Instructions for use
09000
JA
tp PO = = == ———-— - - - — = —-- == жет к « - - —————— = к == и эт неко = —— шт nm == о = =
+
Return your Warranty Registration card today to ensure you
receive all the benefits you're entitled to.
Once your PHILIPS MAGNAVOX purchase is registered, you're eligible to receive all the privileges of
owning a PHILIPS MAGNAVOX product. So complete and return the Warranty Registration Card
enclosed with your purchase at once. And take advantage of these important benefits.
, Warranty | Owner JModel
Verification Confirmation Registration
Registering your product within Your completed Warranty Returning your Warranty
10 days confirms your right to Registration Card serves as Registration Card right away guar-
maximum protection under the verification of ownership in the antees you'll receive all the infor-
terms and conditions of your event of product theft or loss. mation and special offers which
PHILIPS MAGNAVOX warranty. you qualify for as the owner of your
model.
Congratulations on your purchase,
and welcome to the “family!” PHILIPS LES
Dear PHILIPS MAGNAVOX product owner:
Thank you for your confidence in PHILIPS MAGNAVOX. You've selected one of the best-built, best-
backed products
available today. And we'll do everything in our power to keep you happy with your purchase for many
years io come.
As a member of the PHILIPS MAGNAVOX “family,” you're entitled to protection by one of the most
comprehensive warranties and outstanding service networks in the industry.
What's more, your purchase guarantees you'll receive all the information and special offers for which
you qualify, plus easy access to accessories from our convenient home shopping network.
And most importantly you can count on our uncompromising commitment to your total satisfaction.
All of this is our way of saying welcome—and thanks for investing in a PHILIPS MAGNAVOX product.
Sincerely,
= == > P.S. Remember, to get the most from your PHILIPS
MAGNAVOX product, you must return your
Robert Minkhorst Warranty Registration Card within 10 days. So
President and Chief Executive Officer please mail it to us right now!
A This “bolt of lightning” indicates uninsulated material within your unit may cause an electrical
K NOW th ese shock. For the safety of everyone in your household, please do not remove product covering.
Л The “exclamation point” calls attention to features for which you should read the enclosed lit-
Ss a e y Sym bo Is erature closely to prevent operating and maintenance problems.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT
TO RAIN OR MOISTURE.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, and fully insert.
ATTENTION: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la
borne correspondante de la prise et pousser jusqu'au fond.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE NE
AVIS PAS QUVRIR |
PHILIPS TERIA Visit our World Wide Web Site at http://www. philipsmagnavox.com
-— = - — = >. e E om mmm a AA ALA A A CC —к ные — — €—]o— —]]]_—lÑ——]_—] —;——;—]]]——;—U— еле сны habe MS AR ma Ea i —
CAUTION: This Digital Video Disc Player employs a Laser System.
To ensure proper use of this product, please read this owner's manual carefully and retain for future reference.
Should the unit require maintenance, contact an authorized service location - see service procedure.
Use of controls, adjustments or the performance of procedures other than those specified herein may result in
hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications made to this equipment, not expressly approved by Philips Consumer Electronics
Company, or parties authorized by Philips Consumer Electronics Company, could void the user's authority to
operate the equipment.
Location of the required label
PRODUCT IS CERTIFIED BY THE MANUFACTURER TO
COMPLY WITH DHHS RULES 21 CFR SUBCHAPTER J
APPLICABLE AT THE DATE OF MANUFACTURE.
MANUFACTURED
DISTRIBUTED BY:
PHILIPS CONSUMER ELECTRONICS CO.
P, 0 .BOX 14810 KNOXVILLE, TN 37914-1810
2 ни
IMPORTANT SAFETY INSTRUCTION
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER’S MANUAL AND
THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The
safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit
is fully transistorized and does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL ONLY.
. Read owner's manual VE A
After unpacking this product, read BS 2
the owner's manual carefully, and NY - E
follow all the operating and other
instructions. =
. Power Sources
This product should be operated
only from the type of power source
indicated on the marking label. If
you are not sure of the type of power
supply to your home, consult your
product dealer or local power com-
pany. For products intended to
operate from battery power, orother
sources, refer to the operating in-
structions.
. Grounding or Polarization
This product may be equipped with
a polarized alternating current line
plug (a plug having one blade wider
than the other). This plug will fitinto
the power outlet only one way. This
is a safety feature. If you are unable
to insert the plug fully into the out-
let, try reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
>,
. Ventilation
Slots and openings in the cabinet
are provided for ventilation and to
ensure reliable operation of the
product and to protect it from over-
heating. These openings must not
be blocked or covered. The open-
ings should never be blocked by
placing the product on a bed, sofa,
rug or other similar surface. This product should not be
placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer's
instructions have been adhered to.
. Water and Moisture
. Cleaning
. Power-Cord Protection
. Overloading
. Heat
The product should be situated
away from heat sources such as |
radiators, heat registers, stoves, ©
or other products (including ampli-
fiers) that produce heat.
Do not use this product near water
- for example, near a bath tub, wash
bowl, kitchen sink, or laundry tub; in
a wet basement; or near a swim-
ming pool and the like.
Unplug this product from the wall
outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
Power-supply cords should be
routed so that they are not likely to =
be walked on or pinched by items
placed upon or against them, pay-
ing particular attention to cords at
plugs, convenience receptacles,
and the point where they exit from
the product.
Do not overload wall outlets, exten-
sion cords, or integral convenience
receptacles as this can result in a
risk of fire or electric shock.
10. Lightning
For added protection for this prod-
uct during a storm, or when itis left
unattended and unused for long
periods of time, unplug it from the
wall outlet. This will prevent dam-
age to the product due to lightning
and power-line surges.
11.Object and Liquid Entry
Never push objects of any kind into
this productthrough openings as they
may touch dangerous voltage points
or short-out parts that could result in
a fire or electric shock. Never spill
liquid of any kind on the product.
12. Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
13. Accessories
Do not place this product on an
unstable cart, stand, tripod, bracket,
ortable. The product may fall, caus-
ing serious injury to a child or adult, e
and serious damage to the product.
Use only with a cart, stand, tripod,
bracket, or table recommended by
the manufacturer, or sold with the
product. Any mounting of the product should follow the
manufacturer's instructions, and should use a mounting
accessory recommended by the manufacturer.
A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may
cause the product and cart combination to overturn.
A
YE
“NA
14.Disc Tray
Keep your fingers well clear of the
disc tray as it is closing. It may: =
cause serious personal injury.
>
ha ``
15.Burden
Do not place a heavy object on the
product or step onit. The object may
fall, causing serious personal injury
and serious damage to the prod-
uct.
16. Headphones
When you use headphones, keep
the volume at a moderate level. If
you use the headphones continu-
ously at a high volume, it may
cause hearing damage.
17.Disc
Do not use a cracked, deformed,
or repaired disc. These discs
are easily broken and may
cause serious personal injury
and product malfunction.
NN
7, EX
a O
С
(Эм
AS
A A BO a e a = ое —_———
18.Damage Requiring Service
Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the
product.
c) If the product has been exposed to rain or water.
d) Ifthe product does not operate normally by following the
operating instructions. Adjust only those controls that
are covered by the operating instructions as an improper
adjustment of other controls may result in damage and
will often require extensive work by a qualified techni-
cian to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way.
f) When the product exhibits a distinct change in per-
formance - this indicates a need for service.
19. Servicing
Do not attempt to service this prod-
uct yourself as opening or removing
covers may expose you to danger-
ous voltage or other hazards. Refer
all servicing to qualified service per-
sonnel.
20.Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or have the same characteristics as the origi-
nal part. Unauthorized substitutions may resultin fire, electric
shock, or other hazards.
21. Safety Check
Upon completion of any service or
repairs to this product, ask the ser-
vice technician to perform safety
checks to determine that the prod-
uct is in proper operating condition.
4 ни
mm 5
Introduction )
Precautions
Notes on Handling
Mm When shipping the DVD video player, the original shipping
carton and packing materials come in handy. For maximum
protection, repack the unit as it was originally packed at the
factory.
Do not use volatile liquids, such as insect spray, near the
DVD video player. Do not leave rubber or plastic products in
contact with the DVD video player for a long time. They will
leave marks on the cabinet.
The top and rear panels of the DVD video player may
become warm after a long period of use. This is not a
malfunction.
When the DVD video player is not in use, be sure to remove
the disc and turn off the power.
If you do not use the DVD video player for a long period, the
unit may not function properly in the future. Use the DVD
video player occasionally.
Notes on Location
m When you place this DVD video player near a TV, radio, or
VCR, the playback picture may become poor and the sound
may be distorted. In this case, place the DVD video player
away from the TV, radio, or VCR.
Notes on Cleaning
Use a soft, dry cloth for cleaning.
® For stubborn dirt, soak the cloth in a weak detergent solution,
wring the cloth well, and wipe the unit. Use a dry cloth to wipe
it dry.
Do not use any type of solvent, such as thinner and benzine,
as they may damage the surface of the DVD video player.
® If you use a chemical saturated cloth to clean the unit, follow
that products instructions.
Notes on Moisture Condensation
Moisture condensation damages the DVD video
player. Please read the following carefully.
Moisture condensation occurs, for example, when you pour a
cold drink into a glass on a warm day. Drops of water form on
the outside of the glass. In the same way, moisture may
condense on the optical pick-up lens inside this unit, one of the
most crucial internal parts of the DVD video player.
examples of moisture
condensation 7
E Moisture condensation occurs during the
following cases.
@ When you bring the DVD video player directly from a cold
place to a warm place.
@ When you use the DVD video player in a room where you
just turned on the heater, or a place where the cold wind
from the air conditioner directly hits the unit.
O In summer, when you use the DVD video player in a hot
and humid place just after you move the unit from an air
conditioned room.
E Do not use the DVD video player when moisture
condensation may occur.
If you use the DVD video player in such a situation, it may
damage discs and internal parts. Remove the disc, connect
the power cord of the DVD video player to the wall outlet, turn
on the DVD video player, and leave it for two or three hours.
After two or three hours, the DVD video player will have
warmed up and evaporated any moisture. Keep the DVD
video player connected to the wall outlet and moisture
condensation will seldom occur.
rn a =
Introduction )
Table of Contents
J Introduction
A A ME E TEA A A 8
Ш SAFETY PRECAUTIONS
Cerra 2 E Identification of Controls .......................... 7-10 o.
E IMPORTANT SAFETY Front Panel / Rear Panel / DVD display - ©);
=r
INSTRUCTIONS …………….……vreeosrereesercenreerencens 3,4 Remote Control SC
, Preparing the Remote Control (0) =.
EH PrECAaUtIONS ….….....….....reccarcerareererncsrsensersen sacs 5 Operating with the Remote Control =
< Connections
H Connecting to à TV viverra, 11 EM Connecting to Optional Equipment ........ 13, 14
M Connecting to an Audio System ................... 12 Enjoying Dolby Digital (AC-3) Sound
Enjoying Dolby Pro Logic Surround Sound
Enjoying Two-channel Digital Stereo Sound
J Basic Playback
E Playing a Disc .........................e.earereneencen. 15-18 H Locating a Specific Title, Chapter, BE
Basic Playback Or Track -.................mereneronnonincne caen 19,20 Roi
Playing at Twice, Eight Times, or Thirty Times Locating a Title Using the Title Menu e y .
the Normal Speed Locating a Title O
Playing Frame by Frame Locating a Specific Chapter or Track Directly Ore
Playing in Slow Motion Locating a Specific Chapter or Track 2
Resuming Playback from the Same Location Locating a Specific Location on the Disc COR
J Advanced Playbac
E Playing Repeatedly ..................e.emcorororzereeeees 21 Ш Selecting the Camera Angle ........................ 25
Repeating a Title, Chapter, or Track Changing the Camera Angle
Repeating a Specific Segment NM Selecting a Language .....................eeeeenen. 26
Ш Playing na Favorite Order esravestavassaretanaoianao 22 Selecting a Playback Audio Setting
Setting Titles, Chapters, or Tracks in a Favorite Order N Selecting Subtitles ……………………………sesesersesese 27
M Playing in Random Order essen 23 Displaying Subtitles
Playing Titles in Random Order Selecting a Subtitle Language
Playing Chapter or Tracks in Random Order ME Using the On-Screen Display ....................... 28
H Zooming a Picture/ Checking the Operational Status
Playing 3-D (N-2-2) SoUNA are 24 Checking the Remaining Time and Setting Status
Zooming a Picture
Playing 3-D (N-2-2) Sound
x Function Setup
M Customizing the Settings .................—..... 29-36 H Setting the Parental Lock .......................
