Table of Contents
Chapter 1
Product Overview
Introduction
Key Features
Deploy and manage with ease using C-Series Wireless Management Switches.
Internal 5dBi Omni-Directional MIMO antennas optimized for maximum RF performance.
Backward compatible with IEEE802.11a/b/g/n wireless devices.
Integrated Power over Ethernet (IEEE802.3af/at) for lowering deploying costs. Can be powered using either the included power adapter or via PoE with PoE 802.3af/at capable Switches or Injectors.
Band Steering to load balance clients between 2.4GHz and 5 GHz for better throughput performance.
1
Secured Guest Network.
Stylish low profile design with easy ceiling mounting kit.
Note: 1
Feature available only for dual band models.
Introduction
This device is an enhanced-powered, long-range wireless access point. It is designed to operate in numerous environments; from large homes, small and medium-sized businesses, multiple-floor offices, hotels, and other venues, to larger enterprise deployments. Its enhanced-powered, long-range characteristics make it a cost-effective alternative to ordinary Access Points that don’t have the range and reach to connect to a growing number of wireless users who wish to connect to a large hotspot or business network.
To protect sensitive data during wireless transmissions, the device offers different encryption settings for wireless transmissions, including industry standard WPA and WPA2 encryption. The device also includes MAC address filtering to allow network administrators to offer network access only to known computers and other devices based on their MAC addresses.
System Requirements
The following are the Minimum System Requirements in order to configure the device:
Computer with an Ethernet interface or wireless network capability
Windows OS (XP, Vista, 7, 8), Mac OS, or Linux-based operating systems
Web-Browsing Application (i.e. : Internet Explorer, Firefox, Chrome, Safari, or another similar browser application)
Package Contents
The package contains the following items (all items must be in package to issue a refund):
ALLNET Indoor Access Point
Power Adapter
RJ-45 Ethernet Cable
Quick Installation Guide
Ceiling and Wall Mount Screw kit
Applications
Wireless LAN (WLAN) products are easy to install and highly efficient. The following list describes some of the many applications made possible through the power and flexibility of WLANs:
Difficult-to-Wire Environments: There are many situations where wires cannot be installed, deployed easily, or cannot be hidden from view. Older buildings, sites with multiple buildings, and/or areas that make the installation of a Ethernet-based
LAN impossible, impractical or expensive are sites where WLAN can be a network solution.
Temporary Workgroups: Create temporary workgroups/networks in more open areas within a building; auditoriums, amphitheaters classrooms, ballrooms, arenas, exhibition centers, or temporary offices where one wants either a permanent or temporary Wireless LAN established.
The Ability to Access Real-Time Information: Doctors/Nurses, Point-of-Sale Employees, and/or Warehouse Workers can access real-time information while dealing with patients, serving customers, and/or processing information.
Frequently Changing Environments: Set up networks in environments that change frequently (i.e.: Show Rooms, Exhibits, etc.).
Small Office and Home Office (SOHO) Networks: SOHO users require a cost-effective, easy, and quick installation of a small network.
Training/Educational Facilities: Training sites at corporations or students at universities use wireless connectivity to exchange information between peers and easily access information for learning purposes.
Technical Specifications
Wi-Fi Standard
2.4GHz
5GHz
Radio Chains / Streams
Max Data Rate
2.4GHz
5GHz
Interface
LED Indicator
PoE Support
Power Requirement
Environment
Dimensions
ALL-WAPC0435AC
IEEE 802.11b/g/n
IEEE 802.11a/n/ac
2x2:2
300 Mbps
867 Mbps
1 x 10/100/1000 Gigabit Ethernet Port
1 x Reset Button
1 x Power Connector
Power, WLAN, LAN, Mesh
IEEE802.3at
External Power Adapter
DC IN, 12V/2A
Operating:
Temperature: 32°F to 104°F (0°C to 40°C)
Humidity (Non-condensing): 90% or less
Storage:
Temperature: -4°F to 140°F (-20°C to 60°C)
Humidity (Non-condensing): 90% or less
161.5 x 41.5mm
Physical Interface
1.
Reset Button: Press and hold for over 10 seconds to reset to factory default settings.
2.
LED Indicators: LED lights for Mesh, WLAN 5GHz, WLAN 2.4GHz, LAN, and Power
3.
