Nokia 6708 User Guide
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product RM-139 is in conformity with the provisions of the following Council Directive: 1999/5/EC.
A copy of the Declaration of Conformity can be found from http://www.nokia.com/phones/declaration_of_conformity/.
Copyright © 2006 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
US Patent No 5818437 and other pending patents. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java is a trademark of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider.
No license is granted or shall be implied for any other use.
ii Copyright ©2006 Nokia All right reserved
Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC.
See http://www.mpegla.com.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.
This device may contain commodities, technology, or software subject to export laws and regulations from the US and other countries.
Diversion contrary to law is prohibited.
Copyright ©2006 Nokia All right reserved iii
Table of Contents
1. Getting to Know Your Device ................................... 1
Rear View with Backcover Opened.......................................................3
2. Getting Your Device Ready For Use ......................... 8
Installing the SIM Card............................................................................8
Installing and Charging the Battery.................................................. 10
Installing the Battery ......................................................................... 10
Removing the Battery ........................................................................ 11
Charging the Battery.......................................................................... 12
3. Basic Operations ......................................................14
Turning On/Off Your Device................................................................. 14
Turning On Your Device..................................................................... 14
Turning Off Your Device .................................................................... 14
Navigating the Screen........................................................................... 14
Entering Text and Numbers ................................................................. 15
Entering Text and Numbers Using the Virtual Keyboard ......... 15
Entering Latin Alphabets and Numeric Characters....................16
Entering Chinese Characters ............................................................16
Entering Text and Numbers Using the Handwriting
Recognition Method ...........................................................................17
Entering Latin Alphabets and Numeric Characters....................17
Entering Chinese Characters ............................................................17
4. Using the Phone Functions ..................................... 19
Making a Call from the Phone Screen ...........................................19
Making a Call from the Contact List..............................................19
Making a Call from the Call Log......................................................19
Making a Call Using Speed Dial.......................................................20
Making a Call Using Voice Commander ........................................20
Operations During a Call .......................................................................21
Adjusting Volume.................................................................................21
Holding/Retrieving a Call ..................................................................21
Making Another New Call During a Call.......................................21
Answering an Incoming Call during a Call ...................................21
Ending the Active Call ........................................................................21
iv Copyright ©2006 Nokia All right reserved
Talking Privately to One Party during a Conference Call......... 22
Releasing a Calling Party During a Conference Call ................. 22
Ending a Conference Call.................................................................. 22
Miscellaneous Operations .................................................................... 23
Calling Voice Mail-box ...................................................................... 24
Hiding/Showing My Number ........................................................... 24
Transferring Sound.............................................................................. 24
Calling Emergency Numbers ............................................................ 24
Adding Speed Dial............................................................................... 25
Removing Speed Dial ......................................................................... 25
Adding number to Contacts............................................................. 25
Copying/Pasting Number .................................................................. 25
Adjusting Call Settings ...................................................................... 26
Adjusting Tones and Alerts............................................................... 26
Enabling/Disabling Automatic Keypad Lock ................................ 26
5. Using the Application Programs .............................28
Your Device Application Programs .................................................... 28
Creating and Sending Messages......................................................32
Receiving and Viewing Messages....................................................34
Creating a New Contact ....................................................................36
Importing Contacts from a SIM Card.............................................36
Exporting Contacts to a SIM Card ..................................................37
Viewing Contacts.................................................................................37
Managing Contacts Folders ..............................................................37
Managing Contacts.............................................................................37
Contacts Preferences ..........................................................................40
Creating New Calendar Entries........................................................40
Managing Calendar Entries...............................................................41
Managing Calendar Folders ..............................................................42
Setting up Calendar Preferences .....................................................42
Managing Notes...................................................................................43
Managing Note Folders......................................................................44
Copyright ©2006 Nokia All right reserved v
Camera Options When Taking Pictures and
Operations When Playing Music..................................................... 65
Managing Songs.................................................................................. 65
Managing Music Folders................................................................... 67
Viewing Video Clips Using Video Player ....................................... 67
Managing Video Folders.................................................................... 68
Managing Video Clips ........................................................................ 68
Organizing Images .............................................................................. 71
Adding Special Effects to images ................................................... 73
Connecting to/Disconnecting from the Internet........................ 76
Opening the Internet Browser..........................................................76
Key Operations When Browsing ......................................................77
Bookmarking Pages .............................................................................77
Saving Pages for Off-Line Browsing...............................................78
Going to Bookmarked Pages.............................................................78
Operations When Viewing Pages ....................................................78
Managing Bookmarks .........................................................................79
Managing Bookmark Folders ............................................................80
Browser Preferences............................................................................80
Viewing Current Time and Date.......................................................81
Setting Time and Date........................................................................81
Creating New Tasks.............................................................................82
Managing Tasks....................................................................................83
Managing Task Folders.......................................................................84
To-do Preferences................................................................................84
Creating a New Voice Note ..............................................................86
Playing Voice Notes ............................................................................86
Deleting Voice Notes ..........................................................................86
Sending Voice Notes ...........................................................................86
Using Auto Gain Control recording (AGC) ....................................87
vi Copyright ©2006 Nokia All right reserved
Viewing GPRS Data Log..................................................................... 87
Resetting GPRS Data Count ............................................................. 88
Deleting GPRS Data Log.................................................................... 88
6. Expanding the Capabilities of Your Device ........... 89
Installing Application Programs ......................................................... 89
Installing Application Programs from the Internet ................... 89
Installing Application Programs from Installation Files........... 89
Uninstalling Application Programs ................................................ 89
Installing/Removing a Memory Card ................................................ 90
Installing a Standard SD Memory Card ........................................ 90
Installing a Mini SD Memory Card................................................. 91
Removing a Memory Card ................................................................ 91
Formatting a Memory Card.............................................................. 91
Renaming a Memory Card................................................................ 92
7. Managing and Personalizing Your Device.............. 93
Managing Application Programs........................................................ 93
Grouping Application Programs...................................................... 93
Setting Application Programs on the Application
Personalizing Your Device .................................................................... 93
Customizing User Profiles................................................................. 93
Selecting a User Profile ..................................................................... 94
8. Getting Your Device Connected and
Synchronized................................................................. 95
Connecting the Device to Other Devices..........................................95
Infrared Connection ............................................................................95
USB Connection ...................................................................................95
Bluetooth Connection ........................................................................96
Using the Device as a GPRS Modem..................................................97
Setting up GPRS Modem via Infrared Connection.....................97
Setting up GPRS Modem via USB Connection ............................98
Setting up GPRS Modem via Bluetooth Connection .................99
Synchronizing Data .......................................................................... 100
Performing Remote Synchronization with a Server................ 100
9. Troubleshooting Information ................................ 101
Call Related Problems ......................................................................... 101
Message Problems................................................................................ 101
Application Program Problems ......................................................... 102
Connection Problems .......................................................................... 103
10. Battery information ............................................ 104
Charging and discharging.................................................................. 104
Nokia battery authentication guidelines....................................... 105
11. Genuine Enhancements ....................................... 107
Travel Charger (AC-1001C) ............................................................ 107
Copyright ©2006 Nokia All right reserved vii
Stereo Headset (HS-46) ..................................................................108
12. Care and Maintenance ........................................109
13. Additional Safety Information ........................... 110
Operating environment.......................................................................110
Potentially explosive environments.................................................111
Emergency calls .................................................................................112
To make an emergency call............................................................112
Certification information (SAR)........................................................113
viii Copyright ©2006 Nokia All right reserved
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.
SWITCH OFF WHEN REFUELLING
Do not use the device at a refueling point.
Do not use near fuel or chemicals.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the device where blasting is in progress.
USE SENSIBLY
Use only in the normal position as explained in the product documentation. Do not touch the antenna unnecessarily.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the device off near medical equipment.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
SWITCH OFF IN AIRCRAFT
Follow any restrictions.Wireless devices can cause interference in aircraft.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries.
Do not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
Copyright ©2006 Nokia All right reserved ix
BACK-UP COPIES
Remember to
make back-up copies or keep a written record of all important information.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.
Network services
EMERGENCY CALLS
Ensure the phone function of the device is switched on and in service. Press the key as many times as needed to clear the display and return to the start screen. Enter the emergency number, then press the
key. Give your location. Do not end the call until given permission to do so.
To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These network services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize network services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Your device may also have been specially configured. This configuration may include changes in menu names, menu order, and icons. Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols.Some features of this device, such as MMS, browsing, e-mail and content downloading using the browser or over MMS, require network support for these technologies.
For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider, network operator, or other vendor.
x Copyright ©2006 Nokia All right reserved
About your device
The wireless device described in this guide is approved for use on the GSM 900/1800/1900 networks. Contact your service provider for more information about networks.
When using the features in this device, obey all laws, and respect privacy and legitimate rights of others.
When taking and using images or video clips, obey all laws, and respect local customs as well as privacy and legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless device use may cause interference or danger.
Use only batteries, chargers, and enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous. For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.
Copyright ©2006 Nokia All right reserved xi
1
G e t t i n g t o K n o w Y o u r D e v i c e
1. Getting to Know Your Device
Front View
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
No.
Name Description
(1) Power key • Press and hold this key for about 3 seconds to power on and off the device.
• When the device is in sleep mode, press this key to wake up the device.
• When the device is not in sleep mode, press this key to open the Power menu that allows you to select a User profile.
(2) Touch screen The interface for displaying information and operating functions.
(3) Call key • If there is an incoming call, press this key to answer the call.
• In the Phone screen or the Main screen, press this key to access the call history.
(4) Left soft key Press this key to go to the preset mode.
The default setting is Contacts .
(5) Keypad Allows you to enter numbers, symbols and navigate in menus and screens.
(6) Earpiece Generates audio.
(7) Network status/ incoming call indicator
• Flashes in blue: you are under your home network.
• Flashes blue quickly: there is an incoming call.
Copyright ©2006 Nokia All right reserved
(8) Battery/ message indicator
• Flashes yellow: there is a new message or a missed call or beam file.
• Lights up in red: the battery is being charged.
• Flashes red: the battery is running low.
(9) End key
(10) Right soft key
• When there is an incoming call, press this key to reject the call.
• In the Main screen, press this key to go to the Phone screen.
Press this key to go to the preset mode.
The default setting is
(11) Microphone Receives audio.
Calendar .
G e t t i n g t o K n o w Y o u r D e v i c e
Copyright ©2006 Nokia All right reserved 2
G e t t i n g t o K n o w Y o u r D e v i c e
Rear View with Backcover Opened
(1)
(2)
(3)
(4)
No. Name Description
(1) Stylus and stylus housing
Accommodates the stylus.
(2) Loudspeaker
(3) Self-taking mirror
(4) Camera
Generates audio.
Used when taking your self photo.
Built-in type camera set for taking pictures and video clips.
(5) SIM card socket Allows you to install a SIM card.
(6) SIM card stay Holds the SIM card in place.
(7) Battery cover latch
Fixes the battery cover in place.
(8) USB connector Connects to a PC via the supplied data cable.
(9) Battery charger connector
Connects to the battery charger.
(5)
(6)
(7)
(8) (9)
3 Copyright ©2006 Nokia All right reserved
Left Side View
G e t t i n g t o K n o w Y o u r D e v i c e
Right Side View
(1)
(2)
(1)
(3)
(4)
No. Name
(1) Function side key
(2) Volume control key
(3) Memory card slot
(4) Headset connector
Description
• Allows you to set as a hotkey to your desired function.
• Press this key to go to the preset mode.
The default setting is the Main screen.
• By default, in the Phone screen, pressing and holding this key for about 3 seconds activates Voice Commander.
Allows you to control volume.
Allows you to install an SD memory card.
Connects the device to a compatible headset.
(2)
No. Name
(1) Camera key
(2) Infrared window
Description
• Press and hold this key for 3 seconds to go to the Camera screen for taking pictures or capturing video clips.
• When in Camera mode, press this key to take picture or start/stop to capture video clips.
Connects to other devices that support
Infrared connection.
Copyright ©2006 Nokia All right reserved 4
G e t t i n g t o K n o w Y o u r D e v i c e
The Main Screen
(1)
(2)
(3)
(5)
(5) Folder menu Tap this item to open a menu where you can organize your application programs or data using different folders.
(6) Scroll arrows
Tap the up or down arrow on tis button to scroll pages up or down in a screen.
(6)
(4)
No.
Name
(1) Application shortcut bar
Description
Contains shortcut icons for instant access to frequently used application programs.
You can also customize this shortcut bar.
(2) Menu bar Displays menu options in each application program screen.
(3) Application program icons
Allows you to access application programs on your device. Tap an icon to open the application program it represents.
(4) Status bar Displays various status icons.
5 Copyright ©2006 Nokia All right reserved
Status Bar Icons
Icon Description
Indicates signal strength. The more the bars displayed, the better the signal reception. Appearance of the vertical green bars indicates that the GPRS network is connected.
• The icon indicates that GSM network signal is available but no GPRS network is attached.
• The icon indicates that GPRS network is available but no GSM network is attached.
Indicates the status of audio setting.
the speaker is on
: the loudspeaker is in use
: the device is currently in Silent mode
the microphone is muted
Indicates battery status.
: Battery full
: Battery empty
Appears when a call is in progress.
Indicates that you have missed call(s).
Indicates that the incoming call is diverted to another phone.
This icon appears when you have new SMS message(s).
G e t t i n g t o K n o w Y o u r D e v i c e
This icon appears when you have new MMS message(s).
This icon appears when you have both new SMS and
MMS message(s).
This icon appears when you have new email(s).
Indicates that the infrared transmission is in progress.
Indicates that infrared function has been turned on.
Red
White
Green
• Indicates that the Bluetooth connection function has been turned on.
• Indicates that your device is discoverable in the
Bluetooth network.
• Indicates that Bluetooth transmission is in progress.
This icon appears when a headset has been connected to the device.
This icon appears when the keypad is locked.
Indicates that the virtual keyboard is available.
Appears when rejected callers list is set in Call settings .
Copyright ©2006 Nokia All right reserved 6
G e t t i n g t o K n o w Y o u r D e v i c e
The Stylus
The touch screen and stylus design allows you to easily and comfortably enter and browse information on your device.
You can take out the stylus from the device by gently pulling it from the stylus housing as illustrated below:
You can use the pointed tip of the stylus to touch an icon on the screen and to execute the function represented by that icon. This is expressed as "tap" an icon in this users guide. You can also use the stylus to enter text and numbers in combination with the handwriting input method.
The stylus can be further stretched to facilitate the convenience of use.
Important: Use only a stylus approved by Nokia for use with this device. Using any other stylus may invalidate any warranty applying to the device and may damage the touch pad. Avoid scratching the touch pad. Never use an actual pen or pencil or other sharp objects to write on the touch pad.
When you want to put the stylus back, slowly insert it back into the stylus housing.
7 Copyright ©2006 Nokia All right reserved
2. Getting Your Device Ready For Use
G e t t i n g Y o u r D e v i c e R e a d y F o r U s e
Installing the SIM Card
Upon the completion of your subscription to your network service provider, you receive a SIM (Subscriber Identity Module) card.
This card is used to store the services you have subscribed to your network service provider. For example, your phone number and phone book information.
1. Turn the device over and locate the SIM card socket.
SIM card socket
Important: For availability and information on using
SIM card services, contact your SIM card vendor. This may be the service provider, network operator, or other vendor.
Note: You can still use some functions of your device without SIM card in offline mode. To set Offline mode, refer
.
Important: Keep all SIM cards out of the reach of small children.
Copyright ©2006 Nokia All right reserved 8
G e t t i n g Y o u r D e v i c e R e a d y F o r U s e
2. Slide the SIM card in under the metal plate in the SIM card slot with the SIM card's metal contacts facing down and the cut corner at the bottom right.
3. Press down the SIM card stay (as illustrated).
SIM card stay
4. Push the card out of the slot.
Tip! If you want to remove the SIM card, please do the following:
1. Turn off the power of your device.
2. Remove the battery.
9 Copyright ©2006 Nokia All right reserved
G e t t i n g Y o u r D e v i c e R e a d y F o r U s e
Installing and Charging the Battery
Note: A PIN (Personal Identity Number) is associated with the SIM card. The four-digit code is supplied with the
SIM card from your service provider and may have to be entered when powering on the device. For more information, contact your network service provider.
Installing the Battery
1. Press the button at the bottom of the back cover and slide the cover off the device.
Copyright ©2006 Nokia All right reserved 10
G e t t i n g Y o u r D e v i c e R e a d y F o r U s e
2. Place the battery on the device with the battery’s contacts facing downwards and the tooth on the bottom edge of the battery in alignment with the hole on the device, and then press the battery down gently to click it back into place.
3. Push the back cover down on the device and slide it into place.
Removing the Battery
1. Turn off the power of the device.
2. Press the button at the bottom of the back cover and slide the cover off the device.
11 Copyright ©2006 Nokia All right reserved
G e t t i n g Y o u r D e v i c e R e a d y F o r U s e
4. Remove the battery from the device.
3. Slide the battery latch backward and lift the battery upward.
Important: Do not remove the battery when your device is on: you could lose all your personal settings stored either in your SIM card or in Nokia 6708 memory.
Charging the Battery
1. Insert the charger connector into the battery charger socket at the bottom of the device. Make sure you insert the connector with the arrow sign on the top.
2. Plug the charger into a mains outlet.
3. After your device is fully charged, disconnect the charger from the mains outlet and your device.
Copyright ©2006 Nokia All right reserved 12
G e t t i n g Y o u r D e v i c e R e a d y F o r U s e
Note: It takes approximately 3 hours for the travel charger to fully charge a new battery. However, actual time needed may vary.
• It takes at least one charging-discharging cycle for the battery to reach its peak performance.
• Your device can also be charged when connected to the USB via the supplied data cable.
• During charging, the screen of the device will indicate the status of the battery being charged when powered off, and the Battery/message indicator will stay red.
• When the battery is low, you will be prompted by a message on the screen, and the batteery/message indicator will keep flashing in red. When the battery is running out of power, another message will appear to remind you to recharge immediately. Your device will then power off automatically.
Initial Setup
1. Press and hold the power key for approximately 3 seconds.
2. The initial setup screen will follow within a few seconds, asking you to select the language you want to use. Use the stylus to tap the appropriate buttons and options, and then follow the instructions on the screen to proceed.
Note: Refer to " Setting Date and Time " on page 81
for how to setup current date and time.
13 Copyright ©2006 Nokia All right reserved
B a s i c O p e r a t i o n s
3. Basic Operations
Turning On/Off Your Device
Turning On Your Device
Press and hold the power key for approximately 3 seconds. The welcome screen will appear.
Your device has an internal antenna.
Note: As with any other radio transmitting device, do not touch the antenna unnecessarily when the device is switched on. Contact with the antenna affects call quality and may cause the device to operate at a higher power level than otherwise needed. Avoiding contact with the antenna area when operating the device optimizes the antenna performance and the battery life.
• Use the stylus to tap the desired icons in order to open a program or select options.
• Use the keys on the device to perform simple selection and confirmation:
Note: When the keys are used to input digits, for example, in the Message screen or the Phone screen, the navigation keypad will be disabled.
First item Up Previous page
Select/Confirm
Left
Right
Turning Off Your Device
When the power of the device is on, press and hold the power key for approximately 3 seconds.
Navigating the Screen
The keypad can be used to navigate the screen in some applications.
