2-597-54511 (1)
KDF-E42A10
KDF-E50A10
Quick Setup Guide
For further information, see the operating instruction supplied with the TV.
Please retain this guide for your future reference.
Please follow the steps to setup your TV:
1 Connecting Your TV
(See reverse side)
2
3
Running Initial Setup
Programming the Remote Control
For service and technical assistance, call our Customer Information Service Center (Toll Free):
US residents: 1-800-222-SONY (7669) or visit http://www.sonystyle.com/tv/
Canadian residents: 1-877-899-SONY (7669) or visit http://www.sonystyle.ca/tv/
DO NOT RETURN TO THE STORE
Sony Corporation © 2005 Printed in U.S.A.
1
Connecting Your TV
Making Audio/Video Connections
Your new TV includes various types of video inputs and two types of audio jacks; composite-RCA type and digital audio (optical).
Use the outputs/inputs that are available on your components that provide the best video/audio performances:
Best Audio/Video
Performance
Connector type
Connector type
PCM/DOLBY DIGITAL
DIGITAL
AUDIO
(OPTICAL
OUT)
Digital Optical
Digital Coaxial
Will require an adapter to connect to this TV’s digital audio input.
HDMI
(High-Definition Multimedia
Interface)
DVI (Digital Video Interface)
Will require an adapter to connect to this TV.
Analog Audio
Component video
S VIDEO
Composite video
RF/Coaxial
Activating CableCARD™ Service
Before you can use CableCARD service, you need to insert the
CableCARD device (supplied by your cable provider) and activate the service.
Inserting the CableCARD incorrectly may result in permanent damage to the card and the TV.
The connection diagrams shown in the reverse side are recommendations only; other possible solutions may exist. Connections that include an AV receiver can often be complex, so check your AV receiver’s instruction manual for additional details.
See the “Cables Required” chart that appears with the diagram to determine which cables you’ll need. Depending on the components you plan to connect, you may need to purchase extra cables.
Review the following chart to determine which diagram to use to connect the components in your system:
Turn off and unplug all components before making connections.
HD DVR
PC
PC
2
Running Initial Setup
1
Press to turn on the TV.
The Initial Setup screen appears.
2
Press V or v to highlight the on-screen display language. Then press .
The message “First please connect cable and/or antenna” appears. This may require 50+ minutes for completion and “Start auto program now?” appears.
3
Press (Yes) to start Initial Setup.
Initial Setup automatically creates a list of receivable channels from both VHF/UHF antenna and cable TV channels if both sources are connected.
When Initial Setup is complete, the TV will display the total number of analog channels and the total number of digital channels found.
4
Press to exit this screen.
To run Auto Program again at a later time
Refer to the manual on “Initial Setup” and “Auto Program” sections.
3
Programming the Remote Control
The remote control is preset to operate Sony brand video equipment.
Sony Equipment
DVR
DVD/VCR
SAT/CABLE
Programmable Code Number
772
601 (Sony Dream System)
801 (Sony Satellite Receiver)
Follow the steps below to program your TV’s remote control to operate the non-Sony video equipment.
Find the three-digit code for your equipment from the
“Manufacturer’s Codes” listed on right. If more than one code number is listed, try entering from the code listed first.
MUTING TV/VIDEO POWER
TV POWER
DVR
JUMP
SOUND PICTURE TV/SAT
SUR
WIDE
R
E
TU
R
N
G
U
ID
E
PREV REPLAY ADVANCE NEXT
VISUAL SEARCH
VOL
REC
DVD/
VCR
SAT/
CABLE
ANT MTS/SAP FREEZE
WEGA
GATE
PAUSE
REC PAUSE REC STOP
TOP MENU MENU
PLAY
F1
ENT
DIS
PL
AY
CH
TO
O
LS
STOP
F2
TV
1
2
3
1
1 Press and hold the , or FUNCTION button you want to program on the remote control and press the button simultaneously.
The selected FUNCTION button ( , or ) will flash.
2 Enter the three-digit manufacturer’s code number using the 0-9 buttons while the button is lit. If code is not entered within 10 seconds, you must perform the step 1 again.
3 Press button.
When programmed correctly, the selected FUNCTION button will flash twice, and when not, it flashes five times.
TV
To check if the code works
Aim your TV’s remote control at the equipment, and press the green button. If the equipment responds, the programming is completed. If not, try the next code listed.
If no code is input within the above specified time, or an invalid or incorrect code number is input, the remote control automatically goes back to the previous setting.
In some cases, you may not be able to program your remote control to operate other equipment. In such cases, use the equipment’s own remote control.
Removing the batteries or dead batteries may cause the programmed codes to be lost and revert back to the factory setting. Reprogramming the codes may be necessary.
