HP 220mx Reference guide
optical
drive and library
SCSI-2 command
reference
for models
fx, ex and mx
Optical Drive and Library SCSI-2
Command Reference
For fx, ex and mx Models
Edition 4
Manufacturing Part Number: 5969-5727
December 2001
Printed in USA
© Copyright 2001 Hewlett-Packard Company
Notice
This document contains information that is protected by copyright. All
rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written
consent of Hewlett-Packard Company. The information contained in this
document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
printed material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. HewlettPackard shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing,
performance, or use of this material.
Revision History
New editions of this manual incorporate all material updated since the
previous edition. The manual printing date and part number indicate the
current edition. The printing date changes when a new edition is printed.
(Minor corrections and updates incorporated at reprint do not change
this date.)
Edition 1:.
February 1998
Edition 2:.
April 1999
Edition 3:.
June 2000
Edition 4:.
December 2001
ii
Typographical Conventions
The following typographical conventions are used in this manual:
Keycap: Menu choices and screens on the jukebox.
Computer Output: Information displayed in the display window and
screen menu items that you can select.
NOTE
Notes provide information that can be helpful in understanding the
operation of the product.
iii
In This Manual
Chapter 1
SCSI Command Overview: Explains SCSI
commands and how they are used with optical
drives and jukeboxes. This section does not
replace the SCSI-2 Command Specifications.
Chapter 2
SCSI-2 Drive Command Set: Lists all
supported SCSI commands and explains each
command’s structure.
Chapter 3
SCSI-2 Jukebox Command Set: Lists all
supported SCSI autochanger commands and
explains each command’s structure.
Appendix A
Drive Error Codes: Lists all error codes
associated with the optical disk drive.
Appendix B
Autochanger Error Codes: Lists all error codes
associated with the autochanger or optical disk
jukebox system.
Appendix C
Field Replaceable Units (FRUs): Lists all the
field replaceable units for optical jukeboxes by
part number.
Appendix D
Micro/Macro-Moves: Lists all micro- and
macro-moves for the optical jukeboxes.
Appendix E
Programmer’s Tips: Provides information for
building optical disk and jukebox drivers, utilities
and applications.
iv
Contents
1. SCSI Command Overview
Optical Drive Control Through SCSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Drive Control Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
SCSI Bus Phases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Arbitration phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Selection phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Reselection phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Information transfer phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Data phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Command phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Message phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Command Complete 00H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Extended Message 01H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Synchronous Negotiation Started by the Initiator . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Save Data Pointer 02H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Restore Pointers 03H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Disconnect 04H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Initiator-Detected Error 05H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Abort 06H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Message Reject 07H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
No Operation 08H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Message Parity Error 09H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Linked Command Complete 0AH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Linked Command Complete (with flag) 0BH . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Bus Device Reset 0CH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Abort Tag 0DH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Clear Queue 0EH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Queue Tag Messages (20H, 21H, 22H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Identify 80H-FFH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Status Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
Attention Condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
Reset Condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
Unit Attention Condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
SCSI Commands Used by the Target . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18
Explanation of the Command Descriptor Block (CDB) . . . . . . . . . . . . . . . . . . . . . 1-18
2. SCSI-2 Drive Command Set
v
Contents
Numerical List of Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Flag, Link, and RelAdr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Test Unit Ready Command (00H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Rezero Unit Command (01H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Request Sense Command (03H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Sense Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Field Pointer Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Format Unit Command (04H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Format Unit Command Defect List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Reassign Blocks Command (07H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
Reassign Blocks Command Defect List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
Read (Group 0) Command (08H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Write (Group 0) Command (0AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
Seek (Group 0) Command (0BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Inquiry Command (12H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
Mode Select Command (15H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
Mode Select Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
Read-Write Error Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
Disconnect-Reconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
Caching Page 08H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-37
Control Mode Page 0AH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-39
Medium Types Supported Page 0BH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-40
Vendor Unique Format Page 20H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-42
Format Mode 03H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-43
Vendor Unique Page 21H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-46
Mode Page Parameter Default Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-48
DIP Switch Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-51
Reserve Command (16H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-52
Release Command (17H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-53
Mode Sense (Group 0) Command (1AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-54
Read-Write Error Recover Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-57
Disconnect-Reconnect Page 02H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-59
Caching Page 08H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-60
Control Mode Page (0AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-63
Medium Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-64
Vendor Unique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-66
vi
Contents
Format Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-67
Vendor Unique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-70
Start/Stop Unit Command (1BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-73
Receive Diagnostic Results Command (1CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-74
Send Diagnostic Command (1DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-76
Prevent/Allow Medium Removal Command (1EH) . . . . . . . . . . . . . . . . . . . . . . . . . 2-79
Read Capacity Command (25H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-80
Read (Group 1) Command (28H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-82
Write (Group 1) Command (2AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-84
Seek (Group 1) Command (2BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-87
Erase (Group 1) Command (2CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-88
Write and Verify (Group 1) Command (2EH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-90
Verify (Group 1) Command (2FH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-92
Pre-Fetch (34H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-94
Synchronize Cache (35H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-95
Read Defect Data (Group 1) Command (37H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-96
Write Buffer Command (3BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-99
Read Buffer Command (3CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-102
Read Long Command (3EH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-104
Write Long Command (3FH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-106
Log Select Command (4CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-109
Parameter List Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-110
Log Sense Command (4DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-111
Supported Log Pages 00H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-112
Mode Select (Group 2) Command (55H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-122
Mode Sense (Group 2) Command (5AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-125
Read (Group 5) Command (A8H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-128
Write (Group 5) Command (AAH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-131
Erase (Group 5) Command (ACH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-134
Write and Verify (Group 5) Command (AEH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-137
Verify (Group 5) Command (AFH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-140
Read Defect Data (Group 5) Command (B7H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-142
Read Long Command (DEH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-145
Write Long Command (DFH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-147
3. Jukebox SCSI-2 Command Set
Numerical List of Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Alphabetical List of Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
vii
Contents
Test Unit Ready Command (00H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Rezero Unit Command (01H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Request Sense Command (03H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Initialize Element Status Command (07H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Rotate Mailslot Command (0CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Inquiry Command (12H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Inquiry Command Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Vital Product Data Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Reserve Command (16H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
Reserve Command Element List Descriptors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
Release Command (17H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20
Mode Sense Command (1AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
Transport Element (Picker) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
Device Capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-26
Receive Diagnostic Results Command (1CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-33
Send Diagnostic Command (1DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-35
Send Diagnostic Command Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-36
Prevent/Allow Medium Removal Command (1EH) . . . . . . . . . . . . . . . . . . . . . . . . . . 3-37
Position To Element Command (2BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-38
Write Buffer Command (3BH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-39
Read Buffer Command (3CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-43
Log Sense Command (4DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-47
Log Sense Parameter Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-47
Error Logs Table Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-49
Move Success Log Table Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-53
Force Log Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-54
Recovery Log Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-55
Drive Log Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-57
Odometer Log Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-58
Run-Time Log Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-59
Retry Log Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-61
Move History Log Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-63
Move Medium Command (A5H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-64
Exchange Medium Command (A6H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
Read Element Status Command (B8H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-68
Read Element Status Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-69
viii
Contents
Element Type Code 1H - Picker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-70
Element Type Code 2H - Storage Slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-71
Element Type Code 3H - Mailslot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-72
Element Type Code 4H - Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-74
A. Drive Error Codes
Chapter Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-2
Drive Request Sense Command Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-3
Drive Request Sense - Sense Key Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-3
Request Sense - Additional Sense Code Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-5
Internal Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-9
DSP Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-19
B. Autochanger Error Codes
Chapter Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-2
Request Sense Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-3
Additional Sense Data Format for Error Recovery For all models, EXCEPT 40fx
and 80ex. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-8
Hardware Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-19
Autochanger Move Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-29
Jukebox Micro-Move Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-32
Diagnostic Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-40
C. Field Replaceable Units (FRUs)
HP Field Replaceable Units (FRUs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-2
D. Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-2
E. Disconnect Timeout Settings
Disconnect Timeouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-2
ix
Contents
x
Tables
Table 1-1. Target-Supported Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Table 1-2. Extended Message Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Table 1-3. Transfer Period Values (For 9.1 and 5.2 Gbyte Drives) . . . . . . . . . . . . . . 1-8
Table 1-4. Offset Values (For 5.2 and 9.1 Gbyte Drives) . . . . . . . . . . . . . . . . . . . . . . 1-9
Table 1-5. Simple Queue Tag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Table 1-6. Head of Queue Tag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Table 1-7. Ordered Queue Tag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Table 1-8. Target-Supported Status Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Table 2-1. Group 0 Commands (6-byte command) . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Table 2-2. Group 1 and 2 Commands (10-byte command) . . . . . . . . . . . . . . . . . . . . . 2-4
Table 2-3. Group 5 Commands (12-byte command) . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Table 2-4. Test Unit Ready Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Table 2-5. Rezero Unit Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Table 2-6. Request Sense Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Table 2-7. Error Code 70H or 71H Sense Data Format . . . . . . . . . . . . . . . . . . . . . . 2-11
Table 2-8. Sense Key Field Pointer Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Table 2-9. Progress Indication Field Bytes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Table 2-10. Format Unit Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Table 2-11. Format Unit Defect List Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Table 2-12. Physical Sector Format Defect Descriptor. . . . . . . . . . . . . . . . . . . . . . . 2-18
Table 2-13. Block Format Defect Descriptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Table 2-14. Reassign Blocks Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
Table 2-15. Reassign Blocks Command Defect List Header . . . . . . . . . . . . . . . . . . 2-19
Table 2-16. Reassign Blocks Command Defect Descriptor. . . . . . . . . . . . . . . . . . . . 2-20
Table 2-17. Read (Group 0) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Table 2-18. Write (Group 0) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
Table 2-19. Seek (Group 0) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Table 2-20. Inquiry Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
Table 2-21. Vital Product Data Page Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
Table 2-22. Supported Vital Product Data Pages (00H). . . . . . . . . . . . . . . . . . . . . . 2-27
Table 2-23. Unit Serial Number Page (80H). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
Table 2-24. Unique Media ID Page (C1H). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
Table 2-25. Inquiry Command Returned Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-29
Table 2-26. Mode Select (Group 0) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
xi
Tables
Table 2-27. Mode Page Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
Table 2-28. Mode Select Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
Table 2-29. Mode Select Block Descriptor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
Table 2-30. Read-Write Error Recovery Page 01H . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
Table 2-31. Disconnect-Reconnect Page 02H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
Table 2-32. Caching Page 08H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-37
Table 2-33. Control Mode Page 0AH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-39
Table 2-34. Queue Algorithm Modifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-39
Table 2-35. Medium Types Supported Page 0BH . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-40
Table 2-36. Valid Medium Type Combinations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-41
Table 2-37. Vendor Unique Format Page 20H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-42
Table 2-38. Format Mode 03H - Type 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-43
Table 2-39. Format Mode 03H - Type 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-44
Table 2-40. Format Mode 04H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-45
Table 2-41. Vendor Unique Page 21H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-46
Table 2-42. Mode Page Parameter Default Values . . . . . . . . . . . . . . . . . . . . . . . . . . 2-48
Table 2-43. Mode Page 20H Parameter Default Values . . . . . . . . . . . . . . . . . . . . . . 2-49
Table 2-44. DIP Switch Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-51
Table 2-45. Reserve Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-52
Table 2-46. Release Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-53
Table 2-47. Mode Sense (Group 0) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . 2-54
Table 2-48. Mode Sense Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-55
Table 2-49. Mode Sense Descriptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-55
Table 2-50. Mode Page Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-56
Table 2-51. Read-Write Error Recovery Page 01H . . . . . . . . . . . . . . . . . . . . . . . . . . 2-57
Table 2-52. Disconnect-Reconnect Page 02H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-59
Table 2-53. Caching Page 08H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-60
Table 2-54. Control Mode Page (0AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-63
Table 2-55. Medium Types Supported Page 0BH . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-64
Table 2-56. Valid Medium Type Combinations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-65
Table 2-57. Vendor Unique Format Page 20H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-66
Table 2-58. Format Mode 03H - Type 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-67
Table 2-59. Format Mode 03H - Type 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-68
Table 2-60. Format Mode 04H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-69
xii
Tables
Table 2-61. Vendor Unique Page 21H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-70
Table 2-62. Start/Stop Unit Command CDB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-73
Table 2-63. Receive Diagnostic Results Command CDB . . . . . . . . . . . . . . . . . . . . . 2-74
Table 2-64. Received Diagnostic Results Page Codes. . . . . . . . . . . . . . . . . . . . . . . . 2-74
Table 2-65. Supported Diagnostic Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-75
Table 2-66. Controller Test 81H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-75
Table 2-67. Send Diagnostic Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-76
Table 2-68. Supported Diagnostic Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-77
Table 2-69. Send Diagnostic Command Page Codes. . . . . . . . . . . . . . . . . . . . . . . . . 2-77
Table 2-70. Controller Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-78
Table 2-71. Interface Manager Diagnostic Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-78
Table 2-72. Prevent/Allow Medium Removal Command CDB. . . . . . . . . . . . . . . . . 2-79
Table 2-73. Read Capacity Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-80
Table 2-74. Read Capacity Command Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-81
Table 2-75. Read (Group 1) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-82
Table 2-76. Write (Group 1) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-84
Table 2-77. Seek (Group 1) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-87
Table 2-78. Erase (Group 1) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-88
Table 2-79. Write and Verify (Group 1) Command CDB . . . . . . . . . . . . . . . . . . . . . 2-90
Table 2-80. Verify (Group 1) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-92
2-Table 2-81. Pre-Fetch Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-94
2-Table 2-82. Synchronize Cache Command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-95
Table 2-83. Read Defect Data (Group 1) Command CDB . . . . . . . . . . . . . . . . . . . . 2-96
Table 2-84. Read Defect Data Defect List Header . . . . . . . . . . . . . . . . . . . . . . . . . . 2-97
Table 2-85. Physical Sector Format Defect Descriptor. . . . . . . . . . . . . . . . . . . . . . . 2-98
Table 2-86. Write Buffer Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-99
Table 2-87. Buffer Access Mode and ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-100
Table 2-88. Mode Descriptions (For 2.6 Gbyte Capacity Drives Only) . . . . . . . . . 2-100
Table 2-89. Mode Descriptions (For 9.1 and 5.2 Gbyte Capacity Drives Only). . . 2-101
Table 2-90. Read Buffer Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-102
Table 2-91. Read Buffer Descriptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-103
Table 2-92. Buffer Access Mode and ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-103
Table 2-93. Mode Descriptions (For 2.6 Gbyte Capacity Drives Only) . . . . . . . . . 2-103
Table 2-94. Mode Descriptions (For 9.1 and 5.2 Gbyte Capacity Drives Only). . . 2-103
xiii
Tables
Table 2-95. Read Long Command CDB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-104
Table 2-96. Write Long Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-106
Table 2-97. Log Select Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-109
Table 2-98. Parameter List Data for Byte 8 of the Log Select Command . . . . . . . 2-110
Table 2-99. Log Select Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-110
Table 2-100. Log Sense Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-111
Table 2-101. Log Sense Page Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-112
Table 2-102. Supported Log Pages 00H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-112
Table 2-103. Error Counter Page for Write Errors 02H . . . . . . . . . . . . . . . . . . . . . 2-113
Table 2-104. Parameter Codes/Structure for Write Errors . . . . . . . . . . . . . . . . . . 2-113
Table 2-105. Error Counter Page for Read Errors 03H . . . . . . . . . . . . . . . . . . . . . 2-114
Table 2-106. Parameter Codes/Structure for Read Errors . . . . . . . . . . . . . . . . . . . 2-114
Table 2-107. Error Counter Page for Verify Errors 05H . . . . . . . . . . . . . . . . . . . . 2-115
Table 2-108. Parameter Codes/Structure for Verify Errors . . . . . . . . . . . . . . . . . . 2-115
Table 2-109. Last N Error Events Page 07H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-116
Table 2-110. Parameter Pointers/Structure for Last N Error Events Page . . . . . 2-117
Table 2-111. Error Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-118
Table 2-112. Error Counter Page for Erase Errors 33H. . . . . . . . . . . . . . . . . . . . . 2-118
Table 2-113. Parameter Codes/Structure for Erase Errors . . . . . . . . . . . . . . . . . . 2-120
Table 2-114. Error Counter Page for Blank Check Errors 34H . . . . . . . . . . . . . . . 2-120
Table 2-115. Parameter Codes/Structure for Blank Check Errors . . . . . . . . . . . . 2-121
Table 2-116. Mode Select (Group 2) Command CDB . . . . . . . . . . . . . . . . . . . . . . . 2-122
Table 2-117. Mode Select Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-123
Table 2-118. Mode Select Block Descriptor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-124
Table 2-119. Mode Select (Group 2) Command CDB . . . . . . . . . . . . . . . . . . . . . . . 2-125
Table 2-120. Mode Sense Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-126
Table 2-121. Mode Sense Block Descriptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-127
Table 2-122. Read (Group 5) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-128
Table 2-123. Write (Group 5) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-131
Table 2-124. Erase (Group 5) Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-134
Table 2-125. Write and Verify (Group 5) CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-137
Table 2-126. Verify (Group 5) CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-140
Table 2-127. Read Defect Data (Group 5) Command CDB . . . . . . . . . . . . . . . . . . 2-142
Table 2-128. Read Defect Data Defect List Header . . . . . . . . . . . . . . . . . . . . . . . . 2-143
xiv
Tables
Table 2-129. Physical Sector Format Defect Descriptor. . . . . . . . . . . . . . . . . . . . . 2-144
Table 2-130. Read Long Command CDB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-145
Table 2-131. Write Long Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-147
Table 3-1. Numerical List of Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Table 3-2. Alphabetical List of Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Table 3-3. Test Unit Ready Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Table 3-4. Rezero Unit Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Table 3-5. Request Sense Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Table 3-6. Request Sense Data Parameter Block Format . . . . . . . . . . . . . . . . . . . . . 3-9
Table 3-7. Sense Key - Additional Sense Length Values . . . . . . . . . . . . . . . . . . . . . 3-10
Table 3-8. Sense Key Field = Illegal Request (05H) and SKSV Bit = 1. . . . . . . . . . 3-11
Table 3-9. Initialize Element Status Command CDB . . . . . . . . . . . . . . . . . . . . . . . 3-12
Table 3-10. Rotate Mailslot Command CDB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Table 3-11. Inquiry Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Table 3-12. Vital Product Data Page Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Table 3-13. Standard Inquiry Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Table 3-14. Supported Vital Product Data Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Table 3-15. Unit Serial Number Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Table 3-16. Firmware Information Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Table 3-17. Reserve Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
Table 3-18. Reserve Command Element List Descriptors . . . . . . . . . . . . . . . . . . . . 3-19
Table 3-19. Reserve Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20
Table 3-20. Mode Sense Command CDB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
Table 3-21. Mode Sense Allocation Lengths . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-22
Table 3-22. Mode Sense Element Address Assignment Page (1DH) Format . . . . . 3-23
Table 3-23. Number of Transport Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23
Table 3-24. Number of Data Transfer Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23
Table 3-25. Mode Sense Transport Element Parameter Page (1EH) Format . . . . . 3-25
Table 3-26. Mode Sense Device Capabilities Page (1FH). . . . . . . . . . . . . . . . . . . . . 3-27
Table 3-27. Mode Sense Device Capabilities Page (1FH). . . . . . . . . . . . . . . . . . . . . 3-28
Table 3-28. Autochanger Configuration Mode Page (20H). . . . . . . . . . . . . . . . . . . . 3-30
Table 3-29. Receive Diagnostic Results Command CDB . . . . . . . . . . . . . . . . . . . . . 3-33
Table 3-30. Receive Diagnostic Results Command CDB . . . . . . . . . . . . . . . . . . . . . 3-34
Table 3-31. Send Diagnostic Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-35
xv
Tables
Table 3-32. Send Diagnostic Command Parameter List . . . . . . . . . . . . . . . . . . . . . 3-36
Table 3-33. Prevent/Allow Medium Removal Command CDB. . . . . . . . . . . . . . . . . 3-37
Table 3-34. Position To Element Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-38
Table 3-35. Write Buffer Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-39
Table 3-36. Write Buffer Mode Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-40
Table 3-37. User Accessible Buffers and Allowed Write Modes . . . . . . . . . . . . . . . 3-40
Table 3-38. Write Buffer Data Format When Buffer ID Set to Online Drive
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-41
Table 3-39. Drive Control Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-42
Table 3-40. Read Buffer Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-43
Table 3-41. Read Buffer Mode Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44
Table 3-42. User Accessible Buffers and Allowed Read Modes . . . . . . . . . . . . . . . . 3-44
Table 3-43. Read Buffer Data Format When Buffer ID Set to Online Drive
Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-45
Table 3-44. Drive Status Definition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-46
Table 3-45. Log Sense Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-47
Table 3-46. Log Sense Parameter Data Available in Each Page . . . . . . . . . . . . . . . 3-48
Table 3-47. Error Logs Table Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-49
Table 3-48. Error/ Recovery/Runtime Log Data Entry Format . . . . . . . . . . . . . . . . 3-50
Table 3-49. Error Logs Table Format (For 40fx, 80ex, 125ex and 220mx models) . 3-51
Table 3-50. Error Log Entry Format (For 40fx, 80ex, 125ex and 220mx models). . 3-51
Table 3-51. Move Success Log Table Format (For 40fx, 80ex, 125ex and 220mx
models) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-53
Table 3-52. Move Success Logs Entry Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-53
Table 3-53. Force Entry Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-54
Table 3-54. Recovery Log Data Format (For all models EXCEPT 40fx, 80ex,
125ex and 220mx) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-55
Table 3-55. Recovery Log Data Format (For the 40fx, 80ex, 125ex and 220mx
models) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-55
Table 3-56. Recovery Log Entry Format (For the 40fx, 80ex, 125ex and 220mx
models) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-56
Table 3-57. Error Recovery State (For the 40fx, 80ex, 125ex and 220mx models) . 3-56
Table 3-58. Drive Log Data Format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-57
Table 3-59. Drive Log Entry Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-57
xvi
Tables
Table 3-60. Odometer Log Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-58
Table 3-61. Run-Time Logs Data Format (For all models, EXCEPT 40fx, 80ex,
125ex and 220mx) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-59
Table 3-62. Run-Time Logs Data Format (For the 40fx, 80ex, 125ex and 220mx
models) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-59
Table 3-63. Run-Time Log Entry Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-59
Table 3-64. Retry Log Data Format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-61
Table 3-65. Retry Algorithm Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-62
Table 3-66. Move History Log Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-63
Table 3-67. Move History Log Entry Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-63
Table 3-68. Move Medium Command CDB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-64
Table 3-69. Exchange Medium Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
Table 3-70. Read Element Status Command CDB . . . . . . . . . . . . . . . . . . . . . . . . . . 3-68
Table 3-71. Read Element Status Data Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-69
Table 3-72. Medium Transport Element Descriptor Block . . . . . . . . . . . . . . . . . . . 3-70
Table 3-73. Read Element Status Storage Element Descriptor Block . . . . . . . . . . 3-71
Table 3-74. Read Element Status Import/Export Element Descriptor Block . . . . . 3-72
Table 3-75. Read Element Status Data Transfer Element Descriptor Block . . . . . 3-74
Table A-1. Request Sense - Sense Key Values Byte 2, Bits 3 through 0 . . . . . . . . . .A-3
Table A-2. Request Sense - Additional Sense Code Values . . . . . . . . . . . . . . . . . . . .A-5
Table A-3. Internal Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-9
Table A-4. ODC Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-15
Table A-5. ODC Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-17
Table A-6. DSP Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-19
Table A-7. Terms Used In the Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-22
Table B-1. Request Sense - Sense Key Values — Byte 2, Bits 3 through 0. . . . . . . .B-3
Table B-2. Request Sense Data (bytes 12 and 13) . . . . . . . . . . . . . . . . . . . . . . . . . . .B-3
Table B-3. Invalid Address: Sense Code 2IH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-7
Table B-4. Element Full/Empty: Sense Code 3BH . . . . . . . . . . . . . . . . . . . . . . . . . . .B-7
Table B-5. Request Sense - Additional Sense Data (For all models, EXCEPT
40fx, 80ex, 125ex and 220mx) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-8
Table B-6. Request Sense - Additional Sense Data (For models 40fx, 80ex,
125ex and 220mx) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-14
Table B-7. Hardware Error Codes (medium and large models). . . . . . . . . . . . . . . .B-19
xvii
Tables
Table B-8. Hardware Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-22
Table B-9. Autochanger Move Error Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-29
Table B-10. Micro-Move Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-32
Table B-11. Micro-Move Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-32
Table B-12. Diagnostic Tests (EXCEPT for models 40fx, 80ex, 125ex, and
220mx) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-40
Table B-13. Sequence Tests (For models 40fx, 80ex, 125ex, and 220mx) . . . . . . . .B-44
Table C-1. Jukebox FRUs (For all models, EXCEPT 40fx, 80ex, 125ex, and
220mx) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-2
Table C-2. Jukebox FRUs (For the 40fx, 80ex, 125ex and 220mx models) . . . . . . . .C-4
Table D-1. HP Surestore Optical Micro-Move ID Table (For all models, EXCEPT
40fx, 80ex, 125ex and 220mx) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-2
Table D-2. HP Surestore Optical Micro-Move ID Table (For models 40fx, 80ex,
125ex and 220mx) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-17
Table E-1. Timeout Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-2
xviii
SCSI Command Overview
1
SCSI Command Overview
Chapter 1
1-1
SCSI Command Overview
Optical Drive Control Through SCSI
Optical Drive Control Through SCSI
The optical drive can be controlled by the commands described in this
document.
This SCSI command set complies with ANSI X3.131-1994 standards. The
role of the host computer and the target or the address of a disk is
defined in the SCSI specifications as follows:
Initiator
The initiator, usually the host, issues the drive control
commands.
Target device
The target, usually the drive, receives the command and
controls the device.
Addresses
All SCSI commands refer to logical addresses unless
otherwise stated.
1-2
Chapter 1
Drive Control Commands
This section describes all specifications, except command specifications
of the target. The “SCSI Commands Used by the Target” are described
later in this chapter.
SCSI Bus Phases
The target supports the following phases specified in the SCSI standard.
Arbitration phase
When the drive tries to reconnect to an initiator to continue command
operations, it waits for the BUS FREE phase, then enters the
ARBITRATION phase.
Selection phase
The selection phase allows an initiator to select a target for the purpose
of initiating a target function such as a read or write command. During
the selection phase the I/O signal is negated so that this phase can be
distinguished from the reselection phase. The drive examines the DATA
BUS to determine the selecting initiator SCSI ID. If it cannot detect the
ID, the drive does not respond to the selection.
Reselection phase
The reselection phase allows the target to reconnect to an initiator to
continue the command started by the initiator, but suspended by the
target.
Information transfer phase
The command, data, status, and message phases are all grouped together
as the information transfer phases because they are all used to transfer
data or control information via the data bus.
Chapter 1
1-3
SCSI Command Overview
SCSI Command Overview
Drive Control Commands
SCSI Command Overview
Drive Control Commands
Data phase
The data phase encompasses both the “data in” phase and the “data out”
phase to transfer data to and from the drive. Synchronous and
asynchronous data transfers are supported.
The data in phase allows the target to request that data be sent to the
initiator from the target.
The data out phase allows the target to request that data be sent from
the initiator to the target.
Command phase
The command phase sends the Command Descriptor Block (CDB) from
the initiator to the drive.
Message phase
The message phase refers to a message in or a message out phase.
Multiple messages may be sent during either phase. The first byte
transferred in either of these phases is either a single-byte message or
the first byte of a multiple-byte message. Multiple-byte messages are
wholly contained within a single message phase.
Message In phase allows the target to request that messages be sent to
the initiator from the target.
Message Out phase allows the target to request that messages be sent
from the initiator to the target. The target invokes this phase in response
to the attention condition created by the initiator.
See Table 1-1 on page 1-5 for a list of supported messages.
1-4
Chapter 1
Table 1-1
Target-Supported Messages
Code (hex.)
Direction
Description
00H
In
Command Complete
01H
In/Out
Extended Message
02H
In
Save Data Pointer
03H
In
Restore Pointers
04H
In
Disconnect
05H
Out
Initiator-Detected Error
06H
Out
Abort
07H
In/Out
Message Reject
08H
Out
No Operation
09H
Out
Message Parity Error
0AH
In
Linked Command Complete
0BH
In
Linked Command Complete (with flag)
0CH
Out
Bus Device Reset
0DH
Out
Abort Tag
0EH
Out
Clear Queue
20H,21H,22H
In/Out
Queue Tag Simple, Head, Ordered
80H-FFH
In/Out
Identify
Chapter 1
1-5
SCSI Command Overview
SCSI Command Overview
Drive Control Commands
SCSI Command Overview
Drive Control Commands
Command Complete 00H
This message is sent from the target to the initiator to indicate that the
execution of a command has terminated and that valid status has been
sent to the initiator. After successfully sending this message, the target
goes to the Bus Free Phase by releasing BSY (Busy).
Extended Message 01H
This message is sent from either the initiator or the drive to indicate that
the message is an extended message. The drive supports only the
synchronous data transfer request (SDTR) message.
An SDTR message exchange will be initiated by a SCSI device when an
arranged data transfer agreement becomes invalid. The agreement
becomes invalid after an intermediate status such as:
• Hard reset condition
• BUS DEVICE RESET message
• Wide data transfer message
• Power cycle
The initiator may also initiate a SDTR message exchange when
appropriate to negotiate a new data transfer agreement (synchronous or
asynchronous).
Table 1-2
Extended Message Format
Byte
1-6
7
6
5
4
3
2
1
0
0
Extended Message (01H)
1
Extended Message Length (03H)
2
Synchronous Data Transfer Request Code (01H)
3
Transfer Period Factor (m times 4 nanoseconds)
4
REQ/ACK Offset (x)
Chapter 1
The transfer period is the minimum time allowed between leading edges
of successive REQ pulses and of successive ACK pulses.
The REQ/ACK offset is the maximum number of REQ pulses allowed to
be outstanding before the leading edge of its corresponding ACK pulse is
received at the target. This value prevents overflow conditions in the
device’s reception buffer and offset counter. A REQ/ACK offset value of
zero indicates asynchronous mode.
The initiator sets its values according to the rules above that permit it to
receive data successfully. If the drive can also receive data successfully
with these values (or smaller transfer period or larger REQ/ACK offset
or both), it returns the same values in its SDTR message.
Synchronous Negotiation Started by the Initiator
If the initiator recognizes that negotiation is required, it asserts the ATN
signal and sends a SDTR message to begin the negotiating process. After
successfully completing the MESSAGE OUT phase, the drive will
respond with the proper SDTR message. If an abnormal condition
prevents the drive from returning an appropriate response, both devices
will go to asynchronous mode for data transfers between the two devices.
The drive responds to each initiator requested transfer period as shown
in Table 1-3 on page 1-8.
Chapter 1
1-7
SCSI Command Overview
SCSI Command Overview
Drive Control Commands
SCSI Command Overview
Drive Control Commands
Table 1-3
Transfer Period Values (For 9.1 and 5.2 Gbyte Drives)
Initiator Requested
Transfer Period Factor
Drive Response
Transfer Period
0 <= mi <= 25
mt = 25
100 nsec
26 <= mi <= 31
mt = mi
125 nsec
32 <= mi <=37
mt = mi
150 nsec
38 <= mi <=43
mt = mi
175 nsec
44 <= mi <= 50
mt = mi
200 nsec
51 <= mi <= 56
mt = mi
225 nsec
57 <= mi <= 62
mt = mi
250 nsec
63 <= mi <= 68
mt = mi
275 nsec
69 <= mi <= 75
mt = mi
300 nsec
76 <= mi <= 255
mt = mi
Asynchronous
(REQ/ACK offset 0)
The drive responds to each initiator requested REQ/ACK offset as show
in Table 1-4 on page 1-9.
1-8
Chapter 1
Table 1-4
Offset Values (For 5.2 and 9.1 Gbyte Drives)
Initiator Requested
(REQ/ACK Offset)
Drive Response
(REQ/ACK Offset)
0 <= xi <= 15
xt = xi
xt
0 <= xi <= 255
xt = 15
15
Save Data Pointer 02H
This message is sent from the target to direct the initiator to save a copy
of the present active data pointer for the currently attached logical unit.
The drive may issue this message when it disconnects from the SCSI Bus
during data transfer.
Restore Pointers 03H
This message is sent from the target to direct the initiator to restore the
most recently saved pointers to active state. The target may send this
message when a bus error has occurred during the Data In or Status
Phase.
Disconnect 04H
This message is sent from the target to inform an initiator that the
present physical path is going to be broken, but that a later reconnect is
required to complete current operation.
Initiator-Detected Error 05H
When the target receives this message during Data In or Status Phase, it
may retry the transfer after sending a Restore Pointers message.
Abort 06H
This message is sent from the initiator to the target to clear the present
operation. All pending data and status that was made by the current
command is cleared and the target goes to the Bus Free Phase. Pending
data and status for other initiators are not cleared. No status or ending
message is sent for the operation.
Chapter 1
1-9
SCSI Command Overview
SCSI Command Overview
Drive Control Commands
SCSI Command Overview
Drive Control Commands
Message Reject 07H
This message is sent from either the initiator or the target to indicate
that the last message was inappropriate or has not been implemented.
When the target receives a MESSAGE REJECT message from the
initiator, it takes the following action based on which message was
rejected.
Command
Complete
The target goes to Bus Free Phase and does not consider
this as an error.
Disconnect
The target does not disconnect and continues the current command.
Identify
The target goes to the Bus Free Phase and aborts the
command. Sense Key/Additional Sense Code is set to
Hardware Error/Message Reject Error.
Linked Command
Complete
The target goes to the BUS FREE phase and aborts the
command and sets Sense Key/Additional Sense Code to
Aborted Command/Message Error.
Message
Reject
Restore
Pointers
Save Data
Pointers
1-10
The target terminates the command with Check Condition status and sets the Sense Key/Additional Sense
Code to Hardware Error/Message Reject Error.
The target goes to the Bus Free Phase and sets the
Sense Key/Additional Sense Code according to the error
condition.
The target does not disconnect and continues the current command.
Chapter 1
No Operation 08H
This message is ignored by the target.
Message Parity Error 09H
When the target receives this message, it retries the operation by
resending the original message once. If the message cannot be sent
successfully, the target immediately goes to the Bus Free Phase and
aborts the current SCSI command. No further reconnection is attempted
and no status or COMMAND COMPLETE message is returned for the
command. The target sets the Sense Key/Additional Sense Code to
Hardware Error/SCSI Interface Parity Error.
Linked Command Complete 0AH
This message is sent from the drive to an initiator to indicate the
execution of a linked command has been completed and that the status
has been sent.
Linked Command Complete (with flag) 0BH
This message is sent from the drive to an initiator to indicate the
execution of a linked command (with flag bit set to 1) has been completed
and that the status has been sent.
Bus Device Reset 0CH
This message is sent from an initiator to reset the target.
Abort Tag 0DH
The drive goes to the BUS FREE phase following successful receipt of the
ABORT TAG message and clears the current I/O process. If the drive
already started execution of the I/O process, the execution will be halted.
The medium contents may have been modified before the execution was
halted.
Chapter 1
1-11
SCSI Command Overview
SCSI Command Overview
Drive Control Commands
SCSI Command Overview
Drive Control Commands
Clear Queue 0EH
The drive goes to the BUS FREE phase following successful receipt of the
CLEAR QUEUE message. The drive clears all I/O processes, from all
initiators, in the queue for the specified logical unit from the queue. All
active I/O processes are terminated. The medium may have been altered
by partially executed commands. All pending status and data for that
logical unit for all initiators are cleared. A unit attention condition is
generated for all other initiators with I/O processes that either were
active or were queued for that logical unit. The additional sense code is
set to Command Cleared by Another Initiator.
Queue Tag Messages (20H, 21H, 22H)
The drive supports SIMPLE QUEUE TAG, HEAD OF QUEUE TAG, and
ORDERED QUEUE TAG. The Queue Tag Messages consist of two
consecutive bytes, Message Code (20H, 21H, or 22H) and Queue Tag
(00H-FFH) to distinguish each I/O process. The Queue Tag of each I/O
process must be unique for each I/O process, but the numeric value of a
queue tag has no effect on the order of execution.
Table 1-5
Simple Queue Tag
Byte
7
6
5
4
3
0
Message Code (20H)
1
Queue Tag (00H-FFH)
2
1
0
The Simple Queue Tag message specifies that the I/O process be placed
in the logical units command queue. The order of the execution may be
altered within the constraints of the queue management algorithm
specified in the control mode page.
1-12
Chapter 1
Table 1-6
Head of Queue Tag
Byte
7
6
5
4
3
0
Message Code (21H)
1
Queue Tag (00H-FFH)
2
1
0
The Head of Queue Tag message specifies that the I/O process be placed
first in the logical unit's command queue. When the drive receives a
subsequent I/O process received with a Head of Queue Tag message, the
I/O process that has been already done is not interrupted.
Table 1-7
Ordered Queue Tag
Byte
7
6
5
4
3
0
Message Code (22H)
1
Queue Tag (00H-FFH)
2
1
0
The Ordered Queue Tag message specifies that the I/O process be placed
in the logical unit's command queue for execution in the order received.
All queued I/O processes for the logical unit received prior to this I/O
process are executed before this I/O process is executed. All queued I/O
processes received after this I/O process are executed after this I/O
process, except for I/O processes received with a Head of Queue Tag
message.
Identify 80H-FFH
These messages are sent by either the initiator or the target to establish
the physical path connection between initiator and target for a particular
logical unit.
Bit 7
This bit is always set to 1.
Bit 6
This bit is set to 1 by the initiator to indicate that the
initiator has the ability to accommodate the disconnection and reconnection.
Bit 5-3
Reserved.
Chapter 1
1-13
SCSI Command Overview
SCSI Command Overview
Drive Control Commands
SCSI Command Overview
Drive Control Commands
Bit 2-0
These bits specify a logical unit number. Only one logical unit number is identified for any one selection sequence.
Status Phase
A status byte is sent from the target to the initiator during the Status
Phase at the termination of each command unless the command is
cleared by an ABORT message, a BUS DEVICE RESET message, or a
RESET condition. The target supports the following status codes.
Table 1-8
Target-Supported Status Codes
Code (hex.)
Status
00H
Good
02H
Check Condition
04H
Condition Met
08H
Busy
10H
Intermediate/Good
14H
Intermediate Condition Met
18H
Reservation Conflict
28H
Queue Full
Good 00H
This status indicates that the target has successfully completed the
command.
Check Condition 02H
Any error, exception, or abnormal condition that causes sense data to be
set causes a Check Condition status. The Request Sense Command
should be issued following a CHECK CONDITION status to determine
the nature of the condition.
Condition Met 04H
This status or Intermediate-Condition Met is returned when the PreFetch command is satisfied.
1-14
Chapter 1
Busy 08H
A busy status is returned by the target during powerup until all poweron
diagnostic tests have been completed. A busy status is also returned
when multiple commands are outstanding in the target, and a media
access command is received with the DISC PRIV bit cleared in the
identify message.
Intermediate/Good 10H
Unless an error, exception, or abnormal condition causes a Check
Condition status or a Reservation Conflict status, the Intermediate Good
status is returned for every command in a series of linked commands,
excluding the last command. If this status is not returned, the chain of
linked commands is broken; no further commands in the series are
executed.
Intermediate Condition Met 14H
This status is the combination of the Condition Met and the
Intermediate statuses.
Reservation Conflict 18H
This status is returned when a SCSI device attempts to access a logical
unit that is reserved for another initiator.
Queue Full 28H
This status is returned when a Simple Queue Tag, Ordered Queue Tag,
or a Head of Queue Tag message is received and the command queue of
the drive is full. The I/O process is not placed in the command queue. The
drive can handle 32 I/O processes at a time.
Chapter 1
1-15
SCSI Command Overview
SCSI Command Overview
Drive Control Commands
SCSI Command Overview
Drive Control Commands
Conditions
Attention Condition
The Attention Condition allows an initiator to inform the target that the
initiator has a message ready. The target gets this message at its
convenience by performing a Message Out Phase as follows:
1. If the ATN signal becomes true during a COMMAND phase, the drive
enters the MESSAGE OUT phase after transferring part or all of the
command descriptor block bytes.
2. If the ATN signal becomes true during a DATA phase, the drive
enters the MESSAGE OUT phase at the drives earliest convenience.
The initiator will continue REQ/ACK handshakes until it detects the
phase change.
3. If the ATN signal becomes true during a STATUS phase, the drive
enters the MESSAGE OUT phase after the status byte has been
acknowledged by the initiator.
4. If the ATN signal becomes true during a MESSAGE IN phase, the
drive enters the MESSAGE OUT phase before it sends another
message.
5. If the ATN signal becomes true during a SELECTION phase and
before the initiator releases the BSY signal, the drive enters the
MESSAGE OUT phase immediately after that SELECTION phase.
6. If the ATN signal becomes true during a RESELECTION phase, the
drive enters the MESSAGE OUT phase after sending its IDENTIFY
message for that RESELECTION phase.
Reset Condition
The drive implements the hard reset alternative, upon detection of the
RESET condition. When the drive creates the reset conditions, it clears
all I/O processes including queued I/O processes, releases all
reservations, returns any SCSI device operating modes (MODE SELECT,
PREVENT/ALLOW MEDIUM REMOVAL commands, etc.) to their
initial conditions, and generates UNIT ATTENTION condition.
1-16
Chapter 1
Unit Attention Condition
A unit attention condition for a logical unit begins for each initiator for
any of the following conditions:
• Poweron or Reset
• Disk Loaded
• Micro Code Change
• Inquiry Data Change
• Mode Select Data Change
The unit attention condition persists for each initiator until that initiator
issues a command to the logical unit other than Request Sense or Inquiry
for which the target reports a CHECK CONDITION status. If the next
command from that initiator to the logical unit (following the CHECK
CONDITION status) is Request Sense, the Unit Attention sense key is
returned. (If any command other than Request Sense is received, the
unit attention condition is lost.)
If an Inquiry Command is received from an initiator with a pending unit
attention condition (before the target reports CHECK CONDITION
status), the target performs the Inquiry Command and does not clear the
unit attention.
If a Request Sense Command is received from an initiator with a pending
unit attention condition (before the target reports a CHECK
CONDITION status), the target discards any pending sense data,
reports a Unit Attention sense key, and clears the unit attention
condition for that initiator.
Chapter 1
1-17
SCSI Command Overview
SCSI Command Overview
Drive Control Commands
SCSI Command Overview
SCSI Commands Used by the Target
SCSI Commands Used by the Target
This section describes detailed functions of each program supported in
the target. Entries are arranged in order of operation code.
Each entry includes:
1. Command name
2. Operation code
3. Brief description of the command
4. Command descriptor block (CDB)
5. Detailed description of the command
Explanation of the Command Descriptor Block (CDB)
The command descriptor block defines the byte and bit layout for each
supported drive command. Chapter 2 contains these specific
descriptions.
Figure 1-1
Example Command Descriptor Block
NOTE
A Reserved field indicates that the field is reserved and must be set to 0
by the initiator.
The Reserved field for returned data contains 0 as well.
1-18
Chapter 1
Drive
Commands
SCSI-2 Drive
Commands
2
SCSI-2 Drive Command Set
Chapter 2
2-1
SCSI-2 Drive Command Set
Numerical List of Commands
Numerical List of Commands
The following tables list the SCSI-2 commands numerically, by group.
Table 2-1
Group 0 Commands (6-byte command)
Code
(hex.)
Name
Description
Page
Number
00H
Test Unit Ready
Provides a means to check if
the logical unit is ready
2-8
01H
Rezero Unit
Moves the optical head to its
recalibration position
2-9
03H
Request Sense
Requests the detailed error
information
2-10
04H
Format Unit
Initializes the optical disk
(done only once for
unformatted Write-Once
disks)
2-15
07H
Reassign Blocks
Reassigns defective sectors
2-19
08H
Read
Reads data from the specified
logical block address
2-21
0AH
Write
Writes data to the specified
logical block address
2-23
0BH
Seek
Moves the optical head to the
physical track where the
specified logical block exists
2-25
12H
Inquiry
Reads the information
related to the controller and
the drive unit
2-26
15H
Mode Select
Sets optical disk, drive unit,
or controller unit parameters
2-31
16H
Reserve
Gains the exclusive control of
a specified logical unit
2-52
2-2
Chapter 2
SCSI-2 Drive Command Set
Numerical List of Commands
Table 2-1
Group 0 Commands (6-byte command)
Name
Description
Page
Number
17H
Release
Releases a specified logical
unit from the reservation
state
2-53
1AH
Mode Sense
Reads optical disk, drive unit,
or controller unit parameters
2-54
1BH
Start/Stop Unit
Starts or stops rotating the
optical disk, and/or ejects the
optical disk from the drive
unit
2-73
1CH
Receive
Diagnostic
Results
Requests analysis data be
sent to the initiator
2-74
1DH
Send Diagnostic
Requests the disk controller
to perform diagnostic tests
2-76
1EH
Prevent/Allow
Medium
Removal
Prevents or allows removal of
the optical disk in the logical
unit
2-79
Chapter 2
2-3
SCSI-2 Drive Commands
Code
(hex.)
SCSI-2 Drive Command Set
Numerical List of Commands
Table 2-2
Group 1 and 2 Commands (10-byte command)
Code
(hex.)
Name
Description
Page
Number
25H
Read Capacity
Reads the capacity of the
optical disk
2-80
28H
Read
Reads data from the specified
logical block address
2-82
2AH
Write
Writes data to the specified
logical block address
2-84
2BH
Seek
Moves the optical head to the
physical track where the
specified logical block exists
2-87
2CH
Erase
Executes erase operation from
the specified logical block
address on rewritable disks
only
2-88
2EH
Write and
Verify
Writes data to the optical disk
and then verifies the written
data by checking the error
correction code
2-90
2FH
Verify
Verifies the data starting from
the specified logical block
address by checking the error
correction code
2-92
34H
Pre-Fetch
Transfers the specified
number of data blocks starting
from the specified logical block
address to cache memory
2-94
35H
Synchronize
Cache
Initiates the writing of all
cached write data to the
optical disk
2-95
37H
Read Defect
Data
Reads the optical disk defect
information
2-96
2-4
Chapter 2
SCSI-2 Drive Command Set
Numerical List of Commands
Table 2-2
Group 1 and 2 Commands (10-byte command)
Name
Description
Page
Number
3BH
Write Buffer
Writes data to the controller
data buffer.