Displaying the SET UP MENU Screen Setting the Parental Lock
Setting the Audio H Table of LangUaAGSS rer
Setting the Functions
Setting the Displays
J Others
Ш Notes on Discs................ewreesererorerercerreneneea 40 Bl MEMO coerce ree
Ш Before Calling Service Personnel ................ 41 E Factory Service Center Locations
E Specifications..................ee.ererrerercororeereren. 42 E Limited Warranty .................e..........
ar — A Aimy еее ще ен он — we E
+
Introduction )
Identification of Controls
| See the page in [> for details.
Front Panel / Rear Panel / DVD Display
Front Panel
POWER ON/STANDBY button [15)
PREVI (Previous) button
POWER ON/STANDBY indicator [15) — DVD display — PLAY button [15)
7
4 `
я Si
3,
a
-
i
| SPEER
Fa
/
a y
|
|
fl
|
1
a Disc tray 115)
\— OPEN/CLOSE button [15
\— LEVEL knob [11)
——— PHONES jack [11)
Rear Panel
“ NEXT button 20)
— STOP button
———— PAUSE button
S VIDEO OUT jack [11 12” — VIDEO OUT jack [11)[12)[13)
RS _
| | AUD O OUT I EN
o ———l
ANALOG AUDIO
OUT (L/R) jack
11) 12) Power cord \
BITSTREAM/PCM AUDIO OUT jack [13) [14) — Power plug
== = о —
DVD Display
VIDEO CD/Audio CD indicator
H Pressing of the FL ON/OFF button on the remote control
turns the DVD display on or off.
Operating status indicator
Title number indicator
|
FL ON/OFF
On «—» Off
r— MEMORY indicator
SHUFFLE indicator
— PBC indicator
E |
Li Li A
TITLE CHPITRACK > Pe TOTAL — REMAIN
La Ea
Li Li Li
in CD Ca
oe eo Co
я Ур NE en x | |REFEAD) REPEAT) A-B auf} Angle icon indicator
Chapter/track-number indicator __)
DVD indicator
M The indicators vary depending on the kinds of discs you play.
DVD Video discs
* When closing the disc tray:
Example
me
y DVD
Total number of titles
Some DVD video discs may not display
the total number of titles.
VIDEO CDs
When closing the disc tray:
Example
cena vb TOTAL
1e 84538 |
= oT
Total number Total playing time
of tracks of the disc
Lights up when using a PBC-controllable
VIDEO CD.
i
Repeat playback mode indicators
/ Total playing time/remaining time/elapsed time indicators
Audio CDs
* When closing the disc tray:
Example
12 04538
= ——
Total number of Total playing
tracks time of the disc
* During playback:
Example
CRACK >
2 - 3, рур U 99,
Playing chapter Elapsed time of
3 in title 2 the current title
Some DVD video discs may not display
the chapter numbers or elapsed time.
M Other indicators
When playing the
same title, chapter or
track repeatedly.
FD)
When playback is
Al paused.
During random
playback. [23>
* During playback:
Example
dial VD
5 80822
, = =
Playing track 6 Elapsed time of
the current track
Some VIDEO CDs may not display the
track numbers or elapsed time.
When playing a
specific segment
ERE A. repeatedly.
(A-B repeat) [21>
During memory
playback. 22)
* During playback:
Example
CHPARACK, co
5 MONI
D, ¡UU UE
T
Playing track 6 Elapsed time of
the current track
When playing the
entire disc repeatedly.
REPEAT ALL (21)
| When the camera
angle can be changed.
E) |
6 HN
ma 9
Introduction )
Remote Control
Identification of Controls (continued)
The instructions in this manual describe the functions on the remote control.
See the page number inside the [ _) for details.
Ml
LI
ón
OPEN/CLOSE button [15)
| |oPENCLOSE ZOOM FLONOFF POWER |
Kann
|
1 SUBTITLE — 30/
| | SETUP DISPLAY *SU= | SU.
|!
|| ANGLE AUDIO SUBTITLE
DISPLAY button
ANGLE button 25)
=
1
POWER button [15)
FL ON/OFF button
3D button
This button works as the 3D button.
The printed “LAST PLAY” is not a
function of this unit.
SUBTITLE ON/OFF button 27>
SUBTITLE button 27)
AUDIO button
Number buttons
A rire
T button
TITLE button
Direction buttons
(4, Y, <,>)
ENTER button
+
MENU button*
CLEAR button 21)
REV (Reverse) button 17>
; REV PLAY
Ú
Е
2)
| (6) (0
|
© ©.
5 MENU |
Es
FWD PAUSESTEP © (7
— 7) CO A
PLAY button [15)
SKIP STOP SKIP SLOW
RETURN button (32>
PAUSE/STEP button (16 >[17)
FWD (Fast forward) button 17»
SKIP button
EE
MEMORY SHUFFLE REPEAT A-B RPT
STOP button
SLOW button
SKIP button
MEMORY button [22>
> t
SHUFFLE button 23>
* MENU button
о
=
=
о
un
A-B RPT button [21
REPEAT button 21)
Use the MENU button to display the menu screen included on DVD video discs. To operate a menu screen, follow
the instructions in “Locating a Title Using the Title Menu” (19).
Preparing the Remote Control Operating with the Remote Control
Insert the batteries into the remote control so you can use it to This section shows you how to use the remote control.
operate the DVD video player. =
1 Open the cover. Point the remote control at the =
remote sensor on the DVD video =
player and press the buttons.
ul
е 2.
Within about 20 feet
Y
Distance: Within about 20 feet from the front
of the remote sensor
Angle: © Within about 30° in each direction
of the front of the remote sensor
Make sure to match the + and — on the = Do not expose the remote sensor of the
batteries to the marks inside the battery DVD video player to a strong light source
compartment. such as direct sunlight or illumination. If
you do so, you may not be able to operate
3 Close the cover. the DVD video player with the remote
control.
MERS = PUCES
Improper use of batteries may cause battery leakage and corrosion. To * Point the remote control at the remote sensor of the DVD video player.
operate the remote control correctly, follow the instructions below. * Do not drop the remote control.
* Do not insert batteries into the remote contro! in the wrong direction * Do not leave the remote control near an extremely hot or humid place.
(follow the +/- signs). * Do not spill water into or put anything wet on the remote control.
* Do not charge, heat, open, or short-circuit the batteries. Do not throw * Do not open the remote control.
batteries into a fire.
* Do not leave dead or exhausted batteries in the remote control.
Do not use different types of batteries together or mix old and new
batteries.
* If you do not use the remote control for a long period of time, remove
the batteries to avoid possible damage from battery corrosion.
* If the remote control does not function correctly or if the operating
range becomes reduced, replace all batteries with new ones.
* If battery leakage occurs, wipe the battery liquid from the battery
compartment, then insert new batteries.
10 mam
ma 77
Connections ) For details of output sound, see 26).
Connectingtoa TV
Connecting to a TV
Connect the DVD video player to your TV.
E Setting of the sound output
From the on-screen displays, set “AUDIO OUT SEL.” to “ANALOG.” [29> [31
To wall outlet
pe —
со rome Power plug
o
: es 3
— | lp
(red) & (white) |
To S VIDEO OUT | OR
> Signal flow
To VIDEO OUT To ANALOG AUDIO OUT
Audio/video cable (supplied)
| | To audio input jacks
To video input jack (yellow) (red) y (white)
OR
S video cable (supplied) To S video input
If the TV has an $ video input, connect the DVD
video player to the TV using the supplied S video
cable. When using the S video cable, there is no TV or monitor with
need to connect the yellow video cable. audio/video input jacks
* Set your TV to accept
Auxiliary (Line) input.
See your TV owner's
manual for details.
If your TV has an RF (Antenna In) jack only, use an RF modulator
(not supplied) to connect the DVD player to your TV.
| Notes |
* Refer to the owner's manual of the connected TV as well.
* When you connect the DVD video player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any
connections.
* If your television set has one audio input jack, use a Y cable adapter (not supplied) to connect the DVD video player to your TV.
* Connect the DVD video player directly to your TV. If you connect the DVD video player to a VCR, TV/VCR combination, or video selector, the
playback picture may be distorted as DVD video discs are copy protected.
Connecting headphones |
Connect headphones to the PHONES jack on the front panel 7
using a stereo plug. la of o Push the knob out to turn.
Before connecting, temporarily turn down the volume with \ == oi
the LEVEL knob. Readjust to your preference when me ÓóÓ— —— O).
playback begins. = Down” * Up
— a A LA — ARMA AE Er mR m= mmm a к ee am = ama = = ке — =
Connections ) For details of output sound, see [26).
Connecting to an Audio System
You can listen to the sound of the discs in stereo.
Connecting to an Audio System
M Setting of the sound output
From the on-screen displays, set “AUDIO OUT SEL.” to “ANALOG.” ED,
To wall outlet
ER
AU? OST EE
ANALOG ETSTF CANE POL Power plug
e
г i | |]
Сы . : | | с 5
To S VIDEO OUT OR (yellow) (white) \
TO VIDEO
UT
> Signal flow ©
To ANALOG AUDIO OUT
Audio system
(white) (Ola =x О| + Set your amplifier to receive
Olo?¿ EH 10 Auxiliary (Line) input.
EH See your audio system's
(red) "=> owner's manual for details.
To audio input jacks
of the amplifier
To video input jack (yellow) * Set your TV to accept
= Auxiliary (Line) input.
OR See your TV owner’s
S video cable (supplied) To S video input jack manual for details.
If the TV has an S video input, connect
the DVD video player to the TV using
the supplied S video cable. When using
the S video cable, there is no need to
connect the yellow video cable.
TV or monitor with a video input
jack or an S video input jack
| Notes Ÿ
* Refer to the owner's manual of the connected equipment (TV, audio system) as well.
* When you connect the DVD video player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet
before making any connections.
* If you place the DVD video player near a tuner or radio, the radio broadcast sound might be distorted. In this case, place the DVD video player
away from the tuner and radio.
* The output sound of the DVD video player has a wide dynamic range. Be sure to adjust the receiver's volume to a moderate listening level.
Otherwise, the speakers may be damaged by a sudden high volume sound.
* Turn off the amplifier before you connect or disconnect the DVD video player's power cord. If you leave the amplifier power on, the speakers
may be damaged.
12 mm
Connections ) For details of output sound, see [26).
Connecting to Optional Equipment
| { You can enjoy the high quality dynamic sound of Dolby Digital (AC-3), Dolby Pro Logic, and Two-Channel Digital Stereo.
Enjoying Dolby Digital (AC-3) Sound
Dolby Digital (AC-3)
Dolby Digital is the surround sound technology used in movie theaters; it is now available in the home. You can enjoy motion picture and live concert DVD
video discs with this dynamic realistic sound by connecting the DVD video player to a six-channel amplifier equipped with a Dolby Digital (AC-3) decoder or
Dolby Digital (AC-3) processor. If you have a Dolby Pro Logic Surround decoder, you will obtain the full benefit of Pro Logic from the same DVD movies that
provide full 5.1-channel Dolby Digital soundtracks, as well as from titles with the Dolby Surround mark.
E Setting of the sound output qe
* From the on-screen displays, set “AUDIO
OUT SEL.” to “BITSTREAM.” ED,
e Select “AC-3” from the sound recording ET
systems of the disc. A
Use DVD video discs recorded on the Dolby Digital Creed
(AC-3) recording system. To VIDEO OUT To BITSTREAM/PCM AUDIO OUT
Video cable 75 Q coaxial cable
=) Signal flow
Connection example )
To COAXIAL type digital audio input
L N
о Е Amplifier equipped with a
о = © | Dolby Digital (AC-3) decoder
оо E _ 19000
|
| To video input of TV |
FN
Front speaker Front speaker
(left) | TV | (right)
— Center =
“и” ——]
— speaker ~~ NN
—— > ——— = Sub woofer
И с —=—=—
;— TN
= =
Rear speaker — Rear speaker
(left surround) = Va (right surround)
N 7
Manufactured under license from Dolby Laboratories Licensing Corporation. “Dolby,” “AC-3,” “Pro Logic,” and the double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
| Notes
* DO NOT connect the BITSTREAM/PCM AUDIO OUT jack of the DVD video player to the AC-3 RF input of a Dolby Digital Receiver. This input on your AV
Receiver is reserved for Laserdisc use only and is incompatible with the BITSTREAM/PCM AUDIO OUT jack of the DVD video player.
« Connect the BITSTREAM/PCM AUDIO OUT jack of the DVD video player to the “DIGITAL” or “COAXIAL” input of a Dolby Digital Receiver or Processor.
Refer to the owner's manual of the connected equipment as well.
When you connect the DVD video player to other equipment, be sure to tum off the power and unplug all of the equipment from the wall outlet before making any
connections.
