32H503

colour television

Owner’s manual

Contents

Package Contents .................................................. 2

Features ................................................................. 2

Introduction ............................................................. 3

Preparation ............................................................. 3

Safety Precautions ................................................. 3

Environmental Information ..................................... 5

Repair Information .............................................. 5

Remote Control Buttons ......................................... 6

TV and Operating Buttons ...................................... 7

Viewing the Connections - Back Connectors ......... 7

Viewing the Connections - Side Connectors .......... 8

Aerial Connection ................................................... 8

Power Connection .............................................. 8

Using USB Media ................................................... 9

Connecting the TV to a PC ................................... 10

Connecting to a DVD Player................................. 10

Using Side AV Connectors ................................... 10

Remote Control Handset .......................................11

Inserting Batteries ..............................................11

Switching On/Off ....................................................11

To Switch the TV On ..........................................11

To Switch the TV Off ..........................................11

Input Selection .......................................................11

Basic Operations ...................................................11

Operation with the Buttons on the TV ................11

Volume Setting ...............................................11

Programme Selection ....................................11

Viewing Main Menu ........................................11

AV Mode ........................................................11

Operation with the Remote Control ...................11

Volume Setting .............................................. 12

Programme Selection (Previous or Next

Programme) .................................................. 12

Programme Selection (Direct Access) .......... 12

First Time Installation............................................ 12

Viewing Electronic Programme Guide (EPG) ....... 13

EPG Timeline Schedule .................................... 13

EPG Channel Schedule .................................... 13

EPG Now and Next........................................... 14

Recording via EPG Screen ............................... 14

Programme Options.......................................... 14

Installation ............................................................ 14

Auto Channel Scan (Retune) Menu Operation .... 14

Manual Tuning ..................................................... 15

Digital Manual Search....................................... 15

Analogue Manual Search ................................. 15

Analogue Fine Tune.......................................... 15

Managing Stations: Channel List .......................... 15

Operating the Channel List ............................... 15

Moving a Channel ............................................. 16

Deleting a Channel ........................................... 16

Renaming a Channel ........................................ 16

- 1 -

Locking a Channel ............................................ 16

Managing Stations: Favourites ............................. 16

Button Functions ............................................... 16

Managing Stations: Sorting the Channel List ....... 16

On-Screen Information ......................................... 17

Media Playback Using Media Browser ................. 17

Viewing Videos via USB .................................. 17

Viewing Photos via USB ................................... 18

Slideshow Options ............................................ 18

Playing Music via USB ..................................... 18

Recordings Library............................................ 19

Media Browser Settings .................................... 19

Timeshift Recording ............................................. 19

Instant Recording ................................................. 20

Watching Recorded Programmes ....................... 20

Changing Image Size: Picture Formats ................ 21

Con fi guring Picture Settings ................................. 22

Operating Picture Settings Menu Items ............ 22

Picture Settings Menu Items ............................. 22

PC Picture Settings........................................... 22

Con fi guring Sound Settings .................................. 23

Operating Sound Settings Menu Items ............. 23

Sound Settings Menu Items.............................. 23

Con fi guring Your TV’s Settings ............................. 23

Operating Settings Menu Items ........................ 24

Settings Menu Items ......................................... 24

Using a Conditional Access Module (not included) ............................................................... 24

Viewing Conditional Access Menu (*) ............... 24

Con fi guring Language Preferences ...................... 24

Parental Control.................................................... 25

Parental Settings Menu Operation ................... 25

Timers ................................................................... 25

Setting Sleep Timer .......................................... 25

Setting Programme Timers ............................... 25

Recording Con fi guration ....................................... 26

Con fi guring Date/Time Settings ............................ 26

Con fi guring Source Settings ................................. 27

Con fi guring Other Settings ................................... 27

Operation .......................................................... 27

Other Features ..................................................... 28

Teletext ................................................................. 28

Tips ....................................................................... 29

Appendix A: PC Input Typical Display Modes ....... 30

Appendix B: AV and HDMI Signal Compatibility

(Input Signal Types) .............................................. 30

Appendix C: Supported DVI Resolutions.............. 31

Appendix D: Software Upgrade ............................ 31

Appendix E : Supported File Formats for USB

Mode..................................................................... 32

Speci fi cations ....................................................... 33

Important Instruction ............................................. 34

Package Contents

SCREEN LANG

ZOOM REPEAT

SUBTITLE

ROOT TITLE

4

7

1

TEXT

2

5

8

0

3

6

9

SWAP

INFO

P+

SOURCE

V+

OK

PV-

MENU

RETURN FAV SLEEP EPG

DISPLAY PRESETS

Remote Control

LCD TV

Instruction Book

Batteries: 2 X AAA

Note: You should check the contents after opening your purchase and make sure that every item is included.

Note: The HDMI connection between PC and TV may cause radio interference in which case it is recommended to use VGA(DSUB-15) connection.

Features

• Remote controlled colour LCD TV.

• Fully integrated Terrestrial digital TV (DVB-T

MPEG2).

• HDMI connectors for digital video and audio.

• USB input.

• Programme recording

• Programme timeshifting

• 1000 programmes (analogue+digital).

• On Screen Display (OSD) menu system.

• Integrated tuner DVB-T, MPEG2 compatible.

• Scart socket for external devices.

• Stereo sound system. (Nicam)

• Teletext, fastext, TOP text.

• Headphone connection.

• Automatic programming system.

• Forward or backward manual tuning.

• Sleep timer / Child lock.

• Automatic sound mute when no transmission.

• NTSC playback.

• AVL (Automatic Volume Limiting).

• Auto power down.

• PLL (Frequency Search).

• PC input.

• Plug&Play for Windows 98, ME, 2000, XP, Vista,

Windows 7.

• Game Mode

- 2 -

Introduction

Thank you for choosing this product. This manual will guide you through the proper operation of your

TV. Before operating the TV, please read this manual thoroughly. Please keep this manual in a safe place for future reference.

This device is intended to receive and display TV programmes. The different connection options make an additional expansion of the reception and display sources possible (receiver, DVD player, DVD recorder,

VCR, PC etc.).

This device is only suitable for dry indoor use. This appliance is intended solely for private domestic use and may not be used for industrial and commercial purposes. We exclude liability in principle, if the device is not used as intended, or unauthorized modi fi cations have been made. To operate your LCD TV in extreme ambient conditions may cause the damage of the device.

Preparation

For ventilation, leave a free space of at least 10 cm all around the set. To prevent any fault and unsafe situations, please do not place any objects on top of the set. Use this device in moderate climates.

Safety Precautions

Read the following recommended safety precautions carefully.

Power Source

The TV set should be operated only from a 220-240V

AC, 50 Hz outlet. Ensure that you select the correct voltage setting for your convenience.

Power Cord

Do not place the set, a piece of furniture, etc. on the power cord or pinch the cord. Handle the power cord by the plug. Do not unplug the appliance by pulling from the power cord and never touch the power cord with wet hands as this could cause a short circuit or electric shock.

Never make a knot in the cord or tie it with other cords.

The power cord should be placed in such a way that they are not likely to be stepped on. A damaged power cord can cause fi re or give you an electric shock. When it is damaged and needs to be replaced, it should be done by quali fi ed personnel.

Moisture and Water

Do not use this device in a humid and damp place (avoid the bathroom, the sink in the kitchen etc). Do not expose this device to rain or water, as this may be dangerous and do not place objects fi lled with liquids, such as fl ower vases, on top.

If any solid object or liquid falls into the cabinet, unplug the TV and have it checked by quali fi ed personnel before operating it any further.

Cleaning

Before cleaning, unplug the TV set from the wall outlet. Do not use liquid or aerosol cleaners. Use a soft, dry cloth.

Ventilation

The slots and openings on the TV set are intended for ventilation and to ensure reliable operation. To prevent overheating, these openings must not be blocked or covered in anyway.

Heat and Flames

The set should not be placed near to open fl ames or sources of intense heat such as an electric heater. Ensure that no open fl ame sources, such as candles, are placed on top of the TV. Batteries should not be exposed to excessive heat such as sunshine, fi re or the like.

Lightning

In case of storm and lightning or when going on holiday, disconnect the power cord from the wall outlet.

Replacement Parts

When replacement parts are required, make sure that the service technician has used replacement parts, which are speci fi ed by the manufacturer or have the same speci fi cations as the original one. Unauthorized substitutions may result in fi re, electrical shock or other hazards.

Servicing

Please refer all servicing to quali fi ed personnel. Do not remove the cover yourself as this may result in an electric shock.

- 3 -

Waste Disposal

Instructions for waste disposal:

• Packaging and packaging aids are recyclable and should principally be recycled. Packaging materials, such as a foil bag, must be kept away from children.

• Batteries, including those which are heavy metalfree, should not be disposed of with household waste. Please dispose of used batteries in an environmentally friendly manner. Find out about the legal regulations which apply in your area.

• Do not try to recharge batteries, there is a danger of explosion. Replace batteries only with the same or equivalent type.

This symbol on the product or on its packaging means that your electrical device should be disposed at the end of its service life separately from your household wastes.

There are separate collection systems for recycling in the EU. For more information, please contact the local authority or the dealer where you purchased the product.

Disconnecting the Device

The mains plug is used to disconnect the TV set from the mains and therefore it must remain readily operable.

Headphone Volume

Excessive sound pressure from earphones and headphones can cause hearing loss.

Installation

To prevent injury, this device must be securely attached to the wall in accordance with the installation instructions when mounted to the wall (if the option is available).

