mapping software user’s manual
®
© Copyright 2004-2005 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 E. 151 st Street,
Olathe, Kansas 66062 U.S.A.
Tel. 913/397.8200 or 800/800.1020
Fax. 913/397.8282
Garmin (Europe) Ltd.
Unit 5, The Quadrangle,
Abbey Park Industrial Estate,
Romsey, SO51 9DL U.K.
Tel. 44/0870.8501241
Fax. 44/0870.8501251
Garmin Corporation
No. 68, Jangshu 2 nd Road,
Shijr, Taipei County, Taiwan
Tel. 886/2.2642.9199
Fax. 886/2.2642.9099
All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded, or stored in any storage medium for any purpose without prior written consent of Garmin. Garmin hereby grants permission to download a single copy of this manual and of any revision to this manual onto a hard drive or other electronic storage medium to be viewed, and to print one copy of this manual or any revision hereto, provided that such electronic or printed copy of this manual must contain the complete text of this copyright notice and provided further that any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited.
Information in this document is subject to change without notice. Garmin reserves the right to change or improve its products and to make changes in the content without obligation to notify any person or organization of such changes or improvements. Visit the
Garmin Web site (www.garmin.com) for current updates and supplemental information concerning the use and operation of this and other Garmin products.
Garmin ® , BlueChart ® , City Select ® , MapSource ® , MetroGuide ® , and iQue ® are registered trademarks and Que ™ is a trademark of
Garmin Ltd. or its subsidiaries, and may not be used without the express written permission of Garmin.
July 2005 Part Number 190-00417-20 Rev. C Printed in Taiwan
Introduction ........................................................ii
Serial Number ........................................................... ii
Contact Garmin ......................................................... ii
Map Data Information .............................................. ii
Installing MapSource ........................................1
Unlocking Maps ....................................................1
Unlock Codes and Coupon Codes ............................ 1
Saving and Viewing Unlock Codes .......................... 3
Updating Personal Information ................................ 5
Registering Your Product .......................................... 6
Changing or Removing MapSource ...................6
Repairing MapSource ............................................... 6
Modifying Coverage Areas ....................................... 7
Removing MapSource .............................................. 7
Connecting Your GPS Unit to a Computer .........8
Using MapSource ..............................................9
Parts of MapSource ..............................................9
Loading Maps to Your Garmin GPS Unit ..........10
Selecting Maps ....................................................... 10
Adding Maps from Multiple MapSource
Products ............................................................. 12
Transferring MapSource Data ...........................13
iQue ® Users ............................................................. 13
Sending Data to Your GPS Unit ............................ 15
MapSource User’s Manual
I
NTRODUCTION
> T
ABLE OF
C
ONTENTS
Receiving Data from Your GPS Unit ...................... 16
Creating and Editing Waypoints .......................17
Creating Waypoints ................................................ 17
Editing Waypoints .................................................. 18
Finding Places ....................................................18
Finding Nearest Places and Recently Found
Places ................................................................ 19
Creating and Editing Routes .............................20
Creating Routes ...................................................... 20
Editing Routes ........................................................ 21
Tracks ..................................................................22
Viewing Tracks ....................................................... 22
Filtering Tracks ....................................................... 23
Customizing MapSource ...................................23
Warnings and Cautions ..................................24
Index .................................................................25
For additional instructions while you are using
MapSource, click Help > MapSource Help or press F1 on your keyboard to open the detailed
MapSource Help files.
i
ii
I
NTRODUCTION
I
NTRODUCTION
Thank you for choosing Garmin ® MapSource ® —the complete tool for managing your Garmin GPS unit. MapSource provides detailed geographic data that you can view on your computer or load on your GPS unit. This manual has been provided to get you started. For detailed information about using MapSource, refer to the Help system.
Serial Number
Use this area to record the serial number (8-digit number located on the back of the box) in case your MapSource software needs service. Keep your original sales receipt in a safe place or attach a photocopy inside the manual.
Serial Number: ____ ____ ____ ____ ____ ____ ____ ____
Contact Garmin
Contact Garmin if you have any questions or if you should encounter any difficulty while using MapSource.
In the U.S.A, contact Garmin Product Support by phone at
913/397.8200 or 800/800.1020, Monday–Friday, 8 AM–5 PM
Central Time; or by e-mail at [email protected].
In Europe, contact Garmin (Europe) Ltd. at 44/0870.8501241.
