LC-37GD6U
LC-32GD6U
LC-26GD6U
LIQUID CRYSTAL TELEVISION
TÉLÉVISEUR ACL
TELEVISOR CON PANTALLA DE CRISTAL LIQUIDO
OPERATION MANUAL
MODE D’EMPLOI
MANUAL DE OPERACIÓN
LC-37GD6U
LC-32GD6U
LC-26GD6U
LIQUID CRYSTAL TELEVISION
ENGLISH
OPERATION MANUAL
• The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly from the actual operations.
• Some items may be grayed out. They are not selectable.
• The examples used throughout this manual are based on the LC-32GD6U model.
IMPORTANT:
To aid reporting in case of loss or theft, please record the TV’s model and serial numbers in the space provided. The numbers are located at the rear of the
TV.
Model No.:
Serial No.:
IMPORTANT INFORMATION
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrow-head symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within a triangle is intended to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.
2
IMPORTANT INFORMATION
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
CAUTION:
DO NOT PLACE THIS PRODUCT ON AN UNSTABLE CART, STAND, TRIPOD, BRACKET, OR
TABLE. THE PRODUCT MAY FALL CAUSING SERIOUS PERSONAL INJURY AND SERIOUS
DAMAGE TO THE PRODUCT. USE ONLY WITH A CART, STAND, TRIPOD, BRACKET, OR TABLE
RECOMMENDED BY THE MANUFACTURER OR SOLD WITH THE PRODUCT. FOLLOW THE
MANUFACTURER’S INSTRUCTIONS WHEN INSTALLING THE PRODUCT AND USE MOUNTING
ACCESSORIES RECOMMENDED BY THE MANUFACTURER. A PRODUCT AND CART
COMBINATION SHOULD BE MOVED WITH CARE. QUICK STOPS, EXCESSIVE FORCE, AND
UNEVEN SURFACES MAY CAUSE THE PRODUCT AND CART COMBINATION TO OVERTURN.
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.
CAUTION:
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded cables and connectors for connections.
DECLARATION OF CONFORMITY
SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-37GD6U
SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-32GD6U
SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-26GD6U
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
RESPONSIBLE PARTY:
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
TEL: 1-800-BE-SHARP
For Business Customers: URL http://www. sharpusa. com
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
“Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the
National Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”
This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance: www.eia.org
DEAR SHARP CUSTOMER
Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years of trouble-free operation of your product, please read the Important Safety Instructions carefully before using this product.
IMPORTANT SAFETY INSTRUCTIONS
Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your Liquid Crystal Television, please read the following precautions carefully before using the product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) Power Sources — This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.
16) Overloading — Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.
17) Object and Liquid Entry — Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.
18) Damage Requiring Service — Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a) When the AC cord or plug is damaged, b) If liquid has been spilled, or objects have fallen into the product, c) If the product has been exposed to rain or water, d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation, e) If the product has been dropped or damaged in any way, and f) When the product exhibits a distinct change in performance – this indicates a need for service.
19) Replacement Parts — When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
20) Safety Check — Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.
21) Wall or ceiling mounting — When mounting the product on a wall or ceiling, be sure to install the product according to the method recommended by the manufacturer.
3
IMPORTANT SAFETY INSTRUCTIONS
• Water and Moisture — Do not use this product near water – for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the manufacturer’s instructions are followed.
• The Liquid Crystal panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the panel breaks.
• Heat — The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.
• The Liquid Crystal panel is a very high technology product with 3,147,264 thin film transistors, giving you fine picture details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the performance of your product.
Precautions when transporting the Display
When transporting the Display, never carry it by holding onto the speaker. Be sure to always carry the Display by two people holding it with two hands—one hand on each side of the Display.
4
• Lightning — For added protection for this television equipment during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the equipment due to lightning and power-line surges.
• Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
IMPORTANT SAFETY INSTRUCTIONS
• Outdoor Antenna Grounding — If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, Iocation of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H) NEC —NATIONAL ELECTRICAL CODE
• To prevent fire, never place any type of candle or flames on the top or near the TV set.
• To prevent fire or shock hazard, do not expose this product to dripping or splashing.
No objects filled with liquids, such as vases, should be placed on the product.
• To prevent fire or shock hazard, do not place the AC power cord under the TV set or other heavy items.
• Turn off the main power and unplug the AC cord from the wall outlet before handling.
• Use a soft cloth and gently wipe the surface of the display panel. Using a hard cloth may scratch the panel surface.
• Use a soft damp cloth to gently wipe the panel when it is really dirty.
(It may scratch the panel surface when wiped strongly.)
• If the panel is dusty, use an anti-static brush, which is commercially available, to clean it.
• To protect the panel, do not use a dirty cloth, liquid cleaners or chemical cloth to clean it, such materials may damage the panel surface.
5
6
Contents
IMPORTANT INFORMATION ……………………… 1
DEAR SHARP CUSTOMER ………………………… 3
IMPORTANT SAFETY INSTRUCTIONS …………… 3
Contents ……………………………………………… 6
Trademarks …………………………………………… 7
COPYRIGHT AND LICENSE NOTICE …………… 7
Patent Notice ………………………………………… 7
Supplied accessories ……………………………… 8
Preparation …………………………………………… 9
Where to place the TV …………………………… 9
Setting the TV ………………………………… 10
Removing speakers …………………………… 11
Removing the stand …………………………… 12
Setting the Display on the wall ……………… 12
Inserting the batteries ………………………… 13
Using the remote control unit ………………… 13
Cautions regarding remote control unit … 13
Part names ………………………………………… 14
Display ………………………………………… 14
Remote control unit …………………………… 16
Watching TV ……………………………………… 17
Antennas ……………………………………… 17
Cable TV/VCR connection …………………… 17
Outdoor antenna connection ………………… 19
Turning on the power ………………………… 20
Turning off the power ………………………… 20
Initial setup ……………………………………… 21
Changing channels Analog-TV ……………… 22
Changing channels Digital-TV ……………… 22
Changing volume/sound ……………………… 23
Setting MTS/SAP stereo mode ……………… 24
Setting Digital broadcasting audio mode …… 24
Connecting Digital Cable Module …………… 25
Basic adjustment settings ……………………… 26
AV input mode menu items …………………… 26
PC input mode menu items …………………… 27
EZ setup ………………………………………… 27
Channel setup ………………………………… 28
Antenna Setup-DIGITAL ……………………… 30
Favorite channel setting ……………………… 31
Language setting ……………………………… 31
Picture adjustments …………………………… 32
OPC setting ………………………………… 33
C.M.S. (Color Management System) …… 33
Color temperature ………………………… 34
Black ……………………………………… 34
3D-Y/C ……………………………………… 34
Monochrome ……………………………… 35
Film mode (3:2 pull-down) ……………… 35
I/P Setting ………………………………… 35
Sound adjustment ……………………………… 36
Dolby virtual …………………………………… 36
Power control …………………………………… 37
Power control for AV source ……………… 37
Power control for PC source ……………… 37
Digital Setup …………………………………… 38
Video Setup ………………………………… 38
Audio Setup ……………………………… 39
Using memory card ……………………………… 40
Important notes on using memory card …… 40
Card Setup mode menu items ……………… 42
Recording a still image ……………………… 44
Displaying a still image ……………………… 44
Displaying slide show ………………………… 44
Setting/unprotecting Slide Show …………… 45
My Program …………………………………… 45
Audio Select …………………………………… 45
Protecting/unprotecting still picture files …… 46
Deleting a still image file ……………………… 46
Deleting all still image files …………………… 46
Recording a motion picture …………………… 47
Displaying a motion picture ………………… 47
Rec. Mode ……………………………………… 47
Pre Record ……………………………………… 48
Repeat Play …………………………………… 48
Protecting/unprotecting motion picture files … 48
Deleting a motion picture file ………………… 49
Deleting all motion picture files ……………… 49
Format …………………………………………… 49
Using external equipment ……………………… 50
Displaying an external equipment image …… 50
Connecting a DVD player …………………… 51
Connecting a VCR …………………………… 52
Connecting a game console or camcorder ……………………………… 52
Connecting a Digital TV STB ………………… 53
Connecting HDMI equipment …………… 54
Displaying an image from HDMI equipment ………………………………… 54
Connecting a PC ……………………………… 55
Connecting D-VHS Decks
(i.LINK connection) ……………………… 56
About i.LINK
……………………………… 56 i.LINK connection ………………………… 56
Connecting two or more D-VHS decks … 56
Setting the recording mode ……………… 57
Setting the Standby Mode ……………… 57
Selecting a D-VHS deck (i.LINK) ………… 58
Disabling the TV’s operation of a D-VHS deck (i.LINK) ………………… 58
Deleting a preset D-VHS deck (i.LINK) … 59
Controlling an i.LINK device ……………… 59
Automatic input switching to i.LINK
…… 60
Recording digital programs with a D-VHS deck (i.LINK) …………… 61
Useful adjustment settings ……………………… 62
Image position (AV input mode only) ……… 62
Moving the picture on the screen …………… 62
Connecting external speakers ……………… 63
Audio Quality Control ………………………… 64
Auto Sync. adjustment (PC input mode only) … 65
Fine Sync. adjustment (PC input mode only) … 65
Input Select …………………………………… 66
Input label ……………………………………… 67
Picture Flip ……………………………………… 67
AV MODE ……………………………………… 68
View mode for 4:3 Programs ………………… 68
View mode (for PC input mode) ……………… 69
Input signal (for PC input mode) …………… 70
Digital Noise Reduction ……………………… 70
Audio only ……………………………………… 70
Output Select …………………………………… 71
Quick shoot …………………………………… 71
Sleep timer ……………………………………… 71
Title Display Type ……………………………… 72
Closed caption ………………………………… 73
Caption Size ……………………………… 74
Font Style …………………………………… 74
Foreground Color ………………………… 75
Foreground Opacity ……………………… 75
Background Color ………………………… 75
Background Opacity ……………………… 76
Contents
Character Edge …………………………… 76
Secret number setting for parental control
(AV input mode only) ……………………… 77
Parental control (setting V-CHIP level) ……… 79
How to temporarily release the V-CHIP BLOCK ……………………… 83
Reactivating the temporarily released
V-CHIP BLOCK …………………………… 83
Center Channel Input ………………………… 84
Other viewing options …………………………… 85
Viewing a list of Digital broadcast channels … 85
Viewing information of the program ………… 85
Twin picture functions ………………………… 86
Presetting remote control function …………… 86
Appendix ………………………………………… 92
Troubleshooting ………………………………… 92
PC compatibility chart ………………………… 93
RS-232C port specifications ………………… 94
Specifications ………………………………… 96
Optional accessory …………………………… 96
Dimensional drawings …………………………… 97
Trademarks
• Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.
• Manufactured under license from BBE Sound, Inc.
Licensed by BBE Sound, Inc. under USP4638258, 5510752 and 5736897. BBE and BBE symbol are registered trademarks of BBE Sound, Inc.
• “HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.”
• CableCARD™ is a trademark of Cable Television Laboratories, Inc.
COPYRIGHT AND LICENSE NOTICE
• It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior permission be obtained from copyright owners whenever necessary.
• This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited. U. S. Patent Nos. 4,631,603; 4,577,216; 4,819,098; 4,907,093; 5,315,448; 6,381,747; and 6,516,132.
• This digital television is capable of receiving analog basic, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card provided by your cable operator is required to view encrypted digital programming. Certain advanced and interactive digital cable services such as videoon-demand, a cable operator's enhanced program guide and data-enhanced television services may require the use of a set-top box. For more information call your local cable operator.
7
Supplied accessories
Make sure the following accessories are provided with the product.
Remote control unit (g1) “AAA” size battery (g2) AC cord (g1)
RRMCGA264WJSA
Page 13
RF cable (g1)
Page 13
Cable clamp (g1)
Only included with the LC-32GD6U and LC-37GD6U.
QACCDA019WJPZ
Page 10
Operation manual (g1)
LC-37GD6U
LC-32GD6U
LC-26GD6U
8
QCNW-A342WJZZ
Pages 18 and 19
Bracket unit (g1)
The LC-26GD6U is shipped with the speakers attached.
*
LHLDW0110CEZZ
Page 10
LC-37GD6U/LC-32GD6U:
GCOVAA856WJKB
Page 11
* The parts number for screws
Parts number
XEBS940P12000
Bracket unit
** The parts number for speaker unit
Angle
LC-37GD6U/
LC-32GD6U
LC-26GD6U
LHLDZA375WJKA
GCOVAA789WJKA
NOTE
• Always use the AC cord supplied with the LCD-TV.
Color
BLACK
—
—
Q’ty
2
2
2
TINS-B241WJZZ
Preparation
Where to place the TV
First select the location where to place the TV.
1
Selecting the location of the TV
2
Display
Setting the TV in place
Handling the Display
CAUTION
• Select a place with no direct sunlight and good ventilation.
• Do not remove the stand and speaker from the Display unless using an optional bracket to mount it.
• Keep enough space above and behind the Display.
• When you move TV, carry out by two people or more than it.
• When you move the Display, hold the portion of the Display, not the speaker.
4 inches
(10 cm) or more
CAUTION
Adjust the screen with both hands. Put one hand on the Display and tilt the screen while steadying the stand with your other hand.
LC-37GD6U
LC-32GD6U
LC-26GD6U
Maximum Degree of Adjustment
Up Down Left/Right
6˚
6˚
10˚
2˚
2˚
5˚
10˚ each
10˚ each
25˚ each
9
Preparation
Setting the TV
After putting the Display in place, connect the AC cord. Use the cable clamp for bundling the cables.
1
Removing the terminal cover
Display (rear view)
Press down the hooks to remove the cover toward you.
10
2
Connecting the AC cord to the Display
AC cord (with
Ferrite core)
3
Bundling the cables with the clamp
Put the Ferrite core in the space as shown in the figure. If the AC cord is not put in properly, the terminal cover may not close.
Cable clamp for LC-37GD6U/LC-32GD6U for LC-26GD6U
CAUTION
• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE
AC CORD CONNECTED.
Preparation
Removing speakers
1 4
Unfasten the screw used to secure the speaker bracket.
2
Unfasten the screws.
Take off the speaker terminal cover.
3
Disconnect the cable from the speaker.
CAUTION
• Do not remove the stand and speaker from the Display unless using an optional bracket to mount it.
• Before performing work spread cushioning over the base area to lay the Display on. This will prevent it from being damaged.
NOTE
• To attach the speakers, perform the steps in reverse order.
11
Preparation
Removing the stand
Before detaching (or attaching) stand, unplug the AC cord from the AC input terminal.
CAUTION
• Do not remove the stand from the Display unless using an optional wall mount bracket to mount it.
Before attaching/detaching stand
• Before performing work make sure to turn off the TV.
• Before performing work spread cushioning over the base area to lay the Display on. This will prevent it from being damaged.
1 2
12
Unfasten the four screws used to secure the stand in place.
Detach the stand from the Display.
(Hold the stand so it will not drop from the edge of the base area.)
CAUTION
• Do not remove the stand and speaker from the Display unless using an optional bracket to mount it.
NOTE
• To attach the stand, perform the above steps in reverse order.
Setting the Display on the wall
CAUTION
• Installing the Liquid Crystal Television requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper mounting or mounting that results in accident or injury.
Using an optional bracket to mount the Display
• You can ask a qualified service personnel about using an optional AN-37AG2 or AN-LCGWF bracket to mount the Display to the wall. The AN-37AGZ is compatible with the LC-37GD6U and LC-32GD6U only.
• Carefully read the instructions that come with the bracket before beginning work.
Hanging on the wall
AN-37AG2 wall mount bracket. (See the bracket instructions for details.)
About setting the Display angle
LC-37GD6U/LC-32GD6U
LC-37GD6U
Angle of Display
With Speakers
Removed
10˚
With Speakers
Attached
10˚
LC-32GD6U
20˚ 20˚
Vertical mounting
Preparation
Inserting the batteries
If the remote control fails to operate Liquid Crystal Television functions, replace the batteries in the remote control unit.
1
Open the battery cover.
2
Insert two “AAA” size batteries
(supplied with the product).
3
Close the battery cover.
• Place the batteries with their terminals corresponding to the (e) and (f) indications in the battery compartment.
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
• Place the batteries with their terminals corresponding to the (e) and (f) indications.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical leakage in old batteries.
• Remove batteries as soon as they are worn out. Chemicals that leak from batteries can cause a rash. If you find any chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
• If you will not be using the remote control unit for an extended period of time, remove batteries from it.
Using the remote control unit
Use the remote control unit by pointing it towards the remote control sensor on the Display. Objects between the remote control unit and the remote control sensor may prevent proper operation.
Cautions regarding remote control unit
• Do not expose the remote control unit to shock.
In addition, do not expose the remote control unit to liquids, and do not place in an area with high humidity.
• Do not install or place the remote control unit under direct sunlight.
The heat may cause deformation of the remote control unit.
• The remote control unit may not work properly if the remote control sensor on the Display is under direct sunlight or strong lighting. In such cases, change the angle of the lighting or the Display, or operate the remote control unit closer to the remote control sensor.
13
Part names
* The examples used throughout this manual are based on the LC-32GD6U model.
Display
VOLUME buttons
(VOLl/k )
CHANNEL buttons
(CH s/r)
INPUT button
POWER button
14
Remote control sensor Headphone jack
OPC sensor CARD indicator
POWER indicator OPC indicator
SLEEP indicator
*OPC: Optical Picture Control
(See page 33.)
Part names
Display
LC-37GD6U
LC-32GD6U
INPUT 3 terminals
INPUT 1 terminals
MONITOR OUTPUT terminals
INPUT 2 terminals
LC-26GD6U
MONITOR
OUTPUT terminals
INPUT 3 terminals
INPUT 1 terminals i.LINK terminals
CableCARD slot
DIGITAL IN terminal
INPUT 2 terminals
AC INPUT terminal
EXTERNAL SPEAKER terminals
DIGITAL AUDIO OUTPUT terminal
SYSTEM RESET**
CENTER CHANNEL
INPUT terminal
* This terminal
INPUT 5 terminals looks different on the LC-26GD6U.
INPUT 4 terminal
DC OUTPUT terminal
(Terminal for expanded functionality in the near future.)
RS-232C terminal
RESET*
* Press RESET if the system cannot return to its
original state after performing various operations.
ANALOG A IN terminal
ANALOG A OUT terminal
• AV MODE resets to DYNAMIC (Fixed)
• TV channel returns to initial channel (Air:2ch, Cable:1 or 2ch)
• Twin picture resets to normal
• Audio setting initializes
• Dolby virtual resets to off
• Image position initializes
** Press SYSTEM RESET if the system does not operate after starting up.
ANALOG B IN terminal
NOTE
• Pressing RESET will not work if the System is in standby mode.
• Pressing RESET will not delete channel preset or secret number. See page 66 for clearing the secret number when you know it. See page 100 for initializing to the factory preset values when you forget your secret number.
15
16
Part names
Remote control unit
1 17
5
6
7
8
9
10
11
12
13
14
15
16
2
3
4
27
28
29
30
31
32
20
21
22
23
24
25
26
33
18
19
1
TV POWER: Switches the Liquid Crystal Television power on or Standby. (See page 20.)
2
DISPLAY: Displays the channel information.
3
SOURCE POWER: Turns the power of the external equipment on and off.
4
External equipment operational buttons: Operates the external equipment.
5
0 – 9: Sets the channel.
6
A-ANALOG-B: Each button selects the corresponding antenna.
7
VOL k
8
CARD: Switches to card mode.
9
INFO: Displays the program information screen. (See page 85.)
10
Virtual: Select Virtual Dolby Surround settings. (See page 23.)
11 EXIT: Turns off the menu screen.
12 SELECT: Selects the active screen. (See page 86.)
13 TWIN PICTURE: Sets the twin picture mode.
Press again to return to normal screen. (See page
86.)
14 SLEEP: Sets the sleep timer. (See page 71.)
15 AUDIO: Selects the MTS/SAP or the audio mode during malti audio broadcasts. (See page 24.)
16 i.LINK: Displays the i.LINK panel. (See page 58.)
17 FUNCTION: Switches the remote control for TV, CBL/
SAT, VCR, DVD and AUDIO operation. Indicator lights up for the current mode. (See page 87 to 91 for details.)
18
: When pressed all buttons on the remote control unit will light. The lighting will turn off if no operations are performed within about 5 seconds. This button is used for performing operations in dark places.
19 VIEW MODE: Selects the screen size. (See pages 68 and 69.)
20 FLASHBACK: Returns to the previous channel or input external mode. (See page 22.)
21 INPUT: Selects a Liquid Crystal Television input source.
(TV, INPUT 1, INPUT 2, INPUT 3, INPUT 4, INPUT 5, i.LINK, Card) (See pages 50 and 66.)
