User Guide

INTRODUCTION

HDMI................................................................................................................................................5

SAFETY IS IMPORTANT.................................................................................................................5

IN THE BOX.....................................................................................................................................5

SAFETY INFORMATION

KEEP THIS INSTRUCTION.............................................................................................................6

IMPORTANT.....................................................................................................................................6

ELECTRICAL INFORMATION.........................................................................................................7

TV FUNCTIONS / TV CONNECTORS

TV FRONT CABINET FUNCTIONS.................................................................................................8

TV CONNECTIONS.........................................................................................................................9

CONNECTING THE TV ANTENNA...............................................................................................10

CONNECTING EXTERNAL DEVICES..........................................................................................10

CONNECTING DIAGRAM..............................................................................................................11

COMMON INTERFACE SLOT

COMMON INTERFACE.................................................................................................................12

WALL MOUNTING

WALL MOUNTING.........................................................................................................................13

REMOTE CONTROL

REMOTE CONTROL.....................................................................................................................14

REMOTE BUTTONS.....................................................................................................................15

BATTERY INSTALLATION............................................................................................................17

LET’S START

SWITCHING ON............................................................................................................................18

SELECTING SOURCE OPERATION............................................................................................18

FIRST TIME INSTALLATION.........................................................................................................19

CHANNEL LIST.............................................................................................................................19

ANALOGUE TV GUIDE

TV INFORMATION........................................................................................................................21

PICTURE.......................................................................................................................................21

SOUND..........................................................................................................................................22

SETTING.......................................................................................................................................23

FUNCTION....................................................................................................................................23

CHANNEL.....................................................................................................................................25

TELETEXT FUNCTION

TELETEXT FUNCTION.................................................................................................................27

DIGITAL TV GUIDE

CHANNEL......................................................................................................................................29

MANUAL PROGRAM.....................................................................................................................29

PROGRAM EDIT...........................................................................................................................30

CI MENU........................................................................................................................................32

TIMER............................................................................................................................................33

EPG...............................................................................................................................................34

SUBTITLE......................................................................................................................................34

FAV.................................................................................................................................................35

VGA & PC SETUP

PC SETUP.....................................................................................................................................36

PICTURE.......................................................................................................................................37

MULTIMEDIA & USB PVR FUNCTIONS

MULTIMEDIA.................................................................................................................................38

MY ALBUM....................................................................................................................................38

MY MUSIC.....................................................................................................................................39

MY MOVIE.....................................................................................................................................40

MY RECORDER............................................................................................................................40

USB PVR RECORDING & PLAYBACK FUNCTION.....................................................................42

PVR TIME SHIFT...........................................................................................................................42

USB PVR FUNCTION ATTENTIONS............................................................................................43

DVD OPERATION

BASIC OPERATION......................................................................................................................44

SUPPORTING DVD FORMAT.......................................................................................................45

DVD FUNCTIONS OPERATING INSTRUCTIONS.......................................................................46

M

P3 / JPEG PLAYBACK...............................................................................................................48

FUNCTION SETTINGS.................................................................................................................49

DVD FUNCTION GENERAL SETUP.............................................................................................49

SYSTEM SETUP...........................................................................................................................49

LANGUAGE SETUP......................................................................................................................52

AUDIO SETUP...............................................................................................................................53

DOLBY DIGITAL SETUP................................................................................................................54

CARE AND MAINTENANCE.........................................................................................................55

TROUBLESHOOTING

DISPLAY TROUBLESHOOTING...................................................................................................56

SOUND AND TV TROUBLESHOOTING.......................................................................................56

DVD TROUBLESHOOTING..........................................................................................................57

SPECIFICATIONS

SPECIFICATIONS.........................................................................................................................58

DISPLAY MODE

ANALOGIC RGB FORMAT TABLE...............................................................................................59

YPBPR FORMAT TABLE...............................................................................................................59

ADDITIONAL INFORMATION

DISPOSAL....................................................................................................................................60

WARRANTY...................................................................................................................................60

HD Ready 1080p LCD/DVD TV

User Guide

Power Cable

Remote Control

2 x AAA Batteries

TV FRONT CABINET FUNCTIONS

TV Function / TV Connectors

3. Mains Power Switch -

Completely turns ON or OFF the power to the TV set to save on electricity.