Last item Down Next page
• Press the
• Press the
• Press the
• Press the
• Press the
key to move the selection focus up.
key to move the selection focus down.
key to move the selection focus left.
key to move the selection focus right.
key to confirm selection.
• Press the key to go to the first item.
Copyright ©2006 Nokia All right reserved 14
B a s i c O p e r a t i o n s
• Press the
• Press the
• Press the
key to go to the last item.
key to go to the previous item.
key to go to the next item.
Please refer to the illustration below for a detailed description of each part of the virtual keyboard and their functions.
(a) (b) (c) (d)
Entering Text and Numbers
Your device is equipped with a powerful virtual keyboard feature and a handwriting recognition system that enable you to input data more naturally and efficiently.
Whenever text entry is required, the following handwriting tool bar will appear on the screen.
(e)
(f)
Entering Text and Numbers Using the Virtual
Keyboard
Whenever you want to enter/edit text and numbers, or when you tap the icon in the status bar, the virtual keyboard will appear on the screen. The icon will be displayed after tapping in the handwriting tool bar to collapse it.
Part Name
(a) Edit menu
(b) Previous field button
(c) Next field button
(d) Done button
Description
Tap this icon to open a menu where you can select the Cut , Copy and
Paste commands and setup keyboards of different languages.
Tap this button to go to the previous text entry field.
Tap this button to go to the next text entry field.
Tap this button to hide the virtual keyboard.
15 Copyright ©2006 Nokia All right reserved
(e) Text display area
(f) Input mode buttons
Displays the text you entered.
Tap these buttons to switch among different input modes.
B a s i c O p e r a t i o n s
3. The candidates that match the phonetic symbols/pinyin combination or strokes you tapped will appear in the
Candidate area.
Note: The input modes are subject to the current language used on the device.
Entering Latin Alphabets and Numeric
Characters
1. Tap the icon to switch to the Latin alphabet input mode, or the input mode.
icon to switch to the numeric character
2. Tap the desired buttons on the virtual keyboard. The text will appear in the Text display area.
3. Tap the Done button and the text will be placed in the text entry field.
Entering Chinese Characters
1. Tap the or
Stroke input method.
button to switch to the Pinyin or
2. Tap the desired buttons on the virtual keyboard.
Candidate area
If the Chinese character you want to enter appears in the candidate area, tap it and it will appear in the Text display area.
The possible associated characters will then follow in the
Candidate area. You can tap to choose an associated character directly, or continue entering another character by tapping the keys on the keyboard.
4. Tap the Done button and the text will be placed in the text entry field.
Copyright ©2006 Nokia All right reserved 16
B a s i c O p e r a t i o n s
Entering Text and Numbers Using the
Handwriting Recognition Method
Whenever text entry is required, the handwriting tool bar will appear on the screen indicating that the handwriting recognition function is ready.
• Tap to extend, or to collapse the Handwriting tool
• bar.
Tap or selecting mode.
to switch between handwriting and
• Tap and drag to adjust the position of the handwriting toolbar on the screen.
Entering Latin Alphabets and Numeric
Characters
1. Tap to change among Latin alphabet, numeric character or symbol input modes. If the current field is a numeric field - the mode is automatically switched to number.
2. Write from left to right and continuously on any part of the screen. When you stop writing, your strokes will be recognized and text will be placed in the input field automatically.
• Tap to open a menu that allows you to quickly enter certain punctuation marks.
• Tap to start a new line, to add a space (or write
from up to right). To delete a previously entered character, tap (or write from right to left).
• Tap to open Quick guide.
Entering Chinese Characters
1. Tap to switch to the Chinese input mode.
2. Tap to change among Chinese character, numeric character or symbol input modes.
3. Write the character on the screen. When you stop writing, your strokes will be recognized and the possible candidates will appear in the candidate area.
Candidate area
If the Chinese character you want to enter appears in the candidate area, tap it and it will be placed in the input field automatically.
17 Copyright ©2006 Nokia All right reserved
B a s i c O p e r a t i o n s
• Tap to open a menu that allows you to quickly enter certain punctuation marks.
• Tap to start a new line, to add a space (or write
from up to right). To delete a previously entered character, tap (or write from right to left).
• Tap to open Quick guide.
• Tap or to extend or collapse the Handwriting tool bar.
• Tap to extend the candidate area.
• Tap or to switch between handwriting and selecting mode.
• Tap and drag to adjust the position of the handwriting toolbar on the screen.
To setup handwriting recognition settings to fit your personal
writing habits, please refer to " Setting up smARTwriter " on page
.
Copyright ©2006 Nokia All right reserved 18
U s i n g t h e P h o n e F u n c t i o n s
4. Using the Phone Functions
Your device provides the phone functions with which you can:
• Make and receive phone calls.
• View phone records, including incoming calls and outgoing calls.
• Use voice commander to initiate calls.
• Access advanced phone features, for example, call barring and call divert.
Note: For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider, network operator, or other vendor.
Tip! To clear a wrong number, tap the press the key.
3. Tap the initiate the call.
button, or press the
button, or
key to
Making a Call from the Contact List
1. Press the key to open the Contact screen.
2. Tap to select a contact that contains the number you want to call. The contact will appear on the screen.
3. Tap the phone number of the record, and the call will be initiated automatically.
Making a Call
To make an outgoing call, you have the following options:
Making a Call from the Phone Screen
1. Press the (or tab to go to the Phone screen.
) key, and then tap the
2. Tap the numeric buttons on the Phone screen, or press the numeric keys on the keypad to enter the number you want to call.
Making a Call from the Call Log
1. Press the key, and then tap the tab to switch to the Call Log screen.
2. Tap to select a call log item on the Call Log screen.
Alternatively, you can also press the or to select a call log item, and press the to select it.
key
key
19 Copyright ©2006 Nokia All right reserved
U s i n g t h e P h o n e F u n c t i o n s
3. The content of the selected call log item will appear. Tap the
button, or press the key to initiate the call.
Making a Call Using Speed Dial
1. Press the (or ) key, and then tap the tab to switch to the Speed Dial screen.
2. Tap a speed dial icon on the screen, or press and hold a numeric key on the keypad representing the number (name) you want to call. The call will be initiated automatically.
Note: Refer to " Adding Speed Dial " on page 25
for how to set up speed dial.
Tip! You can also call the first 100 numbers in your SIM card phone book by pressing numeric key(s) followed by the
and keys on your device. For example, to call contact number 77 in your SIM card phone book, press
, , , .
Making a Call Using Voice Commander
1. Press and hold the function side key for about 3 seconds. The
Voice Commander will appear on the screen prompting you to say the command.
2. Speak the name for the contact you want to call.
3. Your device will identify the name and initiate the call.
Tip! You can repeat making the last dialed call by following the steps below:
1. Press the (or ) key, and then tap the tab to go to the Phone screen, or the tab to go to the
Speed Dial screen.
2. Press the key twice.
Note: Using voice tags may be difficult in a noisy environment or during an emergency, so you should not rely solely upon voice dialing in all circumstances.
Answering a Call
When you have an incoming call, caller’s name (if available, depending on the setting of the caller’s phone and the network), picture (if enabled) and the following options will appear on the screen.
Copyright ©2006 Nokia All right reserved 20
U s i n g t h e P h o n e F u n c t i o n s
• Answer : Tap this button to answer the call. You can also answer the call by pressing the key.
• Mute : Turn off the ring signal temporarily. you can choose to tap the Answer button to answer it later, or the Send busy button to reject it.
• Send busy : Tap this button to reject the call (or press the
key).
Holding/Retrieving a Call
During a call, tap the Hold button to hold current call. To retrieve the held call, tap the Retrieve button.
Making Another New Call During a Call
During a call, use the numeric buttons on the Phone screen, or press the numeric keys on the keypad to make another call. The call in progress will be put on hold automatically.
Ending a Call
To end a call, tap the End button, or press the key.
Operations During a Call
Adjusting Volume
1. During a call, tap the icon on the Status bar. The
Sounds dialog will appear. Alternatively, you can press the volume key on the left side of the device.
2. Tap and drag the Call volume slider to adjust call volume.
You can also tap the Speaker phone or Mute microphone check box to play sound via the speaker phone or mute the microphone during the call.
Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.
Answering an Incoming Call during a Call
To answer an incoming call during a call, tap the Answer button, or press the hold automatically.
key. The current active call will be put on
When the new incoming call is disconnected, the old call will be retrieved automatically.
Switching Calls
If you have multiple active calls in progress simultaneously, you can tap the Switch button to switch calls.
Ending the Active Call
To end all active call, press the key.
21 Copyright ©2006 Nokia All right reserved
U s i n g t h e P h o n e F u n c t i o n s
Conference Call
Ending a Conference Call
To end a conference call, tap the End button.
Note: This function is a network service dependent function and may require additional subscription.
• The Call Waiting function must be enabled before you can
use the Conference Call function. See " Call Waiting " on page
for more information.
To make a conference call:
1. During a call, make a new call to another new calling party, or answer a new incoming call. Repeat this step if there are multiple calling parties.
2. Tap the Conference button. All active calling parties will be joined together.
Talking Privately to One Party during a
Conference Call
1. Tap the party you would like to call privately.
2. A menu will appear. Tap Extract party . The selected calling party will become the only active one and others will be put on hold automatically.
Releasing a Calling Party During a
Conference Call
1. Tap a calling party on the screen.
2. A menu will appear. Tap Release party .
Call Logs
The Call Logs function provides you with the records of the following call types:
• Answered calls (indicated by the icon)
• Outgoing calls (indicated by the icon)
• Missed calls (indicated by the icon)
• Rejected calls (indicated by the icon)
Tip! If you have missed call(s), the Missed calls dialog will stay on the screen letting you know about the number of calls missed. Tap the View button to enter the Missed Call
Logs screen. If Cancel is tapped, the icon will stay on the screen and you can tap it to open the Missed calls dialog box.
To access Call Logs:
1. Press the (or tab to open the Call Logs screen.
) key and then tap the
2. Tap All Calls to open a menu for selecting the type of call logs you want to view.
3. Tap to select a call type on the menu, and the corresponding call logs will appear on the screen.
Copyright ©2006 Nokia All right reserved 22
U s i n g t h e P h o n e F u n c t i o n s
4. Tap a call log record and the detail information will appear on the screen.
Miscellaneous Operations
Tip! You can make a phone call from a call log record.
Please refer to " Making a Call from the Call Log " on page 19
for details.
Ending All Calls
1. Press the (or tab to go to the Phone screen.
) key, and then tap the
2. Tap Phone , and then tap End all calls to end all calls.
Call Logs Options
Viewing Call Information
1. Press the (or tab to open the Call Logs screen.
) key, and then tap the
2. Tap Phone and select Total call info .
3. The Total call info screen will appear. You can tap the Reset button to reset call information, or tap the Done button to exit.
Deleting All Call Logs
1. Press the (or ) key, and then tap the tab to open the Call Logs screen.
2. Tap Phone and select Delete all calls .
Showing Cost
When enabled, upon ending an outgoing call, the cost of the call will appear on the screen.
1. Press the (or tab to go to the Phone screen.
) key, and then tap the
2. Tap Phone , and then tap Show cost to end all calls.
Note: The actual invoice for calls and services from your service provider may vary, depending on network features, rounding off for billing, taxes and so forth. To show
cost, refer to " Call settings " on page 56
to set the Call cost first.
23 Copyright ©2006 Nokia All right reserved
U s i n g t h e P h o n e F u n c t i o n s
Calling Voice Mail-box
1. Press the (or tab to go to the Phone screen.
) key, and then tap the
2. To start calling your voice mail-box, tap Phone and then tap
Call voice mail-box .
Alternatively, press and hold the feature.
key to activate the
Transferring Sound
During a call, you can use this feature to transfer the call from the paired Bluetooth headset to the handset.
1. Press the (or tab to go to the Phone screen.
) key, and then tap the
2. Tap Phone , and then select Transfer sound .
Note: If your voice mail-box number is not set, you will be prompted to enter it. The voice mail-box number is available from your network service provider.
Note: To enable this function, you have to pair your device with a Bluetooth headset first. Once the call is transferred from the Bluetooth headset to the device during a call, you cannot transfer the call back to the Bluetooth headset again.
Hiding/Showing My Number
When making an outgoing call, you can choose to hide or show your phone number to the recipient of your call.
1. Press the (or tab to go to the Phone screen.
) key, and then tap the
2. Check or uncheck Hide my number to hide or show the number.
3. Tap the initiate the call.
button, or press the key to
Calling Emergency Numbers
This operation allows you to easily access the pre-stored emergency numbers.
1. Press the (or tab to go to the Phone screen.
) key, and then tap the
2. Tap Phone , and then select Emergency numbers.
3. Tap to choose an emergency number from the box, and then tap the Done button to begin dialing the selected number.
Copyright ©2006 Nokia All right reserved 24
U s i n g t h e P h o n e F u n c t i o n s
Tip: Depending on your local network service, the emergency numbers may be called without a SIM card as long as you are under the GSM network coverage. Please check with your network service provider for details.
Adding Speed Dial
Method 1 (using the stylus)
1. Press the (or ) key, and then tap the tab to switch to the Speed Dial screen.
2. Tap to choose an empty speed dial icon. A Select contact window will appear.
3. Choose an appropriate folder, and tap to select a contact from the window, then tap the Done button.
Method 2 (using the keypad)
1. Press the (or ) key, and then tap the tab to switch to the Speed Dial screen.
2. Press and hold any of the numeric key representing an empty speed dial on the keypad for about 3 seconds.
Note: You can press any of the numeric key except 0 and 1 to add Speed Dial.
3. A Select contact window will appear. Choose an appropriate folder, and tap to select a contact, then tap the Done button.
Removing Speed Dial
1. Press the (or ) key, and then tap the tab to switch to the Speed Dial screen.
2. Tap Edit and select Remove speed dial .
3. The Remove speed dial window will appear. Tap to select the speed dial numbers you want to remove and then tap the
Done button.
Adding number to Contacts
1. Press the (or tab to enter the Phone screen.
) key, and then tap the
2. Enter the phone number.
3. When finished, tap Edit and select Add to contacts .
Copying/Pasting Number
With this operation, you can copy the number you entered in the
Phone screen for pasting onto other application programs, for example, Calendar, or copy the number in other application programs onto the Phone screen.
Copying number
1. Press the (or tab to enter the Phone screen.
) key, and then tap the
25 Copyright ©2006 Nokia All right reserved
U s i n g t h e P h o n e F u n c t i o n s
2. Enter the phone number.
3. When finished, tap Edit and select Copy number .
Pasting number
1. Copy the phone number from other application programs.
2. Press the (or tab to enter the Phone screen.
) key, and then tap the
3. Tap Edit and select Paste number .
Zoom
This operation enlarges the user interface on the screen for easier identification and access.
) key to enter the Phone 1. Press the screen.
(or
2. Tap Edit and select Zoom .
Adjusting Call Settings
You can access Call settings following either of the methods below:
• In the Phone screen, tap Edit and select Call settings .
• Go to Settings by tapping the icon in the Main screen, and then tap Call settings on the tab.
For more information about Call settings, see " Call settings " on page 56
.
Adjusting Tones and Alerts
This operation allows you to customize the audio settings of your device.
1. Press the (or tab to enter the Phone screen.
) key, and then tap the
2. Tap Edit and select Tones and alerts .
3. Tap to choose a profile from the menu that appears.
4. Adjust sound settings by selecting a sound for each setting item (for example, Ringing tone , SMS , or MMS ) from the menu, or select Find sound to locate a sound file on your device.
5. Tap the Save button to save your settings for the selected profile, or the Done button to save and apply your settings.
Enabling/Disabling Automatic Keypad Lock
1. Tap the icon in the Application shortcut bar.
2. Tap View and select Keypad lock .
3. A Keypad lock box will appear. Tap to check/uncheck the
Enable automatic keypad lock check box and then tap the
Done button to enable/disable automatic keypad lock.
If automatic keypad lock is enabled, the keys on your device or buttons in the Phone screen will be locked if there is no key or button operation for 30 seconds.
Copyright ©2006 Nokia All right reserved 26
U s i n g t h e P h o n e F u n c t i o n s
Note: When the keypad lock is on, calls still may be possible to the official emergency number programmed into your device.
•
Tip: You can also press the key, then the key in the Phone screen to lock the keypad.
To unlock the keypad, press the
key.
key, and then the
Accessing Help
The Help system on your device provides you with instant information about how to use your device.
To access Help:
) key to enter the Phone 1. Press the screen.
(or
2. Tap Edit and select Help .
27 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
5. Using the Application Programs
The Main Screen
The Main screen is where you can easily access the application programs on your device (for example, Calender, Contacts,
Messaging, and Internet).
• Tap the icon in the Application shortcut bar, all application program icons on your device are displayed. Tap an application program icon to open the application program it represents.
• You can also tap one of the icons at the top of the screen.
These are shortcuts that are always visible. To customize
your shortcuts, see " Setting Application Programs on the
Application Shortcut Bar " on page 93 .
If you have a lot of application programs on your device, use folders to organize them in the Main screen. There are pre-set folders, such as Office (for business application programs) and
Internet (for web-based application programs). To organize your
application programs in folders, see " Grouping Application
.
Your Device Application Programs
Your device comes pre-installed with the following application programs:
Phone
For using the phone functions. See " Using the Phone Functions " on page 19 for details.
Messaging
For creating, sending and receiving messages. See " Messaging " on page 31
for details
Contacts
For managing your contacts. Your contact database can also be
used for making phone calls or sending emails. See " Contacts " on page 36
for details.
Calendar
For organizing your personal appointments and events.
See " Calendar " on page 40 for details.
Copyright ©2006 Nokia All right reserved 28
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Note
A very useful program for jotting down memos. See " Note " on page 43
for details.
Settings
Allows you to setup the settings of your device. See " Settings " on page 44
for details.
Camera
Use this application program with the built-in camera for
capturing still photos and video clips. See " Camera " on page 60
for details.
Music player
With this application program you can listen to music transferred
from your PC or downloaded from the Internet. See " Music
Player " on page 64 for details.
Video player
For playing video clips captured by the built-in camera, transferred from your PC or downloaded from the Internet.
See " Video Player " on page 67
for details.
PhotoBase
Allows you to view and edit images on your device.
for details.
Internet
Allows you to surf the Internet and access various on-line
information. See " Internet " on page 76
for details.
Time
For configuring time/date information and setting alarms.
See " Time " on page 81 for details.
To-do
For tracking your daily todo items. See " To-do " on page 82
for details.
Calculator
Your handy calculator for making calculations. See " Calculator " on page 84 for details.
Remote sync
For performing synchronization via remote connection, refer to
" Performing Remote Synchronization with a Server " on page 100
for details.
Voice
For recording and playing voice notes. See " Voice " on page 85 for
details.
Screen saver
For displaying the screen saver of your device.
29 Copyright ©2006 Nokia All right reserved
Online services
For accessing services of your network service provider.
See " Online Services " on page 87 for details.
GPRS data log
For tracking your GPRS connection history. See " GPRS Data Log " on page 87 for details.
9 Ball
This is a billiards game. For more information, please refer to the online Help in the application.
To access online Help:
1. Open the 9 Ball application.
or keys until Help displays on the 2. Press the screen.
• Press the key to open Help.
Extra Applications
This feature provides you the access to the support pages which requires GPRS connection. With this feature you can install the software on your device or access the care and service information.
File Manager
The function allows you to manage the files on the device, or check the memory information.
