Basics

Read me first

Please read this manual before using the device to ensure safe and proper use.

• Descriptions are based on the device’s default settings.

• Some content may differ from your device depending on the region, service provider, model specifications, or device’s software.

• Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Apps related to the content may not work properly depending on the device’s specifications and the environment that it is used in.

• Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung.

• Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or apps to work improperly.

• Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media.

• You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services depending on your data plan. For large data transfers, it is recommended to use the Wi-Fi feature.

• Default apps that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an app provided with the device, contact a Samsung Service Centre. For user-installed apps, contact service providers.

4

Basics

• Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty.

• Depending on the region or service provider, a screen protector is attached for protection during production and distribution. Damage to the attached screen protector is not covered by the warranty.

• You can see the touchscreen clearly even in strong outdoor sunlight by automatically adjusting the contrast range based on the surrounding environment. Due to the nature of the product, displaying fixed graphics for extended periods may result in afterimages

(screen burn-in) or ghosting.

– It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods and turn off the touchscreen when not using the device.

– You can set the touchscreen to turn off automatically when you are not using it.

Launch the Settings app, tap Display → Screen timeout , and then select the length of time you want the device to wait before turning off the touchscreen.

– To set the touchscreen to automatically adjust its brightness based on the surrounding environment, launch the Settings app, tap Display , and then tap the

Adaptive brightness switch to activate it.

• Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission (FCC).

If your device is approved by the FCC, you can view the FCC ID of the device. To view the

FCC ID, launch the Settings app and tap About phone → Status . If your device does not have an FCC ID, it means that the device has not been authorised for sale in the U.S. or its territories and may only be brought to the U.S. for the owner’s personal use.

• Depending on the region, you can view the regulatory information on the device. To view the information, launch the Settings app and tap About phone → Regulatory information .

5

Basics

Instructional icons

Warning : situations that could cause injury to yourself or others

Caution : situations that could cause damage to your device or other equipment

Notice : notes, usage tips, or additional information

Device overheating situations and solutions

When the device heats up while charging the battery

While charging, the device and the charger may become hot. During wireless charging or fast charging, the device may feel hotter to the touch. This does not affect the device’s lifespan or performance and is in the device’s normal range of operation. If the battery becomes too hot, the charger may stop charging.

Do the following when the device heats up:

• Disconnect the charger from the device and close any running apps. Wait for the device to cool down and then begin charging the device again.

• If the lower part of the device overheats, it could be because the connected USB cable is damaged. Replace the damaged USB cable with a new Samsung-approved one.

• When using a wireless charger, do not place foreign materials, such as metal objects, magnets, and magnetic stripe cards, between the device and the wireless charger.

The wireless charging or fast charging feature is only available on supported models.

6

Basics

When the device heats up during use

When you use features or apps that require more power or use them for extended periods, your device may temporarily heat up due to increased battery consumption. Close any running apps and do not use the device for a while.

The following are examples of situations in which the device may overheat. Depending on the functions and apps you use, these examples may not apply to your model.

• During the initial setup after purchase or when restoring data

• When downloading large files

• When using apps that require more power or using apps for extended periods

– When playing high-quality games for extended periods

– When recording videos for extended periods

– When streaming videos while using the maximum brightness setting

– When connecting to a TV

• While multitasking (or, when running many apps in the background)

– When using Multi window

– When updating or installing apps while recording videos

– When downloading large files during a video call

– When recording videos while using a navigation app

• When using large amount of data for syncing with the cloud, email, or other accounts

• When using a navigation app in a car while the device is placed in direct sunlight

• When using the mobile hotspot and tethering feature

• When using the device in areas with weak signals or no reception

• When charging the battery with a damaged USB cable

• When the device’s multipurpose jack is damaged or exposed to foreign materials, such as liquid, dust, metal powder, and pencil lead

• When you are roaming

7

Basics

Do the following when the device heats up:

• Keep the device updated with the latest software.

• Conflicts between running apps may cause the device to heat up. Restart the device.

• Deactivate the Wi-Fi, GPS, and Bluetooth features when not using them.

• Close apps that increase battery consumption or that run in the background when not in use.

• Delete unnecessary files or unused apps.

• Decrease the screen brightness.

• If the device overheats or feels hot for a prolonged period, do not use it for a while. If the device continues to overheat, contact a Samsung Service Centre.

Device limitations when the device overheats

When the device heats up, the features and performance may be limited or the device may turn off to cool down. The feature is only available on supported models.

