Operating Instructions Plasma Television Model No. TH-H42Z8A Please read these instructions before operating your set and retain them for future reference. The images shown in this manual are for illustrative purposes only. Please refer to Pan European Guarantee Card if you need to contact your local Panasonic dealer for assistance. English Turn your own living room into a movie theatre! Experience an amazing level of multi- Notice for DVB functions • •• • 2 Any functions related to DVB (Digital Video Broadcasting) will work in areas where DVB-T (MPEG2) digital terrestrial broadcasting are received. Consult your local Panasonic dealer with coverage areas. DVB functions may not be available in some countries. Some functions may not be available in some countries. This TV has the capability for DVB specifications. But future DVB services cannot be guaranteed. media excitement Enjoy rich multi-media Set top box •• •• Enjoy your TV! Basic Features DVD Recorder VCR Quick Start Guide Accessories / Options ········· 6 Identifying Controls ·············· 8 Basic Connection ················ 10 Auto Setup······························ 12 DVD player •• •• Watching TV ·············································· 14 Using Programme Guide ·························· 17 Viewing Teletext ········································ 18 Watching Videos and DVDs ······················ 20 Viewing Amplifier with Speaker system Safety Precautions ······································ 4 (Warning / Caution) Notes ··························································· 5 Maintenance ··············································· 5 Quick Start Guide Camcorder Contents Be Sure to Read • •• Advanced Features How to Use Menu Functions ····················· 22 (picture, sound quality, etc.) DVB Settings (DVB) ·································· 26 (pay-TV, software update, time adjustment) Editing Programmes ································· 28 Tuning Programmes ·································· 30 Control Programme Audience ·················· 32 Restore Settings ······································ 33 Input Labels ·············································· 34 Link Functions ·········································· 36 (Q-Link / VIERA Link) External Equipment ··································· 42 This measurement is based on the time taken for the brightness of the panel to reduce to half of it’s maximum level. The time taken to reach this level may vary depending on the image content and the environment where the TV is used. Image retention and malfunctions are not taken into account. FAQs, etc. •• •• Technical Information ································ 44 FAQs ························································· 47 Licence ······················································ 49 Specifications ············································ 50 FAQs, etc. Up to 100,000 hours Plasma Panel Lifetime The Plasma display panel used in the 2008 VIERA TV range is rated for up to 100,000 hours. Advanced • • •• •• •• • 3 Safety Precautions Warning Handling the mains plug and lead •• •• •• •• Insert the mains plug fully into the socket outlet. (If the mains plug is loose, it could generate heat and cause fire.) Ensure that the mains plug is easily accessible. Ensure the earth pin on the mains plug is securely connected to prevent electrical shock. An apparatus with CLASS I construction shall be connected to a mains socket outlet with a protective earthing connection. Do not touch the mains plug with a wet hand. (This may cause electrical shock.) Do not use any mains lead other than that provided with this TV. (This may cause fire or electrical shock.) Do not damage the mains lead. (A damaged lead may cause fire or electrical shock.) Do not move the TV with the lead plugged in the socket outlet. Do not place a heavy object on the lead or place the lead near a high-temperature object. Do not twist the lead, bend it excessively, or stretch it. Do not pull on the lead. Hold onto the mains plug body when disconnecting lead. Do not use a damaged mains plug or socket outlet. •• •• If you find any abnormality, remove the mains plug immediately! AC 220-240 V 50 / 60 Hz Power source • This TV is designed to operate on 220-240 V, 50 / 60 Hz AC. Do not remove covers NEVER modify the TV yourself (High-voltage components may cause serious electrical shock.) Have the TV checked, adjusted, or repaired at your local Panasonic dealer. • Keep liquids away from the TV • • To prevent damage which may result in fire or shock hazard, do not expose this appliance to dripping or splashing. Do not place containers with water (flower vase, cups, cosmetics, etc.) above the TV. (including on shelves above, etc.) Do not expose to direct sunlight and other sources of heat • 4 Avoid exposing the TV to direct sunlight and other sources of heat. To prevent fire never place any type of candle or naked flame on top or near the TV. Do not place foreign objects inside the TV • Do not allow any objects to drop into the TV through the air vents (fire or electrical shock may result). Do not place the TV on sloped or unstable surfaces • The TV may fall off or tip over. Use only the dedicated pedestals / mounting equipment • • Using an unapproved pedestal or other fixtures may make the TV unstable, risking injury. Be sure to ask your local Panasonic dealer to perform setup. Use approved pedestals / mounts (p. 6). Notes Caution ŶWhen cleaning the TV, remove the mains plug Ŷ•When the TV is not going to be used for a long period of time, remove the mains plug • Cleaning an energized TV may cause electrical shock. This TV will still consume some power even in the Off mode, as long as the mains plug is still connected to a live socket outlet. ŶTransport only in upright position • Transporting the TV with its display panel facing upright or downward may cause damage to the internal circuitry. ŶAllow sufficient space around the TV for radiated heat Minimum distance 10 This causes the image to remain on the plasma screen (“image retention”). This is not considered a malfunction and is not covered by the warranty. Typical still images Programme number and other logos Image displayed in 4:3 mode Video game To prevent image retention, contrast is lowered automatically after a few minutes if no signals are sent or no operations are performed. (p. 47) •• • ŶAuto power standby function • If no signal is received and no operation is performed in Analogue TV mode for 30 minutes, the TV will automatically go to standby mode. ŶKeep the TV away from these types of 10 10 Do not display a still picture for a long time equipment • 7 (cm) • • ŶDo not block the rear air vents • When using the pedestal, keep the space between the bottom of the TV and the floor surface. In case of using Wall-hanging bracket, follow the manual of it. • Electronic equipment In particular, do not place video equipment near the TV (electromagnetic interference may distort images / sound). Equipment with an infrared sensor This TV also emits infrared rays (this may affect operation of other equipment). Blocked ventilation by newspapers, table cloths, curtains, etc. may cause overheating, fire or electrical shock. ŶDo not expose your ears to excessive volume from the headphones • Irreversible damage can be caused. Maintenance First, remove the mains plug from the socket outlet. Display panel Regular care: Gently wipe the surface clean of dirt by using a soft cloth. Major contamination: Wipe the surface clean using a soft cloth dampened with clean water or diluted neutral detergent (1 part detergent to 100 parts water). Then, using a soft dry cloth, evenly wipe the surface clean until it is dry. Caution • • The surface of the display panel has been specially treated and may be easily damaged. Do not tap or scratch the surface with your fingernail or other hard object. Take care not to subject the surface to insect repellent, solvent, thinner, or other volatile substances (this may degrade surface quality). Cabinet, Pedestal Regular care: Wipe the surface clean using a soft dry cloth. Major contamination: Dampen a soft cloth with clean water or water containing a small amount of neutral detergent. Then, wring the cloth and wipe the surface clean with it. Finally, wipe the surface clean with a dry cloth. Caution • • • Take care not to subject the TV's surfaces to detergent. (A liquid inside the TV could lead to product failure.) Take care not to subject surfaces to insect repellent, solvent, thinner, or other volatile substances (this may deteriorate the surface by peeling the paint). Do not allow the cabinet and pedestal to make contact with a rubber or PVC substance for a long time. Mains plug Wipe the mains plug with a dry cloth at regular intervals. (Moisture and dust may lead to fire or electrical shock.) 5 Accessories / Options Standard accessories Remote Control • Batteries for the Remote Control (2) OK N2QAYB000222 Check that you have the accessories and items shown 1 2 3 4 5 6 7 8 9 0 • Clamper Mains Lead p. 8 p. 11 R6 (UM3) TV Operating Instructions Cleaning cloth Pedestal p. 7 Pan European Guarantee Card • This product contains possibly dangerous parts (such as plastic bags), that can be breathed in or swallowed by young children accidentally. Keep these parts out of reach of young children. Optional accessories Wall-hanging bracket (vertical) (angle) •• •• Caution • • • TY-WK42PV3W TY-WK42PV4W TY-WK42PR3W TY-WK42PR4W In order to maintain the unit’s performance and safety, be absolutely sure to ask your dealer or a licenced contractor to secure the wall-hanging brackets. Carefully read the instructions accompanying the pedestal, and be absolutely sure to take steps to prevent the TV from tipping over. Handle the TV carefully during installation since subjecting it to impact or other forces may cause product damage. Installing / removing remote’s batteries 1 Pull open 2 Close + - + - Hook Note the correct polarity (+ or -) Caution •• •• • 6 Incorrect installation may cause battery leakage and corrosion, resulting in damage to the remote control. Do not mix old and new batteries. Do not mix different battery types (such as alkaline and manganese batteries). Do not use rechargeable (Ni-Cd) batteries. Do not burn or breakup batteries. Batteries must not be exposed to excessive heat such as sunshine, fire or the like. Attaching the pedestal Warning Do not disassemble or modify the pedestal. Otherwise the TV may fall over and become damaged, and personal injury may result. •Caution • • • • • Assembly screw (4) (silver) • Pole (2) •• THEL062N • TBLX0053 R M5 × 25 ŶAssembling the pedestal Use the four assembly screws to fasten the left and right poles to the base securely. Make sure that the screws are securely tightened. Forcing the assembly screws the wrong way will strip the threads. “L” or “R” mark is stamped on the bottom of the pole. •• • A R D L Front Accessories / Options L M5 × 18 Base R : TBLA3632 L : TBLA3633 • • XYN5+F18FN Assembly screw (4) (black) Quick Start Guide Do not use any other TV and displays. Otherwise the TV may fall over and become damaged, and personal injury may result. Do not use the pedestal if it becomes warped or physically damaged. If you use the pedestal while it is physically damaged, personal injury may result. Contact your nearest Panasonic dealer immediately. During set-up, make sure that all screws are securely tightened. If insufficient care is taken to ensure screws are properly tightened during assembly, the pedestal will not be strong enough to support the TV, and it might fall over and become damaged, and personal injury may result. Ensure that the TV does not fall over. If the TV is knocked or children climb onto the pedestal with the TV installed, the TV may fall