2-99
3CH
Read Buffer
Reads data from the controller
data buffer
2-102
3EH
Read Long
Reads data from the specified
logical block address including
ECC data
2-104
3FH
Write Long
Writes data to the specified
logical block address without
using the ECC generation
circuitry
2-106
4CH
Log Select
Clears drive resident logs and
odometers
2-109
4DH
Log Sense
Reads drive resident logs and
odometers
2-111
55H
Mode Select
Sets optical disk, drive unit, or
controller unit parameters
2-122
Chapter 2
2-5
SCSI-2 Drive Commands
Code
(hex.)
SCSI-2 Drive Command Set
Numerical List of Commands
Table 2-3
Group 5 Commands (12-byte command)
Code
(hex.)
Name
Description
Page
A8H
Read
Reads data from the specified
logical block address
2-128
AAH
Write
Writes data to the specified
logical block address
2-131
ACH
Erase
Executes erase operation from
the specified logical block
address on rewritable disks
only
2-134
AEH
Write and Verify
Writes data to the optical disk
and then verifies the written
data by checking the error
correction code
2-137
AFH
Verify
Verifies the data starting from
the specified logical block
address by checking the error
correction code
2-140
B7H
Read Defect
Data
Reads the optical disk defect
information
2-142
DEH
Read Long
Reads data starting at a
specified logical block address,
including error correction code
data
2-145
DFH
Write Long
Writes data starting at the
specified logical block address,
without using error correction
code generation circuitry
2-147
2-6
Chapter 2
SCSI-2 Drive Command Set
Numerical List of Commands
Flag, Link, and RelAdr
A Link bit of 1 indicates that the drive links to the next command upon
successful completion of the current command. When the command is
terminated successfully, the drive returns the INTERMEDIATE/GOOD
status and the LINKED COMMAND COMPLETE or the LINKED
COMMAND COMPLETE (WITH FLAG) message depending on the state
of the Flag bit. The Flag bit may be set to 1 only when the Link bit is 1. If
this bit is set to 1 with the Link bit, the drive returns the LINKED
COMMAND COMPLETE (WITH FLAG) message upon successful
completion of the command. If this bit is set to 0, it returns the LINKED
COMMAND COMPLETE message.
The Relative Address (RelAdr) bit is set to 1 to indicate that the logical
block address of the command descriptor block is a two's complement
displacement. This negative or positive displacement is added to the
logical block address last accessed on the drive to form the logical block
address for this command.
Chapter 2
2-7
SCSI-2 Drive Commands
Many commands have bits named Flag, Link and RelAdr. The definitions
of these bits are:
SCSI-2 Drive Command Set
Test Unit Ready Command (00H)
Test Unit Ready Command (00H)
This command determines the READY state of a drive. If the drive is in a
READY state when it receives this command, it returns a GOOD status.
A drive is in the READY state when the optical disk is loaded and spun
up, and a read or write operation could successfully complete.
If the drive is not ready when it receives this command, it returns a
CHECK CONDITION with a sense key of NOT READY.
Table 2-4
Test Unit Ready Command CDB
Byte
0
1
6
5
4
3
2
1
0
Flag
Link
Operation Code (00H)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
2-8
7
Reserved (0)
Chapter 2
SCSI-2 Drive Command Set
Rezero Unit Command (01H)
The Rezero Unit Command is identical to the Test Unit Ready Command
(see the previous page).
Table 2-5
Rezero Unit Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Flag
Link
Operation Code (01H)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
Chapter 2
Reserved (0)
2-9
SCSI-2 Drive Commands
Rezero Unit Command (01H)
SCSI-2 Drive Command Set
Request Sense Command (03H)
Request Sense Command (03H)
This command determines the specific error condition when a drive fails
to complete a command and returns a CHECK CONDITION status.
Sense data is preserved for the initiator until retrieved by a Request
Sense Command or until the same drive receives another command.
Internal Error Codes are used to represent the error condition and can be
used to determine what type of error recovery procedure is appropriate.
Table 2-6
Request Sense Command CDB
Byte
0
1
7
6
5
4
3
2
1
Operation Code (03H)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Allocation Length (Table 2-7 on page 2-11)
5
0
Reserved (0)
Flag
Link
The Allocation Length indicates the number of bytes of sense data that
the drive transfers to the initiator. This drive has 22 bytes of sense data.
If an allocation length specified is less, then the allocated amount is
transferred, the remaining sense data is lost, and no error will be
reported. If an allocated length specified is greater, then only 22 bytes of
sense data are transferred and no error will be reported.
2-10
Chapter 2
SCSI-2 Drive Command Set
Request Sense Command (03H)
Sense Data Format
Error Code 70H or 71H Sense Data Format
Byte
7
0
Valid
6
5
4
3
2
0
Reserved (0)
Reserved (0)
ILI
Rsvd (0)
Sense Key
3
Information (MSByte)
4
Information Byte
5
Information Byte
6
Information (LSByte)
7
Additional Sense Length (0EH)
8
Reserved (0)
9
Reserved (0)
10
Reserved (0)
11
Reserved (0)
12
Additional Sense Code
13
Additional Sense Code Qualifier
14
Reserved (0)
15
1
Error Code (70H or 71H)
1
2
SCSI-2 Drive Commands
Table 2-7
SKSV
Sense Key Specific Information
16
Sense Key Specific Information
17
Sense Key Specific Information
18
Internal Error Code (MSByte)
19
Internal Error Code
20
Internal Error Code
21
Internal Error Code (LSByte)
Chapter 2
2-11
SCSI-2 Drive Command Set
Request Sense Command (03H)
Valid
A Valid bit of 1 indicates the information field contains
valid information.
A Valid bit of 0 indicates that the information field does
not contain valid data.
Error Code
An Error Code of 70H indicates that the CHECK
CONDITION status returned is the result of an I/O
process that returned CHECK CONDITION status.
An Error Code of 71H indicates that the CHECK
CONDITION status returned is the result of an error
occurring during a previous command that returned
GOOD status.
ILI
An Incorrect Length Indicator bit of 1 usually indicates
that the requested logical block length did not match
the logical block length of the data on the medium.
Information
If the Valid bit is set to 1, the Information Bytes contain
one of the following:
(1) The logical block address associated with the sense
key.
(2) The difference (residue) of the requested length
minus the actual length in bytes, as determined by the
command, when the ILI bit is set.
SKSV
A Sense Key Specific Valid bit of 1 indicates that the
Sense Key Specific Information is valid.
A SKSV bit of 0 indicates that there is no sense key
specific information.
Sense Key Specific
Information
If the Sense Key is set to 5-Illegal Request and the
SKSV bit is set to 1, the sense key specific field is
defined in Table 2-8 on page 2-13.
If the Sense Key is set to 2-(Not Ready) and the
Additional Sense Code/Additional Sense Code Qualifier
is set to 04/04-(Logical Unit Not Ready, Format in
Progress) and the SKSV bit is set to 1, the sense key
specific field is defined in Table 2-9 on page 2-14.
2-12
Chapter 2
SCSI-2 Drive Command Set
Request Sense Command (03H)
Field Pointer Types
Sense Key Field Pointer Types
Byte
7
6
15
SKSV
(1)
C/D
5
4
Reserved (0)
3
BPV
16
Field Pointer (MSByte)
17
Field Pointer (LSByte)
C/D
2
1
0
Bit Pointer
A Command Data bit of 1 indicates that the illegal
parameter is in the CDB.
A Command Data bit of 0 indicates that the illegal
parameter is in the data sent by the initiator during the
Data-Out phase.
BPV
A Bit Pointer Valid bit of 1 indicates that the Bit Pointer
field specifies which bit of the byte designated by the
Field Pointer field is in error.
A Bit Pointer Valid bit of 0 indicates that the Bit Pointer
field is not valid.
NOTE
Bit Pointer
When the Bit Pointer Valid bit is 1, the Bit Pointer field
specifies which bit of the byte designated by the Field
Pointer field is in error. When a multiple-bit field is in
error, the pointer points to the most significant byte of
the field.
Field Pointer
The Field Pointer indicates which byte of the command
descriptor block or the parameter data was in error.
Bytes are numbered starting from 0. When a multiplebyte field is in error, the pointer points to the mostsignificant byte of the field.
Bytes identified as being in error are not necessarily the bytes that need
to be changed to correct the problem.
Chapter 2
2-13
SCSI-2 Drive Commands
Table 2-8
SCSI-2 Drive Command Set
Request Sense Command (03H)
Table 2-9
Progress Indication Field Bytes
Byte
7
15
SKSV
(1)
6
5
4
3
2
0
Reserved (0)
16
Progress Indication (MSByte))
17
Progress Indication (LSByte)
Progress
Indication
1
The progress indication field value is a percent complete
indication in which the returned value is the numerator
that has 10000H as its denominator.
Internal Error
Code
The Internal Error Code provides detailed information
about the failure.
2-14
Chapter 2
SCSI-2 Drive Command Set
Format Unit Command (04H)
This command is used to initialize the optical disk surface.
NOTE
The format parameters may be set using the Mode Select Commands
(15H or 55H) before executing the Format Unit Command.
Table 2-10
Format Unit Command CDB
Byte
7
6
0
5
4
3
Reserved (0)
2
FmtDta
CmpLst
Reserved (0)
3
Reserved (0)
4
Reserved (0)
NOTE
1
0
Operation Code (04H)
1
5
2
Rsvd
ErsCntl
Reserved (0)
Defect List Format
MkCDA
MkPlst
Flag
Link
The 9.1 and 5.2 Gbyte capacity drives cannot Format, Erase, Write, or
Write and Verify 650 Mbyte and 1.3-Gbyte optical disks.
The 2.6 Gbyte capacity drives cannot Format, Erase, Write, or Write and
Verify 650 Mbyte optical disks.
If this command is issued with any of these drive/media combinations, a
CHECK CONDITION status will result with the Sense Key/Additional
Sense Code set to Data Protect/Write Protected.
FmtDta
A Format Data bit of 1 indicates that the command
includes a Data Out Phase consisting of a 4-byte Defect
List Header.
A FmtDta bit of 0 indicates that the command does not
include a Data Out Phase.
Chapter 2
2-15
SCSI-2 Drive Commands
Format Unit Command (04H)
SCSI-2 Drive Command Set
Format Unit Command (04H)
CmpLst
A Complete List bit of 1 indicates that the previous
G-list is not used to make the defect list.
A CmpLst bit of 0 indicates the previous G-list is added
to the defect list.
Defect List
Format
The Defect List Format can be either Block Format (0)
or Physical Sector Format (5).
MkCDA
Has no effect on the drive.
MkPlst
Has no effect on the drive.
ErsCntl
An Erase Control bit of 0 indicates that an erase is
automatically performed before writing the data when
the drive is directed to perform the certify operation by
the initiator.
An Erase Control bit of 1 suppresses the erase
operation.
NOTE
For Write-Once, this command can be executed only once during the
lifetime of a disk. When an initiator attempts to execute the Format Unit
command more than once for write-once media a CHECK CONDITION
status is returned. The Sense Key/Additional Sense Code is set to
ILLEGAL REQUEST/Invalid Command Operation Code.
2-16
Chapter 2
SCSI-2 Drive Command Set
Format Unit Command (04H)
Format Unit Command Defect List
Table 2-11
Format Unit Defect List Header
Byte
7
6
5
0
1
4
3
2
1
0
Immed
Rsvd
(0)
Reserved (0)
FOV
Rsvd
(0)
DCRT
Reserved (0)
2
Defect List Length (MSByte)
3
Defect List Length (LSByte)
FOV
A Format Options Valid bit of 1 indicates that the DCRT
(Disable Certification) and Immed (Immediate) fields
contain valid information.
A FOV bit of 0 indicates that the DCRT and Immed
fields do not contain valid information.
DCRT
A Disable Certification bit of 1 indicates the drive does
not certify the optical disk during the format process.
A DCRT bit of 0 indicates that the drive certifies the
optical disk during the format process.
When the FOV bit is set to 0, the DCRT bit must also be
set to 0.
DCRT does not apply to Write-Once disks.
Immed
When the Immediate bit is set to 1, it indicates a status
of GOOD is returned before the format operation is
begun.
An Immed bit of 0 indicates a GOOD status is returned
when the format is complete.
Defect List
Length
Chapter 2
The Defect List Length is the total length in bytes of the
Defect Descriptors that follow.
2-17
SCSI-2 Drive Commands
The Format Unit command Defect List consists of the Defect List Header
and zero or more multi-byte Defect Descriptor(s).
SCSI-2 Drive Command Set
Format Unit Command (04H)
Table 2-12
Physical Sector Format Defect Descriptor
Byte
Table 2-13
7
6
5
4
3
2
0
Track Number of Defect (MSByte)
1
Track Number of Defect
2
Track Number of Defect (LSByte)
3
Reserved (0)
4
Reserved (0)
5
Reserved (0)
6
Reserved (0)
7
Sector Number of Defect
1
0
1
0
Block Format Defect Descriptor
Byte
7
6
5
4
3
2
0
Reserved (0)
1
Defect Block Address (MSByte)
2
Defect Block Address
3
Defect Block Address (LSByte)
2-18
Chapter 2
SCSI-2 Drive Command Set
Reassign Blocks Command (07H)
This command reassigns defective sectors. A defect list containing the
Logical Block Addresses to be reassigned is transferred to the drive.
Data in the defective sector is moved to the replacement sector.
Table 2-14
Reassign Blocks Command CDB
Byte
7
6
5
0
1
4
3
2
1
0
Flag
Link
Operation Code (07H)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
Reserved (0)
Reassign Blocks Command Defect List
The Reassign Blocks command defect list is made up of a 4-byte Defect
List Header and zero or more 4-byte Defect Descriptor blocks.
Table 2-15
Reassign Blocks Command Defect List Header
Byte
7
6
5
4
3
2
0
Reserved (0)
1
Reserved (0)
2
Defect List Length (MSByte)
3
Defect List Length (LSByte)
Chapter 2
1
0
2-19
SCSI-2 Drive Commands
Reassign Blocks Command (07H)
SCSI-2 Drive Command Set
Reassign Blocks Command (07H)
Defect List
Length
Table 2-16
The Defect List Length is the total length in bytes of the
Defect Descriptors that follow.
Reassign Blocks Command Defect Descriptor
Byte
7
6
6
4
3
2
1
0
Reserved (0)
1
Defective Block Logical Address (MSByte)
2
Defective Block Logical Address
3
Defective Block Logical Address (LSByte)
0
Each defective sector is decoded to a physical block address and that
physical sector is added to the SDL (Secondary Defect List).
2-20
Chapter 2
SCSI-2 Drive Command Set
Read (Group 0) Command (08H)
This command reads data from the specified logical block address. A
maximum length of 256 logical blocks can be read using the Group 0
Read Command. If the number of logical blocks exceeds 256, use the
Group 1 Read command.
NOTE
The Mode Select Commands (15H or 55H) impact all read, write, format
and erase commands.
Table 2-17
Read (Group 0) Command CDB
Byte
7
0
1
6
5
4
3
2
1
Operation Code (08H)
Logical Unit Number (0)
Starting Logical Block Address (MSByte)
2
Starting Logical Block Address
3
Starting Logical Block Address (LSByte)
4
Transfer Length
5
0
PBA
Transfer
Length
PBA
Chapter 2
Reserved (0)
Flag
Link
The Transfer Length field specifies the number of
contiguous logical blocks of data to be read. A Transfer
Length of 0 specifies that 256 logical blocks are to be
read. Any other value specifies the number of logical
blocks to be read.
A Physical Block Address bit of 1 indicates that physical
block addressing is used. A PBA bit of 0 indicates that
logical block addressing is used.
2-21
SCSI-2 Drive Commands
Read (Group 0) Command (08H)
SCSI-2 Drive Command Set
Read (Group 0) Command (08H)
NOTE
When this command is used with 512 byte/sector 4X/ 8X/14X media, 1024
byte/sector 8X/14X media, or 2048 14X media, it is not possible to address
all logical blocks on the disk because those media types contain >221
logical blocks.
NOTE
When this command is used with 14X 512 or 1024 byte/sector media,
setting the PBA bit will cause the drive to return a CHECK CONDITION
status. The sense key/additional sense code will be set to ILLEGAL
REQUEST/INVALID FIELD in CDB.
2-22
Chapter 2
SCSI-2 Drive Command Set
Write (Group 0) Command (0AH)
This command writes data starting at the specified logical block address.
NOTE
The Mode Select Commands (15H or 55H) impact all read, write, format
and erase commands.
Table 2-18
Write (Group 0) Command CDB
Byte
7
6
0
1
4
3
2
1
0
Operation Code (0AH)
Logical Unit Number
(0)
Starting Logical Block Address
(MSByte)
2
Starting Logical Block Address
3
Starting Logical Block Address (LSByte)
4
Transfer Length
5
NOTE
5
PBA
Ers
Cntl
Reserved (0
Flag
Link
The 9.1 and 5.2 Gbyte capacity drives cannot Format, Erase, Write, or
Write and Verify 650 Mbyte and 1.3-Gbyte optical disks.
The 2.6 Gbyte capacity drives cannot Format, Erase, Write, or Write and
Verify 650 Mbyte optical disks.
If this command is issued with any of these drive/media combinations, a
CHECK CONDITION status will result with the Sense Key/Additional
Sense Code set to Data Protect/Write Protected.
NOTE
For Write-Once media, byte 5, bit 6 and bit 7 are reserved.
Chapter 2
2-23
SCSI-2 Drive Commands
Write (Group 0) Command (0AH)
SCSI-2 Drive Command Set
Write (Group 0) Command (0AH)
Transfer Length The Transfer Length field specifies the number of
contiguous logical blocks of data to be written. A
Transfer Length of 0 specifies that 256 logical blocks are
to be written.
PBA
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
ErsCntl
If the Erase Control bit is set to 0, an erase is
automatically performed before writing the data.
An Erase Control bit of 1 suppresses the erase
operation.
NOTE
When this command is used with 512 byte/sector 4X/ 8X/14X media, 1024
byte/sector 8X/14X media, or 2048 14X media, it is not possible to address
all logical blocks on the disk because those media types contain >221
logical blocks.
NOTE
For write-once optical disks, blank checking is performed before writing
data. If a written block is detected during blank checking, the drive will
return a CHECK CONDITION status. The sense key/additional sense
code will be set to BLANK CHECK/Overwrite Attempted.
NOTE
When this command is used with 14X 512 OR 1024 byte/sector media,
setting the ErsCntl bit or the PBA bit will cause the drive to return a
CHECK CONDITION status. The sense key/additional sense code will be
set to ILLEGAL REQUEST/INVALID FIELD in CDB.
2-24
Chapter 2
SCSI-2 Drive Command Set
Seek (Group 0) Command (0BH)
This command seeks the optical head to the physical track where the
specified logical block exists.
Table 2-19
Seek (Group 0) Command CDB
Byte
7
0
1
6
5
4
3
2
0
Operation Code (0BH)
Logical Unit Number
(0)
Logical Block Address (MSByte)
2
Logical Block Address
3
Logical Block Address (LSByte)
4
Reserved (0)
5
1
PBA
PBA
Reserved (0)
Flag
Link
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
NOTE
When this command is used with 512 byte/sector 4X/ 8X/14X media, 1024
byte/sector 8X/14X media, or 2048 14X media, it is not possible to address
all logical blocks on the disk because those media types contain >221
logical blocks.
NOTE
When this command is used with 14X 512 or 1024 byte/sector media,
setting the PBA bit will cause the drive to return a CHECK CONDITION
status. The sense key/additional sense code will be set to ILLEGAL
REQUEST/INVALID FIELD in CDB.
Chapter 2
2-25
SCSI-2 Drive Commands
Seek (Group 0) Command (0BH)
SCSI-2 Drive Command Set
Inquiry Command (12H)
Inquiry Command (12H)
This command sends controller and drive information to the initiator.
Table 2-20
Inquiry Command CDB
Byte
7
6
5
0
1
4
3
1
0
Operation Code (12H)
Logical Unit
Number (0)
Reserved (0)
2
VPD Identifier
3
Reserved (0)
4
Allocation Length
5
2
Reserved (0)
EVPD
Flag
Link
EVPD
(8X and 14X only). An enable vital product data bit of
1 specifies that the drive shall return the optional vital
product data specified by the page code field. An enable
vital product data bit of 0 specifies that the drive shall
return the standard INQUIRY data.
Page Code
The page code field specifies which page of vital product
data information the drive shall return (Table 2-21).
Allocation
Length
This field specifies the number of bytes that the
initiator has allocated for the return data. An Allocation
Length of 0 is not an error and indicates that no data
will be returned. The initiator will terminate the data in
phase when all available inquiry data has been
returned or when allocation length bytes have been
returned, whichever is less.
If an inquiry command is received from an initiator with
a pending UNIT ATTENTION (before the drive reports
CHECK CONDITION status), the drive performs the
INQUIRY command and does not clear the UNIT
ATTENTION condition.
2-26
Chapter 2
SCSI-2 Drive Command Set
Inquiry Command (12H)
Table 2-22
Vital Product Data Page Codes
Page Code
Description
00H
Supported Vital Product Data Pages
80H
Unit Serial Number Page
C1H
Unique Media ID (UMID) Page
Supported Vital Product Data Pages (00H)
Byte
0
Table 2-23
SCSI-2 Drive Commands
Table 2-21
7
6
5
4
Peripheral Qualifier
3
2
1
0
Peripheral Device Type
1
Page Code (00H)
2
Reserved (0)
3
Page Length (03H)
4
First Supported VPD Page (00H)
5
Second Supported VPD Page (80H)
6
Third Supported VPD Page (C1H)
Unit Serial Number Page (80H)
Byte
0
7
6
5
Peripheral Qualifier
4
3
2
1
Peripheral Device Type
1
Page Code (80H)
2
Reserved (0)
3
Page Length (0AH)
4-13
Product Serial Number (10 ASCII characters)
Chapter 2
0
2-27
SCSI-2 Drive Command Set
Inquiry Command (12H)
Table 2-24
Unique Media ID Page (C1H)
Byte
0
7
6
5
Peripheral Qualifier
4
3
2
1
0
Peripheral Device Type
1
Page Code (C1H)
2
Reserved (0)
3
Page Length (08H)
4-5
Unique Media ID Bytes 1-2
6-8
Unique Media ID Bytes 3-5
9-11
Unique Media ID Bytes 6-8
The Unique Media ID Bytes 1-2 field is “HP” in ASCII.
The Unique Media ID Bytes 3-5 field is a three-byte binary
representation of the serial number of the drive which wrote the UMID
on the media.
The Unique Media ID Bytes 6-8 field is a three-byte random number.
2-28
Chapter 2
SCSI-2 Drive Command Set
Inquiry Command (12H)
Byte
0
Inquiry Command Returned Data
7
6
5
4
Peripheral Qualifier
1
RMB
(1)
2
ISO Version (0)
3
2
Device Type Modifier (0)
ECMA Version (0)
ANSI-Approved Version (2)
Response Data Format (2)
4
Additional Sense Length (33H)a
5-6
Reserved (0)
RelAdr
(1)
0
Peripheral Device Type
3
7
1
WBus32
(0)
WBus16
(0)
Sync
(1)
Linked
(1)
Rsvd
(0)
Cmd
Que (1)
8-15
Vendor Identification “HP~~~~~~” (ASCII)b
16-31
Product Identification “C1113J~~~~~~~~~~” (ASCII)b
(“C1113F~~~~~~~~~~” for 2.6 Gbyte capacity drives)
32-35
Product Revision Level (Current firmware version in ASCII)
36-39
Manufacturing Date Code (Current ASCII data)
40-49
Serial Number (Current ASCII data)
50-55
Drive Identifier “8XMO~~” (ASCII)b
(“4XMO~~” for 2.6 Gbyte capacity drives)
SftRe
(0)
a.This field is always 33H.
b.The ~ represents blank spaces.
Chapter 2
2-29
SCSI-2 Drive Commands
Table 2-25
SCSI-2 Drive Command Set
Inquiry Command (12H)
NOTE
If the drive is properly connected and responds to SCSI selection, the
Peripheral Qualifier field is set to 000. If Direct Access Inquiry Response
(DAIR) has been enabled, the Peripheral Device Type field is set 00H,
(Direct Access Device). Otherwise, the Peripheral Device Type field is set
to 07H (Optical Memory Device). Because the drive does not support
logical unit 1 through 7, an Inquiry command to these logical units always
returns 011 for the Peripheral Qualifier and 1FH (Unknown Device Type)
for the Peripheral Device Type.
RMB
Device Type
Modifier
The Removable Media Bit is set to 1 for removable
optical disks. The drive only supports removable optical
disks, so this bit is always 1.
The drive is not using the Device Type Modifier field
and will return 0.
ISO, ECMA and
ANSI-Approved
Versions
Approved Version fields indicate compliance of the
current firmware to these standards.
Additional Sense
Length
This field indicates the length in bytes of the additional
parameters. This field is always 33H.
RelAdr
The Relative Addressing bit is set to 1, which indicates
that the drive supports relative addressing mode.
WBus32
The Wide Bus 32 bit of 0 indicates that the drive
supports only 8-bit wide data transfers.
WBus16
The Wide Bus 16 bit of 0 indicates that the drive
supports only 8-bit wide data transfers.
Sync
The Synchronous transfer bit of 1 indicates that the
drive supports synchronous data transfer.
Linked
The Linked command bit of 1 indicates that the drive
supports linked commands.
CmdQue
The Command queuing bit of 1 indicates that the drive
supports tagged command queuing.
SftRe
The Soft Reset bit of 0 indicates that the drive responds
to the RESET condition with the hard RESET.
2-30
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
This command sets optical disk and drive parameters for read, write,
format, and erase commands.
Table 2-26
Mode Select (Group 0) Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (15H)
Logical Unit Number
(0)
PF (1)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Parameter List Length (Table 2-27 on page 2-32)
5
SP
Reserved (0)
Flag
SP
Link
A Save Pages bit of 1 indicates that the target performs
the specified MODE SELECT operation, and saves all
the savable pages to non-volatile RAM.
An SP bit of 0 indicates the target performs the specified
MODE SELECT operation, and does not save any
pages.
Parameter List
Length
This byte indicates the number of bytes of parameter
data being transferred during the DATA OUT phase,
including the header. A length of 0 indicates that no
data will be transferred.
Chapter 2
2-31
SCSI-2 Drive Commands
Mode Select Command (15H)
SCSI-2 Drive Command Set
Mode Select Command (15H)
Table 2-27
Mode Page Codes
Page Code
Parameter
List Length
Description
01H
12
Read-Write Error Recovery Page
(See Table 2-30 on page 2-34)
02H
16
Disconnect-Reconnect Page
(See Table 2-31 on page 2-36)
08H
12
Caching Page
(See Table 2-32 on page 2-37)
0AH
8
Control Mode Page
(See Table 2-33 on page 2-39)
0BH
8
Medium Type Supported
(See Table 2-35 on page 2-40)
20H
12
Vendor Unique Format Page
(See Table 2-37 on page 2-42)
21H
12
Vendor Unique Page
(See Table 2-41 on page 2-46)
The Mode Select Parameter List contains a 4-byte header, followed by 0
or 1 block descriptors and 0 or more pages.
A Mode Page of 00H will be rejected and no error will be reported.
2-32
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
Mode Select Header
SCSI-2 Drive Commands
Table 2-28
Mode Select Header
Byte
7
6
5
4
3
2
0
Reserved (0)
1
Medium Type
2
Reserved (0)
3
Block Descriptor Length
1
0
The Medium Type field shall be set to 00H (Default, only one medium
type supported), 02H (Write-once medium), or 03H (Optical Reversible or
Erasable medium). The Block Descriptor Length specifies the length in
bytes of the block descriptor. It shall be equal to 0 or 8. A Block
Descriptor Length of zero indicates that the block descriptor is not
included in the parameter list. This condition is not considered to be an
error.
Table 2-29
Mode Select Block Descriptor
Byte
NOTE
7
6
5
4
3
2
0
Density Code
1
Number of Blocks (MSByte)
2
Number of Blocks
3
Number of Blocks (LSByte)
4
Reserved (0)
5
Block Length (MSByte)
6
Block Length
7
Block Length (LSByte)
1
0
All fields in the Block Descriptor have no effect on the drive.
Chapter 2
2-33
SCSI-2 Drive Command Set
Mode Select Command (15H)
Read-Write Error Recovery
Table 2-30
Read-Write Error Recovery Page 01H
Byte
0
7
6
5
Reserved (0)
3
1
0
DTE
DCR
Page Length (0AH)
AWRE
Rsvd
(0)
TB
RC
Rsvd
(0)
3
Read Retry Count
4-7
Reserved (0)
8
Write Retry Count
9-11
Reserved (0)
AWRE
3
Page Code (01H)
1
2
4
PER
An Automatic Write Reallocation Enable bit of 1
enables the automatic reallocation of defective sectors
during the write operation of the Write commands
(0AH, 2AH, AAH), Write and Verify commands (2EH,
AEH), and Write Long (3FH, DFH).
For rewritable disks, automatic reallocation of defective
sectors occurs during these additional erase operations:
Erase 2CH and Erase ACH.
NOTE
AWRE cannot be disabled on Write-Once media.
TB
A Transfer Block bit of 1 indicates that a data block that
is not recovered within the recovery limits specified is
transferred to the initiator before CHECK CONDITION
status is returned.
A TB bit of 0 indicates that such a data block is not
transferred to the initiator.
RC
A Read Continuous bit of 1 indicates that error
correction codes are not used for data error recovery.
A Read Continuous bit of 0 allows the use of error
correction codes for data error recovery.
2-34
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
PER
A PER bit of 0 indicates that the target does not report
recovered errors.
DTE
A Disable Transfer on Error bit of 1 indicates that the
target terminates the data phase upon detection of a
recovered error.
A DTE bit of 0 indicates that the target does not
terminate the data phase upon detection of a recovered
error.
DCR
A Disable Correction bit of 1 indicates that error
correction codes are not used for data error recovery.
A DCR bit of 0 allows the use of error correction codes
for data error recovery.
Read Retry
Count
Write Retry
Count
Chapter 2
The Read Retry Count field specifies the number of
times the target attempts recovery of a read operation
before reporting an error.
The Write Retry Count field specifies the number of
times the target attempts recovery of a write operation
before reporting an error.
2-35
SCSI-2 Drive Commands
A Post Error bit of 1 indicates that the target reports
recovered errors.
SCSI-2 Drive Command Set
Mode Select Command (15H)
Disconnect-Reconnect
The disconnect-reconnect page provides the initiator the means to tune
the performance of the SCSI bus.
Table 2-31
Disconnect-Reconnect Page 02H
Byte
0
7
6
Reserved (0)
5
4
3
2
1
0
Page Code (02H)
1
Page Length (0EH)
2
Buffer Full Ratio
3
Buffer Empty Ratio
4-9
Reserved (0)
10
Maximum Burst Size (MSByte)
11
Maximum Burst Size (LSByte)
12-15
Reserved (0)
Buffer Full
Ratio
This field has no effect on the drive.
Buffer Empty
Ratio
This field has no effect on the drive.
Maximum Burst
Size
This field indicates the maximum amount of data that
the target transfers during a data phase before
disconnecting if the initiator has granted the disconnect
privilege. This value is expressed in increments of 512
bytes (e.g. a value of one means 512 bytes, two means
1024 bytes, etc.). A value of zero indicates there is no
limit on the amount of data transferred per connection.
2-36
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
Caching Page 08H
Table 2-32
Caching Page 08H
Byte
0
7
5
4
Reserved (0)
1
2
NOTE
6
3
2
1
0
MF
RCD
Page Code (08H)
Page Length (0AH)
Reserved (0)
WCE
3
Reserved (0)
4
Disable Pre-fetch Transfer Length (MSByte)
5
Disable Pre-fetch Transfer Length (LSByte)
6
Minimum Pre-fetch (MSByte)
7
Minimum Pre-fetch (LSByte)
8
Maximum Pre-fetch (MSByte)
9
Maximum Pre-fetch (LSByte)
10
Maximum Pre-fetch Ceiling (MSByte)
11
Maximum Pre-fetch Ceiling (LSByte)
With write caching enabled, data integrity of the information in the buffer
is not guaranteed through power cycling.
WCE
A Write Cache Enable bit of 1 indicates write caching is
enabled.
A Write Cache Enable bit of 0 indicates write caching is
disabled.
RCD
A Read Cache Disable bit of 1 indicates read ahead is
disabled.
A Read Cache Disable bit of 0 indicates read ahead is
enabled.
Chapter 2
2-37
SCSI-2 Drive Commands
The caching parameters table defines the parameters that affect the use
of the cache.
SCSI-2 Drive Command Set
Mode Select Command (15H)
MF
The Multiplication Factor bit is set to 1 and cannot be
changed. This bit is used with the Minimum and
Maximum Pre-fetch fields during READ operations. If
this bit is set to 0 by the MODE SELECT command, a
CHECK CONDITION status is returned with the sense
key/additional sense code set to ILLEGAL REQUEST/
Invalid Parameter List.
Disable Pre-fetch
Transfer
Length
This field sets the threshold value for pre-fetching data
during reads. If the number of blocks to be read is
greater than this value, no pre-fetching occurs.
Minimum
Pre-fetch
Maximum
Pre-fetch
Maximum
Pre-fetch
Ceiling
2-38
The default value is 1 and cannot be changed. If this bit
is set to 0 by the MODE SELECT command, a CHECK
CONDITION status is returned with the Sense Key/
Additional Sense Code set to Illegal Request/Invalid
Parameter List. Since the MF bit is 1 and the Minimum
Pre-fetch bit is also 1, the Minimum Pre-fetch size is
equal to the READ transfer length. This field does not
affect the operation of the drive.
The default value is 1 and cannot be changed. If this bit
is set to 0 by the MODE SELECT command, a CHECK
CONDITION status is returned with the Sense Key/
Additional Sense Code set to Illegal Request/Invalid
Parameter List. Since the MF bit is 1 and the Maximum
Pre-fetch bit is also 1, the Maximum Pre-fetch size is
equal to the READ transfer length. This field does not
affect the operation of the drive.
The Maximum Pre-fetch Ceiling field does not affect the
operation of the drive and can be set to 32 or 64. If
another value is set, a CHECK CONDITION status is
returned with the Sense Key/Additional Sense Code set
to Illegal Request/Invalid Parameter List.
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
Control Mode Page 0AH
Control Mode Page 0AH
Byte
0
7
6
5
4
Reserved (0)
3
2
Page Length (06H)
2
Reserved (0)
Queue Algorithm Modifiera
4-7
0
Page Code (0AH)
1
3
1
Reserved
DQue
Reserved (0)
a.For 9.1 and 5.2 Gbyte Capacity drives only.
Queue Algorithm
Modifier
The queue algorithm modifier field specifies restrictions
on the algorithm used for reordering commands that are
tagged with the Simple Queue Tag message.
DQue
A Disabled Queuing bit of 1 indicates that command
queuing is disabled.
A Disabled Queuing bit of 0 indicates command queuing
is enabled.
Table 2-34
Queue Algorithm Modifier
Value
Definition
0H
Restricted reordering
01H
Unrestricted reordering allowed
2H - 0FH
Reserved
A value of zero (0) in this field specifies that the target will order the
actual execution sequence of the commands with a SIMPLE QUEUE
TAG such that data integrity is maintained for that initiator.
A value of one (1) in this field specifies that the target may reorder the
actual execution of the commands with a SIMPLE QUEUE TAG in any
manner.
Chapter 2
2-39
SCSI-2 Drive Commands
Table 2-33
SCSI-2 Drive Command Set
Mode Select Command (15H)
Medium Types Supported Page 0BH
Table 2-35
Medium Types Supported Page 0BH
Byte
0
7
6
5
Reserved (0)
4
3
2
1
0
Page Code (0BH)
1
Page Length (06H)
2
Reserved (0)
3
Reserved (0)
4
Medium Type One Supported
(02H — Optical Write-once Medium)
5
Medium Type Two Supported
(03H — Optical Erasable Medium)
6
Medium Type Three Supported (00H)
7
Medium Type Four Supported (00H)
The medium types supported page contains a list of the medium types
implemented by the target for logical units.
The code values for each medium type supported by the target (up to four
maximum) and defined in the MODE SELECT command are reported in
ascending order.
If only the default medium type is supported, 0 is reported. If less than
four medium types are supported, the unused entries are returned as 0.
2-40
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
Valid Medium Type Combinations
Byte
Field
Name
Setting
1
(default)
Setting
2
Setting
3
Setting
4
4
Medium
Type 1
Supported
02H
00H
02H
03H
5
Medium
Type 2
Supported
03H
00H
00H
00H
6
Medium
Type 3
Supported
00H
00H
00H
00H
7
Medium
Type 4
Supported
00H
00H
00H
00H
00H
Default Rewritable optical disks only
02H
Write-Once medium
03H
Rewritable medium
Chapter 2
SCSI-2 Drive Commands
Table 2-36
2-41
SCSI-2 Drive Command Set
Mode Select Command (15H)
Vendor Unique Format Page 20H
Table 2-37
Vendor Unique Format Page 20H
Byte
0
NOTE
7
6
Reserved (0)
5
4
3
2
1
0
Page Code (20H)
1
Page Length (0AH)
2
Format Mode
3-11
Format Type Specific Data
The drive supports Format Mode 03H and 04H.
Format Mode 03H is for 650-Mbyte optical disks
Format Mode 04H is for 1.3-, 2.6-, 5.2-, and 9.1-Gbyte optical disks.
2-42
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
Format Mode 03H
Table 2-38
Format Mode 03H - Type 0
Byte
7
6
5
4
3
2
2
Format Mode (03H)
3
Type 00H
4
Size of User Band (MSByte)
5
Size of User Band
6
Size of User Band
7
Size of User Band (LSByte)
8
Size of Spare Band (MSByte)
9
Size of Spare Band (LSByte)
10
Number of Bands (MSByte)
11
Number of Bands (LSByte)
Size of User
Band
Size of Spare
Band
Number of
Bands
Chapter 2
1
0
The Size of User Band field indicates the length of each
user band in number of logical blocks.
The Size of Spare Band field indicates the length of each
spare band in number of logical blocks.
The Number of Bands field indicates the bands on the
disk. The drive can read and write multi-band
formatted disks, but can create only single-band disks.
2-43
SCSI-2 Drive Commands
Format Mode 03H supports two types of format (type 0 and type 1) by
setting byte 3.
SCSI-2 Drive Command Set
Mode Select Command (15H)
Table 2-39
Format Mode 03H - Type 1
Byte
7
6
5
4
3
2
2
Format Mode (03H)
3
Type 01H
4
Reserved (0)
5
Reserved (0)
6
Number of Bands (MSByte)
7
Number of Bands (LSByte)
8
Size of Spare Bands (MSByte)
9
Size of Spare Bands (LSByte)
10
Reserved (0)
11
Reserved (0)
1
0
Type 1 format exists for compatibility. An initiator cannot change the
parameters of this page.
Number of
Bands
Size of Spare
Band
2-44
The Number of Bands field indicates the bands on the
disk.
The Size of User Band field indicates the length of each
spare band in number of logical blocks.
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
Format Mode 04H
Byte
7
5
4
3
2
2
Format Mode (04H)
3-9
Reserved (0)
10
Number of Bands (MSByte)
11
Number of Bands (LSByte)
Number of
Bands
NOTE
6
1
SCSI-2 Drive Commands
Table 2-40
0
The Number of Bands field indicates the bands on the
disk and can be set to 1 (01H), 16 (10H), 30 (1EH), or 34
(22H).
The Number of Bands for 9.1 and 5.2 Gbyte Capacity drives include
1 (01H), 16 (10H), 24 (18H), 30 (1EH), 34 (22H), 38 (26H), or 45 (2DH).
Chapter 2
2-45
SCSI-2 Drive Command Set
Mode Select Command (15H)
Vendor Unique Page 21H
Table 2-41
Byte
0
Vendor Unique Page 21H
7
6
5
4
Reserved (0)
3
2
1
0
Page Code (21H)
1
Page Length (0AH)
2
Reserved (0)
DAIR
3
DWR
Quick
Disconnect
Rsvd (0)
Force
Verify
4
S1-8
S1-7
S1-6
S1-5
S1-4
S1-3
S1-2
S1-1
5
S2-8
S2-7
S2-6
S2-5
S2-4
S2-3
S2-2
S2-1
DOM
FWC
6
Reserved (0)
Reserved (0)
7-11
Reserved (0)
DAIR
A Direct Access Inquiry Response bit of 1 indicates the
Peripheral Device Type field in the Inquiry Data
indicates "Direct Access Device."
A DAIR bit of 0 indicates "Optical Memory Device" in
the Peripheral Device Type field in the Inquiry Data.
DWR
A Disable Write Reordering bit of 1 indicates write
reordering is not enabled.
A DWR bit of 0 indicates write reordering is enabled.
Quick
Disconnect
A Quick Disconnect bit of 1 enables SCSI bus
disconnection before command validation on
performance path commands (i.e. reads, writes).
A Quick Disconnect bit of 0 disables SCSI bus
disconnection before validation on performance path
commands.
2-46
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
Force Verify
A Force Verify bit of 0 indicates normal operation.
NOTE
Bytes 4 and 5
Bytes 4 and 5 are used to read the setting of the DIP
switches on the drive. SX-Y refers to the setting of DIP
switch S50X-Y (see Figure 2-1 on page 2-51 and
Table 2-44 on page 2-51). If SX-Y=0, the switch is set to
the OFF position; if SX-Y=1, the switch is set to the ON
position. These fields are not changeable. The switch
setting value overrides the saved value.
DOM
A drive operating mode of 0 indicates that the drive is
installed in a jukebox environment. A DOM bit of 1
indicates that the drive is installed in a stand-alone
environment.
The DOM bit is not selectable using the Mode Select command.
FWC
NOTE
A Force Write Calibration bit of 1 instructs the drive to
perform the Write Calibration routine at spin-up. A
Force Write Calibration bit of 0 instructs the drive to
perform the Write Calibration routine on receipt of the
first Write command or 5 minutes after spin-up.
The bits DAIR and Force Verify on this mode page can also be controlled
in HP products by changing external switch settings. In HP’s standalone
box products, this is accomplished by changing the thumb wheel settings
on the rear of the box. In HP’s library products, this is accomplished by
changing the front panel settings. In all cases, changes to the mode page
settings will override the external switch settings.
Chapter 2
2-47
SCSI-2 Drive Commands
A Force Verify bit of 1 indicates all write operations are
verified. The Write 6-, 10-, and 12-byte commands
operate as if they were Write Verify 6-, 10-, and 12-byte
commands.
SCSI-2 Drive Command Set
Mode Select Command (15H)
Mode Page Parameter Default Values
The default values of the Mode Page Parameters are as follows:
Table 2-42
Mode Page Parameter Default Values
Page
Field
Default Value
01H
AWRE
1
01H
TB
0
01H
RC
0
01H
PER
0
01H
DTE
0
01H
DCR
0
01H
Read Retry Count
5
01H
Write Retry Count
5
02H
Buffer Full Ratio
20H
02H
Buffer Empty Ratio
20H
02H
Maximum Burst Size
20H
08H
WCE
1
08H
MF
1
08H
RCD
0
08H
Disable Pre-Fetch Transfer Length
40H
08H
Minimum Pre-Fetch
01H
08H
Maximum Pre-Fetch
01H
08H
Maximum Pre-Fetch Ceiling
40H
0AH
Que Algorithm Modifiera
0
0AH
DQUE
0
0BH
Medium Type 1 Supported
02H
2-48
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
Table 2-42
Mode Page Parameter Default Values
Field
Default Value
0BH
Medium Type 2 Supported
03H
0BH
Medium Type 3 Supported
00H
0BH
Medium Type 4 Supported
00H
21H
DAIR
0
21H
DWR
0
21H
Quick Disconnect
0
21H
Force Verify
0
a.This value is for 9.1 and 5.2 Gbyte Capacity drive only.
With power-on or reset and the loaded media holds no format
information in itself, the current value of the format page (20H)
parameters are set as follows:
Table 2-43
Mode Page 20H Parameter Default Values
Page
Field
Current Value
650 Mbytes/Cartridge
20H
Format Mode
3
20H
Type
0
20H
Number of Bands
1
20H
Size of Spare Band
2048
1.3/1.2 Gbytes/Cartridge (1024/512 bytes/sector)
20H
Format Mode
4
20H
Number of Bands
1
2.6 Gbytes/Cartridge (1024 bytes/sector)
20H
Chapter 2
Format Mode
4
2-49
SCSI-2 Drive Commands
Page
SCSI-2 Drive Command Set
Mode Select Command (15H)
Table 2-43
Mode Page 20H Parameter Default Values
Page
Field
Current Value
20H
Number of Bands
34
2.3 Gbytes/Cartridge (512 bytes/sector)
20H
Format Mode
4
20H
Number of Bands
30
5.2 Gbytes/Cartridge (2048 bytes/sector)a
20H
Format Mode
4
20H
Number of Bands
24
4.8 Gbytes/Cartridge (512 bytes/sector)a
20H
Format Mode
4
20H
Number of Bands
45
4.1 Gbytes/Cartridge (512 bytes/sector)a
20H
Format Mode
4
20H
Number of Bands
38
9.1 Gbytes/Cartridge (4096 bytes/sector)b
20H
Format Mode
4
20H
Number of Bands
16
8.6 Gbytes/Cartridge (2048 bytes/sector)b
20H
Format Mode
4
20H
Number of Bands
30
a.This media is for 9.1 and 5.2 Gbyte capacity drives only.
b.This media is for 9.1 capacity drives only.
