AIX 5L Operating

System Installation

Getting Started

AIX

REFERENCE

86 A2 09EG 00

ESCALA

AIX 5L Operating

System Installation

Getting Started

AIX

Software

October 2002

BULL CEDOC

357 AVENUE PATTON

B.P.20845

49008 ANGERS CEDEX 01

FRANCE

REFERENCE

86 A2 09EG 00

The following copyright notice protects this book under Copyright laws which prohibit such actions as, but not limited to, copying, distributing, modifying, and making derivative works.

Copyright Bull SAS 1992, 2002

Printed in France

Suggestions and criticisms concerning the form, content, and presentation of this book are invited. A form is provided at the end of this book for this purpose.

To order additional copies of this book or other Bull Technical Publications, you are invited to use the Ordering Form also provided at the end of this book.

Trademarks and Acknowledgements

We acknowledge the right of proprietors of trademarks mentioned in this book.

AIX® is a registered trademark of International Business Machines Corporation, and is being used under licence.

UNIX® is a registered trademark in the United States of America and other countries licensed exclusively through the Open Group.

Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries

The information in this document is subject to change without notice. Bull will not be liable for errors contained herein, or for incidental or consequential damages in connection with the use of this material.

About This Book

The AIX 5L Version 5.2 Operating System Installation: Getting Started guide provides system administrators with information about how to install and configure the AIX operating system on a standalone system using a CD–ROM device. The two methods described in this book are the new and complete overwrite installation method and the migration installation method. This publication is also available on the ”Hypertext Library for AIX 5.1”

CD-ROM that is shipped with the operating system.

For complete conceptual and task information about installing AIX, see the AIX 5L Version

5.2 Installation Guide and Reference.

Who Should Use This Book

This book provides system administrators with information about performing an AIX installation using the CD–ROM device. The two methods described in this book are the new and complete overwrite installation method and the migration installation method.

Highlighting

The following highlighting conventions are used in this book:

Bold

Italics

Monospace

Identifies commands, subroutines, keywords, files, structures, directories, and other items whose names are predefined by the system. Also identifies graphical objects such as buttons, labels, and icons that the user selects.

Identifies parameters whose actual names or values are to be supplied by the user.

Identifies examples of specific data values, examples of text similar to what you might see displayed, examples of portions of program code similar to what you might write as a programmer, messages from the system, or information you should actually type.

Case–Sensitivity in AIX

Everything in the AIX operating system is case–sensitive, which means that it distinguishes between uppercase and lowercase letters. For example, you can use the ls command to list files. If you type LS, the system responds that the command is ”not found.” Likewise, FILEA,

FiLea, and filea are three distinct file names, even if they reside in the same directory. To avoid causing undesirable actions to be performed, always ensure that you use the correct case.

Preface

iii

ISO 9000

ISO 9000

registered quality systems were used in the development and manufacturing of this product.

Related Publications

The following publications will help you administer your AIX environment:

•

AIX 5L Version 5.2 Installation Guide and Reference

•

AIX 5L Version 5.2 Security Guide

•

AIX 5L Version 5.2 System Management Concepts: Operating System and Devices

•

AIX 5L Version 5.2 System Management Guide: Operating System and Devices

•

AIX 5L Version 5.2 System Management Guide: Communications and Networks

•

AIX 5L Version 5.2 General Programming Concepts: Writing and Debugging Programs

•

AIX 5L Version 5.2 Communications Programming Concepts

•

AIX 5L Version 5.2 Performance Management Guide

•

Performance Toolbox 1.2 and 2.1 for AIX: User’s Guide

•

AIX 5L Version 5.2 Commands Reference

•

AIX 5L Version 5.2 Files Reference

•

AIX 5L Version 5.2 Glossary

•

Common Desktop Environment 1.0: Advanced User’s and System Administrator’s

Guide

•

•

AIX 5L Version 5.2 System User’s Guide: Operating System and Devices

AIX 5L Version 5.2 System User’s Guide: Communications and Networks

iv

Operating System Installation: Getting Started

Contents

About This Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1. Introduction to Base Operating System Installation

Electronic License Agreements

. . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 2. New and Complete Overwrite Installation

Step 1. Prepare Your System

. . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Step 2. Boot from the AIX Product CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Step 3. Set and Verify Installation Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Step 4. Configure the System after Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 3. Migration Installation


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Step 2. Boot from the AIX Product CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Step 3. Verify Migration Installation Settings and Begin Installation . . . . . . . . . . . . .