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Quickpoint
Allows you to view PowerPoint presentations and open native PC format e-mail attachments directly on your device. For details, tap View and select Help in the application.
Quicksheet
This application provides 84 of the commonest formulae found in
Microsoft Excel on your device. For details, tap Edit and select
Help in the application.
Quickword
This application allows you to work with text and word processing documents on your device. For details, tap Edit and select Help in the application.
Recon
With this application program you can use your device to remote control your home applications such as TV, DVD player, air conditioner and so on.
only.
Note: Please use this feature in the authorized area
Stuntcar Extreme
You can play the built-in car race game. For details, read Help in the application.
Copyright ©2006 Nokia All right reserved 30
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Super Drop Mania
A built-in game for you to play. For details, read Help in the application.
Voice Commander
This program allows you to control your device by voice. You can use voice to make a phone call, look up contact person's information or start a program.
XLex Dictionary
A built-in dictionary on the device allows you to look up the
English and Chinese words. For details, tap XLex Dictionary and select Help in the application.
Note: Leaving applications running in the background increases the demand on battery power and reduces the battery life.
• In order to use the Messaging functions, you may need to set
up message settings in advance. Please refer to " Messaging accounts " on page 50
, " Wap accounts " on page 49 , and
" Internet accounts " on page 48
.
SMS (Short Message Service) messages (indicated by the
icon)
An SMS message is a text message delivered from your device via the message center of your service provider to the recipient. In addition to text, it can contain pictures, melodies and animations.
MMS (Multimedia Message Service) messages (represented by the icon)
An MMS message is a message that can contain text, pictures, animations, audio clips and melodies.
Messaging
With the Messaging application program, you can exchange and manage the following types of messages:
Note: Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
Email messages (represented by the icon)
Messages that support POP3, IMAP4, or SMTP protocols and are the same as the ones you can send and receive using your PC.
Note: You need subscription to related services to your network service provider.
Important: Exercise caution when opening messages.
Email messages may contain malicious software or otherwise be harmful to your device or PC.
31 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
CBM (Cell broadcast messages)
Cell broadcast messages is broadcast by the network service provider within a given part of the network coverage area. For details, tap Edit and select Help in CBM.
Creating and Sending Messages
Creating and Sending an SMS Message
1. In the Messaging screen, tap SMS .
2. Tap the New button, or tap Message and select New .
3. Enter the recipient’s phone number in the To: field. You can also tap To: to pick up one or multiple recipient from your contacts.
4. Enter the body text of the message. An SMS message allows the entry of up to 160 characters (70 for non-latin characters) per message, and if the length of your message body exceeds such limit, it will be split into several separate ones and combined into one single message on the recipient’s phone (if supported). You can tap located at the upper right corner of the screen to get the information about current message length information.
Your device supports the sending of text messages beyond the character limit for a single message. Longer messages are sent as a series of two or more messages. Your service provider may charge accordingly. Characters that use accents or other marks, and characters from some language options like Chinese, take up more space limiting the number of characters that can be sent in a single message.
Tip: You can tap Edit and select the Cut , Copy , Paste and
Select all commands when editing text.
5. (Optional) Tap the button to insert a smiley into the message.
6. (Optional) Tap the button to insert an animation or an image into the message.
7. (Optional) Tap the button to insert sound into the message.
8. (Optional) Tap the button to switch between normal and bold text types.
9. (Optional) Tap the button to change text size.
10. (Optional) Tap the button to view common used text.
11. Tap the tab to determine if you want to receive a delivery report for current message. Tap to select On or Off .
If On is selected, you will receive a report regarding the delivery status when the message is sent.
12. Tap the Send button to send the message. If you want to save the message in the Draft box for future editing, tap the
button.
Note: If for any reason the message can not be sent, it will be stored in the Outbox .
Copyright ©2006 Nokia All right reserved 32
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• When sending messages, your device may display "Message
Sent". This is an indication that the message has been sent by your device to the message center number programmed into your device. This is not an indication that the message has been received at the intended destination. For more details about messaging services, check with your service provider.
Creating and sending an MMS Message
1. In the Messaging screen, tap MMS .
2. Tap the New button, or tap Message and select New .
7. (Optional) Tap the icon to insert sounds into current slide, or record sounds for this slide.
8. (Optional) To add more slides, tap the icon, or tap
Message and then select New slide . To go to a slide, tap or
. To delete current slide, tap Message and then select
Delete slide . You can also tap to setup the duration of each slide.
9. To preview the slides, tap the icon.
10. Tap to go to the tab where you can select the carbon copy and blind carbon copy recipients, select a priority level for the message, and check the message size.
11. Tap to go to the tab where you can attach an image, audio recording, or video clip to current message.
Note: An MMS message comprises several slides and you can add text and sounds to each slide. When the message is opened and viewed on the recipient’s compatible device, the slides are automatically played. The sound will also be played if the slide contains it.
3. Enter the recipient’s phone number in the To: field. You can also tap To: to pick up one or multiple recipient from your contacts.
4. Enter the subject in the Subj: field.
5. Enter message body text.
6. (Optional) Tap the icon to browse and insert an image into current slide. To change or delete selected image, tap the image and select Select image or Delete image .
Note: The wireless network may limit the size of MMS messages. If the inserted images and sounds exceed this limit, the device may not be able to send the message. In addition, the maximum size of an MMS message is 100K.
12. Tap the Send button to send the message. If you want to save the message in the Draft box for future editing, tap the
button.
Note: If for any reason the message can not be sent, it will be stored in the Outbox.
33 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Creating and sending an Email Message
Note: In order to use email, you need to complete
message settings in advance. Please refer to " Messaging accounts " on page 50
.
1. In the Messaging screen, tap an email account.
2. Tap the New button, or tap Message and select New .
3. Enter the recipient’s email address in the To: field. You can also tap To: to pick up one or multiple recipient from your contacts.
4. Enter the subject in the Subj: field.
5. Enter the message body text.
6. (Optional) Tap the button to browse and add attachment to the mail.
7. Tap the Send button to send the email. A dialog will pop up asking whether you want to send the message immediately or save the message to Outbox for sending later. Tap to select an appropriate option and then tap the Done button.
Note: If for any reason the message can not be sent, it will be stored in the Outbox.
Message Folders
By default, each message account has 4 different message folders:
• Inbox : Contains received messages.
• Outbox : Contains messages that are ready to be sent but not sent.
• Draft : Contains unfinished messages.
• Sent : Contains a copy of the sent messages.
You can tap a folder name at the upper right corner of each mail account screen and tap to select a different folder.
Receiving and Viewing Messages
Important: Exercise caution when opening messages.
Multimedia message objects may contain malicious software or otherwise be harmful to your device or PC.
Receiving and Viewing SMS and MMS Messages
When you have new SMS or MMS messages, the notification icon
( for SMS, for MMS, and for both new SMS and
MMS messages) will appear on the Status bar. You can tap the icon to view the message.
When viewing messages, you can tap Message and choose to perform the following operations:
• New : Create a new message.
• Reply : Reply to the sender.
• Reply to all (available for MMS only): Reply to the sender and all receivers of this message.
• Forward : Send the received message to other recipients.
Copyright ©2006 Nokia All right reserved 34
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• Send attachment (available for MMS only): Send the message with the attachment.
• Find : Find a specific word in the message.
• Find next : Find the word again.
• Call Sender : Make a call to the sender of the message.
• Move to SIM Card or Move to Messaging (available for SMS messages): Move current message to the memory on SIM card or your device, depending on where the message is currently saved.
• Delete message : Delete current message.
• Disconnect (available for MMS only): Break the Internet connection.
You can also tap the From: field and select to perform the following actions:
• Call : Call this number.
• Send SMS : Send an SMS message to this number.
• Send MMS : Send an MMS message to this number.
• Save contact : Save this number as a new contact.
Receiving and Viewing Email
1. In the Messaging screen, tap an email account.
2. Tap the Get&Send button.
Note: In order to receive and view email, you need to set up Internet and message settings in advance. Please refer
to " Messaging accounts " on page 50 and "
Internet accounts " on page 48 .
3. You will be connected to the Internet automatically, and the device will start sending and receiving email from your mailbox.
4. The received email will appear on the screen. Tap an email message to open and read it. If there are attachments in the email, you can tap to open and view them if they are supported by the application programs on the device.
Important: Exercise caution when opening messages.
E-mail messages may contain malicious software or otherwise be harmful to your device or PC.
When viewing messages, you can tap Message and choose to perform the following operations:
• New : Create a new email.
• Reply : Reply to the sender.
• Reply to all : Reply to all recipients.
• Forward : Send the received email to other recipients.
• Send attachment : Send the attachment of current email.
• Save attachment : Save the attachment of current email.
• Find : Find a specific word in the email.
• Find next : Find the word again.
• Delete message : Delete current email.
• Disconnect : Break the connection to your mailbox.
You can also tap the From: field and select to perform the following actions:
• Send e-mail : send an email to this address.
• Send MMS : send an MMS message to this address.
35 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• Save contact : save this address as a new contact.
Contacts
With the Contact application program, you can easily manage your contacts. In addition to just carrying and viewing these records, you can also quickly make phone calls, send messages/ email and open web pages thanks to the integration with other application programs.
Creating a New Contact
Creating a New Contact from the Phone Screen
See " Adding number to Contacts " on page 25 for more
information.
Creating a New Contact from the Contacts Screen
1. In the Contacts screen, tap Contacts and select New .
2. Tap Unfiled and select a folder where you want to place this contact.
3. Enter contact information.
Note: The personalized ringing tone will only be played if your phone network is CLI (Calling Line Identity) compatible, so the caller can be identified. Otherwise, the default ring tone will be used, regardless of your selection of ringing tone.
4. (Optional) Tap the tab to enter your note for this contact.
5. (Optional) Tap the tab to specify a picture for this contact. Tap the icon to open a box where you can browse and select a picture.
6. Tap the button to save the contact.
Importing Contacts from a SIM Card
1. Make sure that the SIM card is installed on your device.
2. In the Contact screen, tap Phone and select SIM card .
3. Tap Edit and select Copy all to contacts .
4. In the box that follows, tap the Yes button.
Tip: You can specify a ringing tone for the contact by selecting a ringing tone from the Ringing tone drop-down menu.
Copyright ©2006 Nokia All right reserved 36
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Exporting Contacts to a SIM Card
1. Make sure that the SIM card is installed on your device.
2. In the Contacts screen, tap to select a folder that contains the contact you want to export.
3. Tap to open the contact from the list.
4. Tap Edit and select Copy to SIM card .
Managing Contacts Folders
1. In the Contacts screen, tap Phone and select Edit folders .
2. You can:
• Tap the Add button to create a new folder. You will then be asked to enter a name for the new folder. When finished, tap the Done button.
• Tap to select a folder on the list and then tap the Delete button to delete the selected folder.
• Tap the Rename button to change the name of the selected folder. Make changes and then tap the Done button.
Viewing Contacts
The Contact screen displays all contacts on your device. You can also tap a tab below to view only the contacts that begin with the letters on the tab.
To view the detail information of a contact, tap a contact on the screen.
You can:
• Tap the icon, icon or the phone number to make a call to the person.
• Tap the icon or the mail address to start composing a new email for the person.
Managing Contacts
Finding a Contact
1. In the Contacts screen, tap Contacts and select Find .
2. Enter the search keyword and specify where in Contacts will be searched ( in all fields or in Names & Company ).
3. Tap the Find button.
4. The contacts that match your search keyword will appear on the screen. You can tap to select and open a contact.
Note: E-mail messages are automatically placed in
Draft before sending. If sending does not succeed, the e-mail is left in the Outbox.
• Tap the icon or the web address to open the web page in the Internet application program.
Editing a Contact
1. Open a contact.
2. Tap Edit and select Edit contact .
3. Make changes to the contact information.
37 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
4. Tap the button.
Deleting a Contact
Method 1
1. Open a contact.
2. Tap Contacts and select Delete contact .
Method 2
1. In the Contacts screen, tap Contacts and select Contacts manager .
2. Tap to select a folder that contains the contact you want to delete from the Folder drop-down list.
3. In the box below, tap to check the contact(s) you want to delete. You can also tap the Select all check box to select all contacts in the selected folder.
4. Tap the Delete button, and then the Yes button in the box that follows.
5. Tap the Done button.
Copying Contacts
1. Open a contact.
2. Tap Edit and select Copy contact .
Pasting Contacts
In the Contacts screen, tap Edit and select Paste contact .
Moving Contacts to a Different Folder
1. In the Contacts screen, tap Contacts and select Contacts manager .
2. Tap to select a folder that contains the contact you want to move from the Folder drop-down list.
3. Tap to check the contact(s) you want to move. You can also tap the Select all check box to select all contacts in the selected folder.
4. Tap the Move button, and then tap to select the folder where the contact(s) will be moved in the Folder drop-down list in the box that follows.
5. You can tap the Folder button if you wish to create a new folder. Then tap the Move button.
Sending Contacts
Sending a Contact
1. Open a contact.
2. Tap Contacts and select Send as .
3. Select from the following and then tap the Done button:
• Email : send the contact as email attachment. This option is available only when an Email account is created on the device.
• Message : Send the contact to other compatible devices via an SMS message. Enter the number of the recipient and then tap the Send button.
Copyright ©2006 Nokia All right reserved 38
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• MMS : Send the contact to other compatible devices as an
MMS attachment. The MMS message screen will follow for you to compose the message.
Note: Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
• Bluetooth : Send the contact to other compatible devices that support Bluetooth connectivity. A box will appear showing found paired devices. Tap to select a device and then tap the Send button.
• Infrared : Send the contact to other compatible devices that support infrared connection. Align the infrared port of your device with that of the other device, then the transfer will start automatically.
Sending Multiple Contacts
1. In the Contacts screen, tap Contacts and select Contacts manager .
2. Tap to select a folder that contains the contacts you want to send from the Folder drop-down list.
3. Tap to check the contact(s) you want to send. You can also tap the Select all check box to select all contacts in the selected folder.
4. Tap the Send button.
5. Perform the same operation as described in step 3 in
" Sending a Contact " on page 38 .
Sending All Contacts in a Folder
1. In the Contacts screen, tap Phone and select a folder.
2. Tap Contacts and select Send this folder .
3. Perform the same operation as described in step 3 in
" Sending a Contact " on page 38 .
Owner Card
The owner card is your electronic name card. Once created, you can exchange it freely with other people.
Creating Your Owner Card
Method 1
1. In the Contacts screen, tap Contacts and select New .
2. Enter your personal data.
3. Tap Contacts and select Set as owner card .
4. Tap the button.
Method 2
1. Open a contact.
2. Tap Contacts and select Set as owner card .
1. In the Contacts screen, tap Contacts and select Send owner card .
2. Perform the same operation as described in step 3 in
" Sending a Contact " on page 38 .
39 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Editing Owner Card
1. In the Contacts screen, tap Contacts and select View owner card .
2. Perform the same operation as described in " Editing a
.
Contacts Preferences
1. In the Contacts screen, tap Edit and select Preferences .
2. In the box that follows, tap to select a method by which the
Contacts application program sorts your contacts.
3. If you want the preferred phone number to appear next to the contact name when viewing, tap the Show preferred phone number check box. If this option is selected and no preferred number is specified, the first phone number in the contact will be used as the preferred number.
4. Tap the Done button.
Specifying Preferred Phone Number for Contacts
1. Open a contact.
2. Tap Edit and then select Edit contact .
3. Edit the contact information.
4. Tap Edit and then select Show in list .
5. Tap to select a preferred number from the drop-down menu.
6. Tap the Done button.
Calendar
To open the Calendar application program, tap the Calendar icon in the Main screen.
Creating New Calendar Entries
To create a new Calendar entry:
1. In the Calendar screen, tap Calendar and select New .
2. Tap Unfiled and select a folder where you want to store the new entry.
3. Enter the description of the entry and other necessary information.
4. Tap to switch to the note page to write down your note for this entry (optional).
5. Tap the button to save the entry.
Copyright ©2006 Nokia All right reserved 40
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Calendar Views
The Calendar screen provides different views:
• Tap to change to Day view. Calendar entries appear as vertical bars. In
Day view, tap a button on the bar to go to a specific day in the week.
• Tap to change to
Week view. Calendar entries appear as vertical bars. In Week view, tap or to go to the previous or next week.
• Tap to change to
Month view. Calendar entries appear as squares.
In Month view, tap or
to go to the previous or next month.
Managing Calendar Entries
Finding an Entry
To find a specific Calendar entry:
1. In the Calendar screen, tap Calendar and select Find .
2. Enter the keyword and select Everywhere , Future or Past to select where to search.
3. Tap the Find button.
4. The entries that match your search keyword will appear on the screen. You can tap to select and open an entry.
41 Copyright ©2006 Nokia All right reserved
Editing an Entry
1. Open a Calendar entry by tapping it in different views.
2. Make changes to the entry.
3. Tap the button to save your changes.
Deleting an Entry
1. Open a Calendar entry by tapping it in different views.
2. Tap Calendar and select Delete entry .
Deleting Entries in a Period of Time
1. When in the Calendar screen, tap Calendar and select
Remove entries .
2. Tap to select a removal range and then tap the Done button.
Moving a Calendar entry to the To-do Application
Program
1. Open a Calendar entry by tapping it in different views.
2. Tap Calendar and select Move to To-do .
3. Tap the Yes button. The entry will appear in the To-do application program.
4. Tap the button to save your changes.
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Cutting, Copying or Pasting a Calendar Entry to the
To-do Application Program
1. Open a Calendar entry by tapping it in different views.
2. Tap Edit and select Cut entry or Copy entry .
3. Open the To-do application program.
4. Tap Edit and then select Paste entry .
Managing Calendar Folders
1. In the Calendar screen, tap All and select Edit folders .
2. You can:
• Tap the Add button to create a new folder. You will then be asked to enter a name and specify a color for the entries that belong to the new folder. When finished, tap the Done button.
• Tap to select a folder in the list and then tap the Delete button to delete the selected folder.
• Tap the Edit button to edit selected folder. Make changes and then tap the Done button.
Setting up Calendar Preferences
To access Calendar preferences:
1. In the Calendar screen, tap Edit and select Preferences .
2. The Calendar preferences window will appear. Set up the options on the General and Alarm tabs.
3. Tap the Done button.
Copyright ©2006 Nokia All right reserved 42
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Note
With the Note application program you can quickly and easily jot down notes, whether in typed letters or freehand drawing. You can also easily exchange them by sending them to different compatible devices.
Creating Notes
Method 1
1. In the Note screen, tap Note and select New .
2. Tap Unfiled and select a folder where you want to place the new note.
3. Enter the body of your note. You can tap the button to get bold text, and the button to start a bullet list.
4. Tap to switch to the drawing tab for making a freehand drawing. When drawing, tap the button to change stroke color, the button to change stroke thickness, or the button to activate the eraser.
5. Tap the button to save the note.
Method 2
1. Copy text from other application programs.
2. In the Note screen, tap Edit and select Paste .
Managing Notes
Editing Notes
1. Tap to open a note in the Note screen.
2. Make changes to the note.
3. Tap the button to save the note.
Deleting Notes
1. Open a note in the Note screen.
2. Tap Note and select Delete note .
Sending Notes to a compatible device
1. Open a note in the Note screen.
2. Tap Note and select Send as .
3. Select from the following and then tap the Done button:
• Email : Send the note as email attachment. This option is available only when an email account is created on the device.
