Welcome
Thank you for choosing CROSS PACK. CROSS PACK is a compact plug and play digital vinyl system that includes
Mixvibes CROSS DJ software and the U46MK2 audio interface. This DJ software was designed to provide a simple and user-friendly environment, so you can focus on mixing tracks and having fun.
Take a few minutes to run through this quick start guide and you’ll be on your way to making great mixes on
CROSS in no time at all!
We invite you be a part of the MixVibes community to share your experiences with other DJs, find help and advice, and check for available updates. See you online on the forum
1 or on the website
2
Minimum System Requirements for PC
•
Windows XP SP2 or Windows Vista SP1 or Windows 7
•
Pentium 4 / 2 GHz or equivalent
•
512 MB RAM (1 GB recommended)
•
One available USB port
•
Hard drive space for music
Minimum System Requirements for MAC
•
Mac OS X 10.4
•
Intel Core Duo / 1.83 GHz or higher
•
512 MB RAM (1 GB recommended)
•
One available USB port
•
Hard drive space for music
C
Box Contents
•
CROSS installation disc
•
U46MK2 USB audio interface
•
2x control CDs
•
2x control records
M
J
•
1 USB cable; set of RCA cables; RCA Y-adaptor
CM
•
This quick start guide
•
Keyboard stickers
MJ
1 http://forum.mixvibes.com
2 http://www.mixvibes.com
CJ
CMJ
N
3 /
1 U46MK2 Description
1.1 Front Panel
1 2 3 4
CMJ
N
MJ
CJ
J
CM
C
M
Front panel
1 Channel 1/2 input
Input source (MIC/LINE/PHONO) selector: This is where you select input sources of channel 1/2.
MIC input connector: Connect your Microphone to this Balanced 1/4” connector.
+48V Phantom power switch: Supply +48V DC phantom power to input channels 1/2 simultaneously by pressing the button.
Gain control for MIC input: Controls the input level of the microphone.
2 Channel 3/4 input vibe-watermark-bright.pdf 03/04/2009 16:07:52
Input source (Hi-Z/LINE/PHONO) selector: This is where you select input sources of channel 3/4.
Hi-Z input connector: Connect any line level instrument such as an electric guitar or bass guitar to this unbalanced 1/4” connector.
C
Gain control for Hi-Z input: Control the input level of the instrument input.
M
3 Headphone output with volume control
Headphone output connector: Monitor all input and output sources through the headphone output.
to DJ.
4 Power Switch
MJ
CJ
CMJ
N
4 /
1 U46MK2 Description
1.2 Rear Panel
1 2 3 4 5 6
CJ
CMJ
CM
MJ
N
C
M
J
Rear Panel
1 External Power supply connector: If you use a microphone that requires phantom power, especially with a laptop computer, it’s strongly recommended to use a DC +9V/500mA adapter (not included).
2 USB connector: Connects the USB cable to the computer.
3 Mix output: You can monitor all input sources and output sources through the Mix output. Usually, you can use Mix out to connect to powered monitor speakers.
4 Output 1~6: You can use these outputs to connect an external mixer or your sound system (amplifier, powered speakers, or home stereo).
5 vibe-watermark-bright.pdf 03/04/2009 16:07:52 share the same connectors. Use the input source selectors on the front panel to select the input sources.
6 Ground lug: When you use a turntable, connect the ground lead from your turntable to the ground lug to
C help prevent hum.
M
CJ
CMJ
N
J
CM
MJ
5 /
2 Connections
Follow the instructions below to use CROSS and the U46MK2 with a pair of decks and an external mixer.
1 If you are using vinyl, plug the ground of your turntable to the ground lug on the U46MK2 or on your DJ mixer.
2 Connect the outputs of your decks (vinyl or CD) to the RCA inputs of your U46MK2 plugging the left deck into the inputs 1/2 and right deck into the inputs 3/4. Match the left channel (usually white) with the white
RCA sockets on the U46MK2, and right (usually red) with the red sockets.
