HT-J7750W User manual 7.1CH Blu-ray™ Home Entertainment System imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Safety Information ✎✎ The following also applies to the Wireless Receiver Module (SWA-7000). CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL. This symbol indicates that important literature concerning operation and maintenance has been included with this product. ~~ The slots and openings in the cabinet and in the back or bottom are provided for necessary ventilation. To ensure reliable operation of this apparatus, and to protect it from overheating, these slots and openings must never be blocked or covered. -- Do not place this apparatus in a confined space, such as a bookcase, or built-in cabinet, unless proper ventilation is provided. -- Do not place this apparatus near or over a radiator or heat register, or where it is exposed to direct sunlight. -- Do not place vessels (vases etc.) containing water on this apparatus. A water spill can cause a fire or electric shock. ~~ Do not expose this apparatus to rain or place it near water (near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc.). If this apparatus accidentally gets wet, unplug it and contact an authorized dealer immediately. ~~ This apparatus uses batteries. In your community, there might be environmental regulations that require you to dispose of these batteries properly. Please contact your local authorities for disposal or recycling information. ~~ Do not overload wall outlets, extension cords or adaptors beyond their capacity, since this can result in fire or electric shock. ~~ Route power-supply cords so that they are not likely to be walked on or pinched by items placed on or against them. Pay particular attention to cords at the plug end, at wall outlets, and the point where they exit from the apparatus. ~~ To protect this apparatus from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the set due to lightning and power line surges. ~~ Before connecting the AC power cord to the DC adaptor outlet, make sure the voltage designation of the DC adaptor corresponds to the local electrical supply. ~~ Never insert anything metallic into the open parts of this apparatus. Doing so may create a danger of electric shock. ~~ To avoid electric shock, never touch the inside of this apparatus. Only a qualified technician should open this apparatus. ~~ Make sure to plug the power cord in until it is firmly seated. When unplugging the power cord from a wall outlet, always pull on the power cord's plug. Never unplug by pulling on the power cord. Do not touch the power cord with wet hands. ~~ If this apparatus does not operate normally - in particular, if there are any unusual sounds or smells coming from it - unplug it immediately and contact an authorized dealer or service centre. ~~ Maintenance of Cabinet. -- Before connecting other components to this product, be sure to turn them off. -- If you move your product suddenly from a cold place to a warm place, condensation may occur on the operating parts and lens and cause abnormal disc playback. If this occurs, unplug the product, wait for two hours, and then connect the plug to the power outlet. Then, insert the disc, and try to play back again. ~~ Be sure to pull the power plug out of the outlet if the product is to remain unused or if you are leaving the house for an extended period of time (especially when children, elderly, or disabled people will be left alone in the house). -- Accumulated dust can cause an electric shock, an electric leakage, or a fire by causing the power cord to generate sparks and heat or the insulation to deteriorate. ~~ Contact an authorized service centre for information if you intend to install your product in a location with heavy dust, high or low temperatures, high humidity, chemical substances, or where it will operate 24 hours a day such as in an airport, a train station, etc. Failing to do so may lead to serious damage of your product. ~~ Use only a properly grounded plug and wall outlet. -- An improper ground may cause electric shock or equipment damage. (Class l Equipment only.) 2 - English WARNING : ~~ TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES AND OTHER ITEMS WITH OPEN FLAMES AWAY FROM THIS PRODUCT AT ALL TIMES. ~~ To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. CLASS 1 LASER product This product is classified as a CLASS 1 LASER product. Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. CAUTION : ~~ INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED, AVOID EXPOSURE TO BEAM. CLASS 1 KLASSE 1 LUOKAN 1 KLASS 1 PRODUCTO LASER PRODUCT LASER PRODUKT LASER LAITE LASER APPARAT LÁSER CLASE 1 3D Precautions IMPORTANT HEALTH AND SAFETY INFORMATION FOR 3D PICTURES. Read and understand the following safety information before using the 3D function. ~~ Some viewers may experience discomfort while viewing 3D TV such as dizziness, nausea, and headaches. If you experience any such symptom, stop viewing 3D TV, remove the 3D Active Glasses, and rest. ~~ Watching 3D images for an extended period of time may cause eye strain. If you feel eye strain, stop viewing 3D TV, remove your 3D Active Glasses, and rest. ~~ A responsible adult should frequently check on children who are using the 3D function. If there are any reports of tired eyes, headaches, dizziness, or nausea, have the child stop viewing 3D TV and rest. ~~ Do not use the 3D Active Glasses for other purposes (such as general eyeglasses, sunglasses, protective goggles, etc.) ~~ Do not use the 3D function or 3D Active Glasses while walking or moving around. Using the 3D function or 3D Active Glasses while moving around may cause you to bump into objects, trip, and/or fall, and cause serious injury. ~~ If you want to enjoy 3D content, connect a 3D device (3D compliant AV receiver or TV) to the product’s HDMI OUT port using a high-speed HDMI cable. Put on 3D glasses before playing the 3D content. ~~ The product outputs 3D signals only through an HDMI cable connected to the HDMI OUT port. ~~ The video resolution in 3D play mode is limited to the resolution of the original 3D video. You cannot change the resolution to your preference. ~~ Some functions such as BD Wise, screen size adjustment, and resolution adjustment may not operate properly in 3D play mode. ~~ You must use a high-speed HDMI cable for proper output of the 3D signal. ~~ Stay at least three times the width of the screen from the TV when watching 3D images. For example, if you have a 46 inch screen, stay 3.5 meters from the screen. ~~ Place the 3D video screen at eye level for the best 3D picture. ~~ When the product is connected to some 3D devices, the 3D effect may not function properly. ~~ This product does not convert 2D content into 3D. ~~ "Blu-ray 3D" and "Blu-ray 3D" logo are trademarks of the Blu-ray Disc Association. 3 - English Safety Information ~~ To turn this apparatus off completely, you must disconnect it from the wall outlet. Consequently, the wall outlet and power plug must be readily accessible at all times. ~~ Do not allow children to hang on the product. ~~ Store the accessories (battery, etc.) in a location safely out of the reach of children. ~~ Do not install the product in an unstable location such as a shaky self, a slanted floor, or a location exposed to vibration. ~~ Do not drop or strike the product. If the product is damaged, disconnect the power cord and contact a service centre. ~~ To clean this apparatus, unplug the power cord from the wall outlet and wipe the product using a soft, dry cloth. Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air fresheners, lubricants, or detergent. These chemicals can damage the appearance of the product or erase the printing on the product. ~~ Do not expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the apparatus. ~~ Do not dispose of batteries in a fire. ~~ Do not plug multiple electric devices into the same wall socket. Overloading a socket can cause it to overheat, resulting in a fire. ~~ There is danger of an explosion if you replace the batteries used in the remote with the wrong type of battery. Replace only with the same or equivalent type. Contents Getting Started Network Services 5Accessories 42 Logging In to Your Samsung Account 6 43 Using SAMSUNG APPS 5 Speaker Components 7 Rear Panel 8 9 Front Panel 42 Before Using SAMSUNG APPS 45 Screen Mirroring Remote Control Connections Connecting the Speakers 12 Connecting to a TV and External Devices 13 Connecting to a Network Router Settings 14 The Initial Settings Procedure 14 The Home Screen at a Glance 15 Accessing the Settings Screen 15 Settings Menu Functions 21 Radio Setup 22 Network Setup 24 Wi-Fi Direct 25 Upgrading Software 45 Using the Web Browser 49 Linking your Internet Service Accounts to the Product 49BD-LIVE™ Appendix 50 Additional Information 51 Disk and Format Compatibility 58Troubleshooting 61Specifications 63Licences `` Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. Playing Content 27 Playing Commercial Discs 27 Playing Multimedia Files 29 Controlling Video Playback 32 Controlling Music Playback 37 Using Bluetooth 39 Playing Photo Content 41 Using the Special Effects Remote Control Buttons 4 - English Getting Started Check the box for the accessories and speaker components listed or shown below. Accessories ~~ Remote Control ~~ Lithium Battery Getting Started Power Cable (Main Unit, SWA-7000) x 2 ~~ User Manual FM Antenna WARNING, DO NOT INGEST BATTERY, CHEMICAL BURN HAZARD, [The remote control supplied with] This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. Speaker Components Speaker Cable x 2 Screw (5x20) x 16 Stand Base x 4 Centre L R SURROUND SPEAKERS OUT SPEAKER IMPEDANCE : 3Ω ID SET Front/ Front Top x 2 Stand x 4 Surround x 2 5 - English Subwoofer Wireless Receiver Module (SWA-7000) D H-EN HIG VACUUM TUBE SO UND UBE S ACTUU BM E STO D VACU DUVM UND OUND H-EN H-EN HIG HIG D H-EN HIG VACUUM TUBE SO UND Getting Started Front Panel DISPLAY ICONS FUNCTION OPEN/ CLOSE 5V 0.5A 5V 0.5A 5V 0.5A 5V 0.5A STOP 5V 0.5A VOLUME CONTROL PLAY/PAUSE POWER 5V 0.5A VACUUM TUBE AMP D H-EN HIG VACUUM TUBE SO UND 5V 0.5A DISPLAY 5V 0.5A DISC TRAY REMOTE CONTROL SENSOR USB ✎✎ Cellular phones or mobile devices placed near the vacuum tube amp or electronic products placed on the top of the product can cause audio noise or distortion. ✎✎ When the product is on, do not let children touch the product's surface. It will be hot. ✎✎ To upgrade the product's software through the USB jack, you must use a USB flash drive. ✎✎ When the product displays a Blu-ray Disc menu, you cannot start the movie by pressing the button on the product or the remote. To play the movie, you must select Play Movie or Start in the disc menu, and then press the OK button. 5V 0.5Athe home cinema, ✎✎ If you are using the Internet or are playing content from a USB device on your TV through you cannot select the BD/DVD mode with the SOURCE button. To select the BD/DVD mode, exit the Internet or stop the content you are playing on the TV, and then select the BD/DVD mode. 6 - English Rear Panel HDMI OUT AUX IN HDMI IN COOLING FAN * FM ANTENNA FRONT R R SUBWOOFER FRONT TOP FRONT L LAN CENTER SPEAKERS OUT POWER CORD L IMPEDANCE : 3Ω FRONT TOP 1 HDMI OUT HDMI IN SPEAKER OUTPUT CONNECTORS 2 LAN TERMINAL FM ANT L R OPTICAL DIGITAL AUDIO IN EXTERNAL DIGITAL AUDIO IN (OPTICAL) * Connecting the FM Antenna 1. 2. Connect the supplied FM antenna to the FM ANT Jack. Slowly move the antenna wire around until you find a location where reception is good, then fasten it to a wall or other rigid surface. ✎✎ Maintain a minimum of 10 cm of clear space on all sides of the home cinema to ensure adequate ventilation. Do not obstruct the cooling fan or ventilation holes. ✎✎ This product does not receive AM broadcasts. 7 - English Getting Started AUX IN POWER Getting Started Remote Control Tour of the Remote Control Press to open and close the disc tray. Turn the product on and off. Press to select the Home Cinema's mode (HDMI, AUX, BD/DVD, etc.). Adjust the volume. Cut off the sound temporarily. Press to skip backwards([) or forwards(]) or Press and hold to search backwards(() or forwards()). Press to play disc or files. or Press to pause playing. Press to use the Tools menu. or To display the number keypad (may include function keys when applicable) on the screen, press and hold the button. Press to move to the Home screen. Select on-screen menu items and change menu values. ,. : Search for active FM stations and to change channels. Press to stop the disc playing or to exist the menu. Return to the previous menu. Use to enter the Popup menu/Title menu. Press to view the disc menu. Use to display the playback information when playing a Blu-ray/DVD disc or files. Press to apply sound effects. Press to record FM radio broadcasts. Press to apply the DTS Neo:Fusion II effect. These buttons are used both for menus on the product and also several Blu-ray Disc functions. Press to select MANUAL/PRESET in the Tuner function. Set a Sleep time to shut off the product. Select STEREO or MONO for radio broadcasts. Use to set a preset radio frequency. ✎✎ While playing multimedia content in SAMSUNG APPS, press and hold 5 button on the remote to pause playback. To stop playback, press and hold e (EXIT) button on the remote. Installing batteries in the Remote Control 1 Use a coin to turn the remote control cover anti-clockwise to remove it as shown in the figure above. 2 3 Insert a 3V lithium battery. Keep the positive (+) pole upward when inserting the battery. Put the battery cover on and align the '●' marks side by side as shown in the figure above. 8 - English Use a coin to turn the cover clockwise as far as it will go to fix it in place. Connections This section describes various methods of connecting the product to other external components. Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Connecting the Speakers Centre Product Front/ Front Top (R) Surround (R) Front/ Front Top (L) Surround (L) Wireless Receiver Module Front/Front Top Speakers Place these speakers in front of your listening position, facing inwards (about 45°) toward you. Place the front speakers so that their tweeters will be at the same height as your ear. Align the front face of the front/front top speakers with the front face of the centre speaker or place them slightly in front of the centre speakers. Centre Speaker It is best to install the centre speaker at the same height as the front/front top speakers. You can also install it directly over or under the TV. Surround Speakers Subwoofer Place these speakers to the side of your listening position. If there isn't enough room, place these speakers so they face each other. Position them about 60 to 90cm above your ear, facing slightly downward. *U nlike the front and centre speakers, the surround speakers are used mainly for sound effects. Sound will not come from them all the time. The position of the subwoofer is not so critical. Place it anywhere you like. *Surround speakers must be connected to the wireless receiver module. *The appearance of your speakers may differ from the illustrations in this manual. *Each speaker has a coloured label on its back or underside. Each cable has a single coloured band near its end. Match the band on each cable to the speaker label by colour, and then connect the cable to the speaker. See page 10 for exact instructions. 9 - English Connections Subwoofer Position of the product Place it on a stand or cabinet shelf, or under the TV stand. Selecting the Listening Position The listening position should be located about 2.5 to 3 times the TV's screen size away from the TV. For example, if you have a 46 inch screen, locate the listening position 2.92 to 3.50 meters from the screen. Connections Installing the Speakers on the Tallboy Stands 1. Find the speaker cable that is attached to the Stand. Turn the Stand and Stand Base upside-down, unravel the speaker cable, and then draw it through the hole in the Stand Base. 2 1 Stand Base ✎✎ Handle the Stand carefully. It is heavy. 2. Connect the Stand Base to the bottom of the Stand. 3. Insert three 5x20 screws into the marked holes in the Stand Base, and then tighten them with a screwdriver as shown in the illustration. 4. 5. 6. 7. Stand 3 4 5 6 Place the speaker cable into the slot on the bottom of the stand base. Connect the assembled stand and a speaker together by matching the labels on the stand and speaker with each other as shown in the picture. Insert a screw (5x20) into the hole on the rear of the speaker and tighten by turning it clockwise with a screwdriver. Repeat steps 1 through 6 with the other speaker and stand. Speaker Stand Speaker Cable Connections Connect the speaker wire plugs from each speaker to the back of the product by matching the coloured band on each cable to the colours of the speaker jacks. When connecting, make sure to match label colour on the back of speaker. Front Top/ Front Speaker (R) Front Top/ Front Speaker (L) FRONT TOP Wireless Receiver Module FRONT FRONT TOP R FRONT R SUBWOOFER L L IMPEDANCE : 3Ω 2. Match each speaker cable bundle to the correct speaker by matching the coloured band on each bundle to the coloured sticker on the bottom or back of each speaker. CENTER SPEAKERS OUT L R Centre Speaker SURROUND SPEAKERS OUT SPEAKER IMPEDANCE : 3Ω ID SET Subwoofer POWER AUX IN FRONT TOP FRONT R R SUBWOOFER FRONT TOP FRONT L Surround Speaker (R) 10 - English LAN CENTER SPEAKERS OUT Surround Speaker (L) L IMPEDANCE : 3Ω 1. HDMI OUT 1 HDMI IN 2 FM ANT L R OPTICAL DIGITAL AUDIO IN ✎✎ If you place a speaker near your TV set, the screen colour may be distorted because of the magnetic field. ✎✎ Place the wireless receiver module at the rear of the listening position. If the wireless receiver module is too close to the product, sound from the speakers may be disrupted because of interference. ✎✎ If you use a device such as a microwave oven, wireless LAN Card, Bluetooth device, or any other device near the product, sound from the speakers may be disrupted because of interference. ✎✎ The maximum transmission distance from the product to the wireless receiver module is about 10m, but | CAUTION | \\ \\ \\ \\ \\ \\ \\ \\ If you want to install the speakers on the wall, fasten screws or nails (not provided) firmly to the wall wherever you want to hang a speaker, and then, using the hole in the rear of each speaker, carefully hang each speaker on a screw or nail. Do not let children play with or near the speakers. They could get hurt if a speaker falls. When connecting the speaker wires to the speakers, make sure that the polarity (+/­–) is correct. Keep the subwoofer speaker out of reach of children to prevent children from inserting their hands or alien substances into the duct (hole) of the subwoofer speaker. Do not hang the subwoofer on the wall by the duct (hole). he wireless receiving antenna is built into the wireless receiver module. Keep it away from water and T moisture. For optimal listening performance, make sure that the area around the wireless receiver module location is clear of any obstructions. In 2-CH mode, you will hear no sound from the wireless surround speakers. 