . 0
192 . 168 . 0 . 1
Obtain DNS server address automatically
Use the following DNS server address:
Preferred DNS server: 10 . 44 . 33 . 22
Alternate DNS server: 10 . 33 . 22 . 11
< Back(B) Next(N) > Finish Cancel
MagicInfo Setup Wizard - v.1.12
Select Language -step 3
Select the language you want to install on the system for menus and dialogs.
Current Language : Engilsh
Chinese [Traditional]
German
English
French
Italian
Japanese
Korean
Russian
Swedish
Turkish
Chinese [Simplified]
Portuguese
< Back(B) Next(N) > Finish Cancel
4
Enter the IP information.
MagicInfo Setup Wizard - v.1.12
Select Screen Type - step 4
Landscape
Portrait
Do not show again
< Back(B) Apply Finish Cancel
6
Select a display mode.
< Back(B) Next(N) > Finish
5
Select a language. (The default language is English.)
MagicInfo Setup Wizard - v.1.12
Setup Information
1. Application : MagicInfo Pro [LAN,WAN based version\
2. Internet Protocol [TCP/IP]
IP : 192.168.0.102
3. Language : English
4. Screen Type : Landscape
Cancel
7
Double-check the settings you have just configured.
― If the execution icon does not appear, double-click the MagicInfo icon on the desktop. The icon will appear at the bottom right of the screen.
51
Changing the Input source
Source
MENU m → Support → Contents Home → Source → ENTER E
Source
HDMI
AV
Component
PC
DVI
---
---
PC
---
---
MagicInfo ---
Tools Return
The displayed image may differ depending on the model.
Source allows you to select a variety of sources and change source device names.
You can display the screen of a source device connected to the product. Select a source from source list to display the screen of the selected source.
― The input source can also be changed by using the SOURCE button on the remote control.
― The screen may not display correctly if an incorrect source is selected for the source device you want to convert to.
52
Chapter 04
Using MDC
Wake On LAN(WOL):
This feature allows you to power on the product by sending a pre-determined command from an external system to the product over a network.
Make sure the network is capable of data communication with the PC that sends the command to the product. Ensure you have a program that can generate Wake on LAN signals.
Configuring Settings for Multi Control
MENUm→ System → Multi Control → ENTERE
Assign an individual ID to your product.
Configuring settings for Multi Control
• ID Setup
Assign an ID to a set. (Range: 0~99)
Press ▲/▼ to select a number, and press E.
• ID Input
Enter the ID number of the product connected to the input cable for input signal reception.
Enter the number you want using the number buttons on the remote control.
• MDC Connection
Select a method to connect to MDC to receive the MDC signal.
RS232C MDC
Communicates with the MDC via a RS232C MDC cable.
RJ45 MDC
Communicates with the MDC via an RJ45 MDC cable.
― If
MDC Connection is set to RJ45 MDC and the product is powered off, only the WOL function will be enabled. MDC communication will not be available.
― The WOL function is enabled only when MDC Connection is set to RJ45 MDC .
53
MDC Programmeme Installation/Uninstallation
MDC installation can be affected by the graphics card, mother board and network conditions.
If a software installation window is not displayed on the main screen, install with the MDC Unified execution file in the
MDC folder on the CD.
If the directory path is not specified, the programme will be installed in the default directory path.
Select " Launch MDC Unified " and click
" Finish " to run the MDC programme immediately.
The MDC execution icon may not be displayed depending on the PC system or product specifications.
Press F5 if the execution icon is not displayed.
Installation
1
Insert the installation CD into the CD-ROM drive.
2
Click the MDC Unified installation programme.
3
Select a language for installation. Next, click " OK ".
4
When the " Welcome to the InstallShield Wizard for MDC_Unified " screen appears, click " Next ".
5
In the " Licence Agreement " window displayed, select " I accept the terms in the licence agreement " and click " Next ".
6
In the displayed " Customer Information " window, fill out all the information fields and click " Next ".
7
In the displayed " Destination Folder " window, select the directory path you want to install the programme in and click " Next ".
8
In the displayed " Ready to Install the Programme " window, check the directory path to install the programme in and click " Install ".
9
Installation progress will be displayed.
10
Click " Finish " in the displayed " InstallShield Wizard Complete " window.
11
The MDC Unified shortcut icon will be created on the desktop after installation.
Uninstallation
1 Select Settings > Control Panel on the Start menu and double-click Add/Delete Programme.
2 Select MDC Unified from the list and click Change/Remove.
54
Multiple display control "MDC" is an application that allows you to easily control multiple display devices simultaneously using a PC.
What is MDC?
Connecting to MDC
Using MDC via RS-232C (serial data communications standards)
An RS-232C serial cable must be connected to the serial ports on the PC and monitor.
RS232C OUT / IN
Computer
Monitor 2
Monitor 1
55
Using MDC via Ethernet
Enter the IP for the primary display device and connect the device to the PC. One display device can connect to another using an RS-232C serial cable.
Connection using a direct LAN cable
― Multiple products can be connected using the RJ45 port on the product and the LAN ports on the HUB.
Monitor 1
RJ45
HUB
Monitor 2
Computer
56
Connection using a cross LAN cable
― Multiple products can be connected using the RS232C IN / OUT port on the product.
Monitor 1
RJ45 RS232C OUT
Monitor 2
Computer
57
Connection Management
Connection management includes the Connection list and Connection list modification options.
Connection list - Connection list shows the details of the connections such as connection setting (IP/COM, Port No, MAC, and Connection Type), connection status, Set ID
Range , and detected devices.
Each connection can contain a maximum of 100 devices connected in serial daisy-chain fashion. All the LFDs detected in a connection are displayed in the Device list, where the user can make groups and send commands to detected devices.
Connection list modification options - Connection modification options includes Add , Edit , Delete , and Refresh .
58
User Login
Launching the programme displays the user login window.
The initial login ID ( password : admin) and password ( Auto Login : admin) are set to admin.
― After logging in for the first time, make sure to change the password to ensure security.
― To change the password, go to Home > User Settings .
After you are logged in, [ User Login : admin ] appears at the right bottom of the programme.
To log in automatically when the programme restarts, select the Auto Login checkbox in the User Login window.
59
Auto Set ID
Auto Set ID feature assigns a Set ID for all the LFDs connected in daisy-chain of a selected connection.
There can be a maximum of 100 LFDs in a connection.
The Set ID is assigned sequentially in the daisychain running from 1 to 99, and then finally to Set ID 0.
― ID for the last 100th LFD is set to 0.
60
Cloning
Using the Cloning feature, you can copy the setting of one LFD and apply it to multiple selected LFDs.
You can select specific tab categories or all tab categories for cloning, using the copy setting option window.
― To delete the settings you have configured, click the
Paste Settings button.
61
Command Retry
This feature is used to specify the maximum number of times the MDC command will be retried in case of there being no reply or a corrupted reply from an LFD.
The retry count value can be set using the MDC options window.
The retry count value must be between 1-10. The default value is 1.
62
Getting Started with MDC
1
To start the programme, click Start → Programmes → Samsung → MDC Unified.
The login window appears after the MDC programme is launched.
Enter the user ID and password.
• The default user ID and password are admin.
• Make sure to change the password after the first login.
2
Click Add to add a display device.
SET ID Range : Select a range of the unique ID assigned to a monitor.
If the connection is established via RS232C, go to Serial and specify the COM Port .
If the connection is established via Ethernet , enter the IP that was entered for the display device.
63
Main Screen Layout
Menus
Home
2
3
4
1
1 6
5
1 Menu Bar
2 Device Category
3 Schedule Category
4 Set List
5 Modify the Set List
6 Help Topics
Change the status of a display device or the properties of the programme.
View a list of connected display devices or device groups.
View a list of schedules for display devices.
Select the display device you want to adjust.
Add, edit, regroup or delete sets.
Display help topics for the programme.
You can power on or off a selected device or change the input source or volume of the device.
Choose display devices from the list of sets, and select the Home tab.
Select an item and change the corresponding setting.
Power
• On : Power on a selected display.
• Off : Power off a selected display.
Input
2 3
• Input Source : Change the input source.
Input sources available can vary depending on the Display Device Models.
The input source can be changed only for displays that are turned on.
• Channel : Change the channel.
The TV channel can be changed by using the up/down arrow keys.
The channel can be changed only when the input source is TV .
Only registered channels can be selected.
Only applicable to models that support TVs.
64
1
1
Volume
2
2
Alert
3
3
― The volume can be changed or the sound can be muted only for displays that are turned on.
Volume
• Adjust the volume of a selected display.
• The volume can be adjusted using the slider bar in the range of 0 to 100.
Mute
• Enable or disable Mute for a selected display.
Mute will automatically be disabled if Volume is adjusted when Mute is on.
Fault Device
• This menu shows a list of display devices which have following errors - fan error, temperature error, brightness sensor error, or lamp error.
• Select a display device from the list. The Repair button will be enabled.
• Click the Refresh button to refresh the error status of the display device. The recovered display device will disappear from the Fault Device List .
Fault Device Alert
• Display device in which error is detected will be reported by email.
• Fill in all required fields. The Test and OK buttons will be enabled.
Ensure the Sender information and at least one Recipient are entered.
65
User Login
Screen Adjustment
Custom
User Settings
• Add, delete or edit login information.
Logout
• Log out from the current user account as follows.
• Click Logout . The message " Do you want to log admin out?
" is displayed
• Click Yes . The user login window appears.
• If you do not want to log in, click Close . The programme is closed.
― If you close the programme using Logout , the login window will appear prompting you to enter user information even if the Auto Login checkbox is selected.
The screen settings (contrast, brightness, etc.) can be adjusted.
Choose display devices from the list of sets, and select the Picture tab.
Select an item and change the corresponding screen setting.
Picture Mode
• Adjust the picture mode for the selected display device.
Contrast
• Adjust the contrast for the selected display device.
Brightness
• Adjust the brightness for the selected display device.
66
Color
Color and Tint (G/R) are not available if the input source is PC .
Color , Tint (G/R) , Color Tone and Color Temp.
are not available if both PC Source and Video
Source are selected.
Color
• Adjust the colours for the selected display device.
Tint (G/R)
• Adjust the tint for the selected display device.
Color Tone
• Adjust the background colour tone for the selected display device.
Color Temp.
• Adjust the colour temperature for the selected display device.
― This option is enabled if Color Tone is set to Off .
HDMI Black Level
• Adjust the HDMI Black Level for the selected display device.
Options Auto Motion Plus
This option is used to view dynamic images.
• Off : Disable the Auto Motion Plus function.
• Clear : Set the level of Auto Motion Plus to clear. This mode is suitable to display vivid images.
• Standard : Set the level of Auto Motion Plus to standard.
• Smooth : Set the level of Auto Motion Plus to smooth. This mode is suitable to display smooth images.
• Custom : Customize the level of screen burn-in or flickering.
• Demo : This function demonstrates the technology of Auto Motion Plus . The result when the mode is changed can be previewed on the left side of the window.
― Auto Motion Plus may not be available depending on the product.
• Detail : View detailed information about the selected display device.
Brightness Sensor
• Enable or disable the Brightness Sensor for the selected display device.
• The Brightness Sensor detects the ambient light intensity and automatically adjusts the screen brightness.
― Brightness Sensor may not be available depending on the product.
67
Size
MPEG Noise Filter
Reduces MPEG noise to provide improved picture quality.
• Off / Low / Medium / High / Auto
Smart LED
Controls the LED backlight to maximize picture clarity.
Cinema Black
In Movie mode, this feature dims the top and bottom areas of the video image to provide a more immersive viewing experience.
• Off : Turns off the Cinema Black feature.
• On : Adjusts the dimming of the top and bottom areas of the screen according to the video.
Picture Size
• Adjust the screen size for the selected display device.
• The Detail item will be disabled if Picture Size is set to a mode that does not support detailed configuration.
• The -/+ buttons can be used to adjust Zoom .
• The screen can be relocated using the up/down/left/right buttons.
Detail
• You can view details of the selected screen size.
PC Screen Adjustment
• Frequency adjustment or fine-tuning is available by using the -/+ buttons in Coarse or Fine .
• To relocate the screen, click one of the four images below Position .
• To automatically adjust the frequency, fine-tune or relocate the screen, click Auto Adjustment .
68
Advanced features
3D Control
3D Mode
Select the 3D input format.
3D L/R Change
Swap the left and right pictures.
3D → 2D
Displays the image for the left eye only.
3D Auto View
If you set 3D Auto View to Message Notice , a pop up message window appears when the product receives a 3D signal.
3D Optimization
The overall adjustment of 3D effect.
3D Expert Pattern
View a 3D pattern.
3D Effect
Adjust 3D effects like perspective and depth for your preferred 3D viewing experience.
• Auto : Automatically adjust the perspective and depth settings in accordance with the 3D input source.
• Manual : Manually adjust the perspective and depth settings.
69
Advanced Settings Dynamic Contrast
Adjust the screen contrast.
Gamma Control
Adjust the primary colour intensity.
RGB Only Mode
Displays the Red , Green and Blue colour for making fine adjustments to the hue and saturation.
Flesh Tone
Emphasize pink “Flesh Tone.”
Motion Lighting
Reduces power consumption by reducing screen brightness when the picture on the screen is in motion.
LED Motion Plus
Removes blur and judder from scenes with larger amounts of rapid movement to provide a clearer picture.
Color Space
Adjusts the range and variety of colour (the colour space) available to create images.
• Auto / Native / Custom
To adjust Color , Red , Green , Blue and Reset , set Color Space to Custom .
White Balance
Adjust the colour temperature for a more natural picture.
• R-Offset / G-Offset / B-Offset
Adjust each colour (red, green, blue) darkness.
• R-Gain / G-Gain / B-Gain
Adjust each colour (red, green, blue) brightness.
• Reset
Resets the White Balance to it’s default settings.
70
Sound Adjustment
The Bass or Treble item will be disabled if the item is not supported by the selected set.
You can change the sound settings.
Choose display devices from the list of sets, and select the Sound tab.
Bass
• Adjust the bass for the selected display.
Treble
• Adjust the treble for the selected display.
Balance(L/R)
• Adjust the volume of the left and right speakers of the selected display device.
SRS TS XT
• Enable or disable the SRS TS XT effect for the selected display device.
System Setup
Video Wall
Choose display devices from the list of sets, and select the System tab.
The Video Wall function can be used to display part of a whole picture or repeat the same picture on each of connected multiple display devices.
― Video Wall is enabled only when devices are in the group.
Video Wall
• Enable or disable Video Wall .
71
Format
• Select the format to display the split screen.
PIP
Full Natural
Basic information required to adjust PIP will appear in the menu screen.
PIP will be disabled when Video Wall is On .
Note that Picture Size is disabled when PIP is On .
H
• Select the number of horizontal display devices.
V
• A maximum of 15 displays can be arranged in a row.
― A maximum of 6 can be assigned to
V if 15 is assigned to H .
• Select the number of vertical display devices.
• A maximum of 15 displays can be arranged in a row.
― A maximum of 6 can be assigned to H if 15 is assigned to V .
Screen Position
• View the layout of displays (configured by the screen divider) or change the layout as required.
• Screen Position and Preview are enabled when Video Wall is set to on.
• Note that if multiple sets are selected, Preview is enabled only if the settings for H and V match the layout of the selected sets.
• To change the Position , select a set and drag it to a new position.
― The range of screen divider settings may differ depending on the model.
PIP Size
• View the PIP Size of the current display.
PIP Source
• Select a PIP input source.
Sound Select
• Select and enable the sound from either the primary screen or secondary screen.
Channel
• The channel can be changed if PIP Source is TV .
72
General
Fan & Temperature
User Auto Color
• Automatically adjust the screen colours.
― Available only in PC mode.
Auto Power
• Set the product to automatically power on.
Standby Control
• Set the standby mode to activate if an input source is not detected.
Configure the settings required to detect the fan speed and internal temperature for the product's protection.
Fan Control
• Select a method to configure the fan speed.
Fan Speed Setting
• Configure the fan speed.
Temperature
• Detect the internal temperature by specifying the range of temperature.
73
Security
OSD Display
Safety Lock
• Lock the on-screen menus.
― To unlock the menus, set Safety Lock to Off .
Button Lock
• Lock the buttons on the display device.
― To unlock the buttons, set Button Lock to Off .
Source OSD
• Select whether to display a message when the Source is changed.
Not Optimum Mode OSD
• Select whether to display a message when a non-compatible mode is selected.
No Signal OSD
• Select whether to display a message when there is no input signal.
MDC OSD
• Select whether to display a message when settings are changed by the MDC.
74
Time
Timer
Clock Set
Change the current time on the selected display device according to the time set on a PC.
If the time is not set on the display device, null values will be displayed.
On Timer
• Repeat : Specify the period for which you want to repeat the selected Timer .
Once , EveryDay , Mon~Fri , Mon~Sat , Sat~Sun , Manual
• Holiday Apply : The Holiday Management settings can be applied to the Timer .
• On Time : Set the time to power on the selected display device.
• Volume : Specify the volume of the display device when it is powered on by On Time .
• Source : Specify the input source of the display device when it is powered on by On Time .
Off Timer
• Repeat : Specify the period for which you want to repeat the selected Timer .
Once , EveryDay , Mon~Fri , Mon~Sat , Sat~Sun , Manual
• Holiday Apply : The Holiday Management settings can be applied to the Timer .
• Off Time : Set the time to power off the selected display device.
― The checkboxes to select days of the week below
Repeat are enabled only if Manual is selected.
75
Holiday Management
Screen Burn Protection
Holiday Management allows you to prevent devices that are set to be powered on by the Timer from turning on at a specified date.
― The Holiday Management function can be enabled or disabled in the Timer settings menu.
• Add : You can specify holidays.
Click the Add button in the Holiday Management window.
• Delete : Delete holidays. check the corresponding checkboxes and click this button.
• List of holidays: View a list of holidays you have added.
Pixel Shift
Move the screen slightly at specified time intervals to prevent screen burn-in.
76
Screen Saver
― Period (Hour) and Time (Sec) can be configured when Repeat is selected.
This function prevents screen burn-in when the screen of the selected display device is left idle for an extended period of time.
Timer : You can set the timer for Screen Saver .
• Off
• Repeat : Display the image retention-preventive pattern set in Mode at specified time intervals ( Period ).
• Interval : Display the image retention-preventive pattern set in Mode for a specified period of time (from Start Time to
End Time ).
• Mode : Select a screen protective pattern to display.
• Period (Hour) : Specify the time interval to activate the Screen Saver function.
― The option is enabled when Repeat is selected for Timer .
• Time (Sec) : Specify the duration to keep the Screen Saver function on.
― The option is enabled when
Repeat is selected for Timer .
• Start Time : Set start time to display screen saver.
― The option is enabled when Interval is selected for Timer .
• End Time : Set end time to display screen saver.
― The option is enabled when Interval is selected for Timer .
― Start Time and End Time can be configured when Interval is selected.
77
Safety Screen
Lamp Control
The Safety Screen function can be used to prevent screen burn-in when a stationary image displays on the screen of a display device for an extended period of time.
Lamp Control is used to adjust the backlight to reduce power consumption.
Automatically adjust the backlight of the selected display device at a specified time.
If Manual Lamp Control is adjusted, Auto Lamp Control will automatically switch to Off .
Manually adjust the backlight for the selected display.
If Auto Lamp Control is adjusted, Manual Lamp Control will automatically switch to Off .
• Ambient Light : Ambient Light detects ambient light intensity and automatically adjusts the screen brightness of all the
LFDs in the same serial chain.
78
Ticker Input text while a video or image is displayed and display the text on the screen.
Ticker
Enable or disable Ticker .
• Off / On
Message
Enter a message to display on the screen.
Timer
Set the Start Time and End Time to display a message ( Message ).
Position
Select an orientation to display a message ( Message ) from Horizontal and Vertical .
Motion
Specify the Direction and Speed to display a message ( Message ).
Font Options
Specify the message Size , Foreground Color , Foreground Opacity , Background Color and Background Opacity .
79
Tool Settings
Security
Reset
• Panel Control : Turn on or off the screen of a display device.
• Remote Control : Enable or disable the remote control.
• Reset Picture : Reset the screen settings.
• Reset Sound : Reset the sound settings.
• Reset System : Reset the system settings.
• Reset All : Reset the screen, sound and system settings at the same time.
80
Edit Column
Options
Edit Column
Configure the settings for the items that will be displayed on the list of displays.
• Language : Select a language to use in the MDC programme. After selecting a language, restart the MDC programme to use the selected language.
• Command Retry Count : Specify the number of retry attempts when a command fails.
• Error Status Interval : Specify the time interval to query the display device in order to check if " Fault Device " has occurred.
• Mail Alert Interval : Specify the time interval for email notifications in the event when " Fault Device " occurs.
Select the items you want to display in the list of sets.
81
Monitor Window
Information
A window appears showing details for data transfer between the computer and display devices.
• Filter
View the programme information.
82
Other Functions
Resizing a Window
Place the mouse pointer on a corner of the programme window. An arrow will appear.
Move the arrow to customize the size of the programme window.
83
Group Management
Creating Groups
Create groups and manage the list of sets on a group basis.
― Duplicate group names cannot be used.
1
Right-click and select Group Edit in the display device list section on the left side of the programme window.
The Add on the same level button is enabled only if at least one group is created.
2
In the Edit Group window displayed, click Add on the same level or Add on the sub level .
• Add on the same level : Create a group on the same level as the selected group.
84
Deleting Groups
• Add on the sub level : Create a sub-group under the selected group.
3
Enter the group name.
1
Select a group name, and click Edit .
2
In the Edit Group window displayed, click Delete .
3
Click Yes . The group will be deleted.
85
Renaming Groups
Rename
Schedule Management
1
Select a group name, and click Edit .
2
In the Edit Group window displayed, click Rename .
3
If a cursor appears in the old group name, enter a new group name.
Creating Schedules
Create and register a schedule on a group basis.