• If the device becomes hotter than usual, a device overheating message will appear. To lower the device’s temperature, the screen brightness and the performance speed will be limited and battery charging will stop. Running apps will be closed and you will only be able to make emergency calls until the device cools down.

• If the device overheats or feels hot for a prolonged period, a power off message will appear. Turn off the device, and wait until it cools down.

8

Basics

Precautions for operating environment

Your device may heat up due to the environment in the following conditions. Use caution to avoid shortening the battery’s lifespan, damaging the device, or causing a fire.

• Do not store your device in very cold or very hot temperatures.

• Do not expose your device to direct sunlight for extended periods.

• Do not use or store your device for extended periods in very hot areas, such as inside a car in the summertime.

• Do not place the device in any areas that may overheat, such as on an electric heating mat.

• Do not store your device near or in heaters, microwaves, hot cooking equipment, or high pressure containers.

• Do not use a cable whose covering is peeled off or damaged, and do not use any charger or battery that is damaged or malfunctioning.

9

Basics

Device layout and functions

Package contents

Refer to the quick start guide for package contents.

• The items supplied with the device and any available accessories may vary depending on the region or service provider.

• The supplied items are designed only for this device and may not be compatible with other devices.

• Appearances and specifications are subject to change without prior notice.

• You can purchase additional accessories from your local Samsung retailer. Make sure they are compatible with the device before purchase.

• Use only Samsung-approved accessories. Using unapproved accessories may cause the performance problems and malfunctions that are not covered by the warranty.

• Availability of all accessories is subject to change depending entirely on manufacturing companies. For more information about available accessories, refer to the Samsung website.

10

Basics

Device layout

► Galaxy A50 :

Proximity sensor

Front camera

Touchscreen

Multipurpose jack

(USB Type-C)

Speaker

Light sensor

Volume key

Power key

Fingerprint recognition sensor

11

Basics

GPS antenna

Rear camera

(Triple)

Flash

Speaker

Microphone

NFC antenna

(NFC-enabled models)

Microphone

SIM card / Memory card tray

MST antenna

Main antenna

Earphone jack

12

Basics

► Galaxy A70, A70s :

Proximity sensor

Front camera

Touchscreen

Multipurpose jack

(USB Type-C)

Speaker

Light sensor

Volume key

Power key

(Galaxy A70)

Side key (Power/Bixby)

(Galaxy A70s)

Fingerprint recognition sensor

13

Basics

GPS antenna

Rear camera

(Triple)

Flash

NFC antenna

(NFC-enabled models)

Microphone

SIM card / Memory card tray

MST antenna

Main antenna

Speaker

Earphone jack

Microphone

• When using the speakers, such as when playing media files or using speakerphone, do not place the device close to your ears.

• Be careful not to expose the camera lens to a strong light source, such as direct sunlight. If the camera lens is exposed to a strong light source, such as direct sunlight, the camera image sensor may be damaged. A damaged image sensor is irreparable and will cause dots or spots in pictures.

• If you use the device with its glass or acrylic body broken, there may be a risk of injury. Use the device only after it has been repaired at a Samsung Service Centre.

14

Basics

• Connectivity problems and battery drain may occur in the following situations:

– If you attach metallic stickers on the antenna area of the device

– If you attach a device cover made with metallic material to the device

– If you cover the device’s antenna area with your hands or other objects while using certain features, such as calls or the mobile data connection

• Using a Samsung-approved screen protector is recommended. Unapproved screen protectors may cause the sensors to malfunction.

• Do not cover the proximity/light sensor area with screen accessories, such as a screen protector or stickers. Doing so may cause the sensor to malfunction.

Hard keys

Volume key

Power key

(Galaxy A50, A70)

Side key (Power/Bixby)

(Galaxy A70s)

Key

Volume key

Power key/Side key

Side key +

Volume Down key

(Galaxy A70s)

Function

• Press to adjust the device volume.

• When the device is off, press and hold to turn it on.

• Press to turn on or lock the screen.

•

Press and hold to start a conversation with Bixby. Refer to Using

Bixby for more information.

• Press twice or press and hold to launch the app or feature you set.

(Galaxy A70s)

• Press simultaneously to capture a screenshot.

• Press and hold simultaneously to turn off the device.

15

Basics

Setting the Side key (Galaxy A70s)

Select an app or feature to launch by pressing the Side key twice or pressing and holding the

Side key.

