HG221A
HSG1061
User’s Manual
Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference.
FCC Class B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The device complies with Parts 15 of the FCC Rule. Operation is subject to the following two conditions ﹕ (1) this device may not cause harmful interference ﹔ and (2) this device must accept any interference received, including interference that may cause undesired operations.
CANADA
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulation.
This device complies with requirement of EMC directive 2004/108/EC with regard to
Electromagnetic Compatibility, and 73/23/EEC and 93/68/EEC with regard to Low Voltage directive.
Socket-outlet shall be near the equipment and shall be accessible.
2
User’s Manual according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.
Some of the features of the TCO’03 Display requirements:
Ergonomics
Congratulations!
The display you have just purchased carries the TCO’03 Displays label.
This means that your display is designed, manufactured and tested
•
Good visual ergonomics and image quality in order to improve the working environment for the user and to reduce sight and strain problems. Important parameters are luminance, contrast, resolution, reflectance, colour rendition and image stability.
Energy
•
•
Energy-saving mode after a certain time – beneficial both for the user and the environment
Electrical safety
Emissions
•
•
Electromagnetic fields
Noise emissions
Ecology
• The product must be prepared for recycling and the manufacturer must have a certified environmental management system such as EMAS or ISO 14 001
• Restrictions on chlorinated and brominated flame retardants and polymers heavy metals such as cadmium, mercury and lead.
The requirements included in this label have been developed by TCO Development in cooperation with scientists, experts, users as well as manufacturers all over the world. Since the end of the 1980s
TCO has been involved in influencing the development of IT equipment in a more user-friendly direction. Our labelling system started with displays in 1992 and is now requested by users and
IT-manufacturers all over the world.
For more information, please visit www.tcodevelopment.com
3
User’s Manual
RECYCLING INFORMATION
We, the Hanns.G care very much about our environment protection strategy and firmly believe that it helps us have healthier earth via appropriate treatment and recycling of industrial technology devices at the end-of-life.
These devices contain recyclable materials, which can be re-decomposed and re-integrated into brand-new marvels. On the contrary, other material can be classified to hazardous and poisoned substances. We strongly encourage you to contact the provided information to recycle this product.
For more information, please visit www.hannsg.com
4
User’s Manual
TABLE OF CONTENTS
SPECIAL NOTES ON LCD MONITORS ..........................................................7
BEFORE YOU OPERATE THE MONITOR ..........................................................8
CHECKING THE CONTENTS OF THE PACKAGE ......................................8
INSTALLATION INSTRUCTIONS ....................................................................9
MAKING CONNECTIONS................................................................................10
ADJUSTING THE VIEWING ANGLE............................................................. 11
GENERAL INSTRUCTIONS.............................................................................12
FRONT PANEL CONTROL ..............................................................................13
HOW TO ADJUST A SETTINGS ......................................................................14
Q & A FOR GENERAL PROBLEMS ...............................................................17
ERROR MESSAGE & POSSIBLE SOLUTIONS ...........................................18
5
User’s Manual
SAFETY NOTICE
1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.
3. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modification to this equipment. It is the responsibilities of the user to correct such interference.
WARNING:
To prevent fire or shock hazard, do not expose the monitor to rain or moisture. Dangerously high voltages are present inside the monitor. Do not open the cabinet. Refer servicing to qualified personnel only.
PRECAUTIONS
• Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement.
• Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the monitor. If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit instructions.
• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of the monitor and to protect it from overheating, be sure these openings are not blocked or covered. Do not place the monitor on a bed, sofa, rug, or similar surface. Do not place the monitor near or over a radiator or heat register. Do not place the monitor in a bookcase or cabinet unless proper ventilation is provided.
• The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.
• Unplug the unit during a lighting storm or when it will not be used for long period of time. This
• will protect the monitor from damage due to power surges.
Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
• Never push any object into the slot on the monitor cabinet. It could short circuit parts causing a
• fire or electric shock. Never spill liquids on the monitor.