LAN Port (802.3at PoE): Ethernet port for RJ-45 cable.
4.
Power Connector: 12V DC IN for Power Adapter.
5.
Ceiling (Wall) Mount Hole: Using the provided mounting kit, the Access Point can be attached to a ceiling or wall.
6.
Kensington Security Slot: To protect your Access Point, use the Kensington Security Slot to attach a cable lock.
Chapter 2
Before You Begin
Before You Begin
This section will guide you through the installation process. Placement of the ALLNET Access Point is essential to maximize the
Access Point’s performance. Avoid placing the Access Point in an enclosed space such as a closet, cabinet, or stairwell.
Considerations for Wireless Installation
The operating distance of all wireless devices can often not be pre-determined due to a number of unknown obstacles in the environment in which the device is deployed. Obstacles such as the number, thickness, and location of walls, ceilings, or other objects that the Access Point
’s wireless signals must pass through can weaken the signal. Here are some key guidelines for allowing the Access Point to have an optimal wireless range during setup.
Keep the number of walls and/or ceilings between the Access Point and other network devices to a minimum. Each wall and/or ceiling can reduce the signal strength, resulting in a lower overall signal strength.
Building materials make a difference. A solid metal door and/or aluminum stubs may have a significant negative effect on the signal strength of the Access Point. Locate your wireless devices carefully so the signal can pass through drywall and/or open doorways. Materials such as glass, steel, metal, concrete, water (example: fish tanks), mirrors, file cabinets, and/or brick can also diminish wireless signal strength.
Interference from your other electrical devices and/or appliances that generate RF noise can also diminish the Access Point
’ s signal strength. The most common types of devices are microwaves or cordless phones.
Computer Settings
Windows XP/Windows 7
In order to use the Access Point, you must first configure the TCP/IPv4 connection of your Windows OS computer system.
1. Click the
Start button and open the
Control Panel
.
Windows XP
2a. In Windows XP , click on Network Connections.
Windows 7
2b. In
Windows 7
, click
View network status and tasks in the
Network and Internet section, then select
Change adapter settings.
3.
Right click on Local Area Connection and select Properties .
4.
Select
Internet Protocol Version 4 (TCP/IPv4) and then select
Properties
.
5.
Select
Use the following IP address and enter an IP address that is different from the
Access Point and Subnet mask, then click
OK
.
Note
: Ensure that the IP address and Subnet mask are on the same subnet as the device.
For example: Access Point IP address: 192.168.1.1
PC IP address: 192.168.1.2 – 192.168.1.255
PC Subnet mask: 255.255.255.0
Apple Mac OS X
1.
Go to
System Preferences
(it can be opened in the
Applications folder or by selecting it in the Apple Menu).
2.
Select
Network in the
Internet & Network section.
3.
Highlight Ethernet .
4.
In Configure IPv4 , select Manually .
5.
Enter an IP address that is different from the Access Point and
Subnet mask, then click OK .
Note: Ensure that the IP address and Subnet mask are on the same subnet as the device.
For example: Access Point IP address: 192.168.1.1
PC IP address: 192.168.1.2 – 192.168.1.255
PC Subnet mask: 255.255.255.0
6.
Click Apply when finished.
Hardware Installation
1.
Ensure that the computer in use has an Ethernet Controller port (RJ-45 Ethernet Port). For more information, verify with your computer’s user manual.
2.
Connect one end of the Category 5e Ethernet cable into the RJ-45 port of the Access Point and the other end to the RJ-45 port of the computer. Ensure that the cable is securely connected to both the Access Point and the computer.
3.
Connect the Power Adapter DC connector to the DC-IN port of the Access Point and the Power Adapter to an available electrical outlet. Once both connections are secure, verify the following: a) Ensure that the POWER light is on (it will be orange ). b) Ensure that the 2.4 GHz/5 GHz WLAN light is on (it will be blue for 2.4G, and green for 5G). c) Ensure that the LAN (Computer/ Access Point Connection) light is on (it will be blue ). d) Once all three lights are on, proceed to set up the Access Point using the computer.
Mounting the Access Point
Using the provided hardware, the Access Point can be attached to a ceiling or wall.
To attach the Access Point to a ceiling or wall using the mounting bracket:
1.
