English

English

8 Channel SDI

Digital

Video Recorder

M88200H210313E

1

2

English

Before You Begin

FCC Verification

NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and the receiver

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

These devices comply with part 15 of the FCC Rules. Operation is subject to the following two conditions:

These devices may not cause harmful interference, and

These devices must accept any interference received, including interference that may cause undesired operation.

IMPORTANT NOTE:

All jurisdictions have specific laws and regulations relating to the use of cameras. Before using any camera for any purpose, it is the buyer’s responsibility to be aware of all applicable laws and regulations that prohibit or limit the use of cameras and to comply with the applicable laws and regulations.

FCC Regulation (for USA): Prohibition against eavesdropping

Except for the operations of law enforcement officers conducted under lawful authority, no person shall use, either directly or indirectly, a device operated pursuant to the provisions of this Part for the purpose of overhearing or recording the private conversations of others unless such use is authorized by all of the parties engaging in the conversation.

WARNING

Modifications not approved by the party responsible for compliance could void user’s authority to operate the equipment.

IMPORTANT SAFETY INSTRUCTIONS

• Make sure product is fixed correctly and stable if fastened in place

• Do not operate if wires and terminals are exposed

• Do not cover vents on the side or back of the DVR and allow adequate space for ventilation

DEFAULT PASSWORD INFORMATION

To ensure your privacy, this DVR supports password protection.

The default, all-access username is “admin”, the default password is “12345”.

To ensure your ongoing privacy, we strongly recommend setting a password as soon as possible. Choose something that you’ll remember, but that others would be unlikely to guess.

If you do manage to lock yourself out of the DVR, you’ll need to contact us at the Swann Technical Support Telephone Helpdesk - the number is on the back cover.

PLEASE NOTE: THIS DVR SUPPORTS SDI CCTV CAMERAS ONLY! ANALOG CCTV CAMERAS WILL NOT WORK WITH THIS DVR!

English

Introduction

Before You Begin  2

Contents  3

Contents

Camera Management: Video Loss

Connecting the DVR

The Rear Panel of the DVR

Connecting Additional Devices

The Alarm & Sensor I/O Block

Basic Setup

6

8

9

Configuration: General: DST Settings

Configuration: General: More Settings

Configuration: Network: General

Configuration: Network: PPPoE

Configuration: Network: DDNS/NTP

Configuration: Network: Email

Configuration: Network: UPnP/SNMP

Configuration: Network: More Settings

Configuration: Alarm: Status

Configuration: Alarm: Input/Output

Configuration: Live View: General

Configuration: Live View: View The Setup Wizard 11

The Quick Menu   14

The Quick Camera Menu 14

Menu Layout 16

Advanced Configuration

Maintenance: System Info

Maintenance: Log Information

Playback: 18

Export: Normal / Event 19

49

50

Net 54

HDD: Advanced / HDD Detect

Reference

55

Addendum: Third Party Hardware  57

33

38

39

40

41

35

36

37

42

43

44

45

46

Camera Management: OSD (On-Screen Display) 25

Camera Management: PTZ   26

Camera Management: PTZ: More Settings

Camera Management: Motion

27

28

Motion Detection Area Configuration

Camera Management: Privacy Mask

Camera Management: Tamper Proofing

30

31

32

Helpdesk / Technical Support Details  60

3

4

English

Introduction

Congratulations on your purchase of this Swann Digital

Video Recorder (DVR). You’ve made a fine choice for keeping a watchful eye over your home or business. Let’s take a moment to talk about some of the features this DVR offers, and how to get the most out of them.

Getting the DVR Setup

There are three stages to getting your DVR set up. If you want to use the default settings, you’ll only need to complete steps one and two.

Oh my, this is a big manual. How long will this take?

Stage 1. Connecting the DVR (page 5 to page 9)

Yes, but you won’t have to read all of it - you should be up and running by page 15!

This section details what you can connect to the different inputs/outputs of the DVR.

It can take a few hours to connect everything and run through the setup procedure.

Everyone’s setup will vary a little bit - it depends what cameras came with the DVR (if any) and what device(s) you’ve already got.

The latter part of this manual is for advanced users only - the

DVR is seriously configurable - the out-of-the-box settings do a great job in 90% of situations, but some users will want to get into the nitty-gritty detail, so that information is presented for those who need it.

Stage 2. Basic DVR Setup

The DVR needs a few things to be set properly before it can do its thing. Follow the instructions from page 10 to page 15 to get everything working.

The Basic Setup

3. Optional: Advanced DVR Configuration

The default settings will cover most basic installation requirements of the DVR.

The latter part of this manual covers advanced DVR operations.

To get the most out of your hard drive, we’ve configured the

DVR to record only when it detects motion - that way, you won’t fill the hard drive with video of nothing happening.

This DVR comes with all the professional-grade capabilities you’d expect from a quality Swann product, but many advanced capabilities require detailed setup to function correctly.

Before installing anything, connect the DVR and cameras and test your system.

If you’re not an advanced user, don’t worry. The out-of-the-box settings really do work well, and we’d only suggest changing them if you’ve got a really specific plan in mind.

We ensure everything is working properly when we ship them out, but sometimes things can be damaged in transport, and occasionally components can fail. Better to find out now, before everything is fixed in place!

•

•

You’ll need to read a page or two of this section if:

you’re connecting external sensors (page 44).

you want to alter the motion detection sensitivity or the areas it applies to (page 28).

English

Installation Guidelines

•

Do not expose the DVR to moisture. Water is the archenemy of electrical components and also poses a high risk of electric shock.

•

Avoid dusty locations. Dust has a tendency to build up inside the DVR case, leading to a high risk of failure or even fire.

•

Only install the DVR in a well ventilated space. Like all electronics, the circuitry and hard drive in the DVR produce heat, and this heat needs a way out.

• Do not open the DVR case except to install/swap the

hard drive inside. There are no user serviceable parts inside.

•

Do not cut or modify any cable for any reason. Doing so will void your warranty, as well as pose a great risk of fire or electrical shock.

•

Do not expose the DVR to sudden bumps or shocks (for example, being dropped). The DVR is as robust as possible, but many of the internal components are quite fragile.

• Remember that the DVR is, in all likelihood, going to be left on 24 hours a day, 7 days a week. Keep this in mind when choosing a location for installation.

•

Never open the case whilst the DVR is plugged in, and never turn the DVR on whilst the case is open.

Front Panel of the DVR

4 5

1 2 3 6 7 8 9

1) USB 2.0 Port: For connecting USB external storage to the

DVR for backup, or for applying new firmware.

2) Play / Pause: Opens the playback interface from the live viewing mode. Pauses playback or resumes playback when paused.

3) Display: Changes the camera display from single view to multi view. Subsequent presses will cycle through the different views available.

4) HDD LED: Will flash whenever the DVR is writing to/reading from the installed hard drive.

5) Power LED: Will be lit whenever the DVR is supplied power and turned on.

6) Menu / Esc: Opens the DVR’s menu, or goes back one step from a submenu.

7) Select: Selects an option or item from a menu.

8) D-Pad: For navigating around menus when you’re not using the mouse.

9) Infrared Sensor: Monitors signals coming from the infrared remote control. If this sensor is blocked or obstructed, then the functionality of the remote will be impaired.

5

6

English

The Rear Panel of the DVR

2 4 7 10

1 3 5 6 8 9 11

1) Video Inputs 1 - 8: These are your primary video inputs. The channels are labelled by number in the same order as they will appear on your DVR’s interface.

2) Audio Inputs: These will accept a standard line-level signal

(<1V).

3) Audio Output: A standard line-level audio output.

4) VGA Output: For connecting a television or PC monitor with a VGA input.

5) HDMI Output: The primary output of the DVR. For the highest possible video output quality, we suggest using this output.

6) USB 2.0 Port: The supplied mouse connects here. You can also connect USB external storage devices for backup or for applying new firmware.

7) Alarm & Sensor I/O Block: For connecting external alarm sensors and/or alarm output devices (such as sirens or lighting) to the DVR.

8) Network Port: Where you can connect the DVR to a network, typically directly into the router or network switch.

9) RS485 Port: Connector for RS485 devices.

10) Power Switch: Master ON/OFF switch.

11) Power Input: Where you connect the included power cable.

English

Connection Diagram

Connect your cameras to power, using a power splitter

(if included).

Connect the SDI outputs from your cameras into the BNC inputs on the rear of the DVR.

Connect the RS485 multi connection board to the

RS485 input on the DVR.

Connect the

RED

cable to + and BLACK cable to -.

Connect the power adapter(s) to a wall outlet.

RS485 connection:

The RS485 connection requires a plug to be attached to the wire terminals provided using

RED

to + and BLACK to - as marked on the plastic sheath of the connector nears the screws. Use a precision flat-head screwdriver and ensure the wires are held firmly and won’t slip out over time. Don’t use too much force when tightening the screws. Also, the PTZ address needs to be changed for the RS485 control to work - see page 26.

If you’ve got a monitor with VGA

but not HDMI, connect it to the VGA output on the DVR.

Connect an ethernet cable from the LAN port on the DVR to a spare port on your router.

If you’ve got a TV or monitor with

HDMI in, connect to the HDMI port on the DVR.

Connect the DC 12V output from the power supply to the power input.

7

8

English

Connecting Additional Devices

The Audio In ports can be used to connect audio devices to the DVR.

Obviously, your microphone probably won’t look like that one - they’re often built into cameras.

The Audio Out port can be used to connect a stereo, speakers, headphones or other external sound device.

