Register your product and get support at
www.philips.com/welcome
HD4991
EN User manual
ZH-HK 使用手冊
© 2014 Koninklijke Philips N.V.
HD4991_UM_ZH-HK_v1.0_140306
English
Controls overview (fig. 3)
g
1
Your induction cooker
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that Philips
offers, register your product at www.philips.com/
welcome.
2
What’s in the box (fig. 1)
Induction cooker main unit
User manual
Warranty card
Stockpot
Safety leaflet
b
c
Crystallite cooking plate
Cooking zone
Air inlet
i
j
k
l
m
n
Hot pot indicator
Steam/Stew indicator
Roast indicator
Soup/Congee indicator
Display screen
p
o
q
r
s
t
Preset indicator
Menu selection and
power/time switch
On/Off
Timer indicator
Preset/Timer
Childlock
Cooking
temperature/power
Cooking functions overview
Overview (fig. 2)
a
h
Fry indicator
Saute indicator
d
e
f
Control panel
Air outlet
Power cord
Cooking mode Default
Cooking power
cooking power/ regulation
temperature
100-1400W
1400 W/
)
Fry (
200°C
100-1400W
1400 W/
Saute ( )
200°C
Hot pot ( )
Steam/Stew
( )
Roast ( )
Soup/Congee
( )
Cooking mode
2100 W/
280°C
1800 W/
240°C
1400 W/
200°C
1000 W/
160°C
100-2100W
3
100-2100W
Remove all packaging materials of the induction
cooker.
100-1400W
100-2100W
Cooking time
regulation
0-120 minutes
Preset time
regulation
N/A
0-120 minutes
N/A
Hot pot ( )
0-120 minutes
N/A
Steam/Stew ( )
0-120 minutes
0-24 hours
Roast ( )
0-120 minutes
N/A
Fry (
Saute (
)
)
Soup/Congee ( ) 0-120 minutes
0-24 hours
4
Before first use
Preparing the appliance for use
(fig. 4)
1 Place the appliance on a dry, stable and level
surface. (fig. 4-1)
2 Make sure there is at least 10cm free space around
the appliance to prevent overheating. (fig. 4-2)
3 Always place the cookware on the cooking zone
during cooking. (fig. 4-3)
4 Make sure you use cookware of the correct types
and sizes (refer to the table below).
Recommended types and sizes of
cookware (fig. 5)
Material Cookware with a bottom made of iron or
magnetic stainless steel.
Shape
Cookware with a flat bottom.
Size
Cookware with a bottom diameter of 1023cm, depending on the cooking mode
Weight Cookware with a weight of up to 15kg
(including contents)
5
Using the induction cooker
(fig. 6)
There are 6 preset cooking modes: fry, saute, hot pot,
steam/stew, roast and soup/congee.
1 Follow the steps in “Preparing the appliance for
use”.
2 Plug in the induction cooker. (fig. 6-1)
3 Tap the On/Off icon
. (fig. 6-2)
»» the On/Off indicator lights up.
»» The induction cooker beeps.
»» All indicators light up once and then go off.
»» The induction cooker stays in standby mode.
repeatedly until the desired
4 Tap the menu icon
cooking mode is selected. (fig. 6-3)
»» The cooking mode indicator lights up and
the induction cooker starts heating up the
cookware.
»» The remaining cooking time and cooking power
or temperature are displayed on the screen in
sequence.
5 When the cooking is finished, tap the On/Off icon
to stop the cooking process, and the induction
cooker switches to standby mode.
6 Unplug the induction cooker after the fan stops
working. (fig. 6-4)
Using the timer
The induction cooker provides you with flexible
control over the cooking time you want the appliance
to operate in different cooking modes.
1 Follow the steps in “Preparing the appliance for
use”.
2 Plug in the induction cooker. (fig. 6-1)
. (fig. 6-2)
3 Tap the On/Off icon
repeatedly until the desired
4 Tap the menu icon
cooking mode is selected. (fig. 6-3)
until the timer
5 Tap the Preset/Timer icon
indicator lights up. (fig. 6-6)
6 Slide your finger clockwise on the circular Power/
Time switch area to increase the cooking time
by 5 minutes; slide anti-clockwise to decrease the
cooking time by 5 minutes (fig. 6-5). You can also
tap the increase or decrease icon to adjust
the cooking time by the increment of 1 minute.
(fig. 6-7)
7 When the cooking time has elapsed, the induction
cooker beeps and turns off automatically.
Note
•• After you have selected the cooking time, wait
for a few seconds before the induction cooker
automatically confirms it.
Preset time for delayed cooking
With the preset funtion, you can set the time at which
you want the appliance to start cooking in steam/stew
and soup.congee modes.
1 Follow the steps in “Preparing the appliance for
use”.
2 Plug in the induction cooker. (fig. 6-1)
. (fig. 6-2)
3 Tap the On/Off icon
repeatedly until the desired
4 Tap the menu icon
cooking mode is selected. (fig. 6-3)
until the preset
5 Tap the Preset/Timer icon
indicator lights up. (fig. 6-8)
6 Slide your finger clockwise on the circular Power/
Time switch area to increase the preset time by 20
minutes; slide anti-clockwise to decrease the preset
time by 20 minutes (fig. 6-5). You can also tap
the increase or decrease icon to adjust the
preset time by the increment of 1 minute. (fig. 6-7)
7 When the preset time has elapsed, the induction
cooker beeps and starts working automatically.