LCD Screen

The LCD panel is a very high technology product with about a million thin fi lm transistors, giving you fi ne picture details. Occasionally, a few non-active pixels may appear on the screen as a fi xed blue, green or red point. Please note that this does not affect the performance of your product.

Warning! Do not leave your TV in standby or operating mode when you leave your house.

Connection to a Television Distribution

System (Cable TV etc.) from Tuner

Devices connected to the protective earthing of the building installation through the mains connection or through other apparatus with a connection to protective earthing-and to a television distribution system using a coaxial cable, may in some circumstances create a fi re hazard.

Connection to a cable distribution system has therefore to be provided through a device providing electrical isolation below a certain frequency range

(galvanic isolator, see EN 60728-11).

Electrical devices not in the hands of children

Never let children use electrical devices unsupervised.

Children cannot always recognize properly any possible danger. Batteries / accumulators can be life threatening when swallowed. Store batteries out of the reach of small children. In case of swallowing a battery, medical aid has to be sought immediately.

Also keep the packaging away from children as there is danger of suffocation.

The Standby button does not fully switch off this product. Moreover, the device continues to consume power in standby mode. In order to separate the device completely from mains, the mains plug has to be pulled from the mains socket. Because of that the device should be set up in a way, that an unobstructed access to the mains socket is guaranteed, so that in case of emergency the mains plug can be pulled immediately. During periods of prolonged non-use, the TV should be disconnected from the mains power supply.

TRADEMARK ACKNOWLEDGMENT

“Dolby” and the double-D symbol are trademarks of

Dolby Laboratories.

- 4 -

Licence Noti fi cation (Optional)

M a n u f a c t u r e d u n d e r l i c e n s e f r o m D o l b y

Laboratories.

Environmental Information

• This television is designed to consume less energy to save the environment.

You not only help to save the environment but you can also save money by reducing electricity bills thanks to the energy ef fi ciency features of this TV. To reduce energy consumption, you should take the following steps:

• You can use the Power Save Mode setting, located in the Other settings menu. If you set the Power Save

Mode as On, the TV will switch to energy-saving mode and the luminance level of the TV set will be decreased to optimum level. Note that some picture settings will be unavailable when the TV is in Power Save Mode.

• When the TV is not in use, please switch off or disconnect the TV from the mains plug. This will also reduce energy consumption.

• Note that annually, using the TV set in Power Save Mode has more power ef fi ciency than disconnecting the TV from the mains plug instead of keeping stand-by mode. Therefore it is highly recommended to activate Power Save Mode setting to reduce your annual power consumption. And also it is recommended to disconnect the TV from the mains plug to save energy more when you do not use.

• Please help us to save environment by following these steps.

Repair Information

Please refer all servicing to quali fi ed personnel. Only quali fi ed personnel must repair the TV. Please contact your local dealer, where you purchased this TV for further information.

- 5 -

Remote Control Buttons

1.

2.

3.

4.

5.

6.

No function

Play (in Media Browser mode)

Programme recording

Rapid reverse (in Media Browser mode)

7.

8.

9.

No function

Mono/Stereo - Dual I-II / Current Language (*) /

Play preview (in Media Browser mode)

Image size

Green button

Red button

10. Numeric buttons

11. Teletext / Mix

12. Info / Reveal (in TXT mode)

13. Programme Down - Page up / Programme Up -

Page down

14. Mute

15. Favourite mode selection

16. Exit (in DTV mode) / Return / Index page (in

TXT mode)

17. No function (*)

18. No function

19. Recordings Library

20. Picture mode selection

21. Electronic Programme Guide

22. Sleep timer

23. Menu on/off

24. OK / Select / Hold (in TXT mode) / Channel List

25. Volume up / down

26. Navigation buttons

27. AV / Source

28. Previous programme / Now (in EPG mode)

29. Blue button

30. Yellow button

31. No function (**)

32. Subtitle on-off / TXT subtitle (analogue TV mode) / Subtitle (in Media Browser mode).

33. No function

34. Rapid advance (in Media Browser mode)

35. Stop (in Media Browser mode)

36. Pause / Timeshift recording

37. Standby

38. Operation LED light

SCREEN

ZOOM

LANG

REPEAT

SUBTITLE

ROOT TITLE

1 2 3

4 5 6

7 8 9

TEXT

0

SWAP

INFO

P+

P-

OK

SOURCE

V+

V-

MENU

RETURN FAV SLEEP EPG

SEARCH

MODE

DISPLAY PRESETS

These buttons change according to the model:

/ Media Browser (optional) (*) or Angle / No function (*)

/ Web Browser (optional) (**) or Pip / Pip function

(optional) (**)

- 6 -

TV and Operating Buttons

FRONT and REAR VIEW Control switch VIEW Control Switch

MENU

P\CH

TV/AV

MENU

P\CH TV/AV

1.

2.

3.

4.

Standby button

TV/AV button

Programme Up/Down buttons

Volume Up/Down buttons

Note: Press

“ ” / “ ”

buttons at the same time to view main menu.

Viewing the Connections - Back Connectors

SPDIF

Coax.OUT

1.

2.

3.

4.

HDMI 2: HDMI Input

HDMI 1: HDMI Input

HDMI Inputs are for connecting a device that has a HDMI socket. Your TV is capable of displaying

High De fi nition pictures from devices such as a High De fi nition Satellite Receiver or DVD Player. These devices must be connected via the HDMI or Component source. These sockets can accept either 720p or 1080i signals. No sound connection is needed for a HDMI to HDMI connection.

RF Input connects to an aerial antenna system.

Note: If you use a decoder or a media recorder, you should connect the aerial cable through the device to the television with an appropriate antenna cable, as shown in the illustration in the following pages.

SCART input or output for external devices. Connect the SCART cable between the SCART socket on the

TV and the SCART socket on your external device (such as a decoder, a VCR or a DVD player).

Note: If an external device is connected via the SCART socket, the TV will automatically switch to AV mode.

- 7 -

5.

6.

Note : S-VHS signal is supported via the scart socket(optional).

VGA Input is for connecting a personal computer to the TV set.

Connect the PC cable between the PC INPUT on the TV and the PC output on your PC.

SPDIF Out outputs audio signals of the currently watched source.

Use an SPDIF cable to trasfer audio signals to a device that has SPDIF input.

1.

Viewing the Connections - Side Connectors

The CI Slot is used for inserting a CI card. A CI card allows you to view all the channels that you subscribe to. For more information, see “Conditional Access” section.

2.

3.

Side USB input.

Note: That programme recording feature is available via this USB input. You can connect external hard disk drives to this input.

Video Input is used for connecting video signals of external devices.Connect the video cable between the VIDEO IN socket on the TV and the VIDEO OUT jack on your device.

4. Audio Inputs are used for connecting audio signals of external devices. Connect the audio cable between the AUDIO INPUTS on the TV and the AUDIO OUTPUT jacks on your device.

Note: If you connect a device to the TV via the VIDEO INPUT, you should also connect your device with an audio cable to the AUDIO INPUTS of the TV to enable audio.

5. The headphone jack is used for connecting an external headphone to the system.

Connect to the HEADPHONE jack to listen to the TV from headphones.

Aerial Connection

• Connect the aerial to the AERIAL INPUT (ANT) socket located at the rear of the TV.

SPDIF

Coax.OUT

Power Connection

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.

• After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the mains.

- 8 -

Using USB Media

USB Connection

• You can connect a USB hard disk drive or USB memory stick to your TV by using the USB inputs of the TV. This feature allows you to play fi les stored in a USB drive or record programmes.

• 2.5” and 3.5” inch (hdd with external power supply) external hard disk drives are supported.

• To record a programme, you should fi rst connect a USB disk to your TV while the TV is switched off. You should then switch on the TV to enable recording feature. Otherwise, recording feature will not be available.

IMPORTANT !

• You may back up your fi les before making any connections to the TV set in order to avoid any possible data loss. Note that manufacturer will not be responsible for any fi le damage or dataloss.

• It is possible that certain types of USB devices (e.g.

MP3 Players) or USB hard disk drives/memory sticks may not be compatible with this TV.

IMPORTANT : The TV supports only FAT32 disk formatting. NTFS format is not supported. If you connect a USB disk with NTFS format, the TV will ask you to format the content. See the section, “Format

Disk” in the following pages for more information on disk formatting.

Note that ALL the data stored on the USB disk will be lost and then the disk format will be converted to

FAT32 in such a case.

USB Disk Connection

• Plug your USB device to the USB input of the TV.

Note: Plug or unplug your USB disk while the TV is switched off.

Note: If you are going to connect a USB hard disk drive to the TV set, USB connection cable used between the disk drive and the TV should have a USB logo and should be as short as possible.

Note: While formatting a USB hard disk that has 1TB

(Tera Byte) or more fi le capacity, you can experience problems with the formatting process. In such a case, you should format the disk with your personal computer and the formatted disk type should be

FAT32.

SIDE VIEW USB MEMORY

USB

5Vdc

Max:500mA

CAUTION !

• Quickly plugging and unplugging USB devices, is a very hazardous operation. Especially, do not repeatedly quickly plug and unplug the drive. This may cause physical damage to the USB player and especially the USB device itself.

• Do not pull out USB module while playing or recording a fi le.

Programme Recording

To record a programme, you should fi rst connect a

USB disk to your TV while the TV is switched off.

You should then switch on the TV to enable recording feature.

IMPORTANT: When using a new USB hard disk drive, it is recommended that you fi rst format the disk using your TV’s “Format Disk” option.

