Slinex SL-10IP User Manual
Add to My manuals19 Pages
Slinex SL-10IP is not just a door phone - this is an advanced home security system hidden inside a device with a 10-inch color touchscreen. SL-10IP allows you to see and talk to your visitors and unlock the door, even if you are not at home. With the built-in microSD slot, you can record and store video from your door phone, so you can always have a record of who came to your door - even if you missed their call.
advertisement
▼
Scroll to page 2
of
19
SERIES DESIGN DIRECT SL-10IP 10” video door phone User manual Thank you for the choice of our equipment { Design. Uniqueness. Innovation } SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } ! Attention! As a result of continuous upgrades and functionality improvements, technical characteristics of the device can be changed without any preliminary declaration. This manual can contain some inaccuracy or misprint. The owner reserves the right to make corrections to the information described in the user manual and device package. The last revision of this manual is available on www.slinex.com Safety instructions Table of contents 1. Package ............................................................................................................................................................................................3 2. Specification ...................................................................................................................................................................................3 3. Description......................................................................................................................................................................................4 4. Installation.......................................................................................................................................................................................5 4.1 Cable requirements.......................................................................................................................................................5 4.2 Schematic diagrams......................................................................................................................................................6 Read and keep that manual. The device installation process should be carried out by the qulified specialists. Use the device from the –10 ˚C to +55 ˚C, always keep it within that temperature range. Installation surface should be free from vibration and impact influence. Keep this device far from open sources of heat, such as radiators, heaters, and ovens. The device can be installed near other electronic equipment in case if the temperature of the environment does not exceed previously mentioned range. The device should be protected from the direct influence of the natural phenomena, such as direct sunlight, rain or snow. Don’t use aggressive or abradant detergent for the device surface cleaning. Use soft wet cloth or tissue to remove strong dirt. Don’t overpower outlets. It can cause fire or electric shock. 4.3 Unit mount .......................................................................................................................................................................8 5. Operation.........................................................................................................................................................................................9 5.1 Incoming call ...................................................................................................................................................................9 5.2 Door panel and camera image monitoring....................................................................................................... 10 5.3 Incoming call redirection ......................................................................................................................................... 11 5.4 Intercom ......................................................................................................................................................................... 12 6. Monitor settings......................................................................................................................................................................... 12 6.1 Mouse functions.......................................................................................................................................................... 12 6.2 Tool bar ........................................................................................................................................................................... 13 6.2.1 Configurtion settings ................................................................................................................................. 14 6.2.2 Playback settings ......................................................................................................................................... 18 6.2.3 Video recording............................................................................................................................................ 18 6.2.4 Ring settings.................................................................................................................................................. 