11 - English Connections may vary depending on your operating environment. If a steel-concrete wall or metallic wall is between the product and the wireless receiver module, the system may not operate at all, because the radio waves cannot penetrate metal. ✎✎ If the product doesn't make a wireless connection, you need to run an ID Set between the product and wireless receiver module. With the product turned off, press and hold (MUTE) button on the remote control for 5 seconds. Turn on the wireless receiver module. Then, press and hold the "ID SET" button on the back of the wireless receiver module for 5 seconds, and then turn the product on. Connections Connecting to a TV and External Devices AUX IN FRONT TOP FRONT R R SUBWOOFER FRONT TOP FRONT L L IMPEDANCE : 3Ω AUX IN POWER LAN CENTER SPEAKERS OUT HDMI OUT 1 HDMI IN 2 OPTICAL DIGITAL AUDIO IN LAN HDMI OUT R Red W White FM ANT FM ANT L R HDMI IN (ARC) 1 HDMI IN Method 1 External Devices L R 2 Method 2 HDMI OUT OPTICAL DIGITAL AUDIO IN Method 3 AUDIO OUT OPTICAL OUT Connecting to a TV Connect an HDMI cable (not supplied) from the HDMI OUT jack on the back of the product to the HDMI IN jack on your TV. If the TV supports ARC, you can hear the audio from your TV through the home cinema with only this cable connected. See page 18 in this manual and the section on ARC in your TV's user's manual for details. Connecting to External Devices Method 1 HDMI IN : Connecting to an External Component with an HDMI Cable Connect an HDMI cable (not supplied) from the HDMI IN jack on the back of the product to the HDMI OUT jack on your digital device. Select the HDMI1 or HDMI2 mode. Method 2 AUX IN : Connecting an External Analogue Component Using an RCA audio cable (not supplied), connect the AUDIO In jack on the product to the AUDIO Out jack on the external analogue component. Select the AUX mode. ~~ Be sure to match the colours on the cable plugs to the colours on the input and output jacks. Method 3 OPTICAL : Connecting an External Digital Audio Component Use to connect the digital audio output of digital signal components such as Cable Boxes and Satellite Receivers (Set-Top-Boxes) to the home cinema. Using a digital optical cable (not supplied), connect the Optical Digital Audio In jack on the product to the Digital Optical Out jack of the external digital device using a digital optical cable. Select the D. IN mode. ✎✎ To see video from your Cable Box/Satellite receiver, you must connect its video output directly to your TV. ✎✎ This system supports Digital sampling frequencies of 32 kHz or higher from external digital components. ✎✎ This system supports only DTS and Dolby Digital audio. MPEG audio, a bitstream format, is not supported. Selecting an External Device to Use To select an external device after you have connected it, press the SOURCE button. Each time you press the button, the mode changes in this order : BD/DVD ; D. IN ; AUX ; HDMI1 ; HDMI2 ; FM ; BT 12 - English Wireless Network Connecting to a Network Router You can connect your product to your network router using one of the methods illustrated below. Wired Network FRONT TOP FRONT R R SUBWOOFER FRONT TOP FRONT L L IMPEDANCE : 3Ω AUX IN POWER LAN CENTER SPEAKERS OUT HDMI OUT 1 HDMI IN 2 FM ANT L R OPTICAL DIGITAL AUDIO IN Broadband modem (with integrated router) Broadband service Or Broadband service ✎✎ If your wireless IP router supports DHCP, this Router Broadband service Broadband modem ✎✎ Your router or your Internet Service Provider's policies may prevent the product from accessing Samsung's software update server. If this occurs, contact your Internet Service Provider (ISP) for more information. ✎✎ DSL users, please use a router to make a network connection. ✎✎ Try to use the CAT 7 cable to connect. ✎✎ You cannot use the product if the network speed is slower than 10Mbps. ✎✎ To use the DLNA function, you must connect your PC to your network as shown in the illustrations above. The connection can be wired or wireless. product can use a DHCP or static IP address to connect to the wireless network. ✎✎ Set your wireless IP router to Infrastructure mode. Ad-hoc mode is not supported. ✎✎ The product supports only the following wireless security key protocols: -- WEP (OPEN/SHARED), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES) ✎✎ Select a channel on the wireless IP router that is not currently being used. If the channel set for the wireless IP router is currently being used by another device nearby, it will result in interference and communication failure. ✎✎ In compliance with the newest Wi-Fi certification specifications, Samsung home cinemas do not support WEP, TKIP, or TKIP-AES (WPS2 Mixed) security encryption in networks running in the 802.11n mode. ✎✎ Wireless LAN, by its nature, may cause interference, depending on the operating conditions (AP performance, distance, obstacles, interference by other radio devices, etc.). 13 - English Connections Wireless IP sharer Settings The Initial Settings Procedure 1 PLAY DISC ~~ The Home menu will not appear if you do not configure the initial settings. ~~ The OSD (On Screen Display) may change in this product after you upgrade the software version. ~~ The access steps may differ depending on the menu you selected. After you have finished connecting the home cinema to your TV, turn on the TV, and then turn on the home cinema. The first initial setup screen appears. The setup screens appear in this order: Language, Network Configuration, Terms and Conditions, Screen Resolution (Aspect Ratio). Follow the instructions displayed on each screen, which will guide you through the easy setup procedure. When the initial setup is completed, a tutorial screen guiding the Home menu will appear. To exit this screen, press the e (EXIT) button on the remote. ✎✎ To edit your settings after the initial setup, select Settings > System > Setup in the Home screen or select the Reset option. (See page 20) The Home Screen at a Glance 1 PLAY DISC App 1 App 2 3 MULTIMEDIA SAMSUNG APPS 4 App 4 Play photos, videos, or music content from Discs, USB devices, PCs, mobile devices. 3 SAMSUNG APPS Download/Access various for pay or free-of-charge applications. 4 RECOMMENDED A list of useful and popular apps we recommend you download. 5 MY APPS Displays downloaded and installed apps. You can change the display order. (See page 43) 6 Screen Mirroring Set up the wireless mirroring function between the home cinema and a smart phone or tablet. ✎✎ Depending on your country, this menu function 7 Source 2 Select the desired source such as Digital In, AUX, HDMI IN 1, HDMI IN 2, Tuner (FM Radio) or Bluetooth depending on what external device is connected and its status. You can also use the remote's SOURCE button or the main unit's button. 8 Settings MY APPS App 3 2 MULTIMEDIA may not be supported. No Disc RECOMMENDED Displays information about the disc currently in the disc tray. Press OK to start playing the disc. App 5 5 App 6 Screen Mirroring 6 Source Settings 7 8 Set various functions to suit your personal preferences. 14 - English 5V 0.5A `` Selecting an Option on the Home Screen To select an option on the Home screen, move the cursor using the 78:; buttons until it highlights the option of your choice, and then press the OK button. 3 than 5 minutes without using it, a screen saver appear on your TV. If the product is left in the screen saver mode for more than 20 minutes, the power will automatically turn off. OK / DIRECTION Button : ~~ Press 78:; to move the cursor or select an item. ~~ Press the OK button to activate the currently selected item or confirm a setting. 4 e (EXIT) Button : Press to exit the current menu. 1. ✎✎ If you leave the product in the stop mode for more Accessing the Settings Screen Select Settings on the Home screen, and then press OK. The Settings screen appears. Settings Picture Sound Network Smart Hub System Support 2. Picture UHD Output Auto 3D Settings TV Aspect Ratio 16:9 Original BD Wise Off ResolutionAuto Movie Frame (24 fps) Auto DVD 24 fps Conversion Off Settings Menu Functions UHD Output To access the menus, sub-menus, and options on the Settings screen, please refer to the remote control illustration below. Buttons on the Remote Control Used for the Settings Menu 1 3 2 Each Settings function, menu item, and individual option is explained in detail on-screen. To view an explanation, use the 78:; buttons to select the function, menu item, or option. The explanation will usually appear on the right of the screen. A short description of each Settings function starts below. Additional information on some of the functions is also in the Appendix of this manual. 4 1 HOME Button : Press to move to the Home screen. 2 ' (RETURN) Button : Press to return to the previous menu. Picture This option outputs HDMI video at UHD (Ultra High Definition) resolution. This is only available when Movie Frame is set to Auto. ✎✎ To use this feature, you must connect the product to a device that supports UHD resolution and you must have content that plays at 24 fps (film speed). 3D Settings Set up the 3D related functions. 3D Blu-ray Playback Mode: Select whether to play a Blu-ray Disc with 3D contents in 3D Mode. If you move to the Home or Smart Hub Home menu while in 3D mode, the product will switch to 2D automatically. Screen Size: Enter the size of the TV attached to the product. The product will automatically adjust the 3D output to the screen size of the TV. ✎✎ Carefully read the health and safety information 15 - English before viewing 3D content. (See page 3) Settings 1. Detailed Function Information Settings TV Aspect Ratio HDMI Colour Format Lets you adjust the output of the product to the screen size of your TV. (See page 50) Lets you set the colour space format for the HDMI output to match the capabilities of the connected device (TV, monitor, etc). BD Wise BD Wise is Samsung’s latest inter-connectivity feature. When you connect a Samsung product and a Samsung TV with BD Wise to each other via HDMI, and BD Wise is on in both the product and TV, the product outputs video at the video resolution and frame rate of the Blu-ray/DVD Disc. Resolution Lets you set the output resolution of the HDMI video signal to BD Wise, Auto, 1080p, 1080i, 720p, 576p/480p. The number indicates the number of lines of video per frame. The i and p indicate interlaced and progressive scan, respectively. The more lines, the higher quality. Lets you set the product to output video from the HDMI OUT jack with Deep Colour. Deep Colour provides more accurate colour reproduction with greater colour depth. Progressive Mode Lets you improve picture quality when viewing DVDs. Speaker Settings Movie Frame (24 fps) Setting the Movie Frame (24 fps) feature to Auto lets the product adjust its HDMI output to 24 frames per second automatically for improved picture quality if attached to a 24 fps compatible TV. ~~ You can enjoy the Movie Frame (24 fps) feature only on a TV supporting this frame rate. ~~ Movie Frame is only available when the product is in the HDMI 1080p output resolution modes. DVD 24 fps Conversion Converts DVD playback to 24 frames per second and outputs it via HDMI. This option is only available when Movie Frame (24 fps) is set to Auto. ✎✎ This feature applies to NTSC discs only. Fit Screen Size HDMI Deep Colour Sound Sound Output : Lets you select which speakers are active, either the TV's speakers or the home cinema's speakers. Settings (Home theatre speakers) : Lets you adjust the following speaker settings and turn the test tone on and off so you can test the speakers. -- Volume Level : Lets you adjust the relative loudness of each speaker from 6dB to -6dB. For example, if you like deep bass, you can increase the loudness of the subwoofer by 6dB. -- Distance : Lets you adjust the relative distance of each speaker from the listening position up to 9 meters. The farther the distance, the louder the speaker will be. -- Speaker Test : Begins a test to set the best surround sound configuration. Press Stop Test to stop the test while it is in progress. ✎✎ Speaker Test Order Front Left ; Front Right ; Centre ; Surround Left ; Surround Right ; Front Top Left ; Front Top Right ; Subwoofer Lets you select the optimal size for the Smart Hub or Screen Mirroring Screen. 16 - English Speaker Settings (Multiroom Link) : You can enjoy sound through a remote speaker that is connected to the home cinema through your home network. To use the network speaker, select Multiroom. If there is a network speaker available, it will appear on the screen. -- Don't Use : The network speaker is not used. -- Multiroom : The network speaker outputs audio. All network speakers output the same audio regardless of channel using the PCM format only. ✎✎ SOUND EFFECT and 3D SOUND are not Screen Mirroring is active. ✎✎ For further details, refer to the Multiroom Link manual from the web site. www.samsung.com > Support > Search for the product name > Multiroom Link > Download PDF Sound Customiser Sound Customiser lets you calibrate the home cinema for the optimal sound quality based on your hearing level and the ambient conditions. To create a Custom Sound Profile, follow these steps: 1. 2. 3. 4. In the Sound Customiser Menu, select Add Custom Sound. On the next screen, select Start. The Preview screen appears. Select Preview to preview the Test Sound. Select Next, and then press OK to continue. A 6-step test will start. During each stage, the TV will sound a test tone at a different frequency. The tone will begin softly and increase in volume. Select Yes when you can hear the test tone. If you want to listen to it again, select Retry. Each time you select Yes, the TV will move on to the next tone. Once the test is complete, a screen appears that lets you compare the original sound to the calibrated sound. 6. 7. Select Next, and then press the OK button to continue. The on-screen keyboard appears with a default profile name. Enter a name for the calibrated sound profile or accept the default name, select Done, and then press the OK button. Select Done on the next screen, and then press the OK button. The Sound Customiser screen reappears. Custom Sound Profile : Select a Sound Profile you created to activate it. Or select Hearing Impaired, a Custom Sound Profile especially composed of large sounds for those with hearing disorders. ✎✎ If there are more than 3 Custom Sounds registered, Family mode will be activated which is composed of the average value of all registered profiles. Add Custom Sound : Create and add a new Custom Sound Profile. See the instructions above. Edit Custom Sound : Choose a Custom Sound Profile to modify it. Follow the same steps you used when creating a sound profile. This function is only available if you have added a Custom Sound Profile using Add Custom Sound. (See above.) Manage Custom Sound : Rename or delete Custom Sound Profiles. This function is only available if you have added a Custom Sound Profile using Add Custom Sound. To select a profile, highlight the check box to the right of the profile, and then select Rename or Delete. Equaliser Lets you configure the Equaliser settings manually. Smart Volume Lets you set the product so that the volume remains stable when a scene change occurs or when you change the channel. 17 - English Settings applied if Multiroom is set to on. ✎✎ The network speaker is not available when 5. Settings Audio Return Channel Lets you direct the sound from the TV to the Home Cinema speakers. Requires an HDMI connection and an Audio Return Channel (ARC) compatible TV. ~~ If Audio Return Channel is set to On and you are using an HDMI cable to connect the product to the TV, digital optical input is disabled. ~~ If Audio Return Channel is set to Auto and you are using an HDMI cable to connect the product to the TV, ARC or digital optical input is selected automatically. Digital Output Lets you set the Digital Output to match the capabilities of the AV receiver you’ve connected to the product. For more details, please refer to the digital output selection table. (See page 56) Dynamic Range Control Lets you apply dynamic range control to Dolby Digital, Dolby Digital Plus, and Dolby TrueHD audio. Auto: Automatically controls the dynamic range of Dolby TrueHD audio, based on information in the Dolby TrueHD soundtrack. Also turns dynamic range control off for Dolby Digital and Dolby Digital Plus. Off: Leaves the dynamic range uncompressed, letting you hear the original sound. On: Turns dynamic range control on for all three Dolby formats. Quieter sounds are made louder and the volume of loud sounds is reduced. Downmixing Mode Lets you select the multi-channel downmix method that is compatible with your stereo system. You can choose to have the product downmix to Normal Stereo or to Surround Compatible. Audio Sync When the product is attached to a digital TV, lets you adjust the audio delay so that the audio syncs with the video. You can set the delay between 0 and 300 milliseconds. ✎✎ The Auto function in Audio Sync is guaranteed to work only with a Samsung TV that supports the ARC function (the Anynet+ function). Network Status Network Lets you check the current network and Internet status. Network Settings Lets you configure the network connection so you can enjoy various features such as Internet services or DLNA Wi-Fi functionality, and perform software upgrades. Wi-Fi Direct Lets you connect a Wi-Fi Direct device to the product using a peer-to-peer network, without the need for a wireless router. Note that if the product is connected to a wireless network, it may be disconnected when you use Wi-Fi Direct. (See page 24) ✎✎ Text files, such as files with a .TXT or .DOC extension, will not display when you are using the Wi-Fi Direct function. Multimedia Device Settings Allow other devices on your network, such as smart phones and tablets, to share content with your product. Device Name Lets you assign an identifying name to the product. You use this name to identify the product when you are connecting external Wi-Fi devices (smart phones, tablets, etc.) to it. 18 - English BD-Live Settings Lets you set various BD-Live functions. BD-Live allows you to access extra features available on some Blu-ray Discs if you are connected to the Internet. BD-Live Internet Connection : Lets you fully allow, partly allow, or prohibit a BD-Live Internet connection. BD Data Management : Manage BD data downloaded from a BD-Live service or Blu-ray Disc. ✎✎ To use BD-Live, you must insert a USB storage Caption Use to modify captions on VOD playback that supports closed captions. Lets you change displayed caption's font colour and size. ✎✎ The Caption function does not work with VOD services that don't support closed captions. For some VOD services that do support closed captions, the functions settings may not be applied. ✎✎ Depending on your country, this menu function may not be supported. Terms & Policy Samsung account Terms and Conditions, Privacy Policy You can view the terms of use and privacy policy for Smart Hub, Samsung accounts, and various other services. Resets all Smart Hub settings to their default settings. To use, you must enter the security PIN. Press and hold the 123 button until the Num pad appears on the screen. When the Num pad appears, select a number using the 78:; button and then press the OK button. ✎✎ The default security PIN is 0000. Quick start Lets you set the product to turn on quickly by decreasing the boot time. ✎✎ If this function is set to On, Standby power consumption will increase. (About 12W ~ 20W) Language Lets you select the language you prefer for the onscreen menu, disc menu, audio, subtitles, etc. ~~ The language you select for the disc menu, disc audio, or subtitles will only appear if it is supported on the disc. Smart Hub Reset Smart Hub Lets you re-run the Initial Settings procedure. Refer to the descriptions displayed on the screen. Device Manager Lets you connect a wireless USB keyboard or mouse to the USB port on the front of the product. Keyboard Settings: Lets you configure a wireless USB keyboard connected to the product. ✎✎ You can use the keyboard only when a QWERTY keyboard screen or window appears in the Web Browser. Mouse Settings: Lets you configure a wireless USB mouse connected to the product. You can use the mouse in the product's menu in the same way you use a mouse on your PC. `` To use a mouse with the product's menu: 1. Connect the USB mouse to the product. 