Map Data Information
One of Garmin’s goals is to provide customers with the most complete and accurate cartography available to us at a reasonable cost. We use a combination of governmental and private data sources, which we identify as required in product literature and copyright messages displayed to the consumer.
Virtually all data sources contain inaccurate or incomplete data to some degree. This is particularly true for areas outside the
United States, where complete and accurate digital data is either not available or is prohibitively expensive.
If the data source lacks a feature, or if an item is mislocated or misidentified, it will be incorrectly identified or missing in the
Garmin cartography product as well. Each MapSource product has its strengths and weaknesses, and not all are suitable for every purpose. Please keep this in mind as you use and enjoy the benefits the cartography provides.
Garmin encourages customers to report any errors found in our electronic maps by completing our online Error Reporting Form in the Cartography section of our Web site: http://www.garmin
.com/cartography/mapSource/errorForm.html
.
MapSource User’s Manual
I
NSTALLING
M
AP
S
OURCE
Unlocking Maps
Some MapSource products need to be unlocked before you can use the detailed map data. If your product needs to be unlocked, you will find a piece of paper in the product box with an Unlock Code or a Coupon
Code.
If you just finished installing MapSource, the
UnlockWizard opens automatically. You can also unlock your maps from within MapSource. Click the
Utilities menu and then select Unlock Maps.
I
NSTALLING
M
AP
S
OURCE
> U
NLOCKING
M
APS
Unlock Codes and Coupon Codes
An Unlock Code is 25 characters and is printed on a yellow piece of paper. It unlocks all maps associated with your MapSource product. The yellow paper also includes a serial number and a 7-digit Registration
Code. To unlock your product with a 25-Character
.
A Coupon Code is 8 characters and is printed on the
Unlock Certificate. It unlocks a map region of your
MapSource product. To unlock your product with an
8-character Coupon Code, see
NOTE: Keep your Unlock Code or Coupon Code in a safe place. You may need this information if you reinstall MapSource. Garmin cannot give refunds or exchanges for MapSource Unlock
Codes.
MapSource User’s Manual 1
I
NSTALLING
M
AP
S
OURCE
> U
NLOCKING
M
APS
To unlock your product with a 25-Character
Unlock Code:
NOTE: An Internet connection is required for the following procedure.
1. In MapSource, click Utilities > Unlock Maps.
Then click Next.
2. Click Yes, I have a 25-character unlock code.
Then click Next.
3. Click I have an Unlock certificate, I will type it
in. Then click Next.
UnlockWizard
4. Enter your 25-character unlock code and then a comment, if desired. Click Next.
5. If you would like to register your product, you can do so at this time by clicking Yes, I have
a new Registration Code. Enter the 7-digit registration code on the yellow piece of paper.
Click Next and follow the on-screen instructions to register your product.
If you would like to register your product later, click No, I will register my product later and click Next. You can now close the UnlockWizard and use MapSource.
To unlock your product with an 8-character
Coupon Code:
NOTE: An Internet connection is required for the following procedure.
1. In MapSource, click Utilities > Unlock Maps.
Then click Next.
2. Click No, I need to get a 25-character unlock
code. Then click Next.
3. Enter your personal information in the fields provided and click Next.
2 MapSource User’s Manual
4. Select whether you are a new customer or an existing customer. Click Next. If you are an existing customer, enter your Garmin Customer
Code and click Next.
5. To continue, you need either your GPS unit’s internal Unit ID or Serial Number.
To get the Unit ID, follow the appropriate steps in the UnlockWizard. To enter the unit’s Serial
Number, find the number on the back of the unit’s casing and enter it in the space provided.
6. Enter the 8-character Coupon Code found on your Unlock Certificate. Click Next.
I
NSTALLING
M
AP
S
OURCE
> U
NLOCKING
M
APS
7. Select and verify the region that you would like to unlock. After checking the box to agree to the terms, click Next to complete the unlock process. You can now close the UnlockWizard and use MapSource.
Saving and Viewing Unlock Codes
If you ever need to view your Unlock Code, you can do so using the UnlockWizard. You may also want to back up your Unlock Codes to a safe location on your computer in case you need to reinstall MapSource.
If you registered your MapSource product, you can retrieve your Unlock Code from Garmin.
To view your installed Unlock Codes:
1. In MapSource, click Utilities > Unlock Maps.
Then click Next.
2. Click View my installed unlock codes. Then click Next.
Enter your Coupon Code.