* The output sound of the DVD video player has a wide dynamic range. Be sure to adjust the receiver's volume to a moderate listening level. Otherwise, the
speakers may be damaged by a sudden high volume sound.
* Tum off the amplifier before you connect or disconnect the DVD video player's power cord. If you leave the amplifier power on, the speakers may be damaged.
ния 73
РЕЗ - «о A a —A vn —_—_ ко
———= — тли токмо све = сете AAA = нк еже ео емко = ее Ce тт = кости то ше ® ине тс ен A A жене
Warning
Do not set “AUDIO OUT SEL.” to “BITSTREAM?” via the on-screen displays [31> unless you are connecting (via the BITSTREAM/PCM AUDIO
OUT jack) an AV decoder that has the Dolby Digital (AC-3) decoding function. High volume sound may damage your hearing as well as the speakers.
Enjoying Dolby Pro Logic Surround Sound
Enjoying Two-channel Digital Stereo Sound
Dolby Pro Logic Surround Two-channel Digital Stereo
You can enjoy Dolby Pro Logic Surround sound by connecting an You can enjoy Two-channel Digital Stereo sound by connecting an
amplifier and speaker system (right and left front speakers, a center amplifier equipped with a digital audio input and speaker system
speaker, and one or two rear speakers). (right and left front speakers).
» With an amplifier equipped with Dolby Digital (AC-3),
il
Connect the equipment the same way as described in “Enjoying
Dolby Digital (AC-3) Sound” (13) . Refer to that amplifier's owner's
manual and set the amplifier so you can enjoy Dolby Pro Logic Foe pea = > > me
Surround sound. @£ @ © ©
= With an amplifier not equipped with Dolby Digital (AC-3), — | |
Connect the equipment as follows. To VIDEO OUT To BITSTREAM/PCM
AUDIO OUT
= Signal flow
, sais © u Video cable 75 Q coaxial cable
E 2e E A
(o ,
Cora) 1 Connection
i i
To VIDEO OUT To ANALOG AUDIO OUT example | To digital audio input
RP NN
Signal flow o Amplifier with a digital
= audio input
Video cable Audio cable
( Connection x | To video input of TV
To audio input
example vv)
TV |
Amplifier equipped with Front speaker — (=> Front speaker
Dolby Pro Logic Surround = (right)
e <= —
т — - ”
- T — “и”
rm 2 mt
| В video input of TV == >
TV |
Front speaker = = Front speaker _
(left) = = == (right)
==> <<
Ш Set “AUDIO OUT SEL.” to “PCM” via the
Center speaker a on-screen displays. [31D
— Connect one or two rear
“то
Rear speaker = speakers.
The output sound from the
rear speakers will be
monaural even if you
« connect two rear speakers.
J
E Set “AUDIO OUT SEL.” to “ANALOG” via the on-
screen displays. 29) 31)
| Notes |
* Connect the speakers according to the instructions in the owner's manual for the speaker system.
* Refer to the owner's manual of the connected equipment as well.
» When you connect the DVD video player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any
connections,
* The output sound of the DVD video player has a wide dynamic range. Be sure to adjust the receiver's volume to a moderate listening level. Otherwise, the
speakers may be damaged by a sudden high volume sound.
* Turn off the amplifier before you connect or disconnect the DVD video player's power cord. If you leave the amplifier power on, the speakers may be damaged.
14 mm
Basic Playback ) CAUTION
Keep your fingers well clear of the disc tray as it is
P / a yi n g a D i S C closing. It may cause serious personal injury.
POWER ON / STANDBY
indicator 3 PAUSE 4
pee
©
—
This section shows you how to play a disc. 1 2
Basic Playback
E Preparations
* When you want to play DVD video discs or VIDEO CDs, turn on the TV and put the TV in Auxiliary (Line) input mode.
* When you want to enjoy the sound of a disc from the audio system, turn on the audio system and set the amplifier to receive Auxiliary input.
* For connection details, see “Connections.” [11) —
* Set the playback picture size according to the picture tube shape or aspect ratio of the connected TV via the on-screen displays. 35)
POWER Press POWER.
[|
The DVD video player turns on and the POWER ON / STANDBY
indicator on the player lights.
OPENCLOSE Press OPEN/CLOSE.
[4]
The disc tray opens.
Place the disc in the disc tray. E Notes ]
* There are two different disc sizes. Place the
disc in the correct guide in the disc tray. If
A — the disc is out of the guide, it may damage
the disc and cause the DVD video player to
malfunction.
* Do not place anything except DVD video
discs, VIDEO CDs, or audio CDs in the disc
tray.
ZA PLAY Press PLAY. | Notes §
The disc tray closes and playback starts. * For PBC (Playback Control) of VIDEO CDs,
see “On VIDEO CD.”
If you insert a DVD video disc that contains a title menu, or inserta | * you may need to Dress Ie ТТ = or MEN
PBC (Playback Control)-controllable VIDEO CD, a menu screen on on the remote ¢ 0 display the
. в menu screen, depending on the disc.
may appear. See “To start playback from the menu screen.
To start playback of a PBC-controllable VIDEO CD from the menu
screen, set “PBC” to “ON” via the on-screen displays.
au a «E
With the label facing up X
' Notes |
* Do not move the DVD video player during playback. Doing so may damage the disc.
* Use the OPEN/CLOSE button on the remote control or DVD video player to open and close the disc tray. Do not push the disc tray while it is moving.
Doing so may cause the DVD video player to malfunction.
* Do not push up on the disc tray or put any objects other than discs on the disc tray. Doing so may cause the DVD video player to malfunction.
E 75
a
a —
= Eh we wma ев = — e == кк == - — 7 am
M To obtain a higher quality picture
Occasionally, some picture noise may appear on the TV screen
1 while playing a DVD video disc because the high resolution pictures
on these discs include a lot of information. While the amount of noise
2 depends on the TV, you should reduce the sharpness adjustment on
your TV from the position you usually set for normal broadcasts.
TITLE
ENTER E About DVD VCO CDD
MENU The 7 4 > symbols on the heading bar in this manual show
a/v/4/> the playable discs for the function described under that heading.
PAUSE/STEP PYD” : You can use this function with DVD video discs.
4 NED» : You can use this function with VIDEO CDs.
STOP ¿ED : You can use this function with audio CDs.
и и о
To start playback from the menu screen
To pause playback (still playback)
1 Press @ / v /<</» orthe number buttons to
select the title you want. PAUSESTEP — Press PAUSE/STEP during
1/1» playback.
Example
To resume normal playback, press the
SZ 9 PLAY button.
fo]
<> * The sound is muted during still playback.
To remove the disc
2 Press ENTER. (You do not have to press
ENTER to start playback if you use the OFICIOS Press OPEN/CLOSE.
number buttons at step 1.)
| == _ The DVD video player starts playback from
1h ES 6 ) the selected title.
-
* When not using the menu screen of a PBC-controllable
VIDEO CD, set “PBC” to “OFF” vía the on-screen
displays.
Remove the disc after the disc tray
opens completely.
Fr
x
*
x" . X
cago OÍ
pres,
A 1
uy
HN
+
- D
«Bas A
mn
= 1 "
To stop playback
STOP
ED Press STOP.
* Be sure to press the OPEN/CLOSE
button to close the disc tray after you
remove the disc.
J Notes |
* In many Instances, a menu screen will appear after playback of a movie is completed. Prolonged display of an on-screen menu may damage your
television set, permanently etching that image onto its screen. To avoid this, be sure to press the STOP button once the movie is completed.
* If you pause a picture and leave it still for a long while, the screen saver of the DVD video player automatically appears. To turn off the screen saver,
press the PLAY button.
About this owher's manual
This owner's manual explains the basic instructions of this DVD video player. Some DVD video discs are produced in a
manner that allows specific or limited operation during playback. As such, the DVD video player may not respond to all
operating commands. This is not a defect in the DVD video player. Refer to the instruction notes of discs.
“ W ” may appear on the TV screen during operation. A white “ 4 ” means that the operation is not permitted by the DVD video
player; a red “ 4 ” means the operation is not permitted by the disc.
16 mm
Basic Playback )
X 2 X 8 X30
a т o
Frame Slow- ;
by Frame Motion Resuming
El md mi
location where you stopped playback.
Playing at Twice, Eight Times, or Thirty Times the Normal Speed
You can play a disc at twice, eight times, or thirty times the
normal speed. |
Playing a Disc (continued)
You can play discs at various speeds and resume playback from the
REV Press REV or FWD during playback.
(<<) * DVD video disc
Each time you press the REV or FWD
FWD button, the playback speed changes.
>>] REV: Fastreverse playback
| FWD: Fastforward playback
| TV screen
x2 xB X30
— —-
saa rm
Eight times the
normal speed
Thirty times the
normal speed
Twice the
normal speed
VIDEO CD/Audio CD
The fast reverse or fast forward playback
alternates between two speeds.
TV screen
REV FR1 FR2
(<<) _ Fast reverse playback
FWD FF1 FF2
>>] — Fast forward playback
To resume normal playback
PLAY
>)
Press PLAY.
| Notes |
es The DVD video player does not play sound and subtitles during
reverse and forward scan of DVD video discs.
However, the DVD video player plays sound during fast forward or fast
reverse play of audio CDs.
* Twice, eight times, or thirty times the normal playback speeds are only
approximate speeds. These speeds may vary slightly from disc to disc.
mes 7 7
|
|
|
er
он
НО
НОНО.
НН
НОНО
7
с |
|»)
DO ИЕ |
v
A A
VE FWD
t Ms tH
= / 6 PAUSE/STEP
DVD, VCD,
Playing Frame by Frame
You can advance a picture frame by frame.
Press PAUSE/STEP during playback
to begin still playback.
Each time you press the PAUSE/STEP
button, the picture advances one frame.
PAUSE/STEP
ПЛ»
To resume normal playback
PLAY
>)
Note
The sound is muted during frame by frame playback.
Press PLAY.
'
E —— mt emma em dw = a oa nm mem AAA AAA AER a me allie A LD E A A A - = —————
| \ f \
| 1 + | SL р ZZ |
Pedo Izcoa!
- |- са |
{ | — DO |
Pod = > — — |
o a Pe
E des
| ‘ ) 2 Zo
£ PLAY =6=- 1 2
DVD> VCD DVD> _VCD>_.CD
Playing in Slow Motion Resuming Playback from the Same Location
You can play a disc in slow motion. You can stop playback and resume playback later from the same
location on the disc.
SLOW Press SLOW during playback. 1 STOP Press STOP at the location where
[>] Each time you press the SLOW button, the (=) you want to interrupt playback.
slow motion speed changes. The DVD video player memorizes the
TV screen location where you stopped playback.
2 1/8 1/16
— — pj PLAY Press PLAY. o
1/2 the 1/8 the 1/16 the (>) The DVD video player resumes playback ©
normal speed normal speed normal speed =
from the location where you stopped
playback.
BES Pen
To start playback from the beginning regardless of
the location where you stopped playback
1 Press STOP twice.
STOP
Cm)
2 Press PLAY.
The DVD video player's memory is cleared.
PLAY If you are using a DVD video disc, playback
(>) starts from the beginning of the current title.
[f you are using a VIDEO CD or an audio CD,
To resume normal playback playback starts from the beginning of the disc.
* If you want to return to the beginning of a DVD
PLAY Press PLAY video disc, open and close the disc tray once
(>) ' with the OPEN/CLOSE button before pressing
the PLAY button.
| Note | Notes |
The sound is muted during slow motion playback. * The DVD video player's memory is also cleared when:
— you unplug the DVD video player from the wall outlet after you stop
playback.
— you open the disc tray.
— you adjust/change parental lock (37) or select a disc menu
language setting [36).
* There may be a difference of the location where playback resumes
depending on the disc.
* If you change the initial settings of languages 3D or subtitle
languages while the DVD video player is stopped, these new
settings will function only after the DVD video player's memory is
cleared.
18
-— = = = = ——-_ — —-—_ "2 — -- = же ко ==
mu 79
Basic Playback )
+ DVD video disc
Title 1 > | Title 2
Chapter 1 Chapter2| Chapteri Chapter2 Chapter 3
1 | ! 1 I
a a > p w= =
AVE FO LE SL EN
ее —
DVD
Locating a Title Using the Title Menu
If a DVD video disc contains a title menu, you can locate a
specific title using the title menu.
A TE Press TITLE.
O The title menu appears on the TV screen.
Example of a title menu
pl << Press a / w/-/» to select the title
С С°) © you want.
<> If the titles in the title menu are assigned a
number, you can directly locate a specific
title by choosing its assigned number with
the number buttons.
Bi << Press ENTER.
С I |) The DVD video player starts playback from
ED chapter 1 of the selected title.