2-50
Chapter 2
SCSI-2 Drive Command Set
Mode Select Command (15H)
DIP Switch Locations
DIP Switch Locations
Table 2-44
DIP Switch Definitions
SCSI-2 Drive Commands
Figure 2-1
DIP SW S501
DIP SW S502
1
Autochanger Eject
Distance Override
1
Reserved for Production
2
DAIR Enable
2
Reserved for Production
3
Reserved for HP
3
Reserved for Production
4
Reserved for HP
4
Reserved for Production
5
Reserved for Debug
5
Enable SCAM
6
Reserved for Debug
6
Force Verify for Write
Operation
7
Reserved for Debug
7
SCSI Terminator Enablea
8
Reserved for Debug
8
Reserved
a.For 2.6 Gbyte capacity drives, this DIP switch is Fast SCSI Enable.
Chapter 2
2-51
SCSI-2 Drive Command Set
Reserve Command (16H)
Reserve Command (16H)
This command is used to reserve the drive for use by a single SCSI
initiator if and when the drive is connected to multiple initiators.
Table 2-45
Reserve Command CDB
Byte
7
6
5
0
1
4
3
2
1
0
Operation Code (16H)
Logical Unit Number
(0)
3rd
Pty
3rd Party Device ID
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
Reserved (0)
Rsvd
(0)
Flag
Link
The reservation is effective until one of the following occurs:
• The Reserve initiator sends another valid Reserve Command
• The Reserve initiator releases using a Release Command
• Any initiator sends a Bus Device Reset message
• A Reset conditions occurs
Once RESERVED, other initiator commands (except Inquiry and
Request Sense) for the logical unit are rejected and result in a
"Reservation Conflict" status. A Release Command sent by another
initiator is ignored.
3rdPty
3rd Pty
Device ID
2-52
A 3rd Pty bit of 1 indicates that the drive is reserved for
the SCSI device specified in the Third Party Device ID
field.
3rd Pty Device ID indicates identification of the SCSI
device for which the drive is to be reserved.
Chapter 2
SCSI-2 Drive Command Set
Release Command (17H)
This command is sent by the Reserve Command initiator to release the
logical unit for use by other initiators.
Table 2-46
Release Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (17H)
Logical Unit Number
(0)
3rd
Pty
3rd Party Device ID
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
3rdPty
3rd Pty
Device ID
Chapter 2
Reserved (0)
Flag
Rsvd
(0)
Link
A 3rd Pty bit of 1 indicates that the drive is reserved for
the SCSI device specified in the Third Party Device ID
field.
3rd Pty Device ID indicates identification of the SCSI
device for which the drive is to be reserved.
2-53
SCSI-2 Drive Commands
Release Command (17H)
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Mode Sense (Group 0) Command (1AH)
This command is used to acquire optical disk, drive, and drive controller
parameters.
Table 2-47
Mode Sense (Group 0) Command CDB
Byte
7
0
1
2
6
5
4
3
2
1
0
Operation Code (1AH)
Logical Unit Number
(0)
PC
Rsvd
(0)
DBD
Page Code (Table 2-50 on page 2-56)
3
Reserved (0)
4
Allocation Length
5
Rsvd (0)
Reserved (0)
Flag
Link
DBD
A Disable Block Descriptors bit of 1 indicates that no
block descriptor is provided.
A DBD bit of 0 indicates that the block descriptor is
provided.
PC
Page control defines the type of parameter values to be
returned as follows:
00 - Current Values
01 - Changeable Values
10 - Default Values
11 - Saved Values
Page Code
Page code values are the same as for the Mode Select
command. If 00H or 3FH is specified, all pages are
returned.
2-54
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Table 2-48
This field specifies the number of bytes that the
initiator has allocated for returned data. A length of 0
indicates that no data will be returned. The drive will
terminate the data-in phase when the allocation length
has been transferred or when all available data has
been transferred to the initiator.
Mode Sense Header
Byte
7
6
4
3
0
Mode Data Length
1
Medium Type
2
WP
Reserved
3
Table 2-49
5
Cache
(1)
2
1
0
Reserved (0)
Block Descriptor Length
Mode Sense Descriptor
Byte
7
6
5
4
3
2
0
Density Codes
1
Number of Blocks (MSByte)
2
Number of Blocks
3
Number of Blocks (LSByte)
4
Reserved (0)
5
Block Length (MSByte)
6
Block Length
7
Block Length (LSByte)
Chapter 2
1
0
2-55
SCSI-2 Drive Commands
Allocation
Length
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Table 2-50
Mode Page Codes
PageCode
Parameter
List
Length
Description
01H
12
Read-Write Error Recovery Page
(See Table 2-51 on page 2-57)
02H
16
Disconnect-Reconnect Page
(See Table 2-52 on page 2-59)
08H
12
Caching Page
(See Table 2-53 on page 2-60)
0AH
8
Control Mode Page
(See Table 2-54 on page 2-63)
0BH
8
Medium Type Supported
(Table 2-55 on page 2-64)
20H
12
Vendor Unique Format Page
(See Table 2-57 on page 2-66)
21H
12
Vendor Unique Page
(See Table 2-61 on page 2-70)
00H,3FH
80
Request for all Pages
2-56
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Read-Write Error Recover Page
Read-Write Error Recovery Page 01H
Byte
7
6
0
PS (1)
Rsvd
(0)
1
2
5
4
3
2
1
0
DTE
DCR
Page Code (01H)
Page Length (0AH)
AWRE
Rsvd
(0)
TB
RC
Rsvd
(0)
3
Read Retry Count
4-7
Reserved (0)
8
Write Retry Count
9-11
Reserved (0)
PER
PS
The Parameters Savable bit of 1 indicates this
parameter page is savable in non-volatile RAM.
AWRE
An Automatic Write Reallocation Enable bit of 1
enables the automatic reallocation of defective sectors
during the write operation of the Write commands
(0AH, 2AH, AAH), Write and Verify commands (2EH,
AEH), and WRITE LONG command (3FH).
For rewritable disks, automatic reallocation of defective
sectors occurs during these additional erase operations:
Erase 2CH and Erase ACH.
An AWRE bit of 0 does not enable automatic
reallocation of defective sectors.
TB
A Transfer Block bit of 1 indicates that a data block that
is not recovered within the recovery limits specified is
transferred to the initiator before CHECK CONDITION
status is returned.
A TB bit of 0 indicates that such a data block is not
transferred to the initiator.
Chapter 2
2-57
SCSI-2 Drive Commands
Table 2-51
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
RC
A Read Continuous bit of 1 indicates that error
correction codes are not used for data error recovery.
A Read Continuous bit of 0 allows the use of error
correction codes for data recovery.
PER
A Post Error bit of 1 indicates that the target reports
recovered errors.
A PER bit of 0 indicates that the target does not report
recovered errors.
DTE
A Disable Transfer on Error (DTE) bit of 1 indicates
that the target terminates the data phase upon
detection of a recovered error.
DTE bit of 0 indicates that the target does not terminate
the data phase upon detection of a recovered error.
DCR
A Disable Correction bit of 1 indicates that error
correction codes are not used for data error recovery.
A DCR bit of 0 allows the use of error correction codes
for data error recovery.
Read Retry
Count
Write Retry
Count
2-58
The read retry count field specifies the number of times
the target attempts recovery of a read operation before
reporting an error.
The write retry count field specifies the number of times
the target attempts recovery of a write operation before
reporting an error.
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Disconnect-Reconnect Page 02H
Disconnect-Reconnect Page 02H
Byte
7
6
0
PS
(1)
Rsvd
(0)
5
4
3
2
1
0
Page Code (02H)
1
Page Length (0EH)
2
Buffer Full Ratio
3
Buffer Empty Ratio
4-9
Reserved (0)
10
Maximum Burst Size (MSByte)
11
Maximum Burst Size (LSByte)
12-15
Reserved (0)
The disconnect-reconnect page provides the initiator the means to tune
the performance of the SCSI bus.
PS
The Parameters Savable bit of 1 indicates this
parameter page is savable in non-volatile RAM.
Buffer Full
Ratio
This field has no effect on the drive.
Buffer Empty
Ratio
This field has no effect on the drive.
Maximum
Burst Size
Chapter 2
This field indicates the maximum amount of data that
the target transfers during a data phase before
disconnecting if the initiator has granted the disconnect
privilege. This value is expressed in increments of 512
bytes (e.g. a value of one means 512 bytes, two means
1024 bytes, etc.). A value of zero indicates there is no
limit on the amount of data transferred per connection.
2-59
SCSI-2 Drive Commands
Table 2-52
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Caching Page 08H
Table 2-53
Caching Page 08H
Byte
7
6
0
PS
(1)
Rsvd
(0)
1
2
5
4
3
2
1
0
MF
RCD
Page Code (08H)
Page Length (0AH)
Reserved (0)
WCE
3
Reserved (0)
4
Disable Pre-fetch Transfer Length (MSByte)
5
Disable Pre-fetch Transfer Length (LSByte)
6
Minimum Pre-fetch (MSByte)
7
Minimum Pre-fetch (LSByte)
8
Maximum Pre-fetch (MSByte)
9
Maximum Pre-fetch (LSByte)
10
Maximum Pre-fetch Ceiling Length (MSByte)
11
Maximum Pre-fetch Ceiling Length (LSByte)
PS
The Parameters Savable bit of 1 indicates this
parameter page is savable in non-volatile RAM.
WCE
A Write Cache Enable bit of 1 indicates write caching is
enabled.
A WCE bit of 0 indicates write caching is disabled.
MF
The Multiplication Factor bit is set to 1 and cannot be
changed. This bit is set to the Minimum and Maximum
Pre-Fetch fields during READ operations. If this bit is
set to 0 by the MODE SELECT command, a CHECK
CONDITION status is returned with the sense key/
additional sense code set to ILLEGAL REQUEST/
Invalid Parameter List.
2-60
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
RCD
A RCD bit of 0 indicates read ahead is enabled.
NOTE
If WCE and RCD are both set to 1, a CHECK CONDITION status is
returned with the sense key/additional sense code set to ILLEGAL
REQUEST/Invalid Parameter List.
DisablePre-fetchTransfer
Length
This field sets the threshold value for pre-fetching data
during reads. If the number of blocks to be read is
greater than this value, no pre-fetching occurs.
The Disable Pre-fetch Transfer Length default setting
is 64.
Minimum
Pre-fetch
If this bit is set to 0 by the MODE SELECT command, a
CHECK CONDITION status is returned with the sense
key/additional sense code set to ILLEGAL REQUEST/
Invalid Parameter List. Since the MF bit is 1 and the
Minimum Pre-Fetch bit is also 1, the minimum prefetch size is equal to the READ Transfer Length. This
field does not affect the operation of the drive.
The Minimum Pre-fetch default setting is 1 and cannot
be changed.
Maximum
Pre-fetch
If this bit is set to 0 by the MODE SELECT command, a
CHECK CONDITION status is returned with the sense
key/additional sense code set tot ILLEGAL REQUEST/
Invalid Parameter List. Since the MF bit is 1 and the
Maximum Pre-fetch bit is also 1, the maximum prefetch size is equal to the READ Transfer Length. This
field does not affect the operation of the drive.
The Maximum Pre-fetch default setting is 1 and cannot
be changed.
Chapter 2
2-61
SCSI-2 Drive Commands
A Read Cache Disable bit of 1 indicates read ahead is
disabled.
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
MaximumPre-fetch
Ceiling
The Maximum Pre-fetch Ceiling filed does not affect the
operation of the drive and can be set to 32 or 64. In
another value is set, a CHECK CONDITION status is
returned with the sense key/ additional sense code set to
ILLEGAL REQUEST/Invalid Parameter List.
NOTE
With write caching enabled, data integrity of the information in the buffer
is not guaranteed through power cycling.
2-62
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Control Mode Page (0AH)
Control Mode Page (0AH)
Byte
0
7
6
5
4
Reserved (0)
3
2
Page Length (06H)
2
Reserved (0)
4-7
0
Page Code (0AH)
1
3
1
Que Algorithm Modifiera
Reserved (0)
DQue
Reserved (0)
a.For 9.1 and 5.2 Gbyte capacity drives only.
The parameters of the Control Mode Page are all reserved and cannot be
changed by the MODE SELECT command.
PS
The Parameters Savable bit of 1 indicates this
parameter page is savable in non-volatile RAM.
DQue
A Disable Queuing bit of 1 indicates that command
queuing is disabled.
A Disable Queuing bit of 0 indicates that command
queuing is enabled.
NOTE
For more information about the use of Byte 3 (Que Algorithm Modifier),
see Table 2-34 on page 2-39.
Chapter 2
2-63
SCSI-2 Drive Commands
Table 2-54
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Medium Types
Table 2-55
Medium Types Supported Page 0BH
Byte
7
6
5
0
PS
(1)
Rsvd
(0)
4
3
2
0
Page Code (0BH)
1
Page Length (06H)
2
Reserved (0)
3
Reserved (0)
4
Medium Type One Supported
(02H — Optical Write-once Medium)
5
Medium Type Two Supported
(03H — Optical Erasable Medium)
6
Medium Type Three Supported (00H)
7
Medium Type Four Supported (00H)
PS
1
The Parameters Savable bit of 1 indicates this
parameter page is savable in non-volatile RAM.
This page is used to set the medium type(s) supported by the drive. The
drive accepts the following combinations:
2-64
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Valid Medium Type Combinations
Byte
Field
Name
Setting 1
(default)
Setting 2
Setting 3
Setting 4
4
Medium
Type 1
Supported
02H
00H
02H
03H
5
Medium
Type 2
Supported
03H
00H
00H
00H
6
Medium
Type 3
Supported
00H
00H
00H
00H
7
Medium
Type 4
Supported
00H
00H
00H
00H
00H
Default (rewritable optical disks only)
02H
Write-Once optical disks
03H
Rewritable optical disks
Chapter 2
2-65
SCSI-2 Drive Commands
Table 2-56
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Vendor Unique
Table 2-57
Vendor Unique Format Page 20H
Byte
7
6
0
PS
(1)
Rsvd
(0)
4
3
2
1
0
Page Code (20H)
1
Page Length (0AH)
2
Format Mode
3-11
Format Type Specific Data
PS
NOTE
5
The Parameters Savable bit of 1 indicates this
parameter page is savable in non-volatile RAM.
The drive supports Format Mode 03H and 04H.
Format Mode 03H is for 650-Mbyte optical disks.
Format Mode 04H is for 1.3-, 2.6-, 5.2-, and 9.1-Gbyte optical disks.
2-66
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Format Mode
Table 2-58
Format Mode 03H - Type 0
Byte
7
6
5
4
3
2
2
Format Mode (03H)
3
Type 00H
4
Size of User Band (MSByte)
5
Size of User Band
6
Size of User Band
7
Size of User Band (LSByte)
8
Size of Spare Band (MSByte)
9
Size of Spare Band (LSByte)
10
Number of Bands (MSByte)
11
Number of Bands (LSByte)
Size of User
Band
Size of Spare
Band
Number of
Bands
Chapter 2
1
0
The Size of User Band field indicates the length of each
user band in number of logical blocks.
The Size of Spare Band field indicates the length of each
spare band in number of logical blocks.
The Number of Bands field indicates the bands on the
disk. The drive can read and write multi-band
formatted disks, but can create only single-band disks.
2-67
SCSI-2 Drive Commands
Format Mode 03H supports two types of format (type 0 and type 1) by
setting byte 3.
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Table 2-59
Format Mode 03H - Type 1
Byte
7
6
5
4
3
2
2
Format Mode (03H)
3
Type 01H
4
Reserved (0)
5
Reserved (0)
6
Number of Bands (MSByte)
7
Number of Bands (LSByte)
8
Size of Spare Bands (MSByte)
9
Size of Spare Bands (LSByte)
10
Reserved (0)
11
Reserved (0)
1
0
Type 1 format exists for compatibility. An initiator cannot change these
parameters.
Number of
Bands
Size of Spare
Band
2-68
The Number of Bands field indicates the bands on the
disk.
The Size of User Band field indicates the length of each
spare band in number of logical blocks.
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Format Mode 04H
Byte
7
5
4
3
2
2
Format Mode (04H)
3-9
Reserved (0)
10
Number of Bands (MSByte)
11
Number of Bands (LSByte)
Number of
Bands
NOTE
6
1
0
The Number of Bands field indicates the bands on the
disk and can be set to 1 (01H), 16 (10H), 30 (1EH),
or 34 (22H).
The Number of Bands for 9.1 and 5.2 Gbyte Capacity drives include
1 (01H), 16 (10H), 24 (18H), 30 (1EH), 34 (22H), 38 (26H), or 45 (2DH).
Chapter 2
2-69
SCSI-2 Drive Commands
Table 2-60
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
Vendor Unique
Table 2-61
Vendor Unique Page 21H
Byte
7
6
0
PS (1)
Rsvd
(0)
5
4
3
2
1
0
Page Code (21H)
1
Page Length (0AH)
2
Reserved (0)
DAIR
3
DWR
Quick
Disconnect
Rsvd
(0)
Force
Verify
4
S1-8
S1-7
S1-6
S1-5
S1-4
S1-3
S1-2
S1-1
5
S2-8
S2-7
S2-6
S2-5
S2-4
S2-3
S2-2
S2-1
DOM
FWC
6
Reserved (0)
Reserved (0)
7-11
PS
The Parameters Savable bit of 1 indicates this
parameter page is savable in non-volatile RAM.
DAIR
A Direct Access Inquiry Response bit of 1 indicates the
Peripheral Device Type field in the Inquiry Data
indicates "Direct Access Device."
A DAIR bit of 0 indicates "Optical Memory Device" in
the Peripheral Device Type field in the Inquiry Data.
The DAIR default setting is 0.
DWR
A Disable Write Reordering bit of 1 indicates write
reordering is not enabled.
A DWR bit of 0 indicates write reordering is enabled.
The DWR default setting is 0.
2-70
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
A Quick Disconnect bit of 1 enables SCSI bus
disconnection before command validation on
performance path commands (i.e. reads, writes).
A Quick Disconnect bit of 0 disables SCSI bus
disconnection before validation on performance path
commands (i.e. reads, writes).
The Quick Disconnect default setting is 0.
Force Verify
A Force Verify bit of 1 indicates that all write operations
will be verified. The Write 6-, 10-, and 12-byte
commands will operate as if they were Write Verify 6,
10, and 12-byte commands.
A Force Verify bit of 0 indicates normal operation.
The Force Verify default setting is 0.
NOTE
Bytes 4 and 5
Bytes 4 and 5 are used to read the setting of the DIP
switches on the drive. SX-Y refers to the setting of DIP
switch S50X-Y (see Figure 2-1 on page 2-51 and
Table 2-44 on page 2-51). If SX-Y=0, the switch is set to
the OFF position; if SX-Y=1, the switch is set to the ON
position. These fields are not changeable. The switch
setting value overrides the saved value.
DOM
A drive operating mode of 0 indicates that the drive is
installed in a jukebox environment. A DOM bit of 1
indicates that the drive is installed in a stand-alone
environment.
The DOM bit is not selectable using the Mode Select command.
Chapter 2
2-71
SCSI-2 Drive Commands
Quick
Disconnect
SCSI-2 Drive Command Set
Mode Sense (Group 0) Command (1AH)
FWC
NOTE
A Force Write Calibration bit of 1 instructs the drive to
perform the Write Calibration routine at spin-up. A
Force Write Calibration bit of 0 instructs the drive to
perform the Write Calibration routine on receipt of the
first Write command or 5 minutes after spin-up.
The bits DAIR and Force Verify on this mode page can also be controlled
in HP products by changing external switch settings. In HP’s standalone
box products, this is accomplished by changing the thumb wheel settings
on the rear of the box. In HP’s library products, this is accomplished by
changing the front panel settings. In all cases, changes to the mode page
settings will override the external switch settings.
2-72
Chapter 2
SCSI-2 Drive Command Set
Start/Stop Unit Command (1BH)
This command starts or stops rotation of the optical disk in the drive
and/or ejects the optical disk from the drive.
Table 2-62
Start/Stop Unit Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (1BH)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
Immed
4
Reserved (0)
LoEj
Start
5
Reserved (0)
Flag
Link
Immed
An Immediate bit of 1 indicates that status is returned
as soon as the command descriptor block has been
validated.
An Immed bit of 0 indicates that status is returned after
the operation is completed.
LoEj
A Load Eject bit of 0 requests that no action be taken
regarding loading or ejecting the media.
A Load Eject bit of 1 indicates that the media will be
unloaded if the Start bit is 0.
A Load Eject bit of 1 indicates that the media will be
loaded if the Start bit is 1.
NOTE
This command is affected by the Prevent/Allow Medium Removal
command. Do not use LoEj in an autochanger environment.
Start
Chapter 2
A Start bit of 1 indicates that the drive starts rotating
the optical disk. A Start bit of 0 indicates that the drive
stops rotating the optical disk.
2-73
SCSI-2 Drive Commands
Start/Stop Unit Command (1BH)
SCSI-2 Drive Command Set
Receive Diagnostic Results Command (1CH)
Receive Diagnostic Results Command (1CH)
This command requests diagnostic test data resulting from the Send
Diagnostic Command be sent to the initiator.
Table 2-63
Receive Diagnostic Results Command CDB
Byte
7
6
5
0
1
3
2
1
0
Flag
Link
Operation Code (1CH)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Allocation Length (MSByte)
4
Allocation Length (LSByte)
5
Reserved (0)
Allocation
Length
Table 2-64
4
The Allocation Length field specifies the number of
bytes allocated for returned diagnostic data. The
controller returns the number of bytes specified or all
available diagnostic data (10 bytes), whichever is less.
Received Diagnostic Results Page Codes
Page Code
Maximum
Transfer
Length
Description
00H
6
Supported Diagnostics Pages
(See Table 2-65 on page 2-75)
81H
10
Controller Test
(See Table 2-66 on page 2-75)
2-74
Chapter 2
SCSI-2 Drive Command Set
Receive Diagnostic Results Command (1CH)
Supported Diagnostic Pages
Byte
Table 2-66
7
6
5
4
3
2
0
Page Code (00H)
1
Reserved (0)
2
Page Length (0) (MSByte)
3
Page Length (2) (LSByte)
4
Supported Page List (00H)
5
Supported Page List (81H)
1
0
Controller Test 81H
Byte
7
6
5
4
3
2
0
Page Code (81H)
1
Reserved (0)
2
Page Length (0) (MSByte)
3
Page Length (6) (LSByte)
4
Reserved (0)
5
Loop Count Completed
6
Internal Error Code (MSByte)
7
Internal Error Code
8
Internal Error Code
9
Internal Error Code (LSByte)
Chapter 2
1
0
Success
2-75
SCSI-2 Drive Commands
Table 2-65
SCSI-2 Drive Command Set
Send Diagnostic Command (1DH)
Send Diagnostic Command (1DH)
This command initiates drive diagnostic tests.
NOTE
Disconnect must be allowed to run diagnostic tests.
Table 2-67
Send Diagnostic Command CDB
Byte
7
6
5
0
1
4
3
2
1
0
DevOfl
UnitOfl
Flag
Link
Operation Code (1DH)
Logical Unit Number
(0)
PF (1)
Rsvd
(0)
SelfTst
2
Reserved (0)
3
Parameter List Length (MSByte)
4
Parameter List Length (LSByte)
5
Reserved (0)
SelfTst
A Self-Test bit of 1 causes the poweron selftest to run.
This self-test is equivalent to the execution of test
sequence 1, Poweron Sequence. If this bit is 1, the
Parameter List Length must be 0.
A Self-Test bit of 0 indicates the test requested in the
Parameter List Length (See Table 2-70 on page 2-78)
NOTE
A SelfTst bit of 0 should be followed by a Receive Diagnostics Results
Command.
A SelfTst bit of 1 should be followed by a Request Sense Command.
2-76
Chapter 2
SCSI-2 Drive Command Set
Send Diagnostic Command (1DH)
Device Offline bit of 1 must be set for proper operation
of any test besides self-test.
UnitOfl
A Unit Offline bit of 1 must be set for proper operation
of any test besides self-test.
Parameter List
Length
Indicates the number of parameter bytes in the Data
Out Phase that describe the selected test. This value
must be 0 if the SelfTst bit is set to 1.
Table 2-68
Supported Diagnostic Pages
Byte
Table 2-69
7
6
5
4
3
2
0
Page Code (00H)
1
Reserved (0)
2
Page Length (0) (MSByte)
3
Page Length (0) (LSByte)
1
0
Send Diagnostic Command Page Codes
Page Code
Parameter
List
Length
Description
00H
4
Supported Diagnostics Pages
(See Table 2-68 on page 2-77)
81H
12
Controller Test
(See Table 2-70 on page 2-78)
Chapter 2
2-77
SCSI-2 Drive Commands
DevOfl
SCSI-2 Drive Command Set
Send Diagnostic Command (1DH)
Table 2-70
Controller Test
Byte
7
5
4
4
2
0
Page Code (81H)
1
Reserved
2
Page Length (0) (MSByte)
3
Page Length (8) (LSByte)
4
No
Break
1
0
Test Number
(See Table 2-71 on page 2-78)
5
Loop Count
6-11
Reserved (0)
No Break
Table 2-71
6
The No Break bit directs the target not to terminate
looping when an error is detected.
Interface Manager Diagnostic Tests
Diagnostic Test Name
Test Number (hex.)
Selftest
0x01
ROM Checksum Test
0x02
Microprocessor RAM Test
0x03
Buffer RAM Test
0x04
ODC Chip Test
0x05
DSP Communication Test
0x06
2-78
Chapter 2
SCSI-2 Drive Command Set
Prevent/Allow Medium Removal Command (1EH)
This command prevents or allows removal of an optical disk from a drive.
Table 2-72
Prevent/Allow Medium Removal Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (1EH)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
5
Prevent
Reserved (0)
Control Byte (0)
Prevent
Flag
Link
A Prevent bit of 1 prevents removal of the optical disk
from a drive.
A Prevent bit of 0 allows removal of the optical disk
from a drive.
NOTE
The Start/Stop Unit Command affects this command. See Table 2-62 on
page 2-73.
Chapter 2
2-79
SCSI-2 Drive Commands
Prevent/Allow Medium Removal Command
(1EH)
SCSI-2 Drive Command Set
Read Capacity Command (25H)
Read Capacity Command (25H)
This command reads the capacity of the optical disk surface in the drive.
The last logical block address and block length of the medium are
returned.
Table 2-73
Read Capacity Command CDB
Byte
0
1
7
6
5
4
3
2
Logical Unit Number
(0)
Reserved (0)
Logical Block Address (MSByte)
3
Logical Block Address
4
Logical Block Address
5
Logical Block Address (LSByte)
6
Reserved (0)
7
Reserved (0)
9
PMI
0
Operation Code (25H)
2
8
1
RelAdr
Reserved (0)
Reserved (0)
PMI
Flag
Link
A Partial Medium Indicator bit of 1 indicates that the
logical block address field does not need to be set to 0.
A PMI bit of 0 indicates that the logical block address
field must be set to 0.
2-80
Chapter 2
SCSI-2 Drive Command Set
Read Capacity Command (25H)
Read Capacity Command Data
Byte
7
6
5
4
3
2
0
Logical Block Address (MSByte)
1
Logical Block Address
2
Logical Block Address
3
Logical Block Address (LSByte)
4
Block Length (MSByte)
5
Block Length
6
Block Length
7
Block Length (LSByte)
Chapter 2
1
0
2-81
SCSI-2 Drive Commands
Table 2-74
SCSI-2 Drive Command Set
Read (Group 1) Command (28H)
Read (Group 1) Command (28H)
This command reads data from the specified logical block address.
NOTE
The Mode Select Commands (15H, 55H) impact read, write, format, and
erase commands.
Table 2-75
Read (Group 1) Command CDB
Byte
7
0
1
6
5
4
3
2
1
Operation Code (28H)
Logical Unit Number
(0)
DPO
FUA
Reserved (0)
2
Starting Logical Block Address (MSByte)
3
Starting Logical Block Address
4
Starting Logical Block Address
5
Starting Logical Block Address (LSByte)
6
Reserved (0)
7
Transfer Length (MSByte)
8
Transfer Length (LSByte)
9
DPO
0
PBA
Reserved (0)
Flag
RelAdr
Link
A Disable Page Out bit of 1 instructs the target not to
store readahead data in cache after the read data has
been transferred to the initiator.
A DPO bit of 0 instructs the target it may store
readahead data in the cache after the read data has
been transferred to the initiator.
NOTE
The DPO bit is ignored in 9.1 and 5.2 Gbyte capacity drives.
2-82
Chapter 2
SCSI-2 Drive Command Set
Read (Group 1) Command (28H)
FUA
A Force Unit Access bit of 0 indicates that the drive may
access the cache memory.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
Transfer
Length
The Transfer Length field specifies the number of
contiguous logical blocks of data to be transferred.
A value of 0 indicates that no blocks will be transferred
and is not considered an error.
PBA
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
NOTE
For write-once media, blank checking is performed following a failed read.
If the sector is blank, the sense key/additional sense code will be set to
BLANK CHECK/Blank Sector Detected.
NOTE
When this command is used with 14X 512 or 1024 byte/sector media,
setting the PBA bit will cause the drive to return a CHECK CONDITION
status. The sense key/additional sense code will be set to ILLEGAL
REQUEST/INVALID FIELD in CDB.
Chapter 2
2-83
SCSI-2 Drive Commands
A Force Unit Access bit of 1 indicates that data is read
directly from the disk.
SCSI-2 Drive Command Set
Write (Group 1) Command (2AH)
Write (Group 1) Command (2AH)
This command is used to write data starting at the specified logical block
address.
NOTE
The Mode Select Commands (15H, 55H) impact read, write, format, and
erase commands.
Table 2-76
Write (Group 1) Command CDB
Byte
7
6
5
0
4
3
2
0
Rsvd (0)
RelAdr
Flag
Link
Operation Code (2AH)
1
Reserved (0)
DPO
FUA
EBP
2
Logical Block Address (MSByte)
3-4
Logical Block Address
5
Logical Block Address (LSByte)
6
Reserved (0)
7
Transfer Length (MSByte)
8
Transfer Length (LSByte)
9
1
PBA
Ers Cntl
Reserved (0)
NOTE
The 9.1 and 5.2 Gbyte capacity drives cannot Format, Erase, Write, or
Write and Verify 650 Mbyte and 1.3-Gbyte optical disks. The 2.6 Gbyte
capacity drives cannot Format, Erase, Write, or Write and Verify 650
Mbyte optical disks. If this command is issued with any of these drive/
media combinations, a CHECK CONDITION status will result with the
Sense Key/Additional Sense Code set to Data Protect/Write Protected.
NOTE
For Write-Once media, Byte 9, Bit 7 and Bit 6 are reserved (0).
2-84
Chapter 2
SCSI-2 Drive Command Set
Write (Group 1) Command (2AH)
DPO
A DPO bit of 0 instructs the target to store data in the
cache after it has been transferred to the media.
This bit is ignored.
FUA
A Force Unit Access bit of 1 indicates that data is
written directly to the disk.
An FUA bit of 0 indicates that write caching is allowed.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
EBP
An Erase By-Pass bit of 0 indicates an erase is
automatically performed before writing the data.
An EBP bit of 1 suppresses the erase operation.
Transfer Length The Transfer Length field specifies the number of
contiguous logical blocks of data to be transferred for
this command.
A value of 0 indicates that no blocks of data will be
transferred and is not considered an error.
PBA
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
ErsCntl
NOTE
The Erase Control bit is identical to the Erase Bypass
bit.
For write-once optical disks, blank checking is performed before writing
data. If a written block is detected during blank checking, the drive will
return a CHECK CONDITION status. The sense key/additional sense
code will be set to BLANK CHECK/Overwrite Attempted.
Chapter 2
2-85
SCSI-2 Drive Commands
A Disable Page Out bit of 1 instructs the target not to
store the data in the cache after it has been transferred
to the media.
SCSI-2 Drive Command Set
Write (Group 1) Command (2AH)
NOTE
When this command is used with 14X 512 OR 1024 byte/sector media,
setting the ErsCntl bit or the PBA bit will cause the drive to return a
CHECK CONDITION status. The sense key/additional sense code will be
set to ILLEGAL REQUEST/INVALID FIELD in CDB.
2-86
Chapter 2
SCSI-2 Drive Command Set
Seek (Group 1) Command (2BH)
This command seeks the optical head to the physical track where the
specified logical block exists.
Table 2-77
Seek (Group 1) Command CDB
Byte
7
0
1
6
5
4
3
2
0
Flag
Link
Operation Code (2BH)
Logical Unit Number
(0)
Reserved (0)
2
Logical Block Address (MSByte)
3
Logical Block Address
4
Logical Block Address
5
Logical Block Address (LSByte)
6
Reserved (0)
7
Reserved (0)
8
Reserved (0)
9
1
PBA
PBA
Reserved (0)
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
NOTE
When this command is used with 512 byte/sector 14X media or 1024 byte/
sector 14X media, setting the PBA bit will cause the drive to return a
CHECK CONDITION status. The sense key/additional sense code will be
set to ILLEGAL REQUEST/Invalid Field in CDB.
Chapter 2
2-87
SCSI-2 Drive Commands
Seek (Group 1) Command (2BH)
SCSI-2 Drive Command Set
Erase (Group 1) Command (2CH)
Erase (Group 1) Command (2CH)
This command erases data from the specified logical block address. This
command can only be used with rewritable disks.
Table 2-78
Erase (Group 1) Command CDB
Byte
7
0
1
5
4
3
2
1
0
Rsvd
(0)
RelAdr
Flag
Link
Operation Code (2CH)
Logical Unit Number
(0)
Reserved (0)
ERA
2
Logical Block Address (MSByte)
3
Logical Block Address
4
Logical Block Address
5
Logical Block Address (LSByte)
6
Reserved (0)
7
Transfer Length (MSByte)
8
Transfer Length (LSByte)
9
NOTE
6
PBA
Reserved (0)
The 9.1 and 5.2 Gbyte capacity drives cannot Format, Erase, Write, or
Write and Verify 650 Mbyte and 1.3-Gbyte optical disks. The 2.6 Gbyte
capacity drives cannot Format, Erase, Write, or Write and Verify 650
Mbyte optical disks. If this command is issued with any of these drive/
media combinations, a CHECK CONDITION status will result with the
Sense Key/Additional Sense Code set to Data Protect/Write Protected.
2-88
Chapter 2
SCSI-2 Drive Command Set
Erase (Group 1) Command (2CH)
ERA
An ERA bit of 0 indicates that all blocks are erased,
starting from the logical block address to the end of the
specified transfer length.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
Transfer
Length
PBA
The Transfer Length field specifies the number of
contiguous logical blocks of data to be erased. A value of
0 indicates that no blocks will be erased and is not
considered an error.
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
NOTE
If this command is executed for write-once disks, the drive returns a
CHECK CONDITION status with the Sense Key/Additional Sense Code
set to Illegal Request/Invalid Command Operation Code.
NOTE
When this command is executed with 14X 512 or 1024 byte/sector media,
the drive will return a CHECK CONDITION status. The sense key/
additional sense code will be set to ILLEGAL REQUEST/INVALID
COMMAND.
Chapter 2
2-89
SCSI-2 Drive Commands
An Erase All bit of 1 indicates that all remaining blocks
are erased, starting from the logical block address to the
end of the disk. The transfer length must be set to 0.
SCSI-2 Drive Command Set
Write and Verify (Group 1) Command (2EH)
Write and Verify (Group 1) Command (2EH)
Writes data to the optical disk and then verifies the write by reading the
written data and checking the error correction code.
NOTE
The Mode Select Commands (15H, 55H) impact read, write, format, and
erase commands.
Table 2-79
Write and Verify (Group 1) Command CDB
Byte
7
6
0
5
4
3
2
1
0
EBP
Rsvd
(0)
RelAdr
Flag
Link
Operation Code (2EH)
1
Reserved (0)
DPO
Rsvd
(0)
2
Logical Block Address (MSByte)
3-4
Logical Block Address
5
Logical Block Address (LSByte)
6
Reserved (0)
7
Transfer Length (MSByte)
8
Transfer Length (LSByte)
9
PBA
ErsCntl
Reserved (0)
NOTE
The 9.1 and 5.2 Gbyte capacity drives cannot Format, Erase, Write, or
Write and Verify 650 Mbyte and 1.3-Gbyte optical disks. The 2.6 Gbyte
capacity drives cannot Format, Erase, Write, or Write and Verify 650
Mbyte optical disks. If this command is issued with any of these drive/
media combinations, a CHECK CONDITION status will result with the
Sense Key/Additional Sense Code set to Data Protect/Write Protected.
NOTE
For Write-Once media, Byte 9, Bit 7 and Bit 6 are reserved (0).
2-90
Chapter 2
SCSI-2 Drive Command Set
Write and Verify (Group 1) Command (2EH)
DPO
A DPO bit of 0 instructs the target to store the data in
the cache after it has been transferred to the optical
disk.
This bit is ignored.
EBP
An Erase By-Pass bit of 0 indicates an erase
automatically performs before writing the data.
An EBP bit of 1 suppresses the erase operation.
Transfer
Length
PBA
The Transfer Length field specifies the number of
contiguous logical blocks of data to be transferred for
this command. A value of 0 indicates that no blocks will
be transferred and is not considered an error.
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
ErsCntl
The Erase Control bit is identical to the Erase Bypass
bit.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
NOTE
When this command is used with 14X 512 OR 1024 byte/sector media,
setting the ErsCntl bit or the PBA bit will cause the drive to return a
CHECK CONDITION status. The sense key/additional sense code will be
set to ILLEGAL REQUEST/INVALID FIELD in CDB.
Chapter 2
2-91
SCSI-2 Drive Commands
A Disable Page Out bit of 1 instructs the target not to
store the data in the cache after it has been transferred
to the optical disk.
SCSI-2 Drive Command Set
Verify (Group 1) Command (2FH)
Verify (Group 1) Command (2FH)
This command verifies previously written data integrity starting at the
specified Logical Block Address by reading the data and checking the
Error Correction Code. The verification threshold is set to approximately
half of the error correction capability.
Table 2-80
Verify (Group 1) Command CDB
Byte
7
6
5
0
1
4
3
2
1
0
Rsvd
(0)
RelAdr
Operation Code (2FH)
Logical Unit
Number (0)
DPO
Rsvd
(0)
Blk
Vfy
2
Logical Block Address (MSByte)
3
Logical Block Address
4
Logical Block Address
5
Logical Block Address (LSByte)
6
Reserved (0)
7
Verification Length (MSByte)
8
Verification Length (LSByte)
9
DPO
Reserved (0)
Flag
Link
A Disable Page Out (DPO) bit of 1 instructs the target
not to retain the data in the cache after it has been
verified.
A DPO bit of 0 instructs the target to retain the data in
the cache after it has been verified.
This bit is ignored.
2-92
Chapter 2
SCSI-2 Drive Command Set
Verify (Group 1) Command (2FH)
Blk Vfy
A Blk Vfy bit of 0 indicates the drive verifies written
data integrity.
Verification
Length
Rel Adr
The Verification Length field specifies the number of
contiguous logical blocks of data to be verified for this
command. A value of 0 indicates that no blocks will be
verified and is not considered an error.
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
Chapter 2
2-93
SCSI-2 Drive Commands
A Blank Verify bit of 1 indicates the drive verifies that
sectors are erased.
SCSI-2 Drive Command Set
Pre-Fetch (34H)
Pre-Fetch (34H)
The Pre-Fetch command is used to transfer the specified number of data
blocks starting from the specified logical block address to cache memory.
Table 2-81
Pre-Fetch Command
Byte
7
0
6
5
4
3
2
1
0
Immed
RelAdr
Operation Code (34H)
1
Reserved (0)
2
Logical Block Address (MSByte)
3
Logical Block Address
4
Logical Block Address
5
Logical Block Address (LSByte)
6
Reserved (0)
7
Transfer Length (MSByte)
8
Transfer Length (LSByte)
9
Immed
Reserved (0)
Flag
Link
An Immediate bit of 1 indicates that the drive returns a
status as soon as the command descriptor block is
validated.
An Immed bit of 0 indicates that the status is not
returned until the operation is completed.
Transfer
Length
Rel Adr
This field indicates the number of contiguous logical
blocks of data to be transferred.
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
2-94
Chapter 2
SCSI-2 Drive Command Set
Synchronize Cache (35H)
This command initiates the writing of all cached write data to the optical
disk. Ensures that logical blocks in the cache memory, within the
specified range, have their most recent data value recorded on the optical
disk.
Table 2-82
Synchronize Cache Command
Byte
7
0
1
6
5
4
3
2
1
0
Immed
Rsvd
Operation Code (35H)
Reserved (0)
2
Logical Block Address (MSByte)
3
Logical Block Address
4
Logical Block Address
5
Logical Block Address (LSByte)
6
Reserved (0)
7
Number of Blocks (MSByte)
8
Number of Blocks (LSByte)
9
Immed
Reserved (0)
Flag
Link
An Immediate bit of 1 indicates that the target returns
a status as soon as the command descriptor block is
validated.
An Immed bit of 0 indicates that the status is not
returned until the operation is completed.
Number of
Blocks
Chapter 2
The Number of Blocks field specifies the total number of
contiguous logical blocks within the range. A Number of
Blocks bit of 0 indicates that all remaining logical blocks
on the logical unit are within the range. A logical block
within the specified range that is not in cache memory
is not considered an error.
2-95
SCSI-2 Drive Commands
Synchronize Cache (35H)
SCSI-2 Drive Command Set
Read Defect Data (Group 1) Command (37H)
Read Defect Data (Group 1) Command (37H)
This command reads optical disk defect information. The data returned
starts with a 4-byte header, followed by one or more defect descriptors.
Table 2-83
Read Defect Data (Group 1) Command CDB
Byte
7
6
5
4
3
2
0
Operation Code (37H)
1
Reserved (0)
2
Reserved (0)
PList
GList
1
0
Defect List Format
3
Reserved (0)
4
Reserved (0)
5
Reserved (0)
6
Reserved (0)
7
Allocation Length (MSByte)
8
Allocation Length (LSByte)
9
Reserved (0)
Flag
Link
PList and GList A PList bit of 0 and a GList bit of 1 indicates the drive
will return the contents of the defect list (SDL).
A PList bit of 1 and a GList bit of 0 indicates the drive
will return the contents of the PDL.
A PList bit of 1 and a GList bit of 1 indicates the drive
will return the contents of the PDL and the SDL.
2-96
Chapter 2
SCSI-2 Drive Command Set
Read Defect Data (Group 1) Command (37H)
Allocation
Length
Table 2-84
This field specifies the defect list format that is
returned. Only the Physical Sector Format (5) is
supported. If the Block Format (0) is specified, the
defect list will be returned in Physical Sector Format
and a CHECK CONDITION status will be returned at
the completion of the command with the sense key/
additional sense code set to RECOVERED ERROR/
Defect List Not Available.
This field specifies the number of bytes that the
initiator has allocated for the return of this data. A
length of 0 indicates that no data will be returned. This
condition is not considered an error. The drive will
terminate the data — in phase when the allocation
length has been transferred or when all available defect
data has been transferred to the initiator, whichever is
less.
Read Defect Data Defect List Header
Byte
7
6
5
0
1
4
3
2
1
0
Reserved (0)
Reserved (0)
PList
GList
Defect List Format
2
Defect List Length (MSByte)
3
Defect List Length (LSByte)
PList
A PList bit of 1 indicates the Primary List of defects was
returned.
GList
A GList bit of 1 indicates the Grown List of defects was
returned.
Defect List
Format
Defect List
Length
Chapter 2
This field will be set to the Defect List format that was
indicated in byte 2 of the CDB, which specifies the
format of the Defect List data returned by the drive.
This field specifies the length in bytes of the defect
descriptors (see Table 2-85 on page 2-98).
2-97
SCSI-2 Drive Commands
Defect List
Format
SCSI-2 Drive Command Set
Read Defect Data (Group 1) Command (37H)
Table 2-85
Physical Sector Format Defect Descriptor
Byte
7
6
5
4
3
2
1
0
0
Physical Track Number of the Defect (MSByte)
1
Physical Track Number of the Defect
2
Physical Track Number of the Defect (LSByte)
3
Reserved (0)
4
Reserved (0)
5
Reserved (0)
6
Reserved (0)
7
Defective Physical Sector Number
2-98
Chapter 2
SCSI-2 Drive Command Set
Write Buffer Command (3BH)
This command writes data to the drive data buffer. The transfer data
consists of a 4-byte descriptor followed by the buffer data.
CAUTION
If you write data to the buffer area, you may overwrite valid information
that the drive needs for operation.
Table 2-86
Write Buffer Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (3BH)
Logical Unit Number
(0)
Reserved (0)
Mode (Table 2-87 on
page 2-100)
2
Buffer ID (See Table 2-87 on page 2-100)
3
Buffer Offset (MSByte)
4
Buffer Offset
5
Buffer Offset (LSByte)
6
Parameter List Length (MSByte)
7
Parameter List Length
8
Parameter List Length (LSByte)
9
Reserved (0)
Flag
Link
Mode
Indicates which data format is used. Refer to Table 2-87
on page 2-100 for valid values.
Buffer ID
Indicates which buffer is used. Refer to Table 2-87 on
page 2-100 for valid values.
Chapter 2
2-99
SCSI-2 Drive Commands
Write Buffer Command (3BH)
SCSI-2 Drive Command Set
Write Buffer Command (3BH)
Buffer Offset
Indicates at what address the data is written, offset
from the beginning of the buffer. Must be set to 0 when
using Download Microcode ID.