19 Nature protection Don’t throw away the device with other industrial or nutritive trash if you see that symbol. Some regions have separation and recycling systems for the electronic equipment. Connect with local authorities to receive information about recycling of electronic equipment for your region. 6.2.5 SD card removing........................................................................................................................................ 19 6.2.6 System reboot............................................................................................................................................... 19 7. Web browser settings............................................................................................................................................................... 19 7.1 General conditions ..................................................................................................................................................... 19 7.2 Security settings .......................................................................................................................................................... 20 7.3 Network settings ......................................................................................................................................................... 21 Rights and limitation of liability 7.4 Plugin installation ....................................................................................................................................................... 22 All rights reserved. Any part of that document can not be published in any form, translated into other 7.5 Web interface................................................................................................................................................................ 23 languages or reproduced in any way including electronic or mechanical. 7.5.1 Real time monitoring, «LIVE» bookmark ............................................................................................. 23 Document recording and copying is strictly denied without owner permission. 7.5.2 Video playback, «PLAYBACK» bookmark............................................................................................. 24 7.5.3 Remote access settings, «REMOTE SETTING» bookmark............................................................... 26 7.5.4 Local storage settings, «LOCAL SETTING» bookmark..................................................................... 32 8. Mobile device software ........................................................................................................................................................... 33 9. Limited Warranty........................................................................................................................................................................ 36 1 Rev. 1.0 2 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } 1. Package 3. Description SL-10IP door monitor − 1 pc. Wall mounting bracket − 1 pc. USB mouse − 1 pc. IR remote control − 1 pc. Connection wires − 5 pcs. Mounting screws and nuts − 1 pkg. User manual − 1 pc. 2. Specification 4 304 mm 23 SD USB 190 mm mm Screen Resolution Video system 1024×600 pixels PAL/NTSC Audio type Half duplex Call time 120 seconds Internal memory Memory extension slot No SD, up to 64GB Standby mode power consumption 14 W Working mode power consumption 21 W Power supply Mounting type Size Working temperature 3 10”, color TFT (16:9) Built-in power supply, ~100–240 V Surface mount 304×190×23 mm −10...+55 ˚C 3 2 1 5 15 6 14 7 13 8 11 9 10 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 12 Display Remote control IR receiver Local area network (LAN) connection indicator Power LED. Active when power is on. «Up» button – increase talking volume, system settings menu cursor movement, parameter increase inside settings menu «Down» button – decrease talking volume, system settings menu cursor movement, parameter decrease inside settings menu «Volume» button – enter talking volume setting, system settings menu left cursor movement «Intercom» button – start intercom between monitors, system settings menu right cursor movement Microphone SD memory card slot (on the side of the monitor) «Hang Up» – stop conversation with the visitor / current system settings menu exit «Unlock» button – door unlocking Mouse USB connector «Answer» button – incoming call answer and start talking with the visitor «Monitor» button – door panel or camera image monitoring 4 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } 4.2 Schematic diagrams 4. Installation Diagram 1. SL-10IP door panels, cameras and locks connection. 