Attach the mounting bracket to the wall or ceiling using the provided wall/ceiling mounting hardware kit.
2.
Insert the provided short screws into the bottom cover of the Access Point.
Leave enough of the screws exposed to ensure that the unit can be attached to the mounting bracket.
If extra space is required, use the provided spacers and long screws from the T-Rail mounting hardware kit to increase the space between the unit and the mounting bracket.
3.
Mount the Access Point on the mounting bracket by rotating the unit clockwise about 90 degrees to secure it in place.
Attaching the Access Point to a ceiling using the provided T-Rail connectors:
1.
Attach the T-Rail connectors to the bottom cover of the Access Point using the provided short screws.
Note: Two sizes of T-Rail connectors are included in the mounting hardware kit: 15/16in (2.38cm) and 9/16in (1.43cm). If extra space is required to accommodate drop ceiling tiles, use the provided spacers and long screws.
2.
Line up the connected T-Rail connectors with an appropriately sized rail and press the unit onto the rail until it snaps into place.
Note
: To protect your Access Point, use the Kensington Security Slot to attach a cable lock (cable lock is not included).
Chapter 3
Configuring Your Access Point
Configuring Your Access Point
This section will show you how to configure the device using the web-based configuration interface.
Default Settings
Please use your Ethernet port or wireless network adapter to connect the Access Point.
IP Address 192.168.1.1
Username/Password admin/admin
Web Configuration
1.
Open a web browser (Internet Explorer/Firefox/Safari) and enter the IP Address http://192.168.1.1.
Note : If you have changed the default LAN IP Address of the Access Point, ensure you enter the correct IP Address.
2.
The default username and password are: admin . Once you have entered the correct username and password, click the Login button to open the web-based configuration page.
4.If successful, you will be logged in and see the Access Point User Interface.
*Model name varies depending on model.
Chapter 4
Overview
Overview
The Overview section contains the following options:
• Device Status
• Connections
The following sections describe these options.
Device Status
Clicking the Device Status link under the Overview menu shows the status information about the current operating mode.
The
Device Information section shows general system information such as Device Name, MAC address, Current Time,
Firmware Version, and Management VLAN ID
The LAN Information section shows the Local Area Network settings such as the LAN IP Address, Subnet mask, Gateway,
DNS Address, DHCP Client, and STP status.
The
Wirelesss LAN Information 2.4 GHz/5GHz section shows wireless information such as Operating Mode, Frequency, and
Channel. Since the Access Point supports multiple-SSIDs, information about each SSID and security settings are displayed.
*Wireless LAN Information - 5GHz only available for 5GHz capable models.
Connections
Clicking the Connections link under the Device Status menu displays the list of clients associated to the Access Point ’s
2.4GHz/5GHz, along with the MAC address, TX, RX and signal strength for each client. Clicking Kick in the Block column removes this client.
Click Refresh to refresh the Connection List page.
Chapter 5
Network
Basic
This page allows you to modify the device’s IP settings and the Spanning Tree settings. Enabling Spanning Tree protocol will prevent network loops in your LAN network.
IPv4 Settings
IP Network Setting : Select whether the device IP address will use the static IP address specified in the IP Address field or be obtained automatically when the device connects to a DHCP server.
IP Address : The IP Address of this device.
IP Subnet Mask : The IP Subnet mask of this device.
Gateway : The Default Gateway of this device. Leave it blank if you are unsure of this setting.
Primary/Secondary DNS : The primary/secondary DNS address for this device.
IPv6 Settings
Link-Local Address : Check this if you want to use Link-Local Address.
IP Address : The IPv6 IP Address of this device.
Subnet Prefix Length : The IPv6 Subnet Prefix Length of this device.
Gateway : The IPv6 Default Gateway of this device. Leave it blank if you are unsure of this setting.
Primary / Secondary DNS : The primary / secondary DNS address for this device.
Spanning Tree Settings
Status : Enables or disables the Spanning Tree function.
Hello Time : Specify Bridge Hello Time, in seconds. This value determines how often the device sends handshake packets to communicate information about the topology throughout the entire Bridged Local Area Network.
Max Age : Specify Bridge Max Age, in seconds. If another bridge in the spanning tree does not send a hello packet for a long period of time, it is assumed to be inactive.