Launch the Settings app, tap Advanced features → Side key , and then select an option you want.

Soft buttons

Recents button Back button

Home button

When you turn on the screen, the soft buttons will appear at the bottom of the screen. The soft buttons are set to the Recents button, Home button, and Back button by default. Refer to

Navigation bar (soft buttons)

for more information.

16

Basics

Battery

Charging the battery

Charge the battery before using it for the first time or when it has been unused for extended periods.

Use only Samsung-approved battery, charger, and cable specifically designed for your device. Incompatible battery, charger, and cable can cause serious injuries or damage to your device.

• Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty.

• Use only USB Type-C cable supplied with the device. The device may be damaged if you use Micro USB cable.

To save energy, unplug the charger when not in use. The charger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging.

1 Connect the USB cable to the USB power adaptor.

2 Plug the USB cable into the device’s multipurpose jack.

17

Basics

3 Plug the USB power adaptor into an electric socket.

4 After fully charging, disconnect the charger from the device. Then, unplug the charger from the electric socket.

Reducing the battery consumption

Your device provides various options that help you conserve battery power.

• Optimise the device using the device care feature.

• When you are not using the device, turn off the screen by pressing the Power key/Side key.

• Activate power saving mode.

• Close unnecessary apps.

• Deactivate the Bluetooth feature when not in use.

• Deactivate auto-syncing of apps that need to be synced.

• Decrease the backlight time.

• Decrease the screen brightness.

Battery charging tips and precautions

• When the battery power is low, the battery icon appears empty.

• If the battery is completely discharged, the device cannot be turned on immediately when the charger is connected. Allow a depleted battery to charge for a few minutes before turning on the device.

• If you use multiple apps at once, network apps, or apps that need a connection to another device, the battery will drain quickly. To avoid losing power during a data transfer, always use these apps after fully charging the battery.

• Using a power source other than the charger, such as a computer, may result in a slower charging speed due to a lower electric current.

• The device can be used while it is charging, but it may take longer to fully charge the battery.

• If the device receives an unstable power supply while charging, the touchscreen may not function. If this happens, unplug the charger from the device.

18

Basics

• While charging, the device and the charger may heat up. This is normal and should not affect the device’s lifespan or performance. If the battery gets hotter than usual, the charger may stop charging.

• If you charge the device while the multipurpose jack is wet, the device may be damaged.

Thoroughly dry the multipurpose jack before charging the device.

• If the device is not charging properly, take the device and the charger to a Samsung

Service Centre.

Fast charging

The device has a built-in fast charging feature. You can charge the battery more quickly while the device or its screen is turned off.

Increasing the charging speed

To increase the charging speed, turn the device or its screen off when you charge the battery.

While charging the battery when the device is turned off, the icon appears on the screen.

If the fast charging feature is not activated, launch the Settings app, tap Device care →

Battery → → Settings , and then tap the Fast cable charging switch to activate it.

• You cannot use the built-in fast charging feature when you charge the battery using a standard battery charger.

• If the device heats up or the ambient air temperature rises, the charging speed may decrease automatically. This is a normal operating condition to prevent damage to the device.

SIM or USIM card (nano-SIM card)

Installing the SIM or USIM card

Insert the SIM or USIM card provided by the mobile telephone service provider.

For dual SIM models, you can insert two SIM or USIM cards so you can have two phone numbers or service providers for a single device. In some areas, data transfer speeds may be slower if two SIM cards are inserted in the device than when one SIM card is inserted.

Use caution not to lose or let others use the SIM or USIM card. Samsung is not responsible for any damages or inconveniences caused by lost or stolen cards.

19

Basics

Some LTE services may not be available depending on the service provider. For more information about service availability, contact your service provider.

► Single SIM models :

20

Basics

► Dual SIM models :

21

Basics

1 Insert the ejection pin into the hole next to the tray to loosen the tray.

Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be damaged.

2 Pull out the tray gently from the tray slot.

3 ► Single SIM models : Place the SIM or USIM card on the SIM card tray with the goldcoloured contacts facing downwards.

► Dual SIM models : Place the SIM or USIM card on the SIM card tray with the goldcoloured contacts facing downwards. Place the primary SIM or USIM card on the SIM card tray 1 ( 1 ) and the secondary SIM or USIM card on the SIM card tray 2 ( 2 ).