Do not attempt to service the monitor by yourself; opening or removing covers can expose you to dangerous voltages and other hazards. Please refer all servicing to qualified service personnel.
• The wall socket shall be installed near the equipment and shall be easily accessible.
6
User’s Manual
SPECIAL NOTES ON LCD MONITORS
The following symptoms are normal with LCD monitor and do not indicate a problem.
• Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the
•
Power Switch and then turn it on again to make sure the flicker disappears.
You may find slightly uneven brightness on the screen depending on the desktop pattern you use.
• The LCD screen has effective pixels of 99.99% or more. It may include blemishes of 0.01% or
• less such as a missing pixel or a pixel lit all of the time.
Due to the nature of the LCD screen, an afterimage of the previous screen may remain after switching the image, when the same image is displayed for hours. In this case, the screen is
• recovered slowly by changing the image or turning off the Power Switch for hours.
If the screen suddenly flashes erratically or the backlighting fails, please contact your dealer or service center for repair. Do not attempt to repair the monitor yourself.
Lamp Disposal
LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR
DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS. FOR MORE
INFORMATION, CONTACT THE ELECTRONIC INDUSTRIES ALLIANCE AT WWW.EIAE.ORG
.
FOR LAMP SPECIFIC DISPOSAL INFORMATION CHECK WWW.LAMPRECYCLE.ORG
.
7
User’s Manual
BEFORE YOU OPERATE THE MONITOR
FEATURES
• 22” Wide screen TFT Color LCD Monitor
• Crisp, Clear Display for Windows
• Recommended Resolutions : 1680X 1050@60Hz
• Ergonomic Design
• Space Saving, Compact Case Design
CHECKING THE CONTENTS OF THE PACKAGE
The product package should include the following items:
LCD Monitor
Screen Base
Cables and User manual
Power Cord VGA Cable
User’s manual Warranty card
8
Audio Cable
INSTALLATION INSTRUCTIONS
INSTALL REMOVE
User’s Manual
Figure.1. Installing and Removing the Base
INSTALLATION:
1. Align the monitor with the opening in the base.
2. Note that the longer section of the base points forward.
3. Snap the monitor into its base. A clear click sound will affirm that the base is connected correctly.
4. Verify that the monitor is securely attached to the base by looking at the bottom of the base and making sure that the clips are fully engaged in the base.
REMOVAL:
1. Flip over the monitor so that it is upside down.
2. Press the 2 clips on the base that holds the monitor in place.
3. Gently press and hold the 2 clips while pulling the base from the monitor unit they are unattached.
POWER
POWER SOURCE:
1. Make sure that the power cord is the correct type required in your area.
2. This LCD monitor has an Internal universal power supply that allows operation in either
100/120V AC or 220/240V AC voltage area (No user adjustment is required.)
3. Connect the AC-power cord one end to your LCD monitor’s AC-input socket, the other end to wall-outlet .
9
User’s Manual
MAKING CONNECTIONS
CONNECTING TO A PC
Turn off your computer before performing the procedure below.
1. Connect one end of the VGA cable to the back of the monitor and connect the other end to the computer’s D-Sub port.
2. Connect the audio cable between the monitor's audio input and the PC's audio output (green port).
3. Plug one end of the AC power cord to the LCD monitor’s AC input socket, and the other end to
Wall outlet.
4. Turn on your monitor and computer.
1.
3.
Power AC Input
Audio Input
Figure.2. Connecting to a PC
2. VGA Input
10
User’s Manual
ADJUSTING THE VIEWING ANGLE
• For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference.
• Hold the stand so you do not topple the monitor when you change the monitor’s angle.
• You are able to adjust the monitor’s angle from -5 ° to 20 ° .
Figure.3. Monitor Angle
NOTES:
• Do not touch the LCD screen when you change the angle. It may cause damage or break the LCD screen.
• Be careful not to place fingers or hands near the hinges when tilting the monitor, otherwise pinching can result.
