User manual
LED Pad 7
7x10W 6in1 RGBWAUV
LED PAR
Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: [email protected]
Internet: www.thomann.de
22.06.2018, ID: 390703, 428171
Table of contents
Table of contents
1
General notes...............................................................................................................................................
1.1 Further information...........................................................................................................................
1.2 Notational conventions....................................................................................................................
1.3 Symbols and signal words...............................................................................................................
2
Safety instructions.................................................................................................................................. 11
3
Features....................................................................................................................................................... 16
4
Installation.................................................................................................................................................. 17
5
Starting up.................................................................................................................................................. 20
6
Connections and controls................................................................................................................... 24
7
Operating....................................................................................................................................................
7.1 Starting the device...........................................................................................................................
7.2 Main menu..........................................................................................................................................
7.3 Menu overview.................................................................................................................................
7.4 Function in 1-channel DMX mode.............................................................................................
7.5 Functions in 6-channel DMX mode...........................................................................................
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
3
6
7
8
8
32
32
32
38
39
39
Table of contents
7.6 Functions in 7-channel DMX mode........................................................................................... 40
7.7 Functions in 10-channel DMX mode........................................................................................ 41
4
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
8
Technical specifications....................................................................................................................... 43
9
Plug and connection assignments.................................................................................................. 45
10
Troubleshooting...................................................................................................................................... 46
11
Cleaning....................................................................................................................................................... 48
12
Protecting the environment.............................................................................................................. 49
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
5
General notes
1
General notes
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
6
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
General notes
1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download
This manual is also available as PDF file for you to download.
Keyword search
Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides
Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service
If you have any problems with the device the customer service will
gladly assist you.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
7
General notes
1.2 Notational conventions
This manual uses the following notational conventions:
Letterings
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Displays
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
8
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
General notes
Signal word
Meaning
DANGER!
This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING!
This combination of symbol and signal word indicates a possible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE!
This combination of symbol and signal word indicates a possible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs
Type of danger
Warning – high-voltage.
Warning – suspended load.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
9
General notes
Warning signs
Type of danger
Warning – danger zone.
10
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Safety instructions
2
Safety instructions
Intended use
This device is intended to be used as an electronic illumination effect using LED technics. The
device is designed for professional use and is not suitable for use in households. Use the
device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
11
Safety instructions
Safety
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
12
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Safety instructions
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a protective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a registered electrician.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
13
Safety instructions
NOTICE!
Risk of fire
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked flames.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
14
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Safety instructions
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
15
Features
3
Features
The device is suitable for almost all applications, for example in clubs, bars, small stages and
theatres. It is characterized by small size, solid construction also for use ‘on tour’ and enormous
power.
Special features of the device:
n
n
n
n
n
n
16
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
7 × 10 W 6in1 RGBWAUV LEDs
6 colours per lens, so that almost any colour can be mixed
with double bracket for easy setup or mounting
Control via DMX, the supplied IR remote control and via buttons and display on the unit
Automatic mode and sound control
Master / Slave operation
Installation
4
Installation
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
You can install the device on the wall, ceiling or floor. A two-piece mounting bracket with
locking screws is included in the package.
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
17
Installation
NOTICE!
Risk of overheating
Always ensure sufficient ventilation.
The ambient temperature must always be below 40 °C (104 °F).
NOTICE!
Use of stands
When mounting the device onto a stand, ensure that the stand is in a safe and
stable position and that the weight of the device does not exceed the maximum
permissible load capacity of the stand.
18
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Installation
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordinary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or amplifiers.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
19
Starting up
5
Starting up
Create all connections while the device is off. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
20
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Starting up
Connections in DMX mode
Connect the DMX input of the device to the DMX output of a DMX controller or another DMX
device. Connect the output of the first DMX device to the input of the second one, and so on
to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain
is terminated with a resistor (110 Ω, ¼ W).
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
21
Starting up
Connections in master/slave
mode
When you configure a group of devices in master/slave mode, the first unit will control the
other units for an automatic, sound-activated, synchronized show. This function is ideal when
you want to start a show immediately. Connect the DMX output of the master device to the
DMX input of the first slave device. Then connect the DMX output of the first slave device to
the DMX input of the second slave device and so on.
Please note that this device must not be connected to a dimmer.
22
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Starting up
Inserting the battery into the
remote control
Press the lock of the battery holder to the centre of the housing and pull out the battery holder
like a drawer. Insert the battery. The battery is correct if the positive pole points to the housing
base of the remote control. Slide the battery holder back into the remote until it clicks into
place.