MapSource User’s Manual 3
I
NSTALLING
M
AP
S
OURCE
> U
NLOCKING
M
APS
4
Select View my installed unlock codes.
3. The UnlockWizard displays a list of all of the installed MapSource products.
To view the Unlock Code for a product, highlight the product and then click Properties.
To delete an Unlock Code for a product, highlight the product and click Delete.
To back up your Unlock Code:
1. In MapSource, click Utilities > Unlock Maps.
Then click Next.
2. Click Backup my unlock codes to a file. Then click Next.
3. Browse to the folder where you want to store your Unlock Codes.
NOTE: Garmin recommends that you save the back up file to a separate location other than the
MapSource folder.
4. Enter a file name for your Unlock Codes and click Save.
5. The UnlockWizard saves all of your Unlock
Codes into that file for future use. You can now close the UnlockWizard.
To restore your (saved) Unlock Codes:
1. In MapSource, click Utilities > Unlock Maps.
Then click Next.
2. Click Retrieve and reinstall all my Garmin
unlock codes. Then click Next.
3. Select Retrieve my codes from a file on my
PC.
4. Browse for the file where you saved your
Unlock Code and click Open.
5. Your codes should now be restored to
MapSource. Select Yes to return to the
UnlockWizard Options menu or select No, I am
done to exit the UnlockWizard.
MapSource User’s Manual
To retrieve your Unlock Code from Garmin:
NOTE: An Internet connection is required for the following procedure.
1. In MapSource, click Utilities > Unlock Maps.
Then click Next.
2. Click Retrieve and reinstall all my Garmin
unlock codes. Then click Next.
3. If you have registered your MapSource products with Garmin, click Retrieve my unlock codes
from the Garmin Server. Then click Next.
4. Enter your Garmin Customer Code and click
Next. The products you have registered through the Garmin Web site appear. Click Next.
5. Your codes are restored to MapSource. Close the UnlockWizard.
I
NSTALLING
M
AP
S
OURCE
> U
NLOCKING
M
APS
Updating Personal Information
You can update your personal information on file with
Garmin at any time using your Garmin Customer Code and the UnlockWizard.
NOTE: An Internet connection is required for the following procedure.
To update your information with Garmin:
1. In MapSource, click Utilities > Unlock Maps.
Then click Next.
2. Select Update my Garmin account
information and click Next.
3. Enter your Garmin Customer Code. Click Next.
4. Review the products registered in your name and click Next.
5. The Garmin Web site opens in your browser.
Review your personal information and make any adjustments as necessary.
MapSource User’s Manual 5
I
NSTALLING
M
AP
S
OURCE
> C
HANGING OR
R
EMOVING
M
AP
S
OURCE
Registering Your Product
If you have not already registered your product using the UnlockWizard, you can register on Garmin’s Web site at https://www.garmin.com/registration/selectreg
.jsp
.
We highly recommend that you register your
MapSource product to gain important benefits:
• You can be notified of product updates as they occur.
• You have proof of purchase on file with Garmin in case your product needs service.
• You have access to reduced-rate mapping data updates.
Changing or Removing
MapSource
You can repair MapSource if it becomes corrupted.
For some MapSource products, you can modify the regional coverage area. You can also remove any
MapSource product from your computer.
Repairing MapSource
In some MapSource products, you can repair
MapSource if it becomes corrupt. If this option is not available, you can uninstall and reinstall the product.
NOTE: You need your MapSource installation disks to repair MapSource.
To repair MapSource:
1. Insert the MapSource installation disk into your computer disk drive. The InstallShield Wizard opens. Click Next.
2. Select Repair and click Next.
3. Follow the additional instructions to repair
MapSource.
6 MapSource User’s Manual
Modifying Coverage Areas
Some MapSource detailed map products allow you to modify the regional coverage areas. If your MapSource product allows this, Modify appears as an option when you open the MapSource InstallShield Wizard.
NOTE: You need your MapSource installation disks to modify MapSource.
To add or remove specific coverage areas:
1. Insert the MapSource installation disk into your computer disk drive. The InstallShield Wizard opens. Click Next.
2. Select Modify and click Next.
3. Select the areas you want to add or remove.
Click Next.
4. Follow the additional instructions to modify
MapSource.
I
NSTALLING
M
AP
S
OURCE
> C
HANGING OR
R
EMOVING
M
AP
S
OURCE
Removing MapSource
You can remove any MapSource product from your computer without using the MapSource installation disks.
To remove MapSource:
1. Click the Start button. Then select Settings >
Control Panel.