4.1 Cable requirements Disconnect all power cables before device installation. This device can be connected with such cable types depends on the distance between door monitor and door panel: а) Use 4-wire cable with such parameters: • distance up to 25 meters use a cable with 0,22 mm2 square of one wire; • distance 25 to 50 meters use a cable with 0,41 mm2 square of one wire; • distance 50 to 100 meters use a cable with 0,75 mm2 square of one wire. Power Audio Ground Video 0 - 50 m Power Audio Ground Video Power Audio Ground Video 50 - 80 m Power Audio Ground Video Lock Lock Lock power supply Lock power supply Door panel 1 Door panel 2 Shield Shield b) If the distance between door monitor and door panel is between 80 and 100 meters then use a 3-wire cable with 0,75 mm2 square of one wire and RG-59 or RG-6 coaxial cable for the video signal. Power Audio Ground Video Power Audio Ground Video 80-100 m Power Audio GND Video RG-59 or RG-6 c) Shielded or non-shielded twisted pair (not recommended): • distance up to 25 meters non-shielded twisted pair can be used; • distance 25 to 50 meters shielded twisted pair should be used. Not used Audio GND Video Door 2 Door 1 Ext. Power ISP Output CCTV2 CCTV1 Power Audio GND Video Not used Audio GND Video SL-10IP Power Audio Ground Video Power Audio Ground Video Shield 5 0 - 25 m Power Audio Ground Video 25 - 50 m Power Audio Ground Video Shield Ground * +13,5 V CCTV 2 Camera power suppply Video GND GND +12 V Power CCTV 1 Video GND GND +12 V Camera power suppply 6 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } Diagram 2. SL-10IP and SL-07M system connection. 4.3 Unit mount 1) Take the surface mount bracket from the kit and situate it 150-160 cm from the floor line. 2) Mark and drill four halls in the wall. 3) Take four nuts from the kit and hammer them into the drilled halls. 4) Fix surface mount bracket on the wall by four screws from the kit. 5) Connect all communication wires and fix the monitor on the surface mount bracket. TV out Audio GND Data Video Door 2 Door 1 Output CCTV2 CCTV1 Ext. Power ISP SL-10IP (Master) Power Door 1 CCTV 1 Input Door 2 CCTV 2 Output SL-07M (Slave) Audio GND Data Video TV out Audio GND Data Video Door 1 Door 2 Power CCTV 1 CCTV 2 TV out Audio GND Data Video Input Output SL-07M (Slave) Audio GND Data Video Power Door 1 CCTV 1 Input Door 2 CCTV 2 Output SL-07M (Slave) Notes: * Use «Power» plug on the monitor to connect external power supply +13,5 V. While use external power supply please keep main power cord ~100-240 V disconnected from the outlet, otherwise it can damage monitor circuits. ** Door panels, cameras, power supplys, locks and other additional equipment described on the schemes are optional devices and aren’t included into monitors kit. 7 8 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } 5.2 Door panel and camera image monitoring 5. Operation Standby mode 5.1 Incoming call Standby mode Visitor presses call button on the first door panel Press «Monitor» button on the monitor Visitor presses call button on the second door panel Melody is ringing on the monitor and door panel, image from the door panel appears on the monitor screen Melody stops ringing and conversation starts, talking time is 120 seconds Monitor will show the image from the second door panel Press «Monitor» button on the monitor again Press «Monitor» button on the monitor again Press «Unlock» button to open lock connected to the current door panel, relay built into the panel will open the lock Monitor will show the image from the first CCTV camera Monitor will show the image from the second CCTV camera Monitor will show the quad image screen Press «Monitor» button on the monitor again 20 seconds Standby mode Notes: 1) Monitor will be automatically switched into standby mode if the user doesn’t answer incoming call during 60 seconds; 2) Image and sound from the door panel will be active during 20 seconds after the moment user presses button. It let the user know if the visitor passed through the door. 9 Press «Monitor» button on the monitor again Press «Monitor» button on the monitor again Press «Hang up» button to stop conversation or incoming call Press «Answer» button to start conversation with the visitor Monitor will show the image from the first door panel Standby mode Press «Hang up» button to stop monitoring or conversation 20 seconds Press «Unlock» button to open lock connected to the current door panel, relay built into the panel will open the lock Press «Answer» button to start conversation with the visitor 10 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } Notes: 1) If several monitors connected into one system, the user can view the image from door panels on any monitor inside this system. The image will be transferred from the «Master» monitor door panels to the «Slave» monitors. 2) If someone press call button on the door panel while monitoring is active then the image from this door panel appears on the monitor screen and call melody starts. Press «Answer» button to start conversation. 5.4 Intercom Two monitors connected into one system are used. Press «Intercom» button to start intercom conversation Standby mode Intercom Melody starts ringing on the other monitor 5.3 Incoming call redirection Two monitors connected into one system are used. Incoming call from the door panel and the user starts conversation Press and hold «Intercom» button for 3 sec. to start call redirection Conversation with the visitor on the other monitor begins Press «Unlock» button to open lock connected to the current door panel, relay built into the panel will open the lock Intercom Conversation with the other monitor starts Melody starts ringing on the other monitor inside the system and visitor image appears on the monitor screen Press «Hang up» button to stop conversation Press «Answer» button on the other monitor to start conversation with the visitor Note: 20 seconds 6. Monitor settings Press «Answer» button on the other monitor to start conversation Standby mode If someone presses call button on the door panel while intercom is active then the image from this door panel appears on the monitor screen and call melody starts. Press «Answer» button to start conversation with the visitor. 