3. Click the menu options you want. 2. Click the primary button you selected in Mouse Settings. The Simple Menu appears. ✎✎ Some USB HID keyboards and mice may not be compatible with your product. ✎✎ Some HID keyboard keys may not work. ✎✎ Wired USB keyboards are not supported. ✎✎ Some applications may not be supported. 19 - English Settings device into the home cinema's USB port. Setup System Settings ✎✎ If a wireless HID Keyboard does not operate because of interference, move the keyboard closer to the product. Security Press and hold the 123 button until the Num pad appears on the screen. When the Num pad appears, select a number using the 78:; button and then press the OK button. The default security PIN is 0000. Enter the default PIN to access the security function if you haven't created your own PIN. BD Parental Rating: Prevents playback of Blu-ray Discs with a rating equal to or above a specific age rating you have set unless you enter the PIN. DVD Parental Rating: Prevents playback of DVDs with a rating above a specific numerical rating you have set unless you enter the PIN. Change PIN: Lets you change the 4-digit PIN used to access security functions. `` If you forget your PIN 1. 2. Remove any disc or USB storage device. Press and hold the @ button on the front panel for 5 seconds or more. All settings will revert to the factory default settings. ✎✎ When the factory default settings are restored, all the user stored BD data is deleted. General Lets you specify the display brightness and time zone. Front Display: Lets you change the brightness of the front panel. Time Zone: You can specify the time zone that is applicable to your area. Menu Transparency: Lets you adjust the transparency of the menu box. Anynet+ (HDMI-CEC) Anynet+ is a convenient function that offers linked operations with other Samsung products that have the Anynet+ feature, and lets you control those products with one Samsung TV remote. To operate this function, you must connect this product to an Anynet+ Samsung TV using an HDMI cable. To use an Anynet+ (HDMI-CEC) function, follow the instructions below. 1) Connect the product to an Anynet+ (HDMICEC)-compliant Samsung TV using HDMI Cable. 2) Set the Anynet+ (HDMI-CEC) feature to On in both the TV and the product. 3) Search for and then select the product in the TV's Anynet+ (HDMI-CEC) list. For more exact instructions, see the Anynet+ section of the TV's user's manual. DivX® Video On Demand View DivX® VOD Registration Codes to purchase and play DivX® VOD contents. Support Remote Management When activated, lets Samsung Call Centre agents diagnose and fix problems with the product remotely. Requires an active Internet connection. Remote Management service might not be available in some countries. Software Update For more information about the Software Update function, see "Upgrading Software" on page 25. Usage Mode Lets you set the Usage Mode. If you are using the home cinema at home, always select Home Use. Store Demo is for retail display settings only. Contact Samsung Provides contact information for assistance with your product. Reset Reverts all settings to their defaults except for the network and Smart Hub settings. Requires that you enter your security PIN. Press and hold the 123 button until the Num pad appears on the screen. When the Num pad appears, select a number using the 78:; button and then press the OK button. The default security PIN is 0000. 20 - English ~~ To tune to a preset station, press the PRESET button to select PRESET, and then press the 78 buttons to select the preset station. Radio Setup ~~ To listen to the radio, you must connect the supplied FM antenna. Recording FM Radio Operating the Radio with the Remote Control 1. 2. Press the SOURCE button to select FM. Selecting Mono or Stereo Press the ST/MO button. ~~ Each time you press the button, the sound switches between STEREO and MONO. ~~ In a poor reception area, select MONO for a clear, interference-free broadcast. Presetting Stations Example : Presetting FM 89.10 into memory. 1. Press the SOURCE button to select FM. 3. Press the MEMORY button. ~~ NUMBER flashes on the display. Press the MEMORY button again. ~~ Press the MEMORY button before NUMBER disappears from the display on its own. ~~ After you press the MEMORY button, NUMBER disappears from the display and the station is stored in memory. 2. 4. 5. Press the 78 buttons to select <89.10>. To preset another station, repeat steps 2 to 4. 1. Insert a USB device into the USB jack on the front of the product. 2. Press the SOURCE button to select FM, and then then press the 78 buttons to select the station you want to record. 3. Press the A (Red) button to start recording the radio broadcast. Recording begins. ~~ The recorded time is displayed on the left and the recording time still available, based on the amount of free space in the USB storage device, is displayed on the right. D H-EN HIG D H-EN HIG 4. VACUUM TUBE SO UND VACUUM TUBE SO UND Press the e (EXIT) button to finish your recording. The recording is stopped and saved as an .mp3 file at the same time. To play the recorded file, refer to "Playing Files on a Storage Device". ✎✎ The recorded file is saved in the Tuner folder which is created automatically. ✎✎ Only the (OPEN/CLOSE), (POWER), e (EXIT), (MUTE), and VOL +/-, buttons are operable while FM radio is being recorded. ✎✎ If you don't press any buttons while recording, the screen saver will be enabled. ✎✎ Sound effects, such as DSP, EQ, etc., are not recorded during FM radio recording. ✎✎ The radio is recorded at a set, default volume even if you change the volume or press the (MUTE) button during the recording process. ✎✎ If you remove the USB device or Power Cable during the recording process, the portion of the file which has already been recorded may not play back. ✎✎ Recording will not start if the remaining free space in the USB storage device is less than 2MB. ✎✎ If the USB device is removed or has insufficient space (under 2MB), the appropriate message is displayed and the recording stops. 5V 0.5A 5V 0.5A 21 - English Settings Tune to the desired station. ~~ Preset Tuning 1 : Press the PRESET button to select PRESET, and then press the 78 buttons to select a preset station. -- Before you can tune to preset stations, you must add preset stations to the product's memory. ~~ Manual Tuning : Press the PRESET button to select MANUAL, and then press the 78 buttons to tune to a lower or higher frequency. ~~ Automatic Tuning : Press the PRESET button to select MANUAL, and then press and hold the 78 buttons to automatically search the band. You can record your favorite radio broadcast on a inserted USB storage device. Settings Network Setup ĞĞ When you connect this product to a network, you can use network based applications and functions such as Smart Hub and BD-LIVE, and upgrade the product's software through the network connection. For more information about accessing and using Internet services, see the Network Services chapter of this manual on pages 42~49. Instructions for configuring the network connection start below. Configuring Your Network Connection If you didn't configure your network connection during the initial settings procedure or you need to reset the network connection, follow the directions below. Before you begin, contact your Internet Service Provider to find out if your IP address is static or dynamic. If it is dynamic, and you have a wired or wireless network, we recommend using the Automatic configuration procedures described below. If you are connecting to a wired network, connect the product to your router using a LAN cable before you start the configuration procedure. To begin configuring your network connection, follow these steps: 1. 2. 3. 4. In the Home screen, select Settings, and then press the OK button. Select Network, and then press the OK button. Select Network Settings, and then press the OK button. Go to the instructions for Wired networks starting or the instructions for Wireless networks starting on page 23. Wired Network ĞĞ Wired - Manual If you have a static IP address or the automatic procedure does not work, you'll need to set the Network Settings values manually. After following Steps 1 to 3 above: 1. In the Network Settings screen, change Network type to Wired. Then, select Connect and press the OK button. The product searches for a network, and then displays the connection failed message. ✎✎ If it is possible to connect the home cinema to your network wirelessly, select Change Network at this point, change the Network type to Wireless, and then go to the instructions for wireless networks on the next page. Network Settings Wired network connection failed. MAC Address IP Address Subnet Mask Gateway DNS Server Unable to connect to the network. Try the following: check if your IP address is set correctly in IP Settings. Contact your Internet service provider for more information. Change Network 2. 3. 4. Wired – Automatic After following Steps 1 to 3 above: 1. 2. In the Network Settings screen, change Network type to Wired. Then, select Connect and press the OK button. The product detects the wired connection, verifies the network connection, and then connects to the network. When it is done, highlight OK, and then press OK button. XX:XX:XX:XX:XX:XX 0. 0. 0. 0 0. 0. 0. 0 0. 0. 0. 0 0. 0. 0. 0 5. 22 - English IP Settings Retry Close Use the :; buttons to select IP Settings, and then press the OK button. The IP Settings screen appears. Select the IP setting field, and then set it to Enter manually. Select a parameter to enter (IP Address, for example), and then press OK. Use the 78 buttons on the remote control to enter the numbers for the parameter. Or use the Num keypad to enter a parameter number. Press and hold the 123 button until the Num pad appears on the screen. When the Num pad appears, select a number using the 78:; button and then press the OK button. Use the :; buttons on the remote control to move from entry field to entry field within a parameter. When done with one parameter, press the OK button. Press the 7 or 8 button to move to another parameter, and then enter the numbers for that parameter following the instructions in Step 4. 6. Repeat Steps 4 and 5 until you have filled in all parameters. ✎✎ You can get the network parameter values from 7. your Internet provider. When finished entering all the parameter values, select OK, and then press the OK button. The home cinema verifies the network connection and then connects to the network. Wireless Network ĞĞ Wireless - Automatic After following Steps 1 to 3 in "Configuring Your Network Connection" on page 22: 1. When finished, select Done, and then press the OK button. The product verifies the network connection and then connects to the network. ✎✎ You should be able to find the security code or pass phrase on one of the set up screens you used to set up your router or modem. ĞĞ Wireless - Manual If you have a static IP address or the Automatic procedure does not work, you'll need to set the Network Settings values manually. After following Steps 1 to 3 in "Configuring Your Network Connection" on page 22: 1. 2. 3. 4. In the Network Settings screen, change Network type to Wireless. The product searches for and then displays a list of the available networks. Network Settings Select your network type. Network type Wireless network Wireless si-ap You can connect your Bluray player to the internet. Please select which wireless network to use. iptime KIMING_VTOWER Refresh 2. 3. 5. WPS(PBC) Select the desired network, and then press the OK button. On the Security screen, enter your network's security code or pass phrase. Enter letters by selecting a letter with 78:; buttons, and then pressing OK button. 23 - English In the Network Settings screen, change Network type to Wireless. The product searches for and then displays a list of the available networks. Scroll through the list, select the desired network or Add Network, and then press the OK button. If you selected a network in Step 2, go to Step 6. If you selected Add Network, go to Step 4. Enter your wireless network or wireless router's name. ~~ Enter letters by selecting a letter with the 78:; buttons, and then pressing the OK button. ~~ To display capital letters (or redisplay lower case letters if capital letters are displayed), , and then press the OK button. select ~~ To display symbols and punctuation, select 123#&, and then press the OK button. To redisplay letters, select 123#&, and then press the OK button. When finished, select Done, and then press the OK button. On the Security type screen that appears, use the ,. buttons to select the network's Security type, and then press the OK button. On the next screen, enter your network's security code or pass phrase. ~~ Enter letters by selecting a letter with the 78:; buttons, and then pressing the OK button. When finished, select Done, and then press the OK button. The product searches for the network. Settings You can set up a wireless network connection in three ways: -- Wireless Automatic -- Wireless Manual -- WPS(PBC) Before you configure the wireless network connection, disconnect any wireless network devices currently connected to the product or, if applicable, the product's current wired connection. 4. Settings 6. 7. 8. 9. The Network connection fail screen appears. Use:; buttons to select IP Settings, and then press the OK button. Select the IP setting field, and then set it to Enter manually. Select a network parameter to enter (IP Address, for example), and then press OK button. Use the 78 buttons on the remote control to enter the numbers for the parameter. Or use the Num keypad to enter a parameter number. Press and hold the 123 button until the Num pad appears on the screen. When the Num pad appears, select a number using the 78:; button and then press the OK button. Use the :; buttons on the remote control to move from entry field to entry field within a parameter. When done with one value, press the OK button. Press the , or . button to move to another parameter, and then enter the numbers for that parameter following the instructions in Step 8. 10. Repeat Steps 8 and 9 until you have filled in all parameters. ✎✎ You can get the Network parameter values from your Internet provider. 11. When finished, select OK, and then press the OK button. The Security screen appears. 12. On the Security screen, enter your network's security code or pass phrase. Enter letters by selecting a letter with the 78:; buttons, and then pressing the OK button. 13. When finished, select Done at the right of the screen, and then press the OK button. The product verifies the network connection and then connects to the network. 14. After the home cinema verifies the network, select OK, and then press the OK button. ✎✎ You can also begin the Manual Network setup by going to Settings > Network > Network Status. ĞĞ WPS(PBC) 1. In the Network Settings screen, change Network type to Wireless. The product searches for and then displays a list of the available networks. 2. Scroll the list down, select WPS(PBC), and then press the OK button. 3. Press the WPS(PBC) button on your router within two minutes. Your product automatically acquires all the network settings values it needs and connects to your network after the network connection is verified. 4. When it is done, highlight OK, and then press the OK button. ✎✎ For a WPS connection, set your wireless router’s security encryption to AES. WEP security encryption does not support a WPS connection. Wi-Fi Direct The Wi-Fi Direct function allows you to connect Wi-Fi Direct devices to the product and each other using a peer-to-peer network, without a wireless router. ✎✎ Some Wi-Fi Direct devices may not support the DLNA function if connected via Wi-Fi Direct. If this is the case, change the network connection method you used to connect the device to the home cinema. ✎✎ Wi-Fi Direct transmissions can interfere with Bluetooth signals. Before you use the Bluetooth function, we strongly recommend that you turn off the Wi-Fi Direct function on any device in which it is currently on. 1. Turn on the Wi-Fi Direct device and activate its Wi-Fi Direct function. 2. 3. 4. One of the easiest ways to set up the wireless network connection is using the WPS(PBC) function. If your wireless router has a WPS(PBC) button, follow these steps: After following Steps 1 to 3 in "Configuring Your Network Connection" on page 22: 24 - English In the Home screen, select Settings, and then press the OK button. Select Network, and then press the OK button. Select Wi-Fi Direct, and then press the OK button. The Wi-Fi Direct devices that you can connect the home cinema to appear. Settings 2. 3. Wi-Fi Direct Device Name : [HTS]J7750W Select your Wi-Fi Direct device to connect to. AndroidXXXXXXX The PIN pop-up appears. Note the PIN code in the pop-up, and then enter it into the appropriate field in the Wi-Fi Direct device you want to connect. The Connecting pop-up appears, followed by the Connected pop-up. When it closes, you should see the device listed as connected on the Wi-Fi Direct screen. 