over and personal injury may result. Two or more people are required to install and remove the TV. If two or more people are not present, the TV may be dropped, and personal injury may result. ŶSecuring the TV Use the assembly screws to fasten securely. Make sure that the screws are securely tightened. Carry out the work on a horizontal and level surface. •• B View from the bottom Arrow mark Hole for pedestal installation D 7 Accessories / Options Using the clamper Rear of the TV • •• Ŷ Attach the clamper hole Do not bundle the RF cable and mains lead together (could cause distorted image). Fix cables with clampers as necessary. When using the optional accessory, follow the option’s assembly manual to fix cables. Ŷ Bundle the cables To remove from the TV: To loosen: snaps Insert the clamper in a hole Keep pushing both side snaps hooks Set the tip in the hooks knob Keep pushing the knob Identifying Controls TV PULL Function select / Contrast / Brightness / Colour / •Volume Sharpness / Tint (NTSC mode) / Bass / Lift door to open Treble / Balance / Auto Setup (p. 30) AV3 Changes the input mode Headphones jack AV3 terminals (p. 42) (p. 42) Increases or decreases the programme position by one. When a function is already displayed, press to increase or decrease the selected function. When in Standby mode, switches TV On. Recording LED •C.A.T.S. (Contrast Automatic Tracking System) sensor •Remote control signal receiver Standby for Direct TV Recording :orange Senses brightness to adjust picture quality in “Eco” mode in Picture Menu (p. 24) Mains power On / Off switch • 8 Switch On to turn on the TV or turn the TV to standby mode by the remote control Power LED • • Standby: red On: green When using the remote control, indicates the TV has received a command. Identifying Controls Remote Control Standby On / Off switch • Guide • Input mode selection Switches TV On or Off standby (p. 17) Displays Programme Guide or Programme List TV - switches DVB / Analogue mode (p. 14) AV - switches to AV input mode from Input Selection list (p. 20) INPUT GUIDE EXIT •• Makes selections and adjustments OK MENU RETURN Main Menu (p. 22) • Press to access VIERA Link, Picture, Sound and Setup Menus ASPECT OPTION DIRECT TV REC • Programme Information • Programme Up / Down • Press to access VIERA Link Menu directly 2 3 4 5 6 7 8 9 • Numeric buttons •• Sound Mute •Volume Up / Down Easy setting for viewing and sound options Changes programme and teletext pages When in Standby mode, switches TV On 0 (p. 15) Displays programme information Option Menu (p. 15) VCR Switches sound mute On or Off Selects programme in sequence TEXT STTL INDEX HOLD Teletext (p. 18) • Subtitles • Switches to teletext mode (p. 14) Displays subtitles Hold REC PROGRAMME VCR DVD •• Freeze / unfreeze picture (p. 14) Holds the current teletext page (teletext mode) (p. 19) Identifying Controls Accessories / Options VIERA Link Menu (p. 39) 1 (p. 37 and p. 39) Records programme immediately in DVD Recorder / VCR with Q-Link or VIERA Link connection •• Changes aspect ratio from Aspect Selection list Also possible by pressing this button repeatedly until you reach the desired aspect Returns to the previous menu Used for the selection, navigation and operation of various functions Aspect (p. 16) • • Returns to the normal viewing screen Quick Start Guide OK Confirms selections and choices Press after selecting programme positions to quickly change programme •• Exit •Cursor buttons •Return •Coloured buttons • Direct TV Recording • Index (p. 19) • VCR / DVD Panasonic equipment operations (p. 21) Returns to the teletext index page (teletext mode) TV 9 Basic Connection External equipment and cables shown are not supplied with this TV. Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any leads. When disconnecting the mains lead, be absolutely sure to disconnect the mains plug at the socket outlet first. Example 1 Connecting aerial Example 2 Connecting DVD Recorder / VCR TV only TV, DVD Recorder or VCR Rear of the TV Aerial Rear of the TV Aerial AC 220-240 V 50 / 60 Hz AC 220-240 V 50 / 60 Hz Mains lead (supplied) Mains lead (supplied) RF cable AV1 RGB VIDEO AV2 AV1 RGB VIDEO S VIDEO RGB VIDEO COMPONENT COMPONENT AUDIO AUDIO OUT IN AUDIO AUDIO OUT IN Y L L Y PB HDMI 1 R R AV2 RGB VIDEO S VIDEO PR L L PB R R PR HDMI 2 HDMI 1 HDMI 2 RF cable SCART cable (fully wired) RF OUT DVD Recorder or VCR RF IN 10 •• •• • RF cable Note Connect to AV1 / AV2 for a DVD Recorder / VCR supporting Q-Link (p. 37). For HDMI-compatible equipment, possible to connect to HDMI terminals (HDMI1 / HDMI2) by using HDMI cable (p. 42). Q-Link connection p. 36 VIERA Link connection p. 36 Read the manual of the equipment too. Example 3 Connecting DVD Recorder / VCR and Set top box TV, DVD Recorder / VCR and Set top box Rear of the TV Push until both side tabs click • Make sure that the mains lead is securely fixed. AC 220-240 V 50 / 60 Hz To remove from the TV: • Press both tabs and pull on mains connector to release Basic Connection tabs Mains lead (supplied) RF cable AV1 RGB VIDEO Quick Start Guide Aerial AV2 RGB VIDEO S VIDEO COMPONENT AUDIO AUDIO IN OUT Y L L PB R R PR HDMI 1 HDMI 2 SCART cable (fully wired) RF OUT DVD Recorder or VCR RF IN RF cable Fully wired HDMI compliant cable SCART cable (fully wired) RF OUT RF cable RF IN RF cable Set top box RF IN 11 Auto Setup Search and store TV programmes automatically. These steps are not necessary if the setup has been completed by your local dealer. 1 Plug the TV into mains socket and switch On 2 Select the language INPUT GUIDE EXIT OK MENU 3 (Takes a few seconds to be displayed) • Deutsch English Français Italiano Español Português Nederlands 2 3 4 5 6 7 8 9 4 0 Dansk Svenska Norsk Suomi Türkçe Еλληνικά Polski čeština Magyar Slovenčina Български Românǎ Srpski Hrvatski Slovenščina Latviešu eesti keel Lietuvių store Select your country select Country Germany Austria France Italy Spain Portugal Switzerland Malta Andorra OPTION DIRECT TV REC 1 select Menüsprache RETURN ASPECT Denmark Sweden Norway Finland Luxembourg Belgium Netherlands Turkey Greece Poland Czech Hungary Slovakia E.Eu • Depending on the selected countries, you may also be required to select the region. Start Auto Setup Auto Setup - Digital and Analogue Digital Scan Analogue Scan This will take about 6 minutes. Channel Service Name 62 CBBC Channel 62 BBC Radio Wales 62 E4 62 Cartoon Nwk 29 33 BBC1 Free TV: 4 Pay TV: 0 VCR You can now use the remote control to turn On the TV or turn the TV to standby mode. (Power LED: On) TEXT STTL INDEX HOLD 5 2 Radio: 0 Searching 78 69 41 1 • Type Quality Free TV 10 Free TV 10 Free TV 10 Free TV 10 Analogue Analogue Data: 0 Analogue: 2 Auto Setup will start to search for TV programmes and store them. The sorted programme order depends upon the TV signal, the broadcasting system and reception conditions. EXIT RETURN REC VCR DVD • PROGRAMME Sending Preset Data Please wait! 0% 100% Remote control unavailable TV 5 If Q-Link, VIERA Link or similar technology (p. 36), compatible recorder is connected, programme, language, country / region settings are automatically downloaded to the recorder. Select the picture setting Please select your viewing environment. Home Shop • “Shop” and “Home” are equal to “Dynamic” and “Normal” respectively - “Viewing Mode” in “Picture Menu” (p. 24) select set Auto Setup is now complete and your TV is ready for viewing. • 12 To edit programmes “Editing Programmes” (p. 28) Many features available on this TV can be accessed via the On Screen Display menu. Ŷ How to use remote control MENU Open the main menu Move the cursor / select the menu Access the menu / store settings after adjustments have been made or options have been set RETURN Return to the previous menu • EXIT Exit the menu system and return to the normal viewing screen Ŷ ON SCREEN HELP Instructions box Auto Setup Using the On Screen Displays Quick Start Guide Move the cursor / adjust levels / select from a range of options (example: Sound Menu) Sound Menu Mode Bass Treble Balance Headphone Volume Surround Volume Correction Speaker Distance to Wall MPX Select EXIT Change RETURN 1/2 Music Off Over 30cm Stereo Page up Page down On-screen operation guide will help you. •• •• Note If tuning has failed “Auto Setup” (p. 31) If downloading has failed “Download” (p. 25) To initialize all settings “Shipping Condition” (p. 33) If you turned the TV Off during Standby mode last time, the TV will be in Standby mode when you turn the TV On with Mains power On / Off switch. 13 Watching TV 1 Turn power on 2 Select DVB (Digital Video Broadcasting) or Analogue mode (Press for about 1 second) • Mains power On / Off switch should be On. (p. 8) INPUT GUIDE EXIT OK MENU • RETURN ASPECT Also possible to select the mode using the TV button on the front panel of the TV. (p. 8) OPTION DIRECT TV REC 1 BBC ONE WALES 1 2 3 4 5 6 7 8 9 23:35 Coronation Street 20 : 00 ~ 20 : 55 3 0 VCR Select a programme up or down Volume 1 2 3 4 5 6 7 8 9 Profile 1 Change category For info press Information banner appears whenever you select a programme For details p. 15 • • To select the two or three-digit programme number, e.g. 39 3 9 0 (in a short time) To select from the Programme List VCR • TEXT STTL INDEX HOLD Now All DVB Services REC VCR 6 7 8 1 2 3 4 DVD PROGRAMME Cartoon Nwk BBC Radio Wales BBC Radio Cymru BBC ONE Wales BBC THREE BBCi CBBC Channel Select Connect EXIT RETURN watch Page up Page down Ŷ Select a programme using Information banner (p. 15) Possible to confirm the programme name before selecting programmes. TV • select programme Display Information banner if it is not displayed Note While the banner is displayed, select the programme select programme To watch pay-TV p. 27 watch • Possible to set display timeout in “Banner Display Timeout” (p. 25). Ŷ Select a programme using Programme Guide (p. 17) Possible to confirm the Programme Guide or Programme List before selecting programmes. This function may not be available in some countries. • Display Programme Guide or Programme List Select the programme select programme GUIDE watch Ŷ Other useful functions 14 Hold Freeze / unfreeze picture Display subtitles Display / hide subtitles (if available) • To change the language for DVB (if available) “Preferred Subtitles” (p. 25) HOLD STTL Ŷ Other useful functions Display Information banner • Also appears when changing a programme Event Programme Programme type (if it is Radio or Data service) 1 ZDF Radio Current time Example: Coronation Street 20 : 00 ~ 20 : 55 Category Profile 1 Change category For info press 23:35 Now 45 Encrypted DVB: Event Start / Finish time Analogue: Programme status Features available / Message meanings Display Information banner Teletext service available Bad signal Poor TV signal quality Multiple audio available Encrypted Scrambled programme Stereo, Mono Audio mode Subtitle service available 1 - 90 Off Timer remaining time For settings see below • • • • To confirm another tuned programme name To change the category blue EXIT To hide To set display timeout Information on the next event “Banner Display Timeout” (p. 25) (DVB mode) Extra information (press again to hide the banner) (DVB mode) To change • change select Multi Audio (DVB mode) Allows you to select between alternative language for sound tracks (if available) Teletext Language (DVB mode) Allows you to select between alternative language for teletext (if available) Subtitle Language (DVB mode) Allows you to select the language in which subtitles should appear (if available) MPX (Analogue mode) Sound Menu (p. 24) Teletext Character Set Sets the teletext language Setup Menu (p. 25) • Watching TV • OPTION Check or change the current programme status instantly Display the selectable settings for the current programme To watch the programme listed in the banner Viewing • • • • Sound mute On Volume Correction Adjusts volume of individual programme or input mode Note Also possible to change the settings in Menu list (p. 24 and p. 25). Turn the TV off automatically after a fixed period Display the menu MENU Select “Setup” Main Menu Select “Off Timer” and set the time access VIERA Link Picture Off Timer Sound Setup •• • select Setup Menu DVB Profile Edit DVB Service List Link Settings Child Lock Tuning Menu Off Timer Language Teletext Teletext Character Set 1/3 set select Off TOP West To cancel Set to “Off” or turn the TV off. To display the remaining time Information banner (above) When the remaining time is within 3 minutes, the remaining time will flash on screen. 