• For using recording function, you should connect a

USB disk or an external hard disk drive to the TV and connected USB disk should have at least 1 GB capacity and should have 2.0 speed compatibility.

If the connected USB device does not support 2.0 speed, an error message will be displayed.

Note: Recorded programmes are saved into the connected USB disk. If desired, you can store/copy recordings on a computer; however, these fi les will not be available to be played on a computer. You can play the recordings only via your TV.

• For more information on recording programmes, see sections “Instant Recording”, “Timeshifting”,

“Electronic Programme Guide”, “Recordings Library” or “Recording Timers” in the following parts.

• Recorded programmes are stored in the following directory of the connected USB disk: \DVR\RECS.

All recordings are indicated with a number. A text

(txt) fi le is created for each recording. This text file includes information such as broadcaster, programme, and recording time.

• Timeshifting may be stopped according to USB device write speed. If the USB device speed is not enough for video stream bitrate, timeshifting may be stopped and recording may fail. If HD service bitrate is greater than 13 Mbp/sec. some freeze can be seen during timeshifting on both USB disk and on external HDD.

• Recordings of HD programmes can occupy bigger size on the USB disk depending on the broadcast’s resolution. For this reason it is recommended to use USB hard disk drives for recording HD programmes.

• Do not plug out the USB/HDD during the recording.

This may harm the connected USB/HDD.

- 9 -

• Multipartiton support is available. Maximum two different partitions are supported. If the disk have more than two partitions, crash may occur. First partition of the usb disk is used for PVR ready features. It also must be formatted as primary partition to be used for PVR ready features.

• Some stream packets may not be recorded because of signal problems, so sometimes video may freezes during playback.

• Record, Play, Pause, Display (for PlayListDialog) keys could not be used when teletext is ON. If a recording starts from timer when teletext is ON, teletext is automatically turned off. Also teletext usage is disabled when there is ongoing recording or playback.

• Radio record is not supported.

• The Tv can record programmes up to ten hours.

Connecting the TV to a PC

For displaying your computer’s screen image on your

TV, you can connect your computer to the TV set.

Power off both computer and display before making any connections. Use a 15-pin D-sub display cable to connect a PC to the TV. When the connection is made, switch to PC source. See the Input selection section. Set the resolution that suits your viewing requirements. Resolution information can be found in the appendix.

Connecting to a DVD Player

If you want to connect a DVD player to your LCD

TV, you can use connectors of the TV set. DVD players may have different connectors. Please refer to your DVD player’s instruction book for additional information. Power off both the TV and the device before making any connections.

Note : Cables shown in the illustration are not supplied.

• If your DVD player has an HDMI socket, you can connect via HDMI. When you connect to DVD player as illustrated below, switch to HDMI source. See,

“Input Selection” section.

• Most DVD players are connected through

COMPONENT SOCKETS. Use a component video cable to connect video input. For enabling audio, use a component audio cable as illustrated below.

When the connection is made, switch to YPbPr source. See, “Input selection” section.

• You may also connect through the SCART. Use a

SCART cable as shown below.

Note : These three methods of connection perform the same function but in different levels of quality. It is not necessary to connect by all three methods.

Video Connection

PC input of the TV Audio inputs of the TV

PC audio cable

(not supplied)

PC VGA cable

(not supplied)

Scart socket

YPbPr to PC cable (optional) HDMI inputs

Audio output of the PC

Monitor output of the PC

DVD Player

Note: If you connect a PC to the TV using HDMI connection, radio interference may occur. Therefore this type of connection is not recommended. You should use VGA connection instead.

Using Side AV Connectors

You can connect a range of optional equipment to your LCD TV..

• For connecting a camcorder, connect to the VIDEO

IN socket and the AUDIO SOCKETS. Do not connect the camcoder to VIDEO IN socket at the same time since it can cause noise in the picture. For selecting the related source, see the section “Input selection” in the following parts.

• To listen the TV sound from headphones, connect to the HEADPHONE jack of theTV.

- 10 -

Remote Control Handset

Inserting Batteries

• Remove the battery cover located on the back of the handset by gently pulling backwards from the indicated part.

• Insert two AAA/R3 or equivalent type batteries inside. Observe the correct polarity (+/-) when inserting batteries and replace the battery cover.

Input Selection

Once you have connected external systems to your TV, you can switch to different input sources.

Press “ SOURCE ” button on your remote control consecutively for directly changing sources.

(optional)

Note: Remove the batteries from the remote control handset when it is not to be used for a long period.

Otherwise it can be damaged due to any leakage of batteries. Remote range is approximately 7m/23ft.

Note: YPbPr mode can be used only when you connect a device that has a YPbPr output through the

PC input with YPbPr to PC cable (not supplied).

Switching On/Off

Basic Operations

To Switch the TV On

• Connect the power cord to the 220-240V AC, 50 Hz.

Then the standby LED lights up (The led will blink during the standby On/Off).

You can operate your TV using both the remote control and onset buttons.

Operation with the Buttons on the TV

• To switch the TV on from standby mode either:

• Press the “ ” button, P+ or P or a numeric button on the remote control.

Volume Setting

• Press “ ” button to decrease volume or “

” button to increase volume, so a volume level scale

(slider) will be displayed on the screen.

• Press the control switch on the left hand side of the

TV. The TV will then switch on.

Programme Selection

Note: If you switch on your TV via P+ or P- buttons on the remote control or on the TV set, the programme that you were watching last will be reselected.

• Press “ P/CH + ” button to select the next programme or

“ P/CH ” button to select the previous programme.

Viewing Main Menu

To Switch the TV Off

• Press the “ ” button on the remote control or hold the on the TV until shut down, so the TV will switch to standby mode.

• Press “ ” / “ ” buttons at the same time to view main menu. In the Main menu select submenu using “ P/CH ” or “ P/CH + ” buttons and enter the sub-menu using “ ” or “ ” buttons.

To learn the usage of the menus, refer to the menu system sections. • To power down the TV completely, unplug the power cord from the mains socket.

Note: When the TV is switched to standby mode, the standby LED can blink to indicate that features such as Standby Search, Over Air Download or Timer is active

AV Mode

• Press the “ TV/AV ” button in the control panel on the

TV to switch between AV modes.

Operation with the Remote Control

• The remote control of your TV is designed to control all the functions of the model you selected. The functions will be described in accordance with the menu system of your TV.

- 11 -

• Functions of the menu system are described in the following sections.

Volume Setting

• Press V+ button to increase the volume. Press V- button to decrease the volume. A volume level scale

(slider) will be displayed on the screen.

Programme Selection (Previous or Next

Programme)

• Press P button to select the previous programme.

• Press P+ button to select the next programme.

Programme Selection (Direct Access)

• Press the numeric buttons on the remote control to select programmes between 0 and 9. The TV will switch to the selected programme.

First Time Installation

IMPORTANT: Ensure that the aerial is connected and a Common Interface module is not inserted before switching on the TV for the first time installation.

• When the TV is operated for the fi rst time, the installation wizard will guide you through the process. First, the language selection screen will be displayed:

• By pressing “ ” or “ ” button, select the country you want to set and press “ ” button to highlight

Teletext Language option. Use “ ” or “ ” button to select desired Teletext Language.

• Press “ ” button after setting Teletext Language option. Scan Encrypted will be then highlighted.

You should set the Scan Encrypted as Yes if you want to scan coded stations.Afterwards select the desired Teletext Language.

• Press OK button on the remote control to continue and the following message will be displayed on the screen:

To select the “Yes” or “No” option, highlight the item by using “ ” or “ ” buttons and press OK button.

Afterwards the following OSD will be displayed on the screen and the TV will search for both digital and analogue TV broadcasts.

• Use “ ” or “ ” buttons to select your language and press OK button to set the selected language and continue.

• After selecting the language, “ Welcome!

” screen will be displayed, requiring you to set Country,Teletext

Language and Scan Encrypted options.

Note: You can press “MENU” button to cancel.

End of the search process, “Choose Region” osd will be displayed on the screen (if any multiple region variants are detected).Please select country and region choice then press OK to continue.

• After all the available stations are stored, Channel

List will be displayed on the screen. If you like the sort channels, according to the LCN, please select

“Yes” and than press “OK”.

- 12 -

SUBTTL: Press SUBTITLE button to view Select

Genre menu. Using this feature, you can search the programme guide database in accordance with the genre. Info available in the programme guide will be searched and results matching your criteria will be listed.

SWAP(Now) : Shows the current programme.

(RECORD): the TV will start to record the selected programme. You can press again to stop the recording.

• Press OK button to quit channel list and watch TV

Viewing Electronic Programme

Guide (EPG)

You can view the electronic programme guide (EPG) to see information about available programmes.To view the EPG menu please press EPG button on the remote control.

• Press “ ”/“ ” buttons to navigate through channels.

• Press “ ”/“ ” buttons to navigate through the programme list.

• Please note that event information is updated automatically. If there is no event information data available for channels, the EPG will be displayed with blanks.

EPG Timeline Schedule

EPG Channel Schedule

Red button (Prev Day): Displays the programmes of previous day.

Green button (Next day): Displays the programmes of the next day.

Yellow button (Zoom) : Expands programme information.

Blue button (Filter): Views fi ltering options.

Numeric buttons (Jump) : Jumps to the preferred channel directly via numeric buttons.

INFO (Details): Displays the programmes in detail.

OK (Options): Views/records or sets timer for future programmes.

“ ” (Search): Displays “ Guide Search ” menu.

- 13 -

/ / / : Navigate

Red button (Prev Time Slice): Displays the programmes of previous time slice.