The rear USB 2.0 Port can be used to connect the provided mouse for navigation or for backing up footage to a USB Flash

Drive or USB Hard Drive

(HDD).

The front USB 2.0 Port can be used to connect the provided mouse for navigation or for backing up footage to a USB Flash Drive or

USB Hard Drive (HDD).

English

The Alarm & Sensor I/O Block

The DVR has 4 alarm inputs and 1 alarm output, for connecting external sensors.

Alarm In 1 - 4: Connect the output from external sensors here. Only one of the two should be connected here, the other should be connected to the Ground terminal (consult the documentation for the sensor).

The Alarm In number does not directly correspond with a channel number - these can be set later (page 44).

Please note, the alarm & sensor I/O block does not provide power to alarms and sensors. Please make sure that a power supply was included with your device.

9

10

English

Basic DVR Operation

Starting the DVR for the first time:

When you first boot the DVR, it will automatically start the

Setup Wizard which will guide you through the various setup options available.

The USB Mouse (Recommended)

The easiest way to operate the DVR is to use the included USB optical mouse - we put together the look and feel of the menu system specifically for mouse-friendly navigation.

The controls are pretty easy to remember - heck, there are only two buttons. It couldn’t be simpler.

Left click:

• Selects an item or confirms a choice.

Right click:

• Opens the menu bar from the live viewing screen.

• Returns one “step” from a submenu.

• Opens a context menu in some settings screens.

The Scroll Wheel:

• Can be used to adjust the values of sliders and scales when highlighted by the mouse.

Shutting Down & Rebooting

If you want to shut down or reboot the DVR, or simply log out of the user account you’re logged in as, access the Shutdown menu, accessible via the main menu.

To ensure the integrity of your data and recordings, always select Shut Down when powering off the DVR.

Note: Wireless Mice and Bluetooth devices

Note that Wireless Mice and Bluetooth devices are NOT compatible with the DVR. Please use the USB optical mouse supplied.

English

The Setup Wizard

The wizard contains six quick setup screens which will allow you to choose how you want the DVR to behave. Please be patient as it can take up to 45

seconds for the wizard to appear after the DVR is turned on.

You’ll be asked to:

• Select a language.

• Set a password for the ADMIN account.

• Configure the time, date and time zone for your location.

• Configure the DVR so it can operate on your network and access (and be accessed from) the

Internet.

• Initialize and format your hard drive(s), if required.

Setup Wizard: Language

System Language: Choose the language you’d like

the menu system to be displayed in.

Setup Wizard: Wizard

When this check-box is left ticked, the setup wizard will run again the next time the DVR is rebooted or powered on. If you don’t want the wizard to start next time the DVR is turned on, uncheck this box.

To access the wizard once it’s been disabled, open

Main Menu -> Configuration -> General and select

Enable Wizard.

11

12

English

The Setup Wizard

Setup Wizard: Admin Password

For your on-going security and peace of mind, we strongly suggest setting a password for your Admin account. A password can be any combination of numbers (no letters) up to 16 numerals long.

Admin Password: Enter the existing Admin password

here. The default password for the Admin account is

12345. Don’t enter what you’d like the password to be

- that goes in the fields below this one.

New Admin Password (check-box): When checked,

the DVR will accept a new password for the Admin account.

New Password / Confirm: Enter what you’d like the

new password to be in the upper field, and then confirm it in the lower field.

Default Password Information

To ensure your privacy, this DVR supports password protection.

The default, all-access username is “admin”, the default password is “12345”.

To ensure your on-going privacy, we strongly recommend setting a password as soon as possible. Choose something that you’ll remember, but that others would be unlikely to guess.

If you do manage to lock yourself out of the NVR, you’ll need to contact us at the Swann Technical Support

Telephone Helpdesk - the number is on the back cover.

Wizard: Time, Date, Location, Live View

It’s important to ensure that your DVR has the correct time and date, as well as the correct time zone set.

This is particularly true in a legal context when a mistaken time or date can mean the difference between your security footage being regarded as legitimate evidence or not!

Time Zone: Select your location from the list. The East

Coast of the United States is GMT -05:00 and the West

Coast is GMT -08:00. The UK is at GMT+ 00:00 and the

East Coast of Australia is at GMT +10:00.

Remember that these values will be displaced by an hour during DST (daylight savings time) if that applies in your locale. However, don’t set that here - the DVR supports automatically adjusting the time during DST

- see page 35.

English

The Setup Wizard

Wizard: Time, Date, Location, Live View (ctd)

Date Format: How you’d like the date to be displayed. For best results, use the standard format for your

location (MM-DD-YYYY for the USA, DD-MM-YYYY for the UK and Australia).

System Date: The current date setting on the DVR. To alter this value, select the small calendar icon.

System Time: The current time setting on the DVR. To alter this value, select the small clock icon.

Note for NTP Users: Setting the date and time is less important if you’re using NTP (Network Time Proto-

col) but we still recommend you set it here, first. Just in case.

Live View Mode: 3 x 3 is the default mode for live video mode. This will display up to 8 video channels

on-screen at a single time. Selecting 1 x 1 will display the first video channel full-screen - see page 45.

Wizard: Network Settings

NIC Type: What sort of network you’re using. There

are a few to choose from. The vast majority of users will use the default option of 10M/100M/1000M

Self-adaptive. If you’re using a network other than this type, chances are you know about that.

Enable DHCP (check-box): Ensure that this is

checked unless you’re specifically running a manually addressed network (sometimes called static IP addressing) or your router doesn’t support DHCP.

IPv4 Address, Subnet Mask, Default Gateway:

When you’re using DHCP, these values will self-populate. If you’re using a manually addressed network, you’ll need to set these to match the other devices on your network.

To learn more about the Network settings of the DVR - see page 37.

Wizard: HDD Management

Here, you can view and initialize the hard drive(s) in the DVR. Typically, there will be only one entry here, the HDD which came with the DVR (if one was included). Each drive will be identified and be listed along with statistics such as Capacity, Status and Free Space.

If you’re booting the DVR for the first time, the HDD should already be initialized or if you’ve just installed a new HDD, then you’ll need to initialize the drive.

Init: Initializes the HDD so that it’s ready to accept

data.

Warning: Don’t initialize a drive that already has data

on it, as the initialization process will erase any information on the drive.

13

English

The Quick Menu

14

To access the Quick Menu, right click the USB mouse once.

Menu: Opens the Main Menu (see page 16).

Single Screen: Opens a single channel for viewing in fullscreen mode. The slide-out menu contains a list of channels to choose from.

Multi-Screen: Select a multi-screen viewing option, where you’ll be able to see multiple video feeds at once.

Previous Screen: Moves to the previous channel.

Next Screen: Moves to the next channel.

Start Auto-switch: Will periodically display a different video feed from each channel available.

Start Recording: Begins recording on all channels immediately, regardless of the current recording schedule.

Quick Set > Output Mode: Allows you to change the contrast level of the video display.

All-day Playback: Allows you to playback recordings from a single channel for the current day.

The Quick Camera Menu

To access the Quick Camera Menu, left click the USB mouse once on one of the live video inputs available.

Recording: Start or stop live recording.

Instant Playback: Playback the last 5 minutes of recorded video.

Audio On: Enable or disable live audio.

PTZ: To control a PTZ camera or a camera connected to the

RS485 input on the DVR.

Digital Zoom: Enter Digital Zoom mode. Press the left click button on the USB mouse to zoom, and press the right click button to exit. Use the PIP (Picture-in-Picture) screen on the bottom right to select a different area to zoom to.

Close: Close the menu.

Hovering the mouse cursor over each button or icon will display a description of what it does.

English

Operating the DVR Locally

If you’re reading this page, it means that either:

• You’ve got the DVR setup, but its standard recording

program isn’t for you. Fair enough - we cater to all requirements here.

Quick Reference

Some of the more common reasons to have a look in the

Advanced Configuration include:

• You’re interested in what other options and

capabilities the DVR has. Excellent - the answer is “a lot”.

• Everything works except just that one thing that isn’t

right but you don’t know where the option is. Darn.

We’ll try and get you fixed up by the end of this page.

Altering the Recording Schedule

The recording schedule is one of the most important things to get right when configuring the DVR. More information about the schedule can be found at:

• “Record: Schedule” on page 21

There are some sections of Advanced Configuration that we think are of benefit for most DVR owners to know about - in particular, the Alarm settings and the Email Configuration of the DVR.

Configuring the Auto-Email Functions

If you want the DVR to notify you via email when it detects a motion event, then you’ll need to configure:

By Default...

• “Configuration: Network: Email” on page 40

• The DVR has motion recording enabled on every channel, configured to operate at an average level of sensitivity.

• “Camera Management: Motion” on page 28

• To be a little more likely to record a border-line motion event than not (we think it’s better to get a false trigger than miss an event).

• To record video each time it detects a motion event, but not notify you via email (all events will be listed in the log).

Altering the Motion Detection Settings

If you want to change the way the DVR handles motion, then you’ll need to look at:

• “Camera Management: Motion” on page 28

• “Camera Management: Image” on page 27

To alter the DVR’s default behaviour, you’ll need to change some of the advanced settings.

You can do this on the DVR directly or by using the SwannView

Plus client software located on the included CD. There is a fairly comprehensive manual also included. You can also access the

DVR’s built-in web interface using your Internet browser.

Connecting External Sensors to the DVR

To configure external sensors, pair them to video channels and change the associated action for each, see:

• “The Alarm & Sensor I/O Block” on page 9

• “Configuration: Alarm: Input / Output” on page 44

15

English

Menu Layout

16

Playback: To access recorded images, use the Playback menu.