22 DIGITAL: Receives digital broadcasts.
23 CH
r
24 MUTE: Mutes the sound. (See page 23.)
25 CH LIST: Displays the channel list screen.
26 MENU: Displays the menu screen.
27 a/b/c/d: Selects a desired item on the screen.
28 RETURN: Returns to the previous menu screen.
29 FAVORITE CH
A, B, C, D: Selects four preset favorite channels in four different categories. (See page 31 for details.)
While watching, you can toggle the selected channels by pressing A, B, C and D.
30 FREEZE: Sets the still image. Press again to return to normal screen. (See page 86.)
31 CC: Displays captions during closed-caption source.
(See page 73.)
32 EDIT: Registers favorite channel.
33 AV MODE: Selects an audio or video setting. (See page 68.) (AV mode: STANDARD, MOVIE, GAME,
USER, DYNAMIC (Fixed), DYNAMIC. PC mode:
STANDARD, USER.)
Watching TV
Simple operations for watching a TV program
Antennas
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector, plug it into the antenna terminal at the rear of the TV set.
NOTE
• The antenna and the cable converter cannot be connected at the same time.
F-type connector
1. A 75-ohm system is generally a round cable with F-type connector that can easily be attached to a terminal without tools (Commercially available).
75-ohm coaxial cable (round)
2. A 300-ohm system is a flat “twin-lead” cable that can be attached to a 75-ohm terminal through a 300/75-ohm adapter (Commercially available).
300-ohm twin-lead cable (flat)
Cable TV/VCR connection
• Be sure to connect the antenna or the cable converter as follows. Signal reception may fail if improperly connected.
• Be sure to remember what kind of connection is made with your TV.
• The connection type will determine whether to select “Air” or “Cable” for both ANALOG-A and B when configuring “Air/
Cable” settings.
A-1. Connecting with cable TV Converter and VCR
Coaxial Antenna Cable (commercially available)
OUT IN
Cable TV converter
(commercially available) signal splitter
(commercially available)
Cable lead-in
Coaxial Antenna Cable (commercially available)
Audio Cable (commercially available)
Video Cable (commercially available)
VIDEO AUDIO OUT IN
VCR
NOTE
• Be sure to remember what kind of connection is made with your System.
• Shown here is the preferred method of connecting a VCR and CATV Converter to your TV if you are in an area with good signal reception. This way you can view either TV programs or VCR tapes and not be concerned about the position of the
VCR’s TV/VCR switch and you can enjoy stereo tape playback from a stereo VCR.
• While in Standby, no signal outputs from ANALOG-A OUT.
17
Watching TV
Cable TV/VCR connection (continued)
A-2. Connecting with cable converter using AUX terminals for audio and video output.
(If your cable TV converter has both RF OUTPUT and AUX terminals, it is recommended to connect it as shown in example A-1.)
Coaxial Antenna Cable (commercially available)
OUT
VIDEO AUDIO
IN signal splitter
(commercially available)
Cable lead-in
Cable TV Converter
RF Cable (Supplied)
Audio Cable (commercially available)
Video Cable (commercially available)
VIDEO AUDIO OUT IN
NOTE
VCR
• Be sure to remember what kind of connection is made with your TV.
• Shown here is the preferred method of connecting a VCR and CATV Converter to your TV if you are in an area with good signal reception. This way you can view either TV programs or VCR tapes and not be concerned about the position of the
VCR’s TV/VCR switch and you can enjoy stereo tape playback from a stereo VCR.
B.
Connecting with Cable Converter without VCR
Coaxial Antenna Cable (commercially available)
OUT IN
Cable TV converter
(commercially available) signal splitter
(commercially available)
Cable lead-in
18
Coaxial Antenna Cable
(commercially available)
NOTE
• Be sure to remember what kind of connection is made with your TV.
• Switching between ANALOG-A and ANALOG-B is possible by pressing the A-ANALOG-B button on the remote control.
• A good color picture depends on a good TV signal. So does good multi-channel sound. Ask your dealer for advice on how to install your outdoor antenna to receive the best possible signal.
• If you subscribe to Cable TV or have a central antenna for your building, you may not need an outdoor antenna.
Watching TV
C.
Connecting Antenna Cable with VCR
Coaxial Antenna Cable
(commercially available) signal splitter
(commercially available)
Cable lead-in
RF Cable (Supplied)
Audio Cable (commercially available)
Video Cable (commercially available)
VIDEO AUDIO OUT IN
VCR
NOTE
• Be sure to remember what kind of connection is made with your TV.
• Shown here is the preferred method of connecting a VCR to your TV if you are in an area with good signal reception. This way you can view either TV programs or VCR tapes and not be concerned about the position of the VCR’s TV/VCR switch and you can enjoy stereo tape playback from stereo VCR.
• If your lead cable is a 300-ohm twin-lead cable or UHF/VHF separate cable, use a 300/75-ohm adapter or combiner
(output side is 75-ohm coaxial) to connect to the TV (see below).
Outdoor antenna connection
Connecting Antenna Cable
Cable without a CATV converter
Cable TV lead-In
Combination
VHF/UHF antenna
Home Antenna terminal (75-ohm) or 75-ohm coaxial cable (round)
300-ohm twin-lead (flat)
300/75-ohm adapter
(commercially available)
Coaxial cable
(commercially available)
Separate VHF/UHF antenna
VHF
ANTENNA
UHF
ANTENNA
300-ohm twin-lead
Combiner
(commercially available)
300-ohm twin-lead
IN OUT or
75-ohm coaxial cable
NOTICE
F-type connector
75-ohm coaxial cable signal splitter
(commercially available)
RF Cable (Supplied)
F-type connector should be finger-tightened only.
When connecting the RF cable to the TV set, do not tighten
F-type connector with tools.
If tools are used, it may cause damage to your TV set.
(The breaking of internal circuit, etc.)
19
20
Watching TV
POWER indicator
Display
POWER
TV POWER
Turning on the power
Press POWER on the Display or press TV POWER on the remote control.
• POWER indicator (Blue): The TV is on. (After a few seconds, a window appears with sound.)
NOTE
• The initial setup starts when the TV powers on for the first time. If the TV has been turned on before, the EZ setup will not be invoked. See page
27 to try EZ setup from the Setup menu.
Turning off the power
Press POWER on the Display or press TV POWER on the remote control.
• The TV enters standby mode and the image on the screen disappears.
• The POWER indicator on the Display gradually turns off.
NOTE
• If you are not going to use this TV for a long period of time, be sure to remove the AC cord from the power outlet.
CAUTION
• Please do not unplug the AC cord when the POWER indicator is red.
Display status indicator
ON
Standby
OFF (Standby)
CableCARD is downloading data.
w/o CableCARD
Lighting (Blue)
Lights off
—
When CableCARD inserted
Lighting (Blue)
Lights off
Lighting (Red)
Watching TV
Initial setup
When you turn on the TV for the first time, it will automatically memorize the broadcasting channels where you live. Perform the following steps before you press TV POWER on the remote control unit.
1. Insert the batteries into the remote control unit. (See page 13.)
2. Connect the antenna cable to the Display. (See pages 17 to 19.)
3. Plug in the AC cord to the AC outlet. (See page 10.)
Language setting
Select from among 3 languages: English, French and
Spanish.
Channel search
Channel auto search makes the TV look for all channels viewable in the set area.
1
Press a/b to select the desired language listed on the screen, and then press ENTER.
3
Language
Air/Cable
CH Search
English
Français
Español
Press c/d to select “Yes” for ANALOG-A, then press a/b to move down.
Press c/d to select “Yes” for ANALOG-B, then press a/b to move down.
Press c/d to select “Yes” for DIGITAL (Air/
Cable), and press a/b to move down.
Select “Search Start”, and then press
ENTER.
Language
Air/Cable
CH Search
ANALOG-A Yes No
ANALOG-B Yes No
DIGITAL (Air) Yes No
Antenna setting
Make sure what kind of connection is made with your TV when selecting “Air” or “Cable” for both ANALOG-A, B and
DIGITAL.
2
Press c/d to select “Air” or “Cable” for
ANALOG-A, then press a/b to move down.
Press c/d to select “Air” or “Cable” for
ANALOG-B, then press a/b to move down.
Press c/d to select “Air” or “Cable” for
DIGITAL, then press a/b to move down.
Press ENTER to enter the setting.
• This operation makes the System search for both ANALOG-A, B and DIGITAL.
• There are 3 kinds of CATV system, including
Standard, HRC and IRC. Select the one matches to your TV. Select Auto when you do not know which one to select for ANALOG antenna.
Example
Language
Air/Cable
CH Search
ANALOG-A
ANALOG-B
DIGITAL
Air
Air
Air
Example
CH Search
ANALOG-A Air
CH Search
ANALOG-B Air
CH Search
DIGITAL Air
Search Start
Found
Found
Found
ANALOG-A
2
Audio : MONO
Air
NOTE
• When the CableCARD is inserted, only the “Cable” option will be displayed.
NOTE
• Make sure what kind of connection is made with your TV when selecting “Air” or “Cable” for both ANALOG-A, B and DIGITAL.
• If no channel is found, make sure what kind of connection is made with your TV and try EZ setup again (see page
27).
21
Watching TV
Changing channels - Analog-TV
You can change channels in several ways.
NOTE
• While watching a broad cast, press A-ANALOG-B to view the image received from the other tuner.
Changing channels - Digital-TV
You can change channels in several ways.
As well as the methods outlined below, you can also select programs using the Channel List. (See page 85.)
NOTE
• While watching a broad cast, press DIGITAL.
22
Method 1
Using CH r/s on the remote control unit or on the display.
Method 2
1. Press FLASHBACK to switch to the previously tuned channel.
2. Press FLASHBACK again to switch back to the currently tuned channel.
NOTE
• FLASHBACK will not work if no channel has been changed after TV is turned on.
Digital - Air/Cable
Method 1
When you press CH r/sor FLASHBACK, repeat the same steps for Analog-TV.
Method 2
Using remote control buttons (0-9, •
(DOT) and
ENTER) to select the channels including a decimal
point.
To select a 4-digit channel number
(e. g., Channel 22.1):
Method 3
Using remote control buttons (0-9 and ENTER) to select up to 125 channels for VHF/UHF/CATV.
To select a 1 or 2-digit channel number
(e. g., Channel 5):
Press 2
s
2
s•(DOT) s1s
ENTER
Air DIGITAL
2
DIGITAL
22
Air DIGITAL
22 .
Air DIGITAL
22 . 1
Air DIGITAL
22 . 1
Air
Press 5
s
ENTER
ANALOG-A
5
Air ANALOG-A
5
Air
NOTE
• When selecting a 1-digit channel number, it is not necessary to press 0 before the number.
• When you enter 0-9 only, channel selection will be made if there is no operation for a few seconds.
• • (DOT) can be used instead of ENTER.
To select a 3-digit channel number
(e. g., Channel 115):
NOTE
• Complete the above steps within a few seconds.
• When you enter 0-9 and •(DOT), channel selection will be made if there is no operation for a few seconds.
• When entering a 2-part channel number, pushing •(DOT) after the second part of the number has the same function as ENTER.
Digital - Cable (One-part Number)
Method 1
When you press CH r/sor FLASHBACK, repeat the same steps for Analog-TV.
Method 2
Using remote control buttons (0-9 and ENTER) to select the channels including a decimal point.
To select a 3-digit channel number
(e. g., Channel 310):
Press 1
s
1
s
5
ANALOG-B Cable
1
ANALOG-B Cable
11
ANALOG-B Cable
115
Press 3
s1s0s
ENTER
DIGITAL
3
Cable DIGITAL
31
Cable DIGITAL
310
Cable DIGITAL
310
Cable
NOTE
• When you enter 0-9 only, channel selection will be made if there is no operation for a few seconds.
• If you push “0” by itself, nothing will happen.
NOTE
• When you enter 0-9 only, channel selection will be made if there is no operation for a few seconds.
• •(DOT) can be used instead of ENTER.
• Digital Cable Channels are shown by a number with a maximum of 5 digits.
Watching TV
Changing volume/sound
■ Changing the volume
You can change the volume on the Display or on the remote control unit.
■ Using MUTE on the remote control unit
Mutes the current sound output.
Display
VOL l/k
1
Press MUTE.
• “
M” has been displayed on the screen for 30 minutes, and the sound is silenced.
20
Mute
NOTE
Volume adjustment
NOTE
• Within 30 minutes of pressing MUTE, mute can be canceled by using one of the methods below.
• Mute will cancel if you press VOL l/k or MUTE.
• Mute will be canceled after 30 minutes have passed.
However, the TV will not suddenly output a loud sound as the volume level is set to 0 automatically.
20
• VOL l/kon the Display operates the same as VOL k/l on the remote control unit.
Audio status
* When “Output Select” is set to “Variable”, the indicator on the screen changes as shown below.
Output device
Fixed
Output Select
Variable
Speaker
Variable sound
Mute
MONITOR OUT
Constant as specified
Variable sound
NOTE
■ Using
Virtual on the remote control unit
Virtual produces Dolby virtual effect from the
speakers. Each time you press
Virtual, the mode
changes between On and Off.
Dolby Virtual sound options
• On: Makes it possible to enjoy natural, realistic surround sound.
• Off: Outputs the normal sound.
20
• See page 71 for details on the output select function.
Dolby Virtual : Off Dolby Virtual : On
NOTE
• You can have the same settings by choosing “Dolby
Virtual” on the menu items. (See page 36.)
23
Watching TV
Setting MTS/SAP stereo mode
The TV has a feature that allows reception of sound other than the main audio for the program. This feature is called Multi-channel Television Sound (MTS). The
TV with MTS can receive mono sound, stereo sound and Secondary Audio Programs (SAP). The SAP feature allows a TV station to broadcast other information, which could be audio in another language or something completely different like weather information.
You can enjoy Hi-Fi stereo sound or SAP broadcasts where available.
• Stereo broadcasts
View programs like live sporting events, shows and concerts in dynamic stereo sound.
• SAP broadcasts
Receive TV broadcasts in either MAIN or SAP sound.
MAIN sound: The normal program soundtrack (either in mono or stereo).
SAP sound: Listen to second language, supplementary commentary and other information. (SAP is mono sound.)
If stereo sound is difficult to hear.
• Obtain a clearer sound by manually switching to fixed mono-sound mode.
NOTE
• MTS only operates while in TV mode.
You can change MTS as shown below to match the television broadcast signal.
Setting Digital broadcasting audio mode
The types of audio transmitted in a digital broadcast include SURROUND as well as MONO and STEREO.
In addition, it is possible for multipule audio tracks to accompany a single video track.
Press AUDIO to toggle between audio modes.
Examples: when receiving Digital broadcasting
DIGITAL
2.2
Audio1 : STEREO
Air
DIGITAL
2.2
Audio2 : STEREO
DIGITAL
Air
Air
2.2
Audio3 : SURROUND
Examples: when receiving MTS and SAP
STEREO mode
ANALOG-A
2
Audio : STEREO
Air
MAINkSAP mode
ANALOG-A
2
Audio : MAIN
Air
ANALOG-A
2
Audio : MONO
Air ANALOG-A
2
Audio : SAP
Air
MONO mode
ANALOG-A
2
Audio : MONO
Air
24
STEREOkSAP mode
ANALOG-A
2
Audio : ST(SAP)
Air
ANALOG-A
2
Audio : SAP(ST)
Air
ANALOG-A
2
Audio : MONO
Air
Watching TV
Connecting Digital Cable Module
Digital Cable Module is called CableCARD™. By attaching the CableCARD, you can receive various digital services provided by your Cable Company. To obtain and use a CableCARD you need to first submit an application.
Please contact your cable company to discuss receiving an application.
■ When you change your adress (See page 91)
■ About EAS(Emergency Alert System) (See page 91)
1
Press MENU and the MENU screen display.
CableCARD slot
DIGITAL IN terminal
2
Press c/d to select “Digital Setup”, a/b to select “CableCARD MENU”, a/b to select
“Pairing Infor mation”, and then press
ENTER.
Conditional Access
Paring Information
Diagnostic Screen
ECM
1
2
3
4
Turn on the POWER.
Connect the antenna cable to DIGITAL IN.
Select “Cable” from “Air/Cable” in Channel setup mode. (See page 28)
Insert the CableCARD (upper side facing left) into the CableCARD slot.
• A message will appear on the screen. (It might take a couple of minutes before the message appears.) Call the number on the screen and tell the operator the CableCARD ID and Host
ID numbers displayed on the screen.
CableCARD(tm) Pairing Status
In order to start cable service for this device, please contact your cable provider
1-888-555-2222
CableCARD™ ID:
7-561-034-449-009
Host ID:
0-100-331-784-018
NOTE
• Do not insert any PCMCIA card other than CableCARD into the CableCARD slot.
• Please do not pull the AC cord out while the CableCARD is inserted.
• After inserting the CableCARD, it may take several minutes before video output from the selected channel appears on screen.
■ If the above procedure does not work,
please follow the following steps instead.
3
A message will appear on the screen. Call the number on the screen and tell the operator the CableCARD ID and Host ID numbers displayed on the screen.
CableCARD Dialog
CableCARD(tm) Pairing Status
In order to start cable service for this device, please contact your cable provider
1-888-555-2222
CableCARD(tm) ID:
7-561-034-449-009
Host ID:
0-100-331-784-018
• If there is a white triangle at the right side of the screen, the screen is not showing the entire message. Press a/b on your remote control to display the rest of the message.
• When there is a “LINK” button on the screen, there is a link to the next page. Press ENTER to go to the next page.
CableCARD(tm)
Diagnostic Information
Power: ON
In band: O.K.
Out of band: O.K.
Video: O.K.
Audio: O.K.
LINK
Removing CableCARD
1
• Turn on the POWER.
• Check that the CableCARD upgrade screen is not displayed. If it is displayed, wait until it disappears.
• Remove the cableCARD.
Disconnecting the cable antenna
1
• The words “Pairing Information” may be replaced by a different expression depending on the manufacturer of the CableCARD.
• Turn on the POWER.
• Check that the CableCARD upgrade screen is not displayed. If it is displayed, wait until it disappears.
• Disconnect the cable antenna.
25
26
Basic adjustment settings
AV input mode menu items
List of AV menu items to help you with operations
OPC ................................................ Page 33
Backlight ........................................ Page 32
Contrast ......................................... Page 32
Brightness ..................................... Page 32
Color ............................................... Page 32
Tint ................................................. Page 32
Sharpness ...................................... Page 32
Advanced
C.M.S. ................................... Page 33
Color Temp. ......................... Page 34
Black .................................... Page 34
3D-Y/C .................................. Page 34
Monochrome ....................... Page 35
Film Mode ............................ Page 35
I/P Setting ............................ Page 35
Audio
Treble .............................................. Page 36
Bass ............................................... Page 36
Balance .......................................... Page 36
Dolby Virtual .................................. Page 36
Option
Audio Only ..................................... Page 70
Digital Noise Reduction ............... Page 70
HDMI Setup .................................... Page 54
Input Select .................................... Page 66
Output Select ................................. Page 71
Quick Shoot ................................... Page 71
Center Channel Input ................... Page 84
Caption Setup ........................... Page 73-76
Title Display Type .......................... Page 72
Digital Setup
CableCARD Menu ......................... Page 25
Video Setup ................................... Page 38
Audio Setup ................................... Page 39 i.LINK Setup ............................. Page 57, 60
*Software Version
*You can confirm the Software Version.
Power Control
No Signal Off ................................. Page 37
No Operation Off ........................... Page 37
Setup
EZ Setup ................................... Page 27-28
CH Setup ................................. Pages 28-29
Antenna Setup-DIGITAL ............... Page 30
Speaker Setup ............................... Page 64
Input Label ..................................... Page 67
Parental CTRL ........................ Pages 79-83
Position .......................................... Page 62
Picture Flip .................................... Page 67
Language ....................................... Page 31
Basic adjustment settings
*PC input mode menu items
List of PC menu items to help you with operations
*When INPUT5 is set to PC.
OPC ................................................ Page 33
Backlight ........................................ Page 32
Contrast ......................................... Page 32
Brightness ..................................... Page 32
Red ................................................. Page 32
Green .............................................. Page 32
Blue ................................................ Page 32
Advanced
C.M.S. ................................... Page 33
Audio
Treble .............................................. Page 36
Bass ............................................... Page 36
Balance .......................................... Page 36
Dolby Virtual .................................. Page 36
Power Control
Power Management ...................... Page 37
Setup
Speaker Setup ............................... Page 64
Input Signal ................................... Page 70
Auto Sync. ..................................... Page 65
Input Label ..................................... Page 67
Fine Sync. ...................................... Page 65
Picture Flip .................................... Page 67
Language ....................................... Page 31
EZ setup
You can run EZ Setup again, even after setting up the preset channels.
