Note:
The default value for the parameter figuration, the setting value for
State transition 5
mode "2 – Ramp". For configurations with torque control, the default value is operation mode "0 - Coast to stop". In a switch-over of the con-
State transition 5
392 is operation
392 is also altered if necessary.
If transition 5 has been triggered with
Braking time
State transition 5
632 parameterized for the DC brake.
392 = "1 - DC brake“, a new control word is only accepted after the completion of the transition process. The change of state from "Operation enabled“ to "Ready“ is done after the expiry of the time
If the parameter relevant.
State transition 5
can be set back to 0x0F during the stoppage of the drive. In this way, the drive runs back up to its set reference value and remains in the state "Operation enabled“.
The change of state from "Operation enabled“ to "Ready“ is done after the set switchoff threshold has been reached and expiry of the set holding time (equivalent to the behavior in a quick stop). In this, the parameters fmax) and
10.2.4
Holding time
392 = "2 - Ramp“ has been set, the control word
Switch-off threshold
Control via remote contacts
637 (percent of
638 (holding time after switch-off threshold reached) are
In the operation mode
Local/Remote
412 = "2 - Control via remote contacts" the frequency inverter is controlled via the control word in PZD1, with the bits 0 to 5 corresponding to the contact inputs S1IND to S6IND. In addition, two virtual contact inputs S7IND and S8IND are available. These virtual contact inputs are not supported as a standard feature and are reserved for special applications. In the use of the remote contact, the frequency inverter behaves in the same way as in control via the hardware contact inputs. The meaning of these inputs can be seen from the operating instructions.
Note:
Release is only possible if the hardware release is available via digital input S1IND.
State machine:
The values in the states report the feedback message via the state word (Bit 0 to 6) in
PZD1.
Power on
Initialisation
06/05
06/05
Ready
0x23
Enable on
Operation enabled
0x27
Enable off
Quitt fault
Fault
0x08
from any state
25
25
26
Note:
The inputs set via the control word can be observed with the help of parameter
Digital Inputs
250. Digital input S1IND is only displayed as being set if the hardware release is available and the control word / Bit 0 has been set.
If the data set switch-over is used, please make sure that the parameter
Local/Remote
412 is set to operation mode "2 - Control via remote contacts" in all the data sets used.
Bit No.
0
Control word
Name
S1IND / FUF
1 S2IND
State word
Bit No.
Name
0 Ready to switch on
1 Ready
2 S3IND
3 S4IND
4 S5IND
2 Operation enabled
3 Fault
4 Voltage-inhibit
5
6
9
10
11
S6IND
S7IND
7 S8IND
8 -
-
-
-
12
5 Quick stop
6 Switch on inhibit
7 Warning
8 -
9 Remote
10 Reference value reached
11 Limit value reached
IW1 Î chapter 10.2.6
14
15 - 15 Warning 2
State
Ready
Operation
Fault
State word
HEX (*) Bit 6 Bit 5 Bit 3 Bit 2 Bit 1 Bit 0
0x23 0 1 0 0 1 1
0x27 0 1 0 1 1 1
0x08 0 x 1 0 0 0
(*) without considering bits 7 to bit 15
Note:
A fault occurring leads to a switch-over to the "Fault" state.
A fault can only be acknowledged 15 seconds after the occurrence of the fault, as a blocking time is active internally.
Warning bit "Bit No. 7" can be set at any time. It displays an device-internal warning message. The evaluation of the warning available is done by reading out the warning status with the parameter
Warnings
270.
The
(
Local/Remote
412 = 2) has been set and the hardware release is available (S1IND
= 1). Only then can the frequency inverter be controlled via the control word.
The bit Reference value reached "Bit No. 10" is set when the reference value specified has been reached. In the special case of power failure regulation, the bit is also set if the power failure regulation has reached the frequency 0 Hz (see operating instructions). For "Reference value reached“ there is a hysteresis (tolerance range), which can be set via the parameter structions).
max. Control deviation
549 (see operating in-
The bit Limit value active "Bit No. 11" displays that an internal limit is active. This can, for example, be the present current limit, the torque limit or the overvoltage limit. All the functions lead to the reference value being quit or not reached.
The bit Warning 2 "Bit No. 15" reports a warning which leads to a fault switch-off of the frequency inverter within a short time. This bit is set if there is a warning for motor temperature, heat sink/inside temperature, Ixt monitoring or mains phase failure.
26 06/05
06/05