3 Connect the outputs of your U46MK2 to the line inputs of your mixer. Using the included RCA cables, connect the outputs 1/2 into a line input of your mixer, then repeat for the outputs 3/4, into another available line input of your mixer.
4 Set the U46MK2’s input selectors to ’Line’. We recommend to not use any external phono preamp (i.e.
featuring RIAA correction) for the vinyl control input. You must let CROSS deal with the raw input signal:
5 Connect the U46MK2 to a free USB slot of your computer.
6 Turn on your U46MK2.
U46 MK2 line line
C
M
C
Classic turntable or CD player
Mixer
(optional) or CD player
M
Connections
J
CM
CM
Follow the instructions below to use CROSS and the U46MK2 with a MIDI controller and the integrated mixer.
MJ
MJ
1 Connect outputs 1/2 of your U46MK2 to your sound system (amplifier, powered speakers, or home stereo).
CJ
CMJ
2 Connect your headphones to outputs 3/4 of your U46MK2 by using the RCA to mini-jack Y adapter included in the pack.
CJ
N
3 Connect the U46MK2 to a free USB slot of your computer.
4 Turn on your U46MK2.
CMJ
5 Connect the MIDI controller to your computer. Refer to your MIDI controller’s owner’s manual for details.
6 Turn on your MIDI controller.
N
6 /
3 Installation
3.1 Windows
1 Insert CROSS installation disc into your computer’s CD-ROM drive. The installation program will launch automatically. In case it does not, open Windows Explorer, navigate to the CROSS installation disc and double-click on the file «Install Cross .exe».
2 Choose your language and click OK.
Language Selection
C
3 Read and accept the End-User License Agreement by clicking I Agree.
M
MJ
CJ
J
CM
CMJ
N
C
C
4 J
M
CJ
CMJ
N
J
CM
MJ
CM
MJ
CJ
CMJ
N
Components Selection
J
CM
C
M
MJ
CJ
CMJ
N
7 /
3 Installation
5 Choose the folder in which you want to install CROSS and click Next.
Choose Install location
C
6 Choose the Start Menu folder in which you want to create the CROSS shortcut. To start the installation,
M click Install.
J
CJ
CMJ
CM
MJ
N
J
CM
MJ
CJ
C
M
CMJ
N
C
Start Menu Folder Location
M
7 Once the installation is complete you can click Finish. If the check box Run CROSS is selected, CROSS
J
MJ
CJ
J
CM
CMJ
N
CM
MJ
CJ
CMJ
N
Finish Installation
8 /
3 Installation
3.2 Mac OS X
1 Insert the CROSS installation disc into your computer’s CD-ROM drive.
2 install_mac_application.pdf 22/04/2009 12:24:37
3 Drag and drop CROSS into your Applications folder.
Installing CROSS
3.3 Launching CROSS
Windows Go to [Start > All Programs > MixVibes > Cross ] and click on the CROSS icon.
Mac OS X Go to [Applications > Cross ] and double-click on CROSS .
C
M
3.4 License Key
J
C
M
MJ
CJ
CMJ
N
J
CM
License key
MJ
CJ
CMJ
N
CJ
CMJ
CM
MJ
N
C
M
J
9 /
4 Configuring CROSS
4.1 Audio Configuration
1 Go to [File > Preferences > Audio].
Audio Configuration Pane
C
2 Select MixVibes ASIO U46MK2 on PC or U46DJ on Mac from the pull down menu.
M
J
3 vibe-watermark-bright.pdf 03/04/2009 16:07:52
512 samples of buffer.
CM
MJ
4 Select the outputs of the U46MK2 corresponding to the mixer channels.
C
5 Select the inputs of the U46MK2 corresponding to the decks that will playback the control vinyl/CDs.
CJ
CMJ
N
6 If you use control vinyls, set the input level to Phono. If you use control CDs, set the input level to Line.
M
Make sure to follow the connection instructions in section 2. CROSS applies an RIAA correction in "bypass mode" (Line Input on the CROSS mixer) so that you can play regular vinyls.