Step 4. Verify System Configuration after Installation . . . . . . . . . . . . . . . . . . . . . . . . . iii

1-1

1-1

3-1

3-1

3-2

3-2

3-3

2-1

2-1

2-1

2-2

2-4

Preface

v

vi


Chapter 1. Introduction to Base Operating System

Installation

This guide provides an overview of the necessary steps to complete an installation of the

AIX 5.2 Base Operating System (BOS).

The BOS installation program first restores the run–time bos image, then installs the appropriate filesets, depending on whether you are installing from a graphical or an ASCII system. The installation program automatically installs required message filesets and devices filesets, according to the language you choose and the hardware configuration of the installed machine.

You can use the following methods for installing AIX:

New and Complete Overwrite

This method installs AIX 5.2 on a new machine or completely overwrites any BOS version that exists on your system.

Migration This method upgrades from AIX 4.2 or later versions of the BOS to AIX 5.2.

A migration installation preserves most file systems, including the root volume group, logical volumes, and system configuration files. It overwrites the /tmp file system.

Preservation This method replaces an earlier version of the BOS but retains the root volume group, the user–created logical volumes, and the /home file system. It overwrites the /usr, var, tmp, and / (root) file systems. Product

(application) files and configuration data are lost. For information about preservation installation, see the AIX 5L Version 5.2 Installation Guide and

Reference.

The table below shows the differences in the installation steps between the new and complete ovewrite installation and the migration methods.

Table 1. AIX BOS Installation Methods

Installation Steps

Make rootvg

Make filesystem /, /usr, /var

Make filesystem /home

Save Configuration

Restore BOS

Install Additional Filesets

Restore Configuration

New and Complete

Overwrite

Yes

Yes

Yes

No

Yes

Yes

No

Migration

No

No

No

Yes

Yes

Yes

Yes

Electronic License Agreements

AIX 5.2 ships with software license agreements and are viewable electronically. If a product has an electronic license agreement, it must be accepted before software installation can continue. In the case of initial BOS installation, you can view and accept license agreements in a license agreement dialog after the installation has occurred, but before the system is

Introduction to Base Operating System Installation

1-1

available for use as part of Configuration Assistant (graphical consoles) or Installation

Assistant (ASCII consoles).

The Base Operating System (BOS) has a license agreement, but not all software packages do. When you agree to the license agreement for BOS installation, you are also accepting all license agreements for any software installed automatically with the BOS. Some software, such as the GNOME or KDE desktops, can be optionally installed during BOS installation; the appropriate licensing information for such software is displayed separately.

For more information on license manipulation, see the AIX 5L Version 5.2 Installation Guide and Reference.

1-2


Chapter 2. New and Complete Overwrite Installation

Use the following steps to perform a new and complete overwrite installation of AIX 5.2.

•


•

Step 2. Boot from the AIX Product CD

•

Step 3. Set and Verify Installation Settings on page 2-2

•

Step 4. Configure the System after Installation on page 2-4

For more information on new and complete overwrite installation, refer to the Installing the

Base Operating System section in the AIX 5L Version 5.2 Installation Guide and Reference.

Refer to the Network Installation Management (NIM) section in the AIX 5L Version 5.2

Installation Guide and Reference, if you are performing a network installation of AIX.


1. There must be adequate disk space and memory available. AIX 5.2 requires 128 MB of memory and 2.2 GB of physical disk space. For additional release information, see the

AIX 5L Release Notes.