1

2

SIM card tray 2

SIM card tray 1

4 Gently press the SIM or USIM card into the SIM card tray to secure it.

If the card is not fixed firmly into the tray, the SIM card may leave or fall out of the tray.

5 Insert the tray back into the tray slot.

• If you insert the tray into your device while the tray is wet, your device may be damaged. Always make sure the tray is dry.

• Fully insert the tray into the tray slot to prevent liquid from entering your device.

22

Basics

Correct card installation

► Single SIM models :

Nano-SIM card

► Dual SIM models :

Nano-SIM card 1

Use only a nano-SIM card.

microSD card

Nano-SIM card 2 microSD card

23

Basics

Removing the SIM or USIM card

1 Insert the ejection pin into the hole next to the tray to loosen the tray.

2 Pull out the tray gently from the tray slot.

3 Remove the SIM or USIM card.

4 Insert the tray back into the tray slot.

Using dual SIM or USIM cards (dual SIM models)

If you insert two SIM or USIM cards, you can have two phone numbers or service providers for a single device.

Activating SIM or USIM cards

Launch the Settings app and tap Connections → SIM card manager . Select a SIM or USIM card and tap the switch to activate it.

Customising SIM or USIM cards

Launch the Settings app, tap Connections → SIM card manager , and then select a SIM or

USIM card to access the following options:

• Icon : Change the icon of the SIM or USIM card.

• Name : Change the display name of the SIM or USIM card.

• Network mode : Select a network type to use with the SIM or USIM card.

Setting preferred SIM or USIM cards

When two cards are activated, you can assign voice calls, messaging, and data services to specific cards.

Launch the Settings app, tap Connections → SIM card manager , and then set the feature preferences for your cards in Preferred SIM card .

24

Basics

Memory card (microSD card)

Installing a memory card

Your device’s memory card capacity may vary from other models and some memory cards may not be compatible with your device depending on the memory card manufacturer and type. To view your device’s maximum memory card capacity, refer to the Samsung website.

• Some memory cards may not be fully compatible with the device. Using an incompatible card may damage the device or the memory card, or corrupt the data stored in it.

• Use caution to insert the memory card right-side up.

• The device supports the FAT and the exFAT file systems for memory cards. When inserting a card formatted in a different file system, the device will ask to reformat the card or will not recognise the card. To use the memory card, you must format it.

If your device cannot format or recognise the memory card, contact the memory card manufacturer or a Samsung Service Centre.

• Frequent writing and erasing of data shortens the lifespan of memory cards.

• When inserting a memory card into the device, the memory card’s file directory appears in the My Files → SD card folder.

25

Basics

1 Insert the ejection pin into the hole next to the tray to loosen the tray.

Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be damaged.

2 Pull out the tray gently from the tray slot.

When you remove the tray from the device, the mobile data connection will be disabled.

26

Basics

3 Place a memory card on the memory card tray with the gold-coloured contacts facing downwards.

Memory card tray

4 Gently press the memory card into the memory card tray to secure it.

If the card is not fixed firmly into the tray, the memory card may leave or fall out of the tray.

5 Insert the tray back into the tray slot.

• If you insert the tray into your device while the tray is wet, your device may be damaged. Always make sure the tray is dry.

• Fully insert the tray into the tray slot to prevent liquid from entering your device.

Removing the memory card

Before removing the memory card, first unmount it for safe removal.

Launch the Settings app and tap Device care → Storage → → Storage settings → SD card → Unmount .

1 Insert the ejection pin into the hole next to the tray to loosen the tray.

2 Pull out the tray gently from the tray slot.

27

Basics

3 Remove the memory card.

4 Insert the tray back into the tray slot.

Do not remove external storage, such as a memory card or USB storage, while the device is transferring or accessing information, or right after transferring data. Doing so can cause data to be corrupted or lost or cause damage to the external storage or device. Samsung is not responsible for losses, including loss of data, resulting from the misuse of external storage devices.

Formatting the memory card

A memory card formatted on a computer may not be compatible with the device. Format the memory card on the device.

Launch the Settings app and tap Device care → Storage → → Storage settings → SD card → Format .

Before formatting the memory card, remember to make backup copies of all important data stored in the memory card. The manufacturer’s warranty does not cover loss of data resulting from user actions.

28

Basics

Turning the device on and off

Follow all posted warnings and directions from authorised personnel in areas where the use of wireless devices is restricted, such as aeroplanes and hospitals.

