Safety
The following information contains important information related to operator safety and may help prevent equipment problems.
Make sure you observe all of the precautions listed in this manual.
Safety Precautions
• Do not modify this product, as a fire, electrical shock, or breakdown could result.
• Do not attempt to remove the covers and panels, which have been fixed to the product. Some products have a high-voltage part or a laser beam source inside that could cause an electrical shock or blindness. The operator is only allowed to slide out/ in the projection unit of the scanner.
• Only use the supplied power cord.
• Use only the specified power source voltage.
• Do not use a multiple outlet adapter to connect any other appliances or machines.
• Do not touch the plug of the power cord with a wet hand.
• Connect the plug of the power cord securly into the power outlet.
• Do not scratch, abrade, place a heavy object on, heat, twist, bend, pull on, or damage the power cord. Should any of these conditions be found, immediately turn OFF the power switch, unplug the power cord from the power outlet, and call your
Kodak Service Representative.
• Do not use an extension cord. Contact your Kodak Service Representative if an extension cord is required.
• Do not place any container that contains water, metal clips or other small metallic objects on this product.
• Should a piece of metal, water, or any other similar foreign matter get inside the product, immediately turn OFF the power switch, unplug the power cord from the power outlet, and call your Kodak Service Representative.
• If this product becomes inordinately hot or emits smoke, or unusual odor or noise, immediately turn OFF the power switch, unplug the power cord from the power outlet, and then call your Kodak Service Representative. A fire or electrical shock could result if you continue to use the product.
• Connect the plug of the power cord to a wall socket-outlet that is equipped with a grounding terminal.
• If this product has been dropped or the cover is damaged, immediately turn OFF the power switch, unplug the power cord from the power outlet, and call your Kodak Service Representative.
• Do not use flammable sprays, liquids, or gases near this product.
• Do not let any object plug the ventilation holes of this product.
• Do not install this product at a site that is exposed to direct sunlight, or near an air conditioner or heating apparatus.
• Do not place the product in a dusty place, or a site exposed to soot or steam, near a kitchen table, bath, or a humidifier.
• Do not place this product on an unstable or tilted bench, or in a location subject to a lot of vibration and shock
• After installing this product, mount it on a secure base.
• Do not store toner and PC drum units near a floppy disk or watch that are susceptible to magnetism.
• Do not place any objects around the power plug.
• The wall socket-outlet shall be installed near the machine and shall be easily accessible as the power plug may be difficult to pull out when an emergency occurs.
• Always use this product in a well-ventilated location.
• Whenever moving this product, be sure to disconnect the power cord and other cables.
• When unplugging the power cord, be sure to hold onto the plug.
• Do not store toner or PC drum units and other supplies and consumables in direct sunlight and high temperature and humidity.
• Do not attempt to replace the toner unit and PC drum unit in a place exposed to direct sunlight.
• Do not unpack a toner unit or PC drum unit until the time of use. Do not leave an unpacked unit standing; install it immediately.
• Do not keep toner and PC drum units in an upright position or upside down.
• Do not throw or drop a toner unit or PC drum unit.
A-61371 April 2010 i
• Do not use this product in an area where ammonia or other gases or chemicals are present.
• Do not use this product in an environment with a temperature outside the range specified in the Operator's Manual.
• Do not attempt to feed stapled paper, carbon paper or aluminum foil through this product.
• Do not touch or scratch the surface of the toner unit developing roller and the PC drum.
• Use only the recommended supplies and consumables.
Safety rules
• The unit should be kept free from moisture, dirt, dust and exposure to heat and direct sunlight at all times.
• Keep hands, hair and clothing away from rollers and other moving parts.
• Before removing the Projection Lamp Unit, confirm that the machine is turned "OFF".
• Be sure that the proper voltage is used and that the machine is well grounded. The use of electrical extension cords is strongly discouraged.
• For best performance, use the recommended supplies and consumables with this unit.
• Do not attempt to remove any cover that is secured.
FCC Part 15 - Radio Frequency Devices (For U.S.A. Users)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions:
• This device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation.
WARNING
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
The design and production of this unit conforms to FCC regulations, and any changes or modifications must be registered with the FCC and are subject to FCC control. Any changes made by the purchaser or user without first contacting the manufacturer will be subject to penalty under FCC regulations.
Interference-Causing Equipment Standard (ICES-003 ISSUE 4) (For Canada Users)
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
CE Marking (Declaration of Conformity) (For European Users)
This product complies with the following EU directives:
2006/95/EC and 2004/108/EC directives.
This declaration is valid for the area of the European Union (EU) only.
This device must be used with shielded interface cable and shielded network cable.
The use of non-shielded cable is likely to result in interference with radio communications and is prohibited under rules.
Acoustic Noise
Machine Noise Regulation 3 GSGV, 18.01.1991: The sound pressure level at the operator position according to EN27779 is equal to or less than 70dB (A).
