Network Camera
/ /
Installation Guide
/
BIE-7029-000
ENGLISH
Notes on Privacy and Publicity Rights Regarding the Use of Video/Audio
When using the camera (for video or audio recording), it is the full responsibility of the user to protect privacy and avoid any violation of publicity rights. For example, obtain consent to install the camera in advance if specific buildings or rooms are to be monitored. Canon shall have no liability whatsoever in this regard.
Legal Notice
In some cases, camera monitoring may be prohibited by law or regulation, the details of which differ by country or region. Before using the camera, check the laws or regulations of the country or region where the camera is used.
Thank you for purchasing a Canon Network Camera (hereafter referred to as the camera).
VB-H630D/VB-M620D is designed for indoor use only. It is also possible to install the VB-H630VE/
VB-M620VE outdoors, such as underneath eaves.
Be sure to read “Installation Guide” (this document) and “Operation Guide” (included in the Setup
CD-ROM) before use.
This “Installation Guide” explains the installation method for installing the camera on a ceiling or wall and the installation method using the separately sold junction box mounting kit PS600-VB. Be sure to read the “Safety Precautions” section for correct use. After reading this Installation Guide, keep it in a readily accessible location for future reference.
For the installation of this camera recessed into a ceiling or wall using the recessed mounting kit
(sold separately), please read the “Recessed Mounting Kit SR600-VB Installation Guide” included with the recessed mounting kit.
When using the heater unit (sold separately), please read the “Heater Unit HU600-VB User
Manual” included with the heater unit.
The detailed procedures for using this camera are explained in the “Operation Guide”. Read these guides carefully before using the camera to ensure correct use.
* For the latest information (firmware and included software, user manuals, operating environment, etc.), please refer to the Canon Web Site.
* Some cameras are not sold in some countries or regions.
WARNING
To reduce a risk of fire or electric shock, do not expose this product to rain or moisture.
Caution
Request a professional installer for all camera installation work.
Never try to install the camera yourself. Doing so may result in unforeseen accidents such as dropping the camera or electric shock.
Write the serial number and MAC address of the camera (printed on the seal at the bottom of the camera) in the field below before storing this Installation Guide in a safe location.
Serial number
MAC Address
_________________________________
_________________________________
© CANON INC. 2014 Printed in Taiwan
Check Included Items
This product comes with the following items. If any item is missing, contact the dealer where you purchased the product.
1.
Camera
( VB-H630VE/VB-H630D/
VB-M620VE/VB-M620D)
2.
Power connector
3.
Safety wire 4.
Audio interface cable
User Manuals
• Installation Guide (This document)
This guide provides notes on camera installation and explains the procedures to install the camera onto a ceiling or wall.
• Operation Guide (Included in the Setup CD-ROM)
This document explains the initial camera settings, Admin Tools settings, viewer operations and troubleshooting, etc.
Symbols Indicating Camera Model
Camera specific functions will be listed using the icons below.
: VB-H630VE : VB-H630D
: VB-M620VE : VB-M620D
Accessories
The following accessories can be purchased separately as necessary. Some accessories are not sold in some countries or regions.
Recessed Mounting Kit SR600-VB
This dedicated accessory is used to install the camera recessed into a wall or ceiling.
Junction Box Mounting Kit PS600-VB
This dedicated accessory is used to mount the camera to a junction box.
Heater unit HU600-VB
This dedicated accessory is attached to the interior of VB-H630VE/VB-M620VE to maintain operation temperature within the dome and achieve stable operation even in extremely cold environments.
Pendant Mounting Kit PC600-VB
This is a dedicated accessory for large stores with high ceilings used to install the camera at the end of a pipe stretching down from the ceiling.
Important
When this accessory is used, the camera may shake more than the vibrations in the ceiling depending on how the pipe is mounted to the ceiling. If the camera angle is off, use the Camera Angle Setting Tool to readjust the angle (See “Operation Guide” > “Camera Angle Setting Tool”).
Canon AC Adapter PA-V18
A dedicated AC adapter for this camera.
5.
Template for VB-H630D/
VB-M620D for VB-H630VE/
VB-M620VE
6. Dome case lock screw wrench
(VB-H630VE/VB-M620VE only)
7. Setup CD-ROM 8. Installation Guide (This document)
9. Warranty card 10. Notice
Only for European Union and EEA (Norway, Iceland and Liechtenstein)
These symbols indicate that this product is not to be disposed of with your household waste, according to the WEEE Directive (2012/19/EU), the Battery
Directive (2006/66/EC) and/or national legislation implementing those Directives.