There are several playback modes to choose from, such as standard chronological playback mode, or event playback mode.

Export: To copy or backup footage from the DVR, use the

Export menu. You’ll need a compatible USB flash drive or USB external hard drive to store the data. Both FAT32 and NTFS file formats are supported.

Manual: Access manual controls for the recording and alarm functions of the DVR.

HDD: Where you’ll be able to access information about and adjust the settings of your hard drive(s).

Record: Access recording options, such as quality, resolution, bitrate and the recording schedule.

Camera: Adjusts and configures how the DVR looks for cameras via the video inputs. Access to Motion Detection

Configuration is located here.

Configuration: Access and configure many settings of the

DVR, including your network settings, adjusting the time and date, creating or altering user accounts and adjusting the behaviour of the alarm inputs/outputs.

Maintenance: For changing how the DVR performs its automatic maintenance and for upgrading the DVR’s firmware.

Shut Down: To safely lock, shut down or reboot the DVR.

Hovering the mouse cursor over each button or icon will display a description of what it does.

English

Playback: Normal

To initiate playback:

Analog: Select the camera that you’d like to playback. Up to eight cameras can be selected.

Start/End time of record: This will display the start time and date and the end time and date from when the DVR was first configured to record video. This will typically be the first day that you setup and configured the DVR right through to the current day. If you have recently formatted the hard drive, the start time and date will be displayed from that day.

Record Type: Select the type(s) of video you’d like to playback.

The options are Normal, Motion, Alarm, Motion | Alarm,

Motion + Alarm, Manual and All.

FileType: Select from Unlocked, Locked and All.

Start Time: Set your start date and time.

End Time: Set your end date and time.

• Select Search.

• Choose which event(s) you want to play back, and up to four cameras you’d like to view the video(s) from.

• To initiate playback, select Play.

There are two additional options that you can also select -

Detail: This will display a graphical representation of the type of video recorded. Each record type is colour coded, for example Normal is blue, Motion is green.

Playback: To playback all normal and event recordings from each camera at the same time. You can forward, rewind and pause playback. Double-clicking any of the available cameras will display it full-screen. Double-click again to exit full-screen playback.

When you click the Search button, the Search result dialogue box will appear as above. You will see a list of video files located on the hard drive, according to the search criteria that you selected. Select a file and click the Play button to play the video. If you would like to keep the video so it is not deleted by the overwrite option (see page 23), press the Lock button to lock the file. Press the Lock button again to unlock the file.

While you’re playing back footage, the DVR continues to monitor and record normally. Recording from multiple channels simultaneously is so resource intensive that playback performance may be sacrificed to ensure ongoing reliable recording.

When we say “near real-time”, this doesn’t mean things will be in slow motion. Rather, the action will unfold at normal speed, but be represented by half the number of frames per second

(12.5fps/PAL or 15fps/NTSC).

17

English

Playback: Event / Tag

The Event Search menu (above) will show you recordings that were triggered either by an alarm sensor being triggered or by the DVR detecting motion.

Typically, the majority of recordings based upon “Events” are likely to be recordings triggered by the DVR’s motion

detection feature.

The Tag search menu (below) will isolate video events based on the tag information that video carries. It’s similar to Event playback, but it can be easier to group multiple recordings of a similar type.

Playback: Smart Search

The menu controls allow you to select full screen detection or to enable smart search.

18

Right click in the play area to access the smart search function.

The Smart Search function allows you to select an area of the video that may have detected motion. The DVR will then display these areas of motion with a green highlight on the timeline (see above). This makes it very easy to navigate to the sections of video that has motion recording related to that area.

• Use the mouse to move the cursor around the screen.

• Click and drag to select the area you want to search for.

• You will see a grid of red boxes. The outlined boxes mark

the area that you want to select to search for motion.

• By left clicking an area in the grid, you can toggle motion detection ON or OFF in that location.

• Multiple areas of the video can be selected.

English

Playback: Smart Search (ctd)

1 2 3 4 5 6 7

1) Mute: Mutes audio playback.

2) Start clipping: This button allows you to set mark in and mark out points on your video which you can then export to a

USB flash drive or USB hard drive. It’s a basic way to edit a video file that you have selected to play. When you have selected to play a video file, press the Start clipping button at the mark in point and press it again at the mark out point. To save the file, press the Exit button. You will then be prompted if you would like to save the file; click Yes to save. If you have made a mistake, click the Exit button and click No. Repeat the above process. Multiple mark in and mark out points can be applied.

3) Add default tag: Tagging allows you to record information such as location or people at a certain point within the video.

The default tag name is TAG. Multiple tags can be added.

4) Add customized tag: Same as above but you can choose your own tag name.

5) Tag management: This button allows you to edit or delete tags that you have added to the video.

6) Play controls: These are your play, pause, rewind and forward controls.

7) Video Search/Hide/Exit: These buttons allow you to go back to video search, to hide the playback interface and to exit playback.

Export: Normal / Event

The Export Normal menu (above) will show you all recordings that you can export to a USB Flash Drive or USB Hard Drive.

From the Record Type menu, select the type(s) of video you’d like to playback. The options are Normal, Motion, Alarm,

Motion | Alarm, Motion + Alarm, Manual and All. Set your

Start Date/Time and your End Date/Time and click the

Search button.

The Export Event menu (below) will show you recordings that were triggered by the DVR detecting motion or by the alarm sensor being triggered.

Event Type: Click this to select either Alarm Input or Motion.

19

20

English

Manual: Record

The Manual: Record menu allows you to override any default recording schedules in place. The recording schedule for each camera connected, can be changed. Pressing the button next to Analog will stop recording on all cameras. You can also control each camera by pressing the button next to each of the camera names. You can select normal recording (Recording by manual operation) or motion detection recording (Recording by schedule).

Normal: The DVR will constantly record for any period where

Normal is selected. You won’t miss anything, but constant recording will fill your hard drive very quickly. (The DVR does record the equivalent of a DVD film every two hours on every channel, so that’s rather a lot of data!) Typically, we suggest

Motion as a better recording mode for most users.

Motion: The recommended recording setting for most applications. The DVR will only record when it detects something moving in front of a camera, and will then only record footage from the camera(s) that do detect motion unless you alter your Action settings “Camera Management:

Motion” on page 28 to include other channels.

Manual: Alarm

The Manual: Alarm menu allows you to send a trigger to the alarm output(s) to see that it is working correctly.

English

Record: Schedule

Important Guidelines

The schedule presented on-screen applies to one channel only.

Use the Copy function to quickly assign identical schedule layouts to multiple channels at once.

Be careful when programming your schedule. It’s one of the most important aspects of setting up your DVR, and if it’s wrong in any way, it could lead to disastrous complications later.

Camera: Select a camera that you would like to add a schedule to.

Enable Schedule: Select this to enable the schedule.

Copy (Channel): Located at the base of the screen, this will allow you to copy the schedule from the channel you’re editing to another channel or channels.

Note: The Action Options for Motion Detection and the

External Sensors will affect the way the schedule works.

By default, all channels are armed to use Motion

Detection as their recording mode, but not to use external sensors (not included).

Recording Modes:

There are four types of recording to choose from.

Normal: The DVR will constantly record for any period where

Normal is selected. You won’t miss anything, but constant recording will fill your hard drive very quickly. (The DVR does record the equivalent of a DVD film every two hours on every channel, so that’s rather a lot of data!) Typically, we suggest

Motion as a better recording mode for most users.

Motion: The recommended recording setting for most applications. The DVR will only record when it detects something moving in front of a camera, and will then only record footage from the camera(s) that do detect motion.

Before setting any of your schedule to Motion, ensure that

Motion Detection is properly configured for the channel(s) you want to associate with it. See “Camera Management:

Motion” on page 28 for more information about setting up and configuring Motion Detection.

Alarm: The DVR is armed to record if it detects an alarm event. This is the setting you’ll want to use if you’ve connected external sensors to the DVR’s alarm block.

Motion & Alarm (M & A): Will trigger the DVR to record when there is an alarm event and motion being detected.

Motion | Alarm (M | A): Will trigger the DVR to record on either an alarm event or motion being detected.

None: As the name suggests, the DVR will not record

anything.

21

English

Record: Encoding

Encoding Parameters: Each video feed of the DVR is comprised of two components, the Main Stream and the

SubStream.

just caching a few seconds of video which it adds to event recordings as they occur).

Both the Main Stream and the SubStream are always active - you don’t have to choose one for the DVR to use as it’s always using both. You can, however, change the quality, size and types of compression used for either.

If you’re using Motion Detection (recommended) and/or

Alarm based recording as your primary recording method(s), then it’s a really good idea to use Pre-record - sometimes, if an event is fast enough, it might have left view before the DVR can trigger a recording. With Pre-Record, there’s almost no chance you’ll miss it.

Camera: Select a camera that you would like to alter.

Main Stream: The images you’ll see in the live-view interface of the DVR. This is the higher quality of the two streams, and is what you’ll see on the DVR itself or via a local network. You can alter settings for both Normal and Event recording, and it is recommended to select the same settings for both recording types.

Stream Type: What kind of data you want the stream to contain. The cameras included with the DVR stream video only.

Post-record: How long after an event occurs that the DVR will continue to record. It can be very useful - for example, if an intruder or potential target triggers the motion detection but pauses in view; having Post-record enabled will get a much better look at them. 30 seconds is the recommended length for the Post-record setting, but it can be set higher (the options are 5 seconds, 10 seconds, 30 seconds, 60 seconds,

120 seconds, 300 seconds, 600 seconds) depending on your unique circumstances.