6.1 Mouse functions Standby mode User can use the mouse to make monitor settings and change different parameters. Connect the mouse to the USB port situated on the right side of the monitor. Mouse can be connected without monitor power Press «Hang up» button to stop conversation or incoming call disconnection. 1. In standby or monitoring mode click right mouse button to enable or disable Note: instrumental panel. If incoming call was successfully redirected to the other monitor then current monitor will enter standby mode. Right mouse button click 2. In the configuration menu or instrumental panel click right mouse button to exit from the current parameter setting to the previous menu. 3. In playback mode lick right mouse button to enable or disable playback control panel. 11 12 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } 1. Click left mouse button on icon from instrumental panel to enter configuration settings menu. 6.2.1 Configuration settings Press icon on the tool bar to enter configuration settings menu: 2. In configuration settings menu click left mouse button on any icon to enter Left mouse button click Configuration current sub menu settings. 3. Click left mouse on any icon to enter current parmeters screen. 4. Click left mouse button on any parameter to change its value. 5. Click left mouse button on icon to exit from current parameters screen. System 6. Click left mouse on any icon to enter its settings. Left mouse button double click Left mouse button hold & slide Network Playback Double click left mouse on any part of the image in quad screen mode to enter full screen mode. Use left mouse button hold & slide in motion detection settings to set motion detected part of the screen. 6.2 Tool bar Scheduling Alarm Maintenance User Default Information Click right mouse button in standby or monitoring mode to enable or disable the tool bar. Configuration settings menu has the following structure: System → Playback Ring Basic → Language – system menu and settings language → Standard –video signal standard (PAL или NTSC) Remove SD → Resolution – video camera resolution (HD or CVBS) → Time + → Date format – date display format (MM/DD/YY, YY/MM/DD or DD/MM/YY) → Date – date setting → Time format – time display format (12 Hour / 24 Hour) Setup Manual Record E-zoom → Time – time setting Reboot → Video → Channel – choose channel number to change settings → Channel name – current channel name → Color setup – Chroma, Brightness, Contrast and Saturation settings → Video margin – Left, Right, Up and Down image margins → Record – record Resolution and Frame rate settings for all channels Playback – video records stored on the SD card archive playback, (this menu also available on the tool bar by selecting 13 icon, look at the page 18, paragraph 6.2.2). 14 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } Network → Basic → Network type – IP address obtaining type (static or dynamic IP − DHCP) More detailed description of some parameters of «Configurtion» settings menu is listed further. → MAC-address Network → Advanced → Wi-Fi → IP address – IP address setting User can connect door phone to the local network in two ways: wired or wireless Wi-Fi connection. We → Subnet mask – subnet mask setting strongly recommend to use wired connection because it is more reliable than wireless one. Enable Wi-Fi → Gateway – gateway IP address setting module if wireless connection should be used to connect door phone to the local network. Press → DNS address – DNS server IP address switch on the left of «Wi-Fi» sign to activate the module. Then press «Wi-Fi» sign by left mouse button to → Port → Media port – data exchange between door monitor and PC enter Wi-Fi settings menu. → Web port – web interface access port number Press → Setup port – device managing port number mouse button on its name. If the password required for this network then the window with the password → Advanced → DDNS – DDNS server parameter settings. button to start netwrk searching for available networks. Choose the network and press left input field will appear on the display. Input the right password for the current network and press icon → Wi-Fi – Wi-Fi network connection settings to confirm it. The monitor will be rebooted and connected to the current network. → UPnP – UPnP enable or disable. Note that Wi-Fi network name should be only consisted of english characters and numbers (spaces and special → Mobile phone – redirection parameters to mobile devices setting, push symbols are not allowed). Otherwise network registration will not be approved. messages notification setting Press → Sub stream – sub stream parameter settings wireless network parameters can be changed here: → IP firewall – IP addresses filtering (white and black list) icon to connect wireless network manually and then enter all the settings. Also current SSID – wireless