If a chemical symbol is printed beneath the symbol shown above, in accordance with the Battery Directive, this indicates that a heavy metal (Hg
= Mercury, Cd = Cadmium, Pb = Lead) is present in this battery or accumulator at a concentration above an applicable threshold specified in the Battery Directive.
This product should be handed over to a designated collection point, e.g., on an authorized one-forone basis when you buy a new similar product or to an authorized collection site for recycling waste electrical and electronic equipment (EEE) and batteries and accumulators. Improper handling of this type of waste could have a possible impact on the environment and human health due to potentially hazardous substances that are generally associated with EEE. Your cooperation in the correct disposal of this product will contribute to the effective usage of natural resources.
For more information about the recycling of this product, please contact your local city office, waste authority, approved scheme or your household waste disposal service or visit www.canon-europe.
com/weee, or www.canon-europe.com/battery.
Symbols Indicating Safety Precautions
This Installation Guide uses the following marks to indicate important information the user should know in order to use the product safely. Be sure to observe these items.
Warning
Caution
Caution
Important
Note
Inappropriate handling against the instruction accompanied by this sign may result in death or serious injury. Be sure to observe these warnings to ensure safety.
Inappropriate handling against the instruction accompanied by this sign may result in injury. Be sure to observe these precautions to ensure safety.
Inappropriate handling against the instruction accompanied by this sign may result in property damage. Be sure to observe these precautions.
This symbol indicates important or restricted items. Be sure to read this section.
Contains reference information for operation or additional explanations.
Safety Precautions
This section explains precautions that must be observed when using the camera. If they are not observed, injury, death and/or property damage may occur. Read the following information carefully and be sure to observe the precautions.
Installation Precautions
Warning
Do not install in the following places:
• Places in strong direct sunlight, near heat-generating objects, or subject to high temperatures
• Places near fire sources or flammable solvents (alcohol, thinner, fuel, etc.)
• Humid or dusty places
• Places subject to oily smoke or steam
• Places subject to sea air
• Confined or enclosed places
Fire or electric shock may result.
Caution
For installation or inspection of this camera, consult the dealer where you purchased the product.
• This installation should be made by a qualified service person and should conform to all local codes.
• When installing on a ceiling, make sure the surface is capable of withstanding the total weight of the camera and ceiling plates and is sufficiently reinforced if necessary.
• Periodically check the parts and screws for rust and to see if they have loosened, in order to prevent injuries and equipment damage due to falling items.
• Do not install in unstable places, places subject to significant vibration or impact, or places subject to salt damage or corrosive gas.
• Be sure to attach the safety wire when installing the camera.
Failure to do so may result in the camera falling or other accidents.
• Do not touch the edge of metal parts with bare hands.
• Be careful not to trap your fingers during installation of the camera.
Injury may result.
Caution
• Do not move the lens unit by hand.
• Do not install the camera on an unstable surface.
• To maximize shock resistant specifications, do not install on insufficiently strong surfaces or surfaces subject to significant vibration (VB-H630VE/VB-M620VE).
• Take measures to remove static electricity before performing any procedures.
Malfunction may result.
• Take care not to damage wiring or pipes in the room.
Damage to peripheral items may result.
Precautions for Installing the Camera Outdoors (VB-H630VE/VB-M620VE)
When installing the VB-H630VE/VB-M620VE outdoors, observe the following precautions to retain waterproof/dustproof capabilities.
• Be sure to install the camera under eaves or other places out of direct sunlight.
• Install the camera in a place unexposed to long periods of direct rainfall.
• When mounting the camera onto a wall or other upright surface, position the wiring hole straight down to prevent rain infiltration.
• If wiring the camera through the wiring hole on the bottom, use silicone sealant or a rubber mat to ensure waterproofing. Also use an insect repellent sponge if necessary.
• If wiring with a composite pipe (NPT 3/4 inch threaded hole) attached to the wiring hole, wrap teflon tape around the tip of the pipe, clear any debris from the wiring hole and firmly tighten the pipe. Apply silicone sealant after attaching the pipe.
Position the wiring hole straight down
• Firmly fix the dome case to the main unit of the camera with the lock screws, taking care not to pinch cables between the main unit and dome case.