Forward Delay : Specifies Bridge Forward Delay, in seconds. Forwarding Delay Time is the time spent in each of the Listening and
Learning states before the Forwarding state is entered. This delay is provided so that when a new bridge comes onto a busy network, it analyzes data traffic before participating.
Priority : Specify the Priority Number. A smaller number has greater priority.
Save : Click Save to confirm the changes.
Chapter 6
2.4GHz & 5GHz Wireless
2.4GHz/5GHz SSID Profile
Under Wireless Settings , you can edit the SSID profile to fit your needs. Click Edit under the SSID you would like to make changes to.
Enable:
Check this option to enable this profile.
SSID:
Specifies the SSID for the current profile.
Security: Displays the Security Mode the SSID uses. You can click Edit to change the security mode. For more details, see the next section.
Hidden SSID:
Check this option to hide the SSID from clients. If checked, the SSID will not appear in the site survey.
Client Isolation:
Check this option to prevent communication between client devices.
VLAN Isolation:
Check this option to enable VLAN Isolation feature.
VLAN ID:
Specifies the VLAN ID for the SSID profile.
*5GHz settings only available for dual radio models.
Wireless Security
The Wireless Security section lets you configure the Access Point
’s security modes:
WEP, WPA-PSK, WPA2-PSK, WPA-PSK Mixed,
WPA-Enterprise, WPA2-Enterprise and WPA Mixed Enterprise.
It is strongly recommended that you use WPA2-PSK . Click on the Edit button under Wireless Settings next to the SSID to change the security settings.
WEP
Auth Type: Select Open System or Shared Key.
Input Type: ASCII: Regular Text (Recommended) or HEX: Hexadecimal Numbers (For advanced users).
Key Length: Select the desired option and ensure the wireless clients use the same setting. Your choices are: 64, 128, and 152-bit password lengths.
Default Key: Select the key you wish to be default. Transmitted data is ALWAYS encrypted using the Default Key; the other Keys are for decryption only. You must enter a Key Value for the Default Key.
Encryption Key: Enter the Key Value or values you wish to use. The default is none.
WPA-PSK/WPA2-PSK (Pre-Shared Key)
Encryption: Select the WPA/WPA2 encryption type you would like to use. Available options are Both, TKIP(Temporal Key Integrity
Protocol) and AES(Advanced Encryption Standard). Please ensure that your wireless clients use the same settings.
Passphrase: Wireless clients must use the same Key to associate the device. If using ASCII format, the Key must be from 8 to 63 characters in length. If using HEX format, the Key must be 64 HEX characters in length.
Group Key Update Interval:
Specify how often, in seconds, the Group Key changes.
WPA/WPA2-Enterprise
Encryption: Select the WPA/WPA2 encryption type you would like to use. Available options are Both, TKIP(Temporal Key Integrity
Protocol) and AES(Advanced Encryption Standard). Please ensure that your wireless clients use the same settings.
Group Key Update Interval: Specify how often, in seconds, the group key changes.
Radius Server:
Enter the IP address of the Radius server.
Radius Port:
Enter the port number used for connections to the Radius server.
Radius Secret:
Enter the secret required to connect to the Radius server.
Radius Accounting:
Enables or disables the accounting feature.
Radius Accounting Server:
Enter the IP address of the Radius accounting server.
Radius Accounting Port: Enter the port number used for connections to the Radius accounting server.
Radius Accounting Secret:
Enter the secret required to connect to the Radius accounting server.
Interim Accounting Interval:
Specify how often, in seconds, the accounting data sends.
Note:
802.11n does not allow WEP/WPA-PSK TKIP/WPA2-PSK TKIP security mode. The connection mode will automatically change from 802.11n to 802.11g.
Wireless MAC Filter
Wireless MAC Filter is used to allow or deny network access to wireless clients (computers, tablet PCs, NAS, smart phones, etc.) according to their MAC addresses. You can manually add a MAC address to restrict permission to access the Access Point. The default setting is: Disable Wireless MAC Filter.
ACL (Access Control List) Mode:
Determines whether network access is granted or denied to clients whose MAC addresses appear in the MAC address table on this page. Choices given are: Disabled, Deny MAC in the list, or Allow MAC in the list.