Parameter List
Length
Indicates the number of data bytes to be written in the
buffer.
Table 2-87
Table 2-88
Buffer Access Mode and ID
Buffer Type
Buffer ID
Mode
Buffer RAM
0
0
Download Microcode
1
4
Serial Number and Manufacturing Date
4
1
Customer and Product ID
15
1
Mode Descriptions (For 2.6 Gbyte Capacity Drives Only)
Mode
Description
1
Vendor specific
4
Download microcode
0
Data retained for subsequent read buffer command
Buffer RAM
Download
Microcode
Indicates the data buffer space used for transfer to and
from the optical disk.
Indicates the code the drive uses to operate.
Serial Number and
Manufacturing
Date Code
Indicates the drive’s serial number and date code, which
indicates the week of manufacturing.
Customer and
Product ID
Indicates the Vendor Identification and Product
Identification fields of the INQUIRY command
Response Data.
2-100
Chapter 2
SCSI-2 Drive Command Set
Write Buffer Command (3BH)
Mode Descriptions (For 9.1 and 5.2 Gbyte Capacity Drives Only)
Mode
Description
0
Data Mode (same as Mode 2)
1
Vendor specific
2
Data Mode
4
Download Microcode
Chapter 2
2-101
SCSI-2 Drive Commands
Table 2-89
SCSI-2 Drive Command Set
Read Buffer Command (3CH)
Read Buffer Command (3CH)
This command reads data from the drive data buffer. The transfer data
consists of a 4-byte descriptor followed by the buffer data.
Table 2-90
Read Buffer Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (3CH)
Logical Unit Number
(0)
Reserved (0)
2
Buffer ID
3
Buffer Offset (MSByte)
4
Buffer Offset
5
Buffer Offset (LSByte)
6
Parameter List Length (MSByte)
7
Parameter List Length
8
Parameter List Length (LSByte)
9
Reserved (0)
Mode
Flag
Link
Mode
Indicates which data format is to be used. Refer to
Table 2-91 on page 2-103 for valid values.
Buffer ID
Indicates which buffer is to be used. Refer to Table 2-91
on page 2-103 for valid values.
Buffer Offset
Indicates at what address the data should be written,
offset from the beginning of the buffer.
Parameter List
Length
Indicates the number of data bytes to be read from the
buffer.
2-102
Chapter 2
SCSI-2 Drive Command Set
Read Buffer Command (3CH)
Read Buffer Descriptor
Byte
Table 2-92
7
Table 2-94
5
4
3
2
0
Offset Boundary
1
Buffer Capacity (MSB)
2
Buffer Capacity
3
Buffer Capacity (LSB)
1
0
Buffer Access Mode and ID
Buffer Type
Buffer ID
Buffer RAM
0
Buffer RAM
Table 2-93
6
Mode
0
Indicates the data buffer space used for the movement
of data to and from the optical disk.
Mode Descriptions (For 2.6 Gbyte Capacity Drives Only)
Mode
Description
0
Data retained for subsequent read buffer command
Mode Descriptions (For 9.1 and 5.2 Gbyte Capacity Drives Only)
Mode
Description
0
Data Mode (same as Mode 2)
2
Data Mode
3
Descriptor Mode
Chapter 2
2-103
SCSI-2 Drive Commands
Table 2-91
SCSI-2 Drive Command Set
Read Long Command (3EH)
Read Long Command (3EH)
This command reads data starting at the specified Logical Block
Address, including ECC data. Read data is not corrected using ECC.
Table 2-95
Read Long Command CDB
Byte
7
6
0
1
5
4
3
2
1
Operation Code (3EH)
Logical Unit Number
(0)
Reserved (0)
RelAdr
2
Starting Logical Block Address (MSByte)
3
Starting Logical Block Address
4
Starting Logical Block Address
5
Starting Logical Block Address (LSByte)
6
Reserved (0)
7
Transfer Length (MSByte)
8
Transfer Length (LSByte)
9
2-104
0
PBA
SC
Reserved (0)
Flag
Link
Chapter 2
SCSI-2 Drive Command Set
Read Long Command (3EH)
The Transfer Length field specifies the number of bytes
of data and ECC information to be read:
• 4096 media = 4760 bytes (4096 data + 664 pointer,
CRC, pad, & ECC) For 9.1 Gbyte Capacity drives
only.
• 2048 media = 2380 bytes (2048 data + 332 pointer,
CRC, pad, & ECC) For 5.2 Gbyte Capacity drives
only.
• 1K media = 1200 bytes (1024 data + 176 pointer, CRC,
pad, &ECC)
• 512 media = 610 bytes (512 data + 98 pointer, CRC,
pad, &ECC)
• All other numbers are rejected unless SC = 1
PBA
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
SC
A Sector Count bit of 1 indicates the transfer length is
represented in sectors rather than bytes. A "sector"
consists of 2380 bytes for 2K media, 1200 bytes for 1K
media, or 610 bytes for 512 media.
A Sector Count bit of 0 indicates the transfer length is
represented in bytes.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
NOTE
When this command is executed with 14X 512 or 1024 byte/sector media,
the drive will return a CHECK CONDITION status. The sense key/
additional sense code will be set to ILLEGAL REQUEST/INVALID
COMMAND.
Chapter 2
2-105
SCSI-2 Drive Commands
Transfer
Length
SCSI-2 Drive Command Set
Write Long Command (3FH)
Write Long Command (3FH)
This command writes data starting at the specified Logical Block
Address, without using ECC generation circuitry. The ECC field is also
written with data transferred to the drive.
Table 2-96
Write Long Command CDB
Byte
7
6
0
1
4
3
2
1
0
Operation Code (3FH)
Logical Unit Number
(0)
Reserved (0)
RelAdr
2
Starting Logical Block Address (MSByte)
3
Starting Logical Block Address
4
Starting Logical Block Address
5
Starting Logical Block Address (LSByte)
6
Reserved (0)
7
Transfer Length (MSByte)
8
Transfer Length (LSByte)
9
NOTE
5
PBA
SC
Reserved (0)
Flag
Link
The 9.1 and 5.2 Gbyte capacity drives cannot Format, Erase, Write, or
Write and Verify 650 Mbyte and 1.3-Gbyte optical disks. The 2.6 Gbyte
capacity drives cannot Format, Erase, Write, or Write and Verify 650
Mbyte optical disks. If this command is issued with any of these drive/
media combinations, a CHECK CONDITION status will result with the
Sense Key/Additional Sense Code set to Data Protect/Write Protected.
2-106
Chapter 2
SCSI-2 Drive Command Set
Write Long Command (3FH)
The Transfer Length field specifies the number of bytes
of data and ECC information to be written.
• 4096 media = 4760 bytes (4096 data + 664 pointer,
CRC, pad, & ECC) For 9.1 Gbyte Capacity drives
only.
• 2048 media = 2380 bytes (2048 data + 332 pointer,
CRC, pad, & ECC) For 5.2 Gbyte Capacity drives
only.
• 1K media = 1200 bytes (1024 data + 176 pointer, CRC,
pad, &ECC)
• 512 media = 610 bytes (512 data + 98 pointer, CRC,
pad, &ECC)
• All other numbers are rejected unless SC = 1
PBA
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
SC
A Sector Count bit of 1 indicates the transfer length is
represented in sectors rather than bytes. A "sector"
consists of 2380 bytes for 2K media, 1200 bytes for 1K
media or 610 bytes 512 media.
A Sector Count bit of 0 indicates the transfer length is
represented in bytes.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
NOTE
If this command is executed for write-once disks, the drive returns a
CHECK CONDITION status with the Sense Key/Additional Sense Code
set to Illegal Request/Invalid Command Operation Code.
Chapter 2
2-107
SCSI-2 Drive Commands
Transfer
Length
SCSI-2 Drive Command Set
Write Long Command (3FH)
NOTE
When this command is executed with 14X 512 or 1024 byte/sector media,
the drive will return a CHECK CONDITION status. The sense key/
additional sense code will be set to ILLEGAL REQUEST/INVALID
COMMAND.
2-108
Chapter 2
SCSI-2 Drive Command Set
Log Select Command (4CH)
This command clears drive resident logs.
Table 2-97
Log Select Command CDB
Byte
6
5
4
3
0
Operation Code (4CH)
1
Reserved (0)
2
PC (01H)
2
1
0
Flag
Link
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
Reserved (0)
6
Reserved (0)
7
Parameter List Length (MSByte) (0)
8
Parameter List Length (LSByte) (12)
(See Table 2-98 on page 2-110)
9
NOTE
7
Reserved (0)
Initiators should issue LOG SENSE commands prior to issuing LOG
SELECT commands to determine supported pages and page lengths.
The ONLY capability the initiator is given via the Log Select command is
to reset the cumulative logs. Parameter code and parameter information
is listed in Table 2-99 on page 2-110.
Chapter 2
2-109
SCSI-2 Drive Commands
Log Select Command (4CH)
SCSI-2 Drive Command Set
Log Select Command (4CH)
Parameter List Data
Table 2-98
Parameter List Data for Byte 8 of the Log Select Command
Byte
Table 2-99
7
6
5
4
3
2
1
0
Page Code (Table 2-99 on page 2-110)
1
Reserved (0)
2
Reserved (0)
3
Page Length (08)
4
Parameter Code (MSByte)
5
Parameter Code (LSByte)
6
Reserved (0)
7
Password Parameter Length (04)
8
Password Parameter Information (MSByte)
(Table 2-99 on page 2-110)
9
Password Parameter Information
10
Password Parameter Information
11
Password Parameter Information (LSByte)
0
Log Select Command
Page
Code
Description
Parameter
Code
Password
Parameter
Information
2
Write Error Counter Page
8000
4A4F454C
3
Read Error Counter Page
8000
4A6F686E
5
Verify Error Counter Page
8000
45726963
7
Last N error Events Page
1000
53746576
33
Erase Error Counter Page
8000
416C5020
34
Blank Check Counter Page
8000
47657269
2-110
Chapter 2
SCSI-2 Drive Command Set
Log Sense Command (4DH)
This command provides a means for the initiator to manage statistical
information maintained by the drive.
Table 2-100
Log Sense Command CDB
Byte
7
6
5
4
3
0
Operation Code (4DH)
1
Reserved (0)
2
PC (01H)
2
Reserved (0)
4
Reserved (0)
5
Parameter Pointer (MSByte)
(See Table 2-101 on page 2-112)
6
Parameter Pointer (LSByte)
7
Allocation Length (MSByte)
8
Allocation Length (LSByte)
9
Reserved (0)
Parameter
Pointer
Chapter 2
0
Page Code (See Table 2-101 on page 2-112)
3
Allocation
Length
1
Flag
Link
The number of parameter bytes, including the Log Page
and the parameter structures.
The Parameter Pointer field allows the initiator to
request parameter data beginning from a specific
parameter code to the maximum allocation length or
the maximum parameter code, whichever is less. Log
parameters within the specified log page are
transferred in ascending order according to parameter
code.
2-111
SCSI-2 Drive Commands
Log Sense Command (4DH)
SCSI-2 Drive Command Set
Log Sense Command (4DH)
Table 2-101
Log Sense Page Codes
Page
Code
Description
00H
Supported Log Pages
02H
Error Counter Page for Write Errors
(See Table 2-103 on page 2-113)
03H
Error Counter Page for Read Errors
(See Table 2-105 on page 2-114)
05H
Error Counter Page for Verify Errors
(See Table 2-107 on page 2-115)
07H
Last n Error Events Page (See Table 2-109 on page 2-116)
33H
Error Counter Page for Erase Errors (See Table 2-112 on
page 2-119)
34H
Error Counter Page for Blank Check Errors (See
Table 2-114 on page 2-120)
Supported Log Pages 00H
The supported log page returns the list of log pages implemented by the
target. Targets that implement the Log Sense command use this log
page.
Table 2-102
Supported Log Pages 00H
Byte
0
7
6
Rsvd (0)
5
4
3
2
0
Page Code (00H)
1
Reserved (0)
2
Page Length (n-3) (MSByte)
3
Page Length (n-3) (LSByte)
4
Supported Page List
n
Supported Page List
2-112
1
Chapter 2
SCSI-2 Drive Command Set
Log Sense Command (4DH)
Error Counter Page for Write Errors 02H
Byte
0
Table 2-104
7
6
Rsvd (0)
5
4
3
2
1
0
Page Code (02H)
1
Reserved (0)
2
Page Length (n-3) (MSByte)
3
Page Length (n-3) (LSByte)
4
Parameter Code (MSByte)
(See Table 2-104 on page 2-113 or Table 2-106 on page 2-114)
5
Parameter Code (LSByte)
6
Reserved (0)
7
Parameter Length (n-7)
8
Parameter Value
n
Parameter Value
Parameter Codes/Structure for Write Errors
Param.
Code
Length
Bytes
Description
1
12
Sectors Corrected with Retries
2
12
Total Number of Retry Attempts
3
12
Total Sectors Corrected
5
14
Total Bytes Processed
6
12
Total Number of Uncorrectable Sectors
0
46
Request for all pages
Chapter 2
2-113
SCSI-2 Drive Commands
Table 2-103
SCSI-2 Drive Command Set
Log Sense Command (4DH)
Table 2-105
Error Counter Page for Read Errors 03H
Byte
0
Table 2-106
7
6
Rsvd (0)
5
4
3
2
1
0
Page Code (03H)
1
Reserved (0)
2
Page Length (n-3) (MSByte)
3
Page Length (n-3) (LSByte)
4
Parameter Code (MSByte) (See Table 2-104 on page 2-113
or Table 2-106 on page 2-114)
5
Parameter Code (LSByte)
6
Reserved (0)
7
Parameter Length (n-7)
8
Parameter Value
n
Parameter Value
Parameter Codes/Structure for Read Errors
Param.
Code
Length
Bytes
Description
1
12
Sectors Corrected with Retries
2
12
Total Number of Retry Attempts
3
12
Total Sectors Corrected
5
14
Total Bytes Processed
6
12
Total Number of Uncorrectable Sectors
0
46
Request for all pages
2-114
Chapter 2
SCSI-2 Drive Command Set
Log Sense Command (4DH)
Error Counter Page for Verify Errors 05H
Byte
0
Table 2-108
7
6
Rsvd (0)
5
4
3
2
1
0
Page Code (05H)
1
Reserved (0)
2
Page Length (n-3) (MSByte)
3
Page Length (n-3) (LSByte)
4
Parameter Code (MSByte) (See Table 2-106 on page 2-114
or Table 2-108 on page 2-115)
5
Parameter Code (LSByte)
6
Reserved (0)
7
Parameter Length (n-7)
8
Parameter Value
n
Parameter Value
Parameter Codes/Structure for Verify Errors
Param.
Code
Length
Bytes
Description
1
12
Sectors Corrected with Retries
2
12
Total Number of Retry Attempts
3
12
Total Sectors Corrected
5
14
Total Bytes Processed
6
12
Total Number of Uncorrectable Sectors
0
46
Request for all pages
Chapter 2
2-115
SCSI-2 Drive Commands
Table 2-107
SCSI-2 Drive Command Set
Log Sense Command (4DH)
Table 2-109
Last N Error Events Page 07H
Byte
0
7
6
Rsvd (0)
5
4
3
2
0
Page Code (07H)
1
Reserved (0)
2
Page Length (n-3) (MSByte)
3
Page Length (n-3) (LSByte)
4
Parameter Pointer (MSByte)
(See Table 2-110 on page 2-117)
5
Parameter Pointer (LSByte)
6
Reserved (0)
7
Parameter Length (n-7)
8
Parameter Value
n
Parameter Value
2-116
1
Chapter 2
SCSI-2 Drive Command Set
Log Sense Command (4DH)
Parameter Pointers/Structure for Last N Error Events Page
Parameter
Pointer
Length
Bytes
Description
0
10
Number of Events in the Log
(Maximum Events = 50 or 250 for 9.1
Gbyte Drives)
1
34
Most Recent Error Event Log (See
Table 2-109 on page 2-116 or
Table 2-111 on page 2-118)
2
34
Next Most Recent Event (See
Table 2-109 on page 2-116 or Table
Table 2-111 on page 2-118)
50
34
Least recent Error Event (See
Table 2-109 on page 2-116 or
Table 2-111 on page 2-118)
.
.
.
.
.
.
.
.
.
0
Up to 1510
for 50 events;
up to 7510 for
250 events
Request for all pages
Chapter 2
2-117
SCSI-2 Drive Commands
Table 2-110
SCSI-2 Drive Command Set
Log Sense Command (4DH)
Table 2-111
Error Event Log
Byte
7
6
5
4
3
2
1
0
0
Log Type (1-read, 2-write, 3-erase, 4-verify, 5-blank check,
6-spin-up error, 7-loading error, 8-check condition)
1
Occurrence Count
2
Long
(1)
Power On Minutes
3
Half Seconds
4
Half Seconds Fraction (16 uSec) (MSByte)
5
Half Seconds Fraction (16 uSec) (LSByte)
6
Power On Hours (MS Byte)
7
Power On Hours
8
Power On Hours
9
Power On Hours (LSByte)
10
UMID Byte 5
11
UMID Byte 6
12
UMID Byte 7
13
UMID Byte 8
14
Internal Error Code (MSByte)
15
Internal Error Code
16
Internal Error Code
17
Internal Error Code (LSByte)
18
Logical Block Address (MSByte)
19
Logical Block Address
20
Logical Block Address
2-118
Chapter 2
SCSI-2 Drive Command Set
Log Sense Command (4DH)
Table 2-111
Error Event Log
Table 2-112
7
6
5
4
3
2
21
Logical Block Address (LSByte)
22
Physical Block Address (MSByte)
23
Physical Block Address
24
Physical Block Address
25
Physical Block Address (LSByte)
1
0
1
0
Error Counter Page for Erase Errors 33H
Byte
0
7
6
Rsvd (0)
5
4
3
2
Page Code (33H)
1
Reserved (0)
2
Page Length (n-3) (MSByte)
3
Page Length (n-3) (LSByte)
4
Parameter Code (MSByte) (See Table 2-113 on page 2-120 or
Table 2-115 on page 2-121)
5
Parameter Code (LSByte)
6
Reserved (0)
7
Parameter Length (n-7)
8
Parameter Value
n
Parameter Value
Chapter 2
2-119
SCSI-2 Drive Commands
Byte
SCSI-2 Drive Command Set
Log Sense Command (4DH)
Table 2-113
Table 2-114
Parameter Codes/Structure for Erase Errors
Param.
Code
Length
Bytes
Description
1
12
Sectors Corrected with Retries
2
12
Total Number of Retry Attempts
3
12
Total Sectors Corrected
5
14
Total Bytes Processed
6
12
Total Number of Uncorrectable Sectors
0
46
Request for all pages
Error Counter Page for Blank Check Errors 34H
Byte
0
7
6
Rsvd (0)
5
4
3
2
1
0
Page Code (34H)
1
Reserved (0)
2
Page Length (n-3) (MSByte)
3
Page Length (n-3) (LSByte)
4
Parameter Code (MSByte) (See Table 2-115 on page 2-121)
5
Parameter Code (LSByte)
6
Reserved (0)
7
Parameter Length (n-7)
8
Parameter Value
n
Parameter Value
2-120
Chapter 2
SCSI-2 Drive Command Set
Log Sense Command (4DH)
Parameter Codes/Structure for Blank Check Errors
SCSI-2 Drive Commands
Table 2-115
Param.
Code
Length
Bytes
Description
1
12
Sectors Corrected with Retries
2
12
Total Number of Retry Attempts
3
12
Total Sectors Corrected
5
14
Total Bytes Processed
6
12
Total Number of Uncorrectable Sectors
0
46
Request for all pages
Chapter 2
2-121
SCSI-2 Drive Command Set
Mode Select (Group 2) Command (55H)
Mode Select (Group 2) Command (55H)
This command sets optical disk, drive unit, or controller unit
parameters.
Table 2-116
Mode Select (Group 2) Command CDB
Byte
0
1
7
6
5
4
3
2
Logical Unit Number
(0)
PF
(1)
Reserved (0)
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
Reserved (0)
6
Reserved (0)
7
Parameter List Length (MSByte)
8
Parameter List Length (LSByte)
SP
0
Operation Code (55H)
2
9
1
Reserved (0)
SP
Flag
Link
A Save Pages bit of 1 indicates that the target performs
the specified MODE SELECT operation, and saves all
the savable pages to non-volatile RAM. The pages are
only saved if different from those currently saved.
A Save Pages bit of 0 indicates the target performs the
specified MODE SELECT operation, and does not save
any pages.
2-122
Chapter 2
SCSI-2 Drive Command Set
Mode Select (Group 2) Command (55H)
The Mode Select Parameter List contains an 8-byte
header followed by 0 or 1 block descriptors, and followed
by 0 or more pages (see Table 2-117 on page 2-123).
Table 2-117
Mode Select Header
Byte
7
6
5
4
3
2
0
Reserved (0)
1
Reserved (0)
2
Medium Type
3
Reserved (0)
4
Reserved (0)
5
Reserved (0)
6
Block Descriptor Length (MSByte)
7
Block Descriptor Length (LSByte)
Medium Type
Block
Descriptor
Length
Chapter 2
1
0
The Medium Type field will be set to 00H (default, only
one medium type supported), 02H (write-once optical
disks) or 03H (optical reversible or erasable medium).
The Block Descriptor Length specifies the length in
bytes of the block descriptor, equal to 0 or 8. A Block
Descriptor Length of 0 indicates that no block
descriptors are included in the parameter list. This
condition is not considered an error.
2-123
SCSI-2 Drive Commands
Parameter List
Length
This field specifies the length in bytes of the MODE
SELECT parameter list that the initiator will transfer
to the drive during the DATA OUT phase. A length of 0
indicates that no data will be transferred. This
condition is not considered an error.
SCSI-2 Drive Command Set
Mode Select (Group 2) Command (55H)
Table 2-118
Mode Select Block Descriptor
Byte
NOTE
7
6
5
4
3
2
0
Density Code
1
Number of Blocks (MSByte)
2
Number of Blocks
3
Number of Blocks (LSByte)
4
Reserved (0)
5
Block Length (MSByte)
6
Block Length
7
Block Length (LSByte)
1
0
All fields in the Block Descriptor have no effect on the drive.
Refer to “Mode Sense (Group 0) Command (1AH)” on page 2-54 for
detailed information on each page.
2-124
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 2) Command (5AH)
Table 2-119
Mode Select (Group 2) Command CDB
Byte
7
6
0
1
5
4
3
2
1
0
Operation Code (5AH)
Logical Unit Number
(0)
2
Rsvd
(0)
PC
DBD
Reserved (0)
Page Code
3-6
Reserved (0)
7
Allocation Length (MSByte)
8
Allocation Length (LSByte)
9
Reserved (0)
Flag
Link
DBD
A disable block descriptors (DBD) bit of 0 (default)
indicates that block descriptors are provided.
PC
Page control defines the type of parameter values to be
returned as follows:
00 - Current Values
01 - Changeable Values
10 - Default Values
11 - Saved Values
Page Code
Page code values are the same as for the Mode Select
(Group 0) command. If the page code is specified as 00H
or 3FH, all the pages are returned.
Allocation
Length
Chapter 2
Indicates the number of bytes that the indicator has
allocated for return of this data. A length of 0 indicates
that no data will be returned. This condition is not
considered an error. The drive will terminate the data in phase when the allocation length has been
transferred or when all available data has been
transferred to the initiator, whichever is less.
2-125
SCSI-2 Drive Commands
Mode Sense (Group 2) Command (5AH)
SCSI-2 Drive Command Set
Mode Sense (Group 2) Command (5AH)
Table 2-120
Mode Sense Header
Byte
7
6
5
4
3
2
0
Mode Data Length (MSByte)
1
Mode Data Length (LSByte)
2
Medium Type
3
WP
Reserved (0)
Cache
(1)
0
Reserved (0)
4
Reserved (0)
5
Reserved (0)
6
Block Descriptor Length (MSByte)
7
Block Descriptor Length (LSByte)
Mode Data
Length
1
This field specifies the length in bytes of the MODE
SENSE data to follow.
Medium Type
The Medium Type field is set to 00H (default, only one
medium type is supported), 02H (write-once optical
disks), or 03H (rewritable optical disks), depending on
the drive condition (00H if no disk or not ready, and 02H
or 03H if it is ready to access the disk).
WP
A write protect bit of 1 indicates that the optical disk in
the drive is write protected.
2-126
Chapter 2
SCSI-2 Drive Command Set
Mode Sense (Group 2) Command (5AH)
The Cache bit of 1 indicates that caching is supported.
PS
The Parameters Savable bit of 1 indicates this
parameter page is savable in non-volatile storage.
Block Descriptor
Length
The Block Descriptor Length field specifies the length
in bytes of the block descriptor.
Table 2-121
Mode Sense Block Descriptor
Byte
NOTE
7
6
5
4
3
2
0
Density Codes
1
Number of Blocks (MSByte)
2
Number of Blocks
3
Number of Blocks (LSByte)
4
Reserved (0)
5
Block Length (MSByte)
6
Block Length
7
Block Length (LSByte)
1
0
Descriptions of each page can be found in “Mode Sense (Group 0)
Command (1AH)” on page 2-54.
Chapter 2
2-127
SCSI-2 Drive Commands
Cache
SCSI-2 Drive Command Set
Read (Group 5) Command (A8H)
Read (Group 5) Command (A8H)
This command reads data from the specified logical block address.
NOTE
The Mode Select Commands (15H, 55H) impact read, write, format, and
erase commands.
Table 2-122
Read (Group 5) Command CDB
Byte
7
0
1
6
5
4
3
2
Logical Unit Number
(0)
DPO
FUA
Reserved (0)
Logical Block Address (MSByte)
3
Logical Block Address
4
Logical Block Address
5
Logical Block Address (LSByte)
6
Transfer Length (MSByte)
7
Transfer Length
8
Transfer Length
9
Transfer Length (LSByte)
10
Reserved (0)
2-128
0
Operation Code (A8H)
2
11
1
PBA
Reserved (0)
Flag
RelAdr
Link
Chapter 2
SCSI-2 Drive Command Set
Read (Group 5) Command (A8H)
DPO
A DPO bit of 0 instructs the target it may store
readahead data in the cache after the read data has
been transferred to the initiator.
NOTE
The DPO bit is ignored in 9.1 and 5.2 Gbyte capacity drives.
FUA
A Force Unit Access bit of 1 indicates that the drive
reads from the disk.
An FUA bit of 0 indicates that data may come from the
cache memory.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
Transfer
Length
The Transfer Length field specifies the number of
contiguous logical blocks of data to be transferred.
A value of 0 indicates that no blocks will be transferred
and is not considered an error.
PBA
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
NOTE
For Write-Once optical disks, blank checking is performed following a
failed read. If the sector is blank, the sense key/additional sense code will
be set to BLANK CHECK/Blank Sector Detected.
Chapter 2
2-129
SCSI-2 Drive Commands
A Disable Page Out bit of 1 instructs the target not to
store readahead data in cache after the read data has
been transferred to the initiator.
SCSI-2 Drive Command Set
Read (Group 5) Command (A8H)
NOTE
When this command is used with 14X 512 or 1024 byte/sector media,
setting the PBA bit will cause the drive to return a CHECK CONDITION
status. The sense key/additional sense code will be set to ILLEGAL
REQUEST/INVALID FIELD in CDB.
2-130
Chapter 2
SCSI-2 Drive Command Set
Write (Group 5) Command (AAH)
This command writes data starting at the specified logical block address.
NOTE
The Mode Select Commands (15H, 55H) impact read, write, format, and
erase commands.
Table 2-123
Write (Group 5) Command CDB
Byte
7
6
0
1
4
3
2
1
0
EBP
Rsvd
(0)
RelAdr
Flag
Link
Operation Code (AAH)
Logical Unit Number
(0)
DPO
FUA
2
Logical Block Address (MSByte)
3-4
Logical Block Address
5
Logical Block Address (LSByte)
6
Transfer Length (MSByte)
7-8
Transfer Length
9
Transfer Length (LSByte)
10
Reserved (0)
11
NOTE
5
PBA
ErsCntl
Reserved (0)
For Write-Once media, Byte 11, Bit 7 and Bit 6 are reserved (0).
DPO
A Disable Page Out bit of 1 instructs the target not to
store the data in the cache after it has been transferred
to the media.
A DPO bit of 0 instructs the target to store the data in
the cache after it has been transferred to the media.
.
Chapter 2
This bit is ignored
2-131
SCSI-2 Drive Commands
Write (Group 5) Command (AAH)
SCSI-2 Drive Command Set
Write (Group 5) Command (AAH)
FUA
A Force Unit Access bit of 1 indicates that data is
written directly to the disk.
An FUA bit of 0 indicates that write caching will be
allowed.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
EBP
If the Erase By-Pass bit is set to 0, an erase is
automatically performed before writing the data.
An EBP bit of 1 suppresses the erase operation.
Transfer
Length
The Transfer Length field indicates the number of
contiguous logical blocks to be transferred for this
command.
A value of 0 indicates that no blocks will be transferred
and is not considered an error.
PBA
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
ErsCntl
NOTE
The Erase Control bit is identical to the Erase Bypass
bit.
The 9.1 and 5.2 Gbyte capacity drives cannot Format, Erase, Write, or
Write and Verify 650 Mbyte and 1.3-Gbyte optical disks. The 2.6 Gbyte
capacity drives cannot Format, Erase, Write, or Write and Verify 650
Mbyte optical disks. If this command is issued with any of these drive/
media combinations, a CHECK CONDITION status will result with the
Sense Key/Additional Sense Code set to Data Protect/Write Protected.
2-132
Chapter 2
SCSI-2 Drive Command Set
Write (Group 5) Command (AAH)
When this command is used with 14X 512 OR 1024 byte/sector media,
setting the ErsCntl bit or the PBA bit will cause the drive to return a
CHECK CONDITION status. The sense key/additional sense code will be
set to ILLEGAL REQUEST/INVALID FIELD in CDB.
NOTE
For write-once optical disks, blank checking is performed before writing
data. If a written block is detected during blank checking, the drive will
return a CHECK CONDITION status. The sense key/additional sense
code will be set to BLANK CHECK/Overwrite Attempted.
Chapter 2
2-133
SCSI-2 Drive Commands
NOTE
SCSI-2 Drive Command Set
Erase (Group 5) Command (ACH)
Erase (Group 5) Command (ACH)
This command erases data from the specified logical block address. This
command can only be used with rewritable disks.
NOTE
The Mode Select Commands (15H, 55H) impact read, write, format, and
erase commands.
Table 2-124
Erase (Group 5) Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Rsvd
(0)
RelAdr
Operation Code (ACH)
Logical Unit Number
(0)
Reserved (0)
ERA
2
Logical Block Address (MSByte)
3
Logical Block Address
4
Logical Block Address
5
Logical Block Address (LSByte)
6
Transfer Length (MSByte)
7
Transfer Length
8
Transfer Length
9
Transfer Length (LSByte)
10
Reserved (0)
11
2-134
PBA
Reserved (0)
Flag
Link
Chapter 2
SCSI-2 Drive Command Set
Erase (Group 5) Command (ACH)
The 9.1 and 5.2 Gbyte capacity drives cannot Format, Erase, Write, or
Write and Verify 650 Mbyte and 1.3-Gbyte optical disks. The 2.6 Gbyte
capacity drives cannot Format, Erase, Write, or Write and Verify 650
Mbyte optical disks. If this command is issued with any of these drive/
media combinations, a CHECK CONDITION status will result with the
Sense Key/Additional Sense Code set to Data Protect/Write Protected.
NOTE
If this command is executed for write-once disks, the drive returns a
CHECK CONDITION status with the Sense Key/Additional Sense Code
set to Illegal Request/Invalid Command Operation Code.
ERA
An Erase All bit of 1 indicates that all remaining blocks
are erased, starting from the logical block address to the
end of the disk. The transfer length must be set to 0.
An ERA bit of 0 indicates that all blocks are erased,
starting from the logical block address to the end of the
specified transfer length.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
Transfer
Length
PBA
The Transfer Length field specifies the number of
contiguous logical blocks of data to be erased for this
command. A value of 0 indicates that no blocks will be
erased and is not considered an error.
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
Chapter 2
2-135
SCSI-2 Drive Commands
NOTE
SCSI-2 Drive Command Set
Erase (Group 5) Command (ACH)
NOTE
When this command is executed with 14X 512 or 1024 byte/sector media,
the drive will return a CHECK CONDITION status. The sense key/
additional sense code will be set to ILLEGAL REQUEST/INVALID
COMMAND.
2-136
Chapter 2
SCSI-2 Drive Command Set
Write and Verify (Group 5) Command (AEH)
Writes data to the optical disk and then verifies the write by reading the
written data and checking the error correction code.
NOTE
The Mode Select Commands (15H, 55H) impact read, write, format, and
erase commands.
Table 2-125
Write and Verify (Group 5) CDB
Byte
7
6
5
4
0
1
2
1
0
EBP
Rsvd (0)
RelAdr
Flag
Link
Operation Code (AEH)
Logical Unit Number (0)
DPO
Rsvd (0)
2
Logical Block Address (MSByte)
3-4
Logical Block Address
5
Logical Block Address (LSByte)
6
Transfer Length (MSByte)
7-8
Transfer Length
9
Transfer Length (LSByte)
10
Reserved (0)
11
NOTE
3
PBA
ErsCntl
Reserved (0)
For Write-Once media, Byte 11, Bit 7 and Bit 6 are reserved (0).
DPO
A Disable Page Out bit of 1 instructs the target not to
store the data in the cache after it has been transferred
to the media.
A DPO bit of 0 instructs the target to store the data in
the cache after it has been transferred to the media.
This bit is ignored.
Chapter 2
2-137
SCSI-2 Drive Commands
Write and Verify (Group 5) Command (AEH)
SCSI-2 Drive Command Set
Write and Verify (Group 5) Command (AEH)
EBP
An Erase By-Pass bit of 0 indicates an erase
automatically performs before writing the data.
An EBP bit of 1 suppresses the erase operation.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
Transfer
Length
PBA
The Transfer Length field indicates the number of
contiguous logical blocks to be transferred for this
command. A value of 0 indicates that no blocks will be
transferred and is not considered an error.
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
ErsCntl
The Erase Control bit is identical to the Erase Bypass
bit.
NOTE
The 9.1 and 5.2 Gbyte capacity drives cannot Format, Erase, Write, or
Write and Verify 650 Mbyte and 1.3-Gbyte optical disks. The 2.6 Gbyte
capacity drives cannot Format, Erase, Write, or Write and Verify 650
Mbyte optical disks. If this command is issued with any of these drive/
media combinations, a CHECK CONDITION status will result with the
Sense Key/Additional Sense Code set to Data Protect/Write Protected.
NOTE
For write-once optical disks, blank checking is performed before writing
data. If a written block is detected during blank checking, the drive will
return a CHECK CONDITION status. The sense key/additional sense
code will be set to BLANK CHECK/Overwrite Attempted.
2-138
Chapter 2
SCSI-2 Drive Command Set
Write and Verify (Group 5) Command (AEH)
When this command is used with 512 byte/sector 14X media or 1025 byte/
sector 14X media, setting the PBA bit or the ErsCntl bit will cause the
drive to return a CHECK CONDITION status. The sense key/additional
sense code will be set to ILLEGAL REQUEST/Invalid Field in CDB.
Chapter 2
2-139
SCSI-2 Drive Commands
NOTE
SCSI-2 Drive Command Set
Verify (Group 5) Command (AFH)
Verify (Group 5) Command (AFH)
This command verifies the data starting from the specified logical block
address by checking the error correction code.
This command has two modes of operation, depending on the value of the
BV bit. If the Blk Vfy bit is set to 0, it verifies previously written data
integrity starting at the specified Logical Block Address by reading the
data and checking the Error Correction Code. The verification threshold
is set to approximately half of the error correction capability.
Table 2-126
Verify (Group 5) CDB
Byte
0
1
7
6
5
4
3
2
Logical Unit Number
(0)
DPO
Rsvd
(0)
Blk
Vfy
Logical Block Address (MSByte
3
Logical Block Address
4
Logical Block Address
5
Logical Block Address (LSByte)
6
Verification Length (MSByte)
7
Verification Length
8
Verification Length
9
Verification Length (LSByte)
10
Reserved (0)
2-140
0
Rsvd
(0)
RelAdr
Flag
Link
Operation Code (AFH)
2
11
1
Reserved (0)
Chapter 2
SCSI-2 Drive Command Set
Verify (Group 5) Command (AFH)
DPO
A DPO bit of 0 instructs the target to retain the data in
the cache after it has been verified.
This bit is ignored.
Blk Vfy
A Blank Verify bit of 1 indicates the drive verifies that
sectors are erased.
A Blk Vfy bit of 0 indicates the drive verifies written
data integrity.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
Verification
Length
Chapter 2
Specifies the number of contiguous logical blocks of data
to be verified. A value of 0 indicates that no blocks will
be verified and is not considered an error.
2-141
SCSI-2 Drive Commands
A Disable Page Out bit of 1 instructs the target not to
retain the data in the cache after it has been verified.
SCSI-2 Drive Command Set
Read Defect Data (Group 5) Command (B7H)
Read Defect Data (Group 5) Command (B7H)
This command reads optical disk defect information. The data returned
starts with an 8-byte header, followed by one or more defect descriptors.
Table 2-127
Read Defect Data (Group 5) Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (B7H)
Logical Unit Number
(0)
PList
GList
Defect List Format
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
Reserved (0)
6
Allocation Length (MSByte)
7
Allocation Length
8
Allocation Length
9
Allocation Length (LSByte)
10
Reserved (0)
11
PList &GList
Reserved (0)
Link
Flag
A Primary List bit of 0 and a Grown List bit of 1
indicates the drive will return the contents of the
Primary Defect List (PDL) and the Secondary Defect
List (SDL).
A PList bit of 1 and a GList bit of 0 indicates the drive
will return the contents of PDL.
A PList bit of 1 and a GList bit of 1 indicates the drive
will return the contents of the PDL and the SDL.
2-142
Chapter 2
SCSI-2 Drive Command Set
Read Defect Data (Group 5) Command (B7H)
Allocation
Length
Table 2-128
This field specifies the Defect List Format that is
returned. Only the Physical Sector Format (5) is
supported. If the Block Format (0) is specified, the
defect list will be returned in Physical Sector Format
and a CHECK CONDITION status will be returned at
the completion of the command with the sense key/
additional sense code set to RECOVERED ERROR/
Defect List Not Available.
Specifies the number of bytes that the initiator has
allocated for return of this data. A length of 0 indicates
that no data will be returned. This condition is not
considered an error. The drive will terminate the data
— in phase when the allocation length has been
transferred or when all defect data has been transferred
to the initiator, whichever is less.
Read Defect Data Defect List Header
Byte
7
6
5
0
1
4
3
2
1
0
Reserved (0)
Reserved (0)
PList
GList
Defect List Format
2
Reserved (0)
3
Reserved (0)
4
Defect List Length (MSByte)
5
Defect List Length
6
Defect List Length
7
Defect List Length (LSByte)
PList
A primary List bit of 1 indicates that the Primary List
of defects was returned.
GList
A Grown List bit of 1 indicates that the Grown List of
defects was returned.
Chapter 2
2-143
SCSI-2 Drive Commands
Defect List
Format
SCSI-2 Drive Command Set
Read Defect Data (Group 5) Command (B7H)
Defect List
Format
Defect List
Length
Table 2-129
This field will be set to the Defect List Format that was
indicated in byte 1 of the CDB, which specifies the
format of the Defect List data returned by the drive.
This field specifies the total length in bytes of the defect
descriptors (see Table 2-129 on page 2-144).
Physical Sector Format Defect Descriptor
Byte
7
6
5
4
3
2
1
0
0
Physical Track Number of the Defect (MSByte)
1
Physical Track Number of the Defect
2
Physical Track Number of the Defect (LSByte)
3
Reserved (0)
4
Reserved (0)
5
Reserved (0)
6
Reserved (0)
7
Defective Physical Sector Number
2-144
Chapter 2
SCSI-2 Drive Command Set
Read Long Command (DEH)
This command reads data starting at the specified Logical Block
Address, including ECC data. Read data is not corrected using ECC.
Table 2-130
Read Long Command CDB
Byte
7
6
5
4
3
2
0
Operation Code (DEH)
1
Reserved (0)
1
RelAdr
2
Starting Logical Block Address (MSByte)
3
Starting Logical Block Address
4
Starting Logical Block Address
5
Starting Logical Block Address (LSByte)
6
Reserved (0)
7
Transfer Length (MSByte)
8
Transfer Length (LSByte)
9
PBA
Chapter 2
SC
Reserved (0)
0
Flag
Link
2-145
SCSI-2 Drive Commands
Read Long Command (DEH)
SCSI-2 Drive Command Set
Read Long Command (DEH)
Transfer
Length
The Transfer Length field specifies the number of bytes
of data and ECC information to be read:
4096 media = 4760 bytes (4096 data + 664 pointer, CRC,
pad and ECC). For 9.1 Gbyte Capacity drives only.
2048 media = 2380 bytes (2048 data + 332 pointer, CRC,
pad, and ECC). For 5.2 Gbyte capacity drives only.
1K media = 1200 bytes (1024 data + 176 pointer, CRC,
pad, and ECC).
512 media = 610 bytes (512 data + 98 pointer, CRC, pad,
and ECC).
All other numbers are rejected unless SC = 1.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
PBA
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
SC
A Sector Count bit of 1 indicates the transfer length is
represented in sectors rather than bytes. A "sector"
consists of 2380 bytes for 2K media, 1200 bytes for 1K
media or 610 bytes for 512 media.
A Sector Count bit of 0 indicates the transfer length is
represented in bytes.
NOTE
When this command is executed with 14X 512 or 1024 byte/sector media,
the drive will return a CHECK CONDITION status. The sense key/
additional sense code will be set to ILLEGAL REQUEST/INVALID
COMMAND.
2-146
Chapter 2
SCSI-2 Drive Command Set
Write Long Command (DFH)
This command writes data starting at the specified Logical Block
Address, without using ECC generation circuitry. The ECC field is also
written with data transferred to the drive.
Table 2-131
Write Long Command CDB
Byte
7
6
0
1
4
3
2
1
0
Operation Code (DFH)
Logical Unit Number
(0)
Reserved (0)
RelAdr
2
Starting Logical Block Address (MSByte)
3
Starting Logical Block Address
4
Starting Logical Block Address
5
Starting Logical Block Address (LSByte)
6
Reserved (0)
7
Transfer Length (MSByte)
8
Transfer Length (LSByte)
9
NOTE
5
PBA
SC
Reserved (0)
Flag
Link
The 9.1 and 5.2 Gbyte capacity drives cannot Format, Erase, Write, or
Write and Verify 650 Mbyte and 1.3-Gbyte optical disks. The 2.6 Gbyte
capacity drives cannot Format, Erase, Write, or Write and Verify 650
Mbyte optical disks. If this command is issued with any of these drive/
media combinations, a CHECK CONDITION status will result with the
Sense Key/Additional Sense Code set to Data Protect/Write Protected.
Chapter 2
2-147
SCSI-2 Drive Commands
Write Long Command (DFH)
SCSI-2 Drive Command Set
Write Long Command (DFH)
Transfer
Length
The Transfer Length field specifies the number of bytes
of data and ECC information to be read:
4096 media = 4760 bytes (4096 data + 664 pointer, CRC,
pad, & ECC). For 9.1 Gbyte Capacity drives only.
2048 media = 2380 bytes (2048 data + 332 pointer, CRC,
pad, and ECC). For 5.2 Gbyte capacity drives only.
1K media = 1200 bytes (1024 data + 176 pointer, CRC,
pad, &ECC).
512 media = 610 bytes (512 data + 98 pointer, CRC, pad,
&ECC).
All other numbers are rejected unless SC = 1.
Rel Adr
A relative address bit of one indicates that logical block
address specified is a two’s complement offset from the
last logical block address accessed.
A value of 0 indicates that the logical block address is an
absolute address.
PBA
A Physical Block Address bit of 1 indicates that physical
block addressing is used.
A PBA bit of 0 indicates that logical block addressing is
used.
SC
A Sector Count bit of 1 indicates the transfer length is
represented in sectors rather than bytes. A "sector"
consists of 2380 bytes for 2048 media, 1200 bytes for
1024 media or 610 bytes for 512 media.
A Sector Count bit of 0 indicates the transfer length is
represented in bytes.
NOTE
If this command is executed for write-once disks, the drive returns a
CHECK CONDITION status with the Sense Key/Additional Sense Code
set to Illegal Request/Invalid Command Operation Code.
2-148
Chapter 2
SCSI-2 Drive Command Set
Write Long Command (DFH)
When this command is executed with 14X 512 or 1024 byte/sector media,
the drive will return a CHECK CONDITION status. The sense key/
additional sense code will be set to ILLEGAL REQUEST/INVALID
COMMAND.
Chapter 2
2-149
SCSI-2 Drive Commands
NOTE
SCSI-2 Drive Command Set
Write Long Command (DFH)
2-150
Chapter 2
Jukebox SCSI-2 Commands
3
Jukebox SCSI-2 Command Set
Chapter 3
3-1
Jukebox SCSI-2 Command Set
Numerical List of Commands
Numerical List of Commands
Table 3-1
Numerical List of Commands
Code
(hex.)
Name
Description
Page
Number
00H
Test Unit Ready
Checks to determine if the
optical library is ready.
3-6
01H
Rezero Unit
Sets the library to a specific
predefined state.
3-7
03H
Request Sense
Determines a specific error
condition when the library
fails to successfully complete
a command.
3-8
07H
Initialize
Element Status
Checks all elements for
media.
3-12
0CH
Rotate Mailslot
Command
Controls
Controls mailslot rotation.
3-13
12H
Inquiry
Provides vendor, product,
and revision information
3-14
16H
Reserve
Reserves the library for use
by a single SCSI initiator.