1 Click All Schedule List in the schedule section on the left side of the programme window. The Add button will be enabled in the middle.
86
2
Click the Add button. The Add Schedule window will appear.
3
Click Add below the Device Group item, and select the group you want to add a schedule to.
4
Select Date&Time / Action and click OK . The schedule will be added and a list of schedules will appear in the set list window.
Device Group : Select a group.
Date&Time
Instant Execution : Run the schedule immediately.
Timer : Set the date, time and interval to run the schedule.
Action : Select a function that will activate at the specified time and interval.
Schedule Modification
To modify a schedule, select the schedule and click Edit .
Deleting a Schedule
To delete a schedule, select the schedule and click Delete .
87
Troubleshooting Guide
This programme may malfunction sometimes due to a communication problem between the PC and display or electromagnetic waves emitted from nearby electronic devices.
Issue
The display you want to control does not appear on the system information chart.
Solution
1 Check the connection of the RS232C cable (check that the cable is properly connected to appropriate serial port).
2 Check that another display with a duplicate ID is not connected. Connecting displays with a duplicate ID can cause the displays not to be shown due to data collision.
3 Check that the display ID is within the range of 0 and 99. (Change the ID using the Display menu.)
― For a display that supports the ID in a range of 0 to 99, the ID should be set between 0 and 99.
The display you want to control does not appear on the other Control Info Grids.
Check that the display is powered on. (See the power status in the system information chart.)
The following message appears repeatedly.
Ensure you select the input source the display is connected to.
Check that the display you want to control is selected.
Displays power on or off at different time from one another even though On
Time or Off Time is set.
The remote control does not work.
Adjust the time on the PC to synchronize the time between the connected displays.
The remote control may not work if the RS-232C cable is removed or the programme is closed abnormally while the
Remote Control function is Disable . To resolve this, run the programme again and set Remote Control to Enable .
88
How display properties are shown when multiple displays are used
1
When no display is selected: The default value is displayed.
2
When one display is selected: Settings for the selected display are displayed.
3
When two displays are selected (e.g. in sequence of ID 1 and ID 3): The settings for ID 1 are displayed before the settings for ID 3.
4
When the All+Select checkbox is checked and all displays are selected: The default settings are displayed.
89
Chapter 05
Screen Adjustment
Configure the Picture settings ( Backlight , Colour Tone , etc.).
The layout of the Picture menu options may vary depending on the product.
Picture Mode
MENUm → Picture → Picture Mode → ENTERE
Select a picture mode ( Picture Mode ) suitable for the environment where the product will be used.
Different Picture Mode options are displayed depending on the current input source.
Picture Mode
· Backlight
· Contrast
· Brightness
· Sharpness
· Colour
· Tint (G/R) G 50
Information
60
70
45
50
50
R 50
If the input source is PC, DVI
• Information : This mode reduces eye fatigue and is suitable for displaying information to the public.
• Advertisement : This mode is suitable for displaying video content and indoor/outdoor advertisements.
If the input source is AV, Component, HDMI
• Dynamic : This mode is suitable when the ambient light is bright.
• Standard : This mode is generally suitable for any environment.
• Natural : Suitable for reducing eye strain.
• Movie : This mode reduces eye fatigue.
The displayed image may differ depending on the model.
90
Backlight / Contrast / Brightness /
Sharpness / Colour / Tint (G/R)
MENUm → Picture → ENTERE
Picture Mode
· Backlight
· Contrast
· Brightness
· Sharpness
· Colour
· Tint (G/R) G 50
Information
60
70
45
50
50
R 50
Your product has several options for adjusting picture quality.
Input source
PC , DVI , HDMI (when a PC is connected)
Picture Mode
Information
Advertisement
Adjustable options
Backlight / Contrast / Brightness /
Sharpness
Backlight / Contrast / Brightness /
Sharpness / Colour
AV , Component , HDMI Dynamic , Standard , Natural , Movie Backlight / Contrast / Brightness /
Sharpness / Colour / Tint (G/R)
― When you make changes to Backlight , Contrast , Brightness , Sharpness , Colour or Tint (G/R) , the OSD will be adjusted accordingly.
― You can adjust and store settings for each external device you have connected to an input on the product.
― Lowering picture brightness reduces power consumption.
The displayed image may differ depending on the model.
91
Screen Adjustment
MENUm → Picture → Screen Adjustment → ENTERE
Screen Adjustment
Picture Size
· Zoom/Position
PC Screen Adjustment
Resolution Select
16:9
Off
The displayed image may differ depending on the model.
choose size and aspect ratio picture displayed on screen.
Picture Size
― Different Screen Adjustment options are displayed depending on the current input source.
• 16:9 : Sets the picture to 16:9 wide mode.
• Zoom1 : Use for moderate magnification. Cuts off the top and sides.
• Zoom2 : Use for a stronger magnification.
• Smart View 1 : Reduces the 16:9 picture by 50%.
― Smart View 1 is enabled only in HDMI mode.
• Smart View 2 : Reduces the 16:9 picture by 25%.
― Smart View 2 is enabled only in HDMI mode.
• Wide Fit : Enlarges the aspect ratio of the picture to fit the entire screen.
• 4:3 : Sets the picture to basic ( 4:3 ) mode.
― Do not set your product to 4:3 format for a long time.
The borders displayed on the left and right, or top and bottom of the screen may cause image retention (screen burn) which is not covered by the warranty.
• Screen Fit : Displays the full image without any cut-off when HDMI (720p / 1080i / 1080p) or Component (1080i / 1080p) signals are inputted.
• Custom : Changes the resolution to suit the user's preferences.
• Original ratio : If the input source is PC , DVI , HDMI (PC connection), the video will display in the original aspect ratio.
― Available ports may differ depending on the model.
92
Picture Sizes available by Input Source.
Input Source
AV , Component (480i, 480p)
Picture Size
16:9 , Zoom1 , Zoom2 , 4:3 , Custom
Component (1080i, 1080p)
HDMI (720p, 1080i, 1080p)
HDMI (480i, 480p)
PC , DVI , HDMI (when a PC is connected)
16:9 , Wide Fit , Screen Fit , 4:3 , Custom
16:9 , Smart View 1 , Smart View 2 , Wide Fit , 4:3 , Screen Fit ,
Custom
16:9 , Zoom1 , Zoom2 , Smart View 1 , Smart View 2 , 4:3 ,
Custom
16:9 , 4:3 , Original ratio
93
Position
Screen Adjustment
Picture Size
· Position
PC Screen Adjustment
Resolution Select
Zoom1
Off
The displayed image may differ depending on the model.
Zoom/Position
Screen Adjustment
Picture Size
· Zoom/Position
PC Screen Adjustment
Resolution Select
Zoom1
Off
The displayed image may differ depending on the model.
Adjusts the picture position. Position is only available if Picture Size is set to Zoom1 , Zoom2 , Wide Fit , Screen Fit or Custom .
― To use the Position function after selecting Zoom1 , Zoom2 , Wide Fit or Screen Fit , follow these steps.
1
Press the ▼ button to select Position . Press the E button.
2
Press the ▲ or ▼ button to move the picture up or down.
3
Press the E button.
― To use the Zoom/Position function after selecting Screen Fit in HDMI (1080i/1080p) or Component (1080i/1080p) or
Custom , follow these steps.
1
Press the ▼ button to select Zoom/Position . Press the E button.
2
Select the Zoom or Position . Press the E button.
3 Press the ▲/▼/◄/► button to move the picture.
4 Press the E button.
― If you want to reset the picture to its original position, select Reset in the Zoom/Position screen.
The picture will be set to its default position.
94
PC Screen Adjustm
Screen Adjustment
Picture Size
· Zoom/Position
PC Screen Adjustment
Resolution Select
Custom
Available in PC mode only.
The displayed image may differ depending on the model.
Off
Resolution Select
Screen Adjustment
Picture Size
· Zoom/Position
PC Screen Adjustment
Resolution Select
Custom
Off
Available in PC mode only.
The displayed image may differ depending on the model.
• Coarse / Fine
Removes or reduces picture noise.
If the noise is not removed by Fine-tuning alone, use the Coarse function to adjust the frequency as best as possible
( Coarse ) and Fine-tune again. After the noise has been reduced, re-adjust the picture so that it is aligned with the Centre of screen.
• Position
To adjust the PC’s screen position if it is not Centreed or does not fit the product screen.
Press the ▲ or ▼ button to adjust the Vertical Position. Press the ◄ or ► button to adjust the Horizontal Position.
• Image Reset
Resets the image to the default settings.
If the picture is not normal even when the resolution of the graphics card is one of the following, you can optimize the picture quality by selecting the same resolution for the product as the PC using this menu.
Available resolutions: Off / 1024x768 / 1280x768 / 1360x768 / 1366x768
95
Auto Adjustment
MENUm → Picture → Auto Adjustment → ENTERE
Auto Adjustment
Available in PC mode only.
The displayed image may differ depending on the model.
Rotation
MENUm → Picture → Rotation → ENTERE
Rotation
· Aspect Ratio
Landscape
Full Screen
The displayed image may differ depending on the model.
Adjust frequency values/positions and fine tune the settings automatically.
Rotate the product screen orientation.
• Landscape : Display the screen in landscape mode (default).
• Portrait : Display the screen in portrait mode.
― Available in
PC / DVI / HDMI / MagicInfo mode.
96
Aspect Ratio
MENUm → Picture → Aspect Ratio → ENTERE
Rotation Portrait
Full Screen
The displayed image may differ depending on the model.
Set the rotated screen to be either full screen or original.
• Full Screen : Display the rotated screen in full screen.
• Original : Display the rotated screen in the original aspect ratio.
― Available only when Rotation is set to Portrait .
97
Advanced Settings
MENUm → Picture → Advanced Settings → ENTERE
Advanced Settings
Dynamic Contrast
Black Tone
Flesh Tone
RGB Only Mode
Colour Space
White Balance
10p White Balance
Medium
Off
0
Off
Native
Off
The displayed image may differ depending on the model.
Input Source
PC , DVI , HDMI (when a PC is connected)
Picture Mode
Information
Advertisement
AV , Component , HDMI
AV
Natural , Dynamic
Standard
Component , HDMI
Movie
Standard
Movie
Advanced Settings
White Balance / Gamma
Dynamic Contrast / Black Tone / Flesh Tone / Colour Space
/ White Balance / Gamma
Not available
Dynamic Contrast / Black Tone / Flesh Tone / RGB Only
Mode / Colour Space / White Balance / Gamma / Motion
Lighting
Dynamic Contrast / Black Tone / Flesh Tone / RGB Only
Mode / Colour Space / White Balance / 10p White Balance /
Gamma
Dynamic Contrast / Black Tone / Flesh Tone / RGB Only
Mode / Colour Space / White Balance / Gamma / Motion
Lighting
Dynamic Contrast / Black Tone / Flesh Tone / RGB Only
Mode / Colour Space / White Balance / 10p White Balance /
Gamma
98
Advanced Settings
Dynamic Contrast
Black Tone
Flesh Tone
RGB Only Mode
Colour Space
White Balance
10p White Balance
Medium
Off
0
Off
Native
Off
The displayed image may differ depending on the model.
Dynamic Contrast
Adjust the screen contrast.
• Off / Low / Medium / High
Black Tone
Select the black level to adjust the screen depth.
• Off / Dark / Darker / Darkest
Flesh Tone
Emphasize pink Flesh Tone .
RGB Only Mode
Displays the Red , Green and Blue colour for making fine adjustments to the hue and saturation.
• Off / Red / Green / Blue
Colour Space
Adjusts the range and variety of colours (the colour space) available to create images.
• Auto / Native / Custom
― To adjust Colour , Red , Green , Blue and Reset , set Colour Space to Custom .
99
Advanced Settings
White Balance
10p White Balance
Gamma
Motion Lighting
The displayed image may differ depending on the model.
Off
0
Off
White Balance
Adjust the colour temperature for a more natural picture.
• R-Offset / G-Offset / B-Offset : Adjust each colour’s (red, green, blue) darkness.
• R-Gain / G-Gain / B-Gain : Adjust each colour’s (red, green, blue) brightness.
• Reset : Resets the White Balance to its default settings.
10p White Balance
Controls the white balance in 10 point interval by adjusting the red, green, and blue brightness.
• Off / On
Interval : Select interval to adjust.
Red : Adjust the red level.
Green : Adjust the green level.
Blue : Adjust the blue level.
Reset : Resets the 10p White Balance to its default settings.
― Available when the Picture Mode is set to Movie and when the external input is set to all input.
― Some external devices may not support this function.
Gamma
Adjust the primary colour intensity.
Motion Lighting
Reduces power consumption by reducing screen brightness when the picture on the screen is in motion.
• Off / On
100
Picture Options
MENUm → Picture → Picture Options → ENTERE
Picture Options
Colour Tone
Colour Temp.
Digital Noise Filter
MPEG Noise Filter
HDMI Black Level
Film Mode
Standard
10000K
Off
Off
Normal
Off
Off
The displayed image may differ depending on the model.
Select an option using the ▲ and ▼ arrow keys, and the press E.
Use the arrow keys to change the setting, and then press E.
Input source Picture Mode Picture Options
PC , DVI Information Colour Tone / Colour Temp.
/ HDMI Black Level /
Dynamic Backlight
Advertisement Colour Tone / Colour Temp.
/ Digital Noise Filter /
MPEG Noise Filter / HDMI Black Level / Dynamic Backlight
HDMI (when a PC is connected) Information
HDMI
Advertisement
Dynamic , Standard , Natural ,
Movie
Colour Tone / Colour Temp.
/ HDMI Black Level /
Dynamic Backlight
Colour Tone / Colour Temp.
/ Digital Noise Filter /
MPEG Noise Filter / HDMI Black Level / Dynamic Backlight
Colour Tone / Colour Temp.
/ Digital Noise Filter /
MPEG Noise Filter / HDMI Black Level / Dynamic Backlight
AV , Component , HDMI (1080i), Dynamic , Standard , Natural ,
Movie
Colour Tone / Colour Temp.
/ Digital Noise Filter /
MPEG Noise Filter / Film Mode / Dynamic Backlight
101
Picture Options
Colour Tone
Colour Temp.
Digital Noise Filter
MPEG Noise Filter
The displayed image may differ depending on the model.
10000K
Off
Off
Colour Tone
If the input source is PC , DVI or HDMI (PC connection).
• Off / Cool / Standard / Warm
If the input source is AV , Component , HDMI .
• Off / Cool / Standard / Warm1 / Warm2
― Warm1 or Warm2 will be deactivated when the Picture Mode is Dynamic .
― Settings can be adjusted and stored for each external device connected to an input on the product.
Colour Temp.
Adjust the colour temperature ( Red / Green / Blue ). (Range: 3000K–15000K)
― This option is available when Colour Tone is set to Off .
Digital Noise Filter
If the broadcast signal received by your product is weak, you can activate the Digital Noise Filter feature to reduce any static and ghosting that may appear on the screen.
• Off / Low / Medium / High / Auto
― When the signal is weak, try all the options until the the product displays the best picture.
MPEG Noise Filter
Reduces MPEG noise to provide improved picture quality.
• Off / Low / Medium / High / Auto
102
Picture Options
HDMI Black Level
Film Mode
Dynamic Backlight
Normal
Off
Off
The displayed image may differ depending on the model.
HDMI Black Level
Selects the black level on the screen to adjust the screen depth.
• Normal / Low
― Available only in HDMI and DVI mode (AV Timing : 480p, 576p, 720p, 1080i, 1080p).
Film Mode
This mode is suitable to view movies.
Sets the product to automatically sense and process film signals from all sources and adjust the picture for optimum quality.
• Off / Auto1 / Auto2
― Available in AV , Component , HDMI (1080i).
103
Picture Options
HDMI Black Level
Film Mode
Dynamic Backlight
Normal
Off
The displayed image may differ depending on the model.
Reset Picture
MENUm → Picture → Reset Picture → ENTERE
Reset Picture
The displayed image may differ depending on the model.
Dynamic Backlight
Automatically adjust the backlight to provide the best possible screen contrast under the current conditions.
• Off / On
― The Dynamic Backlight is not available when the input source is set to PC , AV Component while Video Wall is On .
Resets your current picture mode to its default settings.
104
Chapter 06
Sound Adjustment
Configure the sound ( Sound ) settings for the product.
Sound Mode
MENUm → Sound → Sound Mode → ENTERE
Sound
Sound Mode
Sound Effect
Speaker Settings
Reset Sound
Standard
The displayed image may differ depending on the model.
You can select a sound mode to suit your personal preferences.
• Standard : Selects the normal sound mode.
• Music : Emphasizes music over voices.
• Movie : Provides the best sound for movies.
• Clear Voice : Emphasizes voices over other sounds.
• Amplify : Increase the intensity of high-frequency sound to allow a better listening experience for the hearing impaired.
― If Speaker Select is set to External , Sound Mode is disabled.
105
Sound Effect
MENUm → Sound → Sound Effect → ENTERE
Sound
Sound Mode
Sound Effect
Speaker Settings
Reset Sound
Standard
The displayed image may differ depending on the model.
Configure your preferred sound effect for output sound.
― If Speaker Select is set to External , Sound Effect is disabled.
― Available only when Sound Mode is set to Standard .
• Virtual Surround ( Off / On )
This function provides a virtual 5.1 channel surround sound experience through a pair of speakers using HRTF(Head
Related Transfer Function) technology.
• Dialog Clarity ( Off / On )
This function allows you to increase the intensity of a voice over background music or sound effects so that dialog can be heard more clearly.
• Equaliser
Use Equaliser to customize sound setting for each speaker.
Balance L/R : Adjusts the balance between the right and left speaker.
100Hz / 300Hz / 1kHz / 3kHz / 10kHz (Bandwidth Adjustment): Adjusts the level of specific bandwidth frequencies.
Reset : Resets the equalizer to its default settings.
106
Speaker Settings
MENUm → Sound → Speaker Settings → ENTERE
Sound
Sound Mode
Sound Effect
Speaker Settings
Reset Sound
Standard
The displayed image may differ depending on the model.
• Speaker Select ( External / Internal )
If you are listening to the sound track of a broadcast or movie through an external receiver, you may hear a sound echo caused by the difference in decoding speed between the products speakers and the speakers attached to your audio receiver. If this occurs, set the product to External .
― When you set Speaker Select to External , the products speakers are turned off.
You will hear sound through the external speakers only. When the Speaker Select is set to Internal , both the product speakers and the external speakers are on. You will hear sound through both.
― If there is no video signal, both the products speakers and the external speakers will be mute.
• Auto Volume ( Off / Normal / Night )
The volume can vary depending on the channel.
Automatically equalize the volume level when switching to another channel.
Normal equalizes the volume level on each channel, so that when you change channels, the volume level is the same.
Night equalizes and decrease the volume level on each channel, so each channel is quieter. Night is useful at night, when you may want to keep the volume low.
― To use the volume control of a connected source device, set Auto Volume to Off . A change to the volume control of the connected source device may not be applied if Auto Volume is set to Normal or Night .
107
Reset Sound
MENUm → Sound → Reset Sound → ENTERE
Sound
Sound Mode
Sound Effect
Speaker Settings
Reset Sound
Standard
The displayed image may differ depending on the model.
Reset all sound settings to the factory defaults.
108
Chapter 07
Network
Network Settings
MENU m → Network → Network Settings → ENTER E
Network Settings
No network cable or Samsung Wireless LAN Adapter connected.
Please plug in a network cable or a Samsung Wireless
LAN Adapter.
Start
Cancel
The displayed image may differ depending on the model.
Connecting to a Wired Network
There are three ways to attach your product to your LAN using cable.
• You can attach your product to your LAN by connecting the LAN port on the back of your product to an external modem using a LAN cable.
See the diagram below.
LAN
The Modem Port on the Wall External Modem
(ADSL / VDSL) RJ45
Modem Cable LAN Cable
• You can attach your product to your LAN by connecting the LAN port on the back of your product to an IP Sharer which is connected to an external modem. Use LAN cable for the connection. See the diagram below.
LAN
The Modem Port on the Wall
External Modem
(ADSL / VDSL)
IP Sharer
(having DHCP server)
RJ45
LAN Cable Modem Cable
― Use Cat 7 cable for the connection.
LAN Cable
109
• Depending on how your network is configured, you may be able to attach your product to your LAN by connecting the LAN port on the back of your product directly to a network wall outlet using a
LAN cable.
See the diagram below. Note that the wall outlet is attached to a modem or router elsewhere in your house.
The LAN Port on the Wall
LAN
Wired Network Settings
Set the network connection to use Internet services such as perform software upgrades.
Automatic Network Settings
Connect to the network using a LAN cable.
Make sure a LAN cable is connected first.
RJ45
LAN Cable
If you have a Dynamic Network, you should use an ADSL modem or router that supports the Dynamic
Host Configuration Protocol (DHCP). Modems and routers that support DHCP automatically provide the IP address, subnet mask, gateway, and DNS values your product needs to access the Internet so you do not have to enter them manually. Most home networks are Dynamic Networks.
Some networks require a Static IP address. If your network requires a Static IP address, you must enter the
IP address, subnet mask, gateway, and DNS values manually on your product Cable Setup Screen when you set up the network connection. To get the IP address, subnet mask, gateway, and DNS values, contact your Internet Service Provider (ISP).
If you have a Windows computer, you can also get these values through your computer.
― You can use ADSL modems that support DHCP if your network requires a Static IP address.
― ADSL modems that support DHCP also let you use Static IP addresses.
How to set up automatically
1
Go to the Network Settings screen. Select Start , press E, and then press E again.
2
The network test screen appears and verifies the network connection.
When the connection has been verified, the “ Wired network and Internet connection completed.
” message appears.
― If the connection process fails, check the LAN port connection.
― If the automatic process cannot find the network connection values or if you want to set the connection manually, go to the next section, network setup.
Manual Network Settings
Offices may use static IP addresses.
If this is the case, ask the network administrator for the IP address, subnet mask, gateway and DNS server address. Enter these values manually.