Resolution: Select a resolution, up to the native resolution of your camera. The higher the resolution, the more potential detail there will be in your images. The higher your resolution, the higher the bitrate will need to be to maintain a level of detail per-pixel.

Expired Time (day): Determines how long the video footage will remain on the hard drive without it being overwritten. The default value 0, instructs the DVR to auto overwrite.

Record Audio (check-box): Whether the DVR will record audio from this camera. The camera must contain a compatible audio device for this option to be selectable.

Frame Rate: The number of frames per second (fps) that the

DVR will record. The default (and maximum) is referred to as

“real-time” and is 30fps (NTSC) or 25fps (PAL).

Video Quality: The actual amount of data the DVR will use to record video.

Substream: A fraction of the Main Stream, and what you’ll see over the Internet or via a mobile device. Typically, the

Substream will be of significantly lower quality and bitrate than the main stream.

Pre-record: While Pre-record is enabled, the DVR will record between X and Y seconds before an event occurs. It’s a little like making the DVR psychic (but not really - it’s actually

22

English

Record: Advanced

Overwrite: When enabled, the DVR will record over the files already stored on the hard drive. The DVR will always record over the oldest files on your hard drive first.

Using the overwrite option is advisable, as the DVR will always be able to record events as they happen. However, it does mean that you’ll need to get important events off the HDD before they’re overwritten.

23

English

Record: Holiday

There are times when you won’t want the DVR to record using its normal programming. Perhaps you require it to record more, or less, or just at different times.

The Record: Holiday screen allows you to define periods of time where the DVR will employ an alternate recording mode

(perhaps at a different quality and on a different schedule as well).

You can define up to 32 holiday periods. These periods can be delineated by date, by weeks or by the month.

Holiday Name: Choose a title for the holiday period in question.

Enable: Whether the selected holiday period is enabled or not.

Mode: Select mode by date, week or month.

Start Date: Select a start date.

End Date: Select an end date.

24

English

Camera Management: OSD (On-screen Display)

The Camera Management: OSD screen is where you can configure the on-screen display for the display name, display date, date format, time format and font size.

Camera Name: Select a name for the camera you’ve selected.

By default, all channels are named as the Camera No. field, but this can be set to anything you’d like up to 32 characters.

Display Name: Whether the name of the camera will be part of the OSD information. This is entirely optional, and depends on your preference.

Display Date: Whether the current date will be part of the

OSD information. We strongly recommend leaving this box

checked, and ensuring that the date is correct! For best results,

use NTP (see Configuration: Network: NTP - page 39).

Display Week: Whether the current day will be part of the OSD information. We strongly recommend leaving this box checked,

and ensuring that the date is correct! For best results, use NTP (see

Configuration: Network: DDNS/NTP - page 39).

Date Format: How you’d like the date to be displayed. We strongly suggest setting this to the default standard for your locale. For example: MM-DD-YYYY for the USA or DD-MM-

YYYY for the UK or Australia.

Time Format: Choose between 12-hour and 24-hour time.

Display Mode: How you would like the OSD to be displayed.

Bear in mind that some OSD settings (such as Transparent and/ or Flashing) are harder for a video forger to impersonate or modify than other settings - on the other hand, they’re harder to read. Select the best setting for your circumstances - it’s worth having a look at a few settings to see what options are available.

OSD Font: The font size of the OSD. There are three sizes to select from.

OSD Display Position: The inset OSD position window allows you to set the exact positions of any overlaid text, such as the camera name and the date and time.

Simply select any item you want to move (such as the Channel

Name and/or the Date and Time) and click and drag it to the position you’d like it to be.

25

English

Camera Management: PTZ

This is where you can configure the DVR to be able to operate

PTZ devices. PTZ stands for Pan, Tilt and Zoom.

Camera: The camera you’d like to associate a PTZ device with.

Baud Rate: Check the documentation that came with your

PTZ device to learn this value. Most Swann PTZ units operate at 2400 or 9600bps.

Data Bit, Stop Bit & Parity: Options that subtly change the way the DVR talks to the device. This is important to get right

- check the documentation that came with your PTZ device to learn these values.

Flow Ctrl: Check the documentation that came with your PTZ device to learn this value.

PTZ Protocol: A protocol is like a language that the DVR uses to talk to the PTZ device. Ensure that this setting matches the requirement of your device.

Address: The command address of the PTZ device you want to associate with this channel. For the RS485 control to work

with the supplied video cameras, change this value to 1.

Note for Remote Access and Mobile Device users:

The PTZ functions of the DVR and compatible cameras can be controlled remotely via the SwannView Plus software, as well as by the SwannView mobile viewing app.

Please note: due to the latency (a fancy word for “delay”) caused by streaming so much data over an Internet connection, there will be a momentary pause between selecting a direction for the camera to move and it actually moving.

Typically the delay will be less than one second; however periods of up to thirty seconds are not uncommon on mobile, wireless or slow Internet connections.

26

English

Camera Management: PTZ: More Settings

PTZ Controls

Arrows: Moves the camera in the direction selected.

Zoom: Increases or decreases the magnification of a vari-focal lens. Not all PTZ devices have a vari-focal lens.

Focus: Alters the focal point of a PTZ device with a vari-focal lens. Try adjusting this control if your images appear soft or blurry. Not all cameras support this function.

Iris: Alters how much light gets into the camera by opening and closing the iris of the camera. Not all cameras support this function.

More Settings

Camera: Select the channel that the PTZ camera is connected to.

Save Preset: Defines a preset point.

Call Preset: Returns the camera to a preset point.

Pattern: Can be set by recording the movement of the camera.

Patrol: Can be used to move the camera to different key points. The duration and speed can be set for each key point.

RS485 Controls

To access the camera’s OSD, press the + Iris button. Press the up and down arrow buttons to navigate the menu and press the + Iris button to confirm your selection.

There are many options available in the OSD menus - many more than we can talk about here, and we’re constantly adding or tweaking options to ensure you have the best experience possible.

Download a guide to the advanced

OSD features of this camera from www.swann.com/osdpro if you want to know more.

27

English

Camera Management: Motion

As Motion Detection is the default recording mode for the

DVR, it’s worth taking a moment to ensure it is properly configured.

If the motion detection sensitivity is too sensitive, then the

DVR will record frequently or continually - any benefit of motion detection will be lost.

If the motion detection sensitivity is not sensitive enough, then the DVR will not record when it should and may not record anything at all.

We think that motion detection is the best way to get your

DVR to operate almost autonomously for long periods of time (typically weeks to months) without you having to worry about losing old footage.

However, it can be important that it’s configured correctly!

How Motion Detection Works

The way that the DVR looks for motion is quite straight forward

- it’s a process where it compares one frame (that is, a single image taken approximately a 25th/30th of a second from the previous image) with the next. A certain amount of “difference” between these two “frames” is interpreted as motion.

As a result, the DVR is able to detect when there is a change in the picture. However, this does not necessarily need to be something moving in the frame. For example, a light being turned on or off, a lightning flash or even the sun coming out momentarily on a cloudy day might be enough to trigger the motion detection on the DVR. However, as these events last only a moment (and are relatively rare) they will only create a few very short redundant clips, which will not take up too much space or pose a problem with scanning through footage.

Here, you’ll be able to set the motion detection features of the DVR for each channel. We suggest that motion detection is, under most circumstances, the most practical recording method for the DVR to employ.

28

English

Camera Management: Motion (ctd)

False Triggers

Which is the bigger problem - a dozen false triggers per day, or missing one critical event?

Setting the motion detection at high sensitivity levels increases the frequency of false alarms. On the other hand, low sensitivity levels increase the risk that a significant motion event (such as an intruder) will not trigger the motion detection to record.

Check the Motion Detection settings both during the day

and at night. In low-light conditions (or when your cameras are using infrared night vision) the DVR may be more or less sensitive to motion, depending on your unique circumstances.

The difference might be very dramatic!

There’s no magic setting which will make motion detection work

perfectly. There will always be some events that it’s not sensitive enough to catch, or minor happenings that will trigger an overly sensitive camera to record. Typically, the best motion detection settings are one’s that give few false triggers but don’t miss

anything.

Even motion detection which false triggers a few times per hour will still save a significant amount of hard drive space compared with a constant recording schedule for the same duration.

Weather

The weather conditions are going to affect your motion detection.

Dramatic weather phenomenon such as heavy rain, strong winds, lightning and so on, may trigger the motion detection with surprising frequency.

On the other hand, things like fog, mist and other obscuring kinds of weather might mask or obscure something moving to the point that the DVR fails to detect them.

You can also use the Privacy Mask option to minimize false triggers by obscuring different parts of your image - see page 31.

How it Works: Once motion detection has been enabled for a channel, it will register to the DVR as a Motion Event. Thus, you can use the Motion recording mode in the schedule to trigger the DVR to record when motion detection triggers an alarm signal.

• Limit the motion sensitive area to only the areas in view that a target could be. In particular, large featureless areas in the camera’s view are the ones most likely to give false triggers - turning off the motion sensitivity to any area a target cannot move in front of will help reduce false triggers - see page 30.

Note: The motion detection feature will seem more sensitive at night. We recommend that you test your motion detection sensitivity both during the day and at night to ensure your sensitivity setting is suitable for either lighting condition.

Enable Motion Detection: Whether or not motion detection is enabled on a specific channel. Each channel can be configured independently of one another.

Some tips to customizing your motion detection sensitivity and actions:

• Consider how important it is to be notified of motion events as they happen.