4. Disconnected Refresh Close will be disconnected when you use the Wi-Fi Direct function. ✎✎ Text files, such as files with a .TXT or .DOC extension, will not display when you are using the Wi-Fi Direct function. You have three ways to complete the Wi-Fi connection: ~~ Through the Wi-Fi device. ~~ Through the product using PBC. ~~ Through the product using a PIN. Upgrading Software The Software Update menu allows you to upgrade the product’s software for performance improvements or additional services. Each is covered below. Through the Wi-Fi Device 1. 2. 3. On the Wi-Fi device, follow the device's procedure for connecting to another Wi-Fi Direct device. See the device's user manual for instructions. When you have completed the procedure, you should see a pop-up on your TV screen saying that a device that supports Wi-Fi Direct has requested to connect. Select OK, and then press the OK button to accept. The Connecting pop-up appears, followed by the Connected pop-up. When it closes, you should see the device listed as connected on the Wi-Fi Direct screen. ~~ The PBC and PIN procedures connect devices automatically. Through the Product Using PBC 1. 2. Select the Wi-Fi Direct device you want to connect to this product, and then press the OK button. The Connecting pop-up appears, followed by the Connected pop-up. When it closes, you should see the device listed as connected on the Wi-Fi Direct screen. Through the Product Using a PIN 1. Select the Wi-Fi Direct device you want to connect to this product, and then press the OK button. ~~ Never turn the product off or back on manually during the update process. 1. In the Home menu, select Settings, and then press the OK button. 2. Select Support, and then press the OK button. 3. Select Software Update, and then press the OK button. 4. To download update software and update now, select Update now, and then press the OK button. See "Update now" on the next page for details. 5. To let the product download update software automatically when available, select Auto update, and then press the OK button. (See page 26) ✎✎ The upgrade is complete when the product turns off, and then turns on again by itself. ✎✎ Samsung Electronics takes no legal responsibility for product malfunction caused by an unstable Internet connection or consumer negligence during a software upgrade. ✎✎ If you want to cancel the upgrade while the upgrade software is downloading, press the OK button. ✎✎ When a system upgrade is in progress, "UPDATE" is displayed on the front panel. 25 - English Settings 5. ✎✎ The current wired or wireless network connection Settings Update now Select Support > Software Update > Update now. An online upgrade downloads and installs the upgrade software directly from the Internet. ✎✎ This option requires an Internet connection. ✎✎ When the system upgrade is done, check the Update by USB 1. Visit Samsung's website on a computer and download the update package to a USB device. ✎✎ Save the update package in the USB device's top-level folder. Otherwise, the product will not be able to locate the update package. software details in the Product Information section of the Contact Samsung screen. ✎✎ Do not turn off the product during the Software Upgrade. It may cause the product to malfunction. 2. You can set the Auto update function so that the product downloads new upgrade software when it is in Auto update mode. In Auto update mode, the product is on, but its Internet connection is active. This allows the product to download upgrade software automatically, when you are not using it. ✎✎ There should be no disc in the product when you Auto update 1. 2. Press the 78 buttons to select Auto update mode, and then press the OK button. Select On or Off. If you select On, the product will automatically download new upgrade software when it is in Auto update mode with the power on. If it downloads new upgrade software, the product will ask you if you want to install it when you turn the product on. Connect the USB device with the update package to the product. 3. Select Support > Software Update > Update now. The software is updated using the update package on the USB device. upgrade the software using the USB jack. ✎✎ When the system upgrade is done, check the software details in the Product Information section of the Contact Samsung screen. ✎✎ Do not turn off the product during the software upgrade. It may cause the product to malfunction. ✎✎ Software upgrades using the USB jack must be performed with a USB flash drive only. ✎✎ To use the Auto update function, your product must be connected to the Internet. 26 - English Playing Content Your home cinema can play content located on Bluray/DVD/CD discs, USB devices, PCs, smart phones, tablets, and on the Web. To play content located on your PC or a mobile device, you must connect the PC or mobile device and the product to your network. To play content on your PC, you must also download and install DLNA network software or already have DLNA network software on your PC. ✎✎ PCs running Windows 7 and Windows 8 have DLNA software (Play To) built in. Playing Commercial Discs 1. Playing Multimedia Files 1. In the Home screen, select MULTIMEDIA, and then press the OK button. The Recently Played screen appears. 2. Press the ^ button to open the disc tray. Select Storage, Network Device at the bottom of the screen. ~~ Storage - Displays storage devices connected to the product. ~~ Network Device - Displays mobile devices, PCs, tablets, and similar devices connected through the network. Place a disc gently into the disc tray with the disc’s label facing up. ✎✎ When you select an item, information about the 3. 4. 3. Press the ^ button to close the disc tray. Playback starts automatically. If playback does not start automatically, press the p button on the remote. Disc Storage & Management ~~ Holding Discs -- Fingerprints or scratches on a disc may reduce sound and picture quality or cause skipping. -- Avoid touching the surface of a disc where data has been recorded. -- Hold the disc by the edges so that fingerprints will not get on the surface. -- Do not stick paper or tape on the disc. ~~ Cleaning Discs -- If you get fingerprints or dirt on a disc, clean it with a mild detergent diluted in water and wipe with a soft cloth. item scrolls across the bottom of the item's listing window. Select an item or device, and then press the OK button. A screen appears listing the contents of the item or device. Depending on how the contents are arranged, you will see either folders, individual files, or both. 4. If necessary, use the 78:; buttons to select a folder, and then press the OK button. 5. Use the 78:; buttons to select a file to view or play, and then press the OK button. 6. The selected file plays. 7. Press the ' (RETURN) button to exit a folder or the e (EXIT) button to return to the Home screen. 8. Go to pages 29~41 for instructions that explain how to control playback of videos, music, and pictures on a storage device. ✎✎ To list only one type of media file, use the Filter ( ) function in the top-right corner of the item or device screen. 27 - English Playing Content 2. -- When cleaning, wipe gently from the inside to the outside of the disc. -- Disc Storage `` Do not keep in direct sunlight. `` Keep in a cool ventilated area. `` Keep in a clean protective jacket and store vertically. Playing Content ✎✎ In the Filter( ) drop down, select Photos, Videos, or Music. ✎✎ Even though the product will display folders that contain all content types, it will only display files of the content type you selected For example, if you selected Music, you will only be able to see music files. Playing Files on a Storage Device Method 1 : If the product is turned on after Turn the product on. 2. Follow the directions in “Playing Multimedia Files” on page 27. In Step 2, select Storage. Method 2 : If you connect a USB device while the product is turned on 1. Connect the storage device to the product. (a recorded CD, a USB device, etc.) The "New device connected." pop-up appears. If two or more storage devices are connected, use the :; buttons to switch between devices. PLAY DISC MULTIMEDIA New device connected. All App 2 MY APPS App 4 App 5 App 6 Screen Mirroring Source Settings ✎✎ If the pop-up does not appear, go to Method 1. 2. ) drop down, select Photos, Videos, or Music. ✎✎ Even though the product will display folders that contain all content types, it will only display files of the content type you selected For example, if you selected Music, you will only be able to see music files. 4. 5. 6. If necessary, use the 78:; buttons to select a folder, and then press the OK button. Select a file to view or play, and then press the OK button. Press the ' (RETURN) button to exit a folder or the e (EXIT) button to return to the Home screen. Go to pages 29~41 for instructions that explain how to control playback of videos, music, and pictures on a storage device. ✎✎ If you insert a disc while playing a USB device or phone, the device mode changes to "Disc" automatically. ✎✎ If your cellular phone is DLNA compatible, you can play content on the phone without connecting a USB cable. You can play media content on the Home cinema that is stored on a computer or mobile device connected to the same network as the Home cinema. Music App 3 ✎✎ In the Filter( Playing Media Content Saved on a Computer/Mobile Device STORAGE DEVICE Videos RECOMMENDED App 1 SAMSUNG APPS Photos No Disc Filter( ) function in the top-right corner of the item or device screen. 3. you connect a storage device 1. ✎✎ To list only one type of media file, use the Use the 78 buttons to select All, Photos, Videos, or Music, and then press the OK button. Depending on how the contents are arranged, you will see either folders, individual files, or both. ✎✎ You may experience compatibility issues when attempting to play media files via a third-party DLNA server. ✎✎ The content shared by a computer or a mobile device may not play depending on the encoding type and file format of the content. In addition, some functions may not be available. ✎✎ The media content may not play smoothly depending on the network status. If this occurs, use a USB storage device. 28 - English 1. 2. 3. 4. 5. 6. Select Network Device at the bottom of the screen, and then press the OK button. Storages devices connected to the same network as the Home cinema are listed. Select a storage device, and then press the OK button. The folders and files shared by the selected storage device are listed. If necessary, use the 78:; buttons to select a folder, and then press the OK button. Controlling Video Playback You can control the playback of video content located on a Blu-ray/DVD disc, USB device, mobile device, or PC. Depending on the disc or contents, some of the functions described in this manual may not be available. Buttons on the Remote Control used for Video Playback Select a file to view or play, and then press the OK button. 1 Press the ' (RETURN) button to exit a folder or the e (EXIT) button to return to the Home screen. 2 Go to pages 29~41 for instructions that explain how to control playback of videos, music, and pictures on a storage device. ✎✎ To list only one type of media file, use the Filter( ) function in the top-right corner of the item or device screen. ✎✎ In the Filter( ) drop down, select Photos, Videos, or Music. ✎✎ Even though the product will display folders that contain all content types, it will only display files of the content type you selected For example, if you selected Music, you will only be able to see music files. ✎✎ Alternatively, move to the media content to play and press the OK button to play the content. 1 Using the disc menu, title menu, popup menu, and title list DISC MENU During playback, press this button to display the Disc menu. TITLE MENU During playback, press this button to display the Title menu or Popup menu. ~~ If your disc has a playlist, press the Sort By button to go to the playlist. 2 Playback related buttons The product does not play sound in Search, or Slow mode. ~~ To return to normal speed playback, press the p button. 29 - English Playing Content 7. In the Home screen, select MULTIMEDIA, and then press the OK button. Playing Content p e (EXIT) Select Scene Starts/Pauses playback. Stops playback. Fast Motion Play During playback, press and hold the [ or ] button. Each time you press and hold the [ or ] button, the playback speed will change. Slow Motion Play In pause mode, press and hold the ] button. Each time you press and hold the ] button, the playback speed will change. Skip Motion Play During playback, press the [ or ] button. Each time you press the [ or ] button, the disc moves to the previous or next chapter or file. Using the TOOLS Menu You can use the Select Scene function during playback to view or start a movie from the scene of your choice. ✎✎ If the index information in the file is damaged or the file does not support indexing, you will not be able to use the Select Scene function. ✎✎ If you are using the DLNA function after connecting to a computer through your network, Select Scene may not be supported. Search Titles : If there is more than one movie on the disc or device, select to start a different title. 1. Select Search Titles, and then press the OK button. 2. Use the 78 buttons to select a title, and then press the OK button. ✎✎ To search in a DVD title, press and hold the TOOLS button while playback is stopped. Enter the number 00 and then desired chapter/ track number (01, 02, … etc.). Chapter Search : Select to play the chapter of your choice. Commercial Discs During playback, press the TOOLS button. 1. Select Chapter Search, and then press the OK button. File-based Video During playback, press the TOOLS button. Use the :; buttons to select Settings(T) in the upper right corner, and then press the OK button. Play from the beginning Select to return to the beginning of the movie, and then press the OK button. 3D Use 3D menu to select the Side by Side or Top Bottom option if the 3D content currently playing does not appear properly in 3D mode. 2. Use the 78 buttons to select a chapter, and then press the OK button. Search Time Bar : Select to play the movie from a selected time point. 1. Select Search Time Bar, and then press the OK button. 2. Press and hold the 123 button until the Num pad appears on the screen. When the Num pad appears, select a number using the ,.:; button and then press the OK button. ✎✎ You can also use the:; buttons to advance ✎✎ Use 3D menu for 3D content only. If you apply the Side by Side or Top Bottom format to 2D content, it will not be displayed properly. 30 - English or rewind the movie. The movie advances or rewinds one minute each time you press the :; buttons. Repeat Mode Lets you repeat a title, chapter, or specific section. -- Off : Select to return to normal playback. -- Title : Choose to repeat a selected title. -- Chapter : Choose to repeat a specific chapter. -- Repeat A-B : Choose to repeat a specific section. 1. 2. Press the OK button at the point where you want repeat play to start (A). Press the OK button at the point where you want repeat play to stop (B). ✎✎ Depending on the disc, the screen may not display all repeat options. when you play a video recorded as a digital file. ✎✎ The screen may not display Chapter or Lets you set the equaliser. ✎✎ Equaliser Settings only appears when Equaliser Mode is On. Audio Select to set the desired audio language. Audio Sync In some cases when the product is connected to a digital TV, the audio signal may not synchronize with the video signal. If this occurs, use Audio Sync to adjust the audio delay time to match the video signal. Subtitle Title immediately. Continue to press the 78 buttons until your choice is inside the applicable field. ✎✎ The screen may not display Repeat A-B immediately. Continue to press the 78 buttons until Repeat A-B is inside the applicable field. ✎✎ You must set point (B) at least 5 seconds of playing time after point (A). Lets you set the desired subtitle language. Lets you set the Picture Mode. -- Dynamic : Increases sharpness and brightness. -- Standard : Choose this setting for most viewing applications. -- Movie : The best setting for watching movies. -- User : Lets you adjust the sharpness and noise reduction function respectively. Lets you set the desired Bonusview option. Picture Mode ✎✎ When you use the BD Wise function, this menu will not appear. Equaliser Mode Set Equaliser Mode on to use the equaliser. Subtitle Settings Lets you set the desired subtitle options. Angle To view a scene from another angle. The Angle option displays the number of angles available to view (1/1, 1/2, 1/3, etc.). BONUSVIEW Video BONUSVIEW Audio Rotate You can rotate the screen clockwise or counterclockwise by 90 degrees. Full Screen Lets you set the size of the video image. Choose Original, Mode1 (larger), or Mode2 (largest). Information Select to view video file information. ✎✎ Depending on the disc or storage device, the Tools menu may differ. ✎✎ Video files with high bitrates of 20Mbps or more strain the product’s capabilities and may stop playing during playback. 31 - English Playing Content ✎✎ Off, Repeat One, and Repeat All appear Equaliser Settings Playing Content Using the Sort By & Options Menus Select the Filter( ) function, and then Videos to display videos only. ✎✎ Even though the product will display folders that contain all content types, it will only display files of the content type you selected For example, if you selected Videos, you will only be able to see video files. On the screen that lists the video files, use the 78:; buttons to select Sort By or Options in the upper right, and then press the OK button. Sort By Videos `` Date Displays all the folders with videos by date. If you select a folder, and then press OK button, displays all the video files in the folder by date. `` Title Displays all the video files on the media or storage device by title. `` Folder Displays all the folders on the media or storage device. ✎✎ The Sort By and Options menus are usually available when you are viewing video files on a USB flash drive, a PC, a disc you recorded yourself, or a mobile device. They are usually not available if you are viewing a commercial Blu-ray, DVD, or CD disc. Controlling Music Playback You can control the playback of music content located on a DVD, CD, USB, mobile device, or PC. Depending on the disc or contents, some of the functions described in this manual may not be available. Buttons on the Remote Control used for Music Playback 4 13 2 Options `` Play Selected Play Selected lets you create a playlist by selecting specific files to play. It works essentially the same way for all media. See "Using Play Selected with a Commercial CD" on page 35. `` Send Select Send to upload selected files to on-line sites (Picasa, Facebook, etc.) or to devices. To use Send with an on-line site, you need to establish an account with the on-line site, and then log in using the Log In function. Send works essentially the same way for music, photos, and videos. For general instructions, see "Using the Send Function" on page 40. 