Getting the Network Connection Values
To view the Network connection values on most Windows computers, follow these steps.
1
Right click the Network icon on the bottom right of the screen.
2
In the pop-up menu that appears, click Status.
110
3
On the dialog that appears, click the Support tab.
4
On the Support Tab, click the Details button. The Network connection values are displayed.
Connecting to a Wireless Network
To connect your product to your network wireless, you need a wireless router or modem and a Samsung
Wireless LAN adapter (WIS10ABGN, WIS12ABGNX) , which you connect to your product back or side panel
USB port. See the illustration below.
How to set up manually
1
Go to the Network Settings screen. Select Start , press E, and then press E again.
2
The network test screen appears and the verification process starts. Press Stop . The verification process stops.
3
Select IP Settings on network connection screen. The IP Settings screen appears.
4
Select the field at the top, press E, and then set IP Settings to Enter manually . Repeat the entry process for each field in the IP Address .
― Setting IP Settings to Enter manually automatically changes DNS setting to Enter manually .
5
When done, select OK at the bottom of the page, and then press E. The network test screen appears and the verification process starts.
6
When the connection has been verified, the “ Wired network and Internet connection completed.
” message appears.
Wireless IP sharer
(router having DHCP server)
The LAN Port on the Wall
Product Panel
Samsung Wireles LAN Adapter
LAN Cable
Samsung’s Wireless LAN adapter is sold separately and is offered by selected retailers, Ecommerce sites, and Samsungparts.com. Samsung’s Wireless LAN adapter supports the IEEE 802.11a/b/g and n communication protocols. Samsung recommends using IEEE 802.11n. When you play video over a network connection, the video may not play smoothly.
― You must use the “Samsung Wireless LAN adapter” (WIS10ABGN, WIS12ABGNX) to use a wireless network.
The Samsung Wireless LAN Adapter and the USB extension Cable are sold separately and are offered by select retailers, Ecommerce sites, and Samsungparts.com.
― Select a channel for the wireless IP sharer that is not currently being used. If the channel set for the wireless IP sharer is currently being used by another device nearby, this will result in interference and communication failure.
― Your product supports only the following wireless network security protocols.
If you select the Pure High-throughput (Greenfield) 802.11n mode and the Encryption type is set to
WEP, TKIP or TKIP AES (WPS2Mixed) on your AP or wireless router, Samsung products will not support a connection in compliance with new Wi-Fi certification specifications.
― If your wireless router supports WPS (Wi-Fi Protected Setup), you can connect to the network via PBC
(Push Button Configuration) or PIN (Personal Identification Number). WPS will automatically configure the SSID and WPA key in either mode.
111
― If your router, modem, or device is not certified, it may not connect to the product via the “Samsung
Wireless LAN adapter”.
― Ensure the product is turned on before you connect the “Samsung Wireless LAN adapter”.
― Connection Methods: You can setup the wireless network connection in three ways.
Auto Setup (Using the Auto Network Search function), Manual Setup, WPS(PBC)
― The product may not recognize the “Samsung Wireless LAN adapter” if you connect it to the product with a USB hub or USB extension cable other than the cable supplied with the product.
4
If the Enter security key.
screen appears, go to step 5. If you select a wireless router that does not have security, go to step 7.
5
If the router has security, enter the Security Key ( Security Key or PIN ).
6
When done, use the right arrow button to move the cursor to Next , and then press E. The network connection screen appears and the verification process starts.
Wireless Network Setting
Automatic Network Setup
Most wireless networks have an optional security system that requires devices that access the network to transmit an encrypted security code called an Access or Security Key . The Security Key is based on a Pass Phrase, typically a word or a series of letters and numbers of a specified length you were asked to enter when you set up security for your wireless network. If you use this method of setting up the network connection, and have a Security Key for your wireless network, you will have to enter the Pass Phrase during the the automatic or manual setup process.
― A connection with the router is established, but the Internet cannot be accessed.
7 When the connection has been verified, the “ Your wireless network and Internet connection are setup and ready to use.
” message appears.
Manual Network Setup
Offices may use static IP addresses.
If this is the case, ask the network administrator for the IP address, subnet mask, gateway and DNS server address. Enter these values manually.
How to set up automatically
1
Go to the Network Settings screen. Select Start , press E.
2
The Network function searches for available wireless networks. When done, it displays a list of the available networks.
3
In the list of networks, press the or button to select a network, and then press the E button twice.
― If the wireless router is set to Hidden (Invisible), you have to select Add Network and enter the correct Network Name and Security Key to establish the connection.
Getting the Network Connection Values
To view the Network connection values on most Windows computers, follow these steps.
1
Right click the Network icon on the bottom right of the screen.
2
In the pop-up menu that appears, click Status.
3
On the dialog that appears, click the Support tab.
4
On the Support Tab, click the Details button. The Network connection values are displayed.
112
How to set up manually
1 Go to the Network Settings screen. Select Start , press E.
2 The Network function searches for available wireless networks. When done, it displays a list of the available networks.
10
When done, select OK at the bottom of the page, and then press E. The network test screen appears and the verification process starts.
11
When the connection has been verified, the “ Your wireless network and Internet connection are setup and ready to use.
” message appears.
3 In the list of networks, press the or button to select a network, and then press the E button twice.
― If the wireless router is set to Hidden (Invisible), you have to select Add Network and enter the correct Network Name and Security Key to establish the connection.
4
If the Enter security key.
screen appears, go to step 5. If you select a wireless router that does not have security, go to step 7.
5
If the router has security, enter the Security Key ( Security Key or PIN ).
6
When done, use the right arrow button to move the cursor to Next , and then press E. The network connection screen appears and the verification process starts.
WPS(PBC)
How to set up using WPS(PBC)
If your router has a WPS(PBC) button, follow these steps.
1
Go to Network Settings screen.
2
Select WPS(PBC) , press E, and then press E again.
3
Press the WPS(PBC) button on your router within 2 minutes. Your product automatically acquires all the network setting values it needs and connects to your network.
4
The network connection screen appears, and network setup is done.
7
Select Stop while network connections are being attempted. This will stop the connection.
8
Select IP Settings on network connection screen. The IP Settings screen appears.
9
Select the field at the top, press E, and then set IP Settings to Enter manually . Repeat the entry process for each field in the IP Address .
― Setting IP Settings to Enter manually automatically changes DNS setting to Enter manually .
113
Network Status
MENU m → Network → Network Status → ENTER E
You can check the current network and Internet status.
Network Status
Your wireless network and Internet connection are setup and ready to use.
MAC Address
IP Address
Subnet Mask
Gateway
DNS Server
00 : 12 : fb : df : 29 : 76
***.
***.
***.
***.
***.
***.
***.
***.
***.
***.
***.
***.
***.
***.
***.
***.
You are connected to the Internet. If you have any problems using online services, please contact your Internet service provider.
IP Settings Retry Close
― The displayed image may differ depending on the model.
Wi-Fi Direct
MENU m → Network → Wi-Fi Direct → ENTER E
Set to connect the product to wireless mobile devices. Using this function, you can connect wireless mobile devices with your product directly without a router.
― To use this function, your mobile device should be supported by the Wi-Fi Direct .
To connect your mobile device with your product using Wi-Fi Direct, follow these steps:
1
Go to Wi-Fi Direct screen. The product starts to search devices.
2
Turn on the Wi-Fi Direct function on your device. Select the desired Wi-Fi device.
• PBC (Push Button Configuration): Press the WPS(PBC) button on your Wi-Fi device within 2 minutes.
Your product automatically acquires all the network setting values it needs and connects to your network.
• PIN : Input the displayed PIN on your device.
― If you want to disconnect the device, select the connected Wi-Fi device, and then select Disconnected .
114
Soft AP AllShare Settings
MENU m → Network → Soft AP → ENTER E
Using this function, you can connect the product on your mobile devices if your mobile devices do not support Wi-Fi Direct . Set the options for connection of Wi-Fi device.
• Soft AP
Turns on or off the Soft AP . When Soft AP is set to On , your mobile devices can find the product name in Wi-Fi connection list.
• Security Key
Set the Security Key manually using the remote control.
B Show security key : Shows the security key. Whether to show the security key is represented by a checkbox at the top.
A Del.
: Deletes the entered security key one digit at a time.
C Space : Inserts a blank space between characters when entering the security key.
Return : Returns to the screen before entering the security key.
The Security Key should consist of more than 8 digits.
Input the generated security key into the device you want to connect.
If network does not operate normally, check the security key again. An incorrect security key may cause a malfunction.
MENU m → Network → AllShare Settings → ENTER E
Shows a list of mobile phones or connected devices which have been set up to use the AllShare Play function with this product.
• Allow / Deny : Allows/Blocks the devices.
• Delete from the list : Deletes the devices from the list.
― This function only deletes the name of the device from the list. If the deleted device is turned on or tries to connect to the product, it may appear on the list again.
Using the AllShare Play Function
An alarm window appears informing you that media contents (videos, photos, music) sent from a mobile phone will be displayed on your product. The contents are played automatically 3 seconds after the alarm window appears. If you press the RETURN or EXIT button when the alarm window appears, the media contents are not played.
― The first time a device accesses your product through the media function, a warning popup window appears. Press the E button to select Allow . This permits the phone to access the product freely and use the AllShare Play function to play content.
― To turn off media contents transmissions from a mobile phone, set Deny in the AllShare Settings .
― Contents may not play on your product depending on their resolution and format.
― The E and / buttons may not work depending on the type of media content.
― Using the mobile device, you can control the AllShare Play . For details, refer to each mobile’s user’s guide.
Device Name
MENU m → Network → Device Name → ENTER E
Select or enter a device name.
This name can be shown on network remote controls over the network.
115
Chapter 08
System
Multi Control
MENUm → System → Multi Control → ENTERE
Multi Control
ID Setup
ID Input
MDC Connection
00
--
RS232C MDC
The displayed image may differ depending on the model.
Configuring settings for Multi Control
• ID Setup
Assign an ID to a set. (Range: 0~99)
Press ▲ or ▼ to select a number, and press E.
• ID Input
Enter the ID number of the product connected to the input cable for input signal reception.
Enter the number you want using the number buttons on the remote control.
• MDC Connection
Select a method to connect to MDC to receive the MDC signal.
RS232C MDC : Communicate with MDC via the RS232C-stereo cable.
RJ45 MDC : Communicate with MDC via the RJ45 cable.
116
Time
MENUm → System → Time → ENTERE
Time
Clock Set
Sleep Timer
On Timer
Off Timer
Holiday Management
The displayed image may differ depending on the model.
You can configure Clock Set or Sleep Timer . You can also set the product to automatically turn on or off at a specified time using the Timer function.
Clock Set
Set the clock to use the various various timer features of the product.
• Clock Set
Set the Date and Time .
Select Clock Set . Select Date or Time , and then press E.
Use the number buttons to enter numbers or press the up and down arrow buttons. Use the left and right arrow buttons to move from one entry field to the next. Press E when done.
― You can set the Date and Time directly by pressing the number buttons on the remote control.
Sleep Timer
Automatically shuts off the product after a preset period of time.
( Off / 30 min / 60 min / 90 min / 120 min / 150 min / 180 min )
― Use the up and down arrows to select a period of time, and then press E. To cancel Sleep Timer , select Off .
117
Time
On Timer
Off Timer
Holiday Management
The displayed image may differ depending on the model.
On Timer
Set On Timer so that your product turns on automatically at a time and on a day of your choosing.
The power is turned on with the specified volume or input source.
On Timer : Set the on timer by making a selection from one of the seven options. Ensure you set the current time first.
( On Timer1 ~ On Timer7 )
― You must set the clock before you can use On Timer .
• Setup : Select Off , Once , Everyday , Mon~Fri , Mon~Sat , Sat~Sun or Manual . If you select Manual , you can choose the days you want On Timer to turn on your product.
― The check mark indicates days you’ve selected.
• Time : Set the hour and minute. Use the number buttons or the up and down arrow keys to enter numbers. Use the left and right arrow buttons to change entry fields.
• Volume : Set the desired volume level. Use the left and right arrow buttons to change the volume level.
• Source : Select the input source of your choice.
• Music / Photo (when the Source is set to USB ): Select a folder in the USB device containing music or photo files you want played when the product turns on automatically.
― This function is available only when a USB device is connected.
― If there is no music file on the USB device or you don’t select a folder containing a music file, the Timer function does not operate correctly.
― If there is only one photo file in the USB, the Slide Show will not play.
― If a folder name is too long, the folder cannot be selected.
― Each USB you use is assigned its own folder. When using more than one of the same type of USB, make sure the folders assigned to each USB have different names.
― We recommend that you use a USB memory stick and a multi card reader when using On Timer . The On Timer function may not work with USB devices with a built-in battery, MP3 players, or PMPs made by some manufacturers because the product can take too long to recognize these devices.
118
Time
On Timer
Off Timer
Holiday Management
The displayed image may differ depending on the model.
Off Timer
Set the off timer ( Off Timer ) by making a selection from one of the seven options. ( Off Timer1 ~ Off Timer7 )
― You must set the clock before you can use Off Timer .
• Setup : Select Off , Once , Everyday , Mon~Fri , Mon~Sat , Sat~Sun or Manual . If you select Manual , you can choose the days you want Off Timer to turn off your product.
― The check mark indicates days you’ve selected.
• Time : Set the hour and minute. Use the number buttons or the up and down arrow keys to enter numbers. Use the left and right arrow buttons to change entry fields.
Holiday Management
Timer will be disabled during a period specified as a holiday.
• Add : Specify the period you want to add as a holiday.
Select the start and end dates of the holiday you want to add using the ▲/▼ buttons, and click the Save button.
The period will be added to the list of holidays.
Start : Set the start date of the holiday.
End : Set the end date of the holiday.
• Delete : Delete all items from the list of holidays.
Select Delete . The message " Delete all holidays?
" will appear.
Select Yes . All holidays will be deleted.
• Apply : Set the On Timer and Off Timer to not activate on public holidays.
Press E to select the On Timer and Off Timer settings you do not want to activate.
The selected On Timer and Off Timer will not activate.
119
Menu Language
MENUm → System → Menu Language → ENTERE
System
Time
Menu Language
Rotate menu
Eco Solution
English
Landscape
The displayed image may differ depending on the model.
Set the menu language.
― A change to the language setting will only be applied to the onscreen menu display. It will not be applied to other functions on your PC.
120
Rotate menu
MENUm → System → Rotate menu → ENTERE
System
Time
Menu Language
Rotate menu
Eco Solution
English
Landscape
The displayed image may differ depending on the model.
Configure the menu screen.
• Landscape : Display the menu in landscape mode (default).
• Portrait : Display the menu in portrait mode on the right side of the product screen.
― Available in PC / DVI / HDMI / MagicInfo mode.
121
Eco Solution
MENUm → System → Eco Solution → ENTERE
Eco Solution
Energy Saving
Eco Sensor
No Signal Power Off
Auto Power Off
Off
Off
15 min
Off
The displayed image may differ depending on the model.
Energy Saving
Reduce the power consumption by adjusting the screen brightness.
Selecting Picture Off switches off the screen. The volume is not disabled.
To switch the screen on, press any button other than the volume button.
• Off / Low / Medium / High / Picture Off
Eco Sensor
To enhance your power savings, the picture settings will automatically adapt to the light in the room.
• Off / On
― Adjusting the Backlight setting under Picture while Eco Sensor is on will disable the Off .
Min. Backlight
When Eco Sensor is On , you can manually adjust the minimum screen brightness. Min. Backlight is the darkest backlight mode. Make sure the Min. Backlight setting is lower than the Backlight setting.
― If Eco Sensor is On , the display brightness may change (become slightly darker or brighter) depending on the surrounding light intensity.
No Signal Power Off
Save power by turning the device off when no signal is received from any source.
• Off / 15 min / 30 min / 60 min.
― Disabled when an attached PC is in power saving mode.
― The product will automatically power off at a specified time. The time can be changed as required.
Auto Power Off
The product will automatically turn off if you don’t press a button on the remote or touch a button on product front panel within 4 hours to prevent overheating.
• Off / On
122
Security
MENUm → System → Security → ENTERE
Security
Safety Lock
Button Lock
Change PIN
Off
Off
The displayed image may differ depending on the model.
Every time you access the Security functions, the PIN screen will appear and the default PIN number is "0-0-0-0" (default password: 0 - 0 - 0 - 0).
Safety Lock
It sets safe lock function.
• Off / On
All the menus and buttons of the product and remote control, except for the LOCK button on the remote control, will be locked by the Safety Lock function.
To unlock the menus and buttons, press the LOCK button and then enter the password (default password: 0 - 0 - 0 - 0).
Button Lock
This menu can be used to lock the buttons on the product.
Only the remote control can control the product if Button Lock is set to On .
• Off / On
Change PIN
The Change PIN screen will appear.
Choose any 4 digits for your PIN and enter it in Enter New PIN . Reenter the same 4 digits in Confirm New PIN .
When the Confirm screen disappears, press the Close button. The product has memorised your new PIN.
123
PIP
MENUm → System → PIP → ENTERE
System
PIP
Auto Protection Time
Screen Burn Protection
Ticker
Video Wall
Off
Off
Off
The displayed image may differ depending on the model.
For PIP sound, refer to the Sound Select instructions.
If you turn the product off while watching in the PIP mode, PIP mode will remain after power
Off/On.
-
You may notice that the picture in the PIP screen becomes slightly unnatural when you use the main screen to view a game or karaoke.
PIP Settings
The picture from the external video source will be in the main screen and the picture from the product will be in the PIP subpicture screen.
Main picture
PC
Sub picture
AV
AV PC , DVI , HDMI
HDMI , DVI ,
MagicInfo Lite
AV
PC , DVI , AV , Component , HDMI
• PIP ( Off / On ): Activate or deactivate the PIP function.
• Source : You can select a source of the sub picture.
• Size ( , , , , , ): Select a size for the subpicture.
• Position ( , , , ): Select a position for the sub-picture.
― In ( , , ) mode, you cannot select Position .
• Sound Select ( Main / Sub ): You can choose to listen to the sound from the Main picture or the Sub picture.
124
Auto Protection Time
MENUm → System → Auto Protection Time → ENTERE
System
Auto Protection Time
Screen Burn Protection
Ticker
Video Wall
Source AutoSwitch Settings
Off
Off
The displayed image may differ depending on the model.
If the screen displays a still image for a certain period of time you define, the product activates the screen saver to prevent the formation of burnt in ghost images on the screen.
• Off / 2 hours / 4 hours / 8 hours / 10 hours
125
Screen Burn Protection
MENUm → System → Screen Burn Protection → ENTERE
Screen Burn Protection
Pixel Shift
Timer
Immediate display
Side Grey
Off
Off
Off
Off
The displayed image may differ depending on the model.
To reduce the possibility of screen burn, this unit is equipped with Pixel Shift screen burn prevention technology.
Pixel Shift moves the picture slightly on the screen.
The Pixel Shift Time setting allows you to programme the time between movements of the picture in minutes.
Pixel Shift
Minimize image retention by finely moving pixels horizontally or vertically.
• Pixel Shift ( Off / On )
― Horizontal , Vertical and Time are enabled only when Pixel Shift is set to On .
• Horizontal : Sets how many pixels the screen moves horizontally.
• Vertical : Sets how many pixels the screen moves vertically.
• Time : Set the time interval for performing the horizontal or vertical movement, respectively.
Available Pixel Shift Settings and Optimum Settings.
Available Settings Optimum Settings
Horizontal (pixels) 0 ~ 4 4
Vertical (pixels) 0 ~ 4 4
Time (minute) 1 min ~ 4 min 4 min
― The Pixel Shift value may differ depending on the product size (inches) and mode.
― Displaying a still image or a 4:3 output for an extended period of time may cause image retention. This is not a defect in the product.
― This function is not available in the Screen Fit mode.
126
Screen Burn Protection
Pixel Shift
Timer
Immediate display
Side Grey
The displayed image may differ depending on the model.
Off
Off
Off
Off
Timer
You can set the timer for Screen Burn Protection .
The Pixel Shift feature stops automatically after a specified period of time.
Timer
• Off
• Repeat : Display the image retention-preventive pattern set in Mode at specified time intervals(Period).
• Interval : Display the image retention-preventive pattern set in Mode for a specified period of time (from Start Time to
End Time ).
― The option is enabled only when Clock Set is configured.
― Mode , Period , Time , Start Time and End Time are enabled only when Timer is set to Repeat or Interval .
• Mode : Select a screen protective pattern to display.
Pixel : Pixels on the screen alternate black continuously.
Rolling bar : A vertical bar moves left to right.
Fading screen : The entire screen becomes brighter, then darker.
― The Rolling bar and Fading screen patterns appear only once regardless of the specified repeat period or time.
• Period : Specify the time interval to activate the Screen Burn Protection function.
― The option is enabled when Repeat is selected for Timer .
• Time : Specify the duration to keep the Screen Burn Protection function on.
― The option is enabled when Pixel is selected for Mode .
• Start Time : Set the start time to activate the screen protection function.
― The option is enabled when Interval is selected for Timer .
• End Time : Set the end time to deactivate the screen protection function.
― The option is enabled when Interval is selected for Timer .
127
Screen Burn Protection
Pixel Shift
Timer
Immediate display
Side Grey
The displayed image may differ depending on the model.
Off
Off
Off
Off
Immediate display
Select the screen saver you want to display immediately.
• Off / Pixel / Rolling bar / Fading screen
Side Grey
When the screen is set to 4:3 aspect ratio, adjust the brightness of white margins on sides to protect the screen.
• Off / Light / Dark
128
Ticker
MENUm → System → Ticker → ENTERE
System
Auto Protection Time
Screen Burn Protection
Ticker
Video Wall
Source AutoSwitch Settings
Off
Off
The displayed image may differ depending on the model.
Input text while a video or image is displayed and display the text on the screen.
• Off / On
― Message , Time , Position , Motion , and Font options are enabled only when Ticker is set to On .