Manufacturer’s codes
DVD Players
Manufacturer Code
Sony
General Electric
Hitachi
JVC
Magnavox
751
755
758
756
757
Mitsubishi
Panasonic
Philips
Pioneer
RCA/PROSCAN
Samsung
Toshiba
Zenith
761
753
757
752, 778
755
758
754
760
DVD Changers
Manufacturer Code
Sony
Panasonic
765
766
DVD/VCR Combo Units
Manufacturer Code
Sony
Broksonic
JVC
Panasonic
767
776
775
777
Samsung
Toshiba
Zenith
774
773
768
HDD/DVD Combo Units
Manufacturer Code
Sony 772, 771, 770
5.1ch DVD AV System
Manufacturer Code
Sony (DAV) 601, 602, 603, 604
AV Receivers
Manufacturer Code
Sony 764
VCRs
Manufacturer Code
Sony
Admiral (M. Ward)
Aiwa*
301, 302, 303
327
338, 344
Audio Dynamic 314, 337
Manufacturer Code
Broksonic
Canon
Citizen
Craig
319, 317
309, 308
332
302, 332
Curtis Mathes
Daewoo
DBX
Dimensia
Emerson
Fisher
Funai
General Electric
Go Video
Goldstar
Hitachi
Instant Replay
JC Penney
JVC
Kenwood
LG
LXI (SEARS)
Magnavox
Marantz
Marta
Memorex
Minolta
Mitsubishi/MGA
Multitech
NEC
Olympic
Optimus
Orion
Panasonic
308, 309, 310
314, 336, 337
332
309, 335
305, 304
323, 324, 325, 326
325, 338, 321
314, 336, 337
309, 308
327
317
308, 309, 306, 307
Pentax
Philco
Philips
Pioneer
Quasar
RCA/PROSCAN
305, 304
308, 309
308, 309, 310
308
308, 309, 306
Realistic
304, 305, 308, 309,
311, 312, 313, 310,
329
309, 330, 328, 335,
324, 338
314 Sansui
Samsung
Sanyo
Scott
322, 313, 321
330, 335
312, 313, 321, 335,
323, 324, 325, 326
Sharp 327, 328
Signature 2000 (M.Ward) 338, 327
SV 2000 338
304, 338, 309
341, 312, 309
314, 336, 337
304
319, 320, 316, 317,
318, 341
330, 335
338
329, 304, 309
322, 339, 340
332
306, 304, 305, 338
309, 308
309, 305, 304, 330,
314, 336, 337
314, 336, 337, 345,
346, 347
314, 336, 332, 337
332
332, 305, 330, 335,
338
Manufacturer Code
Sylvania
Symphonic
Tashiro
Tatung
308, 309, 338, 310
338
332
314, 336, 337
Teac
Technics
Toshiba
Wards
Yamaha
Zenith
314, 336, 338, 337
309, 308
312, 311
327, 328, 335, 331,
332
314, 330, 336, 337
331
Cable Boxes
Manufacturer Code
Sony
Hamlin/Regal
Jerrold/
General Inst./
Motorola
Oak
Panasonic
Pioneer
Scientific Atlanta
230
222, 223, 224, 225,
226
201, 202, 203, 204,
205, 206, 207, 208,
218, 222
227, 228, 229
219, 220, 221
211, 214, 215
209, 210, 211
Tocom
Zenith
216, 217
212, 213
Satellite Receivers
Manufacturer Code
Sony
Dish Network
Echostar
General Electric
801
810
810
802
Hitachi
Hughes
Mitsubishi
Panasonic
Philips
RCA/PROSCAN
Toshiba
Samsung
805
804
809
803
811
802, 808
806, 807
812
* If an Aiwa VCR does not work even though you enter the code for Aiwa, enter the code for Sony instead.
Notes on your new TV
Projection Lamp: Periodic replacement of the projection lamp will maintain the picture quality.
See Replacement Lamp section of the manual.
Wide Mode: Selecting appropriate screen mode will increase enjoyment of your TV viewing.
When watching a Standard Definition source (4:3 aspect ratio) on this TV, you will see bars on both the left and right sides of the screen. Press the WIDE button on your remote to cycle through different screen modes to fill the screen in various ways. (Wide Zoom enlarges the center, Normal is how your TV receives the signal, Full stretches horizontally and Zoom enlarges the image proportionately to fill the screen.)
When watching a High Definition source (16:9 aspect ratio) on this TV, you will see screen filled with a image. Press the
WIDE button on your remote to toggle through different screen modes, especially zooming in to the center of the screen. (Wide Zoom enlarges the center, Full displays the image at its original size, Zoom enlarges the image proportionately to fill the screen.)
When the TV receives a 720p or 1080i formatted signal, the
Normal mode is not available. See Using WIDE Button section of the manual.
If you feel the images on the screen is stretched, press the WIDE button to select a different screen mode.
A
Use this diagram if you have;
Cable Antenna
CableCARD
(optional)