(You may not need to press ENTER if you
use the number buttons at step 2.)
Notes |
e The instructions above describe the basic procedure. The procedure
varies depending on the contents of the DVD video disc. If different
instructions appear on the TV screen, follow those instructions.
* |f you display the title menu during playback and press the TITLE
button again without selecting any title, the DVD video player may
resume playback from the point where you first pressed the TITLE
button. !f it does not, press the PLAY button to resume playback.
Locating a Specific Title, Chapter, or Track
VIDEO CD / Audio CD -
Track 1 Track 2 Track 3 Track4 Track 5
|
na ime am ana | m
Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. VIDEO CDs and audio
1 CDs are divided into tracks. You can quickly locate any specific title, chapter, or track.
DVD,
Locating a Title
You can locate a specific title by entering a title number.
Press T.
Make sure that the space next to TITLE is
highlighted.
Example
TITLE: MT
CHAPTER: 1
Jak Press the corresponding number
со о © buttons for the title you want.
DOES
Example: To select title 2, press
IEE
To select title 12, press
> 2) TITLE: IH
OR CHAPTER: 1
>]
Si PLAY Press PLAY.
The DVD video player starts playback from
chapter 1 of the selected title.
| Notes |
* Some DVD video discs may have chapters, but no titles.
* You can shift the highlight between TITLE and CHAPTER by pressing
the à / W buttons.
* Pressing the CLEAR button resets the TITLE and CHAPTER numbers.
To clear the TITLE and CHAPTER display, press the T button
repeatedly.
* You can select a preferred language for on-screen displays. 35)
|
DVD) VCD CD
Locating a Specific Chapter or Track Directly
If you know the chapter or track number you want to play, you
can locate it directly.
Press T.
Skip steps I and 2 if you are using a VIDEO
CD or an audio CD.
(DVD video disc)
TITLE: MI
CHAPTER: 1
Press w to highlight the space next
2 IN
(3 Es 0) to CHAPTER.
{>>
(DVD video disc) |
TITLE: 1
CHAPTER:
3 oo Press the corresponding number
сз 3 5) buttons of the chapter or track you
9 oa want.
You can use the button to select
numbers from 10 through 99.
Example: To select chapter or track 25, press
| | (VIDEO CD/
(DVD video disc) Audio CD)
(2) -+(5_)
= CHAPTER'MEE | Rack: EE
+10 | > |+10| =»
PLAY Press PLAY.
>) The DVD video player starts playback from
the selected chapter or track.
To select a title and chapter number at the same time
Example: To select chapter 25 in title 2, press
PLAY
DJ Ek-<—>-C-EJ- >)
| N TITLE: 2
Title number Chapter number CHAPTER: JES
| Note $
Pressing the CLEAR button resets the TITLE and CHAPTER numbers.
To clear the TITLE and CHAPTER display, press the T button repeatedly.
- mam — ——— - - - = же — же ое о — - - fa = —
TITLE
T
Number buttons
ENTER
A/Y/<]
CLEAR
PLAY
SKIP
DVD, VCD) CD
Locating a Specific Chapter.or Track
You can fast forward or reverse through consecutive chapters or
tracks.
SKIP Press SKIP |«« or »»! (PREVI or
[) NEXT on the DVD video player)
repeatedly to advance or reverse to
SKIP the chapter or track number you want.
The DVD video player starts playback from
the selected chapter or track.
HE: To locate preceding chapters or tracks
When you press the << button, the DVD
video player starts playback from the
beginning of the current chapter or track.
When you press the << button twice, the
DVD video player starts playback from the
beginning of the preceding chapter or track.
>» : To locate succeeding chapters or tracks
BasiciBlayback
| Note |
Some titles may not display chapter numbers.
Locating a Specific Location on the Disc
You can locate a specific location by entering the time (hours,
minutes, seconds).
Press T twice.
You may have to press further depending on the
disc. Press the button repeatedly until the following
indication appears.
in pla
ее Press the number buttons to enter
OEE the time.
© a Example
[email protected] |TME A
(One hour, 25 minutes, 30 seconds)
61 PLAY Press PLAY.
= The DVD video player starts playback from
the specified location.
Notes |
* Some discs may not respond to this feature.
* Some scenes may not be located correctly as you specified.
* This locating is available only within the current title of the DVD video
disc or within the current track of the VIDEO CD/audio CD. 0 [
Advanced Playback )
Playing Repeatedly
ZZ
Z| ="
You can play a specific title, chapter, track, or segment repeatedly. zn Г
(Title repeat, chapter/track repeat, A-B repeat)
; DVD) VCD CD
Repeating a Title, Chapter, or Track
You can play the same title, chapter, or track repeatedly.
(Title, chapter/track repeat)
[
2
Begin playback of the title, chapter,
or track you want to repeat.
REPEAT
]
Press REPEAT.
Each time you press the REPEAT button, the
repeat mode changes as follows.
* DVD video disc
CHAPTER REPEAT
Repeats the same
| chapter.
}
TITLE REPEAT Repeats the same title.
}
REPEAT OFF Resumes normal
playback.
* VIDEO CD / Audio CD
TRACK REPEAT Repeats the same track.
+
AUL REPEAT Repeats the entire disc.
+
REPEAT OFF Resumes normal
playback.
—Ñ———.[.Ú.Ñ |
To resume normal playback
Note |
CLEAR
O Press CLEAR.
Some discs may not respond to the repeat function.
a 27
Г
НО
||
C1
|
|
зе ae
PL TR RA IEEE
A-B RPT
DYD2 VCD CD,
Repeating a Specific Segment
You can play a specific segment repeatediy. (A-B repeat)
JA ABRPT
as
During playback, press A-B RPT at the
beginning of the segment (point A)
you want to play repeatedly.
YA ABRPT Press A-B RPT again at the end of the
segment (point B).
A-B
The DVD video player automatically returns
to point A and starts repeat playback of the
selected segment (A-B).
To resume normal playback
CLEAR
O Press CLEAR.
| Notes |
* Some discs may not respond to the A-B repeat function.
* You cannot set the A-B repeat function for a segment that includes
multiple camera angles.
* You can specify a segment only within the current title.
There may be a slight difference between point A and the location
where playback actually resumes, depending on the disc.
Advanced Playback )
Playing in a Favorite Order
TITLE: 2 TITLE:2_ , TITLE:1
HA : 25 CHARTER : {25 CHAPTER"
Wi ES
You can combine your favorite titles, chapters, or tracks and play them
in any order. You can program up to 30 items into the memory.
(Memory playback)
—
.* e "* e *.
Setting Titles, Chapters, or Tracks in a Favorite Order
The DVD video player automatically plays titles, chapters, or tracks in the order you program.
JA MEMORY — While playback is stopped, insert a 1 MEMORY ————— setecr:e
: НН
(| disc and press MEMORY.
, 1 To2025 6 T--C--
The following menu appears. 2 T02G12 7 T--C--
3 To1C-- 8 T--C--
HN MEMORY — SELECT:ofe 4 T04C02 9 T--C--
5u--8M 10 T--C--
PRESS [0] Ou
_ __e-- .
: To a. С Chapter Der EXITGLD GEDSET
4 T--C-- 9 T--C-- number
5 T--0-- 10 T--C-- To select another chapter in the same title,
NEXT .
you do not need to select the title number.
EXIT GED GNDSET
Ni PLAY Press PLAY while the MEMORY menu
pi © Enter the items you want, in order, by >] appears on the TV screen.
QO pressing the number buttons, then The DVD video player starts memory
ama ENTER for each item. playback.
+ Each time you press the «/» button, the ——
— — indication next to T and C is highlighted РА’
To change the programmed items y
<a 7 in turn. Highlight the indication — — next to T
С © (to select a title) or C (to select a chapter),
then press the number buttons. 1 While the MEMORY menu appears on the TV screen,
press 4 / Y to move the highlighted bar to the item you
Example: To play chapter 25 in title 2, chapter 12 want to change.
in title 2, all the chapters in title 1, and ‚ ‚ ‚
chapter 2 in title 4. 2 Change the item following the instructions at step 2.
Title number Chapter number
ENTER To cancel the programmed items
|
Метогу 1 (a >|>)—[2)+[(5 )—Ce])
1 While the MEMORY menu appears on the TV screen,
E / Y to move the highlighted bar to the item you
Memory 2 т press A
CO->02J-> Ce) want to cancel.
Memory 3 (4-5 > С.) 2 Press the CLEAR button.
Memory 4 + © ——2)-C) To resume normal playback from memory
layback
To select tracks from a VIDEO CD/audio CD in Py
order, press the number buttons for the track, then CLEAR Press CLEAR.
press the ENTER button for each item you want. O The MEMORY indicator disappears.
| Notes 3
* Some discs may not respond to the memory playback function.
* If you press the REPEAT button during memory playback, the DVD video player repeats the current memory playback.
* If you press the MEMORY button during memory playback, the programmed items will be displayed.
* You cannot select title, chapter, and track numbers not included on the disc.
* If you press the MEMORY or RETURN button while the MEMORY menu appears on the TV screen, the MEMORY menu disappears.
* The programmed items will be cleared when:
— you turn off the DVD video player, or
— you remove the disc. 22 uN
-—=--— "<=" _——_— же — -—— 2 —-.._-_ = == —-
Advanced Playback )
ГИ
CHARTER! A
TR
(Random playback)
DVD
Playing Titles in Random Order
The DVD video player automatically selects the titles in a DVD
video disc and plays them randomly.
Jl SHUFFLE — Press SHUFFLE twice while playback
_ is stopped.
TITLE SHUFFLE
If you press the SHUFFLE button during
playback, the DVD video player automatically
starts random playback after finishing the
current title.
PA PLAY Press PLAY.
| >) The DVD video player starts random
| playback.
Press the PLAY button within about five
seconds after you press the SHUFFLE
button.
To resume normal playback
CLEAR
O Press CLEAR.
Notes |
* Some discs may not respond to the random playback function.
* You cannot use the random playback function and the memory
playback function at the same time.
mu 23
Pla ying i in Random Order
You can play titles, chapters within a title, or tracks in random order.
т
Number buttons
CLEAR
—— PLAY
— SKIP
—. SHUFFLE
DVD2 VCD, CD
Playing Chapters or Tracks in Random Order
The DVD video player automatically selects chapters within a
title, or tracks on a VIDEO CD/audio CD, and plays them
randomly.
Jl © @ ® © Press T, then press the appropriate
pee number buttons for the title which
Mamo contains the chapters you want to
play in random order.
Skip this step if you are using a VIDEO CD/
audio CD.
Example: To play the chapters in title 2 in
random order, press
(DVD video disc)
D-0 |.
DA SHUFFLE Press SHUFFLE while playback is
[ stopped.
(DVD video disc) (VIDEO CD / Audio CD)
CHAPTER SHUFFLE TRACK SHUFFLE
TITLE: 2 TRACK: El
CHAPTER: 1
If you press the SHUFFLE button during
playback, the DVD video player automatically
starts random playback after finishing the
current chapter or track.
PLAY Press PLAY.
The DVD video player starts random
playback.
Press the PLAY button within about five
seconds after you press the SHUFFLE
button.
To resume normal playback
CLEAR
O Press CLEAR.
| Notes {
* Some discs may not respond to the random playback function.
* You cannot use the random playback function and the memory
playback function at the same time.
* If you press the SKIP »» button during random playback, the DVD
video player goes to another chapter or track and starts random
playback.
Ad d Playback
vanced Playback ) [ |
= = | о ZOOM
Zooming a Picture/ Coal
Playing 3-D (N-2-2) Sound SE5= ao
Zoom playback 3-D (N-2-2) sound playback = = = Z
ии © о
=== CLEAR
You can magnify areas within a picture. (Zoom playback) = 5 = ao
1 You can enjoy virtual surround sound. (3-D (N-2-2) sound playback) 2525,
DVD DVD)
Zooming a Picture Selecting 3-D (N-2-2) Sound Enhancement
You can zoom a picture. You can shift the zooming point as well. You can enjoy expansive surround type effects from two
speakers.
ZOOM Press ZOOM during normal, slow or JA AUDIO During playback, press AUDIO
(|) still playback. —) repeatedly until AC-3 appears on the
| ce: screen.
The DVD video player magnifies the center |
of the picture. | ALDI 1 ENG AC-3 6CH
Recording system
For details, see .
If AC-3 does not appear, the DVD video disc
may not be recorded on the Dolby Digital
(AC-3) recording system. On such a disc, the
3-D (N-2-2) sound enhancement cannot
ZOOM work.
<a If you press € / W / <4/b> during zoom 2 AS ay Press 3D.