15 Watching TV Ŷ Other useful functions Change the aspect ratio ASPECT Aspect selection Auto 16:9 14:9 Just 4:3 4:3 Full Zoom1 Zoom2 Zoom3 Enjoy viewing the picture at its optimum size and aspect. Display Aspect Selection list While the list is displayed, select the mode Select Change RETURN Aspect Selection list store ASPECT EXIT select • To change the mode using the ASPECT button only ASPECT (Press repeatedly until you reach the desired mode) Auto 16:9 The best ratio is chosen and the picture expanded to fill the screen. For details p. 44 14:9 Directly displays the image at “16:9” without distortion (anamorphic). Just Displays the image at the standard “14:9” without distortion. Change aspect ratio 4:3 Displays a “4:3” image full-screen. Stretching is only noticeable at the left and right edges. 4:3 Full Displays the image at the standard “4:3” without distortion. Zoom1 Displays a “4:3” image enlarged horizontally to fit the screen. HD signal only • Zoom2 Displays a “16:9” letterbox or “4:3” image without distortion. Displays a “16:9” letterbox (anamorphic) image full-screen without distortion. Zoom3 Displays a “2.35:1” letterbox (anamorphic) image full-screen without distortion. At “16:9”, displays the image at its maximum (with slight enlargement). •• 16 Note Not available in teletext mode. Aspect mode can be memorized separately for SD (Standard definition) and HD (High definition) signals. Using Programme Guide Using Programme Guide enables you to select programme easily, view event informations, etc. Programme GuideʊElectronic Programme Guide (EPG) provides an on-screen listing of the programmes currently broadcast and the future broadcasts over the next seven days (depending on the broadcasters). •• This function varies depending on the country you select (p. 12). Analogue programmes will be listed after DVB programmes. “D” means DVB programme and “A” means Analogue programme. View Programme Guide GUIDE Each time pressed, the layout will be changed (Landscape / Portrait). • • INPUT GUIDE EXIT OK MENU RETURN Programme Guide time Current date and time Example: Programme Guide date Wed 24.10.2007 10:46 ASPECT OPTION DIRECT TV REC 1 2 5 6 7 8 9 Hot Wars D 14 E4 Emmerdal. D 70 CBBC Cha 10 O’ clock News BBC D 72 Cartoon Panorama D 105 BBCi I’ m A Celebrity D 719 BBC Radi Rugby -24 Hr Coronation Street Pop Idol 15 To 1 The Bill 21:00~22:00 Red Cap Good bye 22:30~23:00 Live junction Terminator 23:00~23:30 POP 100 News 23:00~00:00 Rugby Select programme Change display mode EXIT Select channel View RETURN Page up Prog.Type Category +24 Hr Landscape (Displays by programme) Programme Ŷ To the next day (DVB mode) Page up Page down Prog.Type Category selected type (DVB mode) (Type list) Prog. Type All Types green yellow Select the event or programme now on the air All Types Movie News select type view . . . . . Ŷ To view a programme list of the selected category watch (Category list) Ŷ To view details of the event (DVB mode) Category All Services Select the event Press again to return to Programme Guide. blue Ŷ To view advertisement (Depending on the country) If you enter an incorrect postcode for your area, or no postcodes are entered, advertisement may not be displayed correctly. Press the OPTION or select OPTION advertisement RETURN button to return to Programme Guide. • • Info Select Advert Portrait (Displays by time) Ŷ To watch the programme • 70 CBBC Ŷ To view a programme list of the red select select All Services D The Bill Page down +24 Hr 14 E4 All Services All DVB Services All Analogue Services Free Services Pay Services TV Radio Information Profile 1 Profile 2 Profile 3 Profile 4 Only Analogue TV programmes are listed select category view Using Programme Guide Watching TV EXIT DIY SOS 21:00~22:00 All Types D •• Ŷ To return to TV 20:00~21:00 The Bill Info Select Advert (DVB mode) REC Pepsi Char. Sex And The City Ŷ To the previous day TEXT STTL INDEX HOLD 21:00 Red Cap Portrait Wed, 24.10.2007 D 1 BBC O D 7 BBC T 19:30~20:00 Eastender Viewing VCR Wed 24.10.2007 10:46 All Services Horiday Program Select channel Change display mode EXIT Select programme View RETURN Advertisement 0 D 7 BBC THR Example: Event Landscape All Types Wed, 24.10.2007 20:00 - 20:30 DIY SOS : We open in the Battersbys Time: 19:30 20:00 20:30 D 1 BBC ONE Eastender DIY SOS The Bill 3 4 Depending on the country, the postcode entry or update is required. Follow the message’s instructions. Also possible to setup manually from Setup Menu “Update” / “Postcode” in “GUIDE Plus+ Settings” (p. 25) To list favourite programmes p. 29 Note When this TV is turned on for the first time, or the TV is switched off for more than a week, it may take some time before the Programme Guide is completely shown. Ŷ Depending on the country you select, Programme Guide may not be supported In this case, Programme List will appear. Programme List All DVB Services 6 7 8 1 2 3 4 Cartoon Nwk BBC Radio Wales BBC Radio Cymru BBC ONE Wales BBC THREE BBCi CBBC Channel Select Connect EXIT RETURN select programme watch Page up Page down 17 Viewing Teletext You can enjoy teletext broadcasting, including news, weather forecasts and subtitles, if this service is provided by the broadcasters. What is FLOF (FASTEXT) mode? In FLOF mode, four differently coloured subjects are situated at the bottom of the screen. To access more information about one of these subjects, press the appropriately coloured button. This facility enables fast access to information on the subjects shown. What is TOP mode? (in case of TOP text broadcasting) TOP is a particular improvement of the standard teletext service that results in an easier search and effective guide. Fast overview of the teletext information available Easy to use step-by-step selection of the topical subject Page status information at the bottom of the screen Available page up / down red green •• • To select among subject blocks blue To select next subject within the subject block (After the last subject, it moves to the next subject block.) yellow What is List mode? In List mode, four differently coloured page numbers are situated at the bottom of the screen. Each of these numbers can be altered and stored in the TV’s memory. (“Store frequently viewed pages”, p. 19) Ŷ To change mode 1 INPUT GUIDE “Teletext” in Setup Menu (p. 25) Sub page number Switch to Teletext TEXT EXIT • << 01 02 03 04 05 06 07 Displays Index (content varies depending on the broadcasters) Current page number >> 17:51 28 Feb Time / date TELETEXT INFORMATION Colour bar OK MENU RETURN ASPECT OPTION DIRECT TV REC 1 2 3 4 5 6 7 8 2 Select the page 1 2 3 4 5 6 7 8 9 up or or down 0 red green yellow blue (Corresponds to the colour bar) VCR As the blue bar is displayed Ŷ To adjust contrast 9 MENU (Press three times) 0 VCR Ŷ To return to TV TEXT TEXT STTL INDEX HOLD REC VCR DVD Ŷ Using teletext conveniently Reveal hidden data Reveal hidden words e.g. quiz page answers Ŷ Re-hide MENU red red (TOP) FULL / TOP / BOTTOM green (Expand the TOP half) 18 (BOTTOM) MENU (Expand the BOTTOM half) Normal (FULL) Stop automatic updating HOLD (If you wish to hold the current page without updating) HOLD Ŷ To resume HOLD Return to the main index page INDEX Call up a favourite page INDEX View a favourite page stored •• STTL Call up the page stored in “blue”. Factory setting is “P103”. Watch TV and Teletext in two windows at once View in multi window • MENU (Press twice) • Select Picture and text On or Off Operations can be made only in Teletext screen. (List mode only) Store frequently viewed pages in the colour bar Store frequently viewed pages Viewing As page is displayed press and hold Corresponding colour button Ŷ To change stored pages The number changes to white. Enter new page number 2 3 4 5 6 7 8 9 press and hold Viewing Teletext 1 • Colour button you want to change 0 VCR View sub page (Only when teletext is more than one page) Appears at top of the screen View sub page Ŷ To view specific sub page MENU Enter the 4-digit number blue example: P6 • 0 0 0 6 Sub pages: The number of sub pages varies depending on the broadcasters (up to 79 pages). It may take some time for searching, during which time you can watch TV. View the TV picture while searching for a teletext page Watch TV while waiting for update Teletext automatically updates itself when new information becomes available. Changes to TV screen temporarily P108 MENU yellow • Appears when updating is completed yellow View the updated page (You cannot change the programme.) The news page provides a function that indicates arrival of latest news (“News Flash”). 19 Watching Videos and DVDs Connect the external equipment (VCRs, DVD equipment, etc.) and you can watch the input. To connect the equipment p. 10 and p. 11 The Remote Control is capable of operating some functions of selected Panasonic external equipment. • 1 Turn the TV on Ŷ When connecting with SCART as example 2 or 3 (p. 10 and p. 11) • • Ŷ • Receives input signals automatically when playback starts Input signals are automatically identified by the SCART (pin 8) terminal. This function is also available for HDMI connections (p. 42). If input mode is not switched automatically Perform and Dependant on the setup of the equipment INPUT GUIDE EXIT OK MENU 2 Display the Input select menu 3 Select the input mode connected to the equipment RETURN ASPECT OPTION DIRECT TV REC 1 2 3 4 5 6 7 8 9 0 TEXT STTL INDEX HOLD VCR DVD PROGRAMME AV1 AV2/S AV3/S COMPONENT HDMI1 HDMI2 TV • • VCR REC Input Selection 4 watch select You can also select the input using the AV button on the remote control or the front panel of the TV. Press the button repeatedly until the desired input is selected. You can label or skip each input mode “Input Labels” (p. 34) View Displays the selected mode TV Ŷ To return to TV •• 20 Note If the external equipment has an aspect adjustment function, set to “16:9”. For details, see the manual of the equipment or ask your local dealer. Panasonic equipment connected to the TV can be directly operated with the remote control. VCR DVD VCR / DVD switch Select VCR to operate Panasonic VCR or DVD equipment Select DVD to operate Panasonic DVD equipment or Player home theatre Standby Set to Standby mode / Turn on Play Playback videocassette / DVD Stop Stop the operations Rewind / Skip / Search VCR: Rewind, view the picture rapidly in reverse DVD: Skip to the previous track or title Press and hold to search backward REC Programme Up / Down Select programme Record Start recording Setting your remote control to operate Panasonic VCR, DVD, etc. VCR Set the VCR / DVD switch to the appropriate position Press and hold during the following operations Enter the appropriate code for the equipment to be controlled, see table below 1 2 3 4 5 6 7 8 9 DVD Watching Videos and DVDs PROGRAMME • Pause Pause / Resume DVD: Press and hold to play at slow speed Viewing Fast-forward / Skip / Search VCR: Fast-forward, view the picture rapidly forward DVD: Skip to the next track or title Press and hold to search forward Press 0 VCR “VCR” position Equipment VCR DVD •• •• Code 10 (default) 11 “DVD” position Equipment DVD Player home theatre Code 70 (default) 71 Note Confirm if the remote control works correctly after changing the code. The codes will be reset to default values if batteries are replaced. “DVD” means DVD player, DVD recorders and Recorder home theatre. Some operations may not be possible on some equipment models. 