MAC Address:
Enter the MAC address of the wireless client.
Add:
Click
Add to add the MAC address to the MAC Address table.
Delete:
Deletes the selected entries.
Traffic Shaping
Traffic Shaping regulates the flow of packets leaving an interface to deliver improved Quality of Service.
Enable Traffic Shaping: Select to Enable or Disable Wireless Traffic Shaping.
Download Limit: Specifies the wireless transmission speed used for downloading.
Upload Limit: Specifies the wireless transmission speed used for uploading.
Save: Click Save to apply the changes.
Guest Network
The Guest Network function allows administrators to grant Internet connectivity to visitors or guests while keeping other networked devices (computers and hard drives) and sensitive personal or company information private and secure.
Enable SSID:
Select to Enable or Disable SSID broadcasting.
SSID:
Specify the SSID for the current profile. This is the name visible on the network to wireless clients.
Security:
You can use None or WPA-PSK / WPA2-PSK security for this guest network.
Hidden SSID:
Check this option to hide the SSID from broadcasting to discourage wireless users from connecting to a particular
SSID.
Client Isolation:
Check this option to prevent wireless clients associated with your access point to communicate with other wireless devices connected to the AP.
After enabling Guest Network in the SSID Config page, assign an IP Address, Subnet Mask and DHCP server IP address range for this Guest Network.
Manual IP Settings
IP Address:
Specify an IP Address for the Guest Network
Subnet Mask:
Specify the the Subnet Mask IP Address for the Guest Network
Automatic DHCP Server Settings
Starting IP Address: Specify the starting IP Address range for the Guest Network.
Ending IP Address: Specify the ending IP Address range for the Guest Network.
WINS Server IP: Specify the WINS Server IP Address for the Guest Network. WINS means Windows Internet Name Service. It is
Microsoft's implementation of NetBIOS Name Service (NBNS), a name server and service for NetBIOS computer names.
Fast Handover
With Fast Handover enabled, the AP will send a disassociation request to the wireless client and let it find another AP to handover and associate upon detecting the wireless client’s RSSI value lower than specified. The RSSI value can be adjusted to allow more clients to stay associated to this AP. Note that setting the RSSI value too low may cause wireless clients to reconnect frequently.
Management VLAN Settings
This section allows you to assign a VLAN tag to the packets. A VLAN is a group of computers on a network whose software has been configured so that they behave as if they were on a separate Local Area Network (LAN). Computers on VLAN do not have to be physically located next to one another on the LAN.
Status:
If your network includes VLANs and if tagged packets need to pass through the Access Point, select
Enable and enter the VLAN ID. Otherwise, click
Disable
.
Save:
Click
Save to apply the changes.
Note: If you reconfigure the Management VLAN ID, you may lose your connection to the Access Point. Verify that the DHCP server supports the reconfigured VLAN ID and then reconnect to the Access Point using the new IP address.
Chapter 7
Management
SNMP Settings
This page allows you to assign the Contact Details, Location, Community Name, and Trap Settings for Simple Network Management
Protocol (SNMP). This is a networking management protocol used to monitor network attached devices. SNMP allows messages (called protocol data units) to be sent to various parts of the network. Upon receiving these messages, SNMP compatible devices (called agents) returns the data stored in their Management Information Bases. To configure SNMP Settings, click under the Advanced tab on the side bar under Management .
Status: Enables or Disables the SNMP feature.
Contact: Specifies the contact details of the device.
Location:
Specifies the location of the device.
Port:
Displays the port number.
Community Name (Read Only):
Specifies the password for the SNMP community for read only access.
Community Name (Read/Write): Specifies the password for the SNMP community with read/write access.
Trap Destination Address: Specifies the port and IP address of the computer that will receive the SNMP traps.
Trap Destination Community Name: Specifies the password for the SNMP trap community.
SNMPv3 Status: Enables or Disables the SNMPv3 feature.
User Name: Specifies the username for the SNMPv3.feature
Auth Protocol:
Select the Authentication Protocol type: MDS or SHA.
Auth Key:
Specify the Authentication Key for authentication.
Priv Protocol:
Select the Privacy Protocol type: DES.
Priv Key:
Specifies the privacy key for privacy.
Engine ID:
Specifies the Engine ID for SNMPv3.