Sencor Touch Keyboard (controlled by a soft finger touch)

LABEL SIDE

12

13

5

6

7

TV CONNECTIONS

TV Function / TV Connectors

1

2

3

4

8

9

10

11

14

1. 12V DC power input

(intended for feeding to the TV

using a car battery power or

external 12V DC power

supply adapter)

2. HDMI input

3. PC VGA input

4. PC audio input

5. AV Video input

6. AV Right audio input

7. AV Left audio input

8. Y input

9. Pb input

10. Pr input

11. USB connector

12. SCART connecting terminal

13. SPDIF output

14. CI connector

15. TV signal input (TV Aerial input)

16. Audio Earphone output

15

16

TV Function / TV Connectors

(CVBS / YPbPr cables)

You can connect this TV to a compatible device using CVBS and YPbPr cables.

Connect the red, white and yellow (CVBS) or the red, green and blue (YPbPr) outputs to the matching coloured inputs on the compatible device. An additional audio input is required.

TV Function / TV Connectors

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

8

9

4

5

6

7

14

15

16

17

18

19

20

21

22

23

24

10

11

12

13

1

2

3

SOURCE

ATV

DTV

HDMI

SCART

YPBPR

AV

VGA

DVD

INPUT

FIRST TIME INSTALLATION

ENGLISH

UK

CHANNEL LIST

Analogue (ATV) Setup

Between now and the end of 2012 the UK will be turning off all old “analogue” TV transmitters and switching your

TV signal to “digital”. Digital TV offers new ways to enjoy your TV. You will have a greater choice of TV channels as well as access to additional features and services which will enhance your TV-watching experience. This

LCD TV features a built-in Freeview Digital Tuner - please refer to the DTV section of this instruction on page 28.

TV Information

Analogue (ATV) Setup



PICTURE MODE

CONTRAST

BRIGHTNESS

COLOR

TINT

SHARPNESS

COLOR TEMP.

NOISE REDUCTION

STANDARD

50

50

50

50

6

NORMAL

ON

MOVE

SELECT MENU

EXIT

Analogue (ATV) Setup

SOUND MODE

BASS

TREBLE

BALANCE

AVL

MOVE

SOUND

STANDARD

50

50

50

ON

SELECT

MENU

EXIT

S E T T I N G

Analogue (ATV) Setup

LANGUAGE

OSD TIMER

TRANSPARENCE

OVERSCAN

RESET

SETTING

ENGLISH

15 SEC

80

ON

MOVE

SELECT MENU

EXIT

FUNCTION

SLEEP TIMER

ASPECT

TT LANGUAGE

BLUE SCREEN

SYSTEM LOCK

FUNCTION

OFF

FULL

WEST

ON

MOVE SELECT

MENU

EXIT

Analogue (ATV) Setup

SYSTEM LOCK

CHILD LOCK

KEY LOCK

PARENTAL

CHANGE CODE

MOVE

FUNCTION

ON

ON

ON

ON

SELECT

MENU

EXIT

ENTER PASSWORD

*

C H A N N E L

Analogue (ATV) Setup

COUNTRY

AUTO SEARCH

MANUAL PROGRAM

PROGRAM EDIT

CHANNEL

UK

MOVE

SELECT MENU

EXIT

PROGRAM

COLOR. SYS

SOUND. SYS

MANUAL SEARCH

AFT

FINE

SKIP

CHANNEL

1

AUTO

AUTO

192.25 MHz

ON

OFF

MOVE

SELECT MENU

EXIT

Analogue (ATV) Setup

05

06

07

08

09

10

01

02

03

04

NAME

INSERT

MOVE

PROGRAM EDIT

15

16

17

18

11

12

13

14

19

20

25

26

27

28

21

22

23

24

29

30

LOCK

FAV

MENU

EXIT

TELETEXT FUNCTION

Digital TV Setup

If the TV finds some, but not all, of the Digital channels, the TV is functioning correctly but the signal being received is not strong enough. (The signal strength needs to be above 85% - you can see the signal strength the TV is receiving when you search channels/ programmes) you will need to increase the signal reception in order to receive all of the channels available.

The most economical way to do this is by purchasing and connecting a 'signal booster' in between the TV and the TV aerial socket. If this does not solve the problem, you will need to upgrade the TV aerial to a digital hi-gain compatible aerial.