Precautions for Use
Warning
• If you discover defective conditions such as smoke, strange sounds, heat or strange odors, immediately stop using the camera and contact your closest dealer.
Fire or electric shock may result from continued use of the product.
• Do not disassemble or modify the camera.
• Do not damage the connecting cable.
• Do not spill water or other liquid inside the camera, spray the camera with water, or otherwise make it wet.
• Do not insert foreign objects into the camera.
• Do not use flammable sprays near the camera.
• Do not leave LAN cables, external power supplies or AC adapter (sold separately) power connectors connected when the camera is not in use for long periods.
• Do not use flammable solvents such as alcohol, paint thinner or benzine when cleaning the camera.
Fire or electric shock may result.
Notes on Power Supply
Warning
• Only use the dedicated AC Adapter (sold separately) for AC power.
• Do not set any heavy objects on the power cable.
• Do not pull, forcibly bend, scratch, or modify the power cable.
• Do not cover or wrap the AC adapter (sold separately) with cloth or blankets.
Fire or electric shock may result.
Be sure to read the user manual for the dedicated AC adapter (sold separately) before use.
Caution
• After turning off the power, wait for at least five seconds before turning the power on again. If the power is turned on again too quickly, the camera may operate poorly.
External Dimensions
VB-H630VE/VB-M620VE
R62
(R2
.44)
VB-H630D/VB-M620D
R62 (R2.44)
3/4” NPT threaded hole
3- 4.5 ( 0.18)
(mounting screw holes)
155 ( 6.10)
120°
120°
Junction Box Plate
14- 4.5 ( 0.18)
(Junction box fixing holes)
46 (1-13/16)
83.5 (3-9/32)
85.7 (3-3/8)
164
( 6
.46
)
7.5°
12°
4.2 (0.17)
3- 4.6 ( 0.18)
(mounting screw holes)
12
0°
120°
Unit: mm (in.)
Main Specifications
Camera
Image Sensor
Number of Effective Pixels
Scanning Method
Lens
Focal Length* 1
F-number
Viewing Angle
Day/Night Switch
1/3 type CMOS (primary color filter)
Progressive
Approx. 2.1 million pixels
Approx. 1.3 million pixels
3x optical (4x digital) zoom lens (electric drive)
2.8 (W) – 8.4 mm (T)
F1.2 (W) – F2.0 (T)
For 16:9 aspect ratios
Horizontal: 111.0° (W) – 36.5° (T)
Vertical: 60.1° (W) – 20.5° (T)
For 4:3 aspect ratios
Horizontal: 81.2° (W) – 27.3° (T)
Vertical: 60.1° (W) – 20.5° (T)
Auto/Manual
Min. Subject Illumination
Day Mode (color) 0.3 lux (F1.2, shutter speed 1/30 sec., when smart shade control is off, 50IRE)
0.02 lux (F1.2, shutter speed 1/2 sec., when smart shade control is off, 50IRE)
0.008 lux (F1.2, shutter speed 1/2 sec., when smart shade control is on, 50IRE)
Night Mode (monochrome) 0.015 lux (F1.2, shutter speed 1/30 sec., when smart shade control is off, 50IRE)
0.001 lux (F1.2, shutter speed 1/2 sec., when smart shade control is off, 50IRE)
0.0005 lux (F1.2, shutter speed 1/2 sec., when smart shade control is on, 50IRE)
Focus
Shooting Distance
(from front of lens)
Shutter Speed
Exposure
White Balance
One-shot AF/Manual/Fixed at infinity
Day Mode: 0.3 m (12 in.) – infinity
Night Mode: 1.0 m (3.3 ft.) – infinity
1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/8000, 1/10000, 1/16000 sec.
Auto/Auto (Flickerless)/Auto (Shutter-priority AE)/Manual (Shutter Speed, Aperture,
Gain)
Auto/Light Source (Daylight Fluorescent/White Fluorescent/Warm Fluorescent/
Mercury Lamp/Sodium Lamp/Halogen Lamp)/Manual (One-shot WB/R Gain/B
Gain)
Center-Weighted/Average/Spot
9 levels
Metering Mode
Exposure Compensation
Smart Shade Control
AGC Limit
Pan Angle Range
Tilt Angle Range
Rotation Angle Range
Moving Speed
Auto/Manual/Disable
Auto: 3 levels
Manual: 7 levels
Brightens shaded areas of a video
5 levels
350° (±175°)
150° (±75°)
350° (±175°)
Pan: 17.1°/sec., Tilt: 12.6°/sec., Rotation: 25.9°/sec.