Handling: Here you can define what will happen when the camera you’ve selected detects motion. You can trigger additional cameras to start recording, you can adjust your arming schedule, send alerts to the SwannView Plus software or to email or trigger the alarm output.

Using the email alerts is a great way to be kept up-to-speed on what’s happening, but may quickly become annoying if something occurs which will generate a number of false triggers.

As a rule, we suggest employing the email alert only on interior cameras during times that no one should be moving about in front of them.

Say, for example, you are trying to monitor your front yard, whilst in the background there is a busy street, and the cars driving past continually set off the motion detection. What can you do about it? Setting only part of the camera’s view to be motion sensitive might be the answer. This is useful in a number of circumstances, such as monitoring one particular door at the end of a busy hallway, or a backyard with a tree that keeps blowing in the wind.

• It can be important to have a complete record of a subject’s movements and actions for legal reasons.

If your cameras capture an illegal event (typically an intruder, but we’re continually surprised by stories from our users) it is important to have as much information as possible. For example, images of someone in your home may not actually prove that they broke in - but footage of them breaking a window does. If you use a camera inside the home to trigger all exterior cameras with pre-record enabled, then you will have a record of how they entered in addition to what they did.

• Always consider what’s really important.

29

English

Motion Detection Area Configuration

To set the MOTION DETECTION AREA

In the MOTION DETECTION menu, select the AREA SETUP

(shown above) for the channel you wish to setup the MOTION

DETECTION AREA for.

• You will see a grid of red boxes. The outlined boxes mark

the area that is sensitive to motion. The area without the red outlines is not sensitive to motion.

• Use the mouse to move the cursor around the screen.

• By left clicking an area in the grid, you can toggle motion detection ON or OFF in that location.

• Click and drag to select the area you want to select or deselect.

In the sample image above, a person entering the room through the window would trigger the motion detection.

However, a person entering from the right of screen should avoid the motion sensitive area. This is a good solution to monitor the windows (left of image) without getting false triggers every time someone enters the room from the right.

Sensitivity: The Sensitivity setting is controlled by a slider, allowing you to set a value between L (low) and H (high). The closer to H the slider is set, the more sensitive the motion detection will be.

Full Screen: Will select the entire area for motion detection.

Clear: Will clear the entire area.

Get an able-bodied volunteer to move about in front of the cameras you’d like to tune the sensitivity for. The ideal sensitivity level is when your volunteer moving about always triggers the motion detection, but there are no false triggers

(or very few) when your volunteer isn’t moving about.

30

English

Camera Management: Privacy Mask

A Privacy Mask can be used if you want to obscure part of your image. You can also use this option to minimize false triggers for motion detection. You can define up to four areas per channel to mask. Click and drag to select the area you want to select or de-select.

Remember: Anything obscured by a privacy mask won’t be shown in Live View and will not be recorded.

31

English

Camera Management: Tamper Proofing

Tamper Proofing can be used in scenarios where someone may cover up the camera’s field of view or if they are attempting to tamper with the video signal.

Camera: Select the channel that you want to enable for tamper proofing.

Enable Tamper-proof: Select this to enable.

Handling: Here you can define what will happen when the camera you’ve selected detects tampering. You can adjust your arming schedule, send alerts to the SwannView Plus software or to email or trigger the alarm output.

Sensitivity: Increase or decrease the level of sensitivity.

32

English

Camera Management: Video Loss

Camera Management: Video Loss

Video Loss is regarded as a potential alarm event, and is considered to occur any time that the DVR doesn’t receive an active video signal on any of its inputs.

The default behaviour of the DVR, when a channel has no incoming video signal, is simply to display “No Video” in white text on a black background over the associated channel.

If you’re not using all the inputs on your DVR, then some channels will be in “permanent” video loss state. Just be sure that you don’t enable a video loss action for these channels.

Camera: Which channel/camera you’d like to set the video loss behaviour for.

Enable Video Loss Alarm: Whether the selected channel has video loss monitoring active or not.

Camera Management: Video Loss - Handling

Full Screen Monitoring: When the video signal has reestablished connection, the camera will display a full screen image momentarily.

Audible Warning: The DVR will use its internal buzzer to emit an alarm tone. It sounds like an old computer indicating an error, or a large truck backing up.

Alert CMS Software: A warning message is sent to the

SwannView Plus client software installed on the computer.

Send Email: The DVR will send an auto-email alert when the event type you’ve selected occurs. To configure your email settings - see “Configuration: Network: Email” on page 40 for details.

Trigger Alarm Output: Instructs the DVR to output an alarm signal from the alarm output terminal(s). The alarm output(s) must be correctly connected and configured.

33

English

Configuration: General

Language: The language that the DVR’s menus, alerts and other communications will use. English is the only language available.

Resolution: The number of “little dots” that make up an image. This should be set as high as possible, but equal to or lower than the maximum resolution your screen/monitor can display. Things change a little depending on what kind of monitor you’re using, and how it’s connected.

The DVR has five formats available, in two different aspect ratios:

Square (4:3) - 1024 x 768, 1280 x 1024 or 1600 x 1200

Widescreen (16:9) - 1280 x 720 (720p) or 1920 x 1080 (1080p)

Square Monitor via VGA: Use one of the 4:3 formats to correctly align the DVR’s output on your screen. Using a widescreen format will “stretch” the image vertically.

Widescreen Monitor via VGA: If possible, use the widescreen (16:9) format. If your monitor can’t display that resolution, you might need to enable letter-boxing on your monitor and use a 4:3 format.

PC Monitor via HMDI: Choose a format appropriate for your monitor. If it’s a widescreen, use a widescreen format. Set to the highest option that is equal to or less than the screen’s maximum resolution.

Widescreen Plasma/LCD HDTV via HDMI: The resolution should be set to the maximum your television can process not display. Typically, this will be 1080p, as even screens which don’t have that many pixels can still display the image, just with less detail. Check your television’s documentation to learn this value. If your television can’t display 1080p, then use 720p instead.

Time Zone: Particularly important if you’ve enabled NTP - set this to the time zone where you happen to be. For example, people in eastern Australia (Canberra, Sydney and Melbourne) choose GMT+10:00, whilst the Eastern Time zone in the USA and Canada is GMT-05:00. (GMT stands for Greenwich Mean

Time - it’s the baseline that keeps all the different time zones in sync.)

Date Format: The format of the date (DD/MM/YYYY or MM

DD/YYYY and so on).

System Date: This can be edited manually, or set to update automatically by using NTP (see “Configuration: Network:

DDNS/NTP” on page 39).

System Time: This can be edited manually, or set to update automatically by using NTP (see “Configuration: Network:

DDNS/NTP” on page 39).

Mouse Pointer Speed: Move the slider to increase or decrease the mouse pointer speed.

Enable Wizard: When checked, the DVR will automatically run the setup wizard when the DVR is switched on. The wizard itself contains the option to disable it.

Enable ID Authentication: When enabled, the DVR will require a username and password to access, even for local users.

34

English

Configuration: General: DST Settings

Enable DST (check-box): Enable this setting if you’d like the

DVR to adjust the time when daylight savings time begins.

From / To: Here you can define when daylight savings applies to your location. There are many different standards for DST which can vary dramatically even in the same time zone, so you’ll need to tell the DVR when it applies to you.

DST Bias: This refers to the difference in minutes, between

Coordinated Universal Time (UTC) and the local time. Select the time that DST has increased by in your time zone.

NOTE: Some NTP servers are NOT fully compatible with DST

(Daylight Savings Time). This may cause your system to doublecount adding one or removing one more hour than they should, or cancel each other out. You may need to intentionally change your time zone to compensate, or simply not use NTP and DST simultaneously.

35

36

English

Configuration: General: More Settings

Device Name: The name that the DVR considers to be its own and what it will use to register an IP address with your DHCP host.

Device No.: The internal device number of the DVR.

Operation Timeout: Here you can change the time the DVR will exit the menu screen and return to the camera viewing screen if there is no activity.

English

Configuration: Network: General

NIC Type: The DVR has the ability to connect to your LAN

(Local Area Network) at various speeds and can adjust itself accordingly depending on the network traffic. It is recommended to leave the current default setting for the best streaming performance.

Enable DHCP: DHCP (Dynamic Host Configuration Protocol) is a system where one device on your network (usually a router) will automatically assign IP addresses to devices connected to the network. This option is enabled by default and is the recommended way for the DVR to receive an IP address from your router.

If you require the DVR to have a static IP address, you will need to disable this option.

STATIC: Static networks require all devices to have their IP addresses manually defined, as there is no device dedicated to automatically assigning addresses.

IPv4 Address: Just as houses and businesses need to have an address which identifies their location on the road network, so too do computers and other devices need addresses (called

IP ADDRESSES) to identify their position on the electronic network. The DVR uses IPv4 addressing, which consists of four groups of numbers between 0 and 255, separated by periods.

For example, a typical IP address might be “192.168.1.24” or something similar. The most important thing when setting the

IP address is that nothing else on your network shares that IP address.

IPv4 Subnet Mask: If the IP address is like a street address, then a subnetwork is like your neighbourhood. This will be formatted in a similar way to the IP address (i.e. four numbers up to 255 separated by periods) but contain very different numbers. In the above example, the Subnet Mask might be something like: “255.255.255.0”.

IPv4 Default Gateway: This is the address of the “way to the

Internet” - to continue the road analogy, this is like your local access point to the highway. This is an IP address in the same format as the others, and is typically very similar to the IP address of the DVR. To continue the above examples, it might be something such as: “192.168.1.254”.