2. Make sure your hardware installation is complete, including all external devices. See the documentation that came with your system unit for installation instructions.

3. If the system is currently installed, make a backup copy of your system software and data if you are installing over an existing version of AIX. For instructions on how to create a system backup, refer to the Creating System Backups section in the AIX 5L Version


4. If your system needs to communicate with other systems and access their resources, make sure you have the following information before proceeding with installation:

Network Interface Adapter

Host Name

IP Address

Network Mask

Nameserver

Domain Name

Gateway

The interface is created on the adapter.

______._______._______._______

______._______._______._______

______._______._______._______

______._______._______._______


1. Insert the AIX Volume 1 CD into the CD–ROM device.

2. Make sure all external devices attached to the system (such as CD–ROM drives, tape drives, DVD drives, and terminals) are turned on. Only the CD–ROM drive from which you will install AIX should contain the installation media.

3. Power on the system.

4. When the system beeps twice, press F5 on the keyboard (or 5 on an ASCII terminal). If you have a graphics display, you will see the keyboard icon on the screen when the beeps occur. If you have an ASCII terminal (also called a tty terminal), you will see the

New and Complete Overwrite Installation

2-1

word keyboard when the beeps occur. The system will now boot from the installation media.

Note:

If your system does not boot using the F5 key (or the 5 key on an ASCII terminal), refer to your hardware documentation for information on how to get your system to boot from an AIX product CD.

5. Select the system console by pressing F1 (or 1 on an ASCII terminal) and press Enter. If you have more than one display or terminal, follow the instructions on the display or terminal to select one as the console.

6. Select the language for the BOS Installation menus by typing the corresponding number in the Choice field. Press Enter to open the Welcome to Base Operating System

Installation and Maintenance screen.

7. Type 2 to select 2 Change/Show Installation Settings and Install in the Choice field and press Enter.

Welcome to Base Operating System

Installation and Maintenance

Type the number of your choice and press Enter. Choice is

indicated by >>>.

1 Start Install Now with Default Settings

>>> 2 Change/Show Installation Settings and Install

3 Start Maintenance Mode for System Recovery

88 Help ?

99 Previous Menu

>>> Choice [1]: 2

Step 3. Set and Verify Installation Settings

1. In the Installation and Settings screen, verify the installation settings are correct by checking the method of installation ( New and Complete Overwrite), the disk or disks you want to install, the primary language environment settings, and the installation options.

A summary of selected options displays. Confirm your selections and press Enter to begin the BOS installation. The system automatically reboots after installation is complete. Go to Step 4. Configure the System after Installation on page 2-4.

Otherwise, go to sub–step 2.

2. To change the System Settings, which includes the method of installation and disk where you want to install, type 1 in the Choice field and press Enter.

Installation and Settings

Either type 0 and press Enter to install with current settings,

or type the

number of the setting you want to change and press Enter.

1 System Settings:

Method of Installation.............New and Complete

Overwrite

Disk Where You Want to Install.....hdisk0

>>> Choice [0]: 1

2-2


3. Type 1 for New and Complete Overwrite in the Choice field and press Enter. The

Change Disk(s) Where You Want to Install screen now displays.

Change Disk(s) Where You Want to Install

Type one or more numbers for the disk(s) to be used for

installation and press

Enter. To cancel a choice, type the corresponding number and

Press Enter.

At least one bootable disk must be selected. The current choice

is indicated

by >>>.

Name Location Code Size(MB) VG Status Bootable

1 hdisk0 04–B0–00–2,0 4296 none Yes

2 hdisk1 04–B0–00–5,0 4296 none Yes

3 hdisk2 04–B0–00–6,0 12288 none Yes

>>> 0 Continue with choices indicated above

66 Disks not known to Base Operating System Installation

77 Display More Disk Information

88 Help ?

99 Previous Menu

>>> Choice [0]:

4. Select the disk or disks you want to install by typing the number that corresponds to the hard disk name and pressing Enter. The disk will now be selected as indicated by >>>.