• Message : Enter a message to display on the screen.
• Time : Set the Start Time and End Time to display a Message .
• Position : Select an orientation to display a Message from Horizontal and Vertical .
Horizontal ( Left / Centre / Right )
Vertical ( Top / Middle / Bottom )
• Motion : Specify the Direction and Speed to display a Message .
Motion ( Off / On )
Direction ( Left / Right / Top / Bottom )
Speed ( Slow / Normal / Fast )
― Direction and Speed are enabled only when Motion is set to On .
• Font options : Specify the message Size, Text colour, Background colour, Text opacity and Background opacity.
129
Video Wall
MENUm → System → Video Wall → ENTERE
Video Wall
Video Wall
· Format
· Horizontal
· Vertical
· Screen Position
On
Full
1
1
The displayed image may differ depending on the model.
The Video Wall option is only enabled when PIP is set to Off .
If more than four displays are connected horizontally and vertically, it is recommended that you use an input resolution of XGA (1024 x 768) level or higher to prevent a dark picture due to degradation in the contrast or colour intensity.
Customize the layout of multiple displays that are connected to form a video wall.
In addition, display part of a whole picture or repeat the same picture on each of the connected multiple displays.
To display multiple images, refer to MDC Help or the MagicInfo user guide. Some models may not support the MagicInfo function.
Video Wall
You can activate or deactivate Video Wall .
To organize a video wall, select On .
Format
Select a format to display images on multiple displays.
• Full : Display images in full screen.
• Natural : Display images at the original resolution without enlarging or reducing.
― The Format option is only enabled when Video Wall is set to On .
Horizontal
This function automatically divides the screen according to the specified number of horizontal displays.
Enter the number of horizontally arranged displays.
The horizontal screen will automatically be divided according to the number entered.
A maximum of 15 displays can be assigned to the horizontal arrangement.
― The screen can be divided into a maximum of 100 screens (horizontal and vertical screens multiplied). For example, if the horizontal arrangement is set to 15, a maximum of 6 displays can be assigned to the vertical arrangement. Conversely, if the vertical arrangement is set to 15, a maximum of 6 displays can be assigned to the horizontal arrangement.
― The Horizontal option is only enabled when Video Wall is set to On .
130
Video Wall
Video Wall
· Format
· Horizontal
· Vertical
· Screen Position
The displayed image may differ depending on the model.
On
Full
1
1
Vertical
This function automatically divides the screen according to the specified number of vertical displays.
Enter the number of vertically arranged displays.
The vertical screen will automatically be divided according to the number entered.
A maximum of 15 displays can be assigned to the vertical arrangement.
― The screen can be divided into a maximum of 100 screens (horizontal and vertical screens multiplied). For example, if the horizontal arrangement is set to 15, a maximum of 6 displays can be assigned to the vertical arrangement. Conversely, if the vertical arrangement is set to 15, a maximum of 6 displays can be assigned to the horizontal arrangement.
― The Vertical option is only enabled when Video Wall is set to On .
Screen Position
You can customize the arrangement of split screens by moving displays identified with a number using the Screen Position function.
Select Screen Position to display the arrangement of displays (identified with a number) specified according to the
Horizontal or Vertical settings. To customize the arrangement, move a number (display) using the direction buttons on the remote control and press E.
― A maximum of 100 displays can be arranged in Screen Position .
― The Screen Position option is only enabled when Video Wall is set to On .
― The Screen Position window is only displayed when Horizontal and Vertical are configured.
131
Source AutoSwitch Settings
MENUm → System → Source AutoSwitch Settings → ENTERE
Source AutoSwitch Settings
Source AutoSwitch
· Primary Source Recovery
· Primary Source
· Secondary Source
On
Off
All
PC
The displayed image may differ depending on the model.
Turning on the display with Source AutoSwitch On , and the previous video source selection is not active, the display will automatically search the different video input sources for active video.
Source AutoSwitch
When the Source AutoSwitch is On , the display video source will automatically be searched for active video.
The Primary Source selection will be activated, if the current video source is not recognized.
Secondary Source selection will become active, if no primary video source is available.
If both the primary and secondary input sources are not recognized, the display will perform two searches for an active source, each search checking the primary and then secondary source. If both searches fail, the display will return to the first video source and display a message indicating that there is no signal.
When the Primary Source selection is set to All , the display will search all the video source inputs twice in sequence looking for an active video source, returning back to the first video source in the sequence if no video is found.
Primary Source Recovery
Select whether to restore the selected primary input source when a primary input source is connected.
― The Primary Source Recovery function is disabled if Primary Source is set to All .
Primary Source
Specify Primary Source for the automatic input source.
Secondary Source
Specify Secondary Source for the automatic input source.
132
General
MENUm → System → General → ENTERE
General
Max. Power Saving
Game Mode
BD Wise
Menu Transparency
Sound Feedback
Auto Power
Standby Control
Medium
Low
Off
Auto
On
Off
On
The displayed image may differ depending on the model.
Max. Power Saving
Turns off the product to reduce power consumption after the PC has been left idle for a specified period of time.
• Off / On
― Available only PC , DVI , HDMI mode.
Game Mode
When connecting to a game console such as PlayStation™ or Xbox™, you can enjoy a more realistic gaming experience by selecting game mode.
• Off / On
― Precautions and limitations for Game Mode
To disconnect the game console and connect another external device, set Game Mode to Off in the setup menu.
― Game Mode is not available when the input source is set to PC , DVI .
― If Game Mode is On
Picture Mode is set to Standard and Sound Mode is set to Movie .
BD Wise
Provides the optimal picture quality for Samsung DVD, Blu-ray and Home Theatre products which support BD Wise . When BD
Wise is turned On , the picture mode is automatically changed to the optimal resolution.
• Off / On
― Available when you connect Samsung products that support BD Wise through an HDMI cable to the product.
― The BD Wise function is enabled only when a source device with the BD Wise function is connected.
Menu Transparency
Adjust transparency of menu box.
• High / Medium / Low
133
General
Sound Feedback
Auto Power
Standby Control
Lamp Schedule
OSD Display
Power On Adjustment
Temperature Control
Off
Off
Auto
Off
0 Sec
77
The displayed image may differ depending on the model.
Sound Feedback
Your product gives sound feedback when you use product.
Sound Feedback is enabled by default. Turn off Sound Feedback or adjust its volume.
This function is enabled by default. The volume can be adjusted or muted.
― Off / Low / Medium / High
Auto Power
Enabling this option will automatically power on the product if the power cable is connected.
• Off / On
Standby Control
You can set the screen standby mode to be applied when an input signal is received.
• Auto
Power-saving mode will activate if no input signals are detected even though a source device is connected to the display.
The message No Signal will appear if no source device is connected.
― Available in PC / DVI mode.
• On
Power-saving mode will activate if no input signals are detected.
• Off
The message No Signal will appear if no input signals are detected.
― The Standby Control option is only enabled when Source is set to PC , DVI .
― If No Signal is displayed although a source device is connected, check the cable connection.
134
General
Sound Feedback
Auto Power
Standby Control
Lamp Schedule
OSD Display
Power On Adjustment
Temperature Control
Off
Off
Auto
Off
0 Sec
77
The displayed image may differ depending on the model.
Lamp Schedule
Enables the lamp value to be adjusted to a user-specified value at a specified time in MDC mode.
• Off / On
OSD Display
Displays or hides a menu item on the screen.
― Source OSD / No Signal OSD / MDC OSD
Power On Adjustment
You can set the warm-up time for the screen to turn on after the power button is pressed. (Range: 0 – 50 seconds)
― A warm-up time that is too short may damage the product due to overvoltage.
Temperature Control
This function detects the internal temperature of the product. You can specify the temperature range that is acceptable.
The default temperature is set to 77 C.
The recommended operating temperature for this product is 75 to 80 C (based on an ambient temperature of 40 C).
― The screen will become darker if the current temperature exceeds the specified temperature limit. If the temperature continues to rise, the product will power off to prevent overheating.
135
Anynet+ (HDMI-CEC)
MENUm → System → Anynet+ (HDMI-CEC) → ENTERE
Anynet+ (HDMI-CEC)
Anynet+ (HDMI-CEC)
Auto Turn Off
Receiver
On
Yes
Off
The displayed image may differ depending on the model.
The Anynet+ functions do not operate with other manufacturers’ products.
For instructions explaining how to connect Anynet+ external devices, refer to the device’s user manual.
You can connect only one receiver (home Theatre).
Anynet+ (HDMI-CEC)
Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung product remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your
Samsung device has this feature, check if there is an Anynet+ logo on it.
― You can only control Anynet+ devices using the product remote control, not the buttons on the product.
― The product remote control may not work under certain conditions. If this occurs, reselect the Anynet+ device.
― Anynet+ works when the AV device supporting Anynet+ is in the standby or on status.
― While in PIP mode, Anynet+ functions only when an AV device is connected as the primary display. It does not work if the
AV device is connected as a secondary display.
― Anynet+ supports up to 12 AV devices in total. Note that you can connect up to 3 devices of the same type.
Anynet+ Menu
The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected to the product.
Anynet+ Menu
View PC
Description
Changes Anynet+ mode to PC mode.
Device List
(device_name) MENU
(device_name) Tools
Shows the Anynet+ device list.
Shows the menu of the connected device menus. E.g. if a DVD player is connected, the disc menu of the DVD player will appear.
Shows the tools menu of the connected device. E.g. if a DVD player is connected, the tools menu of the DVD player will appear.
― Depending on the device, this menu may not be available.
(device_name) Title Menu Shows the title menu of the disc in the connected device. E.g. If a DVD player is connected, the title menu of the movie in the DVD player will appear.
― Depending on the device, this menu may not be available.
136
Anynet+ (HDMI-CEC)
Anynet+ (HDMI-CEC)
Auto Turn Off
Receiver
The displayed image may differ depending on the model.
On
Yes
Off
Auto Turn Off
Setting an Anynet+ Device to turn Off automatically when the product is turned off.
• No / Yes
― If Auto Turn Off is set to Yes , running external devices will turn off at the same time as the product powers off.
― May not be enabled depending on the device.
Switching between Anynet+ Devices
1
Press the TOOLS button, select Anynet+ (HDMI-CEC) , and then press E.
2
Select Device List , and then press the E button.
If you cannot find a device you want, select Refresh to refresh the list.
3
Select a device, and then press the E button. You can switch to the selected device.
― The Device List menu appears only when you set Anynet+ (HDMI-CEC) to On in the System menu.
― Switching to the selected device may take up to 2 minutes. You cannot cancel the switching operation while switching is in progress.
― If you have selected an Anynet+ device by pressing the SOURCE button and then selecting its input source, you cannot use the Anynet+ function.
― Make sure to switch to an Anynet+ device by using the Device List .
137
Troubleshooting for Anynet+
Problem
Anynet+ does not work.
Possible Solution
• Check if the device is an Anynet+ device. The Anynet+ system supports Anynet+ devices only.
• Check if the Anynet+ device power cord is properly connected.
• Check the Anynet+ device’s Video/Audio/HDMI cable connections.
• Check whether Anynet+ (HDMI-CEC) is set to On in the Anynet+setup menu.
• Check whether the remote control is Anynet+ compatible.
• Anynet+ doesn’t work in certain situations. (initial setup)
• If you have removed and then reconnected the HDMI cable, please make sure to search devices again or turn your product off and on again.
• Check if the Anynet+ function of the Anynet device is set on.
I want to start Anynet+.
I want to exit Anynet+.
The message “ Disconnecting
Anynet+ device ...
” appears on the screen.
• Check if the Anynet+ device is properly connected to the product and check if the Anynet+ (HDMI-CEC) is set to On in the
Anynet+ Setup menu.
• Press the TOOLS button to display the Anynet+ menu and select a menu you want.
• Select View PC in the Anynet+ menu.
• Press the SOURCE button on the product remote control and select a non- Anynet+ device.
•
•
You cannot use the remote control when you are configuring Anynet+ or switching to a view mode.
Use the remote control after the product has completed Anynet+ configuration or has finished switching to Anynet+.
The Anynet+ device does not play.
• You cannot use the play function when initial setup is in progress.
138
Problem
The connected device is not displayed.
Possible Solution
• Check whether or not the device supports Anynet+ functions.
• Check whether or not the HDMI cable is properly connected.
• Check whether Anynet+ (HDMI-CEC) is set to On in the Anynet+ Setup menu.
• Search Anynet+ devices again.
• Anynet+ requires an HDMI connection. Make sure the device is connected to your product with an HDMI cable.
• Some HDMI cables may not support Anynet+ functions.
• If the connection is terminated because there has been a power failure or the HDMI cable has been disconnected, please repeat the device scan.
139
DivX ® Video On Demand
MENUm → System → DivX ® Video On Demand → ENTERE
System
DivX ® Video On Demand On
The displayed image may differ depending on the model.
Play Mode
MENUm → System → Play Mode → ENTERE
System
Play Mode MagicInfo Lite
The displayed image may differ depending on the model.
Shows the registration code authorized for the product.
If you connect to the DivXⓇ web site and register using that code, you can download the VOD registration file.
For more information about DivXⓇ VOD, visit “http://vod.divx.com”.
Select Play Mode .
Changing Play Mode will change the functions in Contents Home .
• MagicInfo Lite / MagicInfo Premium S / MagicInfo Videowall S
― Changing Play Mode will automatically reboot the product and apply changes.
― Changing Play Mode will reset all the previous settings configured in Play Mode.
140
Magic Clone
MENUm → System → Magic Clone → ENTERE
Magic Clone
Clone to USB
Clone From USB
The displayed image may differ depending on the model.
Reset System
MENUm → System → Reset System → ENTERE
System
Reset System
The displayed image may differ depending on the model.
Export the product settings to a USB device or load the settings via a USB device.
This option is useful when assigning the same settings to several products.
• Clone to USB : Copy the product settings to a USB device.
• Clone From USB : Assign the settings saved in a USB device to the product.
After configuration is complete, the product is rebooted automatically.
― The option may not work properly if the USB device contains a file other than a settings file.
― Confirm that the USB device functions properly before running the option.
― The option is available for products with the same Model Code and Software Version .
Go to Support → Contact Samsung and find the product Model Code and Software Version .
This option returns the current settings under system to the default factory settings.
141
Reset All
MENUm → System → Reset All → ENTERE
System
Reset All
The displayed image may differ depending on the model.
PC module power
MENUm → System → PC module power → ENTERE
System
PC module power
The displayed image may differ depending on the model.
PC module: Refers to network boxes or PIM.
This option returns all the current settings for a display to the default factory settings.
The PC module can be turned on/off separately from the LFD.
Synced power-on
To turn on the PC module without turning on the LFD, select Off .
• Off / On
Synced power-off
To turn off the LFD without turning off the PC module, select Off .
• Off / On
142
Chapter 09
Support
Current Version : This is the software version already installed in the product.
Please be careful not to remove the USB drive until the upgrade is complete.
Software Update
MENUm → Support → Software Update → ENTERE
The Software Update menu lets you upgrade your product software to the latest version.
― Be careful not to turn off the power until the upgrade is complete. The product will turn off and on automatically after completing the software upgrade.
― When you upgrade software, all video and audio settings you have made will return to their default settings. We advise you to write down your settings so that you can easily reset them after the upgrade.
By USB
1
Visit http://www.samsunglfd.com
2
Download the latest USB software upgrade exe archive to your computer.
3
Extracts the exe archive to your computer. You should have a single folder with the same name as the exe file.
4
Copy the folder to a USB flash drive.
5
Turn on the product, and then insert the USB flash drive into the USB port of the product.
6
In the product menu, go to Support → Software Update .
7
Select By USB .
143
Contact Samsung
MENUm → Support → Contact Samsung → ENTERE
View this information when your product does not work properly or when you want to upgrade the software.
You can find information regarding our call Centres and how to download products and software.
― Contact Samsung and find the product Model Code and Software Version .
144
Contents Home
MENUm → Support → Contents Home → ENTERE
Support
Contents Home
The displayed image may differ depending on the model.
MagicInfo Lite
MENU m → Support → Contents Home → MagicInfo Lite → ENTER E
― MagicInfo Lite can also be accessed by pressing MagicInfo Lite/S on the remote control.
― To launch MagicInfo Lite , select MagicInfo Lite for the Play Mode on the System .
MagicInfo Lite player allows you to play content (image, video, document files) at a desired time.
You can play content saved in Internal memory or USB memory. You can also play content via MagicInfo Lite Server after connecting to a network.
― Refer to
for details about the MagicInfo Lite menu.
MagicInfo Premium S
MENU m → Support → Contents Home → MagicInfo Premium S → ENTER E
― MagicInfo Premium S can also be accessed by pressing MagicInfo Lite/S on the remote control.
― To launch MagicInfo Premium S , select MagicInfo Premium S for the Play Mode on the System .
― A licence needs to be purchased to use MagicInfo Premium S .
MagicInfo Premium S Player can be used to edit and play content files including templates such as images, videos and documents.
Play content files and templates from USB memory or built-in memory. Alternatively, play content files and templates via
MagicInfo Premium Server over a network.
― Refer to
for details about the MagicInfo Premium S menu.
MagicInfo Videowall S
MENU m → Support → Contents Home → MagicInfo Videowall S → ENTER E
― MagicInfo Videowall S can also be accessed by pressing MagicInfo Lite/S on the remote control.
― To launch MagicInfo Videowall S , select MagicInfo Videowall S for the Play Mode on the System .
― A licence needs to be purchased to use MagicInfo Videowall S .
MagicInfo Videowall S Player allows you to play content at a desired time. Content that can be played includes VideoWall content created in MagicInfo VideoWall Author in addition to other image and video files.
Content can be played only through VideoWall Console over a network.
― Refer to
for details about the MagicInfo Videowall S menu.
145
The input source can also be changed by using the SOURCE button on the remote control.
AllShare Play
MENU m → Support → Contents Home → AllShare Play → ENTER E
Enjoy videos, photos, music files saved on a USB Mass Storage Class (MSC) device.
― Refer to
for details about the AllShare Play menu.
Source
MENUm → Support → Contents Home → Source → ENTERE
You can display the screen of a source device connected to the product. Select a source from Source list to display the screen of the selected source.
Edit Name
MENUm → Support → Contents Home → Source → TOOLS → Edit Name → ENTERE
Sometimes the screen will not display properly unless the name of a source device is specified in Edit Name .
In addition, it is best to rename the source device in Edit Name to obtain optimal picture quality.
― The list can include the following source devices. Source devices on the list differ depending on the selected source.
VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI PC / DVI Devices / TV / IPTV / Blu-ray / HD DVD / DMA
― Available settings in the Picture menu depend on the current source and settings made in Edit Name .
• When connecting a PC to the HDMI terminal, set Edit Name to PC . In other cases, set Edit Name to AV devices.
• When connecting a PC to the HDMI IN port with HDMI cable, you should set the product to PC mode under Edit Name .
• When connecting a PC to the HDMI IN port with HDMI to DVI cable, you should set the product to DVI PC mode under Edit Name .
• When connecting an AV devices to the HDMI IN port with HDMI to DVI cable, you should set the product to DVI Devices mode under Edit Name .
Information
MENUm → Support → Contents Home → Source → TOOLS → Information → ENTERE
You can see detailed information about the selected external device.
146
Chapter 10
AllShare Play
Enjoy videos, photos, music files saved on a USB Mass Storage Class (MSC) device.
AllShare Play can also be accessed by pressing CONTENET(HOME) on the remote control.
What is AllShare Play?
Play photo, video or music files saved on a storage device. Wirelessly connect a smartphone to a PC using a wireless network.
Play various content using one of the following methods in AllShare Play :
• Using internal memory and a USB device: Play video, photo and music files from a USB device. Copy the files to the internal memory.
• Connecting to a PC over a network: Play photo, video and music files saved on a PC through a network connection.
Read the following before using AllShare Play with a USB device
Caution
• Before connecting a USB device to the product, back up files to ensure your data is not damaged or lost.
Samsung Techwin is not liable for any damage or loss of data.
• Do not remove a USB device while it is loading.
• If a USB device is connected using a USB extension cable, the USB device may not be recognized or files saved on the device may not be able to be read.
• If the product does not recognize a connected USB device, the files on the USB device may be corrupted or may not be able to be played.
If this occurs, connect the USB device to the PC to format the device, then make sure the device is connected properly.
• USB HDD greater than 2TB is not supported.
147
Compatible devices with AllShare Play
• Some types of USB devices, digital cameras and audio devices may not be compatible with the product.
• AllShare Play is only compatible with USB MSC devices.
• MSC device refers to a Mass Storage Class Bulk-Only Transport device. Examples of MSC devices include Thumb drives, Flash card readers and USB HDDs. (USB hubs are not supported.)
These MSC devices must be connected directly to a USB port on the product.
• If more than one Picture Transfer Protocol (PTP) device is connected, only one will work at a time.
• If multiple MSC devices are connected, some devices may not be recognized. USB devices that require high power (higher than 500mA or 5V) may not be supported.
• If an overheating warning message appears when a USB device is connected or used, the USB device may not be recognized or function properly.
• The screensaver activates if the product is left idle for a period of time specified in Auto Protection Time .
• Power-saving mode on some external hard disk drives may automatically deactivate after connecting to the product.
File system and formats
• AllShare Play may not function properly with unlicenced multimedia files.
• Media Transfer Protocol (MTP) is not supported.
• Supported file systems include FAT16, FAT32 and NTFS (read only).
• AllShare Play supports the sequential JPEG format.
It does not support the progressive JPEG format.
• Images with a higher resolution take longer to be displayed on the screen.
• The maximum JPEG resolution supported is 15360x8640 pixels.
• If a file is incompatible or corrupted, a message Not Supported File Format.
appears.
• When sorting files in folder view mode, a maximum of 1000 files can be displayed in each folder.
• If a USB device contains 8000 files and folders or more, some files and folders may not open.
• DRM MP3 files downloaded from websites that charge a fee cannot be played.