C H A N N E L

CHANNEL

COUNTRY

LCN

AUTO SEARCH

MANUAL PROGRAM

PROGRAM EDIT

CI MENU

TIMER

MOVE

UK

SELECT MENU

EXIT

CHANNEL

PROGRAM

START SEARCH

CHANNEL FOUND

SIG. QUALITY

SIG. STRENGTH

FREQUENCY

22

BEGIN

0

0

0

474.00

MOVE

SELECT MENU

EXIT

Digital TV Setup

Digital TV Setup

Digital TV Setup

Digital TV Setup

Digital TV Setup

Digital TV Setup

Digital TV Setup

PC SETUP

H-POSITION

V-POSITION

CLOCK

PHASE

AUTO ADJUST

PC SETUP

50

100

100

97

MOVE

SELECT MENU

EXIT

VGA & PC Setup


PICTURE MODE

CONTRAST

BRIGHTNESS

COLOR TEMP.


STANDARD

50

50

50

MOVE

SELECT MENU

EXIT

VGA & PC Setup

Multimedia & USB PVR Function

Multimedia & USB PVR Function

Multimedia & USB PVR Function

Multimedia & USB PVR Function

Multimedia & USB PVR Function

USB PVR RECORDING & PLAYBACK FUNCTION

USB PVR Recording

PVR Time Shift

Multimedia & USB PVR Function

PVR Recording

USB PVR Function

Important Information About USB PVR Function

You can purchase high speed memory sticks from most Electrical or PC stores.

Before making your purchase please confirm the memory stick meets the minimum specifications as below:

Read Speed 20MB/s (Mega Byte Per Second)

Write Speed 6 MB/s (Mega Byte Per Second)

BASIC OPERATION

1. Turn ON and OFF the DVD function

- Turn on the LCD TV and then press INPUT repeatedly to select DVD mode.

2. Insert Disc to DVD

- Insert the Disc to the Disc slot (mirror (record) side of the disc has to face towards front of the unit), the player will load the disc automatically.There will have an on screen indication “

CLOSE

” then

“LOADING”. After loading the disc content, it will switch to play mode automatically. If the disc is already placed inside, the disc will be read automatically.

NOTE: - For some discs, after loading the content of the disc, need to press or select from the disc

menu to start.

- Please make sure when inserting the Disc, the mirror (record) side of the disc should be

facing you.

When inserting the Disc incorrectly, you may damage the DVD mechanism.

To eject the DVD Disc press:

DVD EJECT

(Valid in DVD mode)

3. Play the DVD

- According to the disc content, the disc menu will display for your selection. When playing the disc, you may use button to toggle between Play and Pause mode. This product also supports Menu,

Title, Sequential and Program playback.

4. Menu playback (for DVD/ super VCD and VCD 2.0 discs)

- Press D.MENU button

For DVD discs, the screen will display the DVD Disc Menu (Root Menu)

For Super VCD & VCD2.0 discs, the screen will display the Super VCD, VCD2.0 Disc Menu (PBC:

[OFF])

(Press the D.MENU button to display the PBC status).

Playback the Super VCD & VCD2.0 discs, the default PBC status is ON.

-

For DVD discs, use the navigation buttons to select and Play the highlighted contents; For Super

VCD & VCD2.0 discs, use the numeric buttons to play your favorite content directly.

NOTE: PBC should be OFF.

- Press OK or button to start from the highlighted content.

- Return to the Root Menu when playing the disc

For DVD discs, press D.MENU to display the Disc Menu.

For Super VCD & VCD2.0 discs, when PBC is ON, press D.MENU to display the Disc Menu

.

- STOP

Press button once to stop. Press button to resume from where you stopped.

Press button Twice to stop. Press button to start from beginning.

In order to protect the disc, press button then press EJECT button to take the disc out. When the

disc is ejected, hold the disc edge slightly and take it from the eject direction to prevent scratches.

When not using the DVD function (in stand-by mode or using others modes for a long time), please

take out the disc to protect the DVD loader and the disc.

5. Title playback (for DVD disc only)

- Press TITLE button, there will have an on screen indication “Title Menu”.

- Press the direction or numeric buttons to select your favorite title.

- Then will play from the first chapter of the selected title.

6. Sequential playback (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs

- For Super VCD & VCD discs, if PBC is “ON” status, press button will enter the disc menu. Press

D.MENU button to turn PBC OFF. Press button to start in sequent. For others, while it stopped,

press button to start in sequent.

7. Program playback (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs

- Using Program playback, you can select max. 16 tracks from the disc to playback in programmed

order.

- OSD for program playback as below.

DVD / MP3 / JPEG discs

Super VCD/ VCD/ CD /CD-G/ D-CD discs

PROG PROG

T C T C T C T C

1 : 5 : 9 : 13 :

2 :

3 :

4 :

6 :

7 :

8 :

10 :

11 :

12 :

14 :

15 :

16 :

2

[--]

5

[--]

7

[--]

9

11

[--]

[--]

14

[--]

[--]

16

PLAY CLEAR PLAY CLEAR

-

If it is in PBC ON status, using program playback will turn to PBC OFF automatically.