7
J
Here is a description of the different routing modes:
Simple Stereo
CM
Dual Stereo The master signal is routed to outputs 1/2 and the cue signal is routed to outputs 3/4 on your
U46MK2.
MJ
Split Mono The master and cue signals are folded down to mono. The mono master is routed to output 1 and
External Mixer Deck A direct out is routed to outputs 1/2 on your U46MK2, Deck B direct out is routed to outputs 3/4. and the cue out is routed to outputs 5/6.
CMJ
N
10 /
4 Configuring CROSS
4.2 Time Code Calibration
1 Go to [File > Preferences > Vinyl/CD].
Time Code Calibration Pane
C
M
J
CM
MJ
2 Check Left/Right Control Deck to enable the external control.
3 vibe-watermark-bright.pdf 03/04/2009 16:07:52
4 Start playback of the control records making sure that the pitch is set to zero on your decks and the playback direction is forward. If your decks have a Master Tempo function or any on-board effects, make
C sure they are also disabled as those will interfere with the calibration, and with the time code in general.
CJ
5 Click the ’Calibrate’ buttons. Once proper calibration is achieved, the calibration graphs will output rings
CMJ time code quality is close to 100% when your system is calibrated properly.
N
6 Close the Preferences window.
J
7 Select which deck will control which player by clicking on the A or B deck selector in the Head-Up
Display directly above each deck. A vertical time code quality meter is located between the deck selector
CM and the record icon. This gives you a visual indication of the time code quality during playback. Time
CJ
CMJ
11 /
CJ
CMJ
CM
MJ
N
C
M
J
4 Configuring CROSS
4.3 MIDI Configuration
1 Go to [File > Preferences > MIDI].
MIDI Configuration Pane
C
2 Select your MIDI input device from the pull down menu.
3 Select your MIDI device mapping by clicking on its picture.
CM
C
MJ
CJ
M
CMJ
N
J
CM
MJ
CJ
CMJ
N
12 /
CMJ
N
MJ
CJ
J
CM
C
M
5 Overview of the Graphical User Interface
Once CROSS is configured, you will see the following graphical interface:
Menu
Head-Up
Display
Player
Integrated
Mixer
Dock
Browser
Preview Deck
User Interface
5.1 Menu
The menu lets you access various commands in CROSS.
5.2 Head-Up Display (HUD)
The Head-Up Display contains information essential to your mix:
C
M
1 2 3 4 5
J
Head-Up Display
1 Input level meters.
CM
2 Playback position of the control media.
3 Time code quality meter.
4 Deck Selectors.
MJ
5 The Beat Matcher display gives a visual representation of the synchronization between the players.
CJ
5.3 Players
CMJ
C
The Players control the various playback functions of an audio file. Those function-sets will change based on the
M control mode - internal vs external.
N
J
CM
13 /
MJ
CJ
CMJ
N
5 Overview of the Graphical User Interface
1
2
3
12
4 5 6 7 8 9 10 11
Player
1 Displays the Title, Artist and Duration of the audio file.
C
M
2 Mode selector for the pitch fader. Selects between Speed, Tempo, or Hybrid modes.
3 Pitch fader.
J
CM
4 Full track display. Gives an overview of the waveform for the entire audio file. Clicking on the waveform to will jump to that point in the track.