Language setting
Select from among 3 languages: English, French and
Spanish.
1
2
Press MENU and the MENU screen displays.
Press c/d to select “Setup”.
3
4
Press a/b to select “EZ Setup”, and then press ENTER.
• If you already set the Secret No., go to step 4. If not, skip to step 5.
Input the 4-digit secret number by using 0 – 9.
MENU [Setup ... EZ Setup]
Setup Option
Secret No.
– – – –
5
Press a/b to select the desired language listed on the screen, and then press ENTER.
Language
Air/Cable
CH Search
English
Français
Español
Option
Audio Only ..................................... Page 70
Input Select .................................... Page 66
Output Select ................................. Page 71
Quick Shoot ................................... Page 71
Center Channel Input ................... Page 84
Digital Setup
i.LINK Setup ................................... Page 60
27
28
Basic adjustment settings
Antenna setting
Make sure what kind of connection is made with your TV when selecting “Air” or “Cable” for ANALOG-A, B and DIGITAL.
6
Press c/d to select “Air” or “Cable” for
ANALOG-A, then press a/b to move down.
Press c/d to select “Air” or “Cable” for
ANALOG-B, then press a/b to move down.
Press c/d to select “Air” or “Cable” for
DIGITAL, then press a/b to move down.
Press ENTER to enter the setting.
• This operation makes the Channel search for both
ANALOG-A, B and DIGITAL.
• There are 3 kinds of CATV system, including
Standard, HRC and IRC. Select the one matches to your TV. Select Auto when you do not know which one to select for ANALOG antenna.
Channel search
Channel auto search makes the TV look for all channels viewable in the set area.
7
Press c/d to select “Yes” for ANALOG-A, then press a/b to move down.
Press c/d to select “Yes” for ANALOG-B, then press a/b to move down.
Press c/d to select “Yes” for DIGITAL (Air/
Cable), and press a/b to move down.
Select “Search Start”, and then press
ENTER.
Language
Air/Cable
CH Search
ANALOG-A Yes No
ANALOG-B Yes No
DIGITAL (Air) Yes No
Channel setup
If initial setup does not memorize all the channels in your region, follow the instructions below to manually memorize the channels.
Antenna setting
1
2
Press MENU and the MENU screen displays.
Press c/d to select “Setup”.
3
Press a/b to select “CH Setup”, and then press ENTER.
• If you already set the Secret No., input the 4digit secret number here. See page 77 for setting a secret number.
Air/Cable
CH Search
CH Memory ANALOG-A
ANALOG-B
DIGITAL
Air
Air
Air
Search Start
Searching TV channels
Example
MENU
[Setup ... EZ Setup ... CH Search]
ANALOG-A Air Found
MENU
[Setup ... EZ Setup ... CH Search]
ANALOG-B Air Found
MENU
[Setup ... EZ Setup ... CH Search]
DIGITAL Air Found
NOTE
• If no channel is found, make sure what kind of connection is made with your TV and try EZ setup again.
• Make sure what kind of connection is made with your TV when selecting “Air” or “Cable” for both ANALOG-A, B and DIGITAL.
4
Press a/b to select “Air/Cable”, and then press ENTER.
5
Press c/d to select “Air” or “Cable” for
ANALOG-A, then press a/b to move down.
Press c/d to select “Air” or “Cable” for
ANALOG-B, then press a/b to move down.
Press c/d to select “Air” or “Cable” for
DIGITAL, then press a/b to move down.
Press ENTER to enter the setting.
Example
Air/Cable
CH Search
CH Memory
ANALOG-A
ANALOG-B
DIGITAL
Air
Air
Air
NOTE
• Make sure what kind of connection is made with your TV when selecting “Air” or “Cable” for both ANALOG-A, B and DIGITAL.
• There are 3 kinds of CATV system, including Standard,
HRC and IRC. Select the one matches to your TV. Select
Auto when you do not know which one to select for
ANALOG antenna.
Basic adjustment settings
Channel search
Channel auto search makes the TV look for all channels viewable in the set area.
Channel memory setting
1
Press MENU and the MENU screen displays.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Setup”.
2
Press c/d to select “Setup”.
3
3
Press a/b to select “CH Setup”, and then press ENTER.
• If you already set the Secret No., input the 4digit secret number here. See page 77 for setting a secret number.
4
Press a/b to select “CH Setup”, and then press ENTER.
• If you already set the Secret No., input the 4digit secret number here. See page 77 for setting a secret number.
Press a/b to select “CH Memory”, and then press ENTER.
4
Press a/b to select “CH Search”, and then press ENTER.
5
5
Press a/b to select ANALOG-A, B or
DIGITAL (Air), DIGITAL (Cable), CableCARD, and then press ENTER.
Press c/d to select “Yes” for ANALOG-A, then press a/b to move down.
Press c/d to select “Yes” for ANALOG-B, then press a/b to move down.
Press c/d to select “Yes” for DIGITAL (Air/
Cable), and press a/b to move down.
Select “Search Start”, and then press
ENTER.
Air/Cable
CH Search
CH Memory ANALOG-A Yes No
ANALOG-B Yes No
DIGITAL (Air) Yes No
6
7
Press a/b and press c/d to select the channel you want to skip or not.
Press a/b to select “Skip”, and press c/d to select “On” or “Off”.
• On: Skips channels. (Channel selection disabled using
CH
r
• Off: Does not skip channels. (Channel selection enabled using CH r
Search Start
NOTE
• Make sure what kind of connection is made with your TV when selecting “Air” or “Cable” for both ANALOG-A, B and DIGITAL.
Example: CH Search
MENU [Setup ... CH Setup ... CH Search]
ANALOG-A Air Found
MENU
[Setup ... CH Setup ... CH Search]
ANALOG-B Air Found
MENU [Setup ... CH Setup ... CH Search]
DIGITAL Air Found
NOTE
• Make sure what kind of connection is made with your TV when selecting “Air” or “Cable” for both ANALOG-A, B and DIGITAL.
29
30
Basic adjustment settings
Antenna Setup - DIGITAL
In order to enjoy digital broadcasts, you need a digital broadcast antenna. You can set the antenna configuration through the Antenna Setting screen.
Antenna setting
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Setup”.
3
4
Press a/b to select “Antenna Setup -
DIGITAL”, and then press ENTER.
• If you already set the Secret No., input the 4digit secret number here. See page 77 for setting a secret number.
Press a/b to select “Signal Strength”.
Signal Strength
Channel Strength
Signal Strength
Current 0 Max 0
Make sure the signal strength of each channel received is correctly adjusted.
• This function is available for DIGITAL (Air) only.
1
Input the channel number. (See page 22.)
2
Press a/b to select “Channel Strength”, and then press ENTER.
3
Adjust the direction of the antenna to obtain the maximum signal strength and then press
ENTER.
Signal Strength
Channel Strength
1 2
CH
Signal Strength
Current 0 Max 0
Basic adjustment settings
Favorite channel setting
This function allows you to program 4 favorite channels, in 4 different categories. By setting the favorite channels in advance, you can select your favorite channels easily.
3
Press a/b/c/d to select the channel you want to delete, and then press ENTER.
A
ANALOG-A
3
B
ANALOG-A
18
C
D-Air
100
ANALOG-B
33
ANALOG-A
125
D
ANALOG-B
51
2
3
1
4
Press c/d to select “Yes”, and then press
ENTER.
Yes No
A
ANALOG-A
3
B C D
D-Air
100
ANALOG-A
125
ANALOG-B
33
ANALOG-B
51
Select the channel you want to register as a favorite channel.
Press EDIT.
Press a/b to select “Register”, and then press ENTER.
Register
1 Data Clear
All Data Clear
NOTE
• You can delete all the favorite channels by selecting “All
Data Clear” in step 2 in Delete favorite channel.
Language setting
You can also select a language from the Setup menu.
Select from among 3 languages: English, French and
Spanish.
1
Press MENU and the MENU screen displays.
4
Press a/b/c/d to select the position in the area, and then press ENTER to register.
A
ANALOG-A
3
B C D
Delete favorite channel
1
2
Press EDIT and the favorite channel screen displays.
Press a/b to select “1 Data Clear”, and then press ENTER.
2
Press c/d to select “Setup”.
3
4
Press a/b to select “Language”, and then press ENTER.
Press a/b to select the desired language listed on the screen, and then press ENTER.
English
Français
Español
31
32
Basic adjustment settings
Picture adjustments
Adjusts the picture to your preference with the following picture settings.
Adjustments items for AV source
MENU [Picture]
Picture Audio
OPC
Backlight
Contrast
Off
[ +8] –8
[+30] 0
Brightness [ 0] –30
Color
Tint
[ 0]
[ 0]
–30
–30
Sharpness [ 0] –10
Advanced
Reset
On On : Display
+8
+40
+30
+30
+30
+10
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Picture”.
3
Press a/b to select a specific adjustment item.
4
Press c/d to adjust the item to your desired position.
NOTE
• For resetting all adjustment items to factory preset values, press a/b to select “Reset”, press ENTER, press c/d to select “Yes”, and then press ENTER.
Adjustments items for PC source
MENU
[Picture]
Picture Audio
OPC
Backlight
Contrast
[ +8]
[+30]
Off
–8
0
Brightness [ 0] –30
Red [ 0] –30
Green
Blue
Advanced
[ 0] –30
[ 0] –30
Reset
On On : Display
+8
+40
+30
+30
+30
+30
Selected item
Backlight
cbutton
The screen dims d
button
The screen brightens
Contrast
For less contrast For more contrast
Brightness
Color
Tint
Sharpness
For less brightness For more brightness
For less color intensity
Skin tones become purplish
For more color intensity
Skin tones become greenish
For less sharpness For more sharpness
Selected item
Backlight
cbutton
The screen dims
Contrast
For less contrast For more contrast
Brightness
For less brightness For more brightness
Red
Green
Blue
For weaker red
For weaker green
For weaker blue d
button
The screen brightens
For stronger red
For stronger green
For stronger blue
NOTE
• Select “Advanced” and then press ENTER to set “C.M.S-
Hue”, “C.M.S-Saturation”, “C.M.S-Value”, “Color Temp.”,
“Black”, “3D-Y/C”, “Monochrome”, “Film Mode” or “I/P
Setting”. See pages 33 to 35.
NOTE
• Select “Advanced” and then press ENTER to set “C.M.S-
Hue”, “C.M.S-Saturation” and “C.M.S-Value”.
Basic adjustment settings
OPC setting
Automatically adjusts the brightness of the screen.
C.M.S. (Color Management System)
Color tone is managed using the six-color adjustment setting.
1
Press MENU and the MENU screen displays.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Picture”.
2
Press c/d to select “Picture”.
3
Press a/b to select “OPC”.
3
Press a/b to select “Advanced”, and then press ENTER.
4
Press c/d to select “On” or “On: Display”.
OPC
Backlight
Contrast
Off
[ +8] –8
[+30] 0
Brightness [ 0] –30
Color
Tint
[ 0]
[ 0]
–30
–30
Sharpness [ 0] –10
Advanced
Reset
On On : Display
+8
+40
+30
+30
+30
+10
4
Press a/b to select “C.M.S-Hue”, and then press ENTER.
• You can select “C.M.S-Saturation” or “C.M.S-
Value” here instead of selecting “C.M.S-Hue”.
5
Press a/b to select a specific adjustment item. Press c/d to adjust the item to your desired position.
C. M. S.-Hue
C. M. S.-Saturation
C. M. S.-Value
Changing reds closer to magenta or yellow.
G
C
R
Y
B
[ 0]
[ 0]
[ 0]
[ 0]
–30
–30
–30
–30
[ 0] –30
M
Reset
[ 0] –30
+30
+30
+30
+30
+30
+30
Selected item
Off
On
On: Display
Description
The brightness is fixed at the value set in
“Backlight” (see page 32).
Automatically adjusts
Displays the OPC effect on the screen while adjusting the brightness of the screen.
NOTE
• When set to “On”, the OPC senses the surrounding light and automatically adjusts the backlight brightness. Make sure no object obstructs the OPC sensor, which could affect its ability to sense surrounding light.
• When set to “On: Display”, OPC effect displays on the screen while OPC is adjusting the screen brightness.
Selected item
C.M.S-Hue
C.M.S-
Saturation
C.M.S-
Value
Description
This is a standard to adjust the color either more reddish or more bluish in tone.
Increases or decreases the saturation of a selected color.
A higher value makes the image brighter.
A lower value makes the image darker.
NOTE
• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press
ENTER.
33
34
Basic adjustment settings
Color temperature
For a better white balance, use color temperature correction.
1
Press MENU and the MENU screen displays.
Black
For easier viewing, change the viewing depth by selecting a level for automatically adjusting the dark portion of an image.
1
Repeat steps 1 to 3 in Color temperature.
2
Press c/d to select “Picture”.
2
Press a/b to select “Black”, and then press
ENTER.
3
Press a/b to select “Advanced”, and then press ENTER.
4
Press a/b to select “Color Temp.”, and then press ENTER.
C. M. S-Hue
C. M. S-Saturation
C. M. S-Value
Color Temp.
Black
3D-Y/C
Monochrome
Film Mode
I/P Setting
High
Mid-High
Middle
Mid-Low
Low
3
Press c/d to select “On”, and then press
ENTER.
Selected item
Off
On
Description
No adjustment
For high detail in black portions
3D-Y/C
Provides high quality images with minimal dot crawl and cross color noise.
1
Repeat steps 1 to 3 in Color temperature.
5
Press a/b to select the desired level, and then press ENTER.
Selected item
High
Mid-High
Middle
Mid-Low
Low
Description
White with Bluish tone
White with Reddish tone
2
Press a/b to select “3D-Y/C”, and then press ENTER.
3
Press a/b to select the desired level, and then press ENTER.
Selected item
Standard
Fast
Slow
Description
Normal adjustment
For movie image
For still image
NOTE
• 3D-Y/C is not available for S-video, Component, DVI,
HDMI, CARD, DIGITAL-TV or i.LINK inputs.
Basic adjustment settings
Monochrome
For viewing a video in monochrome.
1
Press MENU and the MENU screen displays.
I/P Setting
Adjusting the image and input signal can give you a more beautiful picture.
1
Repeat steps 1 to 3 in Monochrome.
2
Press c/d to select “Picture”.
2
Press a/b to select “I/P Setting”, and then press ENTER.
3
Press a/b to select “Advanced”, and then press ENTER.
4
Press a/b to select “Monochrome”, and then press ENTER.
C. M. S-Hue
C. M. S-Saturation
C. M. S-Value
Color Temp.
Black
3D-Y/C
Monochrome
Film Mode
I/P Setting
On Off
3
Press c/d to select “Interlace” or
“Progressive”, and then press ENTER.
NOTE
• I/P Setting is set to Progressive when Film Mode is “On”.
• “I/P Setting” is not selectable when channel display shows an input resolution of 480P, 720P or 1080I.
5
Press c/d to select “On”, and then press
ENTER.
Selected item
Off
On
Description
Normal color
For viewing in monochrome
Film mode (3:2 pull-down)
Automatically detects a film-based source (originally encoded at 24 frames/second), analyzes it then recreates each still film frame for high-definition picture quality.
1
Repeat steps 1 to 3 in Monochrome.
2
Press a/b to select “Film Mode”, and then press ENTER.
3
Press c/d to select “On”, and then press
ENTER.
Selected item
Off
On
Description
Normal viewing mode
Detects, analyzes, converts film source
35
36
Basic adjustment settings
Sound adjustment
You can adjust the sound quality to your preference with the following settings.
1
2
Press MENU and the MENU screen displays.
Press c/d to select “Audio”.
MENU [Audio]
Audio Power Control
Dolby virtual
You can enjoy the SURROUND 2ch stereo with Dolby
Pro Logic II technology.
VIRTUAL DOLBY DIGITAL is a technology certified by
Dolby Laboratories that creates a virtualized surround sound experience from two speakers using Dolby Pro
Logic or Dolby Pro Logic II.
VIRTUAL DOLBY DIGITAL retains all the original multichannel audio information and provides the listener with the sensation of being surrounded by additional speakers.
Treble
Bass
[ 0]
[ 0]
Balance [ 0]
Dolby Virtual
Reset
–15
–15
L
+15
+15
R
[Off]
1
2
Press MENU and the MENU screen displays.
Press c/d to select “Audio”.
3
Press a/b to select a specific adjustment item.
4
Press c/d to adjust the item to your desired position.
Selected item
cbutton d
button
3
Press a/b to select “Dolby Virtual”, and then press ENTER.
MENU [Audio ... Dolby Virtual]
Audio Power Control
Treble
For weaker treble For stronger treble
Treble
Bass
[ 0]
[ 0]
Balance [ 0]
Dolby Virtual
Reset
–15
–15
L
+15
+15
R
[Off]
Bass
Balance
For weaker bass For stronger bass
Decrease audio from the right speaker
Decrease audio from the left speaker
NOTE
• Audio menu is grayed out when Output Select is set to
“Variable” or when headphones are in use.
• Balance and Audio Quality Control are grayed out when
Dolby Virtual is set to “On”.
• For resetting all adjustment items to factory preset values, press a/b to select “Reset”, press ENTER, press c/d to select “Yes”, and then press ENTER.
4
Press c/d to select “On”, and then press
ENTER.
NOTE
• You can choose Dolby Virtual by pressing Virtual on the remote control unit.
• Audio menu is grayed out when Output Select is set to
“Variable” or when headphones are in use.
• Balance and Audio Quality Control are grayed out when
Dolby Virtual is set to “On”.
• For some discs, setup may be required on your DVD. In this case, please refer to the operation manual of your
DVD player.
• You may not get the Dolby Virtual Surround effect if you adjust “Treble” or “Bass” setting.
Basic adjustment settings
Power control
Power control setting allows you to save energy.
Power control for AV source
No signal off
When set to “Enable”, the power will automatically shut down if no signal inputs for 15 minutes.
1
Press MENU and the MENU screen displays.
Power control for PC source
Power control setting allows you to save energy.
Power management
When set, the power will automatically shut down.
1
2
Repeat steps 1 and 2 in No signal off.
2
Press c/d to select “Power Control”.
3
Press a/b to select “Power Management”, and then press ENTER.
Press a/b to select “Mode1” or “Mode2”, and then press ENTER.
3
Press a/b to select “No Signal Off”, and then press ENTER.
4
Press c/d to select “Enable”, and then press ENTER.
Off
Mode1
Mode2
• Five minutes before the power shuts down, remaining time displays every minute.
NOTE
• “Disable” is factory preset value.
• When a TV program finishes, this function may not operate.
• Does not function in conjunction with digital broadcasts.
No operation off
When set to “Enable”, the power will automatically shut down if there is no operation for 3 hours.
1
Repeat steps 1 and 2 in No signal off.
2
Enable Disable
Press a/b to select “No Operation Off”, and then press ENTER.
3
Press c/d to select “Enable”, and then press ENTER.
• Five minutes before the power shuts down, remaining time displays every minute.
NOTE
• “Disable” is factory preset value.
Selected item
Off
Mode1
Mode2
Description
• No power management
• Factory preset value.
• If no signal inputs for 8 minutes, the power shuts down.
• Even if you start using the PC and the signal inputs again, the TV stays off.
• The TV turns on again by pressing TV
POWER on the remote control unit. (See page 20).
• Press POWER on the display will have the same result.
• If no signal inputs for 8 seconds, the power shuts down.
• When you start using the PC and the signal inputs again, the TV turns on.
NOTE
• When using a digital PC and setting “Mode2” in Power management, the power may not turn back on automatically even if the signal inputs again.
• If you turn off the power by disconnecting AC cord when setting “Mode2” in power management, the TV may not function properly after turning the power on again. In such case, press TV POWER on the remote control unit.
• Press POWER on the display will have the same result.
37
38
Basic adjustment settings (DIGITAL)
Digital Setup
This setting allows you to set the image of Digital broadcasting.
REC Picture Size
Select the screen size to record on 16:9 video.
1
Press MENU and the MENU screen displays.
Video Setup
You can adjust the settings for Digital image.
2
Press c/d to select “Digital Setup”.
Screen Size
Set the format of image of Digital broadcasting.
3
Press a/b to select “Video Setup”, and then press ENTER.
1
Press MENU and the MENU screen displays.
4
2
Press c/d to select “Digital Setup”.
Press a/b to select “REC Picture Size”, and then press ENTER.
Screen Size
REC Picture Size
3
Press a/b to select “Video Setup”, and then press ENTER.
4 : 3 TV 16 : 9 TV
4
Press a/b to select “Screen Size”, and then press ENTER.
