1
Downloading Images to your Computer
Basic operation such as preparing for downloading images to your computer (connecting your camera and computer), starting up EU, downloading images from your camera to your computer and exiting EU are explained here.
Connecting the Camera and Computer..................... 7
Starting up EU ........................................................... 8
LAN Connection with EU ..............................................
Batch Downloading Images to Your Computer ....... 10
Downloading Selected Images to Your Computer......
Exiting EU................................................................ 14
6
Connecting the Camera and Computer
To download to your computer images shot with your camera, you will need to connect your camera and computer using an interface cable.
For how to connect, see the camera instruction manual.
Before connecting your camera and computer with EU’s Wi-Fi/LAN connection pairing function, see “LAN Connection with EU”
.
Using a genuine Canon interface cable is recommended.
Confirming Computer Settings
Before you start up EU, connect the camera and the computer and turn on the camera’s power, then make sure that the following settings are applied to your computer. If these are not applied, adjust the settings as follows.
Windows 8.1
Select [Control Panel]
[View devices and printers].
Doubleclick the icon of the camera connected to the computer. Select and double-click [Change general settings] in the menu that appears. Set the pull-down menu for [When this device connects to this PC] to [Take no action].
Windows 10
Select the Start menu [Settings] [Devices] [AutoPlay] In the window that appears, locate the pull-down menu under the name of the camera connected to the computer and set it to [Take no action].
After confirming and adjusting the settings, set the camera’s power switch to <OFF>.
To start up EU, you must connect your camera to the same USB port as when you confirmed and adjusted the settings.
To use another USB port, confirm and adjust the settings again.
7
Starting up EU
When the camera’s power switch is set to <ON>, EU will start up, and the camera and computer will be able to communicate.
1
Set the camera’s power switch to < ON >.
2
Double-click the [EOS Utility] icon on the desktop.
Communication between the camera and the computer begins, and the next screen is displayed.
From the next time you connect your camera and the computer,
EU will start when you set your camera’s power switch to <ON>.
EU Main window
EU starts up, the main window appears, and your camera and computer can now communicate. Continue with “Batch
Downloading Images to Your Computer”.
When EU starts, a [ ] icon appears on the taskbar of the desktop.
You can click this icon and display the screen to apply the setting below.
[Do not launch EOS Utility automatically when camera is connected]
If you select [Quit] on this screen, EU will not start automatically when you connect the camera and the computer again.
8
LAN Connection with EU
The Wi-Fi/LAN connection pairing function of EU is used for LAN connection. This function cannot be used with
REBEL T6S 760D
REBEL T6i 750D REBEL T7 2000D 1500D REBEL T6 1300D REBEL T100
4000D 3000D M6 M5 M3 M10 M100
.
Establish a connection following the procedures on Wireless File
Transmitter Instruction Manual, Wi-Fi Function Instruction Manual or
Wired LAN Instruction Manual supplied with the camera, and Wi-Fi
Adapter W-E1 Instruction Manual. Note the difference between connection procedures for EU version 2.14 or later and those for EU version 2.13 or earlier as shown below.
Starting up WFT pairing software
(EU version 2.13 or earlier)
Starting up WFT pairing software is required.
(EU version 2.14, version 3.x)
While starting up WFT pairing software is not necessary, starting up
EU is required.
When a camera is detected
(EU version 2.13 or earlier)
When a camera is detected and a message is displayed, double-click the WFT pairing software icon.
(EU version 2.14, version 3.x)
When a camera is detected and a message is displayed, click the message.
Before starting the procedure to establish a LAN connection, make sure to perform the following confirmation.
1
Start up EU before connecting the camera and the computer.
The following window appears.
2
Click the [Pairing over Wi-Fi/LAN] button. When a message [To connect to the camera via LAN, some
Windows Firewall settings must be changed. Do you want to make these changes?] appears, select [Yes].