Green button (Next Time Slice): Displays the programmes of the next time slice.

Yellow button (Prev Day): Displays the programmes of previous day.

Blue button (Next day): Displays the programmes of the next day.

“ ” button (Filter): Views fi ltering options.

Numeric buttons (Jump) : Jumps to the preferred channel directly via numeric buttons.

OK (Options): Views/records or sets timer for future programmes.

INFO (Details): Displays the programmes in detail.

(RECORD): the TV will start to record the selected programme. You can press again to stop the recording.

EPG Now and Next

/ / / : Navigate

OK (Options): Views/records or sets timer for future programmes.

Blue button (Filter): Views fi ltering options.

INFO (Event Details): Displays the programmes in detail.

Green button: Programme schedule will be listed

Yellow button: Display EPG data in accordane with timeline schedule

(RECORD): the TV will start to record the selected programme. You can press again to stop the recording.

Recording via EPG Screen

IMPORTANT: To record a programme, you should fi rst connect a USB disk to your TV while the TV is switched off. You should then switch on the TV to enable recording feature. Otherwise, recording feature will not be available.

(RECORD): the TV will start to record the selected progamme. You can press again to stop the recording.

Note: Switching to a different broadcast or source is not available during the recording.

/ : Page left / Page right.

Programme Options

In EPG menu, press the OK button to enter the “Event

Options” menu.

Record / Delete Record Timer

IMPORTANT: To record a programme, you should fi rst connect a USB disk to your TV while the TV is switched off. You should then switch on the TV to enable recording feature. Otherwise, recording feature will not be available.

• After you have selected a programme in EPG menu, press the OK button and and Options screen will be displayed. Select “ Record ” option and press the

OK button. After this operation, a recording becomes set to the selected programme.

• To cancel an already set recording, highlight that programme and press the OK button and select the option “ Delete Rec. Timer ”. The recording will be cancelled.

Note: You cannot switch to any other channel or source while there is an active recording on the current channel.

Set Timer / Delete Timer

After you have selected a programme in EPG menu, press the OK button and and Options screen will be displayed. Select “ Set Timer on Event ” option and press OK button. You can set a timer for future programmes.

To cancel an already set reminder, highlight that programme and press the OK button. Then select

“ Delete Timer ” option. The timer will be cancelled.

Note: It is not possible to record or set timer for two or more individual events at the same time interval.

Installation

Press MENU button on the remote control and select Installation by using “ ” or “ ” button. Press

OK button and the following menu screen will be displayed.

Select Channel

In EPG menu, using this option, you can switch to the selected channel.

Select Automatic Channel Scan (Retune) by using “

”/“ ” button and press OK button. Automatic Channel

Scan (Retune) options will be displayed. You can select options by using “ ”/“ ” and OK buttons.

Auto Channel Scan (Retune) Menu

Operation

Analogue: Searches and stores analogue stations.

Digital & Analogue: Searches and stores both analogue and aerial DVB stations.

- 14 -

• Whenever you select an automatic search type and press OK button, a con fi rmation screen will appear on the screen. To start installation process, select

Yes , to cancel select No by using .“ ” or “ ” and

OK button.

• After the auto channel scan type is set and selected and con fi rmed, the installation process will start and the progress bar will move along. Press “MENU” button to cancel process. Located channels are not stored if the process is cancelled.

Manual Tuning

HINT: This feature can be used for direct broadcast entry.

• Select Manual Channel Scan from the Installation menu by using “ ”/“ ” and OK buttons. Manual

Scan options screen will be displayed.

• Select the desired Search Type using “ ” or

“ ” button. Manual search options will change accordingly. Use “ ”/“ ” button to highlight an item and then press “ ” or “ ” button to set an option.

You can press “MENU” button to cancel.

Digital Manual Search

Enter the channel number or frequency using the numeric buttons. You can then press OK button to search. When the channel is located, any new channels that are not on the list will be stored.

Analogue Fine Tune

• Select Analogue Fine Tune from the Installation menu by using “ ” or “ ” and OK buttons. The analogue fi ne tune screen will be displayed. The

Analogue Fine Tune feature will not be available if there are no analogue channels, digital channels and external sources stored.

• Press OK button to proceed. Use “ ” or “ ” button to set Fine Tune. When fi nished, press OK button again.

Managing Stations: Channel List

The TV sorts all stored stations in the Channel List.

You can edit this channel list, set favourites or set active stations to be listed by using the Channel List options.

• Press MENU button to view main menu. Select the

Channel List item by using “ ” or “ ” button. Press

OK to view menu contents.

In manual channel scan, the number of the multiplex or frequency are entered manually and only that multiplex or frequency are searched for the channels.

After selecting search type as Digital , you can enter the multiplex or frequency number using the numeric buttons and press OK button to search.

Analogue Manual Search

Select Edit Channel List to manage all stored channels. Use “ ” or “ ” and OK buttons to select

Edit Channel List.

Operating the Channel List

• Press “ ” or “ ” button to select the channel that will be processed. Press “ ” or “ ” button to select a function on Channel List menu.

• Use P+ or P buttons to move page up or down.

• Press BLUE button to view fi ltering options.

After selecting search type as analogue, you can use

“ ”/“ ” button to highlight an item and then press “

” or “ ” button to set an option.

•

- 15 -

Press MENU button to exit.

Moving a Channel

• First select the desired channel. Select Move option in the channel list and press the OK button.

• Edit Number screen will be displayed. Enter the desired channel number by using the numeric buttons on the remote control. If there is a previously stored channel on that number, a warning screen will be displayed. Select Yes if you want to move the channel and press OK .

• Press the OK button to process. Selected channel is now moved.

Deleting a Channel

You can press GREEN button to tag/untag all channels; YELLOW button to tag/untag channel.

• Select the channel that you want to delete and select

Delete option. Press the OK button to continue.

• A warning screen will appear. Select YES to delete, select No to cancel. Press the OK button to continue.

Renaming a Channel

• Select the channel that you want to rename and select Edit Name option. Press OK button to continue.

• Pressing “ ” or “ ” button moves to the previous/ next character. Pressing “ ” or “ ” button toggles the current character, i.e., ‘b’ character becomes ‘a’ by “ ” and ‘c’ by “ ”. Pressing the numeric buttons

‘0...9’ replaces the highlighted character with the characters printed above the button one by one as the button is pressed.

• When fi nished, press the OK button to save. Press

MENU to cancel.

Locking a Channel

You can press GREEN button to tag/untag all channels; YELLOW button to tag/untag a single channel.

• Select the channel that you want to lock and select

Lock option. Press OK button to continue.

• You will be asked to enter parental control PIN.

Default PIN is set as 0000 . Enter the PIN number.

Managing Stations: Favourites

You can create a list of favourite programmes.

• Press MENU button to view the main menu. Select

Channel List item by using “ ” or “ ” button. Press

OK to view menu contents.

• Select Favourites to manage favourite list. Use “

”/“ ” and OK buttons to select Favourites .

• You can set various channels as favourites so that only the favourite channels are navigated.

• Select a channel by using “ ” or “ ” button. Press

OK button to add selected channel to favourites list.

Press OK button again to remove.

Button Functions

• OK : Add/remove a station.

• YELLOW : Tag/untag a channel.

• GREEN : Tag/untag all channels.

• BLUE : Displays fi ltering options.

Managing Stations: Sorting the

Channel List

You can select broadcasts to be listed in the channel list. To display speci fi c types of broadcast, you should use the Active channel list setting.

Select Active channel list from the Channel list menu by using “ ” or “ ” button. Press OK button to continue.

• Press OK button when the desired channel is highlighted to lock/unlock the channel. The Lock symbol will be displayed next to the selected channel.

You can select a broadcast type option from the list by using “ ” /“ ” and OK buttons.

- 16 -

On-Screen Information

You can press INFO button to display on-screen information. Details of the station and current programme will be displayed on the information banner.

Viewing Videos via USB

The information banner gives information on the channel selected and the programmes on it. The name of the channel is displayed, along with its channel list number.

Hint: Not all channels broadcast the programme data. If the name and time of the programme are not available, then the information banner will be displayed with blanks.

If the selected channel is locked, you must enter the correct four-digit numeric code to view the channel

(default code is 0000 ). “ Enter PIN ” will be displayed on the screen.

Media Playback Using Media

Browser

If the USB stick is not recognized after power off/on or

First Time Installation, unplug the USB device, turn the

TV off and on again and re-insert the USB device.

To display the Media Browser window, press either

“ MENU ” button on the remote control and then select

Media Browser by pressing “ ” or “ ” button. Press

OK button to continue. Media Browser menu options will be displayed.

Also, when you insert USB devices, the media browser screen will be displayed automatically:

When you select Videos from the main options, the available video fi les will be fi ltered and listed on this screen. You can use “ ” or “ ” button to select a video fi le and press OK button to play a video. If you select a subtitle fi le and press OK button, you can select or deselect that subtitle fi le. The following menu will be displayed while playing a video fi le:

Play button) : Starts the video playback.

Stop ( button) : Stops the video playback.

Pause ( button) : Pause the video playback.

Rewind ( button) : Goes backward.

Forward ( button) : Goes forward.

Subtitle/Audio (LANG. button) : Sets subtitle/Audio.

Jump(GREEN button) : Jumps to the preferred channel.

Jump (GREEN button) : Jumps to time. Use numeric buttons to type the desired time and press GREEN button again to proceed.

Yellow : Opens subtitle time correction menu.

Ret/Back : Back to previous menu.