21 How to Use Menu Functions Various menus allow you to make settings for the picture, sound, and other functions. 1 Display the menu 2 Select the menu • MENU Displays the functions that can be set (varies according to the input signal) INPUT GUIDE EXIT OK MENU RETURN access Main Menu VIERA Link Picture select Sound ASPECT OPTION DIRECT TV REC 1 2 3 4 5 6 7 8 9 Setup (example: Picture Menu) Select the item 3 Picture Menu 0 VCR TEXT STTL INDEX HOLD REC VCR select Warm Off Off Adjust or select 4 Picture Menu 1/2 Viewing Mode Contrast Brightness Colour Sharpness Tint Colour Balance Colour Management P-NR TV Ŷ To return to TV at any time EXIT Dynamic (example: Picture Menu) DVD PROGRAMME 1/2 Viewing Mode Contrast Brightness Colour Sharpness Tint Colour Balance Colour Management P-NR Dynamic change store or access (Required by some functions) Warm Off Off (example: Picture Menu) ŶChoose from among alternatives Ŷ To return to the previous screen Number and positions of alternatives Colour Balance Normal Changed RETURN ŶAdjust using the slide bar Sharpness Ŷ To change menu pages up ŶTo reset the settings • • • To reset the picture settings only “Reset to Default” in Picture Menu (p. 24) To reset the sound settings only “Reset to Default” in Sound Menu (p. 24) To initialize all settings “Shipping Condition” in Setup Menu (p. 33) Moved ŶGo to the next screen Tuning Menu down Access Displays the next screen ŶEnter characters by free input menu You can enter names or numbers freely for some items. User input Set characters Name 22 A U a u B V b v C W c w D X d x E F G H I J K L M N O P Q R S T Y Z 0 1 2 3 4 5 6 7 8 9 ! : # e f g h i j k l m n o p q r s t y z ( ) + - . * _ select set Store RETURN Ŷ Overview Main Menu VIERA Link Picture VIERA Link Menu Pause Live TV Direct TV Rec VIERA Link Control Speaker Selection Access Start Recorder Home Cinema Sound Setup The menu of the accessed equipment (p. 39) Picture Menu 1/2 Dynamic Warm Off Off How to Use Menu Functions (picture, sound quality, etc.) Picture Menu 3D-COMB Reset to Default • Viewing Mode Contrast Brightness Colour Sharpness Tint Colour Balance Colour Management P-NR 2/2 Off Set (p. 24) 1/2 Sound Menu Mode Bass Treble Balance Headphone Volume Surround Volume Correction Speaker Distance to Wall MPX Music Off Over 30cm Stereo Sound Menu 2/2 HDMI1 Input Auto Reset to Default Set (p. 24) Setup Menu 1/3 Auto Access Access Access Access Access Access Access Off Access TOP Setup Menu Teletext Character Set Shipping Condition Common Interface System Update Power Save Side Panel Picture Overscan Input Labels Banner Display Timeout Advanced AV Colour System DVB Profile Edit DVB Service List Analogue Service List Link Settings Child Lock Tuning Menu GUIDE Plus+ Settings Off Timer Language Teletext Link Settings VIERA Link Q-Link AV2 out Power off Link Power on Link Download On AV2 TV Set Set Access (p. 25) 2/3 West Access Access Access Off Off On Access 3 seconds Tuning Menu Auto Setup DVB Manual Tuning Analogue Manual Tuning Add New DVB Services New Service Message DVB Signal Condition Access Access Access Access On Access (p. 30) Language Setup Menu Time Zone Refresh Rate Software License System Information 3/3 Auto 100Hz Access Access Access (p. 25) • OSD Language Preferred Audio 1 Preferred Audio 2 Preferred Subtitles 1 Preferred Subtitles 2 Preferred Teletext Access English English English English English (p. 25) Only available items can be selected. 23 How to Use Menu Functions ŶMenu list Menu Item Adjustments / Configurations (alternatives) VIERA Link Pause Live TV Direct TV Rec VIERA Link Control Speaker Selection Controls the connected equipment with VIERA Link function, and enables various convenient recording, playback, etc. (p. 39 - 41) You can also access VIERA Link Menu directly using the VIERA Link button on the remote control. Viewing Mode Basic picture mode (Dynamic / Normal / Cinema / Eco) Dynamic : Provides enhanced picture contrast and sharpness when viewing in a bright room Normal : Recommended for viewing under normal ambient room lighting conditions Cinema : For watching movies in a darkened room producing a cinema-like picture Eco : Adjusts picture settings automatically dependent on ambient lighting conditions Set for each input signal • • Contrast, Brightness, Increases or decreases the levels of these options according to your personal preference Colour, Sharpness Picture Sound 24 Tint With an NTSC signal source connected to the TV, the picture hue can be adjusted to suit your taste For NTSC signal reception only Colour Balance Allows you to set the overall colour tone of the picture (Cool / Normal / Warm) Colour Management Automatically adjusts colours to vivid ones (Off / On) P-NR Picture Noise Reduction Automatically reduces unwanted picture noise and flicker noise in the contoured parts of a picture (Off / Min / Mid / Max) 3D-COMB Occasionally, whilst viewing still or slow moving pictures, colour patterning may be seen Set to “On” to display sharper and more accurate colours (Off / On) For PAL or NTSC signal reception only Not valid on RGB, S-Video, Component and HDMI Reset to Default Press the OK button to reset the present Picture Mode to the default settings Mode Basic sound mode (Music / Speech) Bass Increases or decreases level to enhance or minimise lower, deeper sound output Treble Increases or decreases level to enhance or minimise sharper, higher sound output Balance Adjusts volume level of right and left speakers Headphone Volume Adjusts the volume of the headphones Surround Surround sound settings (Off / On) Provides a dynamic enhancer to simulate improved spatial effects Volume Correction Adjusts volume of individual programme or input mode Speaker Distance to Wall Adjusts the low frequency sound (Over 30cm / Up to 30cm) If the back space between the TV and wall is over 30 cm, “Over 30cm” is recommended. If the back space between the TV and wall is within 30 cm, “Up to 30cm” is recommended. MPX Select stereo / monaural (Mono / Stereo) Normally: Stereo Stereo signal cannot be received: Mono M1 / M2: Available while mono signal is transmitted Analogue mode only • •• •• •• •• HDMI1 Input Select to fit the input signal (Auto / Digital / Analogue) (p. 44) Auto : Automatic detection of digital or analogue sound source Digital : HDMI cable connection Analogue : HDMI-DVI adapter cable connection HDMI input mode only HDMI2 terminal is for digital signal only No setting for HDMI2 available Reset to Default Press the OK button to reset the present Sound Mode to the default settings •• • ŶMenu list Menu Item AV Colour System DVB Profile Edit DVB Service List Analogue Service List VIERA Link Link Settings Q-Link AV1 / AV2 out Power off Link Power on Link Download Teletext Character Set Side Panel Picture Overscan Input Labels Banner Display Timeout Time Zone Refresh Rate • Software License System Information Sets the Analogue programmes manually (p. 31) Adds new DVB services (p. 31) Selects whether to give a notification message when a new DVB service is found (p. 31) Checks the DVB signal condition (p. 31) Performs the update of the GUIDE Plus+ schedule and advertising informations for the GUIDE Plus+ system Sets your postcode for using the GUIDE Plus+ system (p. 17) Displays the system information of the GUIDE Plus+ system Sets the time the TV automatically turns Off (Off / 15 / 30 / 45 / 60 / 75 / 90 minutes) Changes language for on-screen displays Selects the preferred language for DVB multi audio (depending on the broadcaster) Selects the preferred language for DVB subtitles (depending on the broadcaster) To display subtitles p. 14 • Selects the preferred language for DVB teletext service (depending on the broadcaster) Teletext display mode (TOP (FLOF) / List) (p. 18) Selects teletext language (West / East1 / East2) West: English, French, German, Greek, Italian, Spanish, Swedish, Turkish, etc. East1: Czech, English, Estonian, Lettish, Rumanian, Russian, Ukrainian, etc. East2: Czech, Hungarian, Lettish, Polish, Rumanian, etc. Resets all settings, for example, when moving house (p. 33) Uses include to watch pay-TV (p. 27) Downloads new software to TV (p. 27) Reduces brightness of picture to economise on power consumption (Off / On) Increases the brightness of the side panel (Off / Low / Mid / High) The recommended setting is “High” to prevent panel “image retention”. Selects the screen area displaying the image (Off / On) On : Enlarged the image to hide the edge of the image. Off : Displayed the image in the original size. Set to “On” if noise is generated on the edge of the screen. This function is available when aspect is set to Auto (16:9 signal only) or 16:9. This function can be memorized separately for SD (Standard definition) and HD (High definition) signals. Labels or skips each input terminal (p. 34) Sets how long the information banner (p. 15) stays on screen 0 (No display) to 10 sec. in 1-sec. increments Adjusts the time data (p. 27) Changes the image processing of the panel (depending on the input signal) (50Hz / 100Hz) Set to “100Hz” normally Displays the software licence information Displays the system information of this TV •• • • Advanced Shipping Condition Common Interface System Update Power Save • •• How to Use Menu Functions (picture, sound quality, etc.) Postcode System Information Off Timer OSD Language Preferred Audio 1 / 2 Preferred Subtitles 1/2 Preferred Teletext Teletext Language Setup GUIDE Plus+ Settings Update Selects optional colour system based on video signals in AV mode (Auto / PAL / SECAM / M.NTSC / NTSC) Creates list of favourite programmes (p. 29) Skips the unwanted DVB programmes (p. 29) Skips the unwanted Analogue programmes or edits Analogue programmes (p. 29) Sets to use VIERA Link functions (Off / On) (p. 38) Selects which AV terminal is to be used for data communication between this TV and a compatible recorder (AV1 / AV2) (p. 37) Select the connected terminal to the recorder even it is not compatible with Q-Link. Chooses the signal to be transmitted from the TV to Q-Link (TV / AV1 / AV2 / AV3 / Monitor) Monitor: Image displayed on screen Component and HDMI signals cannot be outputted. Sets to use Power off Link function (No / Set) (p. 37 and p. 38) Sets to use Power on Link function (No / Set) (p. 37 and p. 38) Downloads programme, language, country / region settings to a Q-Link or VIERA Link compatible equipment connected to the TV Locks a programme / AV input to prevent access to it (p. 32) Automatically sets the programmes received in the area (p. 31) Sets the DVB programmes manually (p. 31) • Tuning Menu Child Lock Auto Setup DVB Manual Tuning Analogue Manual Tuning Add New DVB Services New Service Message DVB Signal Condition Adjustments / Configurations (alternatives) •• • • • Only available items can be selected. 25 DVB Settings (DVB mode) DVB Settings provide access to various advanced features. 