- According to the highlight area input the title and chapter number by numeric buttons, press button

to start; or move to the <PLAY> by navigation buttons, press OK button to start.

-

While playing the program, you may press PROGRAM button to display the program menu for edit. To clear the program by moving to <CLEAR> and press OK button. Or press button to end the program. When press button again, the disc will play by sequent.

- While playing the program, there will have an on screen indication “PRG PLAY” and the current title and chapter number

.

SUPPORTING DVD FORMAT

This products can play the following format of DVD disc.

Disc Type

Disc Size (Diameter

)

Recorded Time

Single side:120mins. Approx

DVD 12cm

Double side:240mins. Approx

Super VCD

12cm 45mins. Approx

Recorded Content

DVD format:

Compressed digital audio and video

MPEG2

Compressed digital audio and video

VCD 12cm

74mins. Approx

MPEG1

Compressed digital audio and video

Remarks

Include SVCD

Include:

VCD2.0/ VCD1.1

VCD1.0/ DVCD

CD

HD-CD

MP3/JPEG

12cm

12cm

12cm

74mins. Approx

74mins. Approx

600mins. Approx

CD-DA: Digital audio

HD-DA: Digital audio

Digital audio

NOTE: Also support DVD-R, CD-R, CD-RW playback.

WARNING! DO NOT INSERT OR PLAY 8CM DISC, THEY WILL GET STUCK.

Region Code

As it is usual for DVD movies to be released at different times in different regions of the world, all players have region codes and discs can have an optional region code. If you load a disc of a different region code into your player you will see the region code notice on the screen. The disc will not playback and should be unloaded.

ALL 2 1 2

1

3

2

4

DVD FUNCTIONS OPERATING INSTRUCTIONS

1. Play (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs)

-

For DVD disc, press button from root or title menu; while playing the DVD, you may play your favorite

title directly with title selection by pressing the TITLE button.

- For Super VCD & VCD discs, while playing the disc, you may play your favorite tracks by numeric buttons.

(NOTE: When using the Program playback or when it is PBC ON status, you can only use or buttons

to change the track)

- For CD, CD-G & HD-CD discs, while playing the disc, you may play your favorite tracks by numeric buttons.

- For MP3 / JPEG disc, you may play your favorite tracks by numeric buttons from the content menu.

- If input track number is not valid, it will not function.

NOTE: From track 1-10, use numeric buttons directly; For tracks over 10, use numeric buttons directly or press - / -- button first(E.g. Track 15, press - / -- then 5)

2. Previous/Next (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs)

-

While playing the disc;

Press button to play to the last Title / Chapter / track.

Press button to play to the next Title / Chapter / track

- For super VCD & VCD discs, in PBC OFF status;

If the current track is the first one, press button will stop the playback.

If the current track is the last one, press button will stop the playback

.

- For DVD discs, the above functions may vary due to different DVD disc's structure

.

3. Forward/ Backward (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs)

- While playing the disc, you may use forward or backward function

.

-

There are 5 speeds for forward or backward . Press / button to toggle between different speeds in sequent. (FFx2 /FFx4 / FFx8 / FFx16 / FFx32 / Play, or FRx2 /FRx4 / FRx8 / FRx16 / FRx32 / Play).

While in forward or backward, you may press to resume normal speed.

For CD, HD-CD, Mp3, forward or backward also has audio output.

For DVD discs, if backward to first title / chapter, it will start from the beginning.

For Super VCD & VCD discs, in PBC ON status, if backward to the first track, it will start from the beginning

.

NOTE: During Forward or Backward, the sound will be off.

4. Slow motion(for DVD/ Super VCD/ VCDdiscs

)

- While playing the disc, you may use slow motion function

.

There are 5 speeds for slow motion. Press button to toggle between different speeds in sequent.

(SF1/2, SF1/4, SF1/8, SF1/16, SF1/32, Play).

While in slow motion, you may press to resume normal speed.

NOTE: During Slow motion, the sound will be off

.

5. Pause (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs)

- FOR CD, CD-G, HD-CD & MP3/JPEG discs, press button to pause; press button to resume.

- FOR DVD, Super VCD, VCD discs, press button to pause; press button to playback frame by

frame; press button to resume.