IPv6 Address 1/2/Default Gateway: IPv6 is the latest revision of the Internet Protocol (IP). It will eventually replace the older

IPv4 system for assigning IP addresses to devices on your network. The majority of internet server providers (ISPs) are still using the IPv4 system but will eventually transition to IPv6.

As the DVR supports IPv6, you will be able to take advantage of the new system when it arrives.

Mac Address: The Media Access Control address. This is a unique code which nothing else should share. You can’t change this one - it’s hard set when the DVR ships out.

MTU (Bytes): The MTU (Maximum Transmission Unit) is the size of the largest datagram that can be sent over a network. It is recommended to leave the default setting.

Preferred DNS Server: “Domain Name System”. Everything on the Internet is located via an IP address - however, for ease of use, we associate domain names (such as “ www.

exampledomainname.com

”) with those IP addresses. This index is accessible in many locations online, and we call those locations “DNS servers”.

Alternate DNS Server: A backup DNS server. This is here as a redundancy - your DVR will probably work without one.

37

38

English

Configuration: Network: PPPoE

PPPoE is an advanced protocol that allows the DVR to be more directly connected via a DSL modem. This is an option for advanced users only.

Username: Enter the username for your DSL account provider.

Password: Enter the password for your DSL account provider.

English

Configuration: Network: DDNS / NTP

Your USERNAME

Your PASSWORD

Confirm PASSWORD

Static and Dynamic IP Addresses

In much the same way as your home network can use static or dynamic IP addresses, many Internet providers don’t issue

(or charge more for) a static IP address for users. The easiest way to find out is to contact your Internet service provider.

Alternately, you can access the www.whatismyip.com

service, make a note of your IP, then reboot your router/gateway. This should refresh your Internet connection. If your IP address changes, you have a dynamic IP address. If it stays the same, you may have a static IP - contact your ISP to confirm.

How do I deal with a dynamic IP address?

One option is to contact your ISP and request a static IP address. They’ll usually charge a small fee for doing this. It’s worth noting that not all ISPs offer static IP addresses.

If your ISP does not offer static IP addresses then you can use a dynamic referencing service. We provide one free of charge.

We recommend using SwannDNS as your DNS service.

This is a free service for Swann DVR/DVR owners, which we directly support.

To create an account with SwannDNS, go to: http://www.swanndvr.com/ and click the Registration button.

Follow the prompts to create your account.

DDNS Type: SwannDNS is automatically selected as the DNS service ( www.swanndvr.net

).

Device Domain Name: Enter the host name that you set up in your DDNS service. This is the address you use to access your network. For example: yourhostname.swanndvr.net

Username / Password / Confirm: Enter the username and password you setup with your DDNS server. These do not have to match your username/password combination in either your

DVR or router (for the sake of security, we suggest making them different). Confirm your password in the field provided.

For SwannDVR users: Your username is the email address you used to register the account. The password is whatever you selected when you registered.

NTP: Network Time Protocol. If you’ve got the DVR connected to the Internet, you can have it automatically sync time with an online server.

Important:

If you’re using NTP, then it is essential that your Time Zone

(see page 34) and DST (daylight savings time - see page 35) be set correctly.

Interval (min): The amount of time in minutes that will elapse between the DVR updating its internal clock to match that of the NTP server. The default period of 60 minutes is recommended.

NTP Server: The server you’d like to use for NTP. There are many available online - the default (pool.ntp.org) works just fine.

NTP Port: The port used by the NTP server of your choice. The default for pool.ntp.org is 123.

39

40

English

Configuration: Network: Email

smtp.gmail.com

465

Name for sender account outgoing@email address

Name for receiver account receiver@email address

We suggest using Gmail as your email client - it’s quite easy to set up an account and use it solely for the DVR. We’ve tested the email procedure with Gmail, and it does work.

Other email servers may not work correctly - many interpret the procedurally generated email from the DVR as spam and block the mail from being sent.

For the Auto-Mail function to work correctly, the DVR will need to be correctly configured with the details of the email servers and addresses you want to use.

Enable Server Authentication: If your outgoing mail server requires authentication, ensure this box is checked.

Sender Username / Sender Password: The username and password for the outgoing email account.

SMTP Server: The name of the SMTP server of the email provider that you have selected. Here are the SMTP server names for Gmail (Google), Yahoo Mail and Windows Live Mail

(Hotmail):

If you want to use your ISP’s outgoing email, then you’ll need to contact your ISP to learn the correct values for the other fields

(such as the correct SMTP server, SMTP port, SSL requirements and so on).

Sender’s Address: The address you’re sending the email

from. This will be the username you’ve set up for the email server you’re using, followed by “@” and then the email server.

For example: “[email protected]” or similar.

Select Receivers: You can select up to three different receivers to send an email to.

Receiver’s Address: The email address you want the DVR to send emails to. This can be any email address you like, however, bear in mind that the DVR might send a large number of automatic emails under certain conditions.

Enable Attached Picture: When this is selected, the DVR will attach three small images to each email alert (where applicable).

Gmail (Google):

Yahoo Mail:

Windows Live Mail (Hotmail): smtp.live.com

You’ll need to setup an account with one of these email providers. All offer free email accounts. To signup, visit the email provider’s website:

Gmail (Google):

Yahoo Mail: smtp.gmail.com

smtp.mail.yahoo.com

www.gmail.com

www.mail.yahoo.com

For motion-based email alerts, this will be an image of whatever triggered the motion detection.

Interval: The length of time that must elapse after the DVR sends an email alert before it will send another.

Short Interval settings are likely to lead to huge numbers of alerts being sent by the DVR - perhaps even several emails for one event (if that one event lasts longer than the interval setting). On the other hand, a long interval setting might mean you’ll miss a specific update that you needed. There’s no right answer, and you’ll probably have to fine-tune this setting to get the results you’re after - it’ll be different for everyone’s unique circumstances.

Windows Live Mail (Hotmail): www.hotmail.com

SMTP Port: The SMTP port used by the email provider of your choice. The SMTP port for Gmail users is 465.

Enable SSL: Whether the email server you’re using requires a secure link. This should be left on if you’re using any of the preset email servers.

English

Configuration: Network: UPnP / SNMP

UPnP (Above)

Enable UPnP: UPnP makes configuring your network easier and faster. To use the UPnP setting on the DVR, you’ll need a router which supports this feature, with UPnP enabled. Note that many routers which do support UPnP do not come with the feature enabled by default. You may need to ask your

Internet service provider to turn it on.

When UPnP is enabled on your DVR and your router, the Ports that the DVR requires to be open for access to and from the

Internet will automatically be opened and closed as necessary by your router, saving you the trouble of manually forwarding these ports. If UPnP is not enabled, or your router does not support this feature, you’ll need to forward the ports the DVR uses from the router to the DVR - since this is a technically challenging process; we strongly recommend using UPnP if possible. Make sure that the number used for the External

Port and Internal Port match, otherwise the UPnP function will not work.

Edit: Allows you to change the current External Port number.

Mapping IP Address: Will display the public IP address of the router that the DVR is connected to.

Status: If UPnP is working correctly, you will see Active displayed. If UPnP is not enabled or you haven’t forwarded the correct port number, the status will be Inactive.

SNMP (Below)

SNMP: Simple Network Management Protocol. If your network is setup to use SNMP (if you’re not sure, your network administrator(s) should be able to tell you if this protocol is in use) then you can configure it here.

Enable SNMP: Whether SNMP is in use. If it’s not in use, then ensure this stays disabled. The SNMP protocol can interfere with normal networking functionality.

SNMP Version: The version of SNMP currently being used.

SNMP Port: The SNMP port currently being used. This is typically port 161, however exceptions exist.

Read Community: Who has read-only access to information on the network (can view, but not change).

Write Community: Who has control over information on the network (can view, modify, change, create or delete information).

Trap Address: The address of the network trap (the asynchronous notification from agent to manager).

Trap Port: The port being used for the trap.

41

42

English

Configuration: Network: More Settings

Alarm Host IP: The location on your network where an IPbased alarm system is hosted.

Alarm Host Port: The port associated with the IP-based alarm system.

Server Port: This is the internal port that the DVR will use to send information through. The most important things are:

• You’ll need to enable UPnP on your router so your router can selectively open these ports, allowing the DVR to communicate via the Internet. If your router doesn’t support UPnP, you have two options. You can either get a new router (which we’d actually recommend - UPnP is such a good feature!) or you can manually forward ports from the router to the DVR. Port forwarding is a technical and involved process, recommended only for the technically inclined.

•

Nothing else uses this port. The default port number is

8000, which is not used by many other devices/programs.

However, particularly if you have another DVR or DVR-like device, something might be using this port already. If this

is the case, change this value to be unique.

• You’ll need to know this port value when logging within your network or remotely - so, if you change it, remember what it is!

• Make sure that the number used for the External Port and Internal Port match, otherwise the UPnP function will not work.

• You’ll need to know this port value when logging within your network or remotely - so, if you change it, remember what it is!

Multicast IP: Multicast IP is a technique for one-to-many and many-to-many real-time communication over an IP infrastructure in a network. The receiver will receive data from that IP without the need to contact individual devices directly.

In most circumstances this option is not required.

RTSP (Real-Time Streaming Protocol) Port: This port is used to stream real-time images through, and is the port that will be used to communicate with mobile devices.

What port number(s) should I use?

If the default port numbers are in use (85 and/or 8000) then the simplest solution is just to keep “adding one” until you find a port which is not in use. So, if 85 is already taken, try 86 or 87.