1 INPUT GUIDE EXIT If in Analogue mode Select DVB 2 Display the menu 3 Select “Setup” MENU OK MENU RETURN ASPECT OPTION DIRECT TV REC 1 2 3 4 5 6 7 8 9 access Main Menu VIERA Link Picture select Sound Setup 0 VCR 4 VCR Setup Menu Shipping Condition Common Interface System Update Power Save Side Panel Picture Overscan Input Labels Banner Display Timeout Time Zone TEXT STTL INDEX HOLD REC Select “Common Interface”, “System Update” or “Time Zone” DVD PROGRAMME TV Ŷ To return to TV EXIT 5 26 Set 2/3 Access Access Off Off On 3 seconds Auto access select The Common Interface Module menu provides access to software contained on Common Interface (CI) Modules. This function may not be available in some countries or regions. Although CI module may enable you to view some services, this TV does not guarantee all services (e.g. pay-TV). Please use only the approved CI module by the broadcaster. Consult your local Panasonic dealer or broadcasters for more information and conditions of the services. Caution Common Interface Insert or remove straightly and completely CI module Rear of the TV Insert the CI module (optional) The features that appear on screen are dependent on the contents of the selected CI module. Normally pay-TV services will appear without and . If pay-TV service does not appear, perform and . For more details, see the manual of the CI module, or check with the broadcaster. Access “Common Interface” Common Interface Slot 1: Off Module inserted 2 of 2 Follow the on-screen instructions • example: select, go Coloured characters On-screen operation guide may not correspond to the remote control buttons. • • • • DVB Settings (DVB) (pay-TV, software update, time adjustment) Pay-TV • • • CI slot Turn Off Mains power On / Off switch whenever inserting or removing the CI module. If a view card and a card reader come as a set, first insert the card reader, then insert the view card into the card reader. Do not insert the module up side down. red green yellow blue Download new software to TV. For details p. 45 • Update TV’s software system System Update Select “Auto Update Search in Standby” and then set “On” or “Off” System Update Auto Update Search in Standby On System Update Search Now set select • On: Automatically performs a search in standby and downloads an update, if any software updates are available Ŷ To update immediately Select “System Update Search Now” access select Adjust the time data automatically Time Zone Advanced If System Update is performed, the software will be updated (it may change TV functions). If you do not wish to do so, set “Auto Update Search in Standby” to Off. Searches for an update (for several mins.) and displays a corresponding message if any Download • Download may take for about 20 mins. Set the time Auto set select : The time data will be adjusted according to your area automatically. Others : The time data will be corrected based on GMT. 27 Editing Programmes You can make your favourite programme lists and skip unwanted programmes, etc. 1 Select DVB or Analogue •• INPUT GUIDE EXIT “DVB Profile Edit” and “DVB Service List” are available in DVB mode only. “Analogue Service List” is available in Analogue mode only. 2 Display the menu 3 Select “Setup” MENU OK MENU RETURN ASPECT OPTION DIRECT TV REC 1 2 3 4 5 6 7 8 9 access Main Menu VIERA Link Picture select Sound Setup 0 VCR 4 VCR Setup Menu DVB Profile Edit DVB Service List Analogue Service List Link Settings Child Lock Tuning Menu Off Timer Language Teletext TEXT STTL INDEX HOLD REC Select “DVB Profile Edit”, “DVB Service List” or “Analogue Service List” DVD PROGRAMME TV Ŷ To return to TV EXIT 28 5 Set 1/3 Access Access Access Off TOP access select Create your favourite programme list (Profile) from various broadcasters (up to 4: Profile 1 to 4). The list is added to “Category” in Programme Guide (p. 17) and information banner (p. 15) and then easily accessed. Select a programme and add it to the list Profile Editor Wed 12/05/04 10:46 All DVB Services 1 7 14 70 72 105 719 720 List favourite programmes DVB Profile Edit (DVB mode) green Profile 1 BBC One Wales BBC THREE E4 CBBC Channel Cartoon Nwk BBCi BBC Radio Wales BBC Radio Cymru Profile Editor To change the category To display another Profile yellow A programme is added Ŷ To edit Profile Select the field of Profile to edit and: RETURN • • • • Select the character red To move the programme green To delete the programme yellow To delete all programmes blue Select the new position Confirm green You can hide unwanted services. The deleted services cannot be displayed except in this function. Use this function to skip unwanted programmes. “DVB Service List” is listed all tuned DVB programmes in DVB mode. “Analogue Service List” is listed all tuned Analogue programmes in Analogue mode. •• Select a service and add / delete 70 72 105 719 720 1 7 CBBC Channel Cartoon Nwk BBCi BBC Radio Wales BBC Radio Cymru BBC ONE Wales BBC THREE • add / delete DVB Service List select To retune each programme (Manual Tuning) (p. 31) red :add :delete (skip) •• Select the programme to edit Programme position Name Analogue Service List Analogue Service List 1 BBC1 2 ***** 3 ***** 4 5 6 7 3 FTP select Coronation Street CH30 23:35 Advanced You can change the programme name and programme position for Analogue programmes. This function is available in Analogue mode. If a VCR is connected only with the RF cable, edit “VCR”. Edit analogue programmes (Change name, Move) Editing Programmes Analogue Service List To add all programmes to the list 1 BBC One Wales • DVB Service List • select Profile 1 BBC One Wales BBC THREE E4 CBBC Channel Cartoon Nwk BBCi BBC Radio Wales BBC Radio Cymru blue red To name the Profile Skip unwanted programmes Wed 12/05/04 10:46 All DVB Services 1 7 14 70 72 105 719 720 All Analogue Services Change category Edit Ŷ To change the name displayed when selecting programmes Select “Rename” Set characters Store select Edit Service Name RETURN Name green A U a u set B V b v C W c w D X d x E F G H I J K L M N O P Q R S T Y Z 0 1 2 3 4 5 6 7 8 9 ! : # e f g h i j k l m n o p q r s t y z ( ) + - . * _ (maximum: five characters) Ŷ To move the programme position Select new position yellow Store yellow select 29 Tuning Programmes You can retune all the TV programmes when moving house or search for new services which may have recently started broadcasting. INPUT EXIT 1 Select DVB or Analogue 2 Display the menu 3 Select “Setup” • • “DVB Manual Tuning”, “Add New DVB Services”, “New Service Message” and “DVB Signal Condition” are available in DVB mode only. “Analogue Manual Tuning” is available in Analogue mode only. MENU OK MENU RETURN access Main Menu VIERA Link Picture 1 2 3 4 5 6 7 8 9 0 VCR TV select Sound Setup 4 5 Ŷ To return to TV EXIT 6 Select “Tuning Menu” Setup Menu 1/3 DVB Profile Edit DVB Service List Link Settings Child Lock Tuning Menu Off Timer Language Teletext Teletext Character Set select Access Off TOP West Select a function access Tuning Menu Auto Setup DVB Manual Tuning Analogue Manual Tuning Add New DVB Services New Service Message DVB Signal Condition Access Access Access Access On Access Set Ŷ For Auto Setup, using the buttons on the front of the TV (p. 8) Press repeatedly until “Auto Setup” appears Access “Auto Setup” Start “Auto Setup” 30 access • To return to TV select Automatically retune all DVB or Analogue programmes received in the area. Only DVB programmes are retuned in DVB mode. Only Analogue programmes are retuned in Analogue mode. If a Child Lock PIN number (p. 32) has been set, it must be entered. Set all DVB or Analogue programmes automatically •• •Start Auto Setup Settings are made automatically Auto Setup - Digital Auto Setup Scan All digital tuning data will be erased EXIT Start Auto Setup 5 RETURN Auto Setup Free TV: 4 Pay TV: 0 Type Free TV Free TV Free TV Free TV Radio: 0 Searching •• •• Set DVB programme manually 69 This will take about 3 minutes. Channel Service Name 62 CBBC Channel 62 BBC Radio Wales 62 E4 62 Cartoon Nwk Quality 10 10 10 10 Data: 0 All the previous tuning settings are erased. The programme, language, country / region settings are downloaded to a Q-Link or VIERA Link compatible equipment connected to the TV. When the operation is completed, the programme at programme position “1” will be displayed. If tuning has not been done completely “DVB Manual Tuning”, “Analogue Manual Tuning” Normally use “Auto Setup” or “Add New DVB Services” to add DVB programmes to your service list. If tuning has not been done completely or for adjusting the direction of the aerial, use this function. select channel DVB Manual Tuning Frequency Signal Quality Analogue Scan Signal Strength Prog. Service Name 474,00 MHz [CH21] 0 21 0 Type New DVB Manual Tuning Pay TV: 0 Radio: 0 Stopped • Data: 0 All services found will be added to the DVB Service List. • Free TV: 0 adjust frequency (set where the level of “Signal Quality” becomes the maximum) search 1068 10 Use to make small adjustments to the tuning of an individual programme (affected by weather conditions, etc.) Ŷ Manual Tuning Set Analogue programme manually Analogue Manual Tuning Set Analogue programme manually after Auto Setup. Set Sound System and Colour System, and then perform this function. Normally set Colour System “Auto”. If a VCR is connected only with the RF cable, select programme position “0”. • • Analogue Manual Tuning 1 BBC1 Fine Tuning Manual Tuning Sound System Colour System SC1: PAL B, G, H / SECAM B, G SC2: PAL I SC3: PAL D, K / SECAM D, K F: SECAM L / L’ Select the programme Search and store CH33 2 78 1 41 CH33 SC1 Auto Select the programme position 1 2 3 4 5 6 7 8 9 Tuning Programmes Ŷ Fine Tuning search store 0 VCR Add New DVB Services Display a notification message Any new services found will be added to the DVB Service List. Add New DVB Services Scan Analogue Scan 5 21 69 68 This will take about 3 minutes. Channel Service Name Free TV: 0 Pay TV: 0 Type Radio: 0 Searching Quality • The new service is added with the current settings saved as they are. Advanced Add DVB programme automatically Data: 0 Selects whether to give a notification message when a new DVB service is found. (Off / On) New DVB service found! Press OK to add new service. Press EXIT to lgnore. New Service Message Selects a programme and checks the DVB signal condition. To change the programme Check DVB signal DVB Signal Condition • DVB Signal Condition DVB Programme [CH70] CBBC Channel 0 10 Signal Quality 0 10 Signal Strength A good Signal Strength is not an indication of suitable signal for DVB reception. Please use the Signal Quality indicator as follows: Signal Quality: Green bar Good Yellow bar Poor Red bar Bad (Check the aerial) •• • 31 Control Programme Audience You can lock specific programmes / AV input terminals and control who watches them. (When the locked programme / input is selected, a message appears; by entering the PIN number, you can watch it.) 1 Display the menu 2 Select “Setup” MENU INPUT GUIDE EXIT OK MENU RETURN access Main Menu VIERA Link Picture ASPECT select Sound OPTION DIRECT TV REC Setup 1 2 3 4 5 6 7 8 9 3 0 VCR TEXT STTL INDEX HOLD REC VCR Select “Child Lock” Setup Menu access 1/3 DVB Profile Edit DVB Service List Link Settings Child Lock Tuning Menu Off Timer Language Teletext Teletext Character Set select Access Off TOP West DVD Ŷ To return to TV 4 EXIT Set Enter the PIN number (4 digits) Child Lock-PIN Entry Please enter new PIN PIN 1 of 2 * * * * 1 2 3 4 5 6 8 9 7 • • 0 VCR Enter the PIN number twice at first setting. Make a note of the PIN number in case you forget it. Select “Child Lock List” access Child Lock Change PIN Child Lock List Control programme audience Access select Select the programme / input to be locked Child Lock List - Services and AV Name 1 BBC One Wales 7 BBC THREE 14 E4 VCR 1 BBC1 2 ***** AV1 AV2/S Child Lock Wed 12/05/04 10:46 Type Free TV Free TV Free TV Analogue Analogue Analogue AV AV set Lock select Appears when the programme / input is locked Ŷ To change the PIN number Select “Change PIN” in • 32 • • • To cancel Select the locked programme / input To lock all yellow To cancel all locks and enter a new PIN number twice. Note Setting “Shipping Condition” (p. 33) erases the PIN number and all settings. blue Restore Settings Resets the TV to its original condition, i.e. no programmes tuned in. All settings (programmes, picture, sound quality, etc.) are reset. 