You can play music, picture and video fi les from the connected USB memory stick. Use “ ” or “ ” button to select Videos, Photos, Music, Recordings library or Settings.

Press YELLOW button to con fi m

Press “ ” button for clear

Press SWAP(Cancel) button to switch back to previous menu.

- 17 -

Viewing Photos via USB

When you select Photos from the main options, available image fi les will be fi ltered and listed on this screen.

Playing Music via USB

When you select Music from the main options, available audio fi les will be fi ltered and listed on this screen.

Jump (Numeric buttons) : Jump to selected fi le using the numeric buttons.

OK : Views the selected picture in full screen.

/ : Navigate menu

Slideshow ( button) : Starts the slideshow using all images.

GREEN button : Views images in thumbnails.

RED button : Sorts fi les by date.

Yellow Button : Change viewing style

BLUE : Changes media options.

Slideshow Options

Pause ( button) : Pauses the slideshow.

Continue ( button) : Continues the slideshow.

Loop/Shuf fl e (GREEN button) : Press once to disable

Loop. Press again to disable both Loop and Shuf fl e.

Press once more to enable only Shuf fl e. Press again to enable all. You can follow the disabled functions with the change of the icons.

Previous/Next (Left/Right buttons) : Jumps to previous or next fi le on slideshow.

Rotate (Up/Down buttons) : Rotates the image using up/down buttons.

RETURN (Exit) : Back to fi le list.

INFO : Displays help screen.

/ : Navigate menu

Play ( button) : Starts the playback.

Stop ( button) : Stops playback.

Pause ( button) : Pauses the selected playback.

RED button : Sorts fi les by Title,Artist or Album.

Loop/Shuf fl e (GREEN button) : Press once to disable

Loop. Press again to disable both Loop and Shuf fl e.

Press once more to enable only Shuf fl e. Press again to enable all. You can follow the disabled functions with the change of the icons.

Note:

If you start the playback with the button and activate the symbol, the TV will play the next music/video fi le. The playback will proceed accordingly and when the end of the list is reached, it will be played again from the beginning (loop function).

If you start the playback with the OK button and activate the symbol, the same music or video fi le will be played in a loop (repeat function).

If you start the playback with or OK button and activate the symbol, music or video fi le will be played in a shuf fl e.

If you start the playback with or OK button and activate , symbols, music or video fi le playback will continue randomly and the random playback will continue.

0..9 (Numeric buttons) : The TV will jump to the fi le starting with the letter you input via the numeric buttons on your remote control.

Play This (OK button) : Plays the selected fi le.

Previous/Next (Left/Right buttons) : Jumps to previous or next fi le to play.

Yellow Button : Change viewing style

BLUE : Changes media options.

- 18 -

Note: If the Viewing Style is set to Folder in Media

Browser Settings, Music folder will be displayed as sorted and there is no need to sort fi les again by pressing the FAV button.

INFO : Changes fi lter options.

Recordings Library

IMPORTANT: To view recordings library, you should fi rst connect a USB disk to your TV while the TV is switched off. You should then switch on the TV to enable recording feature. Otherwise, recording feature will not be available.

To view the list of recordings, select “ Recordings

Library ” and press the OK button. Recordings Library will then be displayed with available recordings.

Media Browser Settings

All the recordings are kept in a list in the recordings library.

RED button (Delete) : Erases the selected recording.

GREEN button (Edit) : Makes changes on the selected recording.

BLUE button (Sort) : Changes the order of the recordings. You can select from a wide range of sorting options.

OK button : Activates play options menu:

• Play from start: Plays the recording from the beginning.

• Resume: Recommences the recordings.

• Play from offset: Speci fi es a playing point.

Note: Viewing main menu and menu items will not ve available during the playback.

(Resume) : Recommences the recordings.

INFO (Details) : Displays the short extended programmes in detail.

You can set your Media Browser preferences by using the Settings dialog. Press “ ” or “ ” button to highlight an item and use “ ” or “ ” button to set.

View Style : Sets default browsing mode.

Music FF/FR Speed : Sets forwarding/advancing speed.

Slide Show Interval : Sets slide show interval time.

Show Subtitle : Sets subtitle enabling preference.

Subtitle Language : Sets supported subtitle language.

Subtitle Position : Sets subtitle position as up or down.

Subtitle Font Size : Sets subtitle font size (max. 54pt).

Timeshift Recording

IMPORTANT: To record a programme, you should fi rst connect a USB disk to your TV while the TV is switched off. You should then switch on the TV to enable recording feature. Otherwise, recording feature will not be available.

• Press (PAUSE) button while watching a broadcast for switching to timeshifting mode.

• In timeshifting mode, the programme is paused and simultaneously recorded to the connected USB disk (*). Press (PLAY) button again to watch the paused programme from the stopped moment.

• This playback is performed in x1 playback speed.

You will see the timeshift gap between the real and the timeshifted programme in the info bar.

• Use / (PREVIOUS/NEXT) buttons to move forward or backward on timeshift playback. When the timeshift is reached, timeshifting mode will be quitted and you will switch back to watching normal broadcast.

• Press (STOP) button to quit timeshifting mode.

(*) Similtaneous timeshifting recording’s duration depends on your connected USB disk’s file size and defined Max. Timeshift in the Recordings

Con fi guration menu. See the section, “Recordings” for more information on setting Max. Timeshift.

- 19 -

Note: Switching to a different broadcast or source; and viewing main menu are not available during the timeshifting.

• Lip Sync delay may occur during the timeshifting.

Instant Recording

IMPORTANT: To record a programme, you should fi rst connect a USB disk to your TV while the TV is switched off. You should then switch on the TV to enable recording feature. Otherwise, recording feature will not be available.

• Press (RECORD) button to start recording an event instantly while watching a programme. The following OSD appears on the screen:

Watching Recorded

Programmes

In the main menu, use “ ” or “ ” buttons to select

Media Browser. Highlight Recordings Library item by using “ ” or “ ” button and press OK button to enter.

Recordings Library will then be displayed.

IMPORTANT: To view recordings library, you should fi rst connect a USB disk to your TV while the TV is switched off. You should then switch on the TV to enable recording feature. Otherwise, recording feature will not be available.

• Record OSD will then be displayed for a short time and the current event will be recorded.

• You can press (RECORD) button on the remote control again to record the next event on the EPG. In this case, OSD will display the programmed events for recording.

Select a recorded item from the list (if previously recorded) by using “ ” / “ ” button. Press OK button to view Play Options . Select an option by using “ ”

/ “ ” or OK buttons.

Press (STOP) button to cancel instant recording.

The following OSD will be displayed:

Select Yes by using “ ” or “ ” / OK buttons to cancel instant recording.

Note: Switching to a different broadcast or source; and viewing Media Browser are not available during the recording.

Available playback options:

• Play from start: Plays the recording from the beginning.

• Resume: Recommences the recordings.

• Play from offset: Speci fi es a playing point.

Note: Viewing main menu and menu items will not be available during the playback.

Press (STOP) button to stop a playback and return to return to Recordings Library.

Slow Forward

If you press (PAUSE) button while watching recorded programmes, slow forward feature will be available. You can use button to slow forward.

Pressing button consecutively will change slow forwarding speed.

- 20 -

Changing Image Size: Picture

Formats

• You can change the aspect ratio (image size) of the TV for viewing the picture in different zoom modes.

• Press the SCREEN button repeatedly to change the image size. Available zoom modes are listed below.

Auto

When AUTO is selected, the aspect ratio of the screen is adjusted by the information provided by the selected source(if available)

Note: Auto mode only will be available in HDMI, YPbPr and DTV sources.

16:9

This uniformly stretches the left and right sides of a normal picture (4:3 aspect ratio) to fi ll the wide TV screen.

14:9 Zoom

This option zooms to the 14:9 picture.

4:3

Use to view a normal picture (4:3 aspect ratio) as this is its original size.

Panoramic

This stretches the left and right sides of a normal picture (4:3 aspect ratio) to fi ll the screen, without making the picture appear unnatural.

• For 16:9 aspect ratio pictures that have been squeezed into a normal picture (4:3 aspect ratio), use the 16:9 mode to restore the picture to its original shape.

Subtitle

This zooms up the wide picture (16:9 aspect ratio) with subtitles to the full screen.

The top and bottom of the picture are slightly cut off.

Cinema

This zooms up the wide picture (16:9 aspect ratio) to the full screen.

Note : You can shift to screen up or down by pressing

“ ” / “ ” buttons while picture zoom is selected as panaromic, 14:9 Zoom, Cinema or Subtitle.

14:9

This zooms up the wide picture (14:9 aspect ratio) to the upper and lower limits of the screen.

- 21 -

Con

fi

guring Picture Settings

You can use different picture settings in detail.

Press MENU button and select the Picture icon by using “ ” or “ ” button. Press OK button to view

Picture Settings menu.

Operating Picture Settings Menu Items

• Press “

• Use “

” or “ ” button to highlight a menu item.

” or “ ” button to set an item.

• Press MENU button to exit.

Picture Settings Menu Items

Mode : For your viewing requirements, you can set various screen modes. The Picture mode can be set to one of these options: Cinema , Game , Dynamic and Natural .

Contrast : Sets the lightness and darkness values of the screen.

Brightness : Sets the brightness value for the screen.

Sharpness : Sets the sharpness value for the objects displayed on the screen.

Colour : Sets the colour value, adjusting the colors.

Power Save Mode : Use “ ” or “ ” button to select

Power Save Mode.

Press “ ” or “ ” button to set Power Save Mode as

On or Off.