When the Camera Angle Setting Tool is used
Server
Video Compression Method
Video Size
Event Trigger Type
JPEG, H.264
Video Quality
Frame Rate* 2
Max. Frame Rate
JPEG, H.264: 5 levels
JPEG: 0.1 – 30 fps
H.264: 1/2/3/5/6/10/15/30 fps
When streaming JPEG, H.264 (1920 x 1080): 30 fps
When used in the following combinations:
When streaming H.264(1) (1920 x 1080) and H.264(2) (all sizes) simultaneously: 15 fps
When streaming H.264(1) (all sizes) and H.264(2) (1920 x 1080) simultaneously: 15 fps
When streaming H.264(1) (1280 x 960) and H.264(2) (1280 x 960) simultaneously: 15 fps
When streaming H.264(1) (1280 x 720) and H.264(2) (1280 x 720) simultaneously: 15 fps
When streaming JPEG, H.264 (1280 x 960): 30 fps
When used in the following combinations:
I-Frame Interval
Simultaneous Client Access
Camera Control
When streaming H.264(1) (1280 x 960) and H.264(2) (1280 x 960) simultaneously: 15 fps
When streaming H.264(1) (1280 x 720) and H.264(2) (1280 x 720) simultaneously: 15 fps
0.5/1/1.5/2/3/4/5 sec.
Max. 30 Clients + 1 Admin Client
H.264: Max. 10 Clients
Administrator, Authorized user, Guest user (level of control varies depending on user)
Max. 50 user names and passwords registered for authorized users.
Access Control
Encrypted Communications
IEEE 802.1X
Protocol
Privacy Mask
User authority (user name and password), Host Access Restrictions (IPv4, IPv6)
SSL/TLS, IPsec (Auto Key Exchange/Manual)
EAP-MD5, EAP-TLS, EAP-TTLS, EAP-PEAP
IPv4: TCP/IP, UDP, HTTP, FTP, SNMP (MIB2), SMTP (Client), DHCP (Client), DNS
(Client), ARP, ICMP, POP3, NTP, SMTP authentication, RTSP, WV-HTTP
(Canon proprietary), ONVIF
IPv6: TCP/IP, UDP, HTTP, FTP, SMTP (Client), DHCPv6 (Client), DNS (Client),
ICMPv6, POP3, NTP, SMTP authentication, RTSP, WV-HTTP (Canon proprietary), ONVIF
AutoIP
Audio Compression Method
Available
G.711 µ-law (64 kbps)
Audio Communication Method Full-duplex (two-way) Echo cancellation function compliant
Audio File Playback* 3
Sound Transfer Protocol by Canon
Available (audio files can be played back when an event is triggered by the intelligent function or external device input.)
Number of registration: Max. 8 places, Number of mask colors: 1 (select from 9 colors)
Preset
Intelligent Function
JPEG, H.264 : 1920 x 1080, 960 x 540, 480 x 270
1280 x 720, 640 x 360, 320 x 180
1280 x 960, 640 x 480, 320 x 240
JPEG, H.264 : 1280 x 720, 640 x 360, 320 x 180
1280 x 960, 640 x 480, 320 x 240
Max. 20 positions
<Video>
Detection Types: moving object detection, abandoned object detection, removed object detection, camera tampering detection, and passing detection
Detection Settings: Max. 15
<Volume>
Volume Detection
External Device Input, Intelligent Function (Video), Intelligent Function (Volume),
Timer
Image Upload
Event Notification
Image Cropping Function
On-Screen Display
Daylight Saving Time
Custom Settings
FTP/HTTP/SMTP (e-mail)
Temporary storage memory in camera : Max. approx. 5 MB
Frame Rate: Max. 10 fps (JPEG)
Max. 30 fps (H.264)
HTTP/SMTP (e-mail)
Digital PTZ
Cropping sizes : 640 x 360/512 x 288/384 x 216/256 x 144/128 x 72
640 x 480/512 x 384/384 x 288/256 x 192/128 x 96
Available
Available
Number of registers: 4
Items to Reg.: Exposure, Smart Shade Control, Focus, White Balance,
Image Quality Adjustment, Day/Night
Language German/English/Spanish/French/Italian/Chinese (Simplified)/Japanese
“ONVIF” is a trademark of ONVIF Inc.