Turning the device on

Press and hold the Power key/Side key for a few seconds to turn on the device.

When you turn on your device for the first time or after performing a data reset, follow the on-screen instructions to set up your device.

Turning the device off

1 To turn off the device, press and hold the Power key/Side key and the Volume Down key simultaneously.

Volume Down key

Power key/Side key

2 Tap Power off .

To restart the device, tap Restart .

You can set the device to turn off when you press and hold the Side key. Launch the

Settings app, tap Advanced features → Side key , and then tap Power off menu under Press and hold . (Galaxy A70s)

Forcing restart

If your device is frozen and unresponsive, press and hold the Power key/Side key and the

Volume Down key simultaneously for more than 7 seconds to restart it.

29

Basics

Emergency mode

You can switch the device to emergency mode to reduce battery consumption. Some apps and functions will be restricted. In emergency mode, you can make an emergency call, send your current location information to others, sound an emergency alarm, and more.

To activate emergency mode, press and hold the Power key/Side key and the Volume Down key simultaneously.

To deactivate emergency mode, tap → Turn off Emergency mode .

The usage time left shows the time remaining before the battery power runs out. Usage time left may vary depending on your device settings and operating conditions.

Initial setup

When you turn on your device for the first time or after performing a data reset, follow the on-screen instructions to set up your device.

• The initial setup procedures may vary depending on the device’s software and your region.

• You can set up your device with Bixby depending on the selected device language.

1 Turn on the device.

30

Basics

2 Select your preferred device language and select .

Select a language.

3 Read and agree to the terms and conditions and tap Next .

4 Get your content from a previous device.

5 Select a Wi-Fi network and connect to it.

If you do not connect to a Wi-Fi network, you may not be able to set up some device features during the initial setup.

6 Follow the on-screen instructions to proceed the initial setup.

7 Set a screen lock method to protect your device. You can protect your personal information by preventing others from accessing your device. To set the screen lock method later, tap Not now .

8 If the recommended apps screen appears, select apps you want and download them.

9 Sign in to your Samsung account. You can enjoy Samsung services and keep your data up to date and secure across all of your devices. Refer to

Samsung account

for more information.

31

Basics

Samsung account

Introduction

Your Samsung account is an integrated account service that allows you to use a variety of

Samsung services provided by mobile devices, TVs, and the Samsung website. Once your

Samsung account has been registered, you can keep your data up to date and secure across your Samsung devices with Samsung Cloud, track and control your lost or stolen device, see tips and tricks from Samsung Members, and more.

Create your Samsung account with your email address.

To check the list of services that can be used with your Samsung account, visit account.samsung.com

. For more information on Samsung accounts, launch the Settings app and tap Accounts and backup → Accounts → Samsung account → → Help .

Registering your Samsung account

Registering a new Samsung account

If you do not have a Samsung account, you should create one.

1 Launch the Settings app and tap Accounts and backup → Accounts → Add account →

Samsung account .

Alternatively, launch the Settings app and tap .

2 Tap Create account .

3 Follow the on-screen instructions to complete creating your account.

32

Basics

Registering an existing Samsung account

If you already have a Samsung account, register it to the device.

1 Launch the Settings app and tap Accounts and backup → Accounts → Add account →

Samsung account .

Alternatively, launch the Settings app and tap .

2 Enter your Samsung account ID and password and tap Sign in .

If you forget your account information, tap Find ID or Reset password . You can find your account information when you enter the required information.

3 Read and agree to the terms and conditions and tap Agree to finish registering your

Samsung account.

If a pop-up window about using biometric data appears, tap Get started . You can verify your Samsung account password via your biometric data, such as fingerprints. Refer to

Samsung Pass for more information.

Removing your Samsung account

When you remove your registered Samsung account from the device, your data, such as contacts or events, will also be removed.

1 Launch the Settings app and tap Accounts and backup → Accounts .

2 Tap Samsung account → → Remove account .

3 Tap Remove , enter your Samsung account password, and then tap OK .

33

Basics

Transferring data from your previous device

(Smart Switch)

Connect with your previous device via Smart Switch to transfer data.

Launch the Settings app and tap Accounts and backup → Smart Switch .

• This feature may not be supported on some devices or computers.

• Limitations apply. Visit www.samsung.com/smartswitch for details. Samsung takes copyright seriously. Only transfer content that you own or have the right to transfer.

Transferring data wirelessly via Wi-Fi Direct

Transfer data from your previous device to your device wirelessly via Wi-Fi Direct.