2. From the Control Panel page, select Add/
Remove Programs.
3. Highlight MapSource and click Change/
Remove.
4. Follow the instructions to remove MapSource.
OR
1. Click the Start button. Then select Programs
> MapSource > MapSource product
Installation Wizard (if enabled).
2. Click Next.
3. Select Remove.
MapSource User’s Manual 7
I
NSTALLING
M
AP
S
OURCE
> C
ONNECTING
Y
OUR
GPS U
NIT TO A
C
OMPUTER
Connecting Your GPS Unit to a
Computer
Install your MapSource software or run the installation disk for your product before you connect your GPS unit to your computer. If your MapSource product came with a setup guide, follow those instructions to learn how and when to connect your GPS unit to your computer. You can also find this information in your
GPS unit owner’s manual.
To connect your GPS unit to your computer:
1. If your GPS unit came with a PC Interface
Cable, connect your GPS to a serial communications port on your computer (see illustration below).
Serial Communications Port
If your GPS unit came with a USB data cable, connect your GPS to an available USB data port.
USB Data Port
2. Verify that your GPS is turned on and the Serial
Data Format is set to Garmin, if possible.
To verify proper connection to the computer:
1. In MapSource, click Utilities > Get Unit ID.
2. Verify that the name of your GPS unit appears in the Device field. If not, your GPS unit may not be connected properly. Verify that the unit is turned on, check the connection, and then click
Find Device.
8 MapSource User’s Manual
U
SING
M
AP
S
OURCE
> P
ARTS OF
M
AP
S
OURCE
U
SING
M
AP
S
OURCE
Parts of MapSource
The MapSource window contains five main parts: the (1) toolbars, (2) data tabs, (3) splitter bar, (4) Graphic Map, and (5) status bar.
1
2 3 4
5
MapSource User’s Manual 9
U
SING
M
AP
S
OURCE
> L
OADING
M
APS TO
Y
OUR
G
ARMIN
GPS U
NIT
Loading Maps to Your Garmin
GPS Unit
You can load maps to your Garmin GPS in three simple steps:
Selecting Maps
Use the Map tool to select the map regions you want to send to your GPS unit.
• Connect your Garmin GPS unit to your computer.
• Select the maps you want to send to your
GPS unit.
• Transfer the maps to your GPS unit.
For help connecting your GPS unit to your computer,
or consult the owner’s manual for your
GPS unit. To select maps and send them to your GPS unit, see the next two sections, “Selecting Maps” and
“Transferring MapSource Data.” You may also be able to view a tutorial on your MapSource installation disk about selecting and sending maps.
NOTE: To select map regions, you must unlock your MapSource product. For more information, see
.
To select map regions:
1. Zoom to 30 miles (50 km) on the Zoom scale.
2. Click the Map tool or click Tools > Map.
Move the mouse over the Graphic Map. Each map region becomes outlined in yellow when you move over it with the mouse. The name and size of the map region appear in the status bar.
3. Click a map region to select it. To select several map regions at once, click and drag the mouse over the areas you want to select. Selected map regions are shaded pink.
NOTE: Not all Garmin GPS units can use detailed maps. Check your GPS unit owner’s manual to see if your unit is compatible.
10 MapSource User’s Manual
U
SING
M
AP
S
OURCE
> L
OADING
M
APS TO
Y
OUR
G
ARMIN
GPS U
NIT
Names of map regions.
Selected map regions appear shaded in pink.
BlueChart ® map regions appear outlined in pink.
4. To deselect a map region, click a shaded pink area on the Graphic Map. To deselect several map regions, press and hold the Ctrl key while you click and drag across the map regions you want to deselect.
The map regions you select are called a “map set” and are listed in the Maps tab. Click the Maps tab to view the names and sizes of each map region you have selected.
Check the amount of memory your GPS unit has to store map data. Then check the Maps tab to see how much memory your map set requires. If the map set is too big, deselect some map regions.
MapSource User’s Manual
Memory needed to store this map set.
Click to rename map set.
Maps Tab
NOTE: If your GPS unit supports auto-routing, select the Include route calculation data check box (located at the bottom of the Maps tab).
You can create a route in MapSource and then select all of the map regions surrounding that route. You can also select maps around waypoints or tracks. For more
information about creating routes, see page 20
.