11
User’s Manual
OPERATING INSTRUCTIONS
GENERAL INSTRUCTIONS
Press the power button to turn the monitor on or off. The other control buttons are located on the front panel of the monitor (See Figure 4). By changing these settings, the picture can be adjusted to your personal preferences.
• The power cord should be connected.
• Connect the Signal cable from the monitor to the VGA card.
• Press the power button to turn on the monitor. The power indicator will light up.
3.
5.
Figure.4. Control Panel Buttons
CONTROL PANEL BUTTONS:
1. Menu / Return 2. Auto adjustment / Enter
Brightness adjustment button / ▲ [+] 4. Volume adjustment button / ▼ [-]
Power Button 6. Power Indicator
12
User’s Manual
FRONT PANEL CONTROL
• Power Button:
Press this button to switch ON/OFF of monitor’s power.
• Power Indicator:
Orange — Power Saving mode.
• MENU / ENTER:
1. Turn the OSD menu on/off or return to the previous menu.
2. Exit OSD menu when in volume OSD status.
• Adjust ◄ ► :
1. Adjust Brightness and volume when the OSD is off.
2. Navigate through adjustment icons when OSD is ON or adjust a function when function is activated.
• Button:
1. The OSD menu is used as “confirmation” function during start-up.
2. Press and hold this button more than 3 seconds will start 「 Auto Adjust 」 function when using
VGA input only. (The auto adjustment function is used to optimize the 「 horizontal position 」 ,
「 vertical position 」 , 「 clock 」 ,and 「 phase 」 .)
NOTES:
• Do not install the monitor in a location near heat sources such as radiators or air dusts, or in a place subject to direct sunlight, or excessive dust or mechanical vibration or shock.
• Save the original shipping box and packing materials, as they will come in handy if you ever have
• to ship your monitor.
For maximum protection, repackage your monitor as it was originally packed at the factory.
• To keep the monitor looking new, periodically clean it with a soft cloth. Stubborn stains may be removed with a cloth lightly dampened with a mild detergent solution. Never use strong solvents such as thinner, benzene, or abrasive cleaners, since these will damage the cabinet. As a safety precaution, always unplug the monitor before cleaning it.
13
User’s Manual
HOW TO ADJUST A SETTINGS
BRIGHTNESS/ CONTRAST
BRIGHTNESS
CONTRAST
X-CONTRAST
Adjust the brightness value of the display according to your preference. Select 「 BRIGHTNESS 」 option to adjust the brightness value.
Adjust the contrast value of the display according to your preference. Select 「 CONTRAST 」 option to adjust the contrast value.
Optimal setting for high contrast images or videos. The dark and light areas of the image are automatically detected, and the contrast is enhanced to provide a clearer, sharper image. Also, you may select the 「 X-CONTRAST 」 option.
INPUT SETTING
INPUT SETTING
COLOR SETTING
WARM
NATURE
COOL
USER
VGA
Adjust the color temperature value of the display according to your preference: WARM /NATURE/ COOL.
Move the cursor to the User option and select it,
To adjust the red, enter the 「 R 」 option and adjust the level.
To adjust the green, enter the 「 G 」 option and adjust the level.
To adjust the blue, enter the 「 B 」 option and adjust the level.
IMAGE SETTING
AUTO ADJUST
ASPECT RATIO
H-POSITION
V-POSITION
The auto adjustment function is used to optimize the 「 horizontal position 」 , 「 vertical position 」 , 「 clock 」 ,and 「 phase 」 .
[For
VGA Input only]
When the aspect ratio of screen is distorted, you may make adjustments by using this function. “FULL” indicates full screen display, which does not ensure the image is shown as is or in initial scale. “FIT” indicates scaling by the proportion of original images, which may cause the screen showing black bands.