There’s no “right” port number(s) to use - any port number will work provided the DVR is the only device using it. For this reason,

avoid using port numbers 80, 81, 82, 88, 90, and 99 as these are often used by other devices/programs/protocols.

HTTP Port: This is the port through which you will be able to log in to the DVR.

• Like the RTSP port, it will need to be forwarded properly in order to ensure smooth, latency-free communication.

The default value is “85”, as this port is seldom used by other devices or applications. If there is another device on your network using this port, you’ll need to change it to be unique.

English

Configuration: Alarm: Status

Alarm: Input List

The Alarm: Sensor menu will allow you to customize and configure how you’d like the DVR to interpret input from and respond to the sensor input panel on the rear of the DVR.

Alarm Input No.: The connection that corresponds to the input you’ve connected the sensor to. Note that the Alarm

Input Number and the Channel Number don’t have to be the same.

The <- characters indicate that these are alarm inputs.

Alarm Name: The name you want to associate with the alarm. We suggest something descriptive and useful, such as

“Lounge Room PIR Sensor” or “Front Door Sensor”. The DVR will use this name in email alerts and in the event log to let you know where alarms are being generated.

Type: Whether the sensor is a NO (normally open) or

NC (normally closed). You’ll need to check your sensor’s documentation to learn the correct value to use. It refers to the way the sensor tells the DVR when it has detected something. If this is set to the wrong value, you’ll get constant

“false” alarms, which will stop only when the sensor detects something.

Alarm: Output List

Here you can control the operation of the DVR’s Alarm Out port(s).

Note that the alarm output(s) on the DVR is Normally Open

(NO). If you’ve got an external device, it must be configured to use a NO triggering method; otherwise they’ll be in a permanently alarmed state.

Please note: depending on the configuration and intended purpose of your external alarm device, it may or may not continue to be in an alarmed state once the DVR’s signal has ceased.

If you enabled an action for a sensor input and set the sensor type to NO and don’t have a sensor connected to the DVR, then this will constantly trigger alarm events.

43

English

Configuration: Alarm: Input / Output

Alarm: Input (above)

The Alarm: Sensor menu will allow you to customize and configure how you’d like the DVR to interpret input from and respond to the sensor input panel on the rear of the DVR.

Alarm Input No.: The connection that corresponds to the input you’ve connected the sensor to. Note that the Alarm

Input Number and the Channel Number don’t have to be the same.

The <- characters indicate that these are alarm inputs.

Alarm Name: The name you want to associate with the alarm. We suggest something descriptive and useful, such as

“Lounge Room PIR Sensor” or “Front Door Sensor”. The DVR will use this name in email alerts and in the event log to let you know where alarms are being generated.

Type: Whether the sensor is a NO (normally open) or

NC (normally closed). You’ll need to check your sensor’s documentation to learn the correct value to use. It refers to the way the sensor tells the DVR when it has detected something. If this is set to the wrong value, you’ll get constant

“false” alarms, which will stop only when the sensor detects something.

Handling: Here you can define what will happen when the alarm input has been alerted.

Alarm: Output (Below)

Here you can control the operation of the DVR’s Alarm Out port.

Note that the alarm output(s) on the DVR is Normally Open

(NO). If you’ve got an external device, it must be configured to use a NO triggering method; otherwise they’ll be in a permanently alarmed state.

Dwell Time: The amount of time you’d like the DVR to maintain the Alarm Output status.

Handling: Here you can define what will happen when the alarm output(s) has been alerted.

Please note: depending on the configuration and intended purpose of your external alarm device, it may or may not continue to be in an alarmed state once the DVR’s signal has ceased.

44

English

Configuration: Live View: General

Video Output Interface: The default output is VGA/HDMI.

Live Video Mode: 3 x 3 is the default mode for live video mode. This will display up to 8 video channels on-screen at a single time. Selecting 1 x 1 will display the first video channel full-screen. Other views available are 2 x 2, 1 + 5 and 1 + 7.

Dwell Time: The time in seconds to dwell on a video channel when enabling Start Auto-switch in Live View. This only works when the Live Video Mode is set 1 x 1.

Enable Audio Output: This will enable the audio output on the DVR.

Event Output: The default output is VGA/HDMI.

Full Screen Monitoring Dwell Time: The time in seconds to show an alarm event screen.

45

English

Configuration: Live View: View

In Live View, you can change the display order of each camera connected -

1. Select an available viewing window on the right-hand side.

2. Double click one of the available cameras on the left-hand side that you would like to place in the viewing window that you have selected.

Play: Pressing the Play button will start the live view of all cameras connected to the DVR.

Stop: Pressing the Stop button will stop the live view of all cameras connected to the DVR.

Please note: Pressing the stop button means that you will not see a real-time view of all the cameras connected to the

DVR at the main viewing screen. Press the play button to enable real-time view.

46

English

Configuration: Exceptions

An Exception is any deviation from the DVR’s normal behaviour - phrased another way, it’s like saying the DVR’s been working fine except for these events

Illegal Login: This will occur if the DVR detects a login with an incorrect username or password.

Exception Type: What event type you’d like the DVR to react to. By configuring the Action for these events, you can create any combination of audio alerts (see below) or auto-emails to be sent for different event types.

Input/recording resolution mismatch: If the camera connected is not capable of matching the resolution selected in the Record: Encoding menu.

HDD Full: As the name suggests, this event occurs when the

DVR runs out of space on the hard drive to save new footage.

This event is redundant if you’ve got overwrite enabled, as the DVR will automatically delete old footage to ensure it can continue to record.

HDD Error: Occurs when the DVR has trouble accessing its hard drives, or when it cannot detect one at all.

Network Disconnected: Will occur if the DVR has problems connecting to the Internet. This may indicate a problem with the DVR’s configuration, a fault with your network or a problem with your Internet Service Provider (ISP).

Record Exception: This will occur if there are unexpected errors during capture such as a HDD failure, if the HDD is full or if the HDD quota has been changed.

Audio Warning: The DVR will use its internal buzzer to emit an alarm tone. It sounds like an old computer indicating an error, or a large truck backing up.

Send Email: The DVR will send an auto-email alert when the event type you’ve selected occurs.

Trigger Alarm Output: Instructs the DVR to output an alarm signal from the alarm output terminal(s). The alarm output(s) must be correctly connected and configured.

IP Conflicted: This event will occur if the DVR detects another device on the same network with a conflicting IP address. It’s a little like two houses with the same number being on the same street - one house might get the other’s mail, or get woken up at all hours of the night being asked if someone named “Big

Bob” lives there.

Basically, it indicates that two devices are trying to use the same IP address. This shouldn’t occur if you’re using DHCP addressing, unless one or more devices is set to use a STATIC

IP (the static addressing method overrides the automatic assignment process).

47

English

Configuration: User

The Configuration: User menu is where you can define and configure the different levels of access various users have to the DVR.

We suggest that at minimum the admin account be password protected, as it has access to all aspects of the DVR’s operation.

To add additional users, choose Add.

To customize a user’s level of access, choose Edit.

To remove a user, choose Delete.

User’s MAC Address: To restrict remote user access, you can input the MAC address of the remote computer that will be used to access DVR. The DVR will only allow remote access from a computer with this MAC address to gain access.

You cannot modify the access level of the default admin

account - they can do everything.

This is to prevent an unfortunate incident where, for example, no user has the permissions required to change another user’s permissions - which could lead to the DVR being, in at least some senses, inoperable.

48

English

Maintenance: System Info

If you’re looking at the System Information screen, you’ve probably been directed to do so by Swann Technical Support.

If we haven’t told you to come here, you might be wondering what all the information means. On a day-to-day level, the answer is “very little”. However, if you’re still curious:

Device Info: Displays the Device Name, Model, Serial Number,

Firmware and Encoding Version of the DVR.

Camera: Displays the cameras connected to the DVR.

Record: Displays the current recording settings.

Alarm: Displays the current alarm status.

Network: Displays the current network settings.

HDD: Displays the current status of the hard drive installed.

Please note, 0MB free is normal when the overwrite option is enabled.

49

English

Maintenance: Log Information

The Maintenance: Log Information menu contains information for operation, alarm, exceptions and information of the DVR.

6. If you want to export the log file, click the Export button to enter the Export menu. Click the Search button first otherwise the Export button will not be active.

1. Set the log search conditions to refine your search including the Start Time, End Time, Major Type and Minor Type.

2. Click the Search button to start searching the log files.

3. The matched log files will be displayed. Up to 2000 log files can be displayed each time.

4. Double click each file to view detailed information contained in the log.

7. Select the backup device from the Device Name dropdown list. Click New Folder to create a new folder or Format to format the backup device. Click Export to export the log files to the backup device.

To export all the log files, click the Log Export option, select the hard drive that you want to export, select the backup device from the Device Name dropdown list, then click the

Export button.

5. Click the Play button to view the video that is related to that log file.

50

English

Maintenance: Import / Export

The Maintenance: Import / Export menu allows you to import or export your current configuration settings. This will come in handy as it will save you time if you have to reset the

DVR back to factory default settings.

To export your current configuration file, select the backup device from the Device Name dropdown list. Click New

Folder to create a new folder or Format to format the backup device. Click Export to export the configuration file to the backup device.

To import a previously saved configuration file, select the backup device from the Device Name dropdown list. Select the configuration file - it will be called devCfg_(serial

number)_(year/month/time).bin, then click the Import button. After the configuration file has been imported, the

DVR will reboot automatically.