1 Display the menu 2 Select “Setup” MENU INPUT GUIDE EXIT OK MENU RETURN OPTION DIRECT TV REC VIERA Link • ASPECT access Main Menu 2 3 4 5 6 7 8 9 Setup 3 0 VCR TEXT STTL INDEX HOLD REC VCR select Sound DVD PROGRAMME Ŷ To return to TV 4 EXIT • 1 Select “Shipping Condition” Setup Menu Shipping Condition Common Interface System Update Power Save Side Panel Picture Overscan Input Labels Banner Display Timeout Time Zone 2/3 access Access Off Off On select 3 seconds Auto Set Shipping Condition Shipping Condition Advanced Check the message and initialise Restore Settings Restore Settings Control Programme Audience Picture All tuning data will be erased Are you sure? Are you sure? Confirm EXIT RETURN Follow the on-screen instructions • “Auto Setup” will automatically start when Mains power On / Off switch is next turned On. (p. 12) Ŷ To retune TV programmes only, e.g. after moving house “Auto Setup” (p. 31) 33 Input Labels For easier identification and selection of the input mode, you can label each input terminals or skip terminal that is not connected to any equipment. To select the input mode p. 20 • 1 Display the menu 2 Select “Setup” MENU INPUT GUIDE EXIT OK MENU RETURN access Main Menu VIERA Link Picture ASPECT select Sound OPTION DIRECT TV REC Setup 1 2 3 4 5 6 7 8 9 0 VCR 3 Select “Input Labels” Setup Menu Shipping Condition Common Interface System Update Power Save Side Panel Picture Overscan Input Labels Banner Display Timeout Time Zone TEXT STTL INDEX HOLD REC VCR DVD 2/3 Off Off On Access 3 seconds Auto access select PROGRAMME TV Ŷ To return to TV 4 Select a input terminal and set Input Labels AV1 AV2/S AV3/S COMPONENT HDMI1 HDMI2 EXIT DVD AV2/S AV3/S COMPONENT HDMI1 HDMI2 set select The labels you set will be displayed in “Input Selection” menu (p. 20) or banner. If “Skip” is selected, you cannot select the mode. • 34 Ŷ User input You can name each input terminals freely. Select “User input” Set characters select select access Store User input RETURN Name set A U a u B V b v C W c w D X d x E F G H I J K L M N O P Q R S T Y Z 0 1 2 3 4 5 6 7 8 9 ! : # e f g h i j k l m n o p q r s t y z ( ) + - . * _ (maximum: ten characters) • Input Labels Advanced 35 Q-Link ( Link Functions VIERA Link) Q-Link connects the TV and DVD Recorder / VCR, and enables easy recording, playback, etc. (p. 37) VIERA Link (HDAVI ControlTM) connects the TV and the equipment with VIERA Link function, and enables easy control, convenient recording, playback, etc. (p. 38 - 41) You can use Q-Link and VIERA Link functions together. Ŷ Summary of Q-Link and VIERA Link functions Connection Features Q-Link (SCART connection) Preset download Easy playback Power on link Power off link Speaker control Control the menu of the connected equipment by VIERA remote control Direct TV Recording Pause Live TV programme VIERA Link (HDMI connection only) VIERA Link (SCART and HDMI connection) - O∗∗ O O O O O O O O O - O∗ O∗ O O O O :Available with the equipment which has “HDAVI Control 2” or “HDAVI Control 3” function. :Available with the equipment which has “HDAVI Control 3” function. O O∗∗ O∗∗ Connections Read the manual of the equipment, too. Ŷ Q-Link SCART cable • • • DVD Recorder / VCR with Q-Link function Connect the DVD Recorder / VCR supporting Q-Link to the TV’s AV1 or AV2 terminal via a fully wired SCART cable. Ŷ VIERA Link HDMI cable SCART cable Use fully wired SCART cable. HDMI cable Use fully wired HDMI compliant cable. Non-HDMI-compliant cables cannot be utilized. Recommended Panasonic’s HDMI cable part number: • RP-CDHG10 (1.0 m) • RP-CDHG15 (1.5 m) • RP-CDHG20 (2.0 m) • RP-CDHG30 (3.0 m) • RP-CDHG50 (5.0 m) DIGA Recorder / HD Video Camera with VIERA Link function SCART cable • • For Speaker control (Home Cinema) • Connect the equipment supporting VIERA Link to the TV’s AV1, AV2, HDMI1 or HDMI2 terminals via fully wired SCART and HDMI cables together. Some functions are available only with HDMI cable connection. But use both HDMI and SCART cables to support many features normally. To use Amplifier Speaker system HDMI cable RCA cable HDMI cable 36 To use Player theatre HDMI cable Amplifier with VIERA Link function HDMI cable SCART cable HD Video Camera with VIERA Link function • DIGA Recorder with VIERA Link function RCA cable Speaker system Player theatre with VIERA Link function Q-Link Ŷ Preparations • •• •• Connect the DVD Recorder / VCR with the following logos: “Q-Link”, “NEXTVIEWLINK”, “DATA LOGIC”, “Easy Link”, “Megalogic” or “SMARTLINK” Q-Link connection p. 36 Set up the DVD Recorder / VCR. Read the manual of the equipment. Q-Link terminal setup in Setup Menu “Q-Link” (p. 25), “AV1 / AV2 out” (p. 25) Download preset - programme, language, country / region setting (Preset download) “Download” (p. 25) or “Auto Setup” (p. 31) or “Auto Setup” - when first using the TV (p. 12) Ŷ Features available Some recorders are not applicable. Read the manual of the recorder. Recording the current programme in DVD Recorder / VCR immediately. • INPUT GUIDE DIRECT TV REC OK RETURN What you see is What you record 1 2 3 4 5 6 7 8 9 0 VCR TEXT STTL INDEX HOLD REC VCR DVD • • • • How to record TV monitor out Recorder’s tuner TV monitor out Recorder Recorder’s tuner - Recorder’s external input - TV monitor out When Direct TV Recording is performed, the recorder is automatically turned on if it is in Standby mode. Changing programme or turning off the TV is available while the recorder is recording from its own tuner. Changing programme is not available while the recorder is recording from the TV tuner. Turning off the TV will stop the recording if the recording from an AV source connected to the TV. Ŷ To stop recording GUIDE EXIT Information / Message Recording information or if recording is not possible, a message is displayed. Power on link and Easy playback Set Power on Link “Set” in Setup Menu to use this function “Power on Link” (p. 25) When DVD Recorder / VCR starts playback or direct navigator / function menu for the equipment are activated, the TV is turned on and input mode is switched automatically so that you can view the content. (Only when TV is in Standby mode.) Power off link Set Power off Link “Set” in Setup Menu to use this function “Power off Link” (p. 25) When TV is set to Standby mode, the recorder is also automatically set to Standby. (Only when the videocassette or DVD is not active.) Advanced PROGRAMME • “DATA LOGIC” (a trademark of Metz Corporation) • “Easy Link” (a trademark of Philips Corporation) • Direct TV Recording - OPTION DIRECT TV REC DVB AV (watching recorder’s tuner) AV (watching recorder’s external input) AV (watching TV’s external input) Using tuner TV Recorder TV Link Functions (Q-Link / VIERA Link) ASPECT Current mode Analogue EXIT MENU Available conditions: • “Megalogic” (a trademark of Grundig Corporation) • “SMARTLINK” (a trademark of Sony Corporation) 37 Q-Link ( Link Functions VIERA Link) VIERA Link “ ControlTM” Enjoy additional HDMI Inter-Operability with Panasonic products which have “HDAVI Control” function. This TV supports “HDAVI Control 3” function. Connections to the equipment (DIGA Recorder, HD Video Camera, Player theatre, Amplifier, etc.) with HDMI and SCART cables allow you to interface them automatically. These features are limited to models incorporating “HDAVI Control” and “VIERA Link”. • • Some functions are not available depending on the equipment’s version of HDAVI Control. Please confirm the connected equipment’s version of HDAVI Control. VIERA Link “HDAVI Control”, based on the control functions provided by HDMI which is an industry standard known as HDMI CEC (Consumer Electronics Control), is a unique function that we have developed and added. As such, its operation with other manufacturers’ equipment that supports HDMI CEC cannot be guaranteed. Please refer to individual manuals for other manufacturers’ equipment supporting VIERA Link function. About applicable Panasonic equipment, consult your local Panasonic dealer. Ŷ Preparations •• •• • •• Connect the equipment supporting VIERA Link. VIERA Link connection p. 36 Set up the connected equipment. Read the manual of the equipment. For optimal recording, the settings of the recorder might be required. For details, read the manual of the recorder. Download preset - programme, language, country / region setting (Preset download) “Download” (p. 25) or “Auto Setup” (p. 31) or “Auto Setup” - when first using the TV (p. 12) Set VIERA Link On in Setup Menu “VIERA Link” (p. 25) Set up the TV After connection, turn the equipment on and then switch the TV on. Select the input mode to HDMI1 or HDMI2 (p. 20), and make sure that an image is displayed correctly. This setup should be done each time when the following conditions occur: • for the first time • when adding or reconnecting equipment • when changing setup Ŷ Features available Easy playback Automatic Input switching - When the connected equipment is operated, input mode is switched automatically. When it is stopped operating, input mode is returned. Power on link Set Power on Link “Set” in Setup Menu to use this function “Power on Link” (p. 25) When the connected equipment starts playback or direct navigator / function menu for the equipment are activated, the TV is automatically turned on. (Only when TV is in Standby mode.) Power off link 38 Set Power off Link “Set” in Setup Menu to use this function “Power off Link” (p. 25) When TV is set to Standby mode, the connected equipment is also automatically set to Standby. • This function will work even if the TV enters standby mode automatically by Off Timer function or auto power standby function. Ŷ Features available (Using VIERA Link Menu) You can pause the live TV programme and resume later. • •• Access and pause the live TV programme This function is available with DIGA Recorder which has HDD and “HDAVI Control 3” function. Connect DIGA Recorder with both HDMI and SCART cables to use this function. If you cannot operate, check the settings and the equipment “Preparations” (p. 38) Display “VIERA Link Menu” INPUT Pause Live TV programme HDAVI Control 3 and Recorder with HDD ( ) GUIDE EXIT Select “Pause Live TV” and pause pause VIERA Link Menu OK MENU ASPECT Pause Live TV Pause Live TV Direct TV Rec VIERA Control SpeakerLink Selection Speaker Selection RETURN OPTION DIRECT TV REC 3 4 5 6 7 8 9 0 Live TV programme is recorded on HDD from where it was paused. Ŷ To resume (stop pause) resume Select “Pause Live TV” and access About the operations after resuming, read the manual of the equipment. select • • 2 select Ŷ To return to Live TV VCR (cancel pause or resumed playback) TEXT STTL INDEX HOLD • (change the input mode) If you cancel pause or resumed playback, the recorded programme will be deleted from HDD. Recording the current programme in DIGA Recorder immediately. This function is available with DIGA Recorder which has “HDAVI Control 3” function. Connect DIGA Recorder with both HDMI and SCART cables to use this function. If you cannot operate, check the settings and the equipment “Preparations” (p. 38) Changing programme or turning off the TV is available while the recorder is recording from its own tuner. Changing programme is not available while the recorder is recording from the TV tuner. Turning off the TV will stop the recording if the recording from an AV source connected to the TV. Display “VIERA Link Menu” INPUT Direct TV Recording What you see is What you record (HDAVI Control 3) Direct TV Rec GUIDE EXIT Select “Direct TV Rec” and start recording MENU ASPECT Pause Live TV Direct TV Rec VIERA Control SpeakerLink Selection Speaker Selection RETURN OPTION DIRECT TV REC 1 2 3 4 5 6 7 8 0 VCR start VIERA Link Menu OK Start Recorder Home