When shipping, the battery is already installed in the remote and protected against discharge
by a transparent plastic foil. Remove the plastic foil prior to first use.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
23
Connections and controls
6
Connections and controls
Front panel
24
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Connections and controls
1 Locking screws for the mounting bracket.
2 Infrared sensor for receiving signals from the remote control.
3 LEDs.
4 Bracket for floor placement or hanging.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
25
Connections and controls
Rear panel
26
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Connections and controls
5 [DMX IN]
DMX input.
6 Fan
7 Display and operating elements
[ENTER]
Confirms a selected value.
[DOWN]
Button to decrease the displayed value by one.
[UP]
Button to increase the displayed value by one.
[MENU]
Calls up the main menu or a submenu.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
27
Connections and controls
8 [DMX OUT]
DMX output
9 [POWER OUT]
IEC chassis socket for the power supply of further devices
10 Microphone for sound control
11 [100-240V~50/60Hz]
Mains connection socket, designed as IEC chassis plug
28
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Connections and controls
Remote control
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
29
Connections and controls
15 [SLAVE]
Toggles operating modes ‘Master‘ and ‘Slave’.
16 [SPEED]
Activates the setting mode for the programme speed. Adjust the speed using the buttons [UP] and [DOWN] .
17 [UP / DOWN]
To select a desired program or increase / decrease a parameter value.
18 [0 … 9]
To make numeric settings.
19 [W], [A], [R], [G], [B]
To switch the specified base colour on and off.
20 [STROBE]
Turns the strobe function on / off.
21 [SOUND 1 & 2]
Activates sound-controlled mode 1 or 2
30
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Connections and controls
22 [AUTO 1 & 2]
Activates the ‘preprogrammed automatic show’ 1 or 2.
23 [POWER]
Activates or deactivates the device.
24 [DMX]
Press once to set the DMX address. After pressing twice, the DMX mode can be set.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
31
Operating
7
Operating
7.1 Starting the device
Connect the device to the power supply to start operation.
7.2 Main menu
Press [MENU] to activate the main menu. Use [UP] / [DOWN] to change the respectively indicated value. When the display shows the desired value press [ENTER].
32
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Operating
DMX address
Press [MENU]. Press [UP] / [DOWN] repeatedly until the display shows ‘Addr’ . Press [ENTER].
Now you can set the number of the first DMX channel to be used by the device (DMX address).
Use [UP] / [DOWN] to select a value between 1 and 512 (the display shows ‘A001’ … ‘A512’ ).
When the display shows the desired value press [ENTER] to confirm the selection and then
[MENU] to return to the parent menu. To return to the parent menu without making changes,
press [MENU].
Make sure that this number matches the configuration of your DMX controller. The following
table shows the highest possible DMX address for the various DMX modes.
Mode
Highest possible DMX address
1-channel
512
6-channel
507
7-channel
506
10-channel
503
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
33
Operating
DMX mode
Press [MENU]. Press [UP] / [DOWN] repeatedly until the display shows ‘Chnd’ . Press [ENTER].
With [UP] or [DOWN] you can now select one of the following DMX modes:
n
n
n
n
‘1Ch’ (one channel)
‘6Ch’ (six channels)
‘7Ch’ (seven channels)
‘10Ch’ (ten channels)
This setting is only relevant when the device is controlled via DMX. When the display shows
the desired value press [ENTER] to confirm the selection and then [MENU] to return to the
parent menu. To return to the parent menu without making changes, press [MENU].
34
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Operating
Operating mode ‘Auto 1’ / ‘Auto
2’
Press [MENU]. Press [UP] / [DOWN] repeatedly until the display shows ‘AUto’ . Press [ENTER].
With [UP] / [DOWN] you can now select one of the two preprogrammed automatic shows
‘AUT1’ or ‘AUT2’ . Press [ENTER]. Use [UP] / [DOWN] to select a value for the programme speed
between 1 and 9 (display shows ‘SP-1’ … ‘SP-9’ ). Press [ENTER]. Then use [UP] / [DOWN] to
select a value for the strobe frequency between 00 and 99 (display shows ‘St00’ … ‘St99’ ).
When the display shows the desired value press [ENTER] to confirm the selection and then
[MENU] to return to the parent menu. To return to the parent menu without making changes,
press [MENU].
This setting is only relevant if the device is not controlled via DMX. The device can operate in
stand-alone mode or control connected devices of the same type, that must be configured as
slaves. The auto show can only be activated on the master device.
Colour selection
Press [MENU]. Press [UP] / [DOWN] repeatedly until the display shows ‘CoLo’ . Press [ENTER].