1 [ ] buttons : Move to the previous/ next track. 2 e (EXIT) button : Stops a track. 3 Fast Play (Audio CD [CD-DA] only) During playback, press and hold the [ or ] button. Each time you press and hold the [ or ] button, the playback speed will change. 4 p button : Plays/Pause a track. ✎✎ Depending on the disc or storage device, the Options and Sort By menus may differ. All options may not be displayed. 32 - English Music Screen Controls TRACK 001 TRACK 002 TRACK 003 TRACK 004 TRACK 005 TRACK 006 TRACK 001 TRACK 007 TRACK 008 00:00/00:00 TRACK 009 TRACK 010 1 00:43 03:56 , 1 1 04:41 03:43 Display the Equaliser. 03:40 04:06 03:52 03:04 04:02 To access the controls, play a track, and then use the 78:; buttons to move to the control of your choice. ✎✎ The music screen controls are only accessible TRACK 001 when a track is playing. 00:03:35 On the Track List screen, use 78 buttons to move the highlight to the track you want. Press the OK button to play the track. On Screen Music Controls Pause a track. Play a track. 1 1 ✎✎ All controls do not appear at the same time. ✎✎ For file-based contents, the available Settings ( Select the Filter( ) function, and then Music to display music files only. ✎✎ Even though the product will display folders that contain all content types, it will only display files of the content type you selected For example, if you selected Music, you will only be able to see music files. Move to the previous track. Rewind the track. 33 - English 1 ) options will differ. Using the Sort By & Options Menus Move to the next track. 1 Equaliser Settings : Adjust the equaliser manually. (Available only when Equaliser Mode is on) Play Selected : Play Selected lets you select specific files to play. It works essentially the same way for all media. See "Using Play Selected with Self-Recorded Media (CDs, USB Devices, etc.)" on page 35. Ripping : The Ripping function converts CD audio to the mp3 format and saves the converted files on a USB device or a mobile device connected to the product. See Ripping on page 37. Information : Shows the track information. Playing Content On the Music List screen only. 00:00:40 Repeat one track or all tracks. Play tracks in random order. 04:02 1 The Track List screen appears initially, and the first track begins to play. If you are playing a commercially recorded disk and don't press a button on the remote momentarily, the Playback screen appears. To return to the Track List screen, press the ' (RETURN) button. Advance the track. Playing Content On the screen that lists the music files, use the 78:; buttons to select Sort By or Options in the upper right, and then press the OK button. Sort By Music `` Track Displays all the music tracks on the media or storage device. `` Album Displays all the music on the media or storage device by album. `` Artist Displays all the music files on the media or storage device by artist `` Genre Displays all music on the media or storage device by genre. `` Folder Displays all the folders on the media or storage device. Options `` Play Selected Play Selected lets you select specific files to play. It works essentially the same way for all media. See "Using Play Selected with a Commercial CD" on page 35 and "Using Play Selected with Self-Recorded Media (CDs, USB Devices, etc.)" on page 35. `` Send Select Send to upload selected files to on line sites (Picasa, Facebook, etc.) or to devices. To use Send, you need to establish an account with the on-line site, and then log in using the Log In function. Send works essentially the same way for music, photos, and videos. For general instructions, see "Using the Send Function" on page 40. `` Encoding Select to manage the text encoding options. `` Rename Playlist Lets you modify the name of a playlist. `` Delete Playlist Lets you delete a playlist. `` Add to Playlist Lets you add additional files to a playlist. ✎✎ Depending on the disc or storage device, the Options menu may differ. All options may not be displayed. ✎✎ Rename Playlist and Delete Playlist appear only if a playlist exists. Repeating Tracks on an Audio CD You can set the product to repeat tracks on an audio CD (CD-DA/MP3). 1. On the Track List screen during playback, use in the lower the 78:; buttons to select left corner of the screen, and then press the OK button. 1 2. Use the 78 to select the Repeat mode you want - Off, One Song, or All - and then press the OK button. TRACK 001 TRACK 002 TRACK 003 TRACK 004 TRACK 005 TRACK 006 TRACK 001 TRACK 007 TRACK 008 00:00/00:00 TRACK 009 TRACK 010 00:43 03:56 04:41 04:02 03:43 03:40 04:06 03:52 03:04 04:02 Track List screen TRACK 001 00:00:40 Playback screen Press the ' (RETURN) button on the remote to return to the Track List screen. 34 - English 00:03:35 Shuffling Tracks on an Audio CD - Use Clear All to deselect all selected tracks at once. Then, select individual tracks or use Select All to select all the tracks, and then press the ' (RETURN) button on your remote or select Play and then press the OK button. If you do not use Select All or select individual tracks, the Play Selected list will not change. You can set the product to play tracks on an audio CD (CD-DA/MP3) at random. 1. 2. During playback, use the ,.:; buttons to in the lower left corner of the screen, select and then press the OK button. Use the 78 to set the Shuffle mode Off or On, and then press the OK button. Using Play Selected with a Commercial CD 1. 3. 4. 5. 6. 7. On the Track List screen, select Settings ( on the bottom left, and then press the OK button. The Settings menu appears. ) Select Play Selected, and then press the OK button. The Play Selected screen appears. Use the 78 buttons to select a track, and then press the OK button. A check appears to the left of the track. Repeat Step 3 to select and check additional tracks. To remove a track from the list, move to the track, and then press the OK button again. The check on the track is removed. When done, select Play on the bottom left, and then press the OK button. The Track List screen reappears listing only the tracks you checked. The selected tracks play automatically. To cancel the Play Selected list, select Settings ( ) on the bottom left of the Track list screen. On the Settings menu select Play All. The Track List screen reappears with all tracks on the CD listed. ✎✎ You can select up to 99 tracks from an Audio CD (CD-DA) using Play Selected. ✎✎ On the Play Selected screen, you can also choose Select All, Clear All, and Cancel. - Use Select All to select all tracks. This cancels your individual track selections. When you press the ' (RETURN) button on your remote or select Play and then press the OK button, all tracks will appear on the Track List screen, and the product will begin to play all tracks from Track 001. Using Play Selected with Self-Recorded Media (CDs, USB Devices, etc.) 1. 2. 3. 4. 5. 6. 7. 8. 9. Insert a self-recorded CD or USB device with self-recorded files into the home cinema. The New device connected. pop-up appears. Select Music, and then press the OK button on your remote. The File List screen appears displaying icons for tracks, folders, or both. If necessary, use the 78:; buttons to select a folder, and then press the OK button. When the tracks you want to play are displayed, select Options in the upper right, and then press the OK button. Select Play Selected, and then press the OK button. Check boxes appear on the upper left sides of the track icons. Use the 78:; buttons to select a track, and then press the OK button. A check appears in the check box. Repeat Step 6 to check and select additional tracks. To remove a track from the list, move to the track, and then press the OK button again. The check on the track is removed. When done, select Play, and then press the OK button. The Track List screen appears listing only the tracks you checked. The selected tracks play automatically. 10. To cancel the Play Selected list, press the ' (RETURN) button or the e (EXIT) button. If you press ' (RETURN), you return to the File List screen. If you press e (EXIT), you go to the Home screen. 35 - English Playing Content 2. - Cancel cancels any changes you made on the Play Selected screen. When you return to the Track List screen, the Play Selected list will be unchanged. 1 Playing Content ✎✎ If you want to use Play Selected to watch videos, 8. Using Play Selected Starting from the Home Screen 9. use the Filter( ) function to select Videos instead of Music. ✎✎ Select PLAY DISC or MULTIMEDIA depending on the media you are using. - If you selected PLAY DISC, the Track List screen appears. Use the Filter( ) function to select Music, and then follow the directions starting at Step 3 above. - If you selected MULTIMEDIA, select Storage or Network Device on the MULTIMEDIA screen. Then, select your storage media on the Storage screen or device on the Network Device screen. The File List screen appears. Use the Filter( ) function to select Music, and then follow the directions starting at Step 3 above. Creating and Editing a Playlist Stored in a Storage Device Creating a playlist 1. 2. 3. 4. 5. 6. 7. Connect a USB device with stored music to the home cinema's USB jack, and then turn on the home cinema. On the Home screen, select MULTIMEDIA, and then press the OK button. On the MULTIMEDIA screen, select Storage, and then press the OK button. Select the USB device, and then press the OK button. At the top of the screen, select Filter( ) ; Music. After the screen re-displays, select Options ( ) ; Add to Playlist. On the next screen, select an existing playlist, and then press the OK button. OR Select New Playlist, and then press the OK button. If you selected an existing playlist, go to Step 9. If you selected New Playlist, go to Step 8. 10. 11. 12. 13. On the on-screen keyboard, accept the default name for the new playlist or enter a new name. When finished, select Done, press OK, and then go to Step 9. Navigate to the screen that displays the music you want to put into the playlist. Use the 78:; buttons to select a track, and then press the OK button. A check appears in the check box on the left side of the track icon. Repeat Step 10 to check and select additional tracks. To remove a track from the list, move to the track, and then press the OK button again. The check on the track is removed. When finished, select Add at the top of the screen, and then press the OK button. The playlist is saved to the USB device and the Added pop-up appears. Press the OK button. Playing a playlist 1. Connect the USB device with the playlist to the home cinema's USB port. 2. Navigate to the playlist (Home screen ; MULTIMEDIA ; Storage ; USB device ; playlist). 3. Select the playlist, and then press OK. The Track List screen appears and the first track of the playlist starts to play. Editing a playlist 1. While playing a playlist, select Settings ( ) ; Edit Playlist at the bottom-left corner of the Track List screen. 2. Use the 78:; buttons to select a track, and then press the OK button. A check mark appears next to the track. 3. To cancel a selection, select the track again, and then press the OK button. ✎✎ To select all tracks at once, use Select All. To cancel all selections at once, use Deselect All. 36 - English 4. 5. When finished, select Delete at the bottom left of the screen, and then press the OK button. A confirmation pop-up appears. Select Yes, and then press the OK button. ✎✎ Deleting all files included in a playlist will delete the playlist itself, too. ✎✎ You can save up to 5 playlists. 2. 4. 5. 6. Insert a USB device into the USB jack on the front of the product. This is the device you will rip the files to. Put a music CD into the home cinema. In a few moments, the Track List screen appears. On the Track List screen, select Settings ( ) on the lower left of the screen, and then press the OK button. The Settings menu appears. Use the 78 buttons to select Ripping, and then press the OK button. The Ripping screen appears. Use the 78 buttons to select a track, and then press the OK button. A check appears to the left of the track. Repeat Step 5 to select and check additional tracks. ✎✎ To select all tracks at once, select Select All on 7. 8. 9. the bottom left of the screen, and then press the OK button. To remove a track from the list, move to the track, and then press the OK button again. The check on the track is removed. When done, select the Rip button using the 78 buttons, and then press the OK button. The Rip pop-up appears. Use the 78 buttons to select the device to store the ripped files to, and then press the OK button. Ripping begins. ✎✎ Do not disconnect the device while ripping is in progress. You can use a Bluetooth device to enjoy music with high quality stereo sound, all without wires! ~~ Pairing distance : max. 2M, Operating distance : max. 10M ~~ The actual operation may be different depending on your environment even if you use the device within the operating distance. What is Bluetooth? Bluetooth is a technology that enables Bluetoothcompliant devices to interconnect with each other easily using a short, wireless connection. ~~ A Bluetooth device may hum or malfunction: -- When a part of your body is in contact with the receiving/transmitting system of the Bluetooth device or the Home Cinema. -- When it is subject to electrical variation from obstructions caused by a wall, corner, or office partitioning. -- When it is exposed to electrical interference from same frequency-band devices including medical equipment, microwave ovens, and wireless LANs. ~~ Pair the Home Cinema with the Bluetooth device while the two are close together. ~~ The further the distance is between the Home Cinema and the Bluetooth device, the worse the quality is. If the distance exceeds the Bluetooth operational range, the connection is lost. ~~ In poor reception areas, the Bluetooth connection may not work properly. 37 - English Playing Content 3. 11. When ripping is complete, the "Successfully ripped." message appears. Press the OK button. The Track List screen reappears. Using Bluetooth Ripping 1. 10. If you want to cancel ripping after ripping has begun, press the OK button and then select Yes. Select No to continue ripping. Playing Content ~~ The Home Cinema has an effective reception range of up to 10 meters in all directions if there are no obstacles. The connection will be automatically cut off if the device is out of this range. Even within this range, the sound quality may be degraded by obstacles such as walls or doors. ~~ This wireless device may cause electrical interference. during its operation. To connect the Home Cinema to a Bluetooth device -- If the Bluetooth device is turned off, not in place, or malfunctions. Bluetooth device Before you begin, confirm that the Bluetooth device supports the Bluetooth compliant stereo headset function. 2. 3. 4. Press the SOURCE button on the remote control to display the BT message. Select the Bluetooth menu on the Bluetooth device you want to connect. For instructions, refer to the Bluetooth device's manual. Select "[HTS]Jxxxxx" from the list. ~~ When the Home Cinema is connected to the Bluetooth device, the device name of the connected Bluetooth device, followed by the name of home cinema, will appear on the front display of the home cinema. Play music on the connected device. ~~ You can listen to the music playing on the connected Bluetooth device over the Home Cinema system. ✎✎ The Home Cinema only supports Middle Quality SBC data (up to 237kbps@48kHz), and does not support High Quality SBC data ([email protected]). will differ, depending on the specifications of the connected device. ✎✎ Connect only to a Bluetooth device that supports the A2DP Profile. ✎✎ Only one Bluetooth device can be paired at a time. ✎✎ The search or connection functions may not work properly in the following cases: -- If there a strong electric field near or around the home cinema. -- If several Bluetooth devices are simultaneously paired with product. Connect 1. ✎✎ The AVRCP feature is supported. It's functionality Note that such devices as microwave ovens, wireless LAN adapters, fluorescent lights, and gas stoves use the same frequency range as the Bluetooth device, and can cause electric interference. ✎✎ For the best operational compatibility between the home cinema and a Bluetooth device or any other device, such as a Mobile Phone, we recommend you update the device's OS to the latest version. To disconnect the Bluetooth device from the Home Cinema You can disconnect the Bluetooth device from the Home Cinema. For instructions, refer to the Bluetooth device's manual. ~~ When the Home Cinema is disconnected from the Bluetooth device, the Home Cinema will display DISCONNECTED on the front display. To disconnect the Home Cinema from the Bluetooth device Press the (F) button on the front panel of the Home Cinema to switch from BT to another mode or turn off the Home Cinema. ~~ Except when you disconnect the Home Cinema by changing functions, the connected Bluetooth device will wait a certain amount of time for a response from the Home Cinema before terminating the connection. (Disconnection time may differ, depending on the Bluetooth device.) 38 - English ✎✎ In Bluetooth connection mode, the Bluetooth connection will be lost if the distance between the Home Cinema System and the Bluetooth device exceeds 10 meters. When the Bluetooth device comes back into effective range or you restart the Bluetooth device, you will have to pair the device and home cinema again to reconnect. ✎✎ In Bluetooth mode, the screen saver will start if the Bluetooth device stays in the Ready state for 5 minutes. To reconnect the Bluetooth device, turn off the screen saver, and then connect the device. To turn off the screen saver, press any button on the remote control (the Volume button, an 78:; buttons, etc.). Using the Bluetooth Quick start ✎✎ The home cinema must be plugged in for Quick start to work. ✎✎ To use this function, set Settings > System > Quick start to On. ✎✎ To use this function, the Bluetooth connection between the home cinema and your smart device should have been established before. In other words, the home cinema should be found on the list of Bluetooth devices your smart device has already connected to. 1. 