3-18
17H
Release
Releases the library for use
by multiple SCSI initiators.
3-20
1AH
Mode Sense
Determines element
parameter information
3-21
1CH
Receive
Diagnostic
Results
Retrieves diagnostic test
information resulting from
the Send Diagnostic
Command
3-33
3-2
Chapter 3
Jukebox SCSI-2 Command Set
Numerical List of Commands
Table 3-1
Numerical List of Commands
Code
(hex.)
Name
Description
Page
Number
Send Diagnostic
Causes the library to
perform predefined
diagnostic test/exerciser
routines.
3-35
1EH
Prevent/Allow
Medium
Removal
Prevents or allows the
manual insertion or removal
of media through the
mailslot.
3-37
2BH
Position To
Element
Positions the specified
transport element in front of
the specified destination
element.
3-38
3BH
Write Buffer
Command
Writes data to the jukebox
3-39
3CH
Read Buffer
Command
Reads data from the jukebox
3-43
4DH
Log Sense
Retrieves statistical
information about the
library.
3-47
A5H
Move Medium
Moves media between
library elements.
3-64
A6H
Exchange
Medium
Exchanges media at the
source element address with
the destination element
address.
3-66
B8H
Read Element
Status
Retrieves the status of the
storage slots, mailslot,
drives, and picker.
3-68
Chapter 3
Jukebox SCSI-2 Commands
1DH
3-3
Jukebox SCSI-2 Command Set
Alphabetical List of Commands
Alphabetical List of Commands
Table 3-2
Alphabetical List of Commands
Code
(hex.)
Name
Description
Page
Number
A6H
Exchange
Medium
Exchanges media at the
source element address with
the destination element
address.
3-66
07H
Initialize
Element Status
Checks all elements for
media.
3-12
12H
Inquiry
Provides vendor, product, and
revision information
3-14
4DH
Log Sense
Retrieves statistical
information about the library.
3-47
1AH
Mode Sense
Determines element
parameter information
3-21
A5H
Move Medium
Moves media between library
elements.
3-64
2BH
Position To
Element
Positions the specified
transport element in front of
the specified destination
element.
3-38
1EH
Prevent/Allow
Medium
Removal
Prevents or allows the
manual insertion or removal
of media through the
mailslot.
3-37
3CH
Read Buffer
Command
Reads data from the jukebox.
3-43
B8H
Read Element
Status
Retrieves the status of the
storage slots, mailslot, drives,
and picker.
3-68
3-4
Chapter 3
Jukebox SCSI-2 Command Set
Alphabetical List of Commands
Table 3-2
Alphabetical List of Commands
Code
(hex.)
Description
Page
Number
1CH
Receive
Diagnostic
Results
Retrieves diagnostic test
information resulting from
the Send Diagnostic
Command
3-33
17H
Release
Releases the library for use by
multiple SCSI initiators.
3-20
03H
Request Sense
Determines a specific error
condition when the library
fails to successfully complete
a command.
3-8
16H
Reserve
Reserves the library for use
by a single SCSI initiator.
3-18
01H
Rezero Unit
Sets the library to a specific
predefined state.
3-7
0CH
Rotate Mailslot
Command
Controls
Controls mailslot rotation.
3-13
1DH
Send
Diagnostic
Causes the library to perform
predefined diagnostic test/
exerciser routines.
3-35
00H
Test Unit
Ready
Checks to determine if the
optical library is ready.
3-6
3BH
Write Buffer
Command
Writes data to the jukebox
3-39
Jukebox SCSI-2 Commands
NOTE
Name
Throughout this section, a Control Byte (0) is vendor unique and should
always be set to 0.
Chapter 3
3-5
Jukebox SCSI-2 Command Set
Test Unit Ready Command (00H)
Test Unit Ready Command (00H)
This command determines the READY state of the library. If the library
is in a ready state when it receives this command, it returns a GOOD
status. If the library is not ready when it receives the Test Unit Ready
Command, it returns a CHECK CONDITION with a sense key of NOT
READY.
Table 3-3
Test Unit Ready Command CDB
Byte
0
1
3-6
7
6
5
4
3
2
1
0
Operation Code (00H)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
Control Byte (0)
Chapter 3
Jukebox SCSI-2 Command Set
Rezero Unit Command (01H)
Rezero Unit Command (01H)
This command recalibrates the mechanical system and sets the library to
a specific predefined state.
Jukebox SCSI-2 Commands
Table 3-4
Rezero Unit Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (01H)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
Control Byte (0)
Chapter 3
3-7
Jukebox SCSI-2 Command Set
Request Sense Command (03H)
Request Sense Command (03H)
This command determines the specific error condition when the library
fails to successfully complete a command and returns a check condition
status. (Sense data is preserved for the initiator until retrieved by a
Request Sense Command or until the initiator sends another command.)
Codes are used to represent the error condition and this information can
be used to determine what type of error recovery procedure is
appropriate.
Table 3-5
Request Sense Command CDB
Byte
7
0
1
5
4
3
2
1
0
Operation Code (03H)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Allocation Length
5
Control Byte (0)
Allocation
Length
3-8
6
This field contains the number of data bytes to be
returned.
Chapter 3
Jukebox SCSI-2 Command Set
Request Sense Command (03H)
Table 3-6
Request Sense Data Parameter Block Format
Byte
7
0
Valid
6
5
4
3
2
1
Error Code (70H or 71H)
Jukebox SCSI-2 Commands
1
Reserved (0)
2
Reserved (0)
Sense Key (Table 3-7 on
page 3-10)
3-6
Information
7
Additional Sense Length (Table 3-7 on page 3-10)
8-11
Reserved (0)
12
Additional Sense Code (Table B-2 on page B-4)
13
Additional Sense Code Qualifier (Table B-2 on page B-4)
14
Reserved (0)
15
0
SKSV
Sense Key Specific (Table 3-8 on page 3-11)
16-17
Sense Key Specific
18-77
Additional Sense Bytes
Valid
A valid bit of "1" indicates the information field contains
valid information.
Error Code
Either 70H (current error) or 71H (deferred error).
Sense Key and
Additional
Sense Length See Table 3-7 on page 3-10.
Chapter 3
3-9
Jukebox SCSI-2 Command Set
Request Sense Command (03H)
Table 3-7
Sense Key - Additional Sense Length Values
Sense Key
Description
Additional Sense
Length
0H
No Sense
10
1H
Recovered Error
70
2H
Not Ready
10
4H
Hardware Error
70
5H
Illegal Request
10
6H
Unit Attention
10
BH
Aborted Command
10
Information
Contains the Element address in question on an Illegal
Request during a 21H or 3BH sense code.
Additional Sense
Code
The Additional Sense Code specifies detailed
information related to the error reported in the Sense
Key field. See Table B-2 on page B-4.
Additional Sense
Code Qualifier The Additional Sense Code Qualifier specifies detailed
information related to the Additional Sense Code. See
Table B-2 on page B-4.
SKSV
Sense Key
Specific
When set to 1, the Sense Key Specific bytes contains
valid data. When set to 0, Bytes 15, 16, and 17 are zero.
When the Sense Key field is set to Illegal Request (05H)
and SKSV is 1, the Sense Key Specific fields are defined
as shown in Table 3-8 on page 3-11.
Additional Sense
Bytes
This field may contain information when the Additional
Sense Length field contains a value greater than 10. See
Table B-5 on page B-8 and Table B-6 on page B-14.
3-10
Chapter 3
Jukebox SCSI-2 Command Set
Request Sense Command (03H)
Table 3-8
Sense Key Field = Illegal Request (05H) and SKSV Bit = 1
7
6
15
SKSV
(1)
C/D
5
4
Reserved (0)
3
BPV
16
Field Pointer (MSByte)
17
Field Pointer (LSByte)
C/D
2
1
0
Bit Pointer
1 = Illegal Parameter is in Command Descriptor Block.
0 = Illegal Parameter is in Data Out Phase.
BPV
1 = Bit pointer field is valid.
0 = Bit pointer field is invalid.
NOTE
Bit Pointer
Specifies which bit is in error. When a multiple bit field
is in error, the pointer points to the most significant bit
in the field.
Field Pointer
Specifies which byte is in error. Bytes are numbered
starting from 0. When a multiple-byte field is in error,
the pointer points to the most significant byte of the
field.
Bytes identified as being in error are not necessarily the bytes that need
to be changed to correct the problem.
Chapter 3
3-11
Jukebox SCSI-2 Commands
Byte
Jukebox SCSI-2 Command Set
Initialize Element Status Command (07H)
Initialize Element Status Command (07H)
This command checks all elements for optical disks and for relevant
status. This information is retained and can be accessed through the
Read Element Status Command (B8H). Refer to Table 3-70 on page 3-68.
Table 3-9
Initialize Element Status Command CDB
Byte
0
1
NOTE
7
6
5
4
3
2
1
0
Operation Code (07H)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
Control Byte (0)
This command takes a few minutes to complete
3-12
Chapter 3
Jukebox SCSI-2 Command Set
Rotate Mailslot Command (0CH)
Rotate Mailslot Command (0CH)
The host system may send this SCSI vendor-unique command to the
optical disk library to control mailslot rotation.
Rotate Mailslot Command CDB
Byte
7
6
0
1
5
4
3
2
1
0
Operation Code (0CH)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
Open
Open
Control Byte (0)
An Open value of 1 causes the mailslot to rotate out. An
Open value of 0 causes the mailslot to rotate in.
There are three exceptions:
• If another device, including the front panel, already has the mailslot
prevented or reserved.
• If there is an optical disk already in the transport element (picker).
• If the optical disk library is full.
Chapter 3
3-13
Jukebox SCSI-2 Commands
Table 3-10
Jukebox SCSI-2 Command Set
Inquiry Command (12H)
Inquiry Command (12H)
This command requests information describing the type of SCSI device.
This information includes the following:
• Vendor ID
• Product ID
• Product revision
Table 3-11
Inquiry Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (12H)
Logical Unit Number
(0)
Reserved (0)
2
VPD Identifier
3
Reserved (0)
4
Allocation Length
5
Control Byte (0)
EVPD
EVPD
A 0 in this bit requests Standard Inquiry Information.
A 1 in this bit requests the vital product data specified
by the VPD identifier field.
VPD Identifier If EVPD is 0, this field should be 0. If EVPD is 1, this
field will contain the code for the requested vital
product data page (Table 3-12 on page 3-15).
Allocation
Length
NOTE
The number of bytes reserved for returned data.
Vital Product data pages are not supported in “fx” model jukeboxes.
3-14
Chapter 3
Jukebox SCSI-2 Command Set
Inquiry Command (12H)
Table 3-12
Vital Product Data Page Codes
Page Code
Description
0
Supported vital product data pages
Unit serial number
C0H
Firmware information page
Inquiry Command Data
Table 3-13
Standard Inquiry Data Format
Byte
7
6
5
0
Peripheral Qualifier (0)
1
RMB
(1)
2
ISO Version (0)
3
AENC
(0)
4
3
2
0
Peripheral Device Type
(08H=Medium Changer).
Device-Type Qualifier (0)
TrmIOP
(0)
ECMA Version (0)
Reserved (0)
ANSI-Approved
Version (2)
Response Data Format (2)
4
Additional Length (1FH)
5-7
Reserved (0)
8-15
Vendor Identification (HP)
16-31
Product Identification
32-35
Product Revision Level
RMB
1
Removable medium bit. When this bit is set to 1,
medium is removable.
ANSI and
Response Data
Format
The returned value of 2 indicate compliance to X3131199x.
Chapter 3
3-15
Jukebox SCSI-2 Commands
80H
Jukebox SCSI-2 Command Set
Inquiry Command (12H)
AENC,
TrmIOP
Asynchronous event notification and the terminate I/O
process message are not supported.
Response Data
Format
Indicates the inquiry data format complies with X3131199X.
Vendor
Identification All unused bytes are filled with a blank space. (ASCII)
Product
Identification
String
All unused bytes are filled with a blank space. (ASCII)
Vital Product Data Pages
Table 3-14
Supported Vital Product Data Pages
Byte
0
7
6
5
Peripheral Qualifier
(0)
4
3
2
1
0
Peripheral Device Type (08H)
1
Page Code (0)
2
Reserved (0)
3
Page Length (03H)
4
0 (this page)
5
80H (Unit Serial Number Page)
6
C0H (Firmware Information Page - Vendor Unique)
3-16
Chapter 3
Jukebox SCSI-2 Command Set
Inquiry Command (12H)
Table 3-15
Unit Serial Number Page
Byte
0
6
5
4
Peripheral Qualifier
(0)
3
2
1
0
Peripheral Device Type (08H)
1
Page Code (80H)
2
Reserved (0)
3
Page Length (0CH)
4-15
Serial Number (ASCII)
Jukebox SCSI-2 Commands
Table 3-16
7
Firmware Information Page
Byte
0
7
6
5
Peripheral Qualifier
(0)
4
3
2
1
Peripheral Device Type (08H)
1
Page Code (C0H)
2
Reserved (0)
3
Page Length (0AH)
4-7
Controller Firmware Revision (x.xx, ASCII)
8-13
Controller Firmware Type Code (xxxxxx, ASCII)
Chapter 3
0
3-17
Jukebox SCSI-2 Command Set
Reserve Command (16H)
Reserve Command (16H)
This command reserves the library for use by a single SCSI initiator
when the library is connected to multiple initiators.
Table 3-17
Reserve Command CDB
Byte
7
6
5
4
0
3
2
1
0
Operation Code (16H)
1
Logical Unit Number
(0)
3rdPty
Third Party Device
ID
2
Reservation Identification
3
Element List Length (MSByte)
4
Element List Length (LSByte)
5
Control Byte (0)
3rdPty
Third Party
Device ID
Element
Element
When set to 1, the library is reserved for the SCSI
device specified in the Third Party Device ID field.
A third party device ID indicates identification of the
SCSI device the library is to be reserved for.
When set to 1, any valid element identified in the
element list is reserved for the initiator making the
request.
When set to 0, all elements are reserved.
Reservation
Identification Identifies each element reservation with a code word
byte.
Element List
Length
3-18
Defines the size of the element list.
Chapter 3
Jukebox SCSI-2 Command Set
Reserve Command (16H)
Reserve Command Element List Descriptors
Each element list consists of zero or more descriptors. The element list
descriptor defines a series of elements beginning at the specified element
address for the specified number of elements.
Table 3-18
Reserve Command Element List Descriptors
Byte
7
6
5
4
3
2
0
Reserved (0)
1
Reserved (0)
2
Number of Elements (MSByte)
3
Number of Elements (LSByte)
4
Element Address (MSByte)
5
Element Address (LSByte)
Chapter 3
1
0
3-19
Jukebox SCSI-2 Commands
If the number of elements is zero, the element list begins at the specified
element address and continues through the last element address on the
unit. However, if the Element Address is a transport device (a picker) or
an unused Element Address, a status of CHECK CONDITION, Sense
Key = ILLEGAL REQUEST is returned.
Jukebox SCSI-2 Command Set
Release Command (17H)
Release Command (17H)
This command releases the library or element for use by another
initiator.
Table 3-19
Reserve Command CDB
Byte
7
6
5
4
0
3
2
1
0
Operation Code (17H)
1
Logical Unit Number
(0)
3rdPty
Third Party Device
ID
2
Reservation Identification
3
Reserved (0)
4
Reserved (0)
5
Control Byte (0)
Element
3rdPty
When set to 1, the element or unit is released from a
previous reserve which had been made using a third
party reservation.
Element
When set to 1, any reservation from the requesting
initiator with a matching reservation identification is
terminated. All other reservations remain intact.
When this bit is set to 0, the target terminates all
element and unit reservations.
Reservation
Identification Identifies each element reservation code word byte.
3-20
Chapter 3
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
Mode Sense Command (1AH)
This command acquires element parameter information about the
library. This information includes, but is not limited to the following:
• First input/output (mailslot) element address and number of input/
output elements.
• First medium transport element (picker) address and number of
medium transport elements.
• First optical drive element address and number of drives.
• Characteristics of the various element types.
Table 3-20
Mode Sense Command CDB
Byte
7
6
5
4
3
0
Operation Code (1AH)
1
Reserved (0)
2
PC
2
1
Page Code
3
Reserved (0)
4
Allocation Length (Table 3-21 on page 3-22)
5
Control Byte (0)
PC
0
Page Control defines the type of parameter values to be
returned as follows:
0 - Current Values
1 - Changeable Values
2 - Default Values
3 - Saved Values
Chapter 3
3-21
Jukebox SCSI-2 Commands
• First storage slot element address and number of storage slots.
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
Page Code
Valid Page Code values are:
1DH - Element Address Assignment Page (Table 3-22
on page 3-23)
1EH - Transport Element Parameters (Table 3-25 on
page 3-25)
1FH - Device Capabilities Page (Table 3-26 on
page 3-27 or Table 3-27 on page 3-28)
3FH - All Pages
Allocation
Length
Table 3-21
The number of bytes returned for each page code are
shown in the following two tables:
Mode Sense Allocation Lengths
# of Return
Bytes
Page
Code
Description
Table
24
1DH
Element Address
Assignment
Table 3-22 on
page 3-23
8 or 10
1EH
Transport Element
Parameters
Table 3-25 on
page 3-25
24
1FH
Device Capabilities
Table 3-26 on
page 3-27
12
20H
Configuration
Parameters
Table 3-28 on
page 3-30
62 or 64a
3FH
All Pages
a. All models except the 40fx, 80ex, 125ex and 220mx will run in
either single- or double- picker mode. The higher number represents double-picker mode. (Double picker mode is the
default mode).
3-22
Chapter 3
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
Table 3-22
Mode Sense Element Address Assignment Page (1DH) Format
Byte
7
6
5
4
3
Sense Data Length (23)
1-3
Reserved (0)
4
Reserved (0)
1
0
Jukebox SCSI-2 Commands
0
2
Page Code (1DH)
5
Parameter Length (12H)
6
First Medium Transport Element Address (MSByte) (0)
7
First Medium Transport Element Address (LSByte)
(Table 3-23 on page 3-24)
8
Number Of Medium Transport Elements (MSByte) (0)
9
Number Of Medium Transport Elements (LSByte)
(Table 3-23 on page 3-24)
10
First Storage Element Address (MSByte) (0)
11
First Storage Element Address (LSByte) (Table 3-24 on page 3-24)
12
Number Of Storage Elements (MSByte) (0)
13
Number Of Storage Elements (LSByte) (Table 3-24 on page 3-24)
14
First Import/Export Element Address (MSByte) (0)
15
First Import/Export Element Address (LSByte)
(Table 3-24 on page 3-24)
16
Number Of Import/Export Elements (MSByte) (0)
17
Number Of Import/Export Elements (LSByte) (1)
18
First Data Transfer Element Address (MSByte) (0)
19
First Data Transfer Element Address (LSByte) (1)
20
Number Of Data Transfer Elements (MSByte) (0)
21
Number Of Data Transfer Elements (LSByte) (Table 3-24 on page 3-24)
22-23
Reserved (0)
Chapter 3
3-23
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
Table 3-23
Number of Transport Elements
Transport Modea
First Transport
Address
# of Transport
Elements
Dual Picker Mode
16
2
Single Picker Mode
0
1
a.All models except the 40fx, 80ex, 125ex and 220mx will run in either
single-or double-picker mode. All other jukebox models run in singlepicker mode only.
Table 3-24
Number of Data Transfer Elements
Model
First
Storage
Address
Storage
Elements
First Import
Address
40fx
11
16
10
1 or 2
80fx
31
32
20
2
160fx
31
64
20
4
200fx
31
76
20
2
330fx
31
128
20
4 or 6
600fx
31
238
20
6,8,10,12
80ex
11
16
10
1 or 2
160ex
31
32
20
2
320ex
31
64
20
4
400ex
31
76
20
2
660ex
31
128
20
4 or 6
1200ex
31
238
20
4, 6, or 10
3-24
Data
Transfer
Elements
Chapter 3
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
Transport Element (Picker)
Table 3-25
Mode Sense Transport Element Parameter Page (1EH) Format
Byte
7
6
5
4
3
2
Sense Data Length (7) or (9)a
1
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
Reserved (0)
5
6
7
8
9
0
Page Code (1EH)
Parameter Length (02H) or (04H)
Reserved (0)
Rotate
(1)
Member Number In Transport Element Set (0)
Reserved (0)
Rotate
(1)
Member Number In Transport Element Set (1)
a. All models except the 40fx, 80ex, 125ex and 220mx will run in either
single- or double-picker mode. All other jukebox models run in singlepicker mode only. In single picker mode 7 bytes will be returned; in dualpicker mode 9 bytes will be returned.
Parameter
Length
Rotate
Chapter 3
Number of bytes which describe each transport element
(picker).
When set to 1, this bit indicates that the medium
transport element (picker) supports flipping doublesided optical disks.
3-25
Jukebox SCSI-2 Commands
0
1
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
Device Capabilities
The Device Capability Page provides information about library element
storage, Move Medium, and Exchange Medium capabilities.
The following abbreviations are used in the field names of the following
two tables:
• MT - Medium transport element (picker)
• ST - Storage element
• IE - Import/Export element (mailslot)
• DT - Data Transport element (drive)
3-26
Chapter 3
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
Mode Sense Device Capabilities Page (1FH)a
Table 3-26
Byte
7
6
5
4
3
2
0
StorIE
(1)
StorST
(1)
StorMT
(0)
0
Sense Data Length (23)
1-3
Reserved (0)
4
Reserved (0)
5
6
Page Code (1FH)
Parameter Length (12H)
Reserved (0)
7
StorDT
(0)
Reserved (0)
8
Reserved (0)
MT->DT
(1)
MT->IE
(0)
MT->ST
(1)
MT->MT
(0)
9
Reserved (0)
ST->DT
(1)
ST ->IE
(1)
ST->ST
(1)
ST->MT
(1)
10
Reserved (0)
IE->DT
(1)
IE ->IE
(0)
IE ->ST
(1)
IE->MT
(0)
11
Reserved (0)
DT->DT
(1)
DT->IE
(1)
DT->ST
(1)
DT->MT
(1)
12-15
Reserved (0)
16
Reserved (0)
MT<>DT
(1)
MT<>IE
(0)
MT<>ST
(1)
MT<>MT
(0)
17
Reserved (0)
ST<>DT
(1)
ST<>IE
(1)
ST<>ST
(1)
ST<>MT
(0)
18
Reserved (0)
IE<>DT
(1)
IE<>IE
(0)
IE<>ST
(1)
IE<>MT
(0)
19
Reserved (0)
DT<>DT
(1)
DT<>IE
(1)
DT<>ST
(1)
DT<>MT
(0)
20-23
Reserved (0)
a. This table applies to all jukeboxes, EXCEPT the 40fx, 80ex, 125ex and 220mx models.
Chapter 3
3-27
Jukebox SCSI-2 Commands
1
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
Mode Sense Device Capabilities Page (1FH)a
Table 3-27
Byte
7
6
5
4
3
2
1
0
StorIE
(1)
StorST
(1)
StorMT
(0)
0
Sense Data Length (23)
1-3
Reserved (0)
4
Reserved (0)
5
6
Page Code (1FH)
Parameter Length (12H)
Reserved (0)
7
StorDT
(0)
Reserved (0)
8
Reserved (0)
MT->DT
(1)
MT->IE
(0)
MT->ST
(1)
MT->MT
(0)
9
Reserved (0)
ST->DT
(1)
ST ->IE
(1)
ST->ST
(1)
ST->MT
(1)
10
Reserved (0)
IE->DT
(1)
IE ->IE
(0)
IE ->ST
(1)
IE->MT
(0)
11
Reserved (0)
DT->DT
(1)
DT->IE
(1)
DT->ST
(1)
DT->MT
(1)
12-15
Reserved (0)
16
Reserved (0)
MT<>DT
(1)
MT<>IE
(0)
MT<>ST
(1)
MT<>MT
(0)
17
Reserved (0)
ST<>DT
(1)
ST<>IE
(1)
ST<>ST
(1)
ST<>MT
(0)
18
Reserved (0)
IE<>DT
(1)
IE<>IE
(0)
IE<>ST
(1)
IE<>MT
(0)
19
Reserved (0)
DT<>DT
(1)
DT<>IE
(1)
DT<>ST
(1)
DT<>MT
(0)
20-23
Reserved (0)
a. This table applies ONLY to the 40fx, 80ex, 125ex and 220mx models.
3-28
Chapter 3
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
In the descriptions below, XX and YY are abbreviations of the element
types such as MT or ST.
StorXX
When this bit is set to 1, the XX element type provides
independent storage for a cartridge.
XX->YY - Move
Medium
A returned bit value of 1 indicates that the library
supports Move Medium commands from the XX (source)
element to the YY (destination) element. See Table 3-68
on page 3-64 for additional information on the Move
Medium command.
A returned bit value of 0 indicates that Move Medium
commands from the XX element to the YY element are
not supported and will be rejected, with ILLEGAL
REQUEST.
XX<>YY Exchange
Medium
A returned bit value of 1 indicates that the library
supports Exchange Medium commands where the
source is element type XX and destination 1 is element
type YY, and destination 2 is of the same type as the
source element.
An XX<>YY field returned bit value of 0 indicates that
these Exchange Medium commands will be rejected
with ILLEGAL REQUEST. See Table 3-69 on page 3-66
for additional information on the Exchange Medium
Command.
Chapter 3
3-29
Jukebox SCSI-2 Commands
If the StorXX bit is set to 0, it indicates that elements of
that type provide virtual sources or destinations, and
the storage location of the cartridge is provided by an
element of some other type.
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
Table 3-28
Byte
Autochanger Configuration Mode Page (20H)
7
6
5
4
3
2
0
Sense Data Length (11)
1-3
Reserved (0)
4
Reserved (0)
0
Report
Recovered
Write
Verify
Page Code (20H)
5
Page Length (06H)
6
Recovery
Dual
Picker
Starwars
/ Bump
Check
7
Slots
230-238
Mail
In/Out
Mail
Rotation
8
9
1
Secure
Secure
Mail
In/Out
Power
Secure
Reserved (0)
Reserved (0)
SCSI Log
Conf
40
No
Break on
Fail
Reserved (0)
10
Reserved (0)
11
Reserved (0)
This Mode Page provides information on the state of the autochanger’s
configuration options. Page control requests for Current and Saved
values return the same values. Requests for changeable values return all
zeros because none of these values are changeable through a Mode
Select. Requests for Default values return the Default values.
3-30
Chapter 3
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
The following lists the correspondences between fields of this Page and
the control panel options on the jukeboxes.
NOTE
“Large Jukebox” in the following list means Models 330fx, 600fx, 660fx,
1200ex, 1200mx, and 2200mx.
“Small Jukebox” in the following list means Models 40fx and 80ex, 125ex,
and 220mx.
Recovery
Large Jukebox: RECOVERY ON/OFF (1 = ON)
Medium Jukebox: RECOVERY ON/OFF (1 = ON)
Small Jukebox: CONFIG 21 ON/OFF (1 = ON)
Dual Picker
Large Jukebox: DUAL PICKER ON/OFF (1 = ON)
Medium Jukebox: DUAL PICKER ON/OFF (1 = ON)
Small Jukebox: Reserved (0)
Starwars
Large Jukebox: STARWARS ON/OFF (1 = ON)
Medium Jukebox: STARWARS ON/OFF (1 = ON)
Small Jukebox: CONFIG 42 ON/OFF (1 = ON)
Secure
Large Jukebox: SECURE ON/OFF (1 = ON)
Medium Jukebox: SECURE ON/OFF (1 = ON)
Small Jukebox: CONFIG 15 ON/OFF (1 = ON)
Secure Mail
In/Out
Large Jukebox: Reserved (0)
Medium Jukebox: SECURE MAIL IN/OUT (1 = IN)
Small Jukebox: CONFIG 31 ON/OFF (1 = ON)
Power Secure Large Jukebox: POWER SECURE ON/OFF (1 = ON)
Medium Jukebox: POWER SECURE ON/OFF (1 = ON)
Small Jukebox: CONFIG 20 ON/OFF (1 = ON)
Report
Recovered
Write Verify
Chapter 3
Large Jukebox: REP RECOVERED ON/OFF (1 = ON)
Medium Jukebox: REP RECOVERED ON/OFF (1=ON)
Small Jukebox: CONFIG 27 ON/OFF (1 = ON)
Large Jukebox: WRITE VERIFY ON/OFF (1 = ON)
Medium Jukebox: WRITE VERIFY ON/OFF (1 = ON)
Small Jukebox: CONFIG 41 ON/OFF (1 = ON)
3-31
Jukebox SCSI-2 Commands
“Medium Jukebox” in the following list means Models 80fx, 160fx, 200fx,
160ex, 320ex, 400ex, 300mx, 600mx, and 700mx.
Jukebox SCSI-2 Command Set
Mode Sense Command (1AH)
Slots 230-238
Large Jukebox: SLOTS 230-238 ON/OFF (1 = ON)
Medium Jukebox: Reserved (0)
Small Jukebox: Reserved (0)
Mail In/Out
Large Jukeboxes DOOR OPEN/CLOSED 1=CLOSED
Medium Jukebox: Reserved (0)
Small Jukebox: Reserved (0)
Mail Rotation Large Jukebox: Reserved (0)
Medium Jukebox: Reserved (0)
Small Jukebox: CONFIG 32 ON/OFF (1 = ON)
SCSI Log
Large Jukebox: SCSI LOG ON/OFF (1 = ON)
Medium Jukebox: SCSI LOG ON/OFF (1 = ON)
Small Jukebox: Reserved (0)
Conf 40
Large Jukebox: CONF40 ON/OFF (1 = ON)
Medium Jukebox: CONF40 ON/OFF (1 = ON)
Small Jukebox: CONF40 ON/OFF (1 = ON)
No Break on
Fail
3-32
Large Jukebox: Reserved (0)
Medium Jukebox: Reserved (0)
Small Jukebox: CONFIG 8 ON/OFF (1 = ON)
Chapter 3
Jukebox SCSI-2 Command Set
Receive Diagnostic Results Command (1CH)
Receive Diagnostic Results Command (1CH)
NOTE
The following tables provide information that can help with
troubleshooting failed components in a unit. The FRUs returned should
be considered pointers to the best area within the unit to check for the
fault. Simply changing the FRU listed may or may not fix the associated
problem.
Table 3-29
Receive Diagnostic Results Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (1CH)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Allocation Length (MSByte)
4
Allocation Length (LSByte)
5
Control Byte (0)
Allocation
Length
Chapter 3
The maximum number of parameter bytes that may be
sent in the Data In Phase to describe the results of the
test.
3-33
Jukebox SCSI-2 Commands
This command retrieves the results of a library diagnostic test performed
using the Send Diagnostic Command (Table 3-31 on page 3-35). The
diagnostic test number and parameters, error codes, and FRU
information are provided.
Jukebox SCSI-2 Command Set
Receive Diagnostic Results Command (1CH)
Table 3-30
Receive Diagnostic Results Command CDB
Byte
7
6
5
4
3
2
0
Reserved (0)
1
Hardware Error Code
2
FRU 1
3
FRU 2
4
FRU 3
5
Number of the Test that Failed
6-13
Parameters
1
0
Hardware Error
Code
Code is generated only if an unrecoverable error occurs
(See Table B-7 on page B-19).
FRU 1
The FRU most likely to be at fault (See Table C-1 on
page C-2 or Table C-2 on page C-4).
FRU 2
The second most likely FRU to be at fault. (See
Table C-1 on page C-2 or Table C-2 on page C-4).
FRU 3
The third most likely FRU to be at fault (See Table C-1
on page C-2 or Table C-2 on page C-4).
Test Number
The diagnostic test number. This will not be a sequence
number, but the specific test that failed. Refer to
Table B-12 on page B-40 for a list of the jukebox
diagnostic tests.
Parameters
Additional parameters as defined for individual tests.
There may be several like components in a unit. These components may
have a common FRU number. When it is possible to detect which of these
FRUs may be at fault, the error code field reflects the one to check.
3-34
Chapter 3
Jukebox SCSI-2 Command Set
Send Diagnostic Command (1DH)
Send Diagnostic Command (1DH)
This command causes the library to perform certain predefined
diagnostic test/exercise routines.
Table 3-31
Send Diagnostic Command CDB
Byte
7
6
5
0
1
4
3
2
1
0
DevOfL
UnitOfl
Operation Code (1DH)
Logical Unit Number
(0)
Reserved (0)
SelfTst
2
Reserved (0)
3
Parameter List Length (MSByte)
4
Parameter List Length (LSByte)
5
Control Byte (0)
SelfTst
When set to 1, the Poweron Selftest runs. This selftest
is equivalent to running Test Sequence 1, the Poweron
Sequence. The parameter list length must be 0.
When set to 0, the diagnostic specified in the parameter
list is run.
DevOfL
Must be set to 1 for any test other than Selftest.
UnitOfl
Must be set to 1 for any test other than Selftest.
Parameter List
Length
The number of parameter bytes in the Data Out Phase
that describes the test to be run. The valid range is
between 2 and 10, although this value must be 0 if the
Selftest bit is set to 1. See Table 3-32 on page 3-36.
Chapter 3
3-35
Jukebox SCSI-2 Commands
The Request Sense (Table 3-5 on page 3-8) and the Receive Diagnostic
Results (Table 3-29 on page 3-33) commands can be used to get the
results of a test.
Jukebox SCSI-2 Command Set
Send Diagnostic Command (1DH)
Send Diagnostic Command Data
Table 3-32
Send Diagnostic Command Parameter List
Byte
7
0
1
6
5
4
3
2
1
0
Test Number
Break
Loop Count Identifier
2
Parameters
3
Parameters
4
Parameters
5
Parameters
6
Parameters
7
Parameters
8
Parameters
9
Parameters
Test Number
Diagnostic test number. See Table B-12 on page B-40 or
Table B-13 on page B-44 for a list of the jukebox
diagnostic tests.
Break
Indicates how to terminate the loop count if an error
occurs.
0 - Break on first error
1 - Do not break on error
Loop Count
Identifier
The number of times the test will be repeated before the
test is terminated and status is returned.
1H - Run 1 time
2H - Run 10 times
3H - Run 100 times
4H - Run 1000 times
Parameters
3-36
Parameters associated with the specified tests.
Chapter 3
Jukebox SCSI-2 Command Set
Prevent/Allow Medium Removal Command (1EH)
Prevent/Allow Medium Removal Command
(1EH)
Table 3-33
Prevent/Allow Medium Removal Command CDB
Byte
7
6
5
4
0
1
3
2
1
0
Operation Code (1EH)
Logical Unit Number
(0)
Reserved (0)
2
Reserved (0)
3
Reserved (0)
4
5
Prevent
Chapter 3
Reserved (0)
Prevent
Control Byte (0)
A Prevent bit of 1 prevents removal of an optical disk. A
prevent bit of 0 allows removal of an optical disk.
Default is 0.
3-37
Jukebox SCSI-2 Commands
This command either prevents or allows users to insert or remove optical
disks using the mailslot.
Jukebox SCSI-2 Command Set
Position To Element Command (2BH)
Position To Element Command (2BH)
This command positions the specified transport element in front of the
specified destination element.
Table 3-34
Position To Element Command CDB
Byte
0
1
7
6
5
4
3
2
1
Operation Code (2BH)
Logical Unit Number
(0)
Reserved (0)
2
Transport Element Address (MSByte)
3
Transport Element Address (LSByte)
4
Destination Element Address (MSByte)
5
Destination Element Address (LSByte)
6
Reserved (0)
7
Reserved (0)
8
9
0
Reserved (0)
Invert
Control Byte (0)
Transport Element
Address
The default address of zero is the best address for use.
(Changing from the default could result in a decrease in
jukebox performance.) However, this field can also be
set to a specific transport element address (see Table 322 on page 3-23).
Destination Element
Address
See Table 3-22 on page 3-23 in the description of the
Mode Sense Command for more information about
addressing.
Invert
3-38
An Invert bit value of 1 requests the transport element
be inverted (flipped) before being placed in front of the
destination element.
Chapter 3
Jukebox SCSI-2 Command Set
Write Buffer Command (3BH)
Write Buffer Command (3BH)
This command writes data to the jukebox.
Incorrect use of this command may cause an overwrite of critical
information needed for the jukebox to operate. If this occurs, call service.
Only Buffer IDs listed in Table 3-37 on page 3-40 are intended for use
outside of the factory.
Table 3-35
Write Buffer Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (3BH)
Logical Unit Number
(0)
Reserved (0)
Mode (See Table 3-37
on page 3-40)
2
Buffer ID (Table 3-37 on page 3-40)
3
Buffer Offset (MSByte)
4
Buffer Offset
5
Buffer Offset (LSByte)
6
Byte Transfer Length (MSByte)
7
Byte Transfer Length
8
Byte Transfer Length (LSByte)
9
Control Byte (0)
Mode
Indicates which data format is used. Refer to Table 3-37
on page 3-40 for valid values.
Buffer ID
Indicates which buffer is used. Refer to Table 3-37 on
page 3-40 for valid values.
Chapter 3
3-39
Jukebox SCSI-2 Commands
CAUTION
Jukebox SCSI-2 Command Set
Write Buffer Command (3BH)
Buffer Offset
Indicates at what address the data is written, offset
from the beginning of the buffer. Must be set to 0 when
using Download Microcode ID.
Byte Transfer
Length
Indicates the number of data bytes to be written in the
buffer.
Table 3-36
Write Buffer Mode Descriptions
Mode
Table 3-37
Description
1
Vendor specific
4
Download microcode
5
Download microcode
User Accessible Buffers and Allowed Write Modes
User-Accessible Buffers
NOTE
Buffer
ID
Allowed
Write Modes
Download Microcode (FLASH EPROM)
1
4,5
Customer and Product ID (NVRAM)
15
1
Online Drive Repair ID
128
1
Additional buffer IDs are for factory use only and are subject to change
without notice.
3-40
Chapter 3
Jukebox SCSI-2 Command Set
Write Buffer Command (3BH)
Table 3-38
Write Buffer Data Format When Buffer ID Set to Online Drive
Repair
Byte
Description
Drive 1 Control
1
Drive 2 Control
2
Drive 3a Control
3
Drive 4a Control
4
Drive 5a Control
5
Drive 6a Control
6
Drive 7a Control
7
Drive 8a Control
8
Drive 9a Control
9
Drive 10a Control
10
Drive 11a Control
11
Drive 12a Control
12
Reserved
13
Reserved
14
Reserved
15
Reserved
Jukebox SCSI-2 Commands
0
a.Model dependent
Chapter 3
3-41
Jukebox SCSI-2 Command Set
Write Buffer Command (3BH)
Table 3-39
Drive Control Definition
Byte
3-42
Description
00
No change to the drive state.
01
Set drive to "Online_good" state.
04
Set drive to "Offline_failed" state.
06
Set drive to "Offline_good" state.
Chapter 3
Jukebox SCSI-2 Command Set
Read Buffer Command (3CH)
Read Buffer Command (3CH)
This command reads data from the jukebox.
Only the Buffer IDs listed in Table 3-42 on page 3-44 are intended for use
outside of the factory.
Table 3-40
Read Buffer Command CDB
Byte
7
0
1
6
5
4
3
2
1
0
Operation Code (3CH)
Logical Unit Number
(0)
Reserved (0)
2
Buffer ID
3
Buffer Offset (MSByte)
4
Buffer Offset
5
Buffer Offset (LSByte)
6
Byte Transfer Length (MSByte)
7
Byte Transfer Length
8
Byte Transfer Length (LSByte)
9
Control Byte (0)
Mode
Mode
Indicates which data format is to be used. Refer to
Table 3-41 on page 3-44 for valid values.
Buffer ID
Indicates which buffer is to be used. Refer to Table 3-41
on page 3-44 for valid values.
Buffer Offset
Indicates at what address the data should be written,
offset from the beginning of the buffer.
Byte Transfer
Length
Indicates the number of data bytes to be read from the
buffer (maximum of 65535).
Chapter 3
3-43
Jukebox SCSI-2 Commands
NOTE
Jukebox SCSI-2 Command Set
Read Buffer Command (3CH)
NOTE
Additional Buffer IDs are for factory use only and are subject to change
without notice.
Table 3-41
Read Buffer Mode Descriptions
Mode
1
Table 3-42
Description
Vendor specific
User Accessible Buffers and Allowed Read Modes
User-Accessible Buffers
Online Drive Repair ID
3-44
Buffer
ID
Allowed
Read Modes
128
1
Chapter 3
Jukebox SCSI-2 Command Set
Read Buffer Command (3CH)
Table 3-43
Read Buffer Data Format When Buffer ID Set to Online Drive
Repair
Byte
Description
Drive 1 Status
1
Drive 2 Status
2
Drive 3a Status
3
Drive 4a Status
4
Drive 5a Status
5
Drive 6a Status
6
Drive 7a Status
7
Drive 8a Status
8
Drive 9a Status
9
Drive 10a Status
10
Drive 11a Status
11
Drive 12a Status
12
Reserved
13
Reserved
14
Reserved
15
Reserved
Jukebox SCSI-2 Commands
0
a.Model dependent
Chapter 3
3-45
Jukebox SCSI-2 Command Set
Read Buffer Command (3CH)
Table 3-44
Drive Status Definition
Byte
Status
Description
00
Drive is not valid
01
Online_good
The drive is online and in a good
state. This is the normal state. All
accesses allowed.
02
Online_pending
The drive is offline and ready to go
to the "Online_good" state. No
accesses allowed.
04
Offline_failed
The drive is offline and in a failed
state. No accesses allowed. No power
is applied to the drive.
05
Offline_good_pending
The drive is online but requesting to
go the "Offline_good" state. All
accesses allowed.
06
Offline_good
The drive is offline but is not in a
failed state. No accesses allowed. No
power is applied to the drive.
3-46
Chapter 3
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Log Sense Command (4DH)
This command retrieves statistical library information maintained by
the jukebox.
Log Sense Command CDB
Byte
7
6
0
5
4
3
2
1
0
Operation Code (4DH)
1
Logical Unit Number
(0)
2
Reserved (0)
Reserved (0)
Page Code (Table 3-46 on page 3-48)
3
Reserved (0)
4
Reserved (0)
5
Parameter Pointer (MSByte) (0)
6
Parameter Pointer (LSByte) (0)
7
Allocation Length (MSByte)
8
Allocation Length (LSByte)
9
Control Byte (0)
Allocation
Length
The number of parameter bytes, including the Log Page
Descriptor Block and the parameter structures. Refer to
Table 3-46 on page 3-48.
Log Sense Parameter Data
Parameter data returned by the Log Sense Command is organized into
pages. The parameter data available in each page is described in
Table 3-46 on page 3-48.
Chapter 3
3-47
Jukebox SCSI-2 Commands
Table 3-45
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Table 3-46
Log Sense Parameter Data Available in Each Page
Page
Code
Length
Bytesa
Length
Bytesb
Description
0
16
16
List of supported pages
30H
510
366
Error log (Table 3-47 on page 3-49)
31H
72
NSc
Move Success log (Table 3-51 on page 3-53)
32H
varied
NS
Force log (Table 3-53 on page 3-54)
33H
406
366
Recovery log (Table 3-54 on page 3-55)
34H
204
204
Regression (vendor unique)
35H
14-44
24-44
36H
6
NS
Byte 0 = Version #; Byte 1 = Revision #
37H
24
24
The Odometer log (Table 3-60 on page 3-58)
38H
116
366
Run-Time log (Table 3-61 on page 3-59)
39H
108
NS
Retry log (Table 3-64 on page 3-61)
3AH
52
NS
Move History log (Table 3-66 on page 3-63)
3BH
72
164-340
Mechanism Parameters (factory use only)
3CH
8
8
3DH
204
NS
Drive log d (Table 3-58 on page 3-57)
PROM Information (factory use only)
Alternate Regression (factory use only)
a. This column ONLY applies to the 40fx, 80ex, 125ex and 220mx.
b. This column applies to all models, EXCEPT 40fx, 80ex, 125ex and 220mx.
c. If "NS" appears in this field, the log is not supported for all models, EXCEPT
40fx, 80ex, 125ex and 220mx.
d. The length of the drive log depends on the number of drives in the unit. Ten
bytes per drive are available.
All log pages are preceded by a 4-byte header that contains the page
number, a reserved byte, and the length of the data to follow the header.
(Refer to the following example.)
3-48
Chapter 3
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Error Logs Table Format
This table is accessed using the Log Sense Command (4DH), Table 3-45
on page 3-47 with page code 30H. It records hard errors that occur
during normal operation of the jukebox.
Table 3-47
Error Logs Table Format a
Byte #
Description
0
Page Code 30H
1
Reserved = 0
2
Number of bytes to follow (MSByte)
3
Number of bytes to follow (LSByte)
4
Current Entry
5
Number of Entries
6-366
Array of 10 log entries (36 Bytes each)
a. This table applies to all models, EXCEPT 40fx, 80ex, 125ex and
220mx.
Chapter 3
3-49
Jukebox SCSI-2 Commands
This log may be initialized before exerciser or wellness sequences are
run. This allows you to accumulate data related to the test at hand.
When you initialize the cumulative log, all data accumulated is lost.
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Table 3-48
Error/ Recovery/Runtime Log Data Entry Format
Byte
7
6
5
4
3
2
1
0
0
Reserved (0)
1
Hardware Error Code (Table B-7 on page B-19)
2
FRU 1 (Table C-1 on page C-2)
3
FRU 2 (Table C-1 on page C-2)
4
FRU 3 (Table C-1 on page C-2)
5
Command Attempted
6-7
Source Element Number
8-9
Destination Element Number
10-11
Second Destination Element Number
12-16
Micro-Move ID History (Table Table D-1 on page D-2)
17
Failed Micro-Move ID (Table D-1 on page D-2)
18
Failed Micro-Move Error Code (Table B-10 on page B-32)
19
Active
Picker
Active
Thumb
Reserved (0)
20-21
Vertical Motor Commanded Position
22-23
Vertical Motor Actual Position
24-25
Plunge Motor Commanded Position
26-27
Plunge Motor Actual Position
28-29
Translate Motor Commanded Position
30-31
Translate Motor Actual Position
32-35
Odometer
3-50
Chapter 3
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Table 3-49
Byte
Description
0
Page Code 30H
1
Reserved = 0
2-3
Number of bytes to follow
4-5
Current entry number (range 1 - 50)
6-7
Number of entries in the log
8-9
Log entry currently being displayed
10-509
Array of 50 log entries (10 bytes each) See Table 3-50 below.