6. Repeat (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs)

- Press REPEAT button once to display the current repeat mode

.

For Super VCD, VCD, CD, CD-G, HD-CD, discs, while playing in sequent, you may use the repeat playback.There are 2 repeat modes, press REPEAT to toggle between different modes in sequent.

(REPEAT (OFF)/ REPEAT (1)/REPEAT (ALL)).

For DVD discs, you may setup the repeat playback mode. There are 2 repeat modes, press REPEAT to toggle between different modes in sequent. (REP: (OFF) / REP: (CHAPTER) / REP: (TITLE) / REP:

(ALL)).For MP3 / JPEG discs, while playing the disc, you may use the repeat playback. There are 3 repeat modes, press REPEAT to toggle between different modes in sequent. (REPEAT (OFF) /

REPEAT (1) / REPEAT (DIR) / REPEAT (ALL)).

7. Display (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs)

- Press D.DISP button to activate the on screen roll-down menu for the current Title, Chapter, time and other information.

For DVD discs, (2 pages) Press D.DISP button once to display first page as shown below

:

Disc Type Elapsed disc time

DVD TT 0/3 CC 1 / 2 Title Elapsed 00:05:45

Tiltle -/- (Current/ Full)

Press

D.DISP

button again to display second pages shown below:

Language Angle ON/OFF

:English 1/1 :Others1/2 AC3 2CH :OFF

Subtitle -/-(Current/Full)or OFF -/- (Current/ Full) or OFF

For Super VCD discs, (2 pages),Press

D.DISP

button once to display first page: Disc type, Track -/-

(Current / Full), Mute status, PBC status, Repeat mode status, Current track time. Press D.DISP button again to display second page: Audio-/--(Current/Full) or OFF, Audio type, Language, Subtitle

-/-(Current/Full) or OFF. Press D.DISP button again to turn off the on screen display.

For CD, CD-G, HD-CD, MP3 / JPEG discs, Press

D.DISP

button once to display first page: Disc type,

Track -/- (Current / Full), Mute status, Repeat mode status, Current track time.

- Press

D.DISP

button again to turn off the on screen display.

8. Goto (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs)

- This function allows you to play your favorite Title / Chapter / track. Press GOTO button to activate the

on screen scroll-down menu for edit. According to the highlighted area, input your favorite Title /

chapter / Track number by numeric buttons or input the playback time. After editing, press OK to

start. If the input is invalid, it will not function

.

NOTE: While editing, the GOTO button is not function.

- If it is in PBC ON status, this function will switch it to OFF.

- For Mp3/JPEG discs, use numeric buttons directly to select your favorite songs or pictures

.

9. AUDIO (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs)

- Press AUDIO button once to display current audio mode

.

- Press again to toggle between different audio modes in sequent

.

For Super VCD & VCD, CD, CD-G, HD-CD, MP3 discs: (L/L , R/R , STEREO, MIX MONO)

NOTE: Switching to Auto L / R audio channel may be varied due to different discs contents. Bilingual

VCD discs can use AUDIO button to switch between different languages.

10. Language (for DVD and Super VCD discs)

- Press AUDIO button once to display current language.

- Press again to toggle between different languages mode in sequent.

NOTE: For Multi-languages DVD & Super VCD discs, press AUDIO button to select your favorite language.

11. Subtitle (for DVD and Super VCD discs)

- Press SUBTITLE button once to display current sub-title.

- Press again to toggle between different subtitle modes in sequent.

NOTE: For Multi-languages subtitle DVD & Super VCD discs, press SUBTITLE button to select your

favorite subtitle language.

12. Angle (for DVD disc)

- Press ANGLE button once to display current playback angle.

- Press again to toggle between different playback angle codes in sequent. (E.g. Angle -/- (Current/Full) or OFF)

NOTE: Only for DVD with multi-angle, press ANGLE button to select your favorite playback angle.

Selectable playback angle depends on the availability of the DVD contents.

13. Mute (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs

)

- Press MUTE button to mute the audio output. There will have an on screen symbol indicate “MUTE”.

- Press again to cancel, or Press VOL + to cancel and adjust the volume.

- In case there is no audio output, try to press MUTE button to cancel mute.

14. ZOOM / and JPEG discs)

- Press ZOOM button to zoom in the picture.

- There are 3 zoom modes, press ZOOM button to toggle between different zoom modes in sequent.

(Zoom OFF, Zoomx2 , Zoomx4)

- In Zoomx2 and Zoomx4, you may use the navigation buttons to pan the picture for your favorite portion.