2. Connect your previously connected smart device to the product via Bluetooth. (For information on Bluetooth connections, refer to your smart device’s manual.) Once connected, the home cinema turns itself on automatically in BT mode. ~~ Select the desired music to play on your smart device. You can play photo content located on a DVD, USB, mobile device, or PC. Using the Tools Menu While displaying a photo, press the TOOLS button on the remote. Select Settings(T) in the upper right corner of the screen, and then press the OK button. The Tools menu drop down list appears. Slideshow Settings `` Speed : Select to set a slide show's speed. `` Effects : Select to set a slide show's special effects. Rotate Select to rotate the picture. (This will rotate the picture either clockwise or counter clockwise.) Zoom Select to enlarge the current picture. (Enlarge up to 4 times) Picture Mode `` Dynamic : Choose to increase sharpness. `` Standard : Choose for most viewing applications. `` Movie : This is the best setting for watching movies. `` User : Lets you adjust the sharpness and noise reduction function respectively. Background Music Select to listen to music while viewing a slide show. Equaliser Mode Set to On to use the equaliser. Customize your own personal sound preferences using the equaliser settings. Equaliser Settings This function is only available when Equaliser Mode is On. 39 - English Playing Content When the home cinema is turned off, connecting a previously connected smart device to the product via a Bluetooth connection can turn the home cinema on. Playing Photo Content Playing Content Send Select Send to upload selected files to on-line sites (Picasa, Facebook, etc.) or devices. To use Send with an on-line site, you need to establish an account with the on-line site, and then log in using the Log In function. Send works essentially the same way for music, photos, and videos. For general instructions, see "Using the Send Function" on page 40. Information Displays the picture information. ✎✎ Depending on the disc or storage device, the Options menu may differ. All options may not be displayed. ✎✎ To enable the Background Music function, the photo file must be in the same storage media as the music file. However, the sound quality can be affected by the bitrate of the MP3 file, the size of the photo, and the encoding method. ✎✎ You can't enlarge the subtitle and PG graphic in the full screen mode. Using the Sort By and Options Menus When the Photo File List is Displayed Select the Filter( ) function, and then Photos to display photos only. ✎✎ Even though the product will display folders that contain all content types, it will only display files of the content type you selected For example, if you selected Photos, you will only be able to see photo files. On the screen that lists the photo files, use the 78:; buttons to select Sort By or Options in the upper right, and then press the OK button. Sort By Photos `` Date Groups all the photo files on the media or storage device by date. Click a group to see the photos in that group. `` Title Displays all the photo files on the media or storage device by title. `` Folder Displays all the folders on the media or storage device. Options `` Slide Show Starts the slide show. Shows all the files in the current folder, one after another. If you want to create a slide show with a selected group of photos, see Play Selected below. `` Play Selected Play Selected lets you select specific files to play. It works essentially the same way for all media. See "Using Play Selected with SelfRecorded Media (CDs, USB Devices, etc.)" on page 35. `` Send Select Send to upload selected files to on line sites (Picasa, Facebook, etc.) or to devices. To use Send with an on-line site, you need to establish an account with the on-line site, and then log in using the Log In function. ✎✎ Depending on the disc or storage device, the Options menu may differ. All options may not be displayed. Using the Send Function 1. 2. 3. 40 - English Use the 78 buttons to select Send, and then press the OK button. The Selection screen appears. Use the 78 buttons to select a picture, and then press the OK button. A check appears to the left of the picture. Repeat Step 2 to select and check additional pictures. 4. To remove a picture from the list, move to the picture, and then press the OK button again. The check on the picture is removed. 5. When done, press the 78 button to select Send, and then press the OK button. The Send pop-up appears listing the on-line sites (Picasa, Facebook, etc.) or devices that you can send the photos to. 6. Select a destination, and then press the OK button. 7. If you are sending the photos to an on-line site, the site starts. Log in and follow the directions on the screen. ✎✎ To send photos to an on-line site, you must have an account with that site. SOUND EFFECT Function Lets you select a mode that optimizes the sound. 1. Press the SOUND EFFECT button. 3. ress the :; buttons to select the desired P sound effect. 2. ĞĞ Press the 78 buttons to select the desired mode: DSP, Virtual Surround, SFE Mode, or Sports. DSP zzMP3 Enhancer : Helps enhance your sound experience (ex. mp3 music). You can upscale your MP3 level sound (24 kHz, 8bit) to CD level sound (44.1 kHz, 16bit). zzPower Bass : Increases the volume level of bass tones and provides thudding sound effects. zzOff : Select for normal listening. ĞĞ SFE Mode ĞĞ Sports ✎✎ Depending on the disc or storage device, name of this function may differ. zzAnnouncer : Emphasizes the commentator's voice during a sports game to increase your absorption in the game. zzStadium : Emphasizes spectators' cheering during a sports game to add immediacy. zzOff : Select for normal listening. DTS Neo:Fusion II You can enjoy more natural and vivid surround sound with enriched tones by adjusting the depth of sound using the level options. Off On Virtual Surround You can set a two-channel input source to produce sound in 5.1 channel surround mode. 41 - English Playing Content Using the Special Effects Remote Control Buttons ĞĞ zzSymphony Hall in Boston (Hall 1) : Provides a clear vocal as if listening in a concert hall. zzPhilharmonic Hall in Bratislava (Hall 2) : Also provides a clear vocal as if listening in a concert hall, but less powerful than HALL1. zzJazz Club in Seoul B : Recommended setting for Jazz. zzChurch in Seoul : Gives the feel of being in a grand church. zzAmphitheater (Rock) : Recommended setting for Rock. zzOff : Select for normal listening. Network Services You can enjoy various network services such as streaming video or on-line apps by connecting the product to your network. 2. button after you have logged in, the Sign In screen appears. You can select Link Accounts, Edit Profile, Remove Account, and Sign Out. Connect the product to a network. (See page 13) Configure the network settings. (See pages 22~24) Before Using SAMSUNG APPS Logging In to Your Samsung Account Before you access SAMSUNG APPS, we suggest you log in to your Samsung account. ✎✎ If you do not have a Samsung account, create one by selecting Create Account. To create a Samsung account, follow these steps: 1. 2. 3. 4. 5. 6. 7. 8. 9. next time you log in, the product will automatically enter your e-mail and password. All you need to do is select Sign In. ✎✎ If you press the To use network services, you must first: 1. ✎✎ If you selected Sign me in automatically, the With the Home screen displayed, press the button. The Sign In screen appears. Select the ID field, and then press the OK button. The keyboard pop-up appears. Using the keyboard, enter your e-mail address. When finished, select the Done button, and then press the OK button. The Sign In screen reappears. Select the Password field, and then press the OK button. The keyboard pop-up appears. Using the keyboard, enter your password. When finished, select the Done button, and then press the OK button. The Sign In screen re-appears. To make the log in process easier next time, select Sign me in automatically, and then press the OK button. Select Sign In, and then press the OK button. If you haven’t set up Smart Hub, when you use SAMSUNG APPS for the first time, the product will ask you to perform the Smart Hub set up procedure. 1. 2. 3. 4. 5. On the Home screen, select SAMSUNG APPS, and then press the OK button. The Smart Hub pop-up appears asking if you want to set up Smart Hub. Select Yes, and then press the OK button. The Welcome screen appears. Select Start, and then press the OK button. The Smart Hub Terms & Conditions, Privacy Policy screen appears. On the Additional Services and Options screen, you must review and agree to both the Smart Hub Terms and Conditions and the Privacy Policy to use Smart Hub. Scroll down, and then click the View details buttons to review the full documents. ✎✎ You do not need to consent to the Supplemental Privacy Notice, but one or more Smart TV features or functionalities may not be available if you do not. 6. Select I agree to all, and then press the OK button. The Setup Complete screen appears. Press the OK button. The Samsung account Terms and Conditions screen appears. Select I agree, and then press the OK button. 10. Select an image you want to use to identify your account, and then press the OK button. 11. Select Done. 42 - English Using SAMSUNG APPS Through the SAMSUNG APPS screen, you can download applications from the Internet, and launch and run downloaded applications on your TV. To access some applications, you need to have a Samsung account. ✎✎ While playing multimedia content in SAMSUNG APPS, press and hold 5 button on the remote to pause playback. To stop playback, press and hold e (EXIT) button on the remote. The SAMSUNG APPS Screen at a Glance 1 2 RECOMMENDED 3 4 5 WebBrowser 2 3 4 5 MY APPS 2. 6 Most Popular What's New 7 8 9 10 Categories 1 2 3 RECOMMENDED : Displays recommended contents managed by Samsung. You cannot delete Recommended Apps. MY APPS : Displays your personal gallery of applications modifiable on the MY APPS screen. If you selected Categories, select a category icon, and then press the OK button. Otherwise, go to Step 3. ✎✎ On the Most Popular, What's New, and Categories screens, a green arrow is displayed on apps you have already downloaded. 3. Select an app you want to download, and then press the OK button. The Detail Information screen for the App appears. 4. 3 Select Most Popular, What's New, or Categories, and then press the OK button. 5. 6. Most Popular, What’s New and Categories : Select to view and download additional apps. 43 - English Select the Download button on the screen, and then press the OK button. Download changes to Cancel and the app begins to download. If you want to cancel the download, select Cancel, and then press the OK button. When the download is complete, Cancel changes to Open. Select Open, and then press the OK button to start the application. Alternately, press the ' (RETURN) button until the SAMSUNG APPS screen reappears. The app you downloaded will be displayed on the App screen under MY APPS. Network Services 2 Downloading an App 1. SAMSUNG APPS 1 The first time you open the SAMSUNG APPS screen, the Home cinema automatically downloads a group of free apps. Once these apps have been downloaded, they appear on the SAMSUNG APPS screen. To see additional apps, select Most Popular, What's New, or Categories on the bottom of the screen, and then press the OK button. Most Popular displays the most popular apps, What's New the newest. Categories displays a series of icons representing categories such as Video, Game, and Sports. Select a category icon, and then press the OK button. The Home cinema displays the apps in that category. Network Services Starting an Application 1. 2. Select SAMSUNG APPS on the Home screen, and then press the OK button. On the SAMSUNG APPS screen, use the 78:; buttons to select an app, and then press the OK button. The app starts. The Option Menu The Option menu lets you add apps to and delete apps from MY APPS. It also lets you change the position of an app in MY APPS and update apps. Move 1. 2. 3. 4. On the MY APPS screen, select the app you want to move, and then press the OK button for 3 seconds. The Option menu appears. 2. 3. 2. 3. 4. 2. When the app is where you want it, press the OK or e (EXIT) button. On the MY APPS screen, select the app you want to delete, and then press the OK button for 3 seconds. The Option menu appears. Select Delete, and then press the OK button . Use the :; buttons to select Yes, and then press the OK button. On the MY APPS screen, select an app you want to delete and then press the OK button for 3 seconds. The Options menu appears. 1. 2. 3. Use the 8 button to select Delete, and then press the OK button. Select View Details, and then press the OK button. On the MY APPS screen, select an app, and then press the OK button for 3 seconds. The Option menu appears. Select Change View, and then press the OK button. If the current view is Most Played, you will be asked if you want to change to Custom View. If the current view is Custom View, you will be asked if you want to change the view to Most Played. Most Played sorts the apps by the number of times you ran each app. Custom View lets you arrange the apps to your liking. Select OK, and then press the OK button to change the view. Lock/Unlock Locking an app makes it more difficult to delete accidently. 1. 2. 3. Select the Delete Multiple, and then press the OK button. Use the 78:; buttons to select apps you want to delete, and then press the OK button. On the MY APPS screen, select the app you want to see detailed information for, and then press the OK button for 3 seconds. The Option menu appears. Change View Select Move, and then press the OK button. Delete Multiple 1. 1. Use the 78:; buttons to move the app. Delete 1. View Details 4. 44 - English On the MY APPS screen, select the app you want to lock, and then press the OK button for 3 seconds. The Option menu appears. Select Lock/Unlock, and then press the OK button. The PIN input pop-up appears. Enter your PIN. Press and hold the 123 button until the Num pad appears on the screen. When the Num pad appears, select a number using the ,. button and then press the OK button. If you haven't set a PIN, enter the default PIN: 0000. A checkbox appears on each app icon. Use the 78:; button to move to the app you want to lock, and then press the OK button to select it. A check mark appears on the icon. 5. 6. 7. Repeat Step 4 to select other apps. Use Select All or Deselect All on the bottom of the screen to select or deselect all apps at once. To deselect individual apps, select the app again, and then press the OK button. The check mark disappears. When you have finished marking your selections, move to Save on the bottom of the screen, and then press the OK button. A lock mark appears on the selected app’s icon. You will be prompted to enter the PIN number to delete or unlock a locked app. Update Apps 1. 2. 4. Select Update Apps, and then press the OK button. The Update Apps screens lists all the apps that have updates available. Select each app you want to update, and then press the OK button. You can also choose Select All to update all the apps listed. Select Update, and then press the OK button. Screen Mirroring The Screen Mirroring function lets you view the screen of your smart phone or android tablet on the TV you have connected to the product. 1. 2. 3. 4. 5. 6. In the Home screen, select Screen Mirroring, and then press the OK button. Launch AllShare Cast or Screen Mirroring on your device. On your device, find the name of the product in the list of available devices and then select it. The TV displays a connecting message (for example, Connecting to Android_92gb...) and then displays the connected message. In a few moments, the screen of your device appears on the TV screen. AllShare Cast or Screen Mirroring. Note that all devices that have AllShare Cast or Screen Mirroring may not be fully supported, depending on the manufacturer. For further information on mobile connection support, refer to the manufacturer’s web site. ✎✎ When you are using the Screen Mirroring function, video stuttering or audio dropouts may occur, depending on your environment. ✎✎ Bluetooth transmissions can interfere with the Screen Mirroring signal. Before using the Screen Mirroring function, we strongly recommend that you turn off the Bluetooth function on your smart phone or smart device (tablet, etc.). Using the Web Browser You can access the Internet using the Web Browser application. 1. Select SAMSUNG APPS on the Home screen and then press the OK button. 2. On the SAMSUNG APPS screen, select WebBrowser, and then press the OK button. ✎✎ When you run the Web Browser with the product connected by HDMI to a BD Wise compatible TV - and BD Wise is on - the browser is maximized to fill the screen and the TV's resolution is set to the optimal resolution automatically. ✎✎ The Web Browser is not compatible with Java applications. ✎✎ Flash Player contents cannot be played with the Web browser. ✎✎ If you attempt to download a file, and the file cannot be saved, an error message will appear. ✎✎ E-commerce (purchasing products online) is not supported. ✎✎ ActiveX is not supported. ✎✎ Access may be blocked to some websites or to web browsers operated by certain businesses. To stop Screen Mirroring, press the e (EXIT) or ' (RETURN) button on the remote control, or exit the Screen Mirroring function on your smart phone. 45 - English Network Services 3. On the MY APPS screen, select any app, and then press the OK button for 3 seconds. The Option menu appears. ✎✎ You can connect to a device that supports Network Services Link Browsing and Pointer Browsing The Web Browser provides two types of browsing, Pointer Browsing and Link Browsing. When you launch the browser for the first time, Pointer Browsing is active. If you are using a mouse to navigate in the Web Browser, we recommend leaving Pointer Browsing active. With Pointer Browsing, you move the pointer using the directional arrow keys on your remote. The pointer moves freely around the screen, much like the pointer on a computer when you use a mouse. With Link Browsing, you use the directional arrow keys to move a highlight from one link, button, or entry field to the next. The highlight is restricted to the links, buttons, and entry fields. The Control Panel at a Glance The Control Panel, which runs across the top of the screen, has a series of icons which start a number of useful functions. The icons are described below, starting with the icon on the far left of the screen. http://www.samsung.com 100% To activate Link Browsing, follow these steps: 1. 2. Use the 78:; buttons on your remote to move the pointer to the Link Browser icon on the top right of the screen. The Link Browser icon is the third icon from the right. The pointer will be in the correct position if the icon turns blue and the words “Link Browsing” appear on the screen. Press the OK button. Link Browsing is activated and will remain active whenever you bring up the Web Browser or until you change to Pointer Browsing. http://www.samsung.com http://www.samsung.com http://www.samsung.com http://www.samsung.com ttp://www.samsung.com /www.samsung.com w.samsung.com 100% 100% 100% ~~ ~~ ~~ : Moves to thehttp://www.samsung.com previous page. : Moves to http://www.samsung.com the next web page. http://www.samsung.com : Displays the Bookmarks and History screen. You can bookmark the current page, select an existing bookmark, and edit and delete bookmarks. You can also view your browsing history and select a page to revisit. http://www.samsung.com ~~ : Moves to the Home screen of the Web Browser. ~~ http://www.samsung.com : Lets you enter a page address manually using the keyboard pop-up. 100% so that it is ~~ : Reloads the current page refreshed on the screen. 