See the section, “Environmental Information” in this manual for further information on Power Save

Mode.

Note : The backlight function will be inactive if Power

Save Mode is set to on.

Backlight : This setting controls the backlight level and it can be set to Auto, Maximum, Minimum, Medium and Eco Mode (optional).

Note: Backlight can not be activate in VGA or Media

Browser mode or while picture mode is set as Game.

Noise Reduction : If the broadcast signal is weak and the picture is noisy, use Noise Reduction setting to reduce the noise amount. Noise Reduction can be set to one of these options: Low , Medium , High or Off .

Advanced Settings

• Colour Temp: Sets the desired colour tone.Setting

Cool option gives white colours a slight blue stress.For normal colours, select Normal option.

Setting Warm option gives white colours a slight red stress.

• Picture Zoom :Sets the picture size to Auto , 16:9 ,

Subtitle,14:9 , 14:9 Zoom, 4:3 , Panoramic or

Cinema.

• HDMI True Black: While watching from HDMI source, this feature will be visible in the Picture

Settings menu. You can use this feature to enhance blackness in the picture. You can set this feature as

“On” for activating HDMI True Black mode.

• Film Mode (optional) : Films are recorded at a different number of frames per second to normal television programmes.Press “ ” or “ ” buttons to select Film mode. Press “ ” or “ ” buttons to set this feature Auto or Off. Turn this feature to Auto when you are watching fi lms to see the fast motion scenes clearly.

• Colour Shift: Adjust the desired colour tone.

Reset : Resets the picture settings to factory default settings.

While in VGA (PC) mode, some items in Picture menu will be unavailable. Instead, VGA mode settings will be added to the Picture Settings while in PC mode.

PC Picture Settings

For adjusting PC picture items, do the following:

Press “ ” or “ ” button to select Picture icon. Picture menu appears on the screen.

Contrast, Brightness, Colour, Colour Temp and

Picture Zoom settings in this menu are identical to settings de fi ned in TV picture menu under “Main

Menu System”.

Sound,Settings and Source settings are identical to the settings explained in main menu system.

PC Position : Select this to display PC position menu items.

- 22 -

Autoposition : Automatically optimizes the display.

Press OK to optimize.

H Position : This item shifts the image horizontally to right hand side or left hand side of the screen.

V Position : This item shifts the image vertically towards the top or bottom of the screen.

Dot Clock : Dot Clock adjustments correct the interference that appear as vertical banding in dot intensive presentations like spreadsheets or paragraphs or text in smaller fonts.

Phase : Depending on the resolution and scan frequency that you input to the TV set, you may see a hazy or noisy picture on the screen. In such a case you can use this item to get a clear picture by trial and error.

Con

fi

guring Sound Settings

Sound settings can be con fi gured according to your personal preferences.

Press MENU button and select the Sound icon by using “ ” or “ ” button. Press OK button to view

Sound Settings menu.

In the equalizer menu, the preset can be changed to Music , Movie , Speech , Flat , Classic and User .

Press the MENU button to return to the previous menu.

Note : Equalizer menu settings can be changed manually only when the Equalizer Mode is in User .

Balance : This setting is used for emphasizing left or right speaker balance.

Headphone : Sets headphone volume.

Sound Mode: You can select Mono, Stereo, Dual I or Dual II mode, only if the selected channel supports that mode.

AVL : Automatic Volume Limiting (AVL) function sets the sound to obtain fi xed output level between programmes

(For instance, volume level of advertisements tend to be louder than programmes).

Dynamic Bass : Dynamic Bass is used to increase bass effect of the TV set.

Digital Out : Sets digital out audio type.

Con

fi

guring Your TV’s Settings

Detailed settings can be configured to suit your personal preferences.

Press MENU button and select Settings icon by using

“ ” or “ ” button. Press OK button to view Settings menu.

Operating Sound Settings Menu Items

• Press “

• Use “

” or “ ” button to highlight a menu item.

” or “ ” button to set an item.

• Press MENU button to exit.

Sound Settings Menu Items

Volume : Adjusts volume level.

Equalizer : Press OK button to view equalizer submenu.

- 23 -

Operating Settings Menu Items

• Press “ ” or “ ” button to highlight a menu item.

• Press OK button to select an item.

• Press MENU button to exit.

Settings Menu Items

Conditional Access : Controls conditional access modules when available.

Language : Con fi gures language settings.

Parental : Con fi gures parental settings.

Timers : Sets timers for selected programmes.

Date/Time : Sets date and time.

Sources : Enables or disables selected source options.

Other Settings : Displays other setting options of the TV set.

Using a Conditional Access

Module (not included)

IMPORTANT: Insert or remove the CI module only when the TV is SWITCHED OFF.

• In order to watch certain digital channels, a conditional access module (CAM) may be necessary. This module must be inserted in the CI slot of your TV.

• Obtain the Conditional Access Module (CAM) and the viewing card by subscribing to a pay channel company, then insert those to the TV using the following procedure.

• Insert the CAM and then the viewing card to the slot that is located in the terminal cover at the rear side of the TV.

• The CAM should be correctly inserted, it is impossible to insert fully if reversed. The CAM or the TV terminal may be damaged if the CAM is forcefully inserted.

Connect the TV to the mains supply, switch on and then wait for few moments until the card is activated.

• When no module is inserted, “ No Common

Interface module detected ” message appears on the screen.

• Refer to the module instruction manual for details of the settings.

Viewing Conditional Access Menu (*)

(*) These menu settings may change depending on the service provider.

Press MENU button and select the icon by using

“ ” or “ ” button. Press OK button to view Settings menu. Use “ ” or “ ” button to highlight Conditional

Access and press OK to view menu items.

Con

fi

guring Language

Preferences

You can operate the TV’s language settings using this menu.

Press MENU button and select the Settings icon by using “ ” or “ ” button. Press OK button to view

Settings menu. Use “ ” or “ ” button to highlight

Language and press OK to continue:

Use “ ” or “ ” button to set an item. Settings are stored automatically.

Menu : displays the system language.

Preferred

These settings will be used if available. Otherwise the current settings will be used.

• Audio : Sets the preferred audio language.

• Subtitle : Sets the subtitle language. Selected language will be seen in subtitles.

• Teletext : Sets teletext language.

• Guide : Sets the preferred Guide language.

Current (*)

(*) These settings can be changed if only the broadcaster supports. Otherwise, settings will not be available to be changed.

• Audio : Changes the audio language for the current channel.

• Subtitle : Sets the subtitle language for the current channel.

- 24 -

Parental Control

To prohibit viewing of certain programmes, channels and menus can be locked by using the parental control system.

This function enables or disables the menu protection system and allows the PIN code to be changed.

Press MENU button and select the Settings icon by using “ ” or “ ” button. Press OK button to view

Settings menu. Use “ ” or “ ” button to highlight

Parental and press OK to continue:

To display parental lock menu options, the PIN number should be entered. The factory default PIN number is 0000 .

After coding the correct PIN number, parental settings menu will be displayed:

Parental Settings Menu Operation

•

•

Select an item by using “

Use “

” or “ ” button.

” or “ ” button to set an item.

• Press OK button to view more options.

Menu Lock (optional) : Menu lock setting enables or disables the menu access. You can disable access to the installation menu or the whole menu system.

Maturity Lock (optional) : When set, this option gets the maturity information from the broadcast and if this maturity level is disabled, disables access to the broadcast.

Child Lock (optional) : When Child Lock is set, the TV can only be controlled by the remote control. In this case the control panel buttons will not work. Hence, if one of those buttons is pressed, Child Lock Is On will be displayed on the screen when the menu screen is not visible.

Set PIN : De fi nes a new PIN number. Use numeric buttons to enter a new pin number. You will need to enter your new pin a second time for veri fi cation purposes.

IMPORTANT : The factory default pin number is 0000 , if you change the pin number make sure you write it down and keep it safe.

Timers

To view Timers menu, press MENU button and select

Settings icon by using “ ” or “ ” button. Press OK button to view Settings menu. Use “ ” or “ ” button to highlight Timers and press OK to continue:

Setting Sleep Timer

This setting is used for setting the TV to turn off after a certain time.

• Highlight Sleep Timer by using “ ” or “ ” button.

• Use “ ” or “ ” button to set. The timer can be programmed between Off and 2.00

hours (120 minutes) in steps of 30 minutes.

Setting Programme Timers

You can set programme timers for a particular programme using this feature.

Press “ ” button to set timers on an event. Programme timer function buttons will be displayed on the screen.

Adding a Timer

• Press YELLOW button on the remote control to add a timer. The following menu appears on the screen:

Channel : Changes network type by using “ ” or “ ”.

Timer Type : You can select timer type as Record or Timer.

Date : Enter a date using the numeric buttons.

Start: Enter a starting time using the numeric buttons.

End : Enter an ending time using the numeric buttons.

Duration : Displays duration between the starting and ending time.

Repeat : Sets a timer to be repeated as Once, Daily or

Weekly. Use “ ” or “ ” buttons to select an option.

C h a n g e / D e l e t e : S e t s t h e c h a n g e / d e l e t e permission.

Playback : Sets the playback permission and parental settings.

• Press GREEN button to save the timer. Press RED button to cancel.

Change/Delete: Controls parental settings on timers.

Editing a Timer

• Select the timer you want to edit by pressing “ or “ ” button.

”

• Press GREEN button. Edit Timer menu screen will be displayed.

- 25 -

• When fi nished with editing, press GREEN button to save. You can press MENU button to cancel.