• Message : Send the note to other compatible devices via an
SMS message. Enter the number of the recipient and then tap the Send button.
• MMS : Send the note to other compatible devices as an MMS attachment. The MMS message screen will follow for you to compose the message.
43 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Note: Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
• Bluetooth : Send the note to other compatible devices that support Bluetooth connectivity. Select the content to be sent from the Send dialog and tap Send . A box will appear showing the available devices. Tap to select a device and then tap Send .
• Infrared : Send the note to other compatible devices that support infrared connection. Select Infrared and tap Done , select the content to be sent from the Send dialog. Align the infrared port of your device with that of the other device, then the transfer will start automatically.
Managing Note Folders
1. In the Note screen, tap All and select Edit folders .
2. You can:
• Tap the Add button to create a new folder. You will then be asked to enter a name for the new folder. When finished, tap the Done button.
• Tap to select a folder on the list and then tap the Delete button to delete the selected folder.
• Tap the Rename button to edit the selected folder. Make changes and then tap the Done button.
Settings
Settings is a list of all settings sorted into groups. By adjusting these settings, you can control the behavior of your device. To go to the Settings screen, tap the icon in the Main screen or from the Application shortcut bar.
Note: The following groups of Device, Connetion,
Network, Security, and Manager are the default setting. You can change the grouping by selecting Settings in the Setting screen and set groups. Tap one item from the list and select one group from the Change group dialog. Tap Done to complete the new setting.
Device
(represented by the tab)
Backlight
You can the back light to be Automatic, On, or Off. Choose from the drop-down list and tap the OK button.
Auto power on/off
You can set the device to be powered on or off automatically.
International
Use these settings to set your current location as well as the currency, distance and number formats for use in other application programs.
Copyright ©2006 Nokia All right reserved 44
U s i n g t h e A p p l i c a t i o n P r o g r a m s
You can access these settings on two different tabs: Location and
Numbers . Select appropriate settings from the drop-down menus and then tap the Done button.
Preferences
You can set the shortcuts to your preferred features in the Main screen, and set the hot keys to specific functions. When finished setting, tap the Done button.
Screen saver
You can set the device to enable or disable the screen saver, and choose a screen saver you like.
Date & Time
Adjusting the date and time here sets these throughout your device.
Adjusting Time and Date
1. In the Date & Time tab, tap the Date box. A calendar will appear on the screen.
2. Tap to select current date from the calendar.
3. Tap the Time box and adjust current time. Tap the upper part of the boxes that enclose the hour and minute to increase the numbers, or the lower part of the boxes to decrease them.
4. Tap Daylight-saving if you want to use this feature. Select the daylight-saving zone(s) from the dialog that appears and then tap the Done button.
5. Tap the Done button.
Changing Date Format
You can customize the display of times and dates throughout your device on the Format tab.
Specifying Workdays
In the Workdays tab, you can specify the days of the week that you normally work. You can set alarms in the Time application program that only sound on a workday. Specifying the first day of your week customizes the display of both Week and Month views in the Calender application program.
Text input
There are two ways of entering text into your device:
• The smARTwriter handwriting recognition system : Your pen strokes on the screen are converted to individual letters, numbers, or other characters.
• The virtual keyboard : You can "type" text by tapping the
"keys."
The method that you select here is enabled automatically when you need to enter text into your device. If you load other text input software, select it and adjust its settings here.
Setting up smARTwriter
You can change the setting of the smARTwriter handwriting recognition system according to your writing habits. That is, you can “train” smARTwriter to improve the accuracy of recognition.
1. In the Text input setup box, select smARTwriter from the
Primary input method drop-down menu and then tap Setup .
45 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
2. Configure the following options:
• Line color : For selecting the color of pen strokes on the screen.
• Line thickness : For selecting the thickness of pen strokes on the screen.
• Timeout : For specifying the length of time before smARTwriter starts recognizing your handwriting.
• Predict next Chinese character : Check this check box, and the smARTwriter will help to predict the next character after a
Chinese character is written and recognized.
• Add space : Check this check box if you want smARTwriter to automatically add a space after each word.
• Personalize : Tap this button to open the Personalize screen that contains two tabs: the Personalize tab and the Browse tab.
Creating Personalized Writing Models
1. In the Personalize tab, select a character set and character from the Set and Character drop-down menus.
2. Write the character in your own way in the Write a box.
3. Tap Save .
In the Browse tab you can browse the preset handwriting models.
SystemSounds Setting
Allows you to change the settings of warning tone, button click sound, and screen tap sound.
User profiles
You can personalize how your device looks and sounds by configuring and applying user profiles. A user profile is a combination of user settings, including sound settings, display theme settings and appearance settings. You can also set up different profiles for use in different occasions.
To customize a user profile:
1. Tap to select a profile from the Profiles drop-down menu.
2. Specify the settings by selecting options in drop-down menus.
3. Apply the new theme and appearance settings.
Tip: You can tap the icon to listen to the sound.
Welcome Message
You can enable the welcome message by checking the check box.
You can also enter your own customized message in the text editor, change its color and font types. The next time you turn on your device, you will be greeted with the new welcome message.
Language
Selects the system language on your device. To do so, tap to select a language and then tap Done . The device is rebooted automatically for the change to take effect.
Depending on the region-specific configuration, you may also delete some user-installed languages to conserve memory space.
To do so, tap to select a language and then tap Delete .
Copyright ©2006 Nokia All right reserved 46
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Banner
Banner is the text that displays at the center of the Phone screen.
You can create your personal banner by checking the check box and entering your own text in the dialog. The new banner will take effect as soon as you tap the OK button.
Connection
(represented by the
Infrared
Bluetooth
tab)
USB cable
You can use this option to set up the cable connection mode between the device and PC.
• PC Connect : Select this item before connecting the device to your PC and using the PC Sync to perform synchronization and backup/restore.
• Modem : Select this item before connecting the device to your PC and use the device as a modem.
See " Infrared Connection " on page 95
.
See " Bluetooth Connection " on page 96
.
Network
(represented by the tab)
Important: Use only services that you trust and that offer adequate security and protection against harmful software.
GSM networks
Like any mobile phone, your device connects to a "network", which is the path that carries your phone calls, messages, web pages, and emails. The device is designed to use with the GSM and GPRS networks.
When you make a phone call, your device uses GSM. When you connect to the Internet, your device uses either GSM or GPRS depending on the type of Internet account that you select.
Dial-up and high-speed dial-up Internet accounts connect to the
GSM network. GPRS Internet accounts connect to the GPRS network.
When you send or receive SMS messages, your device can use either GPRS or GSM, and, if there is no coverage with one network, it can automatically switch to the other.
The GSM networks setting enables you to select an appropriate network manually if you want to change the network you are connected to, and set up a preferred list of networks. The network and band selections must be supported by your network service provider.
47 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Changing Network Search Mode
Tap the Search tab and select Automatic selection or Manual. selection . If Manual selection is selected, the device will list all of the networks found for you to choose from.
Selecting Another Network
Tap the Search tab and select Manual selection . The device will scan all available networks and show them in a dialog box for you to choose from.
Note: Not all of the networks listed may be available to you. Please refer to your network service provider for further details.
Creating a Preferred Network List
1. Tap the Preferred list tab and then the Add network button.
2. Tap to select a network from the list.
3. Select a position (priority) of the network in the preferred network list.
4. Tap Done .
Note: Please consult your network service provider for availability and further details about the preferred network list function.
Internet accounts
With access to the Internet you can use email and browse the web pages. You can create 2 types of Internet accounts depending on your internet service provider and the type of network you have access to:
• Dial-up account : This is indicated by the icon. With a dial-up account, you are charged for the length of time that you're connected to the Internet.
• GPRS account : This is indicated by the icon. With a GPRS account, you are charged for the amount of information you view, download, or send when you're connected to the
Internet.
Creating New Internet Accounts
You can manually set up the Internet account, or ask your service provider to send you a message that contains the required setup information and creates the account automatically on your device.
To manually set up an Internet account:
1. Tap New on the Accounts tab.
2. Enter the name of the connection in the Account name field.
3. Select a connection type from the Connection type drop-down menu.
4. Tap the Advanced button, then set APN address and the necessary settings according to the data from your network service provider.
5. Tap Done .
Copyright ©2006 Nokia All right reserved 48
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Editing Internet Accounts
1. In the Accounts tab, tap to select an account.
2. Tap Edit .
3. Edit the settings of the selected account.
4. Tap Done .
Deleting Internet Accounts
1. In the Accounts tab, tap to select an account.
2. Tap Delete , and then Yes .
Wap accounts
WAP account settings are essential for using Internet connections and MMS service via a WAP gateway. You can manually set up the WAP account, or ask your service provider to send you a message that contains the required setup information and creates the account automatically on your device.
To manually set up a WAP account:
1. Tap New on the Basic tab.
2. Enter the name of the connection in the Account name field.
3. Select an Internet connection from the Internet account drop-down menu. Before you tap the Use Proxy check box, have the following data ready from your network service provider: Address, Port, Username, and Password.
4. Set up the settings according to the data from your network service provider.
5. Tap the Preferred tab and tap to check the Use WAP account check box.
6. Select a preferred WAP account for Internet connection and
MMS delivery from the Preferred drop-down menu.
7. Tap Done .
Editing WAP Accounts
1. In the Basic tab, tap to select an account.
2. Tap Edit .
3. Edit the settings of the selected account.
4. Tap Done .
Deleting Internet Accounts
1. In the Basic tab, tap to select an account.
2. Tap Delete , then Yes .
Offline
The Offline mode is used where mobile phones and Bluetooth wireless functions are not allowed. To immediately activate the
Offline mode, tap the Offline now button.
You can also check or uncheck the check box in the dialog to determine if you want the device to prompt you the option of the
Offline when your device is switched on.
49
Note: The default information here comes with the device. Ask your SIM card provider for the proper information.
Copyright ©2006 Nokia All right reserved
Warning: In the Offline mode you cannot make or receive any calls (except making emergency calls), or use other features that require network coverage. To make calls, you must first activate the phone function by installing a valid SIM card. If the device has been locked, enter the lock code.
Messaging accounts
Messaging accounts contain various settings for using email,
SMS, MMS and Cell Broadcast services. These accounts must be properly set up before the services can be used.
Cell Broadcast messages are the general messages that your network service provider broadcasts to all subscribers in a particular area. These messages are broadcast in numbered channels. For example, channel 30 might be for local weather,
60 for traffic reports, 80 for information of local hospitals, taxis, or pharmacies.
Note: Please contact your operator for a list of available channels and the information they provide.
Manually Set up Messaging Accounts
1. Have the account data ready from your network service provider.
2. Set up the settings on each tab according to the data.
3. Tap Done .
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Email account data
1. Tap New to create an email account.
2. Tap the Basic tab.
• Account name : Enter a descriptive name for the connection
• Your name : Enter your name.
• E-mail address : Enter the e-mail address given to you by your service provider.
• Connection type : Select the email protocol your remote mailbox service provider recommends.
• Internet accounts : If you have created several email accounts, select one from them as your default email account.
3. Tap the Inbox tab.
• User name : Enter your user name given to you by your service provider.
• Password : Enter your password which will be asked when you try to connect to your mailbox.
• Incoming server address : Enter the IP address or host name or the computer that receives your email.
• Download : Choose the format of email downloaded to your device. The options are Just headers , E-mails smaller than , and No restrictions .
4. Tap the Outbox tab.
• Outgoing server address : Enter the IP address or host name or the computer that sends your email
• Use SMTP Authentication : Check so that the SMTP (Simple
Mail Transfer Protocol) server requires authentication.
Copyright ©2006 Nokia All right reserved 50
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• Use Inbox login details : Use the Inbox login user name and password for connection.
• User name : Enter the SMTP user name.
• Password : Enter the SMTP password.
5. Tap Advanced tab.
• Secure connection : Check to use the encryption to make the connection secure.
• Outgoing mail port : Set to the port on the server that outgoing mail is to be sent through. This is usually a default setting.
• Use MIME encoding : Check to use the regular Internet email format, MIME. The MIME format allows, for example, including images as attachments to the message.
• Incoming mail port : Set to the port on the server that incoming mail is to be retrieved from. This is usually a default setting.
• Secure password authentication : Check to improve password security.
SMS account data
• SMS Service centre address : Enter message center number given to you by your service provider.
• Character set : Decides the way the characters are displayed.
The options are 7bit and UCS2 .
• Message stored for : The time the message center tries to send the message. The options are 1 hour , 6 hours , 1 day ,
7 days , and Maximum . Maximum is the maximum amount of time allowed by the network.
• Connection type: Select the protocol your service provider recommends. The options are GPRS only and GSM only .
• Delivery report : Check to view the status of the sent SMS message.
• Use reply path : Check this item and the service provider will try to send the message you reply by the same service path
(SMS Service centre).
MMS account data
Have the following data ready before you want to create a new
MMS account.
• Account Name : Enter a name for your email account.
• MMS Gateway : The gateway for sending and receiving your messages given by your service provider.
• Messages valid for : The time the message center tries to send the message. The options are 1 hour , 6 hours , 1 day , 7 days , and Maximum . Maximum is the maximum amount of time allowed by the network.
• Transport : The Internet access to deliver the MMS message, which is usually provided by the service provider. The options are HTTP and WAP .
• Internet accounts (only available when HTTP is selected in
Transport ): Select an Internet account for use with MMS transmission.
• WAP accounts (only available when WAP is selected in
Transport): Select a WAP account for use with MMS transmission.
51 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Cell Broadcasting Message setting
1. Tap the Enable cell broadcast check box on the CBM tab to enable the reception of Cell Broadcasting messages.
2. Tap New and select a channel from the dialog box that appears, and then tap OK .
3. To delete a channel, tap a channel and tap Delete , Yes .
Security
(represented by the tab)
IP Security manager
The IP security manager displays stored policies and only one policy can be activated at a time. There are two types of passwords needed:
• IP security password : Is to be set when installing the very first policy, i.e. this password is only set once, but it is possible to change it later at any time by tapping Password button.
• Import password : Is needed when installing a policy and the supplier of the policy gives this.
WIM PIN settings
WIM is used for performing security functions, especially to store and process information needed for user identification and authentication. I.e. it's a tamper-resistant store for private keys, certificates and other objects that may require a PIN for access or modification.
You can select a PIN from the PIN choice list. The WIM objects list changes content dynamically, displaying only the keys that are protected by the selected PIN and also have an associated certificate. Other keys that are protected by the selected PIN but don't have an associated certificate are not shown in the WIM object list.
You can change status of a PIN:
• Enable PIN: A PIN code that is enabled is requested for authorization of an operation. To proceed with the operation you must enter the PIN code.
• Disable PIN : A PIN code that is disabled is not requested to authoress an operation to proceed.
You can change the PIN code:
• Select the PIN you want to change and tap Change PIN code .
• If a PIN code has been blocked, you must unblock it before it can be used again. Select the PIN you want to change and tap Change PIN code .
Tip: For information on how to unblock the PIN, please consult your network service provider.
Password
Your Nokia 6708 features remote lock and screeb saver lock functions for security protection. You are allowed to answer calls and make emergency calls when the device is locked by either locks.
Copyright ©2006 Nokia All right reserved 52
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Remote lock
When your Nokia 6708 is not in hand, you can send a message which contains a key message set previously to the device, the device will be locked automatically.
1. Check Remote lock in Password screen.
2. You are required to set a key message in the Remote locking message dialog that pops up. Tap Done to confirm.
3. The remote lock setting will take effect after restarting the device as instructed.
Screen saver lock
This function requires you to enter the password according to the setting you have done.
1. Select one from the three screen saver lock status from the
Screen lock drop-down list.
• Off : Disables screen saver lock.
• At power-on : Requires the password when you power on the device.
• Always : You will be asked to enter the password when you power on the device or whenever the device is awakened from screen saver mode.
2. Tap Set password to set the password. Then tap Done to complete the password setup.
3. Tap the button and then select Screen saver on the
tab.
4. Set the image or format and time for screen saver. Then tap
OK to confirm.
•
Note: When the screen saver lock is activated, if there is a data transfer request, you will be asked to enter the password to proceed the transmission. However, there will be no notification on the device when downloading data from the device to a PC using PC Suite for the Nokia 6708.
All keys except and either of remote lock and screen saver lock is activated.
Manager
(represented by the
Storage Manager
tab)
will be disabled when
With Storage manager you can do the following:
Managing files
1. In the Storage manager screen, tap File .
2. Select from the Location and Type drop-down menus to locate the files in the File box below.
3. Tap the check box beside each file to select the file. You can select multiple files.
4. Tap Copy to copy the selected file to another location, or
Delete to delete the file from memory.
53 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Uninstalling programs
1. In the Storage manager screen, tap Uninstall .
2. Tap to select a program you want to remove from the device and then tap Uninstall .
Power
Allows you to change the auto power save setting.
By default, your device will display the screen saver if there is no key or touch screen operation for 2 minutes. If you set Auto power save to be 3 minutes, 1 minute after the screensaver is displayed, the device will enter auto power save mode automatically.
In auto power save mode, the device can be waken automatically by an incoming call. You can also wake the device up by pressing the power key.
Master reset
Use Master reset only if you want to reset all the settings on your device to the way they were after initial setup. If you want to keep installed application programs, uncheck the Delete user installed applications check box.
Format disk
When you format a disk, you delete all the information on it, including any application programs that you've installed.
Any memory card that you install on your device are also displayed.
Renaming a Disk
You can rename a disk to give it a more meaningful name.
1. Tap to select a disk you want to rename from the Disk drop-down menu and then tap Rename .
2. Enter the new name and then tap Done .
Formatting a Disk
You can use this function to format a newly purchased memory card for use with the device, or delete all data on the card at once. To format a disk:
1. Tap to select a disk you want to format from the Disk drop-down menu and then tap Format .
2. Tap Yes .
3. The formatting progress starts. Wait until the formatting is carried out completely.
Warning: All user data, as well as pre-installed media files and application program data files will be deleted and all settings will be set to the state they were, when the device was originally delivered.
Important: When formatting a memory card, do not remove it during the process, otherwise the card or data will be damaged.
Copyright ©2006 Nokia All right reserved 54
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Brightness & Alignment
Allows you to change the brightness and calibrate the touch screen.
Setting Brightness
1. To adjust brightness of the display, drag the slider to the left or right.
2. Tap Done .
Adjusting Alignment
1. Tap Alignment button in Brightness & Alignment.
2. Follow the on-screen instructions.
3. Tap Yes to accept the new settings.
Certificate Manager
Digital certificates ensure that the web or WAP pages you visit, or any software you install, really are created by the person you expect.
Certificates may be presented on the pages that you view or the software that you download. Your device compares these certificates with a set of certificates that's stored in Certificate manager to ensure the authenticity of the page or software. If the certificates don't match, your device informs you, and allows you to:
• Prevent the page being loaded or the software being installed, or
• Continue at your own risk
Important: Even if the use of certificates makes the risks involved in remote connections and software installation considerably smaller, they must be used correctly in order to benefit from increased security. The existence of a certificate does not offer any protection by itself; the certificate manager must contain correct, authentic, or trusted certificates for increased security to be available. If
Expired certificate or Certificate not valid yet is shown even if the certificate should be valid, check that the current date and time in your device are correct.
• Before changing any certificate settings, you must make sure that you really trust the owner of the certificate and that the certificate really belongs to the listed owner.