Screen Size
REC Picture Size
5
Press c/d to select the desired picture size, and then press ENTER.
Manual Auto
5
Press c/d to select “Manual” or “Auto”.
Selected item
4:3 TV
16:9 TV
Description
Bars may appear on the top and bottom with some programmes
Display the full screen and keep a picture quality
Selected item
Manual
Auto
Description
Broadcasts in formats other than
480i will be converted and displayed in the 1080i format.
With 480i broadcasts you can change the screen size to the size of your choice.
All broadcasts will be converted and displayed in the 1080i format.
NOTE
• "Manual" is factory preset value.
Basic adjustment settings (DIGITAL)
Audio Setup
You can output digital audio to an AV amp or similar device whose DIGITAL AUDIO INPUT terminal is connected to the DIGITAL AUDIO OUTPUT terminal on the Display. Please select an audio output format compatible with the audio format of the program you are watching and the equipment connected.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Digital Setup”.
3
Press a/b to select “Audio Setup”, and then press ENTER.
4
Press a/b to select “PCM” or "Dolby Digital", and then press ENTER.
PCM
Dolby Digital
Selected item Description
PCM
Dolby Digital
The optical putput terminal outputs audio signal by PCM form. If your digital audio sysytem does not support Dolby Digital, select "PCM".
The optical output terminal outputs audio signal by Dolby Digital form.
It reproduces sound from surround program of digital.
39
40
Using memory card
Important notes on using memory cards
• We will not be liable for misuse of the LCD TV set, any troubles during use, or other problems, or any damages arising out of the use of the LCD TV set, except for the cases for which we are liable by statute.
• If you or other people misuse the LCD TV set, or the LCD TV set is affected by static electricity or electrical noise, the recorded data may be in danger of being changed or lost.
• If you are making a record of importance, run a test in advance to ensure that the recording would be performed correctly in terms of picture or sound quality.
• We do not capture responsibility nor compensate even if pictures or sound could not be recorded correctly because of troubles.
Copyright
Duplicating images and music by copying and/or editing from videocassettes and/or TV programs that are subject to copyrights is only permitted when the edited or copied versions are used for personal pleasure.
With the exception of cases when the user personally is the owner of the copyrights of the object in question or when specific and written permission has been obtained from the owner(s) of the object in question, the user is not permitted to make copies and/or duplications and/or edited versions as this constitutes a violation of the copyright laws, possible exposing the user to demands for compensation for damages. Therefore, strictly adhere to the existing copyright laws.
In addition when using image data that includes third parties, the use without prior permission of these images may constitute an intrusion on the privacy of third parties, so strictly refrain from such usage.
The recording formats
Still picture
Recording/Playback file format
Size of a captured still picture
Recording file format
Motion Picture
Size of a recorded motion picture/number of frames
Playback file format
JPEG (DCF compliant)
640g480 dots
SP/LP... ASF (Motion Picture: MPEG-4 compliant, Sound: WMA-compliant)
EP........ ASF (Motion Picture: MPEG-4 compliant, Sound: G.726-compliant)
SP ... Size: 320g240 dots, Frame: approx. 30 frames/sec
LP ... Size: 320g240 dots, Frame: approx. 30 frames/sec
EP ... Size: 320g240 dots, Frame: approx. 15 frames/sec
ASF (Motion Picture: MPEG-4 compliant, Sound: WMA-compliant)
ASF (Motion Picture: MPEG-4 compliant, Sound: G.726-compliant)
Approximate number of recordable pictures/time
Still Pictures
Still picture
Picture size
640g480
32MB
Memory card
Approx. 300 pictures
128MB
Approx. 1000 pictures
* Recordable numbers may vary depending on the receiving condition of the LCD TV set and/or content of images.
Motion pictures
Recordable time
Picture size
320g240
320g240
320g240
Recording mode
SP
LP
EP
Memory card capacity
256MB 5GB
Approx. 10 min.
Approx. 30 min.
Approx. 1h.
Approx. 4h.
Approx. 10h.
Approx. 25h.
• Recordable time may vary depending on receiving condition of the LCD TV set or content of images.
• The maximum amount of data you can record on a memory card is 1,024 pictures in total including still and motion pictures.
Using memory card
You can use memory cards (commercially available) for recording and playing back pictures.
• Please use an appropriate PC card adapter
(commercially available) for each memory card.
• Following memory cards are available. (Note that names for memory cards vary depending on manufacturers.)
Memory card name
SD Memory Card mini SD™ Card
CompactFlash
MultiMediaCard
SmartMedia
Memory Stick
Memory Stick PRO
Microdrive xD Picture Card
PC Card Hard Disk
Storage capacity
512 MB or less
32 MB or less
2 GB or less
128 MB or less
128 MB or less
128 MB or less
1 GB or less
2 GB or less
128 MB or less
5 GB or less
* Each memory card name is a trademark.
* The capacity of memory card is approximate. The capacity varies depending on the manufacturer.
• To read picture files recorded with digital cameras, use the PC card adapter recommended by the corresponding manufacturer. (The names for PC card adapters vary depending on manufacturers.)
• For directions for use of digital cameras or PC card adapters, please refer to the operation manual provided for each product.
You can playback DCF compliant JPEG pictures captured with other devices in the card playback mode.
• DCF (Design rule for Camera File system) is a standard of the Japan Electronics and Information
Technology Industries Association (JEITA). This standard specifies the image file format used for images shot with a digital camera.
• Some motion pictures recorded with other devices may not be played back correctly.
Commercially available memory cards
SD Memory
Card miniSD™ Card
MultiMediaCard
PC card adapter
SmartMedia
CompactFlash
Memory Stick
Memory Stick
PRO
Microdrive
• Please use an appropriate PC card adapter
(commercially available) for each memory card.
Preparing a memory card
PC Card Hard Disk xD Picture Card
Insert a memory card (commercially available) into a PC card adapter (commercially available).
Example:
Inserting the SD memory card into a PC card adapter.
Notes on using memory cards and PC card adapter
Please note the following when using memory cards and PC card adapters to avoid corruption of data or malfunction of the LCD TV set.
• If you use memory cards other than those shown above, recording or playing back pictures are not guaranteed.
• Some PC card adapters have restrictions of memory card capacity. Refer to the relevant operation manual for such restrictions.
• Some pictures which have been created, modified, or copied on your PC may not be played back.
• Do not bend, drop or apply a shock to memory cards or PC card adapters.
• Keep memory cards or PC card adapters away from heat, water or direct sunlight.
• Do not dismantle or modify memory cards or PC card adapters.
• Refer to the appropriate operation manuals for details on using or keeping memory cards or PC card adapters.
• Do not turn the LCD TV set off while a memory card is in operation (e.g. playing back, recording or displaying a slideshow).
41
Using memory card
Card Setup mode menu items
Still Setup Slide Show
Card
Setup
Video Setup
Format
My Program
Audio Select
File Operation
Rec. Mode
Pre Record
Repeat Play
File Operation
Yes/No
CARD - STILL
Slide show operation panel
1 2
0001/0045
ORDER:NORMAL REPEAT:OFF
SLIDE SHOW
PREV.
NEXT
Interval
Order
Repeat
Setup/Delete All
Off/TV/Input1-Input5
Protect/Delete File/ Delete All
SP/LP/EP
On/Off
Off/File/All
Protect/Delete File/Delete All
1-10/15/20/25/30/
45/60 Sec.
15/30/60 Min.
Normal/Random/
My Program
On/Off
1
Motion picture operation panel
2 3 4
0001/0045
REPEAT:OFF CARD - VIDEO
5
PLAY
MODE : SP
0 0 : 1 5 : 2 5
PLAY
42
1
Rotate the image
2
Pause
3
Go to previous image
4
Start slide show
5
Stop slide show
6
Go to next image
3 4 5 6
6 7 8 9 10 11 12 13
1
Action
2
Go back to the beginning of the file
3
Pause
4
Repeat playback setting
5
Go to the beginning of the next file
6
Recording mode
7
Counter
8
Current action
9
Reverse
10 Playback
11 Stop
12 Fast forward
13 Slow playback
Precautions when playing back PC image data on the LCD TV
Recording formats of image data:
When recording image data on the LCD TV, the recording formats are as follows.
• When recording motion pictures: The SD_VIDEO folder is created and the data is stored in. When playing the card, the SD_VIDEO recording format is recognized.
• When recording still pictures: The DCIM folder is created and the data is stored in. When playing the card, the
DCIM recording format is recognized.
When playing the card, record PC data in a recording format the LCD TV can recognize.
1. When copying motion pictures from a PC to a card recorded with the LCD TV, first place the pictures in the
SD_VIDEO folder before playing them.
2. When copying still pictures from a PC to a card recorded with the LCD TV, first place the pictures in the DCIM folder before playing them.
3. When using a new card for copying motion pictures, first format the card and create an SD_VIDEO folder before placing the data in the folder for playback.
4. When using a new card for copying still pictures, first format the card and create a DCIM folder before placing the data in the folder for playback.
When creating, revising, or copying images using your PC, the edited images may not playback correctly.
Using memory card
Opening the PC CARD slot cover
Use your fingertip to slide the catch in the direction of the arrow.
Ejecting the card
• Make sure the card indicator lights up green.
1
Press EJECT button.
• EJECT button is popped up.
EJECT button
Inserting a PC card adapter
• Press in the EJECT button if it is popped out.
• Insert a memory card to a PC card adapter beforehand. (See page 41.)
• Insert the PC adapter card slowly.
PC CARD slot
2
Press EJECT button again.
CARD indicator
Reverse side
NOTE
• Please do not insert a CableCARD in the PC Card slot.
• When “Please insert a PC card” is displayed, eject the
PC card adapter, and then insert the PC card adapter slowly all the way to the end.
• When over a thousand files are in a card, it takes several minutes to load. (approx. 5 minutes.)
• Even if the green light is on, you can not record on a card right after you inserted it.
• Make sure the CARD indicator lights green when you take out a card. Never take out a card when the CARD indicator lights red. This may damage the card.
• CARD indicator lights up green when the card is inserted.
Selecting Still and Video mode
1
Press CARD and the card mode screen displays.
2
Press c/d to select “Still” or “Video”, and then press ENTER.
• When in CARD mode, press 0-9, CH r/s,
FAVORITE CH or INPUT to switch either TV or
AV input mode.
43
Using memory card
Recording a still image
You can record a still image on the card.
1
Press FREEZE.
Cooking Time
Still
Onion
Tomato
Potato x 1 x 1 x 1
2
Press REC.
Cooking Time
Still
Tomato
Potato x 1 x 1 x 1
• “Still image captured on card.” displays.
3
Press ENTER to update the still image.
Still
Cooking Time
Displaying a still image
1
Press CARD and the card mode screen displays.
2
Press c/d to select “Still”, and then press
ENTER.
3
Press a/b/c/d to select a file you want to display, and then press ENTER.
Still Video
File 1 File 2 File 3
File 4
File 7
File 5
File 8
File 6
File 9
• To display the files that are in the previous or next page, select c/d on the index screen and press ENTER.
• When viewing a still image, by pressing VIEW
MODE the image size changes. Normal – Full.
This function does not work when displaying the index screen.
Displaying slide show
1
Repeat steps 1 to 3 in Displaying a still image above.
• The operation panel displays.
CARD - STILL
0001/0045 ORDER:NORMAL REPEAT:OFF
SLIDE SHOW STOP
PREV.
NEXT
2
Press a/b/c/d to select d, and then press
ENTER.
• Slide show starts.
• Operate slide show with the operation panel appears on the screen.
• To turn off the operation panel, press CARD on the remote control.
NOTE
• See page 42 for operation panel function.
• You can not rotate the image during slide show. Stop slide show to rotate the image.
44
NOTE
The list of broadcasting type or input signal not available for recording:
1 COMPONENT input
2 HDMI input
3 DVI-I input
4 Card picture
5 Copy guarded signal
6 V-chip blocked program
7 i.LINK input
8 DTV Program
Using memory card
Setting/unprotecting Slide Show
You can adjust the interval, order and repeat settings.
My Program
You can select up to thirty-two pictures and specify the order for displaying in slide show.
1
Press CARD and the card mode screen displays.
1
Repeat steps 1 to 4 in Setting Slide Show.
2
3
Press MENU and the MENU screen displays.
Press c/d to select “Card Setup”.
4
Press a/b to select “Still Setup”, and then press ENTER.
5
Press a/b to select “Slide Show”, and then press ENTER.
Slide Show
My Program
Audio Select
File Operation
Interval
Order
Repeat
5 s.
Normal
On Off
2
Press a/b to select “My Program”, and then press ENTER.
3
Press c/d to select “Setup”, and then press
ENTER.
4
Press a/b/c/d to select the files, and then press ENTER.
5
Repeats the operation in step 4. (You can select up to 32 files.)
6
After selecting all the files you want, press
RETURN to return to MENU.
To cancel My Program setting
1
Performs step 1 and 2 in My Program.
6
Press a/b/c/d to select the desired slide show setting, and then press ENTER.
Selected item
Interval
Order
Repeat
Description
Set the frame interval for a slideshow.
Set the frame order for a slideshow. See the right column for My Program setting.
If set to On, the slideshow will play again after showing the last frame.
2
Press c/d to select “Delete All”, and then press ENTER.
3
Press c/d to select “Yes”, and then press
ENTER.
• All the registered numbers are cleared.
Audio Select
You can enjoy the audio from TV or other external equipment during the still image playback.
1
Repeat steps 1 to 4 in Setting Slide Show.
2
Press a/b to select “Audio Select”, and then press ENTER.
3
Press a/b/c/d to select the desired sound output, and then press ENTER.
45
Using memory card
Protecting/unprotecting still picture files
You can protect any file you do not want to delete.
1
Repeat steps 1 to 4 in Setting Slide Show.
2
Deleting all still image files
1
Repeat steps 1 to 4 in Setting Slide Show.
Press a/b to select “File Operation”, and then press ENTER.
Slide Show
My Program
Audio Select
File Operation
Protect
Delete File
Delete All
2
Press a/b to select “Delete All”, and then press ENTER.
3
Press c/d to select “Yes”, and then press
ENTER.
NOTE
• You cannot delete a protected file on the card.
• Do not turn off the power or take out a card when deleting a file. The card may malfunction.
3
4
5
Press a/b to select “Protect”, and then press ENTER.
Press a/b/c/d to select the file you want to protect, and then press ENTER.
• Protect mark ( ) displays.
• Select the file with a protect mark and press
ENTER to cancel file protect.
Repeats the operation in step 4.
6
After setting the files you want to protect, press RETURN to return to MENU.
NOTE
• You cannot delete a protected file on the card.
Deleting a still image file
1
Repeat steps 1 to 4 in Setting Slide Show.
2
Press a/b to select “Delete File”, and then press ENTER.
3
Press a/b/c/d to select the file you want to delete, and then press ENTER.
4
Press c/d to select “Yes”, and then press
ENTER.
5
Repeat the operations in steps 3 and 4 above.
6
After deleting the images you no longer need, press RETURN to return to MENU.
46
NOTE
• You cannot delete a protected file on the card.
• Do not turn off the power or take out a card when deleting a file. The card may malfunction.
Using memory card
Displaying a motion picture
1
Press CARD and the card mode screen displays.
2
Press c/d to select “Video”, and then press
ENTER.
3
Press a/b/c/d to select the file you want to play, and then press ENTER.
• Video playback starts.
4
Press CARD again to display the operation panel.
• See page 42 for the operation panel information.
• When viewing a motion picture, by pressing
VIEW MODE the picture size changes.
Small – Medium – Large.
Recording a motion picture
Use this setting to record images you are currently watching.
Record with the settings made in “Rec. Mode” and
“Pre Record”.
1
Press REC to start recording.
• CARD indicator lights up red.
• Recording information displays in the lower right corner of the screen.
2
Press
H to stop recording.
Rec. Mode
Use this setting for recording images you are currently watching. You can select the recording mode (picture quality) for a motion picture.
1
2
Press CARD and the card mode screen displays.
Press MENU and the MENU screen displays.
3
Press c/d to select “Card Setup”.
NOTE
The list of broadcasting type or input signal not available for recording:
1 COMPONENT input
2 HDMI input
3 DVI-I input
4 Card picture
5 Copy guarded signal
6 V-chip blocked program
7 i.LINK input
8 DTV Program
To display the remaining record time.
Press DISPLAY while not recording.
• Remaining record time displays in the lower right corner of the screen.
NOTE
• Do not remove the AC cord from the socket.
• Recording stops if you press TV POWER on the remote control while recording.
• When card has no capacity for recording, “Card is full” displays and stops recording.
• You cannot change the channel or switch the input source while recording.
4
Press a/b to select “Video Setup” and then press ENTER.
5
6
Press a/b to select “Rec. Mode”, and then press ENTER.
Rec. Mode
Pre Record
Repeat Play
File Operation
SP
LP
EP
Press a/b to select the desired mode, and then press ENTER.
47
48
Using memory card
Pre Record
You can record the picture slightly before the point where you pressed the record button, enabling you to record just the scene you wanted.
Protecting/unprotecting motion picture files
You can protect any file you do not want to delete.
1
Press CARD and the card mode screen displays.
1
Repeat steps 1 to 4 in Rec. Mode.
2
Press MENU and the MENU screen displays.
2
Press a/b to select “Pre Record”, and then press ENTER.
Rec. Mode
Pre Record
Repeat Play
File Operation
On Off
3
4
Press c/d to select “Card Setup”.
Press a/b to select “Video Setup”, and then press ENTER.
5
3
Press c/d to select “On”, and then press
ENTER.
Press a/b to select “File Operation”, and then press ENTER.
Rec. Mode
Pre Record
Repeat Play
File Operation
Protect
Delete File
Delete All
Repeat Play
You can specify one file or all files to replay repeatedly.
1
Repeat steps 1 to 4 in Rec. Mode.
6
2
Press a/b to select “Repeat Play”, and then press ENTER.
3
Press a/b to select desired setting, and then press ENTER.
7
8
Press a/b to select “Protect”, and then press ENTER.
Press a/b/c/d to select the file you want to protect, and then press ENTER.
• Protect mark ( ) displays.
• Select the file with a protect mark and press
ENTER to cancel file protect.
Repeats the operation in step 7.
Off
File
All
Selected item
Description
No playback or repeat.
Plays back and repeats one file.
Plays back all movie files on the card then repeats.
9
After setting the files you want to protect, press RETURN to return to MENU.
Using memory card
Deleting a motion picture file
Format
1
2
Repeat step 1 to 5 in Protecting motion
picture files.
Press a/b to select “Delete File”, and then press ENTER.
1
2
Press MENU and the MENU screen displays.
Press c/d to select “Card Setup”.
3
4
5
Press a/b/c/d to select the file you want to delete, and then press ENTER.
Press c/d to select “Yes”, and then press
ENTER.
Repeat the operations in steps 3 and 4 above.
3
Press a/b to select “Format” and then press ENTER.
4
Press c/d to select “Yes”, and then press
ENTER.
Yes No
6
After deleting the images you no longer need, press RETURN to return to MENU.
NOTE
• You cannot delete a protected file on the card.
• Do not turn off the power or take out a card when deleting a file. The card may malfunction.
NOTE
• Formatting a card deletes all files including the ones which set to protect.
• Do not turn off the power or take out a card while it is being formatted.
Deleting all motion picture files
1
2
Repeat step 1 to 5 in Protecting motion
picture files.
Press a/b to select “Delete All”, and then press ENTER.
3
Press c/d to select “Yes”, and then press
ENTER.
NOTE
• You cannot delete a protected file on the card.
• Do not turn off the power or take out a card when deleting a file. The card may malfunction.
49
50
Using external equipment
You can connect many types of external equipment to your System, like a DVD player, VCR, Digital TV tuner, PC,
HDMI equipment, game console and camcorder. To view external source images, select the input source from
INPUT on the remote control unit or on the Display.
Selecting the INPUT signal
Displaying an external equipment image
Explanation here is for the setting when connecting
DVD to INPUT1 terminal.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Option”.
INPUT button
3
Press a/b to select “Input Select”, and then press ENTER.
MENU [Option ... Input Select]
Option
Audio Only
Digital Noise Reduction
Input Select
Output Select
Quick Shoot
Center Channel Input
Caption Setup
Title Display type
[Low]
[Auto]
[Fixed]
[Off]
[Off]
[No]
To watch a DVD image, select “INPUT1” from “INPUT
SOURCE” menu using INPUT on the remote control unit or on the Display. (See page 66.)
INPUT SOURCE
TV
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5 i.LINK
CARD
NOTE
• If the image does not come in clearly, you may need to change the input signal type setting on the “Input Select” menu.
4
Select the desired signal type.