network name Scheduling – weekly recording schedule (MD – recording when motion detection occurs) Auth mode – authorization type «WPA-PSK» or «WPA2-PSK» can be set Alarm → Channel – current chanel motion detection settings Encryption type – «AES» or «TKIP» encryption types are available → Sensitivity – motion detection sensitivity setting → MD area – area of the image where motion detection is applied → MD Enable – enable / disable motion detection for the current channel → Record – start recording when motion detection occurs setting → Push – push notification enable / disable when motion detection occurs setting Maintenance → SD → Format – format SD card → Auto overwrite – overwriting data on SD card when it is full: Auto or Disable → Upgrade → System upgrade – system software update (need an update file). Password – wireless network password Network → Advanced → Mobile phone Phone port – mobile devices connection port (from 1024 up to 65535). 10510 is defult value mobile port number Push time (s) – push notification delay in seconds. Push – enable or disable push notification for moble devices. Network → Advanced → Sub stream User – add or delete user account Channel – chanel number to make settings Default – restore default monitor settings Frame rate – can be changed from 5 up to 25 frames/second for PAL or from 5 up to 30 frames/second Information – device information, such as: unique UID device number, software version and production for NTSC. date. Bit rate – streaming bit rate quality, 64К, 128К, 192К, 256К or 384К can be seted. Bit rate control – type of video compression: CBR – constant bit rate, VBR – variable bit rate. 15 16 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } 6.2.2 Playback Scheduling Record schedule can be seted up on this screen. There are three types of schedule settings: «MD» – motion Click right mouse button to display instrumental panel. Then press icon to enter playback menu. detection recording (orange color in schedule table), «Normal» – constant recording (green color in schedule table) and «None» – disable recording (grey color in schedule table). Playback Scheduling Channel Mon. Tue. Wed. Thu. Fri. Sat. Sun. 00 06 MD Copy from Date 3 12 18 Normal Mon to Sun. 23 01 08 15 22 29 02 09 16 23 30 12/11/2015 Wed. 03 10 17 24 Time Sat. 00:00 Channel -- 23:59 Time Size 04 05 06 07 11 12 13 14 18 19 20 21 25 26 27 28 0/0 None All Enter date and time and then press button to find reccords matched to your request. Channel column shows the channel number which that file was recorded. «Time» and «Size» columns shows current Choose one of the schedule settings under schedule table and then click on the time which you want to record starting time and its size in MB. Record with orange background indicates that it was recorded as apply this type of setting on the schedule table. One square on the schedule table matches one hour time motion detection trigerred. Record with black background indicates that it was recorded by schedule. interval. Then the first left square of the table matches the time from 00:00 to 01:00 and the last one matches Press left mouse button on file name to start playback in full screen mode. As the playback will be ended up the time from 23:00 to 00:00. When all the settings will be done then press the monitor will be returned to the file list. Press icon to save all the changes. to go to the previous page of the list. Press Alternative way to set all the schedule is to set the schedule for one day and then copy it for other days of go to the last page of the list. button to go to the first page of the list or button to go to the next page of the list or button button to the week. Use «Copy from» bar under schedule. Choose the day which you want to copy schedule from in the left block and choose the day(s) which you want current schedule to be applied to. Press icon to start copying, and then press icon to save all the settings. 6.2.3 Recording There two types of recording in that door phone – manual recording or schedule recording (including motion detection). Manual recording has more priority than schedule recording. In case if manual recording has occured then schedule recording will be paused until the end of manual recording. Schedule recording is described in details on the 17th page of that manual. Maintenance → Upgrade Create an «ivrupgrade» folder on the SD card root. Copy upgrade file into this folder and insert SD card into door phone slot. Press icon to start system upgrade. Firmware upgrade will take two or three Press button on the tool bar to start manual recording. Press button again to stop manual recording. minutes. Don’t remove SD card or turn off the power during this time, otherwise it can demage the door phone. System will be restarted after firmware upgrade. 