9
Batch Downloading Images to Your Computer
You can batch download to your computer the images saved on the memory card inserted in the camera according to the selected condition.
The downloaded images are sorted by date into folders and are then displayed in the main window of Digital Photo Professional version 4.x
(RAW image processing, viewing and editing software) (hereinafter
DPP), which is linked to start up automatically, where you can check them immediately.
3
Select a condition for downloading images and click the [OK] button.
1
Click [Download images to computer].
The setting dialog box closes.
4
Click the text [Start automatic download].
Download images window appears.
2
Click the [Settings] button in [Start automatic download].
The setting dialog box appears.
The [Save File] dialog box appears and image downloading to your computer begins.
The downloaded images are saved in the [Pictures] folder.
When all images have been downloaded, DPP starts up automatically and the downloaded images are displayed in
DPP’s main window.
10
5
Check the downloaded images.
DPP Main window
Check the downloaded images in DPP.
For details on using DPP, refer to the “Digital Photo Professional
Version 4.x Instruction Manual” (PDF electronic manual).
Continue with “Exiting EU”
.
Downloading Selected Images to Your Computer
From the images saved in your camera’s memory card, you can select the ones you want and download them to your computer.
1
Click [Select and download].
The viewer window appears and the images in the memory card are displayed.
You can change the software, which starts up when you download images, from DPP to other software in preferences
([Linked Software] tab sheet)
.
You can change the save destination for images downloaded and images to download in preferences ([Destination Folder] tab sheet
.
Downloading movie files may take some time due to the large file size.
11
2
View the images and select images to download.
Viewer window
Add check mark
You can also select several images with your mouse.
You can click the [ ] button to change the thumbnail order.
You can click the [ ] button to filter the images with various conditions and select images you want to download.
You can click the [ displayed on thumbnails.
] button to select the information
Selecting [Date/time] displays the date and time when the file was created.
You can click the [ ] button to invert selection between selected and not-selected images.
You can click the [ ] button to show only selected images.
You can click the [ date and time files were created.
] button to filter images by the
You can click the [
Click the [
] button to change to the list view.
] button to return to the thumbnail view.
In the list view, you can click on the title of each item to begin sorting.
Click [Folder] to sort in the same way as the [ thumbnail view.
] button in
12
3
Click the [Download] button.
The images downloaded to your computer are displayed in the
[Quick Preview] window.
The download image dialog box appears.
4
Specify the save destination and then click the [OK] button.
Download image dialog box
Displays the save destination on the computer
Specify the save destination
The [Save File] dialog box appears and image downloading to your computer begins.
The [Quick Preview] window allows you to quickly review the downloaded images. You can also resize the [Quick Preview] window.
When all images have been downloaded, DPP starts up automatically and the downloaded images are displayed.
To switch to the main window, click the [Main Window] button in the viewer window.
13
Exiting EU
1
Click the [Quit] button.
By clicking the [Format] button in the viewer window, you can initialize the card to which the images displayed in the viewer window.
In step 2, you can batch checkmark several images in sequence.
After clicking the first image you want to download, hold the
< Shift > key and click the last image, and [ ] will be displayed. By clicking the [ ] button, the selected images will be checkmarked in a batch.
For a list of viewer window functions, see p.107
In an HDR environment, images shot with HDR PQ set on the camera are displayed as HDR PQ (10-bit) images also in the
[Quick Preview] window. For details on an HDR environment, see
“Remote Live View Display when HDR PQ is Set”
The window closes and EU exits.
2
Turn the camera’s power switch to < OFF >.
3
Disconnect the cable from the camera and computer.
Do not pull on the cable; hold the plug and pull out.
EOS Utility Survey Program
Canon requests that information related to your Canon product be sent to Canon (in case of using your Canon product in China, to the legally approved research company) through the Internet. Canon uses such information for development and marketing of products that better meet customer needs.
Even after agreeing, you can change the send settings anytime in the [Survey] tab sheet
in preferences.
14