Do this for each disk that you want to be part of the AIX root volume group. To unselect the destination disk, type the number again and press Enter.

5. Complete the disk selection by typing a 0 in the Choice field and press Enter. The

Installation and Settings screen displays with New and Complete Overwrite as the method of installation and the user selected disks.

6. To change the Primary Language Environment Settings, type 2 in the Choice field and press Enter. Type the number that corresponds to the Cultural Convention,

Language, and Keyboard for your selection and press Enter.

7. To change the More Options, type 3 in the Choice field and press Enter. Among the installation options available to you in AIX 5.2, you can:

– Change the desktop application.

– Enable or disable the Trusted Computing Base option.

– Enable or disable the Controlled Access Protection Profile (CAPP) and Evaluation

Assurance Level 4+ (EAL4+) option.

– Enable the 64–bit kernel.

– Enable the Enhanced Journaled File System (JFS2).

– Install graphics software.

– Install the documentation services software.

For more information about the installation options available in AIX 5.2, see the

Advanced Options section in the AIX 5L Version 5.2 Installation Guide and Reference.

New and Complete Overwrite Installation

2-3

8. Verify that the selections are correct in the Overwrite Installation Summary screen, as follows:

Overwrite Installation Summary

Disks: hdisk0

Cultural Convention: en_US

Language: en_US

Keyboard: en_US

64 Bit Kernel Enabled: No

JFS2

File Systems

Created: No

Desktop: CDE

Enable System Backups to install any system: Yes

Optional Software being installed:

>>> 1 Continue with Install

88 Help ?

99 Previous Menu

>>> Choice [1]:

9. Press Enter to begin the BOS installation. The system automatically reboots after installation is complete.

Step 4. Configure the System after Installation

1. On systems with a graphics display, after a new and complete overwrite installation, the

Configuration Assistant opens. On systems with an ASCII display, after a new and complete overwrite installation, the Installation Assistant opens.

2. Select the Accept Licenses option to accept the electronic licenses for the operating system.

3. Set the date and time, set the password for the administrator (root user), and configure network communications (TCP/IP).

Use any other options at this time. You can return to the Configuration Assistant or the

Installation Assistant by typing configassist or smitty assist at the command line.

4. Select Exit the Configuration Assistant and select Next. Or, press F10 (or ESC+0 ) to exit the Installation Assistant.

5. If you are in the Configuration Assistant, select Finish now, and do not start

Configuration Assistant when restarting AIX and select Finish.

At this point, the new and complete overwrite BOS installation is complete and the initial configuration of the system is complete.

2-4


Chapter 3. Migration Installation

Use the following steps to migrate your current version of the operating system to AIX 5.2.

•


•

Step 2. Boot from the AIX Product CD on page 3-2

•

Step 3. Verify Migration Installation Settings and Begin Installation on page 3-2

•

Step 4. Verify System Configuration after Installation on page 3-3

For more information on Migration Installation, refer to the Migration Installation section in the AIX 5L Version 5.2 Installation Guide and Reference.

Refer to the Network Installation Management (NIM) section in the AIX 5L Version 5.2

Installation Guide and Reference, if you are performing a network installation of AIX.

Attention: This procedure requires shutting down and reinstalling the base operating system. Whenever you reinstall any operating system, schedule your downtime when it least impacts your workload to protect yourself from a possible loss of data or functionality.

Before you perform a migration installation, ensure you have reliable backups of your data and any customized applications or volume groups. For instructions on how to create a system backup, refer to Creating System Backups in the AIX 5L Version 5.2 Installation

Guide and Reference.