15. A- B (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs)

- In normal Playback, fast forward or fast reverse, press A-B button at where you want to start the

repeat portion. There will have an on screen indication “REPEAT A “.

- In normal Playback, fast forward or fast reverse, press A-B button again at where you want to stop

the repeat portion. There will have an on screen indication “REPEAT A B“.

- The repeat function started to playback the portion from A to B automatically.

- Press A-B button again to cancel. There will have an on screen indication “REPEAT OFF”.

For Super VCD, VCD & CD discs, repeat A-B is only function within the same track. When playing the others, repeat A-B will cancel automatically.

For Super DVD discs, repeat A-B is only function within the same Title /Chapter. When playing the others, repeat A-B will cancel automatically.

16. Volume (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs)

- Press - VOL / VOL + buttons to adjust the output volume.

NOTE: Playback DVD discs in original code, is not adjustable

17. INTRO (for Super VCD/ VCD/ CD/ CD-G/ HD-CD

)

- Intro/Scan/ 9 picture displays

.

MP3/JPEG PLAYBACK

After loading the MP3 / JPEG disc, it will start to scan for the stored MP3 /JPEG folders. Then will firstly display the MP3 contents automatically. Screen as follow:

Display current

MP3 playback function

Display the selected file’s content.

File Number: 1/16

Disc

01 MP3

01

02

03

04

05

06

07

08

09

10

Highlight file for current playback.

Display current

JPEG playback function

File Number: 1/16

Disc

01 PICTURE

01

02

03

04

05

06

07

08

09

10

Scroll bar to view next page.

- Using the navigation buttons to check you favorite folder and playback the first file or move to the

your favorite file.

NOTE:

- Press / buttons to move the highlight to folders, documents or mode selection.

- Press numeric buttons to select the contents directly. For number over 10, use numeric buttons

directly or press - / -- button first(E.g. Track 15, press - / -- then 5)

- When playback MP3 files, there is no picture display, only audio output

.

- Playing the JPEG discs, press PROGRAM button to select slide effects. There are 10 slide modes,

press PROGRAM button to toggle between different modes in sequent. (Start from top, Start from

bottom, Start from left, Start from right, Start from upper left corner, Start from four corners, etc)

- When play or pause with picture playback, you may use navigation butoons to flip / rotate the picture

.

button to flip horizontally.

button to flip vertically.

button to rotate left 90°.

button to rotate right 90°.

- When play or pause with picture playback, Press / button to select next / previous page or press numeric buttons to view the corresponding pictures.

FUNCTION SETTINGS

DVD Function General setup

SYSTEM SETUP

SOURCE

TV SYSTEM

TV TYPE

PASS WORD

RATING

DEFAULT

EXIT SETUP

- Press DVD SETUP button to activate the DVD player

OSD menu;

- Press / button to move and highlight between

different sub-menu. Press / OK button to

enter the highlighted sub-menu.

- Press DVD SETUP button to exit the OSD menu, or

move the highlight to EXIT SETUP then press OK

button to exit

.

NOTE: In Setup mode, the following functions will be cancel or pause :

TITLE, SUBTITLE, DISPLAY, PLAY, SETUP, STOP, SLOW / STEP, AUDIO, F.FWD, F.REV, PREV,

NEXT, GOTO, ZOOM, ANGLE, PROGRAM, PREVIEW, REPEAT, A-B

.

System Setup

SOURCE

Select according to what type of media you want to playback:

(DISC, USB, CARD)

Default setting is AUTO.

CARD and USB options is unavailable

.

SYSTEM SETUP

SOURCE

TV SYSTEM

TV TYPE

PASS WORD

RATING

DEFAULT

EXIT SETUP

AUTO

DISC

USB

CARD

TV SYSTEM

This menu enables you to set the picture format for your

TV/DVD

.

NTSC

This format is used by some other countries, e.g. USA

PAL

This is the format used in the EUROPE and the default setting

.

AUTO

This format can be used if your TV/DVD is capable of both

PAL and NTSC formats.

SYSTEM SETUP

SOURCE

TV SYSTEM

TV TYPE

PASS WORD

RATING

DEFAULT

EXIT SETUP

NTSC

PAL

AUTO

NOTE: PAL format is generally used for TVs in the EUROPE. Check your TV user guide for

supported formats.If NTSC is selected

with a non-compatible television you

may experience interference or picture

scrolling

.