Security Information
Security information is displayed when Certificate manager can't be sure of the origin of the page or software. For example, security information will be displayed if:
• The certificate on a page has expired
• The identity of a software manufacturer can't be verified
Security information is also displayed when a certificate on your device:
• Has expired
• Has been revoked by the independent organization that issued it
55 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Adding and Removing Certificates
Your device handles certificates automatically so, most of the time, you can browse the Internet without using Certificate manager. If you do need to add or remove a certificate, you will usually be informed by your network operator or system administrator. You should remove a certificate from Certificate manager if you are informed, or suspect, that the certificate:
• Does not belong to the person who supplied it
• Was issued incorrectly by the independent organization that created it
Type of Certificate
The type can be either User or Certificate Authority.
• User certificate contains your identity. This type of certificate is used when the server asks for client authentication. The client application program requests you to identify yourself by choosing a user certificate.
• Certificate Authority certificates contain server details. This type of certificate is handled by your device when the server only requires server authentication. This means that your identity remains anonymous.
VoiceCommander Setting
Allows you to configure VoiceCommander settings.
PIN code request
Using this feature, you can prevent unauthorized persons from using your device to make or receive phone calls. You can lock / unlock your SIM card and change the SIM card PIN with this setting option.
Note: When the device is locked, calls still may be possible to the official emergency number programmed into your device.
• You can select to have the PIN code request On or Off in the
PIN code request dialog. If you select On , you will be prompted to enter the PIN before entering the online mode of the device.
• To change PIN code, tap the Change Codes tab and then tap the PIN code or PIN2 code button. The PIN2 code is required to access some functions which must be supported by your
SIM card.
• Tap Done to exit.
Note: Note that the PIN code request cannot be changed if the device is switched off or if there is no valid
SIM card inserted. Note also that some SIM cards do not allow you to turn off the PIN code request.
Call settings
Note: If the SIM card is not installed, certain setting items will not appear on the screen.
Copyright ©2006 Nokia All right reserved 56
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Accepted Callers
Accepted callers are those whose calls can reach you. Others will be automatically rejected.
1. Select from the following options in the Accept calls from drop-down menu:
• All callers : Everyone can call you.
• All except listed callers : Everyone can call you except the ones in the rejected caller list. Tap the Add new button to add callers to the list.
• None : No one can call you.
2. Tap Done to exit.
Add to Contacts
If this function is activated, after a call has ended, if the phone number is not already stored in the Contacts application program, you will be asked if you want to add it.
1. Tap the Add party to contacts drop-down menu and select
On . To deactivate this function, tap Off .
2. Tap Done .
Auto redial
If an outgoing call is failed to connect to the network, you can choose to redial the number automatically or to be prompted to make the call again.
1. Tap Off , Auto redial , or Prompt redial in the drop-down list to set Auto redial.
2. Tap Done to exit.
Call Costs
The call costs function allows you to set a limit for total call costs.
If call costs exceed this limit, the device will no longer be able to dial pay calls.
•
Note: The actual invoice for calls and services from your service provider may vary, depending upon network features, rounding off for billing, taxes, and so forth.
When this device is used as a GPRS modem, the GPRS log will be updated automatically.
To set up call costs:
1. Enter the price unit for calculating call cost in the Price per unit field. The value must be between 0.01 and 9999999.
2. Enter the 3-character name of currency in the
3. Select a Credit status : Unlimited
4. Enter a credit limit in the
or Limited
Remaining credit must be between 0.01 and 9999999.
.
Currency field.
field. The value
Note: The estimated value shown in the Remaining credit field is for your reference only. The real cost of calling may vary depending on the service provider the call is made through.
5. Tap Done .
6. Enter your PIN 2 code and then tap Done .
57 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s in controlling restricted services. For example, call time limits and restricted phone numbers.
• If the PIN2 code is incorrectly entered three times consecutively, it will be locked. To unlock it, you will need to enter the PUK2 code, which you obtain from your network operator.
• When no more charging units or currency units are left, calls may only be possible to the official emergency number programmed into the device.
If the Credit status is set to Limited and there is only 30 seconds of credit left, the message "Low credit" will appear on the screen.
If “Credit expired” appears, you can not make any chargeable calls.
Note: The PIN2 is the second PIN code. Its main use is
Note: For the availability and more information about the Call meter function, please consult your network service provider.
Call Waiting
If there is an incoming call when you are in the middle of another call and the call waiting function is enabled, the screen will display the number (if available) of the incoming call and call waiting message to alert you.
1. After Call waiting is selected, the device will inquire the status of your call waiting setting. This will take a few seconds.
2. Select from the following options:
• On : Enable call waiting.
• Off : Disable call waiting.
3. Tap Done to exit.
Calling Cards
You can use this option to set up the device for use with your calling cards.
1. Tap the New button to add a new calling card.
2. Enter necessary information and then tap the Done button.
3. Tap Calling card mode to select from Off , Prompt before call or Always use calling card . If you have multiple calling cards, select one from the Calling cards box first.
4. Tap the Done button.
To delete a calling card, tap to select one in the Calling cards box and then tap the Delete button.
To edit a calling card, tap to select one in the Calling cards box and then tap the Edit button.
Connection alert
When the connection alert function is activated, you will be informed when a successful phone connection is made.
1. Select from the Select connection alert drop-down list. The available options are Off , Vibrate , Ring , and Flash .
2. Tap Done .
Copyright ©2006 Nokia All right reserved 58
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Divert calls
1. After Divert call is selected, the device will inquire the status of your Divert call setting. This will take a few seconds.
2. According to the call type you want to setup, tap the Voice or Data & Fax tab.
3. Tap to select a divert condition (for example, When busy divert to: ) and then select from the following options:
• Voice Mail (available only when a voice mail-box is created): the calls will be diverted to your voice mail-box.
• Lookup in contacts : Pick a number from your contacts.
• Enter number : Enter the number directly.
• Off : Cancel diverting calls.
4. Tap the Done button to exit.
Note: For the availability and more information about the divert call function, please consult your network service provider.
Handsfree
With this function you can setup the way your device works with the handsfree kit. Tap to select an option:
Options for Answering Mode
• Normal : Answer the call as normal.
• Any key : The incoming call will be answered automatically after any key is pressed.
• After 5 seconds : The incoming call will be answered automatically after 5 seconds.
Tip! You can press and hold the button on the controller of the handsfree to answer and end calls.
Options for Bluetooth: Preferred sound device
• Phone : Use the keys on the device to manage calls.
• Headset : Use the keys on the device or the headset to manage calls. If a Bluetooth headset is used, please choose
Headset as the preferred device.
• Handsfree : Use the keys on the device or the handsfree
(Bluetooth car kit) to manage calls. If a Bluetooth car kit is used, please choose Handsfree as the preferred device.
Incoming Call Picture
If the incoming caller has a picture stored in the Contact application program, the picture will appear on the screen when his/her call is received.
Tap to check or uncheck the Show pop-up picture for incoming calls check box. If checked, the picture will be shown.
Restrict Calls
You can request your network service provider to block the dialing or receiving of certain calls. The call barring services require the support of your network. To activate or cancel any of the options, you must enter the network password provided by the network service provider.
59 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Camera
Note: When calls are restricted, calls still may be possible to the official emergency number programmed into your device.
1. After Restrict calls is selected, the device will inquire the status of your current setting. This will take a few seconds.
2. According to the call type you want to setup, tap the
Incoming or Outgoing tab.
3. Tap to select a restriction condition (for example, All incoming: or Incoming when roaming: ) and then select from the following options:
• On : Enable call restriction.
• Off : Disable call restriction.
4. Tap the Done button. You will be asked to enter the restrict code. Enter the code and tap the Done button.
5. To change the restrict code, tap the Change password button.
Note: Call restricting and call diverting cannot be active at the same time.
Voice Mail
You must enter the voice mail-box number here before you can access your voice mail. The voice mail-box number is available from your network service provider.
Enter your voice mail-box number and then tap the Done button.
Note: The Nokia 6708 device supports an image capture resolution of 1280 x 1024 pixels. The image resolution in these materials may appear different.
With the built-in camera and the Camera application program, you can take still pictures, capture video clips for viewing on the device or sharing them with your friends or family by sending them via MMS messages or transferring them to PC.
Taking Still Pictures
1. Press and hold the Camera key for about 2 seconds. The
Camera application program will open automatically.
2. Preview the image using the viewfinder. You can also tap the
+ (or press the
(or press the
key) or button on the screen
key) to zoom in or out on the object.
3. (Optional) Tap the settings.
button to set your desired Camera
4. (Optional) Tap the button (or press the key) to increase, or tap the button (or press the key) to decrease exposure value according to ambient lighting condition.
5. Press the Camera key and the still image will be captured and saved.
Copyright ©2006 Nokia All right reserved 60
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Note: When the image is being saved, the buttons on the screen will become unavailable temporarily.
• When the Camera key is pressed while taking a picture, a shutter sound will be generated, even if you have put the device in Silent mode.
6. The picture you just took will appear in the viewfinder.
You can:
• Tap the button to delete the picture.
• Tap the button to send the picture. Select from the following and then tap the Done button:
• Email : Send the picture as email attachment. This option is available only when an email account is created on the device.
• MMS : Send the picture to other compatible devices as an
MMS attachment. The MMS message screen will follow for you to compose the message.
• Infrared : Send the picture to other compatible devices that
• Tap the button to rename the picture.
• Tap the button to view the picture in the PhotoBase application program.
• support infrared connection. Align the infrared port of your device with that of the other device, then the transfer will start automatically.
Tap the button to exit.
Capturing Video
1. Press the Camera key. The Camera application program will open automatically.
2. Press the button to go to video mode.
3. Preview the image using the viewfinder. You can also tap the
+ (or press the key) or button on the screen (or press the key) to zoom in or out on the object.
Note: Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
• Bluetooth : Send the picture to other compatible devices that support Bluetooth connectivity. A box will appear showing found paired devices. Tap to select a device and then tap the
Send button.
Tip! It is recommended that you tap the + button once to zoom in on the image one level to get better video quality.
• Try to keep the distance between the sound source and the microphone of the device within about 10-15 cm distance when shooting video in order to obtain better sound recording quality.
4. (Optional) Tap the settings.
button to set your desired Camera
61 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
5. (Optional) Tap the button (or press the key) to increase, or tap the button (or press the key) to decrease exposure value according to ambient lighting condition.
6. Tap the “Record” start capturing video.
button or press the Camera key to
7. When capturing is in progress, you can perform the following operations:
• Tap the button to pause capturing. Tap the to resume capturing.
• Tap the image.
+ button (or press the
button
key) to zoom in on the
• Tap the - button (or press the the image.
key) to zoom out on
• Tap the button or press the Camera key to stop capturing. The video clip will be saved.
Note: When the video clip is being saved, the buttons on the screen will become unavailable temporarily.
• Tap the button to exit. The video clip is saved automatically.
8. Alternatively, you can perform the following operations after a video clip is captured:
• Tap the button to delete the video clip.
• Tap the button to send the video clip. Select from the following and then tap the Done button:
• Email : Send the video clip as email attachment. This option is available only when an email account is created on the device.
• MMS : Send the video clip to other compatible devices as an
MMS attachment. The MMS message screen will follow for you to compose the message.
Note: Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
• Bluetooth : Send the video clip to other compatible devices that support Bluetooth connectivity. A box will appear showing found paired devices. Tap to select a device and then tap the Send button.
• Infrared : Send the video clip to other compatible devices that support infrared connection. Align the infrared port of your device with that of the other device, then the transfer will start automatically.
• Tap the button to rename the video clip.
• Tap the button to play the video clip.
• Tap the button to exit. The video clip is saved automatically.
Copyright ©2006 Nokia All right reserved 62
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Camera Options When Taking Pictures and
Capturing Video
Press the key to enter the option menu and setup images or video settings.
Image Settings
When taking pictures, you can choose to set different camera settings for better effect. Tap the button to set your desired camera settings and tap an item in the pop-up options menu to configure its corresponding settings.
• Image size : Tap to select a suitable image size. Larger image size and higher image quality will result in larger picture files.
Note: If Burst Mode is enabled, the 1280 x 1024 pixels
(SXGA) image size will become unavailable.
• Night Mode : Tap to set the night mode on or off.
• Effect : Tap to select different image effect such as Normal ,
Mono , Sepia , Blush and Negative .
• Burst-Mode : Tap to set the Burst-mode on or off. If you set the burst-mode on, there are three burst-mode for you to choose: 6 Multishot , 9 Multishot and 16 Multishot .
Note: When the camera is set to be Burst-mode, to take a multishot, press and hold the Camera key.
• If the image size is set to 1280 x 1024 pixels (SXGA), the
Burst-Mode option will be disabled automatically.
• Self-Timer : When taking pictures, you can enable the
10-second self-timer by setting Self timer on.
• Anti-Shaking : Your device supports anti-shaking function when taking pictures. Tap this item to set this function on or off.
Note: If the Anti-Shaking function is set to On , it will take more time than normal for the device to capture images.
• Settings : Tap to adjust different settings, such as Quality ,
White Balance , Exposure Area , Exposure Bracketing , and
Anti-Flicker .
Note: If Exposure Bracketing is set to On , the device will take 3 pictures in a row when you press the Camera key, and then display the pictures taken for you to select. Tap to select a picture and then tap the button.
• When the Exposure Bracketing function is set to On , it will take more time than normal for the device to capture images.
• It is recommended that you set the Anti-Flicker function to
On when taking pictures with black lines under fluorescent lights.
• The Burst-Mode, Anti-Shaking and Anti-Flickering functions cannot be enabled simultaneously.
63 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• Memory Storage : Tap to select a default storage location
(device memory or SD memory), and filenames.
Note: The available number of shots displayed on the screen is estimated by the picture counter and may not decrease progressively.
• Help : Tap to view the camera help file.
• About : Tap to see more information about the camera.
• Help : Tap to view the camera help file.
• About : Tap to see more information about the camera.
Note: It is recommended that you save the images/ video to the memory card to prevent device memory from running low.
Video Settings
When capturing video, you can choose to set different camera settings for better effect. Tap the button to set your desired camera settings and tap an item in the pop-up options menu configure its corresponding settings.
• Night Mode : Tap to set the night mode on or off.
• Effect : Tap to select different image effect such as Normal,
Mono, Sepia, Blush and Negative.
• Settings : Tap to adjust settings of Audio Settings , Quality ,
White Balance , Exposure Area , Anti-Flicker , and Format .
• Memory Storage : Tap to select a default storage location
(device memory or SD memory), filename and size mode (for displaying under the viewfinder when capturing video) for video clips.
Note: The available number of shots displayed on the screen is estimated by the picture counter and may not decrease progressively.
Music Player
With the Music player application program, you can play music tracks/files in the following formats:
• AMR files (.amr)
• MP3 files (.mp3)
• WAV files (.wav)
• MIDI files (.mid)
Playing Music
1. Tap the Music player application program icon in the Main screen.
2. Tap All and select the location (folder) that contains the music files.
3. The song list will appear in the screen.
Tip! To sort songs on the song list, tap Playlist and then select Maximise . Tap Playlist , then you can sort the songs by name or by size.
Copyright ©2006 Nokia All right reserved 64
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Note: It is recommended that you save music files on the memory card to prevent device memory from running low.
• When copying music files to the device memory/memory card, put them in the folder named "audio" in the "Media files" folder. You can also create new sub-folders in the
"audio" folder to store music files.
Tap to check the songs you want to play in the song list and then tap the button (or press the key) to start playing them.
Warning: Listen to music at a moderate level.
Continuous exposure to high volume may damage your hearing. Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely loud.
• Tap the next song.
button (or press the key) to go to the
• Tap the button (or press the previous song.
• Press the play list.
key) to go to the
key to highlight the previous song in the
• Press the list.
key to highlight the next song in the play
• Tap the button to switch between different modes of random playback. The other mode is (random on).
• Tap the button to switch to different modes of repeat playback. Other modes available are (repeat this) and
(repeat all).
Operations When Playing Music
When playing music, you can:
• Tap the button to stop playing music.
• Tap the button (or press the key) to pause playing current song. Tap the button again to resume normal playback.
Managing Songs
Renaming Songs
1. Tap the icon to open song list, and then tap a song to select it.
2. Tap the button.
3. Enter the new name for the song and then tap OK .
65 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Sending Songs
1. Tap the button to open song list, and then tap a song to select it. You can select multiple songs.
2. Tap the button.
3. Select from the following and then tap the Done button:
• Email : Send the song as email attachments. This option is available only when an email account is created on the device.
• MMS : Send the song(s) to other compatible devices as MMS attachments. The MMS message screen will follow for you to compose the message.
2. Tap the button.
3. From the Folder drop-down list, tap to select a folder where the song will be copied to.
4. Tap Copy .
Note: Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, transferred or forwarded.
Note: Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
• Bluetooth : Send the song(s) to other compatible devices that support Bluetooth connectivity. A box will appear showing found paired devices. Tap to select a device and then tap the
Send button.
• Infrared : Send the song(s) to other compatible devices that support infrared connection. Align the infrared port of your device with that of the other device, then the transfer will start automatically.
Copying Songs
1. Tap the button to open song list, and then tap a song to select it.
Moving Songs
1. Tap the button to open song list, and then tap a song to select it.
2. Tap the button.
3. From the Folder drop-down list, select a folder where the song will be moved to.
4. Tap OK .
Viewing Song Information
1. Tap the button to open song list, and then tap a song to select it.
2. Tap the button.
Deleting Songs
1. Tap the button to open song list, and then tap a song to select it.
Copyright ©2006 Nokia All right reserved 66
U s i n g t h e A p p l i c a t i o n P r o g r a m s
2. Tap the
3. Tap Yes .
button.
Managing Music Folders
1. In the song list screen, tap All and select Edit Folders .
2. You can:
• Tap the Add button to create a new folder. Enter the name for the new folder and specify the storage location (device storage or memory card) and then tap the Done button.
• Tap to select a folder on the list and then tap the Delete button to delete the selected folder.
• Tap the Edit button to rename selected folder. Enter a new name and specify the storage location (device storage or memory card) and then tap the Done button.
Note: It is recommended that when you finish using the
Music player application program, tap Music and select Exit to close it in order to save memory space.
Viewing Video Clips Using Video Player
1. Tap the Video player application program icon in the Main screen.
2. Tap All and select a folder. You can select to view the video clips in the device memory, the memory card or both.
3. Tap Maximise from Playlist to display the list and find out the filename, length, and file size.
4. Tap to select a video clip you want to play and then tap the
button (or press the start playing the video clip.
key). Video player will
Note: When copying video files to the device memory/ memory card, put them in the folder named "video" in the
"Media files" folder. You can also create new sub-folders in the "video" folder to store video files.
Options When Viewing Video Clips
When viewing video clips, you can:
Video Player
With Video player, you can view video clips captured by the camera or transferred from other compatible devices. The Video player application program accepts video clips in the MPEG 4,
3GP format.
• Tap the video image.
button (or press the
• Tap the button (or press the next video clip.
• Tap the button (or press the previous video clip.
key) to pause the
key) to play the
key) to play the
67 Copyright ©2006 Nokia All right reserved
• Tap the button to stop playing the video.
• Tap the button to switch between different modes of random playback. The other mode is (random on).
• Tap the button to switch to different modes of repeat playback. Other modes available are (repeat on) and
(repeat all).
• Tap the button to switch to the options of the slow-motion playback.
Note: The sound is muted during the slow-motion playback.