Deleting a Timer

• Select the timer you want to delete by pressing “

” or “ ” button.

• Press RED button.

• Select YES by using “ ” or “ ” buttons to delete the timer. Select NO to cancel.

Recording Con

fi

guration

Select Recording Con fi guration item in the Settings menu to con fi gure recording settings. The following menu is displayed for recording con fi guration.

requiring you to enter a pin number. If you have not changed the pin number, the factory default is 0000.

After you enter the pin, a pop-up menu appears on the screen to ensure that the hard disk should be formatted, select “YES” and press OK to format the hard disk. Select “NO” and press OK to cancel. Ensure you back up important recordings before you format the USB disk unit.

Hard Disk Info

To view the details about the USB disk, highlight Hard

Disk Info by using “ ” or “ ” key and press OK . USB disk information will be displayed:

Con

fi

guring Date/Time Settings

Select Date/Time in the Settings menu to con fi gure

Date/Time settings. Press OK button.

The following options are available for adjustments:

Start Early (*)

You set recording timer’s starting time to start earlier by using this setting.

(*) Available only for EU country options.

• Use “ ” or “ ” buttons to highlight Date / Time.

Date,Time,Time Settings Mode and Time Zone Setting will be available.

End Late (*)

You set recording timer’s end time to end later by using this settings.

(*) Available only for EU country options.

Max Timeshift

This setting allows you to set the maximum time allowed for timeshifting. Duration options are approximate and can change accordingly, depending on the broadcast received.

Format Disk

IMPORTANT: Note that ALL the data stored on the

USB disk will be lost and then the disk format will be converted to FAT32 if you activate this feature.

•If you want to delete all fi les on the connected USB hard disk drive or memory stick, you can use Format

Disk option.

• Also, if your USB disk malfunctions, you can try formatting the USB disk. In most cases formatting the USB disk will restore normal operation; however,

ALL the data stored on the USB disk will be lost in such a case.

• Press OK button while the Format Disk option is highlighted. A menu will appear on the screen,

- 26 -

Use “ ” or “ ” buttons to highlight the Time Settings

Mode. Time Settings Mode is set using “ ” or “ ” buttons. It can be set to AUTO or MANUAL.

When AUTO is selected, Date/Time and Time Zone options will not be available to be set. If MANUAL option is selected as the Time Zone can be altered:

• By pressing “ ” or “ ” buttons select Time Zone.

Use “ ” or “ ” buttons to change the Time Zone between GMT-12 or GMT+12. Date/Time on the top of the menu list will then change according to the selected Time Zone.

• Changes are automatically stored. Press MENU to exit.

Con

fi

guring Source Settings

You can enables or disable selected source options. The

TV will not switch to the disabled source options when

SOURCE button is pressed.

(optional)

Menu Timeout : Changes timeout duration for menu screens.

Scan Encrypted Channels : When this setting is on, search process will locate the encrypted channels as well. If it is set as Off , encrypted channels will not be located in automatic search or manual search.

Blue Background (Optional) : Activates or deactivates blue background system when the signal is weak or absent.

Software Upgrade : To ensure that your TV always has the most update information, you can use this setting. In order for the proper operation, please ensure that the TV is set to standby mode.

• Select Sources in the Settings menu and press OK button.

• Press“ ” or “ ” buttons to select a source.

• Use “ ” or “ ” button to enable or disable the selected source. Changes are automatically stored.

Note : YPbPr mode can be used only when you connect a device that has a YPbPr output through the

PC input with YPbPr to PC cable (not supplied).

Con

fi

guring Other Settings

To view general con fi guration preferences, select Other

Settings in the Settings menu and press OK button.

You can enable or disable automatic upgrade by setting Automatic Scanning option.

You can manually search for new software by selecting Scan for upgrade .

Application version: Displays the current application version.

Hard of Hearing : If the broadcaster enables any special signal concerning the audio, you can set this setting as On to receive such signals.

Audio Description : Audio description refers to an additional narration track for blind and visually impaired viewers of visual media, including television and movies. The description narrator talks through the presentation, describing what is happening on the screen during the natural pauses in the audio (and sometimes during dialogue, if deemed necessary).

You can use this feature, only if the broadcaster supports that additional narration track.

Auto TV Off: You can set the timeout value of auto off feature.After the timeout value is reached and the TV is not operated for selected time, the TV will go off.

Standby Search (optional) : Use “ ” or “ ” button to select Standby Search and then press “ ” or “

” button to set this setting as On or Off. If you change Standby Search to Off, this function will be unavailable.To use Standby search please make sure that you select Standby Search as On.

Operation

• Press “

• Use “

” or “ ” buttons to select an item.

” or “ ” button to set an option.

• Press OK button to view a sub-menu.

- 27 -

Other Features

Displaying TV Information : Programme Number,

Programme Name, Sound Indicator, time, teletext, channel type and resolution information is displayed on the screen when a new programme is entered or

“ INFO ” button is pressed.

Mute Function : Press “ ” button to disable sound.

Mute indicator will be displayed in the upper side of the screen. To cancel mute, there are two alternatives; the fi rst one is pressing the “ ” button and the second one is increasing the volume level.

Picture Mode Selection : By pressing PRESETS button, you can change Picture Mode settings in accordance with your viewing requirements. Available options are Dynamic, Natural, Cinema and Game.

Displaying Subtitles : You can enable subtitles by pressing the SUBTITLE button of the remote control.

Press SUBTITLE button again to disable subtitle function.

If “ Subtitle ” is On , pressing the “ ” button causes the following warning message display on the screen (** for UK only)

Teletext

The teletext system transmits information such as news, sports and weather on your TV. Note that if the signal degrades, for example in poor/adverse weather conditions, some text errors may occur or the teletext mode may be aborted.

Teletext function buttons are listed below:

“ ” Teletext / Mix : Activates teletext mode when pressed once. Press again to place the teletext screen over the programme (mix).Pressing again will quit the teletext mode.

“RETURN” Index : Selects the teletext index page.

“INFO”Reveal : Shows hidden information (e.g. solutions of games).

“OK” Hold : Holds a text page when convenient. Press again to resume.

“ ”/“ ” Subcode Pages : Selects subcode pages if available when the teletext is activated.

P+ or P- and numbers (0-9) : Press to select a page.

Note: Most TV stations use code 100 for their index pages.

Coloured Buttons (RED/GREEN/YELLOW/

BLUE)

Your TV supports both FASTEXT and TOP text systems. When these systems are available, the pages are divided into groups or topics. When

FASTEXT system is available, sections in a teletext page will become colour-coded and can be selected by pressing the coloured buttons. Press a coloured button that corresponds to with your needs. The coloured writings will appear, showing you which coloured buttons to use when TOP text transmission is present. Pressing “ ” or “ ” commands will request the next or previous page respec tively.

Digital Teletext

• Press the “ ” button.

• The digital teletext information appears.

• Operate it with the coloured buttons, cursor buttons and OK button.

The operation method may differ depending on the contents of the digital teletext.

Follow the instructions displayed on the digital teletext screen.

• When the “ ” button is pressed, the TV returns to television broadcasting.

• The aspect ratio (picture shape) when watching a channel with just digital teletext broadcasting is the same as the aspect ratio of the picture viewed previously.

- 28 -

Tips

Screen Care : Clean the screen with a slightly damp, soft cloth. Do not use abrasive solvents as they may damage the coating layer of the TV screen. For your safety, unplug the mains plug when cleaning the set.

When moving the TV, hold it properly from the bottom of the unit.

Image Persistence : Please note that ghosting may occur while displaying a persistent image. On LED

TVs’ image persistence may disappear after a short time. Try turning the TV off for a while.

To avoid this, do not leave the screen in still picture for extended periods.

No Power : If your TV system has no power, please check the main power cable and connection to the mains socket outlet.

Poor Picture : Have you selected the correct TV system? Is your TV set or house aerial located too close to a non-earthed audio equipment or neon lights, etc.?

Mountains or high buildings can cause double pictures or ghost images. Sometimes you can improve the picture quality by changing the direction of the aerial.

Is the picture or teletext unrecognisable? Check if you have entered the correct frequency. Please retune the channels. The picture quality may degrade when two peripherals are connected to the TV at the same time.

In such a case, disconnect one of the peripherals.

No Picture : Is the aerial connected properly? Are the plugs connected tightly to the aerial socket? Is the aerial cable damaged? Are suitable plugs used to connect the aerial? If you are in doubt, consult your dealer. No Picture means that your TV is not receiving a transmission. Have you selected the correct button on the remote control? Try once more. Also make sure the correct input source has been selected.

Sound : If you cannot hear any sound, check to see if the “ ” button has been pressed. If sound is coming from only one speaker, check if the audio balance has been set to one extreme.

Remote Control : Your TV no longer responds to the remote control. Perhaps the batteries are exhausted.

If so you can still use the local buttons on the TV.

Input Sources : If you cannot select an input source, it is possible that no device is connected. Check the AV cables and connections if you have tried to connect a device

Recording Unavailable : To record a programme, you should fi rst connect a USB disk to your TV while the

TV is switched off. You should then switch on the TV to enable recording feature. Otherwise, recording feature will not be available. If you cannot perform recording, try switching off the TV and then re-inserting the USB device while the TV is switched off.

USB Is too Slow : If “USB is too slow” message is displayed on the screen while starting a recording, try restarting the recording. If you still get the same error, it is possible that your USB disk does not meet the speed requirements. Try connecting another

USB disk.

- 29 -

Appendix A: PC Input Typical

Display Modes

The display has a maximum resolution of 1920 x 1200.