TV TYPE

DVDs are produced in a variety of screen aspect ratios. This menu enables you to select one of the three aspect ratios

:

SYSTEM SETUP

SOURCE

TV SYSTEM

TV TYPE

PASS WORD

RATING

DEFAULT

EXIT SETUP

4:3PS

4:3LB

16:9

4:3 PS

4:3 LB

16:9

- Select the most appropriate aspect

ratio for the DVD being viewed.

4:3PS

Pan and Scan is used for most normal television broadcasts and it is the default setting. It has an aspect ration of 4:3. If you select this setting when viewing a DVD the picture will fill the screen but, you will not see the left and right edges of the picture.

4:3LB

Letter Box will show the DVD in its original aspect ratio so depending on the size of your television screen, you may see black borders above and below the picture

.

16:9

Choose this setting if you have a widescreen television

.

NOTE:

- Playback screen size may vary according to the discs contents.

- For discs with 4:3 contents, using any mode would only display a 4:3 screen

- Screen ratio selection should be according to the connected TV / Display

aspect ratio

.

PASSWORD

- The default setting is locked. No Rating selection or change password could be done. To edit the Rating setting, please enter default password “8888” by numeric buttons, then press OK button to confirm

.

SYSTEM SETUP

SOURCE

TV SYSTEM

TV TYPE

PASSWORD

RATING

DEFAULT

- To change password, input any 4 digit number when

the lock is unlocked. Once the 4 digit number is entered,

that will be your new password

.

EXIT SETUP

SYSTEM SETUP

SOURCE

TV SYSTEM

TV TYPE

PASSWORD

RATING

DEFAULT

EXIT SETUP

1 KID SAFE

2 G

3 PG

4 PG13

5 PG-R

6 R

7 NG.17

8 ADULT

RATING

- Playback for some discs with rating, you can select the rating setting according to your preference. Rating restriction divided in eight different category from KID

SAFE to ADULT.This option is valid when you press stop button twice to playbac and then enter setup menu

.

NOTE: Only editable when password is unlocked. And only

can function when password is locked. It does not,

however, reset either the Password or the Rating

setting.

DEFAULT SETTING

- Press OK button to restore factory default

.

SYSTEM SETUP

SOURCE

TV SYSTEM

TV TYPE

PASSWORD

RATING

DEFAULT

EXIT SETUP

RESTORE

Language Setup

Press SETUP button to enter the DVD OSD menu.

LANGUAGE SETUP

OSD LANGUAGE

AUDIO LANG

SUBTITLE LANG

MENU LANG

EXIT SETUP

ENGLISH

GERMAN

SPANISH

FRENCH

PORTUGUESE

ITALIAN

- OSD Language

Use navigation buttons to select the OSD LANGUAGE

setup icon, press OK button to confirm. There are few

languages for your selection, press / buttons to

toggle between different languages.

NOTE: If the selected language is not included in you

DVD disc content, it will select the default

language of the disc automatically. The default

language setting is English

.

- Audio Language

Use navigation buttons to select the AUDIO LANG setup icon, press OK button to confirm. There

are 6 languages for you selection, press / buttons to toggle between different languages.

(ENGLISH / GERMAN / SPANISH / FRENCH / PORTUGUESE / ITALIAN ).

Press OK button to confirm.

LANGUAGE SETUP

OSD LANGUAGE

AUDIO LANG

SUBTITLE LANG

MENU LANG

EXIT SETUP

ENGLISH

GERMAN

SPANISH

FRENCH

PORTUGUESE

ITALIAN

NOTE: -If the selected language is not included in your DVD disc content, it will select the default language of the

disc automatically. The default language setting

is English.

-Only valid when you press stop button twice to

playback and then enter setup menu.

- Subtitle Language

Use navigation buttons to select the SUBTITLE LANG setup icon, press OK button to confirm.

There are 6 languages for you selection, press / buttons to toggle between different languages.

(ENGLISH / GERMAN / SPANISH / FRENCH / PORTUGUESE / ITALIAN / OFF) Press OK button

to confirm.

LANGUAGE SETUP

OSD LANGUAGE

AUDIO LANG

SUBTITLE LANG

MENU LANG

EXIT SETUP

ENGLISH

GERMAN

SPANISH

FRENCH

PORTUGUESE

ITALIAN

OFF

NOTE: If the selected language is not included in you DVD disc content, it will select the default language

of the disc automatically. The default language setting is ENGLISH.Only valid when you press

stop button twice to playback and then enter setup menu..