Managing Video Folders
1. In the Video player screen, tap All and select Edit folders .
2. You can:
• Tap the Add button to create a new folder. Enter the name for the new folder and then tap the Done button.
• Tap to select a folder on the list and then tap the Delete button to delete the selected folder.
• Tap the Edit button to rename selected folder. Enter a new name and then tap the Done button.
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Managing Video Clips
Renaming Video Clips
1. Tap the button to open video list.
2. Tap to select the video clip you want to rename.
3. Tap the button.
4. Enter the new name in the dialog that appears and then tap
OK .
Sending Video Clips
1. Tap the button to open video list.
2. Tap to select the video clip you want to send.
3. Tap the button.
4. Select from the following and then tap the Done button:
• Email : Send the video clip as email attachment. This option is available only when an email account is created on the device.
• MMS : Send the video clip to other compatible devices as an
MMS attachment. The MMS message screen will follow for you to compose the message.
Note: Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
Copyright ©2006 Nokia All right reserved 68
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• Bluetooth : Send the video clip to other compatible devices that support Bluetooth connectivity. A box will appear showing found paired devices. Tap to select a device and then tap the Send button.
• Infrared : Send the video clip to other compatible devices that support infrared connection. Align the infrared port of your device with that of the other device, then the transfer will start automatically.
Viewing Video Clip Information
1. Tap the button to open video list.
2. Tap to select a video clip.
3. Tap the button. The information about the video clip will appear on the screen.
Deleting Video Clips
1. Tap the button to open video list.
2. Tap to select the video clip you want to delete.
3. Tap the button, and then tap Yes .
PhotoBase
PhotoBase is a powerful image management application program that allows you to view, edit, organize pictures and add special effects to pictures taken by your camera or downloaded/ transferred from other locations.
Viewing Images
1. Tap the PhotoBase application program icon in the Main screen.
2. In the PhotoBase screen, tap All and select a folder.
Note: When copying image files to the device memory/ memory card, put them in the folder named "image" in the
"Media files" folder. You can also create new sub-folders in the "image" folder to store image files.
Note: It is recommended that when you finish using the
Video player application program, tap Video and select Exit to close it in order to save memory space.
69 Copyright ©2006 Nokia All right reserved
3. The images in the selected folder will appear.
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Image viewing options
• You can tap the button to view images as thumbnails, or the button to view images as a list.
• Tap the button to view images as slideshows.
• Tap Thumbnails or List and select Sort by name , Sort by date or Sort by size to sort images according to different conditions.
4. Tap a thumbnail or an item in the list to open the image. The image will appear in the image viewing screen.
When viewing an image, you can:
• Tap the button (or press the previous image.
key) to go to the
• Tap the button (or press the next image.
key) to go to the
• Tap the button to open the image editing screen for editing current image.
• Tap the button to open the image workshop screen for applying special effects to current image.
Copyright ©2006 Nokia All right reserved 70
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• Tap the button to send the current image.
• Tap the button to delete the current image.
• Tap the button to enlarge or reduce the viewing size.
• Tap the button to return to the thumbnail or list view.
Organizing Images
Managing Image Folders
1. In the image thumbnail or list view, tap All and select Edit folders .
2. You can:
• Tap the Add button to create a new folder. You will then be asked to enter a name for the new folder. When finished, tap the Done button.
• Tap to select a folder on the list and then tap the Delete button to delete the selected folder.
• Tap the Edit button to edit selected folder. Make changes and then tap the Done button.
Copying Images to a Different Folder
1. In the image thumbnail or list view, select images you want to copy by checking the check boxes on image thumbnails or next to image items.
2. Tap PhotoBase and select Copy ticked picture(s) to .
3. Select a folder from the drop-down list and then tap the
Copy button.
Deleting Images
Method 1
1. In the image thumbnail or list view, select images you want to delete by checking the check boxes on image thumbnails or next to image items.
2. Tap PhotoBase and select Delete ticked picture(s) .
3. Tap the Yes button.
Method 2
1. Open an image from the thumbnail or list view.
2. Tap the button on the image viewing screen.
3. Tap the Yes button.
Sending Images
1. Open an image from the thumbnail or list view.
2. Tap the button on the image viewing screen.
3. Select from the following and then tap the Done button:
• Email : Send the image as email attachment. This option is available only when an email account is created on the device.
71 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• MMS : Send the image to other compatible devices as an
MMS attachment. The MMS message screen will follow for you to compose the message.
Note: Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
• Bluetooth : Send the image to other compatible devices that support Bluetooth connectivity. A box will appear showing found paired devices. Tap to select a device and then tap the
Send button.
• Infrared : Send the image to other compatible devices that support infrared connection. Align the infrared port of your device with that of the other device, then the transfer will start automatically.
Editing Images
Rotating Images
1. Open an image from the thumbnail or list view.
2. Tap the button to open the image editing screen.
3. Tap the button to rotate the image 90 degrees clockwise, or the button to rotate the image 90 degrees counter-clockwise.
4. Tap the button and then tap Yes to save your changes.
Flipping Images
1. Open an image from the thumbnail or list view.
2. Tap the button to open the image editing screen.
3. Tap the button to flip the image vertically, or the button to flip the image horizontally.
4. Tap the button and then tap Yes to save your changes.
Cropping Images
1. Open an image from the thumbnail or list view.
2. Tap the button to open the image editing screen.
3. Tap the button and then tap Continue in the box that appears.
4. Use the stylus to draw a cropping frame that encompasses the area you want to crop from the original image.
5. If necessary, tap the crossed arrow at the center of the frame to adjust its position on the original image. You can also tap the small red dots at each corner of the frame to adjust its size.
6. Tap the button. The image will be cropped.
7. Tap the button and then tap Yes to save your changes.
Copyright ©2006 Nokia All right reserved 72
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Adding Special Effects to images
5. You will see a text frame on the image with the text you just entered in it. If necessary, tap and drag the crossed arrow mark at the center of the text frame to adjust its position on the image, or tap and drag the small red dots at each corner of the text frame to adjust its size.
6. If necessary, you can tap the button to change text color, or the button to change text size. You can also tap the button to add more text or edit the text in the text frame.
Adding Text to Images
1. Open an image from the thumbnail or list view.
2. Tap the button to open the image workshop screen.
3. Tap Add text .
4. Enter the text you want to add to the image and then tap
OK .
7. Tap the button and then tap Yes to save your changes.
73 Copyright ©2006 Nokia All right reserved
Adding Clipart to Images
1. Open an image from the thumbnail or list view.
2. Tap the button to open the image workshop screen.
3. Tap Add clipart .
4. Tap to select a clipart image. The clipart image will appear on the original image.
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• Tap the button to add more clipart images to the original image.
• Delete a clipart image by tapping it on the original image and then tap the button.
• Adjust the position of the clipart image by tapping it on the original image, tapping the button and then tap and drag the clipart image.
• Adjust the size of the clipart image by tapping it on the original image, tapping the button and then tap and drag the clipart image.
• Rotate the clipart image by tapping it on the original image, tapping the button and then tap and drag the clipart image.
7. Tap the button and then tap Yes to save your changes.
Adding Frames
1. Open an image from the thumbnail or list view.
2. Tap the button to open the image workshop screen.
3. Tap Fun house .
5. If necessary, you can also do the following:
Copyright ©2006 Nokia All right reserved 74
U s i n g t h e A p p l i c a t i o n P r o g r a m s
4. Tap to select a frame. The frame will appear on the original image.
• Flip the original image horizontally by tapping the button.
6. Tap the button and then tap Yes to save your changes.
5. If necessary, you can also do the following:
• Adjust the position of the original image by tapping the button and then tap and drag the original image.
• Adjust the size of the original image by tapping the button and then tap and drag the dotted border of the original image.
• Rotate the original image by tapping the button and then tap and drag the original image.
Using Greeting Card Templates
1. Open an image from the thumbnail or list view.
2. Tap the button to open the image workshop screen.
3. Tap Greeting .
4. Tap to select a template. The template will appear on the original image.
5. If necessary, you can also do the following:
• Adjust the position of the original image by tapping the button and then tap and drag the original image.
• Adjust the size of the original image by tapping the button and then tap and drag the dotted border of the original image.
• Rotate the original image by tapping the button and then tap and drag the original image.
• Flip the original image horizontally by tapping the button.
6. Tap the button and then tap Yes to save your changes.
75 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Adding Warping Effects
1. Open an image from the thumbnail or list view.
2. Tap the button to open the image workshop screen.
3. Tap Warping .
4. Tap Warp and select a pen size for warping: Large pen ,
Medium pen or Small pen .
5. Tap and drag the portions you want to create warping effect on the original image. To clear all changes, tap Warp and then select Undo all changes .
6. Tap the button and then tap Yes to save your changes.
Internet
The Internet browser allows you to view information on the
World Wide Web or on WAP pages. You can also bookmark your favorite pages or save them for off-line viewing.
Before you can use Internet, you need to set up an Internet account in Settings. If you intend to use certain WAP services, it might also be necessary to set up a WAP account in Settings.
Note: Proxy settings for a WAP gateway should be set in the WAP account. Other proxy settings should be set in the Internet account.
Connecting to/Disconnecting from the
Internet
If your device is not connected to the Internet when you try to load a Web page, it will connect automatically. It then remains connected until the idle time you have specified in the Internet accounts settings has elapsed or you disconnect manually.
To disconnect, tap on the Status bar and select Disconnect .
Opening the Internet Browser
Method 1
Press and hold the key on the device.
Method 2
Tap the Internet application program icon in the Main screen.
Method 3
Tap a URL (web address) in a mail or message.
Opening Page
1. Tap Internet and select Open page .
2. In the Location field, enter the web address and then tap
Open . If you have previously visited certain web pages, their addresses will appear in the drop-down list. You can also tap to select one from them.
Copyright ©2006 Nokia All right reserved 76
U s i n g t h e A p p l i c a t i o n P r o g r a m s
To start browsing the Web, just tap any link on the page. Then you can move around on the Web by simply tapping links. A link can be an image or colored, underlined text. An image link is shown with a thin, blue frame that fades away after a second.
After a page has been loaded, you can use Find and Find next in the Internet menu to search for a specific text on that page.
Scrolling Pages
• Press the
• Press the
• Press the
• Press the
key to scroll page up.
key to scroll page down.
key to scroll page left.
key to scroll page right.
Note: Pages with frames and Java scripts may not display properly in the browser.
• If some or all of the images on the web page can’t be displayed, they will appear as . Try loading the data again by tapping Internet and select Reload page or Load all images .
Link Navigation
• Use the keys and , or and to select and navigate between links. A selected link is highlighted.
,
• Press to open a selected link.
• If a link is highlighted when you want to use the Scan text function, press any of the normal scrolling keys ,
Edit
Tip! To switch between full screen and normal view, tap key.
and select Full screen , or simply press the
• When in full screen view, to bring up a popup menu with useful commands, press the key.
Key Operations When Browsing
When browsing, you can use the following keys to conveniently move through the web pages and links.
Bookmarking Pages
1. Navigate to the page you want to bookmark.
2. Tap Internet and select Add to bookmarks .
3. Enter the bookmark name in the Name field and select a location where the bookmark will be saved in the Folder drop-down list, and then tap Done .
77 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Tip! Alternatively, you can bookmark a page by tapping and holding the link to the page and select Add to bookmarks.
Saving Pages for Off-Line Browsing
1. Navigate to the page you want to save.
2. Tap Internet and select Save page .
3. Enter the name for the page in the Name field and select a location where the page will be saved in the Folder drop-down list, and then tap Done .
• A cache is a memory location that is used to store data temporarily. If you have tried to access or have accessed confidential information requiring passwords, empty the cache after each use. The information or services you have accessed is stored in the cache. To empty the cache, see
" Advanced Options " on page 81
.
Going to Bookmarked Pages
Note: This saves the information on the Web page.
However, images and sounds will not be saved.
• Some Web pages are not allowed to be cached. These pages can not be saved.
To open a saved page:
1. Go to the Bookmarks view.
2. Tap the name of the saved page that you want to open.
Note: If you tap a link on a saved page, you will probably get an error message because the linked page is not available offline.
Note: Your device may have some bookmarks loaded for sites not affiliated with Nokia. Nokia does not warrant or endorse these sites. If you choose to access them, you should take the same precautions, for security or content, as you would with any Internet site.
1. Tap Internet and select Bookmarks . Alternatively, you can tap the button on the browser screen.
2. The bookmark list screen will appear.
Tap a bookmark and the bookmarked page will appear on the browser screen.
Operations When Viewing Pages
Pages and Bookmarks
• To move among recently visited pages, tap the
button.
• To stop loading a page, tap the button.
Copyright ©2006 Nokia All right reserved
or
78
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• To return to the home page, tap the
for how to setup your home page.
• To go to the bookmark list, tap the button.
• To return from the bookmark list to the browser screen, tap
Links to Pages
• To open a link, tap the link, or tap and hold the link and then select Open link .
• To view link information, tap and hold the link and then select Link information .
• To add the email address to your contacts, tap and hold the link and then select New contact .
Images
• To save an image on the page, tap and hold the image and select Save image .
• To copy an image to the clipboard, tap and hold the image and select Copy image .
• To view an image in a separate image viewer, tap and hold the image and select View image .
• To send an image, tap and hold the image and select Send image as .
Note: Copyright protections may prevent some images, music (including ringing tones), and other content from being copied, modified, transferred or forwarded.
Links to Phone Numbers
• To make a call to the phone number, tap and hold the link and then select Call .
• To send an SMS to the phone number, tap and hold the link and then select New SMS .
• To send an MMS to the phone number, tap and hold the link and then select New MMS .
• To add the phone number to your contacts, tap and hold the link and then select New contact .
Links to Email
• To send an email to the link address, tap and hold the link and then select New Email .
• To send an MMS to the link address, tap and hold the link and then select New MMS .
Managing Bookmarks
Deleting Bookmarks
1. Tap the button to go to the bookmark list.
2. Tap the check box beside each bookmark item to select it.
You can select multiple bookmarks.
3. Tap Internet and select Delete .
4. Tap Yes .
79 Copyright ©2006 Nokia All right reserved
Editing Bookmarks
1. Tap the button to go to the bookmark list.
2. Tap the check box beside a bookmark item to select it.
3. Tap Edit and select Edit .
4. Tap Edit .
5. Edit the location, name, folder of the bookmark or preferred
WAP account for connecting to this page and then tap the
Done button.
Sending Bookmarks
1. Tap the button to go to the bookmark list.
2. Tap the check box beside a bookmark item to select it.
3. Tap Edit and select Edit .
4. Tap Send as .
5. Select a method for sending the bookmark and then tap the
Done button.
Managing Bookmark Folders
1. In the bookmark list, tap All and select Edit folders .
2. You can:
• Tap the Add button to create a new folder. Enter the name for the new folder and then tap the Done button.
• Tap to select a folder on the list and then tap the Delete button to delete the selected folder.
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• Tap the Rename button to rename selected folder. Enter a new name and then tap the Done button.
Browser Preferences
The Internet browser allows you to change the way the browser deal with the web page contents, security and Internet connections by setting up the preferences options.
To access the preferences options, tap Edit on the browser screen and select Preferences .
Basic Options
• Homepage location : you can specify a favorite page as the default home page when opening the Internet browser by entering the complete address.
• WAP account : Select the WAP account to be used when the home page is loaded.
• Full screen on new page : Specify whether to switch to the full screen view when viewing the new page.
• Vertical scroll bar : Specify whether the vertical scroll bar will be displayed.
• Load images : Select if the images will be loaded when opening a page. If images are not loaded, the page will open faster.
• Play sound : Select if sound should be played when opening a page that contains it.
• Play animation : Select if animations should be played when opening a page that contains them.
Copyright ©2006 Nokia All right reserved 80
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Security Options
• Allow cookies : Select if you want to receive cookies when browsing.
Advanced Options
• WAP Push settings : You can select if you want to receive the
Push messages from your network service provider ( Enable
WAP Push ), if the URL should be opened automatically upon reception ( Auto load URL ), if the out-of-date Push messages should be removed automatically ( Auto delete expired ), and if sound should be played when a Push message is received
( Push sound ).
Note: For more information about the availability of the
WAP Push messages, please consult your network service provider.
• Cache size : Cache is the space for storing the data of visited web pages for faster loading the next time you visit it. Drag the slider to adjust the size of cache space. To clear the data in cache, tap Clear cache. To clear the history record of visited web pages, tap Clear history .
Time
The Time application program allows you to view and set time, date and location information. Besides, you can also set 3 different alarms.
Viewing Current Time and Date
You can view current time and by tapping the clock display on the
Status bar, or open Time in the Main screen.
In the Time screen, you can:
Setting Time and Date
Specifying Your Current Location
Before setting time and date, you must first select your current location.
1. In the Time screen, tap Time and select Set location on the menu that appears.
2. In the Location tab, tap to set the country information.
3. Tap the Numbers tab to set the number format.
4. Tap the Done button.
Setting Date and Time
1. In the Time screen, tap Time and select Set date & time on the menu that appears.
2. In the Date and time tab, enter current time and date.
3. Tap the Format tab and specify time and date format.
4. Tap to go to the Workdays tab and set workdays in a week.
5. Tap the Done button.
81 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Setting Alarms
1. In the Time screen, tap one of the 3 alarm fields.
2. The alarm setting screen will appear.
3. Complete necessary setup and then tap the Done button. You can set up to 3 alarms.
When alarms are set, the icon will display in the Main screen.
Activating/Deactivating Alarms
To enable or disable an alarm, check or uncheck the check box in each alarm field on the Time screen.
Operations When an Alarm Goes off
When an alarm goes off, you can tap Snooze to postpone the alarm for 5 minutes, or Silence to turn off alarm sound. To turn off the alarm, tap Done (or press the key).
To-do
The To-do application program helps you to manage your todo items and track the status. Besides, you can also exchange the to-do items with that of the Calendar application for easy planning of your daily schedule.
Creating New Tasks
1. In the To-do screen, tap To-do and select New .
2. Tap Unfiled and select a folder where you want to place the new task.
3. Enter a description of the task, and then specify the following:
• Completed : Check the check box if the task is already completed.
• Priority : Select a priority for the task.
• Due date : If the task has a due date, you can tap to check this check box, tap the date that appears and then select a date from a calendar.
• Alarm : To set alarm, tap to check this check box, tap the date and time that appear and then adjust alarm time.
• Private : If this check box is checked, when you synchronize tasks with other compatible devices, the private tasks will not be seen in public.
4. Tap the tab and write a note for the task.
5. Tap the button to save the new task.
Viewing Tasks
You can view your tasks on the To-do screen. Overdue tasks will turn into red. You can sort the tasks by tapping Edit and select
Sort by priority or Sort by date .
Copyright ©2006 Nokia All right reserved 82
U s i n g t h e A p p l i c a t i o n P r o g r a m s
To view a task, tap a task item on the To-do screen. The details of the task will appear on the screen.
Managing Tasks
Changing Task Status
If a task is completed, you can check the check box of each task on the To-do screen to mark the task as “completed”.