11
U
SING
M
AP
S
OURCE
> L
OADING
M
APS TO
Y
OUR
G
ARMIN
GPS U
NIT
To select maps around waypoints, routes, or tracks:
Right-click a route, waypoint, or track in its
Data tab and click Select Maps Around Route
( Waypoint/Track) from the shortcut menu.
NOTE: Some MapSource products sell area maps separately. You can only select maps that you have purchased and installed on your computer.
For example, if you select both Topographical and
Roads & Recreational data for the same geographical area, you will not see a combination of topographic and road data. You will only see data from the Roads &
Recreation data set. In order to see the Topographical data, turn the Roads & Recreational data off in your
GPS unit.
Adding Maps from Multiple MapSource
Products
You can add maps from more than one MapSource product to a map set, but you can only see data from one product on your GPS unit if the maps overlap.
The maps are not transparent on the unit and cannot be combined.
If two maps from different MapSource products overlap on your GPS unit, you need to turn the overlapping map off in order to see the other map underneath. Check your GPS unit owner’s manual to learn how to turn MapSource maps on or off.
12 MapSource User’s Manual
Transferring MapSource Data
You can send map sets, waypoints, routes, and tracks to your GPS unit or storage card, or you can receive data from your GPS unit or storage card. You may use one of the following methods to transfer data to or from your GPS unit (check your GPS unit owner’s manual to see what data transfer options are available):
• Serial or USB Cable
• USB Data Card Programmer—You can use this method if your GPS unit uses a Garmin data card (not preprogrammed). The USB Data
Card Programmer works only with Windows 98,
Windows 2000, Windows ME, or Windows XP.
• Compact Flash (CF) or Secure Digital (SD)
Card Reader—If your GPS unit uses a CF or
SD card, you can purchase a third-party card reader to transfer data.
Each time you transfer maps to a data card, you completely erase all data currently stored on the card and replace it with new data. However, if you store maps on a data card and you transfer waypoints, routes,
MapSource User’s Manual
U
SING
M
AP
S
OURCE
> T
RANSFERRING
M
AP
S
OURCE
D
ATA or tracks, you will not erase the maps on the card.
You can transfer waypoints, routes, and tracks from a data card to your GPS unit’s internal memory to prevent them from being deleted from your data card.
You cannot save maps from a data card to your GPS unit’s internal memory.
iQue
®
Users
To transfer data to and from an iQue, you may need to synchronize with your personal computer. You may not be able to send or receive all types of data to/from your iQue. For more information, refer to your iQue owner’s manual.
13
U
SING
M
AP
S
OURCE
> T
RANSFERRING
M
AP
S
OURCE
D
ATA
BlueChart, Fishing Hot Spots, and
LakeMaster Data Cards
Preprogrammed BlueChart, Fishing HotSpots, and
LakeMaster data cards should not be used in the USB
Programmer or in a GPS unit for saving MapSource maps—you will lose the preloaded data. Remove this preprogrammed data card from your GPS unit before you transfer maps. MapSource warns you if you are in danger of erasing data. If you overwrite the preloaded data, Garmin will not replace or recover it.
Reloading the POI Database
If your GPS unit includes a preloaded/preprogrammed
Points of Interest (POI) database, you will see a warning about erasing this preloaded data before you save MapSource maps. This warning does not refer to the basemap of your unit. You can restore preloaded data to your GPS unit by downloading it from the
Garmin Web site.
To reload Points of Interest:
1. Go to http://www.garmin.com
.
2. Click Updates & Downloads.
3. Click the name of your GPS unit.
4. Under Unit Software, click Download.
5. Click to accept the terms of the Software
License Agreement.
6. Under Download Preloaded POI Database, click Download.
Any MapSource maps on your GPS unit will be erased and replaced with the POI database.
14 MapSource User’s Manual
Sending Data to Your GPS Unit
If your GPS unit has a storage card, verify that the card is inserted correctly into the unit. Also, connect your
GPS unit to your computer and set your unit’s Data
Transfer mode to Garmin, if applicable (see your unit owner’s manual for instructions).
Types of data you can send are maps, waypoints, routes, or tracks. Remember, you can only send maps to an iQue.
NOTE: MapSource transfers all of the data listed in a data tab to your GPS unit each time you transfer data.
To send data to a GPS unit or card reader:
1. Select the data you want to send to your GPS unit or card. The data appears in the correct tab on the left side of the window.
2. Click Send To Device or click Transfer >
Send To Device.... The name of your GPS unit or card reader should appear automatically in the Device menu. If not, click Find Device.