Digital Rights Management (DRM) refers to a system for protecting the copyrights of data circulated via the Internet or other digital media by enabling secure distribution and/or disabling illegal distribution of the data.
148
It is recommended to use a USB HDD that has a power adapter.
It is recommended to remove a USB device using the Safely Remove USB
Device function.
Using a USB device
Connecting a USB device
1
Turn on your product.
2
Connect a USB device containing photo, music and/or movie files to the USB port on the back or side panel of the product.
3
A message New device connected.
appears when the USB device is connected properly. Select type of content to play from Videos , Photos , and Music .
― If only one USB device is connected, files saved on the USB device are displayed automatically.
― To view content saved on a USB device, connect the USB device to a USB port on the product.
Removing a USB device
Removing a USB device from Source
1
Press SOURCE on the remote control. Alternatively, go to Source using the OSD menu.
MENUm → Support → Contents Home → Source → ENTERE
2
Select a USB device and press TOOLS on the remote control. Tools option appears.
3 Select Safely Remove USB Device and wait until the USB device is disconnected. The USB device is disconnected.
Deleting AllShare Play from the screen
1 Go to the AllShare Play page.
MENUm → Support → Contents Home → AllShare Play → ENTERE
2
Select all options except My list and press E on the remote control.
3
Select a USB device and press TOOLS on the remote control. Tools option appears.
4
Select Safely Remove USB Device and wait until the USB device is disconnected. The USB device is disconnected.
149
Connecting to a PC over a network
Play photo, video and music files saved on a PC through a network connection in AllShare Play mode.
• For details on how to configure a network, refer to the section Network Settings .
• To view content saved on the PC, connect the product and PC to the same wireless router and visit http://www.samsung.com to download the AllShare PC software.
• Ensure the product and PC are connected to the same network subnet.
All IP addresses are made up of four parts separated by dots.
(E.g. IP address 111.222.333.444) The product should have the same IP address as the PC, except for the fourth part of the address, if they are connected to the same subnet. (E.g. 111.222.333.***)
When connected to a PC over a network, AllShare Play does not support the following features.
• Background Music On and Background Music Setting features
• Feature that sorts files in the Videos , Photos or Music folder according to the default setting
π or µ feature during video playback
• DivXⓇ DRM is not supported.
• Make sure you set the Windows firewall programme to permit the AllShare PC software.
• When using AllShare Play mode through a network connection, available functions may vary depending on the server as follows:
Available sorting modes may vary.
The Scene Search function may not be supported.
The resume function may not be available for multiple users.
(The function only remembers the point where the most recent user stopped playing a video.)
The search function may not work depending on the content information.
• You may experience file stuttering while playing video content over a network connection.
150
Using the AllShare Play features
If you connect the product and a source device such as a cell phone or PC to the same network, you can play media content saved on the device such as videos, photos and music.
Visit http://www.samsung.com or contact the Samsung Techwin Customer Centre for more information.
Additional software may need to be installed on your mobile device.
Refer to the mobile device user manual for details.
― Connect your Samsung display product to a network through AllShare Play and use the special features provided by Samsung as follows:
• Playback of various video formats (DivX, MP4, 3GPP, AVI, ASF, MKV, etc.)
• Video thumbnail feature
• Bookmark feature (to resume video playback)
• Auto-chaptering (scene search)
• Digital Content Management
• Compatibility with various subtitle formats (SRT, SMI, SUB, TXT, TTXT)
• Search with file names
• And many others
― A compatibility issue may occur if a video file is played when a server not provided by Samsung Techwin is connected.
― To use AllShare Play , go to http:// www.samsung.com and download the AllShare software.
151
Using the Basic AllShare Play
Features
MENUm → Support → Contents Home → AllShare Play → ENTERE
AllShare Play / My List /
Recently Played
My List
Videos
What's new
Photos
Music
Playlist
Recently played files will be displayed here.
Updated files will be displayed here.
No playlists have been created.
Create a playlist to quickly and easily access your content.
Return
The displayed image may differ depending on the model.
Sorting the file lists
To sort files, press D on the remote control to specify the sorting criteria.
Sort Criteria
Folder view
Operation
Displays the whole folder. You can view the file name and thumbnail by selecting the folder.
Title Sorts and displays the file title in Symbol/Number/
Alphabet/Special order.
Videos Photos Music c c c c c c
Latest Date
Earliest Date
Monthly
Artist
Album
Genre
Sorts and shows files by the latest date.
Sorts and shows files by the earliest date.
Sorts and shows photo files by month.
Sorts the music file by artist in alphabetical order.
Sorts the music file by album in alphabetical order.
Sorts music files by the Genre.
c c c c c c c c
152
Playing Selected Files
1
Select files from the list of Videos , Photos , or Music files.
2
Press TOOLS on the remote control and select Play selection .
― The option does not appear if a folder is highlighted by the cursor.
3
Select files and press Play .
― c appears for selected files.
― To select all the files in the current folder, press Select All .
― To deselect all the files, press Deselect All .
Copying Files
1
Select files from the list of Videos , Photos , or Music files.
2
Select a storage device.
• Internal Memory : Copy files from Internal Memory to a USB Device memory device.
• USB Device : Copy files from a USB Device memory device to Internal Memory .
3
Press TOOLS on the remote control and select Send .
The option does not appear if a folder is highlighted by the cursor.
4 Select files and press Send .
― c appears for selected files.
― To select all the files in the current folder, press Select All .
― To deselect all the files, press Deselect All .
Creating a Playlist
1
Select files from the list of Videos , Photos , or Music files.
2
Press TOOLS on the remote control and select Add to Playlist .
― The option does not appear if a folder is highlighted by the cursor.
3
Select files and press Add .
The Add to Playlist page appears.
― c appears for selected files.
― To select all the files in the current folder, press Select All .
― To deselect all the files, press Deselect All .
4 Select Create new . The Create a new playlist.
. page appears.
5 Enter a playlist name using the remote control and select Done .
6 A playlist is created.
To play the created playlist, select Play .
To return to the list of files, select OK .
7
A created Playlist is displayed in My list .
153
My list
MENUm → Support → Contents Home → AllShare Play → My list → ENTERE
Access desired content more conveniently and quickly.
To play files, select files or a Playlist and press E.
• Recently played : Display video, photo or music files that were recently played. This mode is suitable when playing files again that were played before.
• What's new : Display new video, photo or music files that were uploaded to a PC or USB device. This mode is suitable when playing new files that were recently uploaded.
• Playlist : Display Playlist files saved on a PC or USB device. To play a Playlist , select the desired Playlist .
My list options
Option Name
Play
Remove
Operations
Play a selected file or Playlist .
Delete a selected file.
Recently played What's new c c c
Playlist c
Delete
Edit playlist
Information
Delete a selected Playlist .
Edit a selected Playlist .
View information about a selected file or Playlist .
c c c c c
154
The Resume function does not support multiple users. (It will only memorise the point where the most recent user stopped playing.)
Videos
MENUm → Support → Contents Home → AllShare Play → Videos → ENTERE
Playing a Video
1
Select the internal memory or a USB device. Select files from the list of files.
2
Press the E button or ∂ (Play) button.
• The file name appears on the top with its playing time.
• If video time information is unknown, the playing time and progress bar are not displayed.
• During video playback, you can search using the ◄ and ► buttons.
• You can use the π(REW), µ(FF), ∑(Pause), ∫(Stop), and ∂(Play) buttons on the bottom of your remote during playback.
( π 3 / π 2 / π 1 / µ 1 / µ 2 / µ 3)
• Press the RETURN button to exit the movie
Using the Play Continuously Function (Resume Play)
If you exit a movie when it is playing, you can play the movie later from the point where you stopped it.
1
Select a file from the list of files.
2
Press the ∂(Play) or E button.
3
The Movie will begin to play from where you stopped it.
― Resume is only available when you resume playing a movie you had stopped.
― Press the ∑ button for pause.
155
Photos
MENUm → Support → Contents Home → AllShare Play → Photos → ENTERE
Viewing a Photo (or Slide Show)
1
Select the internal memory or a USB device. Select a file from the list of files.
2
Press the E button.
• To view files manually, one at a time, press the left or right arrow buttons.
• To start the slide show, press the ∂(Play) button when the file you selected is displayed.
• During the slide show, all files in the file list are displayed in order, starting from the file you selected.
― If you select the wrong background music, you cannot change the music until the BGM (Background Music) has finished loading.
― During a slide show, press the TOOLS button to access additional functions such as Go to Photos List , Stop Slide Show , Slide Show Speed , Slide Show Effect ,
Background Music On / Background Music Off , Background Music Setting , Picture Mode , Sound Mode , Zoom , Rotate and Information .
― You can use the ∑(Pause), ∫(Stop), and ∂(Play) buttons on the bottom of your remote during a slide show.
― When you press the ∫(Stop) or RETURN button, the slide show stops and the main photo screen re-appears.
156
Music
MENUm → Support → Contents Home → AllShare Play → Music → ENTERE
Playing Music
1
Select the internal memory or a USB device. Select files from the list of files.
2
Press the E button or ∂(Play) button.
• When the music is playing, you can search using the π(REW) and µ(FF) button.
― If the sound is abnormal when you play MP3 files, adjust the Equaliser in the Sound menu.
(An over-modulated MP3 file may cause a sound problem.)
157
Pressing the INFO button while a device name is selected will display information about the selected device.
Pressing the INFO button while a file is selected will display information about the selected file.
Videos / Photos / Music Play Option menu
When playing video or photo files, you can press the TOOLS button to display an Options menu.
Option Name
View
Play selection
Operations
Sort music files grouped by Folder view , Title , Artist , Album or Genre .
Select and play files from a list of music files.
Videos
Go to Videos List c
Go to Photos List
Go to Playlist
Play from the beginning
Scene Search
Return to the list of video files.
Return to the list of photo files.
Go to My list .
Title Search
Time Search
Repeat Mode
Picture Size
Picture Mode
Play again the currently playing video from the beginning.
You can use the Scene Search function during playback to view or start a movie from the scene of your choice.
You can move directly to another Title.
c
You can search the movie using l and r buttons at intervals of
1 minute.
c
You can play movie and music files repeatedly.
c
You can adjust the picture size to your preference.
You can change the Picture Mode .
c c c c
Photos Music c c c c c
158
Option Name
Sound Mode
Operations
You can change the Sound Mode .
Audio Language
Subtitle
Subtitle Settings
Start Slide Show / Stop Slide
Show
Slide Show Speed
Slide Show Effect
You can enjoy video in one of supported languages.
The function is enabled only when you play stream-type files which support multiple audio formats.
You can view a subtitle. You can select a specific language if the subtitle file contains multiple languages.
Displays the Subtitle Settings . You can set up a subtitle option.
You can start or stop a slide show.
Alternatively, use the ∂ or ∑ button on the remote.
You can select the slide show speed during the slide show.
Alternatively, use the π or µ button on the remote.
You can set various slide show effects.
Videos c c c c
Background Music On /
Background Music Off
Background Music Setting
You can start or stop background music.
Zoom
Rotate
Information
You can set and select background music when watching a photo file or slide show.
You can zoom into images in full screen mode.
You can rotate images.
View file information.
c
Photos c
Music c c c c c c c c c
159
Supported Subtitle and AllShare Play file formats
Subtitle
External
• MPEG-4 timed text (.ttxt)
• SAMI (.smi)
• SubRip (.srt)
• SubViewer (.sub)
• Micro DVD (.sub or .txt)
• SubStation Alpha (.ssa)
• Advanced SubStation Alpha (.ass)
• Powerdivx (.psb)
Internal
• Xsub
Container: AVI
• SubStation Alpha
Container: MKV
• Advanced SubStation Alpha
Container: MKV
• SubRip
Container: MKV
• MPEG-4 timed text
Container: MP4
Supported image resolutions
File Extension
*.jpg, *.jpeg
Type
JPEG
PNG
*.mpo
BMP
MPO
Resolution
15360 x 8640
1920 x 1080
1920 x 1080
15360 x 8640
160
Supported music file formats
File Extension
*.mp3
*.m4a, *.mpa, *.aac, *.3ga
Type
MPEG
MPEG4
*.flac
FLAC
Codec
MPEG1 Audio Layer 3
AAC
FLAC
Comments
The Seek (jump) function is not supported.
Supports up to 2 channel
Supported Video Formats
• Video content will not play, or not play correctly, if there is an error in the content or the container.
• Sound or video may not work if the contents have a standard bitrate/frame rate above the compatible Frame/sec listed in the table above.
• If the Index Table is in error, the Seek (Jump) function is not supported.
• You may experience file stuttering while playing a video through a network connection.
• The menu may take longer to appear if the video’s bit rate exceeds 10Mbps.
• Some USB/digital camera devices may not be compatible with the player.
Video Decoder
Supports up to H.264, Level 4.1
H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and AVCHD are not supported.
For all Video codecs except MVC, VP8, VP6:
• Below 1280 x 720: 60 frame max
• Above 1280 x 720: 30 frame max
GMC 2 over is not supported.
Supports only BD MVC Spec.
Audio Decoder
Supports up to WMA 10 Pro 5.1 channel.
WMA lossless audio is not supported.
QCELP, AMR NB/WB are not supported.
If Vorbis is only in Webm container, supports up to 2 channel.
161
File
Extension
*.vro
*.mpg
*.mpeg
*.ts
*.tp
*.trp
*.mov
*.flv
*.avi
*.mkv
*.asf
*.wmv
*.mp4
*.mov
*.3gp
*.vob
*.svi
*.m2ts
*.mts
*.divx
*.webm
Container
VRO
VOB
PS
TS
AVI
MKV
ASF
MP4
3GP
WebM
Video Codec
DIVX 3.11 / 4.x / 5.x / 6.x
MPEG4 SP / ASP
H.264 BP / MP / HP
Motion JPEG
Window Media Video v9
MPEG2
MPEG1
VP6
MVC
VP8
Resolution Frame rate
(fps)
1920 x 1080 6~30
Bit rate
(Mbps)
30
640 x 480
1920 x 1080 24 / 25 / 30
6 ~ 30
4
40
8
Audio Codec
AC3
LPCM
ADMPCM
(IMA, MS)
AAC
HE-AAC
WMA
DD+
MPEG(MP3)
DTS Core
G.711(ALaw,μ-Law)
Vorbis
162
Chapter 11
MagicInfo Lite
To launch MagicInfo Lite , select
MagicInfo Lite for the Play Mode on the System .
File Formats Compatible with MagicInfo Lite player
Read before using MagicInfo Lite player
• The file system supports FAT16, FAT32 and NTFS.
• A file with a vertical and horizontal resolution larger than the maximum resolution cannot be played.
Check the vertical and horizontal resolution of the file.
• Check the supported video and audio Codec types and Versions.
• Check the supported file versions.
Flash version up to 10.1 is supported
PowerPoint version up to 97 – 2007 is supported
• Only the last USB device that was connected is recognized.
163
Contents
File Extension Container Video Codec
*.mpg
*.mpeg
*.ts
*.tp
*.trp
*.flv
*.vob
*.svi
*.avi
*.mkv
*.asf
*.wmv
*.mp4
*.mov
*.3gp
*.vro
*.m2ts
*.mts
*.divx
AVI
MKV
ASF
MP4
3GP
VRO
VOB
PS
TS
DIVX 3.11 / 4.x / 5.x / 6.x
MPEG4 SP / ASP
H.264 BP / MP / HP
Motion JPEG
Window Media Video v9
MPEG2
MPEG1
VP6
Resolution
1920 x 1080
640 x 480
Frame rate
(fps)
6~30
Bit rate
(Mbps)
30
4
Audio Codec
AC3
LPCM
AAC
HE-AAC
WMA
DD+
MPEG(MP3)
DTS Core
G.711(ALaw,μ-Law)
164
Video
• 3D video is not supported.
• Content with a resolution larger than the resolution specified in the table above is not supported.
• Video content with a Bit rate or Frame rate larger than the rate specified in the table above can cause choppy video during playback.
• Video content will not play, or not play correctly, if there is an error in the content or the container.
• Some USB/digital camera devices may not be compatible with the player.
• Supports up to H.264, Level 4.1
• H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and
AVCHD are not supported.
• For all Video codecs except MVC, VP8, VP6:
Below 1280 x 720: 60 frame max
Above 1280 x 720: 30 frame max
• GMC 2 or higher is not supported.
• Supports only BD MVC Spec.
Audio
• Audio content with a Bit rate or Frame rate larger than the rate specified in the table above can cause choppy audio during playback.
• Video content will not play, or not play correctly, if there is an error in the content or the container.
• Some USB/digital camera devices may not be compatible with the player.
• Supports up to WMA 10 Pro 5.1 channel. WMA lossless audio is not supported.
• QCELP, AMR NB/WB are not supported.
• Compatible image file format : Jpeg
• Supported maximum resolution : 15,360 x 8,640
• Supported image effects : 13 effects
( Fade1 , Fade2 , Blind , Checker , Stairs , Linear ,
Wipe , Ripple Wash , Drop Wave , Pin Wheel ,
Random Blocks , Spin Fade In )
165
Flash
• Compatible with Flash 10.1
• Flash Animation
Compatible file format : SWF
• Recommended resolution : 960 x 540
Caution
Performance comparable to Flash Player on a Windows operating system cannot be guaranteed
Optimization is needed during content creation
• Flash Video
Compatible file format : FLV
Video
Codec : H.264 BP
Resolution : 1920 x 1080
Audio
Codec : H.264 BP
Caution
F4V file format is not supported
Screen Video is not supported
Power Point
• Compatible document file formats
Extension : ppt, pptx
Version : Office 97 ~ Office 2007
• Functions not supported
Animation effect
3D shapes (which will be displayed in 2D)
Header and footer (some subitems are not supported)
Word Art
Align
A group alignment error may occur
Office 2007
SmartArt is not fully supported. 97 out of 115 subitems are supported.
Object insertion
Opening encrypted documents
Vertical text some subitems are not supported
Slide notes and handout
166
• Compatible document file formats
Extension : pdf
• Functions not supported
Content less than 1 pixel not supported because of performance degradation issue.
Masked Image, Tiled Image content not supported.
Content with Rotated Text, not supported.
3D Shadow Effects not supported.
WORD
• Compatible document file formats
Extension : .doc, .docx
Version : Office 97 ~ Office 2007
• Functions not supported
Page background effect
Some paragraph styles
Word Art
Align
A group alignment error may occur
3D shapes (which will be displayed in 2D)
Office 2007
SmartArt is not fully supported. 97 out of 115 subitems are supported.
Charts
Half-width characters
Letter spacing
Vertical text some subitems are not supported
Slide notes and handout
167
Approving a connected device from the server
1
Access the server you have assigned to your device.
4
Select Lite from the menus on the left.
5
Select Unapproved from the sub-menus of Lite .
6
Select the Approve button for your device from the list of unapproved Lite devices.
2
Enter your ID and password to log in.
3
Select Device from the top menu bar.
168
7
Enter the information required to approve the device.
• Device Name : Enter the device name.
• Device Group : Select to specify the group.
• Location : Enter the current location of the device.
― Pressing the INFO button on the remote when a network schedule is running will display the details of the schedule. Check that the correct device has been selected by viewing the device ID in the details.
8
Select the All menu to check that the device has been registered.
9
When the device is approved by the server, the schedule registered in the selected group will be downloaded to the device. The schedule will run after it is downloaded.
― For further details on how to configure a schedule, refer to the <MagicInfo Lite Server user's manual>.
― If a device is deleted from the list of devices approved by the server, the device will reboot to reset its settings.
Setting the current time
A schedule may not run if the time set on the device is different from the server's current time.
1
Go to the tabs Device → Time .
2
Select your device.
3
Select Clock Set , and sync the time with the server.
• When connecting to the server for the first time, the time on the product is set using the GMT time of the region where the server is installed.
• The time on the product can be changed from the server as shown in step 3.
• Turning the product off and then on again will restore the time setting on the product to the last time that was set from the server.
― For further details on how to manage the time (scheduling, holiday management, etc.), refer to the
<MagicInfo Lite Server user's manual>.
169
MagicInfo Lite
MENUm → Support → Contents Home → MagicInfo Lite → ENTERE
― To launch MagicInfo Lite , select MagicInfo Lite for the Play Mode on the System .
― Press the MagicInfo Lite/S button on the remote control.
MagicInfo Lite player
Network schedule
You can view whether the server is connected (approval) in the MagicInfo Lite menu screen. To view whether the server is connected when a Network schedule is running, press INFO on the remote.
1 Select MagicInfo Lite player in the MagicInfo Lite menu.
MagicInfo Lite
MagicInfo Lite player
Local Schedule Manager
Content manager
Settings
Close
Mode
Local schedule
Server
Connected
USB
Connected
Return
2
Select Network schedule in the MagicInfo Lite player menu.
MagicInfo Lite player
Network schedule
Local schedule
Internal Auto Play
USB Device Auto Play
Close
Mode
Local schedule
Server
Connected
USB
Connected
Return
170
Local schedule
MagicInfo Lite player
Network schedule
Local schedule
Internal Auto Play
USB Device Auto Play
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
Internal Auto Play
MagicInfo Lite player
Network schedule
Local schedule
Internal Auto Play
USB Device Auto Play
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
Go to Local Schedule Manager → Click Create to create a schedule → Select the schedule you want to run
1
Select Local schedule in the MagicInfo Lite player menu screen.
Run schedules created in Local Schedule Manager .
― This menu is disabled if there was no schedule run previously in Local Schedule Manager .
― The option is enabled only when there is at least one content item, except for music files, in Internal Memory .
1
Select Internal Auto Play in the MagicInfo Lite player menu screen.
• Play content, which has been copied to Internal Memory , in alphabetical order.
171
USB Device Auto Play
MagicInfo Lite player
Network schedule
Local schedule
Internal Auto Play
USB Device Auto Play
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
― The option is enabled only when there is at least one content item, except for music files, in the "MagicInfoSlide" folder on
USB Storage.