CLI/SSH Settings
Most users will configure the device through the graphical user interface (GUI). However, for those who prefer an alternative method there is the command line interface (CLI). The CLI can be access through a command console, modem or Telnet connection.
For security
’ s concern, you can enable SSH (Secure Shell) to establish a secure data communication.
CLI Status: Select Enable or Disable to enable or disable the ability to modify the Access Point via a command line interface (CLI).
SSH Status:
Select
Enable or
Disable to enable or disable the ability to modify the Access Point via a command line interface (CLI) with a secure channel.
HTTPS Settings
Hypertext Transfer Protocol Secure (HTTPS) is a communications protocol for secure communication over a computer network, with especially wide deployment on the Internet. Technically, it is not a protocol in and of itself; rather, it is the result of simply layering the Hypertext Transfer Protocol (HTTP) on top of the SSL/TLS protocol, thus adding the security capabilities of SSL/TLS to standard
HTTP communications.
Status: Select Enable or Disable to enable or disable the ability to modify the Access Point via a HTTPS.
HTTPS forward: Enable this option; it will be forwarded to HTTPS if user uses HTTP to access the Access Point.
Email Alert
The Access Point will send email alerts when configurations have been changed.
Status: Check Enable to enable Email Alert feature.
From: Enter the address to show as the sender of the email.
To:
Enter the address to show as the receiver of the email.
Subject:
Enter the subject to show as the subject of the email.
Email Account
Username/Password: Enter the username and password required to connect to the SMTP server.
SMTP Server/Port: Enter the IP address/domain name and port of the SMTP server. The default port of SMTP Server is port 25.
Security Mode : Select the mode of security for the Email alert. The options are None, SSL/TLS and STARTTLS.
Send Test Mail: Click Send Test Mail button to test the Email Alert setup.
Apply: Click Apply to save the changes.
Date and Time Settings
This page allows you to set the internal clock of the Access Point. To access the Date and Time settings, click
Time Zone under the Management tab on the side bar.
Manually Set Date and Time: Manually specify the date and time.
Synchronize with PC:
Click to synchronize the Access Point
’ s internal clock with the computer’s time.
Automatically Get
Date and Time:
Enter the IP address of an NTP server or use the default NTP server to have the internal clock set automatically.
Time Zone:
Choose the time zone you would like to use from the drop-down list.
Enable Daylight Savings:
Check the box to enable or disable daylight savings time for the Access Point. Next, enter the dates that correspond to the present year’s daylight savin gs time.
Click
Apply to save the changes.
WiFi Scheduler
Use the schedule function to reboot the Access Point or control the wireless availability on a routine basis. The Schedule function relies on the GMT time setting acquired from a network time protocol (NTP) server. For details on how to connect the Access Point to an NTP server, see Date and Time Settings.
Auto Reboot Settings
You can specify how often you would like to reboot the Access Point.
Status:
Enables or disables the Auto Reboot function.
Timer: Specifies the time and frequency in rebooting the Access Point by Min, Hour and Day.
WiFi Scheduler
Status: Enables or disables the WiFi Scheduler function.
Wireless Radio: Select 2.4GHz or 5GHz* to use WiFi Schedule.
SSID Selection: Select a SSID to use WiFi Schedule.
Schedule Templates: There are 3 templates available: Always available, Available 8-5 daily and Available 8-5 daily except weekends. Select Custom schedule if you want to set the schedule manually.
Schedule Table: Set the schedule manually.
*5GHz radio settings only available for dual radio models.
Tools
This section allows you to analyze the connection quality of the Access Point and trace the routing table to a target in the network.
Ping Test Parameters
Target IP/Domain Name:
Enter the IP address or Domain name you would like to search.
Ping Packet Size: Enter the packet size of each ping.
Number of Pings: Enter the number of times you wish to ping.
Start:
Click
Start to begin pinging target device (via IP).
Traceroute Parameters
Target IP/Domain Name: Enter an IP address or domain name you wish to trace.
Start:
Click
Start to begin the trace route operation.
Stop:
Halts the traceroute test.
Speed Test Parameters
Target IP/Domain Name: Enter an IP address or domain name you wish to run a Speed Test for.
Time Period : Enter the time in seconds that you would like the test to run for and in how many intervals.