© = q playback, the zoom point shifts. [ The current setting appears. —
— If the zoom point reaches the limit, the color [ap (N-2-2) OFF fa
of “ZOOM” changes. | ET
If you press the CLEAR button, the zoom a
oint returns to the center of the picture. “e
P р 3 AIR y Press 3D to select ON. per
(|) Each time you press the button, ON and TE
OFF alternates. E
| BONS
3D (N-2-2) ON | DE.
To resume normal playback To turn off the 3-D (N-2-2) effect Bot
200M ha _
(7 Press ZOOM during zoom playback. () At step 3, Press 3D to select OFF.
| Notes f | Notes |
* Some discs may not respond to zoom feature. * The effect of 3-D (N-2-2) sound enhancement cannot be fully realized
* During some scenes, the buttons may not work correctly as described through headphones.
above. * You may sense a difference in volume between normal and 3-D
* Zooming does not work on subtitles or menu screens included on DVD enhanced sound.
video discs.
* During zoom playback, the A / Y / / »- buttons cannot work on
menu screens included on the DVD video discs. If you want to use the Spatializer® 3-Dimensional Sound Processing provided by Desper Products. Inc
j -Di | u | y Des . Inc.
menu screens, cancel the zoom playback. Certaín audio features of this product manufactured under a license from Desper
Products, Inc., Spatializer® and the circle-in-square device are trademarks owned
by Desper Products, Inc.
24 una
Advanced Playback )
}
——
—
| |
Selecting the Camera Angle ea:
7)... Е
—= — > IX
1 A preferred angle can be selected from several angles.
DVD,
Changing the Camera Angle
CLEAR
Lure.
- AY
Ë
y
ho
[| del fl
[|]
[] |
LI
If the scene was recorded from multiple angles, you can easily change the camera angle of the scene you are watching.
NA ANGLE
]
Press ANGLE while playing a scene To turn off the angle number indication
recorded with multiple angles. CLEAR
While playing a scene recorded with multiple O Press CLEAR.
angles, the angle icon ( 4 ) appears in the
DVD display and on the TV screen.
Press the ANGLE button while the angle icon , . .
ison. J To disable the angle icon display on the TV
From the on-screen displays, set “OSD” to “OFF.”
Monitor the DVD display when you want to change the
camera angle.
ANGLE Hl
Eh Angle icon
Current angle
number
PA ANGLE
£nTEA
GE
50
Press ANGLE or a while the angle
number appears on the TV screen.
Each time you press the ANGLE or a
button, the camera angle changes.
ANGLE
!
ANGLE H
{
ANGLE
!
|
w : Cycles backward
You can change the camera angle directly by
pressing the number buttons for the angle
number.
Notes |
* You can change the camera angle during still playback. The camera angle changes to the new setting when you resume normal playback.
* If you pause a picture immediately after changing the camera angle, the resumed playback picture may not use the new camera angle.
ная 25
- ее yt mem idl ск rl A -— Ld - — -—
Advanced Playback ) e
| \
x e
Selecting a Language ЗЕЕ
(51,2
Ou to CU
e 2222
5 | > 2
==>; CLEAR
| we СЕ) Ве) (С
You can select a preferred language. == = =
Selecting a Playback Audio Setting
You can easily select a preferred language and sound recording system from those included on the DVD video disc.
About recording systems
This DVD video player uses the Dolby Digital (AC-3) and
PCM recording systems and cannot play DVD video discs
recorded in any other recording system.
AC-3 5.1 Channel is displayed as “AC-3 6CH.”
A AUDIO
J
Press AUDIO during playback.
The current audio setting appears for about
three seconds.
49 i ENG PCM 2CH
— Audio channel
Position Recording system
number Language
The abbreviation of the language appears
instead of the language name. Refer to the
list of languages and their abbreviations.
Note: Total channels available in AC-3 may vary from 1 — 6.
Selecting sound channels of VIDEO CDs
À VIDEO CD may have left and right sound channels and
contain sounds or languages on each. You can switch these
two channels to hear a preferred sound or language.
Press AUDIO or a while the audio
setting appears on the TV screen.
AUDIO
During playback, press AUDIO repeatedly to select the
Each time you press the AUDIO or 4 button, sound channel.
<a the audio settings included on the DVD video О En
Ce) disc change. AUD | L.R Botth the left and right channels pr
(|) are heard. Уно
<У > Example ! a
AUDIO 1 ENG PCM 2CH _ | L The left channel is heard. oi
y Se
AUDIO 2 FRE AC-3 6CH ! qu
} | R The right channel is heard. E
AUDIO 3 SPA PCM 2CH ee
} e
| | Notes | ar
v : Cycles backward >
* Some discs allow you to change audio selections only via the disc a
menu. If this is the case, press the MENU button and choose the ol a
To turn off the audio setting indication appropriate language from the selections on the disc menu. ca +
* When you turn on the DVD video player or replace a disc, the player LE,
CLEAR
O
Output sound format (sampling frequency/quantization bit)
returns to the initial default setting. [31>
When you select a sound which is not included on the disc, the DVD
video player plays a prior sound programmed on the disc.
Press CLEAR.
Audio selection from the menu screen [3D and output jacks on the rear panel
Discs Sound recording system ANALOG BITSTREAM PCM
BITSTREAMPCM jack] ANALOG jacks |BITSTREAMPCM jack] ANALOG jacks |BITSTREAM/PCM jack] ANALOG jacks
Dolby Digital Bitstream 48 kHz/16 bit Bitstream 48 kHz/16 bit | 48 kHz/16 bit | 48 kHz/16 bit
48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit
48 kHz/20 bit — 48 kHz/20 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit
DVD video discs | Linear PcM | 48 kHz/24 bit — 48 kHz/24 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit
96 kH2/16 bit — 96 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit
96 kHz/20 bit — 96 kHz/20 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit
96 kHz/24 bit — 96 kHz/24 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit
VIDEO CDs MPEG! 44.1 kHz/16 bit | 44.1 kHz/16 bit | 44.1 kHz/16 bit | 44.1 kHz/16 bit | 44.1 kHz/16 bit | 44.1 kHz/16 bit
Audio CDs Linear PCM 44.1 kHz/16 bit | 44.1 kHz/16 bit | 44.1 kHz/16 bit | 44.1 kHz/16 bit | 44.1 kHz/16 bit | 44.1 kHz/16 bit | 44.1 kHz/16 bit
26 uu
Advanced Playback )
Selecting Subtitles
Bonsoir! | - ¡Buenas tardes! | Ф ® Ф
7 - —
Ay Good evening!
language.
DVD
Displaying Subtitles
You can display subtitles from those included on the DVD video
disc.
Press SUBTITLE ON/OFF during
playback.
BTITLE
ON/OFF
The current subtitle setting appears for about
three seconds.
SUBTITLE 1 ENG ON
Good evening! — Subtitles
To turn off the subtitles
SUBTITLE
INTE Press SUBTITLE ON/OFF.
The subtitles disappear.
SUBTITLE 1 ENG OFF Appears about for
three seconds.
You can display subtitles on the TV screen and select a preferred subtitle
Notes |
* Some DVD video discs are set to display subtitles automatically, and
you cannot turn them off even if you set the subtitle function to off.
During some scenes, the subtitles may not appear immediately after
you select ON.
* Some DVD video discs will allow you to make subtitle selections and
turn subtitles on or off only via the disc menu.
= 27
|
HI
| |
PU ==! SUBTITLE
| Е ON/OFF
i
| = —— SUBTITLE
| cocon
fa] (= +} PA 4
о A
==, ar =
| DVD;
Selecting a Subtitle Language
You can easily select the subtitle language from those included
on the DVD video disc.
1 SUBTITLE Press SUBTITLE during playback.
[ The current subtitle setting appears for about
three seconds.
SUBTITLE 1 ENG ON
Language
Position number
The abbreviation of the language appears
instead of the language name. Refer to the
list of languages and their abbreviations.
YA SUBTITLE Press SUBTITLE or A while the
(—) subtitle setting appears on the TV
screen.
080
<->
Each time you press the SUBTITLE or A
button, the subtitle languages included on
the DVD video disc change.
Example
SUBTITLE 1 ENG ON
}
SUBTITLE 2 FRE ON
}
SUBTITLE 3 SPA ON
!
|
w : Cycles backward
To turn off the subtitle setting indicator
CLEAR
O Press CLEAR.
E Notes |
* When you turn on the DVD video player or replace a disc, the player
returns to the initial default setting.
When you select a subtitle language which is not included on the disc,
the DVD video player plays a prior language programmed on the disc.
* During some scenes, the subtitles may not appear immediately after
you change the subtitle language by pressing the 4./ Y buttons.
Advanced Playback ) | —
y y | = =) |
Using the On-Screen Display | .::
|Z == 7 DISPLAY
IIS
II
1.7.9
025
jo <> ©
= == т:
You can view information about a disc and its operational status | = о зв Е
on the TV screen. сс
DVD2 VCD CD
Checking the Operational Status
You can view the current title number, track number, and total playing time of the disc on the TV screen.
DISPLAY Press DISPLAY while playback is stopped.
UN Each time you press the DISPLAY button, the on-screen display changes as follows.
(DVD video disc) (VIDEO CD / Audio CD)
Current title number Current track number
Example | Example |
| STOP -+- Operational status | STOP +— Operational status
TITLE: 2 TRACK: 1
CHAPTER: 1 Current chapter number TOTAL 0: 46:30 —— Total playing time of the
disc
J J
Turns off. Turns off.
Checking the Remaining Time and Setting Status
You can view the elapsed time, remaining time, and setting status of the disc on the TV screen.
on
Ww SE
DISPLAY Press DISPLAY during playback. FA
(|) Each time you press the DISPLAY button, the on-screen display changes as follows. 9
. , . =
(DVD video disc) (VIDEO CD / Audio CD) DT.
Current title number Current track number To
Example | pr Current chapter number Example | — Operational status NC RR
- 1 _ - ЖЕ
| PLAY Ir Operational status | PLAY В “On.
TITLE: 3 ~0: 50: 45——{— Remaining time in the TRACK: 3 ~0: 02: 00— Remaining time in the =
CHAPTER Е APSED 9: 10: 24 current title DISC ELAPSED 9: ds: 00 current track ;
> 10: — Remaining time in the o — Remaining time of the disc >
CHAPTER REPEAT | current chapter TRACK REPEAT g 2
— Elapsed time of the — Elapsed time of the current So
current title track A
Playback mode Playback mode -
J J
PLAY | | Turns off.
TITLE: 3 —0; 50;45 — Current audio setting
CHAPTER : APSED O: 10:24 |
: 10:15 i i
AUDIO 1 ENG AC-3 SCH [eure subtitle setting
SUBTITLE12 ENG ON——— ,
ANGLE 1 Current angle setting
The abbreviation of the language (e.g. ENG) appears instead of the
language name. Refer to the list of languages and their abbreviations.
+
BIT RATE: 3.5M= |
|
Data transfer rate (Mbit/s)
= Amount of picture, sound and subtitle data in the DVD video disc
transferred per second.
The larger the value is, the more data processed, but this does not
necessarily insure better picture quality.
Turns off.
28 mu
Function Setup )
Customizing the Settings
| setup menu |
Ц Ц Ц
You can change the default settings to customize performance to your
preference.
Displaying the SET UP MENU Screen
The SET UP MENU screen asks you to select a setting for AUDIO, FUNCTION, and DISPLAY. You may adjust the settings in the
category using the succeeding screen.
1 SET UP Press SET UP while playback is stopped.
( The SET UP MENU screen appears.
Ш SET UP MENU ____ SELECT; fe * The display language can be changed.
Proceed to (35) SCREEN DISPLAYS”, via step 2 below.
AUDIO
FUNCTION
DISPLAY
CET
EX ITEM em
2 a> Press 4 / Y to select the category (AUDIO, FUNCTION, or DISPLAY), then press ENTER.
С = 6 Ш SET UP MENU _ — SELECT: efe in AUDIO SELECT: o
LANGUAGE ENG
AUDIO OUT SEL. ANA
+ AUDIO ENTER D RANGE CONTROL ON
FUNCT LON Ce) KARAOKE VOCAL OFF
<> DISPLAY
=) CET RETURN)
<> EXITED ENTER EXITED Ei
KM SET UP MENU — SELECT: efe I FUNCTION _____ SELECT: fe
BLACK LEVEL NAML
TITLE STOP OFF
AUDIO ENTER REMOTE CONFIRM. ON
FUNCTION Ce] OSD ON
DISPLAY PBC ON
EXIT ESE? Es EXITED (ENTER,
I! SET UP MENU ____ SELECT: EI DISPLAY 0 SELECT: 49
SCREEN DISPLAYS ENG
TV SHAPE 4:3 LB
AUDIO ENTER SUBTITLE _—
FUNCTION Le) DISC MENU ENG
DISPLAY BACK COLOR GRAY
EX IT END E) EXIT Cal (ENTER,
Notes
» The SET UP MENU screen disappears when you press the SET UP button.