MENU Language

LANGUAGE SETUP

OSD LANGUAGE

AUDIO LANG

SUBTITLE LANG

MENU LANG

EXIT SETUP

ENGLISH

GERMAN

SPANISH

FRENCH

PORTUGUESE

ITALIAN

- Use navigation buttons to select the MENU LANG setup

icon, press OK button to confirm. There are 6

languages for you selection, press / buttons to

toggle between different languages. (ENGLISH /

GERMAN / SPANISH / FRENCH / PORTUGUESE /

ITALIAN ) Press OK button to confirm.

- Only valid when you press stop button to playback and

then enter setup menu.

Audio Output

AUDIO OUT

TONE

AUDIO SETUP

SPDIF/OFF

SPDIF/RAW

SPDIF/PCM

EXIT SETUP

Audio Setup

- Use navigation buttons to select the AUDIO OUT setup

icon, press OK button to confirm.

- There are 3 modes for your selection; use navigation

buttons to select different modes, press OK button

to confirm.

(SPDIF / OFF SPDIF / RAW SPDIF / PCM)

.

- SPDIF / OFF: Coaxial output off.

- SPDIF / RAW: When connected the coaxial output to your audio amplifier, playing back the discs with

Dolby, MPEG contents, the coaxial outputs the original signal to your amplifier. Your Amplifier must

have the corresponding decoding function.

- SPDIF / PCM: When connected with 2 channels digital stereo amplifier, playing back the discs with

Dolby, MPEG contents the coaxial outputs with 2 channel to your amplifier.

Tone

- Use / buttons to adjust the Tone setting.

AUDIO OUT

TONE

AUDIO SETUP

EXIT SETUP b

#

+4

+2

+0

-2

-4

Dolby Digital Setup

Dynamic Range

DIGITAL SETUP

DYNAMIC RANGE

DUAL MONO

EXIT SETUP

FULL

6 / 8

4 / 8

2 / 8

OFF

- When switch the compress mode to “Audio output”,

adjust the compress ratio for different effect. When

selected FULL, the peak signal value is smallest.

When selected OFF, the peak signal value is biggest.

Dual Mono

DIGITAL SETUP

DYNAMIC RANGE

DUAL MONO

EXIT SETUP

STEREO

MONO L

MONO R

MIX MONO

- You can select four different audio output, STEREO,

MONO L, MONO R, MIX MONO. The audio out

description of these Selections is shown in the table

below.

MODE LEFT SPEAKER RIGHT SPEAKER

STEREO STEREO-L STEREO-R

L-MONO L-MONO L-MONO

R-MONO R-MONO R-MONO

MIX-MONO L-MONO+R-MONO L-MONO+R-MONO

CARE AND MAINTENANCE

Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will have your new TV. Be sure to turn the power off and unplug the power cord before you begin any cleaning.

Cleaning the screen

1. Here’ s a great way to keep the dust off your screen for a while. Wet a soft cloth in a mixture of

lukewarm water and a little fabric softener or dish washing detergent. Wring the cloth until it’s almost

dry, and then used it to wipe the screen.

2. Make sure the excess water is off the screen, and then let it air-dry before you turn on your TV.

Cleaning the cabinet

To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth. Please be sure not to use a wet cloth

.

Extended Absence

Teletext operation

unplug the power cord to protect against possible damage from lightning or power surges

.

If you expect to leave your TV dormant for a long time (such as a vacation), it’s a good idea to unplug the power cord to protect against possible damage from lightning or power surges.

Handing Discs

1. To remove a disc from its storage case, press on the centre of the case and take the disc out.

2. Hold the disc by the edges, to avoid touching the Recorded side of the disc

.

Cleaning discs

1. Fingerprints and dust should be carefully wiped from the disc's surface with a soft Cloth.

Audio discs and DVD discs have no grooves to collect dust and microscopic debris so gently

wiping with a soft cloth should remove most particles. Wipe in a straight line from the inside

to the outside of the disc. Small dust particles and light stains should have no effect on

reproduction quality.

2. Never use chemicals such as record sprays, antistatic sprays, Benzine, or thinners to clean

the discs. These chemicals can irreparably damage the disc's surface.

3. Discs should be returned to their cases after use. This avoids serious scratches that could

cause the laser pickup to skip.

4. Do not expose discs to direct sunlight, high humidity, or high temperature for extended periods.

Exposure to high temperatures can warp the disc

.

5. Do not stick paper or write anything with a ball point pen on the label side of the disc

.

23.6" : 60cm

23.6" : 1920 x 1080

Video format CVBS / RGB / YPbPr / VGA