Start : Starts the Speed Test.
IPv4 / IPv6 Port: The Access Point uses IPv4 port 5001 and IPv6 port 5002 for the speed test.
LED Control
This section allows you to control the LED control functions: Power status, LAN interface and 2.4GHz/5GHz WLAN interface.
Click Apply to save the settings after selecting your choices from the boxes.
*5GHz settings only available for dual radio models.
Device Discovery
Under Device Discovery, you can choose for the Access Point to automatically scan for local devices to connect to. Click
Scan to begin the process.
Chapter 8
System Manager
Account Setting
This page allows you to change the username and password of the device. By default, the username is admin and the password is admin . The password can contain from 0 to 12 alphanumeric characters and is case sensitive.
Administrator Username: Enter a new username for logging in to the Administrator Username entry box.
Current Password: Enter the old password for logging in to the Current Password entry box.
New Password: Enter the new password for logging in to the New Password entry box.
Verify Password: Re-enter the new password in the Verify Password entry box for confirmation.
Apply: Click Apply to save the changes.
Note: it is highly recommended that you change your password to something more unique for greater security.
Firmware Upgrade
This page allows you to upgrade the Firmware of the Access Point.
To Perform the Firmware Upgrade:
1.
Click the
Browse… button and navigate the OS File System to the location of the Firmware upgrade file.
2.
Select the upgrade file. The name of the file will appear in the Upgrade File field.
3.
Click the
Upload button to commence the Firmware upgrade.
Note:
The device is unavailable during the upgrade process and must restart when the upgrade is completed. Any connections to or through the device will be lost.
Backup/Restore
This page allows you to save the current device configurations. When you save the configurations, you can also reload the saved configurations into the device through the Restore New Settings from a file folder. If extreme problems occur, or if you have set the Access Point incorrectly, you can use the Reset button in the Reset to Default section to restore all the configurations of the Access Point to the original default settings. To Configure the Backup/Restore Settings, click Firmware under the Systems Manager tab.
Factory Setting
Backup Setting: Click Export to save the current device configurations to a file.
Restore New Setting: Choose the file you wish restore for settings and click Import .
Reset to Default: Click the Reset button to restore the Access Point to its factory default settings.
User Setting
Back Up Setting as Default: Click Backup to backup the user settings you would like to use as the default settings.
Restore to User Default: Click Restore to restore the Access Point to user
’ s default settings.
System Log
This page allows you to setup the System Log and local log functions of the Access Point. Click
Log under the
Systems
Manager tab to open up the System Log page.
Status: Enables or disables the System Log function.
Log Type: Select the Log Type mode you would like to use.
Remote Log: Enables or disables the Remote Log feature. If enabled, enter the IP address of the Log you would like to remote to.
Log Server IP Address: Enter the IP address of the log server.
Apply:
Click
Apply to save the changes.
Reset
In some circumstances, you may be required to force the device to reboot. Click on
Reboot the Device to reboot the device.
Logout
Click Logout , it will pop up a warning window. Click OK to logout.
This recycle logo Indicates that this product is capable of being recycled, not that the product has been recycled or will be accepted in all recycling collection systems.
This symbol is new RED aligns the previous directive with the New Legislative Framework for the marketing of products. The revision takes account of the need for improved market surveillance, in particular for the traceability obligations of manufacturers, importers and distributors. It provides improved instruments for market surveillance, such as the possibility to require prior registration of radio equipment, within those categories affected by low levels of compliance.
The Directive requires equipment to be constructed for efficient use of the radio spectrum, as well as electromagnetic compatibility, to avoid interference with terrestrial and orbital communications.
The RoHS directive aims to restrict certain dangerous substances commonly used in electronic and electronic equipment. This RoHS compliant symbol indicate the component is tested for the presence of Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Hex-Cr), Polybrominated biphenyls (PBB), and Polybrominated diphenyl ethers (PBDE).
For Cadmium and Hexavalent chromium, there must be less than 0.01% of the substance by weight at raw homogeneous materials level. For Lead, PBB, and PBDE, there must be no more than 0.1% of the material, when calculated by weight at raw homogeneous materials. Any RoHS compliant component must have 100 ppm or less of mercury and the mercury must not have been intentionally added to the component.
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
Related manuals
advertisement