European Union
This symbol indicates that when the last user wishes to discard this product, it must be sent to appropriate facilities for recovery and recycling. Please contact your local Kodak representative or refer to www.kodak.com/go/recycle for additional information on the collection and recovery programs available for this product.
ii A-61371 April 2010
REACH statement
Please consult www.kodak.com/go/REACH for information about the presence of substances included on the candidate list according to article 59(1) or Regulation (EC) No. 1907/2006 (REACH).
Battery Information
This product contains a Lithium Ion button cell battery. This battery can only be removed or replaced by a qualified Service
Engineer.
Safety Information (34PPM Video Laser Printer)
WARNING: This symbol warns against a potential for burns.
The inside of the printer has areas subject to high temperature, which may cause burns. When checking the inside of the unit for malfunctions such as a paper misfeed, do not touch the locations (around the fusing unit, etc.) which are indicated by a “CAUTION HOT” label.
Laser Safety: This printer is a page printer which operates by means of a laser. There is no possibility of danger from the laser, provided the printer is operated according to the instructions provided in this manual.
Since radiation emitted by the laser is completely confined within protective housing and external covers, the laser beam cannot escape from the machine during any phase of user operation.
This printer is certified as a Class 1 laser product: This means that the printer does not produce hazardous laser radiation.
Internal Laser Radiation: This product employs a Class IIIb Laser Diode that has an invisible laser beam. The Laser Diode and
Scanning Polygon Mirror are incorporated in the print head unit.
Maximum average radiation power: 37 µW at laser Aperture of mirror unit.
Wave length: 770-800 nm
The print head (in the interior of the printer in front of the toner cartridge) consists of the print head unit and the mirror unit. The laser beam is emitted from the print head unit, passes through the mirror unit, then is radiated through the laser aperture of the mirror unit to the interior of the printer.
WARNING: The print head unit is NOT A FIELD SERVICE ITEM. Therefore, the print head unit should not be opened under any circumstances
Laser
Aperture
Head
Unit
Mirror Unit
For United States
CDRH Regulations: This printer is certified as a Class I laser product under the Regulation Performance Standard according to the Food, Drug, and Cosmetic Act of 1990.
Compliance is mandatory for laser products marketed in the United States, and is reported to the Center for Devices and
Radiological Health (CDRH) of the U.S. Food and Drug Administration (FDA) of the Department of Health and Human Services
(DHHS). This means that the product does not produce hazardous laser radiation.
The label shown below indicated compliance with the CDRH regulations and must be attached to laser products marketed in the
United States.
CAUTION: Use of controls, adjustments or performance of procedures other than those specified in this manual may result in hazardous radiation exposure.
This is a semiconductor laser. The maximum power of the laser diode is 15mW, and the wavelength is 770-800 nm.
A-61371 April 2010 iii
All other users
WARNING: Use of controls, adjustments of performance or procedures other than those specified in this manual may result in hazardous radiation exposure.
This is a semiconductor laser. The maximum power of the laser diode is 15mW, and the wavelength is 770-800 nm.
For Denmark
ADVARSEL: Usynlig laserstråling ved åbning, når sikkerhedsafbrydere er ude af funktion. Undgå udsttelse for stråling. Klasse 1 laser produkt der opfylder IEC60825 sikkerheds kravene.
For Finland, Sweden
VAROITUS! : Laitteen käyttäminen muulla kuin tässä köyttöohjeessa mainitulla tavalla saattaa altistaa käyttäjän turvallisuusluokan 1 ylittävälle näkymättömälle lasersäteilylle
VARNNING: Om apparaten används på annat sätt än i denna bruksanvisning specificerats, kan använderen utsattasr för osynling laserstrålnig, som överskrider gränsen för laserklass 1.
VARO: Avattaessa ja suojalukitus ohitettaessa olet alttiina nakymattomalle lasersateilylle. Aja katso sateeseen.
VARNING: Osynlig laserstråining när denna del är öppnad och spärren är urkopplad. Betrakta ej stråien.
For Norway
ADVARSEL: Dersum apparatet brukes på annen måte enn spesifisert i denne bruksanvisning, kan brukeren utsettes for unsynlig laserstråling som overskrider grensen for laser klasse 1.
Dette er en halvleder laser. Maksimal effeckt til laserdiode er 15mW, og bolgelengde er 770-800 nm.
WARNING LABEL
Three laser caution labels are attached to the inside of the machine as shown below.
OZONE RELEASE (For all Users)
During printer operation a small quantity of ozone is released. This amount is not large enough to cause any adverse affects or harm. However, be sure the room where the machine is being used has adequate ventilation, especially if you are printing a high volume of materials, or if the machine is being used continuously over a long period.
WARNING LABEL
A laser safety label is attached to the outside of the machine as shown below.
CLASS 1 LASER PRODUCT
LASER KLASSE 1 PRODUKT iv A-61371 April 2010