The following table is an illustration of some of the typical video display modes. Your TV may not support different resolutions. Supported resolution modes are listed below. If you switch your PC to an unsupported mode, a warning OSD will appear on the screen.

Index

1

2

3

4

5

6

7

20

21

22

23

16

17

18

19

12

13

14

15

8

9

10

11

Resolution

640x350

640x400

640x480

800x600

832x624

1024x768

1152x864

1280x768

1280x768

1280x768

1280x960

1280x1024

1360x768

1400x1050

1400x1050

1400x1050

1400x900

1600x1200

1680x1050

1920x1080

1920x1080

1920x1200

1920x1200

Frequency

85 Hz

70 Hz

60Hz-66Hz-72Hz

-75Hz-85Hz

56Hz-60Hz-70Hz-72Hz

-75Hz-85Hz

75 Hz

60Hz-66Hz-70Hz-72Hz

-75Hz

60Hz-70Hz-75Hz

-85 Hz

60 HzA

60 HzB

75Hz-85Hz

60Hz-75Hz-85Hz

60Hz-75Hz-85Hz

60 Hz

60 HzA

60 HzB

75Hz-85Hz

65Hz-75Hz

60 Hz

60 Hz

60 HzA

60 HzB

60HzA

60Hz

Appendix B: AV and HDMI Signal

Compatibility (Input Signal Types)

Source

EXT

(SCART)

Side AV

YPbPr

HDMI1

HDMI2

1080I

1080P

1080P

480I

480P

576I

576P

720P

720P

1080I

1080I

1080P

1080P

1080P

1080P

Supported Signals Available

PAL 50/60

NTSC 60

O

O

RGB 50

RGB 60

PAL 50/60

NTSC 60

O

O

O

O

480I

480P

576I

576P

720P

720P

1080I

60Hz

60Hz

50Hz

50Hz

50Hz

60Hz

50Hz

O

O

O

O

O

O

O

60Hz

50Hz

60Hz

60Hz

60Hz

50Hz

50Hz

50Hz

60Hz

50Hz

60Hz

24Hz

25Hz

30Hz

50Hz

O

O

O

O

O

O

O

O

O

O

O

O

O

O

O

1080P 60Hz O

(X: Not Available, O: Available)

In some cases a signal on the LCD TV may not be displayed properly. The problem may be an inconsistency with standards from the source equipment (DVD, Set-top box, etc. ). If you do experience such a problem please contact your dealer and also the manufacturer of the source equipment.

- 30 -

6

19

20

21

22

15

16

17

18

23

24

25

11

12

13

14

7

8

9

10

Appendix C: Supported DVI

Resolutions

When connecting devices to your TV’s connectors by using DVI to HDMI cables (not supplied), you can refer to the following resolution information.

Index

1

Resolution

640x400

2

3

4

5

640x480

800x600

832x624

1024x768

1152x864

1152x870

1280x768

1280x768

1280x768

1280x960

1280x1024

1360x768

1400x1050

1400x1050

1400x1050

1400x900

1600x1200

1680x1050

1920x1080

1920x1080

1920x1200

1920x1200

480i-480p

576i-576p

Frequency

70Hz

60Hz-66Hz-72Hz

-75Hz

56Hz-60Hz-70Hz-

72Hz -75Hz

75 Hz

60Hz-66Hz-70Hz-

72Hz -75Hz

60Hz-70Hz-75Hz

75Hz

60 HzA

60 HzB

75Hz

60Hz-75Hz

60Hz-75Hz

60 Hz

60 HzA

60 HzB

75Hz

65Hz-75Hz

60 Hz

60 Hz

60 HzA

60 HzB

60HzA

60Hz

60Hz

50Hz

Appendix D: Software Upgrade

• Your TV is capable of fi nding and updating new software upgrades over broadcast channels.

• For broadcast channels search, the TV looks at the available channels stored in your settings. So before the software upgrade search, it is advised to auto search and update all available channels.

1) Software upgrade search via user interface

• It is possible to manually to check if there is a new software upgrade for your TV set.

• Simply navigate on your main menu. Choose

Settings and select Other Settings menu. In Other

Settings menu navigate on to the Software Upgrade item and press OK button to open Upgrade Options menu.

• In Upgrade Options menu select Scan for upgrade and press OK button.

• If a new upgrade is found, it starts to download the upgrade. A progress bar indicates the remaining download progress. When the download completes successfully a message is displayed for reboot to activate new software. Press OK to continue with the reboot operation.

2) 3.AM search and upgrade mode

• If Automatic scanning in Upgrade Options menu is enabled, the TV wakes up at 03:00 and searches the broadcast channels for new software upgrade. If new software is found and downloaded successfully, with the next power up the TV opens with new software version.

Note on reboot operation : Reboot is the last step in software upgrade operation if download of new software is fi nished successfully. During reboot TV makes fi nal initializations. In the reboot sequence panel power is closed and front led indicates the activity with blinking. Around 5 minutes later TV restarts with new software activated.

• If your TV fails to restart in 10 minutes, unplug power for 10 minutes and re-plug again. TV should open with new software safely. If you still can not get TV working, please kindly repeat unplug and plug sequence a few times more. If your set still can not operate, please call the service personnel to fi x the problem for you.

Caution: While the LED is blinking during reboot do not unplug your TV’s power. Doing this may cause your TV not to re-start again and can only be fi xed by service personnel.

- 31 -

Appendix E : Supported File Formats for USB Mode

Media

File

Extension

.mpg, .mpeg

.dat

.vob

Movie

Music


.avi

.mp3

.jpg .jpeg

Video

MPEG1, 2

Format

Audio

MPEG Layer 1/2/3

MPEG1, 2

MPEG2

MPEG2

MPEG2

PCM/MP3

Xvid 1.00, Xvid 1.01,

Xvid 1.02, Xvid 1.03,

Xvid 1.10-beta1/2

PCM

Remarks

(Maximum resolution/Bit rate etc.)

MAX 1920x1080 @ 30P 20Mbit/sec

MAX 1920x1080 @ 30P 20Mbit/sec

-

MPEG 1 Layer 1 / 2

(MP3)

Baseline JPEG

Progressive JPEG

32Kbps ~ 320Kbps(Bit rate)

32KHz ~ 48KHz(Sampling rate) max WxH = 15360x8640 4147200bytes max WxH = 1024x768 6291456bytes

max WxH = 9600x6400 3840000bytes

Subtitle

.bmp

.sub

.srt

-

Products

Battery

Information for Users on Disposal of old Equipment and

Batteries

[European Union only]

These symbols indicate that equipment with these symbols should not be disposed of as general household waste. If you want to dispose of the product or battery, please consider the collection systems or facilities for appropriate recycling.

Notice : The sign Pb below the symbol for batteries indicates that this battery contains lead.

- 32 -

Speci

fi

cations

TV BROADCASTING

PAL/SECAM B/G D/K K’ I/I’ L/L’

RECEIVING CHANNELS

VHF (BAND I/III)

UHF (BAND U)

HYPERBAND

NUMBER OF PRESET CHANNELS

1000

CHANNEL INDICATOR

On Screen Display

RF AERIAL INPUT

75 Ohm (unbalanced)

OPERATING VOLTAGE

220-240V AC, 50 Hz

AUDIO

German + Nicam Stereo

AUDIO OUTPUT POWER (W

RMS.

) (10% THD)

2 x 6

POWER CONSUMPTION (W)

150 W (max)

< 0,5 W (Standby)

PANEL

16:9 display, 32” Screen Size

DIMENSIONS (mm)

DxLxH (With foot): 212 x 776 x 567

Weight (Kg): 12,30

DxLxH (Without foot): 94 x 776 x 524

Weight (Kg): 11,60

Digital

Reception

DVB-T

MHEG-5 ENGINE compliant with ISO/IEC 13522-5 UK engine Pro fi le 1

Object carousel support compliant with ISO/IEC 135818-6 and UK DTT pro fi le

Frequency range: 474-850 MHz for UK models

170-862 MHz for EU models

Transmission standard: DVB-T. MPEG-2

Demodulation: COFDM with 2K/8K FFT mode

FEC: all DVB modes

Video: MP@ML, PAL, 4:3/16:9

Audio: MPEG Layer I&II 32/44.148kHz.

- 33 for UK

Important Instruction

For your own safety read following instruction carefully before attempting to connect this unit to the mains supply.

MAINS (AC) OPERATION

The wires in the mains lead are coloured in accordance with the following code :

GREEN

&

YELLOW

(Earth)

(if there is earth cable)

FUSE

BLUE

(Neutral)

BROWN

(Live)

IMPORTANT

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured green and yellow must be connected to the terminal which is marked with the letter E, or by the earth symbol, or coloured green or green and yellow.

The wire which is coloured blue or black must be connected to the terminal which is marked with the letter N or coloured Black.

The wire which is coloured brown or red must be connected to the terminal which is marked with the letter L or coloured Red.

For continued protection against risk of fi re, replace only with same type and rating of fuse (ASTA approved 5A 250VAC fuse).

CAUTION

TO PREVENT ELECTRIC SHOCK DISCONNECT FROM THE MAINS BEFORE REMOVING

COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

SAFETY PRECAUTION

THIS EQUIPMENT MUST BE DISCONNECTED FROM THE MAINS WHEN NOT IN USE. DO NOT

ALLOW THIS UNIT TO BE EXPOSED TO RAIN OR MOISTURE.

- 34 -

www.finluxdirect.com

Customer helpline: 0845 459 5282