Cinema Home Cinema • Ŷ To stop recording You can also start recording directly Advanced •• •• •• Link Functions (Q-Link / VIERA Link) 1 • Access Start Recorder Home Cinema Home Cinema select DIRECT TV REC Select “Stop” in “Direct TV Rec” and access VIERA Link Menu Pause Live TV Direct TV Rec VIERA Control SpeakerLink Selection Speaker Selection 9 • Stop Recorder Home Cinema Home Cinema select stop You can also stop recording directly. GUIDE EXIT 39 Q-Link ( Link Functions VIERA Link) Ŷ Features available (Using VIERA Link Menu) You can control some functions of the connected equipment with this TV remote control (point the remote control at the TV’s signal receiver). • •Access and operate the menu of the equipment This function is available with the equipment which has “HDAVI Control 2” or “HDAVI Control 3” function. If you cannot operate, check the settings and the equipment “Preparations” (p. 38) Display “VIERA Link Menu” INPUT GUIDE EXIT Select “VIERA Link Control” OK VIERA Link Menu MENU ASPECT Pause Live TV Direct TV Rec VIERA Control SpeakerLink Selection Speaker Selection RETURN Start Recorder Home Cinema Home Cinema select OPTION DIRECT TV REC Select the equipment you want to access Control the menu of the connected equipment by VIERA remote control Control 2 (HDAVI HDAVI Control 3) VIERA Link Control 1 2 3 4 5 6 7 8 9 • “Home Cinema” means Player theatre, Recorder theatre and Amplifier. VIERA Link Menu Pause Live TV Direct TV Rec VIERA Control SpeakerLink Selection Speaker Selection 0 VCR Recorder / Player / Home Cinema / Video Camera The type of the connected equipment is displayed. Select the type of the equipment and access. Ŷ If you access the invalid equipment select access When the equipment with “HDAVI Control” function is connected The menu of the accessed equipment (Input mode will be changed automatically) VIERA Link Menu Pause Live TV Direct TV Rec VIERA Control SpeakerLink Selection Speaker Selection Start Recorder Home Cinema Home Cinema Start Recorder Home Cinema Home Cinema Recorder / Player / Home Cinema / Video Camera Operate the menu of the equipment • Available VIERA remote control buttons (depending on the connected equipment): The type of the connected equipment is displayed. But you cannot access it. Use its own remote control to operate the equipment. Move the cursor / select the menu Move the cursor / access / adjust Store / set / access When the equipment of other types or manufacturers is connected RETURN EXIT VIERA Link Menu Pause Live TV Direct TV Rec VIERA Control SpeakerLink Selection Speaker Selection Start Others Home Cinema Home Cinema OPTION Others “Others” is displayed. You cannot access it. Use its own remote control to operate the equipment. 40 red green yellow blue • Return to the previous menu Exit the menu Display the operation guide for the equipment / The same functions with the OPTION button of the equipment Access when the key words are displayed on colour bar About the operations for the equipment, read the manual of the equipment. Ŷ Features available (Using VIERA Link Menu) You can control the theatre speaker with this TV remote control (point the remote control at the TV’s signal receiver). • •Access and control the speaker volume This function is available with the Amplifier or Player theatre which has “HDAVI Control” function. If you cannot operate, check the settings and the equipment “Preparations” (p. 38) Display “VIERA Link Menu” INPUT GUIDE EXIT Select “Speaker Selection” OK MENU RETURN VIERA Link Menu Speaker Selection 1 2 3 4 5 6 7 8 9 Start Recorder Home Cinema Home Cinema select • Speaker control OPTION DIRECT TV REC Set to “Home Cinema” or “TV” set 0 VCR Ŷ Home Cinema TEXT STTL INDEX HOLD REC PROGRAMME DVD Amplifier or Player theatre will be automatically turned on if it is in Standby mode and the sound is from theatre speakers connected to the equipment. • • •• Volume up / down Mute The sound of TV speakers is mute. When the equipment is turned off, TV speakers will be active. Ŷ TV Advanced TV VCR Link Functions (Q-Link / VIERA Link) ASPECT Pause Live TV Direct TV Rec VIERA Control SpeakerLink Selection Speaker Selection TV speakers are active. •• •• • •• • • Note This function may not work properly depending on the connected equipment. Image or sound may not be available for the first few seconds when the playback starts. Image or sound may not be available for the first few seconds when Input mode is switched. Volume function will be displayed when adjusting the volume of the equipment. Easy playback is also available by using the remote control for Amplifier or Player theatre. Read the manual of the equipment. About HDMI cable for connecting Panasonic HD Video Camera, read the manual of the equipment. If more than one equipment of the same type are connected to the TV by HDMI cables, for example two DIGA Recorders to HDMI1 and HDMI2, VIERA Link will only be available for the lower terminal number, in this case HDMI1. “HDAVI Control 3” is the newest standard (current as of December, 2007) for HDAVI Control compatible equipment. This standard is compatible with conventional HDAVI equipment. To confirm this TV’s version of HDAVI Control “System Information” (p. 25) 41 External Equipment These diagrams show our recommendations for how to connect the TV to your various equipment. For other connections, consult the instructions for each piece of equipment, the table below, and the specifications (p. 50). (M3 stereo mini plug) AV3 AV1 RGB VIDEO AV2 RGB VIDEO S VIDEO COMPONENT AUDIO AUDIO IN OUT Y L L PB R R PR HDMI 1 (Viewing) HDMI 2 To watch DVDs (Listening) DVD player ŶTypes of connectable equipment to each terminal AV1 AV2 (with HDMI) (with HDMI) Terminal Recording / Playback (equipment) To record / playback videocassettes / DVDs (VCR / DVD recorder) To watch DVDs (DVD player) To watch camcorder images (Video camera) To watch satellite broadcasts (Set top box) To play games (Game equipment) To use amplifier with speaker system Q-Link VIERA Link Direct TV Recording 42 : Recommended Connection AV3 (Front of TV) Headphones Ŷ To adjust volume “Headphone Volume” in the Sound Menu (p. 24) Camcorder / Game equipment (S-VIDEO) or (VIDEO) RF cable (AUDIO) or To record / playback • SCART cable SCART cable Fully wired HDMI compliant cable HDMI equipment To watch satellite broadcasts Set top box “HDMI connection” (p. 44) External Equipment DVD Recorder / VCR To listen with speakers Fully wired HDMI compliant cable DVD Recorder Amplifier with speaker system COMPONENT AUDIO OUT Advanced RCA cable Y L L PB R PR R 1 2 43 Technical Information Auto Aspect The optimum size and aspect can be chosen, and you can enjoy finer images. (p. 16) Ŷ Auto Auto aspect determines the best aspect ratio to use to fill your screen. It does this using a four step process to determine if the picture being viewed is a widescreen picture. If Auto aspect detects a widescreen signal it switches into the appropriate 16:9 or 14:9 widescreen mode. If Auto aspect does not detect a widescreen signal then this advanced TV enhances the picture for optimum viewing pleasure. The text shown on the screen indicates how Auto aspect determined which ratio to use: “WIDE” appears in the top left of the screen if a widescreen identification signal (WSS) is found or a signal found through a SCART or HDMI terminal. Auto aspect switches to the appropriate 16:9 or 14:9 widescreen ratio. This function will also work in any aspect mode. “Auto” appears in the top left of the screen if black stripes above and below the picture are detected. Auto aspect chooses the best ratio and expands the picture to fill the screen. This process can take several minutes, depending on the darkness of the picture. SD Signal name PAL PAL 525/60 DVB M.NTSC NTSC (AV input only) 525(480)/60i 525(480)/60p 625(576)/50i 625(576)/50p 750(720)/50p 750(720)/60p 1125(1080)/50i 1125(1080)/60i 1125(1080)/50p 1125(1080)/60p 1125(1080)/24p TV O O - Aspect Control Signal Widescreen signal (WSS) Control signal through SCART (pin 8) or HDMI terminal AV1 AV2 AV3 COMPONENT AV1 AV2 HDMI1 HDMI2 O O O O O O O - - - - - O O O O O O O O O O O O O O O O O HD O O O O O O O O O O O - • • The ratio varies depending on the programme, etc. If the ratio is greater than the standard “16:9”, black bands may appear at the top and bottom of the screen. If the screen size looks unusual when a widescreen-recorded programme is played back on a VCR, adjust the tracking of the VCR. (See the VCR manual.) Note HDMI connection HDMI (high-definition multimedia interface) allows you to enjoy high-definition digital images and high-quality sound by connecting the TV and the equipment. HDMI-compatible equipment (1) with an HDMI or DVI output terminal, such as a DVD player, a set top box or a game equipment, can be connected to the HDMI terminal using an HDMI compliant (fully wired) cable. About connections, see “External Equipment” (p. 42). •• • •• •• •• • • • • 44 Note HDMI is the world’s first complete digital consumer AV interface complying with a non-compression standard. If the external equipment has only a DVI output, connect to the HDMI1 terminal via a DVI to HDMI adapter cable (2). When the DVI to HDMI adapter cable is used, connect the audio cable to the audio input terminal (HDMI1: use COMPONENT-AUDIO terminals). Audio settings can be made on the “HDMI1 Input” menu screen. (p. 24) Applicable audio signal sampling frequencies (2ch L.PCM): 48 kHz, 44.1 kHz, 32 kHz HDMI2 terminal is for digital audio signal only. Use with a PC is not assumed. If the connected equipment has an aspect adjustment function, set the aspect ratio to “16:9”. These HDMI connectors are “type A”. These HDMI connectors are compatible with HDCP (High-Bandwidth Digital Content Protection) copyright protection. An equipment having no digital output terminal may be connected to the input terminal of either “COMPONENT”, “S-VIDEO”, or “VIDEO” to receive analogue signals. The HDMI input terminal can be used with only the following image signals: 480i, 480p, 576i, 576p, 720p, 1080i and 1080p. Match the output setting of the digital equipment. For details of the applicable HDMI signals, see p. 46. (1): The HDMI logo is displayed on HDMI-compliant equipment. (2): Enquire at your local digital equipment retailer shop. Updating the software system (DVB mode) Update system software regularly to ensure that you have latest version software. If there is an update available, a notification banner is displayed when the service has the update information. To download new software, press “OK” Downloading (approx. 20 mins.) If you choose not to download, press “EXIT”. • Ŷ To update automatically Set “Auto Update Search in Standby” to “On” (p. 27) If there is a new version software being broadcast, the TV will download this automatically. The automatic updating sequence is carried out at 3:00 AM and 5:00 AM every night under the following conditions. Standby (TV turned Off with the remote control) Recording is not in progress. • Ŷ To update manually Perform “System Update Search Now” (p. 27) If there is an update available, a notification banner is displayed. To download new software, press “OK” Downloading (approx. 