100% to your bookmarks. ~~ : Adds the current page 100%you search for ~~ : Lets information by entering words or characters using the keyboard pop-up. See Using the Keyboard Popup on the next page. ~~ 100% : Lets you enlarge or shrink the screen by various percentages. ~~ : Lets you switch between Pointer / Browsing and Link Browsing. ~~ : Lets you configure the Browser’s settings. See “Using the Settings Menu” on page 48. ~~ : Closes the Web Browser. 46 - English www.samsung.com Using the Keyboard Pop-up When you click the , the or 100% access a data or text entry100% field, and then press the OK button, the keyboard pop-up appears. http://www.samsung.com http://www.samsung.com 100% Options on the Keyboard Pop-Up To access the keyboard pop-up 100%options, highlight the button on the bottom left of the keyboard, and then press the OK button. Language Select the language for the keyboard. You can select English, French, Russian, etc. Recommend text As you enter characters, recommended text will be shown. Caps 1234567890 :Clear q w e z x c 123#&a s d ENG r t y v b n f g h u j m i k , www. .com o l . / p ^ * ? - Cancel ~ @ ! 3. 4. 5. 6. 7. Use the 78:; buttons on your remote to move the highlight to a letter or number of your choice. Press the OK button to enter the letter or number into the entry field. To access capital letters, move the highlight to the Caps key on the top left, and then press the OK button. Press the OK button again with the Caps key highlighted to access small letters again. Reset erases the Samsung Keyboard's memory. Select OK to erase everything that the Samsung Keyboard has learned about your writing style, including any new words you have used. Predict Next Letter The keyboard will predict the next letter as you enter letters. The predictions appear in a ring around the letter you have just entered. You can select a predicted letter or move to another letter. You can turn this function On or Off. Accented Character Preview Select if you want to type letters with accent marks. To access symbols and additional punctuation marks, highlight the 123#& button on the left, and then press the OK button. To delete a character you entered, move the highlight to the : button, and then press the OK button. To delete all the characters you entered, move the highlight to the Clear button, and then press the OK button. When finished entering, move the highlight to the Done button, and then press the OK button. ✎✎ If you have a wireless keyboard connected to your product, you can use the wireless keyboard to enter letters, numbers, symbols, and punctuation. Note that the wireless keyboard will work only when the keyboard popup appears and can only be used to enter letters, numbers, symbols, and punctuation. 47 - English Network Services 2. Reset recommended text data Done To use the keyboard pop-up with your remote, follow these steps: 1. The keyboard suggests recommended words as you enter text. You can turn this function On or Off. 100% Network Services Using the Settings Menu The Settings menu contains functions that control how the Browser operates and Browser security functions. To open the Settings menu, highlight the icon in the Control Panel, and then press the OK button. To select an option in the Settings menu, highlight the option, and then press the OK button. http://www.samsung.com 100% Enable Grabbing Approved Sites Private browsing on Set Search Engine Web Browser Settings Help Close `` Manage Approved Sites : Lets you key in URLs to add to the Approved Sites List and delete sites from the Approved Sites list. If you turn this function on and have not added any sites to the Approved Sites list, you will not be able to access any Internet sites. Private browsing on/off Enable or disable the Privacy mode. When the Privacy mode is enabled, the browser does not retain the URLs of sites you visit. If you want to enable Privacy mode, select Yes. If the Privacy mode is running, the “Stop” icon appears in front of the URL at the top of the screen. To disable Privacy mode, select it again when Privacy mode is enabled. Set Search Engine You can set the desired Search Engine. Web Browser Settings Enable/Disable Grabbing Turns the Grabber function on and off. When the Grabber function is on, you can move a web page up and down without dragging the scroll bar. The Grabber function is only available in Pointer Browsing. Approved Sites Lets you restrict your children’s access to inappropriate web pages by allowing access only to the web sites you have registered. Every time you access this function, the PIN screen appears. Press and hold the 123 button until the Num pad appears on the screen. When the Num pad appears, select a number using the ,. button and then press the OK button. The first time you access this function, enter the default PIN, 0000. You can change the PIN using the Reset password for the Approved Sites function. See below. `` Approved Sites feature : Turns the Approved Sites function on or off. `` Reset password for Approved Sites : Change the Approved Sites password. `` Add current site : Lets you add the currently displayed web site to the Approved Sites list. `` Set as homepage : You can set the Browser's home page. `` Pop-up Block : Turns the Pop-up Block on and off. `` Page Block : You can determine whether to block advertisements and select the URLs for which advertisements are blocked. `` General : You can delete personal in information such as website history and browsing data (cookies, etc.), and reset all web browser settings to their factory defaults. You can also set the Security Mode. ✎✎ Set the Security Mode to On to avoid accessing malicious/phishing sites and prevent malicious code from running. `` Encoding : You can set the Encoding setting for web pages to Automatic or select the encoding format manually from a list. `` Pointer : You can set the speed of the cursor when the cursor is set to Pointer Browsing. `` Browser Information : Displays the version number and copyright information for the Web Browser. Help Provides basic information about the operation of the Web Browser. 48 - English ✎✎ Depending on the web site, some of the Web Browser Settings functions may not be activated. Functions that are not activated are greyed out and cannot be used. Linking your Internet Service Accounts to the Product 2. 4. 5. 6. 7. On the Home screen, select the button in the upper right corner, and then press the OK button to log in to your Samsung Account. After you have logged in, select the button again, and then press the OK button. Select Link Accounts in the My Account screen, and then press the OK button. On the Link Accounts screen, select the service you want to link to the product, and then press the OK button. In the ID and Password screen, enter the ID you use to log in to the service you selected using the pop-up keyboard. When finished, select Done, and then press the OK button. Repeat the same process for the password. When finished select Done, and then press the OK button. Attach a USB flash drive to the USB jack on the front of the product, and then check its remaining memory. The memory device must have at least 1GB of free space to accommodate the BD-LIVE services. 2. Select Settings on the Home screen, and then press the OK button. 3. Select Network, and then press the OK button. 4. Select BD-Live Settings, and then press the OK button. 5. Select BD Data Management, and then press the OK button. 6. Select Select Device, and then press the OK button. 7. Select USB device, and then press the OK button. 8. Insert a Blu-ray Disc that supports BD-LIVE. 9. Select an item from the list of BD-LIVE service contents provided by the disc manufacturer. ✎✎ The way you use BD-LIVE and the provided contents may differ, depending on the disc manufacturer. Select OK, and then press the OK button. 49 - English Network Services 3. Once the product is connected to your network, you can enjoy various movie-related service contents available on BD-LIVE compliant discs. 1. The Link Accounts function lets you link your product to your accounts with Internet services such as Pandora so that the product can log you in to the service automatically when you start the app for that service. To create a service account link, follow these steps: 1. BD-LIVE™ Appendix Additional Information Digital Output Notes HDMI OUT Connections ~~ Certain HDMI output resolutions may not work, depending on your TV. ~~ You must have an HDMI connection to enjoy videos with 3D technology. ~~ A long HDMI cable may cause screen noise. If this occurs, set HDMI Deep Colour to Off in the menu. 3D Settings Settings ~~ For some 3D discs, to stop a movie during 3D playback, press the e (EXIT) button once. The movie stops and the 3D mode option is deactivated. To change a 3D option selection when you are playing a 3D movie, press the e (EXIT) button once. The Blu-ray menu appears. Press the e (EXIT) button again, then select 3D Settings in the Blu-ray menu. ~~ Depending on the content and the position of the picture on your TV screen, you may see vertical black bars on the left side, right side, or both sides. TV Aspect Ratio ~~ Depending on the disc type, some aspect ratios may not be available. ~~ If you select an aspect ratio and option which is different than the aspect ratio of your TV screen, the picture might appear to be distorted. ~~ If you select 16:9 Original, your TV may display 4:3 Pillarbox (black bars on the sides of the picture). BD Wise (Samsung Products only) ~~ When BD Wise is On, the Resolution setting automatically defaults to BD Wise and BD Wise appears in the Resolution menu. ~~ If the product is connected to a device that does not support BD Wise, you cannot use the BD Wise function. ~~ For proper operation of BD Wise, set the BD Wise option in both the product and the TV to On. ~~ Be sure to select the correct Digital Output or you will hear no sound or just loud noise. ~~ If the HDMI device (AV receiver, TV) is not compatible with compressed formats (Dolby Digital, DTS), the audio signal outputs as PCM. ~~ Regular DVDs do not have BONUSVIEW audio and Navigation Sound Effects. ~~ Some Blu-ray Discs do not have BONUSVIEW audio and Navigation Sound Effects. ~~ This Digital Output setup does not affect the analogue (L/R) audio or HDMI audio output to your TV. It affects the optical and HDMI audio output when your product is connected to an AV receiver. ~~ If you play MPEG audio soundtracks, the audio signal outputs as PCM regardless of your Digital Output selections (PCM or Bitstream). ~~ Digital Output can be activated when Sound Output is set to TV Speaker. BD-Live Internet Connection ~~ The Internet connection may be restricted while you are using BD-LIVE contents. Anynet+ (HDMI-CEC) ~~ Depending on your TV, certain HDMI output resolutions may not work. Please refer to the user manual of your TV. ~~ This function is not available if the HDMI cable does not support CEC. ~~ If your Samsung TV has an Anynet+ logo, then it supports the Anynet+ function. BD Data Management ~~ In the external memory mode, disc playback may be stopped if you disconnect the USB device in the middle of playback. ~~ Only those USB devices formatted in the FAT file system (DOS 8.3 volume label) are supported. We recommend you use USB devices that support the USB 2.0 protocol with 4 MB/sec or faster read/ write speeds. ~~ The Resume Play function may not work after you format the storage device. ~~ The total memory available to BD Data Management may differ, depending on conditions. DivX® Video On Demand ~~ For more information about DivX(R) VOD, visit “http://vod.divx.com”. 50 - English Front Display Playing JPEG files ~~ You cannot change the brightness of the and the VOL +, - button. button Playing Content Speaker Settings ~~ When Sound Output is set to TV Speaker, audio is produced by the TV speakers. 5V 0.5A HDMI audio ~~ When HDMI audio is output to the TV speakers, it is automatically down-mixed to 2 channels. Audio Return Channel ~~ When Anynet+ (HDMI-CEC) is Off, the Audio Return Channel function is not available. ~~ Using an HDMI cable not certified for ARC (Audio Return Channel) may cause a compatibility problem. ~~ The ARC function is only available if an ARCcompliant TV is connected. Playback Using the TOOLS button while playing back pictures ~~ If the home cinema is connected to a BD Wise compliant TV that has BD Wise On, the Picture Settings menu will not appear. ~~ The Background Music function will not work unless the music file and the photo file are located on the same storage media. Also, sound quality can be impacted by the bitrate of the MP3 music file, the size of the photos, and the encoding method. Disk and Format Compatibility Disc types and content your Product can Play Media ~~ Video files with high bitrates of 20Mbps or more strain the product’s capabilities and may stop playing during playback. Disc Type Details DVD-VIDEO, DVD-RW, DVD-R, DVD+RW, DVD+R, VCD DVD-VIDEO, recorded DVD+RW/DVD-RW(V)/ DVD-R/+R discs that have been recorded and finalised, or a USB storage media containing DivX, MKV, MP4, VCD contents. MUSIC CD-RW/-R, DVD-RW/-R, BD-RE/-R Music recorded on CDRW/-R, DVD-RW/-R, BDRE/-R discs or a USB storage media containing MP3 or WMA contents. PHOTO CD-RW/-R, DVD-RW/-R, BD-RE/-R Photos recorded on CDRW/-R, DVD-RW/-R, BDRE/-R discs or a USB storage media containing JPEG contents. Selecting the Audio Language ~~ The ◄► indicator will not appear on the screen if the BONUSVIEW section does not contain any BONUSVIEW audio settings. ~~ The languages available through the Audio Language function depend on the languages that are encoded on the disc. This function or certain languages may not be available. ~~ Some Blu-ray Discs may allow you to select either the PCM or Dolby Digital audio English soundtrack. Selecting the Subtitle Language ~~ Depending on the Blu-ray Disc/DVD, you may be able to change the subtitle language in the Disc Menu. Press the DISC MENU button. ~~ This function depends on the selection of subtitles that are encoded on the disc and may not be available on all Blu-ray Discs/DVDs. ~~ Information about the main feature BONUSVIEW mode will also appear if the Blu-ray Disc has a BONUSVIEW section. ~~ This function changes both the primary and secondary subtitles at the same time. ~~ The total number of primary and secondary subtitles, respectively, is displayed. VIDEO 51 - English Blu-ray Disc BD-ROM or BD-RE/-R disc recorded in the BD3D Blu-ray Disc RE format. Appendix Playing Video files ~~ You can’t enlarge the subtitle and PG graphics in the full screen mode. Appendix ✎✎ The product may not play certain CD-RW/-R and DVD-R because of the disc type or recording conditions. ✎✎ If a DVD-RW/-R disc has not been recorded properly in DVD video format, it will not be playable. ✎✎ Your product will not play content that has been recorded on a DVD-R at a bitrate that exceeds 10 Mbps. ✎✎ Your product will not play content that has been recorded on a BD-R or USB device at a bitrate that exceeds 30 Mbps. ✎✎ Playback may not work for some types of discs, or when you use specific operations, such as angle change and aspect ratio adjustment. Information about the discs is written in detail on the disc box. Please refer to this if necessary. ✎✎ When you play a BD-J title, loading may take longer than a normal title or some functions may perform slowly. Logos of Discs the Product can Play Blu-ray Disc 3D Blu-ray Disc BD-LIVE Dolby DTS Disc Types your Product cannot Play ~~ HD DVD ~~ DVD-ROM/PD/MV-Disc, etc ~~ DVD-RW(VR mode) ~~ CVD/CD-ROM/CDV/ CD-G/CD-I/LD (CD-Gs play audio only, not graphics.) ~~ DVD-RAM ~~ Super Audio CD (except CD layer) ~~ 3.9 GB DVD-R Disc for Authoring. ✎✎ This product may not respond to all operating commands because some Blu-ray Disc, DVD, and CD discs allow specific or limited operation and provide only certain features during playback. Please note that this is not a defect in the product. ✎✎ Samsung cannot guarantee that this product will play every disc bearing the Blu-ray Disc, DVD, or CD logo because disc formats evolve, and problems and errors may occur during the creation of Blu-ray Disc, DVD, and CD software and/or the manufacture of discs. ✎✎ Please contact the SAMSUNG Customer Care Centre at, if you have questions or encounter difficulty when playing Blu-ray Disc, DVD, or CD discs in this product. Also, refer to rest of this user manual for additional information on playback restrictions. ✎✎ Some commercial discs and DVD discs purchased outside your region may not play on this product. Java DivX PAL broadcast system in U.K, France, Germany, etc. Region Code Both products and discs are coded by region. These regional codes must match for a disc to play. If the codes do not match, the disc will not play. The Region Number for this product is displayed on the rear panel of the product. Disc Type Blu-ray Disc 52 - English Region Code Area a North America, Central America, South America, Korea, Japan, Taiwan, Hong Kong and South East Asia. b Europe, Greenland, French territories, Middle East, Africa, Australia and New Zealand. c India, China, Russia, Central and South Asia. DVDVIDEO 1 The U.S., U.S. territories and Canada 2 Europe, Japan, the Middle East, Egypt, Africa, Greenland 3 Taiwan, Korea, the Philippines, Indonesia, Hong Kong 4 Mexico, South America, Central America, Australia, New Zealand, Pacific Islands, Caribbean 5 Russia, Eastern Europe, India, North Korea, Mongolia 6 China not correspond to the Region number of this product, the product cannot play the disc. AVCHD (Advanced Video Codec High Definition) ~~ This product can play back AVCHD format discs. These discs are normally recorded and used in camcorders. ~~ The AVCHD format is a high definition digital video camera format. ~~ The MPEG-4 AVC/H.264 format compresses images with greater efficiency than the conventional image compressing format. ~~ Some AVCHD discs use the “x.v.Colour” format. This product can play back AVCHD discs that use the “x.v.Colour” format. ~~ “x.v.Colour” is a trademark of Sony Corporation. ~~ “AVCHD” and the AVCHD logo are trademarks of Matsushita Electronic Industrial Co., Ltd. and Sony Corporation. depending on their video resolution and frame rate. Supported Formats Notes on the USB connection ~~ Your product supports USB storage media, MP3 players, digital cameras, and USB card readers. ~~ The product does not support folder or file names longer than 128 characters. ~~ Some USB/digital camera devices may not be compatible with the product. ~~ Your product supports the FAT 16, FAT 32, and NTFS file systems. ~~ Connect USB devices directly to the product’s USB port. Connecting through a USB cable may cause compatibility problems. ~~ Inserting more than one memory device into a multi-card reader may cause the reader to operate improperly. ~~ The product does not support the PTP (Peer to Peer) protocol. ~~ Do not disconnect a USB device while it is transferring or recording data. ~~ The bigger the image resolution, the longer the image takes to display. ~~ This product cannot play MP3 files with DRM (Digital Rights Management) downloaded from commercial sites. ~~ Your product only supports video that is under 30fps (frame rate). ~~ Your product only supports USB Mass Storage Class (MSC) devices such as thumb drives and USB HDD. (HUB is not supported.) ~~ Certain USB HDD Devices, multi-card readers and thumb drives may not be compatible with this product. ~~ If some USB devices require excessive power, they may be limited by the circuit safety device. ~~ If playback from a USB HDD is unstable, provide additional power by plugging the HDD into a wall socket. If the problem continues, contact the USB HDD manufacturer. ~~ SAMSUNG is not responsible for any data file damage or data loss. ✎✎ Some AVCHD format discs may not play, depending on the recording conditions. ✎✎ AVCHD format discs need to be finalised. ✎✎ “x.v.Colour” offers a wider colour range than normal DVD camcorder discs. 