Error Log Entry Format (For 40fx, 80ex, 125ex and 220mx models
only)
Byte
7
6
5
4
3
2
1
0
Diagnostic User Number
1
Hardware Error Code (Table B-7 on page B-19)
2
FRU 1 (Table C-1 on page C-2)
3
FRU 2 (Table C-1 on page C-2)
4
FRU 3 (Table C-1 on page C-2)
5
Test Number
6
Time Stamp (MSByte)
7
Time Stamp
8
Time Stamp
9
Time Stamp (LSByte)
Chapter 3
0
3-51
Jukebox SCSI-2 Commands
Table 3-50
Error Logs Table Format (For 40fx, 80ex, 125ex and 220mx
models ONLY)
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Diagnostic User
Number
0 - Poweron
1 - Front Panel
2 - SCSI Bus
3 - FRU Isolation
4 - Error Recovery
5 - SCSI Reset
6 - SCSI Abort
NOTE
FRU 1
The FRU most likely to be at fault. (See Appendix C).
FRU 2
The second most likely FRU to be at fault. (See
Appendix C).
FRU 3
The third mostly likely FRU to be at fault. (See
Appendix C).
Test Number
The diagnostic test number. See Table B-12 on
page B-40 for a list of diagnostic tests.
Time Stamp
Indicates when the error occurred (measured in hours
since the odometer was initialized).
The FRU numbers returned indicate the most likely cause of the error,
but these FRUs might not be the actual cause of the problem.
3-52
Chapter 3
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Move Success Log Table Format
NOTE
This log is ONLY supported on the 40fx and 80ex models.
Move totals and the ten most recent hard errors are recorded.
Table 3-51
Move Success Log Table Format (For 40fx, 80ex, 125ex and 220mx
models ONLY)
Byte
Description
0
Page Code 31H
1
Reserved = 0
2-3
Number of bytes to follow
4
Current entry number (range 1 - 10)
5
Number of entries in the log
6-9
Total number of good moves since last hard error
10-11
Total number of soft errors since last hard error
12-71
Array of 10 entries, one entry per hard error (Table 3-52 on
page 3-53
NOTE
Hard errors are unrecoverable and generate a hardware error code. Soft
errors are recoverable with normal operation continuing after recovery.
Table 3-52
Move Success Logs Entry Format
Byte
Description
0-3
Current Good Move Count at time of hard error
4-5
Current Recovery Count at time of hard error
Chapter 3
3-53
Jukebox SCSI-2 Commands
This table can be accessed via the Log Sense Command (4DH),
Table 3-45 on page 3-47 with page code 31H. The Move Success Log is
intended for use during normal jukebox operation, not diagnostic
operation.
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Force Log Data Format
NOTE
This log is ONLY supported on 40fx and 80ex models.
This table can be accessed via the Log Sense Command (4DH), Table 345 on page 3-47) with page code 32H. Each cartridge move is actually a
sequence of many small moves called Micro-Moves. Each Micro-Move has
an associated ID number. For each Micro-Move ID, the log reflects the
highest force seen for that Micro-Move ID.
Table 3-53
Force Entry Data Format
Byte
3-54
Description
0
Page Code 32H
1
Reserved = 0
2-3
Number of bytes to follow
4-5
Y-axis maximum force for the Micro-Move ID (Table D-1 on
page D-2 or Table D-2 on page D-17)
6-7
Z-axis maximum force for the Micro-Move ID (Table D-1 on
page D-2 or Table D-2 on page D-17)
Chapter 3
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Recovery Log Data Format
This table can be accessed via the Log Sense Command (4DH), Table 345 on page 3-47, with page code 33H. It records soft errors and related
information on error recovery method and success.
Table 3-54
Recovery Log Data Format (For all models EXCEPT 40fx, 80ex,
125ex and 220mx)
Byte
0
Page Code 33H
1
Reserved = 0
2
Number of bytes to follow (MSByte)
3
Number of bytes to follow (LSByte)
4
Current Entry
5
Number of Entries
6-366
Table 3-55
Description
Array of 10 log entries (36 Bytes each) (See Table 3-48 on
page 3-50)
Recovery Log Data Format (For the 40fx, 80ex, 125ex and 220mx
models ONLY)
Byte
Description
0
Page Code 33H
1
Reserved = 0
2-3
Number of bytes to follow
4-5
Current entry number (range 1 - 20)
5
6-405
Chapter 3
Number of Entries
20 recovery log entries, 20 bytes each (See Table 3-56 on
page 3-56)
3-55
Jukebox SCSI-2 Commands
It is reset to 0 before any jukebox move. Any error that occurs during a
move or during the subsequent error recovery is logged. The information
is only valid for the most recent move.
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Table 3-56
Recovery Log Entry Format (For the 40fx, 80ex, 125ex and 220mx
models ONLY)
Byte
Table 3-57
Description
0
Macro-Move ID (Table D-1 on page D-2)
1
Error Recovery State (Table 3-57 on page 3-56)
2
Micro-Move ID (Table D-2 on page D-17)
3
Micro-Move Error Code (Table B-10 on page B-32)
4-7
Y-input position from the encoder
8-11
Expected Y-input position from the encoder
12-15
Z-input position from the encoder
16-19
Expected Z-input from the encoder
Error Recovery State (For the 40fx, 80ex, 125ex and 220mx
models ONLY)
Byte
Description
0
First retry attempt failed
1
Second retry attempt failed
2
Third retry attempt failed
20
First restore attempt failed
21
Second restore attempt failed
22
Third restore attempt failed
97
Maximum number of retries exceeded
98
Maximum number of restores exceeded
99
Find Home failed
127
Initial entry for this failure
3-56
Chapter 3
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Drive Log Data Format
This table can be accessed via the Log Sense Command (4DH), Table 345 on page 3-47 with page code 35H. It records the number of times a
drive is used by the jukebox.
Drive Log Data Format
Byte
Table 3-59
Description
0
Page Code 35H
1
Reserved = 0
2-3
Number of bytes to follow
4-13
Log entry for Drive #1
14-23
Log entry for Drive #2 (Model dependent, seeTable 3-24 on
page 3-24)
24-33
Log entry for Drive # (Model dependent, see Table 3-24 on
page 3-24)
34-43
Log entry for Drive #4 (Model dependent, see Table 3-24 on
page 3-24)
Drive Log Entry Format
Byte
Description
0-3
Count of optical disk insertions for this drive
4-5
Media source for last move to this drive
6
Media flipped bit for last move to this drive
7
ID/LUN Valid bits for this drive
8
SCSI ID for this drive
9
SCSI LUN for this drive
Chapter 3
3-57
Jukebox SCSI-2 Commands
Table 3-58
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Odometer Log Data Format
This table can be accessed via the Log Sense Command (4DH),
Table 3-45 on page 3-47 with page code 37H. It counts the number of
times various types of moves are completed. An exchange is counted as
two moves.
Table 3-60
Odometer Log Data Format
Byte
Description
0
Page Code 37H
1
Reserved = 0
2-3
Number of bytes to follow
4-7
Move Odometer
8-11
Flip Odometer
12-15
Translate Odometer
16-19
Mailslot Rotate Odometer
20-23
Poweron Hours
3-58
Chapter 3
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Run-Time Log Data Format
Table 3-61
Run-Time Logs Data Format (For all models, EXCEPT 40fx, 80ex,
125ex and 220mx)
Byte
0
Page Code 38H
1
Reserved = 0
2
Number of bytes to follow (MSByte)
3
Number of bytes to follow (LSByte)
4
Current Entry
5
Number of Entries
6-366
Table 3-62
Description
Array of 10 log entries (36 Bytes each)
Run-Time Logs Data Format (For the 40fx, 80ex, 125ex and 220mx
models ONLY)
Byte
Description
0
Page Code 38H
1
Reserved = 0
2-3
Number of bytes to follow
4-7
Number of Macro-Move IDs since this log was reset
8-9
Number of retries done since this log was reset
10-11
Number of inline recoveries since this log was reset
12-13
Number of fatal errors since this log was reset
14
Chapter 3
Number of entries in this log
3-59
Jukebox SCSI-2 Commands
This table can be accessed via the Log Sense Command (4DH), Table 345 on page 3-47 with page code 38H. It keeps a record of error recovery
activity. An entry is added to the Run-Time Log when a move fails or
when any type of error recovery is required. Only the last ten entries are
saved.
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Table 3-62
Run-Time Logs Data Format (For the 40fx, 80ex, 125ex and 220mx
models ONLY)
Byte
15
16-115
Table 3-63
Description
Number of the most current entry
10 Run-time log entries, 10 bytes each (See Table 3-63)
Run-Time Log Entry Format
Byte
0-3
3-60
Description
Number of Macro-Move IDs since this log was reset
4
Macro-Move ID
5
Number of entries in Recovery Log when the entry was
made
6
First Micro-Move ID in the Recovery Log (Table D-1 on
page D-2 or Table D-2 on page D-17)
7
First Micro-Move Error Code in the Recovery Log
(Table B-10 on page B-32)
8
Second Micro-Move ID in Recovery Log (Table D-1 on
page D-2 or Table D-2 on page D-17)
9
Second Micro-Move Error Code in Recovery Log (Table B-10
on page B-32)
Chapter 3
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Retry Log Data Format
NOTE
This log is ONLY supported on the 40fx, 80ex, 125ex and 220mx models.
Each retry algorithm code byte triggers a specific retry algorithm on the
preceding move command. The byte order is the same order in which the
retry algorithms were run.
Table 3-64
Retry Log Data Format
Byte
Description
0
Page Code 39H
1
Reserved = 0
2-3
4-103
Number of bytes to follow
Retry Algorithm Code (Table 3-65 on page 3-62)
104-105
Number of Inline Retries
106-107
Number of Major Retries
The last four bytes may be organized as two 16 bit words. The first word
is the cumulative number of Inline Retries (since the jukebox was built),
and the second word is the cumulative number of Major Retries (since
the jukebox was built). Inline Retries are attempts to move again from
the error position. Major Retries are attempts to move again after a Find
Home command has re-zeroed the unit.
Chapter 3
3-61
Jukebox SCSI-2 Commands
This table can be accessed via the Log Sense Command (4DH),
Table 3-45 on page 3-47, with page code 39H.
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Table 3-65
Retry Algorithm Codes
Number
Algorithm Name
Type
01H
Find Home and Calibrate
Major
03H
Z-axis Home
Major
04H
FRU Isolation
Major
81H
Mailslot
Inline
91H
Drive 1 Eject
Inline
92H
Drive 2 Eject
Inline
93H
Drive 3 Eject
Inline
94H
Drive 4 Eject
Inline
A1H
Drive 1 Insert
Inline
A2H
Drive 2 Insert
Inline
A3H
Drive 3 Insert
Inline
A4H
Drive 4 Insert
Inline
The number of drives within a unit is model dependent. Refer to
Table 3-24 on page 3-24 for the actual number of drives within a specific
jukebox.
3-62
Chapter 3
Jukebox SCSI-2 Command Set
Log Sense Command (4DH)
Move History Log Data Format
NOTE
This log is ONLY supported on the 40fx, 80ex, 125ex and 220mx models.
Table 3-66
Table 3-67
Move History Log Data Format
Byte
Description
0
Page Code 3AH
1
Reserved = 0
2-3
Number of bytes to follow
4-83
6 History Log entries, 8 bytes each (see
Move History Log Entry Format
Byte
Description
0
Least recent Micro-Move ID (Table D-2 on page D-17)
1
Next recent Micro-Move ID (Table D-2 on page D-17)
2
Next recent Micro-Move ID (Table D-2 on page D-17)
3
Next recent Micro-Move ID (Table D-2 on page D-17)
4
Next recent Micro-Move ID (Table D-2 on page D-17)
5
Failed Micro-Move ID (Table D-2 on page D-17)
16
Micro-Move Error Code (Table B-10 on page B-32)
7
Reserved (0)
Micro-Move IDs are the last moves prior to failure, associated with Bytes
5 and 6.
Chapter 3
3-63
Jukebox SCSI-2 Commands
This table can bee accessed via the Log Sense Command (4DH), Table 345 on page 3-47 with page code 3AH.
Jukebox SCSI-2 Command Set
Move Medium Command (A5H)
Move Medium Command (A5H)
NOTE
This command moves optical disks between library elements.
Table 3-68
Move Medium Command CDB
Byte
0
1
7
6
5
4
3
2
Logical Unit Number (0)
Reserved (0)
Transport Element Address (MSByte)
3
Transport Element Address (LSByte)
4
Source Element Address (MSByte)
5
Source Element Address (LSByte)
6
Destination Element Address (MSByte)
7
Destination Element Address (LSByte)
8-9
Reserved (0)
11
0
Operation Code (A5H)
2
10
1
Reserved (0)
Invert
Control Byte (0)
Transport Element
Address
The default address of zero is the best address for use.
(Changing from the default could result in a decrease in
jukebox performance.) However, this field can also be
set to a specific transport element address (see
Table 3-22 on page 3-23).
Source/Destination
Element
Address
See Table 3-22 on page 3-23 in the description of the
Mode Sense Command for more information about
addressing.
3-64
Chapter 3
Jukebox SCSI-2 Command Set
Move Medium Command (A5H)
Invert
An Invert bit value of 1 requests the transport element
be inverted (flipped) before putting the optical disk into
the destination element.
Jukebox SCSI-2 Commands
Chapter 3
3-65
Jukebox SCSI-2 Command Set
Exchange Medium Command (A6H)
Exchange Medium Command (A6H)
The optical disk in the source element is moved to the first destination
element and the optical disk that previously occupied the first
destination element is moved to the second destination element.
Table 3-69
Exchange Medium Command CDB
Byte
0
1
7
6
5
4
3
2
1
Operation Code (A6H)
Logical Unit Number (0)
Reserved (0)
2
Transport Element Address (MSByte)
3
Transport Element Address (LSByte)
4
Source Element Address (MSByte)
5
Source Element Address (LSByte)
6
First Destination Element Address (MSByte)
7
First Destination Element Address (LSByte)
8
Second Destination Element Address (MSByte)
9
Second Destination Element Address (LSByte)
10
11
0
Reserved (0)
Inv2
Inv1
Control Byte (0)
Transport Element
Address
The default address of zero is the best address for use.
(Changing from the default could result in a decrease in
jukebox performance.) However, this field can also be
set to a specific transport element address (see
Table 3-22 on page 3-23).
3-66
Chapter 3
Jukebox SCSI-2 Command Set
Exchange Medium Command (A6H)
Source/Destination
Element
Address
See Table 3-22 on page 3-23 in description of Mode
Sense Command for more information about
addressing.
An Inv2 bit value of 1 specifies that the optical disk will
be inverted (flipped) prior to being deposited into the
second destination element.
Inv1
An Inv1 bit value of 1 specifies that the optical disk will
be inverted (flipped) prior to being deposited into the
first destination element.
Chapter 3
3-67
Jukebox SCSI-2 Commands
Inv2
Jukebox SCSI-2 Command Set
Read Element Status Command (B8H)
Read Element Status Command (B8H)
This command provides the exact status of the various elements
(individual storage slots, mailslot, optical drives, and picker mechanism)
within the library.
Table 3-70
Read Element Status Command CDB
Byte
0
1
7
6
5
4
3
2
1
0
Operation Code (B8H)
Logical Unit Number (0)
Reserved (0)
Element Type Code
2
Starting Element Address (MSByte)
3
Starting Element Address (LSByte)
4
Number Of Elements (MSByte)
5
Number Of Elements (LSByte)
6
Reserved (0)
7
Allocation Length (MSByte)
8
Allocation Length (Middle Byte)
9
Allocation Length (LSByte)
10
Reserved (0)
11
Control Byte (0)
Element Type
Code
Specifies the element type(s) to report.
0H - All element types reported
1H - Medium Transport Element (picker)
2H - Storage Element
3H - Import/Export Element (mailslot)
4H - Data Transfer Element (drive)
3-68
Chapter 3
Jukebox SCSI-2 Command Set
Read Element Status Command (B8H)
Starting Element
Address
Specifies the minimum element address to report.
Number Of
Elements
The number of bytes of element status to return. The
data consists of an 8-byte Element Status Page Header,
followed by one or more Element Status pages.
Read Element Status Data
Read Element Status Data consists of a data header, followed by one or
more Element Status pages.
Table 3-71
Read Element Status Data Header
Byte
7
6
5
4
3
2
1
0
First Element Address Reported (MSByte)
1
First Element Address Reported (LSByte)
2
Number of Elements Reported (MSByte)
3
Number of Elements Reported (LSByte)
4
Reserved (0)
5
Byte Count of Report Available (MSByte)
6
Byte Count of Report Available (Middle Byte)
7
Byte Count of Report Available (LSByte)
0
Byte Count Report
Available
The number of bytes of element status page data
available.
Chapter 3
3-69
Jukebox SCSI-2 Commands
Allocation
Length
Maximum number of elements to report.
Jukebox SCSI-2 Command Set
Read Element Status Command (B8H)
Element Type Code 1H - Picker
Medium Transport Element Descriptor Block
Table 3-72
Byte
7
6
5
4
3
2
1
0
0
Element Type Code (1H)
1
Reserved (0)
2
Element Descriptor Length (MSByte)
3
Element Descriptor Length (LSByte)
4
Reserved (0)
5
Byte Count of Descriptor Data Available (MSByte)
6
Byte Count of Descriptor Data Available (Middle Byte)
7
Byte Count of Descriptor Data Available (LSByte)
8
Element Address (MSByte)
9
Element Address (LSByte)
10
Reserved (0)
11
Except
Reserved
(0)
Full
Reserved (0)
Element Descriptor
Length
The number of bytes in each Element Descriptor Block
Byte Count of
Descriptor Data
Available
Element Descriptor Length for X Number of Elements
of the type shown in byte 0.
Element
Address
The address of the element being reported by this
descriptor block.
Except
When set to 1, the element is in an abnormal state.
Full
When set to 1, the element contains a cartridge.
3-70
Chapter 3
Jukebox SCSI-2 Command Set
Read Element Status Command (B8H)
Element Type Code 2H - Storage Slot
Read Element Status Storage Element Descriptor Block
Table 3-73
Byte
7
6
5
4
3
2
1
Element Type Code (2H)
1
Reserved (0)
2
Element Descriptor Length (MSByte)
3
Element Descriptor Length (LSByte)
4
Reserved (0)
5
Byte Count of Descriptor Data Available (MSByte)
6
Byte Count of Descriptor Data Available (Middle Byte)
7
Byte Count of Descriptor Data Available (LSByte)
8
Element Address (MSByte)
9
Element Address (LSByte)
10
Reserved (0)
11
Access
Except
Reserved
(0)
Jukebox SCSI-2 Commands
0
0
Full
Reserved (0)
Element Descriptor
Length
The number of bytes in each Element Descriptor Block
Byte Count of
Descriptor
Data
Element Descriptor Length for X Number of Elements
of the type shown in byte 0.
Element
Address
The address of the element being reported by this
descriptor block.
Access
When set to 1, access to the element by the Medium
Transport Element is allowed.
Except
When set to 1, the element is in an abnormal state.
Full
When set to 1, the element contains a cartridge.
Chapter 3
3-71
Jukebox SCSI-2 Command Set
Read Element Status Command (B8H)
Element Type Code 3H - Mailslot
Read Element Status Import/Export Element Descriptor Block
Table 3-74
Byte
7
6
5
4
3
2
1
0
Element Type Code (1H)
1
Reserved (0)
2
Element Descriptor Length (MSByte)
3
Element Descriptor Length (LSByte)
4
Reserved (0)
5
Byte Count of Descriptor Data Available (MSByte)
6
Byte Count of Descriptor Data Available (Middle Byte)
7
Byte Count of Descriptor Data Available (LSByte)
8
Element Address (MSByte)
9
Element Address (LSByte)
10
Reserved (0)
11
In- Enab
Ex-Enab
Access
Except
0
Imp/Exp
Full
Reserved (0)
Element Descriptor
Length
The number of bytes in each Element Descriptor Block.
Byte Count of
Descriptor Data
Available
Element Descriptor Length for X Number of Elements
of the type shown in byte 0.
Element
Address
The address of the element being reported by this
descriptor block.
InEnab
When set to 1, Import to the jukebox is enabled.
ExEnab
When set to 1, Export from the jukebox is enabled.
3-72
Chapter 3
Jukebox SCSI-2 Command Set
Read Element Status Command (B8H)
Access
When set to 1, access to the element by the Medium
Transport Element is allowed.
Except
When set to 1, the element is in an abnormal state.
Imp/Exp
When set to 1, the operator inserted the cartridge into
the mailslot.
Jukebox SCSI-2 Commands
When set to 0, the jukebox mechanism puts the
cartridge in the mailslot.
Full
Chapter 3
When set to 1, the element contains a cartridge.
3-73
Jukebox SCSI-2 Command Set
Read Element Status Command (B8H)
Element Type Code 4H - Drive
Table 3-75
Byte
Read Element Status Data Transfer Element Descriptor Block
7
6
5
4
3
2
1
0
Element Type Code (4H)
1
Reserved (0)
2
Element Descriptor Length (MSByte)
3
Element Descriptor Length (LSByte)
4
Reserved (0)
5
Byte Count Of Descriptor Data Available (MSByte)
6
Byte Count of Descriptor Data Available (Middle Byte)
7
Byte Count of Descriptor Data Available (LSByte)
8
Element Address (MSByte)
9
Element Address (LSByte)
10
Reserved (0)
Access
Except
Reserved
(0)
11
Reserved (0)
12
Additional Sense Code (See Table B-2 on page B-4)
13
Additional Sense Code Qualifier (See Table B-2 on page B-4.)
14
Not
Bus
Reserved
(0)
ID
Valid
LU
Valid
Reserved
(0)
15
SCSI Bus Address
16
Reserved (0)
17
SValid
Invert
Full
Logical Unit Number
Reserved (0)
18
Source Storage Element Address (MSByte)
19
Source Storage Element Address (LSByte)
3-74
0
Chapter 3
Jukebox SCSI-2 Command Set
Read Element Status Command (B8H)
Table 3-75
Byte
Read Element Status Data Transfer Element Descriptor Block
7
6
5
4
3
Reserved (0)
24-33a
Drive Serial Number (ASCII)
1
0
a. These fields are applicable for the 300mx, 600mx, 700mx, 1200mx and 2200mx
models only.
Element Descriptor
Length
The number of bytes in each Element Descriptor Block.
Byte Count of
Descriptor Data
Available
Element Descriptor Length for X Number of Elements
of the type shown in byte 0.
Element
Address
The address of the element being reported by this
descriptor block.
Access
When set to 1, access to the element by the Medium
Transport Element is allowed.
Except
When set to 1, the element is in an abnormal state.
Information about the abnormal state is available in the
Additional Sense Code and Additional Sense Code
Qualifier bytes. (See Table B-2 on page B-4)
Full
When set to 1, the element contains a cartridge.
Not Bus
When set to 1, the SCSI Bus Address and the Logical
Unit value fields are not on the SCSI Bus used to select
the library.
Chapter 3
3-75
Jukebox SCSI-2 Commands
20-23a
2
Jukebox SCSI-2 Command Set
Read Element Status Command (B8H)
IDValid
When set to 1, the SCSI Bus Address field contains valid
information.
LUValid
When set to 1, the logical unit number field contains
valid information.
Logical Unit
Number
If valid, provides the logical unit number within the
SCSI bus address of the device served by the jukebox at
this element.
SValid
When set to 1, the source storage element address field
and the invert bit information are valid.
Invert
When set to 1, the cartridge in the element was inverted
by a move operation since it was last in the source
storage element.
3-76
Chapter 3
Drive Error Codes
A
Drive Error Codes
Appendix A
A-1
Drive Error Codes
Chapter Overview
Chapter Overview
This chapter contains the following information:
• Request Sense Command sense key values
• Request Sense Command additional sense code values
• Internal Error Codes
• DSP Error Codes
A-2
Appendix A
Drive Error Codes
Drive Request Sense Command Values
Drive Request Sense Command Values
The Request Sense Command (see Table 2-6 on page 2-10) returns values
for the Sense Key and Additional Sense Code.
Drive Request Sense - Sense Key Values
Table A-1
Request Sense - Sense Key Values Byte 2, Bits 3 through 0
Name
Abbrev.
Description
0H
No Sense
NS
The command completed
successfully.
1H
Recovered Error
RE
The last command was
completed successfully
with some recovery action
performed by the drive/
controller.
2H
Not Ready
NR
The drive cannot be
accessed.
3H
Medium Error
ME
The command terminated
with an unrecovered error
condition that was caused
by a optical disk defect.
4H
Hardware Error
HE
The drive/controller
detected a hardware error.
5H
Illegal Request
IR
There was an illegal
parameter in the
command descriptor block
or in the additional
parameters supplied for
some commands.
Appendix A
A-3
Drive Error Codes
Sense
Key
Drive Error Codes
Drive Request Sense Command Values
Table A-1
Request Sense - Sense Key Values Byte 2, Bits 3 through 0
Sense
Key
Name
Abbrev.
Description
6H
Unit Attention
UA
The optical disk has been
loaded, the unit has been
reset, or the Mode Select
parameters have been
changed.
7H
Data Protect
DP
A command that writes to
the optical disk cannot be
performed due to the
write-protect condition of
the optical disk writeprotect switch.
8H
Blank Check
BC
A blank sector was
detected during a Read
(Group 0 or 1) or Verify, or
a written sector was
detected during a Write
(Group 0 or 1) or a Write
and Verify command.
0BH
Aborted
Command
AC
Indicates that the drive
aborted the last command.
The initiator may be able
to recover by attempting
the command again.
A-4
Appendix A
Drive Error Codes
Drive Request Sense Command Values
Request Sense - Additional Sense Code Values
Bytes 12 and 13
Table A-2
Request Sense - Additional Sense Code Values
Sense
Key
Description
00 00
0H - NS
No Additional Sense Information
03 00
4H - HE
Write Fault, Write Command Failed
04 00
2H - NR
Drive Not Ready
04 01
2H - NR
LUN in Process of Becoming Ready
04 02
2H - NR
LUN Not Ready, Initializing Command
Required
04 04
2H - NR
LUN Not Ready, Format in Progress
09 01
4H - HE
Tracking Servo Failure
09 02
4H - HE
Focus Servo Failure
09 03
4H - HE
Spindle Servo Failure
0C 01
1H - RE
Write Error Recovered with Auto
Reallocation
0C 02
3H - ME
Write Error - Auto Reallocation Failed
10 00
3H - ME
ID CRC or ECC Error
11 00
3H - ME
Unrecovered Read Error
15 00
4H - HE
Random Positioning Error
16 00
3H - ME
Data Synchronization Mark Error
18 00
1H - RE
Recovered Read Data With ECC Procedure
18 01
1H - RE
Recovered Data with Error Correction and
Retries
19 01
1H - RE
Defect List Not Available
Appendix A
Drive Error Codes
Sense
Code
and
Qualifier
A-5
Drive Error Codes
Drive Request Sense Command Values
Table A-2
Request Sense - Additional Sense Code Values
Sense
Code
and
Qualifier
Sense
Key
Description
1A 00
5H - IR
Parameter List Length Error
1B 00
4H - HE
Synchronous Data Transfer Error
1C 00
3H - ME
Defect List Not Found
1C 01
3H - ME
Primary Defect List Not Found
1C 02
3H - ME
Grown Defect List Not Found
20 00
5H - IR
Invalid Command Operation Code
21 00
5H - IR
Logical Block Address out of Range
24 00
5H - IR
Invalid Field In CDB
25 00
5H - IR
LUN Not Supported
26 00
5H - IR
Invalid Parameter List
26 01
5H - IR
Parameter Not Supported
26 02
5H - IR
Parameter Value Invalid
27 00
7H - DP
Write Protected
28 00
6H - UA
Medium Changed
29 00
6H - UA
Power-On, Reset or Bus Device Reset
Occurred
2A 00
6H - UA
Mode Select Parameters Changed
2F 00
6H - UA
Command Cleared by Another Initiator
30 00
3H - ME
Incompatible Cartridge
31 00
3H - ME
Medium Format Corrupted
32 00
3H - ME
No Defect Spare Location Available
32 01
3H - ME
Defect List Update Error
A-6
Appendix A
Drive Error Codes
Drive Request Sense Command Values
Table A-2
Request Sense - Additional Sense Code Values
Sense
Key
Description
39 00
5H - IR
Saving Parameters Not Supported
3A 00
2H - NR
Medium Not Present
3D 00
5H - IR
Invalid Bits in Identify Message
3F 01
6H - UA
Microcode Has Been Changed
40 80
4H - HE
Bias Magnet Failure
40 81
4H - HE
Limited Laser Life
40 84
4H - HE
Temperature Alarm
40 85
4H - HE
Laser Failure, No LD Power
40 86
4H - HE
Read Channel Calibration Error
40 87
4H - HE
Illegal Servo Signal
40 88
4H - HE
Sensor Failure
40 90
4H - HE
DSP Diag Error
40 91
4H - HE
12V Line Failure
40 92
4H - HE
Medium Recognition Error
40 95
4H - HE
Buffer Memory Test Error
40 97
4H - HE
DSP Communication Diag Error
40 98
4H - HE
DSP Download Error
40 99
4H - HE
RAM Diag Error
40 9A
4H - HE
ODC Diag Error
40 9B
4H - HE
Buffer Memory Diag Error
40 9D
4H - HE
Write CAL Error
43 00
BH - AC
Message Error
Appendix A
Drive Error Codes
Sense
Code
and
Qualifier
A-7
Drive Error Codes
Drive Request Sense Command Values
Table A-2
Request Sense - Additional Sense Code Values
Sense
Code
and
Qualifier
Sense
Key
Description
44 00
4H - HE
Internal Target Failure
45 00
BH - AC
Select or Reselect Failure
47 00
BH - AC
SCSI Parity Error
48 00
BH - AC
Initiator Detected Error Message Received
49 00
BH - AC
Invalid Message Error
4E 00
BH - AC
Overlapped Commands Attempted
53 00
4H - HE
Media Load/Eject Failure
53 02
5H - IR
Medium Removal Prevented
92 00
8H - BC
Overwrite Attempted
93 00
8H - BC
Blank Sector Detected
94 00
8H - BC
Written Sector Detected
A-8
Appendix A
Drive Error Codes
Internal Error Codes
Internal Error Codes
NOTE
The XXXX that follows the internal error code refers to the 1 byte dsp/odc
error code where available.
Table A-3
Internal Error Codes
Message
00070000
Medium was changed
00080000
Power on, reset, or bus device reset occurred (5.2 Gb drives)
00080001
Unit Attention: power on reset (9.1 Gb drives)
00080002
SCSI bus reset (9.1 Gb drives)
00080003
SCSI bus device reset message (9.1 Gb drives)
00080004
Autochanger reset (9.1 Gb drives)
00090000
Mode parameter changed
006B0000
Microcode changed
02540000
Queued command cleared by another initiator
012BXXXX
An invalid SCSI message was received
012CXXXX
An invalid bit of Identify message is set to 1
012DXXXX
Parity error was detected while receiving a SCSI message
012EXXXX
A SCSI message was rejected
012FXXXX
The Attention signal was asserted after the Message Out Phase
0130XXXX
A SCSI interface parity error was detected
0131XXXX
The Initiator Detected Error Message was received
0133XXXX
The offset of the synchronous data transfer is too large
Appendix A
Drive Error Codes
Error
Code
(hex.)
A-9
Drive Error Codes
Internal Error Codes
Table A-3
Internal Error Codes
Error
Code
(hex.)
Message
0134XXXX
The period of the synchronous data transfer is too short
0139XXXX
The Clear Queue message was received
013AXXXX
Initiator does not respond to reselection
013BXXXX
Unusual SCSI controller condition
013CXXXX
Unusual SCSI controller condition
0204XXXX
An invalid microcode data was received
020AXXXX
An invalid operation code was specified
020BXXXX
An invalid LBA range was specified
020CXXXX
An invalid field in CDB was specified
020DXXXX
An invalid parameter list was specified
0210XXXX
Parameter list length is wrong
0211XXXX
The parameter saving function is not supported
0212XXXX
The parameter is not currently saved
0213XXXX
Cartridge eject was prevented
0250XXXX
Attempt to write data to a written sector of a write-once disk
0254XXXX
A queued command is cleared by another initiator
0255XXXX
A command was received for the same ITL (or ITLQ) nexus
026CXXXX
An invalid command for the write-once disk was specified
02B3XXXX
Invalid command when using 14x 512 b/s or 1024 b/s disk
0321XXXX
Loader task ended with an unusual condition
0322XXXX
Sensor failure during loader initialization
0323XXXX
Failed recovery procedure during loader initialization
A-10
Appendix A
Drive Error Codes
Internal Error Codes
Table A-3
Internal Error Codes
Message
0324XXXX
Cartridge loading failed
0327XXXX
Cartridge unloading failed
0417XXXX
The loader is being initialized
0418XXXX
No cartridge is in the drive
041AXXXX
The disk is being spun-up
041BXXXX
The disk is being loaded
041CXXXX
The disk load is complete (not an error)
041DXXXX
The drive is not ready
041EXXXX
A disk is being spun-down
041FXXXX
A disk is being unloaded
0420XXXX
Drive unable to go Ready because of an unknown reason
0425XXXX
The drive is in process of becoming ready
046FXXXX
The drive is in process of formatting a disk
0514XXXX
The Defect List Format is not supported
0515XXXX
The cartridge is write-protected
0528XXXX
Invalid cartridge ID hole
0529XXXX
The medium is not supported
053EXXXX
PDL data is invalid
053FXXXX
SDL data is invalid
0540XXXX
DDS sectors were not found
0541XXXX
PDL sector was not found
0542XXXX
SDL sector was not found
Appendix A
Drive Error Codes
Error
Code
(hex.)
A-11
Drive Error Codes
Internal Error Codes
Table A-3
Internal Error Codes
Error
Code
(hex.)
Message
0543XXXX
DMA sector cannot be read
0544XXXX
DDS data are invalid
0545XXXX
SFP sector cannot be read
0546XXXX
SFP data is invalid
0547XXXX
Failed in Erase/Blank Check/Write/Read/Compare test after
disk load and spin-up
0548XXXX
Spare area for defective sector is full
0549XXXX
Failed updating DMA sectors
054AXXXX
PEP data is invalid
054BXXXX
Defective sector was recovered with automatic write
reallocation procedure
054CXXXX
Failed in automatic write reallocation procedure
0551XXXX
A blank sector was detected
0577XXXX
Automatic Write Reallocation performed due to ID Error
0578XXXX
Automatic Write Reallocation performed due to uncorrectable
ECC Error
0579XXXX
Automatic Write Reallocation performed due to SYNCH Error
057AXXXX
Automatic Write Reallocation performed due to Servo Fault
Error
057EXXXX
ID Error recovered by retry
057FXXXX
Uncorrectable ECC Error recovered by retry
0580XXXX
SYNCH Error recovered by retry
0581XXXX
Servo Fault Error recovered by retry
A-12
Appendix A
Drive Error Codes
Internal Error Codes
Table A-3
Internal Error Codes
Message
0582XXXX
ID Error reoccurs after retry even after changing ID Error
criteria
0583XXXX
DMA Update failed after Automatic Reallocation
058AXXXX
DMA Update Error condition
0601XXXX
Received error code NN (see Table A-5 on page A-17) from ODC
chip
0664XXXX
An ODC interrupt time out
0669XXXX
A disk type cannot be distinguished (ID Status is CRC=NG)
066AXXXX
A disk type cannot be distinguished (no ODC interrupt)
066DXXXX
SFP sector cannot be read (ID Status is CRC=NG)
0670XXXX
Cannot abort ODC command
0692XXXX
Error Code NN received from the ODC chip
0702XXXX
Received error code NN (see Table A-6 on page A-19) from the
DSP
075CXXXX
Failed downloading DSP code
075EXXXX
DSP request command communication error occurred
0760XXXX
DSP command communication error occurred
0762XXXX
Failed in the ECHO command of DSP
0767XXXX
Target sector cannot be found (time out after SEEK complete)
0774XXXX
Servo failure during write operation
0789XXXX
LPC calibration failed
078BXXXX
ID Offset Calibration failed
078CXXXX
MO Offset Calibration failed
Appendix A
A-13
Drive Error Codes
Error
Code
(hex.)
Drive Error Codes
Internal Error Codes
Table A-3
Internal Error Codes
Error
Code
(hex.)
Message
078DXXXX
VFO Offset Calibration failed
078EXXXX
ID VGA Calibration failed
078FXXXX
MO VGA Calibration failed
0791XXXX
Focus bias calibration failed
07B4XXXX
Read power calibration failed
0957XXXX
Power-on diagnostic time out
0959XXXX
ROM Checksum Error
095AXXXX
Illegal request for DSP Interface task
095FXXXX
Command Parameter Length contradiction to DSP
0961XXXX
Release wait of DSP I/F task
0965XXXX
ODC command was aborted
0968XXXX
Illegal request to Read/Write task
096EXXXX
Parameter Block data is invalid
0A4FXXXX
12V line is not supplied
0A71XXXX
RAM Test Error
0A72XXXX
ODC Test Error
0E03XXXX
Failed updating the flash ROM
0E05XXXX
Failure when updating the Parameter Block
0E56XXXX
Parameter Block Error
A-14
Appendix A
Drive Error Codes
Internal Error Codes
Table A-4
ODC Error Codes
Description
01
ODC command was aborted
08
Search condition does not occur
11
A number of error bytes exceeds the setting value
12
Cannot detect the SYNC
13
Both 11 and 12 error occur
14
A number of the RESYNC mis-detecting exceeds the setting
value
15
Both 11 and 14 occur
16
Both 12 and 14 occur
17
Both 13 and 14 occur
20
Sector Mark (SM) error
21
ID CRC error
22
Cannot detect the SYNC and the first RESYNC
23
DTRG (Data Transfer Read Gate) becomes non-active
before all data of a sector was transferred
24
Uncorrectable error
25
CRC error (uncorrectable)
29
Cannot follow the read data transfer from the drive
31
Cannot follow the write data transfer from the drive
32
Digital Sum Value (DSV) error
34
Written sector is detected
42
Buffer Memory Write/Read/Compare error
Appendix A
A-15
Drive Error Codes
Code
(hex.)
Drive Error Codes
Internal Error Codes
Table A-4
ODC Error Codes
Code
(hex.)
Description
44
Cannot proceed with error correction because the syndrome
buffer was filled
45
Cannot correct the error bytes within the time of one sector
46
A write data transfer to the encoder was too short
47
A write data transfer to the encoder was too long
48
Unexpected sequence of the error correction occurred
4E
Unexpected interrupt was detected in the ODC chip
4F
Unexpected firmware sequence occurred in the ODC chip
50
Asynchronous interrupt of the DSP was detected
51
Unexpected ID value was detected
52
Both unexpected and expected ID value detected on one
track
54
Target sector was passed before the current position was
detected
57
A detected ID sector number was greater than the
maximum sector number
70
A Parameter List was not prepared
71
A sector number of the Parameter List was greater than the
maximum sector number
72
A sector count of the Parameter List is set to 0 in the W/R/S
73
Undefined condition is set in the DTS, DLS command
7D
Setup command was issued while executing the Identify
operation
7E
A command was issued while executing another command
7F
Undefined command was issued
A-16
Appendix A
Drive Error Codes
Internal Error Codes
Table A-5
ODC Error Codes
Description
01
ODC command was aborted
08
Search condition does not occur
11
A number of error bytes exceeds the setting value
12
Cannot detect the SYNC
13
Both 11 and 12 error occur
14
A number of the RESYNC mis-detecting exceeds the setting
value
15
Both 11 and 14 occur
16
Both 12 and 14 occur
17
Both 13 and 14 occur
20
Sector Mark (SM) error
21
ID CRC error
22
Cannot detect the SYNC and the first RESYNC
23
DTRG becomes non-active before all data of a sector was
transferred
24
Uncorrectable error
25
CRC error (uncorrectable)
29
Cannot follow the read data transfer from the drive
31
Cannot follow the write data transfer from the drive
32
Digital Sum Value (DSV) error
34
Written sector is detected
42
Written sector is detected
Appendix A
A-17
Drive Error Codes
Code
(hex.)
Drive Error Codes
Internal Error Codes
Table A-5
ODC Error Codes
Code
(hex.)
Description
44
Cannot proceed with error correction because the syndrome
buffer was filled
45
Cannot correct the error bytes within the time of one sector
46
A write data transfer to the encoder was too short
47
A write data transfer to the encoder was too long
48
Unexpected sequence of the error correction occurred
4E
Unexpected interrupt was detected in the ODC chip
4F
Unexpected firmware sequence occurred in the ODC chip
50
Asynchronous interrupt of the DSP was detected
51
Unexpected ID value was detected
52
Both unexpected and expected ID value detected on one
track
54
Target sector was passed before the current position was
detected
57
A detected ID sector number was greater than the
maximum sector number
70
A Parameter List was not prepared
71
A sector number of the Parameter List was greater than the
maximum sector number
72
A sector count of the Parameter List is set to 0 in the W/R/S
73
Undefined condition is set in the DTS, DLS command
7D
Setup command was issued while executing the Identify
operation
7E
A command was issued while executing another command
7F
Undefined command was issued
A-18
Appendix A
Drive Error Codes
DSP Error Codes
DSP Error Codes
Table A-6
DSP Error Codes
Description
01
Offset measurement failed
09
AC portion of ID signal calibration failure
0B
Read channel vga calibration failure (1X/2X/4X/8X)
0C
Read channel vga calibration failure (1X/2X/4X/8X)
0D
Read channel OST calibration failure (4X/8X)
0E
Read channel MOVGAcalibration failure (1X/2X)
0F
Focus failure (read channel VGA calibration) (1X/2X/4X/
8X)
10
Cannot be arranged (Read channel IDVGA calibration)
(4X/8X)
11
Medium mischuking (FCSFLR)
21
Spindle off aborted
34
Calibration request
41
Drive is not ready
43
Imitation ATT signal caused by ESD
44
Focus failed (ID search)
45
LPC Attention occurred
52
Illegal zone selected (ALTERNATE ZONE)
53
Illegal zone selected (LD READ/PEP)
54
Illegal target zone (SEEK start)
55
Illegal target zone (SEEK One-Track Jump loop)
Appendix A
A-19
Drive Error Codes
Code
(hex.)
Drive Error Codes
DSP Error Codes
Table A-6
DSP Error Codes
Code
(hex.)
Description
56
Illegal target zone (SEEK landing)
57
Illegal next zone (SEEK landing)
58
Illegal zone (ID search)
59
Illegal zone (ID search)
5A
Illegal zone (focus search)
5B
Kick inner area failed
5C
Servo agc time out
61
Focus on failed
62
Focus on aborted
63
Tracking on failed
64
Tracking drive saturation
65
No ID (No SM or CRC=NG) (DON start)
66
No ID (No SM or CRC=NG) (SEEK start)
67
No ID (No SM or CRC=NG) (SEEK landing)
68
Seek slip too much
69
Voice Coil Motor and Multi-Track Jump Seek time out
6A
Seek target is too far for a One Track Jump
6B
Multi-Track Jump is too long
6C
Focus failure
6D
Tracking failure
6E
Low Pull-in
6F
Focus drive saturation
71
Cannot detect PEP signal
A-20
Appendix A
Drive Error Codes
DSP Error Codes
Table A-6
DSP Error Codes
Description
72
Focus failed (PEP positioning)
74
Focus failed (searching PEP GAP)
75
Focus failed (searching PEP PA)
76
Focus failed (searching PEP data)
77
Focus on failed (before searching PEP data)
78
No PEP gap found
79
Illegal PEP format found (PEP Postamble)
7A
Illegal PEP format found (PEP data)
7B
PEP decoding byte count error
7C
Invalid PEP SYNC found
7D
No PEP SYNC found
7E
PEP CRC=NG
7F
First and second PEP data compare error
C1
An error occurred in the position sensor
C2
Catastrophic error in the bias magnet
C4
R/C revision error
C9
No laser diode power
CA
Assert write fault for controller debug
CF
Temperature alarm
D1
Illegal address selected
D3
Invalid command
D4
Communication failure
E1
Spindle Lock time out (drive on)
Appendix A
Drive Error Codes
Code
(hex.)
A-21
Drive Error Codes
DSP Error Codes
Table A-6
Table A-7
DSP Error Codes
Code
(hex.)