U
SING
M
AP
S
OURCE
> T
RANSFERRING
M
AP
S
OURCE
D
ATA
• If you are using a USB card programmer,
“USB Data Card Programmer” appears in the Device field.
• If you are using a CF or SD card reader, select the correct drive letter from the
Device field.
• If you are sending data to an iQue or cf
Que, select where you want to save data under Map Storage Location. If necessary, select the correct user name from the
Device fields.
3. Under What to Send, check the boxes next to each type of data you want to send.
4. Click Send. MapSource begins sending data to your GPS unit or card reader. After you begin transferring data, you can check the box next to
Turn Off GPS After Transfer, if available.
5. If you are using an iQue or cf Que, synchronize with your personal computer, if necessary, so that your unit receives the data.
MapSource User’s Manual 15
U
SING
M
AP
S
OURCE
> T
RANSFERRING
M
AP
S
OURCE
D
ATA
Receiving Data from Your GPS Unit
If your GPS unit has a storage card, verify that the card is inserted correctly into the unit. Also, connect your
GPS unit or card reader to your computer and set your unit’s Data Transfer mode to Garmin, if applicable
(see your unit owner’s manual for instructions).
To receive data from a GPS unit or card reader:
1. If you are using an iQue, synchronize with your personal computer, if necessary, so that you can send information to MapSource.
2. Click Receive From Device , or click
Transfer > Receive From Device. The name of your GPS unit or card reader should appear automatically in the Device menu. If not, click
Find Device.
• If you are using a USB card programmer,
“USB Data Card Programmer” appears in the Device field.
• If you are using a CF or SD card reader, select the correct drive letter from the
Device field.
• If you are using an iQue, select the correct user name from the Device field.
3. Under What to Receive, check the boxes next to each type of data you want to receive.
4. Click Receive. MapSource begins receiving data from your GPS unit or card reader. The data appears in the correct tab on the left side of the window.
16 MapSource User’s Manual
Creating and Editing Waypoints
A waypoint is any point on the Graphic Map that you store in memory. You can easily create waypoints in
MapSource and then transfer them to your GPS unit.
You can also load waypoints from your GPS unit into
MapSource and then edit them. To send and receive
information from your GPS unit, see page 13
.
Creating Waypoints
When you create a waypoint, MapSource automatically names the waypoint based on its location. If you create a waypoint on an existing map feature, MapSource bases the waypoint name on the feature. If you create a waypoint on an open location, MapSource names the waypoint with a number. Each waypoint you create appears in the Waypoints tab on the left side of the window.
U
SING
M
AP
S
OURCE
> C
REATING AND
E
DITING
W
AYPOINTS
To create a waypoint:
1. Click the Waypoint tool or click Tools >
Waypoint.
2. Locate the place and then click anywhere on the Graphic Map to create a waypoint at that exact spot. To create a waypoint in the center of the Graphic Map, press Ctrl + W on your keyboard. The Waypoint Properties dialog box appears.
MapSource User’s Manual
Waypoint Properties dialog box
3. Make changes to the waypoint properties as necessary. Click More Details to view all available waypoint properties.
4. Click OK to save the waypoint. Click Cancel to exit without creating the waypoint.
17
U
SING
M
AP
S
OURCE
> F
INDING
P
LACES
Editing Waypoints
You can edit the properties of a waypoint by opening the Waypoint Properties dialog box:
• Double-click a waypoint name listed in the
Waypoints tab.
• Click the Selection tool . Then double-click a waypoint on the Graphic Map.
• Right-click any waypoint in the Waypoints tab or on the Graphic Map. Then select Waypoint
Properties.
Finding Places
In MapSource, click the Find button to open the
Find Places dialog box where you can easily find cities, Points of Interest (such as restaurants, parks, and shops) addresses, intersections, or waypoints.
To have the most available search options from your
MapSource product, you must unlock your maps. See
“Unlocking Maps,”
As you type places to search for in the Find Places dialog box, MapSource uses an auto-complete list to make suggestions. For example, as you type the name of a city, a list of cities appears matching the letters you type. You can choose the city directly from the autocomplete list or finish typing the name of the city.
NOTE: If the place you are searching for does not appear in the auto-complete list, MapSource will not allow you to continue typing. Verify the correct spelling of the place.
18 MapSource User’s Manual
Find Places dialog box
To find a place:
1. Click Find Places or click View > Find
Places.
2. Click one of the following tabs: City, Feature,
Address, or Intersection.