MJ
CJ
5 Smart Loop.
6 Manual loop.
CMJ
N
7 Match the speed or tempo of the other deck.
C
8 Sync to the nearest down-beat of the other deck.
M
C
9 Reverse the playback direction.
J
10 Pitch range selector. Set the range of the pitch fader up to +/- 100%.
CM
M
11 Set locators for seamless cue points.
MJ
12 Playback modes for external control media: Absolute, Relative, or Flexible.
CJ
J
13 Cue (internal playback mode only).
CMJ
14 Play/Pause (internal playback mode only).
N
CM
5.4 Integrated Mixer
MJ
CMJ
N
14 /
5 Overview of the Graphical User Interface
1
6
2
4
7
8
9
10
11
5
3
Integrated Mixer
1 Record Master.
C
2 Input selectors (Player or Line In).
3 Player output meters.
4 Gain.
CM
MJ
5 Master output meter.
CJ
6 Pre Fader Listen.
CMJ
7 EQ.
N
8 Crossfader.
9 Master Level.
10 Cue Level.
11 Players Level.
C
5.5 Dock
M
The dock is the central component of CROSS’ media management system. It hosts multiple tabs which can be
J un-docked to view two or more lists at the same time. To un-dock a tab, click on the arrow to the right of the tab icon.
CM
5.6 Browser
MJ
The browser displays the track information in list view and enables you to scroll through your collection and load tracks into the players.
CJ
5.7 Preview Deck
CMJ
The preview deck enables you to quickly preview and select tracks in the headphones without loading them into a
15 /
CMY
K
MY
CY
Y
CM
C
M
6 Control Modes
6.1 External Control Modes
6.1.1 Absolute Mode
In this mode, the playback position of the control record/disc corresponds precisely with the playback position of the audio file in the player.
Use the Absolute mode when you want to use your turntable’s tonearm (or the seek function on your CD) to skip thru the track. If you are using CD decks, you can use their cueing and looping capabilities as well.
6.1.2 Relative Mode
In this mode, the playback position of the control record/disc does not correspond with the playback position of the audio file in the player.
Use the Relative mode when you want to use non-linear functions like hot cues (Locations) and Loops. The
«Automatic Control Mode Switching» preference in the Vinyl/CD preference pane allows CROSS to automatically switch to Relative mode when you set a location or a loop.
6.1.3 Flexible Mode
In this mode, the time code is disabled altogether, allowing you to pick up the needle or stop playback on your deck.
Use the Flexible mode when you need to deactivate the external control for any reason without interrupting a mix:
• vibe-watermark-bright.pdf 03/04/2009 16:07:52 interrupting your mix.
•
CROSS will automatically switch to Flexible mode when the end of the time code is reached while a track
C is still playing.
absolute.pdf 26/02/2009 20:13:01
When in Flexible mode, clicking on the Flexible button stops playback.
M
J
Absolute / Relative / Flexible modes
CM
6.2 Internal Control Mode
MJ
In this mode, use the software to control the playback independently of the control records/discs.
CJ
Use this mode when you want to control the playback using the mouse & keyboard, and/or a MIDI controller.
CMJ
C
C
M
M
J
J
CM
CM
MJ
MJ
CJ
CJ
CMJ
CMJ
N
N
N
16 /
7 Importing Audio
7.1 Importing Folders
To import an entire folder of music:
1 Go to [File > Import > Directory]
2 import_media.pdf 26/02/2009 20:48:47
3 CROSS will import all the audio tracks into the Collection.
Locating a Folder
You can also import files by going to [File > Import > Media] or playlists by going to [File > Import > Playlist].
M
J
CM
MJ
C
CJ
CMJ
N
7.2 iTunes® Integration
C
If you use Apple’s iTunes® software to manage your track collection, you can access your iTunes® Library and playlists by clicking on the iTunes® tab in the Dock.
To import tracks from iTunes®:
M
1 While viewing your collection, un-dock the iTunes® tab.
2
J
3 Drag and drop your selection into the collection window or right-click (CTRL+click on Mac) and choose
Add to Collection.
CM
MJ
CJ
CMJ
N
17 /
8 Loading Tracks
After importing your audio tracks you can load them into the players. There are three ways of loading tracks:
With the mouse
•
Drag and drop a track from the collection to one of the players.
•
Right-click (CTRL+click on Mac) and select Load in Player A, B or Active.