― Ensure a USB device is inserted. Be sure to create a folder named "MagicInfoSlide" in the USB device and put content in the folder.
1
Select USB Device Auto Play in the MagicInfo Lite player menu screen.
• The content contained in the "MagicInfoSlide" folder on the USB device will play in alphabetical order.
• USB Device Auto Play will automatically run if USB memory is connected when Network schedule , Local schedule or
Internal Auto Play is running.
172
Local Schedule Manager
Configure the settings for playback from Local schedule .
Alternatively, select and play content from internal or USB memory according to the customized playback sequence.
Registering a Local schedule
1
Select Local Schedule Manager in the MagicInfo Lite menu screen.
MagicInfo Lite
2
Select Create in the Local Schedule Manager screen.
Storage
Local Schedule Manager
No Playing Schedule
Internal Memory
Create
Edit
Delete
Run
Info
Copy
Close
MagicInfo Lite player
Local Schedule Manager
Content manager
Settings
Close
Return
3 Select Time to set the time you want to play content.
Mode
Local schedule
Server
Connected
USB
Connected
Return
Create
T
C
Time
Contents
12 : 00 am ~
No Item
12 : 00
--:-- am~ --:-- pm
No Items pm
Save
Cancel
Return
A maximum of 24 schedules can be created.
If more than one schedule is created, the start time must be different for each schedule.
(Example of an incorrect setting: 12:00 am - 12:00 am / 12:00 am - 11:00 pm)
Referring to the example shown below, if more than one Local schedule is assigned to a single time slot, schedule B is executed before schedule A.
(E.g., A: 12:00 am - 12:00 am / B: 01:00 pm - 02:00 pm)
173
4
Select Contents to specify the content you want to play.
Internal Memory
No Items
1
2
Contents
USB
Folder1
OK
Deselect All
Cancel
Duration
Return
A maximum of 99 content files can be selected.
5
Select Duration
Contents
Direction
Duration
00:00:05
00:00:05
Up
Down
Save
Cancel
Return
Specify the sequence and time duration to play content files.
• Changing the playing sequence
Select a content file and change the sequence using the Up or Down button.
• Duration
Set the duration to play content.
Duration cannot be specified for videos.
Duration must be at least 5 seconds.
Press Save to save the settings.
174
6
Select Save . Select the memory space you want to save the content to.
Time
Contents
Time
Cont
Create
--:-- am~ --:-- pm
Menu1.jpg Menu2
--:-- am ~ --:-- pm
--:-- am ~ --:-- pm
No Item
No Item
Internal
Delete
ave
Cancel
ncel
Time
Contents
--:-- am~ --:-- pm
No Items
Return
7
Check that the schedule has been added to the Local Schedule Manager .
Storage
Local Schedule Manager
Internal Memory
No Playing Schedule
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Run
Info
Copy
Close
Return
Modifying a Local schedule
― Ensure at least one Local schedule is registered.
1 Select Local Schedule Manager in the MagicInfo Lite menu screen.
MagicInfo Lite
MagicInfo Lite player
Local Schedule Manager
Content manager
Settings
Close
Mode
Local schedule
Server
Connected
USB
Connected
Return
2
Select the local schedule you want to modify.
Storage
Local Schedule Manager
No Playing Schedule
Internal Memory
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Run
Info
Copy
Close
Return
175
3
Select Edit .
Time
Contents
Edit
12:00 am~ 12:00 pm
Menu1.jpg Menu2
Delete
Time
Contents
--:-- am~ --:-- pm
No Items
Time
Contents
--:-- am~ --:-- pm
No Items
Save
Cancel
Return
4
Change the details of the local schedule. Next, select Save .
Deleting a Local schedule
― Ensure at least one Local schedule is registered.
1
Select Local Schedule Manager in the MagicInfo Lite menu screen.
MagicInfo Lite
MagicInfo Lite player
Local Schedule Manager
Content manager
Settings
Close
Mode
Local schedule
Server
Connected
USB
Connected
Return
2
Select the local schedule you want to delete.
Storage
Local Schedule Manager
Internal Memory
No Playing Schedule
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Run
Info
Copy
Close
Return
3
Next, select Delete .
176
Running a Local schedule
― Ensure at least one Local schedule is registered.
1
Select Local Schedule Manager in the MagicInfo Lite menu screen.
MagicInfo Lite
MagicInfo Lite player
Local Schedule Manager
Content manager
Settings
Close
Mode
Local schedule
Server
Connected
USB
Connected
Return
2
Select the local schedule you want to run. Next, select Run .
Storage
Local Schedule Manager
No Playing Schedule
Internal Memory
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Run
Info
Copy
Close
Return
Stopping a Local schedule
― This function is enabled only when a schedule is running.
Selecting Stop will change the running mode from Local schedule to Network schedule .
1
Select Local Schedule Manager in the MagicInfo Lite menu screen.
MagicInfo Lite
MagicInfo Lite player
Local Schedule Manager
Content manager
Settings
Close
Mode
Local schedule
Server
Connected
USB
Connected
Return
2
Select Stop .
Local Schedule Manager
Internal Memory Storage
[Internal Memory] 2012.01.01_1834.lsch
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Stop
Info
Copy
Close
Return
177
Viewing the details of a Local schedule
1 Select Local Schedule Manager in the MagicInfo Lite menu screen.
MagicInfo Lite
MagicInfo Lite player
Local Schedule Manager
Content manager
Settings
Close
Mode
Local schedule
Server
Connected
USB
Connected
Return
2
Select the local schedule you want to view the details of.
Storage
Local Schedule Manager
No Playing Schedule
Internal Memory Create
Edit
Delete
All schedules
2012.01.01_1834.lsch
Run
Info
Copy
Close
Return
3
The details of the schedule will be displayed.
Information
2012.01.01_1834.lsch
12:00 am~12:00 pm, 2 File(s)
- Menu1.jpg Menu2.jpg
Close
Return
178
Copying a Local schedule
1
Select Local Schedule Manager in the MagicInfo Lite menu screen.
MagicInfo Lite
MagicInfo Lite player
Local Schedule Manager
Content manager
Settings
Close
Mode
Local schedule
Server
Connected
USB
Connected
Return
2
Select a storage device where the local schedule files to copy are saved.
Local Schedule Manager
Storage
No Pl USB
Create
Edit
Delete
All schedules
2012.01.01_1834.lsch
Run
Info
Copy
Close
Return
• Internal Memory : Copy local schedules from Internal Memory to a USB memory device.
• USB : Copy local schedules from a USB memory device to Internal Memory .
3
Select local schedule files and press Copy .
Storage
Local Schedule Manager
No Playing Schedule
Internal Memory
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Run
Info
Copy
Close
Return
4
A window appears asking if you want to copy the files to the Internal Memory or USB memory device. Select Yes to copy the files.
179
Content manager
Copying content
1
Select Content manager in the MagicInfo Lite menu screen.
MagicInfo Lite player
Local Schedule Manager
Content manager
Settings
MagicInfo Lite player
Close
Mode
Local schedule
Server
Connected
USB
Connected
Return
2
Select the content you want to copy.
Internal Memory
No Items
Content manager
USB
Folder1
Free Space
Selected File(s) :
5549.2MB
0.0MB (0)
Free Space
Selected File(s) :
6227.2MB
0.2MB (2)
Copy
Delete
Close
Return Select
• If content under Internal Memory is selected: You can copy the content under Internal
Memory to USB memory.
• If content under USB is selected: You can copy the content under USB memory to Internal
Memory .
― Selecting content under Internal Memory and USB memory at the same time will disable copying.
3
Next, select Copy .
180
Deleting content
1
Select Content manager in the MagicInfo Lite menu screen.
MagicInfo Lite player
Local Schedule Manager
Content manager
Settings
MagicInfo Lite player
Close
Mode
Local schedule
Server
Connected
USB
Connected
Return
2
Select the content you want to delete. Next, select Delete .
• Content under Internal Memory and USB memory can be deleted at the same time.
Internal Memory
Content manager
USB
Folder1
Free Space
Selected File(s) :
5549.2MB
0.0MB (0)
Free Space
Selected File(s) :
6227.2MB
0.2MB (2)
Select
Copy
Delete
Close
Return
181
Settings
Settings
Server Network Settings
Default content duration
Content ratio
Image Effect
Default content
Content Layout
Schedule Name
Safely Remove USB Device
Random
None
Landscape
YYYYMMDD
Close
Return
The displayed image may differ depending on the model.
Server Network Settings
To run MagicInfo Lite , connect to a network.
Server
Enter the MagicInfo Lite server settings.
(E.g.: http://192.168.0.10:7001/MagicInfo/)
• If the SSL option is enabled, the server is configured to use https and data transfer is encrypted.
― Enter the server IP address and port number. Use 7001 as the port number. (If unable to connect to the server using port number 7001, check with your server administrator to find the correct port number and then change the port number.)
FTP Mode
Specify the FTP operating mode.
• Active / Passive
Default Storage
Specify the location you want to save content (downloaded from the server) to.
• Internal Memory : Save the content to the internal memory of the product.
• USB : Save the content to USB memory.
― If a Network Settings is running when USB memory is not connected, the default content will run.
182
Default content duration
Specify the duration to play content.
• Image Viewer Time , Doc viewing time , PPT Viewer Time , PDF viewing time , Flash viewing time
― The duration must be at least 5 seconds.
Content Ratio
Specify the display aspect ratio by type when playing content.
• Doc Ratio , PPT ratio , PDF ratio , Video ratio
Original : Display content with the original size.
Full Screen : Display content in full screen.
Image Effect
Configures the image transition effects.
• Fade1 , Fade2 , Blind , Spiral , Checker , Linear , Stairs , Wipe , Ripple Wash , Drop Wave , Pin
Wheel , Random Blocks , Spin Fade In , Random , None
Default content
Specify the content to play by default when launching MagicInfo Lite .
• Content of up to 20MB is supported for Default content .
Content Layout
Change the screen orientation to landscape or portrait view.
• Landscape / Portrait
Schedule Name
Select a schedule title format when creating a local schedule.
• YYYYMMDD / YYYYDDMM / DDMMYYYY
Safely Remove USB Device
Safely removes USB memory
Delete all content
Delete all the content files in Internal Memory .
Reset Settings
Restore all the values under Settings to the default when the product was purchased.
183
When Content is Running
Viewing the details of the content that is running
Information
Software Version
Device Name
Device ID
Mode
Server
USB
Schedule download
: A-LUBXGDSP-0100.18
: Monitor
: FF-FF-FF-FF-FF-FF
: Local schedule
: Disconnected
: Connected
: No Schedule to download
Cancel
Press the INFO button on the remote control.
• Software Version : Displays the software version of a device
• Device Name : Displays the name of a device recognized by the server
• Device ID : Displays the original identification number of a device
• Mode : Displays the current operating mode
( Network schedule , Local schedule , Internal Auto Play or USB Device Auto Play ) of MagicInfo Lite player
• Server : Displays the connection status ( Connected , Disconnected or Not approved ) of the server
• USB : Displays the connection status of a USB device
• Schedule download : Displays the progress of a network schedule being downloaded from the server
The displayed image may differ depending on the model.
184
Changing the settings for the content that is running
Tools
Picture Mode
Sound Mode
PIP
Background Music
Background Music Setting
Safely Remove USB Device
Standard
Standard
Off
Off
Return
The displayed image may differ depending on the model.
Press the TOOLS button on the remote control.
You can change the Picture Mode or Sound Mode setting or safely remove a USB device ( Safely Remove USB Device ) while content is playing by pressing the TOOLS button on the remote control.
• Picture Mode ( Dynamic / Standard / Natural / Movie )
Customizes the screen settings for the content currently playing
• Sound Mode ( Standard / Music / Movie / Clear Voice / Amplify )
Customizes the audio settings for the content currently playing
• PIP ( Off / On )
Activate or deactivate the PIP function.
• Background Music ( Off / On )
Activate or deactivate the Background Music function.
• Background Music Setting ( Shuffle / Play / Cancel / Deselect )
Set music files saved in the Internal Memory as Background Music .
― To enable the Background Music Setting , make sure at least one MP3 file is saved in Internal Memory .
• Safely Remove USB Device
Safely removes USB memory
185
Chapter 12
MagicInfo Premium S
To launch MagicInfo Premium S , select
MagicInfo Premium S for the Play
Mode on the System .
A Licence needs to be purchased to use MagicInfo Premium S .
To download the software, go to the Samsung homepage at http://www.samsunglfd.com.
To purchase a licence, contact a Customer Server Centre.
File Formats Compatible with MagicInfo Premium S Player
Read before using MagicInfo Premium S Player
• The file system supports FAT16, FAT32 and NTFS.
• A file with a vertical and horizontal resolution larger than the maximum resolution cannot be played.
Check the vertical and horizontal resolution of the file.
• Check the supported video and audio Codec types and Versions.
• Check the supported file versions.
Flash version up to 10.1 is supported
PowerPoint version up to 97 – 2007 is supported
• Only the last USB device that was connected is recognized.
― See
page 164 for further details on supported codecs.
186
Video
• 3D video is not supported.
• Content with a resolution larger than the resolution specified in the table above is not supported.
• Video content with a Bit rate or Frame rate larger than the rate specified in the table above can cause choppy video during playback.
• Video content will not play, or not play correctly, if there is an error in the content or the container.
• Some USB/digital camera devices may not be compatible with the player.
• Supports up to H.264, Level 4.1
• H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and
AVCHD are not supported.
• For all Video codecs except MVC, VP8, VP6:
Below 1280 x 720: 60 frame max
Above 1280 x 720: 30 frame max
• GMC 2 or higher is not supported.
• Supports only BD MVC Spec.
Audio
• Audio content with a Bit rate or Frame rate larger than the rate specified in the table above can cause choppy audio during playback.
• Video content will not play, or not play correctly, if there is an error in the content or the container.
• Some USB/digital camera devices may not be compatible with the player.
• Supports up to WMA 10 Pro 5.1 channel. WMA lossless audio is not supported.
• QCELP, AMR NB/WB are not supported.
• Compatible image file format : Jpeg
• Supported maximum resolution : 15,360 x 8,640
• Supported image effects : 8 effects
( Fade1 , Fade2 , Blind , Checker , Stairs , Linear ,
Wipe , Ripple Wash )
187
Flash
• Compatible with Flash 10.1
• Flash Animation
Compatible file format : SWF
• Recommended resolution : 960 x 540
Caution
Performance comparable to Flash Player on a Windows operating system cannot be guaranteed
Optimization is needed during content creation
• Flash Video
Compatible file format : FLV
Video
Codec : H.264 BP
Resolution : 1920 x 1080
Audio
Codec : H.264 BP
Caution
F4V file format is not supported
Screen Video is not supported
Power Point
• Compatible document file formats
Extension : ppt, pptx
Version : Office 97 ~ Office 2007
• Functions not supported
Animation effect
3D shapes (which will be displayed in 2D)
Header and footer (some subitems are not supported)
Word Art
Align
A group alignment error may occur
Office 2007
SmartArt is not fully supported. 97 out of
115 subitems are supported.
Object insertion
Half-width characters
Letter spacing
Charts
Vertical text some subitems are not supported
Slide notes and handout
• Compatible document file formats
Extension : pdf
• Functions not supported
Content less than 1 pixel not supported because of performance degradation issue.
Masked Image, Tiled Image content not supported.
Content with Rotated Text, not supported.
3D Shadow Effects not supported.
Some characters not supported
(Special characters may be corrupted)
188
WORD
• Compatible document file formats
Extension : .doc, .docx
Version : Office 97 ~ Office 2007
• Functions not supported
Page background effect
Some paragraph styles
Word Art
Align
A group alignment error may occur
3D shapes (which will be displayed in 2D)
Office 2007
SmartArt is not fully supported. 97 out of
115 subitems are supported.
Charts
Half-width characters
Letter spacing
Vertical text some subitems are not supported
Slide notes and handout
Template files
• Creation/editing/playback are only available in
Template Manager .
LFD
• Supported in USB Device Auto Play and
Network schedule (Authored in a PC authoring tool for Premium S Player)
• Compatible document file formats
Extension : .lfd
189
Network Schedule Multiframe
Playback restrictions
• A maximum of two video ( Videos ) files can be played.
• If PIP mode is enabled, more than one video ( Videos ) file cannot be played.
• More than one Flash file cannot be played.
• For Office files (PPT and Word files) and PDF files, only one file type is supported at a time.
• LFD(.lfd) files are not supported.
Sound output restrictions
• More than one sound output cannot be used.
• Playback priority: Flash file > network BGM > local BGM > video file in the main frame selected by the user
― Network BGM: Settings can be configured in step 1 when creating a server schedule.
― Local BGM: BGM settings can be configured using the tools displayed after the TOOLS button is pressed during MagicInfo Premium S playback.
― User-selected main frame: Main frame settings can be configured in step 2 when creating a server schedule.
Template files and LFD(.lfd) files
Restrictions
• Scenarios created in a PC authoring tool that were published to a USB device are not supported.
• Scenarios created in a PC authoring tool that were published along with schedule details to a USB device are not supported.
• Playback is only possible via USB Device Auto Play .
An .lfd file must exist under the MagicInfoSlide folder on the USB device.
190
Playback restrictions
• A maximum of two video ( Videos ) files can be played.
• If PIP mode is enabled, more than one video ( Videos ) file cannot be played.
• More than one Flash file cannot be played.
• For Office files (PPT and Word files) and PDF files, only one file type is supported at a time.
• Multiple videos ( Videos ) cannot be played on a single display of a video wall simultaneously.
• More than one PIP content file cannot be played.
Sound output restrictions
• More than one sound output cannot be used.
• Playback priority: Flash file > network BGM > local BGM > video file in the main frame selected by the user
― User-selected main frame: Sound output can be selected in step 3 while authoring in Template Manager
Others
Flash performance can be slower on a PC (H/W performance restrictions)
PIP function restrictions
• PIP function is not available during Flash playback.
• Not supported if the content layout is Portrait . (Note that PIP is supported when configured in Template Manager and applied to an .lfd file.)
• PIP configured in Template Manager or applied to an .lfd file and PIP configured on the product cannot be used simultaneously.
• PIP is always in Landscape mode if configured in Template Manager or applied to an .lfd file.
(Note that the display cannot be rotated when the content layout is Portrait .)
191
Approving a connected device from the server
1
Access the server you have assigned to your device.
4
Select Premium from the menus on the left.
5
Select Unapproved from the sub-menus of Premium .
6
Select the Approve button for your device from the list of unapproved Premium devices.
2
Enter your ID and password to log in.
3
Select Device from the top menu bar.
192
7
Enter the information required to approve the device.
• Device Name : Enter the device name.
• Device Group : Select to specify the group.
• Location : Enter the current location of the device.
― Pressing the INFO button on the remote when a network schedule is running will display the details of the schedule. Check that the correct device has been selected by viewing the device ID in the details.
8 Select the All menu to check that the device has been registered.
9
When the device is approved by the server, the schedule registered in the selected group will be downloaded to the device. The schedule will run after it is downloaded.
― For further details on how to configure a schedule, refer to the <MagicInfo Premium Server user's manual>.
― If a device is deleted from the list of devices approved by the server, the device will reboot to reset its settings.
Setting the current time
A schedule may not run if the time set on the device is different from the server's current time.
1
Go to the tabs Device → Time .
2
Select your device.
3
Select Clock Set , and sync the time with the server.
• When connecting to the server for the first time, the time on the product is set using the GMT time of the region where the server is installed.
• The time on the product can be changed from the server as shown in step 3.
• Turning the product off and then on again will restore the time setting on the product to the last time that was set from the server.
― For further details on how to manage the time (scheduling, holiday management, etc.), refer to the
<MagicInfo Premium Server user's manual>.
193
MagicInfo Premium S
MENU m : T Contents Home MagicInfo Premium S ENTER E
― To launch MagicInfo Premium S , select MagicInfo Premium S for the Play Mode on the System .
― Press the MagicInfo Lite/S button on the remote control.
MagicInfo Premium S Player
Network schedule
You can view whether the server is connected (approval) in the MagicInfo Premium S menu screen.
To view whether the server is connected when a Network schedule is running, press INFO on the remote.
1
Select MagicInfo Premium S Player in the MagicInfo Premium S menu.
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Manager
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
2
Select Network schedule in the MagicInfo Premium S Player menu.
MagicInfo Premium S Player
Network schedule
Local schedule
Template Player
Internal Auto Play
USB Device Auto Play
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
194
Local schedule
MagicInfo Premium S Player
Network schedule
Local schedule
Template Player
Internal Auto Play
USB Device Auto Play
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
Template Player
MagicInfo Premium S Player
Network schedule
Local schedule
Template Player
Internal Auto Play
USB Device Auto Play
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
Go to Local Schedule Manager → Click Create to create a schedule → Select the schedule you want to run
1
Select Local schedule in the MagicInfo Premium S Player menu screen.
Run schedules created in Local Schedule Manager .
― This menu is disabled if there was no schedule run previously in Local Schedule Manager .
Go to Template Manager → Click Create to create a template → Select the template you want to run
1 Select Template Player in the MagicInfo Premium S Player menu screen.
Run templates created in Template Manager .
― This menu is disabled if there was no schedule run previously in Local Schedule Manager .
195
Internal Auto Play
MagicInfo Premium S Player
Network schedule
Local schedule
Template Player
Internal Auto Play
USB Device Auto Play
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
USB Device Auto Play
MagicInfo Premium S Player
Network schedule
Local schedule
Template Player
Internal Auto Play
USB Device Auto Play
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
― The option is enabled only when there is at least one content item, except for music files, in Internal Memory .
1
Select Internal Auto Play in the MagicInfo Premium S Player menu screen.
• Play content, which has been copied to Internal Memory , in alphabetical order.
― The option is enabled only when there is at least one content item, except for music files, in the "MagicInfoSlide" folder on
USB Storage.
― Ensure a USB device is inserted. Be sure to create a folder named "MagicInfoSlide" in the USB device and put content in the folder.