Description
E2
Spindle off failed
E3
Medium mischuking (Spindle On Failure)
E4
Tracking failure for certifier
E5
Spindle lock time out
E6
Focus failure for certifier
F3
E/AR/C Serial Write Block = NG
F4
E/A LPC Serial Write Block = NG
F5
E/A R/C Serial Read Block = NG
Terms Used In the Tables
Acronym
or
Term
Used
Meaning
ATT
Attention Signal
CDB
Command Descriptor Block
CRC
Cyclic Redundancy Check
DDS
Disk Definition Standard
DMA
Defect Management Area
DON
Drive On
DSP
Digital Signal Processor
DSV
Digital Sum Value
DTRG
“D” Trigger Signal
ITL
Initiator Target and Logical Unit
A-22
Appendix A
Drive Error Codes
DSP Error Codes
Table A-7
Terms Used In the Tables
Meaning
ITLAQ
Initiator Target and Logical Unit and Queue Tag
LBA
Logical Block Address
NG
No Good
ODC
Optical Drive Controller
PA
Postamble
PEP
Phase-Encoded Part
PDL
Primary Defect List
RESYNC
Resynchronization pattern
SDL
Secondary Defect List
SM
Sector Mark
SFP
Standard Format Part
SYNC
Synchronization pattern
VCM
Voice Coil Motor
VGA
Variable Gain Adjust
VFO
Variable Frequency Oscillator
Appendix A
Drive Error Codes
Acronym
or
Term
Used
A-23
Drive Error Codes
DSP Error Codes
A-24
Appendix A
Autochanger Error Codes
B
Autochanger Error Codes
Appendix B
B-1
Autochanger Error Codes
Chapter Overview
Chapter Overview
This chapter contains the following autochanger error code tables:
• Request Sense Codes
• Request Sense Maps
• Hardware Error Codes
• Move Error Codes
• Micro-Move Failure Type Codes
• Diagnostic Tests
An error code can be reported through the Log Sense Command (4DH),
Request Sense Command (03H), or through the control panel.
NOTE
See Appendix C for a list of field replaceable units for the each of the
jukebox models.
B-2
Appendix B
Autochanger Error Codes
Request Sense Error Codes
Request Sense Error Codes
This section identifies each of the error responses for the autochanger
"Request Sense Command (03H)", Table 3-5 on page 3-8.
Table B-1
Request Sense - Sense Key Values — Byte 2, Bits 3 through 0
Name
Abbrev.
Description
0H
No Sense
NS
The command completed
successfully.
1H
Recovered
Error
RE
The last command was
completed successfully with
some recovery action
performed by the
autochanger/controller.
2H
Not Ready
NR
The autochanger cannot be
accessed.
3H
Medium Error
ME
The command terminated
with an unrecovered error
condition that was caused by
a optical disk defect.
4H
Hardware
Error
HE
The autochanger/controller
detected a hardware error.
5H
Illegal Request
IR
There was an illegal
parameter in the command
descriptor block or in the
additional parameters
supplied for some commands.
6H
Unit Attention
UA
The optical disk has been
loaded, the unit has been
reset, or the Mode Select
parameters have been
changed.
Appendix B
B-3
Autochanger Error Codes
Sense
Key
Autochanger Error Codes
Request Sense Error Codes
Table B-1
Table B-2
Request Sense - Sense Key Values — Byte 2, Bits 3 through 0
Sense
Key
Name
Abbrev.
Description
0BH
Aborted
Command
AC
This sense key shall be
reported if a target or LUN
receives a second command
from the same initiator
before the previous command
from that initiator has
completed.
Request Sense Data (bytes 12 and 13)
Sense
Code
and
Qualifier
Sense
Key
Description
00 00H
0H-NS
No additional sense information
00 00H
1H-RE
Error recovered invoked and completed
(Table B-6 on page B-14)
04 00H
0B-AC
Aborted command (boot code)
04 01H
2H-NR
Autochanger becoming ready
04 02H
2H-NR
Unit must first initiate element status
04 03H
2H-NR
Fatal error - unit must be corrected
manually
04 88H
02-NR
Firmware download needed (boot code)
04 89H
4H-HE
Download checksum error
15 01H
4H-HE
Move error (Check additional sense bytes)
(Table B-6 on page B-14)
1A 00H
5H-IR
Invalid parameter list length
20 00H
5H-IR
Unsupported command
21 01H
5H-IR
Invalid address - (Table B-3 on page B-7)
B-4
Appendix B
Autochanger Error Codes
Request Sense Error Codes
Table B-2
Request Sense Data (bytes 12 and 13)
Sense
Key
Description
22 00H
5H-IR
Unsupported command
22 80H
5H-IR
Drive is not online
24 00H
5H-IR
Illegal field in CDB
25 00H
5H-IR
Invalid LUN
26 00H
5H-IR
Invalid parameter list
29 00H
6H-UA
Power on sense or bus reset
2A 80H
6H-UA
Online repair parameters
2F 00H
0BH-AC
Command cleared by initiator
3F 01H
06H-UA
Microcode has been changed
3B 0DH
5H-IR
Element full - (Table B-4 on page B-7)
3B 0EH
5H-IR
Source empty - (Table B-4 on page B-7)
3D 00H
5H-IR
Invalid identify message in
3F 03
06-UA
Inquiry data has changed
40 80H
4H-HE
Diagnostic failure (Table B-6 on page B-14)
42 00H
4H-HE
Poweron selftest failure
43 00H
OB-AC
Message parity error
44 00H
4H-HE
Internal target error
45 00H
0B-AC
Reselection timeout error
47 00H
0B-AC
Parity error
48 00H
0B-AC
Initiator detected error
4B 00H
0B-AC
Bus protocol error - data phase error
Appendix B
Autochanger Error Codes
Sense
Code
and
Qualifier
B-5
Autochanger Error Codes
Request Sense Error Codes
Table B-2
Request Sense Data (bytes 12 and 13)
Sense
Code
and
Qualifier
Sense
Key
Description
4E 00H
0B-AC
Bus protocol error (second command sent
early)
53 00H
5H-IR
Media load or eject failed
53 02H
5H-IR
Medium removal prevented
53 82H
5H-IR
Medium removal prevented on drive
55 00H
2H-NR
Transaction queue is full
B-6
Appendix B
Autochanger Error Codes
Request Sense Error Codes
Table B-3
Table B-4
Invalid Address: Sense Code 2IH
Field Pointer
Description
00
Invalid element address
02
Invalid transport element
04
Invalid source element
06
Invalid destination element
08
Invalid second destination element
Element Full/Empty: Sense Code 3BH
Description
02
Transport full
04
Source empty
06
Destination full/empty
08
Second destination full
Appendix B
Autochanger Error Codes
Field Pointer
B-7
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
Additional Sense Data Format for Error
Recovery
For all models, EXCEPT 40fx and 80ex.
Below is a description of the 60 Additional Sense Bytes returned during
the Data In Phase of the Request Sense Command (03H), (Table 3-6 on
page 3-9) from the autochanger. The overall layout of the data is
presented first, followed by a description of each byte.
Table B-5
Request Sense - Additional Sense Data
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Byte
7
6
18
Reserved (0)
19
Hardware Error Code (Table B-7 on page B-19)
20
First FRU (Table A-1 on page A-2)
21
Second FRU (Table A-1 on page A-2)
22
Third FRU (Table A-1 on page A-2)
23
Move Command Attempted
24-25
Source Element Number
26-27
Destination Element Number
28-29
Second Destination Element Number
30-34
Micro-Move ID History (Table C-1 on page C-2)
35
Failed Micro-Move ID (Table C-1 on page C-2)
36
Micro-Move Error Code
37
Active
Picker
38-39
Vertical Motor Commanded Position
Active
Thumb
B-8
5
4
3
2
1
0
Reserved (0)
Appendix B
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
Table B-5
Request Sense - Additional Sense Data
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
7
6
5
4
3
2
1
40-41
Vertical Motor Actual Position
42-43
Plunge Motor Commanded Position
44-45
Plunge Motor Actual Position
46-47
Translate Motor Commanded Position
48-49
Translate Motor Actual Position
50-53
Odometer
54
Move
Cap
Last
SCSI
55
Valid
56
0
Reserved (0)
Cart 16
Cart 17
Reserved (0)
Reservd
(0)
Cart
Tran
Cart
Elem
Reserved (0)
Valid
Reservd
(0)
Cart
Tran
Cart
Elem
Reserved (0)
57
Valid
Reservd
(0)
Cart
Tran
Cart
Elem
Reserved (0)
58-77
Reserved (0)
Autochanger Error Codes
Byte
Hardware Error
Code
Determined by fault isolation, this error code indicates
the cause of the failure. The values of the Hardware
Error Codes are in Table B-7 on page B-19.
First FRU
The most likely Field Replacable Unit to be the cause of
the failure. (See Table A-1 on page A-2)
Second FRU
The second most likely Field Replacable Unit to be the
cause of the failure. (See Table A-1 on page A-2.)
Third FRU
The third most likely Field Replacable Unit to be the
cause of the failure. (Table A-1 on page A-2.)
Appendix B
B-9
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
NOTE
The FRU numbers returned are indicators for the most likely cause of an
error, but may not be the actual cause of a problem. Simply changing the
FRU listed may or may not fix the associated problem.
Move Command
Attempted
0 - Exchange
1 - Move
2 - Seek
3 - Initialize Element
4 - Rezero
5 - Rotate Mailslot
6 - Restore
7 - Passthru
Source Element
Number
The Element Number to which the source refers.
Destination
Element
Number
Second
Destination
Number
Micro-Move
ID History
Failed MicroMove ID
Micro-Move
Error Code
Active Picker
B-10
The Element Number to which the destination refers.
The Element Number to which the second destination
refers.
The last five autochanger Micro-Move IDs for the
original movement command prior to the failure. (See
Table C-1 on page C-2.)
Actual micro-move that failed. (See Table C-1 on
page C-2)
The error code associated with the failed Micro-Move
ID. (See Table B-10 on page B-321.)
This bit signifies which side of the disk transport
mechanism is active: 1= top, 0= bottom.
Appendix B
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
Active Thumb This bit signifies which thumb is active: 0 = north, 1 =
south.
Vertical Motor
Commanded
Position
The position to which the vertical motor was
commanded.
Vertical Motor
Actual
Position
The actual position of the vertical motor.
Plunge Motor
Commanded
Position
Autochanger Error Codes
Plunge Motor
Actual
Position
The position to which the plunge motor was
commanded.
The actual position of the plunge motor.
Translate Motor
Commanded
Position
The position to which the translate motor was
commanded.
Translate Motor
Actual
Position
The actual position of the translate motor.
Odometer
The move odometer.
Mechanism State
Bit Map
(Byte 54)
The state of the jukebox after the termination of the
retry or recovery algorithms. This byte is bit mapped
from least significant bit to most significant bit as
follows:
7 - Move Capability 1=The jukebox is capable of
performing movement commands.
6 - Last SCSI State 1=The jukebox returned cartridges
to the state they were in prior to the failed command.
5-4 Reserved
Appendix B
B-11
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
3 - Cartridge in Transport 16 1=a cartridge is in the
transport 16 mechanism. If the cartridge wasn't
replaced after a failure, the appropriate Element Bit
Map will indicate which cartridge is in the transport.
2 - Cartridge in Transport 17 1=a cartridge is in the
transport 17 mechanism. If the cartridge wasn't
replaced after a failure, the appropriate Element Bit
Map will indicate which cartridge is in the transport.
1-0 Reserved
Source Element
Bit Map
(Byte 55)
Status of the cartridge in the specified Source Element
of the Move or Exchange command after the failure or
retry, as well as the status of the element itself, as
shown below:
7 - Valid 1 = the values in this byte and the Element
Number byte are valid.
6 - Reserved
5 - Cartridge in Transport 1 = the cartridge originally in
this element is still in the transport.
4 - Cartridge in Element 1 = after all recovery
algorithms have been exhausted, the cartridge being
moved from this element remained in this element.
3-0 Reserved
B-12
Appendix B
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
Destination 1 Element
Bit Map
(Byte 56)
Indicates the status of the element that was the First
Destination of the Exchange command after the failure
or retry of the command.
7 - Valid 1= the values in this byte and the Element
Number are valid.
6 - Reserved
5 - Cartridge in Transport 1 = the cartridge originally in
this element is still in the transport.
4 - Cartridge in Element 1 = after all recovery
algorithms have been exhausted, the cartridge being
moved from this element remained in this element.
Destination 2 Element
Bit Map
(Byte 57)
Indicates the status of the element that was the
Destination Element of a move or Second Destination of
the Exchange command after the failure or retry of the
command.
7 - Valid 1 = the values in this byte and the Element
Number are valid.
6 - Reserved
5 - Cartridge in Transport 1 = the cartridge being moved
to this element is still in the transport.
4 - Cartridge in Element 1 = the cartridge being moved
to this element is in this element after all recovery
algorithms have been exhausted.
3-0 Reserved
Appendix B
B-13
Autochanger Error Codes
3-0 Reserved
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
Table B-6
Request Sense - Additional Sense Data
(For models 40fx, 80ex, 125ex and 220mx ONLY)
Byte
7
6
18
Move Error (Table B-9 on page B-29)
19
Hardware Error Code (Table B-8 on page B-22)
20
First FRU (Table A-2 on page A-4)
21
Second FRU (Table A-2 on page A-4)
22
Third FRU (Table A-2 on page A-4)
23
MvCap
24-25
Reserved (0)
26
DInRty
27
Retry Count
28-29
Reserved (0)
30
DInRty
31
Recovery Count
32-34
Reserved (0)
35
Valid
36-37
Source Element Number
38
Valid
39-40
Destination Element Number
41
Valid
42-43
Secondary Source Element Number
44
Valid
45-46
Second Destination Element Number
Last
DEjRty
DEjRty
ErrEn
ErrEn
ErrEn
ErrEn
B-14
5
4
3
2
1
0
Rsvd
(0)
PosLost
CartIn
PkrRec
CarAssy
Reserved (0)
BFHm
FHR
PkrRec
CarAssy
Reserved (0)
BFHm
FHR
CartIn
CartEl
UnexpMt
UnexpFl
CartInv
ElRty
CartEl
UnexpMt
UnexpFl
CartInv
ElRty
CartEl
UnexpMt
UnexpFl
CartInv
ElRty
UnexpMt
UnexpFl
CartInv
ElRty
CartIn
CartIn
CartIn
CartEl
Reserved (0)
Appendix B
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
Table B-6
Request Sense - Additional Sense Data
(For models 40fx, 80ex, 125ex and 220mx ONLY)
7
6
5
47-49
Reserved (0)
50-54
Micro-Move ID History (Table C-2 on page C-17)
55
Failed Micro-Move ID (Table C-2 on page C-17)
56
Micro-Move Error Code (Table B-11 on page B-36)
57-60
Vertical Motor Commanded Position
61-64
Vertical Motor Actual Position
65-68
Horizontal Motor Commanded Position
69-72
Horizontal Motor Actual Position
73-77
Reserved (0)
Move Error
Code
4
3
2
1
0
The movement that was being performed when the
error occurred. The values of the Move Error Codes are
in Table B-9 on page B-29.
Hardware Error
Code
Determined by fault isolation, this error code indicates
the cause of the failure. The values of the Hardware
Error Codes are in Table B-8 on page B-22.
NOTE
First FRU
The most likely Field Replacable Unit to be the cause of
the failure. (See Table A-2 on page A-4)
Second FRU
The second most likely Field Replacable Unit to be the
cause of the failure. (See Table A-2 on page A-4.)
Third FRU
The third most likely Field Replacable Unit to be the
cause of the failure. (See Table A-2 on page A-4.)
The FRU numbers returned are indicators for the most likely cause of an
error, but may not be the actual cause of a problem. Simply changing the
FRU listed may or may not fix the associated problem.
Appendix B
B-15
Autochanger Error Codes
Byte
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
MvCap
A Move Capable bit of 1 indicates the AC is capable of
performing move commands.
LastSCSI
A Last bit of 1 indicates the AC has successfully
returned the cartridges to the state they were in before
the failed command was executed.
PosLost
A Position Lost bit of 1 indicates the AC cannot
calibrate the mechanism and has lost position of the
picker.
CartIn
A Cartridge in Transport bit of 1 indicates a cartridge is
in the picker mechanism.
DInRty
A Drive Insert Retry bit of 1 indicates that more than
one attempt was needed to insert the cartridge into the
drive. (For Byte 26, this attempt refers to Retry
algorithm and for Byte 30 it refers to Recovery
algorithm.).
DEjRty
A Drive Eject Retry bit of 1 indicates that more than one
attempt was needed to eject the cartridge from the
drive. (For Byte 26, this attempt refers to Retry
algorithm and for Byte 30 it refers to Recovery
algorithm.)
PkrRec
A Picker Retracted bit of 1 indicates the picker fingers
were fully retracted after a failure. (For Byte 26, this
attempt refers to Retry algorithm and for Byte 30 it
refers to Recovery algorithm.)
CarAssy
A Horizontal Carriage Locked bit of 1 indicates the
picker fingers were fully retracted after a failure and
the translate pin is engaged. (For Byte 26, this attempt
refers to Retry algorithm and for Byte 30 it refers to
Recovery algorithm.)
B-16
Appendix B
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
BFHm
A Bad Find Home bit of 1 indicates the Find Home
algorithm was started while the optical sensors were
inoperable. (For Byte 26, this attempt refers to Retry
algorithm.)
FHR
A Find Home Recalibration bit of 1 Find Home
algorithm was invoked to recalibrate the mechanism
(For Byte 26, this attempt refers to Retry algorithm and
for Byte 30 it refers to Recovery algorithm).
Retry Count
The total number of retry attempts that were
performed.
Recovery Count The total number of recovery attempts that were
performed.
A "0" indicates that this and the next two bytes contain
invalid data. Valid in bytes 41 and 44 are only set
during the Exchange Medium Command.
ErrEn
An Error Encountered bit of 1 indicates an error
occurred while the picker was enroute to this element.
CartEl
A Cartridge in Element bit of 1 indicates the cartridge
associated with this move is in this element.
UnexpMt
An Element Unexpected Empty bit of 1 indicates this
element was unexpectedly empty.
UnexpFl
An Element Unexpected Full bit of 1 indicates this
element was unexpectedly full.
CartInv
A Cartridge Inverted bit of 1 indicates the cartridge is
inverted from its state before the operation began.
ElRty
An Element Required Retry bit of 1 indicates an
operation in or out of this element required one or more
retries.
Source Element
Number
The Element Number to which the Source Element Bit
Map (Byte 35) refers.
Destination Element
Number
The Element Number to which the Destination Element
Bit Map (Byte 38) refers.
Appendix B
B-17
Autochanger Error Codes
Valid
Autochanger Error Codes
Additional Sense Data Format for Error Recovery
Secondary Source
Element
Number
The Element Number to which the Secondary Source
Element Bit Map (Byte 41) refers.
Second Destination
Element
Number
The Element Number to which the Second Destination
Element Bit Map (Byte 44) refers.
Micro-Move
ID History
Failed MicroMove ID
Micro-Move
Error Code
The last five autochanger Micro-Move IDs for the
original movement command prior to the failure. (See
Table C-2 on page C-17.)
Actual micro-move that failed. (See Table C-2 on page
C-17)
The error code associated with the failed Micro-Move
ID. (See Table 5-11 on page 5-35.)
Vertical Motor
Commanded
Position
The position to which the vertical motor was
commanded.
Vertical Motor
Actual
Position
The actual position of the vertical motor.
Horizontal Motor
Commanded
Position
The position to which the horizontal motor was
commanded.
Horizontal Motor
Actual
Position
The actual position of the horizontal motor.
B-18
Appendix B
Autochanger Error Codes
Hardware Error Codes
Hardware Error Codes
Hardware Errors are reported through the Request Sense Command
(03H), (Byte 19, Table 5-6 on page 5-14), the Log Sense Command (4DH),
and the Receive Diagnostic Results Command (1CH), (Byte 1, Table 3-30
on page 3-34).
If an error is unrecoverable (i.e., something is broken or jammed beyond
recovery without manual intervention), the Autochanger will take an
additional step of attempting to identify the FRU that is causing the
failure.
Up to three FRUs will be returned to aide service in replacement priority.
NOTE
The FRU numbers returned are indicators for the most likely cause of an
error, but may not be the actual cause of a problem. Simply changing the
FRU listed may or may not fix the associated problem.
Table B-7
Hardware Error Codes (medium and large models only)
Error Code
(hex.)
Failure Description
01
ROM checksum error
02
Register error
03
Microprocessor error
04
Controlled area of RAM checksum error
05
RAM test error
06
SCSI chip error
07
Jukebox controller chip error
0F
Configuration module failure
Appendix B
B-19
Autochanger Error Codes
A routine that performs a process of elimination for various FRUs runs
automatically. It attempts to isolate the error to three or less FRUs. If no
error can be found (or if error recovery was made), the unit will return a
No Error status. If an error is found, a Hardware Error Code is returned
when the command completes.
Autochanger Error Codes
Hardware Error Codes
Table B-7
Hardware Error Codes (medium and large models only)
Error Code
(hex.)
Failure Description
11
Drive serial communications failure
1E
Translate motor error
1F
Vertical motor error
10
Drive configuration error
20
Plunge motor error
28
Mailslot sensor error
2B
Top thumb sensor error
2C
Bottom thumb sensor error
32
Invalid test number
33
Invalid configuration
34
Need to initialize element status
35
Exercise test failed
36
Elements reserved
38
Test can only be run from SCSI
39
Unable to run test
3C
Move to
3D
Flip
3E
Translate
3F
Put magazine in
40
Get magazine out
41
Test magazine
42
Put drive in
43
Get drive out
B-20
Appendix B
Autochanger Error Codes
Hardware Error Codes
Table B-7
Hardware Error Codes (medium and large models only)
Failure Description
44
Test drive
45
Put mailslot in
46
Get mailslot out
47
Test mailslot
48
Rotate mailslot in
49
Rotate mailslot out
4A
Test picker
4B
Switch active picker
4C
Restore picker
4D
Find translate home
4E
Find vertical home
4F
Find plunge home
50
Clear flip area
51
Clear magazine path
52
Clear drive path
53
Clear mailslot path
5B
Finish switch picker
5C
Wait plunge
5D
Wait vertical
5E
Powerfail clear path
5F
Powerfail restore cartridges
60
Repeater controller
61
External SCSI cables
Appendix B
Autochanger Error Codes
Error Code
(hex.)
B-21
Autochanger Error Codes
Hardware Error Codes
Table B-8
Hardware Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Error Code
(hex.)
Failure Description
JUKEBOX CONTROLLER PCA ERROR CODES
00
No error
01
ROM checksum error
03
RAM test error
04
Microprocessor test error
05
Controlled area of RAM checksum error a
06
Illegal interrupt encountered by microprocessor
07
Illegal CPU exception encountered by microprocessor
09
Firmware error
SCSI INTERFACE-SPECIFIC ERROR CODES
0B
SCSI controller register error
0C
SCSI controller IC's RAM failed
0D
SCSI controller message error
0E
SCSI controller command error
0F
SCSI controller kill error
10
SCSI controller FIFO error
11
SCSI controller target sequence error
12
SCSI controller command sequence error
13
SCSI controller status sequence error
LOOPBACK ERROR CODES
18
SCSI connector loopback error in DBO or I/O
B-22
Appendix B
Autochanger Error Codes
Hardware Error Codes
Table B-8
Hardware Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Failure Description
19
SCSI connector loopback error in DB1 or C/D
1A
SCSI connector loopback error in DB2 or MSG
1B
SCSI connector loopback error in DB3 or REQ
1C
SCSI connector loopback error in DB4 or ACK
1D
SCSI connector loopback error in DB5 or ATN
1E
SCSI connector loopback error in DB6 or SEL
1F
SCSI connector loopback error in DB7 or BSY
20
SCSI connector loopback error in DBP or RST
MULTIFUNCTION PERIPHERAL IC ERROR CODES
29
RS-232 loopback data did not match what was sent (not
supported)
2A
Timed out waiting for RS-232 loopback data (not
supported)
2B
Timer A did not count down as expected (not supported)
MOTOR CONTROL IC ERROR CODES
2C
Failed read\write test to Motor control IC
2D
Motor control IC loopback test failed
2E
Motor control IC RAM test failed
POWER SUPPLY ERROR CODES
33
Low voltage power supply failed
34
High voltage power supply failed
DRIVE CONNECT ERROR CODES
38
Drive 1 not connected
Appendix B
B-23
Autochanger Error Codes
Error Code
(hex.)
Autochanger Error Codes
Hardware Error Codes
Table B-8
Hardware Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Error Code
(hex.)
Failure Description
39
Drive 2 not connected
3A
Drive 3 not connected
3B
Drive 4 not connected
MECHANISM ERROR CODES
3CH
Unspecified mechanical failure
3EH
Unspecified servo failure
40H
Unable to free the Picker fingers in preparation for
Carriage motion
41H
Unable to verify that the Picker is at the Home position
during Find Home sequence (non-leadscrew side)
42H
Unable to find Home; Cartridge-in-path sensor blocked
43H
Unable to clear Cartridge-in-path sensors by moving
Picker fingers back
44H
Carriage motion failure during Find Home sequence
45H
Unable to free the Picker fingers in preparation for
translate motion
46H
Carriage motion failed while initializing Home position
during Find Home sequence
47H
Translate failed while moving towards non-leadscrew
side during Find Home sequence
48H
Carriage motion failed during Carriage/Picker assembly
calibration (leadscrew side)
49H
Carriage motion failed during Carriage/Picker assembly
calibration (non-leadscrew side)
4AH
Motion error while determining orientation of the Picker
B-24
Appendix B
Autochanger Error Codes
Hardware Error Codes
Table B-8
Hardware Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Failure Description
4BH
No sensor found (V4.2 code only)
4CH
Failed flip motion during the Find Home sequence (V4.5
code)
4DH
Motion error while checking for cartridge in the Picker
4EH
Unable to measure height of sensor on left side
4FH
Unable to measure height of sensor on right side
50H
Excessive tilt of the Carriage/Picker assembly (away
from the drives)
51H
Excessive tilt of the Carriage/Picker assembly (toward
the drives)
52H
Excessive cone angle on Picker
53H
Excessive stack tilt
54H
Unable to complete an interrupted move at power up
EXERCISER TEST ERROR CODES
55H
Unable to find top of unit
56H
Need to issue Initialize Element Status Command
57H
Invalid test configuration
59H
Exerciser unrecovered error
5AH
Invalid test configuration (elements reserved)
5BH
Initialize Element Status command failed
5CH
Shipping Diagnostic run with cartridges in the
mechanism
CALIBRATION SENSOR SYSTEM ERRORS
Appendix B
B-25
Autochanger Error Codes
Error Code
(hex.)
Autochanger Error Codes
Hardware Error Codes
Table B-8
Hardware Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Error Code
(hex.)
Failure Description
60H
Optical sensor failed (leadscrew side - near drives)
61H
Optical sensor failed (non-leadscrew side - near drives)
62H
Optical sensor failed (leadscrew side - near mailslot)
63H
Optical sensor failed (non-leadscrew side - near mailslot)
CARTRIDGE-IN-PATH (CIP) SENSOR SYSTEM ERRORS
64H
Intermittent CIP sensor beam (leadscrew side)
65H
Intermittent CIP sensor beam (non-leadscrew side)
66H
Path physically blocked (leadscrew side)
67H
Path physically blocked (non-leadscrew side)
6BH
CIP LED failed (leadscrew side)
6CH
CIP LED failed (non-leadscrew side)
6DH
CIP sensor failed (leadscrew side)
6EH
CIP sensor failed (non-leadscrew side)
6FH
CIP sensor system failed
MAILSLOT/STORAGE SLOT ERROR CODES
B0H
Mailslot will not rotate
B1H
Inside Mailslot sensor failed
B2H
Mailslot will not accept or release cartridge
B3H
Storage slot will not accept or release cartridge
B4H
Outside Mailslot sensor failed
DRIVE ERROR CODES
B8H
B-26
Drive #1 access error
Appendix B
Autochanger Error Codes
Hardware Error Codes
Table B-8
Hardware Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Error Code
(hex.)
Failure Description
B9H
Drive #2 access error
BAH
Drive #3 access error
BBH
Drive #4 access error
SOLENOID ERROR CODES
Drive #1 access failure; possible solenoid failure
BDH
Drive #2 access failure; possible solenoid failure
BEH
Drive #3 access failure; possible solenoid failure
BFH
Drive #4 access failure; possible solenoid failure
Autochanger Error Codes
BCH
FRU DETECTION TEST ERROR CODES
C8H
Unable to gain proper servo control of the motors
C9H
Unable to move the Picker motor
CAH
Unable to move the Carriage motor
CBH
Unable to move either motor
CCH
Unable to find a hard stop while turning the Picker
motor
CDH
Unable to find a hard stop while turning the Carriage
motor
CEH
Excessive force required to move the Carriage leadscrew
MISCELLANEOUS ERROR CODES
D0H
Find magazine edge failed
D1H
Unexpected mailslot empty
FCH
The test can only be run from the Front Panel
FDH
The test can only be run from the SCSI interface
Appendix B
B-27
Autochanger Error Codes
Hardware Error Codes
Table B-8
Hardware Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Error Code
(hex.)
Failure Description
FEH
The test did not run, probably a configuration error
FFH
Invalid test number
a. For further explanation, refer to the next section "Additional Descriptions of
Hardware Error Codes."
B-28
Appendix B
Autochanger Error Codes
Autochanger Move Error Codes
Autochanger Move Error Codes
NOTE
These error codes ONLY apply to the model 40fx, 80ex, 125ex, and 220mx
jukeboxes.
Move Errors are reported through byte 18 of the Additional Sense Bytes
Request Sense Command (03H) in Table 5-6 on page 5-14.
Table B-9
Autochanger Move Error Codes
Failure Description
00
Failure occurred before any servo-controlled motions
were attempted during Poweron Selftest.
02
Failure while Picker is not moving.
04
Failure while moving the Carriage/Picker assembly
away from drives.
06
Failure while moving the Carriage/Picker assembly
toward drives.
08
Failure while flipping the Picker.
0A
Failure while translating the Picker assembly.
0E
Failure while moving the Picker fingers back in
preparation to translate.
10
Failure while moving the Picker fingers to engage the
cartridge from the source storage element.
12
Failure while moving the Picker fingers back to
remove the cartridge from the source storage element.
18
Failure while moving the Picker fingers forwards to
insert a cartridge in the destination storage element.
1A
Failure while moving the Picker fingers back after
inserting a cartridge in the destination storage slot.
Appendix B
B-29
Autochanger Error Codes
Error Code
(hex.)
Autochanger Error Codes
Autochanger Move Error Codes
Table B-9
Autochanger Move Error Codes
Error Code
(hex.)
Failure Description
20
Failure while moving the Picker fingers forwards to
engage the cartridge ejected from the drive (source).
22
Failure while moving the Picker fingers back to
remove the cartridge from the drive (source).
28
Failure while moving the Picker fingers forwards to
insert the cartridge into the drive (destination).
2A
Failure while moving the Picker fingers back after
inserting a cartridge into the drive (destination).
30
Failure while moving the Picker fingers forward to
engage the cartridge in the mailslot (source).
32
Failure while moving the Picker fingers back to
remove the cartridge from the mailslot (source).
38
Failure while moving the Picker fingers forward to
insert the cartridge in the mailslot (destination).
3A
Failure while moving the Picker fingers back after
inserting the cartridge in the mailslot (destination).
40
Failure while rotating the mailslot actuator inward.
42
Failure to ensure that the mailslot rotated inward.
48
Failure while rotating the mailslot actuator outward.
4A
Failure to ensure that the mailslot rotated outward.
50
Failure while the finding the home position.
52
Failure while calibrating the Carriage/Picker
assembly.
60
Initializing element status failed while testing an
element with a cartridge in the Picker assembly.
80
Failure to remove a cartridge from a source element.
B-30
Appendix B
Autochanger Error Codes
Autochanger Move Error Codes
Table B-9
Autochanger Move Error Codes
Failure Description
84
Failure to leave a cartridge properly in a destination
element.
88
An obstruction was encountered before the cartridge
had been inserted the proper distance.
90
Source element unexpectedly empty.
94
Destination element unexpectedly full.
A0
Front mailslot sensor failed.
A2
Inside mailslot sensor failed.
A4
Drive light stuck on.
B0
Door interlock open.
Appendix B
Autochanger Error Codes
Error Code
(hex.)
B-31
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Jukebox Micro-Move Error Codes
Micro-Move Errors are reported through bytes 50-55 in the additional
sense bytes (Table 5-6 on page 5-14) of the Request Sense Command
(03H) and the "Log Sense Command (4DH)" with page code 33H. (See
Table 3-45 on page 3-47.)
NOTE
For all models EXCEPT 40fx, 80ex, 125ex, and 220mx.
Table B-10
Micro-Move Error Codes
Error Code
(hex.)
Failure Description
00
No error
01
Vertical over voltage exceeded limit set by firmware
02
Vertical over force exceeded limit set by firmware
03
Vertical servo error
04
Vertical timeout
05
Vertical open path
06
Vertical closed path
0A
Plunge over voltage exceeded limit set by firmware
0B
Plunge over force exceeded limit set by firmware
0C
Plunge servo error
0D
Plunge timeout
0E
Plunge open path
0F
Plunge closed path
10
Top picker expected to be active picker in plunge.
Runtime.
B-32
Appendix B
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-10
Micro-Move Error Codes
Failure Description
11
Bottom picker expected to be active picker in plunge.
Runtime.
12
Bottom thumb expected to be active in plunge home.
Powerup.
13
Top thumb expected to be active in plunge home.
Powerup.
14
Translate over voltage error.
15
Translate over force error.
16
Translate servo error.
1A
Vertical open loop
1B
No load complete
1C
Translate open loop
1E
No load complete
1F
Unexpected load complete
20
Unexpected cartridge in drive
21
No cartridge in drive
22
Drive put in accept failed
23
Drive get out accept failed
24
Drive eject failed
25
Drive insert failed
26
Drive eject retry
27
Drive insert retry
28
Clear drive path
29
Drive signal (not used)
Appendix B
Autochanger Error Codes
Error Code
(hex.)
B-33
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-10
Micro-Move Error Codes
Error Code
(hex.)
Failure Description
2A
Drive not connected
32
Magazine put in saturate failed
33
Magazine get out saturate failed
34
Magazine put in accept failed
35
Magazine get out accept failed
36
Magazine measure failed
37
Test magazine failed
38
Return magazine failed
39
Clear magazine path
3C
Mailslot put in saturate failed
3D
Mailslot get out saturate failed
3E
Mailslot put in accept failed
3F
Mailslot get out accept failed
40
Measurement of mailslot depth failed
41
Recovery did not clear vertical path.
42
Rotate mailslot in failed
43
Rotate mailslot out failed
46
Flipped too far
47
Did not flip far enough
48
Flip side incorrect
50
Failed to finish a translate
51
Extra force needed to translate
B-34
Appendix B
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-10
Micro-Move Error Codes
Failure Description
5A
Command received to rotate mailslot but both pickers
are full
5B
Back sensor in mailslot is bad
5C
Front sensor in mailslot is bad
5D
Command received to eject from the mailslot, but both
pickers are full
5E
Attempt to load from an empty mailslot
5F
Engaging the mailslot failed on a rotate in
60
Disengaging the mailslot failed on a rotate in
61
Rotate in catch error (not used)
62
Rotate in push out error (not used)
63
Rotate in armed failed (not used)
64
Did not detect hard stop on a rotate in
65
Rotate in was too much distance
66
Engaging the mailslot failed on a rotate out
67
Disengaging the mailslot failed on a rotate out
68
Did not detect hard stop on a rotate out
69
Rotate out distance was too short
6A
Could not move thumbs out of the vertical path after a
rotate out
6B
Vertical distance difference detected after error
recovery
6C
Cartridge in mailslot incorrectly at rotate in
6D
Mailslot rotate in accept fail
Appendix B
Autochanger Error Codes
Error Code
(hex.)
B-35
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-10
Table B-11
Micro-Move Error Codes
Error Code
(hex.)
Failure Description
6E
Test failed
Micro-Move Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Error Code
(hex.)
Description
0
No error
1
Carriage motor drive voltage exceeded limit set by
firmware.
2
Carriage motor overcurrent detected by hardware.
3
Carriage motor force exceeded limit set by firmware.
4
Picker motor drive voltage exceeded limit set by
firmware.
5
Picker motor overcurrent detected by hardware.
6
Picker motor force exceeded limit set by firmware.
7
Low power supply during motion.
8
High power supply during motion.
9
Move stopped because cartridge-in-path beam blocked.
A
Cartridge not detected by cartridge-in-path beam.
B
Carriage motor not tracking properly.
C
Picker motor not tracking properly.
D
Carriage motor measured voltage less than expected.
E
Picker motor measured voltage less than expected.
10
Find origin failed.
11
Calibrate failed.
B-36
Appendix B
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-11
Micro-Move Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Description
12
Diagnose FRU failed.
13
Initial recovery failed.
14
Find home failed.
15
Picker initialization failed.
16
Cartridge-in-path beams are blocked.
20
Failed to find hard stop at end of flip.
22
Failed to see sensor close at the end of translate.
23
Failed to move to the vertical position needed to
engage the translate pin.
24
Failed to see sensor close at the start of translate.
25
Failed to see height sensor re-open after closing at the
start of a translate.
28
The translate distance was too long.
29
The translate distance was too short.
31
Failed while checking for cartridge in a drive.
32
Failed to find a hard stop returning cartridge to
storage after testing for presence of cartridge.
33
Failed while checking for cartridge in a storage slot.
34
Failed while checking for cartridge in the Picker.
35
Failed while checking for cartridge in the mailslot.
36
Could not free fingers after testing for a cartridge in a
drive.
38
Failed to verify that cartridge exists after insert.
Appendix B
B-37
Autochanger Error Codes
Error Code
(hex.)
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-11
Micro-Move Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Error Code
(hex.)
Description
40
Failed finding the back of storage slot during
retraction.
41
Failed to verify that a disk is in the storage slot on get
using cartridge-in-path beams.
42
Not able to measure the depth of the storage slot.
43
Failed to free fingers from the storage slot.
48
Could not find the back of the storage slot after insert.
49
Failed to verify that a cartridge exists in the storage
slot after insert.
4A
Could not free fingers from storage slot after insert.
50
Could not find the back of the mailslot after get.
51
Failed to verify that a disk is in the mailslot on get
using cartridge-in-path beams.
52
Not able to measure the depth of the mailslot.
58
Could not find the back of the mailslot after insert.
59
Failed to verify that a cartridge exists in the mailslot
after insert.
60
Failed to rotate the mailslot in.
61
Failed to rotate the mailslot out.
70
Exhausted retries while attempting to get the drive to
eject the cartridge.
71
Could not verify that the drive ejected the cartridge.
72
Could not free fingers from the drive.
73
No cartridge in drive.
B-38
Appendix B
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-11
Micro-Move Error Codes (For the 40fx, 80ex, 125ex, and 220mx
models ONLY)
Description
74
No load complete.
75
Drive error signal.
76
Unexpected cartridge in the drive.
77
Unexpected load complete.
78
Exhausted retries attempting to get drive to accept the
cartridge.
79
Could not verify that the drive accepted the cartridge.
7E
Inline recovery attempts exhausted.
Errors above here are counted in the runtime log as in-line.
Errors below here are counted in the runtime log as retries.
90
Drive access was disallowed because drive busy signal
was active.
91
Drive light stuck off.
94
Outside mailslot sensor failed.
95
Inside mailslot sensor failed.
96
Mailslot rotation failure; possibly caused by operator.
FA
Test drive insert retry.
FB
Timed out waiting for drive to eject when testing for
the presence of a cartridge; retry being attempted.
FC
Retry being attempted on drive insert.
FD
Retry being attempted on drive eject.
FE
Mechanism error.
Appendix B
B-39
Autochanger Error Codes
Error Code
(hex.)
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Diagnostic Tests
The following tables describe the optical disk library diagnostic tests for
all models, EXCEPT for 40fx, 80ex, 125ex, and 220mx jukeboxes. See
Table B-13 on page B-44 for diagnostic tests for the 40fx, 80ex, 125ex,
and 220mx models.
CAUTION
Some diagnostic tests can result in a disk being placed into an improper
storage slot. If this happens, the optical disk library file system is no
longer accurate.
NOTE
Not all tests listed in Table 5-12 on page 5-39 are supported on all HP
jukebox models.
Table B-12
Diagnostic Tests (EXCEPT for models 40fx, 80ex, 125ex, and
220mx)
No.
Front Panel
Test Name
Description
1
POWER UP
TEST
Checks out the general capability of jukebox
by running INIT MECHANICS test.
2
WELLNESS
TEST
Checks out the general capability of the
jukebox by running the INIT MECHANICS and
EXERCISE MECH tests. Requires one loaded
cartridge; drive and mailslot must be empty.
5
INIT
MECHANICS
Runs the FIND PLUNGE HOME, FIND VERTICAL
HOME, FIND XLATE HOME, and the INIT ELEM
STATUS tests, and rotates the mailslot out.
10
INIT ELEM
STATUS
Functions the same as the SCSI Initialize
Element Status command. This test
physically scans the entire unit to determine
which storage slots contain disks and if the
drives contain disks.
11
EXERCISE
MECH
Runs VERTICAL TEST, TRANSLATE TEST, FLIP
TEST, MAGAZINE IO, DRIVE IO, and MAILSLOT
IO tests.
B-40
Appendix B
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-12
Diagnostic Tests (EXCEPT for models 40fx, 80ex, 125ex, and
220mx)
Front Panel
Test Name
Description
12
VERTICAL
TEST
Moves the disk transport mechanism up and
down the full length of the rail. Returns
PASS/FAIL. No cartridges required.
13
TRANSLATE
SENSOR
Reports ON or OFF. Looks at translate
sensor.
14
FLIP TEST
Makes a combination of moves with a PASS/
FAIL result. It does several flips at various
locations. No optical disks are required.
15
MAGAZINE IO
Makes a combination of moves with a PASS/
FAIL result. It moves an optical disk from a
randomly-chosen full to a randomly-chosen
empty slot, with a random flip. It then moves
the disk back to its original storage slot with
its original orientation. This test displays
"FAIL" if there are no disks in the jukebox or
if all storage slots are full. The drives and
mailslot must be empty.
16
DRIVE IO
Makes a combination of moves with a PASS/
FAIL result. It moves an optical disk from a
randomly-chosen full slot to a randomlychosen drive, with a random flip. It then
moves the cartridge back to its original slot
with its original orientation. This test
displays if there are no disks in the jukebox
or if all storage slots are full. The drives and
mailslot must be empty.
Appendix B
B-41
Autochanger Error Codes
No.
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-12
Diagnostic Tests (EXCEPT for models 40fx, 80ex, 125ex, and
220mx)
No.
Front Panel
Test Name
Description
17
MAILSLOT IO
Makes a combination of moves with a PASS/
FAIL result. It moves an optical disk from the
lowest-numbered full slot to the mailslot with
a random flip. It then moves the cartridge
back to its original slot with its original
orientation. This test displays if there are no
disks in the jukebox or if all storage slots are
full. The drives and mailslot must be empty.
18
EMPTY DRIVES
Moves cartridges out of the drive
mechanism(s) and returns them to their
storage slots.
20
PLUNGE FULL
SPD
Allows the disk transport mechanics to be
run at full speed. This configuration should
always be used when the jukebox is being
used.
21
PLUNGE 1/2
SPD
Allows the disk transport mechanics to be
run at half speed. Use this configuration for
diagnostic purposes only.
22
PLUNGE 1/4
SPD
Allows the mechanics to be run at quarter
speed. Use this configuration for diagnostic
purposes only.
24
FILL PICKER
Moves an optical disk into the disk transport
mechanism from the first storage slot
containing a disk.
25
EMPTY
PICKER
Moves an optical disk from the disk transport
mechanism to its home storage slot location if
that location is known, otherwise the disk is
placed into the first available empty storage
slot.
26
CLEAR SOFT
LOG
The runtime log (soft error log) is initialized
to all zeros.
B-42
Appendix B
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-12
Diagnostic Tests (EXCEPT for models 40fx, 80ex, 125ex, and
220mx)
Front Panel
Test Name
Description
29
CLEAR HARD
LOG
Sets Information log 0, Autochanger Error
Log, back to zero.
30
VERTICAL
ENCODER
Moves the disk transport mechanism up and
down the full length of the rail. Returns
PASS/FAIL. No cartridges are required.
101
FIND PLUNGE
HOME
Runs mechanism recalibration, establishes
which picker side is up, and determines the
reference points in the picker travel path.
This test assumes that the mechanics and
servo system are functional.
102
FIND
VERTICAL
HOME
Recalibrates the vertical position and verifies
that the vertical path is clear.
103
FIND XLATE
HOME
Calibrates the translate position.
104
PICKER TEST
Flips the disk transport mechanism and
switches active thumbs.
Appendix B
B-43
Autochanger Error Codes
No.
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-13
Sequence Tests (For models 40fx, 80ex, 125ex, and 220mx ONLY)
No.
Test Name
Description
1
Poweron
Checks all digital data paths and normal
machine operation. This sequence runs tests
that are identical to those run when the optical
disk library operation button is switched on.
When the test is requested via SCSI, the tests
which cannot be executed over SCSI will be
skipped.
Sequence Order:
• 3: Controller Test
• 41: Power Supply Test
• Motor Connection Test
• 5: Initialize Mechanism
2
Wellness Test
Checks out the general capability of the
Autochanger. Requires one loaded cartridge;
drives and mailslot empty.
Sequence Order:
• 1: Poweron Test
• 11: Mechanical Exerciser Test
B-44
Appendix B
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-13
Sequence Tests (For models 40fx, 80ex, 125ex, and 220mx ONLY)
No.
Test Name
Description
3
Controller Test
This sequence is run by the Autochanger
controller when the optical disk library
operation switch is switched on to check out all
paths, and operation of the servo motor and
autochanger circuitry.
Sequence Order:
• 30: Processor Test
• 31: ROM Checksum Test
• 33: Non-Destructive RAM Test
Autochanger Error Codes
• 32: RAM Checksum Test
• 34: SCSI Interface Controller IC Test
• 36: Motor Control IC Test
• 35: Multi-Function Peripheral IC Test
• 37: Drive Connect Test
5
Initialize Mechanism
Prepares the unit for movement.
Sequence Order:
• Initialize RAM variables to defaults
• 50: Find Home
Exerciser Tests
10
Initialize Element
Status
Appendix B
Performs the same function as the SCSI
INITIALIZE ELEMENT STATUS command. It
physically scans the entire unit to determine
which storage slots and drives contain disks.