Finding a Task
To find a specific task:
1. In the To-do screen, tap To-do and select Find .
2. Enter the keyword and select where to search.
3. Tap the Find button.
4. The tasks that match your search keyword will appear on the screen. You can tap to select and open a task.
Editing a Task
1. Open a task by tapping it on the To-do screen.
2. Make changes to the task.
3. Tap the button to save your changes.
Deleting a Task
1. Open a task by tapping it on the To-do screen.
2. Tap To-do and select Delete To-do .
Deleting Completed Tasks
1. In the To-do screen, tap To to and select Delete completed .
2. Select whether to delete all completed tasks, or just the completed tasks in a specific folder.
3. Tap Yes to delete the tasks.
Moving Tasks to the Calendar Application Program
1. Open a task by tapping it on the To-do screen.
2. Tap To-do and select Move to Calendar .
3. Tap the Yes Button.
Pasting Tasks from the Calendar Application Program
1. Cut or copy an entry in the Calendar application program.
2. In the To-do screen, tap Edit and select Paste entry .
Sending Tasks
1. Open a task on the To-do screen.
2. Tap To-do and select Send as .
3. Select from the following and then tap the Done button:
83 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• Email : Send the task as email attachment. This option is available only when an email account is created on the device.
• Message : Send the task to other compatible devices via an
SMS message. Enter the number of the recipient and then tap the Send button.
• MMS : Send the task to other compatible devices as an MMS attachment. The MMS message screen will follow for you to compose the message.
• Tap the Add button to create a new folder. Enter the name for the new folder and then tap the Done button.
• Tap to select a folder on the list and then tap the Delete button to delete the selected folder.
• Tap the Rename button to rename selected folder. Enter a new name and then tap the Done button.
Note: Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
• Bluetooth : Send the task to other compatible devices that support Bluetooth connectivity. A box will appear showing found paired devices. Tap to select a device and then tap the
Send button.
• Infrared : Send the task to other compatible devices that support infrared connection. Align the infrared port of your device with that of the other device, then the transfer will start automatically.
To-do Preferences
1. In the To-do screen, tap Edit and select Preferences .
2. Set the following items:
• Display due dates : If unchecked, the set due dates for each task will not appear on the To-do screen.
• Display completed : If unchecked, the completed tasks will not appear on the To-do screen.
• Alarm sound : Tap to select a preferred alarm sound from the drop-down list.
• Vibrating alarm : If checked, the device will vibrate when the task alarm goes off.
Managing Task Folders
1. In the To-do screen, tap All and select Edit folders .
2. You can:
Calculator
You can turn your device into a handy calculator with the
Calculator application program.
Copyright ©2006 Nokia All right reserved 84
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Note: This calculator has limited accuracy and is designed for simple calculations.
Button Description
• Tap this button for the first time to get a value from the calculator memory.
• Tap it for a second time to clear the calculator memory.
• Tap this button to save an entered value to calculator memory.
• When there is already a value on the screen, tap this button to add it to the value in the memory.
Tap this button to deduct the entered value from that in the calculator memory.
Tap this button to delete the last digit you entered.
Tap this button to reset the value on the screen to 0.
To perform calculations, tap the numeric and operative buttons on the Calculator screen, and then tap the button to display calculation result.
You can tap Calculator and then select Copy or Paste to copy a value from or paste it to other application programs.
There are several additional buttons on the Calculator screen:
Voice
You can use the Voice application program to record voice notes and save them as sound clips. You can also send them via MMS and email, or use them as ring tones.
Note: The Voice application cannot be used when a data call or GPRS connection is active.
85 Copyright ©2006 Nokia All right reserved
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Creating a New Voice Note
1. In the Voice screen, tap Voice and then select New Voice note , or tap the New button.
2. Tap the button to start recording.
3. To adjust microphone volume, drag the microphone slider
to the left or right.
4. To stop recording, tap the button. The recording will be saved automatically with recording date and time. You can also tap the button to play the voice note.
4. To pause playing the voice note, tap the resume normal playback, tap the button.
button. To
Deleting Voice Notes
1. In the Voice screen, tap the or button to select the voice note to delete.
2. Tap the Delete button.
Tip! It is recommended that you keep the distance between the sound source and the microphone of the device within about 10 ~ 15 cm in order to obtain better recording quality.
Playing Voice Notes
1. In the Voice screen, tap the or button to select a voice note.
2. Tap the button to start playing the selected voice note.
3. To adjust playback volume, drag the volume slider
to the left or right.
Sending Voice Notes
1. In the Voice screen, tap the or button to select a voice note to send.
2. Tap Voice and then select Send as .
3. Select from the following and then tap the Done button:
• Email : Send the voice note as email attachment. This option is available only when an email account is created on the device.
• MMS : Send the voice note to other compatible devices as an
MMS attachment. The MMS message screen will follow for you to compose the message.
Note: Only devices that have compatible features can receive and display multimedia messages. The appearance of a message may vary depending on the receiving device.
Copyright ©2006 Nokia All right reserved 86
U s i n g t h e A p p l i c a t i o n P r o g r a m s
• Bluetooth : Send the voice note to other compatible devices that support Bluetooth connectivity. A box will appear showing found paired devices. Tap to select a device and then tap the Send button.
• Infrared : Send the voice note to other compatible devices that support infrared connection. Align the infrared port of your device with that of the other device, then the transfer will start automatically.
For more information on how to subscribe to these additional online services and how to use them, please consult your network service provider.
GPRS Data Log
You can use the GPRS data log to track the size of data sent and received via the GPRS data connection.
Using Auto Gain Control recording (AGC)
When the AGC (Auto Gain Control) function is activated, the device will automatically and dynamically adjust the recording volume. If an undesirable background noise in the recorded file is increased, please turn off this function.
• To turn on the AGC function, when in the Voice screen, tap
AGC and then AGC ON .
• To turn off the AGC function, when in the Voice screen, tap
AGC and then AGC OFF .
Viewing GPRS Data Log
1. Tap the GPRS data log application program icon in the Main screen.
2. Tap to select a GPRS connection in the screen.
Online Services
Depending on your network service provider or SIM card capability, you may be able to subscribe for certain additional services, such as online banking services or provision of weather or traffic information. Usually the setting for accessing these services are programmed by your network service provider on your SIM card so your device can identify them.
87 Copyright ©2006 Nokia All right reserved
3. Related information, including total data sent, total data received, data received last/this session and data sent last/ this session, will appear in a new dialog.
U s i n g t h e A p p l i c a t i o n P r o g r a m s
Resetting GPRS Data Count
Tap Reset in the dialog.
Deleting GPRS Data Log
Tap Delete in the dialog.
4. Tap Done to close the dialog.
Copyright ©2006 Nokia All right reserved 88
E x p a n d i n g t h e C a p a b i l i t i e s o f Y o u r D e v i c e
6. Expanding the Capabilities of Your Device
Installing Application Programs
The Symbian operating system adopted by your device is an common system in the industry, and you can install various application programs designed for it. These programs can be obtained from the Internet, from email attachments, on CDs, memory cards or from other compatible devices.
The installation files of the application programs are available in the following formats:
• SIS (Symbian Standard Installation)
• JAR (Java Archive)
Important: Only install and use applications and other software from sources that offer adequate security and protection against harmful software.
Installing Application Programs from the
Internet
Usually, when you download an application program from the
Internet, installation will start automatically after the file is saved to your device. Follow the instructions of the installer to complete the installation process.
Installing Application Programs from
Installation Files
Follow the steps below to install application programs from the installation files on CDs, memory cards, emails or received from other compatible devices.
1. Locate the installation file and save it to the device or the memory card.
2. In the Main screen, tap Manager and select Install .
3. The available programs for installation will appear in the box. Tap to select the program you want to install and then tap Install .
Uninstalling Application Programs
To uninstall application programs from your device:
1. In the Main screen, tap Manager and select Uninstall .
2. Installed programs on your device will appear. Tap to select the program you want to uninstall and then tap Uninstall .
Note: If another software package depends on the software package that you removed, the other software package may stop working. Refer to the documentation of the installed software package for details.
89 Copyright ©2006 Nokia All right reserved
E x p a n d i n g t h e C a p a b i l i t i e s o f Y o u r D e v i c e
Installing/Removing a Memory Card
With additional memory cards you can easily expand the memory space of your device for storing more programs or files or exchange them with other users.
Your device accepts a standard SD (Secure Digital) or a Mini SD (a memory card converter is required) memory card.
Installing a Standard SD Memory Card
1. Open the protective cover on the memory card slot as shown.
Important: Do not remove the memory card in the middle of an operation when the card is being accessed.
Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.
• Use only compatible SD memory cards with this device.
Using an incompatible memory card may damage the memory card as well as the device, and data stored on the incompatible card may be corrupted.
2. Insert the standard SD memory card all the way into the slot.
Pay attention to the direction of the metal contacts on the memory card when inserting.
3. Close the protective cover.
Copyright ©2006 Nokia All right reserved 90
E x p a n d i n g t h e C a p a b i l i t i e s o f Y o u r D e v i c e
Installing a Mini SD Memory Card
1. Insert the Mini SD memory card into the memory card converter.
2. Open the protective cover on the memory card slot as shown.
3. Insert the memory card converter all the way into the slot. Pay attention to the direction of the metal contacts when inserting.
Removing a Memory Card
1. Close all running programs that use the memory card.
2. Open the protective cover on the memory card slot.
3. Push the memory card inward using your fingernail or the opposite side of the stylus. The card will pop up from the slot.
91 Copyright ©2006 Nokia All right reserved
4. Remove the memory card from the slot.
5. Close the protective cover.
Formatting a Memory Card
Important: Formatting the memory card will cause all programs and file data on the card to disappear.
• Make sure the write-protection switch on the memory card has been moved to the write-enabled position.
1. Make sure that the power of the device is sufficient and not too low.
2. Tap the icon in the Main screen and then select Format disk on the tab.
3. From the dialog that appears, tap to select the disk you want to format.
4. Tap Format . Your device will begin formatting the memory card.
Important: Do not remove the memory card while formatting. Otherwise the card will be damaged.
Renaming a Memory Card
1. Tap the icon in the Main screen and then select Format disk on the tab.
2. From the dialog box that appears, tap to select the disk you want to rename.
3. Tap Rename and enter the new name in the Name field.
4. Tap Done .
E x p a n d i n g t h e C a p a b i l i t i e s o f Y o u r D e v i c e
Copyright ©2006 Nokia All right reserved 92
M a n a g i n g a n d P e r s o n a l i z i n g Y o u r D e v i c e
7. Managing and Personalizing Your Device
Managing Application Programs
3. Tap Done .
Grouping Application Programs
You can put application programs in different groups (folders) for easier access.
1. In the Main screen, tap All and select Edit folders .
2. You can:
• Tap the Add button to create a new folder. Enter the name for the new folder and then tap the Done button.
• Tap to select a folder on the list and then tap the Delete button to delete the selected folder.
• Tap the Rename button to rename selected folder. Enter a new name and then tap the Done button.
Setting Application Programs on the
Application Shortcut Bar
You can setup the application program shortcuts located in the application shortcut bar by following the steps below:
1. In the Main screen, tap View and select Preferences .
2. Tap to select the icon of the application program to be replaced in the application shortcut bar in the dialog, and then tap the Set shortcut drop-down list to select a new application program.
93 Copyright ©2006 Nokia All right reserved
File Management
When connected to a PC that runs the PC Suite for the Nokia
6708, you can manage media files on your device from PC easily.
For more information about how to install and configure the PC
Suite for the Nokia 6708 and how to manage files, please refer to the instructions on the CD.
Personalizing Your Device
Customizing User Profiles
You can personalize how your device looks and sounds by configuring and applying user profiles. A user profile is a combination of user settings, including sound settings, display theme settings and appearance settings. You can also setup different profiles for use in different occasions.
To customize a user profile:
1. Tap the icon in the Main screen and then select User
Profiles on the tab.
M a n a g i n g a n d P e r s o n a l i z i n g Y o u r D e v i c e
Tip! You can also enter the profile setup screen by tapping the icon on the Status bar and then tap the
Settings button in the dialog that appears.
2. Tap to select a profile from the Profiles drop-down menu.
3. Specify the settings by selecting options in drop-down menus.
Tip! You can also drag the slider beside the image to change its size on the screen, or tap the Tile check box to tile smaller images on the screen.
4. Tap Save to save, or Done to save and apply current profile settings.
Tip! You can tap the icon to listen to the sound.
Changing Themes
To select a display theme, go to User profiles , scroll down to tap
Apply Theme , and select a theme from the dialog box that follows and then tap Select .
Changing Appearance
To select a different picture as the background image of the Main screen, go to User profiles , scroll down to tap Apply Appearance and then select Find image in the Background drop-down menu.
A new dialog box will follow allowing you to select an image. Tap to select a desired image and then tap Select , Done .
Selecting a User Profile
1. Tap the icon in the Main screen and then select User
Profiles on the tab.
2. Tap to select a profile from the Profiles drop-down menu.
3. Tap Done .
Copyright ©2006 Nokia All right reserved 94
G e t t i n g Y o u r D e v i c e C o n n e c t e d a n d S y n c h r o n i z e d
8. Getting Your Device Connected and Synchronized
Connecting the Device to Other
Devices
You can connect your device to other compatible devices using the following
connections:
• Infrared connection
• Bluetooth connection
• USB connection
After a connection is established (except USB connection), you can use the Send as commands in various application programs to send data to or receive data from the connected devices.
Infrared Connection
Warning: Do not point the IR (infrared) beam at anyone's eye or allow it to interfere with other IR devices. This device is a Class 1 laser product.
1. Enable the infrared function of the device you want to connect to. For more information, refer to the documentation of that device.
2. Tap the icon in the Main screen and then select Infrared on the tab.
3. Select the Infrared status as PC connection or Modem .
4. Set the Infrared function to be On or On for 10 minutes .
5. Tap Done .
6. Align the infrared port of your device with that on the device to be connected. Make sure that the distance in between does not exceed 1 meter (1 m) and there is no obstacles to obstruct transmission.
7. Now you can use the Send as command of the application program to send data, or receive data sent from the connected device. When data is received, you will be prompted to select View to view the received data, or Done to save data to the specific location of the application program.
USB Connection
1. Refer to the user guide on the CD to install and configure the
PC Suite for the Nokia 6708.
2. Make sure that your device is powered on and the connection mode has been set to PC Connect
(See " USB cable " on page 47 ).
3. Connect the USB connector on the device to a USB port on the PC using the supplied data cable.
95 Copyright ©2006 Nokia All right reserved
G e t t i n g Y o u r D e v i c e C o n n e c t e d a n d S y n c h r o n i z e d
Bluetooth Connection
Bluetooth technology enables wireless connections to send images, video clips, music and sound clips, and notes, or to connect wirelessly to compatible devices with Bluetooth technology such as computers. Since devices with Bluetooth technology communicate using radio waves, your device and the other device do not need to be in direct line-of-sight. The two devices only need to be within a maximum of 10 metres of each other, although the connection can be subject to interference from obstructions such as walls or from other electronic devices.
There may be restrictions on using Bluetooth technology in some locations. Check with your local authorities or service provider.
Features that use Bluetooth technology, or allow such features to run in the background while using other features, increase the demand on battery power and reduce the battery life.
In order to avoid malicious software, it is recommended that you turn on Bluetooth connectivity only when you want to use it, or alternatively, make your device invisible to other devices.
Establishing Bluetooth Connection
Refer to the steps below for how to connect your device to a PC via Bluetooth connection.
1. Tap the icon in the Main screen and then select
Bluetooth on the tab.
2. Check the Bluetooth on check box to become connectable to other compatible devices, and then select Yes or For 10 minutes in Visible for other devices .
3. Set up Receiving items as Always receive or Ask first .
4. If necessary, you can also enter a new name for your device in the Name of my device box.
5. Make sure the Bluetooth connection of the device you want to connect is activated.
6. Tap the Devices tab and then Add . Your device searches for all devices in the vicinity.
7. Tap to select the compatible device you want your device to pair with and, if necessary, enter a passkey. When the passkey is accepted, the pairing process is complete.
Important: Do not accept Bluetooth connectivity from sources you do not trust.
Note: The Bluetooth PIN code is a set of code for pairing and identifying Bluetooth devices. You can use any combination of numbers or letters for the code. However, the code entered on your device and another device with
Bluetooth connectivity must be identical.
• If you are using a device with a fixed Bluetooth pin code, please check the documentation that comes with that device for the Bluetooth PIN code.
Copyright ©2006 Nokia All right reserved 96
G e t t i n g Y o u r D e v i c e C o n n e c t e d a n d S y n c h r o n i z e d
Breaking Bluetooth Connection
1. Tap the icon in the Main screen and then select
Bluetooth on the tab.
2. Uncheck the Bluetooth on check box and then tap Done .
6. In the dialog that appears, click the Advanced tab.
7. Refer to the service provider’s setting to enter a command in the Extra initialization commands box, and then click OK . An example of the command is
+cgdcont=1,"ip", "APN"
Using the Device as a GPRS Modem
Setting up GPRS Modem via Infrared
Connection
Note: The steps below describe the setup procedure in
Windows XP.
1. Make sure that your device is switched on and the connection mode has been set to Modem (See
).
2. Align the infrared port of your device with that of your PC.
3. On your PC, click the Start button on Windows Taskbar, right-click on My Computer and select Properties .
4. Click the Hardware tab and then click Device Manager .
5. Double-click Modems , and then Standard Modem over IR
Link .
Note: APN (Access Point Node) is a setting by your network service provider that tells how your data requests should be routed. Consult your network service provider for the actual APN address.
8. Click the Start button on Windows Taskbar, select Connect to , and then Show all connections . Alternatively, you can click the Start button on Windows Taskbar, go to Control
Panel , and select Network Connections .
9. Click Create a new connection .
10. In the New Connection Wizard dialog, click Next .
11. Click Connect to the Internet and then Next .
12. Click Set up my connection manually and then Next .
13. Click Connect using a dial-up modem and then Next .
14. In the dialog that follows, click to choose Standard Modem over IR Link and then click Next .
15. In the dialog that follows, enter a connection name in the
ISP name box, and then click Next .
97 Copyright ©2006 Nokia All right reserved
G e t t i n g Y o u r D e v i c e C o n n e c t e d a n d S y n c h r o n i z e d
16. Enter *99# in Phone number box in the dialog that follows and then click Next .
17. Enter the user name and password in the dialog that follows and then click Next .
Note: Consult your network service provider for the user name and password if required.
18. Click Finish , and then click Properties in the Connect Dial-up
Connection dialog that follows.
19. Click Configure , uncheck Enable hardware flow control and then click OK .
20. Click OK to return to the Connect Dial-up Connection dialog.
Now you can click Dial to start using the device as a GPRS modem to connect to the Internet.
3. Connect the USB connector on the device to a USB port on the PC using the supplied data cable.
4. On your PC, click the Start button on Windows Taskbar, right-click on My Computer and select Properties .
5. Click the Hardware tab and then click Device Manager .
6. Double-click Modems , and then Nokia 6708 VSC Modem
(WDM) .
7. In the dialog that appears, click the Advanced tab.
8. Refer to the service provider’s setting to enter a command in the Extra initialization commands box, and then click OK . An example of the command is
+cgdcont=1,"ip", "APN"
Setting up GPRS Modem via USB Connection
1. Install the PC Suite for the Nokia 6708.
Note: For more information about how to install and configure PC Suite for the Nokia 6708, please refer to the users guide on the CD.
• The steps below describe the setup procedure in Windows XP.
2. Make sure that your device is switched on and the connection mode has been set to Modem
(See " USB cable " on page 47 ).
Note: APN (Access Point Node) is a setting by your network service provider that tells how your data requests should be routed. Consult your network service provider for the actual APN address.