1
Select USB Device Auto Play in the MagicInfo Premium S Player menu screen.
• The content contained in the "MagicInfoSlide" folder on the USB device will play in alphabetical order.
• USB Device Auto Play will automatically run if USB memory is connected when Network schedule , Local schedule or
Internal Auto Play is running.
196
Local Schedule Manager
Configure the settings for playback from Local schedule .
Alternatively, select and play content from internal or USB memory according to the customized playback sequence.
Registering a Local schedule
1
Select Local Schedule Manager in the MagicInfo Premium S menu screen.
2
Select Create in the Local Schedule Manager screen.
Storage
Local Schedule Manager
No Playing Schedule
Internal Memory
Create
Edit
Delete
Run
Info
Copy
Close
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Player
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
3
Select Time to set the time you want to play content.
Create
Return pm
Return
T
C
Time
Contents
12 : 00 am ~
No Item
12 : 00
--:-- am~ --:-- pm
No Items
Save
Cancel
Return
A maximum of 24 schedules can be created.
If more than one schedule is created, the start time must be different for each schedule.
(Example of an incorrect setting: 12:00 am - 12:00 am / 12:00 am - 11:00 pm)
Referring to the example shown below, if more than one Local schedule is assigned to a single time slot, schedule B is executed before schedule A.
(E.g., A: 12:00 am - 12:00 am / B: 01:00 pm - 02:00 pm)
197
4
Select Contents to specify the content you want to play.
Internal Memory
No Items
1
2
Contents
USB
Folder1
OK
Deselect All
Cancel
Duration
Return
A maximum of 99 content files can be selected.
5
Select Duration
Contents
Direction
Duration
00:00:05
00:00:05
Up
Down
Save
Cancel
Return
Specify the sequence and time duration to play content files.
• Changing the playing sequence
Select a content file and change the sequence using the Up or Down button.
• Duration
Set the duration to play content.
Duration cannot be specified for videos.
Duration must be at least 5 seconds.
Press Save to save the settings.
198
6
Select Save . Select the memory space you want to save the content to.
Time
Contents
Time
Con
Create
--:-- am~ --:-- pm
Menu1.jpg Menu2
--:-- am ~ --:-- pm
--:-- am ~ --:-- pm
No Item
No Item
Internal
Delete
Cancel
Save
ncel
Time
Contents
--:-- am~ --:-- pm
No Items
Return
7
Check that the schedule has been added to the Local Schedule Manager .
Storage
Local Schedule Manager
Internal Memory
No Playing Schedule
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Run
Info
Copy
Close
Return
Modifying a Local schedule
― Ensure at least one Local schedule is registered.
1
Select Local Schedule Manager in the MagicInfo Premium S menu screen.
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Player
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
2
Select the local schedule you want to modify.
Storage
Local Schedule Manager
No Playing Schedule
Internal Memory
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Run
Info
Copy
Close
Return
199
3
Select Edit .
Time
Contents
Edit
12:00 am~ 12:00 pm
Menu1.jpg Menu2
Delete
Time
Contents
Time
Contents
--:-- am~ --:-- pm
No Items
--:-- am~ --:-- pm
No Items
Save
Cancel
Return
4
Change the details of the local schedule. Next, select Save .
Deleting a Local schedule
― Ensure at least one Local schedule is registered.
1 Select Local Schedule Manager in the MagicInfo Premium S menu screen.
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Player
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
2
Select the local schedule you want to delete.
Storage
Local Schedule Manager
Internal Memory
No Playing Schedule
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Run
Info
Copy
Close
Return
3
Next, select Delete .
200
Running a Local schedule
― Ensure at least one Local schedule is registered.
1 Select Local Schedule Manager in the MagicInfo Premium S menu screen.
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Player
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
2
Select the local schedule you want to run. Next, select Run .
Storage
Local Schedule Manager
Internal Memory
No Playing Schedule
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Run
Info
Copy
Close
Return
Stopping a Local schedule
― This function is enabled only when a schedule is running.
Selecting Stop will change the running mode from Local schedule to Network schedule .
1
Select Local Schedule Manager in the MagicInfo Premium S menu screen.
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Player
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
2
Select Stop .
Local Schedule Manager
Internal Memory Storage
[Internal Memory] 2012.01.01_1834.lsch
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Stop
Info
Copy
Close
Return
201
Viewing the details of a Local schedule
1 Select Local Schedule Manager in the MagicInfo Premium S menu screen.
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Player
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
2
Select the local schedule you want to view the details of.
Storage
Local Schedule Manager
No Playing Schedule
Internal Memory Create
Edit
Delete
All schedules
2012.01.01_1834.lsch
Run
Info
Copy
Close
Return
3
The details of the schedule will be displayed.
Information
2012.01.01_1834.lsch
12:00 am~12:00 pm, 2 File(s)
- Menu1.jpg Menu2.jpg
Close
Return
202
Copying a Local schedule
1 Select Local Schedule Manager in the MagicInfo Premium S menu screen.
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Player
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
2
Select a storage device where the local schedule files to copy are saved.
Local Schedule Manager
Storage
No Pla
All schedules
2012.01.01_1834.lsch
USB
Create
Edit
Delete
Run
Info
Copy
Close
Return
• Internal Memory : Copy local schedules from Internal Memory to a USB memory device.
• USB : Copy local schedules from a USB memory device to Internal Memory .
3
Select local schedule files and press Copy .
Storage
Local Schedule Manager
No Playing Schedule
Internal Memory
All schedules
2012.01.01_1834.lsch
Create
Edit
Delete
Run
Info
Copy
Close
Return
4
A window appears asking if you want to copy the files to the Internal Memory or USB memory device. Select Yes to copy the files.
203
Template Manager
Registering a Template
1
Select Template Manager in the MagicInfo Premium S menu screen.
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Manager
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
2
Select Create in the Template Manager screen.
Storage
Template Manager
No Playing Schedule
Internal Memory
Create
Edit
Copy
Delete
Play
Preview
Close
Return
3
Select a template in Landscape or Portrait mode.
Create
Select a template.
Landscape Portrait
Next
Cancel
― Interlaced signal rotation is not supported.
204
4
Organize a template by inserting text, video, photo, or PDF files as desired.
Create
Select the position and the background.
Use background image
Preview
Previous
Next
Cancel
To load a file or manually enter text, select Text input .
Contents
Contents
Type
Contents
Size
Source
None
No Items
Fit to screen
PC
OK Cancel
Return
• Type : Select a file type to use to organize a template.
PIP / Videos / Image / Flash / Office / PDF
• Contents : Select a file saved in Internal Memory or a USB device.
• Size : Specify the screen size when displaying a content file on the template page.
Fit to screen / Lock Aspect Ratio
• Source : This option is enabled when Type is set to PIP .
Component / AV / PC / DVI / HDMI
― A template can contain a maximum of two Videos files.
― A template can contain only one PIP file.
(If a PIP file is selected, only one Videos file can be selected.)
― An Office file and a PDF file cannot be contained in the same template.
― A template cannot contain more than one Flash file.
205
5
Select sound or background music.
Create
Select sound or background music.
Background Music
Preview
Previous
Next
Cancel
6
Select Save . Select the memory space you want to save the content to.
Create
Save the template and finish.
Storage
Template Name
Internal
20130101_2222
Preview
Previous
OK
Cancel
• If two Videos files are assigned, select the file with the sound you want to use.
If one of the video files includes PIP content, sound from the PIP content can be selected.
• If a Flash file is selected, it is not possible to enable the sound output from another file or the background music. (Step 5 is skipped.)
• If Background Music is enabled, the sound settings function in a file is not supported.
7
Check that the template has been added to the Template Manager .
Storage
Template Manager
Internal Memory
No Playing Schedule
All schedules
20130101_2222.tlfd
Create
Edit
Copy
Delete
Run
Preview
Close
Return
206
Content manager
Copying content
1
Select Content manager in the MagicInfo Premium S menu screen.
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Manager
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
2
Select the content you want to copy.
Internal Memory
No Items
Content manager
USB
Folder1
Free Space
Selected File(s) :
5549.2MB
0.0MB (0)
Free Space
Selected File(s) :
6227.2MB
0.2MB (2)
Copy
Delete
Close
Return Select
• If content under Internal Memory is selected: You can copy the content under Internal
Memory to USB memory.
• If content under USB is selected: You can copy the content under USB memory to Internal
Memory .
― Selecting content under Internal Memory and USB memory at the same time will disable copying.
3
Next, select Copy .
207
Deleting content
1
Select Content manager in the MagicInfo Premium S menu screen.
MagicInfo Premium S
MagicInfo Premium S Player
Local Schedule Manager
Template Manager
Content manager
Settings
Mode
Local schedule
Server
Connected
USB
Connected
Close
Return
2
Select the content you want to delete. Next, select Delete .
• Content under Internal Memory and USB memory can be deleted at the same time.
Internal Memory
Content manager
USB
Folder1
Free Space
Selected File(s) :
5549.2MB
0.0MB (0)
Free Space
Selected File(s) :
6227.2MB
0.2MB (2)
Select
Copy
Delete
Close
Return
208
Settings
Settings
Server Network Settings
Default content duration
Content ratio
Image Effect
Default content
Content Layout
Schedule Name
Safely Remove USB Device
Random
None
Landscape
YYYYMMDD
Close
Return
The displayed image may differ depending on the model.
Server Network Settings
To run MagicInfo Premium S , connect to a network.
Server
Enter the MagicInfo Premium S server settings.
• If the SSL option is enabled, the server is configured to use https and data transfer is encrypted.
― Enter the server IP address and port number. Use 7001 as the port number. (If unable to connect to the server using port number 7001, check with your server administrator to find the correct port number and then change the port number.)
FTP Mode
Specify the FTP operating mode.
• Active / Passive
Default Storage
Specify the location you want to save content (downloaded from the server) to.
• Internal Memory : Save the content to the internal memory of the product.
• USB : Save the content to USB memory.
― If a Network schedule is running when USB memory is not connected, the default content will run.
209
Default content duration
Specify the duration to play content.
• Image Viewer Time , Doc viewing time , PPT Viewer Time , PDF viewing time , Flash viewing time
― The duration must be at least 5 seconds.
Content Ratio
Specify the display aspect ratio by type when playing content.
• Image ratio , Doc Ratio , PPT Ratio , PDF Ratio , Video Ratio
Original : Display content with the original size.
Full Screen : Display content in full screen.
Image Effect
Configures the image transition effects.
• Fade1 , Fade2 , Blind , Spiral , Checker , Linear , Stairs , Wipe , Random , None
Default content
Specify the content to play by default when launching MagicInfo Premium S .
• Content of up to 20MB is supported for Default content .
Content Layout
Change the screen orientation to landscape or portrait view.
• Landscape / Portrait
Schedule Name
Select a schedule title format when creating a local schedule.
• YYYYMMDD / YYYYDDMM / DDMMYYYY
Safely Remove USB Device
Safely removes USB memory
Delete all content
Delete all the content files in Internal Memory .
Reset Settings
Restore all the values under Settings to the default when the product was purchased.
210
When Content is Running
Viewing the details of the content that is running
Information
Software Version
Device Name
Device ID
Mode
Server
USB
Schedule download
: A-LUBXGDSP-0100.18
: Monitor
: FF-FF-FF-FF-FF-FF
: Local schedule
: Disconnected
: Connected
: No Schedule to download
Cancel
Press the INFO button on the remote control.
• Software Version : Displays the software version of a device
• Device Name : Displays the name of a device recognized by the server
• Device ID : Displays the original identification number of a device
• Mode : Displays the current operating mode
( Network schedule , Local schedule , Template Player , Internal Auto Play or USB Device Auto Play ) of MagicInfo
Premium S Player
• Server : Displays the connection status ( Connected , Disconnected or Not approved ) of the server
• USB : Displays the connection status of a USB device
• Schedule download : Displays the progress of a network schedule being downloaded from the server
The displayed image may differ depending on the model.
211
Changing the settings for the content that is running
Tools
Picture Mode
Sound Mode
PIP
Background Music
Background Music Setting
Safely Remove USB Device
Standard
Standard
Off
Off
Return
The displayed image may differ depending on the model.
Press the TOOLS button on the remote control.
You can change the Picture Mode or Sound Mode setting or safely remove a USB device ( Safely Remove USB Device ) while content is playing by pressing the TOOLS button on the remote control.
• Picture Mode ( Dynamic / Standard / Natural / Movie )
Customizes the screen settings for the content currently playing
• Sound Mode ( Standard / Music / Movie / Clear Voice / Amplify )
Customizes the audio settings for the content currently playing
• PIP ( Off / On )
Activate or deactivate the PIP function.
• Background Music ( Off / On )
Activate or deactivate the Background Music function.
• Background Music Setting ( Shuffle / Play / Cancel / Deselect )
Set music files saved in the Internal Memory as Background Music .
― To enable the Background Music Setting , make sure at least one MP3 file is saved in Internal Memory .
• Safely Remove USB Device
Safely removes USB memory
212
Chapter 13
MagicInfo Videowall S
To launch MagicInfo Videowall S , select MagicInfo Videowall S for the
Play Mode on the System .
A licence needs to be purchased to use MagicInfo Videowall S .
To download the software, go to the Samsung homepage at http://www.samsunglfd.com.
To purchase a licence, contact a Customer Server Centre.
File Formats Compatible with MagicInfo Videowall S Player
Read before using MagicInfo Videowall S Player
MagicInfo Videowall S can only configure and control content files via VideoWall Console.
• Refer to the VideoWall Console user manual for further details.
• To display the menu selection window, press RETURN on the remote control.
― See
page 164 for further details on supported codecs.
213
Video
• 3D video is not supported.
• Content with a resolution larger than the resolution specified in the table above is not supported.
• Video content with a Bit rate or Frame rate larger than the rate specified in the table above can cause choppy video during playback.
• Video content will not play, or not play correctly, if there is an error in the content or the container.
• Some USB/digital camera devices may not be compatible with the player.
• Supports up to H.264, Level 4.1
• H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and AVCHD are not supported.
• For all Video codecs except MVC, VP8, VP6:
Below 1280 x 720: 60 frame max
Above 1280 x 720: 30 frame max
• GMC 2 or higher is not supported.
• Supports only BD MVC Spec.
• Compatible image file format : Jpeg, bmp, png
• Supported maximum resolution : 15,360 x 8,640
A higher resolution image may take longer to display on the screen.
214
Restrictions
• Only one video ( Videos ) file can be played per client.
― Different content files can be played on the displays of a video wall.
Two video ( Videos ) files cannot be played on a single display of a video wall.
Available Available Not available
215
MagicInfo Videowall S
MENUm → Support → Contents Home → MagicInfo Videowall S →
ENTERE → RETURN
― To launch MagicInfo Videowall S , select MagicInfo Videowall S for the Play
Mode on the System .
― Press the MagicInfo Lite/S button on the remote control.
Settings
Settings
Default Storage
Default content
Content Layout
Port
Safely Remove USB Device
Reset
Internal Memory
None
Landscape
51001 Close
Return
Default Storage
Specify the location you want to save content (downloaded from the server) to.
• Internal Memory : Save the content to the internal memory of the product.
• External : Save the content to USB memory.
Default content
Configure the settings for the content that will play by default.
Content Layout
Change the screen orientation to landscape or portrait view.
• Landscape / Portrait
Port
View the port number of the server. Use 51001 as the port number.
• If unable to connect to the server using port number 51001, check with your server administrator to find the correct port number and then change the port number.
Safely Remove USB Device
Safely removes USB memory
Reset
Restore all the values under Settings to the default when the product was purchased.
The displayed image may differ depending on the model.
216
When Content is Running
Software Version
Device Name
Device ID
USB
Information
: A-LUBXGDSP-0100.18
: Monitor
: FF-FF-FF-FF-FF-FF
: Connected
Cancel
The displayed image may differ depending on the model.
Press the INFO button on the remote control.
• Software Version : Displays the software version of a device
• Device Name : Displays the name of a device recognized by the server
• Device ID : Displays the original identification number of a device
• USB : Displays the connection status of a USB device
217
Chapter 14
Troubleshooting Guide
Before calling Samsung Customer Service
Centre, test your product as follows. If the problem persists, contact Samsung
Customer Service Centre.
If the screen remains blank, check the PC system, video controller and cable.
Requirements Before Contacting Samsung Customer Service Centre
Testing the Product
Check if your product is operating normally by using the product test function.
If the screen remains blank while the power LED blinks even when the product is correctly connected to a PC, perform product testing.
1
Power off both the PC and product.
2
Disconnect all the cables from the product.
3
Power on the product.
4
If No Signal is displayed, the product is operating normally.
Checking the Resolution and Frequency
Not Optimum Mode will briefly be displayed if a mode that exceeds a supported resolution is selected
(refer to Supported Resolutions).
218
Check the followings.
Installation issue (PC mode)
The screen keeps switching on and off.
Check the cable connection between the product and PC, and ensure the connection is secure.
Blank spaces are found on all four sides of the screen when an HDMI or HDMI-DVI cable is connected to the product and
PC.
The blank spaces found on the screen have nothing to do with the product.
Blank spaces on the screen are caused by the PC or graphics card. To resolve the problem, adjust the screen size in the HDMI or DVI settings for the graphics card.
If the graphics card settings menu does not have an option to adjust the screen size, update the graphics card driver to the latest version.
(Please contact the graphics card or computer manufacturer for further details about how to adjust the screen settings.)
PC is shown in Source when a PC is not connected.
PC is always shown in Source irrespective of whether or not a PC is connected.
Screen issue
The power LED is off. The screen will not switch on.
No Signal is displayed on the screen (refer to "Connecting to a PC").
Make sure that the power cord is connected.
Check that the product is connected correctly with a cable
Check that the device connected to the product is powered on.
Not Optimum Mode is displayed.
This message is displayed when a signal from the graphics card exceeds the product's maximum resolution and frequency.
Refer to the Standard Signal Mode Table and set the maximum resolution and frequency according to the product specifications.
The images on the screen look distorted.
Check the cable connection to the product
219
Screen issue
The screen is not clear. The screen is blurry.
The screen appears unstable and shaky.
There are shadows or ghost images left on the screen.
The screen is too bright. The screen is too dark.
Screen colour is inconsistent.
White does not really look white.
There is no image on the screen and the power LED blinks every 0.5 to 1 second.
The product will turn off automatically.
Picture quality of the product is different from the dealer shop where it was purchased.
Adjust Coarse and Fine .
Remove any accessories (video extension cable, etc) and try again.
Set the resolution and frequency to the recommended level.
Check that the resolution and frequency of the PC and graphics card are set within a range compatible with the product. Then, change the screen settings if required by referring to the Additional
Information on the product menu and the Standard Signal Mode Table.
Adjust Brightness and Contrast .
Go to Picture and adjust the Colour Space settings.
Go to Picture and adjust the White Balance settings.
The product is in power-saving mode.
Press any key on the keyboard or move the mouse to return to the previous screen.
Go to System and make sure Sleep Timer is set to Off .
If a PC is connected to the product, check the power status of the PC.
Make sure the power cable is connected properly to the product and power outlet.
If the signal from a connected device is not detected, the product automatically turns off after 10 to 15 minutes.
Use an HDMI cable to obtain high-definition (HD) picture quality.
220
Screen issue
The screen display does not look normal.
The brightness and colour do not look normal.
Broken lines are displayed on the edges of the screen.
Lines (red, green or blue) are displayed on the screen.
The display looks unstable and then freezes.
The screen cannot be displayed in full screen.
Encoded video content may cause the display to appear corrupted in scenes featuring fast moving objects such as in a sports event or action video.
Low signal level or low picture quality may cause the display to appear corrupted. This does not mean the product is defective.
A cell phone within a distance of one-meter radius may cause static on analogue and digital products.
Go to Picture and adjust the screen settings such as Picture Mode , Colour , Brightness and
Sharpness .
― Refer to
Picture menu.
Go to System and adjust the Energy Saving settings.
― Refer to
for details about the System menu.
Reset the screen settings to the default settings.
― Refer to
for details about the Reset Picture menu.
If Picture Size is set to Screen Fit , change the setting to 16:9 .
These lines are displayed when there is a defect in DATA SOURCE DRIVER IC on the monitor. Contact a
Samsung Service Centre to resolve the issue.
The screen may freeze when a resolution other than the recommended resolution is used or if the signal is not stable. To resolve the issue, change the PC resolution to the recommended resolution.
A scaled SD (4:3) content file can cause black bars on both sides of an HD channel screen.
A video with an aspect ratio different from the product can cause black bars at the top and bottom of the screen.
Change the screen size setting to full screen on the product or source device.
221
Sound issue
There is no sound.
The volume is too low.
Video is available but there is no sound.
There is static coming from the speakers.
Check the connection of the audio cable or adjust the volume.
Check the volume.
Adjust the volume.
If the volume is still low after turning it up to the maximum level, adjust the volume on your PC sound card or software programmeme.
If an HDMI cable is connected, check the audio output settings on the PC.
Go to Sound and change Speaker Select to Internal .
If a source device is used
• Make sure the audio cable is properly connected to the audio input port on the product.
• Check the audio output settings for the source device.
(For example, if an HDMI cable is connected to the monitor, the audio setting for the cable box may need to be changed to HDMI.)
If a DVI-HDMI cable is used, a separate audio cable is required.
If the product has a headphone port, make sure nothing is connected to it.
Reconnect the power cable to the device and then reboot the device.
Check the cable connection. Make sure a video cable is not connected to an audio input port.
Check the signal strength after connecting a cable.
Low signal level can cause corrupted sound.
222
Sound issue
There is audible sound when the volume is muted.
When Speaker Select is set to External , the volume button and mute function are disabled.
Adjust the volume for the external speakers.
Audio settings for main speakers are separate from the internal speakers on the product.
Changing or muting the volume on the product does not affect an external amplifier(decoder).
Sound from the monitor does not change after Sound Mode is changed.
Audio settings for main speakers are separate from the internal speakers on the product.
Audio settings on a source device do not affect the internal speaker settings on the product.