With [UP] / [DOWN] you can now select a colour ‘Co01’ to ‘Co51’ . When the display shows the
desired value press [ENTER] to confirm the selection. Then use [UP] / [DOWN] to select a value
for the strobe frequency between 00 and 99 (display shows ‘St00’ … ‘St99’ ). When the display
shows the desired value press [ENTER] to confirm the selection and then [MENU] to return to
the parent menu. To return to the parent menu without making changes, press [MENU].
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
35
Operating
Dimmer setting
Press [MENU]. Press [UP] / [DOWN] repeatedly until the display shows ‘StAt’ . Press [ENTER].
Press [UP] / [DOWN] repeatedly until the display shows ‘red’ (for red), ‘Gree’ (for green), ‘bLue’
(for blue), ‘Uhit’ (for white), ‘Anbe’ (for amber) or ‘PUrP’ (for UV). When the display shows the
desired value press [ENTER] to confirm the selection. Then use [UP] / [DOWN] to select a value
for the dimmer setting between 000 and 255 (display shows ‘r000’ … ‘r255’ , ‘g000’ … ‘g255’ ,
‘b000’ … ‘b255’ , ‘U000’ … ‘U255’ , ‘A000’ … ‘A255’ ) or ‘P000’ … ‘P255’ ). When the display shows
the desired value press [ENTER] to confirm the selection. Then use [UP] / [DOWN] to select a
value for the strobe frequency between 00 and 99 (display shows ‘St00’ … ‘St99’ ). When the
display shows the desired value press [ENTER] to confirm the selection and then [MENU] to
return to the parent menu. To return to the parent menu without making changes, press
[MENU].
Sound control
Press [MENU]. Press [UP] / [DOWN] repeatedly until the display shows ‘Soun’ . Press [ENTER].
With [UP] / [DOWN] you can now select one of the two sound modes ‘Sou1’ or ‘Sou2’ . Press
[ENTER]. Use [UP] / [DOWN] to select a value for the microphone sensitivity between 0 and 9
(display shows ‘SEN0’ … ‘SEN9’ ). When the display shows the desired value press [ENTER] to
confirm the selection and then [MENU] to return to the parent menu. To return to the parent
menu without making changes, press [MENU].
36
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Operating
Operating mode ‘Slave’
Press [MENU]. Press [UP] / [DOWN] repeatedly until the display shows ‘SLAv’ . Press [ENTER]. The
display now shows ‘SLA’ . The device is now configured as slave and follows the settings of the
master device to which it is connected. In the other operating modes, the device automatically
operates as master. Press [MENU] to return to the parent menu. This setting is only relevant if
the device is not controlled via DMX.
Remote control
Press [MENU]. Press [UP] / [DOWN] repeatedly until the display shows ‘rEno’ . With [UP] /
[DOWN] you can now either enable (display shows ‘on’ ) or disable (display shows ‘oFF’ ) the
remote control function. When the display shows the desired value press [ENTER] to confirm
the selection and then [MENU] to return to the parent menu. To return to the parent menu
without making changes, press [MENU].
Temperature
Press [MENU]. Press [UP] / [DOWN] repeatedly until the display shows ‘tenP’ . Press [ENTER]. The
display shows the current operating temperature.
Software version display
Press [MENU]. Press [UP] / [DOWN] repeatedly until the display shows ‘Uer’ . Press [ENTER]. The
display now shows the current software version with ‘vXX’ . To return to the parent menu,
press [MENU].