20 mins.) If you choose not to download, press “EXIT”. • • • Note During downloading, do not turn Off the TV or touch any buttons. (The TV is automatically activated after downloading is completed.) The message might be the notification beforehand. In this case, the schedule information (the date that the new version can be used) will appear. You can set the reservation for update. The update will not start when the TV is set to Off. SCART, S-VIDEO and HDMI terminal information Ŷ AV1 SCART terminal Ŷ AV2 SCART terminal (RGB, VIDEO, Q-Link) (RGB, VIDEO, S-VIDEO, Q-Link) Socket Earth CVBS out (video) CVBS earth Red in Red earth Green in Green earth Blue in Blue earth Audio out (L) Audio out (R) Socket Earth CVBS out (video) CVBS earth Red in, S.C. - in Red earth Green in Green earth Blue in Blue earth Audio out (L) Audio out (R) 21 19 17 15 13 11 9 7 5 3 1 20 18 16 14 12 10 8 6 4 2 Ŷ AV3 S-VIDEO 4 pin terminal CVBS in (video) RGB status earth Status RGB Earth -Q-Link data Status CVBS Audio in (L) Audio earth Audio in (R) Chrominance in Luminance in Chrominance earth Luminance earth 21 19 17 15 13 11 9 7 5 3 1 20 18 16 14 12 10 8 6 4 2 CVBS in (video) RGB status earth Status RGB Earth -Q-Link data Status CVBS Audio in (L) Audio earth Audio in (R) Ŷ HDMI terminal 18 16 14 12 10 8 6 4 2 +5V Power SDA Reserved (in cable but N.C. on device) TMDS Clockí TMDS Clock+ TMDS Data0 Shield TMDS Data1í TMDS Data1+ TMDS Data2 Shield FAQs, etc. Hot Plug Detect 19 DDC/CEC Ground 17 SCL 15 CEC 13 TMDS Clock Shield 11 TMDS Data0í 9 TMDS Data0+ 7 TMDS Data1 Shield 5 TMDS Data2í 3 TMDS Data2+ 1 Technical Information AV2 - Pins 15 and 20 are dependent on AV2 S-VHS / VIDEO switching. • Suitable inputs for AV1 include RGB (Red / Green / Blue). 45 Technical Information Input signal that can be displayed COMPONENT (Y, PB, PR), HDMI Mark: Applicable input signal Signal name 525 (480) / 60i 525 (480) / 60p 625 (576) / 50i 625 (576) / 50p 750 (720) / 60p 750 (720) / 50p 1,125 (1,080) / 60i 1,125 (1,080) / 50i 1,125 (1,080) / 60p 1,125 (1,080) / 50p 1,125 (1,080) / 24p •• 46 COMPONENT Note Signals other than above may not be displayed properly. The above signals are reformatted for optimal viewing on your display. HDMI FAQs Before requesting service or assistance, please follow these simple guides to resolve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. White spots or shadow images (noise) • Check the position, direction, and connection of the aerial. To customer using indoor aerial In order to enjoy a good quality DVB image, it is important to receive a good quality DVB signal. For this purpose check “DVB Signal Condition” in Tuning Menu (p. 31). A level of at least 5 is required in order to provide a good picture. It may be necessary to adjust the position and direction of the aerial to achieve the best possible result. Neither image nor sound is produced •• •• • Is the TV in “AV mode”? Is the mains lead plugged into the socket outlet? Is the TV turned On? Check Picture Menu (p. 24) and volume. Check all required SCART cables and connections are firmly in place. Auto aspect • Auto aspect is designed to provide you with the best aspect ratio to use to fill your screen. For user control please see p. 44. S-Video / black and white picture • You can simply clear these Press again to redisplay. No DVB programmes shown after Auto Setup •• • An error message appears •• Follow the message’s instructions. If the problem persists, contact the authorized Service Centre. “VIERA Link” function does not work and an error message appears •• Confirm the connection. Turn the connected equipment on and then switch the TV on. (p. 38) Recording does not start immediately • Check the settings of the recorder. For details, read the manual of the recorder. Permanently lit spots on screen • Due to production process involved in this technology this may result in some pixels which are permanently lit or unlit. This is not a malfunction. Contrast is reduced • Contrast is lowered in the following conditions without any user operation for a few minutes: Ɣ no signal in DVB or AV mode Ɣ selected locked programme Ɣ selected invalid programme Ɣ selected radio service Ɣ displayed menu FAQs, etc. Check the DVB transmitter. Adjust the direction of the aerial to another transmitter installed nearby. Check the analogue broadcast. If the image quality is poor, check the aerial and consult your nearest dealer. Please confirm SCART cable and connection. Also please set “AV1 / AV2 out” in the Setup Menu (p. 25). Frequently Asked Questions Technical Information On Screen messages - I.e. EC/AV1 • • • • Using AV button please confirm your selection is S-Video I.e. AV2/S (p. 20). Q-Link function does not work 47 FAQs Problem Chaotic image, noisy Screen No image can be displayed Blurry or distorted image (no sound or low volume) Unusual image is displayed No sound is produced Sound Sound level is low or sound is distorted Whirling sound is heard • Actions •• • • • • •• •• • Set “P-NR” in the Picture Menu (to remove noise). (p. 24) Check nearby electrical products (car, motorcycle, fluorescent lamp). Is “Colour” or “Contrast” in the Picture Menu set to the minimum? (p. 24) Check Colour System. (p. 31) Reset programme. (p. 31) Turn off the TV with Mains power On / Off switch, then turn it On again. Is “Sound mute” active? (p. 9) Is the volume set to the minimum? Sound signal reception may be deteriorated. Set “MPX” (p. 24) in the Sound Menu to “Mono”. (Analogue only) The sound is from built-in cooling fan (not a sign of faulty operation). Due to the digital reception technologies involved, quality of the DTV signals may be relatively low in some cases, despite good reception of analogue programmes. • Install an aerial individually for the TV and VCR (or use a splitter). TV (Individual aerial) DVB Unable to receive signals with a high-performance aerial Sound is unusual HDMI Pictures from external equipment are unusual when the equipment is connected via HDMI Other TV goes into “Standby mode” The remote control does not work Splitter Aerial Input terminal VCR Interference or frozen / disappearing image in DVB 48 Aerial Output • • • •• •• •• •• •• Aerial Input Aerial Output (Individual aerial) Check “DVB Signal Condition”. (p. 31) If “Signal Quality” or “Signal Strength” are displayed in red, check aerial. If problem persists, consult your local Panasonic dealer. Turn the TV off with the Mains power On / Off switch, then turn it On again. Set the sound setting of the connected equipment to “2ch L.PCM”. Check the “HDMI1 Input” setting in the Sound Menu. (p. 24) If digital sound connection has a problem, select analogue sound connection. (p. 44) Is the HDMI cable connected properly? (p. 42) Turn Off the TV and equipment, then turn them On again. Check an input signal from the equipment. (p. 46) Use an equipment compliant with EIA/CEA-861/861B. Off Timer function is activated. The TV enters “Standby mode” about 30 mins. after analogue broadcasting ends. Are the batteries installed correctly? (p. 6) Has the TV been switched On? Licence •• •• DVB is a trademark of the DVB Digital Video Broadcasting Project (1991 to 1996). HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. HDAVI ControlTM is a trademark of Matsushita Electric Industrial Co., Ltd. GUIDE Plus+ is (1) a registered trademark or trademark of, (2) manufactured under license from and (3) subject of various international patents and patent applications owned by, or licensed to, Gemstar-TV Guide International, Inc. and/or its related affiliates. GEMSTAR-TV GUIDE INTERNATIONAL, INC. AND/OR ITS RELATED AFFILIATES ARE NOT IN ANY WAY LIABLE FOR THE ACCURACY OF THE PROGRAM SCHEDULE INFORMATION PROVIDED BY THE GUIDE PLUS+ SYSTEM. IN NO EVENT SHALL GEMSTAR-TV GUIDE INTERNATIONAL, INC. AND/OR ITS RELATED AFFILIATES BE LIABLE FOR ANY AMOUNTS REPRESENTING LOSS OF PROFITS, LOSS OF BUSINESS, OR INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE PROVISION OR USE OF ANY INFORMATION, EQUIPMENT, OR SERVICES RELATING TO THE GUIDE PLUS+ SYSTEM. Trade Mark of the DVB Digital Video Broadcasting Project (1991 to 1996) TH-H42Z8A Declaration of Conformity No. 5793, 23 June 2008 • • Licence Frequently Asked Questions FAQs, etc. 49 Specifications Power Source AC 220-240 V, 50 / 60 Hz Power Display Sound Consumption panel Average use 385 W Standby condition 0.4 W (Without monitor out recording) 20 W (With monitor out recording) Aspect Ratio 16:9 106 cm (diagonal) Visible screen size 922 mm (W) × 518 mm (H) Number of pixels 2,073,600 (1,920 (W) × 1,080 (H)) [5,760 × 1,080 dots] Speaker 160 mm × 42 mm × 2 pcs, 8 : Audio Output 20 W (10 W + 10 W), 10% THD Headphones M3 (3.5 mm) stereo mini Jack × 1 PAL B, G, H, I, SECAM B, G, SECAM L / L’ VHF E2 - E12 VHF H1 - H2 (ITALY) VHF A - H (ITALY) UHF E21 - E69 CATV (S01 - S05) CATV S1 - S10 (M1 - M10) CATV S11 - S20 (U1 - U10) CATV S21 - S41 (Hyperband) PAL D, K, SECAM D, K Receiving Systems / VHF R1 - R2 VHF R3 - R5 Band name VHF R6 - R12 UHF E21 - E69 PAL 525/60 Playback of NTSC tape from some PAL Video recorders (VCR) DVB Digital terrestrial services via VHF / UHF aerial input. M.NTSC Playback from M. NTSC Video recorders (VCR) NTSC (AV input only) Playback from NTSC Video recorders (VCR) TV signals may not be received in some areas. Aerial - Rear VHF / UHF Temperature : 0 °C - 35 °C Operating Conditions Humidity : 20 % - 80 % RH (non-condensing) AV1 (Scart terminal) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, Q-Link) AV2 (Scart terminal) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, S-Video in, Q-Link) VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 :) AV3 S-VIDEO Mini DIN 4-pin Y:1.0 V[p-p] (75 :) C:0.286 V[p-p] (75 :) AUDIO L - R RCA PIN Type × 2 0.5 V[rms] Y 1.0 V[p-p] (including synchronization) VIDEO ±0.35 V[p-p] PB, PR COMPONENT AUDIO L - R RCA PIN Type × 2 0.5 V[rms] This TV supports “HDAVI Control 3” function. HDMI1 / 2 TYPE A Connectors AUDIO L - R RCA PIN Type × 2 0.5 V[rms] (high impedance) Output 1,048 mm × 727 mm × 327 mm (With Pedestal) Dimensions ( W × H × D ) 1,048 mm × 679 mm × 95 mm (TV only) 32.0 k Net (With Pedestal) Mass 30.0 k Net (TV only) • Connection Terminals •• • 50 • Note Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate. This equipment complies with the EMC standards listed below. EN55013, EN61000-3-2, EN61000-3-3, EN55020. Pedestal: ST-42R4-WG (For safety approval) MEMO • Specifications FAQs, etc. 51 Information for Users on Collection and Disposal of Old Equipment and used Batteries These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries should not be mixed with general household waste. For proper treatment, recovery and recycling of old products and used batteries, please take them to applicable collection points, in accordance with your national legislation and the Directives 2002/96/EC and 2006/66/EC. By disposing of these products and batteries correctly, you will help to save valuable resources and prevent any potential negative effects on human health and the environment which could otherwise arise from inappropriate waste handling. For more information about collection and recycling of old products and batteries, please contact your local municipality, your waste disposal service or the point of sale where you purchased the items. Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation. For business users in the European Union If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information. [Information on Disposal in other Countries outside the European Union] These symbols are only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal. Note for the battery symbol (bottom two symbol examples): This symbol might be used in combination with a chemical symbol. In this case it complies with the requirement set by the Directive for the chemical involved. Customer’s Record The model number and serial number of this product may be found on its rear panel. You should note this serial number in the space provided below and retain this book, plus your purchase receipt, as a permanent record of your purchase to aid in identification in the event of theft or loss, and for Warranty Service purposes. Model Number Serial Number Matsushita Electric Industrial Co., Ltd. Web Site : http://www.panasonic-europe.com ¤ 2008 Matsushita Electric Industrial Co., Ltd. All Rights Reserved. Printed in Czech Republic