There is an echo sound coming from the speakers.
Different decoding speeds between the product speakers and external speakers can cause an echo.
In this case, set Speaker Select to External .
Remote control issue
The remote control does not work.
Make sure that the batteries are correctly in place (+/-).
Check if the batteries are flat.
Check for power failure.
Make sure that the power cord is connected.
Check for any special lighting or neon signs switched on in the vicinity.
Source device issue
A beeping sound is heard when my PC is booting.
If a beeping sound is heard when your PC is booting, have your PC serviced.
223
Other issue
The product smells like plastic.
The monitor appears tilted.
Audio or video cuts out intermittently.
Small particles are found on the edges of the product.
The PIP menu is not available.
When I try to change the PC resolution, a message " defined resolution is not supported.
" appears.
The
There is no sound from the speakers in HDMI mode when a
DVI-HDMI cable is connected.
HDMI Black Level is not functioning properly on an HDMI device with YCbCr output.
The plastic smell is normal and disappears over time.
Remove and then attach the stand again to the product.
Check the cable connection and connect it again if required.
Using a very hard or thick cable may corrupt audio and video files.
Make sure cables are flexible enough to ensure durability. When mounting the product onto a wall, it is recommended to use right-angle cables.
The particles are part of the product design. The product is not defective.
The menu is enabled or disabled depending on the Source mode.
― Refer to
page 124 for details about the
PIP menu.
The message " The defined resolution is not supported.
" appears if the input source resolution exceeds the maximum resolution of the display.
To resolve the issue, change the PC resolution to a resolution supported on the display.
DVI cables do not transmit sound data.
Make sure to connect the audio cable to the correct input jack to enable audio.
This function is available only when a source device, such as a DVD player and STB, is connected to the product via an HDMI (RGB signal) cable.
224
Other issue
There is no sound in HDMI mode.
The IR sensor is not functioning.
Displayed picture colours may not look normal. Video or sound may not be available. This can occur if a source device that only supports an older version of the HDMI standard is connected to the product.
If these issues occur, connect an audio cable along with the HDMI cable.
Some PC graphics cards may not automatically recognize HDMI signals that do not include sound. In this case, manually select a sound input.
PC
DVI PC
Sound input
Auto
Audio In(Stereo ports )
Screen mode
PC settings
PC settings
Make sure the sensor light turns on when a button is pressed on the remote control.
• If the sensor light does not turn on, turn the power switch off and then on again on the back of the product.
(The power LED lights up red when the screen is switched off.)
If the sensor light still does not turn on after the power switch is turned off and then on again, an internal jack may be disconnected.
Contact your nearest service centre to have the product serviced.
• If the sensor light that is on does not flash red when a button is pressed on the remote control, the IR sensor may be defective.
Contact your nearest service centre to have the product serviced.
• If there is no change on the screen when a button is pressed on the remote control although the sensor light flashes red, the mainboard may be defective.
Contact your nearest service centre to have the product serviced.
225
Refer to the user manual for your PC or graphics card for further instructions on adjustment.
Q & A
Question
How can I change the frequency?
How can I change the resolution?
Answer
Set the frequency on your graphics card.
• Windows XP: Go to Control Panel → Appearance and Themes → Display → Settings →
Advanced → Monitor and adjust the frequency in Monitor Settings.
• Windows ME/2000: Go to Control Panel → Display → Settings → Advanced → Monitor and adjust the frequency in Monitor Settings.
• Windows Vista: Go to Control Panel → Appearance and Personalization → Personalize →
Display Settings → Advanced Settings → Monitor and adjust the frequency in Monitor
Settings.
• Windows 7: Go to Control Panel → Appearance and Personalization → Display → Adjust resolution → Advanced Settings → Monitor and adjust the frequency in Monitor Settings.
• Windows 8: Go to Settings → Control Panel → Appearance and Personalization → Display
→ Adjust resolution → Advanced Settings → Monitor and adjust the frequency in Monitor
Settings.
• Windows XP: Go to Control Panel → Appearance and Themes → Display → Settings and adjust the resolution.
• Windows ME/2000: Go to Control Panel → Display → Settings and adjust the resolution.
• Windows Vista: Go to Control Panel → Appearance and Personalization → Personalize →
Display Settings and adjust the resolution.
• Windows 7: Go to Control Panel → Appearance and Personalization → Display → Adjust
Resolution and adjust the resolution.
• Windows 8: Go to Settings → Control Panel → Appearance and Personalization → Display
→ Adjust Resolution and adjust the resolution.
226
Question
How do I set powersaving mode?
Answer
• Windows XP: Set power-saving mode in Control Panel → Appearance and Themes → Display
→ Screen Saver Settings or BIOS SETUP on the PC.
• Windows ME/2000: Set power-saving mode in Control Panel → Display → Screen Saver
Settings or BIOS SETUP on the PC.
• Windows Vista: Set power-saving mode in Control Panel → Appearance and Personalization
→ Personalize → Screen Saver Settings or BIOS SETUP on the PC.
• Windows 7: Set power-saving mode in Control Panel → Appearance and Personalization →
Personalize → Screen Saver Settings or BIOS SETUP on the PC.
• Windows 8: Set power-saving mode in Settings → Control Panel → Appearance and
Personalization → Personalize → Screen Saver Settings or BIOS SETUP on the PC.
227
Chapter 15
Specifications
1 Size
2 Display area
H
V
3 Dimensions (W x H x D)
D
General
Model Name
Panel Size
Display area
Dimensions (W x H x D)
Weight (without stand)
VESA
SMT-3231
32 CLASS (31.5 inches / 80 cm)
698.4 mm (H) x 392.85 mm (V) /
27.5 inches (H) x 15.5 inches (V)
736.0 x 436.0 x 93.5 mm / 29 x 17.2 x 3.7 inches
6.4 kg / 14.1 Ibs
200 mm × 200 mm / 7.9 inches × 7.9 inches
SMT-4031
40 CLASS (40.0 inches / 101 cm)
885.6 mm (H) x 498.15 mm (V) /
34.9 inches (H) x 19.6 inches (V)
925.4 x 542.6 x 93.5 mm /36.4 x 21.4 x 3.7 inches
9.8 kg / 21.6 Ibs
200 mm × 200 mm / 7.9 inches × 7.9 inches
H
W
228
Display Colour
Synchronization
Resolution
Maximum Pixel Clock
Power Supply
Horizontal
Frequency
Vertical
Frequency
Optimum resolution
Maximum resolution
USB
Signal connectors Input
Environmental considerations
Output
Operating
Storage
SMT-3231/4031: 1.07B(10bits Dithering)
30~81 kHz
56~75Hz
1920x1080@60Hz
1920x1080@60Hz
148.5MHz (Analog,Digital)
AC 100 to 240 VAC (+/- 10%), 60 / 50Hz ± 3Hz. Refer to the label at the back of the product as the standard voltage can vary in different countries.
1 DOWN
An America Product Only Composite/Component (common), PC D-Sub, DVI, HDMI, Audio In, RJ45, RS232C In, USB1(Media Player)
Audio Out, RS232C Out
Temperature : 32 F ~ 104 F (0 C ~ 40 C)
Humidity : 10 % ~ 80 %, non-condensing
Temperature : -4 F ~ 140 F (-20 C ~ 45 C)
Humidity : 5 % ~ 95 %, non-condensing
229
― Plug-and-Play
This monitor can be installed and used with any Plug-and-Play compatible systems. Two-way data exchange between the monitor and PC system optimizes the monitor settings.
Monitor installation takes place automatically. However, you can customize the installation settings if desired.
― Due to the nature of the manufacturing of this product, approximately 1 pixel per million (1ppm) may appear brighter or darker on the panel. This does not affect product performance.
― This device is a Class A digital apparatus.
[Recommendation] - EU Only
• Hereby, Samsung Techwin, declares that this Monitor is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
• The official Declaration of Conformity may be found at http://www.samsung.com, go to Support > Search Product
Support and enter the model name.
• This equipment may be operated in all EU countries.
(USA only)
Dispose unwanted electronics through an approved recycler.
To find the nearest recycling location, go to our website: www.samsung.com/recyclingdirect or call, (877) 278 - 0799
230
PowerSaver
The power-saving function of this product reduces power consumption by switching off the screen and changing the colour of the power LED if the product is not used for a specified period of time. The power is not turned off in power-saving mode. To switch the screen back on, press any key on the keyboard or move the mouse. Powersaving mode only functions when the product is connected to a PC with a power-saving function.
PowerSaver
Power Indicator
Normal Operation
Rating
Off
Typical Max
Power saving mode Power off
Blinking On
Power off
(Power Button off)
Off
Power Consumption SMT-3231 70 Watts 47 Watts 77 Watts 0.5 Watts 0.5 Watts 0 Watts
SMT-4031 100 Watts 58 Watts 110 Watts
― The displayed power consumption level can vary in different operating conditions or when settings are changed.
― SOG(Sync On Green) is not supported.
― To reduce the power consumption to 0, turn off the switch at the back or disconnect the power cord. Disconnect the power cable if you will not be using the product for an extended period of time (during vacation, etc.).
231
Horizontal Frequency
The time required to scan a single line from the left to the right side of the screen is called a horizontal cycle. The reciprocal number of a horizontal cycle is called horizontal frequency. Horizontal frequency is measured in kHz.
Vertical Frequency
The product displays a single image multiple times per second (like a fluorescent light) to display what the viewer sees. The rate of a single image being displayed repeatedly per second is called vertical frequency or refresh rate.
Vertical frequency is measured in Hz.
Preset Timing Modes
― This product can be set to only one resolution for each screen size to obtain the optimum picture quality due to the nature of the panel. Using a resolution other than the specified resolution may degrade the picture quality. To avoid this, it is recommended that you select the optimum resolution specified for your product.
Check the frequency when you exchange a CDT product (connected to a PC) for an LCD product. If the LCD product does not support 85Hz, change the vertical frequency to 60Hz using the CDT product before you exchange it with the LCD product.
The screen will automatically be adjusted if a signal that belongs to the following standard signal modes is transmitted from your PC. If the signal transmitted from the PC does not belong to the standard signal modes, the screen may be blank with the power LED on. In such a case, change the settings according to the following table by referring to the graphics card user manual.
Resolution
IBM, 720 x 400
Horizontal Frequency
(kHz)
31.469
Vertical Frequency
(Hz)
70.087
Pixel Clock
(MHz)
28.322
Sync Polarity
(H/V)
-/+
MAC, 640 x 480
MAC, 832 x 624
MAC, 1152 x 870
VESA, 640 x 480
VESA, 640 x 480
VESA, 640 x 480
VESA, 800 x 600
VESA, 800 x 600
VESA, 800 x 600
VESA, 800 x 600
VESA, 1024 x 768
35.000
49.726
68.681
31.469
37.861
37.500
35.156
37.879
48.077
46.875
48.363
66.667
74.551
75.062
59.940
72.809
75.000
56.250
60.317
72.188
75.000
60.004
30.240
57.284
100.000
25.175
31.500
31.500
36.000
40.000
50.000
49.500
65.000
-/-
-/-
-/-
-/-
-/-
-/-
+/+
+/+
+/+
+/+
-/-
232
Resolution
VESA, 1024 x 768
VESA, 1024 x 768
VESA, 1152 x 864
VESA, 1280 x 720
VESA, 1280 x 800
VESA, 1280 x 1024
VESA, 1280 x 1024
VESA, 1366 x 768
VESA,1440 x 900
VESA,1600 x 900
VESA,1680 x 1050
VESA,1920 x 1080
Horizontal Frequency
(kHz)
56.476
60.023
67.500
45.000
49.702
63.981
79.976
47.712
55.935
60.000
65.290
67.500
Vertical Frequency
(Hz)
70.069
75.029
75.000
60.000
59.810
60.020
75.025
59.790
59.887
60.000
59.954
60.000
Pixel Clock
(MHz)
75.000
78.750
108.000
74.250
83.500
108.000
135.000
85.500
106.500
108.000
146.250
148.500
+/+
+/+
+/+
-/+
+/+
+/+
+/+
-/+
+/+
-/+
+/+
Sync Polarity
(H/V)
-/-
233
Chapter 16
Appendix
Responsibility for the Pay Service
(Cost to Customers)
― When the service is requested, in spite of in warranty, we may charge you for a visit from a service technician in the following cases.
Not a product defect
Cleaning of the product, Adjustment, Explanation, Re-installation and etc.
• If a service technician gives instructions on how to use product or simply adjusts options without disassembling product.
• If a defect is caused by external environmental factors (Internet, Antenna, Wired Signal, etc.)
• If a product is reinstalled or devices are connected additionally after installing the purchased product for the first time.
• If a product is reinstalled to move to a different spot or to move to a different house.
• If customer requests instructions on how to use because of another company's product.
• If customer requests instructions on how to use the network or another company's programmeme.
• If customer requests software installation and setup for the product.
• If a service technician removes/cleans dusts or foreign materials inside of the product.
• If customer requests an installation additionally after purchasing a product through home-shopping or online.
A Product damage caused by customer's fault
Product damage caused by customer's mishandling or wrong repair
If a product damage is caused by;
• External impact or drop.
• Use of supplies or separatly sold product unspecified by Samsung.
• Repair from a person besides an engineer of outsourcing service company or partner of Samsung
Techwin Opto-Electronics Co., Ltd.
• Remodeling or repairing the product by customer.
• Using it with incorrect voltage or non-authorised electrical connections.
• Not following the "cautions" in User Manual.
Others
• If product fails by natural disaster. (lightning, fire, earthquake, flood damage, etc)
• If consumable components are all used up. (Battery, Toner, Fluorescent lights, Head, Vibrator, Lamp,
Filter, Ribbon, etc.)
― If customer requests a service in case the product has no defect, service fee may be charged. So please read User Manual first.
234
WEEE
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset,
USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.
Correct disposal of batteries in this product
(Applicable in countries with separate collection systems)
This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66.
If batteries are not properly disposed of, these substances can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them through your local, free battery return system.
235
Optimum Picture Quality and Afterimage Burn-in Prevention
Optimum Picture Quality
• To enjoy the optimum picture quality, go to Control Panel on your PC and adjust the resolution and refresh rate as follows. The picture quality of TFT-LCDs may degrade if the optimum resolution is not selected.
Resolution: 1920 x 1080
Vertical frequency (refresh rate): 56 ~ 75 Hz
Screen refresh rate: refers to the number of times a display image is refreshed per second.
• Due to the nature of the manufacturing of this product, approximately 1 pixel per million (1ppm) may be brighter or darker on the panel. This does not affect product performance.
The number of sub-pixels by panel type: 6,220,800
• Run Auto Adjustment to improve the picture quality. If noise is still found even after auto adjustment, adjust Coarse or Fine .
• Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or defective pixels.
Activate power-saving mode or a dynamic screen saver if you will not be using the product for an extended period of time.
• Unlike CDT monitors, TFT-LCD monitors (due to the nature of the panel) can be set to only one resolution to obtain the optimum picture quality. Therefore, setting a resolution other than the specified resolution may degrade the picture quality. To avoid this, it is recommended that you select the optimum resolution specified for your monitor.
236
Prevention of Afterimage Burn-in
Black Matrix Color-Filter
Source Drain
TFT
Data Bus-Line
Gate
Common
Electrode (ITO)
Pixel Electrode (ITO)
Storage
Capaccitor (Cs)
What is afterimage burn-in?
Afterimage burn-in should not occur when the LCD panel is operating normally. Normal operation refers to a continuously changing video pattern. If the LCD panel displays a fixed pattern for an extended period of time (more than 12 hours), a slight voltage difference may occur between the electrodes in pixels that control the liquid crystals.
Such a voltage difference between electrodes increases with time and makes the liquid crystals thinner. When this occurs, a previous image can remain on the screen when the pattern changes. To prevent this, the accumulated voltage difference should be reduced.
― Afterimage burn-in should not occur when an LCD panel is operating in proper conditions.
Preventing afterimage burn-in
― The best way to protect the product from afterimage burn-in is switching the power off or setting the PC or system to run a screen saver when not in use. Also, Warranty service may be limited depending on instruction guide.
• Powering Off, Screen Saver and Power Saving Mode
Power off the product for 4 hours after using it for 20 hours.
Power off the product for 2 hours after using it for 12 hours.
Go to Display Properties > Power Supply on your PC and set the product to power off as required.
Using a screen saver is recommended.
It is best to use a single-colour or moving-image screen saver.
• Regular colour Change
Use 2 colours
Switch between 2 colours every 30 minutes as shown above.
Type 1
FLIGHT
OZ348
TIME
20:30
UA102 21:10
Type 2
FLIGHT
OZ348
TIME
20:30
UA102 21:10
237
Brightness: refers to the lightness or darkness of a colour which varies depending on the amount of light emitted.
• Avoid combinations of a text colour and background colour of contrasting brightness.
― Avoid using grey as it may contribute to afterimage burn-in.
― Avoid using colours of contrasting brightness (black and white; grey).
FLIGHT : TIME
OZ348 : 20:30
FLIGHT
OZ348
:
:
TIME
20:30
• Regular Text colour Change
Use bright colours of similar brightness.
Interval: Change text colour and background colour every 30 minutes
FLIGHT : TIME
OZ348 : 20:30
FLIGHT
OZ348 :
: TIME
20:30
Move and change text every 30 minutes as shown below.
FLIGHT : TIME
OZ348 : 20:30
FLIGHT
OZ348 :
: TIME
20:30
[ Step 1 ] [ Step 2 ]
Regularly display a moving image along with a logo.
Interval: Display a moving image along with a logo for 60 seconds after using for 4 hours.
FLIGHT
OZ348 :
: TIME
20:30
FLIGHT
OZ348 :
: TIME
20:30
[ Step 3 ]
238
Licence
Manufactured under licence from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
Ⓡ
Manufactured under a licence from U.S. Patent No’s: 5,956,674, 5,974,380,
5,978,762, 6,487,535, 6,226,616, 7,212,872, 7,003,467, 7,272,567, 7,668,723,
7,392,195, 7,930,184, 7,333,929 and 7,548,853. DTS, the Symbol, and DTS and the Symbol together are registered trademarks & DTS Premium Sound | 5.1 is a trademark of DTS, Inc. ⓒ2012 DTS, Inc. All Rights Reserved.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
DivX Certified Ⓡ to play DivX Ⓡ video up to HD 1080p, including premium content.
DivXⓇ, DivX CertifiedⓇ and associated logos are trademarks of DivX, Inc. and are used under licence.
ABOUT DIVX VIDEO: DivXⓇ is a digital video format created by DivX, Inc. This is an official DivX
CertifiedⓇ device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX CertifiedⓇ device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the
DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.
Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274
Open Source Licence Notice
In the case of using open source software, Open Source Licences are available on the product menu.
Open Source Licence Notice is written only English.
239
Terminology
480i / 480p / 720p / 1080i /
1080p____ Each of the scanning rates above refers to the number of effective scanning lines that decides the screen resolution. The scanning rate may be indicated in i (interlaced) or p (progressive), depending on the scanning method.
- Scanning
Scanning refers to a process of sending pixels that form an image progressively.
A larger number of pixels will deliver a clearer and more vivid picture.
- Progressive
In progressive scan mode, all lines of pixels are scanned one by one
(progressively) on the screen.
- Interlaced
In interlaced scan mode, every other line of pixels is scanned from top to bottom first and then the remaining lines of pixels (that were not scanned) are scanned.
Non-interlace Mode and Interlace
Mode____ Non-interlace mode
(progressive scan) displays a horizontal line from the top to the bottom of a screen progressively. Interlace mode displays the odd number lines first and the even number lines next. Noninterlace mode is mainly used in monitors as it produces screen clarity and interlace mode is mainly used in
TVs.
Dot Pitch____ The screen consist of red, green and blue dots. A shorter distance between the dots produces a higher resolution. Dot pitch refers to the distance between the shortest distance between dots of the same colour. Dot pitch is measured in millimeters.
Vertical Frequency____ The product displays a single image many times per second (like a fluorescent light that flickers) to display an image for a viewer to see. The rate of a single image being displayed repeatedly per second is called vertical frequency or refresh rate.
Vertical frequency is measured in Hz.
E.g. 60Hz refers to a single image being displayed 60 times in one second.
Horizontal Frequency____ The time required to scan a single line from the left to the right side of the screen is called a horizontal cycle. The reciprocal number of a horizontal cycle is called horizontal frequency. Horizontal frequency is measured in kHz.
Source____ Input source refers to a video source device connected to the product such as a camcorder or video or DVD player.
Component ports (green, blue and
red)____ The component ports, which identify, transmit and receive contrast signals, provide superior picture quality to any other video connection methods.
Plug & Play____ Plug & Play is a function that allows the automatic exchange of information between a monitor and PC to produce an optimum display environment. The product uses
VESA DDC (international standard) to execute Plug & Play.
Resolution____ Resolution is the number of horizontal dots (pixels) and vertical dots (pixels) that form a screen.
It represents the level of display detail.
A higher resolution enables more data to be displayed on the screen and is useful to perform multiple tasks simultaneously.
E.g. A resolution of 1920 X 1080 consists of 1,920 horizontal pixels (horizontal resolution) and 1,080 vertical pixels
(vertical resolution).
DVD (Digital Versatile Disc)____ DVD refers to a CD-sized mass storage disk where you can save multimedia (audio, video or game) applications using
MPEG-2 video compression technology.
HDMI (High Definition Multimedia
Interface)____ It is an interface that can be connected to a digital audio source as well as a high-definition video source by using a single cable without compression.
Multiple Display Control (MDC)____
MDC (Multiple Display Control) is an application that allows multiple display devices to be controlled simultaneously using a PC. Communication between a PC and monitor takes place using
RS232C (serial data transmission) and
RJ45 (LAN) cables.
240
advertisement
Key Features
- 101.6 cm (40")
- Full HD 1920 x 1080 pixels 16:9
- 8 ms 350 cd/m² 5000:1
- 110 W
Related manuals
advertisement