* The SET UP button can work even during normal playback, however some operations may be inaccessible, a message will appear. In this case, try
again after halting playback with the STOP button.
ия 29
= ож = оожо=о ок жен око око ооо =. nn mt = аа ete them nn жен се = ето = еее = ео. = нее ER ож
и т о
e а
SLUR)
po
a
Lt
vi
=" Mya 4
nl изя 1
4 ta. on +
"a r
4
a FE
+
wr
4 POSTA я
lFumetonsS
» + A
Setting Details Page
LANGUAGE To select a preferred language for the sound track. 31
AUDIO OUT SEL. To select ANALOG, BITSTREAM or PCM according to your connection. 31
D RANGE CONTROL To turn on or off the function that makes faint sounds easier to hear, even 31
if you lower the volume in late hours playback.
KARAOKE VOCAL To turn on or off the vocal output in DVD KARAOKE disc playback. 32
Setting Details Page
BLACK LEVEL To select the black level (contrast) of playback pictures. 33
TITLE STOP To turn on or off the function that automatically stops playback after 33
playing one title.
REMOTE CONFIRM. To turn on or off the confirmation beeper for each press of a remote control 33
button.
OSD To turn on or off the operational status display (On-screen display) on the 34
TV screen.
PBC To use the menu screens when playing a PBC-controllable VIDEO CDs. 34
Setting Details Page
SCREEN DISPLAYS To select the display language. 35
TV SHAPE To select a picture size according to the aspect ratio of your TV. 35
SUBTITLE To select a preferred language for subtitles. 36
DISC MENU To select a preferred language for disc menus. 36
BACK COLOR To select the background color for on-screen displays. 36
-—————— сч о A к = -—— - —---—- —-—-- — 2 —— - = ково = CC 2e 1 - — - x - = ——
30 mm
Function Setup )
Customizing the Settings (continued)
11 AUDIO SELECT coo AUDIO
LANGUAGE ENG
AUDIO OUT SEL. ANA
OD RANGE CONTROL ON
KARAQKE VOCAL OFF
ca
EXIT EU en
After you select AUDIO on the SET UP MENU screen [29), adjust the categories to your preference.
Setting the Audio
SE (Continued from page 29.)
ES © |
Press a / w to select the item, then press ENTER.
<>
3 The setting screen of your selected item appears.
| LANGUAGE | 2
= 6) | <= Select a preferred language by pressing
ED № LANGUAGE Steir. С © вме A/w/</»,then press ENTER.
CAC Ce) = (+)
<» >
р
ENGLISH ITALIAN
FRENCH JAPANESE You will return to the AUDIO screen.
SPANISH DUTCH i
SPANLSE DUTCH — If you do not make any other settings, proceed
GERMAN MALAY to step 4.
| 1
DESCRIPTIVE SERVICE OFF , | , , | ,
EX) TEED [ENTER] * Some DVD video discs contain special language track that describes the actions on-
screen for visually impaired persons. When you set DESCRIPTIVE SERVICE to ON
by pressing the AUDIO button, the DVD video player automatically plays this special
feature.
* Some DVD video discs may be played in a different language than you selected, since
it may be a prior language programmed on the disc.
| AUDIO OUT SEL. | 27 VD DD
Select the output sound type according to your system connection.
fil AUDIO OUT SEL. _SELECT:=¥e
1 (12) 13)
ANALOG aD Select the output sound type ANALOG,
BITSTREAM С = © = (+) BITSTREAM or PCM by pressing a/v,
3D then press ENTER.
=> SETUP) [ENTER) You will return to the AUDIO screen.
— If you do not make any other settings, proceed
to step 4.
| D RANGE CONTROL | 2
ID RANGE CONTROL SELECT: efe ON: Dynamic range is reduced.
D RANGE CONTROL MEN OFF: Full dynamic range is heard.
Select ON or OFF by pressing <q / »-, then
= a ENTER
EL 00,5 тб
<*>
сч) You will return to the AUDIO screen.
EX I TED (ENTER) — If you do not make any other settings, proceed
to step 4.
* This function works only on playback of Dolby Digital (AC-3) recorded discs.
* The level of dynamic range reduction may differ depending on the DVD video disc.
mu 31
AUDIO
7 ENTER
0) 3
a t RETURN RETURN
Co 40 : If you press the RETURN button while a menu appears on the screen, you will return to the
oa E O previous menu screen.
Ш и и
| KARAOKE VOCAL | E”
II KARAOKE VOCAL _ SELECT: fa ON: The primary vocal is output when it is recorded on the disc.
OFF: The primary vocal is not output.
KABAOKE VOCAL e
<a 7 im Select ON or OFF by pressing </b>, then
ON O Ча (3 =] ©) = Ce) press ENTER.
lz >
You will return to the AUDIO screen.
— If you do not make any other settings, proceed
to step 4.
GEN
EXITED ANE
The vocal output feature is used during playback of Dolby Digital (AC-3, multi-channel)
recorded DVD KARAOKE discs. This feature allows you to turn off vocal audio tracks or
restore them for background accompaniment.
ZI SETUP — Press SETUP.
(|) The SET UP MENU screen disappears.
32 и
Function Setup )
Customizing the Settings (continued)
n FUNCTION seer: | FUNCTION
BLACK LEVEL NBML
E TITLE STOP OFF
Е REMOTE CONFIRM ON
Oso ON
| PBC ON
Cal)
EXIT ESE
After you select FUNCTION on the SET UP MENU screen [29), adjust the categories to your preference.
Setting the Functions
JE (Continued from page 29.)
50
Press 4 / w to select the item, then press ENTER.
= -
+ The setting screen of your selected item appears.
<a>. | BLACK LEVEL | 2 IP
050 MN BLACK LEVEL SELECT: af NORMAL: Standard black level (contrast).
BLACK LEVEL ENHANCED: Increased black leve! (contrast).
<a 7 ENTER Select a preferred black level by pressing
VII nooo QS)» (3 </> then press ENTER.
Cm You will return to the FUNCTION screen.
EXITED E — If you do not make any other settings, proceed
to step 4.
| TITLE STOP | 2%”
Ш TITLE STOP SELECT: of ON: Player stops playing the disc after playback of a title is completed.
TITLE STOP OFF: Player continues playing the disc after playback of a title is completed.
<A aq, Select ON or OFF by pressing </», then
ON OFF (3 =] ©) = (+) press ENTER.
zZ
Ex | To a You will return to the FUNCTION screen.
— If you do not make any other settings, proceed
to step 4.
| REMOTE CONFIRM. | 217 Yo CDD
| NI REMOTE CONFIRM. SELECT: efe ON: Beeper sounds with each press of a remote control button.
REMOTE CONFIRM. MEN OFF: The beeper does not sound.
a> = Select ON or OFF by pressing </», then
ЩО 5 m) (e) press ENTER.
OFF
(RETURN < You will return to the FUNCTION screen.
EXIT EST ED — If you do not make any other settings, proceed
to step 4.
mm 33
ENTER
3
RETURN RETURN
O
= с нение = —
a Es 0 TC CE 0 0 0 ее Me -— — + a
: If you press the RETURN button while a menu appears on the screen, you will return to the
previous menu screen.
> и
i OSD SELECT: elo ON: Operational modes are displayed on-screen. (e.g. “PLAY”, 5)
OSD Ex OFF: Operational modes are not displayed.
{a «men Select ON or OFF by pressing </», then
EL 050,68 mo
Em —- You will return to the FUNCTION screen.
EXITED — If you do not make any other settings, proceed
to step 4.
Ш РВС SELECT: fo ON: To use the menu screen when playing a PBC-controllable VIDEO CD.
РВС ETE OFF: When playing without using the menu screen.
TAD ENTER Select ON or OFF by pressing </», then
Ч ОЕЕ С =] >) m) (e) press ENTER.
MED OZ You will return to the FUNCTION screen.
EXIT END Cu — If you do not make any other settings, proceed
* PBC is the abbrebiation of Playback Control.
to step 4.
SETUP
[|
Press SET UP.
The SET UP MENU screen disappears.
= ——— =—-——— -
wr mm mmm am wm cea ос о — =
34 mu
i ep O = = E
Setting the Displays
РЕ
Function Setup )
Customizing the Settings (continued)
SCREEN DISPLAYS ENG
TV SHAPE 4.3 LB
SUBTITLE ---
DISC MENU ENG
BACK COLOR GRAY
Car
EXITED)
ü DISPLAY SEECT e DISPLAY
After you select DISPLAY on the SET UP MENU screen [29), adjust the categories to your preference.
(Continued from page 29.)
The setting screen of your selected item appears.
+
| SCREEN DISPLAYS | "> Yo C00
Press a / v to select the item, then press ENTER.
650
II SCREEN DISPLAYS SELECT: $e
ENGL | SH
FRENCH
SPANISH
cn
EX | T HD em
| ТУ SHAPE | 2
ENTER
gat =) (+)
Select a preferred language by pressing
A /w, then press ENTER.
You will return to the DISPLAY screen.
— If you do not make any other settings, proceed
to step 4.
mW TV SHAPE SELECT: fe
I Es = +
4:3 LETTERBOX
4:3 NORMAL
16:9 WIDESCREEN
EXITED EE)
4:3 LETTERBOX:
4:3 NORMAL:
Select when a 4:3 TV is connected.
Displays theatrical images with
masking bars above and below the
picture.
Select when a 4:3 TV is connected.
Displays pictures cropped to fill your —= „се
TV screen. Either or both sides of the
picture are cut off.
16:9 WIDESCREEN: Select when a 16:9 wide TV is connected.
HEE
Select your TV type by pressing a / v,
then press ENTER.
You will return to the DISPLAY screen.
— If you do not make any other settings, proceed
to step 4.
* The displayable picture size is preset on the DVD video disc. Therefore, the playback
picture of some DVD video discs may not conform to the picture size you select.
* When you play DVD video discs recorded in the 4:3 picture size only, the playback
picture always appears in the 4:3 picture size, regardless of the TV shape setting.
* If you select 16:9 WIDE SCREEN and you own a 4:3 TV set, the DVD playback picture
will be horizontally distorted during playback. Images will appear compressed. Always
be sure that your TV shape conforms to the actual TV in use.
mu 35
3
SUBTITLE
ENTER
MENU
RETURN
RETURN
O
A O ZA = =
: If you press the RETURN button while a menu appears on the screen, you will return to the
previous menu screen.
| SUBTITLE | 297
Hl SUBTITLE — SELECT: fe
[= EET
EE E E
ENGLISH ITALIAN
FRENCH JAPANESE
SPANISH DUTCH
CHINESE KOREAN
GERMAN MALAY
NO SUBTITLES
Pz FANE ICRA AINE + e
EXTENDED FEATURES OFF
EX I TED
06
Select a preferred language by pressing
Al/Y/-</»,then press ENTER.
You will return to the DISPLAY screen.
— If you do not make any other settings, proceed
to step 4.
* Some DVD video discs contain special subtitles, an enhancement of closed captioning for
hearing impaired persons. When you set EXTENDED FEATURES to “ON” by pressing the
SUBTITLE button, the DVD video player automatically displays these special subtitles.
* Some DVD video discs may be set to display subtitles in a different language than you
selected, since it may be a prior subtitle language programmed on the disc.
* Some DVD video discs allow you to change subtitle selections only via the disc menu. If this
is the case, press the MENU button and choose the appropriate subtitle language from the
selection on the disc menu.
| DISC MENU |
Im DISC MENU U SELECT: fe
HAZ 2 Rea — 1 EE]
ENGL I SH “ITALIAN
FRENCH JAPANESE
SPANISH DUTCH
CHINESE KOREAN
GERMAN MALAY
OTHERS
(EEE ET
= =
ETE
EXIT EH
EA ie]
ENTER
| BACK COLOR | PP Yew ¿>
¿0-8
EN To select other languages:
Ш DISC MENU . — SELECT: e
SELECT COUNTRY CODE
AY. SCROLL «> LOCATION
car
EXIT EE) EX)
Select a preferred language by pressing
A | wv | «/», then press ENTER.
You will return to the DISPLAY screen.
— If you do not make any other settings, proceed
to step 4.
1) Select OTHERS and press the ENTER button.
2) Obtain the abbreviation of the preferred language from the
list 39).
3) Select the first character by pressing the € / W buttons.
4) Press the «€ / »>- buttons to shift and select the second
character by pressing the 4 / Y buttons.
5) Press the ENTER button to return to the DISPLAY screen.