1. Ensure that the root user has a primary authentication method of SYSTEM. You can check this condition by typing the following command:

# lsuser –a auth1 root If needed, change the value by typing the following command:

# chuser auth1=SYSTEM root

2. Before you begin the installation, other users who have access to your system must be logged off.

3. Verify that your applications will run on AIX 5.2. Also, check if your applications are binary–compatible with AIX 5.2. If your system is an application server, verify that there are no licensing issues. Refer to your application documentation or provider to verify on which levels of AIX your applications are supported and licensed.

4. Verify that all currently installed software is correctly entered in the Software Vital

Product Database (SWVPD), by using the lppchk command. To verify that all filesets have all required requisites and are completely installed, type the following:

# lppchk –v

5. Check that your hardware microcode is up–to–date.

6. All requisite hardware, including any external devices (such as tape drives or

CD/DVD–ROM drives), must be physically connected and powered on. If you need further information, refer to the hardware documentation that accompanied your system.

7. Use the errpt command to generate an error report from entries in the system error log.

To display a complete detailed report, type the following:

# errpt –a

8. There must be adequate disk space and memory available. AIX 5.2 requires 128 MB of memory and 2.2 GB of physical disk space. For additional release information, see the

AIX 5.2 Release Notes.

Migration Installation

3-1

9. Make a backup copy of your system software and data. For instructions on how to create a system backup, refer to the Creating System Backups section in the AIX 5L Version


10.Turn on attached devices if they are not already on.


1. Insert the AIX Volume 1 CD into the CD–ROM or DVD–ROM device.

2. Reboot the system by typing the following command:

# shutdown –r

3. When the system beeps twice, press F5 on the keyboard (or 5 on an ASCII terminal). If you have a graphics display, you will see the keyboard icon on the screen when the beeps occur. If you have an ASCII terminal (also called a tty terminal), you will see the word keyboard when the beeps occur.

Note:

If your system does not boot using the F5 key (or the 5 key on an ASCII terminal), refer to your hardware documentation for information on how to get your system to boot from an AIX product CD.

Select the system console by pressing F1 (or 1 on an ASCII terminal) and press Enter.

Select a language for the BOS Installation menus by typing the corresponding number at the Choice prompt and press Enter. The Welcome to Base Operating

System Installation and Maintenance menu opens.

Type 2 to select 2 Change/Show Installation Settings and Install in the Choice field and press Enter.

Welcome to Base Operating System

Installation and Maintenance

Type the number of your choice and press Enter. Choice is indicated by

>>>.

1 Start Install Now with Default Settings

2 Change/Show Installation Settings and Install

3 Start Maintenance Mode for System Recovery

88 Help ?

99 Previous Menu

>>> Choice [1]: 2

Step 3. Verify Migration Installation Settings and Begin

Installation

1. Verify that Migration is the method of installation. If Migration is not the method of installation, then select it. Select the disk or disks you want to install.

1 System Settings:

Method of Installation.............Migration

Disk Where You Want to Install.....hdisk0

2. Select Primary Language Environment Settings (AFTER Install).

3. Type 3 to select More Options and press Enter. To use the Help menu to learn more about the options available during a migration installation, type 88 and press Enter in the

More Options menu . For more information about the installation options available in

3-2


AIX 5.2, see the Advanced Options section in the AIX 5L Version 5.2 Installation Guide and Reference.

4. Verify the selections in the Migration Installation Summary screen and press Enter.

5. When the Migration Confirmation menu displays, follow the menu instructions to list system information or continue with the migration by typing 0 and pressing Enter.

Migration Confirmation

Either type 0 and press Enter to continue the installation, or type the

number of your choice and press Enter.

1 List the saved Base System configuration files which will not be

merged into the system. These files are saved in /tmp/bos.

2 List the filesets which will be removed and not replaced.

3 List directories which will have all current contents removed.

4 Reboot without migrating.

Acceptance of license agreements is required before using system.

You will be prompted to accept after the system reboots.

>>> 0 Continue with the migration.

88 Help ?

+––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––

WARNING: Selected files, directories, and filesets (installable options)

from the Base System will be removed. Choose 2 or 3 for more information.