Interface
Network Terminal* 4
Audio Input Terminal
LAN x 1 (RJ45, 100Base-TX (auto/full-duplex/half-duplex))
3.5 mm ( 0.14 in.) mini-jack connector (monaural)
(common for LINE IN & MIC IN) Connect via an audio interface cable (included)
Switch LINE IN/MIC IN in the setting page.
LINE IN x 1 (connect to an amplifier microphone) or
MIC IN x 1 (connect to a microphone w/o amplifier)
Audio Output Terminal
(LINE OUT)
External Device I/O Terminal
Memory Card
3.5 mm ( 0.14 in.) mini-jack connector (monaural)
Connect via an audio interface cable (included)
LINE OUT x 1 (connect to an amplifier speaker)
Input x 2, Output x 2
SD Memory Card, SDHC Memory Card, SDXC Memory Card Compatible.
Frame Rate: Max. 1 fps (JPEG)
Max. 30 fps (H.264)
Others
Operating Environment
Power Supply
Power Consumption
Dimensions
Weight
Impact Resistance
Temperature: -10°C – +50°C (+14°F – +122°F), Humidity: 5% – 85% (without condensation)
Temperature: -30°C – +50°C (-22°F – +122°F), Humidity: 5% – 85%
(without condensation)*
*Equipped with separately sold Heater Unit HU600-VB
PoE: PoE power supply via LAN connector (IEEE802.3af compliant)
AC Adapter: PA-V18 (100 – 240 V AC) (sold separately)
External power source: 24 V AC/12 V DC
Heater Unit HU600-VB (sold separately): 24 V AC only
When using PoE: Max. approx. 8.4 W
Max. approx. 7.8 W
When using AC Adapter PA-V18: Max. approx. 9.9 W (100 V AC)
Max. approx. 10.3 W (240 V AC)
Max. approx. 9.4 W (100 V AC)
Max. approx. 9.2 W (240 V AC)
When using DC:
When using AC:
Max. approx. 9.0 W
Max. approx. 8.3 W
Max. approx. 8.1 W
Max. approx. 7.5 W
Max. approx. 18.7 W*
*when separately sold Heater Unit HU600-VB installed
( x H) 180 x 147 mm ( 7.09 x 5.79 in.)
( x H) 186 x 140 mm ( 7.32 x 5.51 in.)
Approx. 1920 g (4.24 lb.)
Approx. 162 g (5.8 oz.) (Junction Box Mounting Kit)
Approx. 1190 g (2.63 lb.)
Approx. 159 g (5.7 oz.) (Junction Box Mounting Kit)
External materials: aluminum alloy, Dome: polycarbonate plastics
IK10 compliant
With lens shock absorbing mechanism
Estimated shock resistant: 50J (based on Canon’s test method)
IP66 compliant (IEC60529)
Only applies if properly installed and adequately waterproofed
Dust-resistant/
Waterproof Specification
*1 (W): maximum wide angle, (T): maximum telephoto
*2 This number represents the communication performance of the camera. The frame rate may be reduced due to Viewer PC’s specs, the number of clients accessing at the same time, network loads, image quality setting, type or movement of the subject or other reasons.
*3 A third-party amplifier speaker is necessary.
*4 Use a category 5 or better LAN cable, 100 m (328 ft.) or less in length.
The contents of this guide are subject to change without any prior notice.
CANON INC.
30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan
CANON EUROPA N.V.
Bovenkerkerweg 59, 1185 XB Amstelveen, The Netherlands
2
3
4
5
9
10
Lock screw holes
Dome case
7
Inner cover
Dome case
When guiding cables through the side
When guiding cables through the ceiling wiring hole
* Illustrations without icons are examples of VB-H630D/VB-M620D.
Installing the Camera
The following describes procedures for mounting the camera to a ceiling.
Before installing the camera, set the IP address and other network information on the camera using the “VB Initial Setting Tool” on the Setup CD-ROM.
For details on how to operate the “VB Initial Setting Tool”, see “Operation Guide”.
1
Determine an installation position for the camera and drill holes in the ceiling
Use the included template to determine the positions of the fixing screw holes and wiring hole
( 40 mm ( 1.6 in.)) according to the camera orientation. Next, cut out the wiring hole, and drill the fixing screw holes in the the ceiling.
Use the template with the printed side facing you.