17 18 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } 7.2 Security settings 6.2.4 Ring settings Click right mouse button to display the tool bar. Then press icon to enter ring settings menu. Open Internet Explorer browser and press «Tools» icon on the upper right side of the window, then go to Ring settings Ring Browser setup for the remote access to the door phone includes next steps: + 1 «Internet options» menu and choose «Security» bookmark. Press «Custom level...» button and set «Enable» option for the next ActiveX settings and plugins: Volume 15 Ring time 8 • Automatic prompting for ActiveX controls; Unlock time 2 Button sound Close • Script ActiveX controls, marked safe for scripting; Door LED Open • Run ActiveX controls and plug-ins; • Initialize and script ActiveX controls, not marked as safe for scripting; • Binary and script behaviors; • Allow scriptlets; Ring – incoming call ring melody; • Download signed ActiveX controls; Volume – incoming call ring volume; • Download unsigned ActiveX controls. Ring time – incoming call ring time; Press «OK» button and choose «Advanced» bookmark. Find «Security» settings and activate the option: Unlock time – lock relay activation time; • Allow software to run or install even if the signature is invalid. Button sound – enable (open) or disable(close) button sounds; Door LED – enable (open) or disable(close) door panel button backlight LED. Press «OK» to save current setting. Note: Access to the door phone main page can be blocked by Windows firewall and other antivirus software. 6.2.5 SD card removing Click right mouse button to display the tool bar. Then press icon. Now you can remove SD card from the door phone slot. 6.2.6 System reboot Click right mouse button to display the tool bar. Then press icon to reboot the system. 7. Web browser settings 7.1 General conditions Web browser software installation enables door phone remote control. It is recommended to use Windows XP, Windows 7, Windows 8 or Windows 10 with Internet Explorer browser version 7.0 and higher. Mouse can be connected to the door phone any time without power disconnection of the door phone. 19 20 7.3 Network settings DESIGN DIRECT SERIES { Design. Uniqueness. Innovation } 2) Set appropriate IP address from the current network segment, subnet mask and gateway in the door Door phone remote access can be carried out through the Internet or local network connection. Clent phone settings (Configuration → Network → Basic). In the current example IP address can be set as computer IP address should use the same network segment as the door phone. In global network the only 192.168.1.Х, where Х – any number between 0-255, except 255 and 1 (and also except IP addresses that demand is that computer and door phone should be available to use public network and Internet already exist in that segment). Subnet mask – 255.255.255.0 and gateway – 192.168.1.1 connection using IP address or dynamic domain name. Local network connection settings are described Note: below: 1) Check computer IP address, subnet mask and default gateway. Press right mouse button on the Windows «Start» button and choose «Network connections» menu. Press left mouse button twice on the currently used network connection and then press «Details...» button. Here you can see network parameters of the computer, such as IP address, subnet mask and default gateway. If the door phone connected to the global network then public IP address should be used. 7.4 Plugin installation After all settings have been made, open browser and enter door phone IP-address (Configuration → Network → Basic → IP address) into address line. After IP address, enter colon (:) sign and web port number that is used on the door phone (Configuration → Network → Port → Web Port). For example if the current web port is 8090 (default web port), then the final text in the adress line should be like http://192.168.1.50:8090 Note: There is also another way to access network parameters display. Press right mouse button on the «Network» icon (on the task manager bar or on the desktop) and choose «Open Network and Sharing After entering you will be asked to install monitoring software. Confirm this installation and then you can enter door phone web interface to monitor your cameras, panels or change settings: Center» → «Change adapter settings». Press left mouse button twice on the currently used network connection and then press «Details...» button. Select the English language on the upper middle side of the screen. Enter user name and password. USER ID – user name. Default user name is Admin. PASSWORD – password. Default password is 888888. NETWORK – choose MAIN STREAM or SUB STREAM. Main stream has better image quality than sub stream. Open preview – select this option if you want to turn on panels and cameras image monitoring after authorization. 21 22 7.5 Web interface DESIGN DIRECT SERIES { Design. Uniqueness. Innovation } Main control panel is situated on the right side of the web interface window and has such buttons: Web interface web page consists of several bookmarks: LIVE – real time monitoring; Open lock Snapshot PLAYBACK – recorded video playback; Quad mode REMOTE SETTING – remote access settings; LOCAL SETTING – local storage settings; LOGOUT – exit from the web interface. 