With the keyboard
Use the up and down arrow keys to scroll through your collection. Load the highlighted track into one of the players by using the Load shortcut (Configure your shortcuts in [File > Preferences > Keyboard > Media Rack]).
With the control record
On the B-side of the control record, the last track is used for track browsing and selection. Put the needle down anywhere in this track and as the record turns it will browse through your collection. Stop the record on the desired track, lift the needle and put it back to the beginning of the record to load the track into the player.
With the control disc
Track 2 on the control CD is used for track browsing and selection. Select track 2 and press Play to browse your collection using the pitch fader. A negative pitch will scroll down and a positive pitch will scroll up. (The scrolling speed will vary with the pitch, careful not to go too fast...) Once you found the track you want to load, return the pitch to 0 to stop scrolling and select Track 1 to load it into the player.
CJ
CMJ
CM
MJ
N
C
M
J
18 /
9 First Mix with CROSS
1 Load tracks into both players and the waveforms will appear.
2 Begin playback of the control records to start playback of the audio in the players.
3 You should now hear the music in your speakers: You can start mixing.
4 To go from one track to another, move the crossfader from left to right, or use the channels faders on your external mixer (or the CROSS mixer if you are not in External Mixer routing mode).
5 To pre-listen to tracks, use the cue section of your external mixer (or the CROSS mixer if you are not in
External Mixer routing mode).
6 The two audio tracks are most likely not at the same tempo. You need to match the tempo of both tracks, and synchronize one player with the other by:
• adjusting the pitch via the pitch buttons (on your decks if using external control). Use the Beat
Matcher in the Head-Up Display as visual indicator.
• using the Sync buttons to automatically perform those two tasks. Pressing the Sync button will the other player.
MJ
CJ
CMJ C
N M
J
CM
C
M
MJ
CJ
J
CM
CMJ
N
CMJ
N
MJ
CJ
J
CM
C
M
CJ
CMJ
CM
MJ
N
C
M
J
Sync
19 /
10 Troubleshooting
The audio tracks are not playing back
•
Make sure you selected the correct audio interface in the audio preferences window.
•
Make sure you activated the correct audio inputs and outputs of your audio interface in the audio preferences window.
•
Make sure you selected the correct Routing Mode in the audio preferences window.
•
Make sure that your control records/discs have been properly calibrated in the vinyl/CD preferences window.
There is no sound from speakers
•
Check for activity on the output meter of the internal mixer. If there is no response from the meter, check all the controls of the mixer: faders, gain, kills, etc.
•
If you are in external mixer mode, check your connections from your audio interface to your mixer and from your mixer to your sound system. Make sure you have the proper inputs selected on your mixer.
The time code quality is bad
•
Check for proper connections of your turntables’ ground wires.
•
Make sure your needles are clean and not damaged.
•
Make sure there is no dust on your records and needles.
•
Make sure your cables are in good condition. Troubleshoot by using a different cable.
•
C
Make sure your decks are properly connected to your audio interface.
•
Make sure the right and left channels are not inverted.
•
M
Make sure your record is not scratched.
J
CJ
CMJ
CM
MJ
N
20 /
Contact
•
For all technical or sales information, please contact your local reseller or MixVibes directly:
MixVibes
4, rue de la Sablière
92230 Gennevilliers
FRANCE www.mixvibes.com
•
Technical support:
• online on our forum
1
•
Sales Information:
• by email to [email protected]
C
M
J
Copyright 2009 MixVibes. All rights reserved.
CM
The contents of this guide may change without prior notice. Best efforts have been put forth to insure the accuracy of the contents of this guide. MixVibes is not liable for any errors, typographical or other, contained herein. Except any means without the prior written permission of MixVibes. Trademarks and trade names displayed on this guide are the property of their respective owners.
CJ
MIXVIBES CROSS PACK - Quick Start Guide 1.3.0.
CMJ
This guide may be updated from time to time. Please check for updates on our website
2
1 http://forum.mixvibes.com
2 http://www.mixvibes.com
N
21 /
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