1 On the previous device, launch Smart Switch.

If you do not have the app, download it from Galaxy Apps ( Galaxy Store ) or Play Store .

2 On your device, launch the Settings app and tap Accounts and backup → Smart

Switch .

3 Place the devices near each other.

4 On the previous device, tap Send data → Wireless .

5 On the previous device, select an item to transfer and tap Send .

6 On your device, tap Receive .

7 Follow the on-screen instructions to transfer data from your previous device.

34

Basics

Transferring data using external storage

Transfer data using external storage, such as a microSD card.

1 Transfer data from your previous device to external storage.

2 Insert or connect the external storage device to your device.

3 On your device, launch the Settings app and tap Accounts and backup → Smart Switch

→ → Restore .

4 Follow the on-screen instructions to transfer data from external storage.

Viewing imported data

You can view the imported data on the same app from your previous device.

If your new device does not have the same apps to view or play the imported data, the data will be saved to a similar app.

Understanding the screen

Controlling the touchscreen

• Do not allow the touchscreen to come into contact with other electrical devices.

Electrostatic discharges can cause the touchscreen to malfunction.

• To avoid damaging the touchscreen, do not tap it with anything sharp or apply excessive pressure to it with your fingertips.

• It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods. Doing so may result in afterimages (screen burn-in) or ghosting.

• The device may not recognise touch inputs close to the edges of the screen, which are outside of the touch input area.

• It is recommended to use fingers when you use the touchscreen.

35

Basics

Tapping

Tap the screen.

Tapping and holding

Tap and hold the screen for approximately

2 seconds.

Dragging

Tap and hold an item and drag it to the target position.

Double-tapping

Double-tap the screen.

36

Basics

Swiping

Swipe upwards, downwards, to the left, or to the right.

Spreading and pinching

Spread two fingers apart or pinch on the screen.

37

Basics

Navigation bar (soft buttons)

When you turn on the screen, the soft buttons will appear on the navigation bar at the bottom of the screen. The soft buttons are set to the Recents button, Home button, and Back button by default. The functions of the buttons can change according to the app currently being used or usage environment.

Button

Recents button

Recents

Home

Back

Back button

Home button

Function

• Tap to open the list of recent apps.

• Tap to return to the Home screen.

• Tap and hold to launch the Google Assistant app.

• Tap to return to the previous screen.

38

Basics

Hiding the navigation bar

View files or use apps on a wider screen by hiding the navigation bar.

Launch the Settings app, tap Display → Navigation bar , and then tap Full screen gestures under Navigation type . The navigation bar will be hidden and the gesture hints will appear where the soft buttons are located. To use the soft buttons, drag the gesture hint of the desired button upwards.

If you want to hide the gesture hints at the bottom of the screen, tap the Gesture hints switch to deactivate it.

Setting the navigation bar

Launch the Settings app, tap Display → Navigation bar , and then select an option.

• Navigation type : Set the device to hide or display the navigation bar. To hide the navigation bar, tap Full screen gestures . While the navigation bar is hidden, you can use the soft buttons by dragging the gesture hint of the desired button upwards.

• Button order : Change the order of the buttons on the navigation bar.

• Gesture hints : Set the device to display indicators at the bottom of the screen to show where the soft buttons are located. This feature appears only when you select Full screen gestures .

39

Basics

Home screen and Apps screen

The Home screen is the starting point for accessing all of the device’s features. It displays widgets, shortcuts to apps, and more.

The Apps screen displays icons for all apps, including newly installed apps.

The screen may appear differently depending on the region or service provider.

A widget

Bixby Home indicator. View your customised content.

Navigation bar (soft buttons)

Favourite apps

40

Basics

Switching between Home and Apps screens

On the Home screen, swipe upwards or downwards to open the Apps screen.

To return to the Home screen, swipe upwards or downwards on the Apps screen.

Alternatively, tap the Home button or the Back button.

Home screen Apps screen

If you add the Apps button on the Home screen, you can open the Apps screen by tapping the button. On the Home screen, tap and hold an empty area, tap Home screen settings , and then tap the Apps button switch to activate it. The Apps button will be added at the bottom of the Home screen.

Apps button

41

Basics

Display the screen in landscape mode

On the Home screen, tap and hold an empty area, tap Home screen settings , and then tap the Rotate to landscape mode switch to activate it.