7.5.1 Real time monitoring, «LIVE» bookmark Press «LIVE» bookmark to enter real time monitoring mode. Enable / disable monitoring mode Start instant recording on every channel Start / stop conversation Full screen mode One camera monitoring mode Notes: Snapshots saving path is «С:\Users\LocalUser\Documents\IP_XXX.XXX.XXX.XXX\Capture» Records saving path is «С:\Users\LocalUser\Documents\IP_XXX.XXX.XXX.XXX\Records» While video recording is active on any channel you can see R icon on the control panel. Click on any channel image by left mouse button twice to enter one camera monitoring mode. Click on any channel image by right mouse button to enter full screen quad mode. 7.5.2 Video playback, «PLAYBACK» bookmark Press «PLAYBACK» bookmark to open playback window. There are several search types which can be used: On the left down side of every channel you can see control panel, which has several buttons: 1) Search by date. Select the month which records you want to search for by or buttons. Then – start/stop playback; press «REFRESH» button to display current month records. Press on any date from the calendar to display – start/stop recording; records being made this day. – make snapshot; 2) Search by type. Select channel number and event type which you want to search for and then press – increase/decrease brightness; «SEARCH» button. All search results will be displayed in the list below. – increase/decrease contrast; – open lock. Press this button to open current door panel lock. Enter unlocking password (default unlocking password is: 888888) and press «Confirm»; M – means that motion detected on the current channel (can only be observed if motion detection function is enabled for the current channel). 23 24 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } November 2015 Mo Tu We Th Fr Sa Su Pause Playback Slow Time-lapse motion Zoom Playing progress Clip starting/ Stop Accelerated playback Snapshot ending time Volume Download progress 7.5.3 Remote access settings, «REMOTE SETTING» bookmark. Press «REMOTE SETTING» bookmark on the upper side of the screen to enter remote door phone settings. Here you can find encode, record, alarm, network, alarm, mobile and user settings. «ENCODE SETTING» – video quality settings On the left side of the screen press «ENCODE SETTING» to enter video quality settings. Depending on the Double click by left mouse button on selected file or select file from the list and press «PLAY» button to start its playback. You can also download video on your PC using «Download» button to create backup and view cameras and door panels connected to the door phone select resolution type D1 (CVBS) or HD (AHD) and select stream frame rate. it later. 25 - 11- 2015 17 : 41 : 59 November 2015 Mo Tu We Th Fr Sa Su DOOR2 25 26 DESIGN DIRECT SERIES { Design. Uniqueness. Innovation } «RECORD SETTING» – schedule recording settings On the left side of the screen press «RECORD SETTING» to enter schedule recording settings. Here you can enable or disable recording channels, set the schedule and recording type for every channel, such as motion detection, normal schedule recording or no recording. «ALARM SETTING» – alarm paerameters settings On the left side of the screen press «ALARM SETTING», to enter alarm settings menu. Here you can enable or disable motion detection, set motion detection area for every video channel and its sensitivity. 27 «NETWORK SETTING» – network parameters settings On the left side of the screen press «NETWORK SETTING» then select «NETWORK» to enter network parameters menu. Here you can set network connection parameters, such as IP address, netmask, gateway, etc. «MOBILE» – mobile access settings On the left side of the screen press «NETWORK SETTING» then select «MOBILE» to enter mobile settings menu. Here you can set mobile port number, enable or disable push messages and set push time duration. 28 «IP FIREWALL» – IP firewall settings DESIGN DIRECT SERIES { Design. Uniqueness. Innovation } «SYSTEM INFO» – system information On the left side of the screen press «NETWORK SETTING» then select «IP FIREWALL» to enter firewall On the left side of the screen press «SYSTEM INFO» to enter system information menu. Here you can see settings. Here you can enable or disable web interface access for the certain IP addresses. such information as device name, software version, release date and device id number. «ADVANCED SETTING» – system settings On the left side of the screen press «ADVANCED SETTING» to enter system settings menu. Here you can select door phone menu language and video signal encoding type (TV MODE), PAL or NTSC. 29 «REMOTE UPGRADE» – remote software upgrading On the left side of the screen press «REMOTE UPGRADE» to enter software upgrading menu. Press «...» button and select upgrading file. Then press «REMOTE UPGRADE» button to start upgrading process. Don’t turn off the door phone power until upgrading process will be ended. 30 «USER MANAGER» – user accounts management DESIGN DIRECT SERIES { Design. Uniqueness. Innovation } 7.5.4 Local storage settings, «LOCAL SETTING» bookmark On the left side of the screen press «USER MANAGER» to enter user passwords and permissions Press «LOCAL SETTING» bookmark on the upper side of the screen to enter local storage settings. Here you management. can change storage paths for every file type. «ADD or DEL» – add or delete user account On the left side of the screen press «USER MANAGER» then select «ADD or DEL» setting to add or delete user account. Enter new user name and password, then press «ADD USER» button to add a new user acount. Press «DELETE USER» to delete selected user account. 