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
37
Operating
7.3 Menu overview
38
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Operating
7.4 Function in 1-channel DMX mode
Channel
Value
Function
1
0…255
Colour selection
7.5 Functions in 6-channel DMX mode
Channel
Value
Function
1
0…255
Intensity red (0 % to 100 %)
2
0…255
Intensity green (0 % to 100 %)
3
0…255
Intensity blue (0 % to 100 %)
4
0…255
Intensity white (0 % to 100 %)
5
0…255
Intensity amber (0 % to 100 %)
6
0…255
Intensity UV (0 % to 100 %)
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
39
Operating
7.6 Functions in 7-channel DMX mode
Channel
Value
Function
1
0…255
Intensity (0 % to 100 %)
2
0…255
Intensity red (0 % to 100 %)
3
0…255
Intensity green (0 % to 100 %)
4
0…255
Intensity blue (0 % to 100 %)
5
0…255
Intensity white (0 % to 100 %)
6
0…255
Intensity amber (0 % to 100 %)
7
0…255
Intensity UV (0 % to 100 %)
40
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Operating
7.7 Functions in 10-channel DMX mode
Channel
Value
Function
1
0…255
Intensity (0 % to 100 %)
2
0…255
Intensity red (0 % to 100 %)
3
0…255
Intensity green (0 % to 100 %)
4
0…255
Intensity blue (0 % to 100 %)
5
0…255
Intensity white (0 % to 100 %)
6
0…255
Intensity amber (0 % to 100 %)
7
0…255
Intensity UV (0 % to 100 %)
8
0…50
No function
51…101
Auto mode 1
102…152
Auto mode 2
153…203
Sound mode 1
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
41
Operating
Channel
9
10
42
Value
Function
204…255
Sound mode 2
0…255
Automatic show speed, slow to fast, if channel 8 = 51…152
0…255
Microphone sensitivity, if channel 8 = 153…255 (0 to 29: microphone off, 30 to 255 = low
to high)
0…9
No function
10…255
Strobe frequency slow to fast
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Technical specifications
8
Technical specifications
LEDs
7 × 6-in1 LEDs (RGBWAUV), each 10 W
Beam angle
25°
Number of DMX channels
1, 6, 7 or 10 according to operating mode
Battery (remote control)
Lithium button cell, CR 2025, 3 V
Power consumption
70 W
Operating supply voltage
100 – 240 V
Fuse
5 mm × 20 mm, 3.15 A, 250 V, fast-acting
Protection class
IP20
Housing colour
Item no. 390703: white
50/60 Hz
Item no. 428171: black
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
43
Technical specifications
Dimensions (W × H × D)
186 × 186 × 128 mm (without bracket)
260 × 260 × 128 mm (incl. bracket)
Weight
44
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
1.9 kg
Plug and connection assignments
9
Plug and connection assignments
Introduction
This chapter will help you select the right cables and plugs to connect your valuable equipment so that a perfect light experience is guaranteed.
Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug
fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a
short circuit or ‘just’ a not working light show!
DMX connections
The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please
refer to the drawing and table below for the pin assignment of a suitable XLR plug.
Pin
Configuration
1
Ground, shielding
2
Signal inverted (DMX–, ‘cold signal’)
3
Signal (DMX+, ‘hot signal’)
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
45
Troubleshooting
10
Troubleshooting
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordinary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or amplifiers.
In the following we list a few common problems that may occur during operation. We give you
some suggestions for easy troubleshooting:
46
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Troubleshooting
Symptom
Remedy
The unit does not work, no light
Check the mains connection.
Apparently no function despite
proper power supply
Check if the unit is in DMX mode or in ‘slave’ mode. If so,
check the unit in another mode.
No response to the DMX controller
1. Check whether the DMX controller is switched on.
Check the DMX connectors and cables for proper connection.
2. Check the address settings and the DMX polarity.
3. Try using another DMX controller.
4. Check whether the DMX cables run near or parallel to
high-voltage cables that may cause damage or interference to a DMX interface circuit.
If the procedures recommended above do not succeed, please contact our Service Center. You
can find the contact information at www.thomann.de.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
47
Cleaning
11
Cleaning
Optical lenses
Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the
light output. The frequency of cleaning depends on the operating environment: wet, smoky or
particularly dirty surroundings can cause more accumulation of dirt on the optics of the
device.
n Clean with a soft cloth using our lamp and lens cleaner (item no. 280122).
n Always dry the parts carefully.
Fan grids
48
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
The fan grids of the device must be cleaned on a regular basis to remove dust and dirt. Before
cleaning, switch off the device and disconnect AC-powered devices from the mains. Use a lintfree damp cloth for cleaning. Never use solvents or alcohol for cleaning.
Protecting the environment
12
Protecting the environment
Disposal of the packaging material
For the transport and protective packaging, environmentally friendly materials have been
chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose these materials with your normal household waste, but make sure that
they are fed to a recovery. Please follow the notes and markings on the packaging.
Disposal of batteries
Batteries must not be disposed of as domestic waste or thrown into fire. Dispose of the batteries according to national or local regulations regarding hazardous waste. To protect the
environment, dispose of empty batteries at your retail store or at appropriate collection sites.
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
49
Protecting the environment
Disposal of your old device
This product is subject to the European Waste Electrical and Electronic Equipment Directive
(WEEE) in its currently valid version. Do not dispose with your normal household waste.
Dispose this device through an approved waste disposal firm or through your local waste
facility. When discarding the device, comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.
50
LED Pad 7 7x10W 6in1 RGBWAUV
LED PAR
Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