>>> Choice[0]:

After migration is complete, access this information from the /tmp/bos directory.

Step 4. Verify System Configuration after Installation

After the migration is complete, the system will reboot. Configure the system, as follows:

1. On systems with a graphics display, after a migration installation, the Configuration

Assistant opens. On systems with a ASCII display, after a migration installation, the

Installation Assistant opens.

For more information on the Configuration Assistant or the Installation Assistant, see the

Configuring the Operating System section in the AIX 5L Version 5.2 Installation Guide and Reference.

2. Select the Accept Licenses option to accept the electronic licenses for the operating system.

3. Verify the administrator (root user) password and network communications (TCP/IP) information.

Use any other options at this time. You can return to the Configuration Assistant or the

Installation Assistant by typing configassist or smitty assist at the command line.

4. Select Exit the Configuration Assistant and select Next. Or, press F10 (or ESC+0 ) to exit the Installation Assistant.

5. If you are in the Configuration Assistant, select Finish now, and do not start

Configuration Assistant when restarting AIX and select Finish.

When the login prompt displays, log in as the root user to perform system administration tasks.

Migration Installation

3-3

3-4


Technical publication remarks form

Title : ESCALA AIX 5L Operating System Installation Getting Started

Reference Nº :

ERRORS IN PUBLICATION

86 A2 09EG 00 Date: October 2002

SUGGESTIONS FOR IMPROVEMENT TO PUBLICATION

Your comments will be promptly investigated by qualified technical personnel and action will be taken as required.

If you require a written reply, please include your complete mailing address below.

Date : NAME :

COMPANY :

ADDRESS :

Please give this technical publication remarks form to your BULL representative or mail to:

Bull - Documentation D

ept.

1 Rue de Provence

BP 208

38432 ECHIROLLES CEDEX

FRANCE [email protected]

Technical publications ordering form

To order additional publications, please fill in a copy of this form and send it via mail to:

BULL CEDOC

357 AVENUE PATTON

B.P.20845


FRANCE

Phone:

FAX:

E-Mail:

CEDOC Reference #

_ _ _ _ _ _ _ _ _ [ _ _ ]

Designation

_ _ _ _ _ _ _ _ _ [ _ _ ]

_ _ _ _ _ _ _ _ _ [ _ _ ]

_ _ _ _ _ _ _ _ _ [ _ _ ]

_ _ _ _ _ _ _ _ _ [ _ _ ]

_ _ _ _ _ _ _ _ _ [ _ _ ]

_ _ _ _ _ _ _ _ _ [ _ _ ]

_ _ _ _ _ _ _ _ _ [ _ _ ]

_ _ _ _ _ _ _ _ _ [ _ _ ]

_ _ _ _ _ _ _ _ _ [ _ _ ]

_ _ _ _ _ _ _ _ _ [ _ _ ]

_ _ _ _ _ _ _ _ _ [ _ _ ]

[ _ _ ]

: The latest revision will be provided if no revision number is given.

+33 (0) 2 41 73 72 66

+33 (0) 2 41 73 70 66 [email protected]

Qty

Date: NAME:

COMPANY:

ADDRESS:

PHONE:

E-MAIL:

For Bull Subsidiaries:

Identification:

For Bull Affiliated Customers:

Customer Code:

For Bull Internal Customers:

Budgetary Section:

For Others: Please ask your Bull representative.

FAX:

BULL CEDOC

357 AVENUE PATTON

B.P.20845


FRANCE

REFERENCE

86 A2 09EG 00

Utiliser les marques de découpe pour obtenir les étiquettes.

Use the cut marks to get the labels.

AIX

AIX 5L Operating

System Installation:

Getting Started

86 A2 09EG 00

AIX

AIX 5L Operating


Getting Started

86 A2 09EG 00

AIX

AIX 5L Operating


Getting Started

86 A2 09EG 00

No results