2
Loosen the three lock screws on the dome case and remove the dome case
Attaching a Junction Box
Mounting hole (inner side)
Mounting hole (outer side)
Junction box plate
Camera fixing screw (included)
Short screw x 3
Long screw x 3
Dome case fixing screw x 3
Use the junction box plate (included with the separately sold junction box mounting kit PS600-
VB) to mount the camera to the junction box.
1 Attach the junction box plate to the junction box with screws that match the screw holes in the junction box.
2 Guide the cables through the wiring hole and mount the camera to the junction box plate using the 3 included camera fixing screws
(M4).
The camera fixing screws differ in length depending on the camera. Use short screws for VB-H630D/VB-M620D, and long screws for VB-H630VE/VB-M620VE.
3 Wire the cables and attach the inner cover and dome case.
* Diagram of VB-H630VE/VB-M620VE.
Special temper-resistant screws are used for the dome case lock screws. Use the included dome case lock screw wrench.
3
Remove the tape and the inner cover
Important
Do not move the lens unit by hand. This can damage the lens unit.
4
Remove the 4 pieces of tape that prevent lens rotation during shipping, and push the inner cover in the direction of the arrows to remove it. Then remove the 2 pieces of tape attached to the base of the lens.
Open the wiring hole according to the installation method
Use a box cutter to cut a cross shape into the wiring hole cover in order to guide cables through. Do not remove the wiring hole cover.
Use a coin to unscrew the wiring hole cover from the side through which cables will be guided. Screw the wiring hole cover into the other wiring hole. You can fit a composite pipe
(NPT 3/4 inch threaded hole) to the wiring hole.
5
Secure the safety wire
Securely attach the safety wire to an anchor or structure. After securing one end of the safety wire to the ceiling, secure the other end to the camera using the screw that is fastened to the camera.
6
Guide the LAN cable through the wiring hole
When using an external power supply, guide the power interface cable through the wiring hole. Guide the I/O interface cable and the audio interface cable (included) through the wiring hole if necessary.
Important
Cable tie
When using the AC Adapter (sold separately), cut the cable tie and remove the ferrite core. Be sure not to damage the power cable when cutting the cable tie.
7
Fix the camera to the ceiling
Fix the camera at three points to the ceiling using the appropriate screws. Three ceiling fixing screw holes are located on the camera. You must provide screws that correspond to the ceiling fixing screw holes.
8
Wire the cables
Wire the cables referring to “Cable Wiring Method”.
Important
When wiring is complete, seal the wiring hole to keep out insects and dust.
9
Attach the inner cover
Attach the inner cover to its original position.
10
Attach the dome case
Firmly fix the dome case at three points to the camera using the dome case screws.
If the cables cannot be stored above a ceiling made of concrete, etc., break the cutout section of the dome case using diagonal pliers to create a cutout through which to guide the cables.
Cutout section
Important
When attaching the dome case, be sure not to pinch cables between the camera and dome case. Pinched cables may impair dust and waterproofing capabilities.
11
Set the camera angle
When installation is complete, use the Camera Angle Setting Tool to adjust the pan, tilt, rotation, zoom (and focus) see “Operation Guide” > “Camera Angle Setting Tool”).
Using an Memory Card
Inserting the card
Push the memory card as far as possible into the memory card slot with the label facing outward.
Removing the card
Push the memory card in all the way until the card slightly pops out. Pinch the card and remove.
Memory card slot
Important
• Insert the memory card before attaching the dome case.
• Make sure the memory card is not write-protected.
• When using an memory card with the camera for the first time, it is recommended to format the card after inserting it into the camera (see “Operation Guide” > “Setting Page” > “Memory Card”).
Cable Wiring Method
For VB-H630VE/VB-M620VE, secure the various cables with the cable clamps fastened to the camera to prevent damage to cables or connectors due to vibration, etc.
*The diagram is a wiring example for VB-H630VE/VB-M620VE.
External Device I/O Terminals
Heater unit HU600-VB
(sold separately for
VB-H630VE/VB-M620VE)
External Device I/O cable
Cable clamp
Camera
Power cable
Heater cable
Loosen the screw and rotate the cable clamp. Bend the cable clamp as shown in the diagram before wiring the cables.
Tighten the screw to fix the cable clamp and bend the cable clamp to grip the cables.
Firmly bend the cable clamp so that it does not come into contact with the inner cover.
Bend the cable clamp so that it does not exceed this height
Cable clamp
Inner cover
LAN cable
Audio interface cable
(included)
Cable clamp
Bend the cable clamp to grip the cables.