9. Click the Start button on Windows Taskbar, select Connect to , and then Show all connections . Alternatively, you can click the Start button on Windows Taskbar, go to Control
Panel , and select Network Connections .
10. Click Create a new connection .
11. In the New Connection Wizard dialog, click Next .
12. Click Connect to the Internet and then Next .
13. Click Set up my connection manually and then Next .
Copyright ©2006 Nokia All right reserved 98
G e t t i n g Y o u r D e v i c e C o n n e c t e d a n d S y n c h r o n i z e d
14. Click Connect using a dial-up modem and then Next .
15. In the dialog that follows, click to choose Modem - Nokia
6708 VSC Modem (WDM) and then click Next .
16. In the dialog that follows, enter a connection name in the
ISP name box, and then click Next .
17. Enter *99# in Phone number box in the dialog that follows and then click Next .
18. Enter the user name and password in the dialog that follows and then click Next .
2. On your PC, click the Start button on Windows Taskbar, right-click on My Computer and select Properties .
3. Click the Hardware tab and then click Device Manager .
4. Double-click Modems , and then Bluetooth Modem .
5. In the dialog that appears, click the Advanced tab.
6. Refer to the service provider’s setting to enter a command in the Extra initialization commands box, and then click OK . An example of the command is
+cgdcont=1,"ip", "APN"
Note: Consult your network service provider for the user name and password if required.
19. Click Finish , and then click Properties in the Connect Dial-up
Connection dialog that follows.
20. Click Configure , uncheck Enable hardware flow control and then click OK .
21. Click OK to return to the Connect Dial-up Connection dialog.
Now you can click Dial to start using the device as a GPRS modem to connect to the Internet.
Setting up GPRS Modem via Bluetooth
Connection
1. Perform step 1 through 7 in " Establishing Bluetooth
to establish Bluetooth connection.
Note: APN (Access Point Node) is a setting by your network service provider that tells how your data requests should be routed. Consult your network service provider for the actual APN address.
7. Double-click the My Bluetooth Places icon on the Desktop and select View devices in range . The Nokia 6708 icon (or the name referred to your device) will appear.
8. Double-click the Nokia 6708 icon and all available services will appear.
9. Double-click the Dial-up Networking on Nokia 6708 service icon.
10. Click Properties in the Connect Bluetooth Connection dialog that follows.
11. Click Configure , uncheck Enable hardware flow control and then click OK .
99 Copyright ©2006 Nokia All right reserved
G e t t i n g Y o u r D e v i c e C o n n e c t e d a n d S y n c h r o n i z e d
12. Enter *99# in Phone number box and click OK to return to the Connect Bluetooth Connection dialog.
13. Now you can click Dial to start using the device as a GPRS modem to connect to the Internet.
Note: The options from step 7 to 13 may vary by
Bluetooth service provider. Consult your retailer or Bluetooth provider to find out the correct options on the PC if necessary.
Synchronizing Data
Performing Remote Synchronization with a
Server
If you are frequently on the move and need to keep your data synchronized, remote sync will be an ideal choice. Remote synchronization requires support of the following from your network service provider:
• GPRS or dial-up data connection service
• A synchronization server
In order to perform remote synchronization, you need to correctly configure the remote synchronization settings.
Configuring Remote Synchronization Settings
Consult your network service provider and obtain the following information:
• Remote synchronization server address
• User name and password
Next, configure the remote synchronization settings following the steps below.
1. Tap the icon in the Application shortcut bar, all application program icons on your device are displayed.
2. Tap Remote sync .
3. Tap Edit and select Preferences .
4. According to the data obtained form your network service provider, complete the settings on the Server and Protocol tabs.
5. Tap Done .
Performing Remote Synchronization
1. Tap the icon in the Application shortcut bar.
2. Tap Remote sync .
3. Tap Sync .
Copyright ©2006 Nokia All right reserved 100
T r o u b l e s h o o t i n g I n f o r m a t i o n
9. Troubleshooting Information
If you encounter problems when using your device, please refer to the troubleshooting information below to solve them. If the problem still persists after you have tried the suggested solutions, please contact your dealer for assistance.
Note: Do not attempt to disassemble the device by yourself. There are no user serviceable parts inside.
Call Related Problems
Cannot make outgoing calls.
Check the following:
• Is your device in the Offline mode? In the Power menu screen, change to other profiles except Power off and Offline , so you can use the call related functions.
• Is there a SIM card in the device? Install a valid SIM card.
• Is the signal strength strong enough? Try moving to a different location to obtain better signal reception.
• Is the call restricting feature activated? Deactivate the feature if necessary.
Cannot receive calls.
Check the following:
• Is your device in the Offline mode? In the Power menu screen, change to other profiles except Power off and
Offline , so you can use the call related functions.
• Is there a SIM card in the device? Install a valid SIM card.
• Is the signal strength strong enough? Try moving to a different location to obtain better signal reception.
Can not use certain call functions (for example, call waiting, or call barring).
Depending on your network service provider, some call services may require extra subscription. Please contact your network service provider for details.
There are noises during a call.
Check the following:
• Are you near a strong electromagnetic source (such as a TV or a microwave oven) during the call? Move to another location to reduce the interference effects.
• Check the status of signal reception. If necessary, move to another location where reception is better.
Message Problems
Cannot send or receive text messages.
Check the following:
• Is the device in the Offline mode? In the Power menu screen, change to other profiles except Power off and Offline .
101 Copyright ©2006 Nokia All right reserved
T r o u b l e s h o o t i n g I n f o r m a t i o n
• Has the message center number been set? You have to configure the message center number manually in
Messaging accounts if it is not already programmed on the
SIM card.
• Is the signal strength strong enough? Try moving to a different location to obtain better signal reception.
Cannot send or receive multimedia messages.
Check the following:
• Is the device in the Offline mode? In the Power menu screen, change to other profiles except Power off and
Offline .
• Have you subscribed the MMS service to your network service provider? The MMS service may require extra subscription.
• Has the MMS setting been correctly configured? Check the setting with your network service provider.
• The status of device memory. Is there enough space? Delete some files if necessary.
• Is the signal strength strong enough? Try moving to a different location to obtain better signal reception.
Cannot send or receive email.
Check the following:
• Is the device in the Offline mode? In the Power menu screen, change to other profiles except Power off and
Offline .
• Have you subscribed the dial-up or GPRS data service to your network service provider? These services may require extra subscription.
• Has the email setting been correctly configured? Check the setting with your email service provider.
• Is the signal strength strong enough? Try moving to a different location to obtain better signal reception.
Internet Problems
Cannot connect to the Internet.
• Is the device in the Offline mode? In the Power menu screen, switch it to the General mode.
• Have you subscribed the dial-up or GPRS data service to your network service provider? These services may require extra subscription.
• Has the Internet setting been correctly set? Check with your
Internet service provider for correct setting.
Application Program Problems
The application program freezes.
Remove the device battery, put it back on and turn on the device.
Cannot add new data (for example, new contact, task or calender entry).
Check the status of device memory. Is there enough space? Delete some files if necessary.
Copyright ©2006 Nokia All right reserved 102
T r o u b l e s h o o t i n g I n f o r m a t i o n
Error occurs when playing music files or video clips.
• The music file or video clip format may not be compatible with the Music Player. Check the file format or convert it to an acceptable format on PC.
• When exchanging files, make sure that you put the files in their specific folders in device memory or on the memory card, otherwise the device may not be able to recognize them correctly. For example, when copying music files to the device memory/memory card, put them in the folder named "audio" in the "Media files" folder. The folders will be created automatically when running their corresponding application programs. For example, the "audio" folder will be created after you run the Music player application program.
• Is the APN Address correct?
• If the PC suite tool is installed, check that the port is not occupied by the PC suite tool.
System Problems
Cannot turn on the device.
Check the following:
• Is the battery fully charged? Check the battery and fully charge it if necessary.
• Are the battery contact terminals clean? Seek your dealer's help to clean the terminals.
What should I do if the "Low on storage space" message appears?
Try to delete some unnecessary files from the device memory, or move them to the memory card. It is recommended that you use PC Suite for the Nokia 6708 to back up your data regularly in order to prevent loss of data.
Connection Problems
Cannot connect the device to PC using the data cable.
Check the following:
• Is the power of the device turned on?
• Has the USB connection mode on the device been set to PC connect?
Cannot use the device as a GPRS modem to connect to the
Internet.
Check the following:
• Is the power of the device turned on?
• Has the USB connection mode on the device been set to
Modem?
103 Copyright ©2006 Nokia All right reserved
B a t t e r y i n f o r m a t i o n
10. Battery information
Charging and discharging
Your device is powered by a rechargeable battery. The full performance of a new battery is achieved only after two or three complete charge and discharge cycles. The battery can be charged and discharged hundreds of times, but it will eventually wear out. When the talk and standby times are noticeably shorter than normal, replace the battery. Use only Nokia approved batteries, and recharge your battery only with Nokia approved chargers designated for this device.
This device has an internal, removable, rechargeable battery. If a replacement battery is being used for the first time or if the battery has not been used for a prolonged period, it may be necessary to connect the charger then disconnect and reconnect it to begin charging the battery.
Unplug the charger from the electrical plug and the device when not in use. Do not leave a fully charged battery connected to a charger, since overcharging may shorten its lifetime. If left unused, a fully charged battery will lose its charge over time.
If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.
To prolong battery life of NiMh batteries, discharge the battery from time to time by leaving your device switched on until it turns itself off. Do not attempt to discharge the battery by any other means.
Use the battery only for its intended purpose. Never use any charger or battery that is damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object such as a coin, clip, or pen causes direct connection of the positive (+) and negative (-) terminals of the battery. (These look like metal strips on the battery.) This might happen, for example, when you carry a spare battery in your pocket or purse. Short-circuiting the terminals may damage the battery or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer or winter conditions, will reduce the capacity and lifetime of the battery. Always try to keep the battery between
15
°C
and 25
°C
(59
°
F and 77
°
F). A device with a hot or cold battery may not work temporarily, even when the battery is fully charged. Battery performance is particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode.
Batteries may also explode if damaged. Dispose of batteries according to local regulations. Please recycle when possible. Do not dispose as household waste.
Copyright ©2006 Nokia All right reserved 104
B a t t e r y i n f o r m a t i o n
Nokia battery authentication guidelines
Always use original Nokia batteries for your safety. To check that you are getting an original Nokia battery, purchase it from an authorized Nokia dealer, look for the Nokia Original
Enhancements logo on the packaging and inspect the hologram label using the following steps:
Successful completion of the steps is not a total assurance of the authenticity of the battery. If you have any reason to believe that your battery is not an authentic original Nokia battery, you should refrain from using it. If authenticity cannot be verified, return the battery to the place of purchase.
Authenticate hologram
1. When looking at the hologram on the label, you should see the Nokia connecting hands symbol from one angle and the Nokia Original
Enhancements logo when looking from another angle.
2. When you angle the hologram left, right, down, and up, you should see
1, 2, 3, and 4 dots on each side respectively.
105 Copyright ©2006 Nokia All right reserved
What if your battery is not authentic?
If you cannot confirm that your Nokia battery with the hologram on the label is an authentic Nokia battery, please do not use the battery.
The use of a battery that is not approved by the manufacturer may be dangerous and may result in poor performance and damage to your device and its enhancements. It may also invalidate any approval or warranty applying to the device.
To find out more about original Nokia batteries, visit www.nokia-asia.com/batterycheck.
B a t t e r y i n f o r m a t i o n
Copyright ©2006 Nokia All right reserved 106
G e n u i n e E n h a n c e m e n t s
11. Genuine Enhancements
A new extensive range of enhancements is available for your device. Select the enhancements which accommodate your specific communication needs.
Some of the enhancements are described in detail below.
For availability of the enhancements, please check with your local dealer. A few practical rules for enhancements operation:
• Keep the enhancements out of small children’s reach.
• When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.
• Check regularly that all mobile phone equipment in a vehicle is mounted and operating properly.
Use only batteries, chargers and enhancements approved by the phone manufacturer. The use of any other types may invalidate any approval or warranty applying to the device, and may be dangerous.
Power
Type Tech Talktime* Standby*
BP-3001L Li-lon up to 3 - 6 hours up to 148 - 275 hrs
* Variation in operation times may occur depending on SIM card, network and usage settings, usage style and environments. Use of integrated hands-free will affect talktime and standby.
RECHARGEABLE LI-POLYMER BATTERY. USE NOKIA SPECIFIED
CHARGER ONLY. MAY EXPLODE IF DISPOSED OF IN FIRE. DO NOT
SHORT-CIRCUIT. DO NOT INCINERATE. DO NOT DISASSEMBLE.
Travel Charger (AC-1001C)
Small, lightweight travel charger with multivoltage (100 - 240V) switcher technology. Provides easy and convenient way to charge the device.
markets.
Note: The plug types vary according to different
107 Copyright ©2006 Nokia All right reserved
Audio
Stereo Headset (HS-46)
This stereo headset has a beautiful and distinctive Nokia design.
Gives you excellent audio quality and you can answer or end calls by pressing the remote control button.
G e n u i n e E n h a n c e m e n t s
Copyright ©2006 Nokia All right reserved 108
C a r e a n d M a i n t e n a n c e
12. Care and Maintenance
Your device is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you protect your warranty coverage.
• Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that will corrode electronic circuits. If your device does get wet, remove the battery immediately, and allow the device to dry completely before replacing it.
• Do not use or store the device in dusty, dirty areas. Its moving parts and electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten the life of electronic devices, damage batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal temperature, moisture can form inside the device and damage electronic circuit boards.
• Do not attempt to open the device other than as instructed in this guide.
• Do not drop, knock, or shake the device. Rough handling can break internal circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper operation.
• Use a soft, clean, dry cloth to clean the touch screen and any lenses, such as camera, proximity sensor, and light sensor lenses.
• Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage the device and may violate regulations governing radio devices.
• Use chargers indoors.
• Always create a backup of data you want to keep, such as contacts and calendar notes, before sending your device to a service facility.
All of the above suggestions apply equally to your device, battery, charger, or any enhancement. If any device is not working properly, take it to the nearest authorized service facility for service.
109 Copyright ©2006 Nokia All right reserved
A d d i t i o n a l S a f e t y I n f o r m a t i o n
13. Additional Safety Information
Your device and its enhancements may contain small parts. Keep them out of the reach of small children.
Operating environment
Remember to follow any special regulations in force in any area, and always switch off your device when its use is prohibited or when it may cause interference or danger. Use the device only in its normal operating positions. This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 2 centimeters (7/8 inches) away from the body. When a carry case, belt clip or holder is used for body-worn operation, it should not contain metal and should position the device the above-stated distance from your body.
In order to transmit data files or messages, this device requires a good quality connection to the network. In some cases, transmission of data files or messages may be delayed until such a connection is available. Ensure the above separation distance instructions are followed until the transmission is completed.
Medical devices
Operation of any radio transmitting equipment, including wireless phones, may interfere with the functionality of inadequately protected medical devices. Consult a physician or the manufacturer of the medical device to determine if they are adequately shielded from external RF energy or if you have any questions. Switch off your device in health care facilities when any regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of 15.3 centimeters (6 inches) be maintained between a wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless
Technology Research. Persons with pacemakers should do the following:
• Always keep the device more than 15.3 centimeters
(6 inches) from the pacemaker
• Not carry the device in a breast pocket
• Hold the device to the ear opposite the pacemaker to minimize the potential for interference.
If you suspect interference, switch off your device, and move the device away.
Copyright ©2006 Nokia All right reserved 110
A d d i t i o n a l S a f e t y I n f o r m a t i o n
Hearing aids
Some digital wireless devices may interfere with some hearing aids. If interference occurs, consult your service provider.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles such as electronic fuel injection systems, electronic antiskid (antilock) braking systems, electronic speed control systems, and air bag systems.
For more information, check with the manufacturer, or its representative, of your vehicle or any equipment that has been added.
Only qualified personnel should service the device, or install the device in a vehicle. Faulty installation or service may be dangerous and may invalidate any warranty that may apply to the device. Check regularly that all wireless device equipment in your vehicle is mounted and operating properly. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the device, its parts, or enhancements. For vehicles equipped with an air bag, remember that air bags inflate with great force. Do not place objects, including installed or portable wireless equipment in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed, and the air bag inflates, serious injury could result.
Using your device while flying in aircraft is prohibited. Switch off your device or set your device offline before boarding an aircraft.
The use of wireless teledevices in an aircraft may be dangerous to the operation of the aircraft, disrupt the wireless telephone network, and may be illegal.
Potentially explosive environments
Switch off your device when in any area with a potentially explosive atmosphere, and obey all signs and instructions.
Potentially explosive atmospheres include areas where you would normally be advised to turn off your vehicle engine. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Switch off the device at refueling points such as near gas pumps at service stations. Observe restrictions on the use of radio equipment in fuel depots, storage, and distribution areas; chemical plants; or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include below deck on boats, chemical transfer or storage facilities, vehicles using liquefied petroleum gas (such as propane or butane), and areas where the air contains chemicals or particles such as grain, dust, or metal powders.
111 Copyright ©2006 Nokia All right reserved
A d d i t i o n a l S a f e t y I n f o r m a t i o n
Emergency calls
Important: Wireless phones, including this device, operate using radio signals, wireless networks, landline networks, and user-programmed functions. Because of this, connections in all conditions cannot be guaranteed.
You should never rely solely on any wireless device for essential communications like medical emergencies.
To make an emergency call
1. If the device is not on, switch it on. Check for adequate signal strength. Some networks may require that a valid SIM card is properly inserted in the device.
2. Press the key as many times as needed to clear the display and ready the device for calls.
3. Enter the official emergency number for your present location. Emergency numbers vary by location.
4. Press the key.
If certain features are in use, you may first need to turn those features off before you can make an emergency call. Consult this guide or your service provider for more information.
When making an emergency call, give all the necessary information as accurately as possible. Your wireless device may be the only means of communication at the scene of an accident.
Do not end the call until given permission to do so.
Copyright ©2006 Nokia All right reserved 112
A d d i t i o n a l S a f e t y I n f o r m a t i o n
Certification information (SAR)
THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE
TO RADIO WAVES
Your mobile device is a radio transmitter and receiver. It is designed and manufactured not to exceed the limits for exposure to radio frequency (RF) recommended by international guidelines
(ICNIRP). These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines were developed by independent scientific organisations through periodic and thorough evaluation of scientific studies. The guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for mobile devices employs a unit of measurement known as the Specific Absorption Rate, or SAR. The
SAR limit stated in the international guidelines is 2.0 watts/ kilogram (W/kg)*. Tests for SAR are conducted using standard operating positions with the device transmitting at its highest certified power level in all tested frequency bands. Although the
SAR is determined at the highest certified power level, the actual
SAR of the device while operating can be well below the maximum value. This is because the device is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a base station, the lower the power output of the device.
The highest SAR value for this device when tested for use at the ear is 0.69 W/kg. SAR values may vary depending on national reporting and testing requirements and the network band. Use of device accessories and enhancements may result in different SAR values. Additional SAR information may be provided under product information at www.nokia-asia.com.
* The SAR limit for mobile devices used by the public is Testing measurement or terms. The guidelines incorporate a substantial margin of safety to give additional protection for the public and to account for any variations in measurements. SAR values may vary depending on national reporting requirements and the network band. For SAR information in other regions please look under product information at www.nokia.com.
113 Copyright ©2006 Nokia All right reserved
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
Related manuals
advertisement