For INPUT1 signal
MENU [Option ... Input Select]
Auto
COMPONENT
VIDEO
The setting is stored and can be selected on the
“INPUT SOURCE” menu.
CAUTION
• To protect all equipment, always turn off the TV before connecting to a DVD player, VCR, Digital TV tuner, PC,
HDMI equipment, game console, camcorder or other external equipment.
NOTE
• See pages 51 to 55 for external equipment connection.
• Please refer to the relevant operation manual (DVD player,
PC, etc.) carefully before making connections.
• Each time INPUT is pressed, the input source toggles.
• Refer to your external equipment operation manual for the signal type.
Using external equipment
Connecting a DVD player
You can use the INPUT 1, INPUT 2, INPUT 4 or INPUT 5 terminals when connecting to a DVD player and other audiovisual equipment.
When using component cable.
Component video cable
(commercially available)
Audio cable
(commercially available)
DVD player
When using composite cable.
AV cable (commercially available)
DVD player
When using DVI cable. (INPUT 5)
ø 3.5 mm stereo minijack cable
(commercially available)
DVD player
DVI cable (Commercially available)
NOTE
• See page 54 for connecting a DVD player with HDMI terminal.
51
Using external equipment
Connecting a VCR
You can use the INPUT 3 terminal when connecting a VCR and other audiovisual equipment.
NOTE
• The S-video terminal has priority over the video terminals.
S-video cable
(commercially available)
AV cable
(commercially available)
VCR
Connecting a game console or camcorder
A game console, camcorder and some other audiovisual equipment are conveniently connected using the
INPUT 3 terminals.
NOTE
• The S-video terminal has priority over the video terminals.
S-video cable
(commercially available)
AV cable
(commercially available)
52
Game console/Camcorder
Using external equipment
Connecting a Digital TV STB
You can use the INPUT 1, INPUT 2, INPUT 4 or INPUT 5 terminals when connecting a Digital TV STB and other audiovisual equipment.
When using component cable.
Component video cable
(commercially available)
Audio cable
(commercially available)
Digital TV STB
When using composite cable.
AV cable
(commercially available)
Digital TV STB
When using DVI cable. (INPUT 5)
ø 3.5 mm stereo minijack cable
(commercially available)
DVI cable (Commercially available)
Digital TV STB
NOTE
• See page 54 for connecting a Digital TV STB to HDMI terminal.
53
Using external equipment
Connecting HDMI equipment
You can use the INPUT 4 terminal when connecting an HDMI equipment.
HDMI equipment
54
HDMI cable
(Commercially available)
Displaying an image from HDMI equipment
1
2
3
4
To watch an HDMI equipment image, select
“INPUT4” from “INPUT SOURCE” menu using INPUT on the remote control unit or on the Display. (See page 66.)
INPUT SOURCE
TV
INPUT1
INPUT2
INPUT3
INPUT4 i.LINK
CARD
Press MENU and the MENU screen displays.
5
Press a/b to select the desired item and press ENTER.
6
Press a/b/c/d to select the desired setting and press ENTER.
HDMI Setup items
Signal
Type
Selectable items
Auto/RGB/YCbCr
4:4:4/YCbCr 4:2:2
Color
Matrix
Auto/ITU601/
ITU709
Description
Select the signal type from an HDMI terminal. Unless the image quality looks obviously poor, select Auto.
Select the internal color space conversion method when an RGB signal is input. Normally, select
Auto.
Dynamic
Range
Auto View
Standard/
Out of standard
Enable/Disable
Select the signal amplitude range. Normally, select
Standard.
Set whether or not to use
VIEW MODE based on signal recognition, including an HDMI signal.
Press c/d to select “Option”.
Press a/b to select “HDMI Setup”, and then press ENTER.
MENU [Option ... HDMI Setup]
Option
Audio Only
Digital Noise Reduction
HDMI Setup
[Low]
NOTE
• Refer to your external equipment operation manual for the signal type.
Using external equipment
Connecting a PC
Use the INPUT 5 terminal to connect a PC.
NOTE
• Refer to page 81 for a list of PC signals compatible with the TV.
ø 3.5 mm stereo minijack cable
(commercially available)
PC with DVI terminal
DVI cable (Commercially available)
RGB/DVI conversion cable
(Commercially available)
ø 3.5 mm stereo minijack cable
(commercially available)
PC with analog RGB terminal
55
56
Using external equipment
Connecting D-VHS Decks (i.LINK
connection)
Connecting two or more D-VHS decks
Up to 16 D-VHS decks can be connected using a daisy-chain connection with i.LINK cables.
About i.LINK
i.LINK is an interface connection using a serial transfer system and is able to transfer multimedia data, such as digital images and digital sound, between devices that have i.LINK terminals.
i.LINK is a term defined in the IEEE 1394 (Institute of
Electrical and Electronics Engineers) standard.
Currently, the transfer speeds are at 100 Mbps, 200
Mbps and 400 Mbps, each of them expressed as
S100, S200 and S400 respectively. On this TV, the maximum speed is 400 Mbps.
i. LINK devices that can be connected to this
TV.
Only D-VHS decks can be connected to this TV.
Other devices such as DVD recorders, digital video cameras, computers or computer peripheral devices do not meet the specifications for this TV and therefore, cannot be connected.
Materials that can be recorded with the i.LINK
Only digital programs can be recorded by D-VHS decks connected to this TV using the i.LINK. i.LINK
recording is not compatible with ground-wave broadcasts or external input signals (INPUT terminals 1 through 5).
When 3 or more D-VHS decks are connected, branch connection can be used. With branch connections, up to 62 D-VHS decks can be connected.
i.LINK connection
E.g. When only one D-VHS deck is connected:
NOTE
• Please make sure the shapes of the terminal and the plug match, and insert the plug into the terminal straight, not on an angle.
• Use either one of the terminals. These two terminals do not differ in quality or function.
D-VHS deck
Cautions regarding i.LINK connection
• Please use S400 type i.LINK cables.
• Some i.LINK devices may not relay data if their power is off. This TV can relay data during power off, by selecting “Active” in the “Standby Mode” option in
“i.LINK Setup”. (See Page 57.)
• Please do NOT use a loop connection as shown in the diagram.
Only an i.LINK cable is needed to connect the TV and the D-VHS deck. (VIDEO, S-VIDEO, and
AUDIO terminals need not be connected.)
• When using the i.LINK, do not turn off the power of, or pull the cable from i.LINK devices, even if that i.LINK devices is not in use. This may affect the picture and the sound from a D-VHS deck in use.
• If devices such as a DVD recorders, digital video cameras, computers and computer peripheral devices which are not compatible with this TV, are connected to the TV using i.LINK, other i.LINK
connections may be disrupted.
Using external equipment
Setting the recording mode (i.LINK)
• The function for automatically adjusting the recording mode of connected D-VHS decks can be turned on or off.
• Since most of the currently available D-VHS decks automatically recognize the transfer rates of the pictures and sound being recorded and control the recording mode accordingly, you should always set
this Mode to “Pass thru” in normal circumstances.
• Depending on the D-VHS deck used and the type of broadcast being recorded, this TV may not adjust the recording mode properly. In this case, please set the “Recording Mode” to “Pass thru”.
Setting the Standby Mode (i.LINK)
• Power consumption during standby mode can be minimized by changing the setting of the “Standby
Mode” in “i.LINK Setup”.
• When i.LINK is not in use, select “Inactive” in
“Standby Mode”.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Digital Setup”.
1
Press MENU and the MENU screen displays.
3
Press a/b to select “i.LINK Setup”, and then press ENTER.
2
Press c/d to select “Digital Setup”.
4
Press a/b to select “Standby Mode”, and then press ENTER.
3
Press a/b to select “i.LINK Setup”, and then press ENTER.
4
5
Press a/b to select “Recording Mode”, and then press ENTER.
Press c/d to select “Auto” or “Pass thru”, and then press ENTER.
• Normally, this should be set to “Pass thru”.
5
Press c/d to select “Active” or “Inactive”, and then press ENTER.
“Active”: Power continues to pass through the i.LINK
circuit so data can be relayed.
“Inactive”: Power consumption is minimized during stand-by mode. Data cannot be relayed at this setting.
NOTE
• When the main power of the TV is in standby mode
(POWER indicator lights off), i.LINK control commands cannot be received from a D-VHS deck. This does not change even if the “Standby Mode” is set to “Active”. To control the TV from a D-VHS deck, turn the TV power on
(POWER indicator lights up in blue).
• Data cannot be relayed between i.LINK devices when all the following conditions are met: 1) More than one i.LINK
device is connected to the TV with i.LINK cables, 2)
“Standby Mode” is set to “Inactive”, and 3) The power of the TV is in standby mode (POWER indicator lights off).
When the TV is connected between two i.LINK devices in series, select “Active” in “Standby Mode” or connect the
TV at an end of the series as shown in the diagram.
57
58
Using external equipment
Selecting a D-VHS deck (i.LINK)
• In order to control a D-VHS deck from the TV, you must first choose the D-VHS deck to be controlled.
• One D-VHS deck can be chosen from up to 16 i.LINK
connected decks.
• All D-VHS decks connected with i.LINK cables should automatically appear in the selection screen.
1
2
Press i.LINK to display the i.LINK control panel.
1 Model Input
STOP
0 0 : 0 0 : 0 0
D-VHS
PWR
PLAY
• When there is no D-VHS deck connected, the message “No i.LINK model is available” appears. In this case, please connect a D-VHS deck. (See page
56.)
• When there is no D-VHS deck selected, the selection screen appears. In this case, please go to step 3.
Press a/b/c/d to select “Model”, and press ENTER.
• Selection screen appears.
Type Manufacturer Model
NOTE
• Devices that cannot be used with this TV will not appear in the selection screen.
• When an item in the selection screen is grayed out, the item is not recognized by the TV and cannot be selected.
(The item may not be connected properly.)
Disabling the TV’s operation of a D-VHS deck (i.LINK)
• By disabling the TV’s operation of a D-VHS deck, the deck can be operated from another i.LINK
device.
1
• When there is no D-VHS deck connected, “No i.LINK
model is available” appears. Please connect one.
(See page 56.)
• When there is no D-VHS deck selected, the selection screen appears. Please go to step 3.
2
Press i.LINK to display the i.LINK control panel.
1
Model Input
STOP
0 0 : 0 0 : 0 0
D-VHS
PWR
PLAY
Press a/b/c/d to select “Model”, and press ENTER.
• Selection screen appears.
Type Manufacturer Model
3
Press a/b to select a device, and then press
ENTER.
• The control panel for the D-VHS deck appears.
3
Press b to select “Cancel Connection” and press ENTER.
• Operation of the D-VHS deck from the TV is disabled.
Type Manufacturer Model
Cancel Connection
Using external equipment
Deleting a preset D-VHS deck (i.LINK)
• Preset D-VHS decks can be selected from a list.
• If a D-VHS deck is connected, it cannot be deleted from the list.
1
2
3
4
Press c to select “Delete”, and then press
ENTER.
• The selected D-VHS deck is deleted from the list.
• Select “Cancel” to undelete a device.
Type Manufacturer Model
Press i.LINK to display the i.LINK control panel.
Cancel Connection
Press a/b/c/d to select “Selecting a device”, and then press ENTER.
1
Model Input
STOP
0 0 : 0 0 : 0 0
D-VHS
PWR
PLAY
Press a/b to select a device to be deleted, and then press ENTER.
Type Manufacturer Model
Controlling an i.LINK device
• An i.LINK compatible D-VHS deck can be controlled from the TV using the i.LINK control panel on the screen.
• The steps in “i.LINK Setup” on page 57 need to be completed beforehand.
• Please also refer to the operation manual of the D-
VHS deck to be used with this TV.
Basic operation
1
Press i.LINK to display the i.LINK control panel.
• The i.LINK button is also used to exit the i.LINK
control panel.
2
Press a/b/c/d to select a function, and then press ENTER.
i.LINK control panel
Status Display i.LINK device number
Manufucturer
Model
Go to Model
Selection screen
1
Model
Current operation
Tape Counter
PLAY
0 0 : 0 0 : 0 0
D-VHS
PWR
PLAY
Timer Status
(D-VHS recorder can not be operated when timer is set)
Function selected with the cursor
Cassette inserted
Type of Videotape/Tape Format
Write Protect on
(When the defeat tabs are broken recording is impossible)
Input
Select input
PWR
Power On/Off
STOP
PLAY
PAUSE
REC START
NOTE
• The input selection button is used to select either digital broadcasting or i.LINK input.
SKIP BACK
REWIND
FAST FORWARD
SKIP FORWARD
59
60
Using external equipment
NOTE
• Even when a connected D-VHS deck is playing, input signal can be switched to digital broadcasting by shifting the cursor to the input selection button and pressing
ENTER.
• This TV may not be able to operate some D-VHS decks using the control panel, or to display picture and/or sound input from some D-VHS decks.
• Depending on the D-VHS deck, this TV’s i.LINK may not allow viewing of VHS and S-VHS tape or analog recorded
D-VHS tape. In this case, connect the D-VHS deck’s analog output with the TV’s analog input, and switch the
TV’s input mode to external input.
• If a D-VHS deck is operated with the TV’s control panel during timer recording, the recording may fail. Do not use the TV’s control panel to operate the D-VHS deck during timer recording.
• When the TV’s control panel is used to record a program, what is recorded with the D-VHS deck are the pictures and sound of the digital program that the TV is receiving.
• To record the picture and sound of a digital program which the TV is receiving, use D-VHS tape. VHS or S-VHS tape will not record.
• The i.LINK control panel cannot be used during timer recording.
• There may be some programs which D-VHS decks cannot record.
• With some D-VHS decks, the quality of the picture may be distorted during fast forwarding or rewinding.
• IEEE 1394 is the IEEE’s international standard.
• i.LINK and the i.LINK logo are registered trademarks of
Sony Electronic, Inc.
• A copy protection technology is used on D-VHS decks that incorporate copyright protection. This technology has received the approval of the Digital Transmission Licensing
Administrator (DTLA), an organization that administers copyright protection technologies. Some picture and sound data have restrictions on duplication. Such data cannot be digitally copied using the i.LINK. Some picture and sound data may not be able to be sent back and forth between a D-VHS deck that has DTLA copyright protection technology and one that does not.
Automatic input switching to i.LINK
• Input mode can be set to automatically switch to i.LINK when a D-VHS deck connected to the TV is played.
1
2
3
4
5
Press MENU to display the MENU screen.
Press c/d to select “Digital Setup”, and then press ENTER.
Press a/b to select “i.LINK setup”, and then press ENTER.
Press a/b select “i.LINK Autoswitch”, and then press ENTER.
Press c/d to select “Yes”, and then press
ENTER.
i.LINK Autoswitch
Recording Mode
Standby Mode
Yes No
Using external equipment
Recording digital programs with a D-VHS deck (i.LINK)
• Before commencing this procedure, the steps in
“i.LINK Setup” on page 57 need to be completed beforehand.
• Please also refer to the operation manual of the D-
VHS deck to be used with this TV.
1
Select a digital program to be recorded.
2
Press i.LINK to display the i.LINK control panel.
1
Model Input
STOP
0 0 : 0 0 : 0 0
D-VHS
PWR
PLAY
3
Press a/b/c/d to select E, and then press
ENTER.
• Recording starts.
• Select
H and press ENTER to stop recording.
NOTE
• Input mode cannot be switched to i.LINK during recording.
• Some D-VHS decks may not be able to be operated using the TV’s i.LINK control panel.
• When a D-VHS deck connected to the TV is under timer recording, the deck cannot be operated using the TV’s control panel.
• When the TV’s control panel is used to record a program, what is recorded with the D-VHS deck are the pictures and sound of the digital program that the TV is receiving.
• To record the picture and sound of a digital program which the TV is receiving, use D-VHS tape. VHS or S-VHS tape will not record.
61
62
Useful adjustment settings
Image position (AV input mode only)
For adjusting a picture’s horizontal and vertical position.
1
2
4
Press MENU and the MENU screen displays.
Press c/d to select “Setup”.
3
Press a/b to select “Position”, and then press ENTER.
Press a/b to select “H-Pos.” or “V-Pos.”.
H-Pos.
V-Pos.
[ 0]
[ 0]
Reset
–10
–20
+10
+20
Moving the picture on the screen
You can move the picture around on the screen.
Press a/b/c/d to move an image on the screen to the desired position. Press ENTER to return to the initial image position.
NOTE
• While pressing a/b/c/d, an on-screen image,
“Adjusting Position” displays to the desired position.
• This setting cannot be stored. Once the TV shuts down or enters standby mode, the setting is erased. To move the picture around the screen again, you must perform the above procedure again.
• The image position setting using the steps on this page can be stored. Select either according to your objectives.
• “TV”, “INPUT1”, “INPUT2”, “INPUT3” and “INPUT4” can each adjust the image position setting on this page. The same for view modes.
• An on-screen image from PC and card cannot be moved around.
• Even when the image fills the screen, its position can be adjusted with this function.
• Press ENTER to reset the image to original positions.
5
Press c/d to adjust the item to your desired position.
NOTE
• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press
ENTER.
• Adjustments are stored separately according to input
source.
• You can easily move the image position as shown on this page, but when the power is switched off the image will return to the previously memorized position.
Selected item
H-Pos.
V-Pos.
Description
Centers the image by moving it to the left or right.
Centers the image by moving it up or down.
Useful adjustment settings
Connecting external speakers
Rear view
How to connect the speaker cable
Push down the tab.
Insert the end of the cable.
3
Lift the tab back up.
When using external speakers
• Change the speaker setting to external speakers. (See page 64.)
Make sure to connect the speaker terminal and cable polarity (
L, +) properly
• The speaker terminals have plus (
L) and minus (+) polarity.
• Plus is red and minus is black.
• The cables are also divided into plus and minus.
• When connecting the left/right speakers, be sure to connect the plus/minus terminals with the correct cables.
CAUTION
• Make sure external speakers have 4 ohm and 10 watt specifications.
• Connect the plus/minus terminals with the correct cables.
Incorrect connection may cause a short.
NOTE
• Unplug the AC cord from the AC outlet before installing the speakers.
63
64
Useful adjustment settings
Audio Quality Control
Audio Quality Control automatically optimizes the audio quality to suit internal (supplied) speakers.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Setup”.
3
Press a/b to select “Speaker Setup”, and then press ENTER.
4
Select “Audio Quality Control”, and then press ENTER.
5
Press c/d to select “Equalizer” or “Flat”, and then press ENTER.
Selected item
Equalizer
Flat
Description
Sets the optimum Audio Quality Control for the attached speakers.
When you are using your own speakers, output the original sound without using
Audio Quality Control.
NOTE
• When DOLBY Virtual is on, Audio Quality Control automatically sets to Flat.
Useful adjustment settings
Auto Sync. adjustment (PC input mode only)
For automatically adjusting the PC image.
1
Press MENU and the MENU screen displays.
Fine Sync. adjustment (PC input mode only)
Ordinarily you can easily adjust the picture as necessary to change image position using Auto Sync.
In some cases, however, manual adjustment is needed to optimize the image.
2
Press c/d to select “Setup”.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Setup”.
3
Press a/b to select “Auto Sync.”, and then press ENTER.
4
Press c/d to select “Yes”, and then press
ENTER.
• Auto Sync. starts and “Now adjusting the image” displays.
MENU [Setup ... Auto Sync.]
3
4
Press a/b to select “Fine Sync.”, and then press ENTER.
Press a/b to select the specific adjustment item.
Yes No
H-Pos.
V-Pos.
Clock
Phase
Reset
[ 90]
[ 39]
[ 90]
[ 20]
–
–
–
–
+
+
+
+
30%
NOTE
• When Auto Sync. is successful, “Auto Sync completed successfully” displays. If not, Auto Sync. failed.
• Auto Sync. may fail even if “Auto Sync completed successfully” displays.
• Auto Sync. may fail if the computer image has low resolution, has unclear (black) edges, or is moved while executing Auto Sync.
• Be sure to connect the PC to the TV and switch it on before starting Auto Sync.
5
Press c/d to adjust the item to your desired position.
NOTE
• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press
ENTER.
Selected item
H-Pos.
V-Pos.
Clock
Phase
Description
Centers the image by moving it to the left or right.
Centers the image by moving it up or down.
Adjusts the clock frequency.
Adjusts the clock phase.
65
66
Useful adjustment settings
Input Select
INPUT button
Selecting input source
Use this menu to select the input source.
1
Press INPUT.
• A list of selectable sources appears.
2
Press INPUT again to select the input source.
• An image from the selected source automatically displays.
• You can also select the input source by pressing a/b.
• If the corresponding input is not plugged in, you cannot change the input. Be sure to connect the equipment beforehand.