[The availability of this function depends upon the selected model]
Select the 「 H-POSITION 」 left or right. Enter the option and adjust the level. [For VGA only]
Select the 「 V-POSITION 」 option to shift the screen image up or down. Enter the option and adjust the level. [For VGA only]
14
CLOCK
PHASE
SHARPNESS
OSD SETTING
LANGUAGE
H-POSITION
V-POSITION
TRANSPARENCY
OSD TIME-OUT
OSD COLOR
SYSTEM
VOLUME
MUTE
DDC/CI
FACTORY RESET
INFORMATION
User’s Manual
Select the 「 CLOCK 」 option to reduce the vertical flicker of characters on the screen. Enter the option and adjust the level.
[For VGA only]
Select the 「 PHASE 」 option to reduce the horizontal flicker of characters on the screen. Enter the option and adjust the level.
[For VGA only]
Select the 「 SHARPNESS 」 option to adjust the sharpness of the display. Set the value from -2 to 2.
Select 「 LANGUAGE 」 option to change the language of the
OSD. Enter the option and select a language. [Reference only, the OSD Language depends on the selected model]
Select 「 H-POSITION 」 the OSD. Enter the option and adjust the level.
Select 「 V-POSITION 」 option to adjust the vertical position of the OSD. Enter the option and adjust the level.
Select 「 TRANSPARENCY 」 the OSD. Enter the option and adjust the level.
Select 「 OSD TIME-OUT 」 option to set the OSD time out from
10 to 100 seconds. Enter the option and adjust the level.
To choose the color combination of the OSD window, select
「 OSD COLOR 」 option under 「 OSD SETTING 」 menu, choose modes 1/2/3.
Select the 「 VOLUME 」 the option and adjust the level.
Select the 「 MUTE 」 option to switch the function On or Off.
Select the 「 DDC/CI 」 option to switch the function On or Off.
[Dual input mode optional]
Select the 「 FACTORY RESET 」 option to reset to the monitor’s default setting. This will erase the current settings. Enter the option and select On or Off.
Display Horizontal frequency/Vertical frequency/Resolution information.
15
User’s Manual
PLUG AND PLAY
Plug & Play DDC2B Feature
This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD.
It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. The DDC2B is a bidirectional data channel based on the I²C protocol. The host can request EDID information over the
DDC2B channel.
THIS MONITOR WILL APPEAR TO BE NON-FUNCTIONAL IF THERE IS NO VIDEO
INPUT SIGNAL. IN ORDER FOR THIS MONITOR TO OPERATE PROPERLY, THERE
MUST BE A VIDEO INPUT SIGNAL.
This monitor meets the Green monitor standards as set by the Video Electronics Standards
Association (VESA) and/or the United States Environmental Protection Agency (EPA) and The
Swedish Confederation Employees (NUTEK). This feature is designed to conserve electrical energy by reducing power consumption when there is no video-input signal present. When there is no video input signal this monitor, following a time-out period, will automatically switch to power saving mode. This reduces the monitor's internal power supply consumption. After the video input signal is restored, full power is restored and the display is automatically redrawn. The appearance is similar to a "Screen Saver" feature except the display is completely off. The display is restored by pressing a key on the keyboard, or clicking the mouse.
16
User’s Manual
TECHNICAL SUPPORT (FAQ)
Q & A FOR GENERAL PROBLEMS
PROBLEM & QUESTION
Power LED is not on
No Plug & Play
POSSIBLE SOLUTION
*Check if the Power Switch is in the ON position.
*Power Cord should be connected.
*Check if the PC system is Plug & Play compatible.
*Check if the Video Card is Plug & Play compatible.
*Check if any plug pins on the VGA connector are bent.
The display is too dark or too bright.
Picture bounces or a wave pattern is present in the picture
*Adjust the Contrast and Brightness Controls.
The power LED is ON (orange) but there’s no video or no picture.
*Move electrical devices that may cause electrical interference.
*Computer Power Switch should be in the ON position.
*Computer Video Card should be snugly seated in its slot.
*Make sure monitor’s video cable is properly connected to the computer.
*Inspect monitor’s video cable and make sure none of the pins are bent.
*Make sure computer is operational by hitting the CAPS
LOCK key on the keyboard while observing the CAPS
LOCK LED. The LED should either turn ON or OFF after hitting the CAPS LOCK key.
