Appendix B: Setting up a TFTP Server
B.1 Set up a TFTP Server
Upgrading the VoIP Ceiling Speaker firmware requires a TFTP server on which you access the Web interface where you can upload the firmware files.
B.1.1 In a LINUX Environment
To set up a TFTP server on LINUX:
1. Create a directory dedicated to the TFTP server, and move the files to be uploaded to that directory.
2. Run the following command where
/tftpboot/
is the path to the directory you created in
: the directory that contains the files to be uploaded. For example: in.tftpd -l -s /tftpboot/
your_directory_name
B.1.2 In a Windows Environment
You can find several options online for setting up a Windows TFTP server. This example explains how to use the Solarwinds freeware TFTP server, which you can download at: http://www.CyberData.net/support/voip
To set up a TFTP server on Windows:
1. Install and start the software.
2. Select
File
/
Configure
/
Security
tab
/
Transmit Only
.
3. Make a note of the default directory name, and then move the firmware files to be uploaded to that directory.
4. You can find several options online for setting up a Solarwinds server. This example explains how to use the Solarwinds freeware TFTP server, which you can download at: http://www.CyberData.net/support/voip
31
CyberData Corporation VoIP Loudspeaker Amplifier Operations Guide 930111C
32
CyberData Corporation 930111C VoIP Loudspeaker Amplifier Operations Guide