53 - English Appendix ✎✎ If the Region number of a Blu-ray Disc/DVD does ✎✎ Some DivX, MKV and MP4 format discs may not play, Appendix Video File Support File Extension *.avi *.mkv *.asf *.wmv *.mp4 *.mov *.3gp *.vro *.mpg *.mpeg *.ts *.tp *.trp *.mov *.flv *.vob *.svi *.m2ts *.mts *.divx *.ps *.webm *.rmvb `` Limitations Container Video Codec Resolution MVC Frame rate (fps) 24/25/30 Motion JPEG Bitrate (Mbps) Audio Codec 30 AC3 LPCM ADPCM (IMA, MS) AAC HE-AAC WMA DD+ MPEG(MP3) DTS (Core, LBR) 60 H.264 BP/MP/HP AVI MKV ASF MP4 3GP MOV FLV VRO VOB PS TS SVAF Divx 3.11 / 4 / 5 / 6 MPEG4 SP/ASP Window Media Video v9(VC1) AVS RMVB FHD : MAX 30 HD : MAX 60 MPEG2 MPEG1 Microsoft MPEG-4 v3 Window Media Video v7(WMV1), v8(WMV2) H 263 Sorrenson Microsoft MPEG-4 v1, v2 WebM 1920x1080 1280x720 MAX 30 720x576 VP6 640x480 VP8 1920x1080 RV8/9/10 (RV30/40) -- Files are not supported if there are some issues with contents among the supported codecs listed above. -- Normal playback is not guaranteed if the file's container information is wrong or the file itself is corrupted. -- Sound or video play may cutoff for contents with bitrate/frame rates that are above standard. -- The seek (skip) function is not available if the file's index table is damaged. -- Depending on your network status, play may become disrupted when playing contents from the network. -- Some USB/Digital camera devices may not be compatible with the product. -- RMVB format is supported in China, Hong Kong and Southeast Asia. -- AVS codec is supported for contents for China only -- *.ps extension is supported for contents for China only -- DivX codec is not supported for contents in the US 1920x1080 6~30 4 6~30 20 6~30 20 Vorbis RealAudio 6 `` Video decoder -- Supports up to H.264 Level 4.1 (except for FMO/ASO/ RS) -- Does not support VC1 AP L4 -- Except for WMV v7, v8, MSMPEG4 v3, MVC, VP6 Below 1280 X 720: 60 frame max Above 1280 X 720: 30 frame max -- Does not support GMC 2 or higher -- Supports SVAF Top/Bottom, Side by Side, Left/Right view sequence type(2 ES) Only -- Supports BD MVC Spec Only `` Audio decoder --------- Supports WMA 10 Pro (Up to 5.1) Does not support WMA lossless audio. Supports M2 profile ReadlAudio 10 lossless is not supported for contents for China and Hong Kong Does not support QCELP, AMR NB/WB vorbis : Supported up to 5.1 channel DD+ : Supported up to 7.1ch DTS LBR codec is supported in MKV/MP4/TS containers only 54 - English Music File Support File Extension Type Codec Comments *.mp3 MPEG MPEG1 Audio Layer 3 - *.m4a *.mpa *.aac MPEG4 AAC - *.flac FLAC FLAC Supports up to 2ch *.ogg OGG Vorbis Supports up to 2ch WMA WMA *.wav wav wav - *.mid *.midi midi midi type 0 and type 1 Seek not supported Supported on USB only *.ape ape ape NonSmart not supported *.aif *.aiff AIFF AIFF - *.m4a ALAC ALAC - Appendix *.wma Supports WMA 10 Pro (Up to 5.1) Does not support WMA lossless audio Supports up to M2 profile Picture File Support File Extension *.jpg *.jpeg Type Resolution Comments JPEG 15360x8640 - *.png PNG 4096x4096 - *.bmp BMP 4096x4096 - *.mpo MPO 15360x8640 - 55 - English Appendix Digital Output Selections Setup PCM Connection Audio Stream on Blu-ray Disc PCM Up to PCM 7.1ch Dolby Digital Up to PCM 5.1ch Definition for Blu-ray Disc Dolby Digital Dolby TrueHD Dolby TrueHD DTS DTS Up to PCM 7.1ch DTS re-encoded Re-encoded Dolby Digital * DTS-HD High Resolution Audio DTS-HD Master Audio PCM PCM 2ch Dolby Digital Up to PCM 5.1ch Dolby Digital DTS Up to PCM 7.1ch DTS Any Bitstream (Re-encoded Dolby D) PCM Dolby Digital Plus DTSHD High Resolution Audio Bitstream (Re-encoded DTS) HDMI supported AV receiver Dolby Digital Plus DTS-HD Master Audio Audio Stream on DVD Bitstream (Unprocessed) Decodes the main Outputs only the Decodes the main feature audio and main feature audio feature audio and Decodes the main BONUSVIEW audio stream so that your BONUSVIEW audio feature audio and stream together AV receiver can stream together BONUSVIEW audio into PCM audio and decode the audio into PCM audio and stream together adds Navigation bitstream. adds Navigation into PCM audio and Sound Effects, then You will not hear Sound Effects, then adds Navigation re-encodes the PCM BONUSVIEW audio re-encodes the Sound Effects. audio into Dolby or Navigation Sound PCM audio into DTS Digital bitstream or Effects. bitstream. PCM. `` If the Source Stream is 2ch or mono, “Re-encoded Dolby D” Setting are not applied. Output will be PCM 2ch. Blu-ray Discs may include three audio streams : -- Main Feature Audio : The audio soundtrack of the main feature. -- BONUSVIEW audio : An additional soundtrack such as the director or actor’s commentary. -- Navigation Sound Effects : When you choose some menu navigation options, Navigation Sound Effects may sound. Navigation Sound Effects are different on each Blu-ray Disc. 56 - English Resolution according to the content type Setup Auto Content Type BD Wise Movie Frame : Auto Blu-ray Disc Resolution of Blu-ray Disc UHD Output : Auto UHD Output : Off Movie Frame : Off 2160p@24F 1080p@60F 2160p@24F 1080p@24F Max. Resolution of TV input Max. Resolution of TV input 1080p@24F 1080p@24F 1080p 1080p@60F 1080p@60F 720p 720p Movie Frame : Auto (24 fps) 1080p only 1080i 1080i 576p/480p 576p/480p Content Type Setup BD Wise Movie Frame : Auto DVD 24fps Conversion : Auto UHD Output : Auto UHD Output : Off DVD 24fps Conversion : Off Movie Frame : Off Movie Frame : Auto (DVD 24fps Conversion : Auto) 1080p only 1080p 1080i 1080i 720p 576p/480p DVD 576i/480i 2160p@24F 1080p@24F Max. Resolution of TV input Max. Resolution of TV input 1080p@24F 1080p@60F 1080i 720p 720p 576p/480p 576p/480p ✎✎ If the TV you connected to the product does not support Movie Frame or the resolution you selected, the message "If no pictures are shown after selecting 'Yes', please wait for 15 seconds to return to the previous resolution. Do you want to change the resolution?" appears. If you select Yes, the TV's screen will go to blank for 15 seconds, and then the resolution will revert to the previous resolution automatically. ✎✎ If the screen stays blank after you have changed the resolution, remove all discs, and then press and hold the @ button on the top of the product for more than 5 seconds. All settings are restored to the factory default. Run the Initial Settings procedure again. Then, go to Settings > Picture > Resolution in the Menu, and select the correct resolution for your TV. ✎✎ When you run the Initial Settings procedure, re-select the language and aspect ratio (screen size and format) only. Resetting does not affect your network settings, so you should be able to skip Network Setup and Software Update. ✎✎ When the factory default settings are restored, all stored user BD data will be deleted. ✎✎ The Blu-ray Disc must have the 24 frame feature for the product to use the Movie Frame (24fps) mode. 57 - English Appendix Auto 1080p@24F E-contents/ Digital contents Appendix Troubleshooting Refer to the table below when this product does not function properly. If the problem you are experiencing is not listed below or if the instructions below do not help, turn off the product, disconnect the power cord and contact the nearest authorized dealer or Samsung Electronics Service Centre. Symptom You cannot eject the disc. Playback does not start. Playback does not start immediately when you press the p button. Check/Remedy ~~ Is the power cord plugged securely into the outlet? ~~ Turn off the power, and then turn it back on. ~~ Check the region number of the Blu-ray/DVD disc. A Blu-ray/DVD disc purchased from abroad may not be playable. ~~ CD-ROMs and DVD-ROMs cannot be played on this product. ~~ Make sure that the rating level is correct. ~~ Are you using a deformed disc or a disc with scratches on the surface? ~~ Wipe the disc clean. No sound. ~~ The home cinema does not play sound during fast playback, slow playback, and step motion playback. ~~ Are the speakers connected properly? Is the speaker setup correctly customized? ~~ Is the disc severely damaged? You can only hear sound from a few speakers, but not all 8. ~~ ~~ ~~ ~~ Dolby Digital 7.1 CH Surround Sound is not produced. ~~ Is there "Dolby Digital 7.1 CH" marked on the disc? Dolby Digital 7.1 CH Surround Sound is produced only if the disc is recorded with 7.1 channel sound. ~~ Is the audio language correctly set to Dolby Digital 7.1-CH in the information display? The remote control does not work. ~~ Are you operating the remote within its operational range and within the proper angle relative to the sensor? ~~ Are the batteries drained? ~~ The disc is rotating but there is no picture. ~~ Picture quality is poor and the picture is shaking. Audio language and subtitles do not work. ~~ ~~ ~~ ~~ On certain Blu-ray/DVD discs, sound is output from the front speakers only. Check if the speakers are connected properly. Adjust the volume. When playing audio from a CD, the radio, or a TV, the unit outputs sound to the front speakers only. Is the TV power on? Are the video cables connected properly? Is the disc dirty or damaged? A poorly manufactured disc may not be playable. ~~ The Audio Language and subtitle functions will not work if the disc does not contain them. 58 - English Symptom Check/Remedy ~~ Are you using a disc that does not contain menus? The aspect ratio cannot be changed. ~~ The home cinema can play 16:9 Blu-ray/DVD discs in 16:9 Full mode, 4:3 Letter Box mode, or 4:3 Pan-Scan mode, but plays 4:3 Blu-ray/DVD discs in 4:3 mode only. Refer to the Blu-ray Disc jacket, and then select the appropriate aspect ratio. ~~ The product is not working. (Example: The power goes off or you hear a strange noise.) ~~ The Product is not working normally. ~~ Press and hold the remote control's e (EXIT) button for 5 seconds in STANDBY mode. This will reset the unit. -- Using the RESET function will erase all stored settings. Do not use this function unless necessary. You have forgotten the rating level password. ~~ With no disc in the product, press and hold the product's @ button for longer than 5 seconds. INIT appears on the display and all settings will return to their default values. -- Using the RESET function will erase all stored settings. Do not use this function unless necessary. Can't receive radio broadcasts. ~~ Is the antenna connected properly? ~~ If the antenna's input signal is weak, install an external FM antenna in an area with good reception. While listening to TV audio through the product, there is no sound. ~~ If you press the OPEN/CLOSE ^ button while listening to TV audio using the D. IN or AUX functions, the Blu-ray/DVD disc functions are turned on and the TV audio is muted. "Not Available" appears on screen. ~~ The feature is unavailable or the action cannot be completed at this time because: 1. The Blu-ray/DVD disc's software restricts it. 2. The Blu-ray/DVD disc's software doesn’t support the feature (e.g., angles) 3. The feature is not available at the moment. 4. Y ou’ve requested a title or chapter number or search time that is out of range. If the HDMI output is set to a resolution your TV cannot support (for example, 1080p), you may not see a picture on your TV. ~~ Press and hold the @ button on front panel for more than 5 seconds with no disc in the product. All settings will revert to their factory settings. Abnormal HDMI output appears on the screen. ~~ If random noise appears on the screen, it means that TV does not support HDCP (High-bandwidth Digital Content Protection). No HDMI output. ~~ Check the connection between the TV and the HDMI jack of the product. ~~ Check if your TV supports 576p/480p/720p/1080i/1080p HDMI input resolution. 59 - English Appendix The menu screen does not appear even when you select the menu function. Appendix BD-LIVE Symptom The home cinema cannot connect to the BD-LIVE server. When using the BD-LIVE service, an error occurs. Check/Remedy ~~ Test whether the network connection is active by using the Network Status function. ~~ Check whether a USB memory device is connected to the product. ~~ The memory device must have at least 1GB of free space to accommodate the BD-LIVE service. You can check the available size in BD Data Management. (See page 50) ~~ See if the BD-Live Internet Connection option is set to Allow(All). ~~ If all above fails, contact the content provider or update to the latest firmware. ~~ The USB memory device must have at least 1GB of free space to accommodate the BD-LIVE service. You can check the available size in BD Data Management. (See page 50) ✎✎ When the factory default settings are restored, all stored user BD data is deleted. 60 - English Specifications General FM Tuner HDMI 2.7 kg Dimensions 430.0 (W) x 55.0 (H) x 312.0 (D) mm Operating Temperature Range +5°C to +35°C Operating Humidity Range 10 % to 75 % Signal/noise ratio 55 dB Usable sensitivity 12 dB Total harmonic distortion 0.5 % Video 2D : 2160p, 1080p, 1080i, 720p, 576p/480p 3D : 1080p, 720p Audio PCM multichannel audio, Bitstream audio, PCM audio Front speaker output 165W x 2(3Ω) Front Top speaker output 165W x 2(3Ω) Centre speaker output 170W(3Ω) Surround speaker output 165W x 2(3Ω) Subwoofer speaker output 170W(3Ω) Frequency response Analogue input : 20Hz~20kHz (±3dB) Digital input : 20Hz~40kHz (±4dB) S/N Ratio 70dB Channel separation 60dB Input sensitivity (AUX)500mV 61 - English Appendix Amplifier Weight Appendix Speaker system Speaker (7.1ch speaker system) Impedance Frequency Output sound range pressure level Front/ Front Top Surround 3Ω 140Hz~ 20kHz 20Hz ~ 200Hz Maximum input 165W 87dB/W/M Centre Subwoofer Rated input 170W 88dB/W/M 330W 340W Dimensions (W x H x D) (Unit : mm) Weights (Unit : kg) 95.0 x 1215.0 x 101.0 (Stand base: 276.0 x 23.0 x 264.0) 5.01 95.0 x 1160.0 x 101.0 (Stand base: 276.0 x 23.0 x 264.0) 4.73 320.0 x 80.5 x 101.0 1.02 200.0 x 390.0 x 350.0 5.75 ✎✎ Network speeds equal to or below 10Mbps are not supported. ✎✎ Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. ✎✎ Weight and dimensions are approximate. ✎✎ Design and specifications are subject to change without prior notice. ✎✎ For the power supply and Power Consumption, refer to the label attached to the product. ĞĞ SWA-7000 Weight 0.73 kg Dimensions (W x H x D) 50.0 X 201.3 X 132.0 mm Operating Temperature Range +5°C to +35°C Operating Humidity Range 10 % to 75 % Output 165W x 2 CH Frequency range 20Hz~20KHz S/N Ratio 65dB 62 - English Licences Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licencing Limited. DTS, DTS-HD, the Symbol, DTS and the Symbol together, & DTS-HD and the Symbol together are registered trademarks of DTS, Inc. DTS-HD Master Audio | Essential and DTS Neo:Fusion II are trademarks of DTS, Inc. © DTS, Inc. All Rights Reserved. This DivX Certified® device has passed rigorous testing to ensure it plays DivX® video. To play purchased DivX movies, first register your device at vod.divx.com. Find your registration code in the DivX VOD section of your device setup menu. DivX Certified® to play DivX® video up to HD 1080p, including premium content. DivX®, DivX Certified® and associated logos are trademarks of DivX, LLC and are used under license. Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licencing LLC in the United States and other countries. Oracle and Java are registered trademarks of Oracle and/or its affiliates. Other names may be trademarks of their respective owners. This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited. Blu-ray Disc™, Blu-ray™, and the logos are trademarks of Blu-ray Disc Association. This product uses Cinavia technology to limit the use of unauthorized copies of some commercially-produced film and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted. More information about Cinavia technology is provided at the Cinavia Online Consumer Information Centre at http:// www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA." This product incorporates proprietary technology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 20042010 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited. - Open Source Licence Notice In the case of using open source software, Open Source Licences are available on the product menu. 63 - English Appendix This device supports DivX Plus Streaming® for enjoying HD movies and TV shows with advanced features (multilanguage subtitles, multiple audio tracks, chapters, smooth FF/RW, etc.) streamed to your device. © 2015 Samsung Electronics Co., Ltd. All rights reserved. Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Area ` Asia Pacific CHINA HONG KONG MACAU SINGAPORE AUSTRALIA NEW ZEALAND VIETNAM THAILAND MYANMAR MALAYSIA INDONESIA PHILIPPINES TAIWAN JAPAN INDIA BANGLADESH SRI LANKA Contact Centre 400-810-5858 (852) 3698 4698 0800 333 1800-SAMSUNG(726-7864) 1300 362 603 0800 726 786 1800 588 889 0-2689-3232, 1800-29-3232 +95-01-2399-888 1800-88-9999 603-77137477 (Overseas contact) 021-56997777 08001128888 1-800-10-7267864 [PLDT] 1-800-8-7267864 [Globe landline and Mobile] 02-4222111 [Other landline] 0800-329999 0120-363-905 1800 3000 8282 - Toll Free 1800 266 8282 - Toll Free 9612300300 94117540540 AH68-02795H-00 Web Site www.samsung.com/cn/support www.samsung.com/hk/support (Chinese) www.samsung.com/hk_en/support (English) www.samsung.com/support www.samsung.com/sg/support www.samsung.com/au/support www.samsung.com/nz/support www.samsung.com/vn/support www.samsung.com/th/support www.samsung.com/support www.samsung.com/my/support www.samsung.com/id/support www.samsung.com/ph/support www.samsung.com/tw/support www.samsung.com/jp/support www.samsung.com/in/support www.samsung.com/support AH68-02795H-00
advertisement
Key Features
- Blu-Ray player Black
- 1330 W 7.1 channels
- Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS-HD Master Audio
- 3D
- FM radio
- Bluetooth Wi-Fi Ethernet LAN