» Some DVD video discs may not include your pre-selected language. In this case, the DVD
video player automatically displays disc menus consistent with the disc’s initial language
setting.
Il BACK COLOR SELECT: ello BLUE: Blue background.
GRAY: Gray background.
BLUE <a> Select a preferred background color by
GRAY «J = q =) Ce) pressing a / w, then press ENTER.
«= > You will return to the DISPLAY screen.
RETURN — If you do not make any other settings, proceed
EXIT ED ENTER to step 4.
74 SETUP Press SET UP.
|
The SET UP MENU screen disappears.
36 WE
Function Setup )
Г
SI
Setting the Parental Lock
You can use the parental lock function only with DVD video discs equipped
with the parental lock feature.
Setting the Parental Lock
DVD video discs equipped with the parental lock function are rated according to their content. The contents allowed by a parental lock
level and the way a DVD video disc can be controlled may vary from disc to disc. For example, you can cut out violent scenes unsuitable
for children and replace them with more suitable scenes, or lock out playback of the disc altogether.
1 SET UP
Press SET UP during stop.
The SET UP MENU appears on the TV
screen.
e
Press 9 twice.
The following menu appears.
Ш PARENTAL LOCK
PRESET SECURITY CODE
PRESS {0]- [9]
Gar
EXITED E)
СЭ E E
со с 3
7 e) E E)
Press the number buttons to create a
personal four-digit security code,
then press ENTER.
Example
+
1 PARENTAL LOCK
SELECT: afin
PARENTAL LOCK
ON OFF
USAS
If you make a mistake before pressing the
ENTER button, press the CLEAR button and
enter your four-digit security code again.
Press «/» to select “ON,” then
press ENTER.
The following menu appears.
il PARENTAL LOCK __SELECT: >}
COUNTRY USA
USA CAN
LEVELS LEVELS
EXIT ÉS Gud
mm 37
VOZ
7
+
Press «< / > to highlight the country
whose standards were used to rate
the DVD video disc, then press ENTER.
The following menu appears.
ll PARENTAL LOCK SELECT: fe
<a 7 USAS
тя BV IEWABLE LEVELS GINA
(3 (5) © LEVEL?
LEVELG
>> LEVELS
LEVEL4
LEYEL3
LEVEL?
LEVEL 1 BERN
EXITED Gi
a> Press a /w to highlight the parental
(3 = ©) lock level, then press ENTER.
<> You cannot play DVD video discs rated higher
than the level you selected unless you cancel
+ the parental lock function.
For example, when you select level 7, discs
= rated higher than level 7 are locked out and
С С°) 6) cannot be played.
<-> Example: When you select “USA”
UI PARENTAL LOCK | SELECT: fe
LOCKED LEVELB oh —When you
[VIEWABLE LEVEL? select “CAN,”
LEVELS “CAN7”
LEVELS
LEVEL4 appears
LEVEL3 instead.
LEVEL2
LEVEL 1 CONECTA
EX I TED ENTER]
The parental lock level is equivalent to the
following USA movie ratings.
LEVEL 7: NC-17 LEVEL 3: PG
LEVEL 6: R LEVEL 1: G
LEVEL 4: PG 13
The parental lock levels for “CAN” (Canada) are
included for future use. Check the appropriate
parental lock level when you buy a DVD video
disc equipped with the parental lock feature in
the future.
SET UP Press SET UP.
UN The SET UP MENU disappears.
RETURN
O
to the previous screen.
Br A AA - ра
: If you press the RETURN button while a menu appears on the screen, you will return
о
To change the parental lock level
You can change the parental lock level by following the steps
in “Setting the Parental Lock.”
At step 3, press the number buttons to enter your four-digit
security code, then continue to step 4.
If you make a mistake, press the CLEAR button and enter
the correct four-digit security code.
To change your four-digit security code
You can change your four-digit security code.
1 Follow steps I and 2 in “Setting the Parental Lock.”
2 Press the STOP button four times, then press the
ENTER button while the security code menu appears on
the TV screen.
STOP STOP STOP STOP ENTER
(8) + (a )-— (Ga )+ Ca) — Ce)
The four-digit security code is cleared.
3 Press the number buttons to create a new four-digit
security code, then press the ENTER button.
4 Complete steps 4 — 7 in “Setting the Parental Lock” if
necessary, or, press the SET UP button to remove the
SET UP MENU.
| note |
DVD video discs may or may not respond to the parental lock settings.
This is not a defect in the DVD video player. Make sure this function
works with your DVD video discs.
To cancel the parental lock function
1
2
Follow steps 7 and 2 in “Setting the Parental Lock.”
Press the number buttons to enter your four-digit
security code, then press the ENTER button.
If you make a mistake, press the CLEAR button and
enter the correct four-digit security code.
Press «/ >> 10 select “OFF” then press the ENTER
button.
HI PARENTAL LOCK _ SELECT: фе
PARENTAL LOCK OFF
ON OFF
USA7
RETURN)
EXITED ENTER
The SET UP MENU appears again.
Press the SET UP button.
The SET UP MENU disappears, and the parental lock
function is canceled.
36 и
Function Setup )
Table of Languages
Table of Languages and Their Abbreviations
Abbreviation | Language Abbreviation | Language Abbreviation | Language Abbreviation {| Language
of the of the of the of the
Language Language Language Language
——— No alternate EO Esperanto LN Lingala SL Slovenian
language ET Estonian LO Laotian SM Samoan
CHI Chinese EU Basque LT Lithuanian SN Shona
DUT Dutch FA Persian LV Latvian, Lettish so Somali
ENG English FI Finnish MG Malagasy SQ Albanian
FRE French FJ Fiji MI Maori SR Serbian
GER German FO Faroese MK Macedonian SS Siswati
ITA Italian FY Frisian ML Malayalam ST Sesotho
JPN Japanese GA Irish MN Mongolian SU Sundanese
KOR Korean GD Scottish Gaelic MO Moldavian SV Swedish
MAY Malay GL Galician MR Marathi SW Swahili
SPA Spanish GN Guarani MT Maltese TA Tamil
AA Afar GU Gujarati MY Burmese TE Telugu
AB Abkhazian HA Hausa NA Nauru TG Tajik
AF Afrikaans HI Hindi NE Nepali TH Thai
AM Amharic HR Croatian NO Norwegian Tl Tigrinya
AR Arabic HU Hungarian OC Occitan TK Turkmen
AS Assamese HY Armenian OM (Afan) Oromo TL Tagalog
AY Aymara IA Interlingua OR Oriya TN Setswana
AZ Azerbaijani IE Interlingue PA Panjabi TO Tongan
BA Bashkir IK Inupiak PL Polish TR Turkish
BE Belorussian IN Indonesian PS Pashto, Pushto TS Tsonga
BG Bulgarian IS Icelandic PT Portuguese TT Tatar
BH Bihari IW Hebrew QU Quechua TW Twi
Bl Bislama J Yiddish RM Rhaeto-Romance UK Ukrainian
BN Bengali, Bangla JW Javanese RN Kirundi UR Urdu
BO Tibetan KA Georgian RO Rumanian UZ Uzbek
BR Breton KK Kazakh RU Russian VI Vietnamese
CA Catalan KL Greenlandic RW Kinyarwanda VO Volapük
CO Corsican KM Cambodian SA Sanskrit WO Wolof
CS Czech KN Kannada SD Sindhi XH Xhosa
CY Welsh KS Kashmiri SG Sango YO Yoruba
DA Danish KU Kurdish SH Serbo-Croatian ZU Zulu
DZ Bhutani KY Kirghiz SI Singhalese
EL Greek LA Latin SK Slovak
бл,
*
Others )
Notes on Discs
Handling Discs
* Do not touch the playback side of the disc.
Playback side
Cleaning Discs
* Fingerprints and dust on the disc cause picture and sound
deterioration. Wipe the disc from the center outward with a soft cloth.
Always keep the disc clean.
* If you cannot wipe off the dust with a soft cloth, wipe the disc lightly
with a slightly moistened soft cloth, then dry the disc with a dry cloth.
* Do not use any type of solvent such as thinner, benzine, commercially
available cleaners, or antistatic spray for vinyl LPs. It may damage the
disc.
Storing Discs
* Do not store discs in a place subject to direct sunlight or heat.
* Do not store discs in places subject to moisture and dust, such as in a
bathroom or near a humidifier.
* Store discs vertically in a case. Stacking or placing objects on discs
may cause warping.
About This Owner's Manual
This owner's manual explains the basic instructions of this DVD video
player. Some DVD video discs are produced in a manner that allows
specific or limited operation during playback. As such, the DVD video
player may not respond to all operating commands. This is not a defect
in the DVD video player. Refer to the instruction notes of discs.
“4 " may appear on the TV screen during operation.
A white “ y, ” means that the operation is not permitted by the DVD video
player; a red “ 4 ” means the operation is not permitted by the disc.
Notes on Region Numbers
The region number of this DVD video player is 1. If region numbers,
which stand for their playable area, are printed on your DVD video disc
and you do not find or , disc playback will not be allowed by the
player. (In this case, the DVD video player displays a message.)
Playable Discs
This DVD video player can play the following discs.
Disc mark | Contents | Disc size Maximum
playback time
Approx. 4 hours
19 (single sided disc)
DVD Audio em Approx. 8 hours
video | DVD | video (double sided disc)
discs | ICI» (moving Approx. 80 minutes
pictures) | om (single sided disc)
Approx. 160 minutes
(double sided disc)
VIDEO lise Асю + 12 ст | Approx. 74 minutes
CDs IS (moving
pictures) | 8 ст | Approx. 20 minutes
Audio COMPACT 12cm | Approx. 74 minutes
Audio |8cm(CD
CDs DIGITAL AUDIO mu Approx. 20 minutes
You cannot play discs other than those listed above.
This DVD video player uses the NTSC color system and cannot play
DVD video discs recorded in any other color system (PAL, SECAM, etc.).
On VIDEO CD
This DVD video player supports the VIDEO CDs equipped with the PBC
(Version 2.0) function. (PBC is the abbreviation of Playback Control.)
You can enjoy two playback variations depending on types of discs.
* VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this DVD video player in the same
way as an audio CD.
* VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operations of a VIDEO CD not equipped with the PBC
function, you can enjoy playback with interactive software and with a
search function by using the menu displayed on the TV screen (Menu
Playback). Some of the functions described in this owner's manual
may not work with some discs.
Notes on Copyright
It is forbidden by law to copy, broadcast, show, broadcast on cable, play
in public, and rent copyrighted material without permission.
DVD video discs are copy protected; and any recordings made from
these discs will be distorted.
This product incorporates copyright protection technology that is
protected by method claims of certain U.S. patents and other intellectual
property rights owned by Macrovision Corporation and other rights =
owners. Use of this copyright protection technology must be authorized
by Macrovision Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
| Others )
Before Calling Service Personnel
Check the following guide for the possible cause of a problem before requesting service.
Symptoms and Correction
man 47
Symptom Cause Correction Page
No power * The power plug is disconnected. * Connect the power plug securely into the | 11,12
wall outlet.
No picture * The TV is not set to receive DVD signal | * Select the appropriate video input mode 15
output. on the TV so the picture from the DVD
video player appears on the TV screen.
* The video cable is not connected * Connect the video cable securely into the | 11, 12,
securely. jacks. 13, 14
No sound * The equipment connected with the audio | * Select the correct input mode of the audio 15
cable is not set to receive DVD signal receiver so you can listen to the sound
output. from the DVD video player.
* The audio cable is not connected * Connect the audio cable securely into the | 11, 12,
securely. jacks. 13, 14
The power of the equipment connected | * Turn on the equipment connected with the —
With the audio cable is turned off. audio cable.
* The setting of output sound type is not + Set the audio setting correctly. 29, 31
correct.
The playback picture has * The disc is dirty. * Eject the disc and clean it. 40
occasional distortion. e [tis in fast forward or fast reverse * Sometimes a small amount of picture —
playback. distortion may appear. This is not a
malfunction.
Brightness is unstable or noise is | * The copy protection is in effect. * Connect the DVD video player directly to 11
noticeable on playback pictures. the TV. Avoid connecting the DVD video
player to a VCR or TV/VCR combination.
The DVD video player does not * No disc is inserted. * Insert a disc. (Check that the DVD, VCD, 8
start playback. or audio CD indicator in the DVD display
is lit.)
» An unplayable disc is inserted. * Insert a playable disc. (Check the disc 40
type and color system.)
* The disc is placed upside down. * Place the disc with the playback side 15
down (label facing up).
* The disc is not placed within the guide. — | * Place ihe disc correctly inside the guide in | 15
the disc tray.