Selecting input signal type
For setting the signal type of external equipment connected to INPUT 1 and Input 2 terminals.
1
2
Display
Press MENU and the MENU screen displays.
Press c/d to select “Option”.
DVI input signal setting
1
Press INPUT to select INPUT5.
INPUT SOURCE
TV
INPUT1
INPUT2
INPUT3
INPUT4
2
3
4
i.LINK
CARD
Press MENU and the MENU screen displays.
Press c/d to select “Option”.
Press a/b to select “Input Select”, and then press ENTER.
MENU [Option ... Input Select]
Option
Audio Only
Input Select
Output Select
Quick Shoot
[ANALOG PC]
Center Channel Input
[Fixed]
[Off]
[Off]
5
3
Press a/b to select “Input Select”, and then press ENTER.
4
Press a/b to select a signal type you want to set, and then press ENTER.
• If the selected signal type is incorrect, images are not displayed or displayed without any color.
NOTE
• If you set INPUT1 and INPUT2 to Auto, the TV will automatically select the input signal.
• Check the operation manual of the external equipment for the signal type.
• Setting INPUT 1 and INPUT 2 signal selection to “Auto” when other equipment is connected will result in the following connectivity priority.
INPUT 1 and INPUT 2
1. COMPONENT VIDEO
2. VIDEO
Press a/b to select the equipment connected to INPUT 5 terminal, and then press ENTER.
MENU
[Option ... Input Select]
DIGITAL PC
ANALOG PC
DIGITAL AV
ANALOG AV
Useful adjustment settings
Input Label
Lets you set the input terminal displayed using the
INPUT SOURCE menu or channel display.
Picture Flip
You can set the orientation of the picture.
1
Repeat steps 1 and 2 in Input Label.
2
3
Press a/b to select “Picture Flip”, and then press ENTER.
Press a/b to select the desired mode, and then press ENTER.
[Standard]: normal image.
ABC
1
2
Press MENU and the MENU screen displays.
Press c/d to select “Setup”.
3
4
Press a/b to select “Input Label”, and then press ENTER.
Press a/b/c/d to select the new name for the channel, and then press ENTER.
INPUT SOURCE
TV
DVD
INPUT2
INPUT3
INPUT4 i.LINK
CARD
(Example)
NOTE
• You cannot change labels if the INPUT SOURCE is TV, i.LINK or CARD.
[Mirror]: mirror image.
ABC
[Upside Down]: upside down image.
[Rotate]: rotated image.
ABC
ABC
67
68
Useful adjustment settings
AV MODE
AV MODE gives you six viewing options to choose from to best match environment of the TV, which can vary due to factors like room brightness, type of program watched or the type of image input from external equipment.
View mode for 4:3 Programs
1
Press VIEW MODE.
• The View mode menu displays.
• The menu lists the view mode options selectable for the type of video signal currently received.
2
Press VIEW MODE or a/b while the View mode menu is still on the screen.
• You can sequentially select a view mode that has its own aspect ratio.
1
Press AV MODE.
• Present AV MODE displays.
2
Press AV MODE again before the mode displayed on the screen disappears.
• The mode changes as shown below.
Mode selection for TV, INPUT 1 to 5, i.LINK and CARD mode (Example)
AV MODE: STANDARD AV MODE: MOVIE
AV MODE: DYNAMIC
AV MODE: DYNAMIC (Fixed)
AV MODE: GAME
AV MODE: USER [ANALOG-A]
View Mode
Side Bar
S. Stretch
Zoom
Stretch
Side Bar:
Suitable for viewing conventional 4:3 programs in their normal format.
Mode selection for the PC terminal
(Example)
AV MODE: STANDARD AV MODE: USER [PC]
Selected item
STANDARD
MOVIE
GAME
USER
DYNAMIC
(Fixed)
DYNAMIC
Description
For a highly defined image in a normally bright room
For a movie
Lowers image brightness for easier viewing
Allows the user to customize settings as desired. You can set the mode for each input source.
Changing image and sound settings to factory preset values. No adjustments are allowed.
For a clear-cut image emphasizing high contrast for sports viewing
NOTE
• You can select a different AV MODE item for each input mode. (For example, select STANDARD for TV input and
DYNAMIC for VIDEO input.)
• When AV MODE is set to DYNAMIC (Fixed), “No picture adjustments available in Dynamic (Fixed) mode” displays.
S.Stretch: Suitable for stretching
(Smart stretch)
4:3 programs to fill the screen.
Zoom:
Suitable for viewing wide-screen 2.35:1 anamorphic DVDs in full screen.
Stretch:
This mode is useful for 1.78:1 DVDs.
When viewing 1.85:1
DVDs, stretch mode will still show very thin black bands at the top and bottom of the screen.
Useful adjustment settings
a
Input signal
(640m480)
View Mode
Normal
Zoom
Stretch
Dot by Dot
Input signal
(1024m768)
View Mode
Zoom
Stretch
Dot by Dot a
Screen size images.
Input signal Normal Zoom
View mode (for PC input mode)
You can select the screen size.
NOTE
• Connect the PC before making adjustments. (See page
55.)
• Selectable screen size may vary with input signal type.
1
Press VIEW MODE.
• The View mode menu displays.
2
Press VIEW MODE or a/b to select a desired item on the menu.
Stretch Dot by Dot
ex. 640g480 Keeps the original aspect ratio in a full screen display.
Keeps the original aspect ratio in a full screen display. The top and bottom of the image is slightly cropped.
An image fully fills the screen.
Detects the resolution of the signal and displays an image with the same number of pixels on the screen.
Input signal
1024g768
Normal Zoom Stretch Dot by Dot
Keeps the original aspect ratio in a full screen display. The top and bottom of the image is slightly cropped.
An image fully fills the screen.
Detects the resolution of the signal and displays an image with the same number of pixels on the screen.
69
70
Useful adjustment settings
Input signal (for PC input mode)
• Some input signals may have to be registered manually to display properly.
• The pairs of input signals (resolutions) in the list below are not distinguishable when received. In such case, you have to set the correct signal manually. After setting once, it will display when the same signal (resolution) is input again.
640g400
640g480
1024g768
720g400
848g480
1280g768
NOTE
• You can only select the “Input Signal” on the Setup menu when receiving one of the 6 input signals listed above.
Digital Noise Reduction
Produces a clearer video image.
1
2
3
4
Press MENU and the MENU screen displays.
Press c/d to select “Option”.
Press a/b to select “Digital Noise
Reduction”, and then press ENTER.
Press a/b to select the desired level, and then press ENTER.
Off
High
Low
1
2
3
4
Press MENU and the MENU screen displays.
Audio Only
When listening to music from a music program, you can set the Liquid Crystal display off and enjoy audio only.
Press c/d to select “Setup”.
1
Press a/b to select “Input Signal” and then press ENTER.
2
Repeat steps 1 and 2 in Digital Noise
Reduction.
Press a/b to select “Audio Only”, and then press ENTER.
Press a/b to select the desired input signal on the display.
Example
3
Press c/d to select “On”, and then press
ENTER.
640 x 480
848 x 480
Selected item Description
Audio is output without screen image.
On
Off
Both screen images and audio are output.
Useful adjustment settings
Output Select
Allows you to select what controls the audio output.
1
Press MENU and the MENU screen displays.
Sleep timer
Allows you to set a time when the TV automatically switches to standby.
2
Press c/d to select “Option”.
3
4
Press a/b to select “Output Select”, and then press ENTER.
Press c/d to select “Fixed” or “Variable”, and then press ENTER.
Selected item
Fixed
Variable
Description
• Sound via speaker is adjusted with VOL k/l on the remote control unit or VOL l/ k on the Display.
• Sound via the MONITOR OUTPUT terminal is not adjustable and constantly outputs.
• Sound via the MONITOR OUTPUT terminal is adjusted with VOL k/l on the remote control unit or VOL l/k on the Display.
• Sound via speaker is muted.
1
2
Press SLEEP.
• Remaining time displays when sleep timer has been set.
Sleep Timer: Remaining 30
Each time you press SLEEP, the remaining time switches as shown below.
• When set, the time automatically starts counting down.
• If you want to adjust the sleep timer, you can press SLEEP twice then change the time setting.
• Five minutes before time expires, the remaining time displays each minute.
Quick Shoot
Use Quick Shoot Operation to record action video more clearly.
Sleep Timer: Off
Sleep Timer: 30
1
Repeat steps 1 and 2 in Output Select.
Sleep Timer: 60
2
Press a/b to select “Quick Shoot”, and then press ENTER.
3
Press c/d to select “On”, and then press
ENTER.
NOTE
• Quick Shoot may cause image noise. If this occurs turn the function “Off”.
Sleep Timer:
Sleep Timer:
90
120
NOTE
• Select “OFF” by pressing SLEEP to cancel the sleep timer.
• If the sleep timer is activated when set to zero, the TV will enter STANDBY mode.
71
72
Useful adjustment settings
Title Display Type
Select the CH display for Digital broadcasting.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Option”.
3
4
Press a/b to select “Title Display Type”, and then press ENTER.
Press c/d to select “Yes” or “No”, and then press ENTER.
Selected item
Yes
No
Description
“Program information” displays
“Program information” does not display
Useful adjustment settings
Closed caption
• Your TV is equipped with an internal closed caption decoder. Closed caption is the system which allows you to view conversations, narration, and sound effects in TV programs and home videos as subtitles on your
Display.
• Digital Closed Caption which is new service on Digital TV programs allow broadcatser to change caption size and font style and so on. “ENG”(English) or “SPA”(Spanish) or “FRA”(French) or other language codes will be displayed on the screen.
• Not all programs and videos offer closed caption. Please look for the “
N” symbol to ensure that captions will be shown.
• “CC1” or “CC2” displays subtitles of TV dramas and news programs while allowing a full view of the picture.
• “Text1” or “Text2” superimposes on the picture other information (e.g. TV guide, weather) that is independent of the TV in progress.
1
Press CC.
• Present Closed caption information displays.
2
Press CC while the Closed caption information is still on the screen.
• You can sequentially select a closed caption service which you prefer.
ANALOG-A Air
2
Audio : MONO
CC : 1/2 CC1 Closed caption information
• Depending on the signal, information such as
1/4 or 1/2 will appear.
1/2 shows the first of two services.
Example:
If a program has three services(Digital
CC(ENG), CC1 and Text1), closed caption toggles like below.
1/3 ENG 2/3 CC1 3/3 Text1 OFF
• If selected service has gone and there are the other services, the other service will be selected temporarily and service name on the screen will be displayed with round brackets “( )”.
Examples:
If digital CC has gone after a program has two services(Digital CC(ENG) and CC1), closed caption information will be change like below.
1/2 ENG 1/1 CC1
NOTE
• See page 74 to 76 for the detailed closed caption settings.
• When using Twin Picture functions (see page 86), Closed
Caption on the program of the active screen will be displayed.
• When using Freeze functions, closed caption will not be displayed on the right screen (still image).
• When the program contains no closed caption, “--” displays in the closed caption information.
• If the language code, e.g.“ENG”, is not found on Digital
TV programs, “--” will be shown.
• Four kinds of closed caption service(CC1, CC2, Text1,
Text2) are available. However, selectable service(CC1,
CC2, Text1, Text2) are depends on the programs contains.
73
74
Useful adjustment settings
Caption Size
Select a caption size.
1
Press MENU and the MENU screen displays.
Font Style
Select a font style.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Option”.
2
Press c/d to select “Option”.
3
Press a/b to select “Caption Setup”, and then press ENTER.
3
Press a/b to select “Caption Setup”, and then press ENTER.
4
Press a/b to select “Caption Size”.
4
Press a/b to select “Font Style”.
5
A B C
1 2 3
Caption Size
Font Style
Foreground Color
Foreground Opacity
Background Color
Background Opacity
Character Edge
Reset
Default
Default
Default
Default
Default
Default
Default
Press c/d to select the desired size.
5
Press c/d to select the desired style.
NOTE
• Default: The caption size specified by broadcasting station or default size.
• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press
ENTER.
Type 0
Type 1
Type 2
Type 3
Type 4
Type 5
Type 6
Type 7
Selected item
Default
Description
The font specified by broadcasting station or default font.
Proportional font used in the MENU screen.
Monospaced with serifs.
Proportionally spaced with serifs.
Monospaced without serifs.
Proportionally spaced without serifs.
Casual font type.
Cursive font type.
Small capitals.
NOTE
• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press
ENTER.
Useful adjustment settings
Foreground Color
Select a character foreground color.
1
Press MENU and the MENU screen displays.
Foreground Opacity
Select a foreground opacity value.
1
Repeat steps 1 to 3 in Foreground Color.
2
Press c/d to select “Option”.
2
Press a/b to select “Foreground Opacity”.
3
Press a/b to select “Caption Setup”, and then press ENTER.
4
Press a/b to select “Foreground Color”.
3
Press c/d to select the desired value.
NOTE
• Default: The foreground opacity value specified by broadcasting station or default opacity value.
• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press
ENTER.
A B C
1 2 3
Caption Size
Font Style
Foreground Color
Foreground Opacity
Background Color
Background Opacity
Character Edge
Reset
Default
Default
Default
Default
Default
Default
Default
5
Press c/d to select the desired color.
Background Color
Select a character background color.
1
Repeat steps 1 to 3 in Foreground Color.
2
Press a/b to select “Background Color”.
NOTE
• Default: The foreground color specified by broadcasting station or default color.
• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press
ENTER.
3
Press c/d to select the desired color.
NOTE
• Default: The background color specified by broadcasting station or default color.
• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press
ENTER.
75
Useful adjustment settings
Background Opacity
Select a background opacity value.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Option”.
3
Press a/b to select “Caption Setup”, and then press ENTER.
4
Press a/b to select “Background Opacity”.
A B C
1 2 3
Caption Size
Font Style
Foreground Color
Foreground Opacity
Background Color
Background Opacity
Character Edge
Reset
Default
Default
Default
Default
Default
Default
Default
5
Press c/d to select the desired value.
NOTE
• Default: The background opacity value specified by broadcasting station or default opacity value.
• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press
ENTER.
Character Edge
Select a character edge.
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Option”.
3
Press a/b to select “Caption Setup”, and then press ENTER.
4
Press a/b to select “Character Edge”.
5
Press c/d to select the desired setting.
76
NOTE
• Default: The character edge specified by broadcasting station or default edge.
• For resetting all adjustment items to the factory preset values, press a/b to select “Reset”, and then press
ENTER.
Useful adjustment settings
Secret number setting for parental control (AV input mode only)
Allows you to use a secret number to protect certain settings from being accidentally changed.
IMPORTANT:
Three conditions must be met to enable V-Chip (see pages 79 to 83):
1 Secret No. is registered.
2 V-Chip settings have been made.
3 “Status” is set to “On”.
5
Select “New Secret No.”, and then press
ENTER.
Input the new 4-digit secret number by using
0 – 9.
New Secret No.
Secret No. Clear
Input Secret No.
– – – –
– – – –
New Secret No.
Reconfirm – – – –
6
Input the same 4-digit number on the
“Reconfirm” screen as in step 5 to confirm.
New Secret No.
Secret No. Clear
Input Secret No.
New Secret No.
Reconfirm
– – – –
* * * *
– – – –
Setting a secret number
1
2
3
4
Press MENU and MENU screen displays.
Press c/d to select “Setup”.
Press a/b to select “Parental CTRL”, and then press ENTER.
Press a/b to select “Secret No.”, and then press ENTER.
TV MENU [Setup ... Parental CTRL]
V-Chip
Secret No.
Status
7
Press RETURN to start configuring V-Chip settings. (See pages 80 and 82 for details.)
Setting parental control status
Used to enable or disable the parental control function.
1
Repeat steps 1 to 3 in Setting a secret
number.
• Secret number setting menu displays.
2
Input the 4-digit secret number by using 0 –
9.
3
Press a/b to select “Status”, and then press
ENTER.
4
Press c/d to select “On” or “Off”, and then press ENTER.
• Select “On” to enable and “Off” to disable
Parental CTRL.
V-Chip
Secret No.
Status
On Off
NOTE
• You can skip step 1 and 2 above while in Parental CTRL screen.
77
78
Useful adjustment settings
Clearing the secret number
Allows you to clear your secret number.
Changing the secret number
Allows you to change your current secret number.
1
Repeat steps 1 to 3 in Setting a secret
number.
• Secret number setting menu displays.
2
Input the 4-digit secret number by using 0 –
9.
3
Press a/b to select “Secret No.”, and then press ENTER.
4
Press a/b to select “New Secret No.”, and then press ENTER.
5
Input the old 4-digit number you have set using 0 – 9.
MENU [Setup ... Parental CTRL]
New Secret No.
Secret No. Clear
Input Secret No.
New Secret No.
Reconfirm
– – – –
– – – –
– – – –
6
Input the new 4-digit number using 0 – 9.
New Secret No.
Secret No. Clear
Input Secret No.
– – – –
New Secret No.
Reconfirm
– – – –
– – – –
1
Repeat steps 1 to 3 in Setting a secret
number.
• Secret number setting menu displays.
2
Input the 4-digit secret number by using 0 –
9.
3
Press a/b to select “Secret No.”, and then press ENTER.
4
Press a/b to select “Secret No. Clear”, and then press ENTER.
5
Press c/d to select “Yes”, and then press
ENTER.
• Your secret number is cleared.
New Secret No.
Secret No. Clear
Yes No
NOTE
• See page 77 for re-registering with a new secret number after being cleared.
• As a precautionary measure, make a note of your
secret number and keep it in a familiar place. If you lose or forget your secret number, initialize the
Liquid Crystal Television to return all settings except for the TV channel settings to factory preset values.
(See page 100.)
• If the secret number is cleared the Status setting automatically sets to “Off”. “V-Chip” and “Status” will not be selectable from the menu.
7
Input the same 4-digit number on the
“Reconfirm” screen as in step 6 to confirm.
New Secret No.
Secret No. Clear
Input Secret No.
– – – –
New Secret No.
Reconfirm
* * * *
– – – –
Useful adjustment settings
Parental control (setting V-CHIP level)
V-CHIP is an electronic filtering device built into your TV. This tool gives parents a great degree of control over broadcasts accessed by their children. It allows parents to select programs judged suitable for child viewing while blocking ones judged not suitable. It does so automatically once you activate the V-CHIP feature in your
Liquid Crystal Television.
“V-Chip” and “Status” will not be selectable from the menu if you do not first configure your secret
number. (See page 77 for Secret number setting for parental control.)
• The U.S. has two rating systems for viewing content: TV Parental Guidelines and movie ratings.
• The TV Parental Guidelines work in conjunction with the V-CHIP to help parents screen out inappropriate television shows from their children.
• Movie ratings are used for original movies rated by the Motion Picture Association of America (MPAA) as watched on cable TV and not edited for television. The V-CHIP can also be set to block MPAA-rated movies.
Voluntary movie rating system (MPAA)
Age
Rating
G
PG
PG-13
R
NC-17
X
MENU [Setup ... Parental CTRL]
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings
Description
General audiences. All ages admitted.
Parental guidance suggested. Some material may not be suitable for children.
Parents strongly cautioned. Some material may be inappropriate for children under 13.
Restricted. Under 17 requires accompanying parent or adult guardian (age varies in some jurisdictions).
No one 17 and under admitted.
X is an older rating that is unified with NC-17 but may be encoded in the data of older movies.
G
PG
PG-13
R
NC-17
X
NONE a
• If you select “PG-13”, this will automatically block the higher ratings
“R”, “NC-17” and “X”.
NOTE
• Voluntary movie rating system only uses an age-based rating.
TV Parental Guidelines
Rating
Suggested age
TV-Y (All children)
TV-Y7 (Directed to older children)
TV-G (General audience)
TV-PG (Parental Guidance suggested)
TV-14 (Parents strongly cautioned)
TV-MA (Mature audience only)
X: Content rating can be set.
FV
(Fantasy violence)
V
(Violence)
Content
S
(Sexual situation)
L
(Adult language)
D
(Sexually suggestive dialog)
X
X
X
X
X
X
X
X
X
X
X
X
79
80
Useful adjustment settings
Voluntary movie rating system (MPAA)
1
2
3
Press a/b to select “Parental CTRL”, and then press ENTER.
• Secret number setting menu displays only when “Secret No.” is set. (See page 77.)
• “V-Chip” and “Status” will not be selectable from the menu if you do not first configure your secret number. (See page 77.)
4
Input the 4-digit secret number by using 0 –
9.
5
Press a/b to select “V-Chip”, and then press
ENTER.
MENU
[Setup ... Parental CTRL]
V-Chip
Secret No.
Status
6
Press MENU and the MENU screen displays.
Press c/d to select “Setup”.