B-45
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-13
Sequence Tests (For models 40fx, 80ex, 125ex, and 220mx ONLY)
No.
Test Name
Description
11
Mechanism Exercise
Test
Performs a combination of moves with a pass/fail
result. This exerciser is actually a sequence of
other exerciser tests — 12, 13, 14, 15, 16, and 17.
This exerciser returns an error code #57H
Invalid Configuration if there are no cartridges
loaded into the unit, or if any drive is full.
Requires one loaded cartridge, drives and
mailslot empty.
12
Carriage Move Test
Performs a combination of carriage moves with a
pass/fail result. It moves the carriage assembly
to the maximum distance away from the sensor
on both sides. No cartridges are required.
13
Translate Test (Not
valid for the Model
10LC)
Performs a combination of moves with a pass/fail
result. It performs several translations from
various starting positions. No cartridges are
required.
14
Flip Test
Performs a combination of moves with a pass/fail
result. It performs several flips at various
locations. No cartridges are required.
15
Storage Slot Test
Performs a combination of moves with a pass/fail
result. It moves a cartridge from a randomlychosen full slot to a randomly-chosen empty slot,
with a random flip. It then moves the cartridge
back to its original storage slot with its original
orientation. This exerciser returns an error code
#57H Invalid Configuration if there are no
cartridges loaded into the unit, or if any drive is
full. Requires one loaded cartridge.
B-46
Appendix B
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-13
Sequence Tests (For models 40fx, 80ex, 125ex, and 220mx ONLY)
Test Name
Description
16
Drive I/O Test
Performs a combination of moves with a pass/fail
result. It moves a cartridge from a randomlychosen full slot to a drive, with a random flip. It
then moves the cartridge back to its original slot
with its original orientation. It does this once for
each optical drive. Returns an error code #57H
Invalid Configuration if there are no cartridges
loaded into the unit. Requires one loaded
cartridge; drives must be empty.
17
Mailslot I/O
Performs a combination of moves with a pass/fail
result. It moves a cartridge from the lowestnumbered full slot to the mailslot with a random
flip. It then moves the cartridge back to its
original slot with its original orientation.
Returns an error code #57H Invalid
Configuration if there are no cartridges loaded
into the unit. Requires one loaded cartridge;
mailslot must be empty.
18
Speed Factor Setting
Utility
Allows the setting of the speed factor as the first
parameter given. The speed factor determines
how fast the system moves the mechanics. The
number provides 1/Parameter speed (e.g.
Parameter=3 runs the motors at 1/3 of full
speed). This test can only be run from the SCSI
Interface.
19
Zero Maximum Force
Log
The maximum force log is initialized to all zeros.
20
Set Speed Factor to
Full Speed
Allows the mechanics to be run at full speed.
21
Set Speed Factor to
Half Speed
Allows the mechanics to be run at half speed.
22
Set Speed Factor to
Quarter Speed
Allows the mechanics to be run at quarter speed.
Appendix B
B-47
Autochanger Error Codes
No.
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-13
Sequence Tests (For models 40fx, 80ex, 125ex, and 220mx ONLY)
No.
Test Name
Description
23
Shipping
Moves the picker to the appropriate position in
preparation for shipping.
24
Fill Picker
Moves a cartridge into the picker from the first
full storage slot.
25
Empty Picker
Moves a cartridge from the picker to the first
empty storage slot.
26
Zero Runtime Log
The entire runtime log is initialized to all zeros.
27
Set Minimum Retries
This sets the number of retries to 1. This may be
set to see if the chosen test is doing what you
want it to do. After you are satisfied that the test
is what you want, run Test 28 which resets the
number of retries to default values.
28
Set to Default Number
of Retries
Resets the number of retries to powerup default
values. Used after setting retries to 1 by Test 27.
29
Zero Error Log
Sets Information Log 0, Autochanger Error Log
back to zero.
Electronic Core Tests
30
Microprocessor
Operation Test
Performs a functional check of the
microprocessor. This test will shut down the
servo system; a poweron sequence runs upon
completion.
31
ROM Checksum Test
Performs a checksum verification of the ROM.
32
RAM Checksum Test
A checksum of the "Controlled" area of RAM is
kept on an ongoing basis. This test verifies that
the checksum is still valid.
33
Non-Destructive RAM
Test
Tests all of the controller's RAM, checking for
data acceptance and retention. The test is nondestructive to RAM unless interrupted by power
failure. This test will shut down the servo
system; a poweron sequence runs upon
completion.
B-48
Appendix B
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-13
Sequence Tests (For models 40fx, 80ex, 125ex, and 220mx ONLY)
Test Name
Description
34
SCSI Interface
Controller Chip Test
Checks out operations of the SCSI interface
controller chip. This test will not be run if
initiated via SCSI, it reports PASS.
36
Motor Control Chip
Test
Exercises the registers of the motor control IC.
In order to perform correctly, this test shuts
down the servo system.
37
Drive Connect Test
Checks for expected drive configuration. This is
done by polling the drive connect signal on each
of the possible drives. This line is grounded at
the drive end if a drive is connected. If the drives
physically connected do not match the expected
configuration then an error is reported.
38
Control Panel Light
Show &Button Test
Lights each portion of the display individually
and then together. Requires pushing each front
panel button to finish the test.
40
Power Supply Test
Looks at both the 12-Volt and the 24-Volt power
supplies to verify that they are within limits.
The limits for the 12V supply are 11V and 13V
and the 24V supply limits are 23.5V and 25.5V.
41
SCSI Connector
Loopback Test
Performs a loopback through SCSI connectors,
checking proper operation of the SCSI drivers,
receivers, and cables. Requires an external
loopback hood with terminator power. Will not
run if it was initiated via SCSI; if so, it reports
error FCH Test Did Not Run.
(Interactive)
42
Optical Sensor Test
(Interactive if done
through the control
panel)
Appendix B
Checks the status of the optical sensors. Also
checks the status of the mailslot sensor (see Test
43). "0"s are placed on the control panel display
on the left and right of the display. The mark is
an open zero if the sensor is not blocked, and a
zero filled in with lit segments if a sensor is
blocked. No FRU is returned.
B-49
Autochanger Error Codes
No.
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-13
Sequence Tests (For models 40fx, 80ex, 125ex, and 220mx ONLY)
No.
43
Test Name
Description
Mailslot Sensor Test
See the description for Test 42.
(Interactive if done
through the control
panel)
44
Cartridge-in-path
(Interactive if done
through the control
panel)
Displays max/min intensity and ambient
readings for the left and right beams. You must
enter a parameter to choose the beam to display
(0=left, 1=right). The following is an example of
an error message for the right beam and how it
is translated:
F0 is hexadecimal for 240
E1 is hexadecimal for 225
R means right beam
06 is the maximum ambient reading.
00 is the minimum ambient reading.
Intensity
Max
Min
240
225
L/R
R
Ambient
Max
Min
6
0
Press CANCEL to stop.
50
Find Home Sequence
50Find Home SequenceMoves the picker to a
known "home" position. This test assumes
nothing about the state of the mechanics. The
"home" location is the lower left position of the
box. The servo system is initialized to the "home"
location. It then automatically runs Test 51.
51
Carriage/Picker
Assembly Calibration
Test
Runs the portion of the mechanism recalibration
related to the optical sensors. It measures sensor
offsets and calculates picker tilt and droop. This
test assumes that the mechanics and servo
system are functional.
B-50
Appendix B
Autochanger Error Codes
Jukebox Micro-Move Error Codes
Table B-13
Sequence Tests (For models 40fx, 80ex, 125ex, and 220mx ONLY)
Test Name
Description
60
FRU Isolation Test
Assumes that something has physically failed,
either electronic or mechanical. A series of
special low-level tests are executed to select the
three (or fewer) FRUs which are most likely to
be at fault. Tests 30, 31, 33, 35, 36, 40, and 50
are executed as a part of the isolation process.
65
Calibrate Magazines
Calculates a min/max clearance for a magazine.
(The selected magazine should be empty.) The
autochanger requires a disk in the mailslot. The
test passes if clearance is 85 encoder counts (1
mm) up and down. (See Info 23 for actual
values.)
If this test is run by SCSI command, set Byte 1
to the magazine number.
The test returns: PASS or FAIL.
66
Clear Magazine Min/
Max
Clears the value calculated in Test 65.
67
Calibrate Mailslot
Calculates a min/max clearance for the mailslot.
The autochanger requires a disk in the mailslot.
The test passes if clearance is 85 encoder counts
(1 mm) up and down. (See Info 23 for actual
values.)
The test returns: PASS or FAIL.
68
Clear Mailslot Max/
Min
Clears the value calculated in Test 67.
75
UPS Test
Tests whether or not the UPS is connected
properly.
The test returns PASS if connected properly,
FAIL if the UPS is not connected properly or if
there is no UPS connected.
Appendix B
B-51
Autochanger Error Codes
No.
Autochanger Error Codes
Jukebox Micro-Move Error Codes
B-52
Appendix B
Field Replaceable Units
C
Field Replaceable Units (FRUs)
Appendix C
C-1
Field Replaceable Units (FRUs)
HP Field Replaceable Units (FRUs)
HP Field Replaceable Units (FRUs)
Table C-1
Jukebox FRUs (For all models, EXCEPT 40fx, 80ex, 125ex, and
220mx)
FRU #
C-2
Description
1
Controller PCA
2
MO Drive
4
Interconnect PCA
5
Lower Interconnect Board
6
Stars Wars Board
8
SCSI LUN/Repeater PCA (Bus 1)
18
SCSI LUN/Repeater PCA (Bus 2)
19
Configuration Module
22
Display Panel
23
Vertical Motor Gearbox Assembly
24
Vertical Motion Motor
26
Magazine (8 slots)
27
Picker Assembly
29
Mailslot Assembly
30
Vertical Encoder Strip & Sensor
31
Magazines (6 slots)
32
AC/12V Power
33
AC/24V Power
34
Vertical Rope/Pulley System
40
Translate Frame
Appendix C
Field Replaceable Units (FRUs)
HP Field Replaceable Units (FRUs)
Table C-1
Jukebox FRUs (For all models, EXCEPT 40fx, 80ex, 125ex, and
220mx)
FRU #
Description
Vertical Umbilical Cable
43
Translate Umbilical Cable
51
5/12 Power Cable
54
Drive Power Cable
57
Vertical Path-Clear Sensor Cable
59
Internal SCSI Cable
62
MO Drive Power Cable
65
Control Panel Cable
66
Interposer Cable
86
AC Power PCA
220
Media
200
Clear path blockage (no FRU)
201
Cartridge moved
Appendix C
FRUS
Field Replaceable
Units
41
C-3
Field Replaceable Units (FRUs)
HP Field Replaceable Units (FRUs)
Table C-2
Jukebox FRUs (For the 40fx, 80ex, 125ex and 220mx models
ONLY)
FRU #
C-4
Description
1
Autochanger Controller PCA
4
Interconnect PCA
20
MO/MF Drive (single-ended)
21
Left Way
22
Display/Front Panel PCA
23
Carriage Motor
24
Front Panel
25
Picker Motor
26
Magazine
27
Picker
28
Power Supply Module
29
Mailslot Assembly
31
Optical Sensor Assembly
32
Carriage Lead Screw
34
Picker Motor Belt(s)
35
Carriage Motor Belt
36
MO/MF Drive Control ROMa
37
Autochanger Controller ROMSa
38
Fan Assembly
39
Spring Bearing Block Assembly
40
Carriage Assembly
Appendix C
Field Replaceable Units (FRUs)
HP Field Replaceable Units (FRUs)
Table C-2
Jukebox FRUs (For the 40fx, 80ex, 125ex and 220mx models
ONLY)
FRU #
Description
MO Drive/Controller Power Cable
52
5/12V Module Power Cable
55
SCSI Cable (internal)
56
Front Panel Address Cable
57
Motor Power/Encoder Cable
58
Motor Cable
59
Interconnect Cable
65
AC/24V Power Cable
66
Line Switch Cable
67
24V Power Cable
71
Mailslot Connector Cable
75
Interface Cable
FRUS
Field Replaceable
Units
51
a. Code is downloadable into flash ROMs
Appendix C
C-5
Field Replaceable Units (FRUs)
HP Field Replaceable Units (FRUs)
C-6
Appendix C
Micro/Macro-Moves
D
Micro/Macro-Moves
Appendix D
D-1
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
Description
0
Vertical idle.
1
Move picker transport up. Fast.
2
Move picker transport down. Fast.
3
Move picker transport up slowly, looking for resistance.
Used in vertical find home sequence.
4
Move picker transport down slowly, looking for resistance.
Used in vertical find home sequence.
5
Move a small amount upward, to relieve tension in the
servos. Used after finding "home" in the vertical find
home sequence.
6
Make a small vertical movement as a plunge is made into
a drive. Used to "wiggle" the picker during error recovery.
7
Vertical coarse measure (not used).
8
Move picker transport up to the top of the jukebox,
checking for a clear path. Used in the vertical find home
sequence.
9
Move picker transport to the bottom of the jukebox,
checking for a clear path. Used in the vertical find home
sequence.
A
Vertical fine measure (not used).
B
Vertical engage mailslot 1 (not used).
C
Vertical engage mailslot 2 (not used).
D
Vertical get mail duck (not used).
D-2
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
Description
Vertical put mail duck (not used).
F
Vertical saturate home (not used).
10
Vertical relax home (not used).
11
Move slowly up far enough to establish that there is
enough room to flip the picker. Used in the plunge find
home sequence.
12
Move slowly down far enough to establish that there is
enough room to flip the picker. Used in the plunge find
home sequence.
13
Move slowly to the flip clear area (determined in micromoves 11 and 12). Used in the plunge find home
sequence. Also used in power fail recovery to move the
picker off of a cartridge that may have been between the
picker and the magazines when the power failed and the
picker settled.
14
Move slowly downward to the flip clear area (determined
in micro-moves 11 and 12). Used in the plunge find home
sequence.
15
Move vertically to restore the picker to the position it had
before an error (and error recovery) occurred. Only called
in error recovery.
16
Move up. Used in the motor test during powerup.
17
Move down. Used in the motor test during powerup.
18
Move fast vertically to initial element 1.
19
Move fast vertically to initial element 2.
1A
Move fast vertically to initial element 3.
1B
Move fast vertically to initial element 4.
Appendix D
D-3
Micro/Macro-Moves
E
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
D-4
Description
32
Translate idle.
33
Translate and saturate right.
34
Translate and saturate left.
35
Translate right.
36
Translate left.
37
Translate relax.
38
Translate calibrate.
62
Move slowly to one side of the translate frame. Used to
find translate home during powerup. Movements after
powerup use the translate home ID, 63.
63
Move to one side of the translate frame. Used to find
translate home.
64
Plunge idle (not used).
65
Plunge move (not used).
66
Plunge saturate (not used).
67
Move a short distance back from the plunge position
where an overforce shutdown error occurred. Relaxes the
tension.
68
Retract the plunge assembly on the picker all the way
back to find "home" in the plunge axis. May start a flip,
depending on starting position. (One of three plunge find
homes in the sequence; 68, 69, 6A.)
69
Retract the plunge assembly on the picker all the way
back and flip the picker at the same time. Used to find
"home" in the plunge axis. (One of three plunge find
homes in the sequence; 68, 69, 6A.)
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
Description
Retract the plunge assembly on the picker all the way
back and then flip the picker. Used to find "home" in the
plunge axis. Second flip of the sequence. (One of three
plunge find homes in the sequence; 68, 69, 6A.)
6B
Plunge toward magazine to get cartridge.
6C
First time plunge into magazine (first "get"). Feels for
resistance to learn the distance to the cartridge when it is
seated.
6D
Retraction to pull the cartridge out of the magazine.
6E
Plunge get magazine out 2 (not used).
6F
First part of a two-step move to put a cartridge into a
magazine. Puts the cartridge nearly all the way in. Next
part of move is micro-move 70.
70
Second part of a two-step move to put a cartridge into a
magazine. Continues movement of micro-move 6F and
puts the cartridge in the rest of the way (the distance
learned in micro-move 6C).
71
First time plunge into a magazine (first "put"). Feels for
resistance to learn the distance to the cartridge when it is
seated.
72
Retract picker plunge assembly after putting cartridge
into a magazine. Assembly is retracted just far enough
that the thumbs are clear of the picker vertical path.
73
Plunge put magazine out 2 (not used).
74
Plunge put magazine out 3 (not used).
75
First part of a two-step plunge move to put a cartridge
into a drive. Cartridge is inserted to a point where the
drive shutter arms start to engage.
Appendix D
D-5
Micro/Macro-Moves
6A
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
D-6
Description
76
First time "put" plunge into a drive. Slow. Feels for
resistance to learn the distance to the cartridge when it is
seated.
77
First time "get" plunge into a drive. Slow. Feels for
resistance to learn the distance to the cartridge when it is
seated.
78
Fast "put" plunge into a drive (distance has been
previously learned).
79
Retract picker plunge assembly after putting cartridge
into drive. Assembly is retracted just far enough to that
the thumbs are clear of the picker vertical path.
7A
Plunge put drive out 2 (not used).
7B
Plunge put drive out 3 (not used).
7C
(Used in an emergency cartridge eject). Plunge toward a
drive, stopping at a position close to the drive. This the
wait position until the drive ejects the cartridge.
7D
(Used in an emergency cartridge eject). Plunge to contact
and get the cartridge from the drive. Follows micro-move
7C.
7E
Log ID (no motion). Logs that picker is in position in front
of drive, waiting for the drive to eject the cartridge.
7F
Plunge forward to get cartridge from the drive. Thumbs
wrap over the ears on the cartridge.
80
Retract a small amount o take up the slack between the
picker thumbs and the cartridge ears.
81
Retract plunge assembly fully back into the picker.
82
Plunge get drive out 3 (not used).
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
Description
Flip during plunge when cartridge is in the top picker.
84
Flip during plunge when cartridge is in the bottom picker.
85
Plunge finish flip (not used).
86
Plunge test picker saturate with media (not used).
87
Short plunge out to test for a cartridge in the picker. If a
cartridge is in the picker, the path clear beam will be
interrupted. Used in an ISTAT.
88
Short plunge out to test for a cartridge in a magazine
when the picker contains a cartridge. If resistance is felt,
this is interpreted as a cartridge in the magazine. Used in
an ISTAT.
89
Retract picker plunge assembly into the picker after
executing micro-move 88. Used in an ISTAT.
8A
Short plunge to test for a cartridge in a drive when the
picker contains a cartridge. If resistance is felt, this is
interpreted as a cartridge in the drive. Used in an ISTAT.
8B
Plunge out. Used in error recovery. Is an attempt to push
a cartridge out of the vertical picker path and into a
magazine.
8C
Retract thumbs back into the picker. Used in error
recovery. Is an attempt to pull a cartridge out of the
vertical picker path and into the picker. Either this micromove or micro-move 8D is used, depending on position of
the picker at the start of recovery.
8D
Retract thumbs back into the picker. Used in error
recovery. Is an attempt to pull a cartridge out of the
vertical picker path and into the picker. Either this micromove or micro-move 8C is used, depending the on the
position of the picker at the start of recovery.
Appendix D
D-7
Micro/Macro-Moves
83
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
D-8
Description
8E
Move picker plunge assembly out to rearm the picker
mechanism before switching active picker.
8F
Retract picker plunge assembly to a point just short of
tripping the thumb selection mechanism. First of two
steps (second step is micro-move 90).
90
Retract picker fingers all the way back. Trips the
mechanism that makes the opposite thumb "active."
91
Move picker plunge assembly forward, away from the full
retracted position. Clears the tripping mechanism and
makes the new thumb "active."
92
Plunge picker diagnostic 1 (factory use only).
93
Plunge picker diagnostic 2 (factory use only).
94
Plunge picker diagnostic 3 (factory use only).
95
Plunge picker diagnostic 4 (factory use only).
96
Plunge picker back 1 (not used).
97
Plunge picker back 2 (not used).
98
Plunge find handoff distance 1 (factory use only).
99
Plunge find handoff distance 2 (factory use only).
9A
Plunge find handoff distance 3 (factory use only).
9B
Plunge find flip distance 1 (factory use only).
9C
Plunge find flip distance 2 (factory use only).
9D
Plunge find picker length (factory use only).
9E
Plunge picker state 1 (factory use only).
9F
Plunge picker state 2 (factory use only).
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
Description
Plunge finish home (not used).
A1
Plunge finish saturate home (not used).
A2
First of two plunge movements toward the drive during
error recovery. Vertical movement is done before the
second part of this movement (micro-move A3) is done.
A3
Second of two plunge movements toward the drive during
error recovery. Done after a small vertical movement is
done to "wiggle" the picker.
A4
Plunge out. Is an attempt to clear the vertical picker path
during drive error recovery.
A5
First part of a two-step move to fully retract the picker
plunge assembly. Retract assembly almost all the way
back. Next part of move is micro-move A6.
A6
Second part of a two-step move to fully retract the picker
plunge assembly. Continues movement of micro-move A5
and brings picker plunge assembly all the way back.
A7
Move picker plunge assembly forward a small amount
from full retracted position. Completes rearm of the
picker mechanism.
A8
Move to a position where the picker thumb sensor can be
read. Used in the find plunge home recalibration.
A9
Move to a position where the current active picker can be
read. Used in the plunge home recalibration.
AA
Fully retract picker plunge assembly to switch the active
picker. One of three moves used to make the top picker
the active picker during a picker recalibration.
Appendix D
D-9
Micro/Macro-Moves
A0
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
D-10
Description
AB
Move picker plunge assembly forward a small amount to
complete the rearm of the picker mechanism. One of
three moves used to make the top picker the active picker
during a picker recalibration.
AC
Move picker plunge assembly forward to normal position
after a active picker has been change by micro-moves AA
and AB. One of three moves used to make the top picker
the active picker during a picker recalibration.
AD
Move the picker plunge assembly a small amount away
from the flip mechanism so that the mechanism is
rearmed for a flip. Used in a flip sequence.
AE
Move the picker plunge assembly out a small amount
from the full retracted position to relieve the pressure on
the mechanism after a flip.
AF
First of two moves to move the thumb to the magazine
during an ISTAT when no cartridge is in the picker. Next
move is micro-move B0.
B0
Second of two moves to move the thumb to the magazine
during an ISTAT when no cartridge is in the picker. Slow
move to check for an overforce (cartridge in the magazine
slot).
B1
Retract picker plunge assembly back into the picker to a
point where the thumbs can unsplay. Used during an
ISTAT, with no cartridge in the picker, when the thumbs
are splayed and are they must be unsplayed.
B2
Retract picker plunge assembly into the picker to a point
just short of where the thumbs would be released and
unsplay. Used during an ISTAT, with no cartridge in the
picker, when the thumbs are splayed and must be kept
splayed.
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
Description
Retract picker plunge assembly back far enough to
release the thumbs and let them go to an unsplayed
position. Used during an ISTAT, and the thumbs are
being returned to an unsplayed position after contacting,
grabbing, and replacing the first cartridge.
B4
Retract picker plunge assembly into the picker to a point
just short of where the thumbs would be released and
unsplay. Used during an ISTAT, and the thumbs are
being retained in the splayed position after contacting,
grabbing, and replacing the first cartridge.
B5
Retract picker plunge assembly far enough to get the
thumbs out of the vertical picker path. Used during an
ISTAT, no cartridge in the picker, and no cartridge was
contacted in the first magazine.
B6
Pull picker plunge assembly fully back to rearm a "put."
Enable the picker to replace the cartridge it picked up
during an ISTAT.
B7
First of two moves that put a cartridge back into the
magazine after the cartridge is detected during an ISTAT.
Moves the cartridge almost fully into the magazine.
Followed by micro-move B8.
B8
Second of two moves that put a cartridge back into the
magazine after the cartridge is detected during an ISTAT.
Moves the cartridge fully into the magazine.
B9
Second of two moves to test for the presence of a cartridge
in a magazine during an ISTAT when there is a cartridge
in the picker. Slow move to check for an overforce
(cartridge in the magazine slot). Follows micro-move BA.
Appendix D
D-11
Micro/Macro-Moves
B3
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
D-12
Description
BA
First of two moves to test for the presence of a cartridge
in a magazine during an ISTAT when there is a cartridge
in the picker. Fast plunge that places the en of the
cartridge in the picker close to the magazine. Followed by
micro-move B9.
BB
Testing for media in picker. After the physical force check.
BC
Retract picker plunge assembly after detecting a
cartridge in the drive. Used in an ISTAT when there is a
cartridge in the picker.
BD
Retract picker plunge assembly to a point just short of
where the thumbs would be released from their splayed
position. Used if thumbs are splayed after checking
magazines in an ISTAT.
BE
Retract picker plunge assembly after inserting a
cartridge into a drive.
BF
Quickly retract the picker plunge assembly if an error
occurred while inserting a cartridge into a drive.
C0
Retract picker plunge assembly to a point where the
thumbs are released and go to an unsplayed position.
Used in an ISTAT.
C1
Insert cartridge into a drive, just past the shutters.
Distance has not been learned.
C2
Insert cartridge into a drive, just past the shutters.
Distance has NOT been learned. Part one of a two-stage
move. Used in the sequence to return a cartridge into a
drive after an emergency eject during an ISTAT.
C3
Insert cartridge into a drive, just past the shutters.
Distance has been learned. Part one of a two-stage move.
Used in the sequence to return a cartridge into a drive
after an emergency eject during an ISTAT.
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
Description
Insert cartridge fully into a drive. Distance has been
learned. Part two of a two-stage move. Used in the
sequence to return a cartridge into a drive after an
emergency eject during an ISTAT.
C5
Insert cartridge fully into a drive. Distance has been
learned. Additional push in case the drive acknowledge
signal was not seen. Used in the sequence to return a
cartridge into a drive after an emergency eject during an
ISTAT.
C6
Insert cartridge fully into a drive. Distance has been
learned. Part two of a two-stage move. Used in the
sequence to return a cartridge into a drive after an
emergency eject during an ISTAT.
C7
Retract picker to rearm position to splay the fingers. Used
when an error in the drive acknowledge signal is seen and
a drive eject will be done and the thumbs must be in the
splayed position.
C8
Plunge thumbs out close to the end of the picker to get
ready to "get" a cartridge. Done at the same time as
vertical moves and in-transit translates and flips.
C9
Same as micro-move C8 but is a retry (if needed).
CA
Plunge rotate mailslot 1 saturate (not used).
CB
Retract picker plunge assembly back far enough to clear
the thumbs from the vertical picker path. Used after a
cartridge is put in the mailslot.
CC
Plunge out to clear the mailslot path. Distance has not
been learned. Used in error recovery.
CD
Short plunge out to fully seat a cartridge in the mailslot
and to measure the distance of a fully-inserted cartridge.
Appendix D
Micro/Macro-Moves
C4
D-13
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
D-14
Description
CE
Plunge out to clear the mailslot path. Used in error
recovery.
CF
Retract picker plunge assembly in an attempt to clear the
mailslot path. Used in error recovery.
D0
Short plunge to push the cartridge to a fully seated
position during a "get" to the mailslot. Distance is
learned.
D1
Short plunge during a mailslot "put." Ducks under the
mailslot rotation mechanism and positions the picker so
it can move up all the way to mailslot insertion position.
D2
Short plunge to put the cartridge all the way into the
mailslot.
D3
Short plunge during a mailslot "get". Ducks under the
mailslot rotation mechanism and positions the picker so
it can move up all the way to the mailslot "get" position.
D4
Plunge to get the cartridge from the mailslot.
D5
Retract cartridge most of the way into the picker.
Positions the picker so that it can duck under the mailslot
rotation mechanism during a "get."
D6
Continue retraction in micro-move D5. Pull cartridge all
the way back into the picker.
D7
Retract thumbs to a point just inside the picker. Used to
clear the vertical picker path during error recovery.
D8
Plunge to a position where the mailslot rotation actuator
can by pulled in.
D9
Plunge to a position where the mailslot rotation actuator
can by pushed out.
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
Description
DA
Move picker plunge assembly to a position where the
mailslot rotation actuator can be engaged to rotate the
mailslot out. Used when the state of the mailslot is
unknown and must be placed in a known state.
DB
Retract the picker plunge assembly a short distance to
clear the thumbs away from the mailslot after rotating
the mailslot out.
The following move IDs are only for 80fx, 160fx, 200fx, 160ex,
320ex, 400ex, 300mx, 600mx, and 700mx model jukeboxes.
Slow retract of the picker plunge assembly, pulling the
mailslot in. Checks that the cartridge is in properly. First
move of a rotate in.
DD
Retract thumbs back into the picker after rotating the
mailslot out.
DE
Plunge rotate mailslot 3 (not used).
DF
Plunge rotate mailslot 4 (not used).
E0
Plunge rotate mailslot 5 (not used).
E1
First of two moves rotating the mailslot in. Quickly
retract the picker plunge assembly, pulling the mailslot
most of the way in. Followed by micro-move E3.
E2
Plunge out to rotate the mailslot almost all the way out.
E3
Short retraction of the picker plunge assembly until
pressure is felt. Used at end of rotating the mailslot in
and ensures that the mailslot has been rotated fully in.
E4
Short plunge out to relieve the pressure after rotating the
mailslot in.
E5
Short plunge out, feeling for pressure, to ensure that the
mailslot is rotated all the way out.
Appendix D
D-15
Micro/Macro-Moves
DC
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-1
HP Surestore Optical Micro-Move ID Table
(For all models, EXCEPT 40fx, 80ex, 125ex and 220mx)
Move ID
(hex.)
E6
Description
Retract picker plunge assembly a short distance to relieve
the pressure after micro-move E5.
The following move IDs are only for 330fx, 600fx, 660ex,
1200ex, 1200mx and 2200mx model jukeboxes.
DC
Mailslot finished move in.
DD
Mailslot finished move out.
DE
Mailslot pulled cartridge flush with front panel to check
media present/media inserted correctly.
DF
Mailslot starting a move in.
E0
Mailslot starting a move out.
E1
Mailslot in the middle of a move in or move out.
E2
Mailslot approaching the end of a move in or move out.
E3
Mailslot unexpected stop.
E4
Mailslot start initialization after an error or at startup.
E5
Mailslot initialization successful.
E6
Mailslot end move with error; move not complete.
The following move IDs are for all model jukeboxes.
D-16
E7
On powerup, testing for motion in one direction on the
plunge motor.
E8
On powerup, testing for motion in the plunge motor.
Opposite direction than in micro-move E7.
E9
Plunge out to clear the picker vertical path. Used when
path is blocked during powerup.
EA
Picker plunge assembly retraction to clear the picker
vertical path. Used when path is blocked during powerup.
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-2
HP Surestore Optical Micro-Move ID Table
(For models 40fx, 80ex, 125ex and 220mx ONLY)
Move ID
(hex.)
Description
No motion; no commands pending
1
Carriage motion; full speed (away from drives)
2
Carriage motion; full speed (toward drives)
3
Carriage motion; move fingers forward during full speed
(away from drives)
4
Carriage motion; move fingers forward during full speed
(toward drives)
5
Full speed finger motion
7
Pull fingers back to depress flip button
8
Flip
9
Verify flip complete
A
Push fingers out to release flip button
B
Translate picker from non-leadscrew to leadscrew side
C
Translate picker from leadscrew to non-leadscrew side
D
Verify picker translated from non-leadscrew to leadscrew
side
E
Verify picker translated from leadscrew to non-leadscrew
side
F
Release forces after translating picker from nonleadscrew to leadscrew side
10
Release forces after translating picker from leadscrew to
non-leadscrew side
11
Move fingers toward storage slot with intent to grab
cartridge
Appendix D
D-17
Micro/Macro-Moves
0
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-2
HP Surestore Optical Micro-Move ID Table
(For models 40fx, 80ex, 125ex and 220mx ONLY)
Move ID
(hex.)
D-18
Description
12
Detect cartridge in storage slot before grab, and during
Initialize Element Status
13
Take up the slack in the fingers before grabbing the
cartridge
14
Pull cartridge back from storage slot
15
Push cartridge forward into storage slot
16
Detect cartridge in storage slot after insert
17
Pull fingers back from the storage slot after releasing the
cartridge
18
Move fingers toward drive; prepare to grab cartridge
19
No motion; waiting for drive to eject the cartridge
1A
Carriage shake; to assist the cartridge ejected from the
drive to slide into the picker
1B
Move fingers toward drive; with intent to grab cartridge
1C
Pull cartridge back from drive
1D
Insert cartridge into drive, until slider engages
1E
Insert cartridge into drive, after slider has engaged
1F
Push cartridge toward drive using short steps; look for
drive to accept the cartridge
20
Drive failed to accept cartridge; pull cartridge back
21
Drive accepted cartridge, release cartridge and pull
fingers back
22
Carriage motion during mailslot grab
23
Move fingers toward mailslot; with intent to grab
cartridge
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-2
HP Surestore Optical Micro-Move ID Table
(For models 40fx, 80ex, 125ex and 220mx ONLY)
Move ID
(hex.)
Description
Detect cartridge in mailslot before grab
25
Take up the slack in the fingers before grabbing the
cartridge
26
Pull cartridge back from mailslot
27
Carriage motion during mailslot insert
28
Push cartridge forward into the mailslot
29
Detect the cartridge in mailslot after insert
2A
Pull fingers back from mailslot after releasing cartridge
2B
Move leadscrew tab toward mailslot actuator arm before
pulling mailslot in
2C
Carriage motion toward actuator arm before pulling
mailslot in
2D
Move leadscrew tab to mailslot actuator arm before
pushing mailslot out
2E
Carriage motion toward actuator arm where mailslot is
engaged before pushing mailslot out
2F
Rotate the mailslot when rotational position unknown
30
Release tension on the mailslot rotate arm
31
Release tension on the mailslot rotate arm
32
Rotate the mailslot
33
Rotate the mailslot
34
Verify the rotation of the mailslot is complete
35
Rotate the mailslot when rotational position unknown
Appendix D
D-19
Micro/Macro-Moves
24
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-2
HP Surestore Optical Micro-Move ID Table
(For models 40fx, 80ex, 125ex and 220mx ONLY)
Move ID
(hex.)
D-20
Description
36
Check for a cartridge in the picker, same motion is used to
check for a cartridge in mailslot or storage slot when
picker contains a cartridge
37
Move cartridge in or out of picker during test for a
cartridge in a storage slot
38
Move fingers in or out of picker during test for a cartridge
in a storage slot
39
Move cartridge in and out of picker during test for
cartridge in the drive
3A
Check for a cartridge in the drive
3D
Move carriage to cartridge test position in front of drive
3E
Verify the presence of a cartridge by pressing cartridge
against drive face
3F
Short carriage motion to check for cartridge sticking out
of a storage slot after insertion (towards drives)
40
Short carriage motion to check for cartridge sticking out
of a storage slot after insertion (away from drives)
41
Short carriage motion to check for cartridge sticking out
of a drive after insertion (towards drives)
42
Short carriage motion to check for cartridge sticking out
of a drive after insertion (away from drives)
43
Short carriage motion to check for cartridge sticking out
of a drive during error recovery (towards, then away from
drives)
44
Translate slowly to leadscrew side in FIND HOME
sequence
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-2
HP Surestore Optical Micro-Move ID Table
(For models 40fx, 80ex, 125ex and 220mx ONLY)
Move ID
(hex.)
Description
Short translate after finding leadscrew side (toward nonleadscrew side)
46
Short carriage motion after finding leadscrew side (away
from drives)
47
Carriage motion toward drives; looking for hard stop in
FIND HOME sequence
48
Short carriage motion away from drives after hard stop
49
Carriage motion away from drives; finding room to flip in
FIND HOME sequence
4A
Fast carriage motion toward sensors to flip position
4B
Carriage motion toward drives finding room to flip in
FIND HOME sequence
4C
Fast carriage motion when flip position found in needed
direction
4D
Slow flips during FIND HOME sequence
4E
Push fingers slowly out of picker after flips in FIND
HOME sequence
4F
Check for picker belts in FRU Isolation tests, or slow
finger motions during error recovery
50
Carriage motion toward drives; looking for hard stop
before measuring carriage travel
51
Verify the maximum required carriage travel from
sensors
52
Test for presence of cartridge in picker by pushing
against hard stop
53
Long carriage motion during carriage/picker assembly
calibration (Coarse measure)
Appendix D
Micro/Macro-Moves
45
D-21
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-2
HP Surestore Optical Micro-Move ID Table
(For models 40fx, 80ex, 125ex and 220mx ONLY)
Move ID
(hex.)
D-22
Description
54
Short carriage motion during carriage/picker assembly
calibration (Fine measure)
57
Error occurred while inserting cartridge, push cartridge
farther into storage slot
59
Move fingers toward storage slot during storage slot
recovery
5A
Pull fingers back from storage slot during storage slot
recovery
5B
Carriage motion during drive recovery
5C
Carriage motion during storage slot recovery
5D
Carriage motion during drive insert recovery
5E
Slowly push fingers out then into picker during drive
recovery
5F
Drive recovery
60
Drive recovery
61
Short carriage motions during drive recovery (wiggle
motion)
62
Long carriage motion in drive recovery (toward, then
away from drives)
63
Drive recovery, restore picker home in case of unexpected
translate
64
Pull fingers back into picker during recovery.
65
Pull fingers back from storage slot during storage slot
recovery
66
Carriage motion while testing for cartridge in drive
during drive insert recovery
Appendix D
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
Table D-2
HP Surestore Optical Micro-Move ID Table
(For models 40fx, 80ex, 125ex and 220mx ONLY)
Move ID
(hex.)
Description
67
Pull back fingers from drive after releasing cartridge;
during recovery
68
Push cartridge towards drive, using short steps, look for
drive to accept the cartridge; during recovery
69
Carriage motion; during initial recovery (away from
drives)
6A
Carriage motion; during initial recovery (toward drives)
6B
Push fingers out of picker; during initial recovery
6C
Pull fingers back into picker; during initial recovery
6D
Carriage motion; during initial recovery (away from
drives)
6E
Carriage motion; during initial recovery (toward drives)
6F
Checking for carriage motor belt in FRU isolation tests
Micro/Macro-Moves
Appendix D
D-23
Micro/Macro-Moves
HP Surestore Optical Micro-Move IDs
D-24
Appendix D
Disconnect Timeouts
E
Disconnect Timeout Settings
Appendix E
E-1
Disconnect Timeout Settings
Disconnect Timeout Settings
Disconnect Timeout Settings
The following commands will cause a SCSI disconnect. It is useful to
know what the maximum times for disconnect are so driver timeouts can
be set appropriately.
NOTE
In Table E-1 the maximum disconnect time is represented by the nominal
number of seconds plus the number of levels of error recovery times 60.
You can see the maximum time can be very long. An appropriate timeout
may be a compromise between the nominal time and maximum time.
Table E-1
Timeout Settings
Command
Nominal
Disconnect
Time
(seconds)
Maximum
Disconnect
Time
Levels of
Error
Recovery
Exchange Medium
14
600 sec
6
Initialize Element
Status
120
600 sec
6
Move Medium
5
600 sec
6
Position To Element
5
600 sec
6
Prevent/Allow Media
Removal
10
600 sec
6
Read Element Status
120a
600 sec
6
Release
10
600 sec
6
Reserve
10
600 sec
6
Rezero Unit
120
600 sec
6
Send Diagnostic
600b
600 sec
6
Rotate
5
600 sec
6
E-2
Appendix E
Disconnect Timeout Settings
Disconnect Timeout Settings
a. If the Read Element Status Command disconnects, it will
perform movements identical to that of the Initialize
Element Status before sending the element status data.
Therefore, the timeout should be set the same as the
Initialize Element Status command.
b. The Send Diagnostic Command is different from the other
commands in that there are a number of different tests that
may be executed. Also, the test may be run in a loop. It is
recommended that the host never run a diagnostic test in a
loop so set the loop count to one and set the
timeout to 10 minutes.
Disconnect Timeouts
Appendix E
E-3
Disconnect Timeout Settings
Disconnect Timeout Settings
E-4
Appendix E
Index
A
abort 06H, 9
Abort Tag 0DH, 11
addresses, 2
arbitration phase, 3
Attention Condition, 16
autochanger configuration mode page (20H),
30
autochanger move error codes, 29
B
Bus Device Reset 0CH, 11
Busy 08H, 15
C
caching page 08H, 37, 60
Check Condition 02H, 14
Clear Queue OEH, 12
command complete, 10
command complete 00H, 6
Command Descriptor Block (CDB), 18
command phase, 4
commands
alphabetical list, 4
drive control, 3
numerical list, 2
scsi overview, 2
Condition Met 04H, 14
Conditions, 16
control mode page 0AH, 39, 63
conventions
typographical, iii
D
data phase, 4
device capabilities, 26
diagnostic tests, 40
dip switch
definitions, 51
locations, 51
disconnect, 10
disconnect 04H, 9
disconnect timeout settings, 2
disconnect-reconnect page 02H, 36, 59
drive control commands, 3
drive log data format, 57
drive request sense
command values, 3
sense key values, 3
DSP error codes, 19
E
element full/empty, sense code 3BH, 7
erase (group 1) command (2CH), 88
erase (group 5) command (ACH), 134
error codes
autochanger move, 29
hardware, 19
micro-move, 32
error logs table format, 49
exchange medium command (A6H), 66
extended message 01H, 6
F
field replaceable units (FRUs), 2
flag, 7
force log data format, 54
format mode 03H - type 0, 43, 67
format mode 03H - type 1, 44, 68
format mode 04H, 45, 69
format unit command (04H), 15
G
Good OOH, 14
Group 0 Commands,
Group 1 Commands,
Group 2 Commands,
Group 5 Commands,
2
4
4
6
H
hardware error codes, 19
Head of Queue Tag, 13
I
identity, 10
Identity 80H-FFH, 13
information transfer phase, 3
initialize element status command (07H), 12
initiator, 2
initiator-detected error 05H, 9
inquiry command (12H), 26, 14
Intermediate Condition Met 14H, 15
Intermediate/Good 10H, 15
internal error codes, 9
invalid address, sense code 21H, 7
L
link, 7
linked command complete, 10
Linked Command Complete (with flag) 0BH,
11
1
Index
Linked Command Complete 0AH, 11
log select command (4CH), 109
log sense command (4DH), 111, 47
M
medium types support page 0BH, 64
medium types supported page 0BH, 40
message in phase, 4
message out phase, 4
message phase, 4
Message Priority Error 09H, 11
message reject, 10
message reject 07H, 10
messages
target-supported, 5
micro-move error codes, 32
micro-move ID table, 2
mode page 20H parameter default values, 49
mode page parameter default values, 48
mode select (group 2) command (55H), 122
mode select command (15H), 31
mode sense (group 0) command, 54
mode sense (group 2) command (5AH), 125
mode sense command (1AH), 21
mode sense device capabilities page (1FH), 27
mode sense element address assignment
page (1DH), 23
mode sense transport element parameter
page (1EH), 25
move history log data format, 63
move medium command (A5H), 64
move success log table format, 53
N
No Operation 08H, 11
O
ODC error codes, 15
odometer log data format, 58
offset values, 9
Ordered Queue Tag, 13
P
position to element command (2BH), 38
pre-fetch (34H), 94
prevent/allow medium removal command
(1EH), 79, 37
Q
Queue Full 28H, 15
2
Queue Tag Messages (20H, 21H, 22H), 12
R
read (group 0) command (08H), 21
read (group 1) command (28H), 82
read (group 5) command (A8H), 128
read buffer command (3CH), 102, 43
read capacity command (25H), 80
read defect data (group 1) command (37H), 96
read defect data (group 5) command (B7H),
142
read element status command (B8H), 68
read long command (3EH), 104
read long command (DEH), 145
read-write error recover page 01H, 57
read-write error recovery page 01H, 34
reassign blocks command (07H), 19
receive diagnostic results command (1CH),
74, 33
recovery log data format, 55
RelAdr, 7
release command (17H), 53, 20
request sense, 5
sense data for error recovery, 8
sense key values, 3
request sense command (03H), 10, 8
request sense data, 4
request sense error codes, 3
reselection phase, 3
Reservation Conflict 18H, 15
reserve command (16H), 52, 18
Reset Condition, 16
restore pointers, 10
restore pointers 03H, 9
retry log data format, 61
rezero unit command (01H), 9
rezero unit ready command (01H), 7
rotate mailslot command (0CH), 13
run-time log data format, 59
S
save data pointer 02H, 9
save data pointers, 10
SCSI bus phases
arbitration phase, 3
command phase, 4
data phase, 4
information transfer phase, 3
message in phase, 4
message out phase, 4
message phase, 4
Index
reselection phase, 3
selection phase, 3
SCSI command overview, 2
seek (group 0) command (0BH), 25
seek (group 1) command (2BH), 87
selection phase, 3
send diagnostic command (1DH), 76, 35
sense code values, 5
sequence tests, 44
Simple Queue Tag, 12
start/stop unit command (1BH), 73
Status Phase, 14
synchronize cache (35H), 95
synchronous negotiation, 7
T
target device, 2
target SCSI commands, 18
target-supported messages, 5
Target-Supported Status Codes, 14
test unit ready (00H), 8
test unit ready command (00H), 6
transfer period values, 8
typographical conventions, iii
U
Unit Attention Condition, 17
V
vendor unique format page 20H, 42, 66
vendor unique page 21H, 46, 70
verify (group 1) command (2FH), 92
verify (group 5) command (AFH), 140
W
write (group 0) command (0AH), 23
write (group 1) command (2AH), 84
write (group 5) command (AAH), 131
write and verify (group 1) command (2EH),
90
write and verify (group 5) command (AEH),
137
write buffer command (3BH), 99, 39
write long command (3FH), 106
write long command (DFH), 147
3
Index
4
Copyright © 2001
Hewlett-Packard Company
Printed in U.S.A.
Edition 12/2001
www.hp.com/go/support
Printed on recycled paper
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