3. Start typing or selecting the search criteria.
MapSource User’s Manual
U
SING
M
AP
S
OURCE
> F
INDING
P
LACES
4. Click Find to show a list of matches in the
Places list. If you see the message “No items found,” try using more general search criteria.
5. Click to highlight the correct place from the list.
The place appears on the Graphic Map.
6. Click Make Waypoint if you want to save the place as a waypoint. Click OK to close the
Find Places dialog box. Click Cancel to close and return to the part of the map you were previously viewing.
Finding Nearest Places and Recently
Found Places
In MapSource, click the Find Nearest Places button to open the Find Nearest Places dialog box where you can search for map features and other places near a specific location on the Graphic Map. You can find places near a waypoint, any map location, or the center of the Graphic Map.
Click t he Recently Found Places button to open the Recently Found Places dialog box where you can view a list of places you have searched for recently.
19
U
SING
M
AP
S
OURCE
> C
REATING AND
E
DITING
R
OUTES
Creating and Editing Routes
Routes tell you how to get from one place to another.
Depending on your MapSource product, you can create a direct route (a straight-line route), or an auto-route
(turn-by-turn over roads).
Creating Routes
You can create and modify routes in MapSource by using the Route Properties dialog box, the Route tool
, or the Waypoints tab. A route can contain several points; each point is called a via point.
NOTE: Not all MapSource products can create an auto-route. You must be using a routable
MapSource product for MapSource to calculate an auto-route.
To create a route using the Route Properties dialog box:
1. Press Ctrl + R or click Edit > New Route to open the Route Properties dialog box.
2. To add an existing waypoint to the route, click
Insert Waypoint. Select the waypoint from the list that appears. To select multiple waypoints, press the Ctrl or Shift key while you click several waypoints. Then click OK.
3. To add a city, point of interest, address, or intersection, click the Find Places button inside the dialog box.
4. Repeat steps 2–3 until you are finished adding points to your route. Each point you add is listed in order from first to last under the Via
Points tab.
5. To rearrange the points in the list, highlight each point and click the arrows to move the point up or down in the list. To reorder the points from last to first, click Invert.
20 MapSource User’s Manual
To see points on the map, highlight each point and click Show on Map, or check the box next to Center map on selected item to see each point in the center of the map.
6. Click OK to save the new route.
Click Find buttons to search for map features.
Click to insert a waypoint listed in the
Waypoints tab.
U
SING
M
AP
S
OURCE
> C
REATING AND
E
DITING
R
OUTES
Editing Routes
You can edit routes directly on the Graphic Map or using the Route Properties dialog box.
From your route on the Graphic Map, you can add, move, and remove waypoints using the selection tool
.
Moving a route waypoint on the Graphic Map.
Route Properties dialog box
MapSource User’s Manual 21
U
SING
M
AP
S
OURCE
> T
RACKS
From the Route Properties dialog box, you can:
• Add points to a route
• Rename a route
• Invert a route
• Link a file or URL to a route
• View a vertical profile for a route
• View and print text directions for an auto-route
• Delete a route
For more information, refer to the MapSource Help system. Click Help > MapSource Help or press F1 on your keyboard to open the detailed MapSource Help files.
Tracks
Tracks are like little footprints on the Graphic Map that show you exactly where you have been. The track appears as a tiny dotted line made up of track points. As you move, your GPS unit records a track point every second (by default) with the time and your position and speed. Your GPS unit then saves these points as a track.
Viewing Tracks
Tracks received from your GPS unit appear in the
Tracks tab after you receive them. You can view tracks on the Graphic Map and edit them using the Track
Properties dialog box.
Double-click any track in the Tracks tab to open the
Track Properties dialog box. You can change the track name, invert the track, view a vertical profile of the track, and view and edit track points. For more
information, see “Transferring MapSource Data,” page
.
22 MapSource User’s Manual
Track Properties dialog box
Filtering Tracks
Each track point contains time, position, and speed information. From the Track Properties dialog box, click Filter. When you filter a track you have loaded from your GPS unit, you tell MapSource which track points you want to keep and which to discard. You can filter track points by time or distance, or you can let
MapSource filter the track points automatically.
MapSource User’s Manual
U
SING
M
AP
S
OURCE
> C
USTOMIZING
M
AP
S
OURCE
Customizing MapSource
After you become comfortable using MapSource, you may want to customize preferences to meet your needs.
You can change many settings by opening MapSource
Preferences. Click Edit > Preferences to open the
Preferences dialog box.