Press a/b to select “MPAA”, and then press
ENTER.
TV Parental Guidelines (TV Guidelines)
1
Repeat steps 1 to 5 in Voluntary movie
rating system (MPAA).
2
Press a/b to select “TV Guidelines”, and then press ENTER.
3
Press a/b to adjust the item to your desired position. “ ” indicates the item is blocked.
• The setting automatically enters “Block” for any ratings below your selection.
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
NONE
D
L
S
V
FV
When setting an individual content-based rating item, do as follows:
1 Press d to access block content items from the currently selected age-based rating item.
2 Press a/b to select an individual item, and then press ENTER to unblock (“ ” is removed). Repeat the same steps for other items.
3 Press c or RETURN to register after all individual content rating items are set.
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
NONE
D
L
S
V
FV
• If Status is not set to “On” the configuration settings will not work. (See page 77.)
7
Press a/b to adjust the item to your desired position. “ ” indicates the item is blocked.
Press RETURN.
• The setting automatically enters “Block” for any ratings below your selection.
• If Status is not set to “On” the configuration settings will not work. (See page 77.)
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings
G
PG
PG-13
R
NC-17
X
NONE
Useful adjustment settings
Canadian Rating Systems
• The TV rating systems in Canada are based on the Canadian Radio-Television and Telecommunications
Commission (CRTC) policy on violence in television programming.
• While violence is the most important content element to be rated, the structure developed takes into consideration other program content like language, nudity, sexuality and mature themes.
• When setting the V-CHIP on the Canadian system you can choose either the Canadian English ratings or the
Canadian French ratings.
Canadian English ratings
Age
Rating
E
C
C8e
G
PG
14e
18e
Description
Exempt: Includes news, sports, documentaries and other information programming; talk shows, music videos, and variety programming.
Children: Intended for younger children under the age of 8 years. Pays careful attention to themes that could threaten their sense of security and well-being.
Children over 8 years old: Contains no portrayal of violence as the preferred, acceptable, or only way to resolve conflict; nor encourage children to imitate dangerous acts which they may see on the screen.
General: Considered acceptable for all age groups. Appropriate viewing for the entire family, contains very little violence, physical, verbal or emotional.
Parental Guidance: Intended for a general audience, but may not be suitable for younger children (under the age of 8) because it could contain controversial themes or issues.
Over 14 Years: Could contain themes where violence is one of the dominant elements of the storyline, but it must be integral to the development of plot or character. Language usage could be profane and nudity present within the context of the theme.
Adults: Intended for viewers 18 years and older and might contain depictions of violence, which while related to the development of plot, character or themes, are intended for adult viewing. Could contain graphic language and portrayals of sex and nudity.
Canadian French ratings
Age
Rating
E
G
8anse
13anse
16anse
18anse
Description
Exempt programming.
General: All ages and children, contains minimal direct violence, but may be integrated into the plot in a humorous or unrealistic manner.
General but inadvisable for young children: May be viewed by a wide public audience, but could contain scenes disturbing to children under 8 who cannot distinguish between imaginary and real situations. Recommended for viewing with parent.
Over 13 years: Could contain frequent violent scenes and therefore recommended for viewing with parent.
Over 16 years: Could contain frequent violent scenes and intense violence.
Over 18 years: Only for adult viewing. Could contain frequent violent scenes and extreme violence.
81
82
Useful adjustment settings
Canadian English ratings
1
2
3
4
Press MENU and the MENU screen displays.
Press c/d to select “Setup”.
Press a/b to select “Parental CTRL”, and then press ENTER.
• Secret number setting menu displays only when “Secret No.” is set. (See page 77.)
• “V-Chip” and “Status” will not be selectable from the menu if you do not first configure your secret number. (See page 77.)
Input the 4-digit secret number by using 0 –
9.
MENU [Setup ... Parental CTRL]
Setup Option
Secret No.
– – – –
5
Press a/b to select “V-Chip”, and then press
ENTER.
V-Chip
Secret No.
Status
7
Press a/b to adjust the item to your desired position. “ ” indicates the item is blocked.
• The setting automatically enters “Block” for any ratings below your selection.
• If Status is not set to “On” the configuration settings will not work. (See page 77.)
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings
E
C
C8+
G
PG
14+
18+
NONE
Canadian French ratings
1
Repeat steps 1 to 5 in Canadian English
ratings.
2
Press a/b to select “Can. French Ratings”, and then press ENTER.
3
Press a/b to adjust the item to your desired position. “ ” indicates the item is blocked.
• The setting automatically enters “Block” for any ratings below your selection.
• If Status is not set to “On” the configuration settings will not work. (See page 77.)
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings
E
G
8ans+
13ans+
16ans+
18ans+
NONE
6
Press a/b to select “Can. English Ratings”, and then press ENTER.
Useful adjustment settings
How to temporarily release the V-CHIP
BLOCK
• The V-CHIP BLOCK is working and censors a broadcast, “V-CHIP HAS BEEN ACTIVATED.” displays.
1
Press ENTER while the V-CHIP is working and then the secret number setting menu displays.
2
Enter your 4-digit secret number with 0 – 9 and then press ENTER. At this time V-CHIP
BLOCK temporarily releases.
Reactivating the temporarily released
V-CHIP BLOCK
• You can reactivate the temporarily released V-CHIP
BLOCK as shown below.
Method 1:
Select “Status” setting from the Parental CTRL menu to reactivate BLOCK. See page 77.
Method 2:
Select “V-Chip” setting (“MPAA”, “TV Guidelines”,
“Can. English Ratings” or “Can. French Ratings”) from the Parental CTRL to reactivate BLOCK. See pages 80 and 82.
Method 3:
Switch off the TV power.
NOTE
• Performing any of the three above will activate the V-CHIP
BLOCK.
83
Useful adjustment settings
Center Channel Input
You can use the display speakers as center speaker when using 5.1ch surrounding sound system.
Display speaker
* Connect to external audio equipment which supports 5.1ch surround sound system.
Refer to your external equipment operation manual for details.
84
1
Press MENU and the MENU screen displays.
2
Press c/d to select “Option”, and then press
ENTER.
3
Press a/b to select “Center Channel Input”, and then press ENTER.
4
Press c/d to select “On” , and then press
ENTER.
On Off
NOTE
• Sound from Center Channel Input terminal is output from the display speaker.
Other viewing options
Viewing a list of Digital broadcast channels
You can view a list of all currently watchable digital broadcast channels.
Viewing information of the program
You can view information about a digital broadcast you are currently watching.
1
2
3
Press CH LIST while watching a digital broadcast.
• A list of all digital channels (Air or Cable) currently watchable will be displayed.
Broadcast station
Air/Cable
CH LIST
[DIGITAL Air]
CH.
Number
2.1
2.2
2.10
WGBH-SD
PBS-HD
WGBH-DX
(Example) Channel List Screen for Air
Broadcasts
Press a/b to select the channel you want to watch, and then press ENTER to display the selected channel.
1
Press INFO while watching a digital broadcast.
• Information of the current program will be displayed.
Broadcast station
Program
WGBH-SD
WGBH DTV Broadcast Signal
Program information
Input Info.
Video
Audio
CC
Ratings
Optic.
REC i.LINK
REC
480i
STEREO
- -
- -
OK
OK
Sample program information
NOTE
• Sometimes the name of the program is not broadcast. In that case, the program name will not be displayed.
Press c/d to scroll between pages of the
Channel List.
85
Other viewing options
Twin picture functions
Allows you to display two pictures on the screen at one time.
Twin picture in all cases
You can display two same-sized pictures except when inputting from INPUT 4 (HDMI) and INPUT 5 (DVI-I) terminals and CARD.
Picture and still image
You can display two same-sized pictures – one moving and one still.
1
Press TWIN PICTURE.
• Twin picture displays and a selected input source image displays.
1
Press FREEZE.
• A moving image displays on the left screen and a still image displays on the right screen. The still image is one frame captured from a moving image at the moment you press FREEZE.
86
FREEZE
2
3
Press SELECT to set either screen to be active.
• “ z” displays on the active screen, which has sound output.
Press TWIN PICTURE to exit twin picture.
2
3
Update the still image by pressing ENTER.
• Each time you press ENTER, the image on the right screen updates.
• If a PC card with enough capacity is inserted in the system, a message will appear on the screen asking you whether to save the image.
Press REC on the remote control if you want to save. (See page 44.)
NOTE
• This function does not work under the following input conditions:
1INPUT 4 (HDMI)
2INPUT 5 (DVI-I)
3CARD
4Two pictures from the same source (e.g. INPUT 1 and
INPUT 1)
5An image will appear on the right side only if it is a 480i signal.
*An SDTV image has a 480p signal, so it will not appear either.
• When this function is not available, “No dual screen display available” will display.
• Pressing ANALOG-A, B, DIGITAL while viewing in Twin
Picture mode (TV image and video image) with TV selected will display the TV image of the other tuner.
Press FREEZE to exit still image.
NOTE
• This function does not work in INPUT 4 (HDMI), INPUT 5
(DVI-I) and CARD.
• When this function is not available, “No displaying still image available” will display.
• Another image can be saved if a PC card with enough capacity is inserted in the system.
• The still image is automatically erased after 30 minutes.
• If you are using FREEZE and a broadcast activates the V-
CHIP BLOCK, FREEZE will cancel and a block message will appear.
Other viewing options
Presetting remote control function
You can operate the connected AV products (AV
Receiver, Cable Box, SAT tuner, DTV, VCR, DVD, LD) using the presetting manufacturer function for your remote control unit.
Presetting manufacturer codes
1
Press FUNCTION until the LED for your device lights up.
2
After the LED for your device lights up, if you press FUNCTION for three seconds and enter the code registration mode, the LED will blink.
3
Press 0 – 9 to enter the manufacturer code.
(See page 88.)
• Preset mode is finished once the LED no longer lights up.
4
After registering the code, the LED will stop blinking then turn off after one second. (If you perform an incorrect operation, the LED will blink quickly then turn off.)
87
88
Other viewing options
Manufacturer codes
VCR BRAND
Mitsubishi
Montgomery Ward
Multitech
NEC
Panasonic
Pentax
Philco
Philips
RCA
Realistic
Samsung
Sanyo
Scott
Sears
Sharp
Shintom
Sony
Sound Design
Sylvania
Symphonic
Tatung
Teac
Teknika
Thomas
TMK
Toshiba
Video Concepts
Yamaha
Zenith
Akai
Audio
Broksonic
Canon
Capehart
Craig
Curtis Mathis
Daewoo
DBX
Dynatech
Emerson
Fisher
Funai
G.E.
Goldstar
Hitachi
Instant Replay
JC Penney
JVC
Kenwood
Lloyds
Magnavox
Magnin
Marantz
Memorex
Minolta
REMOTE CONTROL
CODE NUMBER
29
15, 22, 30
44, 45
05, 06
05
05, 08
06, 07, 33, 51
01, 02, 10, 24
23, 31
10, 14, 52
20
06, 11, 24
01, 02, 03
36
12, 13, 38
29
05, 08
29
15
15, 29
27, 29
29
21
19, 20
30
15, 29, 30
16
25, 26, 37
15, 22, 30
32
04
34
10, 31
04
34
15, 22, 30
29
21, 32, 35
09, 10, 11
28, 29
04
24
06, 47
04
04, 06, 24, 30
15, 41, 42, 53
14, 15
29
04, 05, 08
31
30
04, 10, 24, 29
06
17, 18, 39, 40
02, 43
DVD/LD BRAND
Denon
JVC
Kenwood
Magnavox
Marantz
Mitsubishi
Panasonic
Philips
Pioneer
Proscan
RCA
Samsung
Sharp
Sony
Toshiba
Yamaha
Zenith
REMOTE CONTROL
CODE NUMBER
02
09, 13
21
04
04
06
02, 22
04, 23
08, 11, 20
03
03, 24
07, 12
01, 10
05, 25
04
02
04
CATV CONVERTER
BRAND
Anvision
Cable Star
Eagle
General Instrument
Jerrold
Magnavox
Oak Sigma
Panasonic
Philips
Pioneer
Randtek
RCA
Scientific Atlanta
Sony
Viewstar
Zenith
REMOTE CONTROL
CODE NUMBER
04, 05
04, 05
05
02, 03, 07, 12, 13, 14,
19, 22
02, 03, 07, 12, 13, 14,
19, 22, 31, 32, 33, 34,
35, 36, 37, 38, 39, 40
04, 05, 09, 14, 17, 18,
20, 21, 24, 25
8
16, 23
04, 05, 09, 15, 17, 18,
20, 21, 24, 25
08, 10, 29, 30, 46
04, 05
16, 27, 44, 45
01, 26
28
04, 05, 09, 15, 17, 18,
20, 21, 24, 25
06, 14
AUDIO BRAND
Sharp
REMOTE CONTROL
CODE NUMBER
01
1
2
Other viewing options
1
2
3
4
Cable control buttons
When the FUNCTION is set to CBL/SAT the cable converter connected to the Display can operate using
1 to 4.
1 SOURCE POWER
Turns the cable converter power on and off.
2
0 – 9
Press a button (or buttons) that corresponds to the channel that you wish to watch.
3 FLASHBACK *
Press to switch between the current channel and the channel you were watching immediately before.
4 CH
r/s
Press CH r or CH s to tune in a higher or lower channel.
* Some manufacturers do not preset FLASHBACK.
NOTE
• CABLE and SAT cannot be selected at the same time.
SAT control buttons
1 SOURCE POWER
Turns the Satellite broadcast tuner power on and off.
2
0 – 9,
•
(DOT)
Press a button (or buttons) that corresponds to the channel that you wish to watch.
3
ENTER, a/b/c/d
ENTER: Press to activate the selected function.
a/b/c/d: Press the button to select items on the SAT
GUIDE screen or SAT MENU screen.
NOTE
• CABLE and SAT cannot be selected at the same time.
3
89
90
8
2
1
5
6
2
4
6
Other viewing options
8
7
3
5
1
3 10
9
4
7
VCR control buttons
The remote control unit button will function as follows when the FUNCTION of the remote control unit is set to VCR.
• When the input selector button having the same number as the input terminal connecting the VCR is pressed, the VCR can operate using 1 to 8.
1 CH
r/s
Press to select the channel of the TV tuner on the VCR.
2 SOURCE POWER
Turns the power of the VCR on and off.
3
F
Sets pauses and still pictures.
4
G
Rewinds the tape and allows picture search.
5
H
Stops the tape transport.
6 REC
Starts recording.
7
J
Rapidly advances the tape and allows picture search.
8
I
Starts playback.
DVD control buttons
The remote control unit button will function as follows when the FUNCTION of the remote control unit is set to DVD.
• When the input selector button having the same number as the input terminal connecting a DVD player is pressed, these players can operate using
1 to 10.
1
U
Pressing quickly once takes you to the start of the next chapter. Each time you press it, you move ahead to the start of the next chapter.
2
T
Pressing quickly once takes you to the start of the chapter currently playing. Each time you press it, you move back to the start of the previous chapter.
3 SOURCE POWER
Turns the power of the DVD player on and off.
4
F
Sets pauses and still pictures.
5
G
Continue pressing to go backward.
6
H
Playback stops when pressing once.
With some DVD players, pressing the button twice may open the disc tray.
7 MENU
When this button is pressed, the DVD menu will display.
8
ENTER, a/b/c/d
ENTER: Press to activate the selected function.
a/b/c/d: Press the button to select items on the DVD
MENU screen.
9
J
Other viewing options
Notice
■ When you change your adress
• If you change your address, please return the
CableCARD to your Cable Provider Company.
• You will not be able to use it at your new address.
■ About EAS(Emergency Alert System)
• In the case of a national emergency, natural disaster, or other emergency situation, Cable MSO will broadcast an Emergency Alert Message (EAS message). When this unit receives an EAS message, if the level of emergency is comparatively low, an alert text message will be displayed on screen. If the level of emergency is high, the receiver will be force tuned to a details channel.
• Alert text messages will be displayed, and force tuning will occur, even during paid programming.
Even when force tuning is active, the user can still change the channel.
• If the unit is force tuned to a channel that has been blocked by Parental Control, the Parental Control setting will be given priority.
NOTE
• If you have a digital cable antenna connected, you can receive EAS messages whether CableCARD is inserted or not.
• EAS messages may be broadcast not only via digital cable, but also via Analog Cable (ANALOG-A) or overthe-air Analog transmission (ANALOG-B).
• When force tuning occurs, Video output from the
MONITOR OUTPUT terminal will also be switched to the details channel.
• An alert text message does not output from MONITOR
OUTPUT terminal.
• If force tuning occurs during twin picture mode, twin picture display will be automatically terminated and the details channel will be displayed on the full screen.
91
92
Appendix
Troubleshooting
• No power
Problem Possible Solution
• Is the AC cord disconnected? (See page 10.)
• Unit cannot be operated.
• External influences such as lightning, static electricity, may cause improper operation. In this case, operate the unit after first turning on the power of the
Display or unplugging the AC cord and replugging it in after 1 or 2 minutes.
• Remote control unit does not operate.
• Is the FUNCTION set correctly? Set it to the TV setting position.
• Are batteries inserted with polarity (e, f) aligned? (See page 13.)
• Are batteries worn out? (Replace with new batteries.)
• Are you using it under strong or fluorescent lighting?
• Is a fluorescent light illuminated near the remote control sensor?
• Picture is cut off/with sidebar screen.
• Is the image position correct? (See page 62.)
• Are screen mode adjustments such as picture size made correctly? (See pages
68 and 69)
• When playing back video in card mode, a part of the image is missing or the image is out of position.
• The video playback setting has been affected as a result of moving the image position when playing back a still image in card mode.
It is recommended not to move the image position when playing back images from a card.
• Strange color, light color, or color misalignment
• Adjust the picture tone. (See pages 31 to 34.)
• Is the room too bright? The picture may look dark in a room that is too bright.
• Check the input signal setting. (See page 66.)
• Power is suddenly turned off.
• No picture
• No sound
• Is the sleep timer set? (See page 71.)
• Check the power control settings. (See page 36.)
• The unit’s internal temperature has increased.
Remove any objects blocking vent or clean the vent.
• Is connection to other components correct? (See pages 51 to 57.)
• Is correct input signal source selected after connection? (See page 66.)
• Is the correct input selected? (See page 66.)
• Is a non-compatible signal being input? (See page 93.)
• Is picture adjustment correct? (See pages 31 to 34.)
• Is “On” selected in “Audio Only”? (See page 70.)
• If, after inserting the CableCARD, you are unable to receive broadcast service, remove the CableCARD and reinsert.
• Is the volume too low? (See page 23.)
• Is “Variable” selected in “Output Select”? (See page 71.)
• Is “On” selected in “Center Channel Input”? (See page 84.)
• Upgrade is displayed continuously.
• Verify your antenna cable is connected property.
• Reinsert the CableCARD. If after reinserting the cableCARD and verifying the antenna cable, and the trouble still exists. Please contact your Cable Provider
Company.
Cautions regarding use in high and low temperature environments
• When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.
• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near a heater, as this may cause the cabinet to deform and the Liquid Crystal panel to malfunction.
Storage temperature: –4°F to +140°F (–20°C to +60°C)
Appendix
Attension about Digital broadcasting
■ The error message about reception of broadcast
The example of an error message displayed on a screen
Error code
• Failed to receive broadcast.
E202
Possible Solution
• Check the antenna cable. Check that the antenna is correctly antenna setup.
• Check the broadcast time in the program guide.
• No broadcast now.
E203
■ The cautions about i.LINK
Cautions sentence
• Record/Playback may fail on the selected model.
• Wrong connection or no i.LINK connection was found. Refer to Operation Manual on connection.
• The selected model is disable to Rec/PLAY. Check that no other model is used.
Possible Solution
• Displayed when you have selected a device that is not compatible with the TV, or that does not have DTLA copy protection technology installed.
• Displayed when a problem is experienced with a connection using i.LINK cable. Check the connection, and re-connect the cable if necessary.
• Displayed when the device you have selected is already being used by another i.LINK connected device. To operate the selected device from the TV, you will first have to override control from the other device.