Part Names
Dome Case/Inner Cover/Camera
Bottom
Wiring hole
Dome case
Dome case
Lock screw
Inner cover
Lens unit
Camera
Wiring hole
Safety wire attachment
Attaches the included safety wire.
Serial number
The camera's serial number. Write the number on the front of this Installation Guide before installing the camera.
MAC address
The camera's unique address. Write the address on the front of this Installation Guide before installing the camera.
Top view of the camera interior
Wiring hole
1 Reset switch
Turn on the power while pushing this switch using a sharp object. Continue to push the switch for 5 seconds or more to restore all factory settings except for the date and time.
2 LED
The blue LED light comes on.
On: When powered on, during reboot
Off: During normal use
3 Memory card slot
4 External device I/O terminals
5 Power connection terminal
6 Installation screw holes
Used when securing the camera to the installation surface, the junction box mounting kit (sold separately), or the recessed mounting kit (sold separately).
7 Wiring hole
8 Audio I/O terminal
Connect the included audio interface cable here to connect audio input and output devices to the camera.
9 100BT LAN connector
A Cable clamps
A Fan
A Heater connection terminal
Connecting the Camera
Power Connection
Power can be supplied to the camera in the three ways described below.
PoE (Power over Ethernet)
The camera supports PoE functions. Power can be supplied to the camera by using a LAN cable to connect it to a PoE HUB that conforms to the IEEE 802.3af standard.
Important
• Check with your dealer for more information about PoE HUB and Midspan technology.
Midspan (a LAN cable power supply device) is a device that, like a PoE HUB, supplies power to the camera via a LAN cable.
• Some PoE HUBs allow current limits for each port, but applying limits may interfere with performance. If using this type of PoE HUB, do not limit the operating current.
• Some PoE HUBs have total consumption current limits for ports, which can interfere with performance when multiple ports are in use. For more information, check the instruction guide for your PoE HUB.
• When the camera is connected to a switching HUB, changing the connection while the camera is operating may cause the HUB learning function to interfere with communication. Do not change the connection when the camera is operating.
• The camera can also be connected to an AC adapter (sold separately) while receiving power from a PoE HUB. In such cases, the PoE power supply is given priority, and the camera does not use the power supply from the AC adapter (sold separately). When the PoE power supply is disconnected, power is supplied automatically from the AC adapter (sold separately).
External Power Supply
12 V DC or 24 V AC input can be used.
Connect the included power connector as shown below.
Screwdriver
Tightening torque: 0.25 N·m (max.)
For 12 V DC and 24 V AC input, use a power supply insulated from 100 V AC.
12 V DC can be connected in a non-polar configuration.
Strip
Important
Approx. 5 – 7 mm
(0.20 – 0.28 in.)
Power connector
(included)
• The power supply should be within the following voltage range.
• 24 V AC: Voltage fluctuation within ±10% of 24 V AC (50 Hz or
60 Hz ±0.5 Hz or less)
Current supply capacity of at least 1.0 A per camera
• 12 V DC: Voltage fluctuation within ±10% of 12 V DC
Current supply capacity of at least 1.5 A per camera
• When using a 12 V DC battery power supply, be sure to connect resistors of at least 0.5 – 1.0
Ω
/20 W in series to the power line.
• For an external power supply, use a double-insulated device.
Recommended Power Cables [Reference]
Cable (AWG) 24
Conductor diameter mm
(in.)
12 V DC maximum cable length m
(ft.)
24 V AC maximum cable length m
(ft.)
0.52
( 0.020)
5
(16.4)
11
(36.1)
22
0.65
( 0.026)
9
(29.5)
18
(59.1)
Use UL cable (UL-1015 or equivalent) for 12 V DC or 24 V AC wiring.
AC Adapter
Use the dedicated AC Adapter (sold separately).
20
0.82
( 0.032)
14
(45.9)
29
(95.1)
18
1.03
( 0.041)
23
(75.5)
46
(150.9)
16
1.30
( 0.051)
32
(105.0)
64
(210.0)
Note
• The camera does not have a power switch. Connecting and disconnecting the LAN cable (PoE power supply), AC adapter, or external power supply plug turns the power ON and OFF, respectively.
• When the camera needs to be rebooted, perform the reboot operation from the camera setting page
(see “Operation Guide” > “Setting Page” > “Maintenance”).