31 32 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } 8. Mobile device software Use twisted pair CAT5 or CAT6 cable or wireless Wi-Fi connection (not recommended) to connect SL-10IP video door phone to the local network. Application setup includes next steps: 1) Enter «GooglePlay» (for Android) or «AppStore» (for iOS) and search for «Slinex» application, then install this applicationи on your mobile device. 2) Connect mobile device into the local network, which is video door station connected. 3) Run «Slinex» application on your mobile device and press icon to add a new device. 4) Press «Click here for connected wired/wireless device» button, then press «LAN search» button. 5) When new device have been found, choose its number in the list and fill in the device information: Name: enter device name in the list (any name you like) UID: unique identification number of the device User: Admin (by default) Password: 888888 (by default) then press «Confirm» button. 6) Device will be added to the bar in the middle part of the screen. You can also press alarm notification on or off by the blue switch in the devices list («Switch ON/OFF notification») – page 35. 7) If you want to view the image from the door station press its icon on the bar and then press any channel icon to start monitoring mode. Press channel icon again to stop monitoring mode. − add new device − additional settings − door unlock − devices list − snapshot − local snapshots and video − start/stop video recording − remote snapshots and video − turn on the sound from the door station − settings − press again to turn off the sound − help + – start conversation − press again to stop conversation 33 34 SERIES DESIGN DIRECT { Design. Uniqueness. Innovation } 9. Limited warranty Manufacturer guarantees product normal functioning during the warranty period if the user keeps all safety instructions described in that manual. enable or disable notification Warranty period is 12 months from the moment of the product purchasing (warranty period could be extended up to 24 months or more, depending on the local regulations). Warranty period allows user to make guarantee repair in cases when normal functioning of the product was violated by the fault of manufacturer and the user haven’t offend transporting, installation and working conditions. This limited warranty does not cover any damage to the product that results from improper installation, accident, abuse, misuse, natural disaster, insufficient or excessive electrical supply, abnormal mechanical or environmental conditions, or any unauthorized disassembly, repair or modification. Warranty void in such cases: • the product was damaged by the fault of the customer; • the product wasn’t properly installed according reccomendations from the manual; • the sticker on the backside of the product was broken; • the product was not used for its intended function. This limited warranty covers only repair, replacement, refund or credit for defective products, as provided above. Manufacturer is not liable for, and does not cover under warranty, any damages or losses of any kind whatsoever resulting from loss of, damage to, or corruption of, content or data or any costs associated with determining the source of system problems or removing, servicing or installing products. This warranty excludes third party software, connected equipment or stored data. Manufacturer is therefore not liable for any losses or damage attributable to third party software, connected equipment or stored data. Press «Edit» to change any Press «Confirm» to save setting on this screen all the settings In the event a product has been discontinued, manufacturer shall either repair the product, offer to replace Notes: Disable door pannels or cameras monitoring for the current device before trying to change any settings or parameters; Disable current device notification to access such parameters as «Delete» or «Device settings». it with a comparable product or provide a refund at the lesser of the purchase price or the product’s current Incoming call notification value. Repaired or replacement products will continue to be covered by this limited warranty for the remainder of the original warranty term. 35 36
advertisement
Key Features
- 10-inch color touchscreen
- Built-in microSD slot for video recording
- Motion detection and night vision
- Two-way audio communication
- Remote access via mobile app
- Integration with home automation systems
- Stylish design that complements any home decor
Related manuals
Frequently Answers and Questions
How do I connect the SL-10IP to my home network?
The SL-10IP can be connected to your home network via Ethernet or Wi-Fi. To connect via Ethernet, simply connect an Ethernet cable from the SL-10IP to your router. To connect via Wi-Fi, open the SL-10IP's settings menu and select the Wi-Fi network you want to connect to.
How do I add a door camera to the SL-10IP?
To add a door camera to the SL-10IP, simply connect the camera to the SL-10IP using the included video cable. Once the camera is connected, it will automatically be detected by the SL-10IP.
How do I record video from the SL-10IP?
To record video from the SL-10IP, insert a microSD card into the built-in microSD slot. Once the microSD card is inserted, the SL-10IP will automatically start recording video. You can access the recorded videos by opening the SL-10IP's settings menu and selecting the "Playback" option.