PC compatibility chart
PC/MAC
PC
MAC13"
MAC16"
MAC19"
VGA
WVGA
SVGA
XGA
Resolution
640 x 400
720 x 400
640 x 480
848 x 480
800 x 600
1024 x 768
WXGA
1280 x 720
1280 x 768
SXGA 1280 x 1024
VGA 640 x 480
SVGA
XGA
832 x 624
1024 x 768
Horizontal Frequency Vertical Frequency VESA Standard
31.5 kHz
37.9 kHz
31.5 kHz
37.9 kHz
31.5 kHz
37.9 kHz
37.5 kHz
43.3 kHz
31.5 kHz
35.1 kHz
37.9 kHz
48.1 kHz
46.9 kHz
53.7 kHz
48.4 kHz
56.5 kHz
60.0 kHz
68.7 kHz
45.0 kHz
48.1 kHz
64.0 kHz
34.9 kHz
49.7 kHz
60.2 kHz
60 Hz
85 Hz
60 Hz
85 Hz
60 Hz
72 Hz
75 Hz
85 Hz
60 Hz
56 Hz
60 Hz
72 Hz
75 Hz
85 Hz
60 Hz
70 Hz
75 Hz
85 Hz
60 Hz
60 Hz
60 Hz
67 Hz
75 Hz
75 Hz
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
Apple and Macintosh are registered trademarks of Apple Computer, Inc.
DDC is a registered trademark of Video Electronics
Standards Association.
Power Management is a registered trademark of
Sun Microsystems, Inc.
VGA and XGA are registered trademarks of
International Business Machines Co., Inc.
93
94
Appendix
RS-232C port specifications
PC Control of the TV
• When a program is set, the Display can be controlled from the PC using the RS-232C terminal.
The input signal (PC/AV) can be selected, the volume can be adjusted and various other adjustments and settings can be made, enabling automatic programmed playing.
•
Attach an RS-232C cable cross-type (commercially available) to the supplied Din/D-Sub RS-232C for the connections.
NOTE
• This operation system should be used by a person who is accustomed to using computers.
Communication conditions
Set the RS-232C communications settings on the PC to match the display’s communications conditions.
The Display’s communications settings are as follows:
Baud rate:
Data length:
Parity bit:
Stop bit:
Flow control:
9,600 bps
8 bits
None
1 bit
None
Communication procedure
Send the control commands from the PC via the RS-232C connector.
The display operates according to the received command and sends a response message to the PC.
Do not send multiple commands at the same time. Wait until the PC receives the OK response before sending the next command.
Command format
Eight ASCII codes e CR
C1 C2 C3 C4 P1 P2 P3 P4
Command 4-digits Parameter 4-digits
Command 4-digits:Command. The text of four characters.
Parameter 4-digits:Parameter 0 – 9, x, blank, ?
Return code
Parameter
Input the parameter values, aligning left, and fill with blank(s) for the remainder. (Be sure that 4 values are input for the parameter.)
When the input parameter is not within an adjustable range, “ERR” returns. (Refer to “Response code format”.)
Any numerical value can replace the “x” on the table.
0
0 0 0 9
⫺
3 0
1 0 0
0 0 5 5
When “?” is input for some commands, the present setting value responds.
?
?
?
?
?
Appendix
Response code format
Normal response
O K
Return code (0DH)
Problem response (communication error or incorrect command)
E R R
Return code (0DH)
Command table
• Commands not indicated here are not guaranteed to operate.
CONTROL ITEM
POWER SETTING
INPUT SELECTION A TOGGLE
TV
INPUT SELECTION B
AV MODE SELECTION
VOLUME
POSITION
VIEWMODE
MUTE
Dolby Virtual
AUDIO SELECTION
SLEEP TIMER
CHANNEL
INPUT1-5 i.LINK
CARD
INPUT 1
INPUT 2
INPUT 5
V-POSITION
CLOCK
PHASE
DIRECT
CHANNEL
(ANALOG)
DIRECT
CHANNEL
(DIGITAL)
COMMAND PARAMETER
P O W R 0 _ _ _
I T G D
I T V D x
0
_
_
_
_
_
_
I A V D * _ _ _
L I N K x _ _ _
I
I
I C R D
I N P 1
A
V
H
N
N
V
O
P
P
P
M D
L
O
2
5
M
S
2
5
6
0
1
1
2 x
0
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
0
1
7
8
_
_
_
_
_
_
_
_
4
5
2
3
6
_
_
_
_
_
_
_
_
_
_ _
*
*
*
*
_
*
_
_
* * * _
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
V
C
P
W
P
L
H
I
O
C
S
D
S
K
E
E
8
M U T E 0
6
7
4
5
2
3
0
1
*
*
*
*
*
*
*
*
_
* * * _
* * *
_
_
*
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
1
2
_
_
_
_
A C D V 0
1
_
_
_
_
O F T M
2
0
1
_ _
A C H A x _ _ _
_
_
_
_
_
_
_
2 _ _ _
_
_
_
_
D C C H
3 _ _ _
4 _ _ _
* * * _
D
D
A
C
2
2
P
U
*
*
*
*
*
*
*
_
(Toggle)
Input terminal number (1–5)
VIDEO
COMPONENT
ANTENNA SELECT
CC
CH UP
CH DOWN
D
C
C
L
2
C
L
C H U P
C H D W
P
* x x
*
_
_
*
_
_
_
D C 1 0 * * * *
D C 1 1 * * * *
_
_
A N T S 0 _ _ _
1 _ _ _
2 _ _ _
3 _ _ _ x _ _ _
It shifts to standby.
CONTROL CONTENTS
It input-switches by the toggle. (It is the same as an input change key)
It input-switches to TV. (A channel remains as it is. (Last memory))
It input-switches to INPUT1~INPUT5.
It input-switches to i.LINK.
It shifts to CARD mode.
An input change is also included.
VIDEO
COMPONENT
DIGITAL PC
ANALOG PC
DIGITAL AV
ANALOG AV
(Toggle)
STANDARD
MOVIE
GAME
USER
DYNAMIC (Fixed)
DYNAMIC
Volume (0–60)
AV mode. (
Ⳳ10)
INPUT5: AV mode. (
Ⳳ90)
PC mode. (0–180)
AV mode. (
Ⳳ20)
INPUT5: AV mode. (
Ⳳ50)
PC mode. (0–100)
Only PC mode. (0–180)
Only PC mode. (0–40)
(Toggle) [AV]
Side Bar [AV]
S.Stretch [AV]
Zoom [AV]
Stretch [AV]
Normal [PC]
Zoom [PC]
Stretch [PC]
Dot by Dot [PC]
(Toggle)
On
Off
(Toggle)
On
Off
(Toggle)
OFF
OFF TIMER – 30 MIN.
OFF TIMER – 60 MIN.
OFF TIMER – 90 MIN.
OFF TIMER – 120 MIN.
The channel number of TV
(1–125)
Although it can choose now, it is toggle operation in inside.
Although it can choose now, it is toggle operation in inside.
(0100-9999)
(1-999)
(0-999)
(0-9999)
(0-6383)
The channel number of TV
Ⳮ1
The channel number of TV ⳮ1
(Toggle)
ANALOG-A
ANALOG-B
DIGITAL
(Toggle)
An input change is included if it is not TV display.
In Air, 2–69ch is effective.
In Cable, 1–125ch is effective.
DIGITAL Air (Two-Part numbers, 2-digit plus 2-digit)
DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit)
Front half of DIGITAL CABLE CHANNEL NO. (Designate major channel)
DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit)
Rear half of DIGITAL CABLE CHANNEL NO. (Designate minor channel)
DIGITAL Cable (One-Part numbers, 5-digit, less than 10,000)
DIGITAL Cable (One-Part numbers, 5-digit, more than 10,000)
If it is not TV display, it will input-switch to TV. same function as CH r
If it is not TV display, it will input-switch to TV. same function as CH s
ANALOG-A s ANALOG-B s DIGITAL
Toggle operation of a closed caption.
NOTE
• If an underbar (_) appears in the parameter column, enter a space.
• If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL CONTENTS.
• As long as that from which the parameter (g) in the table is a numerical value, it may write anything.
95
Appendix
Specifications
Item Model: LC-37GD6U Model: LC-32GD6U
LCD panel
Number of dots
TV
Function
37o Advanced Super
View & BLACK TFT LCD
32o Advanced Super
View & BLACK TFT LCD
3,147,264 dots (1366 m 768 m 3 dots)
American TV Standard ATSC/NTSC System TV-standard (CCIR)
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-125ch
Digital Terrestrial
Broadcast (8VSB)
Digital cable
(64/256 QAM)
2-69ch
1-135ch
Model: LC-26GD6U
26o Advanced Super
View & BLACK TFT LCD
Audio multiplex BTSC System
Brightness
Backlight
Viewing angles
Audio amplifier
Speakers
Terminals Rear
INPUT 1
INPUT 2
450 cd/m 2
60,000 hours (at Backlight Standard position)
H : 170° V : 170°
10W m 2
Ø 8cm 2pcs, Ø 2.5cm 2pcs
INPUT 3
INPUT 4
AV in, COMPONENT in
AV in, COMPONENT in
S-VIDEO in, AV in
HDMI in (Type-A) with HDCP
INPUT 5
EXTERNAL SPEAKER
Audio in, DVI-I in with HDCP
ANALOG ANTENNA 75 q Unbalance, F Type for VHF/UHF/CATV in m 2, out m 1
DIGITAL ANTENNA 75 q Unbalance, F Type for Digital Air/Cable in m 1
MONITOR OUTPUT S-VIDEO out, AV out
4 q 10W (L/R)
CENTER CHANNEL INPUT RCA pin
Front
OSD language
Power Requirement
Power Consumption
Weight
LC-32GD6U
LC-26GD6U
Accessories
DIGITAL AUDIO OUTPUT i.LINK
Optical Digital audio output m 1 (PCM/Dolby Digital)
IEEE1394 m 2 with DTCP
PC CARD slot 68 pin PCMCIA m 1
CableCARD slot 68 pin PCMCIA m 1
DC OUTPUT DC 9 V 7 W MAX
Headphones Ø 3.5mm jack
English/French/Spanish
LC-37GD6U
AC 120 V, 60 Hz
224 W (10 W Standby with AC 120 V)
182 W (10 W Standby with AC 120 V)
40.8 lbs./18.5 kg (Display only),
49.2 lbs./22.3 kg (with Display and speaker),
59.1 lbs./26.8 kg (with Display, speaker and stand)
150 W (7.6 W Standby with AC 120 V)
36.4 lbs./16.5 kg (Display only),
44.5 lbs./20.2 kg (with Display and speaker),
54.5 lbs./24.7 kg (with Display, speaker and stand)
26.5 lbs./12 kg (Display only),
33.1 lbs./15 kg (with Display and speaker),
40.8 lbs./18.5 kg (with Display, speaker and stand)
Operation manual (m1), Remote control unit (m1), AC cord (m1), “AAA” size battery (m2), Cable clamp (m1) (only for LC-37GD6U/LC-32GD6U), RF cable
(m1), Speaker unit (m1) (only for LC-37GD6U/LC-32GD6U), Bracket unit (m1)
(only for LC-37GD6U/LC-32GD6U)
• As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
Optional accessory
for LC-37GD6U/LC-32GD6U
96
The listed optional accessory is available for the Liquid Crystal
Television. Please purchase it at your nearest shop.
• Additional optional accessories may be available in the near future. When purchasing, please read the newest catalogue for compatibility and check the availability.
No.
1
Part name
Wall mount bracket
Part number
AN-37AG2
Dimensional drawings
Display
LC-37GD6U
822.6
677
917
200
115
307
Unit: inch/(mm)
97
98
Dimensional drawings
Display
LC-32GD6U
700.4
677
795
200
115
307
Unit: inch/(mm)
Dimensional drawings
Display
LC-26GD6U
568
519
663
69
Unit: inch/(mm)
279
100
99
100
HOW TO SET THE FACTORY PRESETS
Check that the power indicator is not on. Remove the AC cord and switch off the power. Press and hold down
RESET at the same time as you re-insert the AC Cord into the outlet and switch on the TV.
All setting items (except TV channel) return to the factory presetting.
NOTE
• Running the factory presetting operation also clears the secret number.
You can run the EZ Setup again by using the following steps.
1
Turn on the power of the Display.
2
Press MENU. (Make sure the menu screen displays.)
3
Press c/d to select “Setup”.
4
Press a/b to select “EZ Setup”.
5
Press ENTER.
NOTE
• If the secret number setting screen displays, you need to enter your secret number.
• If you forget your secret number, refer to HOW TO SET THE FACTORY PRESETS above.
The secret number is .
NOTE
• As a precautionary measure, make a note of your secret number above, scissor it from this manual, and keep it in a familiar place.
Calling for Service
For location of the nearest Sharp Authorized Service, or to obtain product literature, accessories, supplies, or customer assistance, please call 1-800-BE-SHARP.
LIMITED WARRANTY
CONSUMER LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the
“Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law.
ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE
LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise.
In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM
STATE TO STATE.
Model Specific Section
Your Product Model Number & Description:
LC-37GD6U • LC-32GD6U • LC-26GD6U LCD Color Television
(Be sure to have this information available when you need service for your Product.)
One (1) year parts and labor from the date of purchase.
Warranty Period for this Product:
Additional Item(s) Excluded from
Warranty Coverage (if any):
Where to Obtain Service:
What to do to Obtain Service: LC37GD6U/LC-32GD6U
Non-rechargeable batteries.
From a Sharp Authorized Servicer located in the United States.
To find the location of the nearest Sharp Authorized Servicer, call Sharp toll free at 1-800-BE-SHARP.
Contact your Sharp Authorized Servicer to obtain in-home service for this Product. The Servicer will come to your home and if it is necessary to remove the Product, the Servicer will reinstall it. Be sure to have Proof of Purchase available.
LC-26GD6U
Ship prepaid or carry in your Product to a Sharp Authorized
Servicer. Be sure to have Proof of Purchase available. If you ship the Product, be sure it is insured and packaged securely.
TO OBTAIN PRODUCT INFORMATION, CALL 1-800-BE-SHARP OR VISIT www.sharpusa.com
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
SHARP CORPORATION
101
102
VALID IN CANADA ONLY
LIMITED WARRANTY
Consumer Electronics Products
Congratulations on your purchase!
Sharp Electronics of Canada Ltd. (hereinafter called “Sharp”) gives the following express warranty to the first consumer purchaser for this
Sharp brand product, when shipped in its original container and sold or distributed in Canada by Sharp or by an Authorized Sharp Dealer:
Sharp warrants that this product is free, under normal use and maintenance, from any defects in material and workmanship. If any such defects should be found in this product within the applicable warranty period, Sharp shall, at its option, repair or replace the product as specified herein.
This warranty shall not apply to:
(a) Any defects caused or repairs required as a result of abusive operation, negligence, accident, improper installation or inappropriate use as outlined in the owner’s manual.
(b) Any Sharp product tampered with, modified, adjusted or repaired by any party other than Sharp, Sharp’s Authorized Service Centres or Sharp’s Authorized Servicing Dealers.
(c) Damage caused or repairs required as a result of the use with items not specified or approved by Sharp, including but not limited to head cleaning tapes and chemical cleaning agents.
(d) Any replacement of accessories, glassware, consumable or peripheral items required through normal use of the product including but not limited to earphones, remote controls, AC adapters, batteries, temperature probe, stylus, trays, filters, belts, ribbons, cables and paper.
(e) Any cosmetic damage to the surface or exterior that has been defaced or caused by normal wear and tear.
(f) Any damage caused by external or environmental conditions, including but not limited to transmission line/power line voltage or liquid spillage.
(g) Any product received without appropriate model, serial number and CSA/cUL markings.
(h) Any products used for rental or commercial purposes.
(i) Any installation, setup and/or programming charges.
Should this Sharp product fail to operate during the warranty period, warranty service may be obtained upon delivery of the Sharp product together with proof of purchase and a copy of this LIMITED WARRANTY statement to an Authorized Sharp Service Centre or an
Authorized Sharp Servicing Dealer. In home warranty service may be provided at Sharp’s discretion on any Sharp television with the screen size of 27” or larger and on any Sharp Over-the-Range Microwave Oven.
This warranty constitutes the entire express warranty granted by Sharp and no other dealer, service centre or their agent or employee is authorized to extend, enlarge or transfer this warranty on behalf of Sharp. To the extent the law permits, Sharp disclaims any and all liability for direct or indirect damages or losses or for any incidental, special or consequential damages or loss of profits resulting from a defect in material or workmanship relating to the product, including damages for the loss of time or use of this Sharp product or the loss of information. The purchaser will be responsible for any removal, reinstallation, transportation and insurance costs incurred. Correction of defects, in the manner and period of time described herein, constitute complete fulfillment of all obligations and responsibilities of Sharp to the purchaser with respect to the product and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise.
WARRANTY PERIODS:
Audio Products
Camcorder
DVD Products
Projector
LCD & Plasma Display TV
Microwave Oven
Television Products
VCR Products
Vacuum Cleaner
Parts & Labour (exceptions noted)
1 year
1 year
1 year
1 year (lamp 90 days)
1 year
1 year (magnetron component-4 additional years)
1 year (picture tube component-1 additional year)
1 year
1 year
To obtain the name and address of the nearest Authorized Sharp Service Centre or Dealer, please contact:
SHARP ELECTRONICS OF CANADA LTD. 335 Britannia Road East, Mississauga, Ontario L4Z 1W9
For more information on this Warranty, Sharp Extended Warranty
Offers, Sharp Canada Products, Accessory Sales, Dealer or Service
Locations, please call (905) 568-7140
Visit our Web site: www.sharp.ca
Revision 04/22/03
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
SHARP CORPORATION
Printed on 100% post-consumer recycled paper.
Imprimé sur 100% de papier recyclé.
Impreso en 100% de papel reciclado de postconsumo.
Printed in Japan
Imprimé au Japon
Impreso en Japón
TINS-B240WJZZ
04P06-JOG
advertisement
* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
Related manuals
advertisement
Table of contents
- 2 IMPORTANT INFORMATION
- 4 DEAR SHARP CUSTOMER
- 4 IMPORTANT SAFETY INSTRUCTIONS
- 7 Contents
- 8 Trademarks
- 8 Patent Notice
- 9 Supplied accessories
- 10 Preparation
- 10 Where to place the TV
- 12 Removing speakers
- 13 Removing the stand
- 13 Setting the Display on the wall
- 14 Inserting the batteries
- 14 Using the remote control unit
- 15 Part names
- 17 Remote control unit
- 18 Cable TV/VCR connection
- 20 Outdoor antenna connection
- 21 Turning on the power
- 21 Turning off the power
- 22 Initial setup
- 23 Changing channels Analog-TV
- 24 Changing volume/sound
- 25 Setting MTS/SAP stereo mode
- 26 Connecting Digital Cable Module
- 27 Basic adjustment settings
- 27 AV input mode menu items
- 28 PC input mode menu items
- 28 EZ setup
- 29 Channel setup
- 31 Antenna Setup-DIGITAL
- 32 Favorite channel setting
- 32 Language setting
- 33 Picture adjustments
- 34 OPC setting
- 35 Color temperature
- 35 3D-Y/C
- 36 Monochrome
- 37 Sound adjustment
- 37 Dolby virtual
- 38 Power control
- 38 Power control for AV source
- 38 Power control for PC source
- 39 Digital Setup
- 39 Video Setup
- 41 Using memory card
- 45 Displaying slide show
- 46 My Program
- 46 Audio Select
- 47 Deleting a still image file
- 47 Deleting all still image files
- 48 Recording a motion picture
- 48 Rec. Mode
- 49 Pre Record
- 49 Repeat Play
- 50 Deleting a motion picture file
- 50 Deleting all motion picture files
- 50 Format
- 51 Using external equipment
- 52 Connecting a DVD player
- 53 or camcorder
- 54 Connecting a Digital TV STB
- 55 Connecting HDMI equipment
- 55 equipment
- 56 Connecting a PC
- 57 i.LINK connection
- 58 Setting the recording mode
- 59 Selecting a D-VHS deck (i.LINK)
- 59 a D-VHS deck (i.LINK)
- 60 Controlling an i.LINK device
- 62 with a D-VHS deck (i.LINK)
- 63 Useful adjustment settings
- 63 Moving the picture on the screen
- 64 Connecting external speakers
- 65 Audio Quality Control
- 68 Input label
- 68 Picture Flip
- 69 AV MODE
- 69 View mode for 4:3 Programs
- 70 View mode (for PC input mode)
- 71 Digital Noise Reduction
- 71 Audio only
- 72 Output Select
- 72 Sleep timer
- 73 Title Display Type
- 74 Closed caption
- 75 Font Style
- 76 Foreground Color
- 76 Foreground Opacity
- 76 Background Color
- 77 Background Opacity
- 77 Character Edge
- 78 (AV input mode only)
- 80 Parental control (setting V-CHIP level)
- 84 V-CHIP BLOCK
- 85 Center Channel Input
- 86 Other viewing options
- 86 Viewing information of the program
- 87 Twin picture functions
- 87 Presetting remote control function
- 93 Troubleshooting
- 94 PC compatibility chart
- 95 RS-232C port specifications
- 97 Optional accessory
- 98 Dimensional drawings