• When using the heater unit HU600-VB (sold separately), use 24 V AC for the VB-H630VE/VB-M620VE power supply. PoE, 12 V DC and the AC adapter cannot be used.
External Device I/O Terminals
External device I/O terminals consist of two input and output systems each. Viewer can be used to check external device input status and control output to an external device (see “Operation
Guide” > “Selecting the External Device Output” and “Displaying Event Status”).
External Device Input Terminals (IN1, IN2)
External device input terminals consist of two sets (IN1, IN2) of two terminals, with the negative terminals connected to the camera interior GND. Connecting cables to the positive and negative terminals and opening or closing the circuit notifies the Viewer.
Important
• When connecting sensors and switches, connect terminals that are electrically isolated from the respective power and GND.
• Do not push the external device I/O terminal button with too much force. Doing so may cause the button to remain pushed-in.
External Device Output Terminals (OUT1, OUT2)
External device output terminals consist of two sets (OUT1, OUT2) of two terminals. The sets have no polarity. Controls from the viewer can be used to open and close the circuit between the terminals. Using optical couplers, the output terminals are isolated from the camera's internal circuit.
The load connected to the output terminals should be within the following rating range.
Rating between output terminals:
Maximum voltage 50 V DC
Continuous load current at or below 100 mA
On resistance: Max. 30Ω
Internal Connection Diagram
10 kΩ 10 kΩ
+3.3 V
1 kΩ
External device
0.1 µF
Input terminal
IN1, IN2
Note
External device
Adaptive wiring for external device cables
Solid conductor AWG: No. 28 – 22
Conductor size: 0.32 – 0.65 mm ( 0.013 – 0.026 in.)
Cable strip should be approx. 8 – 9 mm (0.31 – 0.35 in.).
Output terminal
OUT1, OUT2
Audio Input/Output Terminals
Each audio input/output terminal has one input system and one output system.
Connecting the camera to an audio input/output device such as a microphone or a speaker with an amplifier allows you to send/receive audio through the viewer.
Use the included audio interface cable to connect audio input/output devices to the camera.
Use the 3.5 mm ( 0.14 in.) monaural mini-jack connector to connect an audio output device with the audio interface cable.
Cable marker
OUT
The long end (has cable marker) from the bifurcation point in the cable corresponds to the audio output terminal. The short end
(does not have cable marker) from the bifurcation point in the cable corresponds to the audio input terminal.
IN
Audio Input Dual LINE IN/MIC IN (monaural input)
Although the camera has a single audio input system, it supports two types of microphone input:
LINE IN and MIC IN. Before using the audio input, change the [Audio Input] on the Setting Page
(see “Operation Guide” > “Audio Input”). LINE IN is selected by default.
Input terminal: 3.5 mm ( 0.14 in.) mini-jack (monaural)
• Dynamic MIC IN
Input impedance: 1.75 kΩ ± 20%
* Supported microphones: Output impedance: 400Ω – 600Ω
• Condenser MIC IN
Input impedance (microphone bias resistance): 2.2 kΩ ± 20%
Microphone power supply: plug-in power (voltage: 1.8 V)
* Supported microphones: Condenser microphones with plug-in power support
• LINE IN
Input level: Max. 1 Vp-p
* Use a microphone with an amplifier.
Audio Output Terminal LINE OUT (monaural output)
Connect the camera to a speaker with an amplifier. Audio can be sent to the speaker from Viewer.
Output terminal: 3.5 mm ( 0.14 in.) mini-jack (monaural)
Output level: Max. 1 Vp-p
* Use a speaker with an amplifier.
Important
• Using the wrong settings in [Audio Input] may damage the camera and/or microphone. Be sure to configure settings correctly.
• Microphone characteristics may affect volume and sound quality.
• Images and audio do not always synchronize properly.
• Audio may be interrupted depending on PC characteristics and network environment.
• Video and audio can be streamed to up to 30 clients. However, audio may be interrupted when streaming to many clients or using SSL.
• Audio may be interrupted when using antivirus software.
• Connecting and disconnecting the LAN cable interrupts the audio. Use the viewer to reconnect.
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
Key Features
- Indoor IP security camera
- CMOS 25.4 / 3 mm (1 / 3") 2.1 MP 1920 x 1080 pixels
- Wired Ethernet LAN
- Night vision
- Optical zoom: 3x Digital zoom: 4x
- Dome Ceiling/wall
- Grey
- 1.19 kg
Related manuals
advertisement