Note
•• After you have selected the preset time, wait
for a few seconds before the induction cooker
automatically confirms it.
Setting up child lock
• When the induction cooker is switched on, long
for 3 seconds to activate
tap the childlock icon
childlock.
• To deactivate childlock, long tap the child lock icon
for 3 seconds again.
Note
•• When childlock is activated, only Childlock and
On/Off are responsive.
6
Cleaning (fig. 7)
1 Unplug the appliance and let it cool down.
2 Clean the appliance with a damp cloth (fig. 7-1)
and, if necessary, with some mild cleaning agent
(fig. 7-2).
3 Clean the air outlets with a brush. (fig. 7-3)
7Environment
Do not throw away the appliance with the
normal household waste at the end of its life,
but hand it in at an official collection point for
recycling. By doing this, you help to preserve
the environment.
8
Guarantee and service
If you need service or information or if you have
a problem, please visit the Philips website at www.
philips.com or contact the Philips Consumer Care
Centre in your country (you will find its phone
number in the worldwide guarantee leaflet). If there is
no Consumer Care Centre in your country, go to your
local Philips dealer.
9Troubleshooting
If your induction cooker does not function properly
or if the cooking quality is insufficient, consult the table
below. If you are unable to solve the problem, contact
a Philips service centre or the Consumer Care Centre
in your country.
Problem
The On/Off icon
does not
respond
When I tap
the menu icon,
the light of the
selected mode
does not go on.
E5 or E6 is
displayed on the
screen
E0, E1, E2, E3,
E4, E8 or E9 is
displayed on the
screen.
The induction
cooker stops
working or turns
off automatically.
Solution
There is a connection problem.
Check if the induction cooker is
connected to the mains and if
the plug is inserted firmly into
the wall socket
The light is defective. Take the
appliance to your Philips dealer
or a service centre authorised
by Philips.
Check if the voltage is too low
or too high.
Check if the power cord or
power socket is too hot.
Check if too many appliances are
plugged to the same connector.
The induction cooker has
malfunctions. Take the appliance
to a Philips dealer or a service
centre authorised by Philips.
The induction cooker has been
idle for more than 2 hours.
Check if the air inlet and outlets
are covered.
Temperature around the
induction cooker is too high.
建議的廚具種類和大小(圖 5)
繁體中文
1
您的電磁爐
恭喜你購買 Philips 產品,歡迎來到 Philips 世
界!要享受 Philips 為您提供的全面支援,請在
以下網站 www.philips.com/welcome 註冊您的
產品。
2
包裝盒內容(圖 1)
電磁爐主裝置
用戶手冊