Preferences dialog box
23
W
ARNINGS AND
C
AUTIONS
W
ARNINGS AND
C
AUTIONS
CAUTION: GARMIN MAKES NO WARRANTY AS TO
THE ACCURACY OR COMPLETENESS OF THE MAP
DATA IN THIS PRODUCT AND DISCLAIMS ANY AND
ALL EXPRESS, IMPLIED, OR STATUTORY WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. IT IS THE USER’S RESPONSIBILITY TO
USE THIS PRODUCT PRUDENTLY. THIS PRODUCT IS
INTENDED TO BE USED ONLY AS A TRAVEL AID AND
MUST NOT BE USED FOR ANY PURPOSE REQUIRING
PRECISE MEASUREMENT OF DIRECTION, DISTANCE,
LOCATION, OR TOPOGRAPHY.
The following Warnings and Cautions may apply to some or all of the content in the MapSource BlueChart ® installation disk:
WARNING: No National Hydrographic Office has verified the information in this product and none accept liability for the accuracy of reproduction or any modifications made thereafter.
No National Hydrographic Office warrants that this product satisfies national or international regulations regarding the use of the appropriate products for navigation.
WARNING: This product has been produced, in part or whole, from the United Kingdom Hydrographic Office products. No liability is accepted for the use of this product and it must not be used to assist in navigation. The digital chart(s) contained herein have not been verified or updated. For your safety, users are advised to consult official updated nautical charts for navigational purposes. The Hydrographic Office has not verified the extracted data and the printed chart should be consulted for full navigational details.
CAUTION: The Australian Hydrographic Office does not check the information on this product and the Commonwealth accepts no liability for the accuracy of copying or for any modifications that may have been made to the information which it has supplied. Furthermore, the Commonwealth does not warrant that this product meets any regulations as an appropriate product for navigation or that it contains the latest hydrographic information available.
24 MapSource User’s Manual
A
B
BlueChart
C
Compact Flash (CF) Card
Connecting Your GPS to a
D
F
MapSource User’s Manual
Finding Recently Found Places
G
GPS Unit connecting to a computer
H
I
Installing MapSource
L
Loading Maps to Your GPS 10 compatibility 10
from multiple MapSource
M
P
Pre-programmed Data Cards
R
Route Properties Dialog Box
I
NDEX
S
around routes, waypoints,
T
Tracks
25
I
NDEX
U
Updating Personal Informa-
USB Data Card Programmer
W
creating custom symbols
selecting maps around
26
Waypoint Properties Dialog
MapSource User’s Manual
For the latest free software updates (excluding map data) throughout the life of your
Garmin products, visit the Garmin Web site at www.garmin.com.
© Copyright 2004-2005 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151 st Street, Olathe, Kansas 66062, U.S.A.
Garmin (Europe) Ltd.
Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51 9DL, U.K.
Garmin Corporation
No. 68, Jangshu 2 nd Road, Shijr, Taipei County, Taiwan www.garmin.com
Part Number 190-00417-20 Rev. C
advertisement
Related manuals
advertisement
Table of contents
- 1 MapSource User's Manual
- 4 Introduction
- 4 Serial Number
- 4 Contact Garmin
- 4 Map Data Information
- 5 Installing MapSource
- 5 Unlocking Maps
- 5 Unlock Codes and Coupon Codes
- 7 Saving and Viewing Unlock Codes
- 9 Updating Personal Information
- 10 Registering Your Product
- 10 Changing or Removing MapSource
- 10 Repairing MapSource
- 11 Modifying Coverage Areas
- 11 Removing MapSource
- 12 Connecting Your GPS Unit to a Computer
- 13 Using MapSource
- 13 Parts of MapSource
- 14 Loading Maps to Your Garmin GPS Unit
- 14 Selecting Maps
- 16 Adding Maps from Multiple MapSource Products
- 17 Transferring MapSource Data
- 17 iQue® Users
- 19 Sending Data to Your GPS Unit
- 20 Receiving Data from Your GPS Unit
- 21 Creating and Editing Waypoints
- 21 Creating Waypoints
- 22 Editing Waypoints
- 22 Finding Places
- 23 Finding Nearest Places and Recently Found Places
- 24 Creating and Editing Routes
- 24 Creating Routes
- 25 Editing Routes
- 26 Tracks
- 26 Viewing Tracks
- 27 Filtering Tracks
- 27 Customizing MapSource
- 28 Warnings and Cautions
- 29 Index