51

52

English

Maintenance: Upgrade

The Maintenance: Upgrade menu allows you to upgrade the firmware of the DVR. You’ll only need to use these options if instructed to do so by Swann Technical Support.

Local Upgrade: The firmware will be updated locally using a

USB Flash Drive or USB Hard Drive. Click the Upgrade button to commence the update.

FTP: The firmware will be updated using your computer as a

FTP server. Make sure that both your computer and DVR are connected to the same Local Area Network (LAN). You will need to download and install 3rd party TFTP software onto your computer. Place the firmware file into the root directory of the

TFTP software and input the IP address of your computer into the DVR. Click the Upgrade button to commence the update.

English

Maintenance: Default

The Maintenance: Default menu allows you to reset the DVR and load factory default settings. The DVR will reboot after pressing the OK button. Please note, all data on the HDD will remain.

53

54

English

Maintenance: Net Detect

The Maintenance: Net Detect menu allows you to check network traffic and to obtain real-time information from the

DVR such as network detection, network status and sending and receiving network traffic.

English

HDD: General

The HDD: General menu allows you to initialize the hard drive(s) in the DVR. Don’t initialize a drive that already has data on it, as the initialization process will erase any information on the drive. You also have the option of adding a Networkattached storage device (NAS) that you can record to.

Add: Create a folder on your NAS device, then input the IP address of your NAS device and the folder name that you created earlier.

Init: Initializes the HDD so that it’s ready to accept data.

To find out which NAS devices are compatible with our DVR, please visit our website www.swann.com

or contact

Swann

Technical Support Telephone Helpdesk.

HDD: Advanced / HDD Detect

The HDD: Advanced menu allows you to configure a quota on the HDD for each camera that is connected to the DVR.

Each camera can be allocated a certain amount of space that is available on the HDD. If you have multiple HDDs installed, you can also instruct the DVR on which HDD each camera can record to.

The HDD: Detect menu will display technical specifications of the hard drive(s) installed. If you’re looking at this screen, you’ve probably been directed to do so by Swann Technical

Support.

55

56

English

Troubleshooting

Q: I can’t login to or unlock the DVR - it says my password is wrong.

A: The default username/password combination for the DVR is “admin” with the password “12345”. If that doesn’t work (and you haven’t set a password of your own that you’ve forgotten) then something strange has happened - contact Swann technical support (contact details are on the rear cover).

Q: The DVR will boot up and show live images, but there are no menus being displayed. Why?

A: There might be a fault with one (or more) of the hard drives installed in the DVR. Before the menu system is displayed, the

DVR attempts to detect what drives are connected. If there is an ambiguous signal preventing the DVR from ascertaining whether there is a drive connected or not, then it will keep looking and waiting for the drive to respond.

If you’ve just installed a new drive, disconnect it and see if that fixes the problem. You can also try disconnecting one drive at a time to see if that one is the culprit.

Q: How do I eliminate false-triggers on my motion detection?

A: There’s no guaranteed way to eliminate false triggers, but - in the majority of cases - you can fine-tune the DVR’s motion detection settings to reduce the number of false triggers you’re likely to get. (See “Camera Management: Motion” on page 28 for more detailed information about setting motion detection.)

1. Mask any redundant movement. This includes obvious things like trees blowing in the wind, roads with cars passing and so forth. Some less obvious things which might cause false triggers include: the “flickering” of screens, monitors or fluorescent lights, reflections of movement in windows/ mirrors and so on, lights which are often turned on or off, shadows passing and so on. We can’t possibly imagine what you’re going to find in your unique circumstances, so we encourage you to experiment.

2. Fine-tune your sensitivity. There’s no substitute for getting a volunteer to play the part of intruder and experimenting.

Some cameras are just more “touchy” than others; some lighting conditions are harder to get the settings “right” for.

Q: I’m getting too many email alerts from the DVR.

A: There are a few things that might help, depending what’s generating the email alerts. Here are a few possibilities:

• The emails are for real events, however it is telling me about it multiple times.

This indicates that the DVR is functioning properly, but that the Interval setting for your email alerts is too low. Increasing the Interval time will decrease the number of email alerts the

DVR sends.

• The DVR sends email alerts when nothing seems to be happening.

This suggests that there might be something amiss with your

Motion Detection settings, or with the configuration of your sensors (if used).

The most likely explanation is that there is something in view of your cameras which is moving, or causes the illusion of movement. Have a look at “Camera Management: Motion” on page 28 for some more information.

• The DVR keeps reporting errors (such as Video Loss,

HDD Error or similar).

There seems to be a hardware or configuration fault with the

DVR. These are most often caused by a faulty (or simply poorly connected) connection or cable. Check the integrity of your cables and connections.

English

Addendum: Third Party Hardware

Due to its nature as a networked device, the DVR is often required to operate with third party hardware. We do everything we can to ensure the DVR is compatible with as many third party devices as possible; there will always be some that require a little extra configuration.

•

•

Routers

I’m using a router which doesn’t support DHCP addressing.

or

Some devices on my network require STATIC addressing.

You’ll need to set the address of the DVR manually. You’ll need to:

• Find Your Network’s IP Address Range

Create a Unique IP Address

Assign the IP address information to the DVR.

Assigning the IP Address information to the DVR.

We recommend doing this locally (on the DVR itself) even if you can access the DVR via the network (using the SwannView Plus software) in the meantime.

If you’re connected remotely and the networking information changes, you might lose the connection to the DVR.

• Open the Network: General menu on your DVR (see

“Network: General” on page 37).

• Select Static addressing.

•

IP Address: Enter the unique IP that you created for the

DVR here.

•

Subnet Mask: Enter the same value as the computer’s

Subnet Mask.

•

DNS Server: Enter the same value as the computer’s DNS.

The DVR should now be accessible via your local network.

Before you can access the DVR remotely, you’ll need to

Forward Ports (STATIC addressing does not support UPnP, see below).

Finding your Network’s IP Address Range

First, you’ll need to know the IP address, Subnet Mask and

DNS Server of at least one other device on your network. It’s easiest to find these addresses by using a computer on the same network.

For Windows-based PCs:

• Open the Start Menu, navigate to Accessories and open

Command Prompt.

• Type “ipconfig” and press Enter.

• Your IP Address information will be displayed.

For Mac-based systems:

• From the Apple menu, select System Preferences.

• Click on the Network pane.

• Click on the Advanced button and look under the TCP/IP,

DNS, and Ethernet tabs.

Creating a Unique IP Address

The IP Address of your computer will be made up of four groups of numbers, separated by periods: aaa.bbb.ccc.ddd

I’m using a router which doesn’t support UPnP. How do I

be there.

“forward ports”?

It depends on what type of router you have. There’s no standard procedure for forwarding ports - each manufacturer has their own user interface and procedure for customising the behaviour of the router.

First, check the router’s documentation - the instructions may

If your router’s documentation doesn’t describe the method for port forwarding, then open a web browser and navigate to www.portforward.com - they’ve got instructions on port forwarding for (literally) thousands of different routers.

We can’t offer much more information about forwarding ports here, as this is a process totally dependent on third-party hardware. If you do run into trouble, we suggest contacting the manufacturer of the router.

Alternately, if you’re using an older router which doesn’t support UPnP, then it might be time for an upgrade - modern routers are increasingly powerful and are (in most cases) easier than ever to setup. We think that UPnP is a fantastic feature that’s well worth having, not just for DVRs.

The first three groups of numbers (aaa.bbb.ccc) must be the same as the other device on your network. The last number

(ddd) must be changed to something unique that nothing else on your network uses.

For example:

If your computer’s IP address is 192.168.1.10, then a suitable unique IP address for your DVR will be 192.168.1.210

Note: Each number in the IP address cannot exceed 255.

57

58

English

Warranty Information

USA

Swann Communications USA Inc.

12636 Clark Street

Santa Fe Springs CA 90670

USA

Australia

Swann Communications

Unit 13, 331 Ingles Street,

Port Melbourne Vic 3207

Australia

United Kingdom

Swann Communications LTD.

Stag Gates House

63/64 The Avenue

SO171XS

United Kingdom

Warranty Terms & Conditions

Swann Communications warrants this product against defects in workmanship and material for a period of one (1) year from its original purchase date. You must present your receipt as proof of date of purchase for warranty validation. Any unit which proves defective during the stated period will be repaired without charge for parts or labour or replaced at the sole discretion of Swann. The end user is responsible for all freight charges incurred to send the product to Swann’s repair centres. The end user is responsible for all shipping costs incurred when shipping from and to any country other than the country of origin.

The warranty does not cover any incidental, accidental or consequential damages arising from the use of or the inability to use this product. Any costs associated with the fitting or removal of this product by a tradesman or other person or any other costs associated with its use are the responsibility of the end user.

This warranty applies to the original purchaser of the product only and is not transferable to any third party. Unauthorized end user or third party modifications to any component or evidence of misuse or abuse of the device will render all warranties void.

By law some countries do not allow limitations on certain exclusions in this warranty. Where applicable by local laws, regulations and legal rights will take precedence.

For Australia: Our goods come with guarantees which cannot be excluded under Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to major failure.

English

Notes

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

______________________________________________________________

59

English

60

Helpdesk / Technical Support Details

Swann Technical Support

All Countries E-mail: [email protected]

Telephone Helpdesk

USA toll free

1-800-627-2799

AUSTRALIA toll free

1300 138 324

USA Exchange & Repairs

1-800-627-2799 (Option 1)

(M-F, 9am-5pm US PT)

NEW ZEALAND toll free

0800 479 266

UK

0203 027 0979

© Swann Communications 2013