Rotate the device until it is horizontal to view the screen in landscape mode.

Moving items

Tap and hold an item, and then drag it to a new location. To move the item to another panel, drag it to the side of the screen.

To add a shortcut to an app on the Home screen, tap and hold an item on the Apps screen, and then drag it to the top of the screen. A shortcut to the app will be added on the Home screen.

You can also move frequently used apps to the shortcuts area at the bottom of the Home screen.

42

Basics

Creating folders

Create folders and gather similar apps to quickly access and launch apps.

On the Home screen or the Apps screen, tap and hold an app, and then drag it over another app.

A new folder containing the selected apps will be created. Tap Enter folder name and enter a folder name.

• Adding more apps

Tap Add apps on the folder. Tick the apps to add and tap Add . You can also add an app by dragging it to the folder.

• Moving apps from a folder

Tap and hold an app to drag it to a new location.

• Deleting a folder

Tap and hold a folder, and then tap Delete folder . Only the folder will be deleted. The folder’s apps will be relocated to the Apps screen.

43

Basics

Editing the Home screen

On the Home screen, tap and hold an empty area, or pinch your fingers together to access the editing options. You can set the wallpaper, add widgets, and more. You can also add, delete, or rearrange Home screen panels.

• Adding panels: Swipe to the left, and then tap .

• Moving panels: Tap and hold a panel preview, and then drag it to a new location.

• Deleting panels: Tap on the panel.

• Wallpapers : Change the wallpaper settings for the Home screen and the locked screen.

• Themes : Change the device’s theme. Visual elements of interface, such as colours, icons, and wallpapers, will change depending on the selected theme.

• Widgets : Widgets are small apps that launch specific app functions to provide information and convenient access on your Home screen. Tap and hold a widget, and then drag it to the Home screen. The widget will be added on the Home screen.

• Home screen settings : Change the size of the grid to display more or fewer items on the

Home screen and more.

44

Basics

Displaying all apps on the Home screen

Without using a separate Apps screen, you can set the device to display all apps on the

Home screen. On the Home screen, tap and hold an empty area, and then tap Home screen settings → Home screen layout → Home screen only → Apply .

You can now access all your apps by swiping to the left on the Home screen.

Indicator icons

Indicator icons appear on the status bar at the top of the screen. The icons listed in the table below are most common.

• The status bar may not appear at the top of the screen in some apps. To display the status bar, drag down from the top of the screen.

• Some indicator icons appear only when you open the notification panel.

Icon

/

Meaning

No signal

Signal strength

Roaming (outside of normal service area)

GPRS network connected

EDGE network connected

UMTS network connected

HSDPA network connected

HSPA+ network connected

LTE network connected

Wi-Fi connected

Bluetooth feature activated

Location services being used

Call in progress

Missed call

New text or multimedia message

Alarm activated

Mute mode activated

Vibration mode activated

45

Basics

Icon Meaning

Flight mode activated

Error occurred or caution required

Battery charging

Battery power level

Lock screen

Pressing the Power key/Side key turns off the screen and locks it. Also, the screen turns off and automatically locks if the device is not used for a specified period.

To unlock the screen, swipe in any direction when the screen turns on.

If the screen is off, press the Power key/Side key or double-tap anywhere on the screen to turn on the screen.

Locked screen

46

Basics

Changing the screen lock method

To change the screen lock method, launch the Settings app, tap Lock screen → Screen lock type , and then select a method.

When you set a pattern, PIN, password, face, or fingerprint for the screen lock method, you can protect your personal information by preventing others from accessing your device. After setting the screen lock method, the device will require an unlock code whenever unlocking it.

• Swipe : Swipe in any direction on the screen to unlock it.

• Pattern : Draw a pattern with four or more dots to unlock the screen.

• PIN : Enter a PIN with at least four numbers to unlock the screen.

• Password : Enter a password with at least four characters, numbers, or symbols to unlock the screen.

• None : Do not set a screen lock method.

• Face

: Register your face to unlock the screen. Refer to Face recognition for more

information.

• Fingerprints

: Register your fingerprints to unlock the screen. Refer to Fingerprint recognition

for more information.

You can set your device to perform a factory data reset if you enter the unlock code incorrectly several times in a row and reach the attempt limit. Launch the Settings app, tap Lock screen → Secure lock settings , unlock the screen using the preset screen lock method, and then tap the Auto factory reset switch to activate it.