Missing one of the primary colors (RED, GREEN, or
BLUE)
Screen image is not centered or sized properly.
Picture has color defects
(white does not look white)
*Inspect the monitor’s video cable and make sure that none of the pins are bent.
* Adjust pixel frequency CLOCK and PHASE or press hot-key
(A Button)
*Adjust RGB color or select color temperature.
The screen resolution needs to be adjusted
*Use win 2000/ME/XP Right click anywhere on desktop and select Properties > Settings > Screen Resolution . Use the silder to adjust the reslution and click Apply.
No sound is outputted from monitor’s built-in speaker
*Make sure PC audio output cable is connected to screen ’ s
LINE IN port (or AUDIO IN port).
*Make sure the sound volume adjustment can be clearly identified.
*Make sure the System > Silence option in the monitor menu is on.
17
User’s Manual
ERROR MESSAGE & POSSIBLE SOLUTIONS
MODE
21
22
23
24
17
18
19
20
25
26
27
13
14
15
16
9
10
11
12
5
6
7
8
1
2
3
4
CABLE NOT CONNECTED:
1. Check that the signal-cable is properly connected, if the connector is loose; tighten the connector’s screws.
2. Check the signal-cable’s connection pins for damage.
INPUT NOT SUPPORT :
Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table.
FACTORY PRESET TIMING TABLE:
RESOLUTION
640x350@70Hz
640x400@70Hz
720x400@70Hz
640x480@60Hz
640x480@67Hz
640x480@72Hz
640x480@75Hz
800x600@56Hz
800x600@60Hz
800x600@72Hz
800x600@75Hz
1024x768@60Hz
1024x768@70Hz
1024x768@75Hz
1152x864@75Hz
1152x870@75Hz
1280x720@60Hz
1280x768@60Hz
1280x768@75Hz
1280x960@60Hz
1280x960@75Hz
1280x1024@60Hz
1280x1024@75Hz
1360x768@60Hz
1440x900@60Hz
1440x900@75Hz
HORIZONTAL
FREQUENCY (KHz)
31.469
31.469
31.469
31.469
35
37.861
37.5
35.156
68.681
45
47.396
60.289
60
74.592
63.981
79.976
37.879
48.077
46.875
49.725
48.363
56.476
60.023
67.5
47.712
55.935
70.635
VERTICAL
FREQUENCY (Hz)
70.087
70.087
70.087
59.94
66.667
72.809
75
56.25
75.062
60
59.995
74.893
60
74.443
60.02
75.025
60.317
72.188
75
74.5
60.004
70.069
75.029
75
60.015
59.887
74.984
18
28
29
1600x1200@60Hz
1680x1050@60Hz
75
65.29
User’s Manual
60
59.954
19
User’s Manual
APPENDIX
SPECIFICATIONS
LCD Panel
Video
Display Colors
Max. Resolution
Driving system
Size
Pixel pitch
H-Frequency
V-Frequency
TFT Color LCD
22”
0.282mm(H) x 0.282mm(V)
30KHz – 80KHz
50 – 75Hz
16.7M Colors
1680 x 1050 @60Hz
VESA DDC2B TM Plug & Play
Power consumption
Audio output
Input Terminal
ON Mode
OFF Mode
55W
≤ 1W
Rated Power 1 W rms (Per channel)
VGA
Maximum Screen Size
Power Source
Environmental
Considerations
Dimensions
Hor. : 473.76mm
Ver. : 296.1mm
100~240VAC,50±3Hz,60±3Hz
Operating Temp: 0° to 40°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 85%
518 (W) x 412(H) x 230(D) mm
20.3 ”(W)×16.2 ”(H)×9.0 ”(D)
Weight (NW) 5.8 kg (12.77 lb)
***The above specification is subject to actual product specification and is subject to change without prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can refer to www.hannsg.com FAQ section.
20
advertisement
Related manuals
advertisement