* The disc is dirty. * Clean the disc. 40
* The parental lock function is set. * Cancel the parental lock function or 37,38
change the parental lock level.
Buttons do not work. Power supply fluctuations or other Turn the power on or off with the POWER —
abnormalities such as static electricity button. Or, disconnect the power plug and
may interrupt correct operations. insert it into the wall outlet again.
The remote control does not work | * The remote control is not pointed atthe | Point the remote control at the remote 10
properly. remote sensor of the DVD video player. sensor of the DVD video player.
* The remote control is too far from the * Operate the remote contro! within about 10
DVD video player. 20 feet.
* The batteries in the remote control are * Replace the batteries with new ones. 10
exhausted.
Others )
[DVD Video Player]
DVD Video Player / Outputs / Supplied Accessories
Specifications
Power supply 120 VAC, 60 Hz
Power consumption 18 W
Mass 3.1 kg
External dimensions 370 x 81 x 308 mm (W/H/D)
Signal system Standard NTSC
Laser
Semiconductor laser, wavelength 650 nm
Frequency range (digital audio)
DVD linear sound : 48 kHz sampling 4 Hz to 22 kHz
96 kHz sampling 4 Hz to 44 kHz
Audio CD: 4 Hz to 20 kHz
Signal-to-noise ratio (digital audio)
More than 110 dB
Audio dynamic range (digital audio)
More than 106 dB
Harmonic distortion (digital audio)
Less than 0.001 %
Wow and flutter
Below measurable level (less than 0.001 % (W.PEAK))
Operating conditions
Temperature: 5 °C to 35 °C, Operation status: Horizontal
[Outputs]
Video output
1.0 V (p-p), 75 Q, negative sync., pin jack x 1
S video output
(Y) 1.0 V (p-p), 75 Q, negative sync., Mini DIN 4-pin x 1
(C) 0.286 V (p-p), 75 Q
Audio output (digital audio)
0.5 V (p-p), 75 Q, pin jack x 1
Audio output (analog audio)
2.0 \ (rms), 220 Q, pin jacks (L, R) x 1
Headphone terminal
32 Q (30 mW), Impedance: more than 8 Q
[Supplied Accessories]
S video cable ...................e.eecevecoccacanas
Audio/video cable ..................eeosccennnooo
Remote contro! ..................—eeesvesoscaroro
Batteries (AA) ..................eeoneccscasooren
* Designs and specifications are subject to change without notice.
Others
Memo
Others )
Memo
— Oliners *
ой и В a
44 wm
Philips Consumer Electronics Company
Factory Service Center Locations
See Reverse Side for More Details.
«. *Ж Seattle/Tacoma Area
A À
Detroit/Toledo о
\ e) w
\ 3 Cleveland/ A's o
N Ohio *
= . м ча
o San reteset Are Chicago | % CoJumbus &
Xx Los Angeles
+ Charlotte
x Pittsburgh/WV Are
Knoxviile/E Tennessee
NN | * Philadelphia/S New Jersey
Atlanta/N Georgia
* Dallas ash/Balt
. Orlando
Houston/Galveston
e Tampa/W Florida
* Indicates In-Home Service Only Beaumont/Austin Ft. Myers/SW Florida
1-800-242-9225 San Antonio Miami/SE Florida
* Indicates In-Home/Carry-In Service
mm 45
NOTE: If you reside in one of our Philips Factory Service Branch areas (see directory on back), you can contact the nearest Service Branch to
obtain efficient and expedient repair for your product. If your product is In-Warranty, you should have proof-of-purchase to ensure No Charge
Service. For Qut-of-Warranty service, call the location nearest you.
NOTA: Si vous résidez dans une des régions desservies par une succursale de service après vente du fabricant Philips (voir liste ci-dessous), vous
pourrez contacter la branche de service après vente la plus près de chez vous pour obtenir un service après vente rapide et efficace. Si le produit
est sous garantie, il suffira de présenter une preuve d'achat pour bénéficier d'un service sans frais. Pour les produits non couverts par la garantie,
contactez le centre le plus près de chez vous.
NOTA: Si Ud. reside en una de nuestras zonas para sucursales Philips de servicio al de fabrica (ver directorio mas abajo), Ud. puede comunicarse
con la sucursal de servicio mas cercana para obtener una reparacion oportuna y eficaz de su producto. Si su producto esta todavia bajo garantia,
Ud. debe presentar comprobante de compra para no ocasionar ningunos cargos por servicio. Para servicio después del vencimiento de la
garantía, llame al lugar más cercano de los abajo indicados.
In Canada
How you can obtain efficient and expedient carry-in, mail-in, or in-home service for your product
Please contact Philips at 1-800-661-6162 (French speaking)
1-800-363-7278 (English speaking)
Au Canada
Comment obtenir le service après-vente pour les produits apportés ou envoyés par la poste à notre centre de service ou le service à domicile
Veuillez contacter philips à: 1-800-661-6162 (Francophone)
1-800-363-7278
En el Canada
Cémo recibir servicio efficiente para su producto, en persona, por correo 0 a domicillo
Favor de comunicarse con Philips al: 1-800-661-6162 (francofono)
1-800-363-7278 (angl6fono)
MAC2929 1/98 EL4482-3 Rev. X
QUALITY SERVICE IS AS CLOSE AS YOUR TELEPHONE! SIMPLY LOOK OVER THE LIST BELOW FOR THE NUMBER OF A FACTORY SERVICE CENTER
NEAR YOU. YOUR PRODUCT WILL RECEIVE EFFICIENT AND EXPEDIENT CARRY-IN, MAIL-IN, OR IN-HOME SERVICE, AND YOU WILL RECEIVE PEACE OF MIND,
KNOWING YOUR PRODUCT IS BEING GIVEN THE EXPERT ATTENTION OF PHILIPS’ FACTORY SERVICE. AND, IF THE PHONE NUMBER LISTED FOR YOUR AREA
IS LONG DISTANCE, CALL 1-800-242-9225 ror FACTORY SERVICE.
COMMENT OBTENIR NOTRE SERVICE APRES VENTE RAPIDE ET EFFICACE SOIT PAR COURRIER, À DOMICILE, OU EN SE PRÉSENTANT À UN CENTRE DE SERVICE PHILIPS. PLUS DE 600 CENTRES DE
RECEPTION DE PRODUITS À RÉPARER À TRAVERS LE PAYS: CONTACTER LE CENTRE DE SERVICE AUX CONSOMMATEURS LE PLUS PROCHE POUR SAVOIR L'EMPLACEMENT DE CES DÉPOTS DANS
UN RAYON DE 50 À 75 MILES (80 KM À 120 KM) DU CENTRE DE SERVICE LOCAL.
CÓMO OBTENER UN SERVICIO OPORTUNO Y EFICIENTE POR CORREO, EN CASA O EN PERSONA PARA SU PRODUCTO A TRAVÉS DE UN CENTRO PHILIPS DE SERVICIO. MAS DE 600 SITIOS POR
TODO EL PAIS PARA LA RECEPCION DE PRODUCTOS NECESITADOS DE REPARACIONES: COMUNICARSE CON EL CENTRO DE SERVICIO DE FABRICA MAS CERCANO PARA ESTOS LUGARES DENTRO
DE UN RADIO DE 80 A 120 KM (50 A 75 MILLAS) DEL CENTRO DE SERVICIO LOCAL.
GEORGIA
Philips Factory Service of Georgia
200 N. Cobb Pkwy., Suite 120
Marietta, GA 30062
(770) 795-0085
FT. MYERS, FLORIDA
Philips Factory Service Satellite - Ft. Myers
11601 Cleveland Ave., Suite 15
Ft. Myers, FL 33907
(941) 278-4242
FLORIDA
Philips Factory Service of Florida
1911 US Highway 301 North
Tampa, FL 33619
(813) 621-8181
WESTERN U.S.A.
Philips Factory Service Western Region
681 East Brokaw Rd.
San Jose, CA 95112
(408) 436-8566
NORTH CAROLINA
Philips Factory Service of N. Carolina
520 G Clanton Rd.
Charlotte, NC 28217
(704) 529-6330
TEXAS
Philips Factory Service of Texas
1110 N. Post Oak Rd., Suite 100
Houston, TX 77055
(713) 682-3990
CENTRAL U.S.A.
Philips Factory Service Central US
950 Keynote Circle
Brooklyn Heights, OH 44131
(216) 741-3334
MICHIGAN
Philips Factory Service of Michigan
25173 Dequindre
Madison Heights, MI 48071
(248) 544-2110
ILLINOIS
Philips Factory Service of lllinois
1360 W. Hamilton Pkwy.
Itasca, IL 60143
(630) 775-0990
TENNESSEE
Philips Factory Service of East Tennessee
6700 D Papermill Rd.
Knoxville, TN 37919
(423) 584-6614
MID-ATLANTIC
Philips Factory Service Mid-Atlantic
352 Dunks Ferry Rd.
Bensalem, PA 19020
(215) 638-7500
MAC2929 1/98
46 ua
LIMITED WARRANTY
DVD VIDEO PLAYER
90 Days Free Labor
One Year Exchange Warranty on Parts
This product must be carried in for repair.
WHO IS COVERED?
You must have proof of purchase to receive warranty service. A sales
receipt or other document showing that you purchased the product is
considered proof of purchase.
WHAT IS COVERED?
Warranty coverage begins the day you buy your product. For 90 days
thereafter, all parts will be repaired or replaced, and labor is free. From
90 days to one year from the day of purchase, all parts will be repaired or
replaced, but you pay for all labor charges. After one year from the day
of purchase, you pay for the replacement or repair of all parts, and for
all labor charges.
All parts, including repaired and replaced parts, are covered only for
the original warranty period. When the warranty on the product
expires, the warranty on all replaced and repaired parts also expires.
WHAT IS EXCLUDED?
Your warranty does not cover:
* labor charges for installation or setup of the product, adjustment of
customer controls on the product, and installation or repair of
antenna systems outside of the product.
* product repair and/or part replacement because of misuse, accident,
unauthorized repair or other cause not within the control of Philips
Consumer Electronics Company.
* reception problems caused by signal conditions or cable or antenna
systems outside the unit.
* a product that requires modification or adaptation to enable it to
operate in any country other than the country for which it was
designed, manufactured, approved and/or authorized, or repair of
products damaged by these modifications.
* incidental or consequential damages resulting from the product.
(Some states do not allow the exclusion of incidental or consequen-
tial damages, so the above exclusion may not apply to you. This
includes, but is not limited to, prerecorded material, whether copy-
righted or not copyrighted.)
a product that is used for commercial or institutional purposes
(including but not limited to rental purposes).
WHERE IS SERVICE AVAILABLE?
Warranty service is available in all countries where the product is offi-
cially distributed by Philips Consumer Electronics Company. In coun-
tries where Philips Consumer Electronics Company does not distribute
the product, the local Philips service organization will attempt to pro-
vide service (although there may be a delay if the appropriate spare
parts and technical manual(s) are not readily available).
MAKE SURE YOU KEEP...
Please keep your sales receipt or other document showing proof of
purchase. Attach it to this owner's manual and keep both nearby. Also
keep the original box and packing material in case you need to return
your product.
BEFORE REQUESTING SERVICE...
Please check your owner's manual before requesting service.
Adjustments of the controls discussed there may save you a service
call.
TO GET WARRANTY SERVICE IN U.S.A,
PUERTO RICO OR U.S. VIRGIN ISLANDS...
Take the product to a Philips factory service center (see enclosed list)
or authorized service center for repair. When the product has been
repaired, you must pick up the unit at the center. Centers may keep
defective parts.
(In US.A., Puerto Rico and U.S. Virgin Islands, all implied warranties,
including implied warranties of merchantability and fitness for a particu-
lar purpose, are limited in duration to the duration of this express war-
ranty. Because some states do not allow limitations on how long an
implied warranty may last, this limitation may not apply to you.)
TO GET WARRANTY SERVICE IN CANADA...
Please contact Philips at:
1-800-661-6162 (French Speaking)
1-800-363-7278 (English Speaking)
(In Canada, this warranty is given in lieu of all other warranties. No
other warranties are expressed or implied, including any implied war-
ranties of merchantability or fitness for a particular purpose. Philips is
not liable under any circumstances for any direct, indirect, special, inci-
dental or consequential damages, howsoever incurred, even if notified
of the possibility of such damages.)
REMEMBER...
Please record the model and serial numbers found on the product
below. Also, please fill out and mail your warranty registration card
promptly. It will be easier for us to notify you if necessary.
MODEL #
SERIAL #
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
Philips Service Company, P.O. Box 555, Jefferson City, Tennessee 37760,
(423) 475-8869
EL6191E002 / MAC 6058 / 8-97
188062Е001
Printed in Japan
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