保用證
湯鍋
安全小冊子
概覽(圖 2)
a
微晶玻璃電磁爐面板
D
控制面板
b
烹飪區
e
排氣口
c
進氣口
f
電源線
控制鍵概覽(圖 3)
g
煎炒指示燈
n
預約指示燈
h
快炒指示燈
o
功能選擇及火力/
時間調節
i
火鍋指示燈
p
開/關
j
蒸煮指示燈
q
定時指示燈
k
鐵板燒指示燈
r
預約/定時
l
湯/粥指示燈
s
兒童安全鎖
顯示屏幕
t
烹調溫度/火力指
示燈
m
烹調功能概覽
預設溫度/火力 烹飪火力調控
烹飪模式
1400 瓦/
200°C
瓦/
1400
快炒( )
200°C
2100 瓦/
火鍋( )
280°C
瓦/
1800
蒸煮( )
240°C
鐵板燒( ) 1400 瓦/
200°C
瓦/
1000
湯/粥( )
160°C
100-1400 瓦
烹飪模式
可定時時間
調控
預約烹調時間
煎炒(
0-120 分鐘
N/A
)
0-120 分鐘
N/A
火鍋( )
0-120 分鐘
N/A
蒸煮( )
0-120 分鐘
0-24 小時
煎炒(
快炒(
)
)
鐵板燒( ) 0-120 分鐘
湯/粥( )
3
0-120 分鐘
100-1400 瓦
100-2100 瓦
100-2100 瓦
100-1400 瓦
100-2100 瓦
N/A
0-24 小時
首次使用前
拆去電磁爐的所有包裝材料。
4
準備使用電磁爐(圖 4)
1 將電磁爐放置於穩固、平坦的水平表面上。
(圖 4-1)
2 確保機器周圍 10 公分內沒有其他物體,以防
機器過熱。(圖 4-2)
3 烹飪時請將廚具放置在烹飪區內。(圖 4-3)
4 確保使用正確種類和大小的廚具,詳見下表。
物料
底部使用鐵或電磁不銹鋼製作的廚具。
外形
有平底廚具。
尺寸
底部直徑介於 10 至 23 公分的廚具,
依烹飪模式而定。
重量
至多重 15 公斤的廚具(包括內容物)
5
使用電磁爐(圖 6)
本電磁爐共有 6 種預約烹飪模式:煎炒、快炒、
火鍋、蒸煮、鐵板燒及湯/粥。
1 按照「準備使用電器」的步驟進行操作。
2 接通電磁爐電源。(圖 6-1)
。(圖 6-2)
3 輕觸開/關圖標
»» 開/關指示燈亮起。
»» 電磁爐發出嗶聲。
»» 所有指示燈亮起一下,然後熄滅。
»» 電磁爐處於待機模式。
,選擇您想使用的
4 重複輕觸功能選擇圖標
烹飪模式。(圖 6-3)
»» 烹飪模式指示燈亮起,電磁爐開始加熱廚
具。
»» 剩餘烹調時間和烹調火力或溫度會順序在
屏幕上顯示。
5 完成烹調後,輕觸開/關圖標
停止烹調程
序,電磁爐便會轉至待機模式。
6 等風扇停止運轉後,拔除電磁爐的插頭。
(圖 6.4)
使用定時功能
電磁爐讓您在不同烹飪模式下靈活控制烹調時
間。
1 按照「準備使用電器」的步驟進行操作。
2 接通電磁爐電源。(圖 6-1)
。(圖 6-2)
3 輕觸開/關圖標
,選擇您想使用的
4 重複輕觸功能選擇圖標
烹飪模式。(圖 6-3)
,直到定時指示燈亮
5 輕觸預約/定時圖標
起。(圖 6-6)
6 在火力/時間調節區域上按順時針方向滑動手
指加長烹調時間 5 分鐘;按逆時針方向滑動
手指縮短烹調時間 5 分鐘(圖 6-5)。您亦可
輕觸增加
或減少
圖標,以 1 分鐘為單
位調校烹調時間。(圖 6-7)
7 設定的烹調時間結束時,您會聽到蜂鳴提示,
電磁爐會自動關閉。
提示
• 選好烹飪時間後,靜候數秒,電磁爐將會自
提示
• 選好預約時間後,靜候數秒,電磁爐將會自
動確認。
設定兒童鎖
• 電磁爐工作時,輕觸童鎖圖標
3 秒鐘,進入
兒童鎖模式。
• 如需退出兒童鎖模式,再次輕觸童鎖圖標
3
秒鐘即可。
提示
• 兒童鎖模式下,只有童鎖和開關圖標有反
應。
6
清潔(圖 7)
1 拔除產品插頭,讓產品冷卻。
2 請使用濕布清潔本產品(圖 7-1);如有需要,
請使用溫和的清潔劑(圖 7-2)。
3 使用毛刷清潔排氣口。(圖 7-3)
7
環境
請勿在本產品使用壽命結束後當作一般家
庭垃圾廢棄,應交給官方回收站作循環再
用。這樣做有助保護環境。
8
保障及服務
9
故障排除
如果您需要資料或有疑問,請前往 Philips 網站
www.philips.com,或聯絡您的國家的 Philips 顧客
服務中心(您會在全球保障小冊子上找到其電話號
碼)。如果您的國家沒有顧客服務中心,請前往當
地的 Philips 經銷商。
若電磁爐無法正確運作,或電磁爐烹飪效率不佳,
請參照下表。若您無法解決問題,請聯絡飛利浦服
務中心或您所在國家的顧客服務中心。
問題
解決方案
開/關圖標
沒有響應
連接有誤。檢查電磁爐是否有
連接主電源,插頭和插座是否
有鬆脫。
輕觸功能選擇圖 指示燈損壞。請將產品拿至飛
標後,已選模
利浦經銷商或飛利浦認可的服
式的燈沒有亮
務中心。
起。
熒幕上顯示E5
或E6
動確認。
預約時間延時烹飪
有了預約功能,您可在蒸煮及湯/粥模式下設定開
始烹調的時間。
1 按照「準備使用電器」的步驟進行操作。
2 接通電磁爐電源。(圖 6-1)
。(圖 6-2)
3 輕觸開/關圖標
,選擇您想使用的
4 重複輕觸功能選擇圖標
烹飪模式。(圖 6-3)
,直到定時指示燈亮
5 輕觸預約/定時圖標
起。(圖 6-8)
6 在火力/時間調節區域上按順時針方向滑動手
指加長預約時間 20 分鐘;按逆時針方向滑動
手指縮短預約時間 20 分鐘。您亦可輕觸增加
或減少
圖標,以 1 分鐘為單位調校預約
時間。(圖 6-7)
7 預約時間到時,您會聽到蜂鳴提示,電磁爐會
自動開始運作。
檢查電壓是否太低或太高。
檢查電源線或電源插座是否
過熱。
檢查同一連接器上是否連接太
多插頭。
屏幕上顯示
E0、E1、E2、
E3、E4、E8
或 E9。
電磁爐故障。將本產品帶往您
的 Philips 經銷商或得到認可
的 Philips 維修中心。
電磁爐停止運轉 電磁爐閒置超過 2 小時。
或自動關閉。
檢查進氣口或排氣口是否被
遮蓋住。
電磁爐周圍的溫度過高。
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