47

Basics

Screen capture

Capture a screenshot while using the device and write on, draw on, crop, or share the captured screen. You can capture the current screen and scrollable area.

Use the following methods to capture a screenshot. Captured screenshots will be saved in

Gallery .

• Key capture: Press and hold the Volume Down key and the Power key/Side key simultaneously.

• Swipe capture: Swipe your hand to the left or right across the screen.

• It is not possible to capture a screenshot while using some apps and features.

• If capturing a screenshot by swiping is not activated, launch the Settings app, tap

Advanced features → Motions and gestures , and then tap the Palm swipe to capture switch to activate it.

After capturing a screenshot, use the following options on the toolbar at the bottom of the screen:

• : Capture the current content and the hidden content on an elongated page, such as a webpage. When you tap , the screen will automatically scroll down and more content will be captured.

• : Write or draw on the screenshot or crop a portion from the screenshot. The cropped area will be saved in Gallery .

• : Share the screenshot with others.

If the options are not visible on the captured screen, launch the Settings app, tap

Advanced features , and then tap the Smart capture switch to activate it.

48

Basics

Notification panel

When you receive new notifications, such as messages or missed calls, indicator icons appear on the status bar. To see more information about the icons, open the notification panel and view the details.

To open the notification panel, drag the status bar downwards. To close the notification panel, swipe upwards on the screen.

You can use the following functions on the notification panel.

Launch Settings .

Quick setting buttons

View the notification details and perform various actions.

Preferred SIM or USIM card for each option. Tap to access the

SIM card manager. (dual SIM models)

Clear all notifications.

Access the notification settings.

49

Basics

Using quick setting buttons

Tap quick setting buttons to activate certain features. Swipe downwards on the notification panel to view more buttons.

To change feature settings, tap the text under each button. To view more detailed settings, tap and hold a button.

To rearrange buttons, tap → Button order , tap and hold a button, and then drag it to another location.

50

Basics

Entering text

Keyboard layout

A keyboard appears automatically when you enter text to send messages, create notes, and more.

Text entry is not supported in some languages. To enter text, you must change the input language to one of the supported languages.

Additional keyboard functions View more keyboard functions.

Enter uppercase. For all caps, tap it twice.

Delete a preceding character.

Enter symbols.

Break to the next line.

Enter a space.

Changing the input language

Tap → Languages and types → Manage input languages , and then select the languages to use. When you select two or more languages, you can switch between the input languages by swiping to the left or right on the space key.

51

Basics

Changing the keyboard

Tap to change the keyboard.

To change the keyboard type, tap → Languages and types , select a language, and then select the keyboard type you want.

• If the keyboard button ( ) does not appear on the navigation bar, launch the

Settings app, tap General management → Language and input , and then tap the Show Keyboard button switch to activate it.

• On a 3x4 keyboard , a key has three or four characters. To enter a character, tap the corresponding key repeatedly until the desired character appears.

Additional keyboard functions

• : Predict words based on your input and show word suggestions. To return to the keyboard functions list, tap .

• : Enter emoticons.

• : Enter stickers. You can also enter My Emoji stickers that look like you. Refer to

Using

My Emoji stickers in chats for more information.

• : Attach animated GIFs.

This feature may not be available depending on the region or service provider.

• : Enter text by voice.

• : Change the keyboard settings.

• : Set the device to transliterate characters from English into another language.

This feature may not be available depending on the region or service provider.

• → : Add an item from the clipboard.

• → : Change the keyboard mode or size.

• → : Open the text editing panel.

52

Basics

Copying and pasting

1 Tap and hold over text.

2 Drag or to select the desired text, or tap Select all to select all text.

3 Tap Copy or Cut .

The selected text is copied to the clipboard.

4 Tap and hold where the text is to be inserted and tap Paste .

To paste text that you have previously copied, tap Clipboard and select the text.

Dictionary

Look up definitions for words while using certain features, such as when browsing webpages.

1 Tap and hold over a word that you want to look up.

If the word you want to look up is not selected, drag or to select the desired text.

2 Tap Dictionary on the options list.

If a dictionary is not preinstalled on the device, tap Move to Manage dictionaries , tap next to a dictionary, and then tap INSTALL to download it.

3 View the definition in the dictionary pop-up window.

To switch to the full screen view, tap . Tap the definition on the screen to view more definitions. In the detailed view, tap to add the word to your favourite words list